Beko RFNE 312 E 22 X, RFNE 312 E 43 W, RFNE 312 E 23 W, RFNE 312 E 23 X, RFNE 312 E 33 W User manual [EN,DE,FR,NL]

Refrigerator
User manual
RFNE 312 E 22 X	RFNE 312 E 43 W
RFNE 312 E 23 W
RFNE 312 E 23 X
RFNE 312 E 33 W
RFNE 312 E 33 X
EN DE FR	NL

Please read this manual before using the product!

Dear Customer,

We'd like you to make the best use of our product, which has been manufactured in modern facilities with care and meticulous quality controls.

Thus, we advice you to read the entire user manual before you use the product. In case the product changes hands, do not forget to hand the guide to its new owner along with the product.

This guide will help you use the product quickly and safely.

•Please read the user guide carefully before installing and operating the product.

•Always observe the applicable safety instructions.

•Keep the user guide within easy reach for future use.

•Please read any other documents provided with the product.

Keep in mind that this user guide may apply to several product models. The guide clearly indicates any variations of different models.

C Important information and useful tips.

A Risk of life and property.

B Risk of electric shock.

The product’s packaging is made of recyclable materials, in accordance with the National Environment Legislation.

1 Safety and environment
instructions	4
General safety................................................	4
Intended use....................................................	7
Child safety.......................................................	7
Compliance with WEEE Directive and
Disposing of the Waste Product.............	8
Compliance with RoHS Directive............	8
Package information....................................	8
2 Your Freezer	9
3 Installation	10
Appropriate installation location..........	10
Installing the plastic wedges.................	10
Adjusting the feet........................................	11
Electrical connection..................................	11
4 Preparation	12
5Operating the product	13
Freezing fresh food....................................	15
Recommendations for preserving the
frozen food....................................................	16
Deep-freeze information.........................	16
Placing the food...........................................	17
Door open warning.....................................	17
Changing the door opening direction.17

6 Maintenance and cleaning 18

Avoiding bad odours..................................	18
Protecting the plastic surfaces ............	18
7Troubleshooting	19

Refrigerator/User Manual	3 / 22 EN

1 Safety and environment instructions

This section provides the safety instructions necessary to prevent the risk of injury and material damage. Failure to observe these instructions will invalidate all types of product warranty.

1.1. General safety

•This product should not be used by persons with physical, sensory and mental disabilities, without sufficient knowledge and experience or by children. The device can only be used by such persons under supervision and instruction of a person responsible for their safety. Children should not be allowed to play with this device.

•In case of malfunction, unplug the device.

•After unplugging, wait at least 5 minutes before plugging in again.

•Unplug the product when not in use.

•Do not touch the plug with wet hands! Do not pull the cable to plug off, always hold the plug.

•Wipe the power plug’s tip with a dry cloth before plugging in.

•Do not plug in the refrigerator if the socket is loose.

•Unplug the product during installation, maintenance, cleaning and repair.

•If the product will not be used for a while, unplug the product and remove any food inside.

•Do not use the product when the compartment with circuit cards located on the upper back part of the product (electrical card box cover) (1) is open.

	4 / 22 EN	Refrigerator/User Manual

Safety and environment instructions

1

1

•Do not use steam or steamed cleaning materials for cleaning the refrigerator and melting the ice inside. Steam may contact the electrified areas and cause short circuit or electric shock!

•Do not wash the product by spraying or pouring water on it! Danger of electric shock!

•In case of malfunction, do not use the product, as it may cause electric shock. Contact the authorized service before doing anything.

•Plug the product into an earthed socket. Earthing must be done by a qualified electrician.

•If the product has LED type lighting, contact the authorized service for replacing or in case of any problem.

•Do not touch frozen food with wet hands! It may adhere to your hands!

•Do not place liquids in bottles and cans into the freezer compartment. They may burst out!

•Place liquids in upright position after tightly closing the lid.

•Do not spray flammable substances near the product, as it may burn or explode.

Refrigerator/User Manual	5 / 22 EN

Safety and environment instructions

•Do not keep flammable materials and products with flammable gas (sprays, etc.) in the refrigerator.

•Do not place containers holding liquids on top of the product. Splashing water on an electrified part may cause electric shock and risk of fire.

•Exposing the product to rain, snow, sunlight and wind will cause electrical danger. When relocating the product, do not pull by holding the door handle. The handle may come off.

•Take care to avoid trapping any part of your hands or body in any of the moving parts inside the product.

