Citizen CDC-80VPU, CDC-80VBL Operating Instructions

* POWER SUPPLY

English

CITIZEN model CDC-80/CDC-100 is a dual-powered (high power solar + back-up battery) calculator operative under any lighting conditions.

-Auto power-off function-

The calculator switches the power off automatically if there has been no key entry for about 10 minutes.

-Battery change-

Remove the screw and the battery cover. Install a new battery with the + symbol facing upward. After changing, use a pointed object to press the RESET hole near the battery. Replace the battery cover and secure the screw.

* KEY INDEX

English

[CEON/ C] : Power on / Clear entry / Clear key [M+] : Memory plus key

[M–] : Memory minus key

[MRC] : Memory recall key / Memory clear key [MU] : Price mark-up / down key

[+/–] : ± Sign change key [RATE] : Tax rate setting key

[−RECALLTAX] : Price without tax key / To recall tax rate when pressing [RATE] and [–TAX] keys

[+TAXSET ] : Price with tax key / To store tax rate when pressing [RATE] and [+TAX] keys

The Signs Of The Display Mean The Following :

MEMORY : Memory	TAX : Amount of tax
–MINUS : Minus (or negative)	–TAX : Price excluding tax
ERROR : Overflow-error	+TAX : Price including tax
% : Tax rate stored and recalled	RATE : Tax rate setting
* OPERATION EXAMPLES			English

1.Calculation Examples

Before performing each calculation, press the [CE/C] key two times.

Example				Key operation		Display
2 x 3 = 6				2	[x] 2 [CE/C] 3 [=]	6.
6 + 4 + 7.5 = 17.5				6	[+] 4 [+] 7.5 [=]	17.5
3 – 6 – 4 = –7				3	[–] 6 [–] 4 [=]	–7.
5 x 3 ÷ 0.2 = 75				5	[x] 3 [÷] 0.2 [=]	75.
300 x 27% = 81				300 [x] 27 [%]		81.
11.2		x 100% = 20%		11.2 [÷] 56 [%]		20.
56
300 + (300 x 40%) = 420				300 [+] 40 [%]		420.
300 – (300 x 40%) = 180				300 [–] 40 [%]		180.
54 = 625				5	[x] [=] [=] [=]	625.
1 / 2 = 0.5				2	[÷] [=]	0.5
1			= 0.0625	2	[x] 3 [+] 10 [÷] [=]	0.0625
	(2 x 3 +10)

2.Memory Calculation

	(25 x 5) – (84 ÷ 3)	[MRC] [MRC] [CE/C]			MEMORY	125.
	+ (68 + 17) = 182	25		[x] 5 [M+]
		84		[÷] 3 [M–]	MEMORY	28.
		68		[+] 17 [M+]	MEMORY	85.
		[MRC]			MEMORY	182.
	(52 – 35) ÷ (14 – 3 x 2)	[MRC] [CE/C] 14 [M+] 3 [x] 2
	= 2.125	[M–] 52 [–] 35 [÷] [MRC] [=]			MEMORY	2.125
	135 x (12 + 14) = 3510	[MRC] [MRC] [CE/C]
	(12 + 14) ÷ 5 = 5.2	12		[+] 14 [M+]
		135 [x] [MRC] [=]			MEMORY	3'510.
		[MRC] [÷] 5 [=]			MEMORY	5.2
	3.Constant Calculation
	2 + 3 = 5	2	[+] 3 [=]			5.
	4 + 3 = 7	4	[=]			7.
	3 x 4 = 12	3	[x] 4 [=]			12.
	3 x 6 = 18	6	[=]			18.

4.Overflow Error Clear

1234567890 x 10000		1234567890
= 1'234.567890 x 1010		[x] 10000 [=]
(CDC-100)		[CE/C] [CE/C]
5.Tax Calculation
100+TAX(3%)		3 [RATE] [+TAX]
= 103		100 [+TAX]
Tax amount = 3		[+TAX]
* 3 = Tax amount	103 = Tax inclusive value
206–TAX(3%)		[CE/C] [RATE] [–TAX]
= 200		206 [–TAX]
Tax amount = 6		[–TAX]
* 6 = Tax amount	200 = Tax exclusive value

1'234'567'890. ERROR 1'234.567890 0.

	3.	%
+TAX	103.
TAX	3.
–TAX	3.	%
	200.

