Garmin 0104455 Users Manual

190-00587-50 January, 2012 Revision A
GTS Processor
Installation Manual
DRAFT
DRAFT
Garmin Ltd. or its subsidiaries
All Rights Reserved
Except as expressly provided herein, no part of this manual may be reproduced, copied,
transmitted, disseminated, downloaded or stored in any storage medium, for any purpose without
the express prior written consent of Garmin. Garmin hereby grants permission to download a
single copy of this manual and of any revision to this manual onto a hard drive or other electronic
storage medium to be viewed and to print one copy of this manual or of any revision hereto, provided that such electronic or printed copy of this manual or revision must contain the complete text of this copyright notice and provided further that any unauthorized commercial distribution of
this manual or any revision hereto is strictly prohibited.
Garmin International, Inc.
1200 E. 151st Street
Olathe, KS 66062 USA
Telephone: 913.397.8200
Aviation Panel-Mount Technical Support Line (Toll Free) 1.888.606.5482
www.garmin.com
Garmin (Europe) Ltd.
Liberty House, Bulls Copse Road
Hounsdown Business Park
Southampton, SO40 9RB U.K.
+44/ (0) 870.8501241
Garmin AT, Inc.
2345 Turner Rd., SE
Salem, OR 97302 USA
Telephone: 503.581.8101
RECORD OF REVISIONS
Revision Revision Date Description
A 01/06/2012 Initial Release
Page A GDR 66 Installation Manual Revision A 190-00587-50
INFORMATION SUBJECT TO EXPORT CONTROL LAWS
DRAFT
This document may contain information which is subject to the Export Administration Regulations ("EAR") issued by the United States Department of Commerce (15 CFR, Chapter VII, Subchapter C) and which may not be exported, released, or disclosed to foreign nationals inside or outside of the United States without first obtaining an export license. The preceding statement is required to be included on any and all reproductions in whole or in part of this manual.
WARNING
This product, its packaging, and its components contain chemicals known to the State of California to cause cancer, birth defects, or reproductive harm. This Notice is being provided in accordance with California's Proposition 65. If you have any questions or would like additional information, please refer to our web site at www.garmin.com/prop65
CURRENT REVISION DESCRIPTION
.
Revision
A All All Initial release
Page
Number(s)
Section
Number
DOCUMENT PAGINATION
Section Page Range
Table of Contents i – viii
Section 1 1-1 – 1-10 Section 2 2-1 – 2-10 Section 3 3-1 – 3-22
Section 4 4-1 – 4-14 Appendix A A-1 – A-4 Appendix B B-1 – B-10
Description of Change
GTS Processor Installation Manual Page i 190-00587-50 Revision A
TABLE OF CONTENTS
DRAFT
PARAGRAPH PAGE
Section 1 GENERAL DESCRIPTION .............................................................1-1
1.1 Introduction...................................................................................................................... 1-1
1.2 Equipment Description .................................................................................................... 1-1
1.2.1 GTS Processor Configuration Options.................................................................................1-2
1.3 Interface Summary...........................................................................................................1-2
1.4 Technical Specifications .................................................................................................. 1-2
1.4.1 Environmental Qualification Form.......................................................................................1-2
1.4.2 Physical Characteristics........................................................................................................1-3
1.4.3 General Specifications..........................................................................................................1-3
1.4.4 Power Requirements.............................................................................................................1-3
1.5 Certification ..................................................................................................................... 1-4
1.5.1 GTS Processor TSO/ETSO Compliance ..............................................................................1-4
1.5.2 GTS Processor TSO/ETSO Deviations ................................................................................1-5
1.6 Reference Documents ...................................................................................................... 1-8
1.7 Aviation Limited Warranty.............................................................................................. 1-9
Section 2 INSTALLATION OVERVIEW........................................................2-1
2.1 Introduction...................................................................................................................... 2-1
2.1.1 Unit Configurations ..............................................................................................................2-1
2.1.2 Required Accessories ...........................................................................................................2-1
2.2 Installation Considerations .............................................................................................. 2-3
2.2.1 Antenna Considerations........................................................................................................2-3
2.3 Electrical Bonding ........................................................................................................... 2-3
2.4 Cabling and Wiring..........................................................................................................2-4
2.4.1 Coaxial Cable .......................................................................................................................2-4
2.5 Cooling Requirements ..................................................................................................... 2-9
2.6 Mounting Requirements ................................................................................................ 2-10
Section 3 INSTALLATION PROCEDURE.....................................................3-1
3.1 Unpacking Unit................................................................................................................ 3-1
3.2 Wiring Harness Installation ............................................................................................. 3-1
3.3 Backshell and Configuration Module Assemblies........................................................... 3-3
