D9412G/D7412G

Program Entry Guide

Control Panels

D9412G/D7412G | Program Entry Guide | EN | 2

Trademarks

CoBox is a registered trademark of Lantronix®.

Windows

is either a registered trademark of Microsoft Corporation in the United States and/or other countries.

Documentation Conventions

Type Styles Used in this Manual

To help identify important items in the text, the following type styles are used:

Bold text

Italicized text

Courier Text

[CAPITALIZED TEXT]

Promp

Sub-Promp

Usually indicates selections that you might use while programming your control panel. It can also indicate an important fact.

Used to refer the user to another part of this manual or another manual entirely. It can also used to symbolize names for records that the user creates.

Indicates what can appear on the Remote Programmer’s display, command center/keypad or internal printer.

Used to indicate that a specific key should be pressed.

A thick border is used to indicate a main programming entry as seen in the Remote Programmer’s Display. It is used as a section heading and screen example. Shaded boxes indicate programmer prompts that are only available when Custom or View events are selected.

A dashed border indicates a sub entry under a main programming entry.

0101 0101 0101

Application Note:

These are notes and clarifications of different aspects of the application.

Programming Notes:

These cover notes and clarifications specific to programming the unit.

Programming Tip:

These are helpful shortcuts or reminders for programming the unit.

Important Notes

These notes should be heeded for successful operation and programming.

Warning!

These warn of the possibility of physical damage to the operator, program and/or equipment. Use this when there is an increased risk of physical damage to the operator (severe injury or death) or equipment (destruction of physical components).

Caution

These caution the operator that physical damage to the program and/or equipment.

Access control tip.

Tips, Notes, Cautions and Warnings

Throughout this document helpful tips and notes are presented concerning the entire application and/or programming the unit. They are displayed as follows:

Application Tip:

These are helpful shortcuts or reminders in

using the unit.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | Table of Contents EN | 3

2.10.1 Cmd Cntr (Command Center) Assignment.. 46

Table of Contents

1.0 Introduction.......................................................5

1.1 How to use this Program Entry Guide............. 5

1.2 Literature Referenced.........................................5

1.3 Differences Between the D9412G and

D7412G ...............................................................5

1.4 New Features....................................................... 6

1.5 Product Handlers................................................8

1.6 Programming Options........................................8

1.7 Programming the Control Panel with the

D5200 Programmer............................................9

2.0 9000MAIN ........................................................11

2.1 Phone .................................................................11

2.2 Phone Parameters.............................................12

2.3 Routing ..............................................................15

2.3.1 Called Party Disconnect .................................. 15

2.3.2 Route Number Groups: Which Has the

Highest Priority?...............................................15

2.3.3 Programming a Primary and Backup

Destination ........................................................16

2.3.4 Enhanced Routing............................................16

2.3.5 Programming a Duplicate Report...................16

2.3.6 Routing Destination Communication

Failures............................................................... 16

2.3.7 Message Prioritization within a Route

Number.............................................................. 16

2.3.8 Dialing Attempts...............................................16

2.4 Enhanced Routing............................................23

2.4.1 Programming a Primary and Backup

Destination ........................................................23

2.4.2 Programming a Duplicate Report...................24

2.5 Power Supervision............................................27

2.6 Printer Parameters ............................................29

2.7 RAM Parameters ..............................................31

2.7.1 Uploading and Downloading Reports ...........31

2.7.2 Log Threshold Reports ....................................31

2.7.3 RAM Callback Reports ...................................31

2.8 Miscellaneous....................................................34

2.9 Area Parameters................................................34

2.9.1 Area Parameters................................................34

2.9.2 Programming Account Numbers in 9000

Series Control Panels, versions 6.20 and

Higher ................................................................35

2.9.3 Shared-Area Characteristics ............................40

2.9.4 Bell Parameters .................................................40

2.9.5 Open/Close Options........................................42

2.10 Command Center.............................................46

2.10.2 Area Text .......................................................... 50

2.10.3 Custom Function.............................................. 51

2.11 User Interface ................................................... 53

2.11.1 Commands........................................................ 53

2.11.2 Command Center Selections.......................... 53

2.11.3 Authority Level Selections.............................. 59

2.12 Function List..................................................... 67

2.13 Relay Parameters ............................................. 67

2.13.1 Area Relays....................................................... 68

2.13.2 Panel-Wide Relays........................................... 71

3.0 RADXUSR1/RADXUSR2 ............................ 73

3.1 Passcode/Token Worksheet............................ 73

3.1.1 User Groups...................................................... 73

3.1.2 Passcodes........................................................... 73

3.1.3 User Group Window ....................................... 73

3.1.4 Authority Level by Area ................................. 73

3.1.5 User Name........................................................ 73

3.1.6 Tokens/Cards ................................................... 73

3.1.7 Reporting and Logging.................................... 73

4.0 RADXPNTS..................................................... 77

4.1 Point Index ....................................................... 77

4.1.1 Point Responses................................................ 81

4.2 Point Assignments............................................ 91

4.3 COMMAND 7 and COMMAND 9 ............. 94

5.0 RADXSKED.................................................... 95

5.1 Windows ........................................................... 95

5.1.1 Opening and Closing....................................... 95

5.1.2 User Group Windows.................................... 102

5.2 Skeds................................................................ 104

5.3 Holiday Indexes............................................. 113

5.3.1 Add/Change/Delete ...................................... 113

5.3.2 View Holidays................................................ 114

6.0 RADXAUX1.................................................. 115

6.1 Introduction .................................................... 115

6.2 RAM IV and D5200 Handler

Requirements.................................................. 115

6.3 SDI Automation ............................................. 115

6.4 SDI RAM Parameters.................................... 116

6.4.1 User Interface Modifications for

COMMAND 43............................................. 117

6.4.2 Using an External Modem............................ 118

6.5 Enhanced Communications.......................... 122

6.5.1 Programming Path Numbers and

IP Addresses ................................................... 123

6.6 SDI RAM/Enhanced Communications

Configuration.................................................. 125

6.6.1 Route Group Attempts .................................. 126

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | Table of Contents EN | 4

6.7 Miscellaneous..................................................127

6.8 Cross Point Parameters..................................128

7.0 RADXAXS .....................................................131

7.1 Door Profile.....................................................131

7.2 Strike Profile....................................................133

7.3 Event Profile....................................................134

Programming Prompts Directory ...........................136

Figures

Figure 1: Pager Display Fields.......................................25

Figure 2: Account Number Entry .................................36

Figure 3: User Group 122 Example..............................74

Figure 4: Example Opening Window Timeline (using

two Opening Windows on same day)..........97

Figure 5: COMMAND 43 Flow Chart.......................117

Figure 6: RAM IP Address Prompts...........................118

Figure 7: Com Port Selection within

HyperTerminal.............................................120

Figure 8: External Modem Connection .....................120

Figure 9: Path # IP Add1 to Add4 .............................123

Figure 10: Poll Rate Timeline......................................124

Tables

Table 1: Literature Referenced .....................................5

Table 2: Differences between the D9412G and

D7412G............................................................5

Table 3: New Features................................................... 6

Table 4: Product Handlers ............................................8

Table 5: Programming Error Displays......................... 9

Table 6: Modem IIIa

User ID Numbers..........................................13

Table 7: Modem IIIa

Point Numbers ..............................................13

Table 8: Zones ..............................................................13

Table 9: Diagnostic Reports........................................ 18

Table 10: Burglar Reports .............................................18

Table 11: User Reports..................................................19

Table 12: Test Reports...................................................20

Table 13: Diagnostic Reports........................................ 21

Table 14: Relay Reports................................................21

Table 15: Auto-Function Reports .................................21

Table 16: RAM Reports ................................................22

Table 17: Point Reports.................................................22

Table 18: User Change Reports ................................... 23

Table 19: Access Reports .............................................. 23

Table 20: Event Descriptions, Priorities, and

Numbers.........................................................26

Communication Format Data -

Communication Format Data –

Table 21: Programming Four Digit Account

Numbers ........................................................ 35

Table 22: Programming Ten Digit Account

Numbers ........................................................ 35

Table 23: Verify Time................................................... 37

Table 24: CF### Custom Function Keystrokes........ 52

Table 25: Command Center Programming

Choices .......................................................... 53

Table 26: Authority Level Selections .......................... 59

Table 27: L## Secure Door-Door Mode

Definitions ..................................................... 62

Table 28: BSFK User Code Report ............................. 74

Table 29: P### BFSK/Relay Codes/Relays.............. 93

Table 30: Point Text for Points 240 to 247................. 93

Table 31: Window Selections....................................... 95

Table 32: Programming for Two Same Day Opening

Windows (see Figure 4)................................. 98

Table 33: Programming to Link Two Days over

Midnight ........................................................ 98

Table 34: W# Close Window Stop Programming

Example......................................................... 99

Table 35: Opening/Closing Windows Worksheet... 101

Table 36: Opening/Closing Windows....................... 101

Table 37: Normal Store Hours* ................................. 101

Table 38: Delivery Schedule*..................................... 102

Table 39: Monthly Auditor’s Schedule*.................... 102

Table 40: Cross Point Ranges Within Groups .........128

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 1.0 Introduction EN | 5

1.3 Differences Between the D9412G

1.0 Introduction

1.1 How to use this Program Entry Guide

This guide addresses the programming of the D9412G/D7412G Control Panels only, and should not be used in conjunction with other control panels.

Although this guide specifically refers to the D9412G Control Panels, it can be used for programming the D7412G Control Panels. Differences between the D9412G and D7412G are shown Table 2.

1.2 Literature Referenced

Throughout this guide, references are made to other documents. See Table 1 for a part numbers list of the referenced literature for ordering purposes.

Read the following documents before installing and programming the products.

Table 1: Literature Referenced

Document Name Part Number

1. D1255 Installation Instructions

2. D1256/D1257 Installation Instructions

3. D1260 Installation Guide

4. D1260 Owner’s Manual

5. D5200 Operations Manual

6. D6500 Report Directory

7. D6600 Communications Receiver/Gateway Computer Interface Manual

8. D720 Installation Instructions

9. D9210B Operation and Installation Guide

10. D9210B Program Entry Guide

11. D9210B Program Record Sheet

12. D9412G/D7412G Operation and Installation Guide

13. D9412G/D7412G Program Record Sheet

14. RPS Operations Manual

74-06819-000 74-06925-000

48101 50410 74-06176-000 74-04651-001 39963

74-06918-000 32206

32207 32208 43488

47488

38849

Table 2 describes the differences between the D9412G and the D7412G Control Panels.

Table 2: Differences between the D9412G and

Features D9412G D7412G

Access Control Yes

Expanded users

Passcode-protected custom functions

Number of printers 3 1 Number of points 246 75 Number of relays 128 64

and D7412G

D7412G

Arm/disarm Passcodes Cards/tokens

Eight Doors

249 996

16 4

Yes Two Doors

99 396

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 1.0 Introduction EN | 6

1.4 New Features

The items shown Table 3 are new features added to the D9412G/D7412G Control Panels since version 6.10.

Table 3: New Features

Feature Description

Ground Fault Detect (Version 6.10)

Added Feature when Using Ground Fault Detect (Version 6.10)

Fire Supervision Restoral Event (Version 6.20)

AC Fail Time modification (Version 6.20)

Fire Trouble Resound (Version 6.20)

Perimeter Armed Relay Operation (Version 6.20)

Poll Rate Operation (Version 6.20)

Programming Account Numbers (Version 6.20)

Cross Point Operation (Version 6.30)

For the D9412G/D7412G to detect ground fault conditions, the earth ground terminal on the control panel was electrically isolated from all other terminals. A ground fault detect enable switch (S4) was added to the control panel and is located under Terminal 10, earth ground. For more information on the operation of this function, see the D9412G/D7412G Operation and Installation Guide (P/N: 43488).

When ground fault detect is enabled (S4 closed), Points 1 to 8 can be used for non-powered fireinitiating devices; such as, heat detectors, 4-wire smoke detectors, or pull stations. A D125B Powered Loop Interface or a D129 Dual Class A Interface Module is no longer required when connecting non-powered fire-initiating devices to Points 1 to 8.

A new Fire Supervision Restoral Event was added to the Fire Events route group allowing this event to be transmitted when a Fire Supervision point restores to normal. Previous versions sent either a Fire Alarm Restore or Fire Trouble Restore Event.

The AC Fail Time entry was modified to allow additional programming flexibility. In previous versions, the AC Fail Time was made in either minutes or seconds (depending on the firmware version). However, version 6.20 allows you to select minutes or seconds and the length of time the AC Fail message is delayed (6 hours or 12 hours) after the occurrence. See the AC Fail Time prompt in Section 2.5 Power Supervision for additional information.

The D9412G and D7412G can be programmed to re-sound the fire trouble tone at command center(s) at midnight or at noon if the Fire point is still in a trouble condition. See the A # Silent Alarm prompt in Section 2.13.1 Area Relays for additional information.

The D9412G and D7412G can be programmed to activate a relay output when an area becomes Perimeter Armed using COMMAND 2 (Perimeter Instant), COMMAND 3 (Perimeter Delayed), or COMMAND 8 (Perimeter Partial). See the A # Silent Alarm prompt in Section 2.13.1 Area Relays for additional programming information.

In versions 6.00 and 6.10, a poll rate can be programmed to supervise the connection between the control panel, D9133TTL-E, and the D6600 Receiver. If the supervision connection was lost, future events were still routed to the Primary Path first before attempting the Backup Path. In version 6.20, the ability to instruct the control panel to automatically use the Backup Path if the Primary Path is compromised was added.

The 9000MAIN version 1.12 handler and version 6.20 firmware and higher now can program a four-digit or ten-digit account number for each area. See the A# Acct Number prompt in Section

2.9 Area Parameters for additional programming information. The D9412G and D7412G can now be programmed to group multiple points together in a Cross

Point configuration mode. This feature, more commonly known as Cross Zoning, instructs the control panel to delay its alarm response for a programmed period of time before additional points go into an alarm condition, verifying the burglar alarm condition. To program the D9412G or D7412G for Cross Point operation, review the following:

Location Item

Table 10

Section 4.1.1 Point Responses

Section 6.8 Cross Point Parameters

D1260 Alpha V Command Center Support (Version

6.30)

The new D1260 Alpha V Command Center boasts an easy-to-read, four-line by twenty-character LCD display, eight soft keys for displaying simple selections, and the standard Bosch Security Systems command structure (COMMAND 1, COMMAND 2, and so on). See the Enhanced Command Center prompt in Section 2.10.1 Cmd Cntr (Command Center) Assignment for further programming information.

Bosch Security Systems | 1/04 | 47775E

R# Unverified Evt

Cross Point prompt

D9412G/D7412G | Program Entry Guide | 1.0 Introduction EN | 7

Table 3: continued

Feature Description

Fire Trouble Resound Mode (Version 6.30)

Sked Functions (Version

6.30)

Inovonics Premises RF Compatibility (Version 6.30)

High Speed PSTN RPS Communications (Version

6.30)

New Buzz On Fault Mode (Version 6.30)

Disarm Now message enhancement (Version

6.30)

Panel Buzzer (Version

6.30

To help our Bosch Security Systems dealers program this feature more easily, the prompt, Fire Trouble Resound was added to Section 6.7 Miscellaneous.

The D9412G and D7412G can be programmed to execute Sked 28 (Expanded Off-Normal Test Reports) and Sked 29 (Non-Expanded Off-Normal Test Reports). These new skeds allow the control panel to generate Expanded or Non-Expanded Off-Normal Test Report Event instead of the previously used Expanded Test Report or Non-Expanded Test Report Event. See the S## Function Code prompt, 28 and 29, in Section 5.2 Skeds for further programming information.

In version 6.30 you can add Inovonics Premises RF. Through the use of the D8125INV Wireless Interface, which connects directly to ZONEX 1 and ZONEX 2 (D9412G only) and an Inovonics FA400 Wireless Receiver, up to 238 wireless transmitters can be added to a D9412G (up to 67 can be added to the D7412G). Each D8125INV supports up to 119 wireless transmitters (or 67 if connected to a D7412G). Transmitters added to the system can be monitored for activation, tamper, and low battery conditions. The FA400 Receiver is also supervised and the Inovonics Repeaters can be programmed to be supervised.

Using an off-the-shelf modem (capable of communicating at 9600-baud) and a D9133DC Direct Connect Programming Module, RPS can now communicate with a D9412G or D7412G at 9600baud instead of using the on-board 300 baud modem chip. This is especially useful for those accounts requiring constant RPS communication sessions, such as passcode or token changes or copying the logger. The use of this feature dramatically reduces the time (and money) spent online with the control panel. See Section 6.4.2 Using an External Modem for programming details on the operation of this feature.

A Buzz on Fault Mode (Option 3) was added to the point index parameters. For points with Option 3 enabled, a trouble tone is generated at the keypad when the point is off-normal while the area is disarmed. The user (by either passcode or COMMAND 4) cannot silence this buzz. It silences automatically when the point restores. Apply this feature when you want to monitor specific points and produce an audible annunciation at the command center when the point is faulted. For example, this feature could be used for a driveway sensor or a vestibule door that alerts you to an approaching individual.

The DISARM NOW text that appears during entry delay was modified beginning with version 6.30. The new text that appears alternates between DISARM NOW and the point text of the point that caused the area to go into entry delay. For example, if the point causing the area to go into entry delay was named Front Office Dr, then the control panel displays DISARM NOW then FRONT OFFICE DR during the entirety of entry delay.

Beginning with version 6.3 and higher, the control panel’s on-board buzzer pulses 1 second on, 1 second off, if a supervised command center no longer responds to polls from the control panel. The buzzer is silenced when the supervised command center begins responding to polls again or when [COMMAND][4] is entered from an operational command center.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 1.0 Introduction EN | 8

1.5 Product Handlers

Programming the 9000 Series requires multiple product handlers. The availability of each handler is indicated in Table 4. See the control panel specific Release Notes to determine the most up-to-date handler versions.

Although the handlers shown in Table 4 can be used to program any of the new control panels, not all of the functions operate. For example, the RADXUSR1 Handler is used to program users 000 through 124. Even though the handler allows you to program users 100 through 124, the D7412G does not allow the activation of these users.

Table 4: Product Handlers

Product Handler Function D9412G D7412G

9000MAIN

RADXUSR1 Covers Passcode/Token programming for Users 000 through 124

RADXUSR2 Covers Passcode/Token programming for Users 125 through 249. RADXPNTS Covers Point Index and Point Assignment programming for all points. RADXSKED Covers Open/Close Windows, User Access Windows, Skeds, and

RADXAUX1 Covers SDI Automation, SDI RAM Parameters, Enhanced

RADXAXS

Covers Panel-Wide, Area, Command Center Function List, User Interface, and Relay programming modules.

(99 users for the D7412G).

Holiday Index programming modules.

Communication Parameters, Route Group Attempts, Miscellaneous, and Cross Point Parameters.

Covers the programming parameters for installed D9210B Door Controllers. The Program Entry Guide and Program Record Sheet for this handler comes with the D9210B Access Control Module.

 



   



 

N/A

1.6 Programming Options

This Program Entry Guide is set up in a specific order. Related program entries are grouped together in modules as they appear in the specific product handlers. The handler and the programming module are listed at the top of each page to help you find specific programming prompts.

This Program Entry Guide shows the programming options for each product handler. Each option is listed with:

• The Program Item Prompt: Each prompt is

shown, as it appears in the D5200 Programmer [see the D5200 Programmer Operations Manual (P/N: 74-06176-000)] or the Remote Account Manager [see the RPS Operations Manual (P/N:

38849)]. Sometimes, for space considerations, a prompt must be abbreviated in the Programmer display. In these cases, the meaning of the prompt is explained below the prompt

• Program Entry Default Setting: Because

defaults are set for the typical installation, you may not need to program each prompt. Review the default entries in the Program Record Sheet

shipped with the control panel to determine which prompts must be programmed.

• Program Entry Selections: Only the selections

listed can be used for a particular program item. The programmer does not accept inappropriate entries.

• Program Entry Description: Provides concise

information regarding what can occur with the various entry selections. Read the descriptions carefully to avoid improperly programmed equipment.

• Custom Programming: A new feature of the

D5200 Programmer is the option to select custom programming (Yes or No) to expand programming modules within the D5200. Programming Custom as Yes does not affect a parameter’s programming. It allows parameters for special applications to be visible in the programmer.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 1.0 Introduction EN | 9

1.7 Programming the Control Panel

with the D5200 Programmer

Latch the jumper in the upper right hand corner of the control panel labeled as RESET on the PCB and Reset Pin on the faceplate. Connect the molex end of the cord to the connector labeled PROG on the PCB and PROG CONN on the faceplate. Always initiate a control panel copy at the NEWRECORD or FILENAME display when pressing the [RECV] (copy) key of the D5200. Always initiate a control panel load at the

FILENAME NEWRECORD

(load) key. Disconnect the D5200 before releasing the reset pin.

prompt or set as factory default at the

prompt when pressing the [SEND]

Do not leave the D5200 connected to the PROG connector without latching the RESET pin. Doing so causes SDI ## TROUBLE and CALL FOR SERVICE to display on the command centers. Door controllers also activate depending upon the SDI failure DIP switch setting.

Table 5: Programming Error Displays

Display Description

INCOMPATIBLE PANEL

CHECK CORD/RESET PIN

0101 0101 0101

There is a 5 second to 25 second pause after the reset pin is unlatched during

You are connected to the wrong control panel or using the wrong handler. Check the faceplate for the model number and the handler title.

Check the cord and reset pin

which the control panel scans all the points and properly displays, logs, and reports them.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 1.0 Introduction EN | 10

Notes:

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 11

The control panel is pre-programmed with a

2.0 9000MAIN

Use this programming module to define the operating characteristics that affect panel-wide functions. There are nine programming categories in this module: Phone, Phone Parameters, Routing, Enhanced Communications, Area Parameters, Command Center, User Interface, Function List, and Relay Parameters.

2.1 Phone

The control panel can dial up to four different telephone numbers when sending event reports. All telephone numbers use the same receiver format. Event report routing and communication protocols are discussed in Section 2.3 Routing.

Phone 1

Default: Blank

Selection:

Up to 24 characters (do not enter [SPACE])

7-second dial tone detect period. When a dial tone is detected or the waiting period ends, the control panel begins to dial. To extend the dial tone detect period, place a D before the phone number. To insert a pause during or after dialing, use C in the number sequence. For example, if the control panel hangs up before it hears the Modem IIIa from the D6500/D6600, program extra Cs after the phone number. The control panel waits on line for three extra seconds for each C programmed.

Enter up to 24 of the following characters to define dialing characteristics.

0101 0101 0101

Using both phone data entry lines: The first line of the phone number data entry line must be filled (twelve characters) before you press [ENTER] to move on to the second line. If you enter characters on the second line, and there are less than twelve characters on the first line, the second line clears when you press [ENTER].

Ack tone

Phone 2

0 to 9 Numbers 0 through 9

C 3-second pause

D 7-second dial-tone detect.

# or * Used for the same purpose as pressing

this key on a telephone keypad when manually dialing. For example, an asterisk (*) may be needed to access your long distance service. Do not use these characters when pulse dialing.

Default: Blank

Selection:

See explanation of 2, referred to in the prompts in Section 2.3 Routing.

Up to 24 characters (do not enter [SPACE])

Phone 1

. This number is Phone

Phone 3

Default: Blank

Blank Control panel dials no phone number.

Programming this item Blank does not disable phone routing. To disable reporting to this phone, see Section 2.3

Routing.

This is the telephone number the control panel dials to contact the central station receiver when sending event reports. This number is Phone 1 referred to in the prompts in Section 2.3 Routing.

Bosch Security Systems | 1/04 | 47775E

Selection:

See explanation of 3, referred to in the prompts in Section 2.3 Routing.

Up to 24 characters (do not enter [SPACE])

Phone 1

. This number is Phone

Phone 4

Default: Blank

Selection:

See explanation of 4, referred to in the prompts in Section 2.3 Routing.

Up to 24 characters (do not enter [SPACE])

Phone 1

. This number is Phone

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 12

2.2 Phone Parameters

The program items in this category describe panelwide characteristics for telephone dialing, receiver format, and supervision.

Modem Format

Default: Yes

Selection:

Yes

Central Station Receiver Format for Transmission of Reports: Modem format provides

many reporting advantages over the BFSK format. See the D6500/D6600 Report Directory for more information about the effect of reporting formats.

0101 0101 0101

Yes or No

Radionics’ Modem IIIa

Communication Format: Reports

identify points as 001 through 247 and passcode User ID codes as 000 through 249 at the D6500/D6600 Receiver (unless programmed Yes; see the

Flag

reporting point events, Radionics’ Modem IIIa

Point/User Flag

Point/User

prompt in this section). When

Communication Format also sends point text to the D6500/D6600 as programmed in Point Assignments.

BFSK (2300 Hz or 1400 Hz acknowledgment tone).

Modem Format must be set to Yes when sending events over a network to a D6600 receiver (NetCom).

If Modem Format is No, be sure to assign a number to identify Duress Reports in BFSK Duress Code in this programming section.

Point/User Flag

Default: Yes

Selection:

Yes The control panel sends a flag with

No The control panel does not send the

This program item determines how point and User ID numbers are presented at the D6500/D6600 display, printer, and computer RS-232 output.

Modem Format

When sends expanded Radionics’ Modem IIIa Communication Format reports to the D6500/D6600. If your central station data files are not set up for point and User ID number reporting, you can use this program item to convert these numbers to COMEX Reports.

When

Modem Format

sends expanded Radionics’ Modem IIIa Communication Format Reports to the receiver.

Point/User Flag

Communication Format data as shown in Table 6. The Bosch Security Systems D6500/D6600 Receiver adds the leading zero in the User ID number with

Point/User Flag

Yes or No

each report telling the D6500/D6600 to convert point numbers and User ID numbers to COMEX format. The conversions are shown in Table 6 and Table 7. No matter how the D6500/D6600 is programmed for output to the computer system, points and User ID numbers are converted when this item is Yes. (See the D6600

Communications Receiver/Gateway Computer Interface Manual, Appendix C, Numbered Table and Note 1.)

flag. The D6500/D6600 outputs point numbers as 001 to 247 (rather than 100 to 732) and User ID numbers as 000 to 249 (rather than 000 to F08), as indicated in Table 6 and Table 7.

is Yes, the control panel

affects Radionics’ Modem IIIa

programmed No.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 13

D6000: Opening/Closing User ID numbers are

Table 6: Modem IIIa2 Communication Format

Data - User ID Numbers

identified at the receiver as ZONEs (same identification as independent points).

Table 8: Zones

Point/User Flag NO

000 000 001 to 005 001 to 005 006 to 013 601 to 608 014 to 021 701 to 708 022 to 029 801 to 808 030 to 037 B01 to B08 038 to 045 C01 to C08 046 to 053 D01 to D08 054 to 061 E01 to E08 062 to 069 F01 to F08 070 to 249 000

Point/User Flag YES

User ID Number Zone

1 B 2C 3 D 4E 5 F 66 7 7 88 91 1 92 2 93 3 94 4 95 5 96 0

Table 7: Modem IIIa2 Communication Format

Data – Point Numbers

D6500/D6600 Receiving BFSK Format:

Opening/closing User ID numbers are identified at

Point/User Flag NO

Point/User Flag YES

001 to 008 100 to 800 009 to 024 101 to 116

the receiver as ZN (same identification as independent points). The ZN numbers are based on the tens digit of the User ID number. This only applies for Users 000 through 099. Users 100 through 249 do not report in BFSK format.

025 to 040 201 to 216 041 to 056 301 to 316 057 to 072 401 to 416 073 to 088 501 to 516 089 to 104 601 to 616 105 to 120 701 to 716 121 to 136 801 to 816 153 to 168 217 to 232 169 to 184 317 to 332 185 to 200 417 to 432 201 to 216 517 to 532

DTMF Dialing

Default: Yes

Selection:

Yes Dials the programmed phone

No Pulse dialing only.

Use dual-tone multi-frequency (DTMF) to dial the central station receiver phone number(s) for event reports, and/or the RPS.

Yes or No

number(s) using DTMF.

217 to 232 617 to 632 233 – 247 717 to 731

Independent Zone Control Notice: When using Independent Zone Controls (IZC) to send Opening/Closing Reports by point, do not duplicate reporting independent point numbers with User ID Reports (see Section 3.1 Passcode/Token Worksheet). For example: If an IZC is connected to Point 8, User ID 8 should not be used.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 14

Phone Supv Time

Default: Blank

Selection:

Blank or 10 to 240

Blank No phone line supervision.

10 to 240 Enter the number of seconds (in 10

second increments) you wish to supervise the phone line. After a faulted phone line restores, it takes the same amount of time to initiate restoral responses.

Phone line trouble responses: Command centers display SERVC PH LINE # to indicate which phone line failed. The command center initiates a trouble tone if

Tone

is Yes.

Buzz on Fail

is Yes and

CC Trouble

With dual phone lines (using the D928 Module), the restored phone line handles all messages regardless of the phone line’s number.

