Installation Guide
Face ID2
Face & Fingerprint Recognition for
Time Attendane & Door Access Control System
Step 1
Determine the Location and Positioning
of the Installation
•
Avoid installing the terminals in locations that has contact with
a strong light source (e.g direct sunlight, spotlight, fluorescent
light, etc)
• Avoid installing the terminals in locations with high moisture or
condensation levels in the air
• The recommended installation height of the terminal from the
ground is 1.2 meter.
Step 2
Mounting of Terminals on A Wall
Back Plate
INSTALLATION TIPS:
Best installation location of Face ID 2
must
1 - Avoid sunlight.
2 - 2 meters away from any light source i.e.
ceiling direct flourescent light
3 - Suggested 1.2m from the ground level
(measure from ground to the face capturing camera)
Step 3
Wiring for Power Supply
1. Use the power adapter provided in the package and insert the
power adapter to the port marked A in the diagram.
2. Use power cables (black and red) to connect to a linear power
supply with specifications of 5VDC 3A (Marked B).
POWER SUPPLY (B)
GND
+12V
ALARM PORT
ACCESS
CONTROL
PORT
RS232/RS485 SERIAL PORT
DC12V 3A
Power Supply
POWER
ADAPTER
PORT (A)
USB PORT
TCP/IP PORT
www.fingertec.com
4 feet / 1.2 meter
(recommended)
• After determining the height of the terminal from the ground
level and have made the relevant marks on the wall, drill the
screws into the wall to hang the back plate.
Refer to Appendix II for dimensions and measurements of instal-
lation.
485-
RS485
485+
GND
RS232
cable
3rd party controller
with 26 bits wiegand
input
Door Lock connector. Refer to Appendix I
TXD
RXD
GND
WD1
WD2
1. RS485 Single Connection
485+
485-
RS232/RS485
Data Converter
2. RS485 Network Connection
485+
485485+
4851
RS232/RS485
Wiegand OUT RS232
RX+
RX-
RX+
RX-
Data
Converter
Step 4
Setting Up Data Communications
(Skip this step if you are using USB ash disk to transfer data)
The data communication ports are positioned at the rear of the
terminals, please refer to the diagrams shown on Step 3 to determine the wiring. Plug the communication jacks (TCP/IP, RS232 or
RS485) to the corresponding ports.
TCP/IP – LAN Connection
For TCP/IP connection, plug the special RJ45 jack into the TCP/IP
(LAN) Port of the terminal. Connect the other end (normal RJ45
jack) to the local area network hub or a PC. Configure the device
ID, IP address, subnet mask and Gateway in the terminal (refer to
the hardware user manual for details).
Other Accessories
Note: All Accessories are offered at http://accessory.fingertec.com
AdapTec Plus
R
O
L
O
O
C
K
D
T
I
M
E
R
RS232 – Serial Port Connection
Plug the communication jack that is provided in the package to
connect to the communication port of the terminal. Select wires
with label RX, TX and GND, and connect the other end of these
wires to a DB9 female connector. Configure the device ID and
baudrate of the terminal (refer to the hardware user manual for
details). Use the normal RS232 cable to plug into the RS232 port
of the terminal.
RS485 – Serial Port Connection
Plug the communication jack that is provided in the package to
connect to the communication port of the terminal. Select wires
with label RS485+, RS485- and GND, and connect the other end
of these wires to an RS232/485 data converter. Connect the other
end of the data converter to a DB9 female connector. Configure
the device ID and baudrate of the terminal (refer to the hardware
user manual for details).
Step 5
Finalizing the installation
1. Check that all cable connections are done correctly.
2. Attach the terminal to the corresponding back plates,
tighten the screws to secure the terminal on the wall
3. Switch on the power to the terminal.
4. Start using the terminal.
The AdapTec Plus is a 12VDC power supply inclusive of a
110~240VAC switching linear power. The AdapTec supplies
12VDC power to the FingerTec terminal and door lock system as
well as charges a 12VDC 7.0Ah backup battery simultaneously.
During an event of a power failure, the back up battery automatically provides power to the terminal and maintains the door lock
system. The AdapTec Plus also prevents a secured door from being
opened if it has been tampered with.
Door Lock Accessories
FingerTec offers various door locks accessories to complement
FingerTec door access product range.
Appendix I
Power Supply & Door Lock System Wiring Diagrams
Appendix II
Terminal Dimensions and Measurements
Diagram1 • Normally Close (NC)
NO2
COM2
NC2
SEN
Release Button
EM Lock
Emergency
Break Glass
Overwrite Key
Switch
+
_
2
3
A
_
C
DC12V
GND
BUT
NO1
COM1
NC1
GND
+12V
+
3A
Diagram 2 • Normally Open (NO)
NO2
COM2
NC2
SEN
Release Button
EM Lock
Emergency
Break Glass
Overwrite Key
Switch
+
_
1
3
B
_
D
DC12V
3A
GND
BUT
NO1
COM1
NC1
GND
+12V
+
Door Lock Connectors
WIRING PORT USAGE
NO2
COM2
NC2
SEN
GND
BUT
NO1
NC1
COM1
The terminal will trigger the alarm output
(NO or NC) for the following situations:
• Door forced open (A door sensor must
first be installed)
• Door open time out (A door sensor must
first be installed)
• Terminal has been illegally dismantled
Alarm System
NO Type – NO2 – COM2
NC Type – NC2- COM2
Door Sensor (SEN-GND)
Release Button (BUT-GND)
Dry Contact
(Independent power supply for door
lock)
• NO type door lock (NO1-COM)
• NC type door lock (NC1-COM)
Power Contact
(Using power from terminal to power
on door lock)
• NO type door lock (NO1-GND)
• NC type door lock (NC1-GND)
Dry Contact (independent power
supply for door lock)
• NO type door lock (NO1-COM)
• NC type door lock (NC1-COM)
Power Contact (using power from
terminal to power on door lock)
• COM1 - +12V
Front View of Back Plate
Diagram 3 • Other Accessories
Alarm Device
Type NC dry contact
Alarm Device
Type NO drycontact
Door Sensor
_
+
DC12V
3A
Use either Type NO or Type NC alarm device.
NO2
COM2
NC2
SEN
GND
BUT
NO1
COM1
NC1
GND
+12V