3.4 GA 58 Antenna Installation ............................................................................................. 3-3
3.5 Sensor Systems Incorporated Low-Profile Antenna Installation..................................... 3-3
3.6 Unit Installation ............................................................................................................... 3-3
3.7 Downloading and Installing the GTS Processor Install Tool .......................................... 3-4
3.8 Downloading and Installing the GTS Assert Log Diagnosis Tool .................................. 3-6
3.9 Post Installation Configuration & Checkout.................................................................... 3-9
3.9.1 GTS Processor Configuration/Checkout for Different Installation Types ...........................3-9
3.9.2 Using the GTS Processor Install Tool ................................................................................3-10
3.9.3 Suppression Bus I/O Check................................................................................................3-16
3.9.4 CDTI (Cockpit Display of Traffic Information) Display Setup and Configuration...........3-17
3.9.5 Calibration/Self Test...........................................................................................................3-17
Page ii GTS Processor Installation Manual Revision A 190-00587-50
PARAGRAPH PAGE
DRAFT
3.9.6 Ramp Test and Return To Service Test..............................................................................3-20
3.9.7 Antenna Verification ..........................................................................................................3-22
3.10 Continued Airworthiness ............................................................................................. 3-23
Section 4 SYSTEM INTERCONNECTS..........................................................4-1
4.1 GTS Processor Pin Function List..................................................................................... 4-1
4.1.1 P8001 (Digital) .....................................................................................................................4-1
4.1.2 P8002 (Analog/Discrete) ......................................................................................................4-3
4.1.3 P8003 (Power Supply)..........................................................................................................4-6
4.2 Power ............................................................................................................................... 4-7
4.2.1 Aircraft Power Functions......................................................................................................4-7
4.3 Serial Data........................................................................................................................ 4-8
4.3.1 RS-232..................................................................................................................................4-8
4.3.2 RS-422..................................................................................................................................4-8
4.3.3 ARINC 429...........................................................................................................................4-9
4.3.4 Ethernet.................................................................................................................................4-9
4.3.5 USB ....................................................................................................................................4-10
4.4 Configuration ................................................................................................................. 4-10
4.4.1 Configuration Module ........................................................................................................4-10
4.5 Analog/Discrete .............................................................................................................4-10
4.5.1 Heading Input .....................................................................................................................4-10
4.5.2 Inputs From Compass System/Directional Gyros ..............................................................4-11
4.5.3 Audio ..................................................................................................................................4-12
4.5.4 Active Low Discrete Inputs................................................................................................4-12
4.5.5 Active High Discrete Inputs ...............................................................................................4-13
4.5.6 Annunciator Output ............................................................................................................4-14
4.6 Mutual Suppression Bus ................................................................................................ 4-14
Appendix A Outline and Installation Drawings .............................................A-1
Appendix B Interconnect Examples ................................................................B-1
GTS Processor Installation Manual Page iii 190-00587-50 Revision A
LIST OF FIGURES
DRAFT
FIGURE PAGE
Section 1 GENERAL DESCRIPTION .............................................................1-1
Section 2 INSTALLATION OVERVIEW........................................................2-1
Figure 2-1 GTS Processor Installation with Top and Bottom Directional Antennas ........... 2-5
Figure 2-2 GTS Processor Installation with Top Directional and
Bottom Monopole Antennas.................................................................................................. 2-5
Figure 2-3 GTS 855/GTS 825 Installation with Top Directional Antenna and
No Bottom Antenna ...............................................................................................................2-6
Figure 2-4 Heat Shrink Positioning ...................................................................................... 2-8
Figure 2-5 GTS Processor Vertical Installation Rack (Garmin P/N 011-02572-00).......... 2-10
Figure 2-6 GTS Processor Horizontal Installation Rack (Garmin P/N 115-00784-00) ..... 2-10
Section 3 INSTALLATION PROCEDURE.....................................................3-1
Figure 3-1 GTS Processor Install Tool – Installation ........................................................... 3-4
