Canon LBP-1210 User Manual
Laser Beam Printer
User's Guide
LBP-1210 Laser Printer
User’s Guide
IMPORTANT:
Read this manual carefully.
Use this manual when you need quick reference help.
Copyright
Copyright ©2002 Canon Inc.
All information in this manual is copyrighted. No part of this publication
may be reproduced, transmitted, transcribed, stored in a retrieval system,
or translated into any language or computer language, in any form or by
any means, electronic, mechanical, magnetic, optical, chemical, manual,
or otherwise, without prior written consent from Canon.
Notice
Canon makes no guarantees of any kind with regard to this manual.
Canon is not liable for errors contained herein or for consequential or
incidental damages incurred as a result of acting on information
contained in the manual. The information contained herein shall not be
reproduced in whole or in part without prior written consent from Canon.
Trademarks
LBP, Canon, LASER SHOT, and the Canon Logo are trademarks of
Canon Inc.
Microsoft
trademarks or trademarks of Microsoft Corporation in the United States
and/or in other countries.
Other brand and product names are trademarks or registered trademarks
of their respective companies.
In this manual, Microsoft
Windows NT® are referred to as Microsoft, Windows, and Windows NT
respectively.
®
, Windows®, and Windows NT® are either registered
®
, Microsoft® Windows®, and Microsoft®
ii
About this Guide
The following lists the information included in this guide:
❏
Chapter 1: Introduction.
describes the parts.
❏
Chapter 2: Paper Handling.
you can use, how to load paper, and describes how paper moves
through the printer.
❏
Chapter 3: Using the Canon Advanced Printing Technology.
Describes the Canon Advanced Printing Technology and how to install
and use the software, as well as how to check on the status of a print
job.
❏
Chapter 4: Troubleshooting.
solve printing problems.
❏
Chapter 5: Maintenance.
printer, and how to replace the EP-25 cartridge.
❏
Appendix A.
❏
Appendix B.
network adapter.
❏
Glossary.
Introduces you to the printer features and
Explains the types of paper and sizes
Contains helpful information on how to
Explains how to clean and handle the
Lists the specifications for the printer.
Describes how to connect the printer using the optional
Includes definitions for terminology used in this guide.
Conventions
This guide uses the following conventions:
CAUTION:
Indicates precautions that must be observed to prevent possible injury.
Indicates that neglecting the suggested procedure or practice could result
in damage to the printer.
Indicates notes and memos containing useful tips or detailed information.
iii
Safety Information
FCC Notice (110–127 V model)
Laser Beam Printer, Model L10721A
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
❏
Reorient or relocate the receiving antenna.
iv
❏
Increase the separation between the equipment and receiver.
❏
Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
❏
Consult the dealer or an experienced radio/TV technician for help.
Use of shielded cable is required to comply with class B limits in Subpart
B of Part 15 of FCC Rules.
Do not make any changes or modifications to the equipment unless
otherwise specified in the manual. If such changes or modifications
should be made, you could be required to stop operation of the
equipment.
FCC Notice (220–240 V model)
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference, in which case the user will be
required to correct the interference at his own expense.
•Use of shielded cable is required to comply with Class A limits in
Subpart B of Part 15 of FCC Rules.
Do not make any changes or modifications to the equipment unless
otherwise specified in this guide. If such changes or modifications should
be made, you could be required to stop operation of the equipment.
Notice for EMC Directive (220–240 V model)
“This equipment has been tested in a typical system to comply with the
technical requirements of EMC Directive.”
•Use of shielded cable is necessary to comply with the technical
requirements of EMC Directive.
International E
As an E
meets the E
The International E
international program that promotes energy saving through the use of
computers and other office equipment. The program backs the
development and dissemination of products with functions that
effectively reduce energy consumption. It is an open system in which
business proprietors can participate voluntarily. The targeted products are
office equipment such as computers, monitors, printers, fax machines,
and copiers. Their standards and logos are uniform among the
participating nations.
NERGY STAR
NERGY STAR
NERGY STAR
partner, Canon Inc. has determined that this product
NERGY STAR
Office Equipment Program
guidelines for energy efficiency.
