PROdry
Fast Drying Carpet Cleaner
U S E R ’ S G U I D E
7350 SERIES
3Safety Instructions
4Product View
5Assembly
6Special Features
7-10 Operation
10-11 Maintenance and Care
12Troubleshooting
13Consumer Services
14Replacement Parts
15Additional Accessories
16Warranty
ug120-4035_7350_708En.indd 1 |
8/21/08 4:22:04 PM |
Thank you for buying a BISSELL PROdry carpet cleaner
We’re glad you purchased a BISSELL PROdry carpet cleaner. Everything we know about floor care went into the design and construction of this complete, hightech home cleaning system. By purchasing this product you are helping BISSELL with our commitment to reducing our impact on the environment through an expanding range of sustainable design efforts.
Your carpet cleaner is well made, and we back it with a limited one-year warranty. We also stand behind it with a knowledgeable, dedicated Consumer Services department, so, should you ever have a problem, you’ll receive fast, considerate assistance.
My great-grandfather invented the floor sweeper in 1876. Today, BISSELL is a global leader in the design, manufacture, and service of high quality homecare products like your carpet cleaner.
Thanks again, from all of us at BISSELL.
Mark J. Bissell
President and Chief Executive Officer
2 |
w w w . b i s s e l l . c o m |
8 0 0 . 2 3 7 . 7 6 9 1 |
ug120-4035_7350_708En.indd 2 |
8/21/08 4:22:05 PM |
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should be observed, including the following:
Read all instructions before using your PROdry
WARNING:To reduce the risk of fire, electric shock, or injury:
■Do not immerse.
■Use only on surfaces moistened by cleaning process.
■Always connect to a properly grounded outlet.
■See Grounding Instructions.
■Unplug from outlet when not in use and before conducting maintenance or troubleshooting.
■Do not leave machine when it is plugged in.
■Do not service machine when it is plugged in.
■Do not use with damaged cord or plug.
■If appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped into water, have it repaired at an authorized Service Center.
■Use indoors only.
■Do not pull or carry by cord, use cord as a handle, close door on cord, pull cord around sharp corners or edges, run appliance over cord, or expose cord to heated surfaces.
■Unplug by grasping the plug, not the cord.
■Do not handle plug or appliance with wet hands.
■Do not put any object into appliance openings, use with blocked opening, or restrict air flow.
■Do not expose hair, loose clothing, fingers or body parts to openings or moving parts.
■Do not pick up hot or burning objects.
■Do not pick up flammable or combustible materials (lighter fluid, gasoline, kerosene, etc.) or use in the presence of explosive liquids or vapor.
■Do not use appliance in an enclosed space filled with vapors given off by oil base paint,paint thinner,some moth proofing substances,flammable dust,or other explosive or toxic vapors.
■Do not pick up toxic material (chlorine bleach, ammonia, drain cleaner, gasoline, etc.).
■Do not modify the 3-prong grounded plug.
■Do not allow to be used as a toy.
■Do not use for any purpose other than described in this User’s Guide.
■Do not operate the appliance unless the sole plate is securely assembled in the location provided.
■Do not unplug by pulling on the cord.
■Use only manufacturer’s recommended attachments.
■Use only cleaning products formulated by BISSELL for use in this appliance to prevent internal component damage. See the cleaning fluid section of this guide.
■Keep openings free of dust, lint, hair, etc.
■Do not point attachment nozzle at people or animals
■Keep appliance on a level surface.
■ Unplug before connecting TurboBrush® tool w w w . b i s s e l l . c o m
■Turn off all controls before unplugging.
■Be extra careful when cleaning stairs.
■Close attention is necessary when used by or near children.
■Do not use a flammable or combustible liquid to clean a floor.
■Always install float before any wet pick-up operation.
SAVE THESE INSTRUCTIONS.
This model is for household use only. Commercial use of this unit voids the manufacturer’s warranty.
GROUNDING INSTRUCTIONS
This appliance must be connected to a grounded wiring system. If it should malfunction or break down, grounding provides a safe path of least resistance for electrical current, reducing the risk of electrical shock. The cord for this appliance has an equipment-grounding conductor and a grounding plug. It must only be plugged into an outlet that is properly installed and grounded in accordance with all local codes and ordinances.
Grounded
Outlets
Grounding Pin
WARNING: Improper
connection of the equipment-grounding conductor can result in a risk of electrical shock. Check with a qualified electrician or service person if you aren’t sure if the
outlet is properly grounded. DO NOT MODIFY THE PLUG. If it will not fit the outlet, have a proper outlet installed by a qualified electrician. This appliance is designed for use on a nominal 120-volt circuit, and has a grounding attachment plug that looks like the plug in the drawing above. Make certain that the appliance is connected to an outlet having the same configuration as the plug. No plug adapter should be used with this appliance.
