Chevrolet Equinox 2019 Owner's Manual

Download

chevrolet.com (U.S.) chevrolet.ca (Canada)

Equinox

Owner’s Manual

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . 2

In Brief . . . . . . . ... . . . . . . . . . . . ... . . . 5

Keys, Doors, and Windows . . . . . 29

Seats and Restraints . . . . . . . . . . . 56

Storage . . . . . . . . . . . . . . . . . . . . . . . 107

Instruments and Controls . . . . . . 111

Lighting . ... . . . . . . . . . . . . . . . . . . . 160

Infotainment System . . . . . . . . . . 168

Climate Controls . . . . . . . . . . . . . . 169

Driving and Operating . . . . . . . . . 177

Vehicle Care . . . . . . . . . . . . . . . . . . 274

Service and Maintenance . . . . . 367

Technical Data . . .. . . . . . . . . . . . . 382

Customer Information . . . . . . . . . 386

Reporting Safety Defects . . . . . . 396

OnStar . . . . . . . . . . .. . . . . . . . . . . . . 400

Connected Services . . . . . . . . . . . 408

Index . . . . . . . . . . . . . . . . . . . . 412

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

2 Introduction

Introduction

The names, logos, emblems, slogans, vehicle model names, and vehicle body designs appearing in this manual including, but not limited to, GM, the GM logo, CHEVROLET, the CHEVROLET Emblem, and EQUINOX are trademarks and/or service marks of General Motors LLC, its subsidiaries, affiliates, or licensors.

For vehicles first sold in Canada, substitute the name “General Motors of Canada Company” for Chevrolet Motor Division wherever it appears in this manual.

This manual describes features that may or may not be on the vehicle because of optional equipment that

Litho in U.S.A. Part No. 84134729 A First Printing

was not purchased on the vehicle, model variants, country specifications, features/applications that may not be available in your region, or changes subsequent to the printing of this owner’s manual.

Refer to the purchase documentation relating to your specific vehicle to confirm the features.

Keep this manual in the vehicle for quick reference.

Canadian Vehicle Owners

A French language manual can be obtained from your dealer, at www.helminc.com, or from:

Propriétaires Canadiens

On peut obtenir un exemplaire de ce guide en français auprès du concessionnaire ou à l'adresse suivante:

Helm, Incorporated Attention: Customer Service 47911 Halyard Drive Plymouth, MI 48170 USA

Using this Manual

To quickly locate information about the vehicle, use the Index in the back of the manual. It is an alphabetical list of what is in the manual and the page number where it can be found.

About Driving the Vehicle

As with other vehicles of this type, failure to operate this vehicle correctly may result in loss of control or a crash. Be sure to read the driving guidelines in this manual in the section called “Driving and Operating” and specifically Driver

Behavior 0 178, Driving Environment 0 179, and Vehicle Design 0 179.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Danger, Warning, and Caution

Warning messages found on vehicle labels and in this manual describe hazards and what to do to avoid or reduce them.

Danger

{

Danger indicates a hazard with a high level of risk which will result in serious injury or death.

Warning

{

Warning indicates a hazard that could result in injury or death.

A circle with a slash through it is a safety symbol which means “Do Not,” “Do not do this,” or “Do not let this happen.”

Symbols

The vehicle has components and labels that use symbols instead of text. Symbols are shown along with the text describing the operation or information relating to a specific component, control, message, gauge, or indicator.

M : Shown when the owner’s

manual has additional instructions

Caution

Caution indicates a hazard that could result in property or vehicle damage.

or information.

* : Shown when the service

manual has additional instructions or information.

0 : Shown when there is more

information on another page — “see page.”

Introduction 3

Vehicle Symbol Chart

Here are some additional symbols that may be found on the vehicle and what they mean. See the features in this manual for information.

u : Air Conditioning System G : Air Conditioning Refrigerant Oil 9 : Airbag Readiness Light

! : Antilock Brake System (ABS) $ : Brake System Warning Light

9 : Dispose of Used Components

Properly

B : Engine Coolant Temperature _ : Flame/Fire Prohibited H : Flammable [ : Forward Collision Alert + : Fuses j : ISOFIX/LATCH System Child

Restraints

| : Lane Change Alert @ : Lane Departure Warning A : Lane Keep Assist

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

4 Introduction

* : Malfunction Indicator Lamp : : Oil Pressure

X : Park Assist

~ : Pedestrian Ahead Indicator

O : Power

7 : Rear Cross Traffic Alert

I : Registered Technician

/ : Remote Vehicle Start

> : Seat Belt Reminders

I : Side Blind Zone Alert

h : Start/Stop

7 : Tire Pressure Monitor

d : StabiliTrak/Electronic Stability

Control (ESC)

a : Under Pressure V : Vehicle Ahead Indicator

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

In Brief

Instrument Panel

Instrument Panel . . . . . . . . . . . .. . . . 6

Initial Drive Information

Initial Drive Information . . . .. . . . . . 8

Stop/Start System . . . . .. . . . . . . . . . 8

Remote Keyless Entry (RKE)

System . . . . .. . . . . . . . . . . . . . . . . . . 8

Remote Vehicle Start . . . . . . . . . . . 9

Door Locks . . . . . . . . . . . . . . . . . . . . . 9

Liftgate . . . . . . . . . . . . . . . . . . . . . . . . 10

Windows . . . . . ... . . . . . . . . . . . ... . 10

Seat Adjustment . . . . . . . . . . . . . . . 11

Memory Features . . . . . . . . . . . . . . 12

Heated and Ventilated Seats . . . 13

Head Restraint Adjustment . . .. 13

Seat Belts . . . . . . . . . . . . . . . . . . . . . 14

Passenger Sensing System . . . 14

Mirror Adjustment . . . . . . . . . . . . . . 14

Steering Wheel Adjustment . . .. 15

Interior Lighting . . . . . . . . . . . . . . . . 15

Exterior Lighting . . . . . . . . . . . . . . . 16

Windshield Wiper/Washer . . . . . . 17

Climate Controls . . . . . . . . . . . . . . . 18

Transmission . . . . . . . . . . . . . . . . . . 19

Vehicle Features

Infotainment System . . . . . . . . . . . 20

Steering Wheel Controls . . .. . . . 20

Cruise Control . . . . . . . . . . . . . . . . . 20

Driver Information

Center (DIC) . . . . . . . . . . . . . . . . . 20

Forward Collision Alert (FCA)

System . . . . . .. . . . . . . . .. . . . . . . . 21

Forward Automatic

Braking (FAB) . . . . . . . . . . . . . . . . 21

Front Pedestrian Braking (FPB)

System . . . . . .. . . . . . . . .. . . . . . . . 21

Lane Keep Assist (LKA) . ... . . . 21

Lane Change Alert (LCA) . ... . . 22

Surround Vision . . . . . . . . . . . . . . . 22

Rear Vision Camera (RVC) . . . . 22

Rear Cross Traffic Alert (RCTA)

System . . . . . .. . . . . . . . .. . . . . . . . 22

Park Assist . . . . . . . . . . . . .. . . . . . . 22

Power Outlets . . . . . . . . . . . . . . . . . 23

Universal Remote System . . . . . 23

Sunroof . . . . . . . . . . . . . .. . . . . . . .. . 23

Performance and Maintenance

Traction Control/Electronic

Stability Control . . . . . . . . . . . . . . 25

Tire Pressure Monitor . . . . . . . . . . 25

Fuel (LYX - 1.5L L4 Turbo

Engine) . . . . . .... . . . . . . . . . . . ... 25

In Brief 5

Fuel (LTG - 2.0L L4 Turbo

Engine) . . . . . .... . . . . . . . . . . . ... 26

Fuel (Diesel) . . . . . . . . . . . .. . . . . . . 26

E85 or FlexFuel . . ... . . . . . . . . . . . 26

Engine Oil Life System . ... . . . . 26

Driving for Better Fuel

Economy .. . . . . . .. . . . . .. . . . . . . 27

Diesel Particulate Filter . . . . . . . . 27

Diesel Exhaust Fluid . . . . . . . . .. . 28

Roadside Assistance

Program . . . . . ... . . . . . . . . .. . . . . 28

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

6 In Brief

Instrument Panel

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

1. Air Vents 0 174.

2. Turn Signal Lever. See Turn

and Lane-Change Signals

0 164.

IntelliBeam

System Button (If Equipped). See Exterior Lamp Controls 0 160.

3. Instrument Cluster (Base and

Midlevel) 0 120 or Instrument Cluster (Uplevel) 0 124.

Driver Information Center (DIC) Display. See Driver Information Center

(DIC) (Base Level and Midlevel) 0 141 or Driver Information Center (DIC) (Uplevel) 0 146.

4. Windshield Wiper/Washer

0 112.

5. Infotainment 0 168.

6. Light Sensor. See Automatic Headlamp System 0 163.

7. Hazard Warning Flashers 0 163.

8. Climate Control Systems 0 169 (If Equipped).

Dual Automatic Climate Control System 0 171 (If Equipped).

9. Heated and Ventilated Front Seats 0 64 (If Equipped).

10. Power Outlets 0 115.

11. Wireless Charging 0 116 (If Equipped).

12. USB Port. See the infotainment manual.

Auxiliary Input Jack. See the infotainment manual.

13. All-Wheel Drive 0 214 (If Equipped).

Tow/Haul Mode 0 213.

14. Electric Parking Brake 0 215.

15. Shift Lever. See Automatic

Transmission 0 210.

Manual Mode 0 212.

16. ENGINE START/STOP Button. See Ignition Positions 0 194.

17. Steering Wheel Controls 0 112.

Traction Control/Electronic Stability Control 0 218.

18. Horn 0 112.

In Brief 7

19. Steering Wheel Adjustment 0 112 (Out of View).

20. Cruise Control 0 222.

Heated Steering Wheel 0 112

(If Equipped).

Forward Collision Alert (FCA) System 0 240 (If Equipped).

Lane Keep Assist (LKA) 0 248

(If Equipped).

21. Hood Release. See Hood 0 277.

22. Fog Lamps 0 164 (If Equipped).

23. Exterior Lamp Controls 0 160.

24. Data Link Connector (DLC) (Out of View). See Malfunction

Indicator Lamp (Check Engine Light) 0 132.

25. Instrument Panel Illumination Control 0 165.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

8 In Brief

Initial Drive Information

This section provides a brief overview about some of the important features that may or may not be on your specific vehicle.

For more detailed information, refer to each of the features which can be found later in this owner’s manual.

Stop/Start System

If equipped, the Stop/Start system will shut off the engine to help conserve fuel. It has components designed for the increased number of starts.

When the brakes are applied and the vehicle is at a complete stop, the engine may turn off. When stopped, the tachometer displays AUTO STOP. See Tachometer 0 128. When the brake pedal is released or the accelerator pedal is pressed, the engine will restart. See Stop/Start System 0 198 in Driving and Operating.

Remote Keyless Entry (RKE) System

The Remote Keyless Entry (RKE) transmitter may work up to 60 m (197 ft) away from the vehicle.

With Power Liftgate Shown

Press the button on the side of the RKE transmitter to remove the key. Never pull the key out without pressing the button. The key can be used for all locks.

K : Press to unlock the driver door

or all doors depending on vehicle personalization settings.

For vehicles with the manual liftgate, unlocking all doors will also unlock the liftgate.

Q : Press to lock all doors.

Lock and unlock feedback can be personalized. See Vehicle Personalization 0 151.

b : If equipped with the power

liftgate, press twice quickly to open or close the liftgate.

7 : Press and release to initiate

vehicle locator. Press and hold for at least three seconds to sound the

panic alarm. Press cancel the panic alarm.

7 again to

/ : Press Q and release and then

immediately press and hold least four seconds to start the engine from outside the vehicle. See Remote Vehicle Start 0 36.

See Keys 0 29 and Remote Keyless Entry (RKE) System Operation 0 30.

/ for at

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Remote Vehicle Start

If equipped, the engine can be started from outside of the vehicle.

Starting the Vehicle

1. Press and release Q on the

RKE transmitter.

2. Immediately press and hold for at least four seconds or until the turn signal lamps flash.

Start the vehicle normally after entering.

When the vehicle starts, the parking lamps will turn on.

Remote start can be extended.

Door Locks

To lock or unlock the vehicle from the outside, press

Remote Keyless Entry (RKE) transmitter.

Canceling a Remote Start

To cancel a remote start, do one of the following:

Press and hold parking lamps turn off.

Turn on the hazard warning flashers.

Turn the vehicle on and then off.

See Remote Vehicle Start 0 36.

/ until the

Q : Press to lock the doors. The

indicator light in the switch will come on when the door is locked.

K : Press to unlock the doors.

See Door Locks 0 38.

Q or K on the

In Brief 9

To manually unlock a door from inside the vehicle, pull once on the door handle to unlock it, and a second time to open it.

Keyless Access

Press the button on the driver door handle when the RKE transmitter is within 1 m (3 ft) of the driver door handle. When unlocking from the driver door, the first press unlocks that door; press again within five seconds to unlock all passenger doors. See Remote Keyless Entry (RKE) System Operation 0 30.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

10 In Brief

Liftgate

Manual Liftgate Operation

Unlock the vehicle before opening the liftgate.

To open the liftgate, press the touch pad under the liftgate handle and lift up.

Do not press the touch pad while closing the liftgate. This may cause the liftgate to be unlatched.

Power Liftgate Operation

To operate the power liftgate, the vehicle must be in P (Park). The taillamps flash when the power liftgate moves.

Choose the power liftgate mode by turning the dial on the switch to either the 3/4 or MAX position.

Press

8 to open or close the

liftgate.

Hands-Free Liftgate

The liftgate will not operate if the RKE transmitter is not within 1 m (3 ft).

To operate, kick your foot straight up in one swift motion under the rear bumper between the left exhaust pipe and the license plate, then pull it back.

See Liftgate 0 42.

Windows

Power windows work when the ignition is on, in ACC/ACCESSORY, or in Retained Accessory Power (RAP). See Retained Accessory Power (RAP) 0 200.

Using the window switch, press to open or pull to close the window.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

The windows may be temporarily disabled if they are used repeatedly within a short time.

See Power Windows 0 52.

Seat Adjustment

Manual Front Seats

To adjust a manual seat:

1. Pull the handle at the front of the seat.

2. Slide the seat to the desired position and release the handle.

3. Try to move the seat back and forth to be sure it is locked in place.

Seat Height Adjuster

Move the lever up or down to manually raise or lower the seat.

See Seat Adjustment 0 59.

In Brief 11

Reclining Seatbacks

To recline the manual seatback:

1. Lift the lever.

2. Move the seatback to the desired position, then release the lever to lock the seatback in place.

3. Push and pull on the seatback to make sure it is locked.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

12 In Brief

To return the seatback to an upright position:

1. Lift the lever fully without applying pressure to the seatback, and the seatback returns to the upright position.

2. Push and pull on the seatback to make sure it is locked.

See Reclining Seatbacks 0 60.

Power Driver Seat

To adjust a power driver seat, if equipped:

Move the seat forward or rearward by sliding the control forward or rearward.

Raise or lower the front part of the seat cushion by moving the front of the control up or down.

Raise or lower the entire seat by moving the rear of the control up or down.

See Power Seat Adjustment 0 59.

To recline a power seatback, if equipped:

Tilt the top of the control rearward to recline.

Tilt the top of the control forward to raise.

See Reclining Seatbacks 0 60.

Memory Features

If equipped, memory seats allow two drivers to save and recall their unique seat positions for driving the vehicle, and a shared exit position for getting out of the vehicle. Other feature positions may also be saved, such as power mirrors and power steering wheel, if equipped. Memory positions are linked to RKE transmitter 1 or 2 for automatic memory recalls.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Before saving, adjust all available memory feature positions. Turn the ignition on and then press and release SET; a beep will sound. Then immediately press and hold 1,

2, or

B (Exit) until two beeps

sound. To manually recall these positions, press and hold 1, 2, or

until the saved position is reached.

When Seat Entry Memory is enabled in vehicle personalization, positions previously saved to memory buttons 1 and 2 are recalled when the ignition is changed from off to on or ACC/ ACCESSORY.

When Seat Exit Memory is enabled in vehicle personalization, the feature automatically recalls the previously saved exit position when exiting the vehicle.

Memory adjustments may not be available upon delivery or after service until steps in “Saving Memory Positions” section are performed. See Memory Seats 0 61.

Heated and Ventilated Seats

If available, the buttons are on the climate control panel. To operate, the engine must be running.

To heat the driver or passenger seat, press

on the button show the current setting.

To ventilate the driver or passenger seat, press

on the button show the current setting.

L or M. Indicator lights

{ or C. Indicator lights

In Brief 13

Press the heated or ventilated button once for the highest setting. With each press of the button, the heated or ventilated seat will change to the next lower setting, and then to the off setting. The lights indicate three for the highest setting and one for the lowest.

See Heated and Ventilated Front Seats 0 64.

Head Restraint Adjustment

Do not drive until the head restraints for all occupants are installed and adjusted properly.

To achieve a comfortable seating position, change the seatback recline angle as little as necessary while keeping the seat and the head restraint height in the proper position.

