SPOTCLEAN
PRO SERIES
_______________
USER GUIDE
3624, 2458
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING YOUR PORTABLE DEEP CLEANER.
When using an electrical appliance, basic precautions should be observed, including the following:
WARNING
TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK, OR INJURY:
» Connect to a properly grounded
outlet only. See grounding
instructions. Do not modify the
3-prong grounded plug.
» Do not leave appliance when
it is plugged in. Unplug from
outlet when not in use and
before servicing.
» Do not expose to rain.
Store indoors.
» Do not allow to be used as a toy.
Close attention is necessary when
used by or near children.
» Do not use for any purpose other
than described in this User’s
Guide. Use only manufacturer’s
recommended attachments.
» Do not use with damaged
cord or plug. If appliance is not
working as it should, has been
dropped, damaged, left outdoors,
or dropped into water, have it
repaired at an authorized service
center.
» Always install float before any
wet pick-up operation.
» Do not pull or carry by cord, use
cord as a handle, close a door on
cord, or pull cord around sharp
edges or corners. Do not run
appliance over cord. Keep cord
away from heated surfaces.
» Do not unplug by pulling on
cord. To unplug, grasp the plug,
not the cord.
» Do not handle plug or appliance
with wet hands.
» Do not put any object into
openings. Do not use with any
opening blocked; keep openings
free of dust, lint, hair, and
anything that may reduce air flow.
» Keep hair, loose clothing, fingers,
and all parts of body away from
openings and moving parts.
» Turn off all controls before
plugging or unplugging appliance.
» Use extra care when cleaning
on stairs.
» Do not use to pick up flammable
or combustible materials (lighter
fluid, gasoline, kerosine, etc.)
or use in areas where they may
be present.
» Do not use appliance in an
enclosed space filled with vapors
given off by oil base paint, paint
thinner, some moth proofing
substances, flammable dust, or
other explosive or toxic vapors.
» Do not use to pick up toxic
material (chlorine bleach,
ammonia, drain cleaner, etc.).
» Do not pick up anything that
is burning or smoking, such as
cigarettes, matches, or hot ashes.
» Use only BISSELL cleaning
products intended for use with
this appliance to prevent internal
component damage. See the
Cleaning Fluid section of this
guide.
» Keep appliance on a level surface.
» Do not carry the appliance while
in use.
SAVE THESE INSTRUCTIONS
FOR FUTURE USE
This model is for household use only. Commercial use of this unit voids the manufacturer’s warranty.
WARNING
Improper connection of the equipment-grounding conductor can
result in a risk of electrical shock. Check with a qualified electrician
or service person if you aren’t sure if the outlet is properly grounded.
DO NOT MODIFY THE PLUG. If it will not fit the outlet, have a proper
outlet installed by a qualified electrician. This appliance is designed
for use on a nominal 120-volt circuit, and has a grounding attachment
plug that looks like the plug in the illustration. Make certain that the
appliance is connected to an outlet having the same configuration as
the plug. No plug adapter should be used with this appliance.
www.BISSELL.com
2
GROUNDING INSTRUCTIONS
This appliance must be connected to a grounded wiring system. If it
should malfunction or break down, grounding provides a safe path
of least resistance for electrical current, reducing the risk of electrical
shock. The cord for this appliance has
an equipment-grounding conductor
and a grounding plug. It must only be
plugged into an outlet that is properly
installed and grounded in accordance
with all local codes and ordinances.
Grounded
Outlets
Grounding Pin
Thanks for buying a BISSELL portable carpet cleaner!
We love to clean and we’re excited to share one of our innovative products
with you. We want to make sure your portable carpet cleaner works as well
in two years as it does today, so this guide has tips on using (pages 5-7),
maintaining (page 8), and if there is a problem, troubleshooting (page 9).
In just a few simple assembly steps, you’ll be ready to spot clean. Flip to page
6 and let’s get started!
Safety Instructions...........2
Product View ................4
Cleaning Formula............5
Operations ................6-7
Maintenance & Care .........8
Troubleshooting .............9
Warranty ....................11
Service ......................11
Product Registration ........12
Consumer Care.............12
www.BISSELL.com
3
Product View
Carry Handle
Power Button
Dirty Water
Tank
Power Cord
Quick
Release™
Cord
Wrap
WARNING
To reduce the risk of fire and electric shock due to internal
component damage, use only BISSELL cleaning formulas
intended for use with the deep cleaner.