Phone, Trouble, and Restoral Events report when they occur. They report also when a Diagnostic Report is initiated from a command center or by a Sked.

Alarm On Fail

Default: No

Selection:

Yes Generate alarm responses when a

No Phone failures report as trouble

0101 0101 0101

Yes or No

phone line fails.

responses for Area 1 and/or the account number for Area 1.

Phone Supv Time must be programmed to use this feature.

Phone Failure Alarm Responses: The Alarm Bell relay for Area 1 activates. All Phone Event messages report as Area 1 and/or the account number for Area 1.

Buzz on Fail

Default: No

Selection:

Yes or No

Yes Generate panel-wide trouble tones and

display PHONE FAIL # at command centers when a Phone Fail Event occurs.

No Does not generate trouble tones at

command centers when a Phone Fail Event occurs. PHONE FAIL # still displays.

0101 0101 0101

Phone Supv Time must be programmed to use this feature.

De-selecting individual command centers for panel-wide trouble tones:

Panel-wide trouble tones for programming CC can turn off individual command centers (based on their CC # 1 through 8) # Trouble Tone in Command Center Parameters as No.

Two Phone Lines

Default: No

Selection:

Yes The D928 Dual Phone Line Module is

No No D928 Dual Phone Line Module.

Use this program item when a D928 Dual Phone Line Module is connected to the control panel. Both lines must operate the same; either ground start or loop start.

0101 0101 0101

Yes or No

installed. The LEDs on the D928 light to indicate primary or secondary line trouble and COMM FAIL.

IMPORTANT! Program Phone Supv Time when using two phone lines.

Bosch Security Systems | 1/04 | 47775E

NFPA standards prohibit the use of ground start phone lines in systems monitoring Fire points.

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 15

BFSK Duress Code

Default: 0

Selection:

If Duress Enable in Area Parameters is Yes and

Modem Format

must program a number to identify Duress Reports at the central station.

0 to 9

in Phone Parameters is No, you

Expand Test Rpt

Default: No

Selection:

Yes Report events listed in Routing Group

No Does not report off-normal conditions

Use this program item to add system event information to scheduled Test Reports. Test Reports are set up as scheduled events. See Section 5.2 Skeds.

Yes or No

Test Reports report to the central station if they are off-normal.

for the events listed in the Routing Group Test Reports at test time.

This parameter is related only to Sked Function Code 9 (Test Report) and whether this Sked transmits Expanded Test Report information or not. It does not have any bearing on Sked Function Codes 28 (Expanded Off-Normal Test Report) and 29 (Non-Expanded Off-Normal Test Report).

Ground Start

Default: Long

Selection:

Long Standard duration of ground. Use this

Short Shorter duration of ground. Use this

Some newer ground start telephone exchange switches require a shorter amount of time to initiate dial tone. If the control panel cannot initiate a dial tone on the ground start line with the default (long) setting, try the short setting.

Long or Short

setting for most ground start telephone systems. The duration is 700 milliseconds.

setting for telephone systems where specified. The duration is 250 milliseconds.

Press the [SPACE] bar to scroll through the selections. Press [ENTER] when the correct selection appears in the display.

Use this program item only when the control panel is connected to ground start telephone lines. Ground start is not allowed on UL Listed systems.

2.3 Routing

Use routing to select full or partial groups of events which report to up to four different destinations. Routing includes choosing the most important destination (route number), the events reported to a single or multiple destination, and if the events fail, selecting a backup destination.

2.3.1 Called Party Disconnect

Telephone companies provide called party disconnect to allow the called party to terminate a call. The called party must go on hook (hang up) for a fixed interval before a dial tone is available for a new call. This interval varies with telephone company equipment. D9412G/D7412G firmware allows for called party disconnect by adding a 35 second on hook interval to the dial tone detect function. If the control panel does not detect a dial tone in 7 seconds, it puts the phone line on hook for 35 seconds to activate called party disconnect, goes off hook and begins a 7-second dial tone detect. If no dial tone is detected, the control panel dials the number anyway. Each time the number is dialed, the control panel records this as an attempt. After ten attempts, the control panel goes into communications failure and Comm Fail Route # displays on the command centers.

2.3.2 Route Number Groups: Which Has the Highest Priority?

To program a group, first choose a route number. The lower the route number, the higher priority that group has (for example, events reported for Route 1 have a higher priority than Routes 2, 3, or 4 if each group tries to send a message at the same time). This becomes important when programming duplicate reports or choosing the events you want to ensure report first regardless of the number of events that need to report to multiple groups. Route 1 group primary device is the first destination the control panel attempts to dial if an event in that group must be reported. If the control panel is idle, any event generated for any group initiates a dialing sequence.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 16

2.3.3 Programming a Primary and Backup Destination

Each route number has an an

R# Backup Device

where two phone numbers are programmed, the

Primary Device

the route group attempts to dial first. If the

Primary Device

central station receiver after two dialing attempts, the

destination is the phone number

destination fails to connect to the

R# Backup Device

addition, the control panel can be programmed so the

R# Primary Device

Device

E Network Interface Module. The control panel can also be programmed to make only one attempt for the events using the

2.3.4 Enhanced Routing

In previous versions, only Phone numbers 1 through 4 could be programmed for the Primary and Backup Destinations. The D9412G/D7412G allow events to be transmitted to up to four additional SDI Paths. The D9133TTL-E Network Interface Module (with Ethernet) connects directly to the SDI Bus and occupies SDI Address 88. For additional information regarding the specific programming requirements for enhanced communications, see Sections 2.4 Enhanced Routing and 6.5 Enhanced Communications.

2.3.5 Programming a Duplicate Report

To allow an event within a group to report to multiple groups, the event should be Yes for each route number available. For instance, programming Fire Alarms for Route Group 1 and Route Group 2 results in the fire alarms first reporting to Route Group 1 followed by a duplicate report to Route Group 2.

can be an SDI device, such as a D9133TTL-

R# Primary Device

R# Backup Device

R# Primary Device

. In typical applications

destination is dialed. In

and/or the

before attempting to send

R# Backup

and

2.3.6 Routing Destination Communication Failures

When the the central station after one or two attempts (see

RG# 1 Attempt in

Attempts), the SDI Path is attempted. The central station receives the original event with a COMM FAIL PHONE# = (1, 2, 3, or 4) if the is a phone number. If the SDI Path, the central station receives the original event with A COMM FAIL RG# SDI## (SDI Path 1 = 88, SDI Path 2 = 89, SDI Path 3 = 90, SDI Path 4 = 91). When all attempts to both the

Device

RG# Event is generated. Comm Restore Events are not generated.

2.3.7 Message Prioritization within a Route

The D9412G/D7412G Control Panels meet the digital reporting requirements for UL 864. Fire Alarm Events have the highest priority and are reported first for each group. The next highest priority events are in the following order: panic, duress, medical, intrusion alarm, supervisory, and all troubles and restorals.

0101 0101 0101

2.3.8 Dialing Attempts

The D9412G/D7412G Control Panels have a prompt called Route Group Attempts.).

If this item is set to No, the control panel first makes up to six attempts to make contact using the primary device within a route group. If unsuccessful, it makes up to four attempts to make contact using the backup device before initiating a Comm Fail Report. When only one destination is programmed, the control panel makes ten attempts to contact that destination. Each group takes approximately 10 minutes to go into Comm Fail.

If this item is set to Yes, the control panel only makes one attempt (instead of two) to contact the primary device before attempting to contact the backup device. The route group still makes a total of ten attempts; however, the makes five attempts and then the

Device

R# Primary Device

Section 6.6.1 Route Group

R# Backup Device

R# Primary Device

fails to connect with

phone number or

destination

R# Primary Device

R# Primary

and

R# Backup Device

Number

To comply with NFPA and UL864, you must program Route 1 to report only Fire Alarm Events to ensure the fastest reporting time.

RG# 1 Attempt

fail, a Comm Fail

(see Section 6.6.1

R# Primary Device

R# Backup

makes five attempts.

is an

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 17

Route #

Default: 1

Selection:

1 First group sent

2 Second group sent

3 Third group sent

4 Fourth group sent

Enter the number specifying the route group to program. The route represents the group you wish to send a group of reports. The groups are prioritized. 1 is the first group to report and 4 is the last group to report. Each group has a primary and a backup device. The primary device is the first (most important) destination used to reach the programmed route within this group. The backup device is used if the primary device fails.

1 to 4

R# Primary Device

Default: Blank

Selection:

1 Phone 1 or SDI Path 1 is this group’s

2 Phone 2 or SDI Path 2 is this group’s

3 Phone 3 or SDI Path 3 is this group’s

4 Phone 4 or SDI Path 4 is this group’s

Enter the number specifying the primary device.

Blank, 1 to 4

primary destination.

R# Backup Device

Default: Blank

Selection:

1 Phone 1 or SDI Path 1 is this group’s

3 Phone 3 or SDI Path 3 is this group’s

4 Phone 4 or SDI Path 4 is this group’s

Enter the number specifying the backup device. The backup device is used when the primary device fails to reach the programmed destination.

Blank, 1 to 4

backup destination if the primary destination fails.

Phone 2 or SDI Path 2 is this group’s backup destination if the primary destination fails.

backup destination if the primary destination fails.

View Events?

Default: No

Selection:

Yes

The D5200 Programmer reveals the following subprompts. Leaving user to ignore a large area of programming that might not need to be changed.

Yes or No

Access each routing group and program individual events for this route group only (D5200).

Continue programming without viewing individual groups.

View Events?

as No allows the

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 18

Fire Reports

Selecting Yes enables a report to be sent when the event occurs.

Table 9: Diagnostic Reports

Report Selections Description

R# Fire Alarm R# Fire Restore

Yes, No Yes, No

(Alarm) R# Fire Missing

R# Fire Trouble R# Fire

Yes, No

Yes, No Yes, No

Supervis R# Fire Restore

Yes, No

(T/M/S)

R# Fire Cancel

R# Fire Sup

Yes, No

Miss R# Fire Supv

Rest

* This event is not reported when using BFSK format.

Yes, No

Reports Fire Event. Reports fire restoral

from alarm. Reports missing Fire

point. Reports fire trouble. Reports fire

supervision. Reports fire restoral

from trouble, missing, or bypass.

Reports canceled fire alarm.

Report fire supervisory missing.

Reports restorals from Fire Supervision.

Burglar Reports

Selecting Yes enables sending a report when the event occurs.

Table 10: Burglar Reports

Report Selections Description

R# Alarm

R# Burg

Yes, No

Restore

R# Duress R# Missing

Yes, No Yes, No

Alarm R# Usr Code

Yes, No

Tmpr R# Trouble Rpt

R# Missing Trbl

R# Non Fire

Yes, No

Suprv R# Pt Bus Fail

R# Pt Bus Rstl

R# Non Fire

Yes, No

Cncl R# Alarm

Yes, No

Restore R# Sup Missing

R# Unverfied

†*

Evt

† This event is not reported when using BFSK format. * This event does not produce a corresponding Restoral

Event.

Yes, No

Report Burglar Alarm Event.

Reports non-fire restoral from trouble, missing, or supervisory.

Duress Report. Reports missing

Alarm point. Reports user code

tamper. Reports Trouble

Event. Reports Missing

Trouble Event. Reports Non-fire

Supervision Event. Reports point bus

failure. Reports restoral of

point bus after failure. Reports canceled

non-fire alarm. Reports non-fire

restoral from alarm. Reports supervisory

missing. Reports Unverified

Events for Cross points.

Bosch Security Systems | 1/04 | 47775E

0101 0101 0101

The Unverified Event is transmitted when a single point programmed in Cross Point Group faults into an alarm condition then restores before the Cross Point Time elapses. This event encompasses both Fire and Non-fire points. It is not, however, related to the Verify Time used for smoke detectors.

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 19

Restoral Reports are not sent if the control panel is reset after a point is bypassed and then the point is unbypassed. This is true for both Fire and Non-fire points.

The 9000 Series Control Panels log a Ground Fault Event as Trouble Point 256.

User Reports

Selecting Yes enables a report to be sent when the event occurs.

Table 11: User Reports

Report Selections Description

R# Point Bypass

R# Forced Point

R# Point Open

R# Point Close

R# Forced Arm

R# Fail To Open

R# Fail To Close

R# Ext Clos Tm

R# Opening Rpt

R# Forced Close

R# Closing Rpt

R# FC Perim Inst

R# FC Perim Delay

R# Perim Inst Arm

R# Perim Delay Arm

R# Send User Text

Yes, No

Reports Point Bypass Event.

Reports Forced Point Event.

Reports Point Opening Event.

Reports Point Closing Event.

Reports point forced armed.

Reports Fail to Open Event.

Reports Fail to Close Event.

Reports Extend Close Time Event.

Reports Opening Events.

Reports Point Forced Close Event

Reports Closing Events.

Reports Forced Close Perimeter Instant Armed Event.

Reports Forced Close Perimeter Delay Armed Event.

Reports Perimeter Instant Armed Event.

Reports Perimeter Delay Armed Event.

Reports user text.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 20

0101 0101 0101

Test Reports

To send a single Test Report (R# Test Report), enable Sked Function Code #9 (Test Report) in the Skeds section of the program.

To expand this Test Report to include any off-normal point condition or other offnormal conditions of events listed in Diag Reports as a Non-status Event following a Test Report, Expand Test Rpt in Section

2.2 Phone Parameters must be programmed Yes.

Events R# Log Threshold, R# Log Overflow, and R# RAM Fail are added to the reports sent with Expanded Test Reports if they are enabled in RAM Reports and Expand Test Rpt is also enabled.

To initiate a Status Report, which includes all R# S: ____ Events as a Status Event (as opposed to a Non-status Event), Sked Function Code #10 must be enabled in the Skeds section of the program.

Reporting off-normal conditions as a Status Report following a Test Report is required by some automation systems. Reporting offnormal conditions as a Non-status Report, which follows a Test Report, is required for other automation systems.

An off-normal condition is any point which is missing, trouble, supervisory, or in alarm (as opposed to normal). Also, points not cleared at the command center report as off-normal.

Control Panels with Firmware version 6.30 or higher can generate an Expanded OffNormal Test Report by using Sked Function Code 28 or a Non-Expanded Off-Normal Test Report using Sked Function Code 29. To generate this event, one or more points must be in an off-normal state at the time the Sked executes. Expanded Off-Normal Test Reports include the Off Normal Test Report Event as well as events for any points that are in an off-normal state at the time the report is generated. Non-Expanded Off-Normal Test Report Events are only sent when a point is in the off-normal state but only sends the Off Normal Test Report Event.

Table 12: Test Reports

Report Selections Description

R# S: Alarm R# S: Trouble

Yes, No Yes, No

Status Alarm Report Status Trouble

Report

R# S: Supervised

R# Status

Yes, No

Status Supervised Report

Status Report

Report R# S: Open R# S: Close R# Test Report R# S: Perim

Inst R# S: Perim

Delay R# S: Fire Supv

Yes, No Yes, No Yes, No Yes, No

Yes, No

Status Open Report Status Close Report Test Report Status Perimeter

Instant Arm Report Status Perimeter

Delay Arm Report Status Fire

Supervision Report

R# S: Fire Alarm

R# S: Fire Trbl

Yes, No

Status Fire Alarm Report

Status Fire Trouble Report

R# S: Msng Fire

R# S: MsngBurgTr

R# S: MsngBurgAl

R# S: FireSpMsng

Yes, No

Status Fire Missing Report

Status Burg Missing Trouble Report

Status Burg Missing Alarm Report

Status Fire Supervision Missing Report

R# S: SuperMsng

Yes, No

Status Non-fire Supervision Missing Report

R# S: DrLeftOpen

Yes, No

Status Door Left Open Report

Diag Reports

Selecting Yes enables sending a report when the event occurs. If the off-normal state of the following events (indicated with an *) still exist, they report when a Test Report (see the prompt in Section 2.3.8 Dialing Attempts) is initiated and Expanded Test Rpt is programmed Yes.

Test Reports

sub-

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 21

Table 13: Diagnostic Reports

Report Selections Description

R# SDI Dev Fail*

R# SDI Dev Restl

R# Watchdog Rset

R# ParaChksmFail

R# Reboot R# Ph Line Fail*

R# Ph Line Rstl

R# AC Fail*

R# AC Restorl

R# Batt Missing*

R# Battery Low*

R# Battery Rstl

R# Rt Comm

Fail* R# Rt Comm Rstl

R# Checksum Fail

R# Network Fail

R# Network

Rest

R# Network

Cond

This event covers Comm Fail Route Group and Comm

Fail Phone. If enabled, both events are sent; if disabled, neither event is sent.

This event reserved for future use.

Yes, No

Yes, No Yes, No

Yes, No

Reports SDI device failure.

Reports restoral of SDI device failure.

Reports Watchdog Reset Event.

Reports parameter checksum failure.

Reports Reboot Event. Reports failure of phone

line. Reports restoral of

phone line after failure. Reports failure of AC

power to control panel. Reports restoral of AC

power to control panel after failure.

Reports Battery Missing Detection Event.

Reports low battery power.

Reports restoral of battery power to control panel after Missing or Low Event.

Reports failure to send report to specific route.

Reports restoral of communication to specific route after a failure.

Reports Checksum Fail Event.

Reports failure of network.

Reports restoral of network.

Reports condition of network.

Relay Reports

Selecting Yes enables sending a report when the event occurs.

Table 14: Relay Reports

Report Selections Description

R# Sensor Reset

R# Relay Set

Yes, No

Reports Sensor Reset Event.

Reports Relay Set Event.

R# Relay Reset

Yes, No

Reports Relay Reset Event.

When activating an on-board relay using PC9000, the 9000 Series Control Panel logs and prints the event as Relay 250 (Relay A), Relay 251 (Relay B), and Relay 252 (Relay C).

AutoFunc Reports

The following prompts support customized routing of Auto Function Reports. Selecting Yes enables a report to be sent when the event occurs.

Table 15: Auto-Function Reports

Report Selections Description

R# Sked Executed

R# Sked Changed

R# Execute Fail

Yes, No

Reports Sked Executed Event.

Reports Sked Changed Event.

Reports a Fail to Execute Event.

0101 0101 0101

Only turn on Rt Comm Fail and Rt Comm Restore in one route group.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 22

RAM Reports

Selecting Yes enables sending a report when the RAM Passcode Event occurs.

RAM Access Fail can indicate a wrong RAM passcode when communicating with the control panel, or a valid RAM session was terminated by a means other than a Good-bye or Resetbye command. Remote Reset indicates a Reset-bye command issued from RAM, Bad Call to RAM indicates the control panel called RAM but was unable to connect.

Table 16: RAM Reports

Report

R# Log Threshold

R# Log Overflow

R# Para Changed

R# RAM OK

R# RAM Fail

R# Remote Reset

R# Program OK

R# Program Fail

Selection s

Yes, No

Description

Reports Event log threshold reached.

Reports Log is full, old events are overwritten.

Reports RAM Parameter Change Event.

Reports Successful RAM Access Event.

Reports Failed Access RAM Event.

Reports Remote Reset Event.

Reports Successful Laptop Access Event.

Reports Failed Laptop Access Event.

Point Reports

Selecting Yes enables a report to be sent when the event occurs.

Table 17: Point Reports

Report Selections Description

R# Service Start

R# Service End

R# Fire Walk St

R# Fire Walk End

R# Walk Test St

R# Walk Test End

R# Extra Point

R# Send Point Text*

R# RF Low Bat

R# RF Low Bat Res

* Point text is always transmitted when using

NetCom applications.

Yes, No

Reports Service Walk Test Start Event.

Reports Service Walk Test End Event.

Reports Fire Walk Start event.

Reports Fire Walk End Event.

Reports Walk Test Start Event for Walk Test and Invisible Walk Test.

Reports Walk Test End Event for Walk Test and Invisible Walk Test.

Reports Extra Point Event.

Reports point text.

Reports low battery conditions for RF points.

Reports low battery restoral conditions for RF points.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 23

User Chng Reports

Selecting Yes enables a report to be sent when the event occurs.

Table 18: User Change Reports

Report Selections Description

R# Date Changed

R# Time Changed

R# Delete User*

R# User Code Chg

R# Area Watch

R# Card Assigned

R# Change Level

* With R# Delete User Events, the control panel

always uses the account number from Area 1.

Yes, No

Reports Date Change Event.

Reports Time Change Event.

Reports Delete User Code Event.

Reports User Passcode Add or Change Event.

Reports area watch start and watch end.

Reports Card Assigned to User Event.

Reports Access Control Level Change Event.

Access Reports

Selecting Yes enables a report to be sent when the event occurs.

Access Granted, No Entry, Request to Enter (RTE) and Request to Exit (REX) Events may be turned on or off by each D9210B.

Table 19: Access Reports

Report Selections Description

R# Access Granted

R# No Entry

R# Door Lt Open

R# Cycle Door

R# Door Unlocked

R# Door Secure

R# Door Request

R# Door Locked

Yes, No

Reports Access Granted Event.

Reports No Entry Event.

Reports Door Left Open Event.

Reports Open Door Event.

Reports Unlock Door Event.

Reports Secure Door Event.

Reports RTE or REX Event.

Reports Locked Door Event.

2.4 Enhanced Routing

Enhanced routing allows the control panels to determine whether events are routed over standard telephone lines and/or a local/wide area network (LAN/WAN). To send events over a LAN/WAN, a D9133TTL-E (SDI-Network Interface Module) is required. Additionally, enhanced routing enables/disables the control panel’s ability to send events to a numeric pager. If the installation does not require these applications, skip this section.

With enhanced routing, whether you use standard telephone lines or the D9133TTL-E, you can select full or partial groups of events to be reported to up to four different destinations. Routing includes choosing the most important destination, whether events report to a single or multiple destinations, and if the events fail, the backup destination used.

2.4.1 Programming a Primary and Backup Destination

Each route number has an an

R# Backup Device

enhanced communications, the destination can be either the phone number or the path number IP address to which the route group first attempts to send the event. If the

Device

station receiver after one or two attempts (see also

RG# 1 Attempt

destination is attempted.

destination fails to connect to the central

), the

R# Primary Device

. With the addition of

R# Primary Device

R# Primary

R# Backup Device

and

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 24

2.4.2 Programming a Duplicate Report

Section 2.4 Enhanced Routing determines the route groups and which destinations within the route groups use D9133TTL-E Modules for reporting purposes. A single D9133TTL-E Module can be used to transmit events to up to four different destinations.

For example, if you want to send events using Route Group 1 over a LAN/WAN as your primary destination, and use a standard telephone line as your backup destination, you must program the following sections:

1. Routing (see Section 2.3 Routing) a. Select Route Group 1

b. Program a 1 for Primary Destination c. Program a 1 for Backup Destination d. Enable all applicable events to be included

in Route Group 1.

Phone (see Section 2.1 Phone)

a. Select Phone 1. b. Program Phone 1 with the applicable central

station receiver phone number.

Enhanced Routing (see Section 2.4 Enhanced Routing)

a. Enter Yes for Route Group 1 Primary SDI.

(Tells the control panel to send the events to the D9133TTL-E using IP Address 1.)

b. Enter No for Route Group 1 Backup SDI.

(Tells the control panel to use the phone line to send events if the primary destination fails after one or two attempts.)

Because you are using an SDI Path to send events, you must also program the applicable items in Section 6.5 Enhanced Communications.

If you use a D9133TTL-E as a Primary Device in any of the route groups, follow these programming rules:

• Assign IP Address 1 as the Primary

Device in Route Group 1.

• Assign IP Address 2 as the Primary

Device in Route Group 2.

• Assign IP Address 3 as the Primary

Device in Route Group 3.

• Assign IP Address 4 as the Primary

Device in Route Group 4.

The backup device in any route group can use any phone number or IP address number.

If the External Modem feature is used, RG# Primary SDI and RG# Backup SDI must be set to No. The control panel supports either enhanced communication or external modem, but not both at the same time.

RG# Primary SDI

Default: No

Selection:

Determines if the primary destination for Route Group 1 (2, 3, or 4) is sent to the D913TTL-E.

Yes or No

RG# Backup SDI

Default: No

Selection:

This item determines if the backup destination for Route Group 1 (2, 3, or 4) is sent to the D913TTL-E.

Yes or No

To completely disable Enhanced Routing over an SDI path, RG#Primary SDI, RG#Backup SDI, and Enhanced Comm prompts must all be set to No.

Bosch Security Systems | 1/04 | 47775E

The poll rate entry for the backup SDI path might need to increase due to the amount of traffic on the network and/or excessive signals generated at once. Comm prompts must all be set to No.

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 25

[

1234

001-011-008

]

RG# Primary Pager

Default: No

Selection:

Determines if this route group sends events to a numeric pager. To send events to a numeric pager, a phone number must also be programmed in the route group’s primary destination.

0101 0101 0101

Numeric Pager Capability

The D9412G/D7412G Control Panels can transmit nearly any event to a numeric pager. Any time an event is generated and routed to a numeric pager, the control panel attempts to call the numeric pager once for each message in the queue. To enable the pager, program both the primary and backup phone number to the numeric pager’s phone number in any of the four route groups. Then select which events are to be routed to the numeric pager within the route group selected. When events are sent to a numeric pager, up to four fields can be displayed in the pager message. See

Figure 1.

Figure 1: Pager Display Fields

1 - Account number (1234) 2 - Event policy (001) 3 - Event number (011, Fire Alarm Event) 4 - User number, point number, or relay number

(008)

Yes or No

If programming the control panel to dial a numeric pager, choose its route group carefully. If there are any events to transmit to a central station, be sure to place those events in a lower numbered route group class than the events that are in the route group for the numeric pager.

The account number must contain four numeric digits. No alpha characters (B to F) are allowed when using the numeric pager.

Programming the Pager Phone Number

To program the pager phone number, enter the number used to reach the pager, followed by pauses. Entering C creates a 3-second pause (example: 5552341CCC.)

Experiment with the number of pauses you add after the page phone number. Each pause equals 3 seconds. Try calling the pager yourself first and listening to the length of time it takes to get a beep allowing you to enter touch-tone information. This length is what you must program after the pager’s phone number in Section 2.1 Phone. If you need a longer pause, enter D after the number. Each D equals to 7 seconds.

Using “#” characters in the phone number can affect how the event is displayed on the pager:

• No “#” characters in phone number: Dashes

appear in the display [1234-001-011-008].

• One “#” character in phone number: Dashes

are replaced by zeros [1234000100110008].

• Two or more “#” characters in phone

number: Dashes appear in the display [1234-

001-011-008].

For example, if the phone number 2773074#CC (seven-digit pager phone number followed by “#” and two pauses) is programmed, the pager message displays as follows: [1234000100110008] (dashes are replaced by zeros).

If the “#” is not placed in the phone number, the message displays as follows: [1234-001-011-008]

Also, a user may not want all four fields to be displayed in the pager message. “*” characters in the phone number allow the user to select the number of fields to be displayed in the pager message. To limit the number of fields shown in the pager message, enter the appropriate number of “*” characters in the phone number as shown below.

• Zero “*” characters in phone number: All

four fields are displayed.

• One “*” character in phone number: First

field only is displayed.

• Two “*” characters in phone number: First

two fields are displayed.

• Three “*” characters in phone number: First

three fields are displayed.

• Four or more “*” characters in phone

number: All four fields are displayed.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 26

For example, the phone number 2773074***CC (7 digit pager phone number followed by three

Table 20: continued

asterisks and two pauses) produces the following pager display: [1234-001-011] (three fields display at the pager).

Table 20 shows the description of each event, its priority, and event number.

