APPENDIXA. ALARM LIST

B–63525EN/02

A.1

LIST OF ALARM CODES (CNC)

(1) Program errors /Alarms on program and operation (P/S alarm)

Number Message Contents

000 PLEASE TURN OFF POWER A parameter which requires the power off was input, turn off power. 001 TH P ARITY ALARM TH alarm (A character with incorrect parity was input).

Correct the tape.

002 TV P ARITY ALARM TV alarm (The number of characters in a block is odd). This alarm will

be generated only when the TV check is effective.

003 TOO MANY DIGITS Data exceeding the maximum allowable number of digits was input.

(Refer to the item of max. programmable dimensions.)

004 ADDRESS NOT FOUND A numeral or the sign “ – ” was input without an address at the beginning

of a block. Modify the program .

005 NO DA TA AFTER ADDRESS The address was not followed by the appropriate data but was followed

by another address or EOB code. Modify the program.

006 ILLEGAL USE OF NEGA TIVE SIGN Sign “ – ” input error (Sign “ – ” was input after an address with which it

cannot be used. Or two or more “ – ” signs were input.) Modify the program.

007 ILLEGAL USE OF DECIMAL POINT Decimal point “ . ” input error (A decimal point was input after an address

with which it can not be used. Or two decimal points were input.) Modify the program.

009 ILLEGAL ADDRESS INPUT Unusable character was input in significant area.

Modify the program.

010 IMPROPER G–CODE An unusable G code or G code corresponding to the function not pro-

vided is specified. Modify the program.

011 NO FEEDRATE COMMANDED Feedrate was not commanded to a cutting feed or the feedrate was in-

adequate. Modify the program.

CAN NOT COMMAND G95 (M series)

014

015

020 OVER TOLERANCE OF RADIUS In circular interpolation (G02 or G03), difference of the distance between

021 ILLEGAL PLANE AXIS COMMAN-

022 NO CIRCLE RADIUS The command for circular interpolation lacks arc radius R or coordinate

ILLEGAL LEAD COMMAND (T series)

TOO MANY AXES COMMANDED (M series)

TOO MANY AXES COMMANDED (T series)

DED

A synchronous feed is specified without the option for threading / synchronous feed.

In variable lead threading, the lead incremental and decremental outputted by address K exceed the maximum command value or a command such that the lead becomes a negative value is given. Modify the program.

An attempt was made to move the machine along the axes, but the number of the axes exceeded the specified number of axes controlled simultaneously. Modify the program.

An attempt has been made to move the tool along more than the maximum number of simultaneously controlled axes. Alternatively, no axis movement command or an axis movement command for two or more axes has been specified in the block containing the command for skip using the torque limit signal (G31 P99/98). The command must be accompanied with an axis movement command for a single axis, in the same block.

the start point and the center of an arc and that between the end point and the center of the arc exceeded the value specified in parameter No.

3410. An axis not included in the selected plane (by using G17, G18, G19) was

commanded in circular interpolation. Modify the program.

I, J, or K of the distance between the start point to the center of the arc.

836

B–63525EN/02

037

Number ContentsMessage

APPENDIX

A. ALARM LIST

023 ILLEGAL RADIUS COMMAND

(T series)

025 CANNOT COMMAND F0 IN G02/G03

(M series)

027 NO AXES COMMANDED IN

G43/G44 (M series)

028 ILLEGAL PLANE SELECT In the plane selection command, two or more axes in the same direction

ILLEGAL OFFSET V ALUE

029

030

031 ILLEGAL P COMMAND IN G10 In setting an offset amount by G10, the of fset number following address

032 ILLEGAL OFFSET V ALUE IN G10 In setting an offset amount by G10 or in writing an offset amount by sys-

033

034

035

036 CAN NOT COMMANDED G31

037

038

(M series) ILLEGAL OFFSET V ALUE

(T series) ILLEGAL OFFSET NUMBER

(M series)

ILLEGAL OFFSET NUMBER (T series)

NO SOLUTION A T CRC (M series)

NO SOLUTION A T CRC (T series)

NO CIRC ALLOWED IN ST–UP /EXT BLK (M series)

NO CIRC ALLOWED IN ST–UP /EXT BLK (T series)

CAN NOT COMMANDED G39 (M series)

CAN NOT COMMANDED G31 (T series)

(M series) CAN NOT CHANGE PLANE IN CRC

(M seires)

CAN NOT CHANGE PLANE IN NRC (T seires)

INTERFERENCE IN CIRCULAR BLOCK (M seires)

INTERFERENCE IN CIRCULAR BLOCK (T series)

In circular interpolation by radius designation, negative value was commanded for address R. Modify the program.

F0 (fast feed) was instructed by F1 –digit column feed in circular interpolation. Modify the program.

No axis is specified in G43 and G44 blocks for the tool length offset type C. Offset is not canceled but another axis is of fset for the tool length offset type C. Modify the program.

are commanded. Modify the program.

The offset values specified by H code is too large. Modify the program.

The offset values specified by T code is too large. Modify the program.

The offset number specified by D/H code for tool length offset, cutter compensation, or three–dimensional tool offset is too large. Alternatively , the number of an additional workpiece coordinate system specified with the P code is too large. Modify the program.

The offset number in T function specified for tool offset is tool large. Modify the program.

P was excessive or it was not specified. Modify the program.

tem variables, the offset amount was excessive. A point of intersection cannot be determined for cutter compensation.

Modify the program. A point of intersection cannot be determined for tool nose radius com-

pensation. Modify the program. The start up or cancel was going to be performed in the G02 or G03

mode in cutter compensation C. Modify the program. The start up or cancel was going to be performed in the G02 or G03

mode in tool nose radius compensation. Modify the program. G39 is commanded in cutter compensation B cancel mode or on the

plane other than offset plane. Modify the program. Skip cutting (G31) was specified in tool nose radius compensation

mode. Modify the program. Skip cutting (G31) was specified in cutter compensation mode.

Modify the program. G40 is commanded on the plane other than offset plane in cutter com-

pensation B. The plane selected by using G17, G18 or G19 is changed in cutter compensation C mode. Modify the program.

The offset plane is switched in tool nose radius compensation. Modify the program.

Overcutting will occur in cutter compensation C because the arc start point or end point coincides with the arc center. Modify the program.

Overcutting will occur in tool nose radius compensation because the arc start point or end point coincides with the arc center . Modify the program.

837

Number ContentsMessage

052

APPENDIXA. ALARM LIST

B–63525EN/02

039 CHF/CNR NOT ALLOWED IN NRC

(T series)

040 INTERFERENCE IN G90/G94

BLOCK (T series) INTERFERENCE IN CRC

(M seires)

041

INTERFERENCE IN NRC (T seires)

042 G45/G48 NOT ALLOWED IN CRC

(M series)

044 G27–G30 NOT ALLOWED IN FIXED

CYC (M series)

045 ADDRESS Q NOT FOUND

(G73/G83) (M series)

046 ILLEGAL REFERENCE RETURN

COMMAND

047 ILLEGAL AXIS SELECT Two or more parallel axes (in parallel with a basic axis) have been speci-

048 BASIC 3 AXIS NOT FOUND Start–up of three–dimensional tool compensation or three–dimensional

049 ILLEGAL OPERA TION (G68/G69)

(M series)

050 CHF/CNR NOT ALLOWED IN THRD

BLK (M series)

CHF/CNR NOT ALLOWED IN THRD BLK(T series)

051 MISSING MOVE AFTER CHF/CNR

(M series)

MISSING MOVE AFTER CHF/CNR (T series)

CODE IS NOT G01 AFTER CHF/CNR (M series)

052

CODE IS NOT G01 AFTER CHF/CNR (T series)

TOO MANY ADDRESS COMMANDS (M series)

053

054

TOO MANY ADDRESS COMMANDS (T seires)

NO TAPER ALLOWED AFTER CHF/ CNR (T series)

Chamfering or corner R was specified with a start–up, a cancel, or switching between G41 and G42 in tool nose radius compensation. The program may cause overcutting to occur in chamfering or corner R. Modify the program.

Overcutting will occur in tool nose radius compensation in canned cycle G90 or G94. Modify the program.

Overcutting will occur in cutter compensation C. Two or more blocks are consecutively specified in which functions such as the auxiliary function and dwell functions are performed without movement in the cutter compensation mode. Modify the program.

Overcutting will occur in tool nose radius compensation. Modify the program.

T ool offset (G45 to G48) is commanded in cutter compensation. Modify the program.

One of G27 to G30 is commanded in canned cycle mode. Modify the program.

In canned cycle G73/G83, the depth of each cut (Q) is not specified. Alternatively, Q0 is specified. Correct the program.

Other than P2, P3 and P4 are commanded for 2nd, 3rd and 4th reference position return command.

fied upon start–up of three–dimensional tool compensation or three–dimensional coordinate conversion.

coordinate conversion has been attempted, but the three basic axes used when Xp, Y p, or Zp is omitted are not set in parameter No. 1022.

The commands for three–dimensional coordinate conversion (G68, G69) and tool length compensation (G43, G44, G45) are not nested. Modify the program.

Optional chamfering or corner R is commanded in the thread cutting block. Modify the program.

Chamfering or corner R is commanded in the thread cutting block. Modify the program.

Improper movement or the move distance was specified in the block next to the optional chamfering or corner R block. Modify the program.

Improper movement or the move distance was specified in the block next to the chamfering or corner R block. Modify the program.

The block next to the chamfering or corner R block is not G01,G02 or G03. Modify the program.

The block next to the chamfering or corner R block is not G01. Modify the program.

For systems without the arbitary angle chamfering or corner R cutting, a comma was specified. For systems with this feature, a comma was followed by something other than R or C Correct the program.

In the chamfering and corner R commands, two or more of I, K and R are specified. Otherwise, the character after a comma(“,”) is not C or R in direct drawing dimensions programming. Modify the program.

A block in which chamfering in the specified angle or the corner R was specified includes a taper command. Modify the program.

838

B–63525EN/02

Number ContentsMessage

APPENDIX

A. ALARM LIST

MISSING MOVE V ALUE IN CHF/CNR

055

056 NO END POINT & ANGLE IN CHF/

057 NO SOLUTION OF BLOCK END

058

059 PROGRAM NUMBER NOT FOUND In an external program number search, a specified program number

060 SEQUENCE NUMBER NOT FOUND Commanded sequence number was not found in the sequence number

061 ADDRESS P/Q NOT FOUND IN

062 ILLEGAL COMMAND IN G71–G76

063 SEQUENCE NUMBER NOT FOUND

064 SHAPE PROGRAM NOT MONOTO-

065 ILLEGAL COMMAND IN G71–G73

066 IMPROPER G–CODE IN G71–G73

067 CAN NOT ERROR IN MDI MODE

(M series) MISSING MOVE V ALUE IN CHF/CNR

(T series)

CNR (T series)

(T series) END POINT NOT FOUND

(M series) END POINT NOT FOUND

(T series)

G70–G73 (T series)

(T series)

NOUSL Y (T series)

(T series)

In the arbitrary angle chamfering or corner R block, the move distance is less than chamfer or corner R amount.

In chamfering or corner R block, the move distance is less than chamfer or corner R amount.

Neither the end point nor angle is specified in the command for the block next to that for which only the angle is specified (A). In the chamfering comman, I(K) is commanded for the X(Z) axis.

Block end point is not calculated correctly in direct dimension drawing programming.

In a arbitrary angle chamfering or corner R cutting block, a specified axis is not in the selected plane. Correct the program.

Block end point is not found in direct dimension drawing programming.

was not found. Otherwise, a program specified for searching is being edited in background processing. Alternatively, the program with the program number specified in a one–touch macro call is not found in memory . Check the program number and external signal. Or discontinue the background eiting.

search. Check the sequence number. Address P or Q is not specified in G70, G71, G72, or G73 command.

Modify the program.

1. The depth of cut in G71 or G72 is zero or negative value.

2. The repetitive count in G73 is zero or negative value.

3. the negative value is specified to ∆i or ∆k is zero in G74 or G75.

4. A value other than zero is specified to address U or W though ∆i or ∆k is zero in G74 or G75.

5. A negative value is specified to ∆d, thoughthe relief direction in G74 or G75 is determined.

6. Zero or a negative value is specified to the height of thread or depth of cut of first time in G76.

7. The specified minimum depth of cut in G76 is greater than the height of thread.

8. An unusable angle of tool tip is specified in G76.

Modify the program. The sequence number specified by address P in G70, G71, G72, or G73

command cannot be searched. Modify the program. A target shape which cannot be made by monotonic machining was

specified in a repetitive canned cycle (G71 or G72).

1. G00 or G01 is not commanded at the block with the sequence number which is specified by address P in G71, G72, or G73 command.

2. Address Z(W) or X(U) was commanded in the block with a sequence number which is specified by address P in G71 or G72, respectively .

Modify the program. An unallowable G code was commanded beween two blocks specified

by address P in G71, G72, or G73. Modify the program. G70, G71, G72, or G73 command with address P and Q.

Modify the program.

839

Number ContentsMessage

081

APPENDIXA. ALARM LIST

B–63525EN/02

069 FORMAT ERROR IN G70–G73

(T series)

070 NO PROGRAM SP ACE IN MEMOR Y The memory area is insufficient.

071 DA TA NOT FOUND The address to be searched was not found. Or the program with speci-

072 TOO MANY PROGRAMS The number of programs to be stored exceeded 63 (basic), 125 (option),

073 PROGRAM NUMBER ALREADY IN

USE

074 ILLEGAL PROGRAM NUMBER The program number is other than 1 to 9999.

075 PROTECT An attempt was made to register a program whose number was pro-

076 ADDRESS P NOT DEFINED Address P (program number) was not commanded in the block which

077 SUB PROGRAM NESTING ERROR The subprogram was called in five folds. Modify the program. 078 NUMBER NOT FOUND A program number or a sequence number which was specified by ad-

079 PROGRAM VERIFY ERROR In memory or program collation,a program in memory does not agree

G37 ARRIV AL SIGNAL NOT ASSERTED (M series)

080

081

082

083

G37 ARRIV AL SIGNAL NOT ASSERTED (T series)

OFFSET NUMBER NOT FOUND IN G37 (M series)

OFFSET NUMBER NOT FOUND IN G37 (T series)

H–CODE NOT ALLOWED IN G37 (M series)

T–CODE NOT ALLOWED IN G37 (T series)

ILLEGAL AXIS COMMAND IN G37 (M series)

ILLEGAL AXIS COMMAND IN G37 (T series)

The final move command in the blocks specified by P and Q of G70, G71, G72, and G73 ended with chamfering or corner R. Modify the program.

Delete any unnecessary programs, then retry .

fied program number was not found in program number search. Check the data.

200 (option), 400 (option) or 1000 (option). Delete unnecessary programs and execute program registeration again.

The commanded program number has already been used. Change the program number or delete unnecessary programs and execute program registeration again.

Modify the program number.

tected.

includes an M98, G65, or G66 command. Modify the program.

dress P in the block which includes an M98, M99, M65 or G66 was not found. The sequence number specified by a GOTO statement was not found. Otherwise, a called program is being edited in background processing. Correct the program, or discontinue the background editing.

with that read from an external I/O device. Check both the programs in memory and those from the external device.

In the automatic tool length measurement function (G37), the measurement position reach signal (XAE, YAE, or ZAE) is not turned on within an area specified in parameter 6254 6255 (value ε). This is due to a setting or operator error.

In the automatic tool compensation function (G36, G37), the measurement position reach signal (XAE or ZAE) is not turned on within an area specified in parameter 6254 (value ε). This is due to a setting or operator error.

Tool length automatic measurement (G37) was specified without a H code. (Automatic tool length measurement function) Modify the program.

Automatic tool compensation (G36, G37) was specified without a T code. (Automatic tool compensation function) Modify the program.

H code and automatic tool compensation (G37) were specified in the same block. (Automatic tool length measurement function) Modify the program.

T code and automatic tool compensation (G36, G37) were specified in the same block. (Automatic tool compensation function) Modify the program.

In automatic tool length measurement, an invalid axis was specified or the command is incremental. Modify the program.

In automatic tool compensation (G36, G37), an invalid axis was specified or the command is incremental. Modify the program.

840

B–63525EN/02

Number ContentsMessage

085 COMMUNICATION ERROR When entering data in the memory by using Reader / Puncher interface,

086 DR SIGNAL OFF When entering data in the memory by using Reader / Puncher interface,

087 BUFFER OVERFLOW When entering data in the memory by using Reader / Puncher interface,

088 LAN FILE TRANS ERROR

(CHANNEL–1)

089 LAN FILE TRANS ERROR

(CHANNEL–2)

090 REFERENCE RETURN

INCOMPLETE

091 REFERENCE RETURN

INCOMPLETE

092 AXES NOT ON THE REFERENCE

POINT

094 P TYPE NOT ALLOWED

(COORD CHG)

095 P TYPE NOT ALLOWED

(EXT OFS CHG)

096 P TYPE NOT ALLOWED

(WRK OFS CHG)

097 P TYPE NOT ALLOWED

(AUTO EXEC)

098 G28 FOUND IN SEQUENCE

RETURN

099 MDI EXEC NOT ALLOWED

AFT . SEARCH

100 P ARAMETER WRITE ENABLE On the PARAMETER(SETTING) screen, PWE(parameter writing en-

APPENDIX

an overrun, parity or framing error was generated. The number of bits of input data or setting of baud rate or specification No. of I/O unit is incorrect.

the ready signal (DR) of reader / puncher was turned off. Power supply of I/O unit is of f or cable is not connected or a P .C.B. is defective.

though the read terminate command is specified, input is not interrupted after 10 characters read. I/O unit or P.C.B. is defective.

File data transfer via OSI–ETHERNET has been stopped due to a transfer error.

1. The reference position return cannot be performed normally because the reference position return start point is too close to the reference position or the speed is too slow. Separate the start point far enough from the reference position, or specify a sufficiently fast speed for reference position return.

2. During reference position return with the absolute–position detector, if this alarm occurs even though condition 1 is satisfied, do the following: After turning the servo motor for the axis at least one turn, turn the power off and then on again. Then perform reference position return.

Manual reference position return cannot be performed when automatic operation is halted.

The commanded axis by G27 (Reference position return check) did not return to the reference position.

P type cannot be specified when the program is restarted. (After the automatic operation was interrupted, the coordinate system setting operation was performed.) Perform the correct operation according to th operator’s manual.

P type cannot be specified when the program is restarted. (After the automatic operation was interrupted, the external workpiece offset amount changed.) Perform the correct operation according to th operator’s manual.

P type cannot be specified when the program is restarted. (After the automatic operation was interrupted, the workpiece offset amount changed.) Perform the correct operation according to the operator’s manual.

P type cannot be directed when the program is restarted. (After power ON, after emergency stop or P / S 94 to 97 reset, no automatic operation is performed.) Perform automatic operation.

A command of the program restart was specified without the reference position return operation after power ON or emergency stop, and G28 was found during search. Perform the reference position return.

After completion of search in program restart, a move command is given with MDI. Move axis before a move command or don’t interrupt MDI operation.

abled) is set to 1. Set it to 0, then reset the system.

A. ALARM LIST

841

APPENDIXA. ALARM LIST

B–63525EN/02

Number ContentsMessage

101 PLEASE CLEAR MEMORY The power turned off while rewriting the memory by program edit opera-

tion. If this alarm has occurred, press <RESET> while pressing <PROG>, and only the program being edited will be deleted. Register the deleted program.

109 FORMA T ERROR IN G08 A value other than 0 or 1 was specified after P in the G08 code, or no

value was specified.

110 DAT A OVERFLOW The absolute value of fixed decimal point display data exceeds the al-

lowable range. Modify the program.

111 CALCULA TED DATA OVERFLOW The result of calculation turns out to be invalid, an alarm No.111 is is-

sued. –10

to –10

–29

, 0, 10

–29

to 10

Modify the program.

112 DIVIDED BY ZERO Division by zero was specified. (including tan 90°)

Modify the program.

113 IMPROPER COMMAND A function which cannot be used in custom macro is commanded.

Modify the program.

114 FORMAT ERROR IN MACRO There is an error in other formats than <Formula>.

Modify the program.

115 ILLEGAL VARIABLE NUMBER A value not defined as a variable number is designated in the custom

macro or in high–speed cycle machining. The header contents are improper. This alarm is given in the following cases:

High speed cycle machining

1. The header corresponding to the specified machining cycle number called is not found.

2. The cycle connection data value is out of the allowable range (0 – 999).

3. The number of data in the header is out of the allowable range (0 – 32767).

4. The start data variable number of executable format data is out of the allowable range (#20000 – #85535).

5. The last storing data variable number of executable format data is out of the allowable range (#85535).

6. The storing start data variable number of executable format data is overlapped with the variable number used in the header.

Modify the program.

116 WRITE PROTECTED VARIABLE The left side of substitution statement is a variable whose substitution

is inhibited. Modify the program.

118 PARENTHESIS NESTING ERROR The nesting of bracket exceeds the upper limit (quintuple).

Modify the program.

119 ILLEGAL ARGUMENT The SQRT argument is negative. Or BCD argument is negative, and

other values than 0 to 9 are present on each line of BIN argument. Modify the program.

122 FOUR FOLD MACRO MODAL–CALL The macro modal call is specified four fold.

Modify the program.

123 CAN NOT USE MACRO COMMAND

IN DNC

Macro control command is used during DNC operation.

Modify the program. 124 MISSING END ST ATEMENT DO – END does not correspond to 1 : 1. Modify the program. 125 FORMA T ERROR IN MACRO <Formula> format is erroneous. Modify the program. 126 ILLEGAL LOOP NUMBER In DOn, 1x n x3 is not established. Modify the program.

842

B–63525EN/02

135

136

Number ContentsMessage

APPENDIX

A. ALARM LIST

127 NC, MACRO STATEMENT IN SAME

BLOCK

128 ILLEGAL MACRO SEQUENCE

NUMBER

NC and custom macro commands coexist.

Modify the program.

The sequence number specified in the branch command was not 0 to

9999. Or, it cannot be searched. Modify the program.

129 ILLEGAL ARGUMENT ADDRESS An address which is not allowed in <Argument Designation > is used.

Modify the program. 130 ILLEGAL AXIS OPERA TION An axis control command was given by PMC to an axis controlled by

CNC. Or an axis control command was given by CNC to an axis con-

trolled by PMC. Modify the program. 131 TOO MANY EXTERNAL ALARM

MESSAGES

Five or more alarms have generated in external alarm message.

Consult the PMC ladder diagram to find the cause. 132 ALARM NUMBER NOT FOUND No alarm No. concerned exists in external alarm message clear.

Check the PMC ladder diagram. 133 ILLEGAL DA T A IN EXT . ALARM MSG Small section data is erroneous in external alarm message or external

operator message. Check the PMC ladder diagram.

ILLEGAL ANGLE COMMAND (M series)

135

SPINDLE ORIENT ATION PLEASE (T series)

ILLEGAL AXIS COMMAND (M series)

136

C/H–CODE & MOVE CMD IN SAME BLK. (T series)

137 M–CODE & MOVE CMD IN SAME

BLK.

138 SUPERIMPOSED DATA OVER-

FLOW

139 CAN NOT CHANGE PMC CONTROL

AXIS

141 CAN NOT COMMAND G51 IN CRC

(M series)

142 ILLEGAL SCALE RA TE

(M series)

The index table indexing positioning angle was instructed in other than

an integral multiple of the value of the minimum angle.

Modify the program.

Without any spindle orientation , an attept was made for spindle index-

ing. Perform spindle orientation.

In index table indexing.Another control axis was instructed together with

the B axis.

Modify the program.

A move command of other axes was specified to the same block as

spindle indexing addresses C, H. Modify the program.

A move command of other axes was specified to the same block as M–

code related to spindle indexing. Modify the program.

The total distribution amount of the CNC and PMC is too large during

superimposed control of the extended functions for PMC axis control.

An axis is selected in commanding by PMC axis control.

Modify the program.

G51 (Scaling ON) is commanded in the tool offset mode.

Modify the program.

Scaling magnification is commanded in other than 1 – 999999.

Correct the scaling magnification setting (G51 P

. . . . . . . . . . . . . . . . . . . . . .

or parameter 541 1 or 5421). 143 SCALED MOTION DATA OVER-

FLOW (M series)

144 ILLEGAL PLANE SELECTED

(M series)

145 ILLEGAL CONDITIONS IN POLAR

COORDINATE INTERPOLA TION

The scaling results, move distance, coordinate value and circular radius

exceed the maximum command value. Correct the program or scaling

mangification.

The coordinate rotation plane and arc or cutter compensation C plane

must be the same. Modify the program.

The conditions are incorrect when the polar coordinate interpolation

starts or it is canceled.

1) In modes other than G40, G12.1/G13.1 was specified.

2) An error is found in the plane selection. Parameters No. 5460 and No. 5461 are incorrectly specified.

Modify the value of program or parameter.

146 IMPROPER G CODE G codes which cannot be specified in the polar coordinate interpolation

mode was specified. See section II–4.4 and modify the program.

148 ILLEGAL SETTING DA TA

(M series)

Automatic corner override deceleration rate is out of the settable range of judgement angle. Modify the parameters (No.1710 to No.1714)

843

APPENDIXA. ALARM LIST

Number ContentsMessage

149 FORMAT ERROR IN G10L3 A code other than Q1,Q2,P1 or P2 was specified as the life count type

in the extended tool life management.

150 ILLEGAL TOOL GROUP NUMBER Tool Group No. exceeds the maximum allowable value.

Modify the program.

