WelcomeCheck-In
01-01 09:00 Fri
1 2 3 ESC
4 5 6
7 8 9
0 MENU OK
AC900 R2/M2
Access Control & Time Attendance System
User Guide
CONTENTS
3-4 CHAPTER 1 • GETTING STARTED
Viewing the User Guide in the Internet
Terminal Included Accessories
Included Printed Materials
Activating Terminal
Registering Terminal
5-8 CHAPTER 2 • BASICS
Introduction to Products Overview
Power On/Off Button Keypad
Battery Date/Time Voice Control Security Features
Cleaning Terminal
Restarting and Resetting Terminal
9-15 CHAPTER 3 • CONNECTION
– SYNCING TERMINALS
Installations Communications Ingress Online Activation
Installation and Setup of Ingress Connecting Terminals to Ingress Using USB to Download/Upload Data Communication Key
16-19 CHAPTER 4 • USER
Enrolling User
Verifying User
Types of Verification Method
Adding User Information
Deleting User
Access Level/Privilege
20-23 CHAPTER 5 • SYSTEM
General Settings
Fingerprint Settings
Update Firmware
System Information
Log Information (Log Opt)
24 CHAPTER 6 • DATA
Deleting Transaction Logs Deleting All Data Managing User Privilege
Resetting to Factory Settings
25 CHAPTER 7 • USB
Understanding the Need for USB Flash Disk Type of USB
Downloading Attendance Logs
Downloading User Data
Uploading User Data from USB to Terminal
Uploading Short Messages
26-29 CHAPTER 8 • ACCESS
Using The Terminal as Door Access
Access Options
User Account Options
Access Combination
Lock
Door Sensor Delay
Door Sensor Mode
Door Sensor Alarm
Turning Off Alarm
Duress Options
Alarm Count
Group Verification Type
30 CHAPTER 9 • RFID CARD FUNCTION
Enrollment of RFID Card
Verification Using RFID Card Only
Multi Verification Methods Using RFID
Deleting RFID Card
Changing Card ID
31-32 CHAPTER 10 • MIFARE CARD FUNCTION
Fingerprint Card Key (FP Card Key) Creating PIN Card
Enrolling FP Card
Creating FP Card Registering FP Card Unregistering FP Card Emptying FP Card Dumping FP Card Moving to FP Card Changing FP Card
33 CHAPTER 11 • HID CARD FUNCTION
Registering HID Card
Deleting HID Card
34 CHAPTER 12 • AUTO TEST
Who Should Do The Auto Test?
Run All Tests At Once
FLASH Test
LCD Test
Voice Test
FP Reader
Key Test
RTC Test
35-36 TROUBLESHOOTING
1• GETTING STARTED
Viewing the User Guide in the Internet
The User Guide is available in the package when you purchased the terminal. The User Guide is also available online at fingertec.com and user.fingertec.com. Choose the language that you prefer for your User Guide.
Terminal Included Accessories
AC900 MODEL
WelcomeCheck-In
01-01 09:00 Fri
Screwdriver
Use the screwdriver to open the back plate of fingerprint terminal and to install the back plate against a wall.
A Packet of Bolts
Attach the back plate of the terminal against a wall using the screws provided.
R2 or M2 MODEL
AdapTec AC
Supplying power and door access controller to the terminal.
1 2 3 ESC
4 5 6
7 8 9
0 MENU OK
A Packet of Bolts
Use the screws to hold the back plate of the terminal against a wall.
USB Extension
For USB Flash disk connectivity in fingerprint terminal for downloading and uploading of data.
Screwdriver
Use the screwdriver to open the back plate of fingerprint terminal and to install the back plate against a wall.
RFID Cards (5 pieces) / HID/MIFARE Cards (1 piece)
For card enrollment and verification.
* Exclusively for R2 model only
TCP/IP Connector
Connecting the network cable from a PC or Network switch to a TCP/IP connector at the terminal.
TCP/IP Cable
Connecting fingerprint terminal for Ethernet connection.
CONTENTS 3
Door Accessories Cable
Cables for 12V door lock, push button, 12V alarm, door sensor and 12V door bell, for door access.
RS232/RS485/Wiegand Output Cable
For serial cable connection and Wiegand Output connection.
Power Supply Cable
Connecting fingerprint terminal to the 12V power supply.
Included Printed Materials
•FingerTec Comprehensive DVD
•Quick Start Guide
•Pamphlet
•User Enrollment Template Form
•Warranty Card
Activating Terminal
Every FingerTec access control model comes bundled with a unique license key. To start using the terminal with Ingress, you must connect the terminal to Ingress and perform online activation. Ingress reads the serial number of your terminal and sends it for verification at the FingerTec server via Internet.
