D-Link DCH-Z310 User Manual
DCH-Z310
User Manual
mydlink™ Z-Wave Smoke Alarm
Version 1.00 | 1/04/2017
iD-Link DCH-Z310 User Manual
D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization
of such revisions or changes.
Manual Revisions
Revision Date Description
1.00 December 2, 2016 • Initial Release
Trademarks
D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States or other countries.
All other company or product names mentioned herein are trademarks or registered trademarks of their respective companies.
Apple®, Apple logo®, Safari®, iPhone®, iPad®, iPod touch® and Macintosh® are trademarks of Apple Inc., registered in the U.S. and other countries. App
StoreSM is a service mark of Apple Inc. Chrome™ browser, Google Play™ and Android™ are trademarks of Google Inc. Internet Explorer®, Windows®
and the Windows logo are trademarks of the Microsoft group of companies.
Copyright © 2016 by D-Link Corporation, Inc. All rights reserved. This publication may not be reproduced, in whole or in part, without prior expressed
written permission from D-Link Corporation, Inc.
Preface
iiD-Link DCH-Z310 User Manual
Table of Contents
Preface ................................................................................. i
Manual Revisions ........................................................................... i
Trademarks ...................................................................................... i
Product Overview ..............................................................1
Package Contents ......................................................................... 1
System Requirements ................................................................. 2
Introduction ................................................................................... 3
Hardware Overview ..................................................................... 4
Front/Bottom .........................................................................4
Back............................................................................................5
Wireless Installation Factors ..................................................... 6
Hardware Installation .................................................................. 7
Choosing a Location ............................................................ 7
Mounting the Device ........................................................11
Setting Up Your Device .............................................................13
mydlink™ Home ...............................................................15
My Devices ....................................................................................15
Information ...................................................................................16
My Actions ....................................................................................17
My Places .......................................................................................20
Troubleshooting .............................................................. 22
Manually Adding the Device to Your
Z-Wave™ Network .......................................................................23
Manually Removing the Device From Your Z-Wave™
Network .........................................................................................24
Replacing the Battery................................................................25
Testing Your Smoke Alarm ......................................................26
Technical Specications .................................................. 27
Regulatory Information ..................................................28
Table of Contents
1D-Link DCH-Z310 User Manual
Section 1 - Product Overview
Product Overview
Package Contents
If any of the above items are missing from your package, please contact your reseller.
Quick Install Card
DCH-Z310 mydlink™ Z-Wave Smoke Alarm
1 x CR123A Battery
Mounting Kit
Quick Install Card
2D-Link DCH-Z310 User Manual
Section 1 - Product Overview
System Requirements
General Requirements • A mydlink™ Connected Home Hub
Mobile Requirements • iPhone, iPad, iPod touch, or Android smartphone or tablet
1
1
Please refer to the mobile app’s store page to check whether your device is compatible.
3D-Link DCH-Z310 User Manual
Section 1 - Product Overview
Introduction
Features
The DCH-Z310 mydlink™ Z-Wave Smoke Alarm is a wireless early warning detection system that warns you of developing
res by broadcasting audible alarms via its built-in horn. Based on Z-Wave Plus™ technology, it oers longer battery life, faster
operation, better RF coverage, and easier installation while keeping compatibility with classic Z-Wave™ products. You can set
an alarm via the mydlink™ Home app so when you’re away, the DCH-Z310 will be enabled and ready to send signals to a hub
such as the mydlink™ Home Connected Home Hub. When the alarm is triggered, it will generate an 85 dB (max) audio alarm
while pushing instant notications to your mobile device, so you can stay informed from wherever you are.
Works With Other D-Link Connected Home Devices
The mydlink™ Z-Wave Smoke Alarm can trigger other D-Link Connected Home devices, so you can customize your own home
automation system to suit your purposes.
mydlink™ Home
Manage your smoke detector and connected appliances by using the mydlink™ Home app available for iPhone®, iPad®, iPod
touch®, and Android™ devices. Its intuitive user interface and simple instructions let you easily manage your automated devices
from anywhere.