TAX	6.

6.Price Mark-Up & Down Calculation

	2000+(P x 20%)=P						2000 [÷] 20 [MU]	2'500.
	P=		2000		=2'500
			1- 20%				[MU]	500.
	2500–2000 = 500
	2000–(P x 20%)=P						2000 [÷] 20 [+/–] [MU]	1'666.6666
	P=		2000		=1'666.66
			1+ 20%
		18000 - 15000				x100%	18000 [–] 15000 [MU]	20.
			15000
	= 20%

File name: D560-A_English_03.doc	vision : 2007/10/19	SIZE:250x72mm
PARTS NO. HDBMD560100 (D560/D560A)

* ALIMENTACIÓN

Español

Modeio CITIZEN CDC-80/CDC-100 funciona gracias a un mecanismo de doble carg (luz solar y bateria de apoyo), lo cual le permite operar bajo cualquier condicion de iluminación.

-Función de desconexión automática-

La calculadora se apaga automaticamente si no ha sido utilizada durante10 minutos aproximadamente.

-Reemplazada de la pila-

Si la pila de apoyo necesita ser reemplazada, quite los tornillos del parte inferior y sustituya la pila gastada por una nueva. Después del recambio intoduzca un objeto con punta en el agujero RESET que está cerca de la pila y apriete. Coloque la pila en su posición correcta, con la polaridad indicada.

* TECLADO INFOMATIVO

Español

ON

[CE / C] : Tecla de encendido / Tecla de borrar entrada / Borrar [M+] : Tecla de memoria positiva

[M–] : Tecla de memoria negativa

[MRC] : Tecla de llamada de memoria / Tecla de para limpiar la memoria [MU] : Tecla de subir o bajar precios

[+/–] : ±Tecla de cambio de signo

[RATE] : Tecla del Ajuste del Índice de la Tasa

[−RECALLTAX] : Precio sin la Tecla de Tasa / Para recobrar el índice de la tasa cuando presione las teclas de [RATE] y [–TAX]

[+TAXSET ] : Precio con la Tecla de Tasa / Para almacenar el índice de la tasa cuando presione las teclas de [RATE] y [+TAX]

Símbolos Visualizados :

MEMORY : Memória	TAX : Cantidad de tasa
–MINUS : Menos (o negativo)	–TAX : Precio excluyendo la tasa
ERROR : Error de desbordamiento	+TAX : Precio incluyendo la tasa
% : Índice de impuestos almacenado y recuperación
RATE : Ajuste del índice de la tasa
* EJEMPLO DE FUNCIONES		Español

1.Ejmplos de calculación

Antes de realizar cada cálculo, presione la tecla [CE/C].

Ejemplo					Operación con la tecla		Visualizacón
2 x 3 = 6					2	[x] 2 [CE/C] 3[=]	6.
6		+ 4 + 7.5 = 17.5			6	[+] 4 [+] 7.5 [=]	17.5
3		– 6 – 4 = –7			3	[–] 6 [–] 4 [=]	–7.
5 x 3 ÷ 0.2 = 75					5	[x] 3 [÷] 0.2 [=]	75.
300 x 27% = 81					300 [x] 27 [%]		81.
	11.2		x 100% = 20%		11.2 [÷] 56 [%]		20.
		56
300 + (300 x 40%) = 420					300 [+] 40 [%]		420.
300 – (300 x 40%) = 180					300 [–] 40 [%]		180.
54 = 625					5	[x] [=] [=] [=]	625.
1		/ 2 = 0.5			2	[÷] [=]	0.5
		1		= 0.0625	2	[x] 3 [+] 10 [÷] [=]	0.0625
	(2 x 3 +10)

2.Cálculo de memoria

(25 x 5) – (84 ÷ 3)	[MRC] [MRC] [CE/C]		MEMORY	125.
+ (68 + 17) = 182	25	[x] 5 [M+]
	84	[÷] 3 [M–]	MEMORY	28.
	68	[+] 17 [M+]	MEMORY	85.
	[MRC]		MEMORY	182.
(52 – 35) ÷ (14 – 3 x 2)	[MRC] [CE/C] 14 [M+] 3 [x] 2
= 2.125	[M–] 52 [–] 35 [÷]
	[MRC] [=]		MEMORY	2.125
135 x (12 + 14) = 3510	[MRC] [MRC] [CE/C]
(12 + 14) ÷ 5 = 5.2	12	[+] 14 [M+]
	135 [x] [MRC] [=]		MEMORY	3'510.
	[MRC] [÷] 5 [=]		MEMORY	5.2