Figure 3-2 GTS Processor Install Tool – Installation ........................................................... 3-5
Figure 3-3 GTS Processor Install Tool – Installation ........................................................... 3-5
Figure 3-4 GTS Processor Install Tool – Installation ........................................................... 3-5
Figure 3-5 GTS Processor Install Tool – Installation ........................................................... 3-6
Figure 3-6 GTS Processor Install Tool – Installation ........................................................... 3-6
Figure 3-7 GTS Assert Log Diagnosis Tool – Installation.................................................. 3-7
Figure 3-8 GTS Assert Log Diagnosis Tool – Installation ................................................... 3-7
Figure 3-9 GTS Assert Log Diagnosis Tool – Installation.................................................. 3-8
Figure 3-10 GTS Assert Log Diagnosis Tool – Installation................................................ 3-8
Figure 3-11 GTS Assert Log Diagnosis Tool – Installation................................................ 3-8
Figure 3-12 GTS Processor Install Tool – Normal Tab...................................................... 3-11
Figure 3-13 GTS Processor Install Tool – Configuration Tab (GTS 825 and GTS 855)... 3-12
Figure 3-14 GTS Processor Install Tool – Upload Tab ...................................................... 3-15
Figure 3-15 GTS Processor Install Tool – Assert Tab........................................................ 3-16
Figure 3-16 Self Test ..........................................................................................................3-19
Figure 3-17 Ground Test Enable, GTS Processor Install Tool........................................... 3-20
Figure 3-18 GND TEST Softkey ........................................................................................ 3-20
Section 4 SYSTEM INTERCONNECTS..........................................................4-1
Figure 4-1 View of J8001 connector from back of unit ....................................................... 4-1
Figure 4-2 View of J8002 connector from back of unit ....................................................... 4-3
Figure 4-3 View of J8003 connector from back of unit ....................................................... 4-6
Appendix A Outline and Installation Drawings .............................................A-1
Figure A-1 GTS Processor Vertical Outline Drawing......................................................... A-1
Figure A-2 GTS Processor Vertical Installation Drawing.................................................. A-2
Figure A-3 GTS Processor Horizontal Outline Drawing..................................................... A-3
Figure A-4 GTS Processor Horizontal Installation Drawing............................................... A-4
Page iv GTS Processor Installation Manual Revision A 190-00587-50
FIGURE PAGE
DRAFT
Appendix B Interconnect Examples ................................................................B-1
Figure B-1 GTS Processor Interconnect Example Notes .....................................................B-1
Figure B-2 GTS Processor Interconnect Example................................................................B-2
Figure B-3 GTS Processor Garmin Integrated Flight Deck Interconnect Example .............B-3
Figure B-4 GTS Processor Field Approved (Retrofit) Garmin Integrated
Flight Deck Interconnect Example ........................................................................................B-4
Figure B-5 GTS Processor GNS 4XX/5XX/GMX 200 Interconnect Example....................B-5
Figure B-6 GTS Processor GMA/HSI/Altimeter Interconnect Example .............................B-6
Figure B-7 GTS Processor Dongle Cable (see Sections 3.7 and 3.8.6)................................B-7
Figure B-8 GTS Processor Discrete Interconnect Example .................................................B-8
Figure B-9 GTS Processor Configuration Module Interconnect Example...........................B-9
Figure B-10 GTS Processor Dual Transponder Interconnect Example..............................B-10
GTS Processor Installation Manual Page v 190-00587-50 Revision A
LIST OF TABLES
DRAFT
TABLE PAGE
Section 1 GENERAL DESCRIPTION .............................................................1-1
Table 1-1 Compatible Transponders..................................................................................... 1-2
Table 1-2 Configuration Options.......................................................................................... 1-2
Table 1-3 Physical Characteristics........................................................................................ 1-3
Table 1-4 General Specifications.......................................................................................... 1-3
Table 1-5 Maximum Operation Current Draw ..................................................................... 1-3
Table 1-6 Maximum Boot-Up Current Draw ....................................................................... 1-3
Table 1-7 TSO/ETSO Compliance ....................................................................................... 1-4
Table 1-8 TSO/ETSO Deviations ......................................................................................... 1-5
Table 1-9 Reference Documents........................................................................................... 1-8
Section 2 INSTALLATION OVERVIEW........................................................2-1
Table 2-1 Unit Configuration ............................................................................................... 2-1
Table 2-2 Required Accessories ........................................................................................... 2-1
Table 2-3 Connector Kits...................................................................................................... 2-2
Table 2-4 Optional Accessories............................................................................................ 2-2
Table 2-5 Antennas............................................................................................................... 2-2
Table 2-6 Configuration Module .......................................................................................... 2-2
Table 2-7 Recommended Coaxial Length ............................................................................ 2-7
Table 2-8 Coaxial Cable Set Length Tolerance.................................................................... 2-8