•Do not step or lean on the door, drawers and similar parts of the refrigerator. This will cause the product to fall down and cause damage to the parts.

•Take care not to trap the power cable.

1.1.1 HC warning

If the product comprises a cooling system using R600a gas, take care to avoid damaging the cooling system and its pipe while using and moving the product. This gas

is flammable. If the cooling system is damaged, keep the product away from sources of fire and ventilate the room immediately.

C The label on the inner left side indicates the type of gas used in the product.

	6 / 22 EN	Refrigerator/User Manual

Safety and environment instructions

1.1.2 For models with water fountain

•In order for the water system inside the refrigerator to operate properly, pressure in the water mains must be between 1-8 bars. A pressure regulator must be used if the pressure in the water mains

is higher than 5 bars. If the pressure in the mains is higher than 8 bars, the refrigerator must not be connected to the mains. If you are not sure about how to measure the water pressure, ask for professional help.

•Use drinking water only.

1.2. Intended use

•This product is designed for home use. It is not intended for commercial use.

•The product should be used to store food and beverages only.

•Do not keep sensitive products requiring controlled temperatures (vaccines, heat sensitive medication, medical supplies, etc.) in the refrigerator.

•The manufacturer assumes no responsibility for any damage due to misuse or mishandling.

•The product’s bench life is 10 years. The spare parts necessary for the product to function will be available for this period.

1.3. Child safety

•Keep packaging materials out of children’s reach.

•Do not allow the children to play with the product.

•If the product’s door comprises a lock, keep the key out of children’s reach.

Refrigerator/User Manual	7 / 22 EN

Safety and environment instructions

1.4. Compliance with WEEE Directive and Disposing of the Waste Product

This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE).

This product has been manufactured with high quality parts and

materials which can be reused and are suitable for recycling. Do not dispose of the waste product with normal domestic and other wastes at

the end of its service life. Take it to the collection center for the recycling of electrical and electronic equipment. Please consult your local authorities to learn about these collection centers.

1.5. Compliance with RoHS Directive

• This product complies with EU WEEE Directive (2011/65/EU). It does not contain harmful and prohibited materials specified in the Directive.

1.6. Package information

•Packaging materials of the product are manufactured from recyclable materials in accordance with our National Environment Regulations. Do not dispose of the packaging materials together with the domestic or other wastes. Take them to the packaging material collection points designated by the local authorities.

	8 / 22 EN	Refrigerator/User Manual

2 Your Freezer

1

2

3

4

1.Control Panel

2.Flap

3.Drawers

4.Adjustable front feet

Figures that take place in this instruction manual are schematic and C may not correspond exactly with your product. If the subject parts are

not included in the product you have purchased, then it is valid for other models.

Refrigerator/User Manual	9 / 22 EN

3Installation

3.1.Appropriate installation location

Contact an Authorized Service for the installation of the product. In order to prepare the product for use, refer the information in the user manual and ensure that electrical installation and water installation are appropriate. If not, call a qualified electrician and technician to have any necessary arrangements carried out.

WARNING: Manufacturer shall Bnot be held liable for damages

that may arise from procedures carried out by unauthorized persons.

WARNING: Product must Bnot be plugged in during

installation. Otherwise, there is the risk of death or serious injury!

WARNING:

If the door clearance of the room where the product shall be place is so tight to prevent

Apassing of the product, remove the door of the room and pass the product through the door by turning it to its side; if this does not work, contact the authorized service.

•Placetheproductonanevenfloor surface to prevent jolts.

•Installtheproductatleast30cm away from heat sources such as hobs, heater cores and stoves and at least 5 cm away from electrical ovens.

•Productmustnotbesubjectedto direct sun light and kept in humid places.

•Appropriateairventilationmustbe provided around your product in order to achieve an efficient operation. If the product is to be placed in a recess in the wall, pay attention to leave at least 5 cm distance with the ceiling and side walls.

•

3.2. Installing the plastic wedges

Plastic wedges supplied with the product are used to create the distance for the air circulation between the product and the rear wall.

1.To install the wedges, remove the screws on the product and use the screws supplied together with the wedges.

2.Insert the 2 plastic wedges onto the rear ventilation cover as illustrated in the figure.

	10 / 22 EN	Refrigerator/User Manual

Installation

3.3. Adjusting the feet

If the product stands unbalanced after installation, adjust the feet on the front by rotating them to the right or left.

3.4.Electrical connection

A WARNING: Do not make connections via extension cables or multi-plugs.

