Epson WF-7510, WF-7520 User Manual

WorkForce

WF-7510/WF-7520

Quick Guide

Your WorkForce WF-7510/WF-7520 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Using Special Papers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Placing Originals for Copying, Scanning, or Faxing. . . . . . . . . . . . . . . . . . . . . . 7

Copying a Document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Printing From a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Printing From Your Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Faxing a Document. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Maintaining Your Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Scanning a Document or Photo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Solving Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Guide rapide

Votre WorkForce WF-7510/WF-7520 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Utilisation de supports spéciaux. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Positionnement des originaux . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Copie d’un document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Impression depuis une carte mémoire. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Impression depuis un ordinateur . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Télécopie d’un document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Numérisation d’un document ou d’une photo . . . . . . . . . . . . . . . . . . . . . . . . 65

Entretien de l’imprimante . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Résolution des problèmes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Avis. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Your WorkForce WF-7510/ WF-7520

English

After you set up your WorkForce® WF-7510/WF-7520 (see the Start Here sheet), turn to this Quick Guide and your online User’s Guide for instructions on using your product.

Note: The illustrations in this manual show the WorkForce WF-7520. The instructions apply to both the WF-7510 and WF-7520 unless otherwise noted.

Features Where to find information

Copy, scan, and fax from the easy-to-use control panel

Easy networking—Wi-Fi and Ethernet See the online User’s Guide.

Extra-high capacity ink cartridges See this Quick Guide for installation

Advanced paper handling with Automatic Document Feeder and 250-sheet, wide-format cassette

Wireless printing from mobile devices with Epson Connect

Adjusting the Control Panel

See this Quick Guide for the basics. See the online User’s Guide for details.

instructions.

See the Start Here sheet and the online User’s Guide for paper loading instructions.

See www.epson.com/connect.

The control panel is adjustable. Squeeze the release bar underneath to raise or lower it as shown.

Your WorkForce WF-7510/WF-7520

Using the Control Panel

The control panel makes it easy to use all the features of your product. To save energy, the screen goes dark after several minutes of inactivity. Press any button to wake it up.

1 2 3 4 5 6 7 8

Tip: To turn off the “beep” heard when you press a button on the screen, press select

Printer Setup

, select

Sound

, and select

Off

. If you turn off the sound, the dialing

sound made when you transmit a fax is also turned off.

Number Description

1 Turns product on/off


2 Press

3 Press

4 View menus and status on the LCD Screen

5 Use the arrow keys and

6 Enter numbers, letters, and symbols

7 Press

8 Press

9 Shows wireless network status

10 Resets the active menu selection to its default value

to access the Print Photos menu

Copy

to access your product’s Copy mode

button to navigate menus

Fax

to access your product’s Fax mode

Scan

to access your product’s Scan mode

Setup

Using the Control Panel

Using Special Papers

Epson offers a wide array of high quality papers, making it easy to maximize the impact of your photos, presentations, and creative projects.

You can purchase genuine Epson ink and paper at Epson Supplies Central www.epson.com/ink3 (U.S. sales) or www.epson.ca (Canadian sales). You can also purchase supplies from an Epson authorized reseller. To find the nearest one, call 800-GO-EPSON (800-463-7766).

Paper name Size

Epson Bright White Paper Letter (8.5 × 11 inches

[216 × 279 mm])

Epson Brochure & Flyer Paper Matte

Double-sided

Epson Premium Presentation Paper

Matte

Epson Premium Presentation Paper

Matte Double-sided

Epson Presentation Paper Matte Letter (8.5 × 11 inches

Letter (8.5 × 11 inches [216 × 279 mm])

8 × 10 inches (203 × 254 mm) S041467 50

Letter (8.5 × 11 inches [216 × 279 mm])

A3+ (13 x 19 inches [330 x 483 mm])

A3 (11.7 x 16.5 inches [297 x 420 mm])

11 x 14 inches (279.5 x 355.6 mm)

Letter (8.5 × 11 inches [216 × 279 mm])

[216 × 279 mm])

Legal (8.5 × 14 inches [216 × 356 mm])

A3+ (13 × 19 inches [330 × 483 mm])

11 × 17 inches (279 × 432 mm)