151 TOOL GROUP NUMBER NOT

FOUND

152 NO SP ACE FOR TOOL ENTRY The number of tools within one group exceeds the maximum value re-

153 T–CODE NOT FOUND In tool life data registration, a T code was not specified where one should

154 NOT USING TOOL IN LIFE GROUP

(M series)

155 ILLEGAL T–CODE IN M06

(M series) ILLEGAL T–CODE IN M06

(T series)

156 P/L COMMAND NOT FOUND P and L commands are missing at the head of program in which the tool

157 TOO MANY TOOL GROUPS The number of tool groups to be set exceeds the maximum allowable

158 ILLEGAL TOOL LIFE DATA The tool life to be set is too excessive. Modify the setting value. 159 TOOL DATA SETTING

INCOMPLETE MISMATCH WAITING M–CODE

(T series (At two–path)) MISMATCH WAITING M–CODE

(T series (At three–path))

160

G72.1 NESTING ERROR (M series)

161 ILLEGAL P OF WAITING M–CODE

(T series (three–path control)

G72.1 NESTING ERROR

(M series) 163 169 ILLEGAL TOOL GEOMETRY DATA

175 ILLEGAL G107 COMMAND Conditions when performing circular interpolation start or cancel not

COMMAND G68/G69 INDEPEN-

DENTL Y (T series (At two–path))

(At two–path)

The tool group commanded in the machining program is not set. Modify the value of program or parameter.

gisterable. Modify the number of tools.

be. Correct the program. When the group is not commanded, H99 or D99 was commanded.

Correct the program. In the machining program, M06 and T code in the same block do not cor-

respond to the group in use. Correct the program. Group No.∆∆ which is specified with T∆∆ 88 of the machining program

do not included in the tool group in use. Correct the program.

group is set. Correct the program.

value. (See parameter No. 6800 bit 0 and 1) Modify the program.

During executing a life data setting program, power was turned off. Set again.

Diffrent M code is commanded in heads 1 and 2 as waiting M code. Modify the program.

1) Although the same P command is specified, the waiting M codes do not match.

2) Although the waiting M codes match, the P commands do not match.

3) Two–path wait and three–path wait are specified simultaneously.

Modify the program. A subprogram which performs rotational copy with G72.1 contains

another G72.1 command.

1) The value of address P is a negative value, 1, 2, 4, or a value not smaller than 8.

2) The value specified in P is not consistent with the system configuration.

Modify the program. A subprogram which performs parallel copy with G72.2 contains anoth-

er G72.2 command. G68 and G69 are not independently commanded in balance cut.

Modify the program. Incorrect tool figure data in interference check.

Set correct data, or select correct tool figure data.

correct. T o change the mode to the cylindrical interpolation mode, specify the command in a format of “G07.1 rotation–axis name radius of cylinder.”

B–63525EN/02

844

B–63525EN/02

Number ContentsMessage

APPENDIX

A. ALARM LIST

IMPROPER G–CODE IN G107 (M series)

176

177 CHECK SUM ERROR

178 G05 COMMANDED IN G41/G42

179 P ARAM. (NO. 7510) SETTING

180 COMMUNICATION ERROR

181 FORMAT ERROR IN G81 BLOCK

182 G81 NOT COMMANDED

183 DUPLICA TE G83 (COMMANDS)

184 ILLEGAL COMMAND IN G81

185 RETURN TO REFERENCE POINT

186 P ARAMETER SETTING ERROR

187 HOB COMMAND IS NOT ALLOWED Error in the modal state when G81.4 or G81 is specified

IMPROPER G–CODE IN G107 (T series)

(G05 MODE)

MODE

ERROR

(REMOTE BUF)

(Hobbing machine, EGB) (M series)

(Hobbing machine) (M series)

(Hobbing machine, EGB) (M series)

(Hobbing machine) (M series)

(Hobbing machine, EGB) (M series)

Any of the following G codes which cannot be specified in the cylindrical interpolation mode was specified.

1) G codes for positioning: G28,, G73, G74, G76, G81 – G89, including the codes specifying the rapid traverse cycle

2) G codes for setting a coordinate system: G52,G92,

3) G code for selecting coordinate system: G53 G54–G59

Modify the program. Any of the following G codes which cannot be specified in the cylindrical

interpolation mode was specified.

1) G codes for positioning: G28, G76, G81 – G89, including the codes specifying the rapid traverse cycle

2) G codes for setting a coordinate system: G50, G52

3) G code for selecting coordinate system: G53 G54–G59

Modify the program. Check sum error

Modify the program. G05 was commanded in the G41/G42 mode.

Correct the program. The number of controlled axes set by the parameter 7510 exceeds the

maximum number. Modify the parameter setting value. Remote buffer connection alarm has generated. Confirm the number of

cables, parameters and I/O device. G81 block format error (hobbing machine)

1) T (number of teeth) has not been instructed.

2) Data outside the command range was instructed by either T, L, Q or P.

3) An overflow occurred in synchronization coefficient calculation.

Modify the program. G83 (C axis servo lag quantity offset) was instructed though synchro-

nization by G81 has not been instructed. Correct the program. (hobbing machine)

G83 was instructed before canceled by G82 after compensating for the C axis servo lag quantity by G83. (hobbing machine)

A command not to be instructed during synchronization by G81 was instructed. (hobbing machine)

1) A C axis command by G00, G27, G28, G29, G30, etc. was instructed.

2) Inch/Metric switching by G20, G21 was instructed.

G81 was instructed without performing reference position return after power on or emergency stop. (hobbing machine) Perform reference position return.

Parameter error regarding G81 (hobbing machine)

1) The C axis has not been set to be a rotary axis.

2) A hob axis and position coder gear ratio setting error

Modify the parameter.

1. The canned cycle mode (G81 to G89) is set.

2. The thread cutting mode is set.

3. The C–axis is under synchronous, composite, or superimposed control.

845

APPENDIXA. ALARM LIST

Number ContentsMessage

190 ILLEGAL AXIS SELECT In the constant surface speed control, the axis specification is wrong.

(See parameter No. 3770.) The specified axis command (P) contains an illegal value. Correct the program.

194 SPINDLE COMMAND IN

SYNCHRO–MODE

197 C–AXIS COMMANDED IN SPINDLE

MODE

199 MACRO WORD UNDEFINED Undefined macro word was used. Modify the custom macro. 200 ILLEGAL S CODE COMMAND In the rigid tap, an S value is out of the range or is not specified.

201 FEEDRATE NOT FOUND IN RIGID

TAP 202 POSITION LSI OVERFLOW In the rigid tap, spindle distribution value is too large. (System error) 203 PROGRAM MISS A T RIGID T APPING In the rigid tap, position for a rigid M code (M29) or an S command is in-

204 ILLEGAL AXIS OPERA TION In the rigid tap, an axis movement is specified between the rigid M code

205 RIGID MODE DI SIGNAL OFF 1.Although a rigid M code (M29) is specified in rigid tapping, the rigid

206 CAN NOT CHANGE PLANE

(M series) 207 RIGID DA T A MISMATCH The specified distance was too short or too long in rigid tapping. 210 CAN NOT COMAND M198/M199 M98 and M99 are executed in the schedule operation. M198 is

211 G31 (HIGH) NOT ALLOWED IN G99

(T series)

ILLEGAL PLANE SELECT 212

(M series)

ILLEGAL PLANE SELECT

(T series)

A contour control mode, spindle positioning (Cs–axis control) mode, or rigid tapping mode was specified during the serial spindle synchronous control mode. Correct the program so that the serial spindle synchronous control mode is released in advance.

The program specified a movement along the Cs–axis when the signal CON(DGN=G027#7) was off. Correct the program, or consult the PMC ladder diagram to find the reason the signal is not turned on.

Modify the program. In the rigid tap, no F value is specified.

Correct the program.

correct. Modify the program.

(M29) block and G84 or G74 for M series (G84 or G88 for T series) block. Modify the program.

mode DI signal (DGN G061.0) is not ON during execution of the G84 (G88) block.

2. In a system with the multi–spindle option, the spindle used for rigid tapping is not selected (by DI signal G27#0 and #1, or G61#4 and #5).

Check the PMC ladder diagram to find the reason why the DI signal is not turned on.

Plane changeover was instructed in the rigid mode. Correct the program.

executed in the DNC operation. Modify the program.

1) The execution of an M198 or M99 command was attempted during

scheduled operation. Alternatively, the execution of an M198 command was attempted during DNC operation. Correct the program. The execution of an M99 command was attempted by an interrupt macro during pocket machining in a multiple repetitive canned cycle.

G31 is commanded in the per revolution command when the high– speed skip option is provided. Modify the program.

The arbitrary angle chamfering or a corner R is commanded or the plane including an additional axis. Correct the program.

The direct drawing dimensions programming is commanded for the plane other than the Z–X plane. Correct the program.

B–63525EN/02

846

B–63525EN/02

Number ContentsMessage

APPENDIX

A. ALARM LIST

213 ILLEGAL COMMAND IN

SYNCHRO–MODE (M series)

ILLEGAL COMMAND IN SYNCHRO–MODE (T series)

214 ILLEGAL COMMAND IN

SYNCHRO–MODE

217 DUPLICA TE G51.2 (COMMANDS)

(T series)

218 NOT FOUND P/Q COMMAND IN

G251 (T series)

219 COMMAND G250/G251

INDEPENDENTL Y (T series)

220 ILLEGAL COMMAND IN

SYNCHR–MODE (T series)

221 ILLEGAL COMMAND IN

SYNCHR–MODE (T series)

222 DNC OP. NOT ALLOWED IN

BG.–EDIT (M series)

224 RETURN TO REFERENCE POINT

(M series)

TURN TO REFERENCE POINT (T series)

225 SYNCHRONOUS/MIXED CONTROL

ERROR (T series (At two–path))

226 ILLEGAL COMMAND IN SYNCHRO–

MODE (T series (At two–path))

229 CAN NOT KEEP SYNCHRO–STATE

(T series)

230 R CODE NOT FOUND

(Grinding machine) (M series)

Movement is commanded for the axis to be synchronously controlled. Any of the following alarms occurred in the operation with the simple synchronization control.

1) The program issued the move command to the slave axis.

2) The program issued the manual continuous feed/manual handle

feed/incremental feed command to the slave axis.

3) The program issued the automatic reference position return com-

mand without specifying the manual reference position return after the power was turned on.

4) The difference between the position error amount of the master and

slave axes exceeded the value specified in parameter NO.8313.

A move command has been specified for an axis subject to synchronous control.

Coordinate system is set or tool compensation of the shift type is executed in the synchronous control. Correct the program.

G51.2/G251 is further commanded in the G51.2/G251 mode. Modify the program.

P or Q is not commanded in the G251 block, or the command value is out of the range. Modify the program.

G251 and G250 are not independent blocks.

In the synchronous operation, movement is commanded by the NC program or PMC axis control interface for the synchronous axis.

Polygon machining synchronous operation and axis control or balance cutting are executed at a time. Modify the program.

Input and output are executed at a time in the background edition. Execute a correct operation.

Reference position return has not been performed before the automatic operation starts. Perform reference position return only when bit 0 of parameter 1005 is 0.

Reference position return is necessary before cycle start.

This alarm is generated in the following circumstances. (Searched for during synchronous and mixed control command.

1 When there is a mistake in axis number parameter (No. 1023) set-

ting. 2 When there is a mistake in control commanded. During hobbing synchronization, a command to bring the C–axis under

synchronous, composite, or superimposed control is made. Modify the program or the parameter. A travel command has been sent to the axis being synchronized in syn-

chronous mode. Modify the program or the parameter. This alarm is generated in the following circumstances. 1 When the synchro/mixed state could not be kept due to system over-

load. 2 The above condition occurred in CMC devices (hardware) and syn-

chro–state could not be kept. (This alarm is not generated in normal use conditions.) The infeed quantity R has not been instructed for the G161 block. Or

the R command value is negative. Correct the program.

847

APPENDIXA. ALARM LIST

Number ContentsMessage

231 ILLEGAL FORMAT IN G10 OR L50 Any of the following errors occurred in the specified format at the pro-

grammable–parameter input. 1 Address N or R was not entered. 2 A number not specified for a parameter was entered. 3 The axis number was too large. 4 An axis number was not specified in the axis–type parameter . 5 An axis number was specified in the parameter which is not an axis

type. Correct the program.

6 In the locked state set by the password function, an attempt was

made to set bit 4 (NE9) of parameter No. 3204 to 0 or change the contents of parameter No. 3210.

7 An attempt was made to change a program encryption parameter

(parameter No. 3220 to 3223).

232 TOO MANY HELICAL AXIS

COMMANDS

233 DEVICE BUSY When an attempt was made to use a unit such as that connected via the

239 BP/S ALARM While punching was being performed with the function for controlling ex-

240 BP/S ALARM Background editing was performed during MDI operation. 241 ILLEGAL FORMA T IN G02.2/G03.2

(M series)

242 ILLEGAL COMMAND IN

G02.2/G03.2 (M series)

243 OVER TOLERANCE OF END POINT

(M series)

244 P/S ALARM

(T series)

245 T–CODE NOT ALOWEE IN THIS

BLOCK (T series)

246 ENCODE PROGRAM

NUMBER ERROR

247 ILLEGAL CODE USED

FOR OUTPUT

250 Z AXIS WRONG COMMAND (A TC)

(M series)

Three or more axes (in the normal direction control mode (M series) two or more axes) were specified as helical axes in the helical interpolation mode.

RS–232–C interface, other users were using it.

ternal I/O units ,background editing was performed.

The end point, I, J, K, or R is missing from a command for involute interpolation.

An invalid value has been specified for involute interpolation.

S The start or end point is within the basic circle. S I, J, K, or R is set to 0. S The number of rotations between the start of the involute curve and

the start or end point exceeds 100.

The end point is not on the involute curve which includes the start point and thus falls outside the range specified with parameter No. 5610.

In the skip function activated by the torque limit signal, the number of accumulated erroneous pulses exceed 32767 before the signal was input. Therefore, the pulses cannot be corrected with one distribution. Change the conditions, such as feed rates along axes and torque limit, and try again.

One of the G codes, G50, G10, and G04, which cannot be specified in the same block as a T code, was specified with a T code.

During read of an encrypted program, an attempt was made to store the program with a number exceeding the protection range. (See parameter Nos. 3222 and 223.)

When an encrypted program is output, EIA is set for the punch code. Specify ISO.

Movement along the Z–axis is specified in a block specifying a tool change command (M06T_). (Only for ROBODRILL)

B–63525EN/02

848

B–63525EN/02

Number ContentsMessage

APPENDIX

A. ALARM LIST

251 A TC ERROR

(M series)

252 A TC SPINDLE ALARM

(M series)

253 G05 IS NOT A VAILABLE

(M series)

4500 REPOSITIONING INHIBITED A repositioning command was specified in the circular interpolation

4502 ILLEGAL COMMAND IN BOLT

HOLE

4503 ILLEGAL COMMAND IN LINE AT

ANGLE

4504 ILLEGAL COMMAND IN ARC In an arc (G77) command, the radius (I) or the number of holes (K) was

4505 ILLEGAL COMMAND IN GRID In a grid (G78, G79) command, the number of holes (P, K) was set to

4506 ILLEGAL COMMAND IN SHARE

PROOFS

4507 ILLEGAL COMMAND IN SQUARE In a square (G87) command, the tool size (P,Q) was set to zero or a neg-

4508 ILLEGAL COMMAND IN RADIUS In a radius (G88) command, the traveling pitch (Q) or radius (I) was set

4509 ILLEGAL COMMAND IN CUT AT

ANGLE

4510 ILLEGAL COMMAND IN

LINE-PUNCH

This alarm is issued in the following cases:

S An M06T_ command contains an unusable T code. S An M06 command has been specified when the Z machine coordi

nate is positive.

S The parameter for the current tool number (No. 7810) is set to 0. S An M06 command has been specified in canned cycle mode. S A reference position return command (G27 to G44) and M06 com-

mand have been specified in the same block.

S An M06 command has been specified in tool compensation mode

(G41 to G44).

S An M06 command has been specified without performing reference

position return after power–on or the release of emergency stop.

S The machine lock signal or Z–axis ignore signal has been turned on

during tool exchange. S A pry alarm has been detected during tool exchange. Refer to diagnosis No. 530 to determine the cause. (Only for ROBO-

DRILL) An excessive error arose during spindle positioning for A TC. For details,

refer to diagnosis No. 531. (Only for ROBODRILL) Alarm details

Binary input operation using high–speed remote buffer (G05) or high– speed cycle machining (G05) has been specified in advance control mode (G08P1). Execute G08P0; to cancel advance control mode, before executing these G05 commands.

(G02, G03) mode. In a bolt hole circle (G26) command, the radius (I) was set to zero or a

negative value, or the number of holes (K) was set to zero. Alternatively, I, J, or K was not specified.

In a line-at-angle (G76) command, the number of holes (K) was set to zero or a negative value. Alternatively , I, J, or K was not specified.

set to zero or a negative value. Alternatively , I, J, K, or P was not specified.

zero or a negative value. Alternatively , I, J, K, or P was not specified. In a shear proof (G86) command, the tool size (P) was set to zero, or the

blanking length (I) was 1.5 times larger than the tool size (P) or less. Alternatively, I, J, or P was not specified.

ative value, or the blanking length (I, J) was three times larger than the tool size (P, Q) or less. Alternatively , I, J, P, or Q was not specified.

to zero or a negative value, or the traveling pitch (Q) was greater than or equal to the arc length. Alternatively , I, J, K, P , or Q was not specified.

In a cut-at-angle (G89) command, the traveling pitch (Q) was set to zero, negative value, or another value larger than or equal to the length (I). Alternatively, I, J, P, or Q was not specified.

In a linear punching (G45) command, the traveling distance was set to zero or a value 1.5 times larger than the tool size (P) or less. Alternatively , P was not specified.

849

Number ContentsMessage

APPENDIXA. ALARM LIST

B–63525EN/02

4511 ILLEGAL COMMAND IN

CIRCLE-PUNCH

4520 T , M INHIBITED IN

NIBBLING-MODE

4521 EXCESS NIBBLING MOVEMENT

(X, Y)

4522 EXCESS NIBBLING MOVEMENT

(C)

4523 ILLEGAL COMMAND IN

CIRCLE-NIBBL

4524 ILLEGAL COMMAND IN

LINE-NIBBL

4530 A/B MACRO NUMBER ERROR The number for storing and calling by an A or B macro was set to a value

4531 U/V MACRO FORMAT ERROR An attempt was made to store a macro while storing another macro us-

4532 IMPROPER U/V MACRO NUMBER The number of an inhibited macro (number beyond the range from 01

4533 U/V MACRO MEMORY OVERFLOW An attempt was made to store too many macros with a U or V macro

4534 W MACRO NUMBER NOT FOUND Macro number W specified in a U or V macro command is not stored. 4535 U/V MACRO NESTING ERROR An attempt was made to call a macro which is defined three times or

4536 NO W, Q COMMAND IN

MULTI-PIECE

4537 ILLEGAL Q VALUE IN MULTI-PIECE In the command for taking multiple workpieces (G73, G74), Q is set to

4538 W NO. NOT FOUND IN

MULTI-PIECE

4539 MULTI-PIECE SETTING IS ZERO The command for taking multiple workpieces (G73, G74) was specified

4540 MULTI-PIECE COMMAND WITHIN

MACRO

4542 MULTI-PIECE COMMAND ERROR Although G98P0 was specified, the G73 command was issued.

In a circular punching (G46, G47) command, the same position was specified for both start and end points of the arc, radius (R) of the arc was set to zero, or the pitch (Q) was set to a value exceeding the arc length. Alternatively, R or Q was not specified.

T code, M code, G04, G70 or G75 was specified in the nibbling mode.

In the nibbling mode, the X-axis or Y -axis traveling distance was larger than or equal to the limit (No. 16188 to 16193).

In the circular nibbling (G68) or usual nibbling mode, the C-axis traveling distance was larger than or equal to the limit (No. 16194).

In a circular nibbling (G68) command, the traveling pitch (Q) was set to zero, a negative value, or a value larger than or equal to the limit (No. 16186, 16187), or the radius (I) was set to zero or a negative value. Alternatively, I, J, K, P, or Q was not specified.

In a linear nibbling (G69) command, the traveling pitch (Q) was set to zero, negative value, or a value larger than or equal to the limit (No. 16186, 16187). Alternatively , I, J, P, or Q was not specified.

beyond the range from 1 to 5.

ing a U or V macro. A V macro was specified although the processing to store a macro was

not in progress. A U macro number and V macro number do not correspond with each other.

to 99) was specified in a U or V macro command.

command.

more using a U or V macro command. An attempt was made to store 15 or more macros in the storage area

for macros of number 90 to 99. W or Q was not specified in the command for taking multiple workpieces

(G73, G74).

a value beyond the range from 1 to 4. Macro number W specified in the command for taking multiple work-

pieces (G73, G74) is not stored.

although zero is specified for the function to take multiple workpieces (No. 16206 or signals MLP1 and MLP2 (PMC address G231, #0 and #1)).

The command for taking multiple workpieces (G73, G74) was specified when a U or V macro was being stored.

Although G98K0 was specified, the G74 command was issued.

850

B–63525EN/02

Number ContentsMessage

APPENDIX

A. ALARM LIST

4543 MULTI-PIECE Q COMMAND

ERROR

4544 MULTI-PIECE RESTART ERROR In the command for resuming taking multiple workpieces, the resume

4549 ILLEGAL TOOL DATA FORMAT The quantity of tool data patterns to be saved is too large to fit the usable

4600 T , C COMMAND IN

INTERPOLATION 4601 INHIBITED T, M COMMAND In the block of G52, G72, G73, or G74, a T or M command was specified. 4602 ILLEGAL T-CODE The specified T command is not cataloged on the tool register screen. 4603 C AXIS SYNCHRONOUS ERROR The difference between the position deviation value of C1 axis and C2

4604 ILLEGAL AXIS OPERATION A C-axis command was specified in the block containing a T command

4605 NEED ZRN C–axis synchronization failed. 4630 ILLEGAL COMMAND IN LASER

MODE

4650 IMPROPER G-CODE IN OFFSET

MODE 4700 PROGRAM ERROR (OT +) The value specified in the X-axis move command exceeded the positive

4701 PROGRAM ERROR (OT –) The value specified in the X-axis move command exceeded the nega-

4702 PROGRAM ERROR (OT +) The value specified in the Y-axis move command exceeded the positive

4703 PROGRAM ERROR (OT –) The value specified in the Y-axis move command exceeded the nega-

4704 PROGRAM ERROR (OT +) The value specified in the Z-axis move command exceeded the positive

4705 PROGRAM ERROR (OT –) The value specified in the Z-axis move command exceeded the nega-

5000 ILLEGAL COMMAND CODE

(M series) 5003 ILLEGAL PARAMETER (HPCC)

(M series) 5004 HPCC NOT READY (M series) High–precision contour control is not ready . 5006 TOO MANY WORD IN ONE BLOCK

(M series) 5007 TOO LARGE DISTANCE (M series) In the HPCC mode, the machine moved beyond the limit. 5009 PARAMETER ZERO (DR Y RUN)

(M series) 5010 END OF RECORD The end of record (%) was specified.

Although G98P0 was specified, the Q value for the G74 command was not 1 or 3. Although G98K0 was specified, the Q value for the G73 command was not 1 or 2.

position (P) is set to a value beyond the range from 1 to total number of workpieces to be machined.

area (16 KB). In the linear interpolation (G01) mode or circular interpolation (G02,

G03) mode, a T command or C-axis command was specified.

axis exceeds the parameter value (No. 16364, 16365) with the C–axis synchronous control function.

for multiple tools.

In the laser mode, a nibbling command or pattern command was specified. In the tracing mode, an attempt was made to make a switch to the punching mode.

In the cutter compensation mode, an inhibited G code (pattern command, G73, G74, G75, etc.) was specified.

value of stored stroke limit 1. (Advance check)

tive value of stored stroke limit 1. (Advance check)

value of stored stroke limit 1. (Advance check)

tive value of stored stroke limit 1. (Advance check)

value of stored stroke limit 1. (Advance check)

tive value of stored stroke limit 1. (Advance check) The specified code was incorrect in the high–precision contour control

(HPCC) mode. There is an invalid parameter.

The number of words specified in a block exceeded 26 in the HPCC mode.

The maximum feedrate (parameter No. 1422) or the feedrate in dry run (parameter No. 1410) is 0 in the HPCC model.

I/O is incorrect. modify the program.

851

Number ContentsMessage

APPENDIXA. ALARM LIST

B–63525EN/02

5011 PARAMETER ZERO(CUT MAX)

(M series) 5012 G05 P10000 ILLEGAL START UP

(HPCC)

(M series)

5013 HPCC: CRC OFS REMAIN AT CAN-

CEL (M series) 5014 TRACE DATA NOT FOUND T ransfer cannot be performed because no trace data exists. 5015 NO ROTATION AXIS

(M series) 5016 ILLEGAL COMBINATION OF M

CODE

5018 POLYGON SPINDLE SPEED ER-

ROR

(T series)

5020 PARAMETER OF RESTART ERROR An erroneous parameter was specified for restarting a program.

5030 ILLEGAL COMMAND (G100)

(T series) 5031 ILLEGAL COMMAND (G100, G102,

G103) (T series)

5032 NEW PRG REGISTERED IN B–AXS

MOVE (T series) 5033 NO PROG SPACE IN MEMORY B–

AXS (T series) 5034 PLURAL COMMAND IN G110

(T series) 5035 NO FEEDRATE COMMANDED B–

AXS (T series) 5036 ADDRESS R NOT DEFINED IN

G81–G86 (T series) 5037 ADDRESS Q NOT DEFINED IN G83

(T series) 5038 TOO MANY START M–CODE COM-

MAND (T series) 5039 START UNREGISTERED B–AXS

PROG (T series) 5040 CAN NOT COMMANDED B–AXS

MOVE (T series)

5041 CAN NOT COMMANDED G110

BLOCK (T series)

The maximum cutting feedrate (parameter No. 1422, No. 1430, No. 1431, No. 1432) is 0 in the HPCC mode.

Function category: High–precision contour control Alarm details: G05 P10000 has been specified in a mode from which the system cannot enter HPCC mode.

G05P0 has been specified in G41/G42 mode or with offset remaining.

The specified rotation axis does not exist for tool axis direction handle feed.