See Head Restraints 0 57 and Seat Adjustment 0 59.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

14 In Brief

Seat Belts

Refer to the following sections for important information on how to use seat belts properly:

Seat Belts 0 69

How to Wear Seat Belts Properly 0 70

Lap-Shoulder Belt 0 72

Lower Anchors and Tethers for Children (LATCH System) 0 96

Passenger Sensing System

The passenger sensing system turns off the front outboard passenger frontal airbag under certain conditions. No other airbag is affected by the passenger sensing system. See Passenger Sensing System 0 83.

The passenger airbag status indicator will light on the overhead console when the vehicle is started. See Passenger Airbag Status Indicator 0 131.

Mirror Adjustment

Exterior

To adjust the mirrors:

1. Press

2. Press the arrows on the control

See Power Mirrors 0 50.

j or | to choose the

driver or passenger mirror.

pad to move each mirror in the desired direction.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Interior

Adjustment

Adjust the rearview mirror to clearly view the area behind the vehicle.

Manual Rearview Mirror

If equipped, push the tab forward for daytime use and pull it rearward for nighttime use to avoid glare of the headlamps from behind. See Manual Rearview Mirror 0 51.

Automatic Dimming Rearview Mirror

If equipped, the mirror will automatically reduce the glare of the headlamps from behind. The dimming feature comes on when the vehicle is started. See Automatic Dimming Rearview Mirror 0 51.

Steering Wheel Adjustment

To adjust the steering wheel:

1. Pull the lever down.

2. Move the steering wheel up or down.

3. Pull or push the steering wheel closer or away from you.

4. Pull the lever up to lock the steering wheel in place.

Do not adjust the steering wheel while driving.

In Brief 15

Interior Lighting

Dome Lamps

The dome lamp controls are in the overhead console.

To operate, press the following buttons:

j OFF : Press to turn off the

dome lamps when a door is open. An indicator light on the button will turn on when the dome lamp

override is activated. Press OFF again to deactivate this feature

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

16 In Brief

and the indicator light will turn off. The dome lamps will come on when doors are opened.

+ ON/OFF : Press to turn the dome lamps on manually.

Reading Lamps

There are reading lamps on the overhead console and over the rear passenger doors. These lamps come on when any door is opened.

Rear Reading Lamps

Press the lamp lens to turn the rear passenger reading lamps on or off.

For more information on interior lighting, see Instrument Panel Illumination Control 0 165.

Exterior Lighting

Front Reading Lamps

The front reading lamps are in the overhead console.

Press the lamp lenses to turn the front reading lamps on or off.

The exterior lamp control is on the instrument panel to the left of the steering column.

There are four positions.

O : Turns the exterior lamps off and

deactivates the AUTO mode. Turn to

O again to reactivate the

AUTO mode.

In Canada, the headlamps will automatically reactivate when the vehicle is shifted out of P (Park).

AUTO : Turns the exterior lamps on and off automatically depending on outside lighting.

; : Turns on the parking lamps

including all lamps, except the headlamps.

5 : Turns on the headlamps

together with the parking lamps and instrument panel lights.

See:

Exterior Lamp Controls 0 160

Daytime Running Lamps (DRL) 0 162

Fog Lamps 0 164

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Windshield Wiper/Washer

LO : Use for slow wipes.

In Brief 17

Rear Window Wiper/Washer

The windshield wiper/washer lever is on the side of the steering column. With the ignition on or in ACC/ACCESSORY, move the windshield wiper lever to select the wiper speed.

HI : Use for fast wipes.

INT : Move the lever up to INT for

intermittent wipes, then turn the band up for more frequent wipes or down for less frequent wipes.

OFF : Use to turn the wipers off.

1X : For a single wipe, briefly move

the wiper lever down. For several wipes, hold the wiper lever down.

f : Pull the windshield wiper

lever toward you to spray windshield washer fluid and activate the wipers.

Turn the end of the windshield wiper lever to operate the rear window wiper/washer.

OFF : Turns the system off.

INT : Intermittent wipes.

ON : Slow wipes.

1 : Push the windshield wiper

lever forward to spray washer fluid on the rear window. The lever automatically returns to its original position when released.

See Windshield Wiper/Washer

0 112 and Rear Window Wiper/ Washer 0 113.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

18 In Brief

Climate Controls

The vehicle's heating, cooling, defrosting, and ventilation can be controlled with these systems.

Climate Control System

1. Fan Control

2. MAX Defrost

3. Defrost/Defog

4. A/C (Air Conditioning)

5. Temperature Control

6. Driver and Passenger Heated Seats (If Equipped)

7. Recirculation

8. Air Delivery Mode Controls

9. Rear Window Defogger

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

In Brief 19

Dual Automatic Climate Control System

1. Driver and Passenger Temperature Controls

2. MAX Defrost

3. Air Delivery Mode Controls

4. A/C (Air Conditioning)

5. Heated and Ventilated Front Seats (If Equipped)

6. SYNC (Synchronized Temperature)

7. AUTO (Automatic Operation)

8. Fan Control

9. Power

10. Recirculation

11. Rear Window Defogger

See Climate Control Systems 0 169 (If Equipped) or Dual Automatic Climate Control System 0 171 (If Equipped).

Transmission

Electronic Range Select (ERS) Mode

ERS or manual mode allows for the selection of the range of gear positions. Use this mode when driving downhill to limit the top gear and vehicle speed. See Manual Mode 0 212.

To use this feature:

1. Move the shift lever to L (Manual Mode).

2. Press the plus/minus button on the shift lever, to increase or decrease the gear range available.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

20 In Brief

Vehicle Features

Cruise Control

Infotainment System

See the infotainment manual for information on the radio, audio players, phone, navigation system, and voice or speech recognition. It also includes information on settings.

Steering Wheel Controls

The infotainment system can be operated by using the steering wheel controls. See “Steering Wheel Controls” in the infotainment manual.

1 : Press to turn the cruise control

system on and off. A white indicator comes on in the instrument cluster when cruise is turned on.

* : Press to disengage cruise

control without erasing the set speed from memory.

+RES : If there is a set speed in memory, press to resume that speed or press and hold to accelerate. If cruise control is already active, use to increase vehicle speed.

−SET : Press briefly to set the speed and activate cruise control. If cruise control is already active, use to decrease vehicle speed.

See Cruise Control 0 222 or Adaptive Cruise Control 0 224 (if equipped).

Driver Information Center (DIC)

The DIC display is in the instrument cluster. It shows the status of many vehicle systems.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

w or x : Press to move up or

down in a list.

o or p : Press to move between

the interactive display zones in the cluster.

V : Press to open a menu or select

a menu item. Press and hold to reset values on certain screens.

See Driver Information Center (DIC)

(Base Level and Midlevel) 0 141 or Driver Information Center (DIC) (Uplevel) 0 146.

Forward Collision Alert (FCA) System

If equipped, FCA may help avoid or reduce the harm caused by front-end crashes. FCA provides a

green indicator, is detected ahead. This indicator displays amber if you follow a vehicle too closely. When approaching a vehicle ahead too quickly, FCA provides a flashing red alert on the windshield and rapidly beeps or pulses the driver seat.

V, when a vehicle

See Forward Collision Alert (FCA) System 0 240.

Forward Automatic Braking (FAB)

If the vehicle has Forward Collision Alert (FCA), it also has FAB, which includes Intelligent Brake Assist (IBA). When the system detects a vehicle ahead in your path that is traveling in the same direction that you may be about to crash into, it can provide a boost to braking or automatically brake the vehicle. This can help avoid or lessen the severity of crashes when driving in a forward gear.

See Forward Automatic Braking (FAB) 0 242.

Front Pedestrian Braking (FPB) System

If equipped, the FPB system may help avoid or reduce the harm caused by front-end crashes with nearby pedestrians when driving in a forward gear. FPB displays an

In Brief 21

amber indicator, pedestrian is detected directly ahead. When approaching a detected pedestrian too quickly, FPB provides a red flashing alert on the windshield and rapidly beeps. FPB can provide a boost to braking or automatically brake the vehicle.

See Front Pedestrian Braking (FPB) System 0 243.

~, when a nearby

Lane Keep Assist (LKA)

If equipped, LKA may help avoid crashes due to unintentional lane departures. It may assist by gently turning the steering wheel if the vehicle approaches a detected lane marking without using a turn signal in that direction. It may also provide a Lane Departure Warning (LDW) alert as the lane marking is crossed. The system will not assist or alert if it detects that you are actively steering. Override LKA by turning the steering wheel. LKA uses a camera to detect lane markings between 60 km/h (37 mph) and 180 km/h (112 mph).

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

22 In Brief

See Lane Departure Warning (LDW)

0 248 and Lane Keep Assist (LKA) 0 248.

Lane Change Alert (LCA)

If equipped, the LCA system is a lane-changing aid that assists drivers with avoiding lane change crashes that occur with moving vehicles in the side blind zone (or spot) areas or with vehicles rapidly approaching these areas from behind. The LCA warning display will light up in the corresponding outside mirror and will flash if the turn signal is on. The Side Blind Zone Alert (SBZA) system is included as part of the LCA system.

See Side Blind Zone Alert (SBZA)

0 246 and Lane Change Alert (LCA) 0 246.

Surround Vision

If equipped, views around the vehicle appear in the infotainment display to aid with parking and low-speed maneuvers.

See “Surround Vision” under

Assistance Systems for Parking or Backing 0 235.

Front Vision Camera

If equipped, a view of the area in front of the vehicle appears on the infotainment display to aid with parking and low-speed maneuvers.

See “Front Vision Camera” under

Assistance Systems for Parking or Backing 0 235.

Rear Vision Camera (RVC)

The RVC displays a view of the area behind the vehicle on the infotainment display when the vehicle is shifted into R (Reverse) to aid with parking and low-speed backing maneuvers.

See Assistance Systems for Parking or Backing 0 235.

Rear Cross Traffic Alert (RCTA) System

If equipped, the RCTA system shows a triangle with an arrow on the infotainment display to warn of traffic behind your vehicle that may cross your vehicle's path while in R (Reverse). In addition, beeps will sound, or the driver seat will pulse.

See Assistance Systems for Parking or Backing 0 235.

Park Assist

If equipped, Rear Park Assist (RPA) uses sensors on the rear bumper to assist with parking and avoiding objects while in R (Reverse). It operates at speeds less than 8 km/h (5 mph). RPA may display a warning triangle on the infotainment display and a graphic on the instrument cluster to provide the object distance. In addition, multiple beeps or seat pulses may occur if very close to an object.

See Assistance Systems for Parking or Backing 0 235.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

In Brief 23

Power Outlets

The vehicle has two 12-volt accessory power outlets, which can be used to plug in electrical equipment, such as a cell phone or MP3 player.

There are power outlets:

On the center stack below the climate control system.

In the rear cargo area.

To use the outlet, remove the cover.

See Power Outlets 0 115.

Universal Remote System

If equipped, the Universal Remote System allows for garage door openers, security systems, and home automation devices to be programmed to work with these buttons in the vehicle.

See Universal Remote System 0 156.

Sunroof

1. Sunroof Switch

2. Sunshade Switch

If equipped, the sunroof only operates when the ignition is on or in ACC/ACCESSORY, or when Retained Accessory Power (RAP) is active. See Ignition Positions 0 194 and

Retained Accessory Power (RAP) 0 200.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

24 In Brief

Sunroof Switch

Express-Open/Express-Close : To

express-open the sunroof, press and release release

movement. To express-close the sunroof, press and release Press and release

time to stop movement.

Open/Close (Manual Mode) : To open the sunroof, press and hold

e (1). Press and

e (1) at any time to stop

g (1).

g (1) at any

e (1) until the sunroof reaches

the desired position. To close the sunroof, press and hold

Comfort Stop : The sunroof has a comfort stop feature that stops the sunroof from opening fully. Press

and release the rear of move the sunroof to the partially opened comfort stop position.

Pressing the rear of open the sunroof fully. If the sunshade is not fully open when the comfort stop feature is pressed the second time, the sunshade will open fully.

g (1).

g to

g again will

Vent : From the closed position, press and release the sunroof. Press and release

(1) to close the vent.

Sunshade Switch

Express-open/Express-close : To

express-open the sunshade, press and release release

movement. To express-close the sunshade, press and release

(2). Press and release Q (2) at

any time to stop movement.

Open/Close (Manual Mode) : To open the sunshade, press and hold

r (2) at any time to stop

e (1) to vent

r (2). Press and

r (2) until the sunshade reaches

the desired position. To close the sunshade, press and hold

Q (2).

When the sunroof is opened, an air deflector will automatically raise. The air deflector will retract when the sunroof is closed.

The sunroof cannot be opened or closed if the vehicle has an electrical failure.

The sunroof is equipped with an automatic reversal system. See Sunroof 0 54.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Performance and Maintenance

Traction Control/ Electronic Stability Control

The Traction Control System (TCS) limits wheel slip. The system is on when the vehicle is started.

The StabiliTrak/Electronic Stability Control (ESC) system assists with directional control of the vehicle in difficult driving conditions. The system is on when the vehicle is started.

TCS and StabiliTrak/ESC can be turned off or on using the Driver Information Center (DIC) controls. See Traction Control/Electronic Stability Control 0 218.

Tire Pressure Monitor

This vehicle may have a Tire Pressure Monitor System (TPMS).

The low tire pressure warning light alerts to a significant loss in pressure of one of the vehicle's tires. If the warning light comes on, stop as soon as possible and inflate the tires to the recommended pressure shown on the Tire and Loading Information label. See Vehicle Load Limits 0 190. The warning light will remain on until the tire pressure is corrected.

The low tire pressure warning light may come on in cool weather when the vehicle is first started, and then turn off as the vehicle is driven. This may be an early indicator that the tire pressures are getting low and the tires need to be inflated to the proper pressure.

The TPMS does not replace normal monthly tire maintenance. Maintain the correct tire pressures.

In Brief 25

See Tire Pressure Monitor System 0 323.

Tire Fill Alert (If Equipped)

This feature provides visual and audible alerts outside the vehicle to help when inflating an underinflated tire to the recommended cold tire pressure. See “Tire Fill Alert (If Equipped)” under Tire Pressure Monitor Operation 0 324.

Fuel (LYX - 1.5L L4 Turbo Engine)

Regular Unleaded Fuel

Use only Regular 87 octane — (R +M)/2 — or higher unleaded gasoline in your vehicle. TOP TIER Detergent Gasoline is recommended. Do not use gasoline with an octane rating lower as it will result in reduced performance and

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

26 In Brief

lower fuel economy. See Recommended Fuel (LYX -

1.5L L4 Turbo Engine) 0 251 or Recommended Fuel (LTG - 2.0L L4 Turbo Engine) 0 251.

Fuel (LTG - 2.0L L4 Turbo Engine)

Premium Recommended

Use premium 93 octane — (R+M)/2 — unleaded gasoline in your

vehicle. TOP TIER Detergent Gasoline is recommended. Unleaded gasoline with an octane rating as low as 87 may be used, but it will reduce performance and fuel economy. See Recommended Fuel (LYX -

1.5L L4 Turbo Engine) 0 251 or Recommended Fuel (LTG - 2.0L L4 Turbo Engine) 0 251.

Fuel (Diesel)

Use of diesel fuel with ultra low sulfur content (15 ppm, maximum) is required. See Fuel for Diesel Engines 0 252.

E85 or FlexFuel

No E85 or FlexFuel

Gasoline-ethanol fuel blends greater than E15 (15% ethanol by volume), such as E85, cannot be used in this vehicle.

Engine Oil Life System

The engine oil life system calculates engine oil life based on vehicle use and displays the CHANGE ENGINE OIL SOON message when it is time to change the engine oil and filter.

The oil life system should be reset to 100% only following an oil change.

Resetting the Oil Life System

1. Display REMAINING OIL LIFE on the DIC menu. See Driver Information Center

(DIC) (Base Level and Midlevel) 0 141 or Driver Information Center (DIC) (Uplevel) 0 146.

2. Press and hold seconds while the Oil Life display is active to reset the Oil Life system.

3. REMAINING OIL LIFE 100% will be displayed when the oil life system is successfully reset.

The oil life system can also be reset as follows:

1. Place the ignition in Service Mode. See Ignition Positions 0 194.

V for several

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

2. Display REMAINING OIL LIFE on the DIC menu. See Driver Information Center

(DIC) (Base Level and Midlevel) 0 141 or Driver Information Center (DIC) (Uplevel) 0 146.

3. Fully press and release the accelerator pedal three times within five seconds.

4. If the display changes to 100%, the system is reset.

See Engine Oil Life System 0 288.

Driving for Better Fuel Economy

Driving habits can affect fuel mileage. Here are some driving tips to get the best fuel economy possible:

Set the climate controls to the desired temperature after the engine is started, or turn them off when not required.

Avoid fast starts and accelerate smoothly.

Brake gradually and avoid abrupt stops.

Avoid idling the engine for long periods of time.

When road and weather conditions are appropriate, use cruise control.

Always follow posted speed limits or drive more slowly when conditions require.

Keep vehicle tires properly inflated.

Combine several trips into a single trip.

Replace the vehicle's tires with the same TPC Spec number molded into the tire's sidewall near the size.

Follow recommended scheduled maintenance.

In Brief 27

Diesel Particulate Filter

The engine is equipped with a Diesel Particulate Filter (DPF) that will filter or trap particulates. The DPF is under the vehicle in the exhaust system.