Section 3 INSTALLATION PROCEDURE.....................................................3-1
Table 3-1 Socket and Pin Contact Part Numbers ................................................................. 3-1
Table 3-2 Socket Contact MIL SPEC M39029/5-115 Crimp Tooling................................. 3-1
Table 3-3 Pin Contact GPN 336-00021-00 MIL SPEC M39029/58-360 Crimp Tooling.... 3-2
Table 3-4 Pin Socket Contacts GPN 336-00022-00 MIL SPEC M39029/63-368 and
GPN 336-00023-00 Crimp Tooling....................................................................................... 3-2
Table 3-5 Self Test.............................................................................................................. 3-19
Section 4 SYSTEM INTERCONNECTS..........................................................4-1
Table 4-1 P8001 Connector .................................................................................................. 4-1
Table 4-2 P8002 Connector .................................................................................................. 4-3
Table 4-3 P8002 Connector .................................................................................................. 4-6
Table 4-4 Aircraft Power ...................................................................................................... 4-7
Table 4-5 Remote Power ...................................................................................................... 4-7
Table 4-6 Power On/Off Matrix ........................................................................................... 4-7
Table 4-7 RS-232.................................................................................................................. 4-8
Table 4-8 RS-422.................................................................................................................. 4-8
Table 4-9 ARINC 429........................................................................................................... 4-9
Table 4-10 Ethernet .............................................................................................................. 4-9
Table 4-11 USB .................................................................................................................. 4-10
Table 4-12 Configuration Module ...................................................................................... 4-10
Table 4-13 26 Volt AC References..................................................................................... 4-10
Page vi GTS Processor Installation Manual Revision A 190-00587-50
TABLE PAGE
DRAFT
Table 4-14 Radar Altimeter ................................................................................................ 4-11
Table 4-15 Inputs From Compass System/Directional Gyros ............................................ 4-11
Table 4-16 Audio ................................................................................................................ 4-12
Table 4-17 Active Low Discrete Inputs.............................................................................. 4-12
Table 4-18 Active High Discrete Inputs ............................................................................. 4-13
Table 4-19 Annunciator Output.......................................................................................... 4-14
Table 4-20 Mutual Suppression Bus................................................................................... 4-14
GTS Processor Installation Manual Page vii 190-00587-50 Revision A
Page viii GTS Processor Installation Manual
DRAFT
Revision A 190-00587-50
1 GENERAL DESCRIPTION
DRAFT
1.1 Introduction
This manual presents mechanical and electrical installation requirements for installing the GTS Processor as a Traffic Advisory System (TAS) (GTS 825), Traffic Collision Avoidance System (TCAS I) (GTS 855), and Traffic Collision Avoidance System (TCAS II) (GTS 8000).
1.2 Equipment Description
The GTS Processor is a microprocessor-based Line Replaceable Unit (LRU) that uses active interrogations of Mode S and Mode A/C transponders to provide Traffic Advisories and Resolution Advisories (GTS 8000 only) to the pilot. When installed in a system the GTS Processor can be configured as a TAS (GTS
825) or can be upgraded to a TCAS I (GTS 855) or TCAS II (GTS 8000) by purchasing an enablement card from Garmin. The GTS Processor meets the TSO/ETSO requirements for the configured traffic system function (TAS, TCAS I, or TCAS II). When installed with a 1090 MHz ADS-B transmit class of equipment the GTS Processor also utilizes passive surveillance. Traffic is displayed on an external MFD via ARINC 429 and/or Ethernet High Speed Data Bus (HSDB). An aural alert is also provided to inform the crew a traffic advisory (TA) or resolution advisory (RA) (GTS 8000 only) will be displayed.
A top-mounted directional antenna is used to derive bearing of the intruder aircraft, which is displayed with relative altitude to own aircraft. Top antenna transmitted interrogations are directional, reducing the number of transponders that receive the interrogation, and thus reducing potential garble on the 1090 MHz band. For GTS 825 and GTS 855 installations, a bottom monopole or directional (highly recommended) antenna is optional. For GTS 8000 installations, a bottom monopole or directional (highly recommended) antenna is required. Bottom antenna transmit interrogations and broadcasts (GTS 8000 only) are omni directional, using a monopole antenna or a directional antenna. A bottom directional antenna installation gives the benefit of intruder bearing visibility for targets that are shaded from the top directional antenna. The target bearing accuracy may be degraded for bottom directional antenna installations on aircraft with fixed gear.
NOTE
GTS Processor installations, configured as a GTS 855 TCAS I or GTS 825 TAS, require a Garmin-approved transponder capable of receiving TCAS II broadcast data.
NOTE
GTS Processor installations, configured as a GTS 8000 TCAS II, require a GTX 3000 or other Garmin-approved RTCA DO-185A/B compatible transponder.
NOTE
The GTS Processor is not to be installed in an aircraft with a TSO-C119a-only compatible transponder.
NOTE
A co-installed mode S transponder should be connected to the mutual suppression bus, and meet the mutual suppression requirements of DO-181A or later
GTS Processor Installation Manual Page 1-1 190-00587-50 Revision A
Refer to Table 1-1 for a list of compatible transponders.