M codes which belonged to the same group were specified in a block. Alternatively ,an M code which must be specified without other M codes in the block was specified in a block with other M codes.

Function category: Polygon turning Alarm details: In G51.2 mode, the speed of the spindle or polygon synchronous axis either exceeds the clamp value or is too small. The specified rotation speed ratio thus cannot be maintained.

A parameter for program restart is invalid. The end command (G110) was specified before the registratioin start

command (G101, G102, or G103) was specified for the B–axis. While a registration start command (G101, G102, or G103) was being

executed, another registration start command was specified for the B– axis.

While the machine was moving about the B–axis, at attempt was made to register another move command.

Commands for movement about the B–axis were not registered because of insufficient program memory.

Multiple movements were specified with the G1 10 code for the B–axis.

A feedrate was not specified for cutting feed about the B–axis.

Point R was not specified for the canned cycle for the B–axis.

Depth of cut Q was not specified for the G83 code (peck drilling cycle). Alternatively, 0 was specified in Q for the B–axis.

More than six M codes for starting movement about the B–axis were specified.

An attempt was made to execute a program for the B–axis which had not been registered.

The machine could not move about the B–axis because parameter No.8250 was incorrectly specified, or because the PMC axis system could not be used.

Blocks containing the G1 10 codes were successively specified in tool– tip radius compensation for the B–axis.

852

B–63525EN/02

Number ContentsMessage

APPENDIX

A. ALARM LIST

5043 TOO MANY G68 NESTING

(M series)

TOO MANY G68 NESTING

(T series) 5044 G68 FORMAT ERROR

(M series)

G68 FORMA T ERROR

(T series)

5046 ILLEGAL PARAMETER (ST.COMP) The parameter settings for straightness compensation contain an error.

5050 ILL–COMMAND IN CHOPPING

MODE

(M series) 5051 M–NET CODE ERROR Abnormal character received (other than code used for transmission) 5052 M–NET ETX ERROR Abnormal ETX code 5053 M–NET CONNECT ERROR Connection time monitoring error (parameter No. 175) 5054 M–NET RECEIVE ERROR Polling time monitoring error (parameter No. 176) 5055 M–NET PRT/FRT ERROR Vertical parity or framing error 5057 M–NET BOARD SYSTEM DOWN Transmission timeout error (parameter No. 177)

5058 G35/G36 FORMAT ERROR

(T series)

5059 RADIUS IS OUT OF RANGE A radius exceeding nine digits has been specified for circular interpola-

Three–dimensional coordinate conversion G68 has been specified three or more times.

Three–dimensional coordinate conversion G68.1 has been specified three or more times.

A G68 command block contains a format error. This alarm is issued in the following cases:

1. I, J, or K is missing from a G68 command block (missing coordinate rotation option).

2. I, J, and K are 0 in a G68 command block.

3. R is missing from a G68 command block.

A G68.1 command block contains a format error. This alarm is issued in the following cases:

1. I, J, or K is missing from a G68.1 command block (missing coordinate rotation option).

2. I, J, and K are 0 in a G68.1 command block.

3. R is missing from a G68.1 command block.

Possible causes are as follows:

1. A parameter for a movement axis or compensation axis contains an axis number which is not used.

2. More than 128 pitch error compensation points exist between the negative and positive end points.

3. Compensation point numbers for straightness compensation are not assigned in the correct order.

4. No straightness compensation point exists between the pitch error compensation points at the negative and positive ends.

5. The compensation value for each compensation point is too large or too small.

6 The settings of parameters Nos. 13881 to 13886 are illegal (in the

interpolation type straightness compensation).

A command for switching the major axis has been specified for circular threading. Alternatively, a command for setting the length of the major axis to 0 has been specified for circular threading.

ROM parity error CPU interrupt other than the above

A command for switching the major axis has been specified for circular threading. Alternatively, a command for setting the length of the major axis to 0 has been specified for circular threading.

tion with the center of the arc specified with I, J, and K.

853

Number ContentsMessage

APPENDIXA. ALARM LIST

B–63525EN/02

5060 ILLEGAL PARAMETER IN

G02.3/G03.3 (M series)

5061 ILLEGAL FORMAT IN G02.3/G03.3

(M series)

5062 ILLEGAL COMMAND IN

G02.3/G03.3

5063 IS NOT PRESET AFTER REF.

(M series)

5064 DIFFERRENT AXIS UNIT (IS–B,

IS–C) (M series)

5065 DIFFERENT AXIS UNIT (PMC AXIS)

(M series)

5067 G05 PO COMMANDED IN G68/G51

MODE (HPCC) (M series)

5068 G31 FORMAT ERROR

(M series)

5069 WHL–C:ILLEGA

P–DATA (M series)

5073 NO DECIMAL POINT No decimal point has been specified for an address requiring a decimal

5074 ADDRESS DUPLICA TION ERROR The same address has been specified two or more times in a single

5082 DATA SERVER ERROR This alarm is detailed on the data server message screen.

There is a parameter setting error. Parameter No. 5641 (setting of the linear axis) is not set. The axis set in parameter No. 5641 is not a linear axis. Parameter No. 5642 (setting of a rotation axis) is not set. The axis set in parameter No. 5642 is not a rotation axis. The linear and rotation axes cannot be controlled by the CNC. (The value set in parameter No. 1010 is exceeded.)

The exponential interpolation command (G02.3/G03.3) has a format error. Address I, J, or K is not specified. The value of address I, J, or K is 0.

The value specified in an exponential interpolation command (G02.3/03.3) is illegal. A value that does not allow exponential interpolation is specified. (For example, a negative value is specified in In.)

Function category: Workpiece thickness measurement Alarm details The position counter was not preset before the start of workpiece thickness measurement. This alarm is issued in the following cases:

(1) An attempt has been made to start measurement without first estab-

lishing the origin.

(2) An attempt has been made to start measurement without first pre-

setting the position counter after manual return to the origin.

Circular interpolation has been specified on a plane consisting of axes having different increment systems.

Axes having different increment systems have been specified in the same DI/DO group for PMC axis control. Modify the setting of parameter No. 8010.

HPCC mode cannot be canceled during G51 (scaling) or G68 (coordinate system rotation). Correct the program.

The continuous high–speed skip command (G31 P90) has one of the following errors:

1. The axis along which the tool is moved is not specified.

2. More than one axis is specified as the axis along which the tool is moved.

Alternatively, the EGB skip command (G31.8) or continuous high– speed skip command (G31.9) has one of the following errors:

1. A move command is specified for the EGB axis (workpiece axis).

2. More than one axis is specified.

3. P is not specified.

4. The specified Q value exceeds the allowable range.

Correct the program. The P data in selection of the grinding–wheel wear compensation cen-

ter is illegal.

point.

block. Alternatively , two or more G codes in the same group have been specified in a single block.

854

B–63525EN/02

Number ContentsMessage

5085 SMOOTH IPL ERROR 1 A block for specifying smooth interpolation contains a syntax error. 5096 MISMA TCH W AITING M–CODE

(M series)

5110 NOT STOP POSITION

(G05.1 G1) (M series)

NOT STOP POSITION (G05.1 G1) (21i–M)

5111 IMPROPER MODEL G–CODE

(G05.1 G1) (M series)

IMPROPER MODEL G–CODE (G05.1 G1) (21i–M)

5112 G08 CAN NOT BE COMMANDED

(G05.1 G1) (M series)

G08 CAN NOT BE COMMANDED (G05.1 G1) (21i–M)

5114 NOT STOP POSITION

(G05.1 Q1) (M series)

CAN NOT ERROR IN MDI MODE (G05.1) (21i–M)

5115 SPL : ERROR There is an error in the specification of the rank.

(M series)

5116 SPL : ERROR There is a program error in a block under look–ahead control.

(M series)

5117 SPL : ERROR

(M series)

5118 SPL : ERROR

(M series)

APPENDIX

Different wait codes (M codes) were specified in HEAD1 and HEAD2. Correct the program.

An illegal G code was specified in AI contour control mode. A command was specified for the index table indexing axis in AI control mode.

An illegal G code was specified in AI look–ahead control mode. A command was specified for the index table indexing axis in AI look– ahead control mode.

An illegal G code is left modal when AI contour control mode was specified.

An illegal G code is left modal when AI look–ahead control mode was specified.

Look–ahead control (G08) was specified in AI contour control mode.

Look–ahead control (G08) was specified in AI look–ahead control mode.

At the time of restart after manual intervention, the coordinates at which the manual intervention occurred have not been restored.

AI contour control (G05.1) was specified in MDI mode.

No knot is specified. The knot specification has an error. The number of axes exceeds the limits. Other program errors

Monotone increasing of knots is not observed. In NURBS interpolation mode, a mode that cannot be used together is

specified. The first control point of NURBS is incorrect.

After manual intervention with manual absolute mode set to on, NURBS interpolation was restarted.

A. ALARM LIST

855

Number ContentsMessage

APPENDIXA. ALARM LIST

B–63525EN/02

5122 ILLEGAL COMMAND IN SPIRAL

(M series)

5123 OVER TOLERANCE OF END POINT

(M series)

5124 CAN NOT COMMAND SPIRAL

(M series)

5134 FSSB : OPEN READY TIME OUT Initialization did not place FSSB in the open ready state. 5135 FSSB : ERROR MODE FSSB has entered error mode. 5136 FSSB : NUMBER OF AMPS IS SMALL In comparison with the number of controlled axes, the number of amplifi-

5137 FSSB : CONFIGURATION ERROR FSSB detected a configuration error. 5138 FSSB : AXIS SETTING NOT COM-

PLETE

5139 FSSB : ERROR Servo initialization did not terminate normally .

5155 NOT RESTART PROGRAM BY G05 During servo leaning control by G05, an attempt was made to perform

5156 ILLEGAL AXIS OPERATION

(AICC) (M series)

ILLEGAL AXIS OPERA TION (AICC) (21i–M)

5157 PARAMETER ZERO (AICC)

(M series)

A spiral interpolation or conical interpolation command has an error. Specifically, this error is caused by one of the following:

1) L = 0 is specified.

2) Q = 0 is specified.

3) R/, R/, C is specified.

4) Zero is specified as height increment.

5) Three or more axes are specified as the height axes.

6) A height increment is specified when there are two height axes.

7) Conical interpolation is specified when the helical interpolation

function is not selected.

8) Q < 0 is specified when radius difference > 0.

9) Q > 0 is specified when radius difference < 0.

10) A height increment is specified when no height axis is specified.

The difference between a specified end point and the calculated end point exceeds the allowable range (parameter 3471).

A spiral interpolation or conical interpolation was specified in any of the following modes:

1) Scaling

2) Programmable mirror image

3) Polar coordinate interpolation

In cutter compensation C mode, the center is set as the start point or end point.

ers recognized by FSSB is not enough.

In automatic setting mode, axis setting has not been made yet. Perform axis setting on the FSSB setting screen.

The optical cable may be defective, or there may be an error in connection to the amplifier or another module. Check the optical cable and the connection status.

restart operation after feed hold or interlock. This restart operation cannot be performed. (G05 leaning control terminates at the same time.)

In AI contour control mode, the controlled axis selection signal (PMC axis control) changes. In AI contour control mode, the simple synchonous axis selection signal changes.

In AI look–ahead control mode, the controlled axis selection signal (PMC axis control) changes. In AI look–ahead control mode, the simple synchonous axis selection signal changes.

Zero is set in the parameter for the maximum cutting feedrate (parameter No. 1422 or 1432). Zero is set in the parameter for the acceleration/deceleration before interpolation (parameter No. 1770 or 1771). Set the parameter correctly .

856

B–63525EN/02

Number ContentsMessage

APPENDIX

A. ALARM LIST

5195 DIRECTION CAN NOT BE JUDGED

(T series)

5196 ILLEGAL OPERATION (HPCC)

(M series)

5197 FSSB : OPEN TIME OUT The CNC permitted FSSB to open, but FSSB was not opened. 5198 FSSB : ID DATA NOT READ T emporary assignment failed, so amplifier initial ID information could not

5199 FINE TORQUE SENSING PARAME-

TER

5212 SCREEN COPY : PARAMETER ER-

ROR

5213 SCREEN COPY : COMMUNICA TION

ERROR

5214 SCREEN COPY : DATA TRANSFER

ERROR

5218 ILLEGAL PARAMETER (INCL.

COMP)

5219 CAN NOT RETURN Manual intervention or return is not allowed during three–dimensional

5220 REFERENCE POINT ADJUSTMENT

MODE

5222 SRAM CORRECTABLE ERROR The SRAM correctable error cannot be corrected.

When the touch sensor with a single contact signal input is used in the direct input B function for tool offset measurement values, the stored pulse direction is not constant. One of the following conditions exists:

· The stop state exists in offset write mode.

· Servo of f state

· The direction varies.

· Movement takes place simultaneously along two axes.

Detach operation was performed in HPCC mode. (If detach operation is performed in HPCC mode, this alarm is issued after the currently executed block terminates.)

be read. A parameter related to the fine torque sensing function is illegal.

· The storage interval is invalid.

· An invalid axis number is set as the target axis.

Correct the parameter. There is a parameter setting error. Check that 4 is set as the I/O channel.

The memory card cannot be used. Check the memory card. (Check whether the memory card is write–protected or defective.)

Data transfer to the memory card failed. Check whether the memory card space is insufficient and whether the memory card was removed during data transfer.

There is an inclination compensation parameter setting error. Cause:

1. The number of pitch error compensation points between the negative (–) end and positive (+) end exceeds 128.

2. The relationship in magnitude among the inclination compensation point numbers is incorrect.

3. An inclination compensation point is not located between the negative (–) end and positive (+) end of the pitch error compensation points.

4. The amount of compensation per compensation point is too large or too small.

Correct the parameter.

coordinate conversion. A parameter for automatically set a reference position is set. (Bit 2 of

parameter No. 1819 = 1) Perform automatic setting. (Position the machine at the reference position manually , then perform manual reference position return.) Supplementary: Automatic setting sets bit 2 of parameter No. 1819 to

Cause: A memory problem occurred during memory initialization. Action: Replace the master printed circuit board (SRAM module).

857

APPENDIXA. ALARM LIST

Number ContentsMessage

5227 FILE NOT FOUND A specified file is not found during communication with the built–in

Handy File. 5228 SAME NAME USED There are duplicate file names in the built–in Handy File. 5229 WRITE PROTECTED A floppy disk in the built–in Handy File is write protected. 5231 TOO MANY FILES The number of files exceeds the limit during communication with the

built–in Handy File. 5232 DATA OVER–FLOW There is not enough floppy disk space in the built–in Handy File. 5235 COMMUNICA TION ERROR A communication error occurred during communication with the built–in

Handy File. 5237 READ ERROR A floppy disk in the built–in Handy File cannot be read from. The floppy

disk may be defective, or the head may be dirty. Alternatively , the Handy

File is defective. 5238 WRITE ERROR A floppy disk in the built–in Handy File cannot be written to. The floppy

disk may be defective, or the head may be dirty. Alternatively , the Handy

File is defective. 5242 ILLEGAL AXIS NUMBER

(M series)

5243 DATA OUT OF RANGE

(M series)

5244 TOO MANY DI ON

(M series)

5245 OTHER AXIS ARE COMMANDED

(M series)

5251 ILLEGAL PARAMETER IN G54.2

(M series)

5252 ILLEGAL P COMMAND IN G54.2

(M series)

5257 G41/G42 NOT ALLOWED IN MDI

MODE (M series)

G41/G42 NOT ALLOWED IN MDI MODE (T series)

5300 SET ALL OFFSET DATAS AGAIN After the inch/metric automatic conversion function (OIM: Bit 0 of pa-

5302 ILLEGAL COMMAND IN G68 MODE A command to set the coordinate system is specified in the coordinate

The axis number of the synchronous master axis or slave axis is incor-

rect. (This alarm is issued when flexible synchronization is turned on.)

Alternatively , the axis number of the slave axis is smaller than that of the

master axis.

The gear ratio is not set correctly. (This alarm is issued when flexible

synchronization is turned on.)

Even when an M code was encountered in automatic operation mode,

the flexible synchronization mode signal was not driven on or off.

Check the ladder and M codes.

One of the following command conditions was present during flexible

synchronization or when flexible synchronization was turned on:

1. The synchronous master axis or slave axis is the EGB axis.

2. The synchronous master axis or slave axis is the chopping axis.

3. In reference position return mode

A fixture offset parameter (No. 7580 to 7588) is illegal. Correct the pa-

rameter.

The P value specifying the offset number of a fixture of fset is too large.

Correct the program.

G41/G42 (cutter compensation C: M series) was specified in MDI

mode. (Depending on the setting of bit 4 of parameter No. 5008)

G41/G42 (tool–nose radius compensation: T series) was specified in

MDI mode. (Depending on the setting of bit 4 of parameter No. 5008)

rameter No. 5006) for tool offset data is enabled or disabled, all the tool

offset data must be reset. This message reminds the operator to reset

the data.

If this alarm is issued, reset all the tool offset data. Operating the ma-

chine without resetting the data will result in a malfunction.

system rotation mode.

B–63525EN/02

858

B–63525EN/02

Number ContentsMessage

5303 TOUCH PANEL ERROR A touch panel error occurred.

5306 MODE CHANGE ERROR In a one–touch macro call, mode switching at the time of activation is not

5307 INTERNAL DA TA OVER FLOW

(M series)

5311 FSSB:ILLEGAL CONNECTION A connection related to FSSB is illegal.

5321 S–COMP. VALUE OVERFLOW The straightness compensation value has exceeded the maximum val-

5400 SPL:ILLEGAL AXIS COMMAND

(M series)

5401 SPL:ILLEGAL COMMAND (M series) In a G code mode in which specification of G06.1 is not permitted, G06.1

5402 SPL:ILLEGAL AXIS MOVING

(M series)

5403 SPL:CAN NOT MAKE VECTOR

(M series)

5405 ILLEGAL PARAMETER IN G41.2/

G42.2 (M series)

5406 G41.3/G40 FORMAT ERROR

(M series)

APPENDIX

Cause:

1. The touch panel is kept pressed.

2. The touch panel was pressed when power was turned on.

Remove the above causes, and turn on the power again.

performed correctly.

In the following function, internal data exceeds the allowable range.

1) Improvement of the rotation axis feedrate

This alarm is issued when either of the following is found:

1. Two axes having adjacent servo axis numbers (parameter No.

1023), odd number and even number, are assigned to amplifiers to which different FSSB systems are connected.

2. The system does not satisfy the requirements for performing HRV control, and use of two pulse modules connected to different FSSB systems having different FSSB current control cycles is specified.

ue of 32767.After this alarm is issued, make a manual reference position return.

An axis specified for spline interpolation or smooth interpolation is incorrect. If an axis that is not the spline axis is specified in spline interpolation mode, this alarm is issued. The spline axis is the axis specified in a block containing G06.1 or the next block. For smooth interpolation, the axis specified in G5.1Q2 is incorrect.

is specified. A movement is made along an axis that is not the spline interpolation

axis. For example, in three–dimensional tool compensation mode using an offset vector of which components are the X–, Y–, and Z–axes, when two–axis spline interpolation is performed with the two spline axes set to the X– and Y–axes, a movement along the Z–axis occurs, resulting in this alarm.

Three–dimensional tool compensation vectors cannot be generated.

· When a three–dimensional tool compensation vector is created for

the second or subsequent point, that point, previous point, and next point are on the same straight line, and that straight line and the three– dimensional tool compensation vector for the previous point are in parallel.

· When a three–dimensional tool compensation vector is created at the

end point of smooth interpolation or spline interpolation, the end point and the point two points before are the same.

The parameter setting that determines the relationship between the rotation axis and rotation plane is incorrect.

1) A G41.3 or G40 block contains a move command.

2) A G1.3 block contains a G code or M code for which buffering is suppressed.

A. ALARM LIST

859

Number ContentsMessage

APPENDIXA. ALARM LIST

B–63525EN/02

5407 ILLEGAL COMMAND IN G41.3

(M series)

5408 G41.3 ILLEGAL START_UP

(M series)

5409 ILLEGAL PARAMETER IN G41.3

(M series) 5411 NURBS:ILLEGAL ORDER (M series) The number of steps is specified incorrectly. 5412 NURBS:NO KNOT COMMAND

(M series) 5413 NURBS:ILLEGAL AXIS COMMAND

(M series) 5414 NURBS:ILLEGAL KNOT (M series) The number of blocks containing knots only is insufficient. 5415 NURBS:ILLEGAL CANCEL

(M series) 5416 NURBS:ILLEGAL MODE (M series) A mode that cannot be used with NURBS interpolation mode is speci-

5417 NURBS:ILLEGAL MULTI–KNOT

(M series) 5418 NURBS:ILLEGAL KNOT VALUE

(M series) 5420 ILLEGAL PARAMETER IN G43.4/

G43.5 (M series) 5421 ILLEGAL COMMAND IN G43.4/

G43.5 (M series) 5422 EXCESS VELOCITY IN G43.4/G43.5

(M series)

5425 ILLEGAL OFFSET VALUE (M series) The offset number is incorrect. 5430 ILLEGAL COMMAND IN 3–D CIR

(M series)

5432 G02.4/G03.4 FORMAT ERROR

(M series) 5433 MANUAL INTERVENTION IN 3–D

CIR (M series) 5435 PARAMETER OUT OF RANGE

(TLAC) (M series) 5436 PARAMETER SETTING ERROR 1

(TLAC) (M series) 5437 PARAMETER SETTING ERROR 2

(TLAC) (M series) 5440 ILLEGAL DRILLING AXIS

SELECTED (M series)

1) A G code that belongs to group 01 except G00 and G01 is specified in G41.3 mode.

2) An offset command (a G code belonging to group 07) is specified in G41.3 mode.

3) The block next to G41.3 (startup) contains no movement.

1) In a mode of group 01 except G00 and G01, G41.3 (startup) is specified.

2) At startup, the included angle of the tool direction vector and move direction vector is 0 or 180 degrees.

The parameter setting (No. xxxx to xxxx) that determines the relationship between the rotation axis and rotation plane is incorrect.

No knot is specified. Alternatively, in NURBS interpolation mode, a block not relating to NURBS interpolation is specified.

An axis not specified with controlled points is specified in the first block.

Although NURBS interpolation is not completed yet, the NURBS interpolation mode is turned off.

fied in NURBS interpolation mode. As many knots as the number of steps are not specified at the start and

end points. Knots do not increase in monotone.

A parameter related to pivot tool length compensation is incorrect.

In pivot tool length compensation (type 2) mode, a rotation axis is specified.

As a result of pivot tool length compensation, an attempt was made to move the tool along an axis at a feedrate exceeding the maximum cutting feedrate.

In a modal state in which three–dimensional circular interpolation cannot be specified, a three–dimensional circular interpolation (G02.4/G03.4) is specified. Alternatively, in three–dimensional circular interpolation mode, a code that cannot be specified is specified.

A three–dimensional circular interpolation command (G02.4/G03.4) is incorrect.

In three–dimensional circular interpolation mode (G02.4/G03.4), manual intervention was made when the manual absolute switch was on.

Incorrect parameter setting (set value range)

Incorrect parameter setting (setting of the rotation axis)

Incorrect parameter setting (setting of the tool axis)

The drilling axis specified for the drilling canned cycle is incorrect. The G code command block of the canned cycle does not specify the Z point of the drilling axis. When there is a parallel axis with the drilling axis, the parallel axis is also specified at the same time.

860

B–63525EN/02

Number ContentsMessage

5445 CRC:MOTION IN G39 (M series) Corner circular interpolation (G39) of cutter compensation is not speci-

5446 CRC:NO AVOIDANCE (M series) Because there is no interference evade vector, the interference check

5447 CRC:DANGEROUS AVOIDANCE

(M series)

5448 CRC:INTERFERENCE TO AVD.

(M series)

5452 IMPROPER G–CODE (5AXIS MODE)

(M series)

5453 NOTE: G68 IS CANCELED (HPCC)

(M series)

5455 ILLEGAL ACC. PARAMETER

(M series)

APPENDIX

fied alone but is specified with a move command.

evade function of cutter compensation cannot evade interference. The interference check evade function of cutter compensation deter-

mines that an evade operation will lead to danger. In the interference check evade function of cutter compensation, a fur-

ther interference occurs for an already created interference evade vector.

A G code that cannot be specified is found. (5–axis mode) This alarm is issued when:

1) Three–dimensional cutter compensation (side–face of fset and leading–edge offset) is applied during cutter compensation, or cutter compensation is applied during three–dimensional cutter compensation (side–face offset and leading–edge offset).

2) A leading–edge offset of three–dimensional cutter compensation is applied during side–face offsetting of three–dimensional cutter compensation, or a side–face offset of three–dimensional cutter compensation is applied during leading–edge offsetting of three–dimensional cutter compensation.

3) Tool axis direction tool length compensation is applied during tool length compensation, or tool length compensation is applied during tool axis direction tool length compensation.

4) Tool center point control is provided during tool length compensation, or tool length compensation is applied during tool center point control.

5) Tool center point control is provided during tool axis direction tool length compensation, or tool axis direction tool length compensation is applied during tool center point control. If this alarm is issued, cancel the relevant mode, then specify a dif ferent mode.

When bit 2 of parameter No. 5400 is set to 1, and a reset does not cancel G68, this alarm is issued at the time of program restart. T o release this alarm, press <RESET> and <CAN>. Once this operation is performed, the alarm will not be issued at the next restart.

A permissible acceleration parameter for optimum torque acceleration/ deceleration is incorrect. The cause is one of the following:

1) The ratio of the deceleration rate to the acceleration rate is below the limit.

2) The time required for deceleration to a speed of 0 exceeds the maximum value.

A. ALARM LIST

NOTE

HPCC designates High Precision Contour Control. AICC designates AI Contour Control.

861

APPENDIXA. ALARM LIST

B–63525EN/02

(2) Background edit alarm

Number Message Contents

??? BP/S alarm BP/S alarm occurs in the same number as the P/S alarm that occurs in

ordinary program edit. (070, 071, 072, 073, 074 085,086,087 etc.)

