important Safety instructions

To avoid possible injury or property damage,

OBSERVE ALL WARNINGS AND CAUTIONS.

These instructions are intended for use by qualified

installers only. The dishwasher must be installed by

a qualified service technician or installer.

In addition to these instructions, the dishwasher

shall be installed to meet all electrical and

plumbing codes and ordinances (both national

and local).

Read these installation instructions completely

and follow them carefully. They will save you time

and effort and help to ensure safety and optimum

dishwasher performance.

IMPORTANT

The dishwasher drain hose must be installed

with a portion of it at least 20" (508 mm) off the

cabinet floor; otherwise the dishwasher may not

drain properly.

This dishwasher is intended for indoor

residential use only, and should not be used in

commercial food service establishments.

NEW INSTALLATION - If the dishwasher is a

new installation, most of the work must be done

before the dishwasher is moved into place.

REPLACEMENT- If the dishwasher is replacing

another dishwasher, check the existing

dishwasher connections for compatibility with

the new dishwasher, and replace parts as

necessary.

This appliance has been found to be in

compliance with CAN/CSA-C22.2 No. 167/UL

749. It is the responsibility of the owner and the

installer to determine if additional requirements

and standards apply in specific installations.

,, Not for outdoor use.

Inspect the Dishwasher

After unpacking the dishwasher and prior to

installation, thoroughly inspect the dishwasher for

possible freight or cosmetic damage. Report any

damage immediately. Cosmetic defects must be

reported within 30 days of installation.

NOTE: Do not discard any bags or items that come

with the original package until after the entire

installation has been completed.

Avoiding General Hazards

Do not use the dishwasher until it is completely

installed. When opening the door on an uninstalled

dishwasher, carefully open the door while

supporting the rear of the unit. Failure to follow this

warning can cause the dishwasher to tip over and

result in serious injury.

Before installing the "L"-shaped supplied countertop

mounting brackets (select models), decide which

method will be used to secure the dishwasher into

its opening. Once these mounting brackets are

installed on the dishwasher, removing them is

difficult and will damage the mounting brackets and

the dishwasher.

In some conditions, hydrogen gas can form in a hot

water system that has not been used for weeks.

Hydrogen gas is explosive.

Before filling a dishwasher from a system that has

been off for weeks, run the water from a nearby

faucet in a well ventilated area until there is no

sound or evidence of gas.

Temperatures required for soldering and sweating

will damage the dishwasher's base and water inlet

valve. If plumbing lines are to be soldered or

sweated, keep the heat source at least 6" (152.4

mm) away from the dishwasher's base and water

inlet valve.

Removing any cover or pulling the dishwasher from

the cabinet can expose hot water connections,

electrical power and sharp edges or points. Handle

with care.

Avoiding Electrical Shock/Fire Hazards

Do not allow the electrical and water supply lines to

touch. Separate channels are provided under the

dishwasher.

Do not work on an energized circuit. Doing so could

result in serious injury or death. Only qualified

electricians should perform electrical work. Do not

attempt any work on the dishwasher electric supply

circuit until you are certain the circuit is de-

energized.

Make sure electrical work is properly installed.

There should be no loose electrical connections.

Ensure all electrical connections are properly made.

The customer has the responsibility of ensuring that

the dishwasher electrical installation is in

compliance with all national and local electrical

codes and ordinances. The dishwasher is designed

for an electrical supply of 120V, 60 Hz, AC,

connected to a dishwasher-dedicated, properly

grounded electrical circuit with a fuse or breaker

rated for 15 amps. Electrical supply conductors

shall be a minimum #14 AWG copper only wire

rated at 75°C (167°F) or higher.

This appliance must be connected to a grounded

metal, permanent wiring system, or an equipment-

grounding conductor must be run with the circuit

conductors and connected to the equipment-

grounding terminal or lead on the appliance. Do not

use extension cords.

Avoiding Electrical Shock/Fire Hazards

Do not perform any work on a charged hot water

line. Serious injury could result. Only qualified

plumber should perform plumbing work. Do not

attempt any work on the dishwasher hot water

supply plumbing until you are certain the hot water

supply is shut off.

Do not over tighten the 90 ° elbow. Doing so may

damage the water inlet valve and cause a water

leak.

Temperatures required for soldering and sweating

will damage the dishwasher's water inlet valve. If

plumbing lines are to be soldered or sweated, keep

the heat source at least 6" (152.4 mm) away from

the dishwasher's water inlet valve.

Check local plumbing codes for approved plumbing

procedures and accessories. All plumbing should

be done in accordance with national and local

codes.

