P4SFA BIOS Setup

1

BIOS Setup

Introduction

This manual discussed Award™ Setup program built into the ROM BIOS. The Setup
program allows u sers to modify t he b asic syst em con figuration . Th is speci al infor mation i s
then stored in battery-backed RAM so that it retains the Setup information when the power
is turned off.

The Award BIO S™ installed in your computer syst em’s ROM (Read Only M emory) is a
custom version of an industry standard BIOS. This means that it supports Intel Pentium

®

4
processor input/output system. The BIOS provides critical low-level support for standard
devices suc h as dis k dri v e s a nd serial and parall e l po r ts .

Adding important has customized th e Award BIOS™, but nonstandard, features s uch as
virus and pas sword protection as w ell as special suppor t for detailed fine-tunin g of the
chipset controlling the entire system.

The rest of this manual is intended to guide you through the process of configuring your
system using Setup.

Plug and Play Support

These AWARD BIOS supports the Plug and Play Version 1.0A specification. ESCD
(Extended Sys te m Configura t ion Da t a) wr it e is s upport ed.

EPA Green PC Support

This AWARD BIOS supports Version 1.03 of the EPA Green PC specification.

APM Support

These AWARD BIOS supports Version 1.1&1.2 of the Advanced Power Management
(APM) specification. Power management features are implemented via the System
Management Interrupt (SMI). Sleep and Suspend power management modes are supported.
Power to the har d dis k dri v es a nd video monito rs can be managed by this AWARD BI OS.

P4SFA BIOS Setup

2

PCI Bus Support

This AWARD BIOS also supports Version 2.1 of the Intel PCI (Peripheral Component
Interconnect) local bus specification.

DRAM Support

DDR SDRAM (Double Data Rate Synchronous DRAM) are supported.

Supported CPUs

This AWARD BIOS supports the Intel Pentium

®

4 CPU.

Using Setup

In general, you use the arrow keys to highlight items, press <Enter> to select, use the
<PgUp> and <PgDn> keys to change entries, press <F1> for help and press <Esc> to quit.
The following table provides more detail ab out how to n avigate in t he Setup progra m by
using the k e y bo ar d.

Keystroke Function

Up arrow Move to previous item
Down arrow Move to next item
Left arrow Move to the item on the left (menu bar)
Right arrow Move to the item on the right (menu bar)
Move Enter Move to the item you desired
PgUp key Increase the numeric value or make changes
PgDn key Decrease the numeric value or make changes
+ Key Increase the numeric value or make changes

- Key Decrease the numeric value or make changes
Esc key Main Menu – Quit and not save changes into CMOS

Status Page Setup Menu and Option Page Setup Menu – Exit

Current page and return to Main Menu
F1 key General help on Setup navigation keys
F5 key Load previous values from CMOS
F6 key Load the fail-safe defaults from BIOS default table
F7 key Load the optimized defaults
F10 key Save all the CMOS changes and exit

P4SFA BIOS Setup

3

1 Main Menu

Once you enter Aw ard BIOS™ CMOS Setup Utili ty, the Main Menu will app ear on the
screen. The Main Menu allows you to select from several setup functions. Use the arrow
keys to select among the items and press <Enter> to accept and enter the sub-menu.

 Figure 1. Main Menu

Standard CMOS Features

This submenu c o ntai ns indu st ry s ta nda rd co nf igurable o ptio ns .

Advanced BIOS Features

This submenu all ows yo u to co nfi g ur e enhanced features of the BIOS.

Advanced Chipset Features

This submenu allows you to configure special chipset features.

!! WARNING !!

The information about BIOS defaults on manual (Figure
1,2,3,4,5,6,7,8,9) is just for reference, please refer to the BIOS

installed on bo a rd, fo r upda te inf o r m a tio n.

P4SFA BIOS Setup

4

Integrated Peripherals

This submenu allows you to configure certain IDE hard drive options and Programmed
Input/ Output features .

Power Management Setup

This submenu all o ws yo u to c onfi gure the power manageme nt fe a tur e s.