Depending on a number of factors monitored by the engine computer, the DPF will need to be cleaned of accumulated solids. When a cleaning is needed, the engine computer will initiate a cleaning action by warming the exhaust gas temperature. This feature has been designed to operate automatically, with limited operator involvement or awareness.

Cleaning the DPF (Exhaust Filter)

While the DPF cleaning is automatically controlled by the engine computer, the vehicle will need to operate continuously for approximately 25 minutes and at speeds greater than 50 km/h (30 mph) to clean the DPF effectively.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

28 In Brief

Special DPF Driver Messages

If the vehicle is used for numerous short trips or extended slow-speed operation, the engine computer may not be able to clean the DPF effectively. If this happens, a Driver Information Center (DIC) message will display.

If the vehicle continues to be driven in a manner that prevents effective DPF cleaning, the DPF will become plugged. If this occurs, the engine computer will turn on the malfunction indicator lamp in the instrument cluster and a DIC message will display. See Diesel

Particulate Filter 0 204, Fuel for Diesel Engines 0 252 and Engine Oil 0 284.

Diesel Exhaust Fluid

Diesel Exhaust Fluid (DEF) is used with diesel engines to reduce the amount of regulated emissions produced. The DEF system must be maintained for the vehicle to run properly. It is normal to hear the DEF system purge fluid back into the tank after the vehicle is shut off.

For the correct DEF see

Recommended Fluids and Lubricants 0 378.

As the DEF tank becomes low on fluid, warnings begin with approximately 1 600 km (1,000 mi) of remaining range. These warnings will increase in intensity as the tank becomes empty. Once the tank is empty, the vehicle speed will be limited. If there is an issue with the quality of the fluid or the exhaust fluid system, warnings will be displayed in the Driver Information Center (DIC). See Diesel Exhaust Fluid 0 205.

Roadside Assistance Program

U.S.: 1-800-243-8872

TTY Users (U.S. Only): 1-888-889-2438

Canada: 1-800-268-6800

New Chevrolet owners are automatically enrolled in the Roadside Assistance Program.

See Roadside Assistance Program 0 390.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Keys, Doors, and Windows

Keys and Locks

Keys . . . . . .. . . . . . . . . .. . . . . . . . . .. 29

Remote Keyless Entry (RKE)

System . . . . . .. . . . . . . . .. . . . . . . . 30

Remote Keyless Entry (RKE)

System Operation . . . . . . . . . . . . 30

Remote Vehicle Start . . . . . . . . . . 36

Door Locks . . . . . . . . . . . . . .. . . . . . 38

Power Door Locks . . .. . . . . . . . . . 40

Delayed Locking . . . . . . . . . . .. . . . 40

Automatic Door Locks . . . . . . . . . 41

Lockout Protection . . . . . . . . . . . . . 41

Safety Locks . . . . .. . . . . . . . . ... . . 42

Folding Mirrors . . . . ... . . . . . . . . . . 50

Heated Mirrors . . . . .. . . . . . . . .. . . 50

Automatic Dimming Mirror . . . . . 51

Reverse Tilt Mirrors . . . . . . . . . .. . 51

Interior Mirrors

Interior Rearview Mirrors . . . . . . . 51

Manual Rearview Mirror . . . . . . .. 51

Automatic Dimming Rearview

Mirror . . . . . . . . . . ... . . . . . . . . . ... 51

Windows

Windows . . . . . ... . . . . . . . . . . . ... . 51

Power Windows . . . . . . . . . . . . . . . 52

Sun Visors . . . . . .. . . . . . . . .. . . . . . 54

Roof

Sunroof . . . . . . . . . . . . . .. . . . . . . .. . 54

Doors

Liftgate . . . . . . . . . . . . . . . . . . . . . . . . 42

Vehicle Security

Vehicle Security . . . .. . . . . . . . . . . . 47

Vehicle Alarm System . . . . . . . . . 47

Immobilizer . . . . . . . . . . . . . . . . . . . . 48

Immobilizer Operation . . . . . . . . . 49

Exterior Mirrors

Convex Mirrors . . . . . . . . . . . . . . . . 50

Power Mirrors . . . . ... . . . . . . . . . .. 50

Keys, Doors, and Windows 29

Keys and Locks

Keys

Warning

{

Leaving children in a vehicle with a Remote Keyless Entry (RKE) transmitter is dangerous and children or others could be seriously injured or killed. They could operate the power windows or other controls or make the vehicle move. The windows will function with the RKE transmitter in the vehicle, and children or others could be caught in the path of a closing window. Do not leave children in a vehicle with an RKE transmitter.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

30 Keys, Doors, and Windows

Remove the key by pressing the button on the side of the RKE transmitter near the bottom and pull the key out. Never pull the key out without pressing the button.

See your dealer if a new transmitter is needed.

If locked out of the vehicle, see

Roadside Assistance Program

0 390.

With an active OnStar or connected

The key that is part of the Remote Keyless Entry (RKE) transmitter can be used for all locks.

service plan, an OnStar Advisor may remotely unlock the vehicle. See OnStar Overview 0 400.

Remote Keyless Entry (RKE) System

See Radio Frequency Statement 0 396.

If there is a decrease in the Remote Keyless Entry (RKE) operating range:

Check the distance. The transmitter may be too far from the vehicle.

Check the location. Other vehicles or objects may be blocking the signal.

Check the transmitter's battery. See “Battery Replacement” later in this section.

If the transmitter is still not working correctly, see your dealer or a qualified technician for service.

Remote Keyless Entry (RKE) System Operation

The Keyless Access system allows for vehicle entry when the Remote Keyless Entry (RKE) transmitter is within 1 m (3 ft). See “Keyless Access Operation” later in this section.

The RKE transmitter may work up to 60 m (197 ft) away from the vehicle.

Other conditions can affect the performance of the transmitter. See

Remote Keyless Entry (RKE) System 0 30.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Keys, Doors, and Windows 31

Pressing theft-deterrent system. See Vehicle Alarm System 0 47.

Q may also arm the

K : Press to unlock the driver door.

Press

K again within five seconds

to unlock all doors. The RKE transmitter can be programmed to unlock all doors on the first button press. See Vehicle Personalization 0 151. The turn signal indicators may flash to indicate unlocking has

With Remote Start and Power

Liftgate Shown

The following may be available:

Q : Press to lock all doors. The turn

signal indicators may flash and/or the horn may sound on the second press to indicate locking. See Vehicle Personalization 0 151. If the

driver door is open when pressed and Open Door Anti-Lockout is enabled, all doors will lock and then the driver door will immediately unlock. See Vehicle Personalization 0 151. If a

passenger door is open when pressed, all doors lock.

Q is

occurred. See Vehicle Personalization 0 151. Pressing

may also disarm the theft-deterrent system. See Vehicle Alarm System 0 47.

If equipped with the manual liftgate, unlocking all doors will also unlock the liftgate.

Press and hold fully open. Windows will not operate unless remote window operation is enabled. See Vehicle Personalization 0 151.

K until the windows

b : Press twice quickly to open or

close the power liftgate, if equipped. Press again to stop the power liftgate.

7 : Press and release one time to

initiate vehicle locator. The exterior lamps flash and the horn chirps

three times. Press and hold least three seconds to sound the panic alarm. The horn sounds and the turn signals flash for 30 seconds

or until vehicle is started.

7 is pressed again or the

7 for at

/ : If equipped, first press and

release and hold

four seconds to start the engine from outside the vehicle using the RKE transmitter. See Remote Vehicle Start 0 36.

Keyless Access Operation

With the Keyless Access system, you can lock and unlock the doors and access the liftgate without removing the RKE transmitter from your pocket, purse, briefcase, etc.

Q then immediately press

/ for at least

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

32 Keys, Doors, and Windows

The RKE transmitter should be within 1 m (3 ft) of the liftgate or door being opened. If equipped, there will be buttons on the outside door handles.

Keyless Access can be programmed to unlock all doors on the first lock/unlock press from the driver door. See Vehicle Personalization 0 151.

If equipped with memory seats, RKE transmitters 1 and 2 are linked to seating positions of memory 1 or 2. See Memory Seats 0 61.

Keyless Unlocking/Locking from the Driver Door

When the doors are locked and the RKE transmitter is within 1 m (3 ft) of the driver door handle, pressing the lock/unlock button on the driver door handle will unlock the driver door. If the lock/unlock button is pressed again within five seconds, all passenger doors will unlock.

Driver Shown, Passenger Similar

Pressing the lock/unlock button will cause all doors to lock if any of the following occur:

It has been more than five seconds since the first lock/ unlock button press.

Two lock/unlock button presses were used to unlock all doors.

Any vehicle door has opened and all doors are now closed.

Keyless Unlocking/Locking from Passenger Doors

When the doors are locked and the RKE transmitter is within 1 m (3 ft) of the door handle, pressing the lock/ unlock button on that door handle will unlock all doors. Pressing the lock/unlock button will cause all doors to lock if any of the following occur:

The lock/unlock button was used to unlock all doors.

Any vehicle door has opened and all doors are now closed.

Passive Locking

If equipped with Keyless Access, this vehicle will lock several seconds after all doors are closed if the vehicle is off and at least one RKE transmitter has been removed or none remain in the interior.

If other electronic devices interfere with the RKE transmitter signal, the vehicle may not detect the RKE transmitter inside the vehicle. If passive locking is enabled, the doors may lock with the RKE

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

transmitter inside the vehicle. Do not leave the RKE transmitter in an unattended vehicle.

To customize the doors to automatically lock when exiting the vehicle, see “Remote Lock, Unlock, Start” under Vehicle Personalization 0 151.

Temporary Disable of Passive Locking

Temporarily disable passive locking by pressing and holding

interior door switch with a door open for at least four seconds, or until three chimes are heard. Passive locking will then remain disabled

until

Q on the interior door is

pressed, or until the vehicle is turned on.

Remote Left in Vehicle Alert

When the vehicle is turned off and an RKE transmitter is left in the vehicle, the horn will chirp three times after all doors are closed. To turn on or off, see Vehicle Personalization 0 151.

K on the

Remote No Longer in Vehicle Alert

If the vehicle is on with a door open, and then all doors are closed, the vehicle will check for RKE transmitters inside. If an RKE transmitter is not detected, the Driver Information Center (DIC) will display NO REMOTE DETECTED and the horn will chirp three times. This occurs only once each time the vehicle is driven.

To turn on or off see Vehicle

Personalization 0 151

Keyless Liftgate Opening

When the doors are locked, press the touch pad on the liftgate handle to open the liftgate if the RKE transmitter is within 1 m (3 ft).

Key Access

To access a vehicle with a dead transmitter battery, see Door Locks 0 38.

Keys, Doors, and Windows 33

Programming Transmitters to the Vehicle

Only RKE transmitters programmed to the vehicle will work. If a transmitter is lost or stolen, a replacement can be purchased and programmed through your dealer. The vehicle can be reprogrammed so that lost or stolen transmitters no longer work. Each vehicle can have up to eight transmitters matched to it.

Programming with Recognized Transmitters

A new transmitter can be programmed to the vehicle when there are two recognized transmitters.

To program, the vehicle must be off and all of the transmitters, both currently recognized and new, must be with you.

1. Remove the key lock cylinder cap on the driver door handle. See Door Locks 0 38. Place the two recognized transmitters in the cupholder.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

34 Keys, Doors, and Windows

2. Insert the vehicle key of the transmitter into the key lock cylinder on the driver door handle and turn the key, counterclockwise, to the unlock position five times within 10 seconds.

The DIC displays READY FOR REMOTE #2, 3, 4, ETC.

3. Place the new transmitter into the cupholder.

4. Press ENGINE START/STOP. When the transmitter is learned the DIC display will show that it is ready to program the next transmitter.

5. Remove the transmitter from the cupholder and press

Q on the transmitter.

To program additional transmitters, repeat Steps 3–5.

When all additional transmitters are programmed, press and hold ENGINE START/STOP for 12 seconds to exit programming mode.

6. Put the key back into the transmitter.

7. Replace the key lock cylinder cap. See Door Locks 0 38.

Programming without Recognized Transmitters

If two currently recognized transmitters are not available, follow this procedure to program up to eight transmitters. This feature is not available in Canada. This procedure will take approximately 30 minutes to complete. The vehicle must be off and all of the transmitters you wish to program must be with you.

K or

1. Remove the key lock cylinder cap on the driver door handle. See Door Locks 0 38. Insert the vehicle key of the transmitter into the key lock cylinder on the driver door handle and turn the key, counterclockwise, to the unlock position five times within 10 seconds.

The DIC displays REMOTE LEARN PENDING, PLEASE WAIT.

2. Wait for 10 minutes until the DIC displays PRESS ENGINE START BUTTON TO LEARN and then press ENGINE START/STOP.

The DIC display will again show REMOTE LEARN PENDING, PLEASE WAIT.

3. Repeat Step 2 two additional times. After the third time all previously known transmitters will no longer work with the vehicle. Remaining transmitters can be relearned during the next steps.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

The DIC display should now show READY FOR REMOTE # 1.

When all additional transmitters are programmed, press and hold ENGINE START/STOP for 12 seconds to exit programming mode.

7. Put the key back into the transmitter.

8. Replace the key lock cylinder cap. See Door Locks 0 38.

Starting the Vehicle with a Low Transmitter Battery

When the vehicle is started, if the transmitter battery is weak, the DIC may display NO REMOTE

4. Place the new transmitter into the cupholder.

5. Press ENGINE START/STOP. When the transmitter is learned the DIC display will show that it is ready to program the next transmitter.

6. Remove the transmitter from the cupholder and press

K or

DETECTED or NO REMOTE KEY WAS DETECTED PLACE KEY IN TRANSMITTER POCKET THEN START YOUR VEHICLE. The DIC may also display REPLACE BATTERY IN REMOTE KEY.

Q on the transmitter.

To program additional transmitters, repeat Steps 4–6.

Keys, Doors, and Windows 35

To start the vehicle:

1. Place the transmitter in the cupholder.

2. With the vehicle in P (Park) or N (Neutral), press the brake pedal and ENGINE START/STOP.

Replace the transmitter battery as soon as possible.

Battery Replacement

Replace the battery if the DIC displays REPLACE BATTERY IN REMOTE KEY.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

36 Keys, Doors, and Windows

Caution

When replacing the battery, do not touch any of the circuitry on the transmitter. Static from your body could damage the transmitter.

The battery is not rechargeable. To replace the battery:

3. Remove the battery by pushing on the battery and sliding it toward the bottom of the transmitter.

4. Insert the new battery, positive side facing the back cover. Push the battery down until it is held in place. Replace with a CR2032 or equivalent battery.

5. Snap the battery cover back on to the transmitter.

2. Separate the two halves of the transmitter using a flat tool inserted into the area near the key slot.

1. Press the button on the side of the RKE transmitter and pull the key out. Never pull the key out without pressing the button.

Remote Vehicle Start

The vehicle may have this feature that allows you to start the engine from outside the vehicle.

/ : This button will be on the RKE

transmitter if the vehicle has remote start.

The climate control system will use the previous settings during a remote start. The rear defog may come on during remote start based on cold ambient conditions. The rear defog indicator light does not come on during remote start.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

If the vehicle has heated and ventilated front seats, they may come on during a remote start. See

Heated and Ventilated Front Seats

0 64.

Laws in some local communities may restrict the use of remote starters. For example, some laws require a person using remote start to have the vehicle in view. Check local regulations for any requirements.

Do not use the remote start feature if the vehicle is low on fuel. The vehicle could run out of fuel.

Other conditions can affect the performance of the transmitter. See

Remote Keyless Entry (RKE) System 0 30.

Starting the Engine Using Remote Start

1. Press and release RKE transmitter.

2. Immediately press and hold for at least four seconds or until the turn signal lamps flash. The turn signal lamps flashing

Q on the

confirms the request to remote start the vehicle has been received.

The parking lamps will turn on and remain on as long as the engine is running. The vehicle's doors will be locked.

3. Turn the ignition on before driving.

The engine will shut off after 15 minutes unless a time extension is done or the ignition is turned on.

Extending Engine Run Time

For a 15-minute extension, after 30 seconds repeat Steps 1 and 2 while the engine is still running. The remote start can be extended once.

When the remote start is extended, the second 15 minutes will be added.

For example, if the engine has been running for 15 minutes, and 15 minutes are added, the engine will run for a total of 30 minutes.

Keys, Doors, and Windows 37

A maximum of two remote starts or a start with an extension are allowed between ignition cycles.

The ignition must be turned on and then back off to use remote start again.

Canceling a Remote Start

To shut off the engine:

Press and hold parking lamps turn off.

Turn on the hazard warning flashers.

Turn the ignition on and then off.

Conditions in Which Remote Start Will Not Work

The remote vehicle start feature will not operate if:

A transmitter is in the vehicle.

The hood is not closed.

The hazard warning flashers are on.

There is an emission control system malfunction.

/ until the

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

38 Keys, Doors, and Windows

The engine coolant temperature is too high.

The oil pressure is low.

Two remote vehicle starts or a start with an extension have already been used.

The vehicle is not in P (Park).