WARNING: Damaged

B power cable must be replaced by the Authorized Service Agent.

If two coolers are to be C installed side by side, there

should be at least 4 cm distance between them.

•Our company shall not be liable for any damages that will arise when the product is used without

grounding and electrical connection in accordance with the national regulations.

•Power cable plug must be within easy reach after installation.

•Connect your refrigerator to a grounded outlet rated for a voltage value of 220-240V /50 Hz. Outlet shall have 10 to 16A fuse.

•Do not extension cords or cordless multiple outlets between your product and the wall outlet.

Refrigerator/User Manual	11 / 22 EN

4Preparation

•Your refrigerator should be installed at least 30 cm away from heat sources such as hobs, ovens, central heater and stoves and at least 5 cm away from electrical ovens and should not be located under direct sunlight.

•The ambient temperature of the room where you install your refrigerator should at least be -15°C. Operating your refrigerator under cooler conditions is not recommended with regard to its efficiency.

•Please make sure that the interior of your refrigerator is cleaned thoroughly.

•If two refrigerators are to be installed side by side, there should be at least 2 cm distance between them.

•When you operate your refrigerator for the first time, please observe the following instructions during the initial six hours.

•The door should not be opened frequently.

•It must be operated empty without any food in it.

•Do not unplug your refrigerator. If a power failure occurs out of your control, please see the warnings in

the “Recommended solutions for the problems” section.

•Original packaging and foam materials should be kept for future transportations or moving.

•The baskets/drawers that are provided with the chill compartment must always be in use for low energy consumption and for better storage conditions.

•Food contact with the temperature sensor in the freezer compartment may increase energy consumption of the appliance. Thus any contact with the sensor(s) must be avoided.

•In some models, the instrument panel automatically turns off 5 minutes after the door has closed. It will be reactivated when the door has opened or pressed on any key.

•Due to temperature change as a result of opening/closing the product door during operation, condensation on the door/body shelves and the glass containers is normal

	12 / 22 EN	Refrigerator/User Manual

5 Operating the product

Indicator panel

1

2

3

4

5

6

14

13

12

11

10

9

8

7

1.On/Off Indicator:

This icon ( ) come on when the freezer is turned off. All the other icons turn off.

2.Economic Usage Indicator:

This icon () (comes on when the Freezer Compartment is set to -18°C which is the most economical set value. Economic Usage Indicator turns off when the Quick Fridge or Quick Freeze function is selected.

3.Freezer Compartment Temperature Setting Indicator:

Indicates the temperature set for the Freezer Compartment.

4.Power failure/High temperature / error warning indicator :

This light () illuminates during power failure, high temperature failures and error warnings. During sustained power failures, the highest temperature that the freezer compartment reaches will flash on the digital display.

5.Eco Extra Indicator:

This icon () lights up when this Function is active.

6.Key Lock Indicator:

This icon ( ) lights up when the Key Lock mode is activated.

Figures in this user manual are schematic and may not match the product C exactly. If the subject parts are not included in the product you have

purchased, then those parts are valid for other models.

Refrigerator/User Manual	13 / 22 EN

Operating the product

7.Key Lock Mode:

Press Key Lock ( ) button continuously for 3 seconds. Key lock icon will light up and key lock mode will be activated. Buttons will not function if the Key Lock mode is active. Press Key Lock button continuously for 3 seconds again. Key lock icon will turn off and the key lock mode will be exite.

8- Alarm off warning:

In case of power failure/high temperature alarm, after checking the food located in the freezer compartment

press the alarm off button () to clear the warning.

9.Eco Extra Function:

Press the Eco Extra button () for 3 seconds to activate Eco Extra Function when going on holday for instance. Freezer will start operating in the most economic mode at around 6 hours later and the economic usage indicator will turn on when the function is active.

10.Freezer Set Function:

This function ( ) allows you to change the Freezer compartment temperature setting. Press this button to set the temperature of the freezer compartment to -18, -19, -20, -21, -22, -23 and -24, respectively.

11.Quick Freeze Function:

Quick Freeze indicator ( ) turns on when the Quick Freeze function is on. Press Quick Freeze button again to cancel this function. Quick Freeze indicator will turn off and normal settings will be resumed.

Quick Freeze function will be cancelled automatically 3-4 hours later if you do not cancel it manually. If you want to freeze plenty amount food, press Quick Freeze button before you place the food into the freezer compartment.