Table 20: Event Descriptions, Priorities, and

Numbers

Event

Event Description

Fire Alarm 001 011 Fire Restoral (after Alarm, Supervision) 005 014 Fire Missing 005 013 Fire Trouble 005 012 Fire Supervision 005 124 Fire Restoral (after Tbl, Msg, Bypass) 005 015 Fire Cancel 004 027 Fire Supervision Missing 005 146 Fire Supervision Restore 005 123 Alarm Report 003 016 Burg Restore 006 018 Duress 002 004 Missing Alarm 006 019 User Code Tamper 008 055 Trouble Report 006 017 Missing Trouble 008 020 Non-Fire Supervision 006 078 Point Bus Fail 006 024 Point Bus Restoral 006 091 Non-Fire Cancel 004 045 Alarm Restore 006 026 Supervision Missing 008 147 Unverified Event 006 169 Point Bypass/Command Bypass 007 007 Forced Point 007 008 Point Opening 008 021 Point Closing 008 022 Was Force Armed 007 034 Fail To Open 008 040 Fail To Close 008 041 Extend Close Time 008 044 Opening Report 008 047 Forced Close 007 048 Closing Report 008 050

Priority

Event Number

Event

Event Description

Forced Close Perim Instant 007 084 Forced Close Perim Delay 007 085 Perimeter Instant Armed 008 088 Perimeter Delay Armed 008 089 Send User Text n/a n/a S: Alarm n/a n/a S: Trouble n/a n/a S: Supervision n/a n/a Status Report 008 035 S: Open n/a n/a S: Close n/a n/a Test Report 008 051 S: Perimeter Instant n/a n/a S: Perimeter Delay n/a n/a S: Fire Supervision n/a n/a S: Fire Alarm n/a n/a S: Fire Trouble n/a n/a S: Missing Fire (Trouble) n/a n/a S: Missing Burglary ((Trouble) n/a n/a S: Missing Burglary (Alarm) n/a n/a S: Fire Supervision Missing n/a n/a S: Burglary Supervision Missing n/a n/a S: Door Left Open n/a n/a SDI Device Failure* 004 070 SDI Device Restoral* 008 071 Watchdog Reset 004 077 Parameter Checksum Fail n/a n/a Reboot 008 082 Phone Line Fail 004 068 Phone Line Restoral 008 069 AC Failure 004 072 AC Restoral 008 073 Battery Missing 004 074 Battery Low 004 075 Battery Restoral 008 076 Route Comm Fail 004 066 Route Comm Restore 008 067 Checksum Fail n/a n/a Sensor Reset 007 031 Relay Set 007 032 Relay Reset 007 033 Sked Executed 007 057 Sked Changed 007 058 Fail to Execute 008 151 Event Log Threshold 008 052 Event Log Overflow 008 053

Priority

Event Number

* SDI Device number is not reported when using pager format.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 27

Table 20: continued

Event

Event Description

Parameters Changed 008 054 RAM Access OK 008 064 RAM Access Fail 008 065 Remote Reset 008 079 Program Access OK n/a n/a Program Access Fail n/a n/a Service Start 008 029 Service End 008 030 Fire Walk Start 008 036 Fire Walk End 008 037 Walk Test Start 008 038 Walk Test End 008 039 Extra Point 008 023 Send Point Text n/a n/a RF Low Battery 006 093 RF Battery Restore 006 094 Date Changed 008 059 Time Changed 008 060 Delete User 008 090 User Code Change 008 056 Area Watch 008 042 Card Assigned 008 110 Change Level 007 061 Access Granted 008 003 No Entry 008 115 Door Left Open 008 116 Cycle Door 008 112 Door Unlocked 008 113 Door Secure 008 114 Door Request 008 117 Door Locked 008 145 User Alarm COMMAND 7 002 005 User Alarm COMMAND 9 002 006

Priority

Event Number

2.5 Power Supervision

AC Fail Time

Default: 15

Selection:

Program the amount of time that AC power must be off before the control panel responds to the AC failure. Beginning with version 6.20 and higher, changes were made as to how AC Fail Events are generated. See the following information to determine the available options. The response to restoral of AC power is delayed for the same amount of time. The control panel always monitors AC.

When you program digit is:

• 1, 3, 5, 7, or 9 (such as 3, 5, 11, 13, 15, 21, and

so on): The

• 2, 4, 6, 8, or 0 (such as 2, 4, 6, 10, 12, 20, 22,

and so on): The AC Fail Time interval is in seconds.

For the following items to be true, must be programmed as Yes and must be programmed as No.

When you program digit is:

• 1, 3, or 5 (such as 3, 5, 11, 13, 15, 21, and so

on): The AC Fail Time interval is in minutes

and an AC Fail Event is transmitted after the loss of AC for this amount of time. No additional AC Fail Events are transmitted after 6 hours or 12 hours.

• 2, 4, or 6 (such as 2, 4, 6, 12, 14, 16, 22, 24, 26,

and so on): The AC Fail Time interval is in

seconds and an AC Fail Event is transmitted after the loss of AC for this amount of time. No additional AC Fail Events are transmitted after 6 or 12 hours.

• 7 (such as 7, 17, 27, 37, and so on): The AC

Fail Time interval is in minutes and an AC Fail Event is transmitted after the loss of AC for this amount of time. An additional AC Fail Event is transmitted after 6 hours if the AC Fail condition is still present.

• 8 (such as 8, 18, 28, 38, and so on): The AC

Fail Time interval is in seconds and an AC Fail Event is transmitted after the loss of AC for this amount of time. An additional AC Fail Event is transmitted after 6 hours if the AC Fail condition is still present.

1 to 90 (Blank and 0 are invalid)

AC Fail Time

, if the second

interval is in minutes.

AC Fail/Res Rpt

AC Tag Along

AC Fail Time

, if the second

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 28

• 9 (such as 9, 19, 29, 39, and so on): The AC

Fail Time interval is in minutes and an AC Fail Event is transmitted after the loss of AC for this amount of time. An additional AC Fail Event is transmitted after 12 hours if the AC Fail condition is still present.

• 0 (such as 10, 20, 30, and so on): The AC Fail

Time interval is in seconds and an AC Fail Event is transmitted after the loss of AC for this amount of time. An additional AC Fail Event is transmitted after 12 hours if the AC Fail condition is still present.

For the following items to be true, must be programmed as No and

AC Fail/Res Rpt

AC Tag Along

must also be programmed as No.

When you program

AC Fail Time

, if the second

digit is:

• 1, 3, or 5 (such as 3, 5, 11, 13, 15, 21, and so

on): The AC Fail Time interval is in minutes.

AC Fail/Res Rpt

Default: No

Selection:

Yes Send AC Fail and AC Restoral

No Does not send AC Fail and AC

AC Power Supervision Reports are sent to the central station and local printer at the time programmed for

0101 0101 0101

Yes or No

Reports.

Restoral Reports.

AC Fail Time

To comply with NFPA standards and UL 864 requirements for commercial fire systems, program this item as No and program AC Tag Along as Yes. AC Restoral Reports are not transmitted.

No AC Fail or AC Restoral Events are transmitted.

• 2, 4, or 6 (such as 2, 4, 6, 12, 14, 16, 22, 24, 26,

and so on): The AC Fail Time interval is in

seconds. No AC Fail or AC Restoral Events are transmitted.

AC Tag Along

Default: Yes

Selection:

Yes Send AC messages as tag along events.

Yes or No

• 7 (such as 7, 17, 27, 37, and so on): The AC

Fail Time interval is in minutes. An AC Fail Event is only transmitted after 6 hours if the AC Fail condition is still present.

• 8 (such as 8, 18, 28, 38, and so on): The AC

Fail Time interval is in seconds. An AC Fail Event is only transmitted after 6 hours if the AC Fail condition is still present.

• 9 (such as 9, 19, 29, 39, and so on): The AC

No Do not send AC messages as tag along

events.

Send AC Reports only if any other event occurs while AC is off-normal.

If AC Tag Along is set to Yes and a subsequent event is generated, the AC Fail Event is transmitted first, prior to any subsequent events transmitting.

Fail Time interval is in minutes. An AC Fail Event is only transmitted after 12 hours if the AC Fail condition is still present.

• 0 (such as 10, 20, 30, and so on): The AC Fail

Time interval is in seconds. An AC Fail Event is

0101 0101 0101

AC Tag Along is required for NFPA and UL 864 commercial fire systems. Be sure to program AC Fail/Res Rpt as No if AC Tag Along is programmed Yes.

only transmitted after 12 hours if the AC Fail condition is still present.

Firmware versions 6.20 and higher: To eliminate AC Reporting, AC Tag Along and AC Fail/Res Rpt must be programmed No and the second digit of the AC Fail Time must be a 1, 2, 3, 4, 5, or

Firmware versions 6.10 and lower: To

eliminate AC Reporting, AC Tag Along

eliminate AC Reporting, AC Tag Along and AC Fail/Res Rpt must be

and AC Fail/Res Rpt must be programmed No.

Bosch Security Systems | 1/04 | 47775E

programmed No.

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 29

AC/Battery Buzz

Default: No

Selection:

Yes or No

Yes Initiates panel-wide trouble tone at all

command centers.

No Does not initiate panel-wide trouble

tone at command centers

Initiate a panel-wide trouble tone at command centers when AC fails or battery is low or missing. This program item does not prevent the SERVC AC FAIL or SERVC BATT LOW displays.

0101 0101 0101

To comply with NFPA standards and UL 864 requirements for commercial fire systems, program this item as Yes.

De-selecting individual command centers for panel-wide trouble tones: Panel-wide trouble tones for programming the CC Trouble Tone in the command center parameters to No can turn off individual command centers [based on their CC# (1 to 8)].

Bat Fail/Res Rpt

Default: Yes

Selection:

Battery Failure and Restoral Reports are sent

Yes

to the central station. They are routed to the telephone number programmed for Power/Phone Events.

Modem Reports

Yes or No

Missing or shorted

Discharged below 12.1 VDC

BATTERY MISSING

BATTERY LOW

2.6 Printer Parameters

Up to three D9131A Parallel Printer Interface Modules can be connected to the D9412G’s (one printer for the D7412G’s) SDI bus. Each printer is identified by an address of 17, 18, or 19. Options are available for Routing Reports and area assignments.

Printer Address

Default: 17

Selection:

Enter the printer address you are programming.

P## Area Assign

Default: 1

Selection:

Assign an area to the printer programmed in

Address

P## Supervised

Default: No

Selection:

Yes

No More than one unsupervised printer

Supervise this SDI address and generate Trouble SDI ## Reports and local trouble annunciation if a problem occurs with this printer or the SDI bus.

17, 18, or 19 (only 17 is available for the D7412G)

1 to 8

Yes or No

Only one printer can be installed for this

P## SDI

can be installed using this

address.

P## SDI

address using the same address DIP switch setting.

Unsupervised printers sharing the same address setting print the same text.

Printer

BFSK Reports

Missing, shorted low battery

TROUBLE ZONE 9

No Battery Failure and Restoral Reports are NOT

sent to the central station.

0101 0101 0101

To comply with NFPA standards and UL 864 requirements for commercial fire systems, program this item as Yes.

Bosch Security Systems | 1/04 | 47775E

Trouble SDI ## Reports are always reported as Area 1, Account 1 Events regardless of where the SDI device is assigned.

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 30

When P## Supervised is set to Yes and all Printer Event Groups (such as P##

Fire Events, P## Burglar Event, or P## Usr Chng Evt) are set to No, the control

panel does not generate Trouble SDI ## Reports for the printer if the D9131A becomes disconnected.

P## Scope

Default: No Printer

Selection:

Panel Wide

Account

Area Printer prints all designated events that

Custom See the following Programming Tip.

No Printer No printer installed at this address. If a

Press the [SPACE ] bar to scroll through the selections. Press [ENTER] when the correct selection appears in the display.

0101 0101 0101

No Printer, Area, Account, Panel Wide, Custom

Printer prints all designated events that occur panel-wide. A panel-wide printer can cross account boundaries.

Printer prints all designated events that occur within any area with the same account number in which this printer is assigned.

occur in the area to which this printer is assigned.

Printer prints all events occurring in areas programmed Yes for this prompt regardless of any boundary restrictions.

printer is connected, data does not print.

The following prompts are visible ONLY when you program P## Scope to Custom.

See the report tables in Section 2.3 Routing to identify the events that print. Events programmed as No in routing still print at the local printer. Individual events within the report group cannot be suppressed for events printed at the local printer.

P## Fire Events

Default: See

Selection:

Yes

Use this prompt to determine whether these events print at this printer.

Program Record Sheet

Yes or No

All events in this group print at this printer.

No events in this group print at this printer.

P## Burglar Event

Default: See

Selection:

Program Record Sheet

Yes or No

P## Access Event

Default: See

Selection:

Program Record Sheet

Yes or No

P## User Event

Default: See

Selection:

Program Record Sheet

Yes or No

P## Test Event

Default: See

Selection:

Program Record Sheet

Yes or No

P## A1 [through A8] in Scope

Default: No

Selection:

Yes Include Area # Events in the scope of

No Does not include Area # Events in the

Only available if Custom. This program item determines whether events occurring in an area prints at this printer.

Bosch Security Systems | 1/04 | 47775E

Yes or No

this printer.

scope of this printer.

P## Scope

is programmed

P## Diag Event

Default: See

Selection:

Yes or No

Program Record Sheet

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 31

P## Auto Functions Event

Default: See

Selection:

Program Record Sheet

Yes or No

P## RAM Event

Default: See

Selection:

Program Record Sheet

Yes or No

P## Relay Event

Default: See

Selection:

Program Record Sheet

Yes or No

P## Point Event

Default: See

Selection:

Program Record Sheet

Yes or No

P## Usr Chng Evt

Default: See

Selection:

Program Record Sheet

Yes or No

2.7 RAM Parameters

Use these program items to enable Remote Account Manager (RAM) functions in the control panel using the on-board phone connection. Two other methods of remote programming are available (external modem or LAN/WAN connection) using RAM. See Section 6.4 SDI RAM Parameters for further information on these types of remote programming.

2.7.1 Uploading and Downloading Reports

If the control panel is programmed to send reports in modem format, when RAM makes contact with the control panel and the passcode is incorrect, the control panel sends a RAM Access Fail Report to the D6500/D6600. RAM Access Fail is also generated when the call is not terminated with either a Good-bye or Reset-bye command.

RAM ACCESS OK is sent according to phone routing when a Good-bye command is entered from RAM to terminate the call.

When a Reset-bye is used to terminate the call, a Remote Reset Report is sent to the D6500/D6600, and a RAM ACCESS OK is placed into the control panel’s event log. Reports in the event log that were not sent prior to the Reset-bye are never sent to the D6500/D6600.

When RAM programming changes parameters, a Parameters Changed Report is sent to the D6500/D6600. If any programming changes are made, perform a Reset-bye.

When RAM attempts to make contact with the control panel, the RAM passcode and DataLock code are verified. If the control panel passcode matches and the DataLock code does not, the control panel still generates a RAM Access OK Event. However, the session ends immediately.

To disable remote programming, enter Blank in both

Answer Armed

prompts in this section.

2.7.2 Log Threshold Reports

If communication with RAM is not successful, or if no phone number is programmed in control panel generates Log Threshold and Bad Call to Ram. This indicates the log is filling and the control panel cannot download its events.

If there is no panel generates the Log Threshold and Bad Call to RAM Events immediately. Bad Call to RAM Events are currently logged locally only. If there is a

programmed, the control panel makes multiple attempts to reach RAM before sending the reports. See the an explanation of dialing characteristics.

2.7.3 RAM Callback Reports

When dialing the RAM phone number, the control panel immediately makes two attempts to reach RAM. If the control panel does not reach RAM on the first two attempts, it waits 10 minutes then tries six more times with a 10-minute interval between each attempt. One hour after the last failed attempt, the control panel again starts dialing the RAM phone number. It immediately makes two more attempts then waits 10 minutes and tries six more times with 10-minute intervals between each attempt before generating a Bad Call to RAM Report and abandoning the effort.

Remote Program Dialing Exception: When a RAM phone number is programmed, the user can call RAM by entering [COMMAND][4][3] and pressing the [NEXT] key until CALLRAM? is displayed. Press [ENTER]. When performing this function, only one attempt is made to contact RAM.

RAM Ph

and

Answer Disarmed

RAM Ph

programmed, the control

, the

RAM

prompt in the following section for

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 32

RAM Passcode

Default: 999999

Selection:

0 to 9, A to F (six characters required)

Enter six characters. Do not use a space in the passcode.

The control panel verifies the Remote Account Manager at the central station has valid access before connecting using the RAM passcode.

Log % Full

Default: Blank

Selection:

This parameter determines how full the memory log should be before initiating a call to RAM at the central station. This allows the central station to call the control panel and copy the memory log before messages are overwritten.

Blank disables the Log Threshold and Log Overflow Events. These events are not entered in the log or reported to the D6500/D6600 or the local printer.

The control panel continues to log events after the Log Threshold Report is sent. When it reaches 100% capacity (memory logger is full and previously stored events are overwritten), the control panel generates a local Log Overflow Event.

The control panel does not call RAM again until it downloads the log and the Log % Full percentage is again reached. These events are also sent to the control panel’s event log and to the local printer(s) if installed.

0101 0101 0101

1 to 99, or Blank

The Log Overflow Event is not sent to the central station unless Expanded Test Rpt is programmed Yes.

RAM Call Back

Default: No

Selection:

Yes or No

Yes When the control panel hears the

proper RAM passcode, it hangs up the phone, seizes the phone line, then dials the programmed RAM phone number (see the

RAM Ph

prompt in this section). This ensures that the control panel only communicates with RAM units connected to the programmed phone number.

The RAM session is initiated immediately. No call back is required. The control panel can engage in RAM sessions when called from any phone number and a proper RAM passcode is identified.

This function allows the control panel, after it verifies the RAM passcode, to provide an additional level of security by hanging up and dialing the RAM phone number at the central station before allowing any upload or download.

0101 0101 0101

When using the RAM Call Back feature, be sure to program the character “C” as the last digit in the RAM phone number when using DTMF Dialing.

RAM Line Monitor

Default: Yes

Selection:

Yes Allows the control panel to

Yes or No

communicate with RAM after the answering machine answers the phone.

Bosch Security Systems | 1/04 | 47775E

No Program No if the control panel is not

sharing the phone line with an answering machine.

This program item enables a control panel, which shares a phone line with an answering machine, to communicate with RAM at the central station even though the answering machine answers the phone. You must program

Disarmed

. The control panel must be in the proper

Answer Armed

and/or

Answer

armed state.

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 33

0101 0101 0101

Program this item No if it causes false seizures of the phone line or if you are not using RAM (this indicates a device using the same frequency tone is also using the phone line to which the control panel is connected).

If RAM Call Back is programmed Yes, the control panel hangs up the phone after the RAM tone and a proper RAM passcode is identified. It then calls the RAM phone number.

Answer Armed

Default: See

Selection:

Blank No answer.

1 to 15 The control panel answers the phone

Set the telephone ring counter to answer when all areas are master armed. If any area in the control panel is perimeter armed or disarmed, the Answer Disarmed ring counter is used.

The RAM considers perimeter armed as a disarmed state.

Program Record Sheet

1 to 15, or Blank

after the specified number of rings when all areas are master armed.

Ram Ph

Default: Blank

Selection:

Blank Control panel does not dial a phone

This is the phone number the control panel dials to contact RAM. The control panel dials the programmed number on when the following events occur:

• Log % Full threshold is achieved.

• The control panel is contacted by RAM and

RAM Call Back is programmed Yes.

• COMMAND 43 is initiated and the user selects

Call RAM option.

Enter up to 24 characters to define dialing characteristics.

Up to 24 characters

number for RAM.

Phone #5 (RAM Ph #

)

If Log % Full was programmed with a value (1 to 99) and a RAM phone number is programmed, the control panel dials the RAM phone number when the log threshold is reached. This function is not available in RPS. Do not program Log % Full and RAM phone number at the same time.

See Phone 1 in Section 2.1 Phone.

Answer Disarmed

Default: See

Selection:

Blank No answer.

1 to 15 The control panel answers the phone

Set telephone ring counter to answer when any area is in a perimeter armed or disarmed state.

The RAM considers perimeter armed as a disarmed state.

Program Record Sheet

1 to 15, or Blank

after the specified number of rings when any area in the system is in a perimeter armed or disarmed state.

Remote Program Dialing Exception:

When a RAM phone number is programmed, the user can call RAM by pressing [COMMAND][4][3] then [NEXT] until CONTACT RAM? displays, then press [ENTER]. At this point, the user can press [ENTER] when RAM VIA PHONE? is displayed. When performing this function, only one attempt is made to contact RAM.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 34

2.8 Miscellaneous

Duress Type

Default: 1

Selection:

1 Add 1 to the last digit to generate an alarm. For

example, if the passcode is 6123, 6124 triggers a duress alarm.

If the last digit of the passcode is 0, a duress alarm is generated when the user enters 1 as the last digit of the passcode.

If the last digit of the passcode is 9, a duress alarm is generated when the user enters 0 as the last digit of the passcode.

Add 2 to the last digit to generate an alarm. For example, if the passcode is 6123, 6125 triggers a duress alarm.

If the last digit of the passcode is 8, a duress alarm is generated when the user enters 0 as the last digit of the passcode.

If the last digit of the passcode is 9, a duress alarm is generated when the user enters 1 as the last digit of the passcode.

This program item determines whether users add one (+1) or two (+2) to the last digit of the passcode. To activate a duress alarm, the user increases the value of the last digit of their passcode when entering it at the command center.

Cancel Report

Default: No

Selection:

1 or 2

Duress is enabled/disabled by area in Area Parameters.

The duress alarm is activated when a user enters the duress combination followed by the termination keys ([ESC] or [ENT]).

Yes or No

A Cancel and Fire Cancel Report is created when a passcode is entered to silence an Alarm Bell or a Fire Bell before the bell time expires.

2.9 Area Parameters

This programming module contains three programming categories: Area Parameters, Bell Parameters, and Open/Close Options.

2.9.1 Area Parameters

Area

Default: 1

Selection:

Enter the area number you are programming.

A# Area On

Default: Yes (Area 1 only)

Selection:

Yes Area is enabled.

No Area is disabled.

Use this program item to enable or disable the area specified.

0101 0101 0101

1 to 8

Yes or No

1. When programmed No, points

assigned to this area do not generate events. Command centers with Area scope which are assigned to this area display AREA # DISABLED. When arming and disarming, this area number is not displayed at control centers with the scope to view this area. Status for this area is not reported with Status Reports. All user authority in this area is turned off while the area is disabled.

2. Area 1 must be enabled: System

events such as power and phone supervision do not report properly if Area 1 is disabled.

Yes Send Cancel and Fire Cancel Reports

according to routing.

No Do not send Cancel and Fire Cancel

Reports.

Use this program item to control whether or not Cancel and Fire Cancel Reports are sent.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 35

A# Acct Number

Default: 0000

Selection:

Determines the account number reported for this area. An account number must be assigned to each active area.

Account numbers are used to group areas together. Each area can have a different account number, or several areas may share the same account number. The control panel uses the account number as a reference for arming and command center text displays.

BFSK: Only the last three digits are transmitted. Insert a 0 as the first digit of the account number. Example: 0 2 3 4.

Modem IIIa

2.9.2 Programming Account Numbers in 9000

The 9000MAIN version 1.12 handler and version

6.20 firmware and higher now can program a fourdigit or ten-digit account number for each area.

Programming Four-Digit Account Numbers

To properly program a four-digit account number (such as 1234) using the D5200 Programmer, you must enter leading 0s (zeroes) in Digits 1 to 6, and then enter 1234 into Digits 7 to 10. When 0s are entered for the first six digits (Digits 1 to 6), the 9000 Series Control Panel treats this as a four-digit account number. See Table 21.

For BFSK: 0000 to 0999, 0BBB to 0FFF

For Modem (four-digit account numbers): 0000 to 9999, BBBB to FFFF

For Modem (ten-digit account numbers): 0000000000 to 9999999999, BBBBBBBBBB to FFFFFFFFFF

: Enter a four-digit or ten-digit number.

Series Control Panels, versions 6.20 and Higher

Table 21: Programming Four-Digit Account

Numbers

D5200 Programmer

A# Acct# Dgt 1&2 0 0 A# Acct# Dgt 3&4 0 0 A# Acct# Dgt 5&6 0 0 A# Acct# Dgt 7&8 1 2 A# Acct# Dgt 9&10 3 4

The D5200 account number entry shown in Table 21 appears in RPS as 1234.

Although the D5200 allows the character “A” to be entered into the account, do NOT use this character for the account number.

Any account number digits containing “A” for digits 1 to 6 that were uploaded to and received by RPS are NOT displayed.

If an “A” was erroneously sent to the control panel from the D5200 for any of Digits 1 to 6, this can be corrected by:

• Entering six leading 0s from the

D5200 and sending them to the control panel.

• Entering six leading 0s from RPS,

followed by the four-digit account number, and sending them to the control panel.

Programming Ten-Digit Account Numbers

To properly program a ten-digit account number (such as 1122334455) using the D5200 Programmer, you must enter a character for each of the ten digits. See Table 22:

Table 22: Programming Ten Digit Account

Numbers

Bosch Security Systems | 1/04 | 47775E

D5200 Programmer

A# Acct# Dgt 1&2 1 1 A# Acct# Dgt 3&4 2 2 A# Acct# Dgt 5&6 3 3 A# Acct# Dgt 7&8 4 4 A# Acct# Dgt 9&10 5 5

The D5200 account number entry shown in Table 22 appears in RPS as shown in Figure 2.

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 36

Figure 2: Account Number Entry

22 33 44 5511

3 4 5 6 7

1 - RPS account number entry 2 - Corresponding D5200 account number digits 3 - Digits 1 and 2 4 - Digits 3 and 4 5 - Digits 5 and 6 6 - Digits 7 and 8 7 - Digits 9 and 10

Although the D5200 allows the character “A” to be entered into the account, do NOT use this character for the account number.

Make sure your central station receivers (D6500 MPU version 1.06 or D6600 CPU version 01.01.04) and your automation software are compatible with ten-digit account numbers before programming a ten-digit account number in a 9000 Series control panel.

A# FA Bypass Max

Default: 1

Selection:

Specify the maximum number of combined Controlled points that can be faulted or bypassed when arming this area.

See the prompts

Retrnable

returning a point to the system when the point returns to normal or when the area is disarmed.

1 to 99

P## FA Retrnable

and

P## BA

in Section 4.1.1 Point Responses for

A# Delay Res

Default: No

Selection:

Yes or No

Yes Point Restoral Report is not sent until

the bell time expires or user acknowledges alarm condition.

Restoral Reports are sent when point restores, regardless of bell time.

A# Exit Tone

Default: Yes

Selection:

Yes or No

Sound an exit tone during exit delay at all command centers assigned to this area.

De-selecting individual command centers for exit tones: Exit tones for

programming the CC Exit Tone as No can be turned off for individual command centers (based on their CC# 1 through 8).

A# Exit Dly Time

Default: 60

Selection:

Exit delay time for this area when Master Exit or Perimeter Exit arming.

Blank (0) to 600 ( in 5 second increments)

Points programmed for instant alarms generate alarms immediately, even during exit delay. To prevent instant alarms on points, the user must cause a fault to leave the building, program P### Type in the Point Index as 3 (Interior Follower).

Users can bypass more points than the number entered here during the disarmed state. It is only when the user attempts to Bypass Arm an area (or areas) that this restriction is enforced.

0101 0101 0101

Points need Bypassable programmed Yes to be bypassed or force armed. Force arming does not bypass 24-hour points.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 37

A# Auto Watch

Default: No

Selection:

Yes When the area is disarmed, Watch

No When the area is disarmed, Watch

0101 0101 0101

Yes or No

Mode turns on automatically.

Mode must be turned on or off manually.

Controlled points must be programmed as P## Watch Point to generate a watch tone.

A# Verify Time

Default: 60

Selection:

Alarm verification is designed for use with smoke detectors to reduce the number of false fire alarms. When Verify Time is programmed, the control panel can double check smoke detector point activations before generating alarm signals.

Check with your authority having jurisdiction (AHJ) to determine the maximum verification time allowed.

10 to 60 (in 1-second increments)

DO NOT enable the Cross Point feature in point indexes designated for Fire points.

Points are programmed individually to activate the verification feature. See Section 4.1 resettable Fire point can activate alarm verification for the area to which it is assigned. Use separate area alarm-verification relays.

To enable alarm verification on a point, program

Point Index

Resettable as Yes.

When an Alarm Verification point trips, the control panel automatically removes power to all Resettable points connected to the area’s Reset Sensors relay. The sensor reset removes power to the sensors for the amount of time programmed in Verify Time. When power is reapplied, a 60-second confirmation window begins. If the detector is still in alarm, or trips again during the confirmation window, or if a different Resettable Verification point in the area trips, an alarm is generated.

Example: Verify Time is set for 20 seconds. The alarm verification cycle starts when the detector trips. No report is generated.

Immediately after the detector trips, the area’s sensor reset relay interrupts power to points connected to it for the time in Verify Time.

When power is restored to the points, the 60-second confirmation window is established. If any detector, reset during the verification time, trips again during the confirmation window, an alarm is generated. If no activity occurs during this period, no alarm is generated and the verification window ends. If a Verification point trips again after the window ends, a new verification cycle begins. See Table 23 for an example of verify time.

, Fire Point, Alarm Verify, and

Point Index. Any

Table 23:Verify Time

Verification Point Trip

Example: Total

Cycle time 80 seconds

Bosch Security Systems | 1/04 | 47775E

☛

Verify Time/Reset Sensors

Power removed, ignore activity

■ 20 Seconds ■

60 second Confirmation

Generate alarm if additional activity received.

■■■■■■

Restart Alarm Verification Cycle if an Alarm Verification point trips.

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 38

A# Duress Enable

Default: No

Selection:

Yes Enable Duress alarm for this area.

No Disable Duress alarm for this area.

This entry determines if this area allows duress alarms to be generated. See the

prompt

explanation of duress.

Yes or No

Duress Type

in Section 2.8 Miscellaneous for an

Setting this item to No for a particular area and entering a valid duress passcode for that area at the command center now displays NO AUTHORITY.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 39

A# Area Type

Default: Regular

Selection:

Regular, Master, Associate, or Shared

Regular Arms or disarms as an independent area.