In case you do not have an Internet connection, you would need to do offline activation. Please send the serial number and models of your terminals to your local resellers or support@fingertec.com to request for a product key and activation key.
Registering Terminal
Make sure that you register your terminal’s warranty with us at fingertec.com/ver2/ english/e_warranty.htm.
4
CONTENTS
2 • BASICS
Introduction to Products
FingerTec is a renowned brand name when if comes to commercial fingerprint products for door access and time attendance systems. FingerTec offers a wide range of products to cater to the growing need of biometric products in office/home automation as well as in security industry.
Fingerprint terminals are loaded with powerful microprocessors that can process biometrics authentication methods for accurate personal identification and for collection of precise data for time attendance and door access. In addition, some fingerprint terminals are designed to accept card verification as an added security measure.
This manual covers three models of fingerTec’s fingerprint products, AC900, R2 and M2.
Overview
AC900 MODEL
L.E.D Display
WelcomeCheck-In |
LCD Screen |
01-01 09:00 Fri |
|
|
Keypad |
|
Fingerprint |
|
Sensor |
ITEM |
FUNCTION |
LCD Screen |
Displaying status of terminal, day, date and time. |
|
|
LED Display |
Green LED – The terminal is working fine and it is in standby mode. |
|
Red LED – There is an error at the terminal that requires checking. For |
|
first time use, the terminals need to be charged fully to avoid having |
|
the red light blinking. |
Keypad |
To input instructions into the terminal and to allow configuration. |
|
|
Fingerprint Sensor |
To scan finger for confirmation of identity. |
|
|
CONTENTS 5
R2 or M2 MODEL
L.E.D Display
|
1 |
2 |
3 |
ESC |
RFID Card |
4 |
5 |
6 |
|
Induction |
7 |
8 |
9 |
|
Area |
|
0 |
MENU |
OK |
LCD Screen |
|
Keypad |
USB Port |
Fingerprint |
Speaker |
|
Sensor |
||
|
|
|
|
|
|
|
|
|
|
|
Reset Button |
||
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
||||||
|
|
ITEM |
FUNCTION |
|||||||||
|
|
LCD Screen |
Displaying status of terminal, day, date and time. |
|||||||||
|
|
|
|
|
|
|
||||||
|
|
LED Display |
Green LED – The terminal is working fine and it is in standby mode. |
|||||||||
|
|
|
|
|
|
Red LED – There is an error at the terminal that requires checking. For |
||||||
|
|
|
|
|
|
first time use, the terminals need to be charged fully to avoid having |
||||||
|
|
|
|
|
|
the red light blinking. |
||||||
|
|
|
|
|
|
|
||||||
|
|
Keypad |
To input instructions into the terminal and to allow configuration. |
|||||||||
|
|
|
|
|
|
|
||||||
|
|
Fingerprint Sensor |
To scan finger for confirmation of identity. |
|||||||||
|
|
|
|
|
|
|||||||
|
|
RFID Card Induction Area Area that reads RFID cards. |
|
|||||||||
|
|
USB Port |
To upload/download users information, password and transaction |
|||||||||
|
|
|
|
|
|
logs via USB flash disk. |
|
|||||
|
|
Speaker |
For terminal voice emission. |
|||||||||
|
|
|
|
|
|
|
||||||
|
|
Reset Button |
To restart the terminal as and when required. |
|||||||||
|
|
|
|
|
|
|||||||
|
|
Power On/Off Button |
||||||||||
|
|
|
|
|
|
|||||||
|
|
|
MODEL |
HOW TO TURN ON/OFF |
||||||||
|
|
AC900 |
Push on the ‘0’ button |
|||||||||
|
|
|
|
|
|
|||||||
|
|
R2 or M2 |
There is no power button available. Restart using the reset button |
|||||||||
|
|
|
|
|
|
shown on the bottom of the terminal. |
||||||
6 |
|
|
CONTENTS |
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
Keypad
1 |
|
2 |
|
3 |
|
ESC |
|
|
|
|
|
||
4 |
|
5 |
|
6 |
|
|
|
|
|
|
|
||
7 |
|
8 |
|
9 |
|
|
|
|
|
|
|
|
|
|
|
0 |
|
MENU |
|
OK |
You can insert inputs into the terminals through the keypad. It contains numbers from 0-9, an OK button, an ESC/Cancel button, a Scroll up/down button, a doorbell button and a Menu button.
Battery
Fingerprint terminals operate using power supply from a standard power outlet.
Mini UPS: Mini UPS 12V can also be used to provide power supply to turn on the terminals. Refer to accessory.fingertec.com for more information about accessories.
Date/Time
The terminals displays the date and time at the home screen. Choose the date and time format based on your preference. Press Menu > Options > Systems Options > Date/Time > set your time and save.
