ProLite®
U S E R ’ S G U I D E
3560 SERIES
3
4
4-7
7
8-10 Routine Maintenance
11 Troubleshooting
11 Replacement Parts
12
12
Thanks for buying a BISSELL Lightweight Upright Vacuum Cleaner
We’re glad you purchased a BISSELL Lightweight Upright Vacuum Cleaner. Everything we know about floor care went into the design and construction of this powerful, high-tech home vacuuming system.
Your BISSELL Prolite® Vacuum Cleaner is well made, and we back it with a comprehensive 10-year warranty on the motor housing and 5-year warranty on the motor. We also stand behind it with a knowledgeable, dedicated Consumer Services department, so, should you ever have a problem, you’ll receive fast, considerate assistance.
My great-grandfather invented the floor sweeper in 1876. Today, BISSELL is a global leader in the design, manufacture, and service of high quality homecare products like your BISSELL Prolite Lightweight Upright Vacuum Cleaner.
Thanks again, from all of us at BISSELL.
Mark J. Bissell
President and Chief Executive Officer
2
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should be observed, including the following:
READ ALL INSTRUCTIONS BEFORE USING YOUR PRODUCT NAME HERE.
WARNING: To reduce the risk of fire, electric shock, or injury:
■Always connect to a polarized outlet (left slot is wider than right). Do not modify the polarized plug to fit a non-polarized outlet or extension cord.
■Do not leave vacuum cleaner when it is plugged in. Unplug from outlet when not in use and before servicing.
■Do not use outdoors or on wet surfaces.
■Do not allow to be used as a toy. Close attention is necessary when used by or near children.
■Do not use for any purpose other than described in this User's Guide. Use only manufacturer's recommended attachments.
■Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped into water, return it to a service center.
■Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners. Do not run appliance over cord. Keep cord away from heated surfaces.
■Use extra care when cleaning on stairs.
■Do not use to pick up flammable or combustible materials (lighter fluid, gasoline, kerosine, etc.) or use in areas where they may be present.
■Do not use vacuum cleaner in an enclosed space filled with vapors given off by oil base paint, paint thinner, some moth proofing substances, flammable dust, or other explosive or toxic vapors.
■Do not use to pick up toxic material (chlorine bleach, ammonia, drain cleaner, etc.).
■Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
■Do not use without dust bag and/or filters in place.
■Do not pick up hard or sharp objects such as glass, nails, screws, coins, etc.
■Use only on dry, indoor surfaces.
■Keep appliance on a level surface.
■Do not carry the vacuum cleaner while it is running.
SAVE THESE INSTRUCTIONS FOR FUTURE USE.
THIS MODEL IS FOR HOUSEHOLD USE ONLY.
■Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
■Do not handle plug or vacuum cleaner with wet hands.
■Do not put any object into openings. Do not use with any opening blocked; keep openings free of dust, lint, hair, and anything that may reduce air flow.
■Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.
■Turn off all controls before plugging or unplugging vacuum cleaner.
THIS APPLIANCE HAS A POLARIZED PLUG.
To reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install a proper outlet. Do not change the plug in any way.
3
13.Quick Release Cord Hook
|
1. Handle |
|
2. Power Switch |
10. Power |
3. Handle Tube |
Source |
|
Plug |
12. Power Cord |
|
|
|
Cord Storage |
6. Cloth Bag
4. Connector
Tube
7. Dust Bag
5. Dust Tube
19. Soft |
15. Rotating |
|
Cleaning Brush |
||
Furniture |
9. Motor |
|
Protection |
||
|
||
Guard |
|
W A R N I N G :
Do not plug in your vacuum cleaner until you are familiar with all instructions and operating procedures.
8. Post-
Motor
Filtration
System
14. Powerfoot |
11. Connector |
|
Plug |
|
18. Soft Wheels |
4
