PIXMA iP6600D Bubble Jet Printer
The ultimate direct photo printer for the imaging enthusiast.
PIXMA – HOME PHOTOS HAVE NEVER BEEN THIS REAL
PIXMA is the direct result of Canon’s expertise in print-head technology, photography and copying. Canon’s new PIXMA range
features FINE print-head technology which places microscopic ink droplets on the page with unparalleled accuracy and
consistency. PIXMA delivers superior quality to your photographic and document printing with unsurpassed speed and reliability.
7
Page 2
ULTRA-FINE, DETAILED PHOTO PRINTS
I
Ultra-sharp 1 picolitre FINE technology results
in enhanced shading and precise detail for
superb images.
I
Produce high definition photos and documents
at up to 9600 x 2400 dpi.
I
Features a 6-colour individual ink system with Photo Cyan and Photo
1
1 picolitre FINE technology eliminates graininess to produce razor-sharp images
Magenta for more vivid and brilliant images. Individual ink tanks also
save you money as each colour is stored in a separate tank so you
only need to replace the one that runs out.
I
Enjoy borderless photo printing at home – up to A4 size.
PRINT DIRECT FROM YOUR DIGITAL CAMERA,
MEMORY CARD OR MOBILE PHONE
I
Prints directly from compatible digital cameras using Bubble Jet Direct
or PictBridge technology, the industry standard for direct printing
– no computer required.
I
With Card Direct, you can print photos directly from compatible
memory cards.
3
2
Image simulation
Card Direct Printing
I
Prints photos or stickers wirelessly from compatible mobile phones
via infrared (IrDA) transmission (JPEG only). Or use the optional
BU-20 adaptor to print via Bluetooth.
MORE PRINTING OPTIONS WITHOUT A PC
I
The iP6600D features a huge 3.5 inch colour LCD screen and
easy-to-use operation panel which allows you to view, edit and
enhance your images before you print them – without a PC.
Some new direct print editing features include:
– Automatic Red-eye Correction for images stored on your memory card.
– Camera Phone Image Enhancement which smooths out the
jagged edges when printing low-resolution mobile phone images.
– Face Brightener function to
enhance your images when
printing from your digital
camera or memory card.
I
You can even print an image
from your memory card directly
onto a printable surface CD or
DVD – no computer required.
The under-exposed photo makes the
portrait appear dark and dull.
Mobile Phone Printing
Huge 3.5 inch colour LCD screen
Image simulation
The subject’s face is automatically identified and
adjusted to the optimum tone, depending on the
level of brightness.
Page 3
FAST PRINTING AND MORE PAPER HANDLING OPTIONS
I
Print a true-to-life, borderless 6" x 4" photo in approximately 46 seconds.
I
The USB 2.0 Hi-Speed interface ensures fast data transfer, so you won’t
waste time waiting.
I
Reduce paper wastage with the convenient automatic duplex unit that
5
allows quick and easy double-sided printing. You can also use automatic
duplex and Canon’s PAK-101 (optional Photo Album Kit) to create your
own double-sided photo albums at home.
I
The dual paper-path allows paper to be loaded from both the auto sheet
feeder (ASF) and front cassette, perfect for switching between plain and
photo paper without having to re-load each time.
I
Create your own label designs and print them directly onto printable
CDs and DVDs.
I
Large 300 sheet plain paper capacity.
BE CREATIVE WITH EASY-TO-USE SOFTWARE
I
Easy-PhotoPrint is a user friendly application for
printing out digital photos, retouching portraits
and lab-quality trimming.
4
Automatic Duplex Printing
CD/DVD Printing
I
Easy-WebPrint* eliminates waste and frustration by
automatically adjusting the size of a web page to
6
ensure it fits on the sheet perfectly when you print.
I
PhotoRecord* lets you create beautiful photo albums with imaginative layouts and captions.
I
CD-LabelPrint allows you to layout label designs and print them directly onto printable CDs and DVDs.
* Windows only
Easy-PhotoPrint – Simple 3 step process
TRUE-TO-LIFE PHOTOS THAT LAST A LIFETIME
A beautiful photograph is something worth keeping forever. Now with
ChromaLife 100, the photos you print at home will maintain all their
vibrancy and colour for 100 years.