Simple Setup
Through the free easy-to-use mydlink™ Home app, you can quickly and easily connect the DCH-Z310 to an existing network.
The setup wizard will even guide you through the setup process, so you can get your home automation devices up and running
in no time.
4D-Link DCH-Z310 User Manual
Section 1 - Product Overview
Hardware Overview
Front/Bottom
1
Pairing /
Unpairing / Test
/ Reset Button &
LED
Press the button three times quickly to set the device to Add or Remove mode.
Press the button three times and hold the fourth time until you hear a beep to reset the DCH-Z310 to the
factory default settings.
Blinking Red The alarm has been triggered.
Light O The alarm has not been triggered.
2 Speaker Alarm sounds when the sensor is triggered.
2
1
5D-Link DCH-Z310 User Manual
Section 1 - Product Overview
Hardware Overview
Back
1 Tamper Switch If the detector is removed from a surface (wall, ceiling, etc.), the alarm will sound.
2
Battery
Compartment
Open the cover and insert a CR123A battery to power the device.
2
1
6D-Link DCH-Z310 User Manual
Section 2 - Installation
Wireless Installation Factors
The mydlink™ Z-Wave Smoke Alarm connects to your home automation network using your existing wireless network. Keep in
mind, however, that the number, thickness, and location of walls, ceilings, or other objects that the wireless signals must pass
through, may limit the range. Typical ranges vary depending on the types of materials and background RF (radio frequency)
noise in your home or business. The key to maximizing wireless range is to follow these basic guidelines:
1. Keep the number of walls and ceilings between the extender and other network devices to a minimum - each wall or
ceiling can reduce your adapter’s range by up to 98 feet (30 meters). Position your devices so that the number of walls
or ceilings is minimized.
2. Be aware of the direct line between network devices. At a 45-degree angle, a wall that is 0.5 meters thick (1.5 feet)
appears to be almost 1 meter (3 feet) thick. At a 2-degree angle it can appear over 14 meters (45 feet) thick! Position
devices so that the signal will travel straight through a wall or ceiling (instead of at an angle) for better reception.
3. Building materials make a dierence. A solid metal door or aluminum studs may have a negative eect on range. Try
to position access points, wireless routers, and computers so that the signal passes through drywall or open doorways.
Materials and objects such as glass, steel, metal, walls with insulation, water (sh tanks), mirrors, le cabinets, brick, and
concrete can degrade your wireless signal.
4. Keep your product away (at least 3-6 feet or 1-2 meters) from electrical devices or appliances that generate RF noise.
7D-Link DCH-Z310 User Manual
Section 2 - Installation
Hardware Installation
Choosing a Location
For complete coverage in residential buildings, smoke sensors should be installed in all rooms, halls, storage areas, basements
and attics. The minimum coverage is one sensor on each oor and one in each sleeping area.
• Install the smoke sensor as close to the center of the ceiling
as possible. If this is not practical, install the sensor on the
ceiling no closer than 50 cm from any wall, ceiling joists, or
xtures.
• Install the mydlink Home Smoke Detector as horizontally
level as possible at an inclination angle of no more than 20°.
• In case you must install the DCH-Z310 in a room with a steep
ceiling slope, mount it at least 50 cm but no more than 1 m
below the ceiling peak.
• If mounting on the ceiling is not possible, mount the sensor
on the wall 4-6 inches (10-15cm) from the ceiling.
• If the area to be monitored is greater than 60 m
2
or is separated by
ceiling joists, install multiple mydlink Home Smoke Detectors
for better coverage.
Figure 1:
Leave a minimum of 50 cm length between the alarm and any
wall or corner.
Figure 2:
If installing on an inclined ceiling, leave a minimum of 50 cm but not
more than 100 cm length between the alarm and the ceiling peak.