Cleaning
Tool
Formula
& Clean
Water Tank
Flex Hose
WARNING
Do not plug in your cleaner until you have completely
assembled it per the above instructions and are familiar
with all instructions and operating procedures.
www.BISSELL.com
4
Cleing Formula
Keep plenty of genuine BISSELL for portable
spot cleaning machines on hand so you can
clean whenever it fits your schedule. Always
use genuine BISSELL cleaning formulas.
WARNING
To reduce the risk of fire and electric shock due to internal
component damage, use only BISSELL cleaning formula
intended for use with this machine.
CARPET CLEANING FORMULA ENHANCER
Oxy Boost Pro Boost Prevent Boost
Removes old,
set-in stains
permanently
BOOST
Revives
carpets
to look
their best
Repels stains
from soaking
into carpet
fibers
Pet Oxy
Removes
pet stains
and odors
permanently
PROFESSIONAL
FORMULAS
Professional
Deep Cleaning
Out cleans all
other formulas
Includes
Scotchgard™
Protector
Professional
Pet Urine
Eliminator+Oxy
Our best formula
for pet urine
stains & odors
Includes
Scotchgard™
Protector
Pet Stain & Odor
Removes tough
Boost
pet stains
Includes
Scotchgard™
Protector
PRE TREAT SPOTS AND STAINS TO IMPROVE
CARPET CLEANING PERFORMANCE
Oxy Stain Destroyer Pet Stain PreTreat
Permanent Stain Removal
in 30 seconds
PRETREAT
Pretreat to help remove
tough pet stains and odors
2X* CLEANING FORMULA
DeepClean
& Protect
Deep cleans
carpets
and protects
from future stains
with Scotchgard™
Protector
DeepClean
+ Refresh
Powerful
cleaning with
a refreshing
scent
Deep Clean +
Oxy
Removes deep
down dirt, pet
stains, &
pet odor
ONLY BISSELL Protects from future stains with Scotchgard™ Protector. Scotchgard™ is a trademark of 3M®.
*2.5 fl. oz. of 2X concentrated formula is equivalent to 5.0 fl. oz. of non-concentrated formula.
www.BISSELL.com
5
Asmbly
Before you clean
1. Remove loose dirt and impediments
before deep cleaning.
2. Pretreating (optional):
2a. Pretreating is recommended to
improve cleaning effectiveness for
heavily soiled carpet in high traffic
areas such as entryway and hallways.
2b. BISSELL Stain Pretreat
Spray any BISSELL Stain
Pretreat formula onto heavy traffic
areas, soiled areas or stains.
Allow to penetrate for at least 3 minutes.
Clean as normal, following the
instructions below.
Preparing the machine
1. Release flex hose by twisting the
hose secure latch clockwise. Unwrap
flex hose completely.
2. Attach the Large Stain Tool or Tough
Stain Tool to the hose grip until it snaps
together. Make certain the tool is securely
attached.
3. Twist the Quick Release™ cord wrap
clockwise to unwrap the power
cord completely and plug into
grounded outlet.
Filling the formula & water tank
1. Remove tank from the back of the
machine by lifting up tank carry handle.
Note: This tank was designed with a
flat bottom so it can be easily filled.
2. Unscrew the black cap and remove
bottle insert.
3. Fill tank with hot tap water (140° F/60° C
MAX) to the water
fill line. Add 60 mL/2 oz of BISSELL 2X
formula to the tank.
4. Replace the bottle insert in the tank and
tighten the black cap. Replace the tank
on the machine.
NOTICE
Some Berber carpets have a tendency to fuzz with
wear. Repeated strokes in the same area may
aggravate this condition.
Make only one trip to
the sink by bringing
Tip
the entire portable
cleaner. Fill and empty
in the same trip.
1.
2.
www.BISSELL.com
6
Operatis
Cleaning with your spot cleaner
1. Plug unit in and turn on by pressing power
button.
2.
