D-Link DCS-6010L User Manual

Version 1.0 | 06/06/2012
User Manual
Wireless N 360° Home Network Camera
DCS-6010L
Preface
D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes. Information in this document may become obsolete as our services and websites develop and change. Please refer to the www.mydlink.com website for the most current information.
Revision Date Description
1.0 June 6, 2012 DCS-6010L Revision A1 with rmware version 1.00
Trademarks
D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States or other countries. All other company or product names mentioned herein are trademarks or registered trademarks of their respective companies.
Copyright © 2012 D-Link Corporation.
All rights reserved. This publication may not be reproduced, in whole or in part, without prior expressed written permission from D-Link Corporation.
2D-Link DCS-6010L User Manual
Table of Contents
Product Overview .........................................................................4
Package Contents .................................................................4
Introduction ............................................................................ 5
System Requirements ......................................................... 5
Features .................................................................................... 6
Hardware Overview .............................................................7
Outside .................................................................................7
Internal Ports ...................................................................... 8
Installation ......................................................................................9
Wireless Installation Considerations .............................. 9
Zero Conguration Setup ........................................................10
Camera Installation Wizard .............................................14
Manual Hardware Installation ........................................22
Mounting the Camera .......................................................23
WPS - Push Button Setup .................................................24
mydlink ...........................................................................................25
Camera Status ......................................................................26
Setup .......................................................................................38
Setup Wizard ....................................................................38
Network Setup .................................................................44
Wireless Setup ..................................................................47
Dynamic DNS ...................................................................48
Image Setup .....................................................................49
Audio and Video ..............................................................51
Preset ...................................................................................53
Motion Detection ...........................................................55
Time and Date ..................................................................56
Event Setup .......................................................................57
SD Card ...............................................................................65
Advanced ...............................................................................66
HTTPS ..................................................................................66
Access List ..........................................................................67
Maintenance .........................................................................68
Device Management .....................................................68
Live Video ..............................................................................27
Playback .................................................................................28
Settings ..................................................................................29
Recording Settings .........................................................30
Advanced Settings .........................................................32
Events ......................................................................................33
Conguration ...............................................................................34
Using the Conguration Interface ................................34
Live Video ..............................................................................35
System ................................................................................69
Firmware Upgrade ..........................................................70
Status ......................................................................................71
Device Info ........................................................................71
Logs .....................................................................................72
Help......................................................................................73
Technical Specications ...........................................................74
Safety Statements ......................................................................77
3D-Link DCS-6010L User Manual
Section 1: Product Overview
DCS-6010L Wireless N 360° Home Network Camera
CAT5 Ethernet cable
Power adapter
CD-ROM with User Manual and software
Product Overview

Package Contents

Quick Installation Guide
Mounting Bracket
If any of the above items are missing, please contact your reseller.
Note: Using a power supply with a dierent voltage than the one included with your product will cause damage and void the warranty for this product.
4D-Link DCS-6010L User Manual
Section 1: Product Overview

Introduction

Congratulations on your purchase of the DCS-6010L Wireless N 360° Home Network Camera. The DCS-6010L is a versatile and unique solution for your small oce or home. Unlike a standard webcam, the DCS-6010L is a complete system with a built-in CPU and web server that transmits high quality video images for security and surveillance. The DCS-6010L can be accessed remotely, and controlled from any PC/Notebook over your local network or through the Internet via a web browser. The simple installation and intuitive web-based interface oers easy integration with your Ethernet/Fast Ethernet or 802.11n/g wireless network. The DCS-6010L also comes with remote monitoring and motion detection features for a complete and cost-eective home security solution.

System Requirements

• Computer with Microsoft Windows® 7, Vista®, or XP (for CD-ROM Setup Wizard), Mac OS or Linux
• PC with 1.3GHz or above; at least 128MB RAM
• Internet Explorer 7 or above , Firefox 3.5 or above, Safari 4 and Chrome 8.0 or above
• Existing 10/100 Ethernet-based network or 802.11n wireless network
• A MicroSD memory card (optional) is required for recording to onboard storage. SDHC Class 6 or above is recommended.
• Broadband Internet connection
5D-Link DCS-6010L User Manual
Section 1: Product Overview