PnP/PCI Configurations

This submenu allows you to configure certain “Plug and Play” and PCI options.

PC Health Status

This submenu a llo w s yo u to m o ni t or the hardware of y o ur s y stem.

Frequency Control

This submenu allows you to change CPU Vcor e Voltage a nd CPU/PCI clock. (However,
this function is strongly recommended not to use. Not properly change the voltage and
clock may cause CPU or M/B damage!)

Load Optimized Defaults

This selection allows you to reload the BIOS when the system is having problems
particularly with the boot sequence. These configurations are factory settings optimized
for this system. A confirmation message will be displayed before defaults are set.

Set Password

Setting the passwor d will prohibit everyon e except the supervisor fro m making changes
using the CMO S Se tup U til i ty. You will be prompted with to enter a passwor d.

P4SFA BIOS Setup

5

Save & Exit Setup

Save all c onfiguration chan ges to CM OS(memory) and exit setu p. Confirmation message
will be display e d be f ore proceeding.

Exit Without Saving

Abandon all changes made during the current session and exit setup. confirmation
messa ge will be display ed before proceeding.

Upgrade BIOS

This submenu all o ws yo u to upgrade bios.

P4SFA BIOS Setup

6

2 Standard CMOS Features

The items in Standard CMOS Setup Menu are divided into 1 0 categories. Ea ch category
includes no, one o r more than one setup items. Use the arrow keys to highlight the ite m and
then use the<PgUp> or <PgDn> keys to select the value you want in each item.



Figure 2. Standard CMOS Setup

P4SFA BIOS Setup

7

Main Menu Selections

This table shows the selections that you can make on the Main Menu.

Item Options Description

Date mm : dd : yy Set the system date. Note

that the ‘Day’ automatically
changes when you set the
date.

Time hh : mm : ss Set the system internal

clock.

IDE Primary Master Options are in its sub

menu.

Press <Enter> to enter the
sub menu of detailed
options

IDE Primary Slave Options are in its sub

menu.

Press <Enter> to enter the
sub menu of detailed
options.

IDE Secondary Master Options are in its sub

menu.

Press <Enter> to enter the
sub menu of detailed
options.

IDE Secondary Slave Options are in its sub

menu.

Press <Enter> to enter the
sub menu of detailed

options.
Drive A
Drive B

360K, 5.25 in

1.2M, 5.25 in
720K, 3.5 in

1.44M, 3.5 in

2.88M, 3.5 in

None

Select the type of floppy
disk drive installed in your
system.

Video EGA/VGA

CGA 40
CGA 80

MONO

Select the default video
device.

P4SFA BIOS Setup

8

Item Options Description

Halt On All Errors

No Errors

All, but Keyboard

All, but Diskette

All, but Disk/ Key

Select the situation in which
you want the BIOS to stop
the POST process and
notify you.

Base Memory N/A Displays the amount of

conventional memory
detected during boot up.

Extended Memory N/A Displays the amount of

extended memory detected
during boot up.

Total Memory N/A Displays the total memory

available in the system.

P4SFA BIOS Setup

9

3 Advanced BIOS Features

 Figure 3. Advanced BIOS Setup

Virus Warning

This option al l ows y ou t o choo se t h e Vir u s Warn in g featu re that i s u sed t o prot ect th e IDE
Hard Disk boot sector. If this function is enabled and an attempt is made to write to the
boot sector, BIOS will display a warning message on the screen and sound an alarm beep.

Disabled (default) Virus protection is disabled.
Enabled Virus protection is activated.

CPU L1 & L2 Cache

The option allows you to enable/ disable CPU Cache to speed up the system performance.

Enabled (default) Enable cache.
Disabled Disable cache.

CPU Hyper-Threading

This option allo ws yo u to e na ble or disable d CPU Hy per - Threading.

The Choices: Enabled (Default), Disabled.

P4SFA BIOS Setup

10

CPU L2 Cache ECC Checking

This item allows you to enable/disable CPU L2 Cache ECC Checking.