Ceiling
Center of
ceiling
20 in. (50 cm)
Minimum
Corner
Best Location
Acceptable
Location
Detector
Minimum 0.5M(1.65ft)
to maximum 1M (3.3ft)
8D-Link DCH-Z310 User Manual
Section 2 - Installation
To avoid false alarms, do not install smoke sensors in the following situations:
• Combustion particles produced by burning will trigger the alarm. These are commonly found in kitchens with few windows
or poor ventilation, garages where there may be vehicle exhaust fumes, or near furnaces, hot water heaters, and space
heaters. Position your smoke detector at a distance greater than 20 feet (6 m) from the source of combustion particles. If
a 20-foot distance is not possible, e.g. in a mobile home, try to install the alarm as far away from the combustion particles
as possible, preferably on the wall, and keep the location well-ventilated.
• In very dusty or dirty areas, dirt and dust can build up on the alarm’s sensing chamber, and make it overly sensitive.
Additionally, dust or dirt can block the openings to the sensing chamber and prevent the alarm from sensing smoke
eectively.
• Electrical “noise” from uorescent lights may cause false alarms. Install the smoke sensor at least 5 feet (1.5 m) from
uorescent lights.
Warning:
• Do not mount the mydlink Home Smoke Detector near air vents or wherever there are strong drafts, heavy steam, smoke,
or dust.
• Do not paint the DCH-Z310 as paint may clog the vents and prevent proper functioning.
• Do not use a burning cigarette to test the DCH-Z310 as cigarette smoke clogs the vents. Use the test button to check the
device’s functionality.
• Never remove the battery from smoke alarm to stop a nuisance alarm. Open a window or fan the air around the smoke
alarm to get rid of the smoke. The alarm will turn itself o when the smoke is gone. If nuisance alarms persist, attempt to
clean the smoke alarm as described in this User’s Manual.
• Do not stand close to the smoke alarm when the alarm is sounding. The alarm is loud in order to wake you in an emergency.
Too much exposure to the horn at close range may be harmful to your hearing.
9D-Link DCH-Z310 User Manual
Section 2 - Installation
Placement Examples
The following diagrams are examples of where you can place DCH-Z310 units to ensure thorough coverage of your environment.
DININ G R OOM
BEDROOM
KITCHEN
Smoke al arms f or more secu ri ty
LIVING ROOM
BED
ROOM
BED
ROOM
• Install a separate smoke alarm in every bedroom and one on
each oor excluding the kitchen and bathroom for minimum
coverage.
• Install a separate smoke alarm in every bedroom and an
additional one in the hallway for best coverage.
FAMILY R OOM
BEDROOM
KITCHEN
Smoke al arms f or minimum secu rity
LIVING ROOM
BED
ROOM
BED
ROOM
BED
ROOM
10D-Link DCH-Z310 User Manual
Section 2 - Installation
Ground oor Kitchen
Basement
Smoke detectors for minimum security
Garage
Bedroom
Bedroom
Bedroom
Placement for Multi-oor Residences
If you have more than one oor to cover, install DCH-Z310 units in the following recommended locations for the best coverage.
11D-Link DCH-Z310 User Manual
Section 2 - Installation
Mounting the Device
Step 3:
Place the bracket so that the two longest hole slots are aligned
with the horizontal line you drew in Step 1. In each keyhole slot,
use a pencil to mark the location for the plastic anchors and
screws.
Step 1:
Draw a horizontal line that is six inches long at your chosen install
location.
Step 2:
Remove the mounting bracket from your device by rotating it
counter-clockwise.
12D-Link DCH-Z310 User Manual
Section 2 - Installation
Step 4:
Remove the bracket from the wall. Depending on the material
of the wall or ceiling, use appropriate tools to drill two holes at
your markings. After drilling the holes, insert the plastic anchors
to support the screws.
Step 5:
Screw the bracket into the wall. Line up the bracket and the smoke
sensor, then push the sensor onto the mounting bracket.
Step 6:
Attach the cover to the mounting bracket for your device by
turning it clockwise to x it into place. Ensure that the smoke
sensor is securely attached to the mounting bracket.