Part number

S041586 500

S042384 150

S041257 S04218050100

S041263 50

S041260 50

S041468 50

S041568 50

S041062 100

S041067 100

S041069 100

S041070 100

Sheet count

Using Special Papers

Part

Paper name Size

Epson Ultra Premium Photo Paper

Glossy

Epson Premium Photo Paper Semi-

gloss

Epson Premium Photo Paper Glossy 4 × 6 inches (102 × 152 mm) S041808

Epson Photo Paper Glossy 4 × 6 inches (102 × 152 mm) S041809

Epson Photo Quality Self-adhesive

Sheets

Epson Iron-on Cool Peel Transfer

paper

4 × 6 inches (102 × 152 mm) S042181

5 × 7 inches (127 × 178 mm) S041945 20

8 × 10 inches (203 × 254 mm) S041946 20

Letter (8.5 × 11 inches [216 × 279 mm])

11 × 14 inches (279.5 ×355.6 mm)

11 × 17 inches (279 × 432 mm)

A3 (11.7 × 16.5 inches [297 × 420 mm])

A3+ (13 × 19 inches [330 × 483 mm])

4 × 6 inches (102 × 152 mm) S041982 40

Letter (8.5 × 11 inches [216 × 279 mm])

A3+ (13 x 19 inches [330 x 483 mm])

5 × 7 inches (127 × 178 mm) S041464 20

8 × 10 inches (203 × 254 mm) S041465 20

Letter (8.5 × 11 inches [216 × 279 mm])

11 x 17 inches (279 x 432 mm) S041290 20

A3+ (13 x 19 inches [330 x 483 mm])

Letter (8.5 × 11 inches [216 × 279 mm])

A4 (8.3 × 11.7 inches [210 × 297 mm])

Letter (8.5 × 11 inches [216 × 279 mm])

number

S04217460100

S042182 S0421752550

S041466 20

S041290 20

S041288 20

S041289 20

S041331 20

S041327 20

S04172740100

S042183 S0416672550

S0441289 20

S04203850100

S041141 S041649 S041271

S041106 10

S041153 10

Sheet count

20 50 100

Note: Media availability varies by country.

Using Special Papers

For detailed paper loading instructions, see the Start Here sheet or online User’s Guide.

For best results:

■

Fan paper before loading.

■

Load paper printable side down; it is usually whiter or brighter.

■

Always load paper short edge first and make sure the edge guides are against the paper.

■

Make sure the paper is loaded against the edge guide and not sticking out from the end of the cassette. The paper may slide forward slightly as you insert the cassette. This is normal.

■

Do not use paper with binder holes.

Using Special Papers

Placing Originals for Copying, Scanning, or Faxing

Before you copy, scan, or fax, place your documents on the scanner glass or in the Automatic Document Feeder (ADF). Place photos on the scanner glass only.

Using the Scanner Glass

You can place a photo or a document up to A3 on the scanner glass.

1. Open the document cover.

2. Place your original facedown on the scanner glass, with the top against the back left corner.

3. Close the cover gently to keep your original in place.

Using the Automatic Document Feeder

You can place up to 30 letter- to A3-size sheets (11.69 × 16.54 inches) in the ADF. For double-sided scanning, use letter- or A4-size paper only.

1. Open the ADF paper support, and then move the edge guide outward.

2. Fan the originals, then tap them on a flat surface to even the edges.

Placing Originals for Copying, Scanning, or Faxing

3. Insert the originals faceup, top edge first. The

Note: If you’re using the 2-up Copy layout, make sure the originals are loaded as shown below.

ADF

icon appears on the screen.

4. Slide the edge guide against the originals, but not too tight.

Using the Automatic Document Feeder

Copying a Document

Follow the steps in this section to copy black-and-white or color documents.

Note: You can use the Copy/Restore Photos option to copy photos onto 4 × 6-inch (102 × 152 mm) and 5 × 7-inch (127 × 178 mm) Epson photo paper (various types available) for instant photo reprints. See the online User’s Guide for details.

You can copy documents onto plain paper, Epson Bright White Paper, or Epson Presentation Paper Matte. If you use the Automatic Document Feeder (ADF), you can copy up to 30 sheets at a time.