These instructions depict an installation method for

stainless steel braided hose or PEX hot water

supply lines. If using copper tubing or other material

for water supply, defer to a licensed plumber for

proper installation.

Hammer HoleSaw PipeWrench AdjustableWrench

TapeMeasure

SlotScrewdriver

PhillipsScrewdriver

TorxT-20Screwdriver

\-- '/

........ ::::zO

Wire Cutter Wire Stripper O 2 mm (1/16 in) Drill Level

Electrical Supply Cable - Minimum #14 AWG, 2 conductor, 1

ground, insulated copper conductors rated 75°C or higher

Hot Water Supply Line - Minimum 3/8" O.D. copper tubing or

metal braided dishwasher supply line

Shut-off valve and fittings appropriate for hot water supply

line (copper tubing/compression fitting, or braided hose

UL listed conduit connector or strain relief is required if you

attach the field wiring directly to the terminal block

O 4xl 7mm

A Extra Tall item Sprinkler (See Use and Care Manual)

B Toe Panel Screws

C Mounting Brackets

D Mounting Bracket Screws

E Toe Panel (2 pieces)

F Toe Panel caps and screws (select models only)

G Screw Clamp (for hose)

H Water Supply Adaptor Fitting

I Flexible Edge Protector Grommet for electrical wire

J Rubber Drain Hose Adaptor

K Toe Panel Mounting Brackets (select models only)

Outer toe panel (3rd piece) (select m°deis only)

M Side Mount Force Distributor (Alternate Side Mount only)

N Mounting Bracket Screws (Alternate Side Mount only)

O Installation Guide for Fully integrated Door Panel (select

m_els only)

P Junction Box

Q Wrench (wrench, size 13)

_(_,O O 4x13mm

! i i!_

(_,------ O4x36mm TJ7

Avoid Scalding or Electrical Shock Hazard!

Make sure the water supply and electrical supply are

shut off before installation or service.

NOTE: This dishwasher is designed to be enclosed on

the top and both sides by standard residential kitchen

cabinetry.

Select a location as close to the sink as possible for

easy access to water supply and drain lines.

For proper dishwasher operation and appearance,

ensure that the enclosure is square and has the

dimensions shown in Figure 1.

90 °

Figure 1

NOTE: If your dishwasher opening width measures

>235/8" (600 mm) use the TOP or SIDE MOUNT

mounting methods.

If your dishwasher opening width measures 235/8"

(600 mm) use the ALTERNATE SIDE MOUNT

mounting method.

If the dishwasher is to be installed in a corner, make

sure that there is adequate clearance to open the

door. See Figure 2.

betweenCheckclearance

dishwasherdoor

andwail;

Countertop

Figure 2

Avoid Electrical Shock/Fire Hazard!

Do not allow the electrical and water supply lines

to touch.

After locating the proper place for your new

dishwasher, you will need to create any required

openings to allow for passage of the water, drain and

electrical line. In order to avoid interference with the

dishwasher when sliding it into the cabinet, place your

openings within the dimensions shown in Figure 3.

Figure 3

Required Openings:

4 3/4" X 2 3/8" (120 x 60 mm) - To pass the included

electrical supply junction box through to adjacent

cabinet.

Note: If the incoming electric supply, water supply and

drain connections are aft in the same cabinet, the one

43/4"x 23/8'' (120 x 60 mm) hole will be large enough

for all three to pass through.

4" x 2" (100 x 50 mm) - To pass the included water

supply line toward the water supply.

1/4,,

1 (32 mm) diameter - To pass the dishwasher drain

hose toward the drain connection.

Before sliding the dishwasher into the cabinet, remove

the hose clip at the back of the dishwasher as shown

in Figure 4. The hose clip may be used later to hold

the drain hose as shown in Figure 10.

Figure 4

In select models, remove the rubber apron on top of

the dishwasher and set aside for later use (Figure 5).

Figure 5

Avoid Electrical Shock Hazard!

Do not work on an energized circuit. Doing so could

result in serious injury or death. Only qualified

electricians should perform electrical work. Do not

attempt any work on the dishwasher electric supply

circuit until you are certain the circuit is de-energized.

Avoid Fire Hazard!

Make sure electrical work is properly installed. Only

qualified electricians should perform electrical work.

Electrical Supply

The customer has the responsibility of ensuring that

the dishwasher electrical installation is in

compliance with all national and local electrical

codes and ordinances. The dishwasher is designed

for an electrical supply of 120V, 60 Hz, AC,

connected to a dishwasher-dedicated, properly

grounded electrical circuit with a fuse or breaker

rated for 15 amps. Electrical supply conductors

shall be a minimum #14 AWG copper wire rated at

75°C (167°F) or higher.