Remote Start Ready

If the vehicle does not have the remote vehicle start feature, it may have the remote start ready feature. This feature allows your dealer to add the manufacturer's remote vehicle start feature. See your dealer to add the manufacturer's remote vehicle start feature to the vehicle.

Door Locks

Warning

{

Unlocked doors can be dangerous.

(Continued)

Warning (Continued)

Passengers, especially children, can easily open the doors and fall out of a moving vehicle. The doors can be unlocked and opened while the vehicle is moving. The chance of being thrown out of the vehicle in a crash is increased if the doors are not locked. So, all passengers should wear seat belts properly and the doors should be locked whenever the vehicle is driven.

Young children who get into unlocked vehicles may be unable to get out. A child can be overcome by extreme heat and can suffer permanent injuries or even death from heat stroke. Always lock the vehicle whenever leaving it.

(Continued)

Warning (Continued)

Outsiders can easily enter through an unlocked door when you slow down or stop the vehicle. Locking the doors can help prevent this from happening.

To lock or unlock the doors from the outside:

Press

Q or K on the Remote

Keyless Entry (RKE) transmitter. See Remote Keyless Entry (RKE) System Operation 0 30.

Use the key in the driver door. The key lock cylinder is covered with a cap.

To lock or unlock the doors from the inside:

Press

Q or K on the power door

lock switch.

Push down on the door lock knob to lock a door.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Pull the door handle once to unlock the door. Pull the handle again to unlatch it.

Keyless Access

Driver Door Key Lock Cylinder Access (In Case of Dead Battery)

Keys, Doors, and Windows 39

To replace the cap:

1. Pull the door handle (1) to the open position and hold it open until cap installation is complete.

If equipped, the RKE transmitter must be within 1 m (3 ft) of the liftgate or door being opened. Press the button on the door handle to open. See Remote Keyless Entry (RKE) System Operation 0 30.

To access the driver door key lock cylinder:

1. Pull the door handle (1) to the open position and hold it open until cap removal is complete.

2. Insert the key into the slot (3) on the bottom of the cap (2) and lift the key upward.

3. Move the cap (2) rearward and remove.

4. Use the key in the cylinder.

2. Insert the two tabs (6) at the back of the cap between the seal (5) and the metal base (4).

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

40 Keys, Doors, and Windows

5. Check that the cap is secure.

Free-Turning Locks

The door key lock cylinder turns freely when either the wrong key is used, or the correct key is not fully inserted. The free-turning door lock feature prevents the lock from being forced open. To reset the lock, turn it to the vertical position with the correct key fully inserted. Remove the key and insert it again. If this does not reset the lock, turn the key halfway around in the cylinder and repeat the reset procedure.

3. Slide the cap forward and press the forward edge to install the cap in place.

4. Release the door handle.

Power Door Locks

Q : Press to lock the doors. The

indicator light in the switch will come on when the door is locked.

K : Press to unlock the doors.

Delayed Locking

This feature delays the actual locking of the doors until five seconds after all doors are closed.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Delayed locking can only be turned on when the Open Door Anti-Lockout feature has been turned off.

Q is pressed on the power

When door lock switch with the door open, a chime will sound three times indicating that delayed locking is active.

The doors will then lock automatically five seconds after all doors are closed. If a door is reopened before five seconds have elapsed, the five-second timer will reset once all the doors are closed again.

Press

Q on the door lock switch

again, or press transmitter, to override this feature and lock the doors immediately.

Delayed locking can be programmed. See Vehicle Personalization 0 151.

Q on the RKE

Automatic Door Locks

The doors will lock automatically when all doors are closed, the ignition is on, and the vehicle is shifted out of P (Park).

If a vehicle door is unlocked and then opened and closed, the doors will lock either when your foot is removed from the brake or the vehicle speed becomes faster than 13 km/h (8 mph).

To unlock the doors:

Automatic door locking cannot be disabled. Automatic door unlocking can be programmed. See Vehicle Personalization 0 151.

K on the power door lock

Press switch.

Shift into P (Park).

Lockout Protection

If the ignition is on or in ACC/ ACCESSORY and the power door lock switch is pressed with the

Keys, Doors, and Windows 41

driver door open, all the doors will lock and only the driver door will unlock.

If the vehicle is off and locking is requested while a door is open, when all doors are closed the vehicle will check for RKE transmitters inside. If an RKE transmitter is detected and the number of RKE transmitters inside has not reduced, the driver door will unlock and the horn will chirp three times.

Lockout Protection can be manually overridden by pressing and holding

Q on the power door lock switch.

Open Door Anti-Lockout

If Open Door Anti-Lockout is turned on and the vehicle is off, the driver door is open, and locking is requested, all the doors will lock and the driver door will remain open. Press the button again to lock the driver door. The Open Door Anti-Lockout feature can be turned on or off. See Vehicle Personalization 0 151.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

42 Keys, Doors, and Windows

Safety Locks

The rear door safety locks prevent passengers from opening the rear doors from inside the vehicle.

Manual Safety Locks

If equipped, the safety lock is on the inside edge of the rear doors. To use the safety lock:

1. Move the lever forward to the lock position.

2. Close the door.

3. Do the same for the other rear door.

To open a rear door when the safety lock is on:

1. Unlock the door by activating the inside handle, by pressing the power door lock switch, or by using the Remote Keyless Entry (RKE) transmitter.

2. Open the door from the outside.

When the safety lock is enabled, adults and older children will not be able to open the rear door from the inside. Cancel the safety locks to enable the doors to open from the inside.

To cancel the safety lock:

1. Unlock the door and open it from the outside.

2. Move the lever rearward to unlock. Do the same for the other door.

Doors

Liftgate

Warning

{

Exhaust gases can enter the vehicle if it is driven with the liftgate or trunk/hatch open, or with any objects that pass through the seal between the body and the trunk/hatch or liftgate. Engine exhaust contains carbon monoxide (CO) which cannot be seen or smelled. It can cause unconsciousness and even death.

If the vehicle must be driven with the liftgate or trunk/hatch open:

Close all of the windows.

Fully open the air outlets on or under the instrument panel.

(Continued)

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Warning (Continued)

Adjust the climate control system to a setting that brings in only outside air and set the fan speed to the highest setting. See “Climate Control Systems” in the Index.

If the vehicle is equipped with a power liftgate, disable the power liftgate function.

See Engine Exhaust 0 203.

Keys, Doors, and Windows 43

Entry (RKE) transmitter twice within five seconds. See Remote Keyless Entry (RKE) System Operation 0 30.

Use the pull cup to lower and close the liftgate. Do not press the touch pad while closing the liftgate. This may cause the liftgate to be unlatched.

The liftgate has an electric latch. If the battery is disconnected or has low voltage, the liftgate will not open. The liftgate will resume operation when the battery is reconnected and charged.

Always close the liftgate before driving.

Power Liftgate Operation

Caution

To avoid damage to the liftgate or liftgate glass, make sure the area above and behind the liftgate is clear before opening it.

Manual Liftgate

To unlock the liftgate, press K on the power door lock switch or

press

K on the Remote Keyless

To open the liftgate, press the touch pad under the liftgate handle and lift up.

If equipped with Keyless Access, the liftgate can be opened when locked if the RKE transmitter is within 1 m (3 ft) of the touch pad. See Remote Keyless Entry (RKE) System Operation 0 30.

Warning

{

You or others could be injured if caught in the path of the power liftgate. Make sure there is no one in the way of the liftgate as it is opening and closing.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

44 Keys, Doors, and Windows

Caution

Driving with an open and unsecured liftgate may result in damage to the power liftgate components.

The power liftgate switch is on the driver door. The vehicle must be in P (Park). The taillamps flash when the power liftgate moves.

The modes are:

MAX: Opens to maximum height.

3/4: Opens to a reduced height that can be set from 3/4 to fully open. Use to prevent the liftgate from opening into overhead obstructions such as a garage door or roof-mounted cargo. The liftgate can be manually opened all the way.

OFF: Opens manually only.

To open or close the power liftgate, select MAX or 3/4 mode.

Press

b twice quickly on the

RKE transmitter until the liftgate moves.

Press

8 on the driver door.

The driver door must either be unlocked or locked without the security armed.

Press the touch pad under the liftgate handle after unlocking all doors. A locked vehicle can be opened if the RKE transmitter is within 1 m (3 ft) of the touch pad.

Press l on the bottom of the liftgate next to the pull cup to close.

Press any liftgate button, the touch pad, or

while the liftgate is moving to stop it. Pressing any liftgate button or

pressing RKE transmitter again restarts the operation in the reverse direction. Pressing the touch pad on the liftgate handle will restart the motion, but only in the opening direction.

b on the RKE transmitter

b twice quickly on the

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Caution

Manually forcing the liftgate to open or close during a power cycle can damage the vehicle. Allow the power cycle to complete.

The power liftgate may be temporarily disabled under extreme low temperatures, or after repeated power cycling over a short period of time. If this occurs, the liftgate can still be operated manually.

If the vehicle is shifted out of P (Park) while the power function is in progress, the liftgate will continue to completion. If the vehicle is accelerated before the liftgate has completed moving, the liftgate may stop or reverse direction. Check for Driver Information Center (DIC) messages and make sure the liftgate is closed and latched before driving.

Falling Liftgate Detection

If the power liftgate automatically closes after a power opening cycle, it indicates that the system is reacting to excess weight on the liftgate or a possible support strut failure. A repetitive chime will sound while the falling liftgate detection feature is operating. Remove any excess weight. If the liftgate continues to automatically close after opening, see your dealer for service before using the power liftgate.

Interfering with the power liftgate motion or manually closing the liftgate too quickly after power opening may resemble a support strut failure. This could also activate the falling liftgate detection feature. Allow the liftgate to complete its operation and wait a few seconds before manually closing the liftgate.

Obstacle Detection Features

If the liftgate encounters an obstacle during a power open or close cycle, the liftgate will automatically reverse direction and move a short distance

Keys, Doors, and Windows 45

away from the obstacle. After removing the obstruction, the power liftgate operation can be used again. If the liftgate encounters multiple obstacles on the same power cycle, the power function will deactivate. After removing the obstructions, manually close the liftgate, This will allow normal power operation functions to resume.

If the vehicle is locked while the liftgate is closing, and an obstacle is encountered that prevents the liftgate from completely closing, the horn will sound as an alert that the liftgate did not close.

Pinch sensors are on the side edges of the liftgate. If an object is caught between the liftgate and the vehicle and presses against a sensor, the liftgate will reverse direction and then stop. The liftgate will remain open until it is activated again or closed manually.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

46 Keys, Doors, and Windows

Setting the 3/4 Mode

To change the position the liftgate stops at when opening:

1. Select MAX or 3/4 mode and power open the liftgate.

2. Stop the liftgate movement at the desired height by pressing any liftgate button. Manually adjust the liftgate position if needed.

3. Press and hold pull cup on the outside of the liftgate until the turn signals flash and a beep sounds. This indicates the setting has been recorded.

The liftgate cannot be set below a minimum programmable height. If there is no light flash or sound, then the height adjustment may be too low.

l next to the

Manual Operation

Select OFF to manually operate the liftgate. See “Manual Liftgate” at the beginning of this section.

Attempting to move the liftgate too quickly and with excessive force may result in damage to the vehicle.

Operate the liftgate manually with a smooth motion and moderate speed. The system includes a feature which limits the manual closing speed to protect the components.

Hands-Free Operation

The liftgate may be operated with a kicking motion under the rear bumper between the left exhaust pipe and the license plate.

The RKE transmitter must be within 1 m (3 ft) of the rear bumper to operate the power liftgate hands-free.

The hands-free feature will not work while the liftgate is moving. To stop the liftgate while in motion use one of the liftgate buttons.

Caution

The hands-free feature will not work while the liftgate is moving. To stop the liftgate while in motion use one of the liftgate switches.

The hands-free feature can be customized. See Vehicle Personalization 0 151. Choose from the following:

On-Open and Close : The kicking motion is activated to both open and close the liftgate.

On-Open Only : The kicking motion is activated to only open the liftgate.

Off : The feature is disabled.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Keys, Doors, and Windows 47

Length of Kick Zone

To operate, kick your foot straight up in one swift motion under the rear bumper between the left exhaust pipe and the license plate, then pull it back.

Caution

Splashing water may cause the liftgate to open. Keep the RKE transmitter away from the rear bumper detection area or turn the liftgate mode to OFF when

(Continued)

Caution (Continued)

cleaning or working near the rear bumper to avoid accidental opening.

Do not sweep your foot side to side.

Do not keep your foot under the bumper; the liftgate will not activate.

Do not touch the liftgate until it has stopped moving.

This feature may be temporarily disabled under some conditions. If the liftgate does not respond to the kick, open or close the liftgate by another method or start the vehicle. The feature will be re-enabled.

When closing the liftgate using this feature, there will be a short delay. The taillamps will flash and a chime will sound. Step away from the liftgate before it starts moving.

Vehicle Security

This vehicle has theft-deterrent features; however, they do not make the vehicle impossible to steal.

Vehicle Alarm System

This vehicle has an anti-theft alarm system.

The indicator light, on the instrument panel near the windshield, indicates the status of the system:

Off : Alarm system is disarmed.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

48 Keys, Doors, and Windows

On Solid : Vehicle is secured

during the delay to arm the system.

Fast Flash : Vehicle is unsecured. A door, the hood, or the liftgate is open.

Slow Flash : Alarm system is armed.

Arming the Alarm System

1. Turn off the vehicle.

2. Lock the vehicle in one of three ways:

Use the RKE transmitter.

With a door open, press the interior

3. After 30 seconds the alarm system will arm, and the indicator light will begin to slowly flash indicating the alarm system is operating.

Pressing transmitter a second time will bypass the 30-second delay and immediately arm the alarm system.

Q on the RKE

The vehicle alarm system will not arm if the doors are locked with the key.

If the driver door is opened without first unlocking with the RKE transmitter, the horn will chirp and the lights will flash to indicate pre-alarm. If the vehicle is not started, or the door is not unlocked

by pressing transmitter during the 10-second pre-alarm, the alarm will be activated.

If a door, the hood, or the liftgate is opened without first disarming the system, the turn signals will flash and the horn will sound for about 30 seconds. The alarm system will then re-arm to monitor for the next unauthorized event.

Disarming the Alarm System

To disarm the alarm system or turn off the alarm if it has been activated:

K on the RKE

Press

K on the RKE transmitter.

Start the vehicle.

To avoid setting off the alarm by accident:

Lock the vehicle after all occupants have left the vehicle and all doors are closed.

Always unlock a door with the RKE transmitter.

Unlocking the driver door with the key will not disarm the system or turn off the alarm.

How to Detect a Tamper Condition

If K is pressed on the RKE transmitter and the horn chirps and the lights flash three times, an alarm occurred previously while the alarm system was armed.

If the alarm has been activated, a message will appear on the DIC.

Immobilizer

See Radio Frequency Statement 0 396.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Immobilizer Operation

This vehicle has a passive theft-deterrent system.

The system does not have to be manually armed or disarmed.

The vehicle is automatically immobilized when the vehicle is turned off.

The immobilization system is disarmed when the vehicle is started or the ignition is in ACC/ ACCESSORY and a valid transmitter is present in the vehicle.

The security light, in the instrument cluster, comes on if there is a problem with arming or disarming the theft-deterrent system.

The system has one or more RKE transmitters matched to an immobilizer control unit in your

vehicle. Only a correctly matched RKE transmitter will start the vehicle. If the transmitter is ever damaged, you may not be able to start your vehicle.

When trying to start the vehicle, the security light may come on briefly when the ignition is turned on.

If the engine does not start and the security light stays on, there is a problem with the system. Turn the ignition off and try again.

If the vehicle will not change ignition modes, and the RKE transmitter appears to be undamaged, try another transmitter. Refer to “Starting the Vehicle with a Low Transmitter Battery” in Remote

Keyless Entry (RKE) System Operation 0 30. Or, you may try

placing the transmitter in the cupholder.

If the ignition mode will not change with the other transmitter or in the cupholder, your vehicle needs service. If the ignition does change modes, the first transmitter may be faulty. See your dealer who can

Keys, Doors, and Windows 49

service the theft-deterrent system and have a new RKE transmitter programmed to the vehicle.

It is possible for the immobilizer system to learn new or replacement RKE transmitters. Up to eight transmitters can be programmed for the vehicle. To program additional transmitters, see “Programming Transmitters to the Vehicle” under

Remote Keyless Entry (RKE) System Operation 0 30.

Do not leave the transmitter or device that disarms or deactivates the theft-deterrent system in the vehicle.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

50 Keys, Doors, and Windows

Exterior Mirrors

Power Mirrors

Convex Mirrors

Warning

{

A convex mirror can make things, like other vehicles, look farther away than they really are. If you cut too sharply into the right lane, you could hit a vehicle on the right. Check the inside mirror or glance over your shoulder before changing lanes.

The passenger side mirror is convex shaped. A convex mirror's surface is curved so more can be seen from the driver seat.

To adjust the mirrors:

1. Press

2. Press the arrows on the control

j or | to choose the

driver or passenger mirror.

pad to move each mirror in the desired direction.

Folding Mirrors

Manual Folding Mirrors

The mirrors can be folded inward toward the vehicle to prevent damage when going through an

automatic car wash. Push the mirror outward to return it to the original position.

