Page 1
TM
G1000
audio panel pilot’s guide
supplement for Mooney
M20M & M20R
Page 2
Record of Revisions
Revision Date of Revision Revision Page Range Description
A 10/18/04 6B-1 Initial release.
Garmin G1000 Audio Panel Pilot’s Guide Supplement for Mooney M20M & M20R 190-00446-00 Rev. A
Page 3
AUDIO PANEL SUPPLEMENT
FOR MOONEY M20M & M20R
This document is only intended to highlight G1000
AIRCRAFT ENTERTAINMENT INPUTS
Audio Panel (GMA 1347) information that is specific to
Mooney M20M and M20R aircraft and it supersedes related information presented in the G1000 Audio Panel
channels MUSIC 1 and MUSIC 2.
Pilot’s Guide.
COCKPIT VOICE RECORDER (CVR)
NOTE: For a description of the GMA 1347 as
well as details as to its operation, please see the
Garmin G1000 Audio Panel Pilot’s Guide.
pit voice recorder.
DUAL PANEL OPERATION
HEADSET JACKS & KEYED ICS OPERATION
Mooney aircraft are equipped with four (4) stereo
headset jacks (for the pilot, copilot and two passengers).
Keyed ICS operation is not available on Mooney air-
craft.
el installations.
TRANSCEIVERS
Mooney aircraft are not factory-equipped with
COM3 MIC, COM3 and TEL capability. On Mooney aircraft, if COM3 or TEL is disabled on the GMA Configuration Page of the PFD, pressing the COM3 MIC, COM3,
or TEL key, respectively, does not illuminate the corresponding annunciator light.
Not recommended
Mooney aircraft are not equipped with entertainment
Mooney aircraft are not factory-equipped with a cock-
Mooney aircraft are not configured for dual audio pan-
Not supported
on Mooney aircraft
for use in
Mooney aircraft
Not supported
on Mooney aircraft
NOTE: The use of split COM (COM 1/2 key) is
not recommended in Mooney aircraft.
AIRCRAFT RADIOS
DME, ADF and AUX radios are not supported on this
G1000 system configuration for Mooney aircraft. On
Mooney aircraft, if ADF, DME, or AUX is disabled on the
GMA Configuration Page of the PFD, pressing the ADF,
DME, or AUX key, respectively, does not illuminate the
corresponding annunciator light.
190-00446-00 Rev. A Garmin G1000 Audio Panel Pilot’s Guide Supplement for Mooney M20M & M20R
Figure 6B.1.1 G1000 Audio Panel (GMA 1347)
6B-1