140 BP/S alarm It was attempted to select or delete in the background a program being

selected in the foreground. (Note) Use background editing correctly .

NOTE

Alarm in background edit is displayed in the key input line of the background edit screen instead of the ordinary alarm screen and is resettable by any of the MDI key operation.

(3) Absolute pulse coder (APC) alarm

Number Message Contents

300 APC alarm: nth–axis origin return Manual reference position return is required for the nth–axis (n=1 – 8). 301 APC alarm: nth–axis communication nth–axis (n=1 – 8) APC communication error. Failure in data transmis-

sion Possible causes include a faulty APC, cable, or servo interface module.

302 APC alarm: nth–axis over time nth–axis (n=1 – 8) APC overtime error.

Failure in data transmission. Possible causes include a faulty APC, cable, or servo interface module.

303 APC alarm: nth–axis framing nth–axis (n=1 – 8) APC framing error. Failure in data transmission.

Possible causes include a faulty APC, cable, or servo interface module.

304 APC alarm: nth–axis parity nth–axis (n=1 – 8) APC parity error.

Failure in data transmission. Possible causes include a faulty APC, cable, or servo interface module.

305 APC alarm: nth–axis pulse error nth–axis (n=1 – 8) APC pulse error alarm.

APC alarm.APC or cable may be faulty .

306 APC alarm: nth–axis battery

voltage 0

307 APC alarm: nth–axis battery low 1 nth–axis (n=1 – 8) axis APC battery voltage reaches a level where the

308 APC alarm: nth–axis battery low 2 nth–axis (n=1 – 8) APC battery voltage has reached a level where the

309 APC ALARM:

n AXIS ZRN IMPOSSIBL

nth–axis (n=1 – 8) APC battery voltage has decreased to a low level so that the data cannot be held. APC alarm. Battery or cable may be faulty .

battery must be renewed. APC alarm. Replace the battery .

battery must be renewed (including when power is OFF). APC alarm .Replace battery .

Return to the origin has been attempted without first rotating the motor one or more times. Before returning to the origin, rotate the motor one or more times then turn off the power .

(4) Inductsyn alarms

Number Message Description

330 INDUCTOSYN:DATA ALARM The absolute–position data (offset data) from Inductosyn cannot be

detected.

331 INDUCTOSYN:ILLEGAL PRM Parameter No. 1874, 1875, or 1876 is set to 0.

862

B–63525EN/02

APPENDIX

(5) Serial pulse coder

(SPC) alarms

No. Message Description

A. ALARM LIST

360 n AXIS : ABNORMAL CHECKSUM

(INT)

361 n AXIS : ABNORMAL PHASE DA TA

(INT)

362 n AXIS : ABNORMAL REV .DATA

(INT) 363 n AXIS : ABNORMAL CLOCK (INT) A clock error occurred in the built–in pulse coder. 364 n AXIS : SOFT PHASE ALARM (INT) The digital servo software detected invalid data in the built–in pulse

365 n AXIS : BROKEN LED (INT) An LED error occurred in the built–in pulse coder. 366 n AXIS : PULSE MISS (INT) A pulse error occurred in the built–in pulse coder. 367 n AXIS : COUNT MISS (INT) A count error occurred in the built–in pulse coder. 368 n AXIS : SERIAL DA TA ERROR

(INT) 369 n AXIS : DA TA TRANS. ERROR

(INT) 380 n AXIS : BROKEN LED (EXT) The LED of separate detector is erroneous. 381 n AXIS : ABNORMAL PHASE

(EXT LIN) 382 n AXIS : COUNT MISS (EXT) A pulse error occurred in the separate detector. 383 n AXIS : PULSE MISS (EXT) A count error occurred in the separate detector. 384 n AXIS : SOFT PHASE ALARM

(EXT) 385 n AXIS : SERIAL DA TA ERROR

(EXT) 386 n AXIS : DA TA TRANS. ERROR

(EXT) 387 n AXIS : ABNORMAL ENCODER

(EXT)

A checksum error occurred in the built–in pulse coder.

A phase data error occurred in the built–in pulse coder.

A rotation speed count error occurred in the built–in pulse coder.

coder.

Communication data from the built–in pulse coder cannot be received.

A CRC or stop bit error occurred in the communication data being received from the built–in pulse coder.

A phase data error occurred in the separate linear scale.

The digital servo software detected invalid data in the separate detector.

Communication data from the separate detector cannot be received.

A CRC or stop bit error occurred in the communication data being received from the separate detector.

An error occurs in the separate detector. For details, contact the manufacturer of the scale.

D The details of serial

pulse coder alarm

202

#1 (CKA) : The serial pulse coder is defective. Replace it.

The details of serial pulse coder alarm are displayed in the diagnosis display (No. 202 and No.203) as shown below.

CSA

BLA

PHA

PCA

BZA

CKA

SPH

#6 (CSA) : The serial pulse coder is defective. Replace it. #5 (BLA) : The battery voltage is low. Replace the batteries. #4 (PHA) : The serial pulse coder or feedback cable is defective. Replace the serial

pulse coder or cable.

#3 (PCA) : The serial pulse coder is defective. Replace it. #2 (BZA) : The pulse coder was supplied with power for the first time.

Make sure that the batteries are connected. Turn the power off, then turn it on again and perform a reference position return.

#0 (SPH) : The serial pulse coder or feedback cable is defective. Replace the serial

pulse coder or cable.

863

APPENDIXA. ALARM LIST

B–63525EN/02

DTE203

CRC

STB#4PRM

#3 #2 #1 #0

#7 (DTE) : The serial pulse coder encountered a communication error.

The pulse coder, feedbak cable, or feedback receiver circuit is defective. Replace the pulse coder, feedback cable, or NC–axis board

#6 (CRC) : The serial pulse coder encountered a communication error.

The pulse coder, feedback cable, or feedback receiver circuit is defective. Replace the pulse coder, feedback cable, or NC–axis board.

#5 (STB) : The serial pulse coder encountered a communication error.

The pulse coder, feedback cable, or feedback receiver circuit is defective. Replace the pulse coder, feedback cable, or NC–axis board.

#4 (PRM) : An invalid parameter was found. Alarm No. 417 (invalid servo

parameter) is also issued.

(6) Servo alarms(1/2)

Number Message Contents

401 SERVO ALARM: n–TH AXIS VRDY

OFF

402 SERVO ALARM: SV CARD NOT EX-

IST

403 SERVO ALARM: CARD/SOFT MIS-

MATCH

404 SERVO ALARM: n–TH AXIS VRDYONEven though the n–th axis (axis 1–8) READY signal (MCON) went off,

405 SERVO ALARM: (ZERO POINT RE-

TURN FAULT)

407 SERVO ALARM: EXCESS ERROR The following error occurred during simple synchronous control:

409 SERVO ALARM: n AXIS TORQUE

ALM

410 SERVO ALARM: n–TH AXIS – EX-

CESS ERROR

411 SERVO ALARM: n–TH AXIS – EX-

CESS ERROR

413 SERVO ALARM: n–th AXIS – LSI

OVERFLOW

The n–th axis (axis 1–8) servo amplifier READY signal (DRDY) went off. Refer to procedure of trouble shooting.

The axis control card is not provided.

The combination of the axis control card and servo software is illegal. The possible causes are as follows:

· A correct axis control card is not provided.

· Correct servo software is not installed on flash memory.

the servo amplifier READY signal (DRDY) is still on. Or, when the power was turned on, DRDY went on even though MCON was off. Check that the servo interface module and servo amp are connected.

Position control system fault. Due to an NC or servo system fault in the reference position return, there is the possibility that reference position return could not be executed correctly . Try again from the manual reference position return.

The difference in machine coordinates between the synchronized axes exceeds the value set in parameter No. 8314.

Abnormal servo motor load has been detected. Alternatively , abnormal spindle motor load has been detected in Cs mode.

One of the following errors occurred:

1) The positional deviation value when the n–th axis stops exceeds the value set in parameter No. 1829.

2) In simple synchronous control, the compensation amount for synchronization exceeds the value set in parameter No. 8325.

This alarm is issued only for the slave axis. The position deviation value when the n–th axis (axis 1–8) moves is

larger than the set value. Refer to procedure of trouble shooting.

The contents of the error register for the n–th axis (axis 1–8) exceeded

power. This error usually occurs as the result of an improperly set

parameters.

864

B–63525EN/02

Number ContentsMessage

APPENDIX

A. ALARM LIST

415 SERVO ALARM: n–TH AXIS – EX-

CESS SHIFT

417 SERVO ALARM: n–TH AXIS – PA-

RAMETER INCORRECT

420 SERVO ALARM: n AXIS SYNC

TORQUE (M series)

421 SERVO ALARM: n AXIS EXCESS

ER (D)

422 SERVO ALARM: n AXIS In torque control of PMC axis control, a specified allowable speed

423 SERVO ALARM: n AXIS In torque control of PMC axis control, the parameter–set allowable

430 n AXIS : SV . MOT OR OVERHEAT A servo motor overheat occurred. 431 n AXIS : CNV . OVERLOAD 1) PSM: Overheat occurred.

432 n AXIS : CNV . LOW VOLT CON-

TROL

433 n AXIS : CNV . LOW VOLT DC LINK 1) PSM: The DC link voltage has dropped.

434 n AXIS : INV . LOW VOLT CONTROL SVM: The control power supply voltage has dropped. 435 n AXIS : INV . LOW VOLT DC LINK SVM: The DC link voltage has dropped. 436 n AXIS : SOFTTHERMAL (OVC) The digital servo software detected the soft thermal state (OVC). 437 n AXIS : CNV . OVERCURRENT

POWER

A speed higher than 524288000 units/s was attempted to be set in the n–th axis (axis 1–8). This error occurs as the result of improperly set CMR.

This alarm occurs when the n–th axis (axis 1–8) is in one of the conditions listed below. (Digital servo system alarm)

1) The value set in Parameter No. 2020 (motor form) is out of the specified limit.

2) A proper value (11 1 or –1 1 1) is not set in parameter No.2022 (motor revolution direction).

3) Illegal data (a value below 0, etc.) was set in parameter No. 2023 (number of speed feedback pulses per motor revolution).

4) Illegal data (a value below 0, etc.) was set in parameter No. 2024 (number of position feedback pulses per motor revolution).

5) Parameters No. 2084 and No. 2085 (flexible field gear rate) have not been set.

6) A value outside the limit of {1 to the number of control axes} or a non– continuous value (Parameter 1023 (servo axis number) contains a value out of the range from 1 to the number of axes, or an isolated value (for example, 4 not prceded by 3).was set in parameter No. 1023 (servo axisnumber).

7) A torque control parameter is set incorrectly in PMC axis control. (The torque constant parameter is set to 0.)

During simple synchronous control, the difference between the torque commands for the master and slave axes exceeded the value set in parameter No. 2031.

The difference between the errors in the semi–closed loop and closed loop has become excessive during dual position feedback. Check the values of the dual position conversion coefficients in parameters No. 2078 and 2079.

has been exceeded.

cumulative travel distance has been exceeded.

2) β series SVU: Overheat occurred.

1) PSM: Control power voltage has dropped.

2) PSMR: The control power supply voltage has dropped.

3) β series SVU: The control power supply voltage has dropped.

2) PSMR: The DC link voltage has dropped.

3) α series SVU: The DC link voltage has dropped.

4) β series SVU: The DC link voltage has dropped.

PSM: Overcurrent flowed into the input circuit.

865

Number ContentsMessage

APPENDIXA. ALARM LIST

B–63525EN/02

438 n AXIS : INV . ABNORMAL CUR-

RENT

439 n AXIS : CNV . OVERVOLT POWER 1) PSM: The DC link voltage is too high.

440 n AXIS : CNV . EX DECELERATION

POW.

441 n AXIS : ABNORMAL CURRENT

OFFSET

442 n AXIS : CNV . CHARGE FAILURE 1) PSM: The spare discharge circuit of the DC link is abnormal.

443 n AXIS : CNV . COOLING FAN FAIL-

URE

444 n AXIS : INV . COOLING FAN FAIL-

URE

445 n AXIS : SOFT DISCONNECT

ALARM

446 n AXIS : HARD DISCONNECT

ALARM 447 n AXIS : HARD DISCONNECT (EXT) A broken wire in the separate detector was detected by hardware. 448 n AXIS : UNMA TCHED FEEDBACK

ALARM 449 n AXIS : INV . IPM ALARM 1) SVM: IPM (intelligent power module) detected an alarm.

453 n AXIS : SPC SOFT DISCONNECT

ALARM

456 ILLEGAL CURRENT LOOP The current control cycle settings (parameter No. 2004, bit 0 of pa-

457 ILLEGAL HI HRV (250US) Use of high–speed HRV is specified although the current control

458 CURRENT LOOP ERROR The current control cycle setting does not match the actual current

459 HI HRV SETTING ERROR Of two axes having adjacent servo axis numbers (parameter No.

1) SVM: The motor current is too high.

2) α series SVU: The motor current is too high.

3) β series SVU: The motor current is too high.

2) PSMR: The DC link voltage is too high.

3) α series SVU: The C link voltage is too high.

4) β series SVU: The link voltage is too high.

1) PSMR: The regenerative discharge amount is too large.

2) α series SVU: The regenerative discharge amount is too large. Alternatively, the regenerative discharge circuit is abnormal.

The digital servo software detected an abnormality in the motor current detection circuit.

2) PSMR: The spare discharge circuit of the DC link is abnormal.

1) PSM: The internal stirring fan failed.

2) PSMR: The internal stirring fan failed.

3) β series SVU: The internal stirring fan failed.

SVM: The internal stirring fan failed.

The digital servo software detected a broken wire in the pulse coder.

A broken wire in the built–in pulse coder was detected by hardware.

The sign of feedback data from the built–in pulse coder differs from that of feedback data from the separate detector.

2) α series SVU: IPM (intelligent power module) detected an alarm.

Software disconnection alarm of the α pulse coder. Turn off the power to the CNC, then remove and insert the pulse coder cable. If this alarm is issued again, replace the pulse coder.

rameter No. 2003, and bit 0 of parameter No. 2013) are incorrect. Possible problems are as follows.

– For the two axes whose servo axis numbers (settings of parame-

ter No. 1023) are an odd number followed by an even number (a pair of axes 1 and 2 or axes 5 and 6, for example), a different current control cycle is set for each of the axes.

– The requirements for slaves needed for the set current control

cycle, including the number, type, and connection method of them, are not satisfied.

cycle is 200 µs.

control cycle.

1023), odd number and even number, high–speed HRV control can

be performed for one axis and not for the other.

866

B–63525EN/02

Number ContentsMessage

460 n AXIS : FSSB DISCONNECT FSSB communication was disconnected suddenly. The possible

461 n AXIS : ILLEGAL AMP INTERFACE The axes of the 2–axis amplifier were assigned to the fast type inter-

462 n AXIS : SEND CNC DA TA FAILED Because of an FSSB communication error, a slave could not receive

463 n AXIS : SEND SLA VE DATA

FAILED

464 n AXIS : WRITE ID DA TA FAILED An attempt was made to write maintenance information on the ampli-

465 n AXIS : READ ID DA TA FAILED At power–up, amplifier initial ID information could not be read. 466 n AXIS : MOTOR/AMP COMBINA-

TION

467 n AXIS : ILLEGAL SETTING OF

AXIS

468 HI HRV SETTING ERROR(AMP) Use of high–speed HRV is specified for a controlled axis of an ampli-

APPENDIX

causes are as follows:

1) The FSSB communication cable was disconnected or broken.

2) The power to the amplifier was turned off suddenly.

3) A low–voltage alarm was issued by the amplifier.

face.

correct data. Because of an FSSB communication error, the servo system could

not receive correct data.

fier maintenance screen, but it failed.

The maximum current rating for the amplifier does not match that for the motor.

The servo function for the following has not been enabled when an axis occupying a single DSP (corresponding to two ordinary axes) is specified on the axis setting screen.

1. Learning control (bit 5 of parameter No. 2008 = 1)

2. High–speed current loop (bit 0 of parameter No. 2004 = 1)

3. High–speed interface axis (bit 4 of parameter No. 2005 = 1)

fier which does not support high–speed HRV.

A. ALARM LIST

D Details of servo alarm

#7 (OVL) : An overload alarm is being generated.

#6 (LV) : A low voltage alarm is being generated in servo amp.

#5 (OVC) : A overcurrent alarm is being generated inside of digital servo. #4 (HCA) : An abnormal current alarm is being generated in servo amp.

#3 (HVA) : An overvoltage alarm is being generated in servo amp.

#2 (DCA) : A regenerative discharge circuit alarm is being generated in servo amp.

#1 (FBA) : A disconnection alarm is being generated.

#0 (OFA) : An overflow alarm is being generated inside of digital servo.

The details of servo alarm are displayed in the diagnosis display (No. 200 and No.204) as shown below.

OVL200

#6 LV

OVC#4HCA

HVA

DCA

FBA

OFA

(The details are indicated in diagnostic data No.201).

Check LED.

(The details are indicated in diagnostic data No. 201)

867

APPENDIXA. ALARM LIST

B–63525EN/02

ALD201

#6 #5 #4

EXP

#3 #2 #1 #0

When OVL equal 1 in diagnostic data No.200 (servo alarm No. 400 is being generated):

#7 (ALD) 0 : Motor overheating

1 : Amplifier overheating When FBAL equal 1 in diagnostic data No.200 (servo alarm No. 416 is

being generated):

ALD EXP Alarm details

1 0 Built–in pulse coder disconnection (hardware) 1 1 Separately installed pulse coder disconnection

(hardware)

0 0 Pulse coder is not connected due to software.

204

OFS

MCC#4LDA

PMS

#2 #1 #0

#6 (OFS) : A current conversion error has occured in the digital servo.

#5 (MCC) : A magnetic contactor contact in the servo amplifier has welded.

#4 (LDA) : The LED indicates that serial pulse coder C is defective #3 (PMS) : A feedback pulse error has occured because the feedback cable is

defective.

(7) Over travel alarms

Number Message Contents

500 OVER TRAVEL : +n Exceeded the n–th axis (axis 1–8) + side stored stroke check I.

(Parameter No.1320 or 1326 NOTE)

501 OVER TRA VEL : –n Exceeded the n–th axis (axis 1–8) – side stored stroke check I.

(Parameter No.1321 or 1327 NOTE)

502 OVER TRAVEL : +n Exceeded the n–th axis (axis 1–8) + side stored stroke check II.

(Parameter No.1322 )

503 OVER TRA VEL : –n Exceeded the n–th axis (axis 1–8) – side stored stroke check II.

(Parameter No.1323)

504 OVER TRAVEL : +n Exceeded the n–th axis (axis 1–8) + side stored stroke check III.

(Parameter No.1324 )

505 OVER TRA VEL : –n Exceeded the n–th axis (axis 1–8) – side stored stroke check III.

(Parameter No.1325 ) 506 OVER TRAVEL : +n Exceeded the n–th axis (axis 1–8) + side hardware OT. 507 OVER TRA VEL : –n Exceeded the n–th axis (axis 1–8) – side hardware OT. 508 INTERFERENCE: +n

(T series (two–path control))

509 INTERFERENCE: –n

(T series (two–path control))

510 OVER TRAVEL: +n Alarm for stroke check prior to movement. The end point specified in a

511 OVER TRAVEL: –n Alarm for stroke check prior to movement. The end point specified in a

A tool moving in the positive direction along the n axis has fouled anoth-

er tool post.

A tool moving in the negative direction along the n axis has fouled anoth-

er tool post.

block falls within the forbidden area defined with the stroke check in the

positive direction along the N axis. Correct the program.

block falls within the forbidden area defined with the stroke check in the

negative direction along the N axis. Correct the program.

868

B–63525EN/02

Number ContentsMessage

514 INTERFERENCE : +n The rotation area interference check function found interference on the

515 INTERFERENCE : –n The rotation area interference check function found interference on the

APPENDIX

plus side of the n axis.

minus side of the n axis.

A. ALARM LIST

NOTE

Parameters 1326 and 1327 are effective when EXLM(stroke check switch signal) is on.

(8) Servo alarms

Number Message Contents

600 n AXIS: INV. DC LINK OVER CUR-

RENT

601 n AXIS: INV . RADIATOR FAN FAIL-

URE 602 n AXIS: INV . OVERHEAT The servo amplifier was overheated. 603 n AXIS: INV . IPM ALARM(OH) The IPM (intelligent power module) detected an overheat alarm. 604 n AXIS: AMP. COMMUNICATION

ERROR 605 n AXIS: CNV . EX. DISCHARGE

POW. 606 n AXIS: CNV . RADIATOR FAN FAIL-

URE 607 n AXIS: CNV . SINGLE PHASE FAIL-

URE

DC link current is too large.

The external dissipator stirring fan failed.

Communication between the SVM and the PSM failed.

PSMR: Regenerative power is too large.

PSM: The external dissipator stirring fan failed. PSMR: The external dissipator stirring fan failed.

PSM: Input voltage is in the open–phase condition. PSMR: Input voltage is in the open–phase condition.

(9) Overheat alarms

Number Message Contents

700 OVERHEA T: CONTROL UNIT Control unit overheat

Check that the fan motor operates normally , and clean the air filter.

701 OVERHEA T: FAN MOTOR The fan motor on the top of the cabinet for the contorl unit is overheated.

Check the operation of the fan motor and replace the motor if necessary .

704 OVERHEA T: SPINDLE Spindle overheat in the spindle fluctuation detection

(1) If the cutting load is heavy , relieve the cutting condition. (2) Check whether the cutting tool is share. (3) Another possible cause is a faulty spindle amp.

(10)Rigid tapping alarms

Number Message Contents

740 RIGID TAP ALARM: EXCESS ER-

ROR 741 RIGID TAP ALARM: EXCESS ER-

ROR 742 RIGID TAP ALARM: LSI OVER-

FLOW

The positional deviation of the stopped spindle has exceeded the set value during rigid tapping.

The positional deviation of the moving spindle has exceeded the set value during rigid tapping.

An LSI overflow has occurred for the spindle during rigid tapping.

869

APPENDIXA. ALARM LIST

B–63525EN/02

(11)Serial spindle alarms

Number Message Contents

749 S–SPINDLE LSI ERROR It is serial communication error while system is executing after power

supply on. Following reasons can be considered.

1) Optical cable connection is fault or cable is not connected or cable is cut.

2) MAIN CPU board or option 2 board is fault.

3) Spindle amp. printed board is fault.

4) The spindle amplifier is under an abnormal condition. (The SPM indication is A, A1, A2, or the like, depending on the type of the abnormality.)

If this alarm occurs when CNC power supply is turned on or when this alarm can not be cleared even if CNC is reset, turn of f the power supply also turn off the power supply in spindle side. If the spindle amplifier is under an abnormal condition, check the SPM indication (A, A1, A2, or the like). Then, refer to the FANUC SER VO MOTOR ai series MAINTENANCE MANUAL (B–65285EN) or FANUC SERVO MOTOR a series MAINTENANCE MANUAL (B–65165E) to solve the problem.

750 SPINDLE SERIAL LINK ST AR T

FAULT

752 FIRST SPINDLE MODE CHANGE

FAULT

754 SPINDLE–1 ABNORMAL TORQUE

ALM

762 SECOND SPINDLE MODE

CHANGE FAULT

764 SPINDLE–2 ABNORMAL TORQUE

ALM

772 SPINDLE–3 MODE CHANGE ER-

ROR

774 SPINDLE–3 ABNORMAL TORQUE

ALM

782 SPINDLE–4 MODE CHANGE ER-

ROR

784 SPINDLE–4 ABNORMAL TORQUE

ALM

This alarm is generated when the spindle control unit is not ready for starting correctly when the power is turned on in the system with the serial spindle. The four reasons can be considered as follows:

1) An improperly connected optic cable, or the spindle control unit’s power is OFF.

2) When the NC power was turned on under alarm conditions other than SU–01 or AL–24 which are shown on the LED display of the spindle control unit. In this case, turn the spindle amplifier power off once and perform startup again.

3) Other reasons (improper combination of hardware) This alarm does not occur after the system including the spindle control unit is activated.

4) The second spindle (when SP2, bit 4 of parameter No. 3701, is 1) is in one of the above conditions 1) to 3).

See diagnostic display No. 409 for details. This alarm is generated if the system does not properly terminate a

mode change. The modes include the Cs contouring, spindle positioning, rigid tapping, and spindle control modes. The alarm is activated if the spindle control unit does not respond correctly to the mode change command issued by the NC.

Abnormal first spindle motor load has been detected.

Refer to alarm No. 752.(For 2nd axis)

Same as alarm No. 754 (for the second spindle)

Same as alarm No. 752 (for the third spindle)

Same as alarm No. 754 (for the third spindle)

Same as alarm number 752 (for the fourth spindle)

Same as alarm number 754 (for the fourth spindle)

870

B–63525EN/02

D The details of spindle

alarm No.750

D 1st and 2nd spindles

APPENDIX

A. ALARM LIST

409

D 3rd and 4th spindles

409

#6 #5 #4 #3

SPE

S2E

S1E

SHE

#3 (SPE) 0 : In the spindle serial control, the serial spindle parameters fulfill the

spindle unit startup conditions.

1 : In the spindle serial control, the serial spindle parameters do not fulfill

the spindle unit startup conditions.

#2 (S2E) 0 : The second spindle is normal during the spindle serial control startup.

1 : The second spindle was detected to have a fault during the spindle

serial control startup.

#1 (S1E) 0 : The first spindle is normal during the spindle serial control startup.

1 : The first spindle was detected to have a fault during the spindle axis

serial control startup.

#0 (SHE) 0 : The serial communications module in the CNC is normal.

1 : The serial communications module in the CNC was detected to have a

fault.

The details of spindle alarm No. 750 are displayed in the diagnosis display (No. 409) as shown below.