1. Load paper in the sheet feeder (see page 6).

2. Place your original document on the scanner glass, or load your documents in the ADF (see page 7).

3. Press the

Copy

button.

4. Press u or d or use the numeric keypad to select the number of copies you want (up to 99).

5. Press l or r to change the copy density (lightness or darkness).

6. To copy your original(s) onto a different size paper, press the

Reduce/Enlarge

button

and select one of the preset options or a custom paper size.

7. To change the print quality, press the

Standard Quality

8. To change other print settings, press x

Settings

■

To make double-sided copies (WorkForce WF-7520 only), select

Copying

. Then select the desired option and press OK.

Quality

button and choose

, then select

Paper and Copy

Copying a Document

Draft, Best or

2-Sided

■

To reduce your originals so that pages print side-by-side, two per sheet, select

2-up Copy

as the

Layout

setting. This is for use only with single-sided originals;

be sure to load them as shown on page 8.

■

You can also change the paper type, paper size, and other print settings. Press u or d to select the setting, then press then press

Note: Not all Paper Type, Paper Size, Layout, and Quality settings may be available depending on the options you choose. See the online User’s Guide for details.

. Press u or d to select an option,

9. After you finish selecting settings, press x

10. Press the

Note: When printing two-sided, if ink on the front of the paper smears, select a longer

Dry Time in the Paper and Copy Settings menu (WorkForce WF-7520 only).

Stop

B&W

Color xStart

button to begin copying. To cancel copying, press

to exit the settings menu.

Copying a Document

Printing From a Memory Card

Your product lets you print photos directly from your digital camera’s memory card; just insert it into the memory card slot and you’re ready to print.

See the online User’s Guide for a list of compatible memory cards and instructions on copying memory card files between your product and a computer, and printing photos directly from your camera.

Inserting the Card

1. Make sure your printer is turned on.

2. Insert your card as shown.

Note: Do not force the card into the slot; it won’t go in all the way.

The memory card access light flashes, then stays lit. Now you can view your photos on the LCD screen and print them (see page 12).

Memory card access light

Removing the Card

After you finish printing your photos, follow these steps to remove the card:

1. Make sure the memory card access light is not flashing.

Caution: Do not remove the card or turn off your printer while the memory card access light is flashing; you may lose data on the card.

2. If the product is connected to your computer with a USB cable, do one of the following before removing the memory card or turning off the printer:

■

Windows®: Right-click the name of your card (removable disk) in My Computer or Windows Explorer, and select

■

Mac OS® X: Drag the removable disk icon from your desktop into the trash, then remove the card.

3. Pull the card straight out of its slot.

Eject

Printing From a Memory Card

Printing Photos From the LCD Screen

You can select individual photos for printing as you view them on the LCD screen.

1. Load several sheets of Epson photo paper (various types available; see page 4).

2. Press the

3. Press l or r to scroll through your photos and display one that you want to print.

Note: To crop the photo, press the Display/Crop button. Press + or – to frame the image; use the arrow buttons to move the frame. Press OK twice when done.

4. Press u or d to select the number of copies you want of that photo.

5. Repeat steps 3 and 4 to select more photos.

6. Press the x


button, then select

View and Print Photos

Print Settings

. You see this screen:

7. Select the

8. If desired, press the y

Paper Size

and

Paper Type

Back

button and select

reduction or other photo-enhancing features.

9. When you’re done selecting settings, press the x

10. When you’re ready to print, press x

To cancel printing, press

Printing Photos From the LCD Screen

y Stop

of the paper you’ve loaded.

Photo Adjustments

button.

Print Photo

to turn on red-eye

Printing From Your Computer

This section describes the basic steps for printing from a Windows or Mac® computer. For detailed instructions on printing, see the online User’s Guide.

Printing in Windows

1. Select the print command in your application.

Select your Epson printer

Click here to open your printer software

2. Make sure your Epson printer is selected, then click the button.

(If you see a

Properties

Setup, Printer

on the next screen.)

, or

Options

button, click it. Then click

Printing From Your Computer

Preferences

Properties

Preferences

3. On the Main tab, select the basic print settings. Make sure you choose the correct

Paper Type

setting for the paper you are using (see page 15 for details).