3.Constante

2 + 3 = 5						2 [+] 3 [=]				5.
4 + 3 = 7						4 [=]				7.
3 x 4 = 12						3 [x] 4 [=]				12.
3 x 6 = 18						6 [=]				18.
4.Limpiar para desbordamiento y error
1234567890 x 10000						1234567890		1'234'567'890.
= 1'234.567890 x 1010						[x] 10000 [=]	ERROR		1234.567890
(CDC-100)						[CE/C] [CE/C]				0.
5.Calculación de impuestos
100+TAX(3%)						3 [RATE] [+TAX]			3.	%
= 103						100 [+TAX]		+TAX	103.
Suma de impuesto = 3						[+TAX]		TAX	3.
* 3 = Suma de impuesto						103 = Valor con impuesto
206–TAX(3%)						[CE/C] [RATE] [–TAX]		–TAX	3.	%
= 200						206 [–TAX]			200.
								TAX
Suma de impuesto = 6						[–TAX]			6.
* 6 = Suma de impuesto						200 = Valor sin impuesto
6.Cálculo de subir o bajar precios
2000+(P x 20%)=P						2000 [÷] 20 [MU]			2'500.
P=		2000	=2'500
		1- 20%				[MU]			500.
2500–2000 = 500
2000–(P x 20%)=P						2000 [÷] 20 [+/–] [MU]			1'666.6666
P=		2000		=1'666.66
		1+ 20%
	18000 - 15000				x100%	18000 [–] 15000 [MU]				20.
		15000
= 20%

File name: D560-A_Spanish_03.doc version : 04/09/10

* FONT DE ALIMENTACÃO

Português

CITIZEN modelo CDC-80/CDC-100 tem dupla fonte de alimentação de energia (energia solar e bateria de reserva), permitindo operar sob qualquer condição de iluminação.

-Função Auto power-off (desligamento automá)-

A calculadora desliga automáticamente, caso nenhum a tecla seja utilizada por aproximadamente 10 minutos.

-Troca de bateria-

Remova o parafuso e a tampa da bateria. Instale uma bateria nova com o símbolo + voltado para cima. Depois do carregamento, use um objeto pontudo para pressionar o furo do RESET (REAJUSTE) próximo da bateria. Recoloque a tampa da bateria e aperte o parafuso.

* ÍNDICE DE TECLAS

Português

ON

[CE / C] : Tecla para Ligar / Tecla para Limpar Entrada / Limpar [M+] : Tecla de mais da memoria

[M–] : Tecla de menos da memoria

[MRC] : Tecla da rechamada da memória / Tecla para limpar a memória [MU] : Tecla para Marca Preço para cima / baixo

[+ / –] : Tecla para mudar Sinal ±

[RATE] : Tecla para Ajuste do Índice da Taxa

RECALL

[−TAX] : Preço sem a Tecla de Taxa / Para recuperar o índice da taxa quando pressionadas as teclas [RATE] e [–TAX]

SET

[+TAX ] : Preço com a Tecla de Taxa / Para armazenar o índice da taxa quando pressionadas as teclas [RATE] e [+TAX]

Símbolos Visualizados :

MEMORY : Memória	TAX : Quantia de taxa
–MINUS : Menos (ou negativo)	–TAX : Preço excluindo a taxa
ERROR : Erro por transbordamento	+TAX : Preço incluindo a taxa
% : Valor da taxa armazenada e chamada
RATE : Ajuste do índice da taxa
* EXEMPLOS DE OPERACÃO		Português

1.Exemplo de calculos

Antes de executar cada cálculo, pressione a tecla [CE/C] 2 vezes.