Features

360 Degree Surveillance
The built-in sheye lens gives you a full 360 degrees of coverage, allowing it to monitor an entire room with ease. It can also be placed on a wall for 180 degree coverage of a hallway. Distortion correction gives you a panoramic view or a normal corrected image that you can pan across easily.
Simple to Use
The DCS-6010L is a stand-alone system with a built-in CPU, requiring no special hardware or software. The DCS-6010L supports both ActiveX mode for Internet Explorer and Java mode for other browsers such as Firefox® and Safari®.
Supports a Variety of Platforms
Supporting TCP/IP networking, HTTP, and other Internet related protocols. The DCS-6010L can also be integrated easily into other Internet/Intranet applications because of its standards-based features.
802.11n Wireless or Ethernet/Fast Ethernet Support
The DCS-6010L oers wireless 802.11n and Ethernet/Fast Ethernet connectivity, making the DCS-6010L easy to integrate into your existing network environment. The DCS-6010L works with a 10Mbps Ethernet based network or 100Mbps Fast Ethernet based network for traditional wired environments, and works with 802.11n routers or access points for added exibility. The Site Survey feature also allows you to view and connect to any available wireless networks.
Web Conguration
Using a standard Web browser, administrators can congure and manage the Network Camera directly from its own Web page via Intranet or Internet. This means you can access your DCS-6010L anytime, anywhere in the world.
Broad Range of Applications
With today’s high-speed Internet services, the Network Camera can provide the ideal solution for delivering live video images over the Intranet and Internet for remote monitoring. The Network Camera allows remote access using a Web browser for live image viewing, and allows the administrator to manage and control the Network Camera anytime, anywhere in the world. Many applications exist, including industrial and public monitoring of homes, oces, banks, hospitals, child-care centers, and amusement parks.
Remote Monitoring Utility
The D-ViewCam application adds enhanced features and functionality for the Network Camera and allows administrators to congure and access the Network Camera from a remote site via Intranet or Internet. Other features include image monitoring, recording images to a hard drive, viewing up to 32 cameras on one screen, and taking snapshots.
6D-Link DCS-6010L User Manual
Section 1: Product Overview
1
2

Hardware Overview

Outside

5
6
3
4
1 Camera Lens
2 Camera Cover
3 Microphone
4 MicroSD Card Slot
5 WPS Status LED
6 Status LED
7 WPS Button
7
8
Records video of the surrounding area
Rotate the cover counter-clockwise to remove it and access the Ethernet port and power connector
Caution: When removing the cover, remove it slowly to avoid disconnecting the microphone.
Records audio from the surrounding area
Insert a MicroSD card for Local storage for storing recorded image and video
Indicates the WPS connection status of the camera
current status
Indicates the camera's current power and connectivity status.
Press this button, then press the WPS button for 5 seconds on your router to set up a wireless connection automatically
Indicates the camera's
8 Reset Button
Press and hold this button for 10 seconds to reset the camera
7D-Link DCS-6010L User Manual
Section 1: Product Overview

Internal Ports

You can access the inside of the DCS-6010L by rotating the camera cover counter-clockwise, then lifting it o of the camera.
Caution: When removing the cover, remove it slowly to avoid disconnecting the microphone.
1 Ethernet Cable
2 Power Cable
Pre-attached Ethernet cable.
Pre-attached power cable.
8D-Link DCS-6010L User Manual
Section 2: Installation