Select your

Document Size

Click here for quick access to settings

Note: For quick access to the most common settings, select one of the Printing Presets on the left side of the screen. You can delete these presets or create your own by clicking the

Add/Remove Presets

4. For more printing options, click the

Note: For more information about print settings, click Help or see your online

User’s Guide.

button.

More Options

tab.

Select your

Paper Type

Click here for 2-Sided Printing

5. Click OK to save your settings.

6. Click

to start printing.

Printing With a Mac

Follow the steps below to print from Mac OS X 10.5 to 10.6. If you’re printing from Mac OS X 10.4, see your online User’s Guide for instructions.

1. Open a photo or document in an application.

2. Open the

Printing With a Mac

File

menu and select

3. Select your Epson printer as the

Printer

setting.

Select your Epson printer

Click to expand, if necessary

4. Select basic copy and page settings. For borderless printing, choose a setting with a

Borderless

option by clicking on a paper size and selecting the

Paper Size

borderless option.

Note: If the setting you want isn’t shown (for example, Scale), check for it in your application before printing or check for it at the bottom of this window.

Copy and page settings

Application settings

Pop-up menu

5. Choose

Quality

Print Settings

from the pop-up menu, and select your

and other print settings.

Media Type, Print

6. Choose any other printing options you may need from the pop-up menu. See the online User’s Guide for details.

Printing With a Mac

7. Click

8. To monitor your print job, click the printer icon in the Dock.

Selecting the Correct Paper Type

Select the correct

Paper Type

(Windows) or

Media Type

(Mac OS X) setting in your

printer software so the ink coverage can be adjusted accordingly.

For this paper/media Select this setting

Plain paper Epson Bright White Paper Epson Presentation Paper Matte Epson Photo Quality Self-adhesive Sheets Epson Iron-on Cool Peel Transfer paper

Epson Ultra Premium Photo Paper Glossy Ultra Premium Photo Paper Glossy

Epson Premium Photo Paper Glossy Premium Photo Paper Glossy

Epson Photo Paper Glossy Photo Paper Glossy

Epson Premium Photo Paper Semi-gloss Premium Photo Paper Semi-Gloss

Epson Premium Presentation Paper Matte Premium Presentation Paper Matte

Epson Brochure & Flyer Paper Matte Double-sided

Envelopes Envelope

Plain Paper/Bright White Paper

Selecting the Correct Paper Type

Faxing a Document

Your product lets you send faxes by entering fax numbers, selecting entries from a speed dial or group dial list, or using the one-touch dial buttons. Using the Automatic Document Feeder (ADF), you can fax up to 30 pages at a time.

Note: You can also send or receive a fax from your computer using the Epson FAX Utility. For more information, see the online User’s Guide.

Breakdown or repair of this product may cause loss of fax data and settings. Epson is not responsible for backing up or recovering data and settings during or after the warranty period. We recommend that you make your own backup or print out your fax data and settings.

This product allows you to store names, telephone numbers, and fax data in its memory even when the power is turned off. Use the following procedure to erase the memory if you give away or dispose of the product: Select F

Settings > All Settings

data.

. This procedure will erase all of your network settings and fax

Connecting a Phone or Answering Machine

Setup > Restore Default

1. Connect the phone cable from the wall jack to the

LINE

port on the back

of the product.

Note: If you’re connecting the product to a DSL phone line, you must plug a DSL filter into the wall jack or you won’t be able to use the fax or telephone equipment. Contact your DSL provider for the necessary filter.

2. To use a telephone or answering machine, you need a second phone cable. Connect one end of the cable to the telephone or answering machine, and connect the other end to the

EXT.

port on the back of the product.

Telephone wall jack

Faxing a Document

In Auto Answer mode, if the incoming call is a fax and you pick up the phone or the answering machine answers, the product automatically begins receiving the fax. If the other party is a caller, the phone can be used as normal or a message can be left on the answering machine.

Note: Any phone or answering machine must be connected to the product to detect an incoming fax call when the phone is picked up. Epson cannot guarantee compatibility with VoIP, cable phone systems, or fiberoptic digital services such as FiOS™.

EXT.

port for your

Setting Up Fax Features

Before sending or receiving faxes, you should create a fax header and select the number of rings before the fax answers.