Office Equipment Program is an
v
Laser Safety (110–127 V / 220–240 V models)
Laser radiation could be hazardous to the human body. For this reason,
laser radiation emitted inside this printer is hermetically sealed within the
protective housing and external cover. In the normal operation of the
product by the user, no radiation can leak from the machine.
This printer is classified as a Class 1 laser product under EN608251:1994, and in the USA, it is classified as Class 1 under the code of
Federal Regulations, §1040.10 of Title 21.
The label shown below is attached to this printer. This label is attached to
the laser scanner unit inside the printer. (110–127 V / 220–240 V models)
This printer has been classified under EN60825-1:1994 and conforms to
the following classes:
vi
CLASS 1 LASER PRODUCT
LASER KLASSE 1
APPAREIL A RAYONNEMENT LASER DE CLASSE 1
APPARECCHIO LASER DI CLASSE 1
PRODUCTO LASER DE CLASE 1
APARELHO A LASER DE CLASSE 1
(220-240 V model only)
CAUTION:
Performance of procedures other than those specified in this manual may
result in hazardous radiation exposure.
Important Safety Instructions
CAUTION:
This printer is a high-precision electronic device. Before operation, be
sure to read the following instructions to handle the printer properly.
❏
Read the manual carefully before operation.
❏
Do not dispose of these instructions. Save them for future reference.
❏
Follow all warnings and instructions on the printer and consumables.
❏
Do not place the printer on an unstable cart, stand, or table.
❏
When installing the printer, carefully observe the location
requirements described in this guide.
❏
The shaded part of the face-up delivery area may be hot. Be careful
not to touch it.
❏
Do not expose the printer to a wet environment.
❏
Do not expose the printer directly to a chemical environment
(experimental laboratories, etc.). The exterior of the printer is made of
plastic, and the outside covering might fade, become deformed, or
melt.
❏
Do not install the printer where it will be exposed to smoke or steam.
❏
Be sure to connect the printer to a grounded outlet.
❏
Do not operate the printer until all packing materials (packing tape,
spacers, and styrofoam molds) have been removed.
vii
❏
110–127 V model only:
This product is equipped with a 3-wire grounding type plug, a plug
that has a third (grounding) pin. As a safety feature, this plug fits only
into a grounding-type power outlet. If you are unable to insert the plug
into the outlet, contact an electrician to replace your obsolete outlet.
Do not defeat the purpose of the grounding-type plug.
❏
220–240 V model only:
A certified power supply cord is to be used with this equipment. For a
rated current up to 6 A, a type not lighter than H05VV-F 3G 0.75 mm
or H05VVH2-F 3G 0.75 mm2 shall be used.
❏
Be sure to turn off the power before unplugging or plugging in the
printer power cord or interface cable.
❏
When moving the printer, be sure to turn off the power before
unplugging the power cord.
❏
Be sure to unravel the power cord prior to plugging it in; otherwise it
may lead to damage, overheating, short-circuit, or result in fire.
❏
Be sure to plug the power cord firmly into the power outlet, as any
flammable material caught between an opening might result in fire.
❏
Avoid using an extension cord. If you must use an extension cord, be
sure to take the following precautions. Failure to do this might lead to
overheating, result in fire, or cause flickering due to a drop in voltage.
•Be sure not to exceed the allowed rating current of the extension
cord.
2
viii
•Use a short extension cord. Do not connect several extension cords
together.
•Make sure that the total ampere rating of the products plugged into
the extension cord does not exceed the extension cord ampere
rating.
❏
Slots and openings in the cabinet are provided for ventilation. To
ensure reliable operation of the printer and to protect it from
overheating, these openings must not be blocked or covered. The
openings should never be blocked by placing the printer on a bed,
sofa, shag rug, or other similar surface.
❏
The printer should never be placed near or over a radiator, heat
register, or flame. It should not be placed in a built-in installation
unless proper ventilation is provided.
Ventilation slots
❏
Before connecting the printer to a power source, check the voltage
rating label at the back of the printer to ensure that the printer voltage
matches that of the power source. The voltage rating label is located
on the rear side of the printer. If the voltage label is missing, contact
your nearest authorized dealer or the place of purchase.