Master Does not allow arming for this area unless all associate areas with the same A# account number are

master exit delay arming or master armed. CHK AREA displays if the associate areas are not armed. Exception: RPS allows master areas to be armed without all associate areas being in the armed state.

A master area can be disarmed regardless of the armed state of the other areas in the account.

Multiple master areas can be programmed in a single account.

0101 0101 0101

Programming Tip:

CC# Scope affects master arming

Area:

A master area with a CC# Scope Area requires the associate areas

are independently armed, or master exit delay before the master area can arm.

Panel Wide/Account Wide:

Upon arming the master area, all associate areas within the CC# Scope of the master area begins Master Exit Delay Arm. The shared areas begin.

Using the arming sked (S## Function 1) requires that you first use an arming sked to arm the associate areas before using an arming

sked to arm the master area. In addition, arming master areas with RAM IV, Keyswitch, or Auto Close parameters (see Open/Close Options) is allowed to occur before all associate areas are armed.

Associate

Allows arming and disarming regardless of the armed state of the other areas with the same A# account number. This type of area is used with a master area and is associated by having the same account number.

Command centers assigned to associate areas, when used in conjunction with shared areas, should have the CC# Scope programmed to encompass the shared area.

Shared Shared areas cannot be armed using a passcode, keyswitch, sub-control, sked, or by RAM. Doing so

produces a Watchdog Reset.

The scope of all associate areas must include the shared area(s) in order to view faulted points.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 40

2.9.3 Shared-Area Characteristics

Arming a Shared Area

Requires all associate areas to be armed. As soon as the last associate area is armed, the shared area begins its arming sequence automatically. Passcode, keyswitch, sub-controls, or RAM cannot arm shared areas. To display faulted points at associated areas, the shared and associate areas must have the same account number.

Disarming a Shared Area

Shared areas automatically disarm when any associate area in the control panel is disarmed. Passcode, tokens/cards, keyswitch, sub-controls, or RAM cannot disarm shared areas.

Shared Area Arming Sequence

When shared areas automatically begin to arm, the arming is based on the programmed for the area number where the command center was assigned.

Shared Area Not Ready

If a point is faulted in the shared area, CHK AREA displays on the associate command center that is arming the last associate area. Associate area command centers can display faults from shared areas as long as the shared areas fall within the scope of the associate area.

Force Arming a Shared Area

When CHK AREA is displayed, pressing [ESC] displays FORCE ARM at the associate command center. Pressing [ENTER] force arms the shared area if the user has authority to bypass points, the point is bypassable, AND the number of faulted points does not exceed the force arm max amount for the shared area. Remember to include the shared area in the associate area’s scope.

Viewing Shared Area Armed Status

View Area Status can be used from a command center outside of the shared area to view the shared area’s armed state.

Silencing Sounders in the Shared Area

Shared area alarms and troubles can be silenced from any command center.

To silence sounders, the user needs an authority level assigned to the shared area. If the user also has the authority to arm/disarm the area, then ALREADY ARMED or ALREADY DISARMED momentarily displays.

A# Exit Dly Time

Access Control Readers Assigned to the Shared Area

The shared area momentarily disarms then begins the exit delay sequence, allowing a user to walk to an associate area and disarm. If the token/card reader assigned to the shared area includes any associate area in the handler), both the associate area and shared area disarms when the token/card is presented.

Closing Reports for Shared Areas

If Closing Reports for shared areas are required, passcodes also need a valid authority level assigned in the shared area.

2.9.4 Bell Parameters

The D9412G/D7412G have two main types of annunciation: Fire Bell and Burg Bell. Both Fire and Burg Bells share the same terminal (Terminal 6) on the control panel as shipped from the factory.

In the event of a simultaneous Fire Bell and Burg Bell occurrence, the Fire Bell takes precedence over the Burg Bell regardless of which relay or terminal output they share.

When the Fire and Burg Bells share the same output and a Fire Bell occurs while the Burg Bell is ringing, the Fire Bell pattern overrides the Burg Bell pattern. At the end of the fire time, the burg pattern resumes.

When the Fire and Burg Bells share the same output and a Burg Bell occurs while a Fire Bell is sounding, the control panel waits until the Fire time expires before starting the Burg Bell.

Either a single bell (panel-wide) or a number of bells (area) can be used on the control panel. For programming these applications, see Section 2.13.1 Area Relays.

When both Fire and Burg Bells occur simultaneously and a user enters a valid passcode, a Fire Cancel Report for the fire alarm and a Cancel Report for the burg alarm reports to the central station if Cancel Reports is programmed Yes.

D## CC# Scope

(in the access

Area

Default: 1

Selection:

Enter the area number you are programming.

1 to 8

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 41

A# Fire Time

Default: 9

Selection:

Enter the number of minutes the bell rings for Fire Alarm points. The relay activated for this time is programmed in

The bell output begins as soon as the fire alarm occurs. It shuts off the bell when the programmed number of minutes expires.

If programmed for 1 minute, the output may be anywhere from 0 to 60 seconds of bell time. Program Fire Time for 2 minutes or more to ensure you have ample output time.

1 minute to 90 minutes

A# Fire Bell

Check with your AHJ to determine the appropriate bell time for your geographical area.

in Area Relays.

A# Fire Pat

A# Burg Time

Default: 6

Selection:

Enter the number of minutes the bell rings for Burglary Alarm points. The relay activated for this time is programmed in Relays.

The bell output begins as soon as the burglary alarm occurs. It shuts off the bell when the programmed number of minutes expires.

When the control panel’s internal clock begins a new minute, it considers the first minute expired. Program Burg Time for 2 minutes or more.

1 minute to 90 minutes (in 1 minute increments)

A# Alarm Bell

Check with your AHJ to determine the appropriate bell time for your geographical area.

in Area

Default: Pulse

Selection:

Steady Steady Output

Pulse Pulse March Time

CaStnd California Standard

TmCod3 Temporal Code 3

Select the bell pattern this area uses to signal an alarm on a Fire point.

Press the [Space] bar to scroll through the selections. Press [Enter] when the correct selection appears in the display.

Steady, Pulse, CaStnd, TmCod3

120 beats per minute, at an even tempo

10 seconds audible + 5 seconds silent + 10 seconds audible + 5 seconds silent. This sequence repeats until bell time expires.

0.5 seconds On, 0.5 seconds Off, 0.5 seconds On, 0.5 seconds Off, 0.5 seconds On, 1.5 seconds Off; pattern repeats. This sequence repeats for a minimum of 3 minutes and with a ± 10% tolerance.

When two Fire points sharing the same relay go into alarm, the bell pattern of the most recent fire event takes precedence.

A# Burg Pat

Default: Steady

Selection:

Select the bell pattern this area uses to signal an alarm on a Non-fire point.

Press the [SPACE] bar to scroll through the selections. Press [ENTER] when the correct selection appears in the display.

Steady, Pulse, CaStnd, TmCod3

A# Single Ring

Default: No

Selection:

Yes

No Restart bell output with each alarm

Determines if an alarm from a Non-fire point can restart the alarm bell time with each Alarm Event, or only initiate alarm output once per arming period.

This does not silence the command center alarm bell tone, or prevent any reports. This feature does not affect Fire points. Fire points restart bell time with each new alarm.

Yes or No

One bell output per arming period. After one alarm, alarms on any Nonfire points in the same area cannot restart the bell until the armed state changes. An alarm on a different point in same area restarts bell output.

event.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 42

2.9.5 Open/Close Options

If a 24-hour point alarms while the area is disarmed, arming that area with a keyswitch does not clear the A# Single Ring flag.

Silencing the bell resets A# Single Ring.

A# Bell Test

Default: No

Selection:

Yes Initiate Bell Test.

No Do not initiate Bell Test.

Provide alarm output from the relay programmed at

A# Alarm Bell

confirmed or the exit delay time expired.

Bell Test After Confirmation

In areas that report opening and closing activity, the Bell Test happens after the control panel sends the Closing Report and receives the acknowledgment from the central station receiver. For proper operation of the Bell Test after closing confirmation, the following rules apply:

• The control panel must report opening and

closings to the central station.

• Restricted openings and closings should not be

used, and Opening and Closing Windows should not be used.

Area Armed Confirmation

In areas that do NOT report opening and closing activity, the alarm bell relay output for this area is activated for 2 seconds after exit time expires.

Yes or No

after the Closing Report was

Multiple Bell Tests occur: When more than one area is armed at the same time (such as using the ARM ALL AREAS? function), the bell rings for 2 seconds with a 2 second pause between each bell activation if all areas have the same exit delay time programmed. Otherwise, the Bell Test occurs as each area arms and it completes its exit delay time.

Programming determines if Opening, All Normal Closing, and Force Arm/Bypass Closing Events are reported to the remote central station. Without remote reporting, all control panel and area arming (Closing Events) and disarming (Opening Events) default to local events.

Use this programming category to determine which opening and closing supervision characteristics are required.

There are three ways to generate reports from the control panel. You can generate reports by account, by area, or a combination of both.

To suppress reports:

• Use Opening/Closing Windows to suppress

reports for a specified period of time and then automatically turn them on again.

• Use the Restricted O/C options. A Closing

Report is sent if the user is force arming, sending duress, or bypass arming. An Opening Report is sent if the user is disarming during an alarm condition or unbypasses points when disarming. If the system is normal, no Opening or Closing Report is sent.

For the scheduled suppression of Opening and Closing Reports, see Section 5.1.1 Opening and Closing) to define Opening and Closing Windows.

Account Opening and Closing Reports

Opening and Closing Reports are sent by account when the last area in a group of areas with the same account number(s) is armed.

Area Opening and Closing Reports

Closing Reports are sent for each area as it is armed. The account number is also sent for each area.

Customizing Account Opening and Closing Reports

You can eliminate area Opening and Closing Reports from selected areas in the account by programming

A# Area O/C

No for those areas.

When areas arm simultaneously and report to the central station, the Bell Test occurs as the central station receiver confirms each area.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 43

Combination Account and Area Opening and Closing Reports

To send both account openings and closings, and individual area openings and closings for all areas in the account, you must:

• Program

account.

• Program

account.

Closing Reports: When areas in the account are independently armed, each area generates an Area Closing Report. When the last area is armed, it also generates an Account Closing Report.

Opening Reports: When the first area in the account is disarmed, it generates an Account Opening Report along with an Area Opening Report. When the remaining areas in the account are disarmed, each area generates an Area Opening Report.

Area Only Opening/Closing Supervision Features

Use these features to supervise opening and closing activity by area. Auto Close, Fail To Open, and Fail To Close all work independently of the

O/C

feature. To use these features, you must

program O/C Windows.

A# Acct O/C

A# Area O/C

Yes for all areas in the

A# Acct

Area

Default: 1

Selection:

Enter the area number you are programming.

1 to 8

A# Acct O/C

Default: No

Selection:

Yes Send Opening and Closing Reports by

account.

Use this selection if the control panel sends reports to an automation system that cannot interpret multiple Area Opening/Closing Reports, or if No in the Phone category (BFSK format is in use and Opening and Closing Reports are enabled).

An Account Opening Report is generated when the first area in an account is opened (disarmed). After the Account Opening Report is sent, disarming other areas in the account does not generate another Account Opening Report. An Account Closing Report is generated only when the last area in an account is closed (armed). Opening and Closing Reports for accounts do not contain any area information.

Opening and Closing Windows affect Account Opening and Closing Reports: If

an account opening or closing is generated while an Opening or Closing Window for this area is in effect, and is programmed Yes, the report is not sent. All areas sharing the same account number should use the same Opening and Closing Window times.

Yes or No

Modem Format

is programmed

Disable O/C

in Window

Bosch Security Systems | 1/04 | 47775E

No Do not send Opening and Closing Reports by

account.

Determines if this area generates Account Opening and Closing Reports. Program this item the same for all areas in the account.

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 44

A# Area O/C

Default: Yes

Selection:

Yes Include the Area # and generate Opening and

Closing Reports for this area when it is armed.

No Do not include the Area # or generate

Opening and Closing Reports for this area.

Determines if the area number and the account number are reported upon arming and disarming. As long as reports when arming this area individually. If

Account O/C

account number must also be armed.

An Area Opening Report is generated when each area is opened (disarmed). An Area Closing Report is generated when each individual area is closed (armed).

Yes or No

Account O/C

is Yes, all areas with the same

Do not program this item as Yes if the control panel reports to an automation system that cannot interpret multiple Area Opening/Closing Reports.

is No, the account number

A# Disable O/C in Window

Default: Yes

Determines if opening and closing activity is reported when it occurs inside an Opening or Closing Window as programmed in O/C Windows.

Reports are always logged and printed on a local printer, if installed.

A# Auto Close

Default: No

Selection:

Yes

The area automatically master arms at the end of the Close Window.

When the area is armed automatically, a Closing Report is sent if Area and/or Account Reports are programmed to do so.

No Do not automatically arm the area at the end

of the Close Window.

With this program item, the control panel can automatically master arm the area at the end of the Closing Window regardless of the previous armed state.

Yes or No

Regardless of A# Force Arm Max or P## Bypassable, an unconditional force arm

occurs resulting in faulted points being left out of the system until they return to normal.

Selection:

Yes Do not send Opening and Closing Reports to

the central station if they occur inside an active window.

If an Opening or Closing Report occurs outside a window, send it with an early or late modifier. See Section 5.1.1 Opening and Closing.

The active window must be a Closing Window for Closing Reports. It must be an Opening Window for Opening Reports.

No Send Opening and Closing Reports to the

central station even when they occur inside a programmed window. If an opening or closing occurs outside of the appropriate window, it reports but does NOT have an early or late modifier.

If you want to monitor all opening and closing activity, but you also want to use features provided by Opening and Closing Windows, program this item No, and program appropriate O/C Windows.

Yes or No

A# Fail to Open

Default: No

Selection:

Yes Fail to Open Report occurs for this area if the

area was not disarmed when the Opening Window stop time occurred.

No Fail to Open Report is not sent for this area.

Use to determine if a Fail to Open Report is sent for this area. This can determine if a user failed to disarm the area prior to the Opening Window expiring. Normal Opening and Closing Reports do not need to be programmed to use this feature.

Yes or No

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 45

A# Fail to Close

Default: No

Selection:

Yes Fail to Close Report occurs for this area if the

area was not armed when the Closing Window stop time occurred.

Note:

No Fail to Close Report is not sent for this area.

Note:

Determines if a Fail to Close Report is sent for this area. Use to determine if a user failed to arm the area before the Closing Window expires. Normal Opening and Closing Reports do not need to be programmed to use this feature.

Yes or No

An exit delay time must be programmed in Exit Dly Time.

If Auto Close is programmed Yes, a Fail to Close Report is sent because it occurs when the Closing Window stop time occurred.

If Disable O/C in Window is Yes, the Fail to Close Report is followed by Closing Late or F(orce) Close Late.

A# Restrictd O/C

Default: No

Selection:

Yes Restrict Opening and Closing Reports for this

area. Yes to generate Restricted Opening and Closing Reports.

Note:

Opening/Closing Window does not affect this report. Windows do not prevent Restricted Opening and Closing Reports from being sent. Early or late designations are NOT added to Opening/Closing Reports when they are sent according to the rules for Restricted Opening/Closing Reports.

No Do not Restrict Opening and Closing Reports

for this area.

Regardless of programming in Authority Levels restricted in this area when this item is programmed No.

Yes or No

A# Area O/C

If a passcode is not required for arming or disarming and this item is Yes, the area only sends Restricted Opening and Closing Reports. In this case, Restricted Reports are sent without User ID.

L## Restricted O/C

must be programmed

, reports are not

Note:

Was Force Armed and Forced Close Events can still be sent to the central station if enabled in Routing when force arming the system.

This item determines if this area can restrict Opening and Closing Report activity.

A Restricted Opening Report refers to the control panel sending an Area Opening Report only when the area is disarmed after a non-fire alarm.

A Restricted Closing Report refers to the control panel sending an Area Closing Report only when the area was master armed with Controlled points that were faulted during the arming sequence. The sequence of reports generated by a restricted closing is: Was Force Armed, Forced Point, Forced Close, and Closing Report.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 46

A# Perimeter O/C

Default: No

Selection:

Yes This area can send Perimeter Opening and

Closing Reports.

No This area cannot send Perimeter Opening and

Closing Reports.

This item determines if this area can send Perimeter Instant and Perimeter Delay Closing Reports and normal Opening Reports to the central station. Opening/Closing Windows do not suppress this event.

Yes or No

Modem format reporting is required. Some central station automation systems cannot process these reports.

Cmd Center

Default: 1

Selection:

1 to 8

2.10 Command Center

This programming module contains three programming categories: Cmd Cntr Assignment, Area Text, and Custom Function.

2.10.1 Cmd Cntr (Command Center) Assignment

This programming category assigns a command center to an area and determines if the command center is supervised. The command centers are connected to the control panel using a two-wire serial data interface bus (SDI bus). This bus can support up to eight supervised command centers, each with its own unique command center address (CC) and corresponding DIP switch address settings. Should the command centers not be supervised, you can install multiple command centers with the same DIP switch address setting for up to 32 unsupervised command centers.

SDI CC#

1 1 ON ON ON ON -- ON

22 OFF ON ON ON -- ON

3 3 ON OFF ON ON -- ON

4 4 OFF OFF ON ON -- ON

5 5 ON ON OFF ON -- ON

6 6 OFF ON OFF ON -- ON

7 7 ON OFF OFF ON -- ON

8 8 OFF OFF OFF ON -- ON

Enter the command center (CC) number for the SDI address you are programming. This number corresponds to the DIP switch address settings shown.

Address Number

123456

DIP Switch Setting

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 47

CC# Supervised

Default: See

Selection:

Yes Only one command center can be installed for

this CC SDI address.

No More than one command center can be

installed using this CC SDI address with the same address DIP switch setting.

Supervise this SDI address and generate Trouble SDI Reports and local trouble annunciation if a problem occurs with this command center or the SDI bus.

Command centers sharing the same address setting display the same text and emit the same tones regardless of which command center keys are pressed.

Trouble SDI # Reports are always reported as Area 1, Account 1 Events regardless of the area the SDI device is assigned.

Program Record Sheet

Yes or No

CC# Scope

Default: See

Selection:

Panel Wide

Account An Account command center can view

Area An Area command center is restricted

Program Record Sheet

Panel Wide, Custom, No Keypad, Area, and Account

A panel-wide command center can view information and perform Arming and Disarming functions for all areas in the control panel. A panel-wide command center can cross account boundaries. This is normally used with a master area.

information, and perform Arming and Disarming functions for all areas with the same

A# Acct Number

, in Area Parameters. This is normally used for an associate area.

to viewing information and Arming/Disarming functions for the area to which it is assigned.

0101 0101 0101

When this prompt is Yes, you cannot have duplicate DIP switch settings.

When a D1260 Alpha V Command Center is assigned to a command center address, you must program CC# Supervised as Yes.

CC# Area Assign

Default: 1

Selection:

Blank is not a valid entry.

Enter the area number where you are installing this command center or command centers with this address and the same DIP switch settings.

1 to 8

Custom A Custom command center has no

command center restrictions.

No Keypad

No command center installed at this address. CALL FOR SERVICE displays, indicating the control panel is not polling this address.

This program item is used to define the areas affected when this command center is armed, the areas this command center can view, and the areas this command center can move to.

Press the [SPACE] bar to scroll through the selections. Press [ENTER] when the correct selection appears in the display.

In applications where command centers include the scope of more than one area, active alarms in remote areas must be acknowledged prior to arming or disarming the local area.

The following prompts are visible ONLY when you program CC## Scope to Custom. If the scope was previously programmed to be other than No Keypad, default settings based on the previous scope appear. Prior to exiting a custom program, check each area and ensure it is properly enabled and disabled.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 48

CC# A1[through A8] in Scope

Default: See preceding important note

Selection:

Yes or No

Yes Include this area in the scope of this

command center.

No Do not include this area in the scope of

this command center.

Determines whether any of the eight areas (Area 1 to Area 8) and Doors (Door 1 to Door 8) are included in the scope of this command center for viewing status, arming or disarming, and controlling doors from the command center.

CC# Entr Key Rly

Default: Blank

Selection:

Blank The [ENTER] key is not used to cycle

1 to 128, A, B, C

Enter Key Relay: Program the relay number that momentarily activates for 10 seconds when a user enters a valid passcode and presses the [ENTER] key on the command center. Two events are generated when this function is used: RELAY ### SET with User ID, and RELAY ### RESET without User ID.

1 to 128, A, B, C, and Blank

a relay.

Assign the relay number that activates when [ENTER] is pressed at this command center after the user enters a valid passcode.

When programmed to activate a relay, the [ENTER] key cannot be used for any other function.

Relays used for this function must not be shared with any other point, sensor reset, control panel, or bell functions. This can cause erroneous relay operation.

CC# Entr Cycl Dr

Default: No

Selection:

Yes The [ENTER] key is used to cycle the

Enter Key Cycle Door: Program this prompt as Yes to initiate the door cycle sequence (this includes shunting the point assigned to the door) for the door number programmed in user enters a valid passcode and presses [ENTER]. ACCESS GRANTED prints on the local printer and at the central station receiver, if programmed.

0101 0101 0101

Yes or No

door programmed for CC Assign Door.

The [ENTER] key is not used to cycle the door.

CC Assign Door

when a

The service passcode cannot be used for the CC# Entr Cycl Dr application.

When programmed to activate a relay, the [ENTER] key cannot be used for any other function.

Relays used for this function must not be shared with any other point, sensor reset, control panel or bell functions. This can cause erroneous relay operation.

1. The door does not cycle if Entr Key

Rly is programmed.

2. 9210 NOT READY appears at this

command center when you press [ENTER] if the D9210B is not programmed with a D# Entry Area (in the RADAXS handler) or if CC Assign Door does not have a door number assigned.

1. Entering a valid code and pressing

[ENTER] silences a bell if one is ringing.

2. Use this function for a low-level

access control strike on a door. This does not shunt a point.

3. This action is logged as two events,

Relay Set and Relay Reset.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 49

CC# Assign Door

Default: Blank

Selection:

Blank No door controller is assigned for adding

1 to 8 Assign the door controller that enters the

Program the door number used by this command center for adding tokens/cards and displaying CC Close Door.

0101 0101 0101

1 to 8, Blank

tokens or the CLOSE DOOR # displays on the command center.

Add User Mode when initiated. This door activates the CLOSE DOOR # displays at this command center if CC Close Door is Yes.

1. IMPORTANT! 9210 NOT READY

appears at this command center when you attempt to add a user if a door is not programmed for this prompt and a door is not assigned to the area using the D# Entry Area in the RADAXS handler. This indicates the control panel cannot initiate the Add User Mode until a door is assigned to this command center.

2. A door does not need to be assigned

to a command center for the user to control the door(s) using the Door Control function. Any door that is active can be controlled by a user who has the door control authority enabled at a command center with the doors area, assigned in the access handler, within its scope.

Determines whether this command center, or any command center with the same address setting, emits the panel-wide trouble tones (power, phone, SDI bus, and Zonex bus).

Panel-wide trouble tones do not include Point Troubles, Buzz on Fault, or Close Door Now.

Assign two CCs to the same area so one command center emits the tone and another does not.

CC# Entry Tone

Default: Yes

Selection:

Yes This command center sounds entry

No This command center does not sound

Determines whether this command center, or any command center with the same address setting, emits the Disarm Now entry delay tone. Any Delay point within the area scope of this command center initiates the entry sequence.

0101 0101 0101

Yes or No

tones.

entry tones.

This prompt allows you to manage the tone by command center. Entry Tone can also be turned off when programming your P## Entry Tone off in Point Index.

Assign two CCs to the same area so one command center emits the tone and another does not.

During the Add User Mode, token/cards, door control requests, and RTE/REX does not function. Put the Door Mode into an UNLOCKED state before adding users if there is heavy activity for this door.

CC# Trouble Tone

Default: Yes

Selection:

Yes

No Panel-wide troubles do not sound.

Bosch Security Systems | 1/04 | 47775E

Yes or No

Panel-wide trouble tones sound and visual displays show at this command center.

Visual displays still show.

CC# Exit Tone

Default: Yes

Selection:

Yes This command center sounds entry

No This command center does not sound

Determine whether this command center or any command center with the same address setting, emits the Exit Now ### exit delay tone during the delay arming of an area(s). Any command center with a scope to arm this area can initiate the exit tone sequence.

Yes or No

tones.

entry tones.

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 50

0101 0101 0101

This prompt allows you to manage the tone by command center. Exit Tone can also be turned off when programming A# Exit Tone in Area Parameters.

Assign two CCs to the same area so one command center emits the tone and another does not.

CC# Arm Now Warn

Default: No

Selection:

Yes

Yes or No

This command center activates a tone and displays PLEASE CLOSE NOW.

No This command center does not activate

the tone or display PLEASE CLOSE NOW.

Determines whether this command center sounds an audible tone and displays the PLEASE CLOSE NOW warning on the command center when a Closing Window activates, indicating the area automatically arms soon.

CC# Close Door

Default: No

Selection:

Yes This command center sounds a tone

No This command center does not sound

Determines whether this command center sounds an audible tone and displays the CLOSE DOOR # warning on the command center. This occurs when the door is physically held open past the shunt time and the extend time has a value greater than zero (see the Access Program Entry Guide) for the door assigned to this area in

Yes or No

and displays CLOSE DOOR #.

the tone or activate the display.

CC# Assign Door

When a D1260 Alpha V Command Center is installed at this command center address, this item must be set to Yes. This instructs the control panel to send additional information to the D1260 required for proper operation.

0101 0101 0101

Remember to program CC# Supervised to Yes if a D1260 Alpha V Command Center is installed at this address. Failure to follow this programming requirement results in improper operation of the D1260.

2.10.2 Area Text

Use this programming category to create custom Idle Text displays for the command centers.

Each display can be programmed with up to sixteen alphanumeric characters, including: A to Z, 0 to 9, ?, &, @, -, *, +, $, #, _, /.

Characters not listed are invalid and cannot be used for text.

Area

Default: 1

Selection:

1 to 8

Enter the area number you are programming.

Area# Is On

Default: See

Selection:

Enter the text for this area that displays when the area is master armed or master instant armed and other areas sharing the same account number are not yet master armed. This display does not appear when the area is perimeter armed.

Program Record Sheet

Area # Not Ready

Default: See

Program Record Sheet

CC# EnhancCmdCtr

Default: No

Selection:

Yes

Bosch Security Systems | 1/04 | 47775E

Yes or No

This command center is a D1260 Alpha V Command Center.

This command center is not a D1260 Alpha V Command Center.

Selection:

Sixteen alphanumeric characters

Enter the text for this area that displays when the area is disarmed but points are faulted.

Area # Is Off

Default: See

Selection:

Enter the text for this area that displays when the area is disarmed and no points are faulted.

Program Record Sheet

Sixteen alphanumeric characters

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 51

Area # Acct Is On

Default: See

Selection:

Enter the text that displays when all areas sharing the same account number are master armed. The ACCT IS ON text appears at all command centers assigned to these areas, if more than one area has the same account number. The ACCT IS ON text also appears if only one area in the system is used. See the prompts

in Section 2.10.1 Cmd Cntr (Command Center)

Assignment. When all areas in the account are master armed, the Area # Is On text is replaced by the ACCT IS ON text if the area is armed before all the areas with the same account number.

0101 0101 0101

A blank entry disables the ACCT IS ON display for this area, allowing an account wide area to display the AREA # IS ON text instead of the ACCT IS ON text.

Each area can have unique ACCT IS ON text, or you can program the same text in each area of the account so when all the areas in the account are armed, they all show the same text.

Program Record Sheet

Sixteen alphanumeric characters

CC# Area Assign

and

Area # Acct Is

2.10.3 Custom Function

Custom functions are a way to simplify use of complex keystroke sequences entered at the command center. These items are similar to speed dialing on a telephone. A custom function can automatically initiate an end user request by pressing [ENTER] once the custom function text is displayed on the command center. You can have up to sixteen custom functions and restrict the use of these by area and authority level.

Each

Custom Function ###

characters of programmable text (

item has sixteen

CF### Text

When the Custom Function is assigned to the menu

M## Function

(see Section 2.12 Function List) the

user can press [PREV] or [NEXT] to scroll to

CF### Text

. The user accesses the menu by

pressing [MENU] on the command center.

The user needs the appropriate authority level enabled for the

L## C Function 128 to 143

Section 2.11 User Interface, to use the custom function.

Consider the scope of the command center used to access the Custom Function. Each Custom Function is enabled in the function menu by

1 [through 8

]. If the Custom Function is not

M# CC Address

assigned to a specific command center address, it does not appear in the menu.

0101 0101 0101

Although it is not programmed in this area, the new D1260 Alpha V Command Center can display up to sixteen characters for an Area Name on line 1 of its display. The Area Text (Area # Is Off, Area # Not Ready, Area # Is On, and Acct # Is On) programmed in this module appears on line 2 of the D1260 Alpha V Command Center. When programming custom text, it should be logical to users viewing it on the D1260. For example, the Area Name Text can be programmed to display Front Office and the Area # Is Off text (programmed in this section) could be programmed to display Ready To Arm. The D1260 would then show on line 1

Front Office and on line 2, Ready To Arm.