Installation

Wireless Installation Considerations

This D-Link device can connect to your wireless network from anywhere within the operating range of your wireless network. However, the number, thickness and location of walls, ceilings, or other objects that the wireless signals must pass through, may limit the range. Typical ranges vary depending on the types of materials and background RF (radio frequency) noise in your home or business. The key to maximizing wireless range
is to follow these basic guidelines:
1. Minimize the number of walls and ceilings between your adapter and other network devices (such as your Network Camera) - each wall or ceiling can reduce your adapter’s range from 3-90 feet (1-30 meters).
2. Be aware of the direct line between network devices. A wall that is 1.5 feet thick (.5 meters), at a 45-degree angle appears to be almost 3 feet (1 meter) thick. At a 2-degree angle, it looks over 42 feet (14 meters) thick. Position your devices so that the signal will travel straight through a wall or ceiling (instead of at an angle) for better reception.
3. Building Materials make a dierence. A solid metal door or aluminum studs may weaken the wireless signal. Try to position your access points, wireless routers, and other networking devices where the signal passes through drywall or open doorways. Materials and objects such as glass, steel, metal, walls with insulation, water (sh tanks), mirrors, le cabinets, brick, and concrete will degrade your wireless signal.
4. Keep your product at least 3-6 feet or 1-2 meters away from electrical devices or appliances that generate RF noise.
5. If you are using 2.4GHz cordless phones or other radio frequency sources (such as microwave ovens), your wireless connection may degrade dramatically or drop completely. Make sure your 2.4GHz phone base is as far away from your wireless devices as possible. The base transmits a signal even if the phone in not in use.
9D-Link DCS-6010L User Manual
Section 2: Installation
Zero Conguration Setup
If you have a mydlink-enabled Cloud Router, you can take advantage of Zero Conguration. Zero Conguration automatically congures your camera's settings for you, and adds it to your mydlink account automatically. This type of setup allows you to set up your camera by simply plugging it in and connecting it to your router.
Connect your camera to your mydlink-enabled Cloud Router and Zero Conguration will automatically congure your DCS-6010L and automatically add the camera to your mydlink account. After the short time it takes to do this you can remotely access your camera from the www.mydlink.com website to manage and monitor your DCS-6010L.
Connect the Ethernet Cable
Using the pre-attached Ethernet cable connect the free-end to your network.
To use a longer ethernet cable or install a coupling adaptor, or see "Internal Ports" on page 8 for more details. for how to change the Ethernet cable.
Attach the External Power Supply
Attach the external power supply to your wall outlet or power strip.
1 Ethernet Cable
2 Power Cable
Pre attached Ethernet cable
Pre attached power cable.
1
2
10D-Link DCS-6010L User Manual
Section 2: Installation
Optional: WPS Wireless Connection
Alternatively, if your router supports WPS, you can use the WPS button on the camera to easily create a secure wireless connection to your network.
To create a WPS connection:
Step 1
Press and hold the WPS button for approximately 5-6 seconds. The WPS LED will blink.
Step 2
Within 60 seconds press the WPS button on your router. On some routers, you may need to log in to the web interface and click on an on-screen button to activate the WPS feature. If you are not sure where the WPS button is on your router, please refer to your router’s User Manual.
The DCS-6010L will automatically create a wireless connection to your router. While connecting, the status LED will ash. When the connection process is complete, the status LED will turn solid.
You can now remove the pre-attached Ethernet cable by removing the camera cover and disconnecting the Ethernet cable. See "Internal Ports" on page 8 for more details.
Note: If your router does not support WPS, you can still use the wired connection method on the previous page. After Zero Conguration setup is complete, your router's wireless settings will be automatically transferred to the camera.
WPS ButtonWPS LED
11D-Link DCS-6010L User Manual
Section 2: Installation
Check Your mydlink Account
From any computer, open a web browser, go to http://www.mydlink.com and log into your account. Once mydlink detects your camera, a New Device Found! notice will appear in the bottom-left corner. Click on the device name to continue.
A summary and conrmation notication will appear with the automatically congured details. Make a note of the details and click OK to add the camera to your account.
12D-Link DCS-6010L User Manual
Section 2: Installation
Zero Conguration is now complete and your camera has been added to your mydlink account. You can now view your camera on the mydlink Live View tab.
If you wish to connect your camera to your router wirelessly, you can simply disconnect the Ethernet cable and move the camera to its intended location; your router's wireless settings have been automatically transferred to the camera, and no further conguration is required.
Your camera is now set up, and you can skip to "mydlink" on page 25 to learn more about the mydlink features of this camera, or to "Conguration" on page 34 for advanced conguration of your camera.
13D-Link DCS-6010L User Manual
Section 2: Installation

