Citizen CH-437C User Manual

INSTRUCTION MANUAL

FOR

DIGITAL BLOOD PRESSURE MONITOR

REF CH-437C

English
Español
Português
Deutsch

- Eng 1-

- Eng 1 -

GENERAL REMARKS

General remarks on blood pressure and blood pressure measurement

1. If the cuff is to be deflated quickly, depress “POWER” switch.

2. The attached cuff is suited for an arm circumstance of 22 cm to 32 cm.

3. When attaching the cuff, the air hose should be placed on the inside of your arm on top
of the arterial.

4. Self measurement is not therapy! In no case may you change the dosage of medication
prescribed by your physician.

5. In preparation for blood pressure measurement, you should urinate and then remain
relatively still for 10 to 15 minutes prior to measurement.

6. Exercising, eating, drinking, smoking, etc., prior to measurement may affect the results.

7. Blood pressure varies constantly throughout the day. Measurement should be made
regularly at the same time each day.

8. DO NOT be too impressed by the results of one measurement. Keep a record of blood
pressure variations. Many reading tell a story.

9. Emotional stress may tend to cause blood pressure to rise.

For proper measure of blood pressure

1. Take a deep breath five or six times and then relax before measuring your blood
pressure. If you are tense when taking the measurement, you will not get a valid reading.

2. Blood pressure will be elevated when you are in a worrisome or irritated state, suffering
from lack of sleep or constipation, or after exercise or a meal.

3. Wrap the cuff around the arm and tighten it so that one finger may be inserted between
the cuff and arm. (See page 15)

4. DO NOT measure blood pressure after bathing or drinking.

5. When you feel like relieving yourself, you should do so before measuring your blood
pressure.

6. Measure your blood pressure where the room temperature is about 20°C. DO NOT
measure blood pressure when it is too cold (below 10°C) or too hot (above 40°C) in the
room.

- Eng 2-

- Eng 2 -

GENERAL REMARKS

7. DO NOT try to measure blood pressure immediately after drinking coffee or tea or
smoking.

8. Measure blood pressure with a relaxed and quiet posture. Keep the center of the cuff at
the level of your heart, and DO NOT move your arm or talk.

9. DO NOT measure blood pressure after the cuff has been on for a few minute, as your
arm will have built up higher blood pressure, and you will not get valid reading.

10. Next figure shows the classification of blood pressure according to WHO-standard.

Remarks:

The graph is not exact,
but may be used as a
guide in understanding
non-invasive blood
pressure measurements.
The device intended for
use in adult population.

Definition and Classification of Blood Pressure Levels

Measure your blood pressure at the same time on a daily basis.

* The blood pressure changes at all times. This means that data gathered over a long

period has great significance instead of data on just one measurement. It is therefore
necessary to measure your blood pressure on a daily basis. Ideally, you should measure
your blood pressure daily at the same time as far as possible.

English

English

- Eng 3-

- Eng 3 -

PRECAUTION FOR USE AND MAINTENANCE

Precaution for use

1. If you suffer from heart disease, high blood pressure or other circulatory disease, please
consult your doctor first.

2. If you feel abnormal pressure of the cuff during use or any other irregularity, reduce the
pressure by immediately switching off the power or remove the batteries and consult the
sales outlet where purchased.

3. If you think the measured value is abnormal or if measuring makes you feel unwell,
discontinue use and consult your doctor.

4. Measurement of blood pressure may not be possible for someone with a weak pulse or
arrhythmia.

5. If blood pressure is measured repeatedly, congestion, swelling, etc. may occur in some
people.

6. If blood pressure is measured repeatedly, an accurate result will not be achieved. An
interval of about 10 minutes should be allowed.

7. Consult your physician before use if you suffer a severe disorder of blood circulation in
the arms. Failure to do so may cause health hazards.

8. Measurement may not be possible for someone with an insufficient blood flow in the area
to be measured or frequent irregular heartbeats. Consult your physician for judgment.

9. DO NOT wrap the arm cuff around an injured arm.

10. DO NOT

11. DO NOT use in the vicinity of flammable gases such as anesthetic gases because of the

12. DO NOT use in enriched oxygen environments such as a hospital’s hyperbaric chamber

13. DO NOT use a mobile phone near the unit. Doing so may result in malfunction.

wrap the arm cuff to the arm where a drip (intravenous infusion) or blood
transfusion under medical treatment. Failure to do so may cause an injury or a serious
accident.

risk of ignition and explosion.

or oxygen tent because of the risk of ignition and fire.

- Eng 4-

- Eng 4 -

PRECAUTIONS FOR USE AND MAINTENANCE

14. If you use a cardiac pacemaker, consult your physician before using the monitor.

15. Be sure to use this unit only for measuring blood pressure. DO NOT use it for any
other purpose.

16. Be sure to use only our authorized parts and accessories. Parts and accessories
not approved for use with the device may damage the unit.

17. DO NOT use this unit on infants.

18. Blood pressure measurement may not be possible for anyone with common
arrhythmias such as atrial or ventricular premature beats or atrial fi brillation.