DRAFT
Table 1-1 Compatible Transponders
Capable of
GTX Transponder
Model
GTX 330/330D
GTX 330 ES/330D ES
GTX 33/33D
GTX 33 ES/33D ES
GTX 328
GTX 3000 Yes Yes Yes
1. Remote mounted transponders require a compatible controller. Contact Garmin for details.
2. Factory update is required to allow ADS-B functionality.
3. GTX Software version 6.11 or higher.
4. GTX Software version 6.10 or higher.
1.2.1 GTS Processor Configuration Options
Table 1-2 lists the GTS Processor surveillance configuration options, enabled at the time of installation.
(1)
(1)
Receiving TCAS II
Broadcast Data
(Required for GTS
Processor)
(3)
Yes
(3)
Yes
(3)
Yes
(3)
Yes
(4)
Yes
Table 1-2 Configuration Options
ADS-B Capable
RTCA DO-185A/B
Compatible
(2)
Yes
Yes No
(2)
Yes
Yes No
No No
No
No
Traffic
Model
Number
GTS 825 011-02571-00 TSO-C147 X X 400
GTS 855* 011-02571-00 TSO-C118 X X 400
GTS 8000* 011-02571-00 TSO-C119c X X 400
*Requires upgrade using GTX Processor TCAS I/TCAS II Enablement Process. See Section XXX for instructions.
1.3 Interface Summary
The GTS Processor is designed as an open architecture system that uses typical ARINC 429, RS-232, and Ethernet communications interfaces.
1.4 Technical Specifications
1.4.1 Environmental Qualification Form
It is the responsibility of the installing agency to obtain the latest revision of the GTS Processor Environmental Qualification Form. To obtain a copy of this form, see the dealer/OEM portion of the Garmin web site (www.garmin.com number:
Garmin Part
Number
GTS Processor Environmental Qualification Form, Garmin part number 005-00630-02
Applicable
TSO
). This form is available directly from Garmin under the following part
Advisory
System
(TAS)
Traffic Alert and Collision
Avoidance
System
(TCAS I)
Traffic Alert and Collision
Avoidance
System
(TCAS II)
1090 ES
ADS-B
Receiver
Transmit
Power
(Watts)
Page 1-2 GTS Processor Installation Manual Revision A 190-00587-50
1.4.2 Physical Characteristics
DRAFT
Table 1-3 Physical Characteristics
Characteristics Specifications
GTS Processor Width w/out rack 3.42 inches (86.9 mm)
GTS Processor Height w/out rack 6.25 inches (158.8 mm)
GTS Processor Width with vertical rack 3.67 inches (93.1 mm)
GTS Processor Height with vertical rack 6.74 inches (171.1 mm)
GTS Processor Depth with vertical rack 15.48 inches (396.7 mm)
GTS Processor Width with horizontal rack 6.42 inches (163.1 mm)
GTS Processor Height with horizontal rack 4.10 inches (104.1 mm)
GTS Processor Depth with horizontal rack 14.79 inches (375.7 mm)
GTS Processor Depth w/Connector Kit 14.78 inches (375.4 mm)
GTS Processor Unit Weight w/out Connector Kit 11.30 lbs (5.13 kg)
GTS Processor Unit Weight with Connector Kit w/Vertical Rack 12.65 lbs (5.74 kg)
GTS Processor Unit Weight with Connector Kit w/Horizontal Rack 13.25 lbs (6.01 kg)
1.4.3 General Specifications
Table 1-4 contains general specifications. For detailed environmental specifications, see the Environmental Qualification Form.
Table 1-4 General Specifications
Characteristics Specifications
Operating Temperature Range -55°C to +70°C.
Humidity 95% non-condensing
Altitude Range -1,500 ft to 55,000 ft
Software Compliance RTCA/DO-178B level B
Hardware Compliance RTCA/DO-254 Level B
Environmental Compliance RTCA/DO-160F
1.4.4 Power Requirements
Tables list the power requirements for the GTS Processor
Table 1-5 Maximum Operation Current Draw
Characteristics Specifications
GTS Processor Power Consumption
Table 1-6 Maximum Boot-Up Current Draw
Characteristics Specifications
GTS Processor Boot-Up Current Draw
2.5 A max operating at 28.0 Vdc
5.0 A max operating at 14.0 Vdc
2.5 A at 28.0 Vdc for 700 ms
5.0 A at 14.0 Vdc for 700 ms
GTS Processor Installation Manual Page 1-3 190-00587-50 Revision A
1.5 Certification
DRAFT
The conditions and tests required for TSO/ETSO approval of this article are minimum performance standards. It is the responsibility of those installing this article either on or within a specific type or class of aircraft to determine that the aircraft installation conditions are within the TSO/ETSO standards. TSO/ ETSO articles must have separate approval for installation in an aircraft. The article may be installed only if performed under 14 CFR part 43 or the applicable airworthiness requirements.