Camera Installation Wizard

Insert the Installation CD-ROM into your computer’s optical drive to start the autorun program.
The CD-ROM will open the Camera Installation Wizard. Simply click Setup Your Camera to go through the Installation Wizard, which will guide you through the installation process from connecting your hardware to conguring your camera.
14D-Link DCS-6010L User Manual
Section 2: Installation
Select your preferred language for the installation from the drop down menu and click on Start to continue.
Connect the included Ethernet cable to the internal network cable connector of the DCS-6010L and attach it to the network.
Click Next to continue.
15D-Link DCS-6010L User Manual
Section 2: Installation
Connect the other end of the same Ethernet cable to a router.
Click Next to continue.
Attach the external power supply to the power connector located inside the DCS-6010L and connect it to your wall outlet or power strip.
Click Next to continue.
16D-Link DCS-6010L User Manual
Section 2: Installation
The LED on the front of the DCS-6010L will blink, then turn solid green once it successfully connects to your network. Click Next to proceed.
If the LED continues to stay red, check your connections or click on the "What should I do if the LED stays red?" link for more information.
Select your camera from the list, then click Next. If you have multiple cameras, you can identify them by the MAC ID printed on the label on the back of your camera.
17D-Link DCS-6010L User Manual
Section 2: Installation
If you wish to remove the camera from a previously registered mydlink account, press and hold the reset button on the rear panel for at least 10 seconds and click Restart to restart the wizard.
After you have selected your camera from the list, you will be asked to create and conrm a password for it. The password is case sensitive and must contain at least 2 letters.
Click Next to continue.
18D-Link DCS-6010L User Manual
Section 2: Installation
To move the camera to a wireless connection by using WPS or by selecting a wireless network, select the appropriate option then follow the steps displayed. Otherwise, click Next to continue.
Complete the mydlink account registration form with your details making sure to select the I accept mydlink terms and conditions box, and click the Next button.
19D-Link DCS-6010L User Manual
Section 2: Installation
If you already have a mydlink account, enter your login details and click Next to proceed.
Conrm your mydlink account details and give the camera a unique name and click Done.
20D-Link DCS-6010L User Manual
Section 2: Installation
Conrm your camera login details and IP address details and click Done.
Your DCS-6010L camera is now set up. Log on to your mydlink account and explore the exciting benets available to you.
Your camera is now set up, and you can skip to "mydlink" on page 25 to learn more about the mydlink features of this camera, or to "Conguration" on page 34 for advanced conguration of your camera.
21D-Link DCS-6010L User Manual
Section 2: Installation

Manual Hardware Installation

If you wish to set up your camera without using the Camera Setup Wizard, please follow these steps.
Note: In order to use the mydlink features of this product, you will need to go through the Camera Setup Wizard.
Connect the Ethernet Cable
Using the pre-attached Ethernet cable connect the free end to your network.
To use a longer ethernet cable or install a coupling adaptor, or see "Internal Ports" on page 8 for more details. for how to change the Ethernet cable.
Attach the External Power Supply
Attach the external power supply to your wall outlet or power strip.
1 Ethernet Cable
2 Power Cable
Pre attached Ethernet cable
Pre attached power cable.
1
2
22D-Link DCS-6010L User Manual
Section 2: Installation

Mounting the Camera

The DCS-6010L is suitable for mounting to a ceiling, wall or desktop using the bracket provided.
Note: In order to use the mydlink features of this product, you will need to go through the Camera Setup Wizard.
Step 1
Unclip the wall bracket from the DCS-6010L by sliding the base down.
Step 2
Position the mounting bracket in the desired location and mark the surface behind it holes using the bracket as a stencil / in pencil
Step 3
Use a 6mm drill bit to make required holes approximately 25mm deep.
Step 4
Insert wall anchors.
Step 5
Ax bracket using the screws provided.
Step 6
Clip the DCS-6010L to the bracket ensuring a tight t
Note: if mounting on a wall ensure the camera is oriented with the cables positioned to the bottom of the device.
1
23D-Link DCS-6010L User Manual
Section 2: Installation

WPS - Push Button Setup

If your router supports WPS, you can use the WPS button on the camera to easily create a secure wireless connection to your network.
To create a WPS connection:
Step 1
Press and hold the WPS button for approximately 5-6 seconds. The WPS LED will blink.
Step 2
Within 60 seconds press the WPS button on your router. On some routers, you may need to log in to the web interface and click on an on-screen button to activate the WPS feature. If you are not sure where the WPS button is on your router, please refer to your router’s User Manual.
WPS ButtonWPS LED
The DCS-6010L will automatically create a wireless connection to your router. While connecting, the status LED will ash. When the connection process is complete, the status LED will turn solid.
Note: If your router does not support WPS, you can still use the wired connection method on the previous page.
24D-Link DCS-6010L User Manual
Loading...
+ 54 hidden pages
