Contents
................
01....... Blood Pressure Monitor Intended Use
02....... 1. What is blood pressure ?
02....... 2. Why is it useful to measure blood
pressure at home ?
.......... A. WHO blood pressure classi¿cations
.......... B. Variations in blood pressure
04....... 3. Important information before use of the
unit
06....... 4. Device description
.......... A. Name of the parts
.......... B. Description of display symbols
08....... 5. Changing Batteries
08....... 6. Attaching pressure cuff
09....... 7. Correct measurement position
A
Contents
................
10....... 8. Symbol Di¿nitions.
12....... 9. How to measure.
.......... A. Inserting batteries in position.
.......... B. Setting date and time.
.......... C. Steps to take blood pressure
measurement.
.......... D. Storing recalling and erasing
measurement data.
.......... E. To change batteries.
15....... 10. Maintenance.
15....... 11. Safe-keeping.
15....... 12. To prevent malfunction.
16....... 13. Warning.
17....... 14. Speci¿cations.
B
MEDICAL DISCLAIMER
This manual and product are not meant to be a
substitute for advice provided by your doctor or other
medical professional.
You are not to use the information contained herein,
or this product for diagnosing or treating a health
problem or prescribing any medication. If you have or
suspect that you have a medical problem, promptly
consult your healthcare provider.
Blood Pressure Monitor Intended Use:
Measures human's Systolic blood pressure, Diastolic blood
pressure and heart rate on wrist by oscillometric measurement
method.
The product is recommended for use by people over the age of
18 and is for home use and not clinical use.
1
1. What is blood pressure ?
Blood pressure is a measurement of the force of blood Àowing
against the walls of the arteries. Arterial blood pressure is
constantly changing during the course of the cardiac cycle.
The highest pressure in the cycle is called the systolic blood
pressure, the lowest is the diastolic blood pressure. Both
pressure readings, the systolic and the diastolic are necessary
to enable a physician to evaluate the status of a patient's blood
pressure. Many factors such as physical activity, anxiety or the
time of day, can inÀuence your blood pressure. Blood pressure
is typically low in the morning and increases from the afternoon
to the evening. It is lower in the summer and higher in the
winter.
2. Why is it useful to measure blood pressure
at home ?
Having one's blood pressure measured by a doctor in a
hospital or a clinic, and a group health checks, tend to stimulate
nervousness in the subject and may even create high blood
pressure. Also varies blood pressure in accordance with a
variety of conditions and so judgment is not possible on the
basis of a single measurement.
The blood pressure measured ¿rst thing in the morning after
getting up, before taking any food and with the subject still, is
known as the fundamental blood pressure. In practice it is rather
dif¿cult to record the fundamental blood pressure, but to come
2
as near as possible to measuring the blood pressure in an
environment that is close to this, is why it is useful to take the
measurement at home.
A. WHO blood pressure classifications
Standards for assessment
of high or low blood
pressure without regard to
age, have been established
by the World Health
Organization (WHO), as
shown in the chart.
* Figure No.1
B. Variations in blood pressure
Individual blood pressures vary greatly both on a daily and a
seasonal basis. These variations are even more pronounced
in hyper tense patients. Normally the blood pressure rises
while at work and is at its lowest during sleeping period.
(Hyper tense: means a person who has high blood
pressure symptom.)
The graph below illustrated
the variations in blood
pressure over a whole day
with measurement taken
every ¿ve minutes.
* Figure No.2
3
The thick line represents sleep. The rise in blood pressure at 4
PM (A in the graph) and 12 PM (B in the graph) correspond to
an attack of pain.
3. Important information before use of the unit
Please rest for at least 5~10 minutes before taking the
measurement.
To allow your blood vessels to return to the condition prior to
taking the measurement, please wait at least 3~5 minutes
between measurements. You may need to adjust the wait
time according to your personal physiological situation.
If you have one of the circulatory problems as arteriosclerosis,
diabetes, liver disease, kidney disease, severe hypertension,
peripheral circulation......, please consult your doctor or
healthcare professional before using the devices.
Wait 30 ~ 45 minutes before measurement if you’ve just
consumed caffeinated beverages or smoked cigarettes.
Blood pressure measurements should be interpreted by a
physician or trained health professional who is familiar with
your medical history. By using the unit regularly and recording
the results for your physician to interpret, you keep your
physician informed of the continuing trends in your blood
pressure.
Wind the cuff snugly around your wrist and the cuff must be at
the same level as your heart.
Do not vibrate the unit during measurement, or the proper
measurement will not be achieved.