The Choices: Enabled (default), Disabled.

Quick Power On Self Test

Enabling this op tion wil l cau se a n abri d ged version of th e P ower On Self-T est (P OS T) to
execute after you power up the computer.

Enabled (default) Enable quick POST.
Disabled Normal POST.

First /Second/Third/ Boot Other Device

These BIOS attempts to load the operating system from the devices in the sequence
selec te d in these ite ms.

The Choices: Floppy, LS120, HDD-0, SCSI, CDROM, HDD-1, HDD-2, HDD-3,
ZIP100, LAN, HPT370, Enabled, Disabled.

Swap Floppy Drive

For systems with two floppy drives, this option allows you to swap logical drive
assignments.

The Choices: Enabled, Disabled (defa ult ).

Boot Up Floppy Seek

Enabling this option will test the floppy drives to determine if they have 40 or 80 tracks.
Disabling this o ptio n reduces the ti m e it take s to boo t- up.

The Choices: Enabled (default), Disabled.

Boot Up NumLock Status

Selects the NumLock. State after power on.

On (default) Numpad is number keys.
Off Numpad is arrow keys.

Gate A20 Option

Select if chipset or keyboard controller should control Gate A20.

Normal A pin in the keyboard controller

controls Gate A20.

Fast (default) Lets chipset control Gate A20.

Typematic Rate Setting

When a key is held down, the keystroke will repeat at a rate determined by the keyboard
controller. When enabled, the typematic rate and typematic delay can be configured.

Disabled (default)
Enabled

P4SFA BIOS Setup

11

Typematic Rate (Chars/Sec)

Sets the rate at which a keystroke is repeated when you hold the key down.

The Choices: 6 (default), 8,10,12,15,20,24,30.

Typematic Delay (Msec)

Sets the delay time after the key is held down before it begins to repeat the keystroke.

The Choices: 250 (defa ult ), 500,750,1000.

Security Option

This option w ill enable on ly individ uals with passwords t o bring t he system online and /or
to use the CMOS Setup Utility.

System A password is requi red for the sy stem to boot and is

also required to access the Setup Utility.

Setup (default) A password is required to access the Setup Utility

only.

This will only apply if pas sw o rds ar e s et from the Setup main m e nu.

APIC Mode

This option al lows you to enable or dis able the AP IC (Advanced Programmable In terrupt
Control).
The Choices: Enabled (default), Disabled.

MPS Version Control For OS

The BIOS supports version 1.1 and 1.4 of the Intel Multi-Processor Specification.
Select version supported by the oper ation system running on this computer.
The Choices: 1.4 (default), 1.1.

OS Select For DRAM > 64MB

A choice other than Non-OS2 is only used for OS2 systems with memory exceeding 64MB.

The Choices: Non-OS2

(default), OS2.

HDD S.M.A.R. T. Capa b i lity

This item allows you to enable/disable the S.M.A.R.T. function of the hard disk.

The Choices: Disabled (default), Enabled.

Report No FDD For WIN 95

Whether report no FDD for WIN 95 or not.

The Choices: No (default), Yes.

Video BIOS Shadow

Determines whether video BIOS will be copied to RAM for faster execution.

Enabled (default) Optional ROM is enabled.
Disabled Optional ROM is disa ble d.

P4SFA BIOS Setup

12

Summary Screen Show

This item allows you to enable/ disable display the Summary Screen Show.

The Choices: Disabled (default), Enabled.

P4SFA BIOS Setup

13

4 Advanced Chipset Features

This submenu allows you to configur e the specific features of t he chipset installed on your
system. This chipset manage bus speeds and access to system memory resources, such as
DRAM. It also coord in ates co mmuni cation s w ith t he P C I b us. Th e d efault settin gs th at ca me
with your sys tem have been opti mized and therefore sh ould not be chan ged unless you are
suspicious that the settings have been changed inco rrectly.