The following tables provide a list of applicable TSO/ETSOs for the GTS Processor.
1.5.1 GTS Processor TSO/ETSO Compliance
When installed as a system, the GTS Processor, which includes a GA 58 (or other Garmin approved antenna), and a CDTI (Cockpit Display of Traffic Information) comprise what Garmin considers to be a minimum generic GTS Processor system installation. The GTS Processor lacks a display and by itself is an incomplete system and cannot completely meet the requirements of TSO-C119c/ETSO-C119c, TSO-C118/ETSO-C118 or TSO-C147/ETSO-C147.
Table 1-7 TSO/ETSO Compliance
GTS
Processor
Configuration
Traffic Alert and Collision
GTS 8000
GTS 855
GTS 825
GTS 8000,
GTS 855, and
GTX 825
*Equipment is capable of TSO-C166b/ETSO-C166a Class A1S/Type 1 Receiving Only per
RTCA/DO-260B when installed with a single antenna.
*Equipment is capable of TSO-C166b/ETSO-C166a Class A1/Type 1 Receiving Only when installed with
diversity antennas.
*The Class level is dependent upon the installation.
Avoidance System (TCAS II) Airborne Equipment
Traffic Alert and Collision Avoidance System (TCAS I) Airborne Equipment
Traffic Advisory System (TAS) Airborne Equipment
Extended Squitter Automatic Dependent Surveillance – Broadcast (ADS-B) and Traffic Information Service – Broadcast (TIS-B) Equipment Operating on the Radio Frequency of 1090 Megahertz (MHz)
Function TSO/ETSO Category
TSO-C119c
ETSO-C119c
TSO-C118
ETSO-C118
TSO-C147
ETSO-C147
TSO-C166b†
ETSO-C166a†
Class A
Class A1S/
Type 1
Receiving
Only*
Class A1/
Type 1
Receiving
Only*
Applicable
LRU SW Part
Numbers
All
006-B1244-0( )
through
006-B1244-2( )
except
006-B1244-00
through
006-B1244-03
All
006-B1224-0( )
through
006- B1224-2( )
except
006- B1224-00
through
006-B1224-03
All
006-B1224-0( )
through
006- B1224-2( )
except
006- B1224-00
through
006- B1224-03
All
006- B1224-0( )
through
006- B1224-2( )
except
006-B1224-00
through
006-B1224-03
Applicable
CLD Part Numbers
006-C0081-2( )
006-C0081-2( )
006-C0081-2( )
006-C0081-2( )
Page 1-4 GTS Processor Installation Manual Revision A 190-00587-50
NOTE
DRAFT
A statement identifying whether the installation is TSO-C166b/ETSO-C166a Class A1S/Type 1 Receiving Only or TSO-C166b/ETSO-C166a Class A1/Type 1 Receiving Only, per RTCA/DO-260B, should be included in the ship's log during Installation.
† Installation of this Receiving Only class of equipment is intended only for those aircraft in which a 1090 MHz ADS-B transmit class of equipment, or other complementary ADS-B link transmit class of equipment (such as UAT), is already installed. When no such ADS-B link transmit class of equipment is installed, the ADS-B receive functionality is disabled by disabling the 'ADSB TX Capable' configuration option (see section 3.9.2).
1.5.2 GTS Processor TSO/ETSO Deviations
Table 1-8 TSO/ETSO Deviations
TSO/ETSO Deviation
1. Garmin was granted a deviation from TSO-C118 section a.(1) to use RTCA DO-197A, instead of RTCA DO-197 as the Minimum Performance Standard
2. Garmin was granted a deviation from TSO-C118 section a.(2) to use RTCA DO-160F, instead of RTCA DO-160B as the standard for Environmental Conditions and Test Procedures for Airborne Equipment.
3. Garmin was granted a deviation from TSO-C118 section a.(3)(i) to use RTCA DO-178B instead of RTCA DO-178A.
4. Garmin was granted a deviation from RTCA DO-197A section 2.2.3.2.1 to use the Interrogations Spectrum requirement of RTCA DO-185B section 2.2.3.3 instead of the requirement of RTCA DO-197A section 2.2.3.2.1.
TSO-C118
5. Garmin was granted a deviation from RTCA DO-197A section 2.2.3.5 to use the “Mode C Only All-Call” format specified by RTCA DO-185B section 2.2.3.8.1 instead of the “Mode C” format for ATCRBS interrogations.
