Keylock 7700
Simple Card Reader for Door Access &
Time Attendance System
User Guide
3-4 CHAPTER 1 • GETTING STARTED
Viewing the User Guide in the Internet
Included Accessories
Included Printed Materials
Activating Keylock 7700
Registering Warranty
57 CHAPTER 2 • BASICS
Introduction
Overview
Reactivating Keylock 7700
Keypad
How to Access Main Menu
Setting of Date and Time
Setting Language
Cleaning
Restarting and Resetting Keylock 7700
810 CHAPTER 3 • MAIN MENUMANAGING USERS
Enrolling User
Verifying User
Deleting User
Access Level/Privilege
1113 CHAPTER 4 • DOOR ACCESS OPTIONS
Enabling Alarm
Number of Tries Allowed
Lock (Period of Door Opening)
Verification Mode Setting
Type of Visitor Mode
Card Only Option
Deleting Logs
Clearing All Data
Clearing Admin Privilege
Delete S Logs
14 CHAPTER 5 • MANAGING USB FLASH DISK
Using USB to Download/Upload Data
Using USB to Download Logs
Using USB to Download Users
Using USB to Upload Users
Using USB to Update Firmware
1516 CHAPTER 6 • SYSTEM INFORMATION
Browsing Attendance Logs
Device Information
CONTENTS
3
CONTENTS
Long Shaft
Rubber Cushion
Screws
RFID Keychain (5pcs)
AA Batteries
Door Frame
Panel
Door Latch
Keyhole
Blocker
Mechanical Key
Latch Front
Panel
7700 D (Double Latch) 7700 S (Single Latch)
Allen Key
Door Frame
Panel
Door Latch
Keyhole
Blocker
Note: Each package will only include accessories relevant to the latch type chosen.
1 • Getting Started
VIEWING THE USER GUIDE IN THE INTERNET
The Keylock 7700 User Guide is available in the package when you purchased the
FingerTec Keylock 7700. The User Guide is also available online at www.fingertec.
com and user.fingertec.com. Choose your preferred language for the User Guide.
INCLUDED ACCESSORIES
4
CONTENTS
INCLUDED PRINTED MATERIALS
• FingerTec Comprehensive DVD
• Quick Start Guide
• Pamphlet
• User Enrollment Template Form
• Warranty Card
ACTIVATING KEYLOCK 7700
Insert four AA batteries to the back of Keylock 7700 and
push the Power Up button to start up Keylock 7700. 4
AA Batteries can last up to approximately 4000 standard
operations.
REGISTERING WARRANTY
Make sure that you register your Keylock 7700’s warranty with us at www.fin-
gertec.com/ver2/english/e_warranty.htm.
5
CONTENTS
2 • Basics
INTRODUCTION
FingerTec’s Keylock 7700 is a breakthrough in mechanical door lock design featuring superior attributes. Keylock 7700 offers fingerprint, password and card verification systems, all in one machine for a convenient operation process. Enrollment and
management of users is now hassle-free. An administrator can perform enrollment,
deletion and amendment of user(s) at Keylock 7700. Keylock 7700 is also designed to
allow data transmission through USB flash disk.
OVERVIEW
Item Function
LCD Screen To display status of battery, status of Keylock 7700, date and time.
Touch Screen Keypad To input instructions to Keylock 7700 and perform configuration.
Card Induction Area To read the card information based on the card system of Keylock 7700.
Power Up Button To power up the Keylock 7700 device from idle mode.
Keyhole Open the cover to find the keyhole if you want to unlock the door by
using a mechanical key.
LCD Screen
Touch Screen
Keypad and
Card Induction
Area
Fingerprint
Scanner
Handle
Keyhole
Backup Battery Connector
Battery Slots
USB Port
Power Up Button
6
CONTENTS
9
Item Function
Fingerprint Scanner To scan fingerprint for confirmation of identity.
Battery Slots To insert four pieces of standard AA batteries for power.
USB Port To connect the USB extension provided to download/upload data
from/to Keylock 7700.
REACTIVATING KEYLOCK 7700
Keylock 7700 is an energy-saving device. Right after every use, Keylock 7700 will return to its idle status. Press the Power Up button to reactivate Keylock 7700.
KEYPAD
Item Function
to To input the number 0-9.
To input the number 8 / To move up in
the Menu.
To input the number 0 / To move down
in the Menu.
To return to the previous instruction.
To access to the main menu/ To select or
confirm instructions.
HOW TO ACCESS THE MAIN MENU
It is required to enroll the administrator’s fingerprint template into Keylock 7700 before proceeding to enroll for normal users. If the administrator’s fingerprint template
is deleted, new user enrollment will not be possible anymore. However, a normal
user can assign himself as an administrator to access the system menu and enroll
new users.