19. The monitor is not intended to be a diagnostic device, because it is intended for
home use.

Maintenance Precautions

1. DO NOT store the blood pressure monitor in locations exposed to direct sunlight,
high temperatures (over 60°C), low temperatures (below -20°C), high relative
humidity (over 95%) or excessive amounts of dust.
Make sure to store the blood pressure monitor, where children, pets and or pests
are not there.

2. DO NOT drop the blood pressure monitor or the cuff and subject it to other
shocks or vibration.

3. Remove the batteries if the monitor will be left unused for a long period.

4. DO NOT attempt to disassemble the monitor or the cuff.

5. DO NOT bend the cuff or the air hose excessively.

6. If the monitor is very dirty, wipe it clean with a cloth moistened with sterilizing
alcohol or a neutral detergent. Then wipe it with a dry cloth.

7. NEVER clean the blood pressure monitor with thinners or benzene, as this could
damage the monitor.

8. To clean the cuff, wipe it with a moist cloth. Avoid hard rubbing, as this will cause
air leakages. Take care also not to get water into the air hose.

Warning

No modifi cation of this device is allowed.

English

- Eng 5-

PRECAUTIONS FOR USE AND MAINTENANCE

Intended Use

• This device is noninvasive blood pressure monitor by oscillometric method. This
device can measure the systolic blood pressure (SYS), the diastolic blood pressure
(DIA) and the pulse rate automatically.

• This device is intended to be used for checking personal health condition at home
under the direction of a physician and is not intended to be a diagnostic device.

• This device is not intended for use with neonates or infant, and not intended for
automatic cycling measurement.

Symbols Explanation

: The CE marking is meant to provide information to market inspectors in

the EU member countries.
: Type BF applied part
: Keep dry

: Warning

: Refer to instruction manual before use

: Appliance compliance WEEE directive

: Accumulators and battery packs for separate collection

Pb

: Manufacturer

The device has been tested and homologated in
accordance with EN60601-1-2 for EMC. This does

Warning

not guarantee in any way that the device will not be
affected by electromagnetic interference. Avoid using
the device in high electromagnetic environment.

Reference European standard:

The blood pressure measuring device corresponds to regulation EN60601-1,
EN1060-1, EN1060-3, EN1060-4.

- Eng 6-

PRECAUTIONS FOR USE AND MAINTENANCE

Nature and frequency of maintenance:

This product is designed for use over an extended period of time;
however, it is generally recommended that it be inspected every two
years to ensure proper function and performance.

Protect the nature environment:

Please help to protect natural environment by respecting national and/or local recycling regulations
when disposing of the battery and the product at the end of their useful live.

WEEE MARK

If you want to dispose this product, do not mix with general household waste. There is a
separate collection systems for used electronics products in accordance with legislation under
the WEEE Directive (Directive 2002/96/EC) and is effective only within European Union.

Information for Users on Collection and Disposal of used Batteries.

The symbol in this information sheet means that used batteries should not be mixed with
general household waste.
For proper treatment, recovery and recycling of used batteries, please take them to applicable
collection points.
For more information about collection and recycling of batteries, please contact your local
municipality, your waste disposal service or the point of sale where you purchased the items.

Information on Disposal in other Countries outside the European Union.

This symbol is only valid in the European Union.
If you wish to discard used batteries, please contact your local authorities or dealer and ask for the
correct method of disposal.

Note for the battery symbol.

The symbol might be used in combination with a chemical symbol. In this case it complies with the
requirement set by the Directive for the chemical involved.

Calibration:

The blood pressure measuring device is generally recommended to have the monitor inspected
every two years to ensure correct functioning and accuracy. Please contact a distributor.

Name : CITIZEN SYSTEMS (H.K.) LIMITED
Address : 01/F, 64 Hung To Road, Kwun Tong, Kowloon, Hong Kong

European Representative:

Name : WvW electronishe Geräte Vertrieb GmbH
Address : Fintelmannstraße 20/Eingang, Martin-Heydert-Straße,

• For technical data, please contact our European Representative

D-14109 Berlin, Germany

- Eng 7-

Pb

English

Air Hose socket

MEMORY switch

POWER switch

Stand-by

Battery compartment cover

AC adapter socket

Pocket
(for storing arm cuff)

Systolic blood pressure
display section

Diastolic blood pressure
display section

Pulse display
section

SYS

DIA

PULS

/min.

Arm cuff

Air hose plug

Air hose

IDENTIFICATION OF PARTS

- Eng 8-

- Eng 8 -

HOW TO LOAD BATTERIES

Air hose
plug

AC adapter
plug

lock section

draw

push

Remove the plugs.

1

Remove the air hose plug and AC adapter
plug.

Remove the Pocket.

2

While pressing the lock section on the bottom
of the pocket, pull the pocket in the direction
of the arrow.

Open the battery compartment

3

cover.

While pressing the lock section of the battery
compartment cover, pull the cover toward you
to open.

English

- Eng 9 -