❏
The power cord should be routed so that it is not likely to be walked
on or pinched by items placed on or against it. Pay particular attention
to the plug, the power socket, and the point where the cord exits the
unit.
❏
Keep the power cord and cables away from children.
❏
Do not handle plugs with wet hands.
❏
When the printer will not be used for a long period, turn the power off
and unplug the power cord for safety.
❏
Unplug the printer from the wall outlet before cleaning. Do not spray
liquid cleaners or aerosol cleaners directly on the cabinet or the
openings, as the spray could penetrate inside the printer and
contaminate internal parts. Use a damp cloth for cleaning.
❏
Never push objects of any kind into the printer through openings in the
enclosure, as the objects might touch dangerous voltage points or
short out parts. This could result in a fire or electrical shock. Never
spill liquid of any kind into the printer.
❏
Unplug the printer and request servicing from qualified service
personnel in the following situations:
•When the power cord or plug is damaged or becomes frayed.
• If liquid is spilled into the printer.
• If the printer is exposed to water.
ix
• If the printer does not operate normally when the operating
instructions are followed. Adjust only those controls that are
covered by the operating instructions, since improper adjustment
of other controls may damage the printer and may require
extensive work by a qualified technician to restore the product to
normal operation.
• If the printer is dropped or the cabinet is damaged.
• If the printer exhibits a distinct change in performance, indicating a
need for servicing.
• If the printer produces smoke, odor, or excessive noise.
❏
The outlet should always be free from any obstacles so as to allow
easy access.
❏
When unplugging the printer, always disconnect the power cord by
pulling on the plug, not the cord itself.
❏
Any misuse of electrical equipment is hazardous. Do not allow
children to handle power cords or cables.
❏
Do not attempt to service this printer yourself, except as instructed in
this guide. Opening or removing covers that are intended to be
removed only by qualified service personnel may expose you to
dangerous voltage points or other risks. Refer all servicing in those
compartments to qualified service personnel.
❏
Do not attempt to modify the printer.
❏
Do not remove the warning or instruction labels on the printer.
x
Operating Environment
When selecting a location for the printer, check the following guidelines:
•Make sure the location is flat and sturdy.
•When power is on (printer plugged into an AC outlet):
Temperature: 7.5˚C-35˚C (45.5˚F-95˚F)
Relative humidity: 5-90% RH with no condensation
•Make sure the surrounding area is well ventilated.
• The printer must not be in a direct draft.
Avoid placing the printer in the following
locations:
•Under direct sunlight, near heaters,
air conditioners, or open flames.
Strong light entering the printer unit causes the internal cartridge drum
surface to deteriorate and degrades the printing.
•Near magnets or equipment that generates magnetic fields.
•Near areas subject to vibration.
• In dusty places or places where the air contains high concentrations
of salt or corrosive gases.
•Near water pipes and refrigerators.
If humidity is less than 30%, use a humidifier or an anti-static mat to
prevent buildup of electrostatic charges.
If the room temperature rises abruptly, or the printer is moved from a cool
and dry place to a warm and humid place, condensation may form inside
the printer and cause problems with paper delivery or a deterioration in
print quality and, in some cases, result in printer error. To prevent this,
allow the printer to sit for an hour or more to adjust to the new
temperature.
xi
Observe the following requirements when the power is off (printer
unplugged from the AC outlet):
•Temperature: 0˚C-35˚C (32˚F-95˚F).
•Relative Humidity: 35-85% RH with no condensation.
Carrying the Printer
CAUTION:
Do not carry the printer by holding the front panel or by holding it at the
front and rear. This could result in damage to the printer or personal
injury if the printer is dropped.
xii
Before transporting the printer, always remove the EP-25 cartridge and
store it in its original protective bag or wrap it in a thick cloth to protect it
from strong light.
