Beko RDNT360I50VZWB, RDNT470E50VZJG, RDNT340E50VZX, RDNT440E50VZX, RDNT470E50VZX User manual [EN]

RDNT470E50VZJG	RDNT470E50VZDJX	RDNT360I50VZWB
RDNT340E50VZX	RDNT470E50VZJG
RDNT440E50VZX	RDNT470E50VZWB
RDNT470E50VZX	RDNT440E50VZWB
EN

Please read this user manual first!

Dear Customer,

We hope that your product, which has been produced in modern plants and checked under the most meticulous quality control procedures, will provide you an effective service.

Therefore, read this entire user manual carefully before using the product and keep it as a reference. If you handover the product to someone else, give the user manual as well.

The user manual will help you use the product in a fast and safe way.

•Read the manual before installing and operating the product.

•Make sure you read the safety instructions.

•Keep the manual in an easily accessible place as you may need it later.

•Read the other documents given with the product.

Remember that this user manual is also applicable for several other models. Differences between models will be identified in the manual.

Explanation of symbols

Throughout this user manual the following symbols are used:

CImportant information or useful tips.

AWarning against dangerous conditions for life and property. BWarning against electric voltage.

CONTENTS
1 Your Refrigerator	3
2 Important Safety
Warnings	4
Intended use......................................	4
General safety....................................	5
For products with a ...........................	9
water dispenser;.................................	9
Child safety........................................	9
Compliance with WEEE Directive and
Disposing of the Waste Product: .......	9
Package information........................	10
HC warning......................................	10
Things to be done for energy saving.10
Recommendations for the fresh food
compartment...................................	11

5 Using your refrigerator 17

Indicator panel.................................	17
Indicator panel.................................	20
Freezing fresh food...........................	22
Recommendations for preservation of
frozen food.......................................	22
Placing the food...............................	22
Deep-freeze information...................	23
Making ice........................................	23
Twist Ice – matic .............................	24
Ice container....................................	24
Fan..................................................	25
Crisper.............................................	25
Chiller compartment.........................	25
Description and cleaning of odour
filter: ................................................	26

3 Installation	12
Points to be paid attention to when the
relocation of the refrigerator..............	12
Electrical connection........................	12
Disposing of the packaging..............	13
Disposing of your old refrigerator......	13
Placing and Installation.....................	13
Adjusting the legs.............................	14
Door Open Warning.........................	14
Changing the illumination lamp ........	14
4 Preparation	16

6 Maintenance and	27
cleaning

Protection of plastic surfaces .......... 27

7 Troubleshooting

28

2 EN

1 Your Refrigerator

15		12
	*14
		*13

	*14			*1
		*9
	12	*2		4
	11		*3
	*10
	*9
	16
	*8
			*5
	*7
	6		6
1.	Freezer - compartment	10.	Bottle shelf
door shelf		11.	Fridge - compartment
2.	Temperature setting button	glass shelf
3.	Moving door shelf	12.	Fan
4.	Egg section	13.	Freezer compartment shelf
5.	Bottle shelf	14.	Icebox / Ice-making
6.	Adjustable feet	compartment
7.	Crisper	15.	Freezer compartment
8.	Chiller compartment	16.	Fridge compartment
9.	Lock and key	*optional

Figures that take place in this instruction manual are schematic and may not correspond exactly with your product. If the subject parts are not included in the product you have purchased, then it is valid for other models.

3 EN

	Important Safety Warnings
2
Please review the
				WARNING:
following information.
				A Do not damage the
Failure to observe this
				refrigerant circuit.
information may cause
injuries or material
				WARNING:
damage. Otherwise, all				Do not use
warranty and reliability				electrical
commitments will				appliances inside
become invalid.				the food storage
Original spare parts will				A compartments
be provided for 10 years,				of the appliance,
following the product				unless they
purchasing date.				are of the type
Intended use				recommended by
		WARNING:		the manufacturer.
		Keep ventilation
		openings, in	This appliance is intended
		the appliance	to be used in household
A		enclosure or	and similar applications
		in the built-in	such as
		structure, clear of	– staff kitchen areas in
		obstruction.	shops, offices and other
			working environments;
		WARNING:	– farm houses and by
		Do not use	clients in hotels, motels
		mechanical devices	and other residential type
		or other means	environments;
A		to accelerate the	– bed and breakfast type
		defrostingprocess,	environments;
		other than those	– catering and similar
		recommended by		non-retail applications.
		the manufacturer.

4 EN

General safety

•When you want to dispose/scrap the product, we recommend you to consult the authorized service

in order to learn the required information and authorized bodies.

•Consult your authorized service for all your questions and problems related to the refrigerator. Do not intervene or let someone intervene to the refrigerator without notifying the authorised services.

•For products with a freezer compartment; Do not eat cone ice cream and ice cubes immediately after you take them out of the freezer compartment! (This may cause frostbite in your mouth.)

•For products with a freezer compartment; Do not put bottled and canned liquid beverages in the freezer compartment. Otherwise, these may burst.

5

•Do not touch frozen food by hand; they may stick to your hand.

•Unplug your refrigerator before cleaning or defrosting.