Hold cleaning tool approximately 2.5cm
above soiled surface. Press spray trigger to
apply cleaning solution to soiled area.
3.
Using the brush on the cleaning tool, gently
scrub area to be cleaned.
4. For thorough cleaning, spray additional
solution while brush and suction are in
contact with surface.
5.
Apply downward pressure on cleaning
tool and pull it toward you. The suction
will remove the dirt and cleaning solution.
Continue until no more dirt can be removed.
6. As a final step, use “drying strokes” (by not
pressing the spray trigger) to remove as
much liquid/moisture as possible. Repeat this
step as often as necessary.
Cleaning with 3"/4"/6" tool
1. Attach the 3”/4”/6” Tough Stain Tool to the
handheld cleaning hose.
2. Press the spray trigger to mist solution over
and onto the soiled area.
3. Release spray trigger and gently scrub the
stain.
4. To lift the stain away, apply downward
pressure on the tool and slowly pull it toward
you. Then use “drying strokes” (by not
pressing down trigger) to remove remaining
moisture. Repeat as needed.
WARNING
Keep spray away from face. Failure to do so may
result in personal injury.
IMPORTANT
Check the manufacturer’s tag before
cleaning upholstery. Test a small, hidden
area for colourfastness. If colour is
aected, do not use. If manufacturer’s
tag is missing or not coded, check with
your furniture dealer.
Cleaning with stain trapper tool*
*select models only
1.
Attach the Stain Trapper tool to the end of
the hose.
2. Slowly move the tool back and forth over the
stain. Be careful not to move the tool back
and forth too quickly or soiled water will flow
back into the hose.
3. To empty the tool, rotate the small tank on
the bottom of the tool to unlock it.
4. Dump dirty water into a sink or toilet and
rinse the tank out with clean water.
5. Replace the tank by lining up the locking
teeth with their mating slots (make sure
the two teeth that are closest together are
pointed toward the brush). Turn the tank to
lock it into place.
www.BISSELL.com
7
Mainnce & Care
Empty dirty tank
1. When the dirty tank reaches the “FULL” line
on the tank it is time to empty.
2. Remove dirty tank and carry to a utility sink,
toilet or outside (where you will
dispose of the dirty water).
3. To unlock the dirty tank lid, rotate handle over
the back of the tank. Remove lid and pour out
dirty water. Rinse out dirty tank
to remove any debris.
4. Replace top of tank, and rotate the handle
forward to lock in place on front of tank.
5. Before replacing tank on machine, wipe
debris from red filter.
Cleaning machine
1. Remove and rinse the tools under clean,
running water. Allow tools to dry.
2. It is recommended that you suction clean
water from a bowl to rinse out the hose.
Then lift end of hose and stretch out to
ensure all water is cleared from hose.
3. Wrap the flex hose around the hose wrap
and secure with latch.
Machine care (check regularly)
Cleaning Debris Filter
1. Remove all hair and debris from the red
filter.
2. Place the Dirty Water Tank back onto the
machine.
Machine storage
Store machine in a protected dry area.
WARNING
To reduce the risk of fire, electric shock, or injury, turn
power OFF and disconnect plug from electrical outlet
before performing maintenance or troubleshooting.
2.
4.
Tip
Debris
Filter
3.
5.
For best results
empty, rinse and
dry tanks and tools
before storing.
www.BISSELL.com
8
NOTICE
To reduce the risk of a leaking condition, do not
store unit where freezing may occur. Damage to
internal components may result.
Trbleshting
Problem Possible causes Remedies
Formula and water tank may be
Reduced spray
or
no spray
empty
Formula and water tank may
not be seated completely
Pump may have lost prime Hold end of hose below water level in tank
To reduce the risk of electric shock, turn power switch
o and disconnect plug from electrical outlet before
performing maintenance or troubleshooting checks.
Refill tank
Turn power OFF; Remove and reseat tank
to prime
WARNING
Loss of suction
power
Tanks may not be seated properly
Dirty tank has picked up maximum amount of dirty water and
has reached full line
Formula and water tank is
empty
Pick up both tanks and reseat them so they
fit snuggly on the unit
Empty dirty tank
Check fluid levels in formula and water tank
www.BISSELL.com
9
Nos
www.BISSELL.com
10
Warranty
This warranty gives you specific legal rights,
and you may also have other rights which
may vary from state to state. If you need
additional instruction regarding this warranty
or have questions regarding what it may
cover, please contact BISSELL Consumer
Care by e-mail or telephone as described
below.