Figure 4. Advanced Chipset Setup

Advanced DRAM Control 1

To control the DDR SDRAM. If you highlight the literal “Press Enter” next to the
“Advanced DRAM Control” label and then press the enter key, it will take you a submenu
with the following options:

DRAM Timing Control

This item determines DRAM clock/ timing follow SPD or not.

The Choices: By SPD(default), Manual.

RAS Precharge Time (tRP)

This items allows you to speci fy the delay from prechar ge command to activate
command.
The Choices: 2T, 3T (default).

P4SFA BIOS Setup

14

RAS Active Time (tRAS)

This item s al lo w s y ou to sp e c i fy the m i nimum bank ac tiv e time.

The Choices: 6T (default), 5T.
RAS to CAS Delay (tRCD)

Use this item to specif y th e d elay fr o m th e activ ation of a bank to the time that a
read or write command is accepted.

The Choices: 2T, 3T (default).
CAS Latency Setting

When synchronous DRAM is installed, the number of clock cycles of CAS
latency depends on the DRAM ti m i ng .

The Choices: By SPD (default), 2T, 2.5T, 3T.

DRAM Addr/ Cmd Rate

The Choices: Auto (default), 1T, 2T.

Prefetch Caching

This item allows you enable/disable Prefetch Caching.
The Choices: Enabled, Disabled (default).

Memory Hole at 15M-16M

When enabled, you ca n reserve an area of system memory for ISA adapter ROM. When
this area is r ese rv ed , it cannot be cached. R ef er to the user documentat ion of the peripheral
you are installing for more information.
The Choices: Disabled (default), Enabled.

AGP Aperture Size

Select the s ize of the A ccelerat ed Grap hics P ort (AG P) ap erture. The ap erture is a port ion
of the PCI memory address range dedicated for graphics memory address space. Host
cycles that hit the aperture range are forwarded to the AGP without any translation.
The Choices: 4M, 8M,16M, 32M, 64M (default), 128M, 256M.

Graphic Window WR Combin

This item allows you enable/disable Graphic Window write-combine.
The Choices: Enabled, Disabled (de fa ult ).

P4SFA BIOS Setup

15

5 Integrated Peripherals



Figure 5. Integrated Peripherals

SIS OnChip IDE Device

If you highlight the literal “Press Enter” next to the “SIS OnChip IDE Device” label and
then press the enter key, it will take you a submenu with the following options:

Internal PCI/IDE

This item allows you select Internal PCI/IDE.

The Choices: Both (default), Disabled, Primary, Secondary.

IDE Primary / Secondary Master / Slave PIO

The IDE P IO (Programmed Input / Outpu t) fields l et you set a P IO mod e (0-4)
for each of the IDE devices that the onboard IDE interface supports. Modes 0
through 4 provide successively increased performance. In Auto mode, the system
automatically determines the best mode for each device.

The Choices: Auto (default ) , Mo de 0, Mode1, Mode 2, Mode3, Mode4.

Primary / Secondary Master / Slave UltraUDMA

Ultra DMA/133 functionality can be implemented if it is supported by the IDE
hard drives in your system. As well, your operating environment requires a DMA
driver (Windows 95 OSR2 or a third party IDE bus master driver). If your hard
drive and your system software both support Ultra DMA/133, select Auto to
enable BIOS support.
The Choices: Auto (default), Disabled.

P4SFA BIOS Setup

16

IDE Burst Mode

This item allows you enable/disable IDE Burst Mode.

The Choices: Enabled (default), Disabled.

SIS OnChip PCI Device

If you highlight the literal “Press Enter” next to the “SIS OnChip PCI Device” label and
then press the enter key, it will take you a submenu with the following options:

SIS USB Controller

This option allows you to control SIS USB Controlller.

The Choices: Enabled (default), Disabled.

USB Ports Number

This option allows you to control USB Ports Number.

The Choices: 6

(default), 5, 4, 3.

USB 2.0 Supports

This option allows you to enabled or disabled USB2.0 Supports.

The Choices: Disabled, Enabled (def a ult) .

USB Keyboard Support

Enables suppor t fo r USB a tt ac hed keyboa rds.