4
Perform measurement quietly in a relaxed position.
Do not wind the cuff over jacket or sweater sleeve, or
measurement cannot be done.
Keep in mind, that blood pressure naturally varies from
time to time throughout the day and also is affected by lots
of different factors such as smoking, alcohol consumption,
medication and physical activity.
People with a condition that causes circulatory problems
(diabetes, kidney disease, arteriosclerosis or poor peripheral
circulation) may get lower readings with this monitor that
with a blood pressure monitor that is used on the upper arm.
Please consult your physician to determine if your wrist blood
pressure accurately reÀects your actual blood pressure.
Blood pressure measurement determine with the unit are
equivalent to those obtained by a trained observer using
the cuff / stethoscope auscultation method. Within the limits
prescribed by the Standard of EN 1060-4.
This product is not suitable for pregnant women.
5
4. Device description:
A. Name of the parts
U
SE
R
FUNCTION
BUTTON
RECALL
M
MEMORY
BUTTON
START/STOP
BUTTON
( Stand-by)
M
CARRYING CASE
ALKALINE
BATTERY
UM-4 (AAA) 1.5 V x 2
START
STOP
LCD DISPLAY
1
2
A
V
G
:
P
M
SYS
m
m
H
g
DIA
m
m
H
g
Pulse
/min
SETTING BUTTON
WRIST CUFF
* Figure No.3
6
B. Description of display symbols
USER 1
USER 2
LAST 3 READING
AVERAGE
LOW BATTERY
SYMBOL
HOUR：MINUTE
(ALSO REPRESENTS AS YEAR
UNDER SETTING MODE)
MONTH/DATE
1
2
AVG
:
PM
HEART RATE SYMBOL
7
SYSTOLIC
RATE
DIASTOLIC
RATE
HEART RATE
5. Changing batteries
Remove the battery cover at the left side of the unit and insert
batteries into the battery compartment in accordance with
ribbon strip as shown, taking extreme care that the polarities +
and - are observed.
Important notice: to take the batteries out easily, just pull the
ribbon strip for help.
* Figure No.4
6. Attaching pressure cuff
A. Wrap the pressure cuff around the wrist.
a. The display of the unit should be
placed on the palm side of the wrist.
b. The wrist should be bare.
1 cm
(0.4 inch)
8
* Figure No.5
B. Fasten the pressure cuff snugly.
a. Do not pull strongly on the pressure
cuff.
13.5 ~ 19.5 cm
(5.3 ~ 7.7 inch)
b. Do not make the pressure cuff too
tight.
* Figure No.5-1
. Correct measurement position
7
It is extremely important for the measured values, that the cuff
is at the same height of the heart.
Higher or deeper position will give deviations from the true
value.
Measurement while sitting down:
a. Place your elbow on a table or other object
(such as our carry case).
b. Use the armrest to position the arm so
that the pressure cuff is at the same
height as the heart.
c. Relax your hand with the palm facing up.
9
* Figure No.6
8. Symbol Definitions
SYMBOLS
Low Battery
Symbol
Heart Rate
Symbol
Definitions
This symbol appears when the battery power
is excessively low or the polarity reverses.
We suggest you replace all batteries with
ᇄ
new ones, and make sure the +/- polarities
are properly positioned.
Once pulse is detected, the symbol Àashes
with each pulse beat.
Our suggestion:
ᇄ
Please do not talk or move during
measurements.
AVG
Last 3 Reading
Average
1
User 1
2
User 2
This symbol appears when LCD displays
average value of last 3 readings.
Appears when the monitor is operated by
User 1.
Appears when the monitor is operated by
User 2.
10
SYMBOLS/
SYMPTOMS
Measuring Error
Symbol shown
on display
or the blood
pressure value
is displayed
excessively low
or high.
Measuring
Error Symbol
Measuring
Error Symbol
Measuring
Error Symbol
Note: If "EP" appears on the display, just return the device to
your local distributor or importer.
CONDITIONS/
CAUSES
Cuff has been placed
incorrectly.
Did you talk or move
during measurement?
Shaking of the wrist
with the cuff on.
Air circuit abnormality.
InÀation pressure
exceeding 300
mmHg.
Error determining
measurement data.
11
INDICATION/
CORRECTION
Wrap the cuff properly
so that it is positioned
correctly.
Measure again. Keep
wrist steady during
measurement.
Measure again.
Switch the unit off,
then measure again.
Measure again.