7
The combination of genuine
Canon ChromaLife 100 ink and selected Canon photo papers lets you print
long-lasting photos of unrivalled quality. Thanks to ChromaLife 100, the precious
memories in your albums will still be bright and fresh a century from now.
Canon has a range of specialty photo papers
that’s suitable for virtually every photo size
and use. To ensure you gain all the long-lasting
benefi ts of ChromaLife 100, make sure you
choose Canon’s Photo Paper Pro, Photo Paper
ChromaLife 100 Ink
Plus Glossy, Photo Paper Plus Semi-gloss
or Glossy Photo Paper.
Canon Photo Papers
Want to know more? Visit canon.com.au
Page 4
PIXMA iP6600D SPECIFICATIONS
PRINTER FUNCTIONS
Paper Feeding Automatic feed
Printing Method Bubble Jet ink-on-demand with FINE
Printing Speed
Colour graphics: approx. 17 ppm††
Photo Paper Plus Glossy (6" x 4" image
Maximum Printing Resolution1 9600 x 2400 dpi
Borderless Printing 5" x 7", 6" x 4", A4, Credit Card size
Ink Tanks CLI-8C/M/Y/Bk/PC/PM – individual ink tanks
Ink Yield* Borderless 6" x 4" photo: CLI-8C – approx.
Approx. Paper Handling (ASF /
Plain Paper (13mm): 150 /
Super White Paper (SW-201): 100 / 100
High Resolution Paper (HR-101N): 80 / 80
Photo Paper Pro (PR-101): A4: 10, 6" x 4": 20 / A4: 10, 6" x 4": 20
Photo Paper Plus Glossy (PP-101): A4 / 5" x 7": 10, 6" x 4": 20 / A4 / 5" x 7": 10, 6" x 4": 20
Photo Paper Plus Semi-gloss (SG-101): A4: 10, 6" x 4": 20 / A4: 10, 6" x 4": 20
Glossy Photo Paper (GP-401): A4: 10, 6" x 4" / Credit card: 20 / A4: 10, 6" x 4": 20
Glossy Photo Paper-everyday use (GP-501): A4: 10, 6" x 4": 20 / A4: 10, 6" x 4": 20
Matte Photo Paper (MP-101): A4: 10, 6" x 4": 20 / A4: 10, 6" x 4": 20
Photo Paper Plus Double Sided (PP-101D): A4 / 5" x 7": 10 / A4: 5" x 7": 10
Photo Stickers (PS-101): 1 / N/A
Envelopes (DL, Com#10): 10 / 5
Transparencies (CF-102): 30 / 30
T-Shirt Transfers (TR-301): 1 / 1
Supported Paper Sizes A4, A5, B5, Letter, Legal, Envelopes
Supported Paper Weights Plain Paper: 64–105g/m
Canon specialty paper (max paper weight):
4
Monochrome: approx. 18 ppm
Paper Cassette)
150
Printable Area Bordered printing – Top Margin: 3mm,
Borderless photo printing – Top/Bottom/Right/
Bundled Software Windows: Easy-PhotoPrint, Easy-WebPrint
Macintosh: Easy-PhotoPrint, CD-LabelPrint
Interface PC: USB 2.0 Hi-Speed,
Camera Direct: Direct Print Port (PictBridge /
Mobile Phone: IrDA 1.2 (JPEG only),
Operating System Windows XP/2000/Me/98
Mac OS X v 10.2.1 or later
GENERAL FEATURES
Weight Approx. 7.2kg
Power Source AC 100-240V, 50/60Hz
Power Consumption Max: 17W (printing), Standby: 2W
Acoustic Noise Level 35dB(A) in best quality mode
Operating Environment Temperature: 5-35ºC, Humidity: 10-90% RH
Storage Environment Temperature: 0-40ºC, Humidity: 5-95% RH
Dimensions (W x D x H) 429 x 304 x 183mm (minimum dimensions
Included in the Box
PIXMA iP6600D Bubble Jet printer, CD Tray, Setup Software & User’s Guide CD-ROM,
Printed Manual, 6 individual ink tanks (CLI-8C, CLI-8M, CLI-8Y, CLI-8Bk, CLI-8PC, CLI-8PM),
Print-head, 12 months warranty card, Power cord, Sample Photo Paper
(Full-photolithography Inkjet Nozzle
Engineering) technology
on PP-101 in default mode):
approx. 46 seconds borderless
†
†††
(54mm x 86mm)
1000, CLI-8M – approx. 670, CLI-8Y – approx.