The Choices: Disabled (default), Enabled.

SIS AC97 Audio

This option allows you to control the onboard AC97 Audio.

The Choices: Auto (default), Disabled.

SIS S/W Modem

This option allows you to control the onboard S/W Modem.

The Choices: Auto (default), Disabled.

SIS 10/100M ETHERNET

This option allows you to control the 10/100M Ethernet.

The Choices: Auto (default), Disabled.

SIS MAC Address Input

Onboard SuperIO Device

If you highlight the literal “Press Enter” next to the “Onboard Super IO Device” label and
then press the enter key, it will take you a submenu with the following options:

Onboard FDC Controller

Select Enabled if your system has a floppy disk controller (FDC) installed on the
system bo ar d and y o u wis h to use it . I f ins tal l a nd FDC o r the s y st e m ha s no
floppy driv e, select Disabled in this field.
The Choices: Enabled (default), Disabled.

P4SFA BIOS Setup

17

Onboard Serial Port 1

Selec t an addr ess and corresponding int e rr upt for t he f irs t and s e co nd s erial ports .
The Choices: Disabled, 3F8/IRQ4 (default), 2F8/IRQ3, 3E8/IRQ4, 2E8/IRQ3,

Auto.

Onboard Serial Port 2

Selec t an addr ess and corresponding int e rr upt for t he f irs t and s e co nd s erial ports .

The Choices: Disabled (default), 2F8/IRQ3, 3F8/IRQ4, 3E8/IRQ4,
2E8/IRQ3, Auto.

UART Mode Selec t

This item allows you to determine which Infra Red (IR) function of onboard I/O
chip.

The Choices: Normal, AS KIR, IrDA (default ).

UR2 Duplex Mode

Select the value required by the IR device connected to the IR port. Full-duplex
mode permits simultaneous two-direction transmission. Half-duplex mode
permits transmission in one direction only at a time.

The Choices: Half (default), Full.

Onboard Parallel Port

This item al lows you to d etermine acc ess onboard parall el port cont roller with
which I/O Addre s s.

The Choices: 378/IRQ7 (default), 278/IRQ 5, 3BC/IRQ7, Disable d.

Parallel Port Mode

The default va lue is SPP.

SPP(default) Using Parallel port as Standard Printer Port.
EPP Using Parallel Port as Enhanced Parallel Port.
ECP Using Parallel port as Extended Capabilities Port.
ECP+EPP Using Parallel port as ECP & EPP mo de .

ECP Mode Use DMA

Select a DMA Channel for the port.

The Choices: 3 (default), 1.

Game Port Address

Game Port I/ O Addre s s.

The Choices: 201 (default), 209, Disabled.

Midi Port Address

Midi Port Base I/O Address.
The Choices: 330 (defa ult),300, 290, Disabled.

P4SFA BIOS Setup

18

Midi Port IRQ

This dete rmines the IRQ in which the Midi Por t c an use.

The Choices: 5, 10 (default).

IDE HDD Block Mode

Block mode i s otherwis e known as block tr ansfer, multi ple comm ands, or mult iple sector
read/write. Select the “Enabled” option if your IDE hard drive supports block mode (most
new drives do). The system will automatically determine the optimal number of blocks to
read and write per secto r.

The Choices: Enabled (default), Disabled.

Init Display First

With systems that have multiple video cards, this option determines whether the primary
display use s a PCI Slo t or an AGP Slot.

The Choices: PCI Slot (default), AGP.

AGP Auto Calibration

This item allows you enable/disable AGP Auto Calibration.

The Choices: Enabled (default), Disabled.

System Share Memory Size

This item allows you to select the system share memory size.

The Choices: 32MB (default), 64MB, 16MB, 8MB, 4MB.

IDECH0/1 Access Interface

This item allows you to select the IDECH0/1 Access Interface.

The Choices: EDB Bus (default), PCI Bus.

USB0 Access Interface

This item allows you select the USB0 Access Interface.

The Choices: EDB Bus

(default), PCI Bus.

USB1 Access Interface

This item allows you select the USB1 Access Interface.