•Vapor and vaporized cleaning materials should never be used in cleaning and defrosting processes of your refrigerator. In such cases, the vapor may get in contact with the electrical parts and cause short circuit or electric shock.

•Never use the parts on your refrigerator such as the door as a means of support or step.

•Do not use electrical devices inside the refrigerator.

•Do not damage the parts, where the refrigerant is circulating, with drilling or cutting tools. The refrigerant that might blow out when the gas channels of the evaporator, pipe extensions or surface

coatings are punctured causes skin irritations

EN and eye injuries.

•Do not cover or block the ventilation holes on your refrigerator with any material.

•Electrical devices must be repaired by only authorised persons. Repairs performed by incompetent persons create a risk for the user.

•In case of any failure or during a maintenance or repair work, disconnect your refrigerator’s mains supply by either turning off the relevant fuse

or unplugging your appliance.

•Do not pull by the cable when pulling off the plug.

•Ensure highly alcoholic beverages are stored securely with the lid fastened and placed upright.

•Never store spray cans containing

flammable and explosive substances in the refrigerator.

•Do not use mechanical devices or other means to accelerate the defrosting process, other than those

recommended by the manufacturer.

•This product is not intended to be used by persons with physical, sensory or mental disorders or unlearned or inexperienced people (including children) unless they are attended by a person who will

be responsible for their safety or who will instruct them accordingly for use of the product

•Do not operate a damaged refrigerator. Consult with the service agent if you have any concerns.

•Electrical safety of your refrigerator shall be guaranteed only if the earth system in your house complies with standards.

•Exposing the product to rain, snow, sun and wind is dangerous with respect to electrical safety.

•Contact authorized service when there is a power cable damage to avoid danger.

6 EN

•Never plug the refrigerator into the wall outlet during installation. Otherwise, risk of death or serious injury may arise.

•This refrigerator is intended for only storing food items. It must not be used for any other purpose.

•Label of technical specifications is located on the left wall inside the refrigerator.

•Never connect your refrigerator to electricitysaving systems; they may damage the refrigerator.

•If there is a blue light on the refrigerator, do not look at the blue light with optical tools.

•For manually controlled refrigerators, wait for at least 5 minutes to start the refrigerator after power failure.

•This operation manual should be handed in to the new owner of the product when it is given to others.

•Avoid causing damage on power cable when transporting the refrigerator. Bending cable may cause fire. Never place heavy objects on power cable. Do not touch the plug with wet hands when plugging the product

•Do not plug the refrigerator if the wall outlet is loose.

•Water should not be sprayed on inner or outer parts of the product for safety purposes.

•Do not spray substances containing inflammable gases such as propane gas near the refrigerator to avoid fire and explosion risk.

•Never place containers filled with water on top of the refrigerator; in the event of spillages,

7 EN

this may cause electric shock or fire.

•Do not overload the refrigerator with food. If overloaded, the food

items may fall down and hurt you and damage refrigerator when you open the door.

•Never place objects on top of the refrigerator; otherwise, these objects may fall down when you open or close the refrigerator’s door.

•As they require a precise temperature, vaccines, heat-sensitive medicine and scientific materials and etc. should not be kept in the refrigerator.

•If not to be used for a long time, refrigerator should be unplugged. A possible problem in power cable may cause fire.

•Refrigerator may move if adjustable legs are not properly secured on the floor. Properly securing adjustable legs on the floor can prevent the refrigerator to move.

•When carrying the refrigerator, do not hold it from door handle. Otherwise, it may be snapped.

•When you have to place your product next to another refrigerator or freezer, the distance between devices should be at least 8cm. Otherwise, adjacent side walls may be humidified.

•The product shall never be used while the compartment which is located at the top or back of your product and in which electronic boards are available (electronic board box cover) (1) is open.

1

1

8 EN

For products with a water dispenser;

•Pressure for cold water inlet shall be maximum 90 psi (6.2 bar). If your water pressure exceeds 80 psi (5.5 bar), use a pressure limiting valve in your mains system. If you do not know how to check your water pressure, ask for the help of a professional plumber.

•If there is risk of water hammer effect in your installation, always use a water hammer prevention equipment in your installation. Consult Professional

plumbers is you are not sure that there is no water hammer effect in your installation.

•Do not install on the hot water inlet. Take precautions against of the risk of freezing of the hoses. Water temperature operating interval shall be 33°F (0.6°C) minimum

and 100°F (38°C) maximum.

•Use only potable water.

Child safety

•If the door has a lock, the key should be kept away from reach of children.

•Children must be supervised to prevent them from tampering

with the product.

Compliance with WEEE Directive and Disposing of the Waste Product:

This product complies

with EU WEEE Directive (2012/19/EU). This product

bears a classification symbol for waste electrical and electronic equipment

(WEEE).

This product has been manufactured with high quality parts and materials which can be reused and are suitable for recycling. Therefore, do not dispose the product with normal domestic waste at the end of its service life. Take it to a collection point for the recycling of electrical and electronic equipment. Please consult your local authorities

to learn the nearest collection point. Help protect the environment and natural resources by recycling used products. For children’s safety, cut the power cable and break the locking mechanism of the door, if any, so

that it will be non-functional before disposing of the product.

9 EN