Memory Mirrors

The vehicle may have memory mirrors. See Memory Seats 0 61.

Lane Change Alert (LCA)

The vehicle may have LCA. See Lane Change Alert (LCA) 0 246.

Side Blind Zone Alert

The vehicle may have Side Blind Zone Alert. See Side Blind Zone Alert (SBZA) 0 246.

Heated Mirrors

If equipped, the heated outside mirrors turn on when the rear window defogger is on and help to clear fog or frost from the surface of the mirrors.

K : This button is on the climate

control panel.

See “Rear Window Defogger” under

Dual Automatic Climate Control System 0 171.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Keys, Doors, and Windows 51

Automatic Dimming Mirror

The vehicle has an automatic dimming outside mirror on the driver side. The mirror will adjust for the glare of headlamps behind you.

Reverse Tilt Mirrors

If equipped with memory seats, the passenger and/or driver mirror tilts to a preselected position when the vehicle is in R (Reverse). This allows the curb to be seen when parallel parking.

The mirror(s) return to the original position when:

The vehicle is shifted out of R (Reverse), or remains in R (Reverse) for about 30 seconds.

The ignition is turned off.

The vehicle is driven in R (Reverse) above a set speed.

To turn this feature on or off, see Vehicle Personalization 0 151.

Interior Mirrors

Interior Rearview Mirrors

Adjust the rearview mirror for a clear view of the area behind the vehicle.

Do not spray glass cleaner directly on the mirror. Use a soft towel dampened with water.

Manual Rearview Mirror

If equipped, push the tab forward for daytime use and pull it rearward for nighttime use to avoid glare of the headlamps from behind.

Automatic Dimming Rearview Mirror

If equipped, automatic dimming reduces the glare of headlamps from behind. The dimming feature comes on when the vehicle is started.

Windows

Warning

{

Never leave a child, a helpless adult, or a pet alone in a vehicle, especially with the windows closed in warm or hot weather. They can be overcome by the extreme heat and suffer permanent injuries or even death from heat stroke.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

52 Keys, Doors, and Windows

The vehicle aerodynamics are designed to improve fuel economy performance. This may result in a pulsing sound when either rear window is down and the front windows are up. To reduce the sound, open either a front window or the sunroof, if equipped.

Power Windows

Warning

{

Children could be seriously injured or killed if caught in the path of a closing window. Never leave the Remote Keyless Entry (RKE) transmitter in a vehicle with children. When there are children in the rear seat, use the window lockout switch to prevent operation of the windows. See Keys 0 29.

Power windows work when the ignition is on, in ACC/ACCESSORY, or when Retained Accessory Power (RAP) is active. See Retained Accessory Power (RAP) 0 200.

Using the window switch, press to open or pull to close the window.

The windows may be temporarily disabled if they are used repeatedly within a short time.

Window Lockout

This feature stops the rear door passenger window switches from working.

Press

2 to engage the rear

window lockout feature. The indicator light is on when engaged.

Press

2 again to disengage.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Window Express Movement

All windows can be opened without holding the window switch. Press the switch down fully and quickly release to express open the window.

If equipped, pull the window switch up fully and quickly release to express close the window.

Briefly press or pull the window switch in the same direction to stop that window’s express movement.

Window Automatic Reversal

Automatic Reversal System Override

{

If automatic reversal system override is active, the window will not reverse automatically. You or others could be injured and the window could be damaged. Before using automatic reversal system override, make sure that all people and obstructions are clear of the window path.

System

The express-close feature will reverse window movement if it comes in contact with an object. Extreme cold or ice could cause the window to auto-reverse. The window will operate normally after the object or condition is removed.

When the engine is on, override the automatic reversal system by pulling and holding the window switch if conditions prevent it from closing.

Programming the Power Windows

Programming may be necessary if the vehicle's battery has been disconnected or discharged. If the window is unable to express-up, program the window:

1. Close all doors.

Warning

Keys, Doors, and Windows 53

2. Turn the ignition on or to ACC/ ACCESSORY.

3. Partially open the window to be programmed, then close it and continue to pull the switch briefly after the window has fully closed.

4. Open the window and continue to press the switch briefly after the window has fully opened.

Remote Window Operation

If equipped, this feature allows all the windows to be opened remotely. If enabled in vehicle personalization,

press and hold transmitter. See Vehicle Personalization 0 151.

K on the RKE

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

54 Keys, Doors, and Windows

Sun Visors

Roof

Sunroof

Pull the sun visor down to block glare. Detach the sun visor from the center mount to pivot to the side window and, if equipped, extend along the rod.

1. Sunroof Switch

2. Sunshade Switch

If equipped, the sunroof only operates when the ignition is on or in ACC/ACCESSORY, or when Retained Accessory Power (RAP) is active. See Ignition Positions 0 194 and

Retained Accessory Power (RAP) 0 200.

Sunroof Switch

Express-Open/Express-Close : To

express-open the sunroof, press and release release

movement. To express-close the sunroof, press and release Press and release

time to stop movement.

Open/Close (Manual Mode) : To open the sunroof, press and hold

e (1). Press and

e (1) at any time to stop

g (1).

g (1) at any

e (1) until the sunroof reaches

the desired position. To close the sunroof, press and hold

Comfort Stop : The sunroof has a comfort stop feature that stops the sunroof from opening fully. Press

and release the rear of move the sunroof to the partially opened comfort stop position.

Pressing the rear of open the sunroof fully. If the sunshade is not fully open when the comfort stop feature is pressed the second time, the sunshade will open fully.

g (1).

g to

g again will

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Vent : From the closed position, press and release the sunroof. Press and release

(1) to close the vent.

Sunshade Switch

Express-open/Express-close : To

express-open the sunshade, press and release release

movement. To express-close the sunshade, press and release

(2). Press and release Q (2) at

any time to stop movement.

Open/Close (Manual Mode) : To open the sunshade, press and

hold reaches the desired position. To close the sunshade, press and hold

r (2) at any time to stop

r (2) until the sunshade

e (1) to vent

r (2). Press and

Automatic Reversal System

The sunroof has an automatic reversal system that is only active when the sunroof is operated in express-close mode.

If an object is in the path while express closing, the reversal system will detect an object, stop, and open the sunroof again.

If frost or other conditions prevent closing, override the feature by closing the sunroof in manual mode. To stop movement, release the switch.

Q (2).

When the sunroof is opened, an air deflector will automatically raise. The air deflector will retract when the sunroof is closed.

The sunroof cannot be opened or closed if the vehicle has an electrical failure.

Keys, Doors, and Windows 55

Dirt and debris may collect on the sunroof seal or in the track. This could cause an issue with sunroof operation or noise. It could also plug the water drainage system. Periodically open the sunroof and remove any obstacles or loose debris. Wipe the sunroof seal and roof sealing area using a clean cloth, mild soap, and water. Do not remove grease from the sunroof.

If water is seen dripping into the water drainage system, this is normal.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

56 Seats and Restraints

Seats and Restraints

Head Restraints

Head Restraints . . . . . . . . . . . . . . . 57

Front Seats

Seat Adjustment . . . . . . . . . . . . . . . 59

Power Seat Adjustment . . . . . . . . 59

Lumbar Adjustment . . . . . . . . . . . . 60

Reclining Seatbacks . . . . . . . . . . . 60

Memory Seats . . . . . . . . . . . . . . . . . 61

Heated and Ventilated Front

Seats . . . . . . ... . . . . . . . . . . ... . . . 64

Rear Seats

Rear Seats . . . . . . . . . . . . . . . . . . . . 65

Heated Rear Seats . . . . . . . . . . . . 68

Seat Belts

Seat Belts . . . . . . . . . . . . . . . . . . . . . 69

How to Wear Seat Belts

Properly .. . . . . . .. . . . . . . . . . . . . . 70

Lap-Shoulder Belt . . . . . . . . . . . . . 72

Seat Belt Use During

Pregnancy .. . . . . . . . . . . .. . . . . . . 75

Seat Belt Extender . . . . . . . . . . . . . 75

Safety System Check . . . . . . . . . . 76

Seat Belt Care . . .. . . . . . . . . . . . . . 76

Replacing Seat Belt System

Parts after a Crash . ... . . . . . . . 76

Airbag System

Airbag System . . . . . . . . . . . . . . . . . 77

Where Are the Airbags? . ... . . . 79

When Should an Airbag

Inflate? . . . . . . . . . . . . . . . . . . . .. . . 80

What Makes an Airbag

Inflate? . . . . . . . . . . . . . . . . . . . .. . . 81

How Does an Airbag

Restrain? . . . . . ... . . . . . . . . . ... . 81

What Will You See after an

Airbag Inflates? . . . . . . . . . . . . . . 82

Passenger Sensing System . . . 83 Servicing the Airbag-Equipped

Vehicle . . . . . . . . . . . . . . . . . . . . . . . 87

Adding Equipment to the

Airbag-Equipped Vehicle . . . . . 87

Airbag System Check . . ... . . . . . 88

Replacing Airbag System Parts

after a Crash . . . . . . . . . . . . . . . . . 89

Child Restraints

Older Children . . . . . . . . . . . . . . . . . 89

Infants and Young Children . . . . 91

Child Restraint Systems . . . . . . . 93

Where to Put the Restraint . . . . . 95

Lower Anchors and Tethers for

Children (LATCH System) . . . . 96

Replacing LATCH System

Parts After a Crash . ... . . . . . 101

Securing Child Restraints (With

the Seat Belt in the

Rear Seat) . . . . . . . . . . . . . . .. . . 102

Securing Child Restraints (With

the Seat Belt in the

Front Seat) . . . . .. . . . . . . . . .. . . 104

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Head Restraints

The vehicle’s front seats have adjustable head restraints in the outboard seating positions.

Warning

{

With head restraints that are not installed and adjusted properly, there is a greater chance that occupants will suffer a neck/ spinal injury in a crash. Do not drive until the head restraints for all occupants are installed and adjusted properly.

If your vehicle has rear head restraints that fold down, always return them to the full upright position whenever an occupant is seated in the seat.

Adjust the head restraint so that the top of the restraint is at the same height as the top of the occupant's head. This position reduces the chance of a neck injury in a crash.

Front Seats

The vehicle's front seats have adjustable head restraints in the outboard seating positions.

Seats and Restraints 57

The height of the head restraint can be adjusted.

To raise or lower the head restraint, press the button located on the side of the head restraint and pull up or push the head restraint down, and release the button. Pull and push on the head restraint after the button is released to make sure that it is locked in place.

The front seat outboard head restraints are not removable.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

58 Seats and Restraints

Rear Seats

Adjusting the Rear Head Restraint

The vehicle's rear seats have adjustable head restraints in the outboard seating positions.

The height of the head restraint can be adjusted. Pull the head restraint up to raise it. Try to move the head restraint to make sure that it is locked in place.

To lower the head restraint, press the button, located on the top of the seatback, and push the head restraint down. Try to move the

head restraint after the button is released to make sure that it is locked in place.

Folding the Rear Head Restraint

The head restraint can be folded rearward to allow for better visibility when the rear seat is unoccupied.

To fold the head restraint, press the button on the side of the head restraint.

The head restraint will fold rearward automatically.

When an occupant or child restraint is in the seat, always return the head restraint to the full upright position. Pull the head restraint up and forward until it locks into place. Push and pull on the head restraint to make sure that it is locked.

Always adjust the head restraint so that the top of the restraint is at the same height as the top of the occupant's head.

Rear outboard head restraints are not removable.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Front Seats

Seat Adjustment

Warning

{

You can lose control of the vehicle if you try to adjust a driver seat while the vehicle is moving. Adjust the driver seat only when the vehicle is not moving.

To adjust the seat position:

1. Pull the handle at the front of the seat cushion to unlock it.

2. Move the seat forward or rearward and release the handle.

3. Try to move the seat back and forth to be sure it is locked in place.

Seat Height Adjuster

Move the lever up or down to raise or lower the seat.

Seats and Restraints 59

Power Seat Adjustment

Warning

{

The power seats will work with the ignition off. Children could operate the power seats and be injured. Never leave children alone in the vehicle.

To adjust a power seat, if equipped:

Move the seat forward or rearward by sliding the control forward or rearward.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

60 Seats and Restraints

Raise or lower the front part of the seat cushion by moving the front of the control up or down.

Raise or lower the entire seat by moving the rear of the control up or down.

To adjust the seatback, see Reclining Seatbacks 0 60.

Lumbar Adjustment

If equipped, press and hold the front or rear of the control to increase or decrease lumbar support.

Reclining Seatbacks

Warning

{

Sitting in a reclined position when the vehicle is in motion can be dangerous. Even when buckled up, the seat belts cannot do their job.

The shoulder belt will not be against your body. Instead, it will be in front of you. In a crash, you could go into it, receiving neck or other injuries.

The lap belt could go up over your abdomen. The belt forces would be there, not at your pelvic bones. This could cause serious internal injuries.

For proper protection when the vehicle is in motion, have the seatback upright. Then sit well back in the seat and wear the seat belt properly.

Do not have a seatback reclined if the vehicle is moving.

Manual Reclining Seatbacks

Warning

{

If either seatback is not locked, it could move forward in a sudden stop or crash. That could cause injury to the person sitting there. Always push and pull on the seatbacks to be sure they are locked.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

2. Push and pull on the seatback to make sure it is locked.

Power Reclining Seatbacks

To recline a manual seatback:

1. Lift the lever.

2. Move the seatback to the desired position, and then release the lever to lock the seatback in place.

3. Push and pull on the seatback to make sure it is locked.

To return the seatback to the upright position:

1. Lift the lever fully without applying pressure to the seatback, and the seatback will return to the upright position.

To adjust a power seatback, if available:

Tilt the top of the control rearward to recline.

Tilt the top of the control forward to raise.

Seats and Restraints 61

Memory Seats

Before saving, adjust all available memory feature positions. Turn the ignition on and then press and release SET; a beep will sound.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

62 Seats and Restraints

Then immediately press and hold 1, 2, or

B (Exit) until two beeps

sound. To manually recall these positions, press and hold 1, 2, or

until the saved position is reached. Follow the instructions under “Saving Memory Positions.”

The vehicle identifies the current driver’s RKE transmitter number (1–

8). See Remote Keyless Entry (RKE) System Operation 0 30. Only RKE transmitters 1 and 2 can be used for automatic memory recalls. A Driver Information Center (DIC) welcome message indicating the transmitter number may display for the first few ignition cycles following a transmitter change. For Seat Entry Memory to work properly, save the positions to the memory button (1 or

2) matching the RKE transmitter number displayed in the DIC welcome message. Carry the linked RKE transmitter when entering the vehicle.

Memory adjustments may not be available upon delivery or after service until steps in “Saving Memory Positions” section are

performed.

Vehicle Personalization Settings

To have the Seat Entry Memory movement begin when the vehicle is started, select the Settings menu, then Vehicle, then Seating Position, and then Seat Entry Memory. Select On or Off. See “Seat Entry Memory” later in this section.

Seat Exit Memory movement begins when the ignition is turned off and the driver door is opened, or when the ignition is turned off with the driver door already opened, select the Settings menu, then Vehicle, then Seating Position, and then Seat Exit Memory. Select On or Off. See “Seat Exit Memory” later in this section.

See Vehicle Personalization 0 151 for additional setting information.

Identifying Driver Number

To identify the driver number:

1. Start the vehicle with a different key or RKE transmitter. The DIC should display the driver number; 1 or 2. Turn the ignition off and remove the key or RKE transmitter from the vehicle.

2. Start the vehicle with the initial key or RKE transmitter. The DIC should display the other driver number not shown in Step 1.

Saving Memory Positions

Read these instructions completely before saving memory positions.

To save preferred driving positions 1 and 2:

1. Turn the ignition on or to ACC/ ACCESSORY.

A DIC welcome message may indicate driver number 1 or 2.

2. Adjust all available memory features to the desired driving position.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

3. Press and release SET; a beep will sound.

4. Immediately press and hold the 1 or 2 memory button matching the above DIC welcome message until two beeps sound.

If too much time passes between releasing SET and pressing 1, the memory position will not be saved and two beeps will not sound. Repeat Steps 3 and 4.

1 or 2 corresponds to the driver number. See “Identifying Driver Number” previously in this section.

5. Repeat Steps 1–4 for a second driver using 1 or 2.

To save the position for Seat Exit Memory, repeat Steps 1–4

using

B. This saves the position

for getting out of the vehicle.

Save preferred memory feature positions to both 1 and 2 if you are the only driver.

B and

Manually Recalling Memory Positions

Press and hold 1, 2, or the previously saved memory positions.

To stop Manual Memory Recall movement, release 1, 2, or

press any of the following controls:

Power seat

Memory SET

Power mirror, with the driver or passenger side mirror selected

Power steering wheel, if equipped

Seat Entry Memory

The vehicle identifies the number of the current driver’s RKE transmitter (1–8). See Remote Keyless Entry (RKE) System Operation 0 30. If the RKE transmitter is 1 or 2, and Seat Entry Memory is programmed on in vehicle personalization, the positions saved to the same memory button number 1 or 2 are automatically recalled when the ignition is turned on, or turned from

B to recall

B or

Seats and Restraints 63

off to ACC/ACCESSORY. RKE transmitters 3–8 will not provide automatic memory recalls.