The Choices: EDB Bus (default), PCI Bus.

USB2 Access Interface

This item allows you select the USB2 Access Interface.

The Choices: EDB Bus (default), PCI Bus.

P4SFA BIOS Setup

19

USB2.0 Access Interface

This item allows you select the USB2.0 Access Interface.

The Choices: EDB Bus (default), PCI Bus.

MAC Access Interface

This item allows you select the MAC Access Interface.

The Choices: Embedded Bus (de f a ult), PCI Bus.

Audio Access Interface

This item allows you select the Audio Access Interface

The Choices: Embedded Bus

(default), PCI Bus .

P4SFA BIOS Setup

20

6 Power Management Setup

The Power Management Setup Menu allows you to configure your system to utilize energy
conservation and power up/power down features.



Figure 6. Power Management Setup

ACPI function

This item displays the status of the Advanced Configuration and Power Management
(ACPI).

The Choices: Enabled (default), Disabled.

ACPI Suspend Type

The item allows you to select the suspend type under the ACPI operating system.

The Choices: S1 (POS) (default) Power on Suspend

S3 (STR) Suspend to RAM
S1 & S3 POS+STR

Power Management

This category allows you to select the type (or degree) of power saving and is dir ectly
related to the followi ng modes :

1. HDD Power Down.

P4SFA BIOS Setup

21

2. Suspend Mode.

There are four options of Power Management, three of which have fixed mode setting s

Min. Power Saving

Minimum power management.
Suspend Mode = 1 hr.

Max. Power Saving

Maximum power management only available for sl CPU’s.
Suspend Mode = 1 m in.

User Defined (default)

Allows you to set each mode indiv idually.
When not disable d, e a c h o f the ra ng es are fro m 1 min. to 1 hr.

Suspend Mode

The item allows you to select the suspend type under ACPI operating system.

The Choices: Disa bled (default), 1 Min, 2 Min, 4 Min, 6 Min, 8 Min, 20 Min,

30 Min, 40 Min, 1 Hour.

Video Off Option

This field determines when to activate the video off feature for monitor power
management.

The Choices: Suspend→Off, Always on, Susp, StbyOff (Default), All

modesOff.

Video Off Method

This option determines the manner in which the monitor is goes blank.

V/H SYNC+Blank

This selection will cause the system to turn off the vertical and horizontal
synchronization ports and write blanks to the video buffer.

Blank Screen

This option only writes blanks to the video buffer.

DPMS Supported

(default)

Initial displ ay power management signaling.

P4SFA BIOS Setup

22

Switch Function

You can choos e whether or not to permit your system or enter complete suspend mod e.
Suspend mode offers greater power savings, with a correspondingly longer with a
correspondingly longer awakening period.

The Choices: Break/ Wake (default), Disabled.

Modem Use IRQ

This determines the IRQ, which can be applied in MODEM use.

The Choices: Auto (default), 3, 4, 5, 7, 9, 10, 11, NA.

Hot Key Function As

This item allows you select Hot Key Function As Power Off (Ctrl-Alt-Backspace).
The Choices: Power Off (default), Suspend, Disabled.

HDD Off After

After a selected period of drive inactivity, the hard disk drive will power down while all
other devices remain active.

The Choices: Disa bled

(default), 1 Min, 2 Min, 3 Min, 4 Min, 5 Min, 6 Min, 7

Min, 8 Min, 9 Min, 10 Min, 11 Min, 12 Min, 13 Min, 14 Min, 15 Min.

Power Button Override

When you select Delay 4 sec, pressing the power button for more than 4 seconds forces the
system to enter the Soft-Off state.

The Choices: Instant Off (default), Delay 4 Sec.

Power State Resume Control

This item allows you to select Power State Resume Control.

The Choices: Always off (default), Always on, Keep Pre-State.

PM Wake Up Events

If you highlight th e literal “Press En ter” n ext to the “ PM Wake Up Events” lab el and th en
press the enter key, it will take you a submenu with the following options:

IRQ [3-7, 9-15], NMI

This item allows you enable/disable IRQ [3-7,9-15] NMI.