Exemplo					Operação com a tecla		Visualização
2 x 3 = 6					2	[x] 2 [CE/C] 3[=]	6.
6		+ 4 + 7.5 = 17.5			6	[+] 4 [+] 7.5 [=]	17.5
3		– 6 – 4 = –7			3	[–] 6 [–] 4 [=]	–7.
5 x 3 ÷ 0.2 = 75					5	[x] 3 [÷] 0.2 [=]	75.
300 x 27% = 81					300 [x] 27 [%]		81.
	11.2		x 100% = 20%		11.2 [÷] 56 [%]		20.
		56
300 + (300 x 40%) = 420					300 [+] 40 [%]		420.
300 – (300 x 40%) = 180					300 [–] 40 [%]		180.
54 = 625					5	[x] [=] [=] [=]	625.
1		/ 2 = 0.5			2	[÷] [=]	0.5
		1		= 0.0625	2	[x] 3 [+] 10 [÷] [=]	0.0625
	(2 x 3 +10)

2.Memória

(25 x 5) – (84 ÷ 3)	[MRC] [MRC] [CE/C]		MEMORY	125.
+ (68 + 17) = 182	25 [x] 5 [M+]
	84 [÷] 3 [M–]		MEMORY	28.
	68 [+] 17 [M+]		MEMORY	85.
	[MRC]		MEMORY	182.
(52 – 35) ÷ (14 – 3 x 2) =	[MRC] [CE/C] 14 [M+] 3 [x] 2
2.125	[M–] 52 [–] 35 [÷]
	[MRC] [=]		MEMORY	2.125
135 x (12 + 14) = 3510	[MRC] [MRC] [CE/C]
(12 + 14) ÷ 5 = 5.2	12 [+] 14 [M+]
	135 [x] [MRC] [=]		MEMORY	3'510.
	[MRC] [÷] 5 [=]		MEMORY	5.2
3.Constante
2 + 3 = 5	2 [+] 3 [=]			5.
4 + 3 = 7	4 [=]			7.
3 x 4 = 12	3 [x] 4 [=]			12.
3 x 6 = 18	6 [=]			18.
4.Erro por excesso
1234567890 x 10000	1234567890		1'234'567'890.
= 1'234.567890 x 1010	[x] 10000 [=]	ERROR	1'234.567890
(CDC-100)	[CE/C] [CE/C]			0.

5.Cálculo da Taxa

100+TAX(3%)		3 [RATE] [+TAX]
= 103		100 [+TAX]
Soma da Taxa = 3		[+TAX]
* 3 = Soma da Taxa	103	= Valor com taxa incluída
206–TAX(3%)		[CE/C] [RATE] [–TAX]
= 200		206 [–TAX]
Soma da Taxa = 6		[–TAX]
* 6 = Soma da Taxa	200	= Valor excluído de Taxa

	3.	%
+TAX	103.
TAX	3.
–TAX	3.	%
	200.

TAX	6.

6.Cálculo para marcação de preço para cima & para baixo

	2000+(P x 20%)=P						2000 [÷] 20 [MU]	2'500.
	P=		2000		=2'500
			1- 20%				[MU]	500.
	2500–2000 = 500
	2000–(P x 20%)=P						2000 [÷] 20 [+/–] [MU]	1'666.6666
	P=		2000		=1'666.66
			1+ 20%
		18000 - 15000				x100%	18000 [–] 15000 [MU]	20.
			15000
	= 20%

File name: D560-A_Portuguese_03.doc version : 04/09/10

* KRAFTVERSORGUNG

Deutsch

CITIZEN model CDC-80/CDC-100 wird durch 2 voneinander unabhängigen Energiequellen versorgt (Entweder durch eine sehr starke solar-zelle oder durch eine batterie). Der rechner arbeitet selbst unter schlechtesten lichtbedingungen.

-Automatische Ausschaltung-

Der rechner schaltet sich automatisch ab, wenn diesen 10 minuten nicht mehr benutzen.

-Batterlewechsel-

Installieren Sie eine neue Batterie mit nach oben gerichteter + Markierung. Benutzen Sie anschließend einen spitzen Gegenstand, um damit in die RESET Öffnung nahe bei der Batterie zu drücken. Bringen Sie die Batterieabdeckung wieder an, und ziehen Sie die Schrauben an.

*

ERKLARUNGEN VON SCHLUSSEL

Deutsch

[CEON/ C] : An / Eingabe löschen / Löschen Taste

[M+] : Speicher Plus taste

[M–] : Speicher Minus taste

[MRC] : Speicher Abruf taste / Speicher Löschen taste

[MU] : Preisangabe-oben / unten Taste

[+ / –] : ±Vorzeicheneingabetaste

[RATE] : Steuerraten-Einstellungstaste

RECALL

[−TAX] : Preis ohne Steuern Taste / Abrufen der Steuerrate, wenn die

Tasten [RATE] und [–TAX] gedrückt werden.