Avoid Fire Hazard!

Make sure there are no loose electrical connections.

Make sure all electrical connections are properly made.

Electrical Connection

The dishwasher electrical supply junction box (P) and

dedicated receptacle must be mounted in an

accessible cabinet adjacent to the dishwasher (do not

mount the junction box or receptacle behind the

dishwasher). You will need a 43/4" x 23/8" (120 x 60

mm) opening through the cabinet in order to pass the

junction box through (see Figure 6). If the opening is

made through wood, sand it smooth. If the opening is

made through metal, use the included protective

grommet (I) or other approved method to protect

wiring from damage. Use the four screws included (or

appropriate fastener) in the parts bag to securely

mount the junction box so that it can be easily

accessed (see Figure 6). The electrical supply can be

connected in two ways:

_on box and I

roe prong #ug[

_m _nclu_

i_r,_i_wasF_J

Figure 6

Grounding Instructions

The dishwasher must be properly grounded before

operating. This appliance must be connected to a

grounded metal permanent wiring system or an

equipment grounding conductor must be run with

the circuit conductors and connected to the

equipment grounding terminal or lead on the

dishwasher. Make sure that the dishwasher is

connected to a suitable ground in compliance with

all local codes or, in the absence of a local code,

with the NATIONAL ELECTRICAL CODE in the

United States or the CANADIAN ELECTRIC CODE

C22.1-1atest edition in Canada as well as any

provincial/state or municipal or local codes that

apply.

Dishwasher Electrical Rating

60 12 1,300 (max)

Figure 7

Method A - Three prong plug and receptacle

Use the included three-prong plug and junction box to

connect to a dedicated household receptacle. Make sure

the household receptacle meets the electrical supply

requirements as well as national and local codes.

Method El - To permanently connect to househol

or field wiring

Remove the dishwasher electrical supply junction

box cover and connect to the power supply cord

from the house installation (see Figure 7).

Remove 2" to 3" (51 - 76 mm) of the outer

casing of the household or field supply wiring as

shown in Figure 8. Remove 3/8" to 1/2" (10 - 13

mm) of the insulation from each wire as shown in

Figure 8.

Hot Water Supply

The hot water heater should be set to deliver

approximately 120 ° F (49 ° C) water to the

dishwasher. Water that is too hot can cause some

detergents to lose effectiveness. Lower water

temperatures will increase run times. The hot water

supply pressure must be between 15 - 145 psi (1 -

i0 bar).

I._ 2"- 3" ..................:_-

(51mm - 76mm)

3/8"- I/2" I

(10mm- 13ram)

IMPORTANT NOTES:

,, If using a solder joint instead of a compression

fitting, be sure to make all solder connections

before connecting the water supply line to the

dishwasher.

,, Make sure there are no sharp bends or kinks in

the water line that might restrict water flow.

,, Always use the appropriate seal when making

plumbing connections.

,, Before connecting the water supply line to the

dishwasher, flush the incoming water line for

approximately 5 minutes to clear any foreign

material.

,, Turn on the water supply and check for leaks

after connections are made.

Figure 8

3. Insert the bare copper or green wire(ground) to

the "G" ground connection ,,__L__,,of the terminal

block and securely tighten the terminal block

screw (see Figure 7).

4. Insert the white (neutral) wire to the "N"

connection of the terminal block and securely

tighten the terminal block screw.

5. Insert the black (hot) wire to the "L" connection of

the terminal block and securely tighten the

terminal block screw.

6. Check all electrical connections to make sure

they are secure and then attach the junction box

cover with the 4 screws.

Avoid Electrical Shock Hazard!

To avoid possible injury or property damage, care

should be exercised when the dishwasher is installed

or removed to reduce the likelihood of damage to the

power cord.

Avoid Scald Hazard!

Do not perform any work on a charged hot water line.

Serious injury could result. Only qualified plumbers

should perform plumbing work. Do not attempt any work

on the dishwasher hot water supply plumbing until you

are certain the hot water supply is shut off.

Temperatures required for soldering and sweating will

damage the dishwasher. If plumbing lines are to be

soldered or sweated, keep the heat source at least 6

inches (152.4 mm) away from the dishwasher.

Water Supply Shut Off Valve

Install an easily accessible shut-off valve (not

supplied) in the hot water supply line, as shown in

Figure 9. All solder connections must be made

before the water line is connected to the

dishwasher.

+ 18 hidden pages