9. How to measure
A. Inserting batteries in position:
a. Open battery cover.
b. Refer to the picture in positioning batteries. (Figure No.4)
c. All LCD segments appear on the display in 3 seconds.
B. Setting Date and Time:
a. Press " " button over 2 secs ("year" starts Àashing)
Press " "
b. Press " " button ("month" starts Àashing)
Press " " button to set the correct month (1,2,3,.....12)
c. Press " " button again ("date" starts Àashing)
Press " " button to set the correct date
d. Press " " button again ("hour" starts Àashing)
Press " " button to set the correct hour in 12-hour
format
e. Press " " button again ("minute" starts Àashing)
Press " " button to set the correct minute (0,1,2,3,.....59)
f. Press " " button again to switch to normal time
(month, date, hour and minute appear on the display)
C. Steps to take blood pressure measurement:
a. Wrap the cuff around the wrist (Refer to Wrapping of Wrist
cuff as Figure No. 5)
b. Sit upright on the chair to have correct posture. (Refer to
Correct Posture in Taking Blood Pressure as (Figure No. 6)
button to set the correct year (2011,2012,…2026)
12
c. Press" "button. Press " " button to select USER
(
display '888' in 3 seconds. Afterward, displays the updated
START
STO
P
2
1
) . Press " " button again. All elements
START
STO
P
time. The measuring blood pressure symbol will Àash on
the display and then the air pressure will automatically
pump up to 195 mmHg. If blood pressure tends to be on
the high level, the air pressure will automatically increase
to the required level for measurement. * Do not move or
talk in the midst of taking blood pressure measurement.
d. After the air pressure is increased, it will slowly decrease.
When the pulse rate is detected, HEART RATE symbol
will start Àashing.
*Note!
• If the cuff does not stop inÀating, remove the cuff at once.
• To interrupt the measurement, you may press the button.
The cuff will deÀate immediately after a button is pressed.
ART
ST
STO
P
e. After taking blood pressure measurement, the Systolic rate,
Diastolic rate and pulse rate will be on the display for 1 minute.
D. Storing, recalling and erasing measurement data:
a. Storing data: 60 measurement values for 2 users each (120
memory in total)
After each blood pressure measurement, the Systolic rate,
diastolic rate, heart rate and the time & date of speci¿c day
will be automatically stored. The memory holds the latest
60 measurement data. If more than 60 measurements, the
memory will automatically clear out the earliest data.
13
b. Recalling data:
(1). Press " M " button.If there is no data in the memory,
only TIME/DATE and USER symbol will appear on the
display. If yes, the ¿rst reading will be the average of
the latest 3 measurements. (The average value dose
not appear if there are two or fewer measurements
stored in memory.)
Press " M " button again, the latest measurement will
(2).
appear with the number as well as the recording date
and time. The data called up on the display is numbered
accordingly. After reading the recalled data as rotator 60-set
of the stored data, press " M " to switch to normal time.
(3). To discontinue in the midst of reading of the data,
press " " button.
(4).You can select USER memory ( ) by
T
AR
ST
STO
P
2
1
pressing " " button.
c. Erasing data:
(1). Press " M " button and press " " to select USER
( ).
2
1
(2). Press hold " " and " " button to clear memories.
" CLA " show up on the display for 3 seconds.
E. To change batteries:
When " " show up on the display, the battery is weak.
Change the batteries or it will not be possible to take blood
pressure measurement. All batteries used must be the same
type. Do not mix alkaline, standard(carbon-zinc) or rechargeable
(cadmium) batteries. Do not mix old and new batteries.
14
10.MAINTENANCE:
Use a piece of cloth with water or mild cleansing agent to
clean the case and then use a piece of dry cloth to wipe it dry.
Do not use gas or any strong cleansers in cleaning.
When the unit is not to be used for a long time, remove the
batteries. (Leaking of battery liquid can cause trouble)
11.SAFE-KEEPING:
Always keep the unit in the carrying case after its use.
Do not put the item directly under the sunlight, in high
temperature, or humid and dusty places.
Do not store in extremely low (less than - 20 °C) or high(more
than 70 °C) temperature.
12.TO PREVENT MALFUNCTION:
Do not in any way twist the wrist cuff.
Do not start the air pressure when the wrist cuff is not
wrapped around the wrist.
Do not attempt to disassemble or change any parts of the
monitor including wrist cuff.
Do not drop the product or put it through strong impact.
15
13.WARNING:
The device measures the blood pressure of adult only.
The device is not supposed to be used if your wrist has any
wound or injury.