Custom Function

Default: 128

Selection:

128 to 143

Enter the Custom Function number you want to program. You can program up to sixteen Custom Functions, which are numbered 128 to 143.

CF### Text

Default: See

Selection:

Determines the menu text displayed at the command center for the custom function item. Use this text to represent the functions performed by this menu item.

Program Record Sheet

Sixteen alphanumeric characters. See

Section 2.10.2 Area Text

for

valid character entries.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 52

CF### Key Strokes

Default: See

Selection:

Selection Key Faceplate Label

0 to 9 0 to 9

A [COMMAND]

B [PREV] (previous)

C [ESC] (escape) MENU

D[NEXT]

E [ENT] (enter) YES

The keystrokes simulate any sequence of keystrokes the user can perform at a command center. You can program up to 32 keystrokes for each Custom Function.

0101 0101 0101

D5200 Data Entry: Use the D5200 [↓]

key to move the cursor to the first data entry line. When you want to enter more than sixteen keystrokes, the first line of the data entry line must be filled before you move on to the second line. If you make entries on the second line, and the first line has less than sixteen characters, the second line clears when you press [ENTER].

Program Record Sheet

Up to 32 characters: 0 to 9, A, B, C, D, and E

↑

↓

Table 24: CF### Custom Function Keystrokes

Command Keystroke

1 (Master arm area) A19 2 (Perimeter instant arm) A29 3 (Perimeter delay arm) A39 6 (Watch Mode) A69 7 (Special alert) A79 8 (Perimeter partial arm) A89 9 ( Special alert) A99 0 (Bypass a point) A09

• 128 to 143 Enable Custom Function 128

through 143, (Menu Function only): This

function determines if a passcode is required when attempting to access a Custom Function from the menu list. ENTER PASSCODE (or Enter Passcode + Enter Key on the D1260) displays when this function is passcode protected.

0101 0101 0101

If a command within the Custom Function is passcode protected, the command center displays ENTER PASSCODE and waits for the user to enter a valid passcode before proceeding with the rest of the Custom Function. If a passcode is not entered within 10 seconds, the Custom Function times out and the display returns to idle text.

0101 0101 0101

The scope of the command center where the Function List is accessed can affect the way the Custom Function operates.

Programming Custom Function Keystrokes

• First, find the command you want to execute in

the User Interface section of the Program Record Sheet.

• Single digit commands must be programmed

with 9 as the second digit.

0101 0101 0101

Skeds cannot execute Custom Functions that are passcode protected. D720 LED command center does not support Custom Functions that are passcode protected.

• Some functions cannot be entered directly

because they are nested inside a higher-level function. To automatically execute these functions, you must add the appropriate keystrokes.

• For example: In the Change Display

(COMMAND 49) function there are three subfunctions: Bright Display, Dim Display, and Date/Time Display.

- To turn up the display, enter:

[A][4][9][E]

- To dim the display, enter:

[A][4][9][D][E]

- To display time and date, enter:

[A][4][9][B][E]

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 53

• Custom Functions can perform several tasks at

once. For example:

- To toggle relays 7, 8, and 9 in one Custom

Function enter: [A] [5] [4] [7] [E] [E] [8] [E] [E] [9] [E] [E] [C]

- To add a temporary passcode, enter:

[A] [5] [6] [3] [0] [E] [E] [9] [8] [7] [E] [E] [D] [E] [1] [E] [1] [E] [1] [E] [1] [E] [1] [E] [1] [E] [1] [E] [1] [E] [C] This adds user 30, passcode 987 with authority level 1 in all areas.

- To delete the passcode, enter:

[A] [5] [3] [3] [0] [E] [E] [E] [C]

• To program multiple area Arming or Disarming

functions, use keystroke sequences including COMMAND 50 (Move to Area) and COMMAND 1.

0101 0101 0101

Custom function cannot be used to change time (such as Daylight Savings Time). Use Skeds S## Function Codes 13 and 14 to adjust for Daylight Savings Time (see S##

Custom Function prompt in Section 5.2 Skeds.

2.11 User Interface

Define which functions can be used by each of the fourteen user authority levels. Each user can be assigned the same or different authority level by area. The user has rights in the area where the command center is assigned based on the authority level assigned to the user’s passcode for that area.

When the passcode is entered at the command center, the control panel checks the authority level. The control panel executes the function only in areas where the passcode has the authority to use the function.

2.11.1 Commands

Similr to command initiation used in other Bosch Security Systems products, the Commands method provides continuity in the arming commands across product lines and makes an easy transition for dealers using other Bosch Security Systems products. With commands, the end user presses [COMMAND] and then the numeral of the command to initiate. For example, [COMMAND][2] arms the perimeter of the area. Some prompts can only be accessed from a menu and is noted as such by (Menu Function only). To access these functions, press [MENU], enter the function number, and use the [PREV] and [NEXT] keys to scroll through the choices.

The D9412G/D7412G Program Record Sheet lists the commands available with the system. Command numbers are shown in the column labeled Command. If a particular function does not have a command number, it can only be accessed through the Function List.

If you plan to use only commands to operate the system, along with arming and disarming by entering a passcode, then you do not need to program Custom Function or Function List.

2.11.2 Command Center Selections

Programming choices in this section determine if command center functions are disabled (blank), enabled (E), or restricted (P) panel-wide.

Press the [SPACE ] bar to scroll through the selections. Press [ENTER] when the correct selection appears in the display.

Table 25: Command Center Programming

Choices

Selection Description

Blank Disable the function panel-wide.

Accessing the function using a command or the Function List displays NO AUTHORITY.

E Enable the function panel-wide.

The function can be executed without entering a passcode.

P Passcode required. When the

passcode is entered at the command center, the control panel checks the user’s authority level. See Section 2.11.3 Authority

Level Selections.

See Section 2.11.3 Authority Level Selections for a detailed description of the

functions on the following pages. These parameters only determine if the authority level functions are passcode protected.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 54

Master Arm Delay

Default: P

Selection:

Blank Disable Master Arm Delay cannot be

#2 Master Arm Delay [COMMAND][1]

Use this arming function to master arm disarmed areas. If enabled, the following arming choices are available to the user with this authority.

Blank, E, or P

Passcode: Required for all users with

Master Arm Delay enabled for their authority level.

Enable: A user does not need a passcode to use [COMMAND][1].

accessed in the function menu or initiated with a command even if this function is enabled for the user’s authority level.

Mstr Arm Inst

Default: Blank

Selection:

#3 Master Arm Instant [COMMAND][1][1]

Use this arming function to master arm instant areas that are disarmed. If enabled, the following arming choices are available to the user with this authority. Entry and exit delays are not provided with this arming function. This causes a Perimeter and Interior Delay point to act as an Instant point.

Blank, E, or P

Perim Instant

Default: P

Selection:

#4 Perimeter Instant Arm [COMMAND][2]

Instant arms all perimeter points with a

Response Response

where the command center is assigned. Entry and exit delays are not provided with this arming function. This function causes a Perimeter Delay point to act as a Perimeter Instant point.

Blank, E, or P

P## Point

that initiates an instant alarm (see in Section 4.1.1 Point Responses) in the area

P## Pt

Perim Delay

Default: P

Selection:

#5 Perimeter Delay Arm [COMMAND][3]

Delay arms all Perimeter points in the area where the command center is assigned. Entry and exit delays are provided with this Arming function. This function does not cause a Perimeter Instant point to act as a Delay point.

Blank, E, or P

Watch Mode

Default: E

Selection:

#6 Watch Mode [COMMAND][6]

This function lets you know when a perimeter and Interior point programmed as faulted when the point is disarmed. Interior points do not emit a Watch Tone if the area is perimeter armed. This function provides command center audible/visual and optional relay activation (see

Watch Mode

Blank, E, or P

P## Watch Point

in Section 2.13.1 Area Relays).

A #

Perim Partial

Default: P

Selection:

#7 Perimeter Partial Arm [COMMAND][8]

Arms normal Perimeter points only while other faulted Perimeter points programmed as

Bypassable

provided with this Arming function.

Blank, E, or P

P##

are ignored. Entry and exit delays are

Perim Partial ignores the A# FA Bypass Max entry in Section 2.9 Area Parameters.

Local Only Reporting: No Closing Report is sent to the central station, but a Perimeter Delay Closing Event is generated in the event log.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 55

View Area Stat

Default: P

Selection:

#8 View Area Status (MENU FUNCTION only)

Use this function to view the armed status of all areas within the scope of the command center assigned to this area. The armed states include A# AREA # IS OFF (disarmed), A# AREA # IS ON (master delay armed), ALL ON INSTANT (master instant armed), and AREA # PERIM ON (perimeter instant armed or perimeter delay armed). All area types, master, associate, regular, and shared can be viewed using this function.

Blank, E, or P

View Memory

Default: E

Selection:

#9 View Event Memory [COMMAND][4][0]

Use this function to view prior alarm, trouble, and supervisory activity occurring since the last time the system armed. Event memory is not cleared until the area is re-armed.

Blank, E, or P

View Pt Status

Fire Test

Default: P

Selection:

#12 Fire Test [COMMAND][5][8]

Use this function to test 24-hour points in areas within the scope of the command center where the function is entered. Controlled points, 2, 3, cannot be tested using the Fire Walk Test Mode.

Blank, E, or P

P## Type 1

Send Report

Default: P

Selection:

#13 Send Report [COMMAND][4][1] or [COMMAND][4][2]

Use this function to test the communication link between the control panel and the central station receiver(s). It can send a Test Report or a Status Report to the phone numbers programmed in Routing. The Test Report includes additional information if

2.1 Phone.

Access Control Functions

Blank, E, or P

Expand Test Rpt

is enabled in Section

Default: E

Selection:

#10 View Point Status (MENU FUNCTION only)

Use this function to view points assigned to the area where the command center is assigned. This function shows point text and the electrical condition (normal, open, short, and missing) of each point in the area.

Blank, E, or P

Walk Test

Default: E

Selection:

#11 Walk Test [COMMAND][4][4]

Use this function to test Controlled points in areas within the command center’s scope without sending reports to the central station. 24-hour points cannot be tested using this Walk Test Mode.

Blank, E, or P

Door Control

Default: P

Selection:

#14 Door Control [COMMAND][4][6])

This top level display must be enabled for the user to access the cycle door, unlock door, and secure Door functions (see Section 2.11.3 Authority Level Selections). Use this item when programming door control in your function menu.

Blank, E, or P

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 56

Access Ctl Level

Default: P

Selection:

#37 Access Control Levels (MENU FUNCTION only)

Shows the current on/off state of control levels 1 through 14, pertaining to Access Control Only,

L## Access Level

( allows the user to toggle levels on and off and prevent access control levels from being valid during an extended period. This change only affects the user’s token/cards, it does not affect command center Door Control functions.

Blank, E, or P

and

L## Disarm Level

). It

Chg Display

Default: E

Selection:

#15 Change Display [COMMAND][4][9]

Use this function to select either a bright or dim display with loud or soft command center warning tones. You can also choose the time/date display.

Blank, E, or P

Add User

Default: P

Selection:

#18 Add User [COMMAND][5][6]

Use this function to add/change passcodes, add/change tokens/cards and Sub-users, and add/change control panel authority levels (L##) by area.

Blank, E, or P

Del User

Default: P

Selection:

#19 Delete User [COMMAND][5][3]

Use this function to delete a user’s passcode and tokens/cards. It does not delete user names.

Blank, E, or P

This function deletes the passcode, master user, and all sub-users associated with the user number.

Extend Close

Chg Time/Date

Default: E

Selection:

#16 Change Time and Date [COMMAND][4][5]

Use this function to set the time and date in the control panel.

Blank, E, or P

Chg Passcode

Default: P

Selection:

#17 Change Passcodes [COMMAND][5][5]

Use this function to change your passcode. This is a panel-wide function that can be executed from any command center assigned to an area where the user has authority.

Blank, E, or P

Regardless of whether an E or a P is entered when a COMMAND 55 is performed, the command center prompts for the user’s current passcode first.

Default: P

Selection:

#20 Extend Close [COMMAND][5][1]

Use this function to change the expected closing time for the area. The window cannot be adjusted until the Close Early Begin time passes and the Closing Window is active.

Blank, E, or P

View Log

Default: E

Selection:

#21 View Log (MENU FUNCTION only)

Use this function to view all of the main events Door Cycle and the main event modifiers By User in the event log memory. User Name and Point Text are NOT stored in the event log but appear when the control panel matches them with both the user ID ### and the point ###.

Each main event takes up one line in the log. Each modifier also takes up one line in the log.

The log in the control panel can store between 500 and 1000 events in the control panel log.

Blank, E, or P

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 57

Print Log

Default: P

Selection:

#22 Print Event Log (MENU FUNCTION only)

Use this function to print all the events stored in the control panel starting at the start date and ending with the last event in the log.

Blank, E, or P

User Cmd 7

Default: P

Selection:

#23 User COMMAND 7 [COMMAND][7]

Use this function to activate an alarm programmed in COMMAND 7 in the RADXPNTS Handler.

Blank, E, or P

User Cmd 9

Default: P

Selection:

#24 User COMMAND 9 [COMMAND][9]

Use this function to activate an alarm programmed in COMMAND 9 in the RADXPNTS Handler.

Blank, E, or P

Bypass a Pt

Default: P

Selection:

#25 Bypass a Point [COMMAND][0]

Use this function to bypass individual points that are

P## Bypassable

command center can be bypassed where the function is entered (see Section 2.10.1 Cmd Cntr (Command Center) Assignment).

The control panel ignores alarms/troubles and does not display point faults when a point is bypassed.

Blank, E, or P

. Points within the scope of the

Unbypass a Pt

Default: P

Selection:

#26 Unbypass a Point [COMMAND][0][0]

Use this function to unbypass individual points that are programmed either

Bypass Returnable

command center can be unbypassed where the function is entered (see Section 2.10.1 Cmd Cntr (Command Center) Assignment). The control panel responds to alarms/troubles and displays point faults when a point is unbypassed.

Blank, E, or P

P## FA Retrnable

. Points within the scope of the

P##

Reset Sensors

Default: E

Selection:

#27 Reset Sensors [COMMAND][4][7]

Use this function to activate the Reset Sensors function for Fire or Intrusion points programmed as

P## Resettable

within the scope of the command center where the function is entered resets (see Section 2.10.1 Cmd Cntr (Command Center) Assignment).

Blank, E, or P

in Section 4.1 Point Index. Points

Change Relay

Default: P

Selection:

#28 Change Relays [COMMAND][5][4]

Use this function to manually set and reset Relays 1 through 128 (1 through 64 in a D7412G) installed in the system.

Blank, E, or P

Remote Program

Default: P

Selection:

Blank, E, or P

Bosch Security Systems | 1/04 | 47775E

#29 Remote Programming [COMMAND][4][3]

Use this function to initiate RAM sessions. When the phone is ringing at the control panel, initiating this function causes the control panel to seize the line.

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 58

Move to Area

Default: P

Selection:

#30 Move to Area [COMMAND][5][0]

Use this function to temporarily switch the command center’s assignment to a different area. This can be used to perform any function that can be performed by a command center assigned to the area in programming.

Users are limited to performing functions enabled by the authority level they have in the area to which the command center is moved. After 15 seconds of no activity at the keypad, the command center reverts back to the originally programmed area.

Blank, E, or P

Display Rev

Default: E

Selection:

#32 Display Software Revision [COMMAND][5][9]

Use this function to show the control panel’s software revision number in the command center display.

Blank, E, or P

Service Walk

Default: P

Selection:

#33 Service Walk Test (MENU FUNCTION only)

Use this function to Walk Test all 246 points in the entire control panel regardless of the

Blank, E, or P

P## Type

The Service Walk Test is available on the D9412G using the Service Menu [9][9][ENT]. The D7412G does NOT include the Service Walk Test in the Service Menu. The D7412G needs the Service Walk Test function enabled in the Function List to access the Service Walk Test.

Default Text

Default: P

Selection:

#34 Default Text [COMMAND][5][7]

It may be difficult to determine the armed state of an area using the programmed custom text. Use this function to temporarily switch to the control panel default text, shown on the Program Record Sheet.

Blank, E, or P

Change Skeds

Default: P

Selection:

#35 Change Skeds [COMMAND][5][2]

Execute this panel-wide function from any command center assigned to an area where the user has authority. Use this function to change the from the command center to make adjustments to Skeds.

Custom Functions

Blank, E, or P

S## Time

C Function 128 [through 143]

Default: E

Selection:

128 to 143 Enable Custom Functions 128 through 143 (MENU FUNCTION only)

Determines whether or not a passcode is required when accessing a custom function from the menu list. ENTER PASSCODE (or Enter Passcode + Enter Key on the D1260) displays when this function is passcode protected. If a command within the Custom Function is passcode protected, the command center displays ENTER PASSCODE (or Enter Passcode + Enter Key on the D1260) and waits for the user to enter a valid passcode before proceeding with the rest of the Custom Function. If a passcode is not entered within 10 seconds, the Custom Function times out and the display returns to idle text.

Blank, E, or P

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 59

2.11.3 Authority Level Selections

Use Section 2.11.3 Authority Level Selections to determine which Authority Level can access command center functions that are Passcode Protected. You do not need to select Enable items in the Authority Level section if the command center function is disabled or enabled. There are two selections you can use for each individual function for the authority level you are programming.

Press the [SPACE] bar to scroll through the selections. Press [ENTER] when the correct selection appears in the display.

Table 26: Authority Level Selections

Authority Level Description

Blank

Disabled: This function is not authorized for the user who is assigned this authority level.

Enabled: This function is authorized for the user who is assigned this authority level.

Authority Level

Default: 1

Selection:

Enter the number of the authority level you want to program. Authority Level 15 (Service Passcode) cannot be edited.

1 to 14

L## Disarm

Default: See Selection: Blank or E

Program Record Sheet

#1 Disarm

Use the disarming function to disarm areas that are master armed or perimeter armed. If enabled, the following disarming choices are available to the user with this authority.

DISARM ALL: Disarms all areas within the

of the command center being used by

Scope

accessing the Function Menu and the authority level of the user performing the function.

DISARM AREA: Disarms only the displayed area.

CC#

0101 0101 0101

There are many options available for arming and disarming. This depends on A# Area Type and CC# Scope. Read the definitions of area type in Section 2.9 Area

Parameters and CC# Scope in Section

2.10.1 Cmd Cntr (Command Center) Assignment.

L## Master Arm Delay

Default: See Selection: Blank or E

#2 Master Arm Delay [COMMAND][1]

Master arms areas based on the command center using an exit delay time.

When this item is accessed through the Function List, Master Arm All allows the user to arm all areas according to the authority level of the user and within the an exit delay time.

Arm Area arms only the area displayed.

If COMMAND 1 is used, it arms only the area where the command center is assigned.

CC# Scope

Program Record Sheet

CC# Scope

of the command center using

of the

.L## Mstr Arm Inst

Default: See Selection: Blank or E

#3 Master Arm Instant [COMMAND][1][1]

When this item is accessed through the Function List, Master Arm Inst allows the user to arm all areas according to the user’s authority level and within the

CC# Scope

without an exit delay time by accessing the Function Menu.

Arm Area arms only the area to which the command center is assigned.

If COMMAND 11 is used, it arms only the area where the command center is assigned.

Use COMMAND 11 carefully because all Perimeter and Interior points become Instant Armed.

Program Record Sheet

of the command center being used

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 60

L## Perim Instant

Default: See Selection: Blank or E

#4 Perimeter Instant Arm [COMMAND][2]

Instant arm all Perimeter points, including Delayed points, only in the area where the command center is assigned.

Program Record Sheet

L## Perim Delay

Default: See Selection: Blank or E

#5 Perimeter Delay Arm [COMMAND][3]

Delay arm all Perimeter Delay point responses only in the area where the command center is assigned.

Program Record Sheet

L## Watch Mode

Default: See Selection: Blank or E

#6 Watch Mode [COMMAND][6]

Initiate the Watch Mode in the area to which this command center is assigned.

Program Record Sheet

L## Perim Partial

Default: See Selection: Blank or E

#7 Perimeter Partial Arm [COMMAND][8]

Partially arms only the area where the command center is assigned.

This function ignores the A# FA Bypass Max entry in Area Parameters.

0101 0101 0101

Local Only Reporting: No Closing Report is sent to the central station, but a Perimeter Delay Closing Event is generated in the event log.

Program Record Sheet

L## View Area Stat

Default: See Selection: Blank or E

#8 View Area Status (MENU FUNCTION only)

View the current arm/disarm and not ready to arm status of all areas within the scope of the command center in this area. The user needs arming/disarming authority.

Program Record Sheet

L## View Memory

Default: See Selection: Blank or E

#9 View Event Memory [COMMAND][4][0]

View all memory events that occurred since the last time the system was armed for all areas within the scope of the command center in this area.

Program Record Sheet

L## View Pt Status

Default: See Selection: Blank or E

#10 View Point Status (MENU FUNCTION only)

View the current status of all points in the area to which this command center is assigned.

Program Record Sheet

L## Walk Test

Default: See Selection: Blank or E

#11 Walk Test [COMMAND][4][4]

Initiate a Walk Test for all Interior/Perimeter Controlled points in the area to which this command center is assigned.

The following features are provided with the Walk Test Mode:

• During this test, the battery powers the control

panel only. A Battery Test is initiated during the full duration of the test to ensure the battery capacity is capable of supporting the full load of the control panel while AC is failed.

- This test includes an initial 2-second Bell

Test when starting the Walk Test.

- The test ends once all points are tested or

until the test times out after 20 minutes of no activity.

• Local alarm annunciation and event printing

without reporting to the central station receiver.

• D1255 command center displays a sequential

count after each point is activated and restored as well as the text for the point.

• The command center displays ALL PTS

TESTED and an All Points Tested Event is

reported to the central station receiver (if programmed) when the last point is tested.

• If enabled in Routing, Walk Start and Walk End

are reported at the central station receiver for the beginning and end of the test.

Program Record Sheet

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 61

To Walk Test a Door point connected to a D9210B Access Interface Module, the door must be opened without activating the door sequence or allowing it to time out past the extended shunt time.

L## Fire Test

Default: See Selection: Blank or E

#12 Fire Test [COMMAND][5][8]

Initiate a Fire Walk Test for all 24-hour points in the area where this command center is assigned.

When a Fire Test is initiated, one person can test a fire system without assistance. The following features are provided with the Fire Test Mode:

• During this test, the battery powers the control

panel only. A Battery Test is initiated during the full duration of the test to ensure the battery capacity is capable of supporting the full load of the control panel while AC is failed.

- This test includes a 2-second Bell Test (Fire

Bell relay) for each Fire point that is tested.

- The test ends once all points are tested or

until the test times out after 20 minutes of no activity.

• Local alarm annunciation and event printing

without reporting to the central station receiver.

• Automatic smoke detector reset Sensors

Resetting for all Fire points programmed with

P## Resettable

• D1255 command center displays a sequential

count after each point is activated and restored, as well as the text for the point.

• If enabled in Routing, Fire Walk Start and Fire

Walk End are reported at the central station receiver for the beginning and end of the test.

A# Verify Time for Fire points programmed with P## Alarm Verify as Yes is ignored during the Fire Walk Test.

Program Record Sheet

as Yes.

L## Send Report

Default: See Selection: Blank or E

#13 Send Report [COMMAND][4][1] or [COMMAND][4][2]

Send a Test Report from any command center assigned to an area where the user has authority.

Program Record Sheet

Access Control Functions

The following functions enable the user to control the doors using the command center. Users can have authority to access the Door Control and can use either all or part of the functions within.

All doors display when this function is chosen. This function does not follow the scope of the command center.

L## Door Control

Default: See Selection: Blank or E

#14 Door Control [COMMAND][4][6]

This item only allows programming access to the following three sub-prompts. It does not affect the user’s access to Cycle Door, Unlock Door, and Secure Door.

Cycle Door, Unlock Door, and Secure Door cannot be accessed through the Function List. Door Control must be added to the Function List to access the door control functions, or COMMAND 46 may be used.

The following prompts are sub-functions of Door Control. They become visible in the D5200 Programmer when you Enable Door Control and press [ENTER] on the D5200.

0101 0101 0101

Cycle Door must be enabled for all three sub-functions to operate. If Cycle Door is disabled, all three sub-functions do not operate.

Program Record Sheet

L## Cycle Door

Default: See Selection: Blank or E

Cycle Door (MENU FUNCTION only)

Press the command center number keys [1] through [8] that correspond to the door number to cycle doors. For example, pressing [2] and [ENTER] cycles door number 2, which is indicated by C in the display.

Cycle Door allows the user with this authority level to access the CYCLE? 12345678 function.

Program Record Sheet

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 62

L## Unlock Door

Default: See Selection: Blank or E

Unlock Door (MENU FUNCTION only)

Press the command center number keys [1] through [8] that correspond to the door number to unlock/relock doors. For example, pressing [2] and [ENTER] unlocks door number 2, which is indicated by U in the display.

Unlock Door allows the user with this authority level to access the UNLOCK? 12345678 function.

Program Record Sheet

L## Secure Door

Default: See Selection: Blank or E

Secure Door (MENU FUNCTION only)

Press the command center number keys [1] through [8] that correspond to the door number to secure/unsecure doors. For example, pressing [2] and [ENTER] secures door number 2, which is indicated by an X in the display.

Secure Door allows the user with this authority level to access the SECURE? 12345678 function.

Program Record Sheet

Table 27: L## Secure Door-Door Mode

Definitions

Door State Definition

Lock Door

Secure Door

Unlock Door

Cycle Door

Normal Door: When a door is in the Lock Door state, one can initiate the door sequence using Skeds, CYCLE DOOR?, command center functions, door requests, and valid token/card requests.

No Access Allowed: When a door is in the Secure Door state, no access is allowed through the door until it is returned to the Lock Door state. This includes Sked and command center functions.

Free Access: When a door is in the Unlocked Door state, the door is already shunted and the strike does not prevent the door from opening. In this state, the user does not need to activate a door request or present a valid token/card.

Momentary Access: This is a temporary Door Mode in which the door initiates the door sequence as if a valid token/card was read. This state occurs using the command center and RAM. A sked cannot activate this state.

Bosch Security Systems | 1/04 | 47775E

L## Access Ctl Lvl

Default: See Selection: Blank or E

#37 Access Control Levels (MENU FUNCTION only)

Changing the Access Control Level in any area affects all users and all doors associated with that level for all areas.

Access Level Ctl allows the user with this authority level to enable/disable access control levels for all doors activated in the control panel regardless of the area in which the doors are assigned.

Program Record Sheet

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 63

L## Chg Display

Default: See Selection: Blank or E

#15 Change Display [COMMAND][4][9]

Change the display (bright display, dim display, and time display) in the area where this command center is assigned.

Program Record Sheet

L## Chg Time/Date

Default: See Selection: Blank or E

#16 Change Time and Date [COMMAND][4][5]

Change the date and time for the control panel in this area.

Program Record Sheet

L## Chg Passcode

Default: See Selection: Blank or E

#17 Change Passcodes [COMMAND][5][5]

Change a user passcode.

Program Record Sheet

L## Add User

Default: See Selection: Blank or E

#18 Add User [COMMAND][5][6]

Add/change users, add/change authority levels, add/change tokens/cards.

9210 NOT READY appears if a door controller is not assigned (see CC#

Assign Door in Section 2.10.1 Cmd Cntr (Command Center) Assignment) to the

command center used to add/change tokens/cards.

Program Record Sheet

L## Del User

0101 0101 0101

Although an individual user (001 through

249) can be deleted separately, take caution. User passcode, token/cards cannot be deleted individually within a group (for example, User 001 has three additional sub-users that use the same authority levels for that group). When dealing with an individual user, change that user’s token/passcode so other users in the group do not need to be readded.

L## Extend Close

Default: See Selection: Blank or E

#20 Extend Close [COMMAND][5][1]

Change the closing time in the area where the function is entered.

Program Record Sheet

L## View Log

Default: See Selection: Blank or E

#21 View Log (MENU FUNCTION only)

View all panel-wide events in the control panel’s memory log.

Program Record Sheet

L## Print Log

Default: See Selection: Blank or E

#22 Print Event Log (MENU FUNCTION only)

Print all panel-wide events from the log to the printer in the area where the user is executing this function.

This item can also be accessed using the Service Menu ([9][9][ENT]).

Program Record Sheet

Default: See Selection: Blank or E

#19 Delete User [COMMAND][5][3]

Delete users.

Bosch Security Systems | 1/04 | 47775E

Program Record Sheet

L## User Cmd 7

Default: See Selection: Blank or E

#23 User COMMAND 7 [COMMAND][7]

Can be used in Function Menu. Generate the alarm programmed at COMMAND 7 in the RADXPNTS Handler.

Program Record Sheet

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 64

L## User Cmd 9

Default: See Selection: Blank or E

#24 User COMMAND 9 [COMMAND][9]

Can be used in Function Menu. Generate the alarm programmed at COMMAND 9 in the RADXPNTS Handler.