To turn Seat Entry Memory on or off, see "Vehicle Personalization Settings" previously in this section and Vehicle Personalization 0 151.

The shift lever must be in P (Park) to start Seat Entry Memory. Seat Entry Memory will complete if the vehicle is shifted out of P (Park) prior to reaching the saved memory position.

To stop Seat Entry Memory movement, turn the ignition off or press any of the following controls:

Power seat

Memory SET, 1, 2, or

Power mirror, with the driver or passenger side mirror selected

Power steering wheel, if equipped

If the saved memory seat position does not automatically recall or recalls to the wrong positions, the driver’s RKE transmitter number (1

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

64 Seats and Restraints

or 2) may not match the memory button number that positions were saved to. Try saving the position to the other memory button or try the other RKE transmitter.

Seat Exit Memory

Seat Exit Memory is not linked to an RKE transmitter. The position saved

B is used for all drivers. To turn

Seat Exit Memory on or off, see "Vehicle Personalization Settings" previously in this section and Vehicle Personalization 0 151.

If turned on, the position saved to

B is automatically recalled when

one of the following occurs:

The vehicle is turned off and the driver door is opened within a short time.

The vehicle is turned off with the driver door open.

To stop Seat Exit Memory movement, press any of the following memory controls:

Power seat

Memory SET, 1, 2, or

Power mirror, with the driver or passenger side mirror selected

Power steering wheel, if equipped

Obstructions

If something has blocked the driver seat and/or power steering wheel while recalling a memory position, the recall may stop. Remove the obstruction and try the recall again. If the memory position still does not recall, see your dealer for service.

Heated and Ventilated Front Seats

Warning

{

If temperature change or pain to the skin cannot be felt, the seat heater may cause burns. To reduce the risk of burns, use care when using the seat heater, especially for long periods of time. Do not place anything on the seat that insulates against

(Continued)

Warning (Continued)

heat, such as a blanket, cushion, cover, or similar item. This may cause the seat heater to overheat. An overheated seat heater may cause a burn or may damage the seat.

If available, the buttons are on the climate control panel. To operate, the engine must be running.

Press

L or M to heat the driver or

passenger seat cushion and seatback.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Press the button once for the highest setting. With each press of the button, the heated seat will change to the next lower setting, and then to the off setting. The lights indicate three for the highest setting and one for the lowest.

The passenger seat may take longer to heat up.

Press

{ or C to ventilate the driver

or passenger seat. A ventilated seat has a fan that pulls air through the seat cushion and seatback. The air is not cooled.

Press the button once for the highest setting. With each press of the button, the ventilated seat will change to the next lower setting, and then to the off setting. The lights indicate three for the highest setting and one for the lowest.

Remote Start Heated and Ventilated Seats

During a remote start, the heated or ventilated seats, if equipped, can be turned on automatically. When it is cold outside, the heated seats turn

on, and when it is hot outside the ventilated seats turn on. The heated or ventilated seats are canceled when the ignition is turned on. Press the heated or ventilated seat button to use the heated or ventilated seats after the vehicle is started.

The heated or ventilated seat indicator lights do not turn on during a remote start.

The temperature performance of an unoccupied seat may be reduced. This is normal.

The remote start heated or ventilated seats may be enabled or disabled in the vehicle personalization menu. See Remote Vehicle Start 0 36 and Vehicle Personalization 0 151.

Seats and Restraints 65

Rear Seats

Rear Seat Reminder

If equipped, the message REAR SEAT REMINDER LOOK IN REAR SEAT displays under certain conditions indicating there may be an item or passenger in the rear seat. Check before exiting the vehicle.

This feature will activate when a second row door is opened while the vehicle is on or up to 10 minutes before the vehicle is turned on. There will be an alert when the vehicle is turned off. The alert does not directly detect objects in the rear seat; instead, under certain conditions, it detects when a rear door is opened and closed, indicating that there may be something in the rear seat.

The feature is active only once each time the vehicle is turned on and off, and will require reactivation by opening and closing the second row doors. There may be an alert even when there is nothing in the rear seat; for example, if a child entered

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

66 Seats and Restraints

the vehicle through the rear door and left the vehicle without the vehicle being shut off.

The feature can be turned on or off. See Vehicle Personalization 0 151.

Reclining the Seatback

To recline the seatback:

1. Pull the reclining seatback handle.

2. Move the seatback to the desired position, and then release the handle to lock the seatback in place.

3. Push and pull on the seatback to make sure it is locked.

Folding the Seatback

Either side of the seatback can be folded for more cargo space. Fold a seatback only when the vehicle is not moving.

Caution

Folding a rear seat with the seat belts still fastened may cause damage to the seat or the seat belts. Always unbuckle the seat belts and return them to their normal stowed position before folding a rear seat.

To fold the seatback:

1. Fold the head restraint. See Head Restraints 0 57.

2. Pull the handle on top of the seatback to unlock it.

A tab near the seatback lever raises when the seatback is unlocked.

3. Fold the seatback forward.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

4. Stow the seat belt in the belt stowage clip.

Repeat the steps to fold the other seatback, if desired.

If equipped, the rear seatbacks can also be folded forward by pulling the levers on the passenger side of the rear cargo area.

Raising the Seatback

Warning

{

Seats and Restraints 67

Warning

{

A seat belt that is improperly routed, not properly attached, or twisted will not provide the protection needed in a crash. The person wearing the belt could be seriously injured. After raising the rear seatback, always check to be sure that the seat belts are properly routed and attached, and are not twisted.

To raise a seatback:

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

68 Seats and Restraints

1. Ensure the seat belt is in the belt stowage clip.

2. Lift the seatback up and push it rearward to lock it in place.

A tab near the seatback lever retracts when the seatback is locked in place.

3. Return the head restraint to the upright position. See Head Restraints 0 57.

4. Push and pull the top of the seatback to be sure it is locked into position.

5. Repeat the steps to raise the other seatback, if necessary.

When the seat is not in use, it should be kept in the upright, locked position.

Heated Rear Seats

Warning

{

If temperature change or pain to the skin cannot be felt, the seat heater may cause burns. See the Warning under Heated and Ventilated Front Seats 0 64.

If equipped, the rear heated seat buttons are on the rear of the center console.

z to heat the left or right

Press outboard seat cushion and seatback.

+ to heat the left or right

Press outboard seatback only.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Seat Belts

This section describes how to use seat belts properly, and some things not to do.

Warning

{

Do not let anyone ride where a seat belt cannot be worn properly. In a crash, if you or your passenger(s) are not wearing seat belts, injuries can be much worse than if you are wearing seat belts. You can be seriously injured or killed by hitting things inside the vehicle harder or by being ejected from the vehicle. In addition, anyone who is not buckled up can strike other passengers in the vehicle.

It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, passengers riding in these areas are more likely to be seriously injured or killed. Do not allow

(Continued)

Warning (Continued)

passengers to ride in any area of the vehicle that is not equipped with seats and seat belts.

Always wear a seat belt, and check that all passenger(s) are restrained properly too.

This vehicle has indicators as a reminder to buckle the seat belts. See Seat Belt Reminders 0 130.

Why Seat Belts Work

Seats and Restraints 69

When riding in a vehicle, you travel as fast as the vehicle does. If the vehicle stops suddenly, you keep going until something stops you. It could be the windshield, the instrument panel, or the seat belts!

When you wear a seat belt, you and the vehicle slow down together. There is more time to stop because you stop over a longer distance and, when worn properly, your strongest bones take the forces from the seat belts. That is why wearing seat belts makes such good sense.

Questions and Answers About Seat Belts

Q: Will I be trapped in the vehicle

after a crash if I am wearing a seat belt?

A: You could be — whether you are

wearing a seat belt or not. Your chance of being conscious during and after a crash, so you

can unbuckle and get out, is much greater if you are belted.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

70 Seats and Restraints

Q: If my vehicle has airbags, why

should I have to wear seat belts?

A: Airbags are supplemental

systems only. They work with seat belts — not instead of them. Whether or not an airbag is provided, all occupants still have to buckle up to get the most protection.

Also, in nearly all states and in all Canadian provinces, the law requires wearing seat belts.

It is very important for all occupants to buckle up. Statistics show that unbelted people are hurt more often in crashes than those who are wearing seat belts.

There are important things to know about wearing a seat belt properly.

How to Wear Seat Belts Properly

Follow these rules for everyone's protection.

There are additional things to know about seat belts and children, including smaller children and infants. If a child will be riding in the vehicle, see Older Children 0 89 or Infants and Young Children 0 91. Review and follow the rules for children in addition to the following rules.

Sit up straight and always keep your feet on the floor in front of you (if possible).

Always use the correct buckle for your seating position.

Wear the lap part of the belt low and snug on the hips, just touching the thighs. In a crash,

this applies force to the strong pelvic bones and you would be less likely to slide under the lap belt. If you slid under it, the belt would apply force on your abdomen. This could cause serious or even fatal injuries.

Wear the shoulder belt over the shoulder and across the chest. These parts of the body are best able to take belt restraining forces. The shoulder belt locks if there is a sudden stop or crash.

Warning

{

You can be seriously injured, or even killed, by not wearing your seat belt properly.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Seats and Restraints 71

Always use the correct buckle for your seating position.

Never allow the lap or shoulder belt to become loose or twisted.

Never wear the shoulder belt under both arms or behind your back.

Never route the lap or shoulder belt over an armrest.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

72 Seats and Restraints

Lap-Shoulder Belt

All seating positions in the vehicle have a lap-shoulder belt.

The following instructions explain how to wear a lap-shoulder belt properly.

1. Adjust the seat, if the seat is adjustable, so you can sit up straight. To see how, see “Seats” in the Index.

2. Pick up the latch plate and pull the belt across you. Do not let it get twisted.

The lap-shoulder belt may lock if you pull the belt across you very quickly. If this happens, let the belt go back slightly to unlock it. Then pull the belt across you more slowly.

If the shoulder portion of a passenger belt is pulled out all the way, the child restraint locking feature may be engaged. If this happens, let the belt go back all the way and start again.

Engaging the child restraint locking feature in the front outboard seating position may affect the passenger sensing system. See Passenger Sensing System 0 83.

If the webbing locks in the latch plate before it reaches the buckle, tilt the latch plate flat to unlock.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

3. Push the latch plate into the buckle until it clicks.

Pull up on the latch plate to make sure it is secure. If the belt is not long enough, see Seat Belt Extender 0 75.

Position the release button on the buckle so that the seat belt could be quickly unbuckled if necessary.

To unlatch the belt, push the button on the buckle. The belt should return to its stowed position.

Always stow the seat belt slowly. If the seat belt webbing returns quickly to the stowed position, the retractor may lock and cannot be pulled out. If this happens, pull the seat belt straight out firmly to unlock the webbing, and then release it. If the webbing is still locked in the

4. To make the lap part tight, pull up on the shoulder belt.

retractor, see your dealer.

Before a door is closed, be sure the seat belt is out of the way. If a door is slammed against a seat belt, damage can occur to both the seat belt and the vehicle.

Seats and Restraints 73

Seat Belt Pretensioners

This vehicle has seat belt pretensioners for front outboard occupants. Although the seat belt pretensioners cannot be seen, they are part of the seat belt assembly. They can help tighten the seat belts during the early stages of a moderate to severe frontal, near frontal, or rear crash if the threshold conditions for pretensioner activation are met. Seat belt pretensioners can also help tighten the seat belts in a side crash or a rollover event.

Pretensioners work only once. If the pretensioners activate in a crash, the pretensioners and probably other parts of the vehicle’s seat belt system will need to be replaced. See Replacing Seat Belt System Parts after a Crash 0 76.

Do not sit on the outboard seat belt while entering or exiting the vehicle, or at any time while sitting in the seat. Sitting on the seat belt can damage the webbing and hardware.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

74 Seats and Restraints

Rear Seat Belt Comfort Guides

Warning

{

A seat belt that is not properly worn may not provide the protection needed in a crash. The person wearing the belt could be seriously injured. The shoulder belt should go over the shoulder and across the chest. These parts of the body are best able to take belt restraining forces.

Rear seat belt comfort guides may provide added seat belt comfort for older children who have outgrown booster seats and for some adults. When installed on a shoulder belt, the comfort guide positions the shoulder belt away from the neck and head.

This vehicle will have rear seat belt comfort guides in the rear outboard seating positions.

To install:

1. Remove the guide from its storage pocket on the side of the seatback.

2. Place the guide over the belt, and insert the two edges of the belt into the slots of the guide.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

3. Be sure that the belt is not twisted and it lies flat. The elastic cord must be behind the belt with the plastic guide on the front.

removed from the guide. Slide the guide back into its storage pocket on the side of the seatback.

Seat Belt Use During Pregnancy

Seat belts work for everyone, including pregnant women. Like all occupants, they are more likely to be seriously injured if they do not wear seat belts.

4. Buckle, position, and release the seat belt as described previously in this section. Make sure the shoulder belt crosses the shoulder. The belt should be close to, but not contacting, the neck.

To remove and store the comfort guide, squeeze the belt edges together so that the seat belt can be

Seats and Restraints 75

A pregnant woman should wear a lap-shoulder belt, and the lap portion should be worn as low as possible, below the rounding, throughout the pregnancy.

The best way to protect the fetus is to protect the mother. When a seat belt is worn properly, it is more likely that the fetus will not be hurt in a crash. For pregnant women, as for anyone, the key to making seat belts effective is wearing them properly.

Seat Belt Extender

If the vehicle's seat belt will fasten around you, you should use it.

But if a seat belt is not long enough, your dealer will order you an extender. When you go in to order it, take the heaviest coat you will wear, so the extender will be long enough for you. To help avoid personal injury, do not let someone else use it, and use it only for the seat it is made to fit. The extender has been designed for adults. Never use it for securing child restraints. For more

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

76 Seats and Restraints

information on the proper use and fit of seat belt extenders see the instruction sheet that comes with the extender.

Safety System Check

Periodically check the seat belt reminder, seat belts, buckles, latch plates, retractors, shoulder belt height adjusters (if equipped), and seat belt anchorages to make sure they are all in working order. Look for any other loose or damaged seat belt system parts that might keep a seat belt system from performing properly. See your dealer to have it repaired. Torn, frayed, or twisted seat belts may not protect you in a crash. Torn or frayed seat belts can rip apart under impact forces. If a belt is torn or frayed, have it replaced immediately. If a belt is twisted, it may be possible to untwist by reversing the latch plate on the webbing. If the twist cannot be corrected, ask your dealer to fix it.

Make sure the seat belt reminder light is working. See Seat Belt Reminders 0 130.

Keep seat belts clean and dry. See Seat Belt Care 0 76.

Seat Belt Care

Keep belts clean and dry.

Seat belts should be properly cared for and maintained.

Seat belt hardware should be kept dry and free of dust or debris. As necessary, exterior hard surfaces and seat belt webbing may be lightly cleaned with mild soap and water. Ensure there is not excessive dust or debris in the mechanism. If dust or debris exists in the system please see the dealer. Parts may need to be replaced to ensure proper functionality of the system.

Warning

{

Do not bleach or dye seat belt webbing. It may severely weaken the webbing. In a crash, they might not be able to provide adequate protection. Clean and rinse seat belt webbing only with mild soap and lukewarm water. Allow the webbing to dry.

Replacing Seat Belt System Parts after a Crash

Warning

{

A crash can damage the seat belt system in the vehicle. A damaged seat belt system may not properly protect the person using it, resulting in serious injury or even death in a crash. To help make sure the seat belt systems are working properly after a crash,

(Continued)

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Warning (Continued)

have them inspected and any necessary replacements made as soon as possible.

After a minor crash, replacement of seat belts may not be necessary. But the seat belt assemblies that were used during any crash may have been stressed or damaged. See your dealer to have the seat belt assemblies inspected or replaced.

New parts and repairs may be necessary even if the seat belt system was not being used at the time of the crash.

Have the seat belt pretensioners checked if the vehicle has been in a crash, or if the airbag readiness light stays on after you start the vehicle or while you are driving. See Airbag Readiness Light 0 130.

Airbag System

The vehicle has the following airbags:

A frontal airbag for the driver

A frontal airbag for the front outboard passenger

A seat-mounted side impact airbag for the driver

A seat-mounted side impact airbag for the front outboard passenger

A roof-rail airbag for the driver and the passenger seated directly behind the driver

A roof-rail airbag for the front outboard passenger and the passenger seated directly behind the front outboard passenger

All vehicle airbags have the word AIRBAG on the trim or on a label near the deployment opening.

Seats and Restraints 77

For frontal airbags, the word AIRBAG is on the center of the steering wheel for the driver and on the instrument panel for the front outboard passenger.

For seat-mounted side impact airbags, the word AIRBAG is on the side of the seat closest to the door.

For roof-rail airbags, the word AIRBAG is on the ceiling or trim.

Airbags are designed to supplement the protection provided by seat belts. Even though today's airbags are also designed to help reduce the risk of injury from the force of an inflating bag, all airbags must inflate very quickly to do their job.

Here are the most important things to know about the airbag system:

Warning

{

You can be severely injured or killed in a crash if you are not wearing your seat belt, even with airbags. Airbags are designed to

(Continued)

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

78 Seats and Restraints

Warning (Continued)

work with seat belts, not replace them. Also, airbags are not designed to inflate in every crash. In some crashes seat belts are the only restraint. See When Should an Airbag Inflate? 0 80.