Limited Two-Year Warranty
Subject to the *EXCEPTIONS AND
EXCLUSIONS identified below, upon receipt
of the product BISSELL will repair or replace
(with new or remanufactured components
or products), at BISSELL’s option, free of
charge from the date of purchase by the
original purchaser, for two years any
defective or malfunctioning part.
See information below on “If your BISSELL
product should require service”.
This warranty applies to product used for
personal, and not commercial or rental
service. This warranty does not apply to
fans or routine maintenance components
such as filters, belts, or brushes. Damage or
malfunction caused by negligence, abuse,
neglect, unauthorized repair, or any other
use not in accordance with the User’s Guide
is not covered.
BISSELL IS NOT LIABLE FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES OF ANY
NATURE ASSOCIATED WITH THE USE OF
THIS PRODUCT. BISSELL’S LIABILITY WILL
NOT EXCEED THE PURCHASE PRICE OF
THE PRODUCT.
Some states do not allow the exclusion or
limitation of incidental or consequential
damages, so the above limitation or
exclusion may not apply to you.
*EXCEPTIONS AND EXCLUSIONS FROM
THE TERMS OF THE LIMITED WARRANTY
THIS WARRANTY IS EXCLUSIVE AND
IN LIEU OF ANY OTHER WARRANTIES
EITHER ORAL OR WRITTEN. ANY IMPLIED
WARRANTIES WHICH MAY ARISE
BY OPERATION OF LAW, INCLUDING
THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE, ARE LIMITED
TO THE TWO YEAR DURATION FROM
THE DATE OF PURCHASE AS DESCRIBED
ABOVE.
Some states do not allow limitations on
how long an implied warranty lasts so the
above limitation may not apply to you.
NOTE: Please keep your original sales receipt. It provides proof of date of
purchase in the event of a warranty claim.
Service
If your BISSELL product should require service:
Contact BISSELL Consumer Care to locate a BISSELL Authorized Service Center in your area.
If you need information about repairs or replacement parts, or if you have questions about
your warranty, contact BISSELL Consumer Care.
Website:
www.BISSELL.com
E-mail:
www.BISSELL.com/email-us
Please do not return this product to the store.
Other maintenance or service not included in the manual should be
performed by an authorized service representative.
For any questions or concerns, BISSELL is happy to be of service.
Contact us directly at 1-800-237-7691.
Call:
BISSELL Consumer Care
1-800-237-7691
Monday – Friday 8am - 10pm ET
Saturday 9am - 8pm ET
Sunday 10am - 7pm ET
www.BISSELL.com
11
Register your product today!
Registering is quick, easy and offers you benefits over the lifetime of your product.
You’ll receive:
BISSELL Rewards Points
Automatically earn points for
discounts and free shipping on
future purchases.
Faster Service
Supplying your information now
saves you time should you need
to contact us with questions
regarding your product.
Product Support Reminders
and Alerts
We’ll contact you with any
important product maintenance
reminders and alerts.
Special Promotions
Optional: Register your email
to receive notice of offers,
contests, cleaning tips and more!
Visit www.BISSELL.com/registration!
Visit the BISSELL website: www.BISSELL.com
When contacting BISSELL, have model number of cleaner available.
Please record your Model Number: ___________________
Please record your Purchase Date: ___________________
NOTE: Please keep your original sales receipt. It provides proof of purchase
date in the event of a warranty claim. See the Warranty page for details.
For cleaning tips and more visit www.BISSELL.com or find us at:
12
BISSELL BISSELLClean BISSELL BISSELLBISSELLClean
We c’t wait to ar from y!
Rate this product and let us (and millions
of your closest friends) know what you think!
www.BISSELL.com
©2018 BISSELL Homecare, Inc
Grand Rapids, Michigan
All rights reserved. Printed in China
Part Number 161-4866 03/18 RevD
Visit our website at: www.BISSELL.com
Loading...