SET

[+TAX ] : Preis mit Steuern Taste / Speichern der Steuerrate, wenn die

Tasten [RATE] und [+TAX] gedrückt werden.

Anzeigesymbole :

MEMORY : Speicher

TAX : Steuerbetrag

–MINUS : Minus(oder negative) –TAX : Preis ohne Steuern

ERROR : Überflussfehler

+TAX : Preis mit Steuern

% : den Steuersatz zu speichern und wieder aufzurufen

RATE : Steuerrate-Einstellung

*

DAS BEISPIEL FUR OPERATIONEN

Deutsch

1.Berechnungsbeispiele

Drücken Sie vor dem Ausführen einer Berechnung jeweils die [CE/C] Taste 2 mal.

Beispiel

Tastenkombination

Anzeige

2 x 3 = 6

2 [x] 2 [CE/C] 3 [=]

6.

6 + 4 + 7.5 = 17.5

6 [+] 4 [+] 7.5 [=]

17.5

3 – 6 – 4 = –7

3 [–] 6 [–] 4 [=]

–7.

5 x 3 ÷ 0.2 = 75

5 [x] 3 [÷] 0.2 [=]

75.

300 x 27% = 81

300 [x] 27 [%]

81.

11.2

x 100% = 20%

11.2 [÷] 56 [%]

20.

56

300 + (300 x 40%) = 420

300 [+] 40 [%]

420.

300 – (300 x 40%) = 180

300 [–] 40 [%]

180.

54 = 625

5 [x] [=] [=] [=]

625.

1 / 2 = 0.5

2 [÷] [=]

0.5

1

= 0.0625

2 [x] 3 [+] 10 [÷] [=]

0.0625

(2 x 3 +10)

2.Speicher

(25 x 5) – (84 ÷ 3)

[MRC] [MRC] [CE/C]

MEMORY

125.

+ (68 + 17) = 182

25 [x] 5 [M+]

84 [÷] 3 [M–]

MEMORY

28.

68 [+] 17 [M+]

MEMORY

85.

[MRC]

MEMORY

182.

(52 – 35) ÷ (14 – 3 x 2)

[MRC] [CE/C] 14 [M+] 3 [x] 2

= 2.125

[M–] 52 [–] 35 [÷]

[MRC] [=]

MEMORY

2.125

135 x (12 + 14) = 3510

[MRC] [MRC] [CE/C]

(12 + 14) ÷ 5 = 5.2

12 [+] 14 [M+]

135 [x] [MRC] [=]

MEMORY

3'510.

[MRC] [÷] 5 [=]

MEMORY

5.2

3.Konstant

2 + 3 = 5

2 [+] 3 [=]

5.

4 + 3 = 7

4 [=]

7.

3 x 4 = 12

3 [x] 4 [=]

12.

3 x 6 = 18

6 [=]

18.

4.Korrektur und überlauf-fehleer

1234567890 x 10000

1234567890

1'234'567'890

= 1'234.567890 x 1010

[x] 10000 [=]

ERROR

1'234.567890

(CDC-100)

[CE/C] [CE/C]

0.

5.Steuerberechnung

100+TAX(3%)

3 [RATE] [+TAX]

3.

%

= 103

100 [+TAX]

+TAX

103.

Steuersumme = 3

[+TAX]

TAX

3.

* 3 = Steuersumme

103 = Wert mit steuersumme

206–TAX(3%)

[CE/C] [RATE] [–TAX]

–TAX

3.

%

= 200

206 [–TAX]

200.

TAX

Steuersumme = 6

[–TAX]

6.

* 6 = Steuersumme

200 = Wert ohne steuersumme

6.Preismarkierungs auf & abrundungsrechngung

2000+(P x 20%)=P

2000 [÷] 20 [MU]

2'500.

P=

2000

=2'500

1- 20%

[MU]

500.

2500–2000 = 500

2000–(P x 20%)=P

2000 [÷] 20 [+/–] [MU]

1'666.6666

P=

2000

=1'666.66

1+ 20%

18000 - 15000

x100%

18000 [–] 15000 [MU]

20.

15000

= 20%

File name: D560-A_German_03.doc

version : 04/0910