Wearing your seat belt during a crash helps reduce your chance of hitting things inside the vehicle or being ejected from it. Airbags are “supplemental restraints” to the seat belts. Everyone in the vehicle should wear a seat belt properly, whether or not there is an airbag for that person.

Warning

{

Because airbags inflate with great force and faster than the blink of an eye, anyone who is up against, or very close to, any airbag when it inflates can be

(Continued)

Warning (Continued)

seriously injured or killed. Do not sit unnecessarily close to any airbag, as you would be if sitting on the edge of the seat or leaning forward. Seat belts help keep you in position before and during a crash. Always wear a seat belt, even with airbags. The driver should sit as far back as possible while still maintaining control of the vehicle. The seat belts and the front outboard passenger airbags are most effective when you are sitting well back and upright in the seat with both feet on the floor.

Occupants should not lean on or sleep against the door or side windows in seating positions with seat-mounted side impact airbags and/or roof-rail airbags.

Warning

{

Children who are up against, or very close to, any airbag when it inflates can be seriously injured or killed. Always secure children properly in the vehicle. To read how, see Older Children 0 89 or Infants and Young Children 0 91.

There is an airbag readiness light on the instrument cluster, which shows the airbag symbol.

The system checks the airbag electrical system for malfunctions. The light tells you if there is an electrical problem. See Airbag Readiness Light 0 130.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Where Are the Airbags?

Seats and Restraints 79

The front outboard passenger frontal airbag is in the passenger

The driver frontal airbag is in the center of the steering wheel.

side instrument panel.

Driver Side Shown, Passenger

Side Similar

The driver and front outboard passenger seat-mounted side impact airbags are in the side of the seatbacks closest to the door.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

80 Seats and Restraints

Warning (Continued)

or even death. The path of an inflating airbag must be kept clear. Do not put anything between an occupant and an airbag, and do not attach or put anything on the steering wheel hub or on or near any other airbag covering.

Driver Side Shown, Passenger

Side Similar

The roof-rail airbags for the driver, front outboard passenger, and second row outboard passengers are in the ceiling above the side windows.

Warning

{

If something is between an occupant and an airbag, the airbag might not inflate properly or it might force the object into that person causing severe injury

(Continued)

Do not use seat accessories that block the inflation path of a seat-mounted side impact airbag.

Never secure anything to the roof of a vehicle with roof-rail airbags by routing a rope or tie‐down through any door or window opening. If you do, the path of an inflating roof-rail airbag will be blocked.

When Should an Airbag Inflate?

This vehicle is equipped with airbags. See Airbag System 0 77. Airbags are designed to inflate if the

impact exceeds the specific airbag system's deployment threshold. Deployment thresholds are used to predict how severe a crash is likely to be in time for the airbags to inflate and help restrain the occupants. The vehicle has electronic sensors that help the airbag system determine the severity of the impact. Deployment thresholds can vary with specific vehicle design.

Frontal airbags are designed to inflate in moderate to severe frontal or near frontal crashes to help reduce the potential for severe injuries, mainly to the driver's or front outboard passenger's head and chest.

Whether the frontal airbags will or should inflate is not based primarily on how fast the vehicle is traveling. It depends on what is hit, the direction of the impact, and how quickly the vehicle slows down.

Frontal airbags may inflate at different crash speeds depending on whether the vehicle hits an object straight on or at an angle, and

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

whether the object is fixed or moving, rigid or deformable, narrow or wide.

Frontal airbags are not intended to inflate during vehicle rollovers, rear impacts, or many side impacts.

In addition, the vehicle has advanced technology frontal airbags. Advanced technology frontal airbags adjust the restraint according to crash severity.

Seat-mounted side impact airbags are designed to inflate in moderate to severe side crashes depending on the location of the impact. Seat-mounted side impact airbags are not designed to inflate in frontal impacts, near frontal impacts, rollovers, or rear impacts. A seat-mounted side impact airbag is designed to inflate on the side of the vehicle that is struck.

Roof-rail airbags are designed to inflate in moderate to severe side crashes depending on the location of the impact. In addition, these roof-rail airbags are designed to inflate during a rollover or in a

severe frontal impact. Roof-rail airbags are not designed to inflate in rear impacts. Both roof-rail airbags will inflate when either side of the vehicle is struck or if the sensing system predicts that the vehicle is about to roll over on its side, or in a severe frontal impact.

In any particular crash, no one can say whether an airbag should have inflated simply because of the vehicle damage or repair costs.

What Makes an Airbag Inflate?

In a deployment event, the sensing system sends an electrical signal triggering a release of gas from the inflator. Gas from the inflator fills the airbag causing the bag to break out of the cover. The inflator, the airbag, and related hardware are all part of the airbag module.

For airbag locations, see Where Are the Airbags? 0 79.

Seats and Restraints 81

How Does an Airbag Restrain?

In moderate to severe frontal or near frontal collisions, even belted occupants can contact the steering wheel or the instrument panel. In moderate to severe side collisions, even belted occupants can contact the inside of the vehicle.

Airbags supplement the protection provided by seat belts by distributing the force of the impact more evenly over the occupant's body.

Rollover capable roof-rail airbags are designed to help contain the head and chest of occupants in the outboard seating positions in the first and second rows. The rollover capable roof-rail airbags are designed to help reduce the risk of full or partial ejection in rollover events, although no system can prevent all such ejections.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

82 Seats and Restraints

But airbags would not help in many types of collisions, primarily because the occupant's motion is not toward those airbags. See When Should an Airbag Inflate? 0 80.

Airbags should never be regarded as anything more than a supplement to seat belts.

What Will You See after an Airbag Inflates?

After frontal and seat-mounted side impact airbags inflate, they quickly deflate, so quickly that some people may not even realize the airbags inflated. Roof-rail airbags may still be at least partially inflated for some time after they inflate. Some components of the airbag module may be hot for several minutes. For location of the airbags, see Where Are the Airbags? 0 79.

The parts of the airbag that come into contact with you may be warm, but not too hot to touch. There may be some smoke and dust coming from the vents in the deflated airbags. Airbag inflation does not

prevent the driver from seeing out of the windshield or being able to steer the vehicle, nor does it prevent people from leaving the vehicle.

Warning

{

When an airbag inflates, there may be dust in the air. This dust could cause breathing problems for people with a history of asthma or other breathing trouble. To avoid this, everyone in the vehicle should get out as soon as it is safe to do so. If you have breathing problems but cannot get out of the vehicle after an airbag inflates, then get fresh air by opening a window or a door. If you experience breathing problems following an airbag deployment, you should seek medical attention.

The vehicle has a feature that may automatically unlock the doors, turn on the interior lamps and hazard warning flashers, and shut off the fuel system after the airbags inflate.

The feature may also activate, without airbag inflation, after an event that exceeds a predetermined threshold. After turning the ignition off and then on again, the fuel system will return to normal operation; the doors can be locked, the interior lamps can be turned off, and the hazard warning flashers can be turned off using the controls for those features. If any of these systems are damaged in the crash they may not operate as normal.

Warning

{

A crash severe enough to inflate the airbags may have also damaged important functions in the vehicle, such as the fuel system, brake and steering systems, etc. Even if the vehicle appears to be drivable after a moderate crash, there may be concealed damage that could make it difficult to safely operate the vehicle.

(Continued)

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Warning (Continued)

Use caution if you should attempt to restart the engine after a crash has occurred.

In many crashes severe enough to inflate the airbag, windshields are broken by vehicle deformation. Additional windshield breakage may also occur from the front outboard passenger airbag.

Airbags are designed to inflate only once. After an airbag inflates, you will need some new parts for the airbag system. If you do not get them, the airbag system will not be there to help protect you in another crash. A new system will include airbag modules and possibly other parts. The service manual for the vehicle covers the need to replace other parts.

The vehicle has a crash sensing and diagnostic module which records information after a crash.

See Vehicle Data Recording and

Privacy 0 398 and Event Data Recorders 0 398.

Let only qualified technicians work on the airbag systems. Improper service can mean that an airbag system will not work properly. See your dealer for service.

Passenger Sensing System

The vehicle has a passenger sensing system for the front outboard passenger position. The passenger airbag status indicator will light on the overhead console when the vehicle is started.

The words ON and OFF will be visible during the system check. When the system check is

Seats and Restraints 83

complete, either the word ON or OFF will be visible. See Passenger Airbag Status Indicator 0 131.

The passenger sensing system turns off the front outboard passenger frontal airbag under certain conditions. No other airbag is affected by the passenger sensing system.

The passenger sensing system works with sensors that are part of the front outboard passenger seat and seat belt. The sensors are designed to detect the presence of a properly seated occupant and determine if the front outboard passenger frontal airbag should be allowed to inflate or not.

According to accident statistics, children are safer when properly secured in a rear seat in the correct child restraint for their weight and size.

Whenever possible, children aged 12 and under should be secured in a rear seating position.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

84 Seats and Restraints

Never put a rear-facing child seat in the front. This is because the risk to the rear-facing child is so great, if the airbag inflates.

Warning

{

A child in a rear-facing child restraint can be seriously injured or killed if the passenger frontal airbag inflates. This is because the back of the rear-facing child restraint would be very close to the inflating airbag. A child in a forward-facing child restraint can be seriously injured or killed if the passenger frontal airbag inflates and the passenger seat is in a forward position.

Even if the passenger sensing system has turned off the passenger frontal airbag, no system is fail-safe. No one can guarantee that an airbag will not deploy under some unusual circumstance, even though the airbag is turned off.

(Continued)

Warning (Continued)

Never put a rear-facing child restraint in the front seat, even if the airbag is off. If securing a forward-facing child restraint in the front outboard passenger seat, always move the seat as far back as it will go. It is better to secure child restraints in the rear seat. Consider using another vehicle to transport the child when a rear seat is not available.

The passenger sensing system is designed to turn off the front outboard passenger frontal airbag if:

The front outboard passenger seat is unoccupied.

The system determines an infant is present in a child restraint.

A front outboard passenger takes his/her weight off of the seat for a period of time.

There is a critical problem with the airbag system or the passenger sensing system.

When the passenger sensing system has turned off the front outboard passenger frontal airbag, the OFF indicator will light and stay lit as a reminder that the airbag is off. See Passenger Airbag Status Indicator 0 131.

The passenger sensing system is designed to turn on the front outboard passenger frontal airbag anytime the system senses that a person of adult size is sitting properly in the front outboard passenger seat.

When the passenger sensing system has allowed the airbag to be enabled, the ON indicator will light and stay lit as a reminder that the airbag is active.

For some children, including children in child restraints, and for very small adults, the passenger sensing system may or may not turn off the front outboard passenger frontal airbag, depending upon the person's seating posture and body build. Everyone in the vehicle who has outgrown child restraints should

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

wear a seat belt properly — whether or not there is an airbag for that person.

Warning

{

If the airbag readiness light ever comes on and stays on, it means that something may be wrong with the airbag system. To help avoid injury to yourself or others, have the vehicle serviced right away. See Airbag Readiness Light 0 130 for more information, including important safety information.

If the On Indicator Is Lit for a Child Restraint

The passenger sensing system is designed to turn off the front outboard passenger frontal airbag if the system determines that an infant is present in a child restraint. If a child restraint has been installed and the ON indicator is lit:

1. Turn the vehicle off.

2. Remove the child restraint from the vehicle.

3. Remove any additional items from the seat such as blankets, cushions, seat covers, seat heaters, or seat massagers.

4. Reinstall the child restraint following the directions provided by the child restraint manufacturer and refer to

Securing Child Restraints (With the Seat Belt in the Rear Seat) 0 102 or Securing Child Restraints (With the Seat Belt in the Front Seat) 0 104.

Make sure the seat belt retractor is locked by pulling the shoulder belt all the way out of the retractor when installing the child restraint, even if the child restraint is equipped with a seat belt lock off. When the retractor lock is set, the belt can be tightened but not pulled out of the retractor.

Seats and Restraints 85

5. If, after reinstalling the child restraint and restarting the vehicle, the ON indicator is still lit, turn the vehicle off. Then slightly recline the vehicle seatback and adjust the seat cushion, if adjustable, to make sure that the vehicle seatback is not pushing the child restraint into the seat cushion.

Also make sure the child restraint is not trapped under the vehicle head restraint. If this happens, adjust the head restraint. See Head Restraints 0 57.

6. Restart the vehicle.

The passenger sensing system may or may not turn off the airbag for a child in a child restraint depending upon the child’s size. It is better to secure the child restraint in a rear seat. Never put a rear-facing child restraint in the front seat, even if the ON indicator is not lit.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

86 Seats and Restraints

If the Off Indicator Is Lit for an Adult-Sized Occupant

If a person of adult size is sitting in the front outboard passenger seat, but the OFF indicator is lit, it could be because that person is not sitting properly in the seat or that the child restraint locking feature is engaged. Use the following steps to allow the system to detect that person and enable the front outboard passenger frontal airbag:

1. Turn the vehicle off.

2. Remove any additional material from the seat, such as blankets, cushions, seat covers, seat heaters, or seat massagers.

3. Place the seatback in the fully upright position.

4. Have the person sit upright in the seat, centered on the seat cushion, with legs comfortably extended.

5. If the shoulder portion of the belt is pulled out all the way, the child restraint locking feature will be engaged. This may unintentionally cause the passenger sensing system to turn the airbag off for some adult-sized occupants. If this happens, unbuckle the belt, let the belt go back all the way, and then buckle the belt again without pulling the belt out all the way.

6. Restart the vehicle and have the person remain in this position for two to three minutes after the ON indicator is lit.

Warning

{

If the front outboard passenger airbag is turned off for an adult-sized occupant, the airbag will not be able to inflate and help protect that person in a crash, resulting in an increased risk of serious injury or even death. An adult-sized occupant should not ride in the front outboard passenger seat, if the passenger airbag OFF indicator is lit.

Additional Factors Affecting System Operation

Seat belts help keep the passenger in position on the seat during vehicle maneuvers and braking, which helps the passenger sensing system maintain the passenger airbag status. See “Seat Belts” and “Child Restraints” in the Index for additional information about the importance of proper restraint use.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

A thick layer of additional material, such as a blanket or cushion, or aftermarket equipment such as seat covers, seat heaters, and seat massagers can affect how well the passenger sensing system operates. We recommend that you not use seat covers or other aftermarket equipment except when approved by GM for your specific vehicle. See Adding Equipment to

the Airbag-Equipped Vehicle 0 87

for more information about modifications that can affect how the system operates.

The ON indicator may be lit if an object, such as a briefcase, handbag, grocery bag, laptop, or other electronic device, is put on an unoccupied seat. If this is not desired, remove the object from the seat.

Warning

{

Stowing articles under the passenger seat or between the passenger seat cushion and

(Continued)

Warning (Continued)

seatback may interfere with the proper operation of the passenger sensing system.

Servicing the Airbag-Equipped Vehicle

Airbags affect how the vehicle should be serviced. There are parts of the airbag system in several places around the vehicle. Your dealer and the service manual have information about servicing the vehicle and the airbag system. To purchase a service manual, see

Publication Ordering Information 0 395.

{

For up to 10 seconds after the vehicle is turned off and the battery is disconnected, an airbag can still inflate during improper service. You can be injured if you

Warning

(Continued)

Seats and Restraints 87

Warning (Continued)

are close to an airbag when it inflates. Avoid yellow connectors. They are probably part of the airbag system. Be sure to follow proper service procedures, and make sure the person performing work for you is qualified to do so.

Adding Equipment to the Airbag-Equipped Vehicle

Adding accessories that change the vehicle's frame, bumper system, height, front end, or side sheet metal may keep the airbag system from working properly.

The operation of the airbag system can also be affected by changing, including improperly repairing or replacing, any parts of the following:

Airbag system, including airbag modules, front or side impact sensors, sensing and diagnostic module, or airbag wiring

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

88 Seats and Restraints

Front seats, including stitching, seams or zippers

Seat belts

Steering wheel, instrument panel, overhead console, ceiling trim, or pillar garnish trim

Inner door seals, including speakers

Your dealer and the service manual have information about the location of the airbag modules and sensors, sensing and diagnostic module, and airbag wiring along with the proper replacement procedures.

In addition, the vehicle has a passenger sensing system for the front outboard passenger position, which includes sensors that are part of the passenger seat. The passenger sensing system may not operate properly if the original seat trim is replaced with non-GM covers, upholstery, or trim; or with GM covers, upholstery, or trim designed for a different vehicle. Any object, such as an aftermarket seat heater or a comfort-enhancing pad or device, installed under or on top

of the seat fabric, could also interfere with the operation of the passenger sensing system. This could either prevent proper deployment of the passenger airbag(s) or prevent the passenger sensing system from properly turning off the passenger airbag(s). See Passenger Sensing System 0 83.

If the vehicle has rollover roof-rail airbags, see Different Size Tires and Wheels 0 332 for additional important information.

If the vehicle must be modified because you have a disability and have questions about whether the modifications will affect the vehicle's airbag system, or if you have questions about whether the airbag system will be affected if the vehicle is modified for any other reason, call Customer Assistance. See Customer Assistance Offices 0 388.