#6 #5 #4 #3

SPE

S4E

S3E

SHE

#3 (SPE) 0 : In the spindle serial control, the serial spindle parameters fulfill the

spindle unit startup conditions.

1 : In the spindle serial control, the serial spindle parameters do not fulfill

the spindle unit startup conditions.

#2 (S2E) 0 : The fourth spindle is normal during the spindle serial control startup.

1 : The fourth spindle was detected to have a fault during the spindle

serial control startup.

#1 (S1E) 0 : The third spindle is normal during the spindle serial control startup.

1 : The third spindle was detected to have a fault during the spindle axis

serial control startup.

#0 (SHE) 0 : The serial communications module in the CNC is normal.

1 : The serial communications module in the CNC was detected to have a

fault.

871

APPENDIXA. ALARM LIST

B–63525EN/02

(12)Safety zone alarms

Number Message Contents

4800 ZONE : PUNCHING INHIBITED 1 When a safety zone check was executed, a punch command was

specified in area 1 where punching is inhibited.

4801 ZONE : PUNCHING INHIBITED 2 When a safety zone check was executed, a punch command was

specified in area 2 where punching is inhibited.

4802 ZONE : PUNCHING INHIBITED 3 When a safety zone check was executed, a punch command was

specified in area 3 where punching is inhibited.

4803 ZONE : PUNCHING INHIBITED 4 When a safety zone check was executed, a punch command was

specified in area 4 where punching is inhibited.

4810 ZONE : ENTERING INHIBITED 1 +X When a safety zone check was executed, the machine moving in the

positive X direction entered area 1 into which entry is inhibited.

4811 ZONE : ENTERING INHIBITED 1

–X

4812 ZONE : ENTERING INHIBITED 2 +X When a safety zone check was executed, the machine moving in the

4813 ZONE : ENTERING INHIBITED 2

–X

4814 ZONE : ENTERING INHIBITED 3 +X When a safety zone check was executed, the machine moving in the

4815 ZONE : ENTERING INHIBITED 3

–X

4816 ZONE : ENTERING INHIBITED 4 +X When a safety zone check was executed, the machine moving in the

4817 ZONE : ENTERING INHIBITED 4

–X

4830 ZONE : ENTERING INHIBITED 1 +Y When a safety zone check was executed, the machine moving in the

4831 ZONE : ENTERING INHIBITED 1

–Y

4832 ZONE : ENTERING INHIBITED 2 +Y When a safety zone check was executed, the machine moving in the

4833 ZONE : ENTERING INHIBITED 2

–Y

4834 ZONE : ENTERING INHIBITED 3 +Y When a safety zone check was executed, the machine moving in the

4835 ZONE : ENTERING INHIBITED 3

–Y

4836 ZONE : ENTERING INHIBITED 4 +Y When a safety zone check was executed, the machine moving in the

4837 ZONE : ENTERING INHIBITED 4

–Y

4870 AUTO SETTING FEED ERROR The feed rate of safety zone auto setting is other than the parameter

When a safety zone check was executed, the machine moving in the negative X direction entered area 1 into which entry is inhibited.

positive X direction entered area 2 into which entry is inhibited. When a safety zone check was executed, the machine moving in the

negative X direction entered area 2 into which entry is inhibited.

positive X direction entered area 3 into which entry is inhibited. When a safety zone check was executed, the machine moving in the

negative X direction entered area 3 into which entry is inhibited.

positive X direction entered area 4 into which entry is inhibited. When a safety zone check was executed, the machine moving in the

negative X direction entered area 4 into which entry is inhibited.

positive X direction entered area 1 into which entry is inhibited. When a safety zone check was executed, the machine moving in the

negative Y direction entered area 1 into which entry is inhibited.

positive Y direction entered area 2 into which entry is inhibited. When a safety zone check was executed, the machine moving in the

negative Y direction entered area 2 into which entry is inhibited.

positive Y direction entered area 3 into which entry is inhibited. When a safety zone check was executed, the machine moving in the

negative Y direction entered area 3 into which entry is inhibited.

positive Y direction entered area 4 into which entry is inhibited. When a safety zone check was executed, the machine moving in the

negative Y direction entered area 4 into which entry is inhibited.

value (No. 16538, No. 16539).

872

B–63525EN/02

Number ContentsMessage

4871 AUTO SETTING PIECES ERROR In safety zone auto setting, the safety zone pieces are not correct. Or

4872 AUTO SETTING COMMAND

ERROR

APPENDIX

the position detector has gone wrong, please tell your machine tool builder.

M code, S code or T code is specified with safety zone auto setting command (G32). G32 is specified in the nibbling mode, in the cutter compensation, in the rotation mode or the scaling mode.

A. ALARM LIST

(13) System alarms

Number Message Description

900 ROM PARITY A parity error occurred in the CNC, macro, or servo ROM. Correct

910 SRAM PARITY : (BYTE 0) A RAM parity error occurred in the part program storage RAM. Clear 911 SRAM PARITY : (BYTE 1) 912 DRAM PARITY : (BYTE 0) A RAM parity error occurred in the DRAM module. Replace the

913 DRAM PARITY : (BYTE 1) 914 DRAM PARITY : (BYTE 2) 915 DRAM PARITY : (BYTE 3) 916 DRAM PARITY : (BYTE 4) 917 DRAM PARITY : (BYTE 5) 918 DRAM PARITY : (BYTE 6) 919 DRAM PARITY : (BYTE 7) 920 SERVO ALARM (1–4 AXIS) Servo alarm (first to fourth axis). A watchdog alarm condition oc-

921 SERVO ALARM (5–8 AXIS) Servo alarm (fifth to eighth axis). A watchdog alarm condition oc-

926 FSSB ALARM FSSB alarm.

930 CPU INTERRUPT CPU error (abnormal interrupt).

935 SRAM ECC ERROR An error occurred in RAM for part program storage.

950 PMC SYSTEM ALARM

PCxxx YYYYYYYYYYYYYY

951 PMC WATCH DOG ALARM An error occurred in the PMC.

970 NMI OCCURRED IN PMCLSI With the PMC–SA1, an error occurred in the PMC control LSI device

971 NMI OCCURRED IN SLC With the PMC–SA1, an I/O Link disconnection was detected.

(These alarms cannot be reset with reset key.)

the contents of the flash ROM having the displayed number.

the RAM, or replace the SRAM module or motherboard. Subsequently , re–set the parameters and all other data.

DRAM module.

curred, or a RAM parity error occurred in the axis control card. Replace the axis control card.

Replace the axis control card.

The motherboard or CPU card may be faulty .

Action: Replace the master printed circuit board (SRAM module), perform all–clear operation, and set all parameter and other data again.

An error occurred in the PMC. For details of PCxxx, see the list of system alarm messages in Section A.2, ”LIST OF ALARMS (PMC)” in this manual.

(Watchdog alarm) The motherboard may be faulty .

on the motherboard. (I/O RAM parity) Replace the motherboard.

Check the I/O Link.

873

Number DescriptionMessage

APPENDIXA. ALARM LIST

B–63525EN/02

972 NMI OCCURRED IN OTHER MOD-

ULE 973 NON MASK INTERRUPT An NMI occurred as a result of an unknown cause. 974 F–BUS ERROR A bus error occurred on the FANUC bus.

975 BUS ERROR A bus error occurred on the motherboard.

976 L–BUS ERROR A bus error occurred on the local bus.

An NMI occurred on a board other than the motherboard. The option board may be faulty .

The motherboard or option board may be faulty .

The motherboard may be faulty .

874

B–63525EN/02

APPENDIX

A.2

LIST OF ALARMS (PMC)

(1) PMC ALARMS/SYSTEM ALARMS (PMC–SB7)

Alarm number Faulty location/corrective action Contents

A. ALARM LIST

ER01 PROGRAM DA TA ERROR 1) Re–input the sequence program.

2) Replace the master printed circuit board.

ER02 PROGRAM SIZE OVER 1) Reduce the sequence program.

2) Contact FANUC to have a larger number–of–Ladder–steps option specified.

ER03 PROGRAM SIZE ERROR (OPTION)

ER04 PMC TYPE UNMA TCH Using an offline programmer, change the

ER06 PMC CONTROL SOFTWARE TYPE UNMATCH

ER07 NO OPTION (LADDER STEP)

1) Reduce the sequence program.

2) Contact FANUC to have a larger number–of–Ladder–steps option specified.

sequence program to that for the correct PMC type.

Contact FANUC to specify certain PMC type

1) Restore the backed up CNC parameter data.

2) Check the data sheet and re–input the CNC parameters.

3) Contact FANUC to specify a number– of–Ladder–steps option of the necessary size.

The sequence program is invalid.

The sequence program is too large. The sequence program is invalid.

The sequence program exceeds the size specified by the number–of–Ladder– steps option.

The setting of the type in the sequence program differs from the actual type.

The combination of CNC system configuration and PMC type is invalid. (Example: PMC–SB5 is used for a 3–path CNC system.)

No number–of–Ladder–steps option is found.

ER08 OBJECT UNMA TCH 1) Contact FANUC. An unsupported function is used in the

sequence program.

ER09 PMC LABEL CHECK ERROR PLEASE TURN ON POWER AGAIN WITH PUSHING ’O’&’Z’. (CLEAR PMC SRAM)

ER10 OPTION AREA NOTHING (xxxx)

ER11 OPTION AREA NOTHING (xxxx)

1) Press and hold down the ’O’ and ’Z’ key combination, and turn the CNC back on.

2) When using the loader control function, power on the CNC again while pressing the ”5” and ”Z” keys.

3) Replace the backup battery.

4) Replace the master printed circuit board.

Contact FANUC to reconfigure the PMC management software.

With a change in the PMC type, for example, the retention–type memory of the PMC must be initialized.

The PMC management software is not loaded correctly .

The PMC C board management software is not loaded correctly .

875

APPENDIXA. ALARM LIST

Alarm number ContentsFaulty location/corrective action

B–63525EN/02

ER12 OPTION AREA ERROR (xxxx)

ER13 OPTION AREA ERROR (xxxx)

ER14 OPTION AREA VERSION ERROR (xxxx)

ER15 OPTION AREA VERSION ERROR (xxxx)

ER16 RAM CHECK ERROR (PROGRAM RAM)

ER17 PROGRAM P ARITY 1) Re–input the sequence program.

ER18 PROGRAM DATA ERROR BY I/O

Contact FANUC to reconfigure the PMC management software.

Contact FANUC to reconfigure the PMC management software

Replace the master printed circuit board. The initialization of the memory used to

2) Replace the master printed circuit board.

Re–input the sequence program. While the sequence program was being

The PMC management software is invalid. (The series of BASIC and OPTION do not match.)

The PMC C board management software is invalid. (The series of BASIC and OPTION do not match.)

The PMC management software is invalid. (The editions of BASIC and OPTION do not match.)

The PMC C board management software is invalid. (The editions of BASIC and OPTION do not match.)

store the sequence program failed. The parity of the sequence program is

invalid.

read, an interrupt command was generated.

ER19 LADDER DA TA ERROR Display the Ladder edit screen again and

exit from editing by using the [<<] key .

ER20 SYMBOL/COMMENT DA TA ERROR

ER21 MESSAGE DA TA ERROR Display the message data edit screen

ER22 PROGRAM NOTHING 1) Re–input the sequence program.

ER23 PLEASE TURN OFF POW-ERTurn the CNC off and then back on. With a change in the PMC type, for ex-

ER25 SOFTWARE VERSION ERROR (PMCAOPT)

ER26 PMC CONTROL MODULE ERROR (PMCAOPT)

Display the symbol/comment edit screen again and exit from editing by using the [<<] key.

again and exit from editing by using the [<<] key.

2) Replace the master printed circuit board.

Contact FANUC to reconfigure the PMC management software.

1) Contact FANUC to reconfigure the PMC management software.

2) 2) Replace the master printed circuit board.

During Ladder editing, the system was forcibly switched to the CNC screen with a function key.

During symbol/comment editing, the system was forcibly switched to the CNC screen with a function key .

During message data editing, the system was forcibly switched to the CNC screen with a function key .

The sequence program is empty.

ample, the power must be turned off and then back on.

The PMC management software is invalid. (The edition of PMCAOPT does not match.)

The initialization of the PMC management software failed.

876

B–63525EN/02

Alarm number ContentsFaulty location/corrective action

APPENDIX

A. ALARM LIST

ER27 LADDER FUNC. PRM IS OUT OF RANGE

ER32 NO I/O DEVICE 1) Check that the I/O device is on.

ER33 I/O LINK ERROR Replace the master printed circuit board. The LSI of the I/O Link is defective. ER34 I/O LINK ERROR (xx) 1) Check the connection of the cable

ER35 TOO MUCH OUTPUT DA TA IN GROUP (xx)

ER36 TOO MUCH INPUT DATA IN GROUP (xx)

Modify the sequence program. Change the parameter number of the function instruction to a value within the valid range.

2) Check that the I/O device was turned on before the CNC was turned on.

3) Check the connection of the cable.

leading to a device in group xx.

2) Check that the I/O device was turned on before the CNC.

3) Replace that device in group xx in which the PMC control module is installed.

Reduce the amount of output data in group xx.

Reduce the amount of input data in groupxxThe amount of input data in I/O Link

An out–of–range parameter number is specified with function instruction TMR, TMRB, CTR, DIFU, or DIFD.

An I/O device such as the I/O Link, connection unit, and Power Mate is not connected.

In a slave in group xx, an error occurred in communication with an I/O device.

The amount of output data in I/O Link group xx exceeds the limit (33 bytes). The excess data is nullified.

group xx exceeds the limit (33 bytes). The excess data is nullified.

ER38 MAX SETTING OUTPUT DA TA OVER (xx)

ER39 MAX SETTING INPUT DA TA OVER (xx)

ER40 I/O LINK–II SETTING ERROR (CHx)

ER41 I/O LINK–II MODE ERROR (CHx)

ER42 I/O LINK–II STATION NO.ERROR (CHx)

ER97 I/O LINK (CHxyyGROUP)

Modify the total amount of output data in each group to 128 bytes or less.

Modify the total amount of input data in each group to 128 bytes or less.

Reconfigure the I/O Link–II. The I/O Link–II setting is invalid.

Reconfigure the I/O Link–II. The I/O Link–II mode setting is invalid.

Reconfigure the I/O Link–II. The I/O Link–II station number setting is

1) Check whether the cables of I/O devices in group yy are connected properly.

2) Check the power to each I/O device.

3) Check the parameter setting of the I/O link assignment data selection function.

The I/O Link I/O area is insufficient. (The allocation of any group after group xx on the output side is nullified.)

The I/O Link I/O area is insufficient. (The allocation of any group after group xx on the input side is nullified.)

(CH1: Primary board, CH2: Secondary board)

invalid. (CH1: Primary board, CH2: Secondary board)

The number of assigned I/O modules in group yy differs from that of I/O devices actually connected.

Note)This alarm can control how the

check function operates through the use of keep relay K906.2. K906.2 = 0: Connection check is performed (initial value). K906.2 = 1: Connection check is not performed.

877

APPENDIXA. ALARM LIST

Alarm number ContentsFaulty location/corrective action

B–63525EN/02

ER98 ILLEGAL LASER CONNECTION

ER99 X,Y96–127 ARE ALLOCATED

WN02 OPERATE ADDRESS ERROR

WN03 ABORT NC–WINDOW/ EXIN

WN05 PMC TYPE NO CONVERSION

Modify the allocation of the I/O module. When an I/O device for a laser is used,

the allocation of the I/O module does not match the actual I/O device configuration.

Modify the allocation of the I/O module. When an I/O device for a laser is used,

another I/O device is allocated to X96–127/Y96–127. X96–127/Y96–127 are used for I/O devices for a laser, and cannot be used for other devices.

Modify the setting of the PMC system parameter, address of the operator’s panel for Series 0.

1) Check that the Ladder program is free from problems and then restart the Ladder program (by pressing the RUN key).

2) Turn the CNC off and then back on.

Using an offline programmer, change the sequence program to that for the correct PMC type.

The setting of the PMC system parameter, address of the operator’s panel for Series 0, is invalid.

The Ladder program was stopped during communication between the CNC and PMC. Function instructions such as WINDR, WINDW , EXIN, and DISPB may not be executed normally .

The setting of the type in the sequence program differs from the actual type. (Example: For the PMC–SB5, the Ladder program of the PMC–SA3/SA5 was transferred.)

WN06 TASK STOPPED BY DEBUG FUNC

WN07 LADDER SP ERROR (STACK)

WN17 NO OPTION (LANGUAGE) 1) Restore the backed up parameter

WN18 ORIGIN ADDRESS ERROR

WN19 GDT ERROR (BASE, LIMIT)

WN20 COMMON MEM. COUNT OVER

To restart a user task that has been stopped, stop the sequence program and then execute it again.

Modify the sequence program so that the subprogram nesting level is eight or less.

data.

2) Check the data sheet and re–input the parameters.

3) Contact FANUC to specify a PMC C program option of the necessary size.

1) On the PMC system parameter screen, press [ORIGIN].

2) Set the PMC system parameter, LANGUGE ORIGIN, to the address indicated by the RC_CTLB_INIT in the map file.

Modify the setting in the user–defined GDT in the link control statement or build file.

Change the number of shared memories to eight or less. Modify the link control statement, build file, or other source files for shared memories.

When a PMC C board is used, a user task has been stopped due to a break by a debug function.

For a subprogram call with the function instruction CALL or CALLU, the nesting level is too deep (exceeds 8).

When a PMC C board is used, no PMC C program option is found.

When a PMC C board is used, the PMC system parameter, LANGUAGE ORIGIN, is invalid.

When a PMC C board is used, the BASELIMIT or ENTRY in the user–defined GDT is invalid.

When a PMC C board is used, the number of shared memories exceeds eight.

878

B–63525EN/02

Alarm number ContentsFaulty location/corrective action

APPENDIX

A. ALARM LIST

WN21 COMMON MEM. ENTRY ERROR

WN22 LADDER 3 PRIORITY ERROR

WN23 TASK COUNT OVER Change the TASK COUNT in the link con-

WN24 TASK ENTRY ADDR ERROR

WN25 DATA SEG ENTRY ERROR

WN26 USER TASK PRIORITY ERROR

Modify the ENTRY in the shared memory GDT in the link control statement.

Change the value of the TASK LEVEL (LADDER LEVEL 3) in the link control statement to 0, 10 to 99, or –1.

trol statement to 16 or less. (T o change the task count, modify the link control statement, build file, and the configuration of the files to be linked.)

Change the GDT table in the build file to 32 (20H) to 95 (5FH).

Change the DATA SEGMENT GDT ENTRY value in the link control statement and the GDT table in the build file to 32 (20H) to 95 (5FH).

Change the TASK LEVEL of each task in the link control statement to a value from 10 to 99 or –1. (Note that –1 can be specified for the TASK LEVEL of only one task, including the third Ladder level).

When a PMC C board is used, the ENTRY in the shared memory GDT is out of range.

When a PMC C board is used, the priority of LADDER LEVEL 3 is out of range.

When a PMC C board is used, the number of user tasks exceeds 16.

When a PMC C board is used, the user task entry address selector is out of range.

When a PMC C board is used, the data segment entry address is out of range.

When a PMC C board is used, the priority of the user task is out of range.

WN27 CODE SEG TYPE ERROR Change the value of the code segment ac-

cording to the segment setting in the link control statement and build file.

WN28 DA TA SEG TYPE ERROR Change the value of the data segment ac-

cording to the segment setting in the link control statement and build file.

WN29 COMMON MEM SEG TYPE ERROR

WN30 IMPOSSIBLE ALLOCATE MEM.

WN31 IMPOSSIBLE EXECUTE LIBRARY

Change the value according to the segment setting in the link control statement and build file.

1) Check that the USER GDT ADDRESS in the link control statement and the start address of the code segment in the build file are correct.

2) Change the PMC system parameter, MAX LADDER AREA SIZE, to a minimum.

3) Change the stack size in the link control state to a minimum.

1) Check the types supported by the library.

2) Reconfigure the PMC management software and contact FANUC.

When a PMC C board is used, the code segment type is invalid. The setting of the RENA–MESEG code segment in the bind control file is wrong.

When a PMC C board is used, the data segment type is invalid. The setting of the RENA–MESEG data segment in the bind control file is wrong.

When a PMC C board is used, the shared memory segment type is invalid. The setting of the RENAMESEG segment in the shared memory bind control file is wrong.

When a PMC C board is used, the memory area for data, stacks, and others cannot be reserved.

When a PMC C board is used, library functions cannot be executed.

879

APPENDIXA. ALARM LIST

Alarm number ContentsFaulty location/corrective action

B–63525EN/02

WN32 LNK CONTROL DATA ERROR

WN33 LNK CONTROL VER.ERROR

WN34 LOAD MODULE COUNT OVER

WN35 CODE AREA OUT OF RANGE

WN36 LANGUAGE SIZE ERROR (OPTION)

WN37 PROGRAM DA TA ERROR (LANG.)

WN38 RAM CHECK ERROR (LANG.)

1) Check that the address of RC_CTLNB_INIT is set for the PMC system parameter, LANGUAGE ORIGIN.

2) Create the link control statement again.

Modify the link control statement in the PMC C program.

Change the number of independent load modules to eight or less.

Check the link map and allocate segments within the range of RAM.

1) Reduce the PMC C program.

2) Contact FANUC to specify a PMC C program option of a larger size.

Initialize the PMC C program memory . ([EDIT] → [CLEAR] → [CLRLNG] → [EXEC])

Replace the master printed circuit board. The initialization of the PMC C program

When a PMC C board is used, link control statement (program control) data is invalid.

When a PMC C board is used, a link control statement data edition error has occurred.

When a PMC C board is used, the number of independent load modules exceeds eight.

When a PMC C board is used, the code segment area is out of the range of the RAM.

When a PMC C board is used, the PMC C program exceeds the size specified for the PMC C program option.

The PMC C program memory must be initialized.

memory failed.

WN39 PROGRAM PARITY (LANG.)

WN40 PROGRAM DA TA ERROR BY I/O (LANG.)

WN41 LANGUAGE TYPE UNMATCH

WN42 UNDEFINE LANGUAGE ORIGIN ADDRESS

WN48 UNAVAIL LANGUAGE BY CNC UNMA TCH

1) Re–input the PMC C program.

2) Replace the master printed circuit board.

Re–input the language program. While the PMC C program was being

1) Re–input the PMC C program.

2) Replace the master printed circuit board.

1) On the PMC system parameter screen, click [ORIGIN].

2) Set the PMC system parameter, LANGUGE ORIGIN, to the address indicated by the RC_CTLB_INIT in the map file.

Remove the PMC C board. A PMC C board is installed in a CNC in

The parity of the PMC C program parity is invalid.

read, an interrupt command was generated.

When a PMC C board is used, an unusable C program is input.

When a PMC C board is used, the PMC parameter , LANGUAGE ORIGIN, is not set.

which a PMC C board cannot be used.

880

B–63525EN/02

(2) Alarm messages (PMC–SA1)

Message Contents and solution

ALARM NOTHING Normal status

APPENDIX

A. ALARM LIST

ER00 PROGRAM DA TA ERROR(ROM)

ER01 PROGRAM DA TA ERROR(RAM)

ER02 PROGRAM SIZE OVER The size of sequence program exceeds the maximum size of LADDER(PMC–SC

ER03 PROGRAM SIZE ERROR(OPTION)

ER04 PMC TYPE UNMA TCH The PMC model setting of the sequence program is not corresponding to an actual

ER05 PMC MODULE TYPE ERROR

ER07 NO OPTION (LADDER STEP)

The sequence program in the ROM is not written correctly . (solution) Please exchange ROM for the sequence program.

The sequence program in the debugging RAM is defective. (solution) Please clear the debugging RAM and input LADDER again.

The debugging RAM is not installed though the RAM is selected.

(solution) Please install the debugging RAM or install ROM for sequence program

and select ROM with K17#3=0.

only). (solution) Please change MAX LADDER AREA SIZE at the SYSPRM screen and

restart the system.

The size of sequence program exceeds the option specification size. (solution) Please increase the option specification size.

Or, reduce the size of sequence program.

model. (solution) Please change the PMC model setting by the offline programmer.

The module type of the PMC engine is not correct. (solution) Please exchange the module of PMC engine for a correct one.

There is no step number option of LADDER.

ER10 OPTION AREA NOTHING (series name)

ER1 1 OPTION AREA NOTHING (series name)

ER12 OPTION AREA ERROR (series name)

ER13 OPTION AREA ERROR (series name)

ER14 OPTION AREA VERSIION ERROR (series name)

ER15 OPTION AREA VERSIION ERROR (series name)

ER16 RAM CHECK ERROR (PROGRAM RAM)

ER17 PROGRAM P ARITY The parity error occurred on ROM for sequence program or the debugging RAM.

The management software for the PMC–SB has not been transferred. (solution) The sof twar e i nstallat ion is not consi s tent w ith the o rder. Contac t FANUC.

The management software for the PMC C board has not been transferred. (solution) The sof twar e i nstallat ion is not consi s tent w ith the o rder. Contac t FANUC.

The series of the management software for the PMC–RB differs between BASIC and OPTION. (solution) Contact FANUC.

The series of the management software for the PMC C board differs between BASIC and OPTION. (solution) Contact FANUC.

The edition of the management software for the PMC–RB differs between BASIC and OPTION. (solution) Contact FANUC.

The edition of the management software for the PMC C board differs between BASIC and OPTION. (solution) Contact FANUC.

The debugging RAM cannot be read/written normally . (solution) Please exchange the debugging RAM.

(solution) ROM: The deterioration of ROM may be deteriorated

Please exchange ROM for the sequence program

RAM: Please edit the sequence program once on PMC

Still the error occurs, exchange the debugging RAM.