6. Garmin was granted a deviation from RTCA DO-197A section 2.2.6 to use selective Mode S interrogations following all the applicable protocols for Mode-S surveillance interrogations in the NAS as stated in DO-185B and DO-181D.
7. Garmin was granted a deviation from RTCA DO-197A section 2.2.9.1 to realize the bearing estimation function using a direction finding antenna augmented by tracked correlated ADS-B data when such data is available and of sufficient integrity.
8. Garmin was granted a deviation from RTCA DO-197A section 2.2.11 to use the suppression pulse on the aircraft suppression bus specified by RTCA DO-185B section 2.2.3.12 (70 +/-1 µs from top antenna and 90 +/-1 µs from bottom antenna) instead of 100 +/-5 µs.
GTS Processor Installation Manual Page 1-5 190-00587-50 Revision A
ETSO-C118
DRAFT
TSO-C119c
ETSO-C119c
Table 1-8 TSO/ETSO Deviations, Continued
1. Garmin was granted a deviation from ETSO-C118 section 3.1.1 to use RTCA DO-197A, instead of RTCA DO-197 as the Minimum Performance Standard.
2. Garmin was granted a deviation from ETSO-C118 section 3.1.2 to use EUROCAE ED-14F, instead of EUROCAE ED-14D as the standard for Environmental Conditions and Test Procedures for Airborne Equipment.
3. Garmin was granted a deviation from RTCA DO-197A section 2.2.3.2.1 to use the Interrogations Spectrum requirement of RTCA DO-185B section 2.2.3.3 instead of the requirement of RTCA DO- 197A section 2.2.3.2.1.
4. Garmin was granted a deviation from RTCA DO-197A section 2.2.3.5 to use the “Mode C Only All-Call” format specified by RTCA DO-185B section 2.2.3.8.1 instead of the “Mode C” format for ATCRBS interrogations.
5. Garmin was granted a deviation from RTCA DO-197A section 2.2.9.1 to realize the bearing estimation function using a direction finding antenna augmented by tracked correlated ADS-B data when such data is available and of sufficient integrity.
6. Garmin was granted a deviation from RTCA DO-197A section 2.2.11 to use the suppression pulse on the aircraft suppression bus specified by RTCA DO-185B section 2.2.3.12 (70 +/-1 μs from top antenna and 90 +/-1 μs from bottom antenna) instead of 100 +/-5 μs.
1. Garmin was granted a deviation from RTCA DO-185B section 2.2.3.13.2.1.1 to not have the ability to interface with FAA TSO-C119a compatible transponder units.
2. Garmin was granted a deviation from RTCA DO-185B section 2.2.4.4.2.2.b to use the Enhanced Preamble Detection method of RTCA DO-260B Appendix I section I.4.1
3. Garmin was granted a deviation from RTCA DO-185B section 2.2.4.4.2.2.c to use the Baseline Multi-sample bit and confidence declaration technique of RTCA DO-260B Appendix I section I.4.2.3.1.
4. Garmin was granted a deviation from RTCA DO-185B section 2.2.6.7.2 to realize the bearing estimation function using a direction finding antenna augmented by tracked correlated ADS-B data when such data is available and of sufficient integrity.
1. Garmin was granted a deviation from ETSO-C119c to use EUROCAE ED-14F instead of EUROCAE ED-14D as the standard for Environmental Conditions and Test Procedures for Airborne Equipment.
2. Garmin was granted a deviation from RTCA DO-185B section 2.2.3.13.2.1.1 to not have the ability to interface with FAA TSO-C119a compatible transponder units.
3. Garmin was granted a deviation from RTCA DO-185B section 2.2.4.4.2.2.b to use the Enhanced Preamble Detection method of RTCA DO-260B Appendix I section I.4.1.
4. Garmin was granted a deviation from RTCA DO-185B section 2.2.4.4.2.2.c to use the Baseline Multi-sample bit and confidence declaration technique of RTCA DO-260B Appendix I section I.4.2.3.1.
5. Garmin was granted a deviation from RTCA DO-185B section 2.2.6.7.2 to realize the bearing estimation function using a direction finding antenna augmented by tracked correlated ADS-B data when such data is available and of sufficient integrity.
Page 1-6 GTS Processor Installation Manual Revision A 190-00587-50
TSO-C147
DRAFT
ETSO-C147
ETSO-C166a
Table 1-8 TSO/ETSO Deviations, Continued
1. Garmin was granted a deviation from TSO-C147 section 1.c to use RTCA DO-160F, instead of RTCA DO-160D as the standard for Environmental Conditions and Test Procedures for Airborne Equipment.