Note: To select other settings or use the Epson FAX Utility, see the online

User’s Guide.

Entering Fax Header Information

You should enter your name and phone number in the fax header before sending faxes so that recipients can identify the origin of the fax.

Note: If you leave your product unplugged for a long period of time, the date and time settings may get lost. See the online User’s Guide for instructions on resetting them.

Entering Your Sender Name

1. Press the

2. Press u or d to select

Fax

button, then press x

Header

, then pressOK.

3. Press

to select

Fax Header

4. Use the keypad to enter your sender name (see “Using the Keypad to Enter Numbers and Characters” on page 19). You can enter up to 40 digits.

5. When you’re done, use the arrow buttons to select the Header screen.

Setting Up Fax Features

Done

, then press OK to return to

Entering Your Phone Number

1. From the Header screen, press u or d to select

Your Phone Number

, then press OK.

You see the phone number input screen.

2. Use the numeric keypad to enter your phone number (up to 20 digits).

3. When you’re done, press

4. Press x

to exit the Fax Menu.

Using the Keypad to Enter Numbers and Characters

When entering phone numbers and text in Fax mode, follow these guidelines:

■

To enter a fax number, use the numeric keypad. Press the #button to insert the

symbol for international phone numbers. Press r to enter a space or l to delete a

character.

■

To enter characters, use the l, r, u, or d arrow buttons to highlight a letter on the screen. Press

to select it.

Use the on-screen function buttons to select uppercase (

AB12

), lowercase (

ab12

), symbols (

!#%@

), or spaces

( ), or to delete characters ( ).

When you’re finished, highlight

Done

and press OK.

Function buttons

Selecting the Number of Rings to Answer

If you connected an answering machine and it is set to pick up on the fourth ring, you should set the product to pick up on the fifth ring or later:

1. Press the

2. Press u or d to select

3. Press u or d to select

Fax

button, then press x

Communication

Rings to Answer

, then press OK.

4. Press u or d or use the numeric keypad to select the number of rings, then press Select more rings than you use for the answering machine.

5. Press x

to exit the Fax Menu.

Setting Up Fax Features

Sending a Fax From the Control Panel

You can send a fax by manually entering a fax number, as described below.

Note: To dial the number using a telephone, by redialing, or by selecting from your speed dial list, see the next section. To send a fax from your computer using the Epson FAX Utility, see your online User’s Guide.

1. Press the

2. Place your original(s) for faxing (see page 7).

3. Use the numeric keypad to enter the fax number. You can enter up to 64 digits.

Fax

button.

4. To change fax settings, press x

5. Press the

Note: If the recipient’s fax machine prints only in black and white, your fax is automatically sent in black and white even if you select color.

■

B&W

Color xStart

If you are scanning with the ADF, your document is automatically scanned and

and select settings as necessary.

button to send your fax.

faxed.

■

If you place your document on the scanner glass, you can scan additional pages after the first one is sent.

■

If the fax number is busy, you see a redialing message and the product redials after one minute. To redial immediately, press

To cancel faxing, press y

Stop

at any time.

Redial/Pause

Other Ways to Dial a Fax Number

Here are some other ways you can dial a fax number:

■ Redial/Pause

■ Speed Dial

group dial entry, press the

■

If you’ve connected a telephone to the product, dial the number from the phone. Select

: Redial the last fax number you used.

: Select or type the number of the speed dial entry and press OK. To use a

Send

, then press the

Speed Dial

B&W

button twice.

Color xStart

button.

Note: Don’t hang up the phone until you begin transmitting the fax.

If you turn off the product, the following data stored in the product’s temporary memory will be lost: received faxes that haven’t yet been printed, faxes scheduled to be sent later, and faxes being retransmitted automatically.

Sending a Fax From the Control Panel

Receiving Faxes

Before receiving faxes, make sure you load plain paper and select the correct settings for the paper you’ve loaded.

1. Press the

2. Press x

3. Select

Note: If the incoming fax is larger than the paper you loaded, it is reduced to fit or printed on multiple pages, depending on the Auto Reduction setting you select.

4. Press x

To receive faxes automatically, press the on the

Note: To change the number of rings before the product answers, see page 19.

Paper Size

Auto

light.