The Choices: Enabled (default), Disabled.

IRQ 8 Break Suspend

This item al lo w s yo u en abl e/disable I RQ 8 Break Suspend.

The Choices: Disabled (default), Enabled.

RING/ WOL Power Up Control

This item al l ow s yo u to c ontr o l the RING Pow e r Up.
The Choices: Enabled, Disabled (default).

P4SFA BIOS Setup

23

MACPME Power Up Control

This item al lo w s yo u to c o ntr ol the MACPME Power Up.

The Choices: Enabled, Disabled (defa ult ).

PCIPME Power Up Control

This item al lo w s yo u to c o ntr ol the PCIPME Po wer Up.

The Choices: Enabled, Disabled (default).

Power Up by Alarm

When you select Enab led, fi elds app ear tha t l et you s et th e alar m t h at retu rns the
system to Full On state.

The Choices: Disabled (default), Enabled.
Month Alarm

Select a month (1-12) or NA if you want th e alarm active during all months

Day of Month Alarm

Select a date in the month. Select 0 if you prefer to set a weekly alarm.

Time (hh:mm:ss) Alarm

Set the time you want the alarm to go off on the days when it is activated.

Reload Global Timer Events

Reload Global Ti mer Event s are I/O events whose occurr ence can prevent the syst em fro m
entering a pow er saving mode or ca n awak en the syst em from su ch a mod e. In eff ect, the
system remains alert for anything, which occurs to a device, which is configured as Enabled,
even when the system is in a power down mode.

Primary IDE Disabled (default), Enabled.
Secondary IDE Disabled

(default), Enabled.

FDD, COM, LPT Port Disabled (default), Enabled.
PCI, PIRQ[A-D]# Disabled (default), Enabled.

Delay Prior to Thermal

The Choices: None (default), 1Min, 2Min, 4Min, 8Min, 16Min, 32Min, 64Min.

P4SFA BIOS Setup

24

7 PnP/PCI Configurations

This section describes configuring the PCI bus system. PCI, or Personal Computer
Interconnect, is a system which allows I/O devic es to operate at speeds nearing the speed of
the CPU itself uses when communicating with its own special components. This section
covers some very technical items and it is strongly recommended that only experienced
users should make any changes to the default settings.



Figure 7. PnP/PCI Configuration s

Reset Configuration Data

The system BIOS supports the PnP feature which requires the system to record which
resources are assigned and protects resources from conflict. Every peripheral device has a
node, which i s call ed E SCD. This node recor ds w hich resou rces ar e assign ed to it. The
system needs to record and update ESCD to the memory locations. These locations (4K)
are reserved in the system BIOS. If the Disabled (d efault) option is ch osen, the system‘s
ESCD will update only wh en the n ew confi gurat ion varies from the last one. If the Enabl ed
option is chosen, th e syst em is forc ed to up date ESCDs and then is auto matically s et to th e
“Disabled” mode.

The above settings will be shown on the screen only if “Manual” is chosen for the resources
controlle d by func tio n.
Legacy is the term, which signifies that a resource is assigned to the ISA Bus and provides
non-PnP ISA add-on cards. PCI / ISA PnP signifies that a resource is assigned to the PCI

P4SFA BIOS Setup

25

Bus or provides for ISA PnP add-on cards and peripherals.

The Choices: Disabled (default), Enabled.

Resources Controlled By

By Choosing “Auto(ESCD)” (default), the system BIOS wil l detect th e system resources
and automatically assign the relative IRQ and DMA channel for each peripheral.By
Choosing “Manual”, the user will need to assign IRQ & DMA for add-on cards. Be sure
that there are no IRQ/DMA and I/O port conflicts.

IRQ Resources

This submenu will allow you t o assi gn each s yst em interrupt a type, dependi ng on th e type
of device using the interru p t. When you press the “Press Enter” tag, you w ill be directed to
a submenu that will allow you to configure the system interrupts. This is only
configurable when “Resources Controlled By” is set to “Manual”.

