FingerTec FTDP User Manual
User Guide
Version 1.0.0.1
CONTENTS
Part 1 : FTDP User Guide (General)
4 Chapter 1 • INTRODUCTION
5 Chapter 2 • INSTALLATION
6 Chapter 3 • TERMINAL MANAGEMENT
Adding FingerTec Terminals
Via TCP/IP Connection
Via RS232/RS485 Connection
Via URL
Configuring Terminals
Deleting a Terminal
8 Chapter 4 • USER MANAGEMENT
Downloading Users from the Terminal
Uploading Users to Terminal
Deleting Users from the Terminal or Software
Adding Users Manually into the Software
Exporting User Information
12 Chapter 5 • ACCESS CONTROL
Time Zones & Group Time Zones
Valid Time Zones
Group Time Zones
Different Verification Methods
Reviewing Users’ Time Zone
15
Chapter 6 • TRANSACTION MANAGEMENT
Downloading Transaction Logs from the Terminals
Searching for Transaction Logs
Exporting Transaction Logs
Part 2: FTDP for Home Users
16 Chapter 7 • FTDP for Home Users
18 INFORMATION ABOUT FINGERTEC
3
Part 1 : FTDP User Guide (General)
1 • INTRODUCTION
The FingerTec Data Processor (FTDP) is a basic software designed to interact with all
FingerTec terminals. The FTDP was developed to help ease the system integrator or software developer’s job of fully integrating their FingerTec terminals with their company’s
existing systems.
The FTDP software’s main functions are:
Downloading / uploading user information from/to terminals
Downloading transaction logs from terminals
Configuring settings of terminals
Exporting user information and transaction logs into various file formats for input into
a 3rd party system
Storing data into a Microsoft Access database as a centralized database which is acces-
sible by using the ODBC Manager
E
S
C
1
23
4
56
7
9
8
K
O
E
N
U
M
0
FingerTec Terminals
Microsoft Access
Database
FTDP
F i n g e r T e c D a t a P r o c e s s o r
FTDP
ODBC
3rd party
S
M
TC
system
S
CM
T
Manager
Previously a system integrator or software developer had to use the BioBridge SDK (Software Development Kit) to develop their own solutions or software to obtain data from
FingerTec terminals. ” Previously, a system integrator or software developer would have
to use the BioBridge SDK (Software Development Kit) to develop their own solutions
or software to obtain data from FingerTec terminals. With the FDTP, you will be able to
perform the basic functions such as adding/deleting users, as well as able to export the
raw data out of the terminal, to be processed by a third party software of your choice. In
short, the FDTP is a basic version of the TCMS v2 and the BioBridge SDK combined.
Software developers can now integrate the information and transaction logs from the
via Microsoft Access to build up or customize a total solution for users”
4
2 • INSTALLATION
Follow these steps to install the FTDP in your PC successfully.
Double click on the “FingerTec Data Processor.exe” icon to run the installation file.
The installation process will initialize automatically. Click Next.
Read and understand the license agreement and select “I accept the terms in the li-
cense agreement”. Click Next to proceed.
Click Next to install the software into the recommended path. Click Change if you wish
to specify the location to install the program.
Click Install to proceed. Wait while the installation process completes.
Click Finish to when the process is completed.
A new icon labeled “FingerTec Data Processor” will be displayed on the desktop.
Double click the icon to run the software.
A login interface prompt will request a password when you try to run the FTDP. The default password is 123. Insert the password and click Login to enter the FTDP.
5
3 • TERMINAL MANAGEMENT
To enter the terminal management page, click on Terminal. You can add, edit, and delete
terminals from this page.
Adding FingerTec Terminals
VIA TCP/IP CONNECTION
To Add: Click Add > Insert the terminal’s IP address > Check that “Port No.” value is 4370
> Check that “COMM Key” value is 0 > Assign a name to the terminal > Click Connect to
start connection.
Connection by serial port: RS232/RS485
Click on the Comm check box if you are connecting to a terminal via the RS232 or RS485 wires.
VIA RS232/RS485 CONNECTION
To Add: Define the Comm Port > Define the Baud Rate > Check that “COMM Key” value
is 0 > Assign a name to the terminal > Click Connect to start connection.
Connection by URL
6
You can click on URL if you are connecting to the terminal via the Internet.
VIA URL
To Add: Define the URL > Check that “Port No.” volue is 4370 > Check that “COMM Key”
volue is 0 > Define the “DNS” > Assign a name to the terminal > Click Connect to start connection > Check for the correct terminal details > Click Save.
Terminal details
Con guring Terminals
The FTDP enables you to configure the settings in a terminal via the software.
To Configure Settings: Click Advance Settings > Click Get Settings > Define settings
(Refer to TCMS v2.2 manual, page 15) > Click Set Settings to upload settings to terminal.
Deleting a Terminal
Deleting a terminal from the FDTP is simple. Just select the terminal you wish to delete
and click Delete.
7