2. Garmin was granted a deviation from TSO-C147 Appendix 1 section 1.6 to use selective Mode S interrogations as specified by RTCA DO-185A section 2.2.3.9 and 2.2.4.5.4.2 following all the applicable protocols for Mode-S surveillance interrogations in the NAS as stated in RTCA DO-185B and RTCA DO-181D.
3. Garmin was granted a deviation from RTCA DO-197A section 2.2.3.2.1 to use the Interrogations Spectrum requirement of RTCA DO-185B section 2.2.3.3 instead of the requirement of RTCA DO-197A section 2.2.3.2.1.
4. Garmin was granted a deviation from RTCA DO-197A section 2.2.3.5 to use the “Mode C Only All-Call” format specified by RTCA DO-185B section 2.2.3.8.1 instead of the “Mode C” format for ATCRBS interrogations.
5. Garmin was granted a deviation from RTCA DO-197A section 2.2.9.1 to realize the bearing estimation function using a direction finding antenna augmented by tracked correlated ADS-B data when such data is available and of sufficient integrity.
6. Garmin was granted a deviation from RTCA DO-197A section 2.2.11 to use the suppression pulse on the aircraft suppression bus specified by RTCA DO-185B section 2.2.3.12 (70 +/-1 μs from top antenna and 90 +/-1 μs from bottom antenna) instead of 100 +/-5 μs.
1. Garmin was granted a deviation from ETSO-C147 section 3.1.2 to use EUROCAE ED-14F, instead of EUROCAE ED-14D as the standard for Environmental Conditions and Test Procedures for Airborne Equipment.
2. Garmin was granted a deviation from ETSO-C147 Appendix 1 section 1.6 to use selective Mode S interrogations as specified by RTCA DO-185B section 2.2.3.9 and 2.2.4.5.4.2 following all the applicable protocols for Mode-S surveillance interrogations in the NAS as stated in RTCA DO­185B and RTCA DO-181D.
3. Garmin was granted a deviation from RTCA DO-197A section 2.2.3.2.1 to use the Interrogations Spectrum requirement of RTCA DO-185B section 2.2.3.3 instead of the requirement of RTCA DO-197A section 2.2.3.2.1
4. Garmin was granted a deviation from RTCA DO-197A section 2.2.3.5 to use the “Mode C Only All-Call” format specified by RTCA DO-185B section 2.2.3.8.1 instead of the “Mode C” format for ATCRBS interrogations.
5. Garmin was granted a deviation from RTCA DO-197A section 2.2.9.1 to realize the bearing estimation function using a direction finding antenna augmented by tracked correlated ADS-B data when such data is available and of sufficient integrity.
6. Garmin was granted a deviation from RTCA DO-197A section 2.2.11 to use the suppression pulse on the aircraft suppression bus specified by RTCA DO-185B section 2.2.3.12 (70 +/-1 μs from top antenna and 90 +/-1 μs from bottom antenna) instead of 100 +/-5 μs.
1. Garmin was granted a deviation from ETSO-C166a, section 4.2 to allow not marking the unit with the class information, which is instead provided in the installation and operation manual.
2. Garmin was granted a deviation from ETSO-C166a to use RTCA DO-260B instead of RTCA DO-260A as the Minimum Performance Standard.
3. Garmin was granted a deviation from ETSO-C166a to use RTCA DO-160F instead of RTCA DO-160E as the Environmental Standard.
4. Garmin was granted a deviation from RTCA DO-260B section 2.2.4.3.4.7.3.b to use the Conservative and Brute Force error correction techniques specified by RTCA DO-260B section
2.2.4.4.3.1 instead of 2.2.4.4.2.2.d and Appendix A, Section 3 of RTCA DO-185B.
5. Garmin was granted a deviation from RTCA DO-260 and Brute Force error correction techniques specified by RTCA DO-260B section 2.2.4.4.3.1 instead of section 2.2.4.4.2.2.d and Appendix A, Section 3 of RTCA DO-185B.
B section
2.2.4.5.b to use the Conservative
GTS Processor Installation Manual Page 1-7 190-00587-50 Revision A
1.6 Reference Documents
DRAFT
The following publications are sources of additional information for installing the GTS Processor. Before installing the GTS Processor, the installer should read all referenced materials along with the manual.
Table 1-9 Reference Documents
Part Number Document
190-00313-11 Jackscrew Backshell Installation Instructions
190-00303-00 G1000 System Installation Manual
190-00587-51 GTS Processor System Maintenance Manual
190-00903-00 G1000 System Maintenace Manual LJ/VLJ
190-00907-00 G1000 System Maintenance Manual Standard Piston/Turboprop Aircraft
Page 1-8 GTS Processor Installation Manual Revision A 190-00587-50
1.7 Aviation Limited Warranty
DRAFT