881

APPENDIXA. ALARM LIST

Message Contents and solution

B–63525EN/02

ER18 PROGRAM DATA ERROR BY I/O

ER19 LADDER DA TA ERROR Editing the LADDER was interrupted by the power off or by the switch to the CNC

ER20 SYMBOL/COMMENT DA TA ERROR

ER21 MESSAGE DA TA ERROR Editing the message data was interrupted by the power off or the switch to the CNC

ER22 PROGRAM NOTHING There is no sequence program ER23 PLEASE TURN OFF POW-ERThere is a change in setting LADDER MAX AREA SIZE etc.

ER24 LADDER, LANGUAGE AREA OVERLAP

ER25 SOFTWARE VERSION ERROR (PMCAOPT)

Transferring the sequence program from offline programmer was interrupted by the power off etc. (solution) Please clear the sequence program and transfer the sequence program

again.

screen by the function key etc. (solution) Please edit LADDER once on PMC.

Or, please input LADDER again.

Editing the symbol and comment was interrupted by the power off or by the switch to the CNC screen by the function key etc. (solution) Please edit symbol and comment once on PMC.

Or, please input symbol and comment again.

screen by the function key etc. (solution) Please edit message data once on PMC.

Or, please input message data again.

(solution) Please restart the system to make the change effective. The C program area overlaps the ladder program area.

(solution) Adjust the address range assigned to C programs. The PMC–SB management software editions are inconsistent.

(solution) Contact FANUC.

ER26 SOFTWARE VERSION ERROR (PMCAOPT)

ER27 LADDER FUNC. PRM IS OUT OF RANGE

The PMC–SB management software cannot be initialized. (solution) Contact FANUC.

The parameter number for function instruction TMR, TMRB, CTR, DIFU, or DIFD is not in the range. (solution) Correct the number so that it is within the range.

*When ER00 to ER27 occur, sequence program is not available.

Message Contents and solution

ER32 NO I/O DEVICE Any DI/DO unit of I/O Unit or the connection unit etc. is not connected. When built–in

I/O card is connected, this message is not displayed. (solution) When built–in I/O card is used:

Please confirm whether the built–in I/O card is certainly connected with. When I/O Link is used: Please confirm whether the DI/DO units turning on. Or please confirm the connection of the cable.

ER33 SLC ERROR The LSI for I/O Link is defective.

(solution) Please exchange the module of PMC engine.

ER34 SLC ERROR(xx) The communication with the DI/DO units of the xx group failed.

(solution) Please confirm the connection of the cable connected to the DI/DO

units of the xx group. Please confirm whether the DI/DO units turned on earlier than CNC and PMC. Or, please exchange the module of PMC engine on the DI/DO units of the xx group

882

B–63525EN/02

APPENDIX

Message Contents and solution

A. ALARM LIST

ER35 TOO MUCH OUTPUT DA TA IN GROUP(xx)

ER36 TOO MUCH INPUT DATA IN GROUP(xx)

ER38 MAX SETTING OUTPUT DA TA OVER(xx)

ER39 MAX SETTING INPUT DA TA OVER(xx)

ER98 ILLEGAL LASER CONNECTION

The number of the output data in the xx group exceeded the max. The data, which exceed 32 bytes, become ineffective. (solution) Please refer to the following for the number of the data for each group.

“FANUC I/O Unit–MODEL A connecting and maintenance manual” (B–61813E) “FANUC I/O Unit–MODEL B connecting manual”(B–62163E)

The number of the input data in the xx group exceeded the max. The data, which exceed 32 bytes, become ineffective. (solution) Please refer to the following for the number of the data for each group.

“FANUC I/O Unit–MODEL A connecting and maintenance manual” (B–61813E) “FANUC I/O Unit–MODEL B connecting manual”(B–62163E)

The assignment data for a group exceeds 128 bytes. (The assignment data of output side of xx group or later become ineffective.) (solution) Please reduce the assignment data to 128 bytes or less for the number of the output data of each group.

The assignment data for a group exceeds 128 bytes. (The assignment data of input side of xx group or later become infective.) (Solution) Please reduce the assignment data to 128 bytes or less for the number of

the input data of each goup.

An I/O unit for the laser and assigned data do not match. (solution) Check that the ladder assignment data and actual I/O units match.

ER99 X, Y96–127 ARE ALLOCATED

WN02 OPERA TE PANEL ADDRESS ERROR

WN03 ABORT NC–WINDOW/ EXIN

WN04 UNAVAIL EDIT MODULE The LADDER editing module cannot be recognized.(PMC–SAx/SBxx=1 to 3)

WN05 PMC TYPE NO CONVERSION

WN06 TASK STOPPED BY DEBUG FUNC

WN07 LADDER SP ERROR (STACK)

WN17 NO OPTION (LANGUAGE) There is no C language option.

When the laser I/O link is provided, ladder I/O is assigned to X96–X127 and Y96–Y127. (solution) Delete the data assigned to X96–X127 and Y96–Y127.

The address setting data of the operator’s panel for FS–0 is illegal. (solution) Please correct the address setting data.

LADDER was stopped while CNC and PMC were communicating. The functional instruction WINDR, WINDW, EXIN, DISPB, and etc. may not work normally. (solution) When restarting the system, this alarm will be released. Execute the

sequence program(Press RUN key) after confirming whether there is a problem in LADDER or not.

(solution) Please confirm the slot position installed.

Please confirm the installed module.

A ladder program for the PMC–SA3/SA5 was transferred to the PMC–SB5. (solution) Correct the ladder type.

Some user tasks are stopped by break point of the debugging function.

When functional instruction CALL(SUB65) or CALLU(SUB66) was executed, the stack of the LADDER overflowed. (solution) Please reduce the nesting of the subprogram to 8 or less.

WN18 ORIGIN ADDRESS ERROR

The LANGUAGE ORIGIN address of the system parameter is wrong (solution) Please set the address of symbol RC_CTLB_INIT in the map file to the

LANGUAGE ORIGIN of the system parameter.

883

APPENDIXA. ALARM LIST

Message Contents and solution

B–63525EN/02

WN19 GDT ERROR (BASE,LIMIT)

WN20 COMMON MEM. COUNT OVER

WN21 COMMON MEM. ENTRY ERROR

WN22 LADDER 3 PRIORITY ERROR

WN23 TASK COUNT OVER The number of user tasks exceeds 16.

WN24 T ASK ENTRY ADDR ERROR

WN25 DA TA SEG ENTRY ERROR

The value of BASE, LIMIT or ENTRY of user defined GDT is illegal. (solution) Please correct the address in link control statement and build file.

The number of common memories exceeds 8. (solution) Please reduce the number of common memories to 8 or less. It is

necessary to correct a link control statement,build file and the source file for the common memory .

GDT ENTRY of the common memory is out of range. (solution) Please correct the address of GDT ENTRY of the common memory in the link control statement.

The priority of LADDER LEVEL 3 is out of range. (solution) Please correct the value of LADDER LEVEL 3 in the link control statement

within the range of 0 or 10–99 or –1.

(solution) Please confirm TASK COUNT in the link control statement. When the

number of tasks is changed, it is necessary to correct the link control statement, build file and the composition of the files to be linked.

The selector of the entry address to the user task is out of range. (solution) Please correct the table of GDT in build file to the value within

32(20H)–95(5FH).

The entry address of the data segment is out of range. (solution) Please correct DAT A SEGMENT GDT ENTRY in the link control statement

and the table of GDT in build file within 32(20H)–95(5FH).

WN26 USER TASK PRIORITY ERROR

WN27 CODE SEG TYPE ERROR The code segment type is illegal. The code segment of RENAMESEG in the binding

WN28 DA TA SEG TYPE ERROR The data segment type is illegal. The data segment of RENAMESEG in the binding con-

WN29 COMMON MEM SEG TYPE ERROR

WN30 IMPOSSIBLE ALLOCATE MEM.

WN31 IMPOSSIBLE EXECUTE LIBRARY

The priority of the user task is out of range. (solution) Please correct the TASK LEVEL in link control statement within the

range of 10–99 or –1. Note: Only one task can have TASK LEVEL –1 (including LADDER

LEVEL 3).

control file is wrong. (solution) Please correct the entry of the code segment in the link control statement

to correspond to the entry in the build file.

trol file is wrong. (solution) Please correct the entry of the code segment in the link control statement

to correspond to the entry in the build file.

The segment type of common memory is illegal. The segment of RENAMESEG in the building control file of the common memory is wrong. (solution) Please correct the entry of common memory in the link control statement to correspond to the entry in the build file.

The memories for the data and stack etc. cannot be allocated. (solution) Please confirm whether the value of code segment in build file and USER

GDT ADDRESS in link control statement is correct or not. Or please reduce the value of MAX LADDER AREA SIZE of the system parameter and the size of the stack in link control statement at the least

The library function cannot be executed. (solution) Please confirm the object model of the library.

Or, system ROM of PMC must be replaced with one of later version.

884

B–63525EN/02

APPENDIX

Message Contents and solution

A. ALARM LIST

WN32 LNK CONTROL DATA ERROR

WN33 LNK CONTROL VER. ERROR

WN34 LOAD MODULE COUNT OVER

WN35 CODE AREA OUT OF RANGE

WN36 LANGUAGE SIZE ERROR (OPTION)

WN37 PROGRAM DA TA ERROR (LANG.)

WN38 RAM CHECK ERROR (LANG.)

WN39 PROGRAM P ARITY (LANG.)

WN40 PROGRAM DA TA ERROR BY I/O (LANG.)

Link control statement data is illegal. (solution) Please confirm whether the address of symbol RC_ CTLB_INIT in map file

is set to LANGUAGE ORIGIN of the system parameter. Or , please make the link control statement again.

A link control statement data version error occurred. (Solution) Correct the link control statement in the C program.

The number of independent load modules exceeds eight. (solution) Decrease the number of independent load modules to eight or small

er.

The specified code area is beyond the address range. (solution) Correct the C program.

The size of a C program exceeds the option size. (solution) Decrease the size of the C program.

A C program is destroyed. (solution) Transfer the C program again.

A parity mismatch occurred in a C program. (solution) Transfer the C program again.

Transfer of a C program was interrupted by, for example, a power failure. (solution) Clear the C program, then transfer the C program again.

WN41 LANGUAGE TYPE UNMATCH

WN42 UNDEFINE LANGUAGE ORIGIN ADDRESS

A C program type mismatch occurred. (solution) Correct the C program.

No language origin address is set. (solution) Set the language origin address.

NOTE

Alarms WN17 to WN42 indicate errors related to PMC user C programs.

885

(3) System alarm messages (PMC–SB7)

Message Contents and solution

APPENDIXA. ALARM LIST

B–63525EN/02

1 PC004 CPU ERR

xxxxxxxx:yyyyyyyy

PC006 CPU ERR

xxxxxxxx:yyyyyyyy

PC009 CPU ERR

xxxxxxxx:yyyyyyyy

PC010 CPU ERR

xxxxxxxx:yyyyyyyy

2 PC030 RAM PARITY aa:bb A RAM parity error occurred in the PMC.

3 PC050 I/OLINK(CHx)

aa:bb–aa:bb or PC050 IOLINK CHx

aabb– aabb:aabb

A CPU error occurred in the PMC. xxxxxxxx and yyyyyyyy indicate internal error code.

If this error occurs, the motherboard may be faulty . Replace the motherboard, then check whether the error recurs. If the error still

occurs even after the replacement of the motherboard, report the conditions under which the error occurred (system configuration, operation, time and frequency of error occurrences, etc.) to FANUC.

aa and bb indicate internal error code. If this error occurs, the motherboard may be faulty . Solution)

Replace the motherboard, then check whether the error recurs. If the error still occurs even after the replacement of the motherboard, report the conditions under which the error occurred (system configuration, operation, time and frequency of error occurrences, etc.) and the indicated internal error code to FANUC.

A communication error occurred in the I/O Link. CHx is channel number. aa and bb indicate internal error code.

If this error occurs, the possible causes are as follows: (1) Although the base expansion is assigned when the I/O Unit A is used, the

base is not connected. (2) A cable is not connected securely. (3) Cabling is faulty . (4) I/O equipment (I/O unit, Power Mate, etc.) is faulty . (5) The power to the master or slave unit of the I/O Link is disconnected. (6) A DO–pin short–circuit occurred in an I/O device. (7) The motherboard is faulty .

4 PC060 FBUS

xxxxxxxx:yyyyyyyy

PC061 FL–R

xxxxxxxx:yyyyyyyy

PC062 FL–W

aa: xxxxxxxx:yyyyyyyy

Solution) (1) Check whether the I/O assignment data and the actual I/O equipment con-

nection match. (2) Check whether the cables are connected correctly . (3) According to “FANUC I/O Unit–MODEL A Connection and Maintenance

Manual” (B–61813E) or “FANUC I/O Unit–MODEL B Connection manual”

(B–62163E), check for an error in the cable specifications. (4) Replace the I/O unit interface module, cable, or motherboard. Then, check

whether the error still occurs. A bus error occurred in the PMC.

aa, xxxxxxxx, and yyyyyyyy indicate internal error code. If this error occurs, the hardware may be faulty . Solution)

Report the conditions under which the error occurred (system configuration, operation, time and frequency of error occurrences, tc.), the indicated internal error code, and the LED status on each board to FANUC.

886

B–63525EN/02

5 PC070 SUB65 CALL (STACK) A stack error occurred during execution of ladder function instruction

APPENDIX

Contents and solutionMessage

CALL/CALLU. Solution)

Check the correspondence between the CALL/CALLU instruction and SPE instruction. If the error cannot be located, report the conditions under which the error occurred and the ladder program to F ANUC.

A. ALARM LIST

6 PC080 SYS EMG

xxxxxxxx:yyyyyyyy

PC081 FL EMG

xxxxxxxx:yyyyyyyy

7 PC097 PARITY ERR

(LADDER)

PC098 PARITY ERR (DRAM)

A system alarm was caused by another software. Solution)

Report the conditions under which the error occurred (system configuration, operation, time and frequency of error occurrences, etc.), the indicated internal error code, and the LED status on each board to F ANUC.

A parity error occurred in the PMC system. If this error occurred, the motherboard may be faulty . Solution)

887

APPENDIXA. ALARM LIST

(4) System alarm messages (for the C language board)

Message Contents and solution

B–63525EN/02

1 PC1nn CPU INTERRT

xxxxyyyyyy

ST ATUS LED lL

2 PC130 RAM PRTY aa

xxxxyyyyyy

ST ATUS LED jL

5 PC160 F–BUS ERROR

xxxxyyyyyy PC161 F–BUS ERROR xxxxyyyyyy PC162 F–BUS ERROR xxxxyyyyyy ST ATUS LED Lj

CPU error (abnormal interrupt) nn : Exception code

Exception code of the i80486. For details, refer to the relevant manual that describes the CPU.

00 Division error. For example, the divisor in a division instruction is 0.

12 Stack exception caused by, for example, stack segment limit viola

tion

13 General protection exception generated when, for example, a seg

ment limit is exceeded

xxxx : Segment selector where the system error occurred

A value 0103 to 02FB indicates the C execution area. yyyyyy : Offset address at which the system error occurred (Solution)

If a C program is not used, or if the cause of the error cannot be determined even by checking the C program, contact FANUC.

A parity error occurred in user RAM or DRAM on the C language board. aa : RAM parity error occurrence information xxxx : Segment selector where the system error occurred yyyyyy : Offset address at which the system error occurred

A bus error occurred on the C language board. xxxx : Segment selector where the system error occurred yyyyyy : Offset address at which the system error occurred

6 PC170 F–BUS ERROR

xxxxyyyyyy PC171 F–BUS ERROR xxxxyyyyyy PC172 F–BUS ERROR xxxxyyyyyy ST ATUS LED Lj

7 PC199 ROM PARITY eeeeeeee

ST ATUS LED Ll

ST ATUS LED (green)

j : Off J : On lL : Blink

A bus error occurred on the C language board. xxxx : Segment selector where the system error occurred yyyyyy : Offset address at which the system error occurred

A parity error occurred in system ROM on the C language board. eeeeeeee : ROM parity error information

888

B–63525EN/02

APPENDIX

(5) Alarm messages (For EDIT: PMC–SB7)

Messages displayed during update of the PMC ladder diagram editing

Alarm number Faulty location/corrective action Contents

A. ALARM LIST

OVERLAPPED COM If COME is missing, add it in proper posi-

tion. If the COM is unnecessary , remove it.

END IN COM END1 IN COM END2 IN COM

JMPE IN COM JMPE and corresponding JMP must have

SP/SPE IN COM If COME is missing, add it in proper posi-

COME WITHOUT COM If COM is missing, add it in proper position.

DUPLICATE CTR NUMBER (WARNING)

If COME is missing, add it in proper position. If COM is unnecessary, remove it.

same COM/COME status. Review JMP range and COM range, to adjust not to overlap with each other: it is possible that one range includes the other completely .

tion. If the COM is unnecessary , remove it.

If the COME is unnecessary, remove it. If some of them are unnecessary, remove

them. If all of them are necessary, assign other number to parameter of them to make them unique. (If two or more instructions with same parameter number will never be active simultaneously at one time, the Ladder program has a possibility to work correctly, however, it is recommended from safety and maintenance points of view, that all these instructions should have different parameter number with each other.)

There is no COME that corresponds to this COM.

END,END1,END2, or END3 is found between COM and COME.

JMPE is found between COM and COME, and JMP and corresponding JMPE have different COM/COME status.

SP or SPE is found between COM and COME.

There is no COM that corresponds to this COME.

Plural CTRs have the same number as their parameter. (This is warning.)

ILLEGAL CTR NUMBER If unnecessary, remove it. Assign correct

number not to exceed the maximum number defined by each PMC model.

DUPLICATE DIFU/DIFD NUMBER (WARNING)

ILLEGAL DIFU/DIFD NUMBER If unnecessary, remove it. Assign correct

NO END NO END1 NO END2 NO END3

If some of them are unnecessary, remove them. If all of them are necessary, assign other number to parameter of them to make them unique. (If two or more instructions with same parameter number will never be active simultaneously at one time, the Ladder program has a possibility to work correctly, however, it is recommended from safety and maintenance points of view, that all these instructions should have different parameter number with each other.)

number not to exceed the maximum number defined by each PMC model.

Add END, END1, END2 or END3 in proper position.

CTR has parameter number that is out of range.

Plural DIFUs or DIFDs have the same number as their parameter. (This is warning.)

DIFU or DIFD has parameter number that is out of range.

END, END1, END2 or END3 is not found.

889

APPENDIXA. ALARM LIST

Alarm number ContentsFaulty location/corrective action

B–63525EN/02

DUPLICATE END1 DUPLICATE END2 DUPLICATE END3

GARBAGE AFTER END GARBAGE AFTER END2 GARBAGE AFTER END3

OVERLAPPED JMP If JMPE is missing, add it in proper posi-

JMP/JMPE TO BAD COM LEVEL JMP and corresponding JMPE must have

COME IN JMP COME and corresponding COM must

END IN JMP END1 IN JMP END2 IN JMP END3 IN JMP

Remove extra END1, END2 or END3. Multiple END1, END2 or END3 are

Remove unnecessary nets, and move necessary nets to proper position so that they will be executed.

tion. If the JMP is unnecessary, remove it.

same COM/COME status. Review JMP range and COM range, to adjust not to overlap with each other: it is possible that one range includes the other completely .

have same JMP/JMPE status. Review COM range and JMP range, to adjust not to overlap with each other: it is possible that one range includes the other completely.

If JMPE is missing, add it in proper position. If JMP is unnecessary, remove it.

found.

There are some nets after END, END2 or END3, which will not be executed.

There is no JMPE that corresponds to this JMP.

JMP and corresponding JMPE have different COM/COME status.

COME is found between JMP and JMPE, and COM and corresponding COME have different JMP/JMPE status.

END,END1,END2, or END3 is found between JMP and JMPE.

SP/SPE IN JMP If JMPE is missing, add it in proper posi-

tion. If the JMP is unnecessary, remove it.

JMPB OVER COM BORDER JMPB and its destination must have same

COM/COME status. Review range of JMPB and COM range, to adjust not to overlap with each other: it is possible that one range includes the other completely .

JMPB OVER LEVEL JMPB can only jump to the same program

level, or within a subprogram. If the JMPB is unnecessary, remove it. If LBL for the JMPB is missing, add it in proper position. If it should be JMPC, correct it.

LBL FOR JMPB NOT FOUND If JMPB is unnecessary, remove it. If LBL

is missing, add it in proper position.

JMPC IN BAD LEVEL JMPC is used to jump from a subprogram

to level 2. If the JMPC is unnecessary , remove it. If it should be JMPB or JMP, correct it.

LBL FOR JMPC NOT FOUND If JMPC is unnecessary, remove it. If LBL

is missing, add it in proper position: JMPC jumps into level 2. If it should be JMPB or JMP, correct it.

SP or SPE is found between JMP and JMPE.

JMPB and its destination differ in COM/ COME status.

JMPB jumps to different program level.

Can not find proper LBL for JMPB.

JMPC is used in other than subprogram.

Can not find proper LBL for JMPC.

890

B–63525EN/02

Alarm number ContentsFaulty location/corrective action

APPENDIX

A. ALARM LIST

LBL FOR JMPC IN BAD LEVEL JMPC is used to jump from a subprogram

to level 2. If the JMPC is unnecessary , remove it. If another LBL of same L–address that the JMPC is intended to jump exists in the subprogram, assign different L–address to these two LBLs. If it should be JMPB or JMP, correct it.

JMPC INTO COM LBL for JMPC must be located out of any

COM and COME pair. If the JMPC is unnecessary, remove it. If the LBL is located wrong, move it to correct position. If the L– address of JMPC is wrong, correct it.

JMPE WITHOUT JMP If JMP is missing, add it in proper position.

If the JMPE is unnecessary, remove it.

TOO MANY LBL Remove unnecessary LBLs. If this error

still occurs, adjust the construction of program to use less LBLs.

DUPLICATE LBL If some of these LBLs are unnecessary , re-

move them. If all of these LBLs is necessary , assign other L–addresses to them to make all LBLs unique.

OVERLAPPED SP If SP is missing, add it in proper position. If

the SPE is unnecessary, remove it.

Destination of JMPC is not level 2.

JMPC jumps to LBL between COM and COME.

There is no JMP that corresponds to this JMPE.

There are too many LBLs.

Same L–address is used in plural LBLs.

There is no SP that corresponds to this SPE.

SPE WITHOUT SP If SP is missing, add it in proper position. If

the SPE is unnecessary, remove it.

END IN SP If SPE is missing, add it in proper position.

If END is in wrong place, move it to proper position.

DUPLICATE P ADDRESS If some of these SPs are unnecessary, re-

move them. If all of these SPs is necessary , assign other P–addresses to them to make all SPs unique.

DUPLICATE TMRB NUMBER (WARNING)

ILLEGAL TMRB NUMBER If unnecessary, remove it. Assign correct

number not to exceed the maximum number defined by each PMC model.

There is no SP that corresponds to this SPE.

END is found between SP and SPE.

Same P–address is used in plural SPs.

Plural TMRBs have the same number as their parameter. (This is warning.)

TMRB has parameter number that is out of range.

891

APPENDIXA. ALARM LIST

Alarm number ContentsFaulty location/corrective action

B–63525EN/02

DUPLICATE TMR NUMBER (WARNING)

ILLEGAL TMR NUMBER If unnecessary, remove it. Assign correct

NO SUCH SUBPROGRAM If it calls wrong subprogram, correct it. If the

UNA V AILABLE INSTRUCTION Confirm that this ladder program is correct

SP IN BAD LEVEL SP can be used at top of a subprogram.

number not to exceed the maximum number defined by each PMC model.

subprogram is missing, create it.

one. If this program is correct one, all these unsupported instructions have to be removed.

Correct it so that no SP exists in other place.

Plural TMRs have the same number as their parameter. (This is warning.)

TMR has parameter number that is out of range.

Subprogram that is called by CALL/CALLU is not found.

Unsupported instruction for this PMC model is found.

SP is found in wrong place.

LADDER PROGRAM IS BROKEN This ladder program must be all cleared

once, and remake ladder program. NO WRITE COIL Add proper write coil. Write coil is necessary, but is not found. CALL/CALLU IN BAD LEVEL CALL/CALLU must be used in Level 2 or in

subprograms. Do not use any other

places. SP IN LEVEL3 If END3 is located wrong, move it to correct

position. If the SP is unnecessary , remove

it.

Ladder program may be broken by some reason.

CALL/CALLU is used in wrong place.

SP is found in level 3.

892

B–63525EN/02

Alarm number Faulty location/corrective action Contents

APPENDIX

A. ALARM LIST

Messages that may be displayed during net editing on PMC program editor screen

TOO MANY FUNCTIONAL INSTRUCTIONS IN ONE NET

TOO LARGE NET Divide the net into plural nets so that step

NO INPUT FOR OPERA TION Coil without input, or coil connected to out-

OPERATION AFTER FUNCTION IS FORBIDDEN

WRITE COIL IS EXPECTED Add proper write coil to the net. Write coil is expected, but not found. BAD COIL LOCA TION Coil can be located only at rightmost col-

SHORT CIRCUIT Find contact with terminals connected by

Only one functional instruction is allowed

to constitute a net. If necessary, divide the

net into plural nets.

number in a net may become small.

put of functional instruction that has no out-

put, causes this error. If coil is not neces-

sary , remove it. If necessary, connect it to

meaningful input.

Output of functional instruction can not be

connected to a contact, nor to conjunction

with other signal that will be implemented

by logical–or operation.

umn. Any coil located at other place must

be erased once, and place necessary coils

in correct place.

short circuit, and correct connections.

Too many functional instructions are in one net.

Net is too large. When a net is converted into the object, the net exceeds 256 steps.

No signal is provided for logical operation.

No logical operation with functional instruction output is permitted, except write coils.

Coil is located in bad position.

Some contacts are connected with short circuit.

FUNCTION AFTER DIVERGENCE IS FORBIDDEN

ALL COIL MUST HAVE SAME INPUT

BAD CONDITION INPUT Check the connection of all condition in-

NO CONNECTION Find gap that is expected to be connected,

NET IS TOO COMPLICATED Examine every connection, and find un-

P ARAMETER IS NOT SUPPLIED Enter all of the relay addresses, and pa-

Functional instruction can not be used in

output section of net. If necessary, divide

the net into plural nets.