8 0 0 . 2 3 7 . 7 6 9 1 |
3 |
ug120-4035_7350_708En.indd 3 |
8/21/08 4:22:06 PM |
Product view
|
|
|
|
|
|
|
|
|
|
|
|
|
Spray Trigger |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Quick Release™ |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
Power Switch |
|
|
|
|
|
|
|
|
|
|
|
|
|
Cord Wrap |
|
|
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|||||||
Hose Secure Latch |
|
|
|
|
|
|
|
|
|
Power Cord |
|||||
|
|
|
|
|
|
|
|
||||||||
Upper Hose Wrap |
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|||||||
Ready-to-use Hose |
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
||||||
Large, |
|
|
|
|
|
|
|
|
|||||||
Easy-To-Maneuver |
|
|
|
|
|
|
|
|
|||||||
Wheels |
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|||||||
Handle Release |
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
WARNING:
To reduce the risk of fire and electric shock due to internal component damage, use only BISSELL cleaning fluids intended for use with the deep cleaner. Non-BISSELL cleaning solutions may harm the machine and void the warranty.
Cleaning fluid
Tough Stain Tool
Handle Assembly
Easy Carry
Handle
Oxy Gen2
PowerTool™
Lower Body
Assembly
Ready
Tools™ Dial
TLR PowerRoller
Keep plenty of genuine BISSELL Fiber Cleansing Formula™ on hand so you can clean whenever it fits your schedule. Always use genuine BISSELL deep cleaning formulas. Non-BISSELL cleaning solutions may harm the machine and will void the warranty.
48 oz. BISSELL |
48 oz. BISSELL |
48 oz. BISSELL |
48 oz. BISSELL |
48 oz. BISSELL |
42.67 oz. BISSELL |
22 oz. |
|||
Fiber Cleansing |
MultiAllergen |
Pet Odor and |
Natural Orange |
Lavender Essence |
3X Concentrated |
BISSELL |
|||
Formula™ with |
Removal™ |
Soil Removal™ |
Extract Formula |
Formula with |
Fiber Cleansing |
Tough Stain |
|||
Scotchgard™ |
Formula™ with |
Formula with |
with Scotchgard™ |
Scotchgard™ |
Formula with |
PreCleaner™ |
|||
Protector |
Scotchgard™ |
Scotchgard™ |
Protector |
Protector |
Scotchgard™ |
item # |
|||
item # 0710 |
Protector |
Protector |
item # 0740 |
item # 0750 |
Protector |
0400 |
|||
|
|
item # 0720 |
item # 0730 |
|
|
|
|
item # 0716 |
|
4 |
w w w . b i s s e l l . c o m |
|
|
|
|
|
|
8 0 0 . 2 3 7 . 7 6 9 1 |
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
||||
ug120-4035_7350_708En.indd 4 |
8/21/08 4:22:25 PM |
How to use this guide
This user’s guide has been designed to help you get the maximum satisfaction from your PROdry carpet cleaner. You’ll find assembly and operating instructions, safety precautions, as well as maintenance and troubleshooting instructions. Please read this user’s guide thoroughly before assembling your carpet cleaner.
Your carpet cleaner comes in three easy to assemble components:
•Handle assembly
•Upper hose wrap
•Lower body assembly
Four Phillips head screws are included and can be found taped to the handle assembly.
Assembly
The only tool you will need to assemble your PROdry is a Phillips head screwdriver.
1.Slide upper handle into lower body assembly and secure with 2 screws.
2.Attach upper hose wrap using 2 screws.
3.Wrap hose clockwise around the upper and lower hose wraps as shown on page 4. Be sure to properly secure grip into the notched holder.
4.Keep hose locked in place with the secure latch.
5.Wrap the power cord as shown on page 4.
6.Place Oxy Gen2 PowerTool in the center tool caddy and the tough stain tool on the hose wand.
w w w . b i s s e l l . c o m
Warning:
Do not plug in your cleaner until you have completely assembled it per the following instructions
and are familiar with all instructions and operating procedures.
Tip: Regular carpet cleaning can reduce dust and allergens in your home.
1.
2a.
2b.
Upper Hose
Wrap Screws
Upper Handle
Screws
8 0 0 . 2 3 7 . 7 6 9 1 |
5 |
ug120-4035_7350_708En.indd 5 |
8/21/08 4:22:30 PM |