IRQ-3 assigned to PCI Device
IRQ-4 assigned to PCI Device
IRQ-5 assigned to PCI Device
IRQ-7 assigned to PCI Device
IRQ-9 assigned to PCI Device
IRQ-10 assigned to PCI Device
IRQ-11 assigned to PCI Device
IRQ-12 assigned to PCI Device
IRQ-14 assigned to PCI Device
IRQ-15 assigned to PCI Device

PCI / VGA Palette Snoop

Choose Disabl ed or Enabled. S ome graphic controll ers which are not VGA compatible
take the output from a VGA controller and map it to their display as a way to provide boot
information and VGA compat ibility.

However, the color inf ormation comin g from the VGA controll er is draw n from the p alette
table inside the VGA controll er to generate th e proper colors, an d the graphic con troller
needs to know what is in the palette of the VGA controller. To do this, the non-VGA
graphic controller watches for the Write access to the VGA palette and registers the snoop
data. In PCI based syst ems, wh ere th e VGA control ler is on th e PCI b us and a non- VGA
graphic controller is on an ISA bus, the Write Access to the palette will not show up on the
ISA bus if the PCI VGA controller responds to the Write.

In this case, th e PCI VGA con troll er should not respon d to the Writ e, it should only snoop
the data and permit the access to be forwarded to the ISA bus. The non-VGA ISA graphic
controller can then snoop the da ta on the ISA bus. Unless you have the above situation,
you should disable this option.

Disabled (default) Disables the function.
Enabled Enables the function.

P4SFA BIOS Setup

26

8 PC Health Status

 Figure 8. PC Health Status

Shutdown Temperature

This item allows you to set up the CPU shutdown Temperature. T his item only effective
under Windows 98 ACPI mode.

The Choices: Disabled (default), 60

O

C/140OF, 65OC/149OF, 70OC/158OF,

75

O

C/167OF.

CPU Vcore/AGP Voltage/+3.3V/+5V/+12V/-12V/-5V/ 5V(SB) Voltage Battery

Detect the system’s voltage status automatically.

Current CPU Temp

This field displays the current temperature of CPU.

Current CPUFAN Speed

This field displays the current speed of CPU fan.

P4SFA BIOS Setup

27

Current SYS FAN Speed

This field displays the current speed SYSTEM fan.

Show H/W Monitor in POST

If your computer contains a monitoring system, it will show PC health status during POST
stage.

P4SFA BIOS Setup

28

9 Frequency Control

 Figure 9. Frequency Control

CPU Clock Ratio

This item allows you to select the CPU Ratio.

The Choices: 0X (default).

CPU Volta g e

This item allows you to select CPU Voltage Regulator.

The Choices: Default (default), +1 . 7％, +3.45％, +5.1％.

DDR Voltag e

This item allows you to select DDR Voltage Regulator.

The Choices: 2.5V (Default), 2. 6, 2.7, 2.8.

Auto Detect DIMM/ PCI Clk

This item allows you to enable / disable auto Detect PCI Clock.
The Choices: Enabled (default), Disabled.

P4SFA BIOS Setup

29

Spread Spectrum

This item allows you to enable/disable the Spread Spectrum function.

The Choices: Enabled (default), Disabled.

CPU Frequency

This item allows you to control CPU Frequency.

The Choices: Default (default), 100MHz, 133MHz.

DRAM Frequency

This item allows you to control DRAM Frequency.
The Choices: By SPD (default) , 200MH z, 266M Hz, 333M Hz.

If unfortunately, the system’s frequency that you are selected is
not functioning, there are two methods of booting-up the syst em.
Method 1: Clear the CMOS data by setting the JCMOS1 ((2-3) closed ))

as “ON” status. All the CMOS data will be loaded as
defaults setting.

Method 2: Pr ess the <Insert> key and Power button simultaneously,

after that keep-on pressing the <Insert> key until the
power-on screen showed. This action will boot-up the
system according to FSB of the processor.