Left terminals of all coils in a net must be

connected to same input point.

puts of the functional instruction. Especial-

ly for functional instruction that has more

than one condition input, check if connec-

tions to condition inputs interfere with each

other.

and correct the connection.

necessarily bending connection, or coils

that are connected to different point.

rameters of functional instructions.

Functional instruction is used in output section of net.

When a net contains more than one coil, the coils should not have any contact beside them affects only of the coils.

Some condition input of functional instruction is not connected correctly .

There is signal connected to nowhere.

Net is too complicated to analyze.

Relay with blank address, or blank parameter of functional instruction, is found.

893

APPENDIXA. ALARM LIST

B–63525EN/02

(6) Alarm messages (For EDIT)

Message Contents and solution

ADDRESS BIT NOTHING The address of the relay/coil is not set. FUNCTION NOT FOUND There is no functional instruction of the input number. COM FUNCTION MISSING The funcitonal instruction COM (SUB29) is not correctly dealt with.

Correspondence of COM and COME (SUB29) is incorrect.

Or, the number of coil controlled by COM is specified by the model which the number

cannot be specified. EDIT BUFFER OVER There in no empty area of the buffer for the editing.

(solution) Please reduce NET under editing. END FUNCTION MISSING Functional instruction END1,END2,END3 and END do not exist. Or, there are error net

in END1,END2,END3,END.

Or, order of END1,END2,END3, and END is not correct. ERROR NET FOUND There is an error net. ILLEGAL FUNCTION NO. The wrong number of the functional instruction is searched. FUNCTION LINE ILLEGAL The functional instruction is not correctly connected. HORIZONTAL LINE ILLEGAL The horizontal line of the net is not connected. ILLEGAL NET CLEARED Because the power had been turn off while editing LADDER, some net under editing

was cleared. ILLEGAL OPERA TION Operation is not correct.

The value is not specified and only INPUT key was pushed.

The address data is not correctly inputted.

Because the space to display the instruction on screen is not enough, the functional

instruction cannot be made. SYMBOL UNDEFINED The symbol which was inputted is not defined. INPUT INV ALID There is an incorrect input data.

Non–numerical value was inputted with COPY, INSLIN,C–UP,C–DOWN etc.

The input address was specified for write coil.

An illegal character was specified for the data table. NET TOO LARGE The input net is larger than the editing buffer.

(solution) Please reduce the net under editing. JUMP FUNCTION MISSING The functional instruction JMP(SUB10) is not correctly dealt with.

Correspondence of JMP and JMPE(SUB30) is incorrect.

The number of coil to jump is specified by the model which the number of coil cannot

specified. (It is possible to specify the coil number only on PMC–RB/RC.) LADDER BROKEN LADDER is broken. LADDER ILLEGAL There is an incorrect LADDER. IMPOSSIBLE WRITE You try to edit sequence program on the ROM. OBJECT BUFFER OVER The sequence program area was filled.

(solution) Please reduce the LADDER. P ARAMETER NOTHING There is no parameter of the functional instruction. PLEASE COMPLETE NET The error net was found in LADDER.

(solution) After correcting the error net, please continue operating.

894

B–63525EN/02

Message Contents and solution

PLEASE KEY IN SUB NO. Please input the number of the functional instruction.

(solution) If you do not input the functional instruction, please push soft key “FUNC”

PROGRAM MODULE NOTHING You tried to edit though there was neither RAM for debugging nor ROM for sequence

program. RELA Y COIL FORBIT There is an unnecessary relay or coil. RELA Y OR COIL NOTHING The relay or the coil does not suffice. PLEASE CLEAR ALL It is impossible to recover the sequence program.

(solution) Please clear the all data. SYMBOL DA TA DUPLICATE The same symbol name is defined in other place. COMMENT DA TA OVERFLOW The comment data area was filled.

(solution) Please reduce the number of the commnet. SYMBOL DA TA OVERFLOW The symbol data area was filled.

(solution) Please reduce the number of the symbol. VERTICAL LINE ILLEGAL There is an incorrect vertical line of the net.

APPENDIX

again.

A. ALARM LIST

MESSAGE DA TA OVERFLOW The message data area was filled.

(solution) Please reduce the number of the message. 1ST LEVEL EXECUTE TIME

OVER P ARA NO. RANGE ERR: The parameter number for a function instruction is not in the range.

P ARA NO. DUPLICATE: The parameter number for a function instruction is used more than once.

The 1st level of LADDER is too large to complete execution in time.

(solution) Please reduce the 1st level of LADDER.

(solution) Correct the number so that it is within the range.

(solution) If the duplicate numbers pose the problem of simultaneous operation,

change the parameter number to an unused number.

895

APPENDIXA. ALARM LIST

(7) Error Messages (at Automatic Write to Flash ROM after Ladder Editing)

Error message Contents and solution

PROGRAM ALREADY EXISTS A program already exists on flash ROM. (At BLANK)

B–63525EN/02

PROGRAM ALREADY EXISTS (EXEC?)

PROGRAM NOTHING There is no program on flash ROM. ERASE ERROR

F–ROM WRITE ERROR 13 F–ROM WRITE ERROR 28

WRITE ERROR F–ROM WRITE ERROR 12 F–ROM WRITE ERROR 29

READ ERROR ANOTHER USED

F–ROM WRITE ERROR 9 F–ROM WRITE ERROR 36

MUST BE IN EMG STOP NOT EMG STOP F–ROM WRITE ERROR 10 F–ROM WRITE ERROR 37

NO OPTION There is no ROM cassette option. SIZE ERROR

IMPOSSIBLE WRITE (SIZE OVER) NO SPACE F–ROM WRITE ERROR 1 F–ROM WRITE ERROR 15 F–ROM WRITE ERROR 35

A program already exists on flash ROM.

(Remedy) When the message is displayed, pressing the EXEC key again causes

write or erasure operation. (At write or erasure)

Flash ROM is abnormal. Replacement is required.

Ask FANUC Service Representative for replacement.

Flash ROM is used by other than PMC.

The CNC is not in the emergency stop state.

The sequence program is larger than the flash ROM size. (At write)

(Remedy) Try the condense function. (EDIT/CLEAR screen) If the same phenome-

non is still observed, the flash ROM size must be enlarged.

The sequence program to be read is larger than the RAM size. (At read)

(Remedy) RAM must be enlarged.

896

B–63525EN/02

APPENDIX

A. ALARM LIST

(8) Error Messages (at Assignment Data Editing)

Message Contents and solution

ERR: GROUP NO. (0—15) The group number must be 0 to 15. ERR: BASE NO. (0—1) The base number must be 0 or 1. WARN: BASE NO. MUST BE 0 For I/O Unit–B, the base number must be 0. The base number was set to 0 forcibly. ERR: SLOT NO. (1—10) For I/O Unit–A, the slot number must be 1 to 10. ERR: SLOT NO. (0, 1—30) For I/O Unit–B, the slot number must be 0 or a number 1 to 30. ERR: SLOT NO. MUST BE 0 When power on/off information for I/O Unit–B is set, the slot number must be 0. ERR: ILLEGAL NAME The input assignment name is illegal or not supported. Enter a correct name. INPUT INV ALID The input character string is illegal. Enter a character string in a correct input format

again. IMPOSSIBLE WRITE An attempt was made to edit ROM data. ROM data cannot be edited. ERR: ADDRESS ALREADY

ASSIGNED ERR: ADDRESS OVER A set address exceeds the maximum value (X127, Y127). Check the addresses dedi-

ERR: SLOT ALREADY DEFINED The specified slot is already assigned. Check the existing data. WARN: SLOT ALREADY

DEFINED ERR: UNIT TYPE MISMA TCH

(IN OR OUT) WARN: UNIT TYPE MISMATCH

(MODEL)

The specified address is already assigned. Assign another address. Alternatively, de-

lete the existing data, then set the address again.

cated to the unit to be set.

The specified slot is already assigned. Check the existing data.

An output module cannot be allocated to an X address, or an input module cannot be

allocated to a Y address.

I/O Unit–A and I/O Unit–B are assigned to the same group. These units cannot exist

together within the same group.

897

APPENDIXA. ALARM LIST

(9) Alarm messages (For I/O)

Error message Contents and solution

PROGRAM ALREADY EXISTS A program already exists on flash ROM. (At BLANK)

B–63525EN/02

PROGRAM ALREADY EXISTS (EXEC ?)

PROGRAM NOTHING There is no program on flash ROM. ERASE ERROR

F L

WRITE ERROR

READ ERROR

S H

ANOTHER USED Flash ROM is used by other than PMC.

MUST BE IN EMG STOP

NOT EMG STOP

NO OPTION There is no ROM cassette option. SIZE ERROR The sequence program is larger than the flash ROM size. (At write)

I/O OPEN ERROR nn nn = –1: RS–232C is used by other than PMC.

I/O WRITE ERROR nn nn = 20: RS–232C connection is incorrect.

S T

· F D C

I/O READ ERROR nn nn = 20: RS–232C connection is incorrect.

A S

T H

ADDRESS IS OUT OF RANGE

(xxxxxx)

R S

DA TA ERROR Illegal data was read.

A program already exists on flash ROM. Remedy) When the message is displayed, pressing the EXEC key again

causes write or erasure operation. (At write or erasure)

Flash ROM is abnormal. Replacement is required. Ask FANUC Service Representative for replacement.

The CNC is not in the emergency stop state.

Remedy) Try the condense function. (EDIT/CLEAR screen) If the same

phenomenon is still observed, the flash ROM size must be en-

larged. The sequence program to be read is larger than the RAM size. (At read) Remedy) RAM must be enlarged.

Remedy) Check whether RS–232C is used by other than PMC.

On the online setting screen (see Section 8.5.1 in III), check

that “NOT USE” is indicated for RS–232C. nn = 6: The RS–232C option is not found. nn = 20: RS–232C connection is incorrect. Remedy) Check whether channel setting, connection, baud rate, and

other settings are correct.

Remedy) Check whether channel setting, connection, baud rate, and

other settings are correct. nn = 22: Communication cannot be performed correctly .

Remedy) Check whether the cable is broken.

Remedy) Check whether channel setting, connection, baud rate, and

other settings are correct. nn = 22: Communication cannot be performed correctly . Remedy) Check whether the cable is broken.

Data for other than the PMC debugging RAM area was transferred. xxxxxx: Indicates the transfer address.

Remedy) Check the cable and setting (speed). When a program in C was being read into the 16i/18i/21i: Remedy) Press soft keys [EDIT], [CLEAR], [CLRLNG], then [EXEC] to

clear the C area.

PROGRAM DA TA ERROR An attempt was made to output data, but the data was illegal.

Remedy) Check the alarm on the alarm screen.

898

B–63525EN/02

CREA TE ERROR The specified file name is illegal.

NO MORE SP ACE or WRITE ERROR There is not enough free space on the memory card.

NOT READY No memory card is installed.

MOUNT ERROR Unformatted.

WRITE PROTECT The memory card is protected.

BA TTER Y ALARM The battery for the memory card is too weak.

FILE NOT FOUND The specified file number or file name is not found.

E M O

DELETE ERROR The file cannot be deleted.

PROGRAM ALREADY EXISTS There are duplicate file names.

I/O WRITE ERROR nn I/O READ ERROR nn I/O COMPARE ERROR nn I/O DELETE ERROR nn I/O LIST ERROR nn I/O FORMAT ERROR nn

APPENDIX

Contents and solutionError message

Remedy) Specify a file name in the MS–DOS form. (See 7.2 (5))

Remedy) Delete files to create free space.

Remedy) Check whether a memory card is installed.

Remedy) Perform formatting. (See 7.3.4 (a))

Remedy) Set the protect switch of the memory card to OFF.

Remedy) Replace the memory card battery .

Remedy) With LIST, check the file name or file number.

Remedy) Change the file attribute.

Remedy) Use another file name. nn = 30: No memory card is installed.

Remedy) Check whether a memory card is installed. nn = 31: The memory card cannot be written to. Remedy) Set the protect switch of the memory card to OFF.

Replace the memory card with an S–RAM card. nn = 32: The battery for the memory card is too weak. Remedy) Replace the memory card battery . nn = 102: There is not enough free space on the memory card. Remedy) Delete files to create free space. nn = 135: The memory card is unformatted. nn = 105: The memory card is unformatted. Remedy) Format the memory card. nn = 114: The specified file is not found. Remedy) With LIST, check the file name or file number. nn = 115: The specified file is protected. Remedy) Check the file attribute.

A. ALARM LIST

COMPARE ERR XXXXXX=AA : BB CONT? (Y/N)

C O M

DA TA ERROR Illegal data has been read.

M O

PROGRAM DA TA ERROR An attempt was made to output data, but the data was illegal.

Data differs between the device and PMC. XXXXXX: Address aa: Data on the PMC bb: Data on the device Remedy) T o continue operation, enter Y; otherwise, enter N. Then, press

the INPUT key .

Remedy) Check the cable and setting (speed). When a program in C was being read into the 16i/18i/21i: Remedy) Press soft keys [EDIT], [CLEAR], [CLRLNG], then [EXEC] to

clear the C area.

Remedy) Check the alarm on the alarm screen.

899

A.3

APPENDIXA. ALARM LIST

B–63525EN/02

ALARM LIST (SERIAL SPINDLE)

When a serial spindle alarm occurs, the following number is displayed on the CNC. n is a number corresponding to the spindle on which an alarm occurs. (n = 1: First spindle; n = 2: Second spindle; etc.)

NOTE*1

Note that the meanings of the SPM indications differ depending on which LED, the red or yellow LED, is on. When the red LED is on, the SPM indicates a 2–digit alarm number. When the yellow LED is on, the SPM indicates an error number that designates a sequence problem (for example, when a rotation command is entered with the emergency stop state not released). ³ See Appendix A.4, “Error Codes (Serial Spindle).”

Alarm Numbers and Alarms Displayed on the α Series Spindle Amplifier

SPM in-

No. Message

(750) SPINDLE SERIAL LINK

ERROR

dica-

tion(*1)

A0A1 Replace the ROM on the SPM

Faulty location and remedy Description

control printed circuit board.

2 Replace the SPM control printed

circuit board.

The program does not start normally. ROM series error or hardware abnormality on the SPM control printed circuit board

(749) S–SPINDLE LSI ERROR A1 Replace the SPM control printed cir-

cuit board.

7n01 SPN_n_ : MOTOR OVER-

HEAT

7n02 SPN_n_ : EX SPEED ER-

ROR

7n03 SPN_n_ : FUSE ON DC

LINK BLOWN

01 1 Check and correct the peripheral

temperature and load status.

2 If the cooling fan stops, replace it.

02 1 Check and correct the cutting

conditions to decrease the load.

2 Correct parameter No. 4082.

03 1 Replace the SPM unit.

2 Check the motor insulation status. 3 Replace the interface cable.

An abnormality was detected in the CPU peripheral circuit of the SPM control circuit.

The thermostat embedded in the motor winding operated. The internal temperature of the motor exceeds the specified level. The motor is used in excess of the continuous rating, or the cooling component is abnormal.

The motor speed cannot follow a specified speed. An excessive motor load torque is detected. The acceleration/deceleration time in parameter No. 4082 is insufficient.

The PSM becomes ready (00 is indicated), but the DC link voltage is too low in the SPM. The fuse in the DC link section in the SPM is blown. (The power device is damaged or the motor is ground– fault.) The JX1A/JX1B connection cable is abnormal.

7n04 SPN_n_ : INPUT FUSE/

POWER FAULT

04 Check the state of the input power

supply to the PSM.

900

The PSM found a missing power supply phase. (PSM alarm 5)

B–63525EN/02

SPM in-

No. DescriptionFaulty location and remedy

Message

dica-

tion(*1)

APPENDIX

A. ALARM LIST

7n06 SPN_n_ : THERMAL

SENSOR DISCONNECT

7n07 SPN_n_ : OVERSPEED 07 Check for a sequence error. (For ex-

7n09 SPN_n_ : OVERHEAT

MAIN CIRCUIT

7n11 SPN_n_ : OVERVOLT

POW CIRCUIT

7n12 SPN_n_ : OVERCUR-

RENT POW CIRCUIT

06 1 Check and correct the parameter.

2 Replace the feedback cable.

ample, check whether spindle synchronization was specified when the spindle could not be turned.)

09 1 Improve the heat sink cooling sta-

tus.

2 If the heat sink cooling fan stops,

replace the SPM unit.

11 1 Check the selected PSM.

2 Check the input power voltage and

change in power during motor deceleration. If the voltage exceeds 253 VAC (for the 200–V system) or 530 VAC (for the 400–V system), improve the power supply impedance.

12 1 Check the motor insulation status.

2 Check the spindle parameters. 3 Replace the SPM unit.

The temperature sensor of the motor is disconnected.

The motor speed has exceeded 1 15% of its rated speed. When the spindle axis was in position control mode, positional deviations were accumulated excessively (SFR and SRV were turned off during spindle synchronization.)

Abnormal temperature rise of the power transistor radiator

Overvoltage of the DC link section of the PSM was detected. (PSM alarm indication: 7) PSM selection error. (The maximum output specification of the PSM is exceeded.)

The motor output current is abnormally high. A motor–specific parameter does not match the motor model. Poor motor insulation

7n15 SPN_n_ : SP SWITCH

CONTROL ALARM

7n16 SPN_n_ : RAM FAUL T 16 Replace the SPM control printed cir-

7n18 SPN_n_ : SUMCHECK

ERROR PGM DATA

7n19 SPN_n_ : EX OFFSET

CURRENT U

7n20 SPN_n_ : EX OFFSET

CURRENT V

7n21 SPN_n_ : POS SENSOR

POLARITY ERROR

15 1 Check and correct the ladder se-

quence.

2 Replace the switching MC.

cuit board.

18 Replace the SPM control printed cir-

cuit board.

19 Replace the SPM unit. Abnormality in an SPM component is

20 Replace the SPM unit. Abnormality in an SPM component is

21 Check and correct the parameters.

(No. 4000#0, 4001#4)

The switch sequence in spindle switch/output switch operation is abnormal. The switching MC contact status check signal and command do not match.

Abnormality in an SPM control circuit component is detected. (RAM for external data is abnormal.)

Abnormality in an SPM control circuit component is detected. (Program ROM data is abnormal.)

detected. (The initial value for the U phase current detection circuit is abnormal.)

detected. (The initial value of the V phase current detection circuit is abnormal.)

The polarity parameter setting of the position sensor is wrong.

901

APPENDIXA. ALARM LIST

SPM in-

No. DescriptionFaulty location and remedy

Message

dica-

tion(*1)

B–63525EN/02

7n24 SPN_n_ : SERIAL

TRANSFER ERROR

7n26 SPN_n_ : DISCONNECT

C–VELO DETECT

7n27 SPN_n_ : DISCONNECT

POS–CODER

7n28 SPN_n_ : DISCONNECT

C–POS DETECT

7n29 SPN_n_ : SHORTTIME

OVERLOAD

24 1 Place the CNC–to–spindle cable

away from the power cable.

2 Replace the cable.

26 1 Replace the cable.

2Re–adjust the pre–amplifier.

27 1 Replace the cable.

2Re–adjust the BZ sensor signal.

28 1 Replace the cable

2Re–adjust the pre–amplifier.

29 Check and correct the load status. Excessive load has been applied

The CNC power is turned off (normal power–off or broken cable). An error is detected in communication data transferred to the CNC.

The signal amplitude of the detection signal (connector JY2) on the Cs contour control motor side is abnormal. (Unconnected cable, adjustment error , etc.)

1 The spindle position coder (con-

nector JY4) signal is abnormal.

2 The signal amplitude (connector

JY2) of the MZ or BZ sensor is abnormal. (Unconnected cable, adjustment error , etc.)

The position detection signal (connector JY5) for Cs contour control is abnormal. (Unconnected cable, adjustment error , etc.)

continuously for a certain period of time. (This alarm is issued also when the motor shaft has been locked in the excitation state.)

7n30 SPN_n_ : OVERCUR-

RENT POW CIRCUIT

7n31 SPN_n_ : MOTOR LOCK

OR V–SIG LOS

7n32 SPN_n_ : RAM FAUL T

SERIAL LSI

7n33 SPN_n_ : SHORTAGE

POWER CHARGE

30 Check and correct the power supply

voltage.

31 1 Check and correct the load status.

2 Replace the motor sensor cable

(JY2 or JY5).

32 Replace the SPM control printed cir-

cuit board.

33 1 Check and correct the power sup-

ply voltage.

2 Replace the PSM unit.

Overcurrent is detected in PSM main circuit input. (PSM alarm indication:

1) Unbalanced power supply. PSM selection error (The maximum PSM output specification is exceeded.)

The motor cannot rotate at a specified speed. (A level not exceeding the SST level for the rotation command has existed continuously.) Abnormality in the speed detection signal.

Abnormality in an SPM control circuit component is detected. (The LSI device for serial transfer is abnormal.)

Charging of direct current power supply voltage in the power circuit section is insufficient when the magnetic contractor in the amplifier is turned on (such as open phase and defective charging resistor).

902

B–63525EN/02

SPM in-

No. DescriptionFaulty location and remedy

Message

dica-

tion(*1)

APPENDIX

A. ALARM LIST

7n34 SPN_n_ : PARAMETER

SETTING ERROR

7n35 SPN_n_ : EX SETTING

GEAR RA TIO

7n36 SPN_n_ : OVERFLOW

ERROR COUNTER

7n37 SPN_n_ : SPEED DE-

TECT P AR. ERROR

7n39 SPN_n_ : 1–ROT Cs SIG-

NAL ERROR

7n40 SPN_n_ : NO 1–ROT Cs

SIGNAL DETECT

7n41 SPN_n_ : 1–ROT POS–

CODER ERROR

34 Correct a parameter value according

to the manual. If the parameter number is unknown, connect the spindle check board, and check the indicated parameter.

35 Correct the value according to the pa-

rameter manual.

36 Check whether the position gain val-

ue is too large, and correct the value.

37 Correct the value according to the pa-

rameter manual.

39 1 Adjust the 1–rotation signal in the

pre–amplifier. 2 Check the cable shield status. 3 Replace the cable.

40 1 Adjust the 1–rotation signal in the

pre–amplifier. 2 Check the cable shield status. 3 Replace the cable.

41 1 Check and correct the parameter.

2 Replace the cable. 3Re–adjust the BZ sensor signal.

Parameter data exceeding the allowable limit is set.

Gear ratio data exceeding the allowable limit is set.

An error counter overflow occurred.

The setting of the parameter for the number of pulses in the speed detector is incorrect.

An incorrect relationship between the 1–rotation signal and the number of AB phase pulses was detected during Cs contour control.

The 1–rotation signal is not generated during Cs contour control.

1 The 1–rotation signal of the

spindle position coder (connector JY4) is abnormal.

2 The 1–rotation signal (connector

JY2) of the MZ or BZ sensor is abnormal.

3 Parameter setting error

7n42 SPN_n_ : NO 1–ROT.

POS–CODER DETECT

7n43 SPN_n_ : DISCON. PC

FOR DIF. SP. MODE

7n44 SPN_n_ : CONTROL

CIRCUIT(AD) ERROR

7n46 SPN_n_ : SCREW

1–ROT POS– COD. ALARM

42 1 Replace the cable.

2Re–adjust the BZ sensor signal.

43 Replace the cable. The differential speed position coder

44 Replace the SPM control printed cir-

cuit board.

46 1 Check and correct the parameter.

2 Replace the cable. 3Re–adjust the BZ sensor signal.

1 The 1–rotation signal of the

spindle position coder (connector JY4) is disconnected.

2 The 1–rotation signal (connector

JY2) of the MZ or BZ sensor is disconnected.

signal (connector JY8) in SPM type 3 is abnormal.

Abnormality in an SPM control circuit component was detected (A/D converter abnormality).

An abnormality equivalent to alarm 41 was detected during thread cutting operation.

903

APPENDIXA. ALARM LIST

SPM in-

No. DescriptionFaulty location and remedy

Message

dica-

tion(*1)

B–63525EN/02

7n47 SPN_n_ : POS–CODER

SIGNAL ABNORMAL

7n49 SPN_n_ : HIGH CONV.

DIF. SPEED

7n50 SPN_n_ : SPNDL CON-

TROL OVERSPEED

7n51 SPN_n_ : LOW VOLT DC

LINK

47 1 Replace the cable.

2Re–adjust the BZ sensor signal. 3 Correct the cable layout (vicinity of

the power line).

49 Check whether the calculated differ-

ential speed value exceeds the maximum motor speed.

50 Check whether the calculated value

exceeds the maximum motor speed.

51 1 Check and correct the power sup-

ply voltage. 2 Replace the MC.

1 The A/B phase signal of the

spindle position coder (connector JY4) is abnormal.

2 The A/B phase signal (connector

JY2) of the MZ or BZ sensor is ab-

normal. The relationship between the A/B phase and 1–rotation signal is incorrect (Pulse interval mismatch).

In differential speed mode, the speed of the other spindle converted to the speed of the local spindle has exceeded the allowable limit (the differential speed is calculated by multiplying the speed of the other spindle by the gear ratio).

In spindle synchronization, the speed command calculation value exceeded the allowable limit (the motor speed is calculated by multiplying the specified spindle speed by the gear ratio).

Input voltage drop was detected. (PSM alarm indication: 4) (Momentary power failure or poor MC contact)

7n52 SPN_n_ : ITP SIGNAL

ABNORMAL I

7n53 SPN_n_ : ITP SIGNAL

ABNORMAL II

7n54 SPN_n_ : OVERLOAD

CURRENT

7n55 SPN_n_ : POWER LINE

SWITCH ERROR

7n56 SPN_n_ : INNER COOL-

ING FAN STOP

7n57 SPN_n_ : EX DECEL-

ERATION POWER

52 1 Replace the SPM control printed

circuit board.