In the event of the cuff pumping up and not stopping, please
open the cuff at once.
To ensure precise measurement reading, recalibration of
the device is recommended after 2 years from the date of
purchase. Shipping plus handling cost and recalibration
service fee shall be charged accordingly.
Limited Warranty
This device is warranted to be free from manufacturing
defects for a period of 1 year from the date of purchase.
Within the warranty period, should there be any
manufacturing defect found and repair is needed, please
contact your local distributor accordingly.
Please note warranty does not cover damage caused by,
including but not limited to: misuse or abuse; accident;
the attachment of any unauthorized accessory; alteration
to the product; improper installation; unauthorized repair
or modi¿cation; improper use of electrical/ power supply;
dropped product; failure to follow required maintenance and
safe-keeping; transportation damage.
16
14.SPECIFICATIONS:
Model Number
Method of Measurement
Range of Measurement
Accuracy
InÀation
DeÀation of Pressure
Exhaust
Display
Sets of Memory
Unit Dimension
Unit Weight
Cuff Size
Operating Temperature
Transportation/ Storage
Temperature
Auto power off
Power Supply
Battery Life
Accessories
These speci¿cations are subject to change without notice for
purpose of improvement.
:CH-618
:Oscillometric
:Pressure 0 ~ 300 mmHg
pulse 40 ~ 199 beats/minute
:Pressure +/- 3 mmHg,
Pulse +/- 5% of reading
:Automatic inÀation (Air Pump)
:Automatic air release control valve
:Automatic exhaust valve
:Liquid Crystal Digital Display
:60 sets for 2 users each
:L70XW72XH30mm (L2.8XW2.8XH1.2 inch)
:Approx.127g (Batteries excluded and Cuff included.)
:Wrist circumference approx.
13.5 - 19.5 cm (5.3-7.7 inch)
:Temperature: 10 ~ 40 °C (50 ~ 104 °F)
Humidity: 15% ~ 90% R.H.
:Temperature: -20 ~ 70 °C (-4 ~ 158 °F)
Humidity: 90% R.H.
:Whenever not used for 1 minute
:2 x 'AAA' (2x1.5 V) Alkaline battery (3V DC)
:Approx. 250 times measurement
:Carrying case, instruction manual 2 pcs "AAA" battery
17
Note:
This blood pressure monitor complies with
0197
Safety standard:
EN 60601-1 Medical electrical equipment part 1: General
requirements for safety
EMC standard:
EN 60601-1-2 Medical electrical equipment part 1-2: General
Performance standards:
EN 1060-1 Non-invasive sphygmomanometers - General
requirements
EN 1060-3 Non-invasive sphygmomanometers - Supplementary
requirements for electromechanical blood pressure
measuring systems.
EN 1060-4 Non-invasive sphygmomanometers - Test procedures
to determine the overall system accuracy of automated
non-invasive sphygmomanometers.
Important/Caution/Note!
Read the operating instructions.
Follow instructions for use.
the EC Directive and bears the CE mark
"CE0197". This blood pressure monitor
also complies with mainly following
standards,(included but not limited)
requirements for safety- Collateral standard:
Electromagnetic compatibility- Requirements and tests
18
Classification:
- BF type applied part
- Internally powered equipment
- IPX0
- Not suitable for use in presence of Àammable
anaesthetic mixture with air or with Oxygen or nitrous
oxide
- Continuous operation with short-time loading
To avoid inaccurate results caused by
electromagnetic interference between electrical and
electronic equipments, do not use the device near a
cell phone or microwave oven.
Discard the used product to the recycling collection
point according to local regulations.
Manufacturer:
HEALTH & LIFE Co., Ltd.
9F, No. 186, Jian Yi Road, Zhonghe District,
New Taipei City, Taiwan
Authorized Representative in the European Community:
EMERGO EUROPE
Molenstraat 15, 2513 BH, The Hague, The Netherlands
19
WEEE MARK
If you want to dispose this product, do not mix with general
household waste. There is a separate collection systems for
used electronics products in accordance with legislation under
the WEEE Directive (Directive 2002/96/EC) and is effective only
within European Union.
Information for Users on Collection and Disposal of used Batteries.
The symbol in this information sheet means that used batteries
should not be mixed with general household waste.
For proper treatment, recovery and recycling of used batteries,
please take them to applicable collection points.
For more information about collection and recycling of batteries,
please contact your local municipality, your waste disposal service
or the point of sale where you purchased the items.
20
Pb
Distributed by:
Distributed by:
P/N:323101936 VER:001
Loading...