Program Record Sheet

L## Bypass a Pt

Default: See Selection: Blank or E

#25 Bypass a Point [COMMAND][0]

Bypass points with this authority level

Program Record Sheet

L## Unbypass a Pt

Default: See Selection: Blank or E

#26 Unbypass a Point [COMMAND][0][0]

Unbypass points with this authority level.

Program Record Sheet

L## Reset Sensors

Default: See Selection: Blank or E

#27 Reset Sensors [COMMAND][4][7]

Reset sensors with this authority level.

Program Record Sheet

L## Change Relay

Default: See Selection: Blank or E

#28 Change Relays [COMMAND][5][4]

Set RELAY ON? and reset RELAY OFF? relays in the control panel.

Do not use the Chg Relays? function to toggle relays reserved for special functions. Special function relays are Area and Panel Wide Relay functions as well as relays assigned to CC# Entr Key Rly?.

Program Record Sheet

L## Remote Program

Default: See Selection: Blank or E

#29 Remote Programming [COMMAND][4][3]

Initiate a RAM session once the phone rings at the control panel.

Program Record Sheet

L## Move to Area

Default: See Selection: Blank or E

#30 Move to Area [COMMAND][5][0]

Temporarily switch to a different area and perform command center functions related to the area to which the command center is switched.

Program Record Sheet

L## Display Rev

Default: See Selection: Blank or E

#32 Display Software Revision [COMMAND][5][9]

Display the control panel software revision 9412 REV ##.##.

Program Record Sheet

L## Service Walk

Default: See Selection: Blank or E

#33 Service Walk Test (MENU FUNCTION only)

Initiate a Service Walk Test for all 24-hour Interior/Perimeter Controlled points in the control panel.

Points are not included in this test if:

• Points are in an area that is already in a Walk

Test Mode.

• Points are assigned to an area that is not enabled

A# Area On

• Points are in an area that is Master or Perimeter

armed.

• When a Service Walk Test is initiated, one

person can test all the points in the control panel without assistance. The following features are provided with the Service Test Mode:

- Display tells you exactly how many points

can be tested.

- A Battery and Bell Test does not occur

during this Walk Test.

- The test ends once all points are tested or

until the test times out after 20 minutes of inactivity.

- Local event printing without alarm

annunciation or reporting to the central station receiver.

Program Record Sheet

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 65

- D1255 command center displays a

sequential count after each point is activated and restored as well as the text for the point.

- The D1255 command center displays ALL

PNTS TESTED.

- If enabled in Routing, Service Start and

Service End are reported at the central station receiver for the beginning and end of the test.

Point 128 and Point 248 appear as missing. This is normal. These points are used for supervising the Zonex bus 1 (Point 128) and Zonex bus 2 (Point

248). If these points indicate a short, the Zonex bus has a fault.

Extra points can be viewed using this function. Extra points occur under two conditions: an extra point is a point wired electrically to the Zonex bus with a blank

P### Point Index

exist for the same Zonex address.

, or two Zonex devices

L## Default Text

Default: See Selection: Blank or E

#34 Default Text [COMMAND][5][7]

Temporarily display the armed state of the area using control panel default text, A# AREA # IS ON, A# NOT READY, A# AREA # IS OFF, and A# ACCOUNT IS ON.

Program Record Sheet

L## Change Skeds

Default: See Selection: Blank or E

#35 Change Skeds [COMMAND][5][2]

Change skeds that can be edited.

Skeds can be restricted from being edited by programming S## Time Edit? to No.

Custom Functions

Program Record Sheet

L## C Function 128 [through 143]

Default: See Selection: Blank or E

128 to 143 Enable Custom Function 128 through 143 (MENU FUNCTION only)

Execute the desired Custom Function.

Program Record Sheet

Report Levels

L## Force Arm

Default: See Selection: Blank or E

Allows a user with this authority level to Force Arm.

Program Record Sheet

L## Area O/C

Default: See Selection: Blank or E

Generate Opening and Closing Reports if the area where this authority level is assigned sends Opening and Closing Reports.

Program Record Sheet

L## Restricted O/C

Default: See Selection: Blank or E

Initiate an Opening Report if a bell is ringing or a Closing Report when force/bypass arming. The area where this authority level is assigned must be programmed for restricted openings and closings (see the

Open/Close Options)

A# Restrictd O/C

Program Record Sheet

prompt in Section 2.9.5

.L## Perimeter O/C

Default: See Selection: Blank or E

Report Perimeter Opening and Closing Reports if the area where this authority level is assigned sends Perimeter Opening and Closing Reports.

Program Record Sheet

L## Send Duress

Default: See Selection: Blank or E

Send a Duress Report if the area where this authority level is assigned sends duress. (See the

Duress Enable

Parameters).

Program Record Sheet

prompt in Section 2.9 Area

L## Passcode Arm

Default: See Selection: Blank or E

Arm an area by entering a passcode and pressing [ENTER].

Program Record Sheet

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 66

L## Passcode Disarm

Default: See Selection: Blank or E

Disarm an area by entering a passcode and pressing [ENTER].

Access Control Levels

Program Record Sheet

L## Security Level

Default: See Selection: M, P, D, or Blank

M Users have access rights for this area

P Users have access rights for this area

D Users have access rights for this area

Blank Users do not have access rights to this

Security Level [TOKEN FUNCTION]

When the user presents a token/card at the reader, access is granted only when the user has the authority to enter the area under certain armed conditions.

Program Record Sheet

when the area is in any armed state.

when the area is Perimeter Armed or disarmed but not while the area is Master Armed.

only while it is disarmed.

area.

L## Disarm Level

Default: See Selection: I, D, or Blank

I Users change the Master Armed state

Blank Users do not have disarm rights in this

Burglar bells are silenced in the local area when a user disarms with a token/card or presents the token/card during an alarm. The user must use a passcode to silence a Fire Bell. Cancel Reports are sent after a valid passcode or token/card silences the bell.

Program Record Sheet

and Perimeter Armed state to Perimeter Instant. The armed state does not change in other areas, and the armed state does not change if the area is already in the perimeter instant or disarmed state. User needs access level for Master Armed (M) state.

Users change the local area’s Master Armed state and Perimeter Armed state to the Disarm state. User needs access level for Master Armed (M) or Perimeter Armed (P) state. All areas within the scope of the command center assigned to the

D# CC# Scope

in the access handler, and areas to which the user has disarm rights, disarm as programmed.

area.

Bosch Security Systems | 1/04 | 47775E

0101 0101 0101

Opening and Closing Reports are sent to the central station receiver if programmed.

For more information on programming this prompt for a shared area, see Access

Control Readers Assigned to the Shared Area in Section 2.9.3 Shared-Area Characteristics.

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 67

2.12 Function List

The Function List is accessed when the user presses [MENU] (or the key corresponding to menu) on the D1260) while the command center is displaying the idle text. Up to 32 functions M### Function(s) can be programmed.

Each CC # command center address can display a combination of all/each of the 32 menu items. The D1255 displays one menu item at a time. The D1260 displays up to two menu items at a time. Enabling the function in the menu list does this by command center address. The function name shown in the Functions column on the record sheet appears in the command center display in capital letters. For example, WATCH MODE displays for

Mode.

Menu Item

Default: See Selection: 1 to 32

Enter the menu item number you are programming. The M## Function displays sequentially in the order they are programmed. (M 1 Function is the first function that appears in the menu and M 32 Function is the last function that appears when scrolling through the menu).

0101 0101 0101

A failure to program Menu Item 1 causes COMMAND DISABLED to appear in the command center display.

Program Record Sheet

M## Function

Default: See Selection:

Enter the function number indicated in the “#” column of the Program Record Sheet and next to the function in Section 2.11 User Interface.

0101 0101 0101

Function numbers 128 to 143 are custom functions and display the text programmed for CF ### Text.

There is no restriction on how many times you may assign a specific function to the menu. By doing so, you can assign the same function at different command centers so they appear differently in some areas than in others.

Program Record Sheet

Blank, 1 to 30, 32 to 35, 37, and 128 to 143

#6 Watch

M## CC Address 1 [through 8]

Default: See Selection: Yes or No

Yes This menu item appears at this

Programming this prompt determines at which CC address setting this Menu Item appears.

Program Record Sheet

command center address.

This menu item does not appear at this command center address.

2.13 Relay Parameters

Relays provide dry contact (normally open/closed) outputs for LED annunciation and other applications as well as wet (12 VDC on/off) voltage outputs for basic alarm system functions (such as Bell Output or Reset Sensors). The applications are endless, but primarily, relays are used to enhance a system’s capability to perform output functions.

• Panel-Wide Relays: These relays provide an

output related to a panel-wide indication. For annunciation, these relays can indicate system wide troubles for power, phone, and overall control panel summary of alarms, troubles, and supervisory conditions.

• Area Relays: These relays provide an output by

the area that the relay is assigned to. An area can have its own bell and sensor reset indications. Relays can also indicate the area armed state and whether any off normal conditions such as a force arm occurred.

• On Board Relays: There are three on-board 12

VDC voltage-outputs that provide power when activated on the control panel. These outputs are default programmed from the factory as Relays A, B, and C. Typically, Relay A (Terminal 6) is used for the bell, Relay B (Terminal 7) is used for an alternate alarm output (such as another bell), and Relay C (Terminal 8) is used for Sensor Reset (Relays B and C require the optional D136 Relays).

• Off-Board Relays: The D9412G can also

control 128 (64 for the D7412G) dry contact form C relays when up to sixteen optional D8129 OctoRelay Modules are installed. These relays are used for Area Relay, Panel-Wide Relay, and Individual Point Fault Relays.

• Relay Follows Point: Relays can also be used

to activate when a point programmed for

RlyResp Type

(in Section 4.1 Point Index) is off

normal or in alarm condition.

P##

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 68

• Relay Reports: When relay activity is reported

to the receiver (see Section 2.3 Routing), on-board relays are reported as follows: A = 253, B = 254, C = 255. The others report as 001 to 128. The Relay Report is RELAY SET RELAY # rrr when the relay is turned on and RELAY RESET RELAY # rrr when the relay is turned off. Relay Reports are also printed on the local printer and stored in the control panel memory log.

• Controlling Relays: As mentioned, relays can

be activated depending upon conditions that exist with the control panel. In addition, relays can be controlled by the user using the Chg Relay? function, Relay On/Relay Off skeds, and the Remote Account Manager.

Review the following programming tips, notes, and applications before programming your relays.

DO NOT use the CHG RELAYS? function to toggle relays reserved for special functions. Special function relays are Area and Panel Wide Relay functions as well as relays assigned to CC Entr Key Rly and P## RlyResp Type.

0101 0101 0101

Check relay status after reprogramming or resetting the control panel. All relays are turned off after the control panel resets. The control panel checks certain relay functions each minute and resumes the correct state after the reset. Other relays must be manually set to the correct state using the Change Relay Function (COMMAND 54).

These Relay functions resume the proper state within 1 minute:

Alarm Bell Perimeter Fault Summary Fire Summary Trouble Area Armed Reset Sensors Fire Bell AC Fail Summary Alarm Phone Fail Silent Alarm Summary SupBurg Area Fault Battery Trouble Summary Fire Tbl Communications Fail Watch Mode Summary SupFire

These Relay functions must be manually reset with Change Relay function (COMMAND 54):

Relay C is always on. Assigning any other relay (1 to 128, A or B) deactivates Relay C so this output can be used for other functions. When Relay C is programmed for A# Rest Sensors, power is always supplied from Terminal 8 of the control panel.

Fail To Close Force Armed Duress Log % Full

2.13.1 Area Relays

Each area can be assigned a unique relay number for each of the events listed in this section.

Area

Default: 1 Selection: 1 to 8

Enter the area number you are programming.

A# Alarm Bell

Default: A Selection:

This voltage output relay activates and provides 12 VDC output when a Non-fire point ( No) assigned to this area goes into alarm.

0101 0101 0101

Blank, 1 to 128 (1 to 64 for D7412G), A, B, or C

P## Fire

Burg Time and Burg Pat must be programmed in Bell Parameters. This relay activates according to the bell pattern and remains active until the bell time expires. P## Silent Bell must be No for the bell to ring upon alarm.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 69

A# Fire Bell

Default: A Selection: Blank, 1 to 128 (1 to 64 for D7412G),

A, B, or C

This voltage output relay activates and provides 12 VDC output when a Fire point (

P## Fire

is Yes)

assigned to this area goes into alarm.

0101 0101 0101

Fire Time and Fire Pat must be programmed in Bell Parameters. This relay activates according to the bell pattern and remains active until the bell time expires. P## Silent Bell must be No in order for the bell to ring upon alarm.

0101 0101 0101

Although Relay C is a valid entry for A# Fire Bell, do not program Relay C for this entry.

A# Reset Sensors

Default: C Selection:

Unlike the default relay for Alarm Bell and Fire Bell, this voltage-output relay (Relay C) de-activates for 5 seconds when the Reset Sensors? function is initiated from the command center or during a Fire Walk Test.

Blank, 1 to 128 (1 to 64 for D7412G), A, B, or C

The Reset Sensor time converts from the 5 second default time to the time programmed in A# Verify Time (see Section 2.9 Area Parameters) when a point programmed for P## Alarm Verify (Section 4.1 Point Index) goes into an alarm condition.

0101 0101 0101

When sharing one relay to reset sensors in two or more areas, you must program the following. Failure to do so causes TROUBLE PT ### for all point types programmed as P## Resettable.

• CC # Scope must include all the areas

that are sharing the relay.

• L## Reset Sensors for the user

initiating the sensor reset must be enabled for all the areas that are sharing the relay.

• A# Verify Time must be the same

number of seconds for all the areas that are sharing the relay.

A# Fail to Close

Default: Blank Selection:

Blank, 1 to 128 (1 to 64 for D7412G), A, B, or C

Activates when the Closing Window expires for the specified area. It remains activated until midnight, or until another Closing Window starts, or the control panel is reset, whichever occurs first.

See Programming Tip #5 in this section for additional relay functions.

A# Force Armed

Default: Blank Selection:

Activates when this area is Force Armed. It remains activated until the area is disarmed or the control panel is reset.

Blank, 1 to 128 (1 to 64 for D7412G), A, B, or C

Bosch Security Systems | 1/04 | 47775E

When perimeter force arming, this relay does not activate.

A# Watch Mode

Default: Blank Selection:

Activates when a Controlled point programmed for

P## Watch Point

while the area is in Watch Mode and the point is not armed. It remains activated for 2 seconds after each point is faulted.

Blank, 1 to 128 (1 to 64 for D7412G), A, B, or C

is tripped in the specified area

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 70

A# Area Armed

Default: Blank Selection: Blank, 1 to 128 (1 to 64 for D7412G),

A, B, or C

Activates when the specified area becomes master armed (exit delay must expire before the relay activates). The relay remains activated until the area is disarmed. It does not deactivate during the entry delay time.

If multiple areas use the same relay, the relay activates when all areas are armed. It deactivates when the first area disarms.

Programming a 64 in Area 8’s Silent Alarm relay causes the Area Armed relay to energize at the beginning of the exit delay time.

Keyswitch area armed status with LEDs. Use a D8129 Module and connect an LED to display the armed state.

Alternate communication trigger: This output relay can be used to trigger the input zone of a device being used as a slave to report control panel arming status.

A# Area Fault

Default: Blank Selection: Blank, 1 to 128 (1 to 64 for D7412G),

A, B, or C

The relay activates whenever a controlled (

Type 1, 2, 3

only) Perimeter or Interior point is faulted. The relay remains activated until all Perimeter and Interior points in the area are normal.

Keyswitch area armed status with LEDs. Use a D8129 Module and connect an LED to light when this relay is activated indicating that the area is not ready to arm.

P##

0101 0101 0101

Burg Time needs a bell period programmed and A# Duress Enable must be Yes. This relay activates steadily regardless of bell pattern and remains active until the bell time expires.

A# Perim Fault

Default: Blank Selection: Blank, 1 to 128 (1 to 64 for D7412G),

A, B, or C

The relay activates when a Controlled Perimeter point (

P## Type 1

) assigned to the specified area is faulted. This relay activates regardless of the areas armed state. This relay provides a steady output until all Perimeter points in the area return to normal.

This relay does not activate on interior faults. To detect all area point faults, program all points as Perimeter points in the area where this relay is assigned.

A# Silent Alarm

Default: Blank Selection: Blank, 1 to 128 (1 to 64 for D7412G),

A, B, or C

This relay activates when a point assigned to the specified area and programmed for goes into alarm.

0101 0101 0101

Programming Tip #1: Burg Time needs a bell period programmed. This relay activates according to the bell pattern and remains active until the bell time expires or a valid passcode is entered.

0101 0101 0101

Programming Tip #2: Programming 64 in Area 8’s Silent Alarm Relay causes the Area Armed or Perimeter Armed Relay (see Programming Tip #5) to energize at the beginning of the exit delay time.

P## Silent Bell

A# Duress Relay

Default: Blank Selection: Blank, 1 to 128 (1 to 64 for D7412G),

A, B, or C

The relay activates when a Duress alarm is generated from a command center assigned to the specified area.

Bosch Security Systems | 1/04 | 47775E

0101 0101 0101

Programming Tip #3: Programming a non-zero value in Area 5’s Silent Alarm Relay enables Ground Fault Detect on the D9412G or D7412G Control Panels. See the D9412G/D7412G Operation and Installation Guide regarding Ground Fault Detect.

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 71

0101 0101 0101

Programming Tip #4:

Fire Trouble Resound was added to firmware versions 6.20 and later. This feature, when enabled, resounds the Fire Trouble condition at 12:00 PM or 12:00 AM if the Fire Trouble condition still exists. It does not, however, retransmit the Fire Trouble condition at the specified time. The Fire Trouble Event is only sent, if programmed to do so, at the time it occurs.

• To disable the Fire Trouble Resound

feature, program a 0 in Area 6’s Silent Alarm Relay entry.

• To enable the Fire Trouble Resound

feature at 12:00 PM, program a 61 in Area 6’s Silent Alarm Relay entry.

• To enable the Fire Trouble Resound

feature at 12:00 AM, program a 62 in Area 6’s Silent Alarm Relay entry.

Note:

Programming a value other than 0, 61, or 62 enables the Fire Trouble Resound feature at 12:00 AM.

Beginning in Firmware version 6.30 and higher, a Fire Trouble Resound prompt was added to Section 6.7 Miscellaneous. This prompt operates as described.

Programming Tip #5:

Perimeter Armed Relay was added to firmware versions 6.20 and later. This feature, when enabled, turns the Fail to Close Relay function into a Perimeter Armed Relay function.

To switch the Fail to Close Relay into a Perimeter Armed Relay function, program a 63 in Area 7’s Silent Alarm Relay entry. Then, program a relay number into the appropriate area you wish to activate when the area becomes Perimeter Armed (COMMAND 2, COMMAND 3, or COMMAND 8). See Programming Tip #2 for additional information.

2.13.2 Panel-Wide Relays

The following eleven relay options activate when they occur anywhere in the control panel. They are not restricted by area boundaries.

AC Failure

Default: Blank Selection: Blank, 1 to 128 (1 to 64 for D7412G),

A, B, or C

Activates when the control panel responds to an AC power failure as programmed in

AC Fail Time

in Section 2.5 Power Supervision. This relay automatically resets when AC power is restored.

Use this relay as an option to create audible annunciation using the command centers for all applications excluding commercial fire systems.

Battery Trouble

Default: Blank Selection:

Blank, 1 to 128 (1 to 64 for D7412G), A, B, or C

Activates when battery voltage falls below 85% of capacity (12.1 VDC) for a fully charged (13.8 VDC) battery, or when the battery is in a missing condition. This relay automatically resets when battery power is restored.

Use this relay as an option to create audible annunciation using the command centers for all applications excluding commercial fire systems.

Phone Fail

Default: Blank Selection:

Activates when a telephone line failure occurs. A time must be entered in Ph Supv Time (see Section

2.2 Phone Parameters) for this relay to activate. This relay automatically resets upon restoral of the phone line(s).

Blank, 1 to 128 (1 to 64 for D7412G), A, B, or C

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 2.0 9000MAIN EN | 72

Comm Fail

Default: Blank Selection: Blank, 1 to 128 (1 to 64 for D7412G),

A, B, or C

This relay activates when a control panel is unable to communicate a report after making ten attempts to each routing destination. At the same time, COMM FAIL RT ## displays at the command center. This relay automatically resets when a report is sent successfully.

Use this relay to report primary digital report failure to an alternate communication device.

Log % Full

Default: Blank Selection: Blank, 1 to 128 (1 to 64 for D7412G),

A, B, or C

Enter the number of the relay that activates when the log reaches the programmed percentage of its capacity as programmed in RAM Parameters program item Log % Full. This relay provides a steady output until a Get Log and Set Pointer is performed from the RPS.

Summary Fire

Default: Blank Selection:

Enter the number of the relay that activates when any Fire point in the system ( Yes) goes into alarm. This relay provides a steady output until all Fire points in the system are returned to normal.

Blank, 1 to 128 (1 to 64 for D7412G), A, B, or C

P## Type 0, P## Fire

Summary Alarm

Default: Blank Selection: Blank, 1 to 128 (1 to 64 for D7412G),

A, B, or C

Enter the relay’s number that activates when a Nonfire point goes into alarm. This relay provides a steady output until the alarm is acknowledged by a valid passcode then cleared from alarm memory with an acknowledgment at the command center.

Summary Fire Tbl

Default: Blank Selection: Blank, 1 to 128 (1 to 64 for D7412G),

A, B, or C

This relay activates when any Fire point in the control panel is in trouble, or if a Fire Supervision point is missing. This relay provides a steady output until all Fire points restore to a normal condition.

Summary SupFire

Default: Blank Selection: Blank, 1 to 128 (1 to 64 for D7412G),

A, B, or C

Activates when any Fire Supervisory point in the control panel is in a supervisory condition (off normal). This relay provides a steady output until all Fire Supervisory points are restored to a normal condition.

Summary Trouble

Default: Blank Selection:

Activates when any Non-fire point in the control panel is in a trouble condition. This relay provides a steady output until the user at the command center acknowledges the trouble.

Blank, 1 to 128 (1 to 64 for D7412G), A, B, or C

Summary SupBurg

Default: Blank Selection:

Activates when any Non-fire Supervisory point in the control panel is in a supervisory condition, or if a Supervisory Burg point is missing. This relay provides a steady output until it is acknowledged at the command center.

Blank, 1 to 128 (1 to 64 for D7412G), A, B, or C

This relay does not activate for silent alarms.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 3.0 RADXUSR1/RADXUSR2 EN | 73

3.0 RADXUSR1/RADXUSR2

3.1 Passcode/Token Worksheet

These programming items assign user groups 001 to 249 a passcode, area assignment by authority level, and a User Group Window.

0101 0101 0101

3.1.1 User Groups

For the D9412G, there are 249 groups (99 groups for the D7412G) consisting of one user with a passcode and token, (master) and three users with tokens/cards but not a passcode (sub-user). All users in the group share the same authority level as the master user.

3.1.2 Passcodes

Only the master user is assigned a passcode. The passcode can be three to six digits. Entering three digits in Programming the passcode to the master user. Sub-users cannot use the passcode. While the system allows tokens/cards to be added to USER 0 (service passcode), the tokens/cards do not function because the service passcode uses Authority Level 15.

3.1.3 User Group Window

Use

U### Passcode

periods throughout the day. Assign the number (1 to

8) programmed in

Windows #

COMMAND DISABLED appears on the command center after the user enters the passcode and presses [ENTER].

3.1.4 Authority Level by Area

A user group is assigned an authority level of 1 through 14 for each area using the

Auth

for each area. Not programming an authority level for an area is indicated by the NOT AUTHORIZED display on the command center.

Two handlers in the D5200 Programmer are used to program the users. RADXUSR1 Handler programs users 000 to 124. RADXUSR2 programs users 125 to 249 (D9412G only).

User ###

U### User Group

This window does not affect tokens/cards, it only affects the passcode of the master user.

chooses the master user.

U### Passcode

to enable/disable the

for up to eight different time

U### User Group

. If the user is outside a window,

assigns a

to a

User

U### Area #

prompt. The authority level can be different

When using the Add/Change User function at the command center, the authority levels and the changes made affect the master user’s passcode and the entire group’s token/cards.

When using the ACCESS CTL LVL function at the command center, the whole group is affected by whether the level is on or off for access control functions only.

When using the DELETE USER? function, the whole group is deleted. There is no means to delete each user within the group individually. It is recommended that you use the ADD/CHG USER? function to change a user token/card instead of deleting the whole group.

3.1.5 User Name

Each user group can be assigned one This name is logged and reported to the central station for all the users in the group. The user ID is used to differentiate which user’s token/card was executed.

Beginning with v6.30, when using a D1260 Command Center, User 249 text is used for contact information text (such as telephone numbers). If a D1260 is installed on the system, do not use User 249 for user ID information.

3.1.6 Tokens/Cards

The master user assigned the passcode can also be assigned a token/card. This is done by programming

U### Mstr Site

the

Three more token/cards are assigned to the user group for sub-users using the

U### SU# C/D

3.1.7 Reporting and Logging

Modem Format

reports to the central station. Regardless of the reporting format, they log and print at the local printer as shown. Each sub-user is identified by the master user’s three-digit number plus an extension of 0, 1, 2, or 3. These numbers are called Sub-user ID Codes.

Figure 3 shows all the users for User Group 122 as they would appear.

and

U### Mstr C/D

U### SU# Site

must be Yes for the following

U### Name

and

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 3.0 RADXUSR1/RADXUSR2 EN | 74

Figure 3: User Group 122 Example

Master User:

ID 122

♦ CRD ID 122-0

Sub User -1: ID 122-1

♦

CRD ID 122-1

Sub User -2: ID 122-2.

♦

CRD ID 122-2

Sub User -3: ID 122-3.

♦

CRD ID 122-3

1 - User passcode 2 - User token/card

0101 0101 0101

In reporting systems using modem format, all three digits of the User ID Code are transmitted to the central station with appropriate reports. Central station automation computer systems may only accept Zonex and COMEX style User Ids. See Point/User Flag in Section 2.1 Phone.

In BFSK, only one number is transmitted. This number represents a group of ten users as shown in Table 28. Users 100 through 249 do not report in BFSK format.

Table 28: BSFK User Code Report

User Code 000 to 009

BFSK

Report

User Code 010 to 019

BFSK

Report

User Code 020 to 029

BFSK

Report

User Code 030 to 039

BFSK

Report

User Code 040 to 049

BFSK

Report

User ###

Default: 001 Selection: 000 or 001 to 249 (001 to 099 for the

D7412G)

Enter the User number you are programming.

0101 0101 0101

User 000 is the Service Authority Level (Level 15). You cannot change the programming for user 000.

Only the Service Authority Level (User

000) can delete User 000. When a user other than User 000 tries to delete the passcode for User 000, the command center displays NOT IN USE.

User 000 cannot be added/changed at the command center whether it exists or not.

User Code 050 to 059

BFSK

Report

User Code 060 to 069

BFSK

Report

User Code 070 to 079

BFSK

Report

User Code 080 to 089

BFSK

Report

User Code 090 to 099

BFSK

Report

U### Passcode

Default: See Selection: Three to six digits ( 0 to 9)

Enter three to six digits to enable a passcode for the master user in this group.

0101 0101 0101

User I.D.000 is the Service Passcode. The default Service Passcode is 123.

The programmer does not allow you to enter any passcode number that could conflict with a duress passcode. If Duress Type is a 1, passcodes within a range of 1 for existing passcodes cannot be entered. This rule applies even if duress is disabled. For example, once a passcode of 654321 is entered, 654322, 654323, 654320, and 654329 cannot be entered.

Program Record Sheet

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 3.0 RADXUSR1/RADXUSR2 EN | 75

A silence bell authority is built into all authority levels, even if they are the default and none of the available programmable functions are enabled. A user passcode can silence a Fire/Burg bell as long as any authority level is assigned to the area where the bell can be silenced.

U### User Group

Default: Blank Selection: Blank, 1 to 8

Use this parameter to create a group of up to 249 users (99 for the D7412G) whose combinations can be enabled/disabled using an automatic user window. This is the number entered into the

User Group

Multiple windows can be programmed for one user group (up to eight) within one 24-hour period. For example, if User Group 1 has a window running from 8:00 AM (start time) to 4:00 PM (stop time), the users for that group may use their passcodes only between that time. Between 4:00 PM that day and 8:00 AM the next day, the users may not use their passcodes.

0101 0101 0101

User Group Window times cannot be changed from the command center. Once a window is assigned to a user group, the users in that group rely on the window to be active (within the start and stop times) for their passcodes to function. The only way to disable the window is by reprogramming the control panel from the D5200 or RAM.

for any active

To enable this user’s passcode at all times, leave U### User Group blank.

W# User Window

U### Area 1 [through Area 8] Auth

Default: See Selection: 1 to 14 or Blank

Assign an authority level to the user for this area.