To change the date format: Press Menu > Options > Systems Options > Fmt > Determine the date format based on your preference.
Voice Control
Voice Control lets you control the level of volume emitted by the terminal.
TURN ON/OFF
The system lets you turn on/off the voice based on your preference. Press Menu > Options > System Option > Adv Option > Voice > Y/N.
ADJUST VOLUME
The default volume of the terminal’s voice is 67. The volume can go as high as 100 and as low as 0. To sustain the performance of the speaker, it’s recommended to stay at range 60-70. To adjust the volume Press Menu > Options > System Option > Adv Option > Adj VOL (%) > adjust accordingly .
CONTENTS 7
Security Features
Security features help protect the information in the terminal from being accessed by unauthorized individuals.
ADMIN AFFIRM
Register an administrator into the system by enrolling fingerprints or a password to a user ID. Press Menu > User Manage > Enroll Admin > Choose enrollment method > Perform enrolment and Save. After enrolling an administrator, the main menu can only be accessed by the administrator.
TAMPER SWITCH
The fingerprint terminals come with a tamper switch located at the rear of the terminals. During installation, the tamper switch is compressed against the back plate. Any attempt to dismantle the terminal will trigger an alarm and a “System Broken” message will be displayed on the panel.
Cleaning Terminal
CLEANING THE BODY
Use a dry cloth to clean the terminal’s body. Do not use any liquids, household cleaners, aerosol spray, solvents, alcohol, ammonia and abrasive solutions to clean the body of the terminal because it could damage it.
Restarting and Resetting Terminal
If a feature isn’t functioning as it should, try restarting or resetting the terminals
RESTARTING THE TERMINAL
Push the On/Off button or “reset button” on the terminal to restart the terminal. If you can’t restart the terminal, or if the problem persists, you might want to reset.
RESETTING THE TERMINAL
Press Menu > Option > System Option > Adv Opt > Reset terminal. Resetting of the terminal will cause all your settings to return to its original factory settings. Make sure that you have backed up all data before you proceed.
8
CONTENTS
3 • CONNECTION – SYNCING TERMINALS
Installations
FingerTec terminals offer several connections for power and communications. Installations of FingerTec time attendance terminals are simple.
MOUNT ON WALL
Back Plate
1 2
3
4 5 6
7 8 9
0
4 feet / 1.2 meter (recommended)
Attached the back plate on the wall securely and attach the terminal to the back plate when mounting it on the wall.
Communications
Connection points for power and communication are available on top of the terminals. Refer to the following diagrams for the terminals you require.
CONTENTS 9
AC900 MODEL
|
|
Output |
TCP/IP Port |
||
|
|
Voltage |
|||
|
|
+12V 0 |
(Ethernet Connection) |
||
Access Connection |
|
|
|
||
1. Normal Open Lock Connection |
|
|
|||
|
|
NO |
|
|
|
Door Strike |
|
|
|
|
|
|
|
GND |
|
RS232 Cable |
|
|
|
|
|
||
NO +12V |
GND -12V |
|
|
|
|
2. Normal Close Lock Connection |
GND |
GND |
|||
PWR |
RX |
||||
|
|
|
|||
Electromagnetic/ |
NC |
COM |
TX |
||
|
|
||||
Drop Bolt |
|
|
NO |
GND |
|
(less than 1A) |
GND |
NC |
485A |
||
GND |
NC |
|
GND |
485B |
|
|
AL+ |
GND |
|||
|
|
|
|||
|
|
|
AL |
D0 |
|
Switch |
|
|
BUT |
D1 |
|
|
|
BUT |
GND |
+5V |
|
|
|
B+ |
SEN |
||
|
|
|
|||
|
|
GND |
B- |
GND |
|
|
|
|
|
||
*requires 2 cables which has no +/- value Using the push switch
1. RS485 Single Connection
485A RX+
485B RX-
RS232/ RS485
Data Converter
2. RS485 Network Connection
485A |
|
485B |
RX+ |
485A |
RX- |
485B |
RS232/ RS485 |
|
Data Converter |
10
CONTENTS
R2 or M2 MODEL
|
|
|
|
ALM+ |
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
ALM- |
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
NC |
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
COM |
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
For NC |
NO |
|
. |
|