Contents
Chapter 1 Introduction .......................................................................................... 1
Printer Features....................................................................................... 2
Parts of the Printer .................................................................................. 4
Front View..................................................................................... 4
Rear View...................................................................................... 4
Inside the Printer ........................................................................... 5
Chapter 2 Paper Handling ..................................................................................... 7
Paper Requirements................................................................................ 8
Plain Paper..................................................................................... 9
Transparencies............................................................................... 9
Labels ............................................................................................ 9
Envelopes .................................................................................... 10
Postcards...................................................................................... 11
Storing Paper ........................................................................................ 11
Paper Path ............................................................................................. 12
Selecting Paper Delivery ...................................................................... 13
Face-down Delivery .................................................................... 13
Face-up Delivery ......................................................................... 14
Loading Paper into the Cassette ........................................................... 15
Loading Envelopes into the Cassette........................................... 18
Loading Paper Manually ...................................................................... 23
Chapter 3 Using the Canon Advanced Printing Technology ............................ 25
Installing the CAPT .............................................................................. 26
Windows 95/98/Me .............................................................................. 26
Plug and Play............................................................................... 26
Add Printer Wizard ..................................................................... 30
Windows NT 4.0/2000/XP ................................................................... 35
Windows 2000 Plug and Play ..................................................... 35
Windows XP Plug and Play ........................................................ 38
Windows NT 4.0 Add Printer Wizard......................................... 41
Windows 2000 Add Printer Wizard ............................................ 45
Windows XP Add Printer Wizard ............................................... 51
Connecting to the LBP-1210 Already on Your Network ..................... 57
Network Download ..................................................................... 57
Windows 95/98/Me Add Printer Wizard..................................... 58
Windows NT 4.0 Add Printer Wizard......................................... 59
xiii
Windows 2000 Add Printer Wizard ............................................ 59
Windows XP Add Printer Wizard ............................................... 60
Printer Sharing...................................................................................... 61
Connecting the LBP-1210 as a Network Printer ......................... 61
Status Display.............................................................................. 63
Canon LASER SHOT LBP-1210 Group.............................................. 64
Printing with the CAPT ........................................................................ 65
Windows 95/98/Me Printer Properties........................................ 66
Windows NT 4.0/2000/XP Printer Properties and Default
Document Properties* ................................................................. 79
Checking the Status of a Print Job........................................................ 93
Opening the Status Window........................................................ 94
Using the LBP-1210 Status Window .......................................... 95
Network Printer Status .............................................................. 106
The Status Window Icon ........................................................... 107
Closing the Status Window ....................................................... 108
Messages ................................................................................... 108
Chapter 4 Troubleshooting ................................................................................ 111
Finding Information............................................................................ 111
Paper Jams .......................................................................................... 113
Locating Paper Jams.................................................................. 113
Removing Paper Jams ............................................................... 117
Print Quality Problems ....................................................................... 124
Printout Has Vertical White Streaks ......................................... 124
Printout Has Black Specks ........................................................ 125
Printout Too Light..................................................................... 125
Printout Too Dark...................................................................... 125
Printer Problems ................................................................................. 126
CAPT Problems.................................................................................. 129
CAPT Messages ................................................................................. 132
Using the Trouble Shooter.................................................................. 134
Uninstalling the CAPT ....................................................................... 136
Chapter 5 Maintenance ...................................................................................... 137
Handling and Cleaning the Printer ..................................................... 137
Handling the Printer .................................................................. 137
Cleaning the Printer................................................................... 138
EP-25 Cartridge .................................................................................. 138
Storage Guidelines .................................................................... 139
Handling Guidelines.................................................................. 140
Replacing the EP-25 Cartridge.................................................. 141
xiv
Cleaning..................................................................................... 143
Appendix A Printer Specifications ....................................................................... 145
Appendix B Network Adapter: AXIS 1610 ......................................................... 147
Connecting Directly From Clients...................................................... 148
Connecting Through A Print Server................................................... 149
Protocols ............................................................................................. 149
Using NetPilot To Configure Your Network Adapter........................ 149
Installing the Network Print Monitor ........................................ 149
Specifications...................................................................................... 150
Glossary ............................................................................................................. 151
Index ............................................................................................................. 163
xv
xvi
Chapter 1
Introduction
Congratulations on your purchase of the Canon LBP-1210 Laser Printer.
This chapter introduces you to the printer and explains its features.
Your new laser printer has many advanced features, including the CAPT
(Canon Advanced Printing Technology). The CAPT gives you instant
access to printer information.
Introduction
The LBP-1210 offers outstanding print quality, flexible paper handling,
energy-efficient printing, and trouble-free operation.