Blank means the user has no authority in this area.

Program Record Sheet

U### Name

Default: See Selection: Sixteen alphanumeric characters

Enter Alphabetic-characters A to Z in capital letters

Period (.), comma (,), percent (%), parentheses [()], equal (=), greater/less than (<>), exclamation (!), braces ({}), apostrophe (’), carat (^), grave accent (`), tilde (~), semi-colon (;), and colon (:) are not allowed.

Enter up to sixteen characters of text for this user group.

Programming this group with a departmental, team, or function name identifies all the users in this group in a function related manner, such as ENGINEERING.

Card Data Format

The D9412G/D7412G and D9210B Controller comply with the 26-BIT Wiegand card data format. In essence, the format consists of 26 bits (3.2 bytes) of data. The first bit is used for the even parity. The next 8 bits (first byte) is used for the

. The next 16 bits (second and third byte) are

Code

used for the for the odd parity.

As long as the reader and tokens/cards you are using are 26-BIT Wiegand compatible, they function with this system.

Use only the readers identified as being compatible with the D9210B door control module. Information on these readers can be found in the D9210B O/I Manual.

For more information, see the Security Industry Association (SIA) Access Control 26-BIT Wiegand Reader Interface Standard.

Program Record Sheet

U### Card Data

. The last bit is used

U### Site

U### Mstr Site

Default: Blank Selection: 000 = (0) to 254 or Blank (255)

Bosch Security Systems | 1/04 | 47775E

Master User ### Site Data

Enter the first three decimal numbers on the back of the token/card. This is the first byte (bits 2 through

9) of data for a 26-bit Wiegand card. This is called the site number. Tokens/cards with a site code of 255 are not compatible with the D9412G/D7412G Control Panels.

D9412G/D7412G | Program Entry Guide | 3.0 RADXUSR1/RADXUSR2 EN | 76

0101 0101 0101

Converting hexadecimal to decimal: If your card label contains letters as well as numbers, the number is hexadecimal.* Convert the hexadecimal number to decimal using your calculator. If you cannot convert in this way, use the reader and the Add/Chg User? Function to add the tokens/cards.

Perform the following test to confirm you can convert properly:

Use 319EB0 as the hexadecimal number. On your calculator, press [HEX]. Enter all the hexadecimal characters into the calculator. Press [DEC] and your hexadecimal characters convert to the following eight digits: 03251888. The site number is 032. Enter it in U### Mstr

Site. Your card data is 51888. Enter it into U### Mstr C/D.

* A hexadecimal number can contain all

numerals. If the code does not work try converting the number from hexadecimal to decimal.

U### SU1 through SU3 C/D

Default: Blank Selection: 00000 = (0) to 655354 or Blank

(65535)

Sub-users one through three card data.

Always tag your tokens before adding them to the system so you do not mix them up. Use the CRD ID ###-# number to index them.

U### Mstr C/D

Default: Blank Selection: 00000 = (0) to 65534 or Blank (65535)

Master User ### Card Data

Enter the remaining five decimal numbers on the back of the token/card. This is the second and third byte (bits 10 through 25) of data for a 26-bit Wiegand card. This is called the card data.

You must program

U### Mstr Site

before

programming this prompt.

U### SU1 through SU3 Site

Default: Blank Selection: 000 = (0) to 254 or Blank (255)

Sub-users one through three Site Data.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 4.0 RADXPNTS EN | 77

The NEW RECORD program contains default

4.0 RADXPNTS

4.1 Point Index

Use this programming module to construct personality types for points used in the system. The Index numbers are used in Point Assignments. Each unique point index number determines the control panel’s responses to specific conditions occurring on the Protective points.

entries and descriptions that match RPS defaults for point indexes. See the D9412G/D7412G Program Record Sheet for defaults.

Point Index

Default: 1 Selection: 1 to 31

The number of the point personality you are programming. You can define up to 31 individual personalities.

P## Type

Default: See Selection: 0 to 9

P ## Type

Description

24-hour: A 24-hour point is not turned on and off from a command center. 24-hour points are

armed all the time, and can be used for fire protection (see the

4.1.1 Point Responses), panic, medical, and police alerts.

24-hour points can be programmed as bypassable. Consider the application carefully before using the bypassable option. Bypassable 24-hour points should be programmed to Buzz on Fault.

When a 24-hour point is bypassed, send the report as it occurs. If the area contains all 24-hour points, the area is never armed or disarmed. A Deferred Bypass Report is not sent.

24-hour protection for fire doors, roof hatches, and so on. Instead of programming this type of protection as a 24-hour point, consider using a Perimeter point type with a Point Response of 9 to E. 24-hour points do not show faults when an arming function is entered, but Perimeter points do. When programming this type of protection, consider also using the Buzz on Fault and Local While Disarmed options.

Perimeter: Perimeter points are armed with all Arming functions. Points programmed as perimeter can also be armed as a group (using Perimeter-Arming functions) separately from points programmed as interior. This lets the user partially arm the system to establish Perimeter protection while occupying the interior of the protected premises.

Perimeter points can be programmed to initiate entry delay time. If the point initiates entry delay, it can also initiate an entry tone.

When a Perimeter point is programmed for entry delay, entry delay time is always provided. If the area is in entry delay when a second Perimeter point trips, the control panel compares the remaining entry delay time to the time programmed for the second Perimeter point. If the second Perimeter point’s entry delay time is less than the remaining time, it shortens the entry delay time.

Perimeter points programmed for an instant point response, generate an alarm immediately when tripped, even during entry or exit delay.

Program Record Sheet

P ## Fire Point

prompt in Section

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 4.0 RADXPNTS EN | 78

P ## Type Selection

Description

Interior: Interior points are armed only by master arming the area. They are NOT armed when

using Perimeter Arming functions. These points are typically used to monitor interior detection devices such as interior doors, motion detectors, photoelectric beams, and carpet mats.

Instant Interior Points: Interior points are usually programmed for an instant alarm (see Section

4.1.1 Point Responses). Points programmed for instant alarms generate alarms immediately, even

during entry or exit delay. Delayed Interior Points: Interior points can be programmed for a delayed point response. A

delayed response means that if the point is tripped while the area is armed, it initiates entry delay. It does not generate an alarm until entry delay expires.

When an Interior point is programmed for entry delay, entry delay time is always provided. If the area is in entry delay when the Interior point trips, the control panel compares the remaining entry delay time to the time programmed for the Interior point. If the Interior point’s entry delay time is less than the remaining time, it shortens the entry delay time.

Delayed points can also initiate an entry tone at the command center (see the prompt in Section 4.1.1 Point Responses).

In some cases, you may need to create an Interior point that causes an instant alarm only if entry delay protection is not tripped first. Use Interior Follower to create this type of protection.

Interior Follower: Interior Follower points are armed only by master arming the area. They are NOT armed when using Perimeter-Arming functions.

An Interior Follower point does not create an alarm if it trips while the area is in entry delay. An Interior Follower does not change the amount of remaining entry delay time.

If no entry delay is in effect when the Interior Follower trips, it creates an instant alarm.

You must program a delayed Point Response (4, 5, 6, 7, or 8) for an Interior Follower point. The control panel ignores the entry in

Note:

It may be necessary to increase the debounce count for Interior Follower points to prevent Interior Follower points from going into alarm before the control panel recognizes that a Perimeter Delay point was faulted. Program the Interior Follower’s debounce for one number higher than the debounce count on Perimeter delay

P## Entry Delay

for an Interior Follower point.

P## Ent Tone Off

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 4.0 RADXPNTS EN | 79

P ## Type

Description

Keyswitch Maintained: Program Point Response as 1. Do not connect initiating devices to a

Keyswitch point.

Normal:

Short:

Open:

Program Point Response as 2, the point responds as follows:

Normal:

Open:

Short:

Trouble and Restoral Reports are not sent if

Alarm and Restoral Reports are not sent if

Keyswitch Momentary: Used for area arming and disarming. programmed 1. Do not connect initiating devices to a Keyswitch point.

N→S→N:

The area is disarmed.

When this point changes from normal to open, the area arms.

A short is a trouble when the area is disarmed. A short is an alarm when the area is armed. When this point changes from shorted to normal or open, it restores.

When this point changes from open to normal, the area arms.

The area is disarmed.

A short is a trouble when the area is disarmed. A short is an alarm when the area is armed. When this point changes from shorted to normal or open, it restores.

Local While Disarmed

Local While Armed

When this point momentarily changes from normal to shorted to normal, it toggles the armed state of the area.

is Yes.

Point Response

must be

Open:

Trouble and Restoral Reports are not sent if

Keyswitch Points. Special rules apply to points used for Keyswitch functions. These special point types do not respond

the same way to the point response entry as Point Types 1, 2, and 3. Responses for keyswitch point types are described in

Section 4.1.1 Point Responses.

Open/Close Point:

Local bells are silenced through the command center.

Normal:

Open:

Short:

An open is a trouble while the point is disarmed. An open is an alarm while the point is armed.

When this point changes from open to normal, it restores.

Local Disarmed

Used for point arming and disarming.

The point is armed and sends a Point Closing Report. A Point Closing Report is not sent if Local Armed is Yes.

An open is an alarm when the point is armed. An open is a trouble when the point is disarmed. Alarm and Restoral Reports are not sent if

The point is disarmed and sends a Point Opening Report. A Point Opening Report is not sent if

Local Armed

is Yes.

Point Response

Local Disarmed

must be programmed 1.

is Yes.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 4.0 RADXPNTS EN | 80

P ## Type Selection

Description

D279 (O/C Non-Priority): The D279 provides point arming and disarming independent of the area

arm state. A non-priority D279 point arm state does not affect the area arm state.

Point Response

must be programmed 1. Local bells are silenced through the command center. For bell control at the D279, use P## Type 8.

Cut the W1 jumper on the D279 to send Point Opening and Point Closing Reports. If the D279’s W1 jumper is not cut, no Open or Close Report is sent, regardless of control panel programming.

Normal:

Open:

The point is armed and sends a Point Closing Report. Point Closing Report is not sent if

Local Armed

is Yes.

The point is disarmed and sends a Point Opening Report. A Point Opening Report is not sent if Local Armed is Yes.

Short:

A short is an alarm when the point is armed. A short is a trouble when the point is disarmed. Alarm and Restoral Reports are not sent if

Local Disarmed

is Yes.

D279 (O/C Priority): The D279 provides point arming and disarming independent of the area arm state. A priority D279 point must be armed before an area can be armed. Program

Point Response

as 2.

Cut the W1 jumper on the D279 to send area Opening and Closing Reports as programmed in Area Parameters and to provide bell control. If the D279’s W1 jumper is NOT cut then no Area Open or Area Close Report is sent, and alarm bells can only be silenced from a command center, no matter how the control panel is programmed.

Normal:

When this point changes from open to normal, the area arms.

Open:

The area is disarmed. The alarm bell silences if an alarm occurred while the area was armed.

Short:

A short is a trouble while the area is disarmed. A short is an alarm while the area is armed. When this point changes from shorted to normal or open, it restores.

Easikey: This point is programmed for access. Program

Point Response

as 1. If the system is Master Armed or Perimeter Armed (with or without delays), presenting a valid token to the Easikey reader shorts the point and disarms its assigned area. Presenting a valid token in a Disarmed state does not clear trouble or alarm memory or rearm the area.

Keyswitch Points. Special rules apply to points used for Keyswitch functions. These special point types do not respond

the same way to the point response entry as Point Types 1, 2, and 3. Responses for keyswitch point types are described in Section 4.1.1 Point Responses.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 4.0 RADXPNTS EN | 81

4.1.1 Point Responses

Applications for Point Responses 9, D, and E:

Combine Point Responses 9, D, and E with Perimeter point types to create more flexible 24-hour protection. Unlike 24-hour points, a faulted Perimeter point with a Point Response of D and E displays at the command center when arming. Like a 24hour point, a point programmed this way can generate alarms whether the area is armed or disarmed.

Combining Point Response 9 with the Local While Disarmed feature provides off-site reporting when the area is armed, but only local alarm annunciation when the area is disarmed.

Combining Point Response 9 with the Local While Armed feature provides off-site reporting when the area is disarmed, but only local alarm annunciation when the area is armed.

Point Response E: Use this for Zonex/Asic motion detectors. The control panel can report troubles while Master Armed.

Point Response F: Does not sound at local command centers but activates RlyResp Type 1 and command center faults. To annunciate the off-normal state at a command center, program Disp as Dvc as Yes and/or BuzzOn Fault as 1 or 2. This point response does not generate alarms or activate an alarm relay.

Point Response 8, 9, A, B, and C provide supervisory (24-hour) reporting.

Characteristics of a Fire Point:

Reporting: When a group of events occur,

the control panel routes and prints out Fire Reports first.

Visual Annunciation: Fire troubles continue to scroll until the trouble is cleared. Once acknowledged, FIRE TROUBLE scrolls to let the end user know that a Fire point, or group of Fire points, is still in trouble. PanelWide Relays, Summary Fire, and Summary Fire Tbl activate if a relay is assigned when any Fire point goes into alarm or is in trouble.

Audible Annunciation: A Fire point activates the A# Fire Bell relay programmed in Relay Parameters. The amount of time and pattern of the relay activation is programmed by area in Bell

Parameters, A# Fire Time, and A# Fire Pat.

Supervisory: A Fire point can send a Fire Supervisory Report and activate the

Summary Fire, Sup and Summary Fire Tbl, Panel-Wide Relays with a P## Response of 8-9-A-B-C.

Alarm Verification: A Fire point can delay an alarm by the time programmed in A# Verify Time in the Area Parameters. Combined with A# Resettable, a Fire point also resets the electrical circuit for the verify time amount.

Reset Sensor: A fire device that requires resetting can be manually reset using the reset sensor relay for the area it is assigned to.

Bosch Security Systems | 1/04 | 47775E

Fire Walk: Use the Fire Walk function to test Fire points in the system.

To provide an audible tone for a restored Fire Supervisory point, use P## RlyResp Type 1 and connect to a graphic annunciator.

D9412G/D7412G | Program Entry Guide | 4.0 RADXPNTS EN | 82

P## Pt Response

Default: See

Program Record Sheet

Selection: 0 to F

Controlled (Non-24-Hour Points)

Point Response 0123456789ABCDEF

Armed Open

Armed Short

Disarmed Open

Disarmed Short

IIIIDDIIDIIIIIT IIIIIIDDDIIIIII

TT TIITIT

TT T ITI I

24-Hour Points

Point Response 0123456789ABCDEF

Open ITIT ITSTS S

Short I I T T I T T S S S

Key: I = Instant alarm

D = Delayed alarm

T = Trouble

S = Supervisory

Blank = Audible/visual response

Example of Controlled point:

Point Type = 1

Point Response = 8

Perimeter point with delayed alarm response when armed (opened or shorted) and no response when disarmed.

Example of 24-hour point:

Point Type = 0

Point Response = 8

24-hour point with supervisory response when open and a trouble response when shorted.

0101 0101 0101

When programming the point response for Inovonics Wireless Transmitters, regardless of how the transmitter is programmed, the D8125INV Wireless Interface always sends the off-normal state to the control panel as a short and a tamper condition as an open. As a result, typical point responses for the Inovonics transmitters would include 0, 1, 6, 7, and E for Controlled points, and 0 and 1 for 24-hour Burg points. When programming a transmitter as a Fire point, a Point Response of 1 is recommended.

Note:

Wireless transmitters are NOT UL Listed with the D9412G/D7412G in fire or burglary applications. At present, Inovonics Wireless Transmitters, when used with the D8125INV Wireless Interface on a 9000 Series Control Panel, are not UL Listed for use with fire or burglary applications.

Bosch Security Systems | 1/04 | 47775E

With Supervisory Pt Response (S = Supervisory), the BFSK format does not transmit fire supervisory or Non-fire Supervisory Events. Modem format must be used with Supervisory Point Responses.

D9412G/D7412G | Program Entry Guide | 4.0 RADXPNTS EN | 83

P## Entry Delay

Default: See Selection: 5 seconds to 600 seconds

Use this option to enter the amount of entry delay time that a user has after faulting a Controlled point

P## Type 1, 2, 3

( (

P## Pt Response

displays for the duration of the time programmed when the point is faulted in the delay condition.

0101 0101 0101

Beginning with firmware revision 6.30 and higher, the D1255 alternates between DISARM NOW and the point text of the point that caused the area to go into entry delay.

If this time expires before disarming, or if the point is faulted to an instant response (I), an alarm occurs.

0101 0101 0101

Make entries in 5 second increments. The programmer does not allow off-increment entries.

If another Perimeter or Interior Follower Delay point trips while the area is already in entry delay, the control panel adjusts the delay time to the Delay point with the least amount of delay time.

Use P## Type 3 Interior Follower to program points that do not go into instant alarm the user must fault in order to get to the command center and disarm during the entry or exit delay period.

Program Record Sheet

) with a delayed response (D)

) of 4, 5, 6, 7, or 8. DISARM NOW

P## Ent Tone Off

Default: No Selection: Yes or No

Yes Disable entry delay tone when this

point is faulted to the delay response.

No A tone sounds at command centers

when this point initiates entry delay.

This option enables/disables the entry delay warning tone for this point.

Do not set points to No if they are actually used to notify the user to disarm the system. The possibility of false alarms increases if the entry delay warning is not used.

0101 0101 0101

Entry Tone can also be turned off when programming your CC Entry Tone, in Section 2.10 Command Center, which allows you to manage the tone by command center.

You may want to disable the entry tone in high security applications where you do not want to annunciate entry delay.

P## Silent Bell

Default: No Selection: Yes or No

Yes Activate the Silent Alarm relay when

this point goes into alarm. Command centers do not sound the alarm tone for Non-fire points.

No Activate either the Fire Bell relay or

Alarm Bell relay and sound the alarm tone at command centers when this point goes into alarm. If this is a Fire point, it activates the Fire Bell relay programmed in Relay Parameters. Otherwise, it activates the Alarm Bell relay. The amount of time and pattern of the relay activation is programmed by area in Bell Parameters.

If you want this point to eventually ring the bell because the message failed to reach the central station receiver, program P##

Audible After 2 Failures as Yes.

P## Ring Til Rst

Default: No Selection: Yes or No

Yes

No The relay programmed to provide fire

Use this option to determine if the bell continues to ring until the Fire Bell time expires. The point returns to a normal condition when the user acknowledges the alarm to silence the bell.

The relay programmed to provide fire alarm output for this point cannot be de-activated until the point restores to normal.

alarm output for this point can be deactivated before the point restores to normal.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 4.0 RADXPNTS EN | 84

If the point restores and the fire alarm is not silenced from the command center, the fire alarm output continues until Fire Bell time expires. If the point does not restore, the fire alarm output continues even after bell time expires.

Use this option for fire applications to meet the requirement that audible alarms cannot be silenced until the fault condition clears or the Fire Bell time expires.

P## Audible After 2 Failures

Default: No Selection: Yes or No

Yes

Use this option for reporting Non-fire points programmed as alarm bell to ring if the control panel fails to report the Alarm Event at the end of two failed attempts to the remote central station receiver.

0101 0101 0101

A# Burg Alarm relay activates after two failed attempts.

P## Silent points do not cause the A# Burg Alarm relay to activate even if the report does not get to the central station receiver.

P## Silent

to eventually cause the

When a point that is programmed for P## Silent Bell is faulted, the timer for the A#

Burg Time starts, even though the bell is not yet ringing. It can take up to 3 minutes before the second attempt fails. Ensure A# Burg Time is programmed to provide the amount of bell time you need, minus the 3 minutes it can take before the bell actually begins to ring.

0101 0101 0101

To prevent the command center alarm tone and the A# Burg Alarm bell from sounding, this point needs P## Silence Bell programmed as Yes.

ALARM SILENCED displays at the command center if this Invisible point causes a bell to ring upon an alarm and a valid passcode is entered.

P## Invisible Pt

Default: See Selection: Yes or No

Yes

No Activity from this point is visible at the

Use this option to determine whether the point appears in the command center display upon an Alarm condition. For LED command centers, the LED does not illuminate upon an alarm condition. Point text appears and annunciation is made for Invisible points programmed for a trouble condition in point response.

Bosch Security Systems | 1/04 | 47775E

Program Record Sheet

Command centers do not display alarm activity from this point.

command centers.

D9412G/D7412G | Program Entry Guide | 4.0 RADXPNTS EN | 85

P## Buzz On Fault

Default: Blank Selection: Blank, 1 to 3

Selection Operation for Controlled Points

(Point Types 1, 2, and 3)

Blank

1 The point generates a Buzz Until Restore at the

The point only generates a buzz at the command center if it goes into the trouble condition indicated in the P## Point Response.

command center for any fault condition while the point is disarmed. The buzz continues until the point restores and the user acknowledges the condition using a passcode or COMMAND 4. The point must be normal before the user can silence the buzz.

The point generates a buzz at the command center for any fault condition when the point is disarmed. The point does not need to be normal before the user can silence the buzz.

The point generates a buzz at the command center for any fault condition when the area is disarmed. The user cannot silence this buzz, but it silences automatically when the point is restored. If the fault condition results in a trouble response, the command center continues to buzz even after the user acknowledges the condition if the fault is still present.

Operation for 24-hour Points (Point Type 0)

Same

The point generates a Buzz Until Restore at the command center for any fault condition regardless of the armed state. The buzz continues until the point restores and the user acknowledges the condition using a passcode or COMMAND 4. The point must be normal before the user can silence the buzz.

The point generates a buzz at the command center for any fault condition regardless of the armed state. The point does not need to be normal before the user can silence the buzz.

The point generates a buzz at the command center for any fault condition regardless of the armed state. The user cannot silence this buzz, but it silences automatically when the point is restored. If the fault condition results in a trouble response, the command center continues to buzz even after the user acknowledges the condition if the fault is still present.

The buzz does not automatically stop once the point is restored when using Option 1 or

2. The user must acknowledge the buzz prior to the buzz stopping. However, when using Option 3, the buzz automatically stops when the point restores to normal without user intervention.

Points bypassed (by the user, Sked, Swinger Bypass, or RAM) do not generate a Buzz On Fault condition at the command center.

P## Watch Point

Default: See Selection: Yes or No

Yes

No Do not activate Watch Mode responses

Use this option to allow a Controlled point to generate a watch tone as long as the area is disarmed and not being faulted into a trouble or alarm condition.

Program Record Sheet

This point activates Watch Mode responses if it is faulted while the control panel is in Watch Mode.

for this point.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 4.0 RADXPNTS EN | 86

P## RlyResp Type

Default: See Selection: Blank, 1 to 2

Blank Point state does not affect the operation

Use this option to cause a relay (1 to 127 for D9412G; 1 to 64 for D7412G) to respond when a corresponding point with the same number (1 to

127) is faulted. [This requires connecting D8129 OctoRelays to Zonex Bus 1 and/or Zonex Bus 2 (D9412G only). See address settings on the back of the D9412G/D7412G Program Record Sheet (P/N:

47488)].

Point 128 is reserved for other use than an actual point. Only the first 127 points can have an associated relay. Relays are not available for Points 129 to 247.

Do not use the Chg Relays? function to toggle relays reserved for special functions. Special function relays are Area and Panel Wide Relay functions as well as relays assigned to CC Entr Key Rly and P## RlyResp Type.

Program Record Sheet

of the corresponding relay.

Relay Follow Point: The relay corresponding with this point activates when the point is faulted to any off normal condition. The relay automatically resets when the point is returned to normal.

Relay Latches: The relay corresponding with this point latches when the point goes into an alarm condition. This relay provides a steady output until the alarm is acknowledged by a valid passcode then cleared from alarm memory with an acknowledgment at the command center.

P## Disp as Dvc

Default: No Selection: Yes or No

Yes

Display CHECK DEVICE when this point is off normal.

Do not display CHECK DEVICE when this point is off normal.

Use this option to cause the command center to display CHECK DEVICE once a point is off normal or was acknowledged after going into alarm.

Use this function for devices with a dry contact output which faults a point once the device is in a trouble condition.

P## Local While Disarmed

Default: See Selection: Yes or No

Yes

No Report events occurring from this

* Restoral Reports are still transmitted if the alarm,

trouble, or bypass (by Sked, RAM, or Swinger bypass) condition occurred when the area disarmed, and the point restored.

Use this option to allow a Controlled point (

Type 1, 2, 3

Restoral Reports only when the area is armed. This prompt does not affect local annunciation.

Local While Disarmed suppresses all reports from 24-hour points. Do not use P## Type 0 for this prompt. Remember that this only works for Disarmed points, and a Type 0 is a 24-hour Always Armed point. Instead, choose any type other than 0, and use a point response that reports an alarm whether the point is armed or not. For instance, P## Type 1 and P## Response 9 reports an alarm on an open or a short (I) whether the area is armed or not.

Local While Disarmed affects Keyswitch points. This prompt suppresses keyswitch (troubles/restorals) and D279 (alarms/troubles/restorals). Do not use this parameter for these applications.

Program Record Sheet

Suppress Alarm, Trouble and Restoral* Reports from this point while the area it is assigned to is disarmed.

point while the area is disarmed.

P##

), to report Alarms, Troubles, and

P## Local While Armed

Default: No Selection: Yes or No

Yes

Suppress Alarm, Trouble and Restoral* Reports from this point while the area it is assigned to is armed.

Report events occurring from this point while the area is armed.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 4.0 RADXPNTS EN | 87

* Restoral Reports are still transmitted if the alarm,

trouble, or bypass (by Sked, RAM, or Swinger bypass) condition occurred when the area disarmed, and the point restored.

Allows a controlled point (P## Type 1, 2, 3), to report Alarms, Troubles, and Restoral Reports only when the area is disarmed. This prompt does not affect local annunciation.

Local While Armed suppresses all reports from 24-hour points. Do not use P## Type 0 for this prompt. This only works for disarmed points. Type 0 is a 24-hour always armed point. Choose any Type other than 0, and use a point response that reports an alarm whether the point is armed or not. For instance, P## Type 1 and P## Response 9 reports an alarm on a trouble or a short whether the area is disarmed or not.

Local While Armed affects Keyswitch Points. This prompt suppresses keyswitch (alarms/troubles/restorals) and D279 (opening/closing/troubles/restorals). Do not use this parameter for controlled points that arm/disarm.

P## Disable Rst

Default: No Selection: Yes or No

Yes Enable Restoral Reports form this

point.

* Restoral Reports are still transmitted if the alarm,

trouble, or bypass (by sked, RAM, or Swinger bypass) condition occurred when the area disarmed, and the point restored.

Use this option to disable any Restoral Reports from this point after it returns to normal from an alarm or trouble condition.

Disable Restoral Reports from this point.

P## FA Retrnable

Default: No Selection: Yes or No

Yes This point automatically returns to the

system when it restores to normal.

This point stays out of the system until the area is disarmed.

Use this option to allow points that were force armed out of the area to return back to the armed state once they become normal again without having to disarm the system.

Use on loading dock doors, which must be left open until loading is completed. Once the loading dock door is closed, the point detects any subsequent opening and reports an alarm.

P## BP Retrnable

Default: No Selection: Yes or No

Yes

No This point stays out of the system

Use this option to return a point that was bypassed, force armed, or swinger bypassed back into the system once the area this point is assigned to is disarmed.

This point automatically returns to the system when the area is disarmed.

through arming and disarming cycles.

Turn this item to No for Interlock points.

When the point cannot return to the system through disarming, the point must be manually unbypassed using the Unbypass?, command center function, Sked Functions 4 and 5 or remotely unbypassed using RAM.

Bosch Security Systems | 1/04 | 47775E

0101 0101 0101

For Force Armed points to remain bypassed, ensure P## FA Retrnable is No.

D9412G/D7412G | Program Entry Guide | 4.0 RADXPNTS EN | 88

P## Bypassable

Default: No Selection: Yes or No

Yes This point can be bypassed and force

armed.

Use this option to allow this point to be bypassed and/or force armed.

Bypassing a 24-hour point: When a 24-hour point or 24-hour Supervisory point is bypassed, 24 HOUR BYPASS continuously scrolls at the command center. 24 HOUR BYPASS scrolls to indicate a 24hour Non-fire point, BYPASS scrolls to indicate a 24-hour Fire point or a Fire Supervisory point is bypassed.

This point cannot be bypassed or force armed from the command center or RAM. However, it can be force armed by automatic arming at the end of the Closing Window (see the

prompt in Section 2.9.5

A# Auto

Open/Close Options) or by a Sked programmed to arm the area.

P## Fire No

is bypassed. FIRE

Alternative to a 24-hour Point: For alarm capability of a 24-hour point without the continuous scrolling, use a Perimeter point with a Point Response of 9 to E.

P## Swinger Byps

Default: No Selection: Yes or No

Yes Enable Swinger Bypass for this point.

No Disable Swinger Bypass for this point.

Use this option to allow the control panel to automatically bypass a point that erroneously reports four Alarm or Trouble Events within an hour of the first event.