. |
|
. |
|||||
|
|
|
||||||||||
or NO |
|
|
|
|
. |
|
. |
|
. |
|||
|
|
|
|
. |
|
. |
|
. |
||||
door |
|
|
BUT |
|
|
. |
|
. |
|
. |
||
|
|
. |
|
. |
|
. |
||||||
|
|
|
|
. |
|
. |
|
. |
||||
lock |
|
|
|
|
. |
|
. |
|
. |
|||
|
|
|
|
. |
|
. |
|
. |
||||
|
|
|
|
|
|
|
|
. |
|
. |
|
. |
system |
|
|
|
|
. |
|
. |
|
. |
|||
GND |
|
. |
|
. |
|
. |
||||||
|
|
|
|
|
. |
|
. |
|
. |
|||
SEN
BEL+
BEL-
GND
+12V
DC12V
Power Supply
1. RS485 Single Connection
485+ |
RX+ |
|
485- |
RX- |
|
|
RS232/RS485 Data |
|
|
Converter |
|
2. RS485 Network Connection |
||
485+ |
|
|
485- |
RX+ |
|
485+ |
RX- |
|
485- |
RS232/RS485 Data |
|
Converter |
||
|
||
BEEP
GLED
RLED
INWD0
Wiegand
IN
INWD1
GND
Power
OUT +12V
3rd party controller with 26 bitswiegand output
|
RJ45-1 |
|
|
RJ45-2 |
|
|
|
TCP/IP |
TCP/IP |
RJ45-3 |
|
|
|
|
|
RJ45-6 |
|
|
WD0 |
|
|
WD1 |
Wiegand |
3rd party controller |
|
OUT |
GND |
|
|
with 26 bits wiegand |
|
|
input |
|
|
|
RXD |
|
|
TXD |
RS232 |
|
|
|
RS232 |
GND |
|
cable |
|
|
|
|
|
|
485+ |
|
|
|
RS485 |
|
485- |
|
CONTENTS 11
For NC (normally closed) |
|
|
|
|
|
|
|
|
|
|
|
|
|
||
door lock system |
|
EM lock |
|
+ |
|
|
|
|
|
ALM+ |
|
||||
|
|
|
|
(NC) |
|
- |
|
|
|
|
|
|
|
||
|
|
|
ALM- |
|
|||||||||||
|
|
|
|
Emergency |
|
2 |
|
|
|
|
|
|
|
||
|
|
|
|
|
|||||||||||
|
|
|
|
break glass |
|
3 |
|
|
|
|
|
NC |
|
||
|
|
|
|
(NC) |
|
|
|
|
|
|
|
|
|||
|
|
|
|
Key switch |
|
A |
|
|
|
|
|
COM |
|
||
|
|
|
|
(NC) |
|
C |
|
|
|
|
|
NO |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Release |
|
|
|
|
|
|
|
|
BUT |
|
|
|
|
|
|
button |
|
|
|
|
|
|
|
|
GND |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Door |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
sensor |
|
|
|
|
|
|
|
|
SEN |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
Doorbell |
|
|
|
|
|
BEL+ |
|
||||
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
BEL- |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
GND |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
For NO (normally open) |
|
DC12V Power Supply |
|
+12V |
|
||||||||||
|
|
|
|||||||||||||
|
|
|
|
||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
door lock system |
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
EM lock |
|
+ |
|
|
|
|
|
|
ALM+ |
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
(NO) |
|
- |
|
|
|
|
|
|
ALM- |
|
|
|
|
|
|
Emergency |
|
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
break glass |
|
3 |
|
|
|
|
|
|
NC |
|
|
|
|
|
|
(NO) |
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
COM |
|
|
|
|
|
Key switch |
|
B |
|
|
|
|
|
|
|||
|
|
|
|
(NO) |
|
D |
|
|
|
|
|
NO |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Release |
|
|
|
|
|
|
|
|
BUT |
|
|
|
|
|
|
button |
|
|
|
|
|
|
|
|
GND |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Door |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
sensor |
|
|
|
|
|
|
|
|
SEN |
|
|
|
|
|
|
Doorbell |
|
|
|
|
|
|
|
|
BEL+ |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
Please refer to |
|
|
|
|
|
|
|
|
|
|
|
BEL- |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
AdapTec AC |
|
|
|
|
|
|
|
|
|
|
|
GND |
|
|
|
Installer Manual |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
NOTE |
if you are using |
DC12V Power Supply |
|
|
+12V |
|
|||||||||
AdapTec AC. |
|
|
|
|
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
............
............
............
............
............
............
1 8
TOP
FRONT
1 8
USB PORT
Linking with USB flash disk for remote data |
|
This feature is |
NOTE |
not available in |
|
transfer. |
AC900 |
TCP/IP PORT
Connect with CAT 5 cable for LAN connection, one end to this port and another end to the computer’s TCP/IP Port.
TCP/IP for Single Connection – Linking the terminal to a single computer using TCP/IP requires Ethernet 10/100Base-T Crossover Cable. The cable can be used to cascade hubs or to connect Ethernet stations back-to-back without a hub. It
works with both 10Base-T and 100Base-TX
12
CONTENTS