Airbag System Check

The airbag system does not need regularly scheduled maintenance or replacement. Make sure the airbag readiness light is working. See Airbag Readiness Light 0 130.

Caution

If an airbag covering is damaged, opened, or broken, the airbag may not work properly. Do not open or break the airbag coverings. If there are any opened or broken airbag coverings, have the airbag covering and/or airbag module replaced. For the location of the airbags, see Where Are the Airbags? 0 79. See your dealer for service.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Replacing Airbag System

Child Restraints

Parts after a Crash

Older Children

Warning

{

A crash can damage the airbag systems in the vehicle. A damaged airbag system may not properly protect you and your passenger(s) in a crash, resulting in serious injury or even death. To help make sure the airbag systems are working properly after a crash, have them inspected and any necessary replacements made as soon as possible.

If an airbag inflates, you will need to replace airbag system parts. See your dealer for service.

If the airbag readiness light stays on after the vehicle is started or comes on when you are driving, the airbag system may not work properly. Have the vehicle serviced right away. See Airbag Readiness Light 0 130.

Older children who have outgrown booster seats should wear the vehicle’s seat belts.

Seats and Restraints 89

The manufacturer instructions that come with the booster seat state the weight and height limitations for that booster. Use a booster seat with a lap-shoulder belt until the child passes the fit test below:

Sit all the way back on the seat. Do the knees bend at the seat edge? If yes, continue. If no, return to the booster seat.

Buckle the lap-shoulder belt. Does the shoulder belt rest on the shoulder? If yes, continue. If no, try using the rear seat belt comfort guide, if available. See “Rear Seat Belt Comfort Guides” under Lap-Shoulder Belt 0 72. If a comfort guide is not available, or if the shoulder belt still does not rest on the shoulder, then return to the booster seat.

Does the lap belt fit low and snug on the hips, touching the thighs? If yes, continue. If no, return to the booster seat.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

90 Seats and Restraints

Can proper seat belt fit be maintained for the length of the trip? If yes, continue. If no, return to the booster seat.

Q: What is the proper way to

wear seat belts?

A: An older child should wear a

lap-shoulder belt and get the additional restraint a shoulder belt can provide. The shoulder belt should not cross the face or neck. The lap belt should fit snugly below the hips, just touching the top of the thighs. This applies belt force to the child's pelvic bones in a crash. It should never be worn over the abdomen, which could cause severe or even fatal internal injuries in a crash.

Also see “Rear Seat Belt Comfort Guides” under Lap-Shoulder Belt 0 72.

According to accident statistics, children are safer when properly restrained in a rear seating position.

In a crash, children who are not buckled up can strike other people who are buckled up, or can be thrown out of the vehicle. Older children need to use seat belts properly.

Warning

{

Never allow more than one child to wear the same seat belt. The seat belt cannot properly spread the impact forces. In a crash, they can be crushed together and seriously injured. A seat belt must be used by only one person at a time.

Warning

{

Never allow a child to wear the seat belt with the shoulder belt behind their back. A child can be seriously injured by not wearing the lap-shoulder belt properly. In a crash, the child would not be restrained by the shoulder belt. The child could move too far forward increasing the chance of head and neck injury. The child might also slide under the lap belt. The belt force would then be applied right on the abdomen.

(Continued)

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Warning (Continued)

That could cause serious or fatal injuries. The shoulder belt should go over the shoulder and across the chest.

need, for everyone, to use safety restraints. In fact, the law in every state in the United States and in every Canadian province says children up to some age must be restrained while in a vehicle.

{

Children can be seriously injured or strangled if a shoulder belt is wrapped around their neck. The shoulder belt can tighten but cannot be loosened if it is locked. The shoulder belt locks when it is pulled all the way out of the retractor. It unlocks when the shoulder belt is allowed to go all the way back into the retractor, but it cannot do this if it is wrapped around a child’s neck.

Infants and Young Children

Everyone in a vehicle needs protection! This includes infants and all other children. Neither the distance traveled nor the age and size of the traveler changes the

If the shoulder belt is locked and tightened around a child’s neck, the only way to loosen the belt is to cut it.

Warning

(Continued)

Seats and Restraints 91

Warning (Continued)

Never leave children unattended in a vehicle and never allow children to play with the seat belts.

Every time infants and young children ride in vehicles, they should have the protection provided by appropriate child restraints. Neither the vehicle's seat belt system nor its airbag system is designed for them.

Children who are not restrained properly can strike other people, or can be thrown out of the vehicle.

Warning

{

Never hold an infant or a child while riding in a vehicle. Due to crash forces, an infant or a child will become so heavy it is not possible to hold it during a crash. For example, in a crash at only 40 km/h (25 mph), a 5.5 kg (12 lb)

(Continued)

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

92 Seats and Restraints

Warning (Continued)

infant will suddenly become a 110 kg (240 lb) force on a person's arms. An infant or child should be secured in an appropriate restraint.

Warning

{

Children who are up against, or very close to, any airbag when it inflates can be seriously injured

(Continued)

Warning (Continued)

or killed. Never put a rear-facing child restraint in the front outboard seat. Secure a rear-facing child restraint in a rear seat. It is also better to secure a forward-facing child restraint in a rear seat. If you must secure a forward-facing child restraint in the front outboard seat, always move the front passenger seat as far back as it will go.

Child restraints are devices used to restrain, seat, or position children in the vehicle and are sometimes called child seats or car seats.

There are three basic types of child restraints:

Forward-facing child restraints

Rear-facing child restraints

Belt-positioning booster seats

The proper child restraint for your child depends on their size, weight, and age, and also on whether the child restraint is compatible with the vehicle in which it will be used.

For each type of child restraint, there are many different models available. When purchasing a child restraint, be sure it is designed to be used in a motor vehicle. If it is, the restraint will have a label saying that it meets federal motor vehicle safety standards. The restraint manufacturer's instructions that come with the restraint state the weight and height limitations for a particular child restraint. In addition,

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

there are many kinds of restraints available for children with special needs.

Warning

{

To reduce the risk of neck and head injury in a crash, infants and toddlers should be secured in a rear-facing child restraint until age two, or until they reach the maximum height and weight limits of their child restraint.

Warning

{

A young child's hip bones are still so small that the vehicle's regular seat belt may not remain low on the hip bones, as it should. Instead, it may settle up around the child's abdomen. In a crash, the belt would apply force on a body area that is unprotected by any bony structure. This alone could cause serious or fatal

(Continued)

Warning (Continued)

injuries. To reduce the risk of serious or fatal injuries during a crash, young children should always be secured in appropriate child restraints.

Child Restraint Systems

Rear-Facing Infant Restraint

A rear-facing child restraint provides restraint with the seating surface against the back of the infant.

Seats and Restraints 93

The harness system holds the infant in place and, in a crash, acts to keep the infant positioned in the restraint.

Forward-Facing Child Restraint

A forward-facing child restraint provides restraint for the child's body with the harness.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

94 Seats and Restraints

Securing an Add-On Child Restraint in the Vehicle

Warning

{

A child can be seriously injured or killed in a crash if the child restraint is not properly secured in the vehicle. Secure the child restraint properly in the vehicle using the vehicle’s seat belt or

Booster Seats

A belt-positioning booster seat is used for children who have outgrown their forward-facing child restraint. Boosters are designed to improve the fit of the vehicle's seat belt system until the child is large enough for the vehicle seat belts to fit properly without a booster seat. See the seat belt fit test in Older Children 0 89.

LATCH system, following the instructions that came with that child restraint and the instructions in this manual.

To help reduce the chance of injury, the child restraint must be secured in the vehicle. Child restraints must be secured in vehicle seats by lap belts or the lap belt portion of a lap-shoulder belt, or by the LATCH system. See Lower Anchors and

Tethers for Children (LATCH System) 0 96 for more information.

Children can be endangered in a crash if the child restraint is not properly secured in the vehicle.

When securing an add-on child restraint, refer to the instructions that come with the restraint which may be on the restraint itself or in a booklet, or both, and to this manual. The child restraint instructions are important, so if they are not available, obtain a replacement copy from the manufacturer.

Keep in mind that an unsecured child restraint can move around in a collision or sudden stop and injure people in the vehicle. Be sure to properly secure any child restraint in the vehicle — even when no child is in it.

In some areas of the United States and Canada, Certified Child Passenger Safety Technicians (CPSTs) are available to inspect and demonstrate how to correctly use and install child restraints. In the U.S., refer to the National Highway Traffic Safety Administration (NHTSA) website to locate the nearest child safety seat inspection station. For CPST

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

availability in Canada, check with Transport Canada or the Provincial Ministry of Transportation office.

Securing the Child Within the Child Restraint

Warning

{

A child can be seriously injured or killed in a crash if the child is not properly secured in the child restraint. Secure the child properly following the instructions that came with that child restraint.

Where to Put the Restraint

According to accident statistics, children and infants are safer when properly restrained in an appropriate child restraint secured in a rear seating position.

Whenever possible, children aged 12 and under should be secured in a rear seating position.

Never put a rear-facing child restraint in the front. This is because the risk to the rear-facing child is so great if the airbag deploys.

{

A child in a rear-facing child restraint can be seriously injured or killed if the front passenger airbag inflates. This is because the back of the rear-facing child restraint would be very close to the inflating airbag. A child in a forward-facing child restraint can be seriously injured or killed if the front passenger airbag inflates and the passenger seat is in a forward position.

Even if the passenger sensing system has turned off the front passenger frontal airbag, no system is fail-safe. No one can guarantee that an airbag will not deploy under some unusual circumstance, even though it is turned off.

Warning

(Continued)

Seats and Restraints 95

Warning (Continued)

Secure rear-facing child restraints in a rear seat, even if the airbag is off. If you secure a forward-facing child restraint in the front seat, always move the front passenger seat as far back as it will go. It is better to secure the child restraint in a rear seat.

See Passenger Sensing System 0 83 for additional information.

When securing a child restraint with the seat belts in a rear seat position, study the instructions that came with the child restraint to make sure it is compatible with this vehicle.

Child restraints and booster seats vary considerably in size, and some may fit in certain seating positions better than others.

Depending on where you place the child restraint and the size of the child restraint, you may not be able to access adjacent seat belts or LATCH anchors for additional

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

96 Seats and Restraints

passengers or child restraints. Adjacent seating positions should not be used if the child restraint prevents access to or interferes with the routing of the seat belt.

Wherever a child restraint is installed, be sure to follow the instructions that came with the child restraint and secure the child restraint properly.

Lower Anchors and Tethers for Children (LATCH System)

The LATCH system secures a child restraint during driving or in a crash. LATCH attachments on the child restraint are used to attach the child restraint to the anchors in the

vehicle. The LATCH system is designed to make installation of a child restraint easier.

In order to use the LATCH system in your vehicle, you need a child restraint that has LATCH attachments. LATCH-compatible rear-facing and forward-facing child seats can be properly installed using either the LATCH anchors or the vehicle’s seat belts. Do not use both the seat belts and the LATCH anchorage system to secure a rear-facing or forward-facing child seat.

Booster seats use the vehicle’s seat belts to secure the child in the booster seat. If the manufacturer recommends that the booster seat be secured with the LATCH system, this can be done as long as the booster seat can be positioned properly and there is no interference with the proper positioning of the lap-shoulder belt on the child.

Make sure to follow the instructions that came with the child restraint, and also the instructions in this manual.

When installing a child restraint with a top tether, you must also use either the lower anchors or the seat belts to properly secure the child restraint. A child restraint must never be attached using only the top tether.

The LATCH anchorage system can be used until the combined weight of the child plus the child restraint is

29.5 kg (65 lbs). Use the seat belt alone instead of the LATCH anchorage system once the combined weight is more than

29.5 kg (65 lbs).

See Securing Child Restraints (With

the Seat Belt in the Rear Seat) 0 102 or Securing Child Restraints (With the Seat Belt in the Front Seat) 0 104.

Child restraints built after March 2014 will be labeled with the specific child weight up to which the LATCH system can be used to install the restraint.

The following explains how to attach a child restraint with these attachments in the vehicle.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

Not all vehicle seating positions or child restraints have lower anchors and attachments or top tether anchors and attachments. In this case, the seat belt must be used (with top tether where available) to secure the child restraint. See Securing Child Restraints (With

the Seat Belt in the Rear Seat) 0 102 or Securing Child Restraints (With the Seat Belt in the Front Seat) 0 104.

seating position that will accommodate a child restraint with lower attachments (2).

Top Tether Anchor

Lower Anchors

A top tether (3, 4) is used to secure the top of the child restraint to the vehicle. A top tether anchor is built into the vehicle. The top tether attachment hook (2) on the child restraint connects to the top tether anchor in the vehicle in order to reduce the forward movement and

rotation of the child restraint during Lower anchors (1) are metal bars built into the vehicle. There are two lower anchors for each LATCH

driving or in a crash.

Seats and Restraints 97

The child restraint may have a single tether (3) or a dual tether (4). Either will have a single attachment hook (2) to secure the top tether to the anchor.

Some child restraints that have a top tether are designed for use with or without the top tether being attached. Others require the top tether always to be attached. In Canada, the law requires that forward-facing child restraints have a top tether, and that the tether be attached. Be sure to read and follow the instructions for your child restraint.

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

98 Seats and Restraints

Lower Anchor and Top Tether Anchor Locations

To assist in locating the lower anchors, each second row anchor position has a label, near the crease between the seatback and the seat cushion.

To assist in locating the top tether anchors, the top tether anchor

Rear Seat

symbol is near the top tether anchors.

I : Seating positions with top

tether anchors.

H : Seating positions with two

lower anchors.

Top Tether Anchors

The top tether anchors for each rear seating position are on the back of the rear seatback. The rear compartment storage panel/cover might need to be adjusted to access the anchors. Be sure to use an anchor on the same side of the vehicle as the seating position where the child restraint will be placed.

Do not secure a child restraint in a position without a top tether anchor if a national or local law requires that the top tether be attached, or if

Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12145779) - 2019 - crc - 3/29/18

the instructions that come with the child restraint say that the top tether must be attached.

According to accident statistics, children and infants are safer when properly restrained in a child restraint system or infant restraint system secured in a rear seating position. See Where to Put the Restraint 0 95 for additional information.

Securing a Child Restraint

To reduce the risk of serious or fatal injuries during a crash, do not attach more than one child restraint to a single anchor. Attaching more than one child restraint to a single anchor could cause the anchor or attachment to come loose or even break during a crash. A child or others could be injured.

{

Designed for the LATCH System

Warning

{

A child could be seriously injured or killed in a crash if the child restraint is not properly attached to the vehicle using either the LATCH anchors or the vehicle seat belt. Follow the instructions that came with the child restraint and the instructions in this manual.

{

Warning

(Continued)

Seats and Restraints 99

Warning (Continued)

but it cannot do this if it is wrapped around a child’s neck. If the shoulder belt is locked and tightened around a child’s neck, the only way to loosen the belt is to cut it.

Buckle any unused seat belts behind the child restraint so children cannot reach them. Pull the shoulder belt all the way out of the retractor to set the lock, and tighten the belt behind the child restraint after the child restraint has been installed.

Caution

Do not let the LATCH attachments rub against the vehicle’s seat belts. This may damage these parts. If necessary, move buckled seat belts to avoid rubbing the LATCH attachments.

(Continued)

Chevrolet Equinox 2019 Owner's Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Introduction

Canadian Vehicle Owners

Using this Manual

About Driving the Vehicle

Danger, Warning, and Caution

Symbols

In Brief

Instrument Panel

Initial Drive Information

Stop/Start System

Remote Keyless Entry (RKE) System

Remote Vehicle Start

Door Locks

Liftgate

Windows

Seat Adjustment

Memory Features

Heated and Ventilated Seats

Head Restraint Adjustment

Seat Belts

Passenger Sensing System

Mirror Adjustment

Steering Wheel Adjustment

Interior Lighting

Exterior Lighting

Windshield Wiper/Washer

Climate Controls

Transmission

Vehicle Features

Cruise Control

Infotainment System

Steering Wheel Controls

Driver Information Center (DIC)

Forward Collision Alert (FCA) System

Forward Automatic Braking (FAB)

Front Pedestrian Braking (FPB) System

Lane Keep Assist (LKA)

Lane Change Alert (LCA)

Surround Vision

Rear Vision Camera (RVC)

Rear Cross Traffic Alert (RCTA) System

Park Assist

Power Outlets

Universal Remote System

Sunroof

Performance and Maintenance

Traction Control/ Electronic Stability Control

Tire Pressure Monitor

Fuel (LYX - 1.5L L4 Turbo Engine)

Fuel (LTG - 2.0L L4 Turbo Engine)

Fuel (Diesel)

E85 or FlexFuel

Engine Oil Life System

Driving for Better Fuel Economy

Diesel Particulate Filter

Diesel Exhaust Fluid

Roadside Assistance Program

Keys, Doors, and Windows

Keys and Locks

Keys

Remote Keyless Entry (RKE) System

Remote Keyless Entry (RKE) System Operation

Remote Vehicle Start

Door Locks

Power Door Locks

Delayed Locking

Automatic Door Locks

Lockout Protection

Safety Locks

Doors

Liftgate

Vehicle Security

Vehicle Alarm System

Immobilizer

Immobilizer Operation

Exterior Mirrors