The control panel reports a Swinger Bypass P### upon the fourth report. If the point has a partial count (less than four events during an hour), the count is reset to zero and three more events are required upon the next report before the control panel initiates the bypass.

0101 0101 0101

P## Bypassable does not need to be programmed Yes for swinger bypass to work.

A Swinger Shunted point returns to the system if P## BP Returnable? is Yes. If not, return the point to the system as described in the application note for P##

BP Returnable.

P## Report Bypass at Occurrence

0101 0101 0101

A point can be bypassed at the command center using the BYPASS? function, which reports as a Command Bypass. When bypassed by Sked Function 3, the report is Sked Bypass. When bypassed by RAM a RAM Bypass reports after RAM disconnects. When swinger shunted, a Swinger Shunt is reported. If the point is not bypassable, it cannot be bypassed in any of the above cases.

Programming Bypassable as Yes for Cross points may cause missed CrossPoint alarms. For example, if Points 1 and 2 were programmed as Cross points and Point 1 was Bypassed or Force Armed, Point 2 cannot generate an Alarm Cross Point Event. Point 2 may, however, generate an Unverified or Alarm Event depending on how the point was tripped. Be careful when using this feature with Cross point applications.

Default: No Selection: Yes or No

Yes

Send a Command Bypass Report at the time the point is bypassed.

No Do not send a Command Bypass

Report at the time the point is bypassed.

This option allows a point to generate a Command Bypass Report as soon as a user bypasses the point from the command center. This option should be enabled for all Bypassable 24-hour points. You may also elect to report a bypassed point at the time the area is armed. See

P## Defer BP Report

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 4.0 RADXPNTS EN | 89

P## Defer BP Report

Default: No Selection: Yes or No

Yes Send a Point Bypass Report with the

Closing Report instead of a Command Bypass Report when a user bypasses the point.

No Do not defer Bypass Reports.

Use this option to prevent ( that are bypassed by the user (COMMAND BYPASS) from occurring until the area is armed. Once the area is armed, the bypassed points and any point being bypassed during the arming sequence report as POINT BYPASS along with the Closing Report.

0101 0101 0101

Bypass Reports do not occur when arming the area if the Closing Report is suppressed by O/C Windows or are not reported.

Bypass Reports for 24-hour points do not report If P## Report Bypass at

Occurrence and P## Defer Bypass Report are both No.

P## Type 0 to F

) points

The Cross point feature is available only on points programmed as having an Instant point response. Also, Controlled points (Point Types 1, 2 and 3) do not follow the Cross point operation (described as follows) during entry or exit delay.

The Cross point option is designed to reduce false alarms. To achieve this, points can be programmed so the control panel must see an alarm condition within a programmed period of time (called Cross Point Time) from at least two points within a Cross Point Group before Cross Point Alarm Events are generated. These points need the Cross point option enabled in their corresponding point indexes to be able to generate this event. See Section 6.8 Cross Point Parameters for additional programming requirements to program the Cross Point Timer.

Cross Point Groups were established in the D9412G and D7412G to support the Cross Point function. There are 31 Cross Point Groups in the D9412G and ten in the D7412G. Each Cross Point Group consists of eight points and is identified by the point numbers in them (such as, Cross Points 1 to 8, Cross Points 9 to 16, and so on).

The Cross point function only applies to Alarm conditions. It does not apply to Trouble or Supervisory conditions.

To report the bypass at occurrence and when the area is armed, program P##

Report Bypass at Occurrence and P## Defer Bypass Report as Yes. A

Command Bypass Report is sent as soon as it occurs and a Point Bypass Report is sent with the Closing Report.

P## Cross Point

Default: No Selection: Yes or No

Yes This point is a Cross point.

No This point is not a Cross point.

The Cross point function is available only in Firmware revisions 6.30 and higher.

Do not use Cross points for Fire points.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 4.0 RADXPNTS EN | 90

P## Fire Point

Default: No Selection: Yes or No

Yes This point is a Fire point.

No This point is not a Fire point.

Use this option to make a 24-hour point a Fire point. This option makes this point the highest priority event in the control panel when an alarm occurs for both reporting and displaying on the command center.

Characteristics of a Fire Point

Reporting: When a group of events

occur, the control panel routes and prints out Fire Reports first.

Visual Annunciation: FIRE TROUBLES continues to scroll until the trouble is cleared. Once acknowledged, a FIRE TROUBLE scroll lets the end user know that a Fire point, or group of Fire points, is still in trouble. Panel Wide Relays, Summary Fire, and Summary Fire Tbl activates if a relay is assigned when any Fire point goes into alarm or is in trouble.

Audible Annunciation: A Fire point activates the A# Fire Bell relay programmed in Relay Parameters. The amount of time and pattern of the relay activation is programmed by area in Bell

Parameters, A# Fire Time, and A# Fire Pat.

Supervisory: A Fire point can send a Fire Supervisory Report and activate the

Summary Fire Sup and Summary Fire Tbl Panel Wide Relays with a P## Response of 8-9-A-B-C.

Alarm Verification: A Fire point can delay an alarm by the time programmed in A# Verify Time in the Area parameters.

Reset Sensor: A fire device that requires resetting can be manually reset using the reset sensor relay for the area where it is assigned.

Fire Walk: Fire points can be tested in the system using the Fire Walk Test which automatically resets each point for five seconds when it is tripped and rings the Fire Bell for two seconds.

You should dedicate a fire annunciation device to all your Fire points if they are assigned to a single area in a multiple area system. Special red command centers and annunciators with specific keys for fire systems are designed for this type of application (D1256 and D1257).

Do not use the Cross point function for Fire points.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 4.0 RADXPNTS EN | 91

P## Alarm Verify

Default: See Selection: Yes or No

Yes Enable alarm verification on this point.

Use this option only with Fire points to designate them for alarm verification.

When an Alarm Verification point goes into alarm, the control panel removes power to all Resettable points for the duration programmed in

in Section 2.9 Area Parameters. If the point (or

Time

another Resettable point in the area) is still in alarm, or goes back into alarm within 60 seconds after the initial verification time reset, an alarm is generated.

During a Fire Walk Test the reset time is 5 seconds. The time programmed in A# Verify Time is ignored. Use the Cross point function for Fire points.

Program Record Sheet

Alarm verification points must be programmed as resettable.

Disable alarm verification on this point.

A# Verify

P## Resettable

Default: See Selection: Yes or No

Yes This point is reset by the Reset Sensor?

No This point is not resettable.

Use this option if this is a Powered point that requires interruption of power to reset a latched alarm condition. The Resettable point option is typically used with smoke detectors and glass break detectors.

When initiated (either through a Fire Walk Test or the command center’s Reset Sensor? Function) or when the RAM interrupts power to the device for 5 seconds, Sensor Reset is reported to the central station receiver.

Program Record Sheet

function and during the alarm verification sequence.

When a sensor reset is initiated, the control panel does not accept alarms from any points with P## Resettable programmed as Yes. During the 5-second reset time, alarms from these points are ignored.

Do not mix fire and intrusion devices on the same powered loop.

4.2 Point Assignments

These entries assign point indexes to Points 1 to 127, 129 to 247 for the D9412G and Points 1 to 75 for the D7412G, and assigns the points to the areas. Also included in this section are parameters used to set the point’s debounce count, BFSK/Relay (for use when transmitting in BFSK or assigning relays to follow alarms for a group of points), and custom command center and report text for each point.

Point Number

Default: 1 Selection: 1 to 127, 129 to 247

Enter the point number you are programming. When transmitting in Modem IIIa point number is reported to the D6500/D6600. When transmitting in BFSK, you must assign a zone number in BFSK/Relay.

0101 0101 0101

Point numbers 128 and 248 are reserved for Zonex bus 1 and 2 supervision.

, the three-digit

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 4.0 RADXPNTS EN | 92

P### Point Index

Default: See Selection: Blank (00) to 31

This entry selects one of the 31 that define the point’s characteristics and determines how the control panel responds to various point conditions.

Blank (00) disables the point.

Missing Point Reports occur if a point address does not exist for a point assigned a point index. Extra Point Events occur if more than two devices have the same address.

When a POPIT is missing, the control panel generates the following responses based on the point type:

• Fire points generate missing trouble

• Non-fire 24-hour points generate

• Non-fire, non 24-hour points generate

POPIT modules monitor their sensor loops for three conditions: loop normal, loop open, and loop shorted. They report these three conditions to the control panel. The control panel uses point programming to interpret the sensor loop information reported by the POPITs and to make the appropriate system response.

Program Record Sheet

P## Index

codes

responses.

missing alarm responses.

missing alarm responses while armed, and trouble responses while disarmed. Exception: Non-fire, non-24-hour points with a point response of 9 to D generate a missing alarm response while disarmed.

P### Debounce

Default: 2 Selection: 1 to 15

1 .300 seconds

2 .600 seconds

3 .900 seconds

4 1.2 seconds

5 1.5 seconds

6 1.8 seconds

7 2.1 seconds

8 2.4 seconds

9 2.7 seconds

10 3.0 seconds

11 3.3 seconds

12 3.6 seconds

13 3.9 seconds

14 4.2 seconds

15 4.5 seconds

The debounce count is the number of times the control panel scans a point before initiating an alarm. Scan cycles are 300 ms.

For appropriate settings consult the manufacturer’s instructions for the device connected to this point.

0101 0101 0101

Bosch Security Systems recommends an entry of two or higher. Interior Follower points need a debounce of at least three.

Door points assigned to D9210B modules need a debounce of at least four.

P### Area Assign

Default: 1 Selection: 1 to 8

The areas are numbered 1 to 8. Select the area number to which the point is assigned.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 4.0 RADXPNTS EN | 93

P### BFSK/Relay

Default: See Selection: 0 to 9

Use this option to:

2. Determine the point number reported in BFSK

when this point is tripped.

3. Activate a relay when the point goes into an

alarm condition, even if the control panel is programmed for Modem reporting as shown in Table 29.

BFSK/Relays do not activate for Fire Supervisory or Non-Fire Supervisory points.

Table 29: P### BFSK/Relay Codes/Relays

BFSK Code

1 73 9 27410 3 75 11 47612 5 77 13 67814 7 79 15 88016

* Address setting = 1 (on), 2 (off), 3 (on), 4 (on)

Local annunciation on the command centers and Local Printer reporting and the View Log display the actual point number (1 to 247), not the BFSK report code

Program Record Sheet

Trips Relay

D8129 on Zonex

Bus 2 for D9412G*

D8129 on Zonex

Bus 2 for D7412G*

Two relays can activate when this point goes into alarm if the P## Rly Resp Type for this point is programmed.

Use these codes to activate relays on the D8129 OctoRelay (or C8137 Transmitter Interface). You can assign the same code to several points providing a summary zone alarm output. When the point goes into alarm, the relay activates. When the alarm is acknowledged and is no longer scrolling in the command center display, the relay resets.

P### Point Text

Default: See Selection: Up to sixteen alphanumeric

Enter alphabetic characters (A to Z) in capital letters.

Enter up to sixteen characters of text to describe the point. This point text is displayed at command centers, if the point is programmed as visible, and reported to the D6500/D6600 when transmitting in Radionics Modem IIIa point).

Include the point number in custom point text. This helps the user when viewing events, initiating bypasses, and so on. It can also simplify troubleshooting.

When a D1260 Command Center is installed on the system, the point text for Points 240 to 247 can be used for Area Name Text for Areas 1 to 8, respectively. See Table 30:

Table 30: Point Text for Points 240 to 247

Program Record Sheet

characters

format (if it is a reporting

0101 0101 0101

Do not assign a BFSK/Relay to Invisible points. To avoid triggering a BFSK/Relay, program this prompt as 0.

On the D9412G, do not use relays 73 through 80 for Area or Panel-Wide Relay functions when using BFSK relays. Doing so prevents the BFSK relays from triggering.

On the D7412G, do not use relays 9 through 16 for Area or Panel Wide Relay functions when using BFSK relays. Doing so prevents BFSK relays from triggering.

Bosch Security Systems | 1/04 | 47775E

Point Text Corresponding Area Name Text

Point 240 Area 1 Point 241 Area 2 Point 242 Area 3 Point 243 Area 4 Point 244 Area 5 Point 245 Area 6 Point 246 Area 7 Point 247 Area 8

D9412G/D7412G | Program Entry Guide | 4.0 RADXPNTS EN | 94

4.3 COMMAND 7 and COMMAND 9

These entries assign point indexes, BFSK report code, BFSK relay that trips, and the text for the COMMAND 7 and COMMAND 9 command center functions.

CMD7 Point Index

Default: 31 Selection: Blank (00) to 31

This entry selects one of the 31 that define how the control panel reacts when a COMMAND 7 is initiated.

0101 0101 0101

The point index code used for COMMAND 7 must not be used for any other points on the system.

If the point index for COMMAND 7 has Fire points programmed Yes, this causes access control doors to unlock if Fire Unlock is also programmed Yes (see the D9210B Program Entry Guide).

CMD7 BFSK/Relay

Default: 1 Selection: 0 to 9

Selects one of the digits shown for reporting in BFSK or for activating relays 73 to 80 (on the D9412G) or relays 9 to 16 (for the D7412G) when COMMAND 7 is initiated (see the Section 4.2 Point Assignments).

P### BFSK/Relay

P## Index

prompt in

codes

CMD9 Point Index

Default: 31 Selection: Blank (00) to 31

This entry selects one of the 31

P## Index

codes that define how the control panel reacts when a COMMAND 9 is initiated.

0101 0101 0101

The point index code used for COMMAND 9 must not be used for any other points on the system.

If the point index for COMMAND 9 has Fire points programmed as Yes, this causes access control doors to unlock if Fire Unlock is also programmed Yes (see the D9210B Program Entry Guide).

CMD9 BFSK/Relay

Default: 1 Selection: 0 to 9

This entry selects one of the digits shown for reporting in BFSK or for activating relays 73 to 80 (on the D9412G) or relays 9 to 16 (for the D7412G) when a COMMAND 9 is initiated (see the

BFSK/Relay

prompt in Section 4.2 Point Assignments).

P###

COMMAND 9 does not activate the Summary Fire Alarm relay.

CMD9 Point Text

COMMAND 7 does not activate the Summary Fire Alarm relay.

CMD7 Point Text

Default: [COMMAND][7] Selection: Up to sixteen alphanumeric

characters

Enter alphabetic characters A to Z in capital letters

Enter up to sixteen characters of text to describe the point. This point text is displayed at command centers (if the point is programmed as visible) and reported to the D6500/D6600 when transmitting in Radionics’ Modem IIIa point).

Bosch Security Systems | 1/04 | 47775E

format (if it is a reporting

Default: [COMMAND][9] Selection:

Up to sixteen alphanumeric characters

Enter alphabetic characters (A to Z) in capital letters

format (if it is a reporting

point).

D9412G/D7412G | Program Entry Guide | 5.0 RADXSKED EN | 95

5.0 RADXSKED

5.1 Windows

Use this programming module to define the windows for Opening and Closing and User Access.

5.1.1 Opening and Closing

Use these windows to set a schedule for disarming and arming. The disarming and arming schedules provide several independent features:

• Suppress normal Opening and/or Closing

Reports when programmed Yes.

• Generate a Fail to Open Report if the area is not

disarmed on schedule when is programmed Yes.

• Provide a warning tone and a PLEASE CLOSE

NOW display at the command center when it is

time to arm the area.

• Generate a Fail to Close Report if the area is not

armed on schedule when programmed Yes.

• Automatically arm the area at the end of the

Closing Window when programmed Yes.

Opening and closing schedules can be set up independently. For example, if you only want to use features provided by Closing Windows, leave times blank in the Opening Windows prompts and program Closing Window times.

A worksheet is provided at the end of this section for your convenience. Following the worksheet are examples of how to program Opening and Closing Windows for particular applications (see Table 35 through Table 39.

About the Program Record Sheet: A column labeled Sked # is found on the Program Record Sheet provided with the control panel. These numbers appear in D6500/D6600 reports and local printer reports when the window Begin Time executes.

Window selections 1 through 8 correspond with odd numbered Skeds 41 through 55 for Open Window and correspond with even numbered Skeds 42 through 56 for Close Window. For example, when the Opening Window for Window 1 executes, a Sked 41 Executed Event is generated. See Table 31.

A# Disable O/C in Windows

A# Fail To Open

A# Fail To Close

A# Auto Close

Table 31: Window Selections

Selection Sked # Window Sked # Windo

1 41 Open 42 Close 243Open44Close 3 45 Open 46 Close 447Open48Close 5 49 Open 50 Close 651Open52Close 7 53 Open 54 Close 855Open56Close

Window

Default: 1 Selection: 1 to 8

Enter the window number you want to program.

W# Sunday

Default: No Selection: Yes or No

Yes Activate this window on Sundays.

No Do not activate this window on

Sundays.

This prompt, and the next six day of the week prompts, select the days of the week the Opening and/or Closing Windows are active.

Exceptions:

To prevent the windows from activating on certain days of the year, program enable at least one Holiday Index. When

Holiday

the week programmed unless the Holiday Index designates the date as a holiday.

If Opening and/or Closing Windows are only needed on certain days of the year, do not program the windows to execute on any days of the week. Instead, program Holiday Index with the days of the year you want the window to be active.

is Yes, the window executes on the days of

Xept Holiday

No and select a

Yes, and

Xept

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 5.0 RADXSKED EN | 96

W# Monday

Default: No Selection: Yes or No

W# Tuesday

Default: No Selection: Yes or No

W# Wednesday

Default: No Selection: Yes or No

W# Thursday

Default: No Selection: Yes or No

W# Friday

Default: No Selection: Yes or No

W# Saturday

Default: No Selection: Yes or No

W# Open Early Begin

Default: 00:00 Selection: HH:MM (hours and minutes)

00:00 to 23:59

Open Early Begin: This program item is one of

three required to create an Opening Window. To finish programming an Opening Window, Open Window Start and Open Window Stop must be programmed.

Use Open Early Begin to set the time the control panel looks for an Opening Window. When Opening and Closing Reports are enabled, disarming the area between midnight and the Open Early Begin time generates an Opening Report. In addition:

• If Disable O/C in Window is Yes: Disarming

the area between the Open Early Begin and the Open Window Start time generates an Early to Open Event (if the Open Early Begin time is the same as the Open Window Start time, the Early to Open Event is not sent). Disarming the area between the Open Window

Start and Open Window Stop time creates a local event in the Panel log but does not send the Opening Report to the central station.

Disarming the area after the Open Window Stop and the next window’s Open Early Begin time (or midnight, whichever comes sooner) generates a Late to Open Event.

• If Disable O/C in Window is Yes: Disarming

the area generates an Opening Report without the early or late modifier, regardless of when the area is disarmed.

When you are programming multiple windows to activate on a single day, program the windows in chronological order. Be careful not to program a window’s Open Early Begin time for a time that is between any other window’s Open Window Start and Open Window Stop time.

0101 0101 0101

Disabled windows have a blank begin time. If the entry for this prompt is blank, but times are programmed for Open Window Start and Open Window Stop, the window is disabled.

To disable the window, both the hours and minutes spaces must be Blank.

00:00 is midnight, 23:59 is 11:59 PM. Make entries using a 24-hour clock (for example, 7:00 AM is entered as 07:00, 2:45 PM is entered as 14:45).

Disable/Restart the control panel to activate today’s window. If you are programming a window that must activate on the same day you are programming it, do a disable/restart after programming.

Do not program a window to cross the midnight boundary.

W# Open Window Start

Default: 00: 00 Selection: HH:MM (hours and minutes)

Enter the time you want the control panel to start the Opening Window. The window goes into effect at the beginning of the minute.

00:00 is midnight, 23:59 is 11:59 PM. Make entries using a 24-hour clock (for example, 7:00 AM is entered as 07:00, 2:45 PM is entered as 14:45).

This program item is one of three required to create an Opening Window. To program an Opening Window, Open Early Begin and Open Window Stop must also be programmed. See the

Early Begin

feature explanations.

prompt in this section for report

W# Open

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 5.0 RADXSKED EN | 97

W# Open Window Stop

Default: 00: 00 Selection: HH:MM (hours and minutes)

Enter the time you want the control panel to end the Opening Window. The window stops at the end of the minute.

00:00 is midnight, 23:59 is 11:59 PM Make entries using a 24-hour clock (for example, 7:00 AM is entered as 07:00, 2:45 PM is entered as 14:45).

This program item is one of three required to create an Opening Window. To program an Opening Window, Open Early Begin and Open Window Start must also be programmed.

If the area is not disarmed by the time the Open Window Stop time expires, the control panel generates a Fail to Open Report if enabled in Fail To Open.

Opening Reports generated between the Open Window Start time and Open Window Stop time can be suppressed by programming

Window

Yes. See the

Open Early Begin

for other report feature explanations.

Do not use a time of 23:59 as a window stop time unless another window begins on the next day at 00:00.

0101 0101 0101

Fail to Open Reports are not sent for windows that stop at 23:59.

Figure 4: Example Opening Window Timeline (using two Opening Windows on same day)

Disable O/C in

prompt

1 - Areas disarmed between midnight and 6 AM

generate Opening Reports.

2 - Areas disarmed between 6 AM and 7 AM

generate Early to Open Reports.

3 - If the area is disarmed between 7 AM and 8 AM

regular Opening Reports are generated. If Disable O/C in Window is programmed Yes the Opening Report is not transmitted to the central station.

4 - If the area is not disarmed by 8:01 AM, a Fail to

Open Event is generated if Fail to Open is programmed Yes in Opening and Closing Options.

5 - If the user disarms the area between 8:01 AM and

12:59, PM a Late to Open Event is generated.

6 - Areas that are disarmed between 1 PM and 2 PM

generate Early to Open Reports.

7 - If the area is disarmed between 2 PM and 3 PM

regular Opening Reports are generated. If Disable O/C in Window is programmed Yes, the Opening Report is not transmitted to the central station.

8 - If the area is not disarmed by 3:01 PM, a Fail to

Open Event is generated if Fail to Open is programmed Yes in Opening and Closing Options.

9 - If the user disarms the area between 3:01 PM and

11:59 PM, a Late to Open Event is generated.

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 5.0 RADXSKED EN | 98

Table 32: Programming for Two Same Day Opening Windows (see Figure 4)

W# Day of Week

1 2

S M T W T F S S M T W T F S

Open Close

Early

Begin

06: 00 07 : 00 08: 00

13 : 00 14 : 00 15 : 00

Start Stop

Early

Begin

Start Stop

eXcept

Holiday

Yes / No Yes / No

Holiday

Index Area(s)

1 2 3 4 1 2 3 4

1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8

Do not program a single window to cross the midnight boundary. The window stop time must be later than the window start time. To program a window that effectively crosses the midnight boundary, you must program two windows.

For example, to program windows for an area that opens between 11:30 PM and 12:30 AM, five days a week, use two windows as shown in Table 33.

Table 33: Programming to Link Two Days over Midnight

Open Close

Early

W# Day of Week

S M T W T F S

S M T

W T F S

Begin Start Stop

22 : 00 23 : 30 23 : 59 00 : 00 00 : 00 00 : 30

W# Close Early Begin

Default: 00: 00 Selection: HH:MM (hours and minutes)

00:00 to 23:59

Close Early Begin: This program item is one of

three required to create a Closing Window. To finish programming a Closing Window, Close Window Start and Close Window Stop must be programmed.

Use Close Early Begin to set the time that you want the control panel to look for a Closing Window. When Opening and Closing Reports are enabled, arming the area between midnight and the Close Early Begin time generates a Closing Report. In addition:

• If Disable O/C in Window is Yes: Arming the

area between the Close Early Begin time and the Close Window Start time generates a Closing Early Event (if the Close Early Begin time is the same as the Close Window Start time, the Closing Early Event is not sent).

Arming the area between the Close Window Start and Close Window Stop time creates a local event in the Panel log but does not send the Closing Report to the central station.

Early

Begin Start Stop

Arming the area after the Close Window Stop and the next window’s Close Early Begin time (or midnight, whichever comes sooner) generates a Closing Late Event.

• If Disable O/C in Window is No: Disarming

the area generates a Closing Report without the early or late modifier, regardless of when the area is armed.

When you are programming multiple windows to activate on a single day, program the windows in chronological order. Be careful not to program a window’s Close Early Begin time for a time that is between any other window’s Close Window Start and Close Window Stop time.

Disabled windows have a blank begin time. If the entry for this prompt is blank, but times are programmed for Close Window Start and Close Window Stop, the window is disabled.

To disable the window, both the hours and minutes spaces must be blank.

00:00 is midnight, 23:59 is 11:59 PM. Make entries using a 24-hour clock (for example, 7:00 AM is entered as 07:00, 2:45 PM is entered as 14:45).

eXcept

Holiday

Yes No Yes No

Holiday

Index Area(s)

1 2 3 4 1 2 3 4

1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8

Bosch Security Systems | 1/04 | 47775E

D9412G/D7412G | Program Entry Guide | 5.0 RADXSKED EN | 99

Disable/Restart the control panel to activate today’s window. If you are programming a window that needs to activate on the same day that you are programming it, do a disable/restart after programming.

W# Close Window Start

Default: 00: 00 Selection: HH:MM (hours and minutes)

Enter the time that you want the control panel to start the Closing Window. The window goes into effect at the beginning of the minute.

00:00 is midnight, 23:59 is 11:59 PM. Make entries using a 24-hour clock (for example, 7:00 AM is entered as 07:00, 2:45 PM is entered as 14:45).

This program item is one of three required to create a Closing Window. To program a Closing Window, Close Early Begin and Close Window Stop must also be programmed.

If the area is not armed when the Close Window Start time comes, a warning tone sounds and PLEASE CLOSE NOW displays at the command center. To temporarily silence the tone, press the [ESC] key on the command center. The warning tone restarts in 10 minutes if the area is not armed.

See the

W# Close Early Begin

prompt in this

section for report feature explanations.

W# Close Window Stop

Default: 00: 00 Selection: HH:MM (hours and minutes)

Enter the time that you want the control panel to end the Closing Window. The window stops at the end of the minute.

00:00 is midnight, 23:59 is 11:59 PM. Make entries using a 24-hour clock (for example, 7:00 AM is entered as 07:00, 2:45 PM is entered as 14:45).

This program item is one of three required to create a Closing Window. To program a Closing Window, Close Early Begin and Close Window Start must also be programmed.

If the area is not armed by the time the Close Window Stop time expires, the control panel generates a Fail to Close Report if enabled in Fail To Close.

Closing Reports generated between the Close Window Start time and Close Window Stop time can be suppressed by programming

Window

Yes. See the

W# Close Early Begin

Disable O/C in

prompt for other report feature explanations.

Do not use a time of 23:59 as a window stop time unless the window continues on the next day at 00:00. Fail to Close Reports are not sent, and the Auto Close feature does not work for windows that stop at 23:59.

For example, to program windows for an area that closes between 11:30 PM and 12:30 AM, five days a week, use two windows as shown in Table 34.

Table 34: W# Close Window Stop Programming Example

Open Close

Early

W# Day of Week

S M T W T F S

S M T

W T F S

Begin Start Stop

22 : 00 23 : 30 23 : 59 00 : 00 00 : 00 00 : 30

Bosch Security Systems | 1/04 | 47775E

Early

eXcept

Holiday

Yes No Yes No

Holiday

Index Area(s)

1 2 3 4 1 2 3 4

1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8

D9412G/D7412G | Program Entry Guide | 5.0 RADXSKED EN | 100

W# Xept Holiday

Default: No Selection: Yes or No

Yes Do not activate this window on

holidays.

To use this selection, the window must be programmed to activate on at least one day of the week and a Holiday Index must be enabled.

No A holiday does not prevent this

window from activating.

You also use this selection if Opening and/or Closing Windows are only needed on certain days of the year. Do not program the windows to execute on any days of the week. Instead, program at least one Holiday Index with the days of the year you want the window to be active.

Determine if the window is disabled on holidays, or is active only on holidays.

To prevent the windows from activating on certain days of the year, program enable at least one Holiday Index. When

Holiday

on the days of the week programmed unless the date is designated as a Holiday by the Holiday Index(es) selected.

Holiday Indexes for O/C Windows

You can enable up to four Holiday Indexes for use with Opening/Closing Windows. Enable at least one Holiday Index if Yes for this window, or if you want this window to activate only on specific dates. Holidays are programmed in Section 5.3 Holiday Indexes.

is programmed Yes, the window executes

Xept Holiday

W# Xept Holiday

No, and select

Yes, and

Xept

is programmed

W# Holiday 2

Default: No Selection: Yes or No

W# Holiday 3

Default: No Selection: Yes or No

W# Holiday 4

Default: No Selection: Yes or No

W# Area 1 [through 8]

Default: No Selection: Yes or No

Yes Activate the window in the area

number (#) specified.

Eight separate program items determine whether a particular window activates in each of the eight areas of the control panel.

Disable the window in the area number (#) specified.

W# Holiday 1

Default: No Selection: Yes or No

Yes Use Holiday Index 1 with this window.

Bosch Security Systems | 1/04 | 47775E

Do not use Holiday Index 1 with this window.