320, CLI-8Bk – approx. 1500, CLI-8PC
– approx. 200, CLI-8PM – approx. 140
(DL, Com#10), 5" x 7", 6" x 4",
Credit Card (54mm x 86mm)
approx 273g/m
Double Sided)
Bottom Margin: 5mm,
Left/Right margin: 3.4mm
Left margin: 0mm
PhotoRecord, CD-LabelPrint
with optional BU-20 adaptor and Bluetooth
enabled computer
Bubble Jet Direct)
Bluetooth Ver. 1.2 with optional BU-20
adaptor (JPEG only)
2
2
(Photo Paper Plus
5
Bluetooth printing
2
6
,
(no condensation)
(no condensation)
with paper trays and other extensions closed)
PRINT SPEED GUIDES
†
Black Text
A4
* Ink yield calculation is based on printing Canon 24 standard digital images on Photo Paper Plus
Glossy (6" x 4" borderless print) with default settings in Windows XP driver. This figure is an average
value, measured when printing continuously using the ink immediately after it is unsealed, until the
ink is out. Ink yield may vary depending on photos printed, applications software used, print mode
and type of paper used. This should be used as a guide only and does not take into account ink that
might be used for head cleaning or head refreshing to maintain printer performance.
Please visit our website for further details.
1. Ink droplets can be placed with a pitch of 1/9600 inch at minimum.
2. PictBridge camera direct and Bubble Jet Direct printing requires PictBridge or Bubble Jet Direct
compatible digital cameras in order to function. Check with your digital camera manufacturer or
users guide to determine PictBridge or Bubble Jet Direct compatibility.
3. Compatible memory cards include CompactFlash,
Stick PRO,
Note: xD-Picture Card,
be used with the addition of a special adaptor sold separately – ask your memory card supplier.
4. Print speed dependent on system configuration, image/document complexity, type of paper used,
software, print mode and does not take into account data processing time on host computer.
5. USB 2.0 Hi-Speed performance requires Windows XP with Service Pack 1 or Windows 2000 with
Service Pack 4 with pre-installed USB 2.0 Hi-Speed port.
6. Easy-WebPrint requires Microsoft
7. Up to 100 Years’ Life in a Photo Album when printed with ChromaLife 100 ink on selected
Canon photo papers. Kept in a photo album, shut out light and air (gas), temperature 23 degrees
and 50% humidity. Predicted value from the accelerated test. Result may vary based on individual
environmental factors. For more information, please visit canon.com.au/ChromaLife100
All specifications may change without notice.
††
Text & Colour
Graphics A4
TM
SD CardTM and MultimediaCard.®
TM
Memory Stick Duo,TM Memory Stick Pro DuoTM and miniSD Card can only
The 1 year warranty can be upgraded to 3 years for a minimal cost and
is backed by Canon’s Customer Care Info-Line support. Driver updates
and Technical Support are also available from our websites
– canon.com.au or canon.co.nz
†††
6" x 4"
®
Internet Explorer version 5.5, version 6.0 recommended.
®
Microdrive, SmartMedia,® Memory Stick,® Memory
Canon Australia Pty. Ltd.
Freecall: 1800 021 167
Facsimile No: + 61 2 9805 2632
Canon is a registered trademark of Canon Inc. and ‘advanced simplicity’ is a registered trademark of
Canon Australia Pty Limited. PIXMA and the PIXMA logo are trademarks of Canon Inc. Microsoft,
Windows and the Windows logo are registered trademarks of Microsoft Corporation in the United
States and in other countries. All other trademarks are the property of their respective owners.
Canon New Zealand Limited
Freecall: 0800 222 666
Facsimile No: + 64 9 489 0380
canon.com.au
canon.co.nz
canon.com.au/digitalimage
CAN0724