Chapter 1 Introduction 1
Printer Features
The LBP-1210 combines the following features to form a versatile
printing system:
Quick startup
The printer is ready to print in less than 8 seconds after it is turned on
(start-up time), and has a first print time of less than 10 seconds. This
means that you can print documents quickly and efficiently.
Impressive output
Thanks to the CAPT (Canon Advanced Printing Technology), the 600 dpi
resolution gives you crisp, clean, laser-sharp output at 14 pages per
minute.
Low power consumption
The printer comes with an efficient power management system. Power
consumption is very low, particularly when idle.
Stylish, compact design
The printer provides compact, lightweight, easy-to-use functionality in a
smooth, stylish design. The small footprint gives you more work space to
help you meet your needs.
CAPT Printing Software
The CAPT is easy to install, and with it you can set custom paper sizes,
overlay bitmaps on documents (for example, you can print your logo on
each page), tile up to nine pages on one sheet of paper, and switch easily
between complicated setups using user-defined profiles. The Status
Window gives you written and spoken feedback about your print jobs,
even over a network.
2 Introduction Chapter 1
Quiet operation
Its quiet operation makes this printer an ideal output device, even in an
open-office environment.
Flexible paper handling
Both the cassette and the manual feeding slot accept plain paper of
various sizes—Letter, A4, B5, or Executive—as well as transparencies,
labels, envelopes, postcards and other special paper. The cassette handles
up to 250 sheets of 64 g/m
2
plain paper with a maximum stack height of
25 mm. For manual feeding, sheets are fed one at a time. Delivery can be
face down or face up.
Direct Network Connection
With the optional network adapter, you can connect directly to the
LBP-1210 over a network, without having to go through a server.
Introduction
Chapter 1 Introduction 3
Parts of the Printer
Front View
Face-down delivery slot
Power lamp
Paper guides
Delivery selection
cover
Manual feed slot
Cassette
Rear View
Front cover
Power switch
Parallel port
interface connector
USB port
interface connector
Power socket
4 Introduction Chapter 1
Inside the Printer
Transfer roller
Fixing assembly
For more information about setting up the printer, see the Getting Started
Guide.
Introduction
Chapter 1 Introduction 5
6 Introduction Chapter 1
Chapter 2
Paper Handling
This chapter describes how to select the different types of paper you can
use with your printer and how to load them. It includes the following
information:
❏ Paper Requirements
❏ Storing Paper
❏ Paper Path
❏ Selecting Paper Delivery
❏ Loading Paper into the Cassette
❏ Loading Paper Manually
Paper Handling
Chapter 2 Paper Handling 7
Paper Requirements
Make sure that the paper you use meets the following requirements.
Printing speed may vary depending on: paper size, paper type, or number
of pages to be printed. This is due to protective functions working in
order to prevent troubles such as breakdown caused by heating.
Loading Type Size
Weight
2
(g/m
)
Capacity
Cassette Plain paper Letter, A4, Executive, B5. 64-163 Max height:
Envelopes 98 x 162 mm to
176 x 250 mm
(COM 10,
Monarch, DL, B5, C5)
Postcards 100 x 148 mm -- Max. height:
Other Index card: 3" x 5"* -- Max. height:
Manual Plain paper 76.2 x 127 mm to
216 x 356 mm
Including the following
standard paper sizes:
Letter: 8-1/2" x 11"
A4: 210 x 297 mm
Executive: 7-1/4" x 10-1/2"
B5: 182 x 257 mm
Transparencies A4 -- 1 sheet
Labels A4 -- 1 sheet
Envelopes 98 x 162 to 176 x 250 mm
(COM 10,Monarch, DL, B5,
C5)
-- Max. height:
64-163 1 sheet
-- 1 sheet
25mm (Approx. 250
sheets of 64 g/m
paper)
25 mm
25 mm
25 mm
2
Postcards 100 x 148 mm -- 1 sheet
Other Index cards: 3" x 5"* -- 1 sheet
*Only use index cards that are 0.18 mm to 0.28 mm thick.
8 Paper Handling Chapter 2
Plain Paper
Follow these guidelines when selecting paper:
❏ Paper that is too thick or too thin, or that has irregular shapes, cutouts,
or perforations should not be used.