2 Replace the spindle interface

printed circuit board in the CNC.

53 1 Replace the SPM control printed

circuit board.

2 Replace the spindle interface

printed circuit board in the CNC.

54 Review the load state. An overload current was detected.

55 1 Replace the magnetic contactor.

2 Check and correct the sequence.

56 Replace the SPM unit. The cooling fan in the SPM control cir-

57 1 Decrease the acceleration/decel-

eration duty.

2 Check the cooling condition (pe-

ripheral temperature).

3 If the cooling fan stops, replace the

resistor.

4 If the resistance is abnormal, re-

place the resistor.

NC interface abnormality was detected (the ITP signal stopped).

The power line state signal of the magnetic contactor for selecting a spindle or output is abnormal.

cuit stopped. An overload was detected in the re-

generative resistance. (PSMR alarm indication: 8) Thermostat operation or short–time overload was detected. The regenerative resistor was disconnected, or an abnormal resistance was detected.

904

B–63525EN/02

SPM in-

No. DescriptionFaulty location and remedy

Message

dica-

tion(*1)

APPENDIX

A. ALARM LIST

7n58 SPN_n_ : OVERLOAD IN

PSM

7n59 SPN_n_ : COOLING FAN

STOP IN PSM

7n62 SPN_n_ : MOTOR VCMD

OVERFLOWED

7n66 SPN_n_ : AMP MODULE

COMMUNICATION

7n73 SPN_n_ : MOTOR SEN-

SOR DISCONNECTED

7n74 SPN_n_ : CPU TEST ER-

ROR

7n75 SPN_n_ : CRC ERROR 75 Replace the SPM control printed–cir-

7n79 SPN_n_ : INITIAL TEST

ERROR

7n81 SPN_n_ : 1–ROT MO-

TOR SENSOR ERROR

58 1 Check the PSM cooling status.

2 Replace the PSM unit.

59 Replace the SPM unit. The cooling fan in the PSM stopped.

62 Check and correct the parameters.

(No. 4021, 4056 to 4059)

66 1 Replace the cable.

2 Check and correct the connection.

73 1 Replace the feedback cable.

2 Check the shield processing. 3 Check and correct the connection. 4 Adjust the sensor.

74 Replace the SPM control printed–cir-

cuit board.

79 Replace the SPM control printed–cir-

cuit board.

81 1 Check and correct the parameter.

2 Replace the feedback cable. 3 Adjust the sensor.

The temperature of the radiator of the PSM has increased abnormally. (PSM alarm indication: 3)

(PSM alarm indication: 2) The specified motor speed is too

large. An error was found in communication

between amplifiers.

The motor sensor feedback signal is not present.

An error was detected in a CPU test.

An error was detected in a CRC test.

An error was detected in an initial test operation.

The one–rotation signal of the motor sensor cannot be correctly detected.

7n82 SPN_n_ : NO 1–ROT

MOTOR SENSOR

7n83 SPN_n_ : MOTOR SEN-

SOR SIGNAL ERROR

7n84 SPN_n_ : SPNDL SEN-

SOR DISCONNECTED

7n85 SPN_n_ : 1–ROT SPNDL

SENSOR ERROR

7n86 SPN_n_ : NO 1–ROT

SPNDL SENSOR ERROR

7n87 SPN_n_ : SPNDL SEN-

SOR SIGNAL ERROR

82 1 Replace the feedback cable.

2 Adjust the sensor.

83 1 Replace the feedback cable.

2 Adjust the sensor.

84 1 Replace the feedback cable.

2 Check the shield processing. 3 Check and correct the connection. 4 Check and correct the parameter. 5 Adjust the sensor.

85 1 Check and correct the parameter.

2 Replace the feedback cable. 3 Adjust the sensor.

86 1 Replace the feedback cable.

2 Adjust the sensor.

87 The one–rotation signal of the spindle

sensor is not generated.

The one–rotation signal of the motor sensor is not generated.

An irregularity was detected in a motor sensor feedback signal.

The spindle sensor feedback signal is not present.

The one–rotation signal of the spindle sensor cannot be correctly detected.

The one–rotation signal of the spindle sensor is not generated.

An irregularity was detected in a spindle sensor feedback signal.

905

APPENDIXA. ALARM LIST

SPM in-

No. DescriptionFaulty location and remedy

Message

dica-

tion(*1)

B–63525EN/02

7n88 SPN_n_ : COOLING RA-

DIFAN FAILURE

7n97 SPN_n_ : OTHER

SPINDLE ALARM

7n98 SPN_n_ : OTHER CON-

VERTER ALARM

No. Message

9001 SPN_n_ : MOTOR OVER-

HEAT

9002 SPN_n_ : EX SPEED ER-

ROR

88 Replace the SPM external cooling

fan.

97 Replace the SPM. Another irregularity was detected.

98 Check the PSM alarm display. A PSM alarm was detected.

SPM in-

dica-

tion(*1)

01 1 Check and correct the peripheral

02 1 Check and correct the cutting

Faulty location and remedy Description

temperature and load status.

2 If the cooling fan stops, replace it.

conditions to decrease the load.

2 Correct parameter No. 4082.

The external cooling fan stopped.

The motor speed cannot follow a specified speed. An excessive motor load torque is detected. The acceleration/deceleration time in parameter No. 4082 is insufficient.

9003 SPN_n_ : FUSE ON DC

LINK BLOWN

9006 SPN_n_ : THERMAL

SENSOR DISCONNECT

9007 SPN_n_ : OVERSPEED 07 Check for a sequence error. (For ex-

9009 SPN_n_ : OVERHEAT

MAIN CIRCUIT

03 1 Replace the SPM unit.

2 Check the motor insulation status. 3 Replace the interface cable.

06 1 Check and correct the parameter.

2 Replace the feedback cable.

ample, check whether spindle synchronization was specified when the spindle could not be turned.)

09 1 Improve the heat sink cooling sta-

tus.

2 If the heat sink cooling fan stops,

replace the SPM unit.

The temperature sensor of the motor is disconnected.

Abnormal temperature rise of the power transistor radiator

906

B–63525EN/02

SPM in-

No. DescriptionFaulty location and remedy

Message

dica-

tion(*1)

APPENDIX

A. ALARM LIST

9011 SPN_n_ : OVERVOLT

POW CIRCUIT

9012 SPN_n_ : OVERCUR-

RENT POW CIRCUIT

9015 SPN_n_ : SP SWITCH

CONTROL ALARM

9016 SPN_n_ : RAM FAUL T 16 Replace the SPM control printed cir-

9018 SPN_n_ : SUMCHECK

ERROR PGM DATA

11 1 Check the selected PSM.

2 Check the input power voltage and

change in power during motor deceleration. If the voltage exceeds 253 VAC (for the 200–V system) or 530 VAC (for the 400–V system), improve the power supply impedance.

12 1 Check the motor insulation status.

2 Check the spindle parameters. 3 Replace the SPM unit.

15 1 Check and correct the ladder se-

quence.

2 Replace the switching MC.

cuit board.

18 Replace the SPM control printed cir-

cuit board.

Overvoltage of the DC link section of the PSM was detected. (PSM alarm indication: 7) PSM selection error. (The maximum output specification of the PSM is exceeded.)

The motor output current is abnormally high. A motor–specific parameter does not match the motor model. Poor motor insulation

The switch sequence in spindle switch/output switch operation is abnormal. The switching MC contact status check signal and command do not match.

Abnormality in an SPM control circuit component is detected. (RAM for external data is abnormal.)

Abnormality in an SPM control circuit component is detected. (Program ROM data is abnormal.)

9019 SPN_n_ : EX OFFSET

CURRENT U

9020 SPN_n_ : EX OFFSET

CURRENT V

9021 SPN_n_ : POS SENSOR

POLARITY ERROR

9024 SPN_n_ : SERIAL

TRANSFER ERROR

9027 SPN_n_ : DISCONNECT

POS–CODER

19 Replace the SPM unit. Abnormality in an SPM component is

detected. (The initial value for the U phase current detection circuit is abnormal.)

20 Replace the SPM unit. Abnormality in an SPM component is

detected. (The initial value of the V phase current detection circuit is abnormal.)

21 Check and correct the parameters.

(No. 4000#0, 4001#4)

24 1 Place the CNC–to–spindle cable

away from the power cable.

2 Replace the cable.

27 1 Replace the cable.

2Re–adjust the BZ sensor signal.

The polarity parameter setting of the position sensor is wrong.

The CNC power is turned off (normal power–off or broken cable). An error is detected in communication data transferred to the CNC.

1 The spindle position coder (con-

nector JY4) signal is abnormal. 2 The signal amplitude (connector

JY2) of the MZ or BZ sensor is ab-

normal.

(Unconnected cable, adjustment

error , etc.)

907

APPENDIXA. ALARM LIST

SPM in-

No. DescriptionFaulty location and remedy

Message

dica-

tion(*1)

B–63525EN/02

9029 SPN_n_ : SHORTTIME

OVERLOAD

9030 SPN_n_ : OVERCUR-

RENT POW CIRCUIT

9031 SPN_n_ : MOTOR LOCK

OR V–SIG LOS

9032 SPN_n_ : RAM FAUL T

SERIAL LSI

9033 SPN_n_ : SHORTAGE

POWER CHARGE

29 Check and correct the load status. Excessive load has been applied

continuously for a certain period of time. (This alarm is issued also when the motor shaft has been locked in the excitation state.)

30 Check and correct the power supply

voltage.

31 1 Check and correct the load status.

2 Replace the motor sensor cable

(JY2 or JY5).

32 Replace the SPM control printed cir-

cuit board.

33 1 Check and correct the power sup-

ply voltage.

2 Replace the PSM unit.

Overcurrent is detected in PSM main circuit input. (PSM alarm indication:

1) Unbalanced power supply. PSM selection error (The maximum PSM output specification is exceeded.)

The motor cannot rotate at a specified speed. (A level not exceeding the SST level for the rotation command has existed continuously.) Abnormality in the speed detection signal.

Abnormality in an SPM control circuit component is detected. (The LSI device for serial transfer is abnormal.)

9034 SPN_n_ : PARAMETER

SETTING ERROR

9035 SPN_n_ : EX SETTING

GEAR RA TIO

9036 SPN_n_ : OVERFLOW

ERROR COUNTER

9037 SPN_n_ : SPEED DE-

TECT P AR. ERROR

9041 SPN_n_ : 1–ROT POS–

CODER ERROR

34 Correct a parameter value according

to the manual. If the parameter number is unknown, connect the spindle check board, and check the indicated parameter.

35 Correct the value according to the pa-

rameter manual.

36 Check whether the position gain val-

ue is too large, and correct the value.

37 Correct the value according to the pa-

rameter manual.

41 1 Check and correct the parameter.

2 Replace the cable. 3Re–adjust the BZ sensor signal.

Parameter data exceeding the allowable limit is set.

Gear ratio data exceeding the allowable limit is set.

An error counter overflow occurred.

The setting of the parameter for the number of pulses in the speed detector is incorrect.

1 The 1–rotation signal of the

spindle position coder (connector

JY4) is abnormal. 2 The 1–rotation signal (connector

JY2) of the MZ or BZ sensor is ab-

normal. 3 Parameter setting error

908

B–63525EN/02

SPM in-

No. DescriptionFaulty location and remedy

Message

dica-

tion(*1)

APPENDIX

A. ALARM LIST

9042 SPN_n_ : NO 1–ROT.

POS–CODER DETECT

9043 SPN_n_ : DISCON. PC

FOR DIF. SP. MODE

9046 SPN_n_ : SCREW

1–ROT POS– COD. ALARM

9047 SPN_n_ : POS–CODER

SIGNAL ABNORMAL

9049 SPN_n_ : HIGH CONV.

DIF. SPEED

42 1 Replace the cable.

2Re–adjust the BZ sensor signal.

43 Replace the cable. The differential speed position coder

46 1 Check and correct the parameter.

2 Replace the cable. 3Re–adjust the BZ sensor signal.

47 1 Replace the cable.

2Re–adjust the BZ sensor signal. 3 Correct the cable layout (vicinity of

the power line).

49 Check whether the calculated differ-

ential speed value exceeds the maximum motor speed.

1 The 1–rotation signal of the

spindle position coder (connector

JY4) is disconnected. 2 The 1–rotation signal (connector

JY2) of the MZ or BZ sensor is dis-

connected.

signal (connector JY8) in SPM type 3 is abnormal.

An abnormality equivalent to alarm 41 was detected during thread cutting operation.

1 The A/B phase signal of the

spindle position coder (connector

JY4) is abnormal. 2 The A/B phase signal (connector

JY2) of the MZ or BZ sensor is ab-

normal. The relationship between the A/B phase and 1–rotation signal is incorrect (Pulse interval mismatch).

9050 SPN_n_ : SPNDL CON-

TROL OVERSPEED

9051 SPN_n_ : LOW VOLT DC

LINK

9052 SPN_n_ : ITP SIGNAL

ABNORMAL I

9053 SPN_n_ : ITP SIGNAL

ABNORMAL II

9054 SPN_n_ : OVERLOAD

CURRENT

9055 SPN_n_ : POWER LINE

SWITCH ERROR

50 Check whether the calculated value

exceeds the maximum motor speed.

51 1 Check and correct the power sup-

ply voltage.

2 Replace the MC.

52 1 Replace the SPM control printed

circuit board.

2 Replace the spindle interface

printed circuit board in the CNC.

53 1 Replace the SPM control printed

circuit board.

2 Replace the spindle interface

printed circuit board in the CNC.

54 Review the load state. An overload current was detected.

55 1 Replace the magnetic contactor.

2 Check and correct the sequence.

In spindle synchronization, the speed command calculation value exceeded the allowable limit (the motor speed is calculated by multiplying the specified spindle speed by the gear ratio).

Input voltage drop was detected. (PSM alarm indication: 4) (Momentary power failure or poor MC contact)

NC interface abnormality was detected (the ITP signal stopped).

The power line state signal of the magnetic contactor for selecting a spindle or output is abnormal.

909

APPENDIXA. ALARM LIST

SPM in-

No. DescriptionFaulty location and remedy

Message

dica-

tion(*1)

B–63525EN/02

9056 SPN_n_ : INNER COOL-

ING FAN STOP

9057 SPN_n_ : EX DECEL-

ERATION POWER

9058 SPN_n_ : OVERLOAD IN

PSM

9059 SPN_n_ : COOLING FAN

STOP IN PSM

9066 SPN_n_ : AMP MODULE

COMMUNICATION

9073 SPN_n_ : MOTOR SEN-

SOR DISCONNECTED

9074 SPN_n_ : CPU TEST ER-

ROR

56 Replace the SPM unit. The cooling fan in the SPM control cir-

cuit stopped.

57 1 Decrease the acceleration/decel-

eration duty.

2 Check the cooling condition (pe-

ripheral temperature).

3 If the cooling fan stops, replace the

resistor.

4 If the resistance is abnormal, re-

place the resistor.

58 1 Check the PSM cooling status.

2 Replace the PSM unit.

59 Replace the SPM unit. The cooling fan in the PSM stopped.

66 1 Replace the cable.

2 Check and correct the connection.

73 1 Replace the feedback cable.

2 Check the shield processing. 3 Check and correct the connection. 4 Adjust the sensor.

74 Replace the SPM control printed–cir-

cuit board.

An overload was detected in the regenerative resistance. (PSMR alarm indication: 8) Thermostat operation or short–time overload was detected. The regenerative resistor was disconnected, or an abnormal resistance was detected.

The temperature of the radiator of the PSM has increased abnormally. (PSM alarm indication: 3)

(PSM alarm indication: 2) An error was found in communication

between amplifiers.

The motor sensor feedback signal is not present.

An error was detected in a CPU test.

9075 SPN_n_ : CRC ERROR 75 Replace the SPM control printed–cir-

cuit board.

9079 SPN_n_ : INITIAL TEST

ERROR

9081 SPN_n_ : 1–ROT MO-

TOR SENSOR ERROR

9082 SPN_n_ : NO 1–ROT

MOTOR SENSOR

9083 SPN_n_ : MOTOR SEN-

SOR SIGNAL ERROR

9084 SPN_n_ : SPNDL SEN-

SOR DISCONNECTED

9085 SPN_n_ : 1–ROT SPNDL

SENSOR ERROR

79 Replace the SPM control printed–cir-

cuit board.

81 1 Check and correct the parameter.

2 Replace the feedback cable. 3 Adjust the sensor.

82 1 Replace the feedback cable.

2 Adjust the sensor.

83 1 Replace the feedback cable.

2 Adjust the sensor.

84 1 Replace the feedback cable.

2 Check the shield processing. 3 Check and correct the connection. 4 Check and correct the parameter. 5 Adjust the sensor.

85 1 Check and correct the parameter.

2 Replace the feedback cable. 3 Adjust the sensor.

An error was detected in a CRC test.

An error was detected in an initial test operation.

The one–rotation signal of the motor sensor cannot be correctly detected.

The one–rotation signal of the motor sensor is not generated.

An irregularity was detected in a motor sensor feedback signal.

The spindle sensor feedback signal is not present.

The one–rotation signal of the spindle sensor cannot be correctly detected.

910

B–63525EN/02

SPM in-

No. DescriptionFaulty location and remedy

Message

dica-

tion(*1)

APPENDIX

A. ALARM LIST

9086 SPN_n_ : NO 1–ROT

SPNDL SENSOR ERROR

9087 SPN_n_ : SPNDL SEN-

SOR SIGNAL ERROR

9088 SPN_n_ : COOLING RA-

DIFAN FAILURE

9097 SPN_n_ : OTHER

SPINDLE ALARM

9098 SPN_n_ : OTHER CON-

VERTER ALARM

9110 SPN_n_ : AMP COMMU-

NICATION ERROR

9111 SPN_n_ : CONV.LOW

VOLT CONTROL

86 1 Replace the feedback cable.

2 Adjust the sensor.

87 The one–rotation signal of the spindle

sensor is not generated.

88 Replace the SPM external cooling

fan.

Check the SPM alarm display . Other spindle alarm

Check the PSM alarm display. Other converter alarm

b0 1 Replace the communication cable

between amplifier and module.

2 Replace the SPM or PSM control

printed circuit board.

b1 Replace the PSM control printed cir-

cuit board.

The one–rotation signal of the spindle sensor cannot be correctly detected.

An irregularity was detected in a spindle sensor feedback signal.

The external cooling fan stopped.

Communication error between amplifier and module

Low converter control power supply voltage (PSM indication = 6)

9112 SPN_n_ : CONV.EXDIS-

CHARGE POW.

9113 SPN_n_ : CONV.COOL-

ING FAN FAILURE

9120 SPN_n_ : COMMUNICA-

TION DA TA ERROR

9121 SPN_n_ : COMMUNICA-

TION DA TA ERROR

9122 SPN_n_ : COMMUNICA-

TION DA TA ERROR

b2 1 Check the regenerative resis-

tance. 2 Check the motor selection. 3 Replace the PSM

b3 Replace the cooling fan. Stopped cooling fan of the converter

C0 1 Replace the communication cable

between CNC and SPM. 2 Replace the SPM control printed

circuit board. 3 Replace the CNC side spindle in-

terface printed circuit board.

C1 1 Replace the communication cable

between CNC and SPM. 2 Replace the SPM control printed

circuit board. 3 Replace the CNC side spindle in-

terface printed circuit board.

C2 1 Replace the communication cable

between CNC and SPM. 2 Replace the SPM control printed

circuit board. 3 Replace the CNC side spindle in-

terface printed circuit board.

Excessive converter regenerative power (PSM indication = 8)

radiator (PSM indication = A)

Communication data alarm

911

APPENDIXA. ALARM LIST

B–63525EN/02

A.4

ERROR CODES (SERIAL SPINDLE)

Errors Displayed on the α Series Spindle Amplifier

SPM indication(*1)

00 Check the *ESP and MRDY sequence. (For MRDY , pay

attention to the parameter setting regarding the use of the MRDY signal (bit 0 of parameter No. 4001).)

01 Check the spindle motor speed detector parameter (bits

2, 1, and 0 of parameter No. 401 1).

02 Check the parameters for the detector for Cs contour

control (bit 5 of parameter No. 4001 and bit 4 of parameter No. 4018).

03 Check the position coder signal parameter (bit 2 of pa-

rameter No. 4001).

04 Check the orientation software option. Although the orientation option is not set, an orientation

05 Check the spindle output switching software option and

power line status signal (RCH).

06 Check the sequence (CON, SFR, SRV). Although the Cs contour control mode is specified,

07 Check the sequence (SFR, SRV). Although the servo mode (rigid tapping, spindle posi-

09 Check the sequence (SPSYC, SFR, SRV) Although spindle synchronization mode is specified,

10 During execution of the C–axis control command, do not

specify another operation mode. Before entering another mode, cancel the Cs contour control command.

11 During execution of the servo mode command, do not

specify another operation mode. Before entering another mode, cancel the servo mode.

Faulty location and remedy Description

NOTE*1

Note that the meanings of the SPM indications differ depending on which LED, the red or yellow LED, is on. When the yellow LED is on, an error code is indicated with a 2–digit number. The error code is not displayed on the CNC screen. When the red LED is on, the SPM indicates the number of an alarm generated in the serial spindle. ³ See Appendix A.3, “Alarms (Serial Spindle).”

Although neither *ESP (emergency stop signal; there are two types of signals including the PMC signal and PSM contact signal(*2)) nor MRDY (machine ready signal) is input, SFR (forward rotation signal)/SRF (reverse rotation signal)/ORCM (orientation command) is input.

When the spindle motor has a high–resolution magnetic pulse coder (Cs sensor) (bits 6 and 5 of parameter No. 4001 are set to 0 and 1, respectively), 128 /rev is to be set for the speed detector (bits 2, 1, and 0 of parameter No. 4011 are set to 0, 0, and 1, respectively). However, a value other than 128 /rev is set. In this case, the motor is not excited.

Although use of a high–resolution magnetic pulse coder (bit 5 of parameter No. 4001 = 1) or use of the Cs contour control function by the sensor (bit 4 of parameter No. 4018 = 1) is not set, a Cs control command is input. In this case, the motor is not excited.

Although use of the position coder signal (bit 2 of parameter No. 4001 = 1) is not set, a servo mode (rigid tapping, spindle positioning) or spindle synchronization command is input. In this case, the motor is not excited.

command (ORCM) is input. Although the output switching option is not set, the low–

speed winding is selected (RCH = 1).

SFR/SRV is not input.

tioning) is specified, SFR/SRV is not input.

SFR/SRV is not input. Although Cs contour control mode is set, another op-

eration mode (servo mode, spindle synchronization, or orientation) is specified.

Although servo mode (rigid tapping, or spindle positioning) is set, another operation mode (Cs contour control, spindle synchronization, or orientation) is specified.

912

B–63525EN/02

SPM indication(*1)

12 During execution of the spindle synchronization com-

mand, do not specify another operation mode. Before entering another mode, cancel the spindle synchronization command.

13 During execution of the orientation command, do not

specify another operation mode. Before entering another mode, cancel the orientation command.

14 Input the SFT or SRV signal. The SFT and SRV signals are both input at the same

15 Check bit 5 of parameter No. 4000 and PMC signal

(CON).

16 Check bit 5 of parameter No. 4000 and PMC signal

(DEFMD).

17 Check bits 2, 1, and 0 of parameter No. 401 1. Setting of the speed detector parameter (bits 2, 1, and

18 Check bit 2 of parameter No. 4001 and PMC signal

(ORCM).

19 During execution of the orientation command, do not

specify another operation mode. Before entering another mode, cancel the orientation command.

20 Check bit 5 of parameter No. 4001, bit 5 of parameter No.

4014, and bit 4 of parameter No. 4018.

21 Input the slave operation mode command (SLV) in nor-

mal operation mode.

22 Input the position control command in normal operation

mode

23 Check bit 5 of parameter No. 4014 and PMC signal

(SLV).

24 Check the PMC signal (INCMD). Perform orientation by

specifying an absolute position first.

25 Check the spindle amplifier specifications and parameter

setting (bit 4 of parameter No. 4018).

APPENDIX

DescriptionFaulty location and remedy

Although spindle synchronization is being performed, another operation mode (Cs contour control, servo mode, or orientation) is specified.

Although the orientation command is being executed, another operation mode (Cs contour control, servo mode, or synchronization) is specified.

time. When bit 5 of parameter No. 4000 is set to 1 to indicate

the presence of the differential speed mode function, Cs contour control is specified.

When bit 5 of parameter No. 4000 is set to 0 to indicate the absence of the differential speed mode function, the differential speed mode command (DEFMD) is input.

0 of parameter No. 401 1) is invalid. (The corresponding speed detector is not present.)

Although bits 2 of parameter No. 4001 is set to 0 not to use the position coder signal, a command for orientation by a position coder (ORCMA) is input.

Although orientation by a magnetic sensor is being performed, another operation mode is specified.

When the use of the slave operation mode function is set (bit 5 of parameter No. 4014 = 1), the use of a high– resolution magnetic pulse coder (bit 5 of parameter No. 4001 = 1) or the use of the Cs contour control function by the sensor (bit 4 of parameter No. 4018 = 1) is specified. These items cannot be set at the same time.

Although position control (such as servo mode or orientation) is being performed, a slave operation mode command (SLV) is input.

Although slave operation mode is set (SLVS = 1), a position control command (such as servo mode or orientation) is input.

Although bit 5 of parameter No. 4014 is set to 0 not to use the slave operation mode function, a slave operation mode command (SL V) is input.

Orientation is performed in incremental operation mode (INCMD = 1) first, then the absolute position command (INCMD = 0) is input.

Although the spindle amplifier SPM type 4 is not used, the use of the Cs contour control function by the sensor is set (bit 4 of parameter No. 4018 = 1).

A. ALARM LIST

NOTE*2

PSM contact signal

Between ESP1 and ESP2 on the PSM Contact open: Emergency stop

Contact closed: Normal operation

913