Fax

button.

and select

Receive Settings

and make sure the setting matches the size of paper you loaded.

when done.

Auto

button to turn

Auto Answer light

If you run out of paper during printing, you see an error message. Load more paper and press the

Start

button to continue.

To receive faxes manually, turn off the

B&W

Auto

light and follow

Color

these steps:

1. When your telephone rings, lift the phone off the hook.

2. Select

Receive

, then press the

B&W

Color xStart

button.

3. After all the pages are received, replace the phone on the hook.

4. Press

to print the fax.

Receiving Faxes

Maintaining Your Product

Follow the instructions in this chapter to check and clean the print head nozzles, check ink levels, and replace ink cartridges. If you need to align the print head, see the online User’s Guide.

Caution: To keep your product looking like new, don’t place anything on top of the cover or use it as a writing surface, If you need to clean the cover, use only a soft, nonabrasive microfiber-type cloth.

Checking the Print Head Nozzles

If your printouts are faint or have gaps in them, some of the nozzles in the print head may be clogged or ink may be running low in one or more of the ink cartridges. Follow the steps below to check the print head nozzles.

1. Load a few sheets of plain paper.

2. Press

F Setup

3. Press u or d to select

4. Select

5. Press the

6. Check the nozzle check pattern that prints to see if there are gaps in the lines.

7. If there are no gaps, the print head is clean. Select

Maintaining Your Product

Nozzle Check

ColorxStart

press y

Back

to continue printing.

If there are gaps or the pattern is faint, select (see page 23).

Maintenance

, then press OK.

button.

Nozzles are clean Nozzles need cleaning

, then press OK.

Finish Nozzle Check,

Head Cleaning

to clean the print head

and then

Cleaning the Print Head

If print quality has declined and the nozzle check indicates clogged nozzles, you can clean the print head. Print head cleaning uses ink, so clean it only if necessary.

Note: You cannot clean the print head if an ink cartridge is expended, and may not be able to clean it when a cartridge is low. You must replace the cartridge first (see page 25).

1. Load a few sheets of letter- or A4-size paper.

2. Press

3. Press u or d to select

F Setup

Maintenance

, then press OK.

4. Press u or d to select

Head Cleaning

, press OK, then press OK again.

5. Choose the colors you want to clean.

Tip: Use the nozzle check pattern to determine which colors need cleaning. You can save ink by cleaning only selected colors.

Cleaning lasts around 2 1/2 minutes. When it’s finished, you see a message on the LCD screen.

Caution: Never turn off the product during head cleaning or you may damage it.

6. Press 2 to run a nozzle check and confirm that the print head is clean.

Note: If you don’t see any improvement after cleaning the print head four times, leave the product on and wait at least six hours to let any dried ink soften. Then try cleaning the print head again. If quality does not improve, one of the ink cartridges may need to be replaced. If that doesn’t help, contact Epson as described on page 34.

If you do not use your product often, it is a good idea to print a few pages at least once a month to maintain good print quality.

Cleaning the Print Head

Checking Ink Levels

You can check the ink levels anytime right on the LCD screen. To check the ink levels with your Windows or Macintosh software, see the instructions in your online User’s Guide.

Note: Printing stops when an ink cartridge is expended. If a color cartridge is expended, you may be able to continue printing temporarily with black ink; see the online User’s Guide for more information. If the black cartridge is expended, you must replace it to continue printing.

1. Press

2. Press

F Setup

to select

Ink Levels

3. The ink cartridge status is displayed. See page 25 to replace a cartridge, if necessary.

4. Press y

Back

to exit.

In Windows, a window may appear on your computer screen if you try to print when ink is low. This window can optionally display ink offers and other updates from Epson.

Note: To disable checking for ink offers or updates from Epson, see the instructions in your online User’s Guide.

Purchasing Epson Ink Cartridges

You can purchase genuine Epson ink and paper at Epson Supplies Central at www.epson.com/ink3 (U.S. sales) or www.epson.ca (Canadian sales). You can also purchase supplies from an Epson authorized reseller. To find the nearest one, call 800-GO-EPSON (800-463-7766).