❏ Never use paper that is wet, highly textured, rough, torn, wrinkled, or
damaged.
❏ Extremely smooth paper or paper with special coatings does not print
well.
❏ The laser printing process uses high temperatures to fuse toner to the
paper. Use paper that will not melt, vaporize, offset, discolor, or emit
dangerous fumes at about 190˚ C (374˚ F).
❏ Do not use thermal or carbon paper, or paper with glue, staples, clips,
or ribbons.
For colored paper, use colors that are not damaged by the heat of the
printer’s fixing assembly (about 190˚ C or 374˚ F).
Transparencies
The acceptable size is A4. The transparencies must be able to withstand
the heat generated by the fixing assembly (about 190˚ C or 374˚ F)
without damage.
Paper Handling
Labels
Labels are paper with pressure-sensitive adhesive. Acceptable size is A4.
Note the following conditions when choosing a label sheet:
❏ The label print face (top, or face sheet) must be made of ordinary,
matte-finish paper similar to copy paper.
❏ The paper backing must be able to withstand the heat generated by the
fixing assembly (about 190˚ C or 374˚ F). The backing must not be
made of easily removable coated paper.
Chapter 2 Paper Handling 9
Envelopes
❏ Do not use labels with exposed adhesive, which may stick to the EP-
25 cartridge or the fixing roller, causing the labels to peel off and
serious paper jams to occur.
Follow these guidelines when printing on envelopes:
❏ Envelopes must not have any fasteners, snaps, or windows, or be made
of artificial materials.
❏ Do not use envelopes that discolor or melt at about 190˚ C (374˚ F),
envelopes which might emit dangerous fumes when heated, or
envelopes that seal with pressure-sensitive adhesives.
❏ Do not use envelopes which are damaged, curled or wrinkled, or that
have an irregular shape.
❏ Do not use oversized envelopes, or envelopes with folds.
❏ Poorly manufactured envelopes are not recommended.
10 Paper Handling Chapter 2
Postcards
Follow these guidelines when printing on postcards:
❏ Postcards should not be greater than 0.28 mm in thickness.
❏ Postcards should be free of glue, clips, and staples.
❏ Do not use postcards that are damaged or curled, or that have special
coatings or an irregular shape.
Storing Paper
Improper paper storage might cause a deterioration of print quality and
paper performance. Therefore, note the following when storing paper:
❏ Store unused paper in its wrapping to protect against humidity.
❏ Do not store paper directly on the floor as the floor is usually humid.
❏ If you must store paper in a very humid place, use a specially designed
storage box.
❏ Keep paper on a flat surface to prevent excessive in-ream paper curl.
❏ Do not stack paper too high to prevent excessive in-ream paper curl.
❏ Do not subject paper to direct sunlight or a humid environment.
Paper Handling
If paper is moved to a place with a very different temperature, leave it
there for about one day before using it; otherwise it could curl or develop
wrinkles.
Chapter 2 Paper Handling 11
Paper Path
Understanding how paper travels inside the printer helps you better
handle paper loading and jams.
A sheet of paper enters the printer from the cassette or the manual feed
slot. It travels to the image transfer area where the printer drum has been
statically charged. A laser beam changes the static charge on the drum
and toner clings to those parts of the drum. As the paper rolls across the
drum, the toner transfers to the paper. The toner is then fused to the paper
by the fixing assembly. The paper either comes out from the face-up
delivery slot or travels to the face-down delivery slot, depending on the
paper delivery method selected.
12 Paper Handling Chapter 2
Selecting Paper Delivery
Use the delivery selection cover to choose face-up or face-down delivery.
When the cover is open, face-up delivery is selected. When the cover is
closed, face-down delivery is selected.
Face-down Delivery
Printouts are stacked in order in the face-down delivery slot (which can
hold up to 125 sheets of 64 g/m
To select face-down delivery, close the delivery selection cover.
2
paper).
Face-down
Paper Handling
Face-up
❏ Do not replace paper in the face-down delivery slot once it is removed
from the slot. This could result in damage to the flaps inside the slot.
❏ Never insert paper or other objects into the face-down delivery slot.
Chapter 2 Paper Handling 13
Loading...