Use the following list when you order or purchase new ink cartridges:

Ink color High-capacity Extra High-capacity

Black 126 127

Cyan 126 127

Magenta 126 127

Yellow 126 127

Checking Ink Levels

Note: We recommend that you use genuine Epson cartridges and do not refill them. The use of other products may affect your print quality and could result in product damage.

Yields vary considerably based on images printed, print settings, paper type, frequency of use, and temperature. For print quality, a small amount of ink remains in the cartridge after the “replace cartridge” indicator comes on. The product ships with full cartridges and part of the ink from the first cartridges is used for priming the product.

For best printing results, use up a cartridge within six months of opening the package and before the expiration date on the cartridge box.

Store ink cartridges in a cool, dark place. If cartridges have been exposed to cold temperatures, allow them to warm up to room temperature for at least 3 hours before using them.

Replacing Ink Cartridges

Make sure you have a new ink cartridge before you begin.

Caution: Do not open ink cartridge packages until you are ready to install the ink. Cartridges are vacuum packed to maintain reliability.

Leave the expended cartridge installed until you have obtained a replacement, or the ink remaining in the print head nozzles may dry out.

1. Turn on the product.

2. If an ink cartridge is low or expended, you see a message on the LCD screen indicating which color to replace. Press

If you’re replacing a cartridge before you see a message on the LCD screen, press select

Ink Cartridge Replacement

F Setup

, select

Maintenance

3. Open the scanner, then open the cartridge cover.

, then

Replacing Ink Cartridges

4. Squeeze the tab on the cartridge and lift it up. Dispose of it carefully. Do not take the used cartridge apart or try to refill it.

Warning: If ink gets on your hands, wash them thoroughly with soap and water. If ink gets into your eyes, flush them immediately with water. Keep ink cartridges out of the reach of children and don’t drink the ink.

5. Before you open the new cartridge package, shake it gently four or five times. Then remove it from the package.

6. Remove the yellow tape from the bottom of the ink cartridge.

Caution: Do not remove any other labels or seals, or ink will leak. Do not touch the green chip on the front of the cartridge. This can damage the ink cartridge.

7. Insert the new ink cartridge into the holder and push it down until it clicks into place.

8. Once you replace all the cartridges that need replacing, close the cartridge cover and push it down until it clicks into place.

9. Close the scanner to begin charging the ink. This takes about 2 1/2 minutes. When you see a completion message on the LCD screen, ink charging is finished.

Caution: Never turn off the product while ink is charging or you’ll waste ink. If you see an ink replacement message on the LCD screen, press OK and press down all the cartridges securely. Then press OK again. If you remove a low or expended ink cartridge, you cannot reinstall and use the cartridge.

Replacing Ink Cartridges

Scanning a Document or Photo

You can use your product to scan original documents and photos and save them on your computer.

Quick Scanning With the Scan Button

Use the You can even scan a photo and have it automatically included in an email message.

Note: For Mac OS X 10.6, see “Scanning With Mac OS X 10.6” on page 29.

1. Place your original document or photo as shown on page 7.

2. Press the

3. Press u or d to select one of the following options:

4. If you’re scanning to a memory card, select your scan settings and then press x

Scan

button to quickly scan a photo or document and save it on your computer.

Scan

button.

■ Scan to Memory Card

an inserted memory card.

■ Scan to PC

ideal for scanning photos.

■ Scan to PC (PDF)

ideal for scanning documents.

■ Scan to PC (Email)

application, and attaches a JPG image to a new outgoing message. This works with MAPI-type email such as Microsoft not web-based email such as Gmail.

■ Scan to PC (WSD)

Windows Vista (English only). To use this feature, you must first set up WSD (Web Services for Devices) on the computer you want to scan to.

Scan

to begin scanning.

automatically creates a JPG image and saves it to your computer;

automatically creates a JPG image or PDF and saves it to

automatically creates a PDF file and saves it to your computer;

automatically scans a photo, resizes it, launches your email

Outlook or Windows Live Mail, but

lets you manage wireless scanning in Windows 7 or

Start

If you’re scanning to your computer, select connected by a USB cable, or select the name of your computer if your product is connected over a network. Press

Once your image is scanned, you see its icon in Windows Explorer or Mac Finder as an attachment in your email application.

USB Connection

to begin scanning.

Scanning a Document or Photo

if your product is

, or

+ 61 hidden pages