12.On/Off Function:

This function ( ) allows you to make the Fridge turn off when pressed for 3 seconds.The fridge could be turned on by pressing On/Off button for 3 seconds again .

13.Energy Saving Indicator :

If the product doors are kept closed for a long time energy saving function is automatically activated and energy saving symbol is illuminated. ( )

When energy saving function is activated, all symbols on the display other than energy saving symbol will turn off. When the Energy Saving function is activated, if any button is pressed or the door is opened, energy saving function will be canceled and the symbols on display will return to normal.

Energy saving function is activated during delivery from factory and cannot be canceled.

14.Quick Freeze Indicator :

This icon ( ) comes on when the Quick Freeze function is on.

	14 / 22 EN	Refrigerator/User Manual

Operating the product

5.1. Freezing fresh food

• In order to preserve the quality of the food, it shall be frozen as quickly as possible when it is placed in the freezer compartment, use the fast freezing feature for this purpose.

• You may store the food longer in freezer compartment when you freeze them while they are fresh.

• Pack the food to be frozen and close the packing so that it would not allow entrance of air.

• Ensure that you pack your food before putting them in the freezer. Use freezer containers, foils and moisture-proof papers, plastic bags and other packing materials instead of traditional packing papers.

• Label each pack of food by adding the date before freezing. You may distinguish the freshness of each food pack in this way when you open your freezer each time. Store the food frozen before in the front side of compartment to ensure that they are used first.

CThe freezer compartment defrosts automatically.

•Frozen food must be used immediately after they are thawed and they should not be re-frozen.

•Do not freeze too large quantities of food at one time.

Refrigerator/User Manual	15 / 22 EN

Operating the product

	Freezer	Fridge
	Compartment	compartment	Remarks
	Setting	Setting
	-18°C	4°C	This is the normal recommended setting.
	-20,-22 or -24°C	4°C	These settings are recommended when the
			ambient temperature exceeds 30°C.
			Use when you wish to freeze your food in a short
	Quick Freeze	4°C	time. Your product will return to its previous
			mode when the process is over.
			Use these settings if you think that your fridge
	-18°C or colder	2°C	compartment is not cold enough because of the
			hot ambient conditions or frequent opening and
			closing of the door.

5.2. Recommendations for preserving the frozen food

Compartment shall be set to -18°C at least.

1.Put packages in the freezer as quickly as possible after purchase without allowing the to thaw.

2.Check whether the "Use By" and "Best Before" dates on the packaging are expired or not before freezing it.

3.Ensure that the package of the food is not damaged.

5.3.Deep-freeze information

According to IEC 62552 standards, the product shall freeze at least 4.5 kg of food at 32°C ambient temperature to -18°C or lower within 24 hours for every 100-litres of freezer volume.

It is possible to preserve the food for a long time only at -18°C or lower temperatures.

You can keep the freshness of food for many months (at -18°C or lower temperatures in the deep freeze).

Foods to be frozen should not be allowed to come in contact with the previously frozen items to prevent them from getting thawed partially.

Boil the vegetables and drain their water in order to store vegetables for a longer time as frozen. After draining their water, put them in air-proof packages and place them inside the freezer. Food such as bananas, tomatoes, lettuce, celery, boiled eggs, potatoes are not suitable for freezing. When these foods are frozen, only their nutritional value and taste shall be affected negatively. They shall not be spoiled so that they would create a risk for human health.

	16 / 22 EN	Refrigerator/User Manual

Operating the product

5.4. Placing the food

	Freezer	Various frozen food
		such as meat, fish,
	compartment
		ice cream, vegetables
	shelves
		and etc.
	Refrigerator	Food in pans, covered
		plates and closed
	compartment
		containers, eggs (in
	shelves
		closed container)
	Door shelves	Small and packaged
	of fridge
		food or beverage
	compartment
	Crisper	Vegetables and fruits
		Delicatessen
	Fresh zone	(breakfast food,
		meat products that
	compartment
		shall be consumed in
		a short time)

5.5. Door open warning

(This feature is optional)

An audio warning signal will be given when the door of your product is left open for at least 1 minute. This warning will be muted when the door is closed or any of the display buttons (if any) are pressed.

Door open warning is given to user both visually and acoustically. If the warning continues for 10 minutes, interior lights will be turned off.

5.6. Changing the door opening direction

Door opening direction of your refrigerator can be changed according to the place you are using it.If this is necessary, please call your nearest Authorized Service.

Above description is a general expression.For information on changing the opening direction of the door, you must refer to the warning label located on the inner side of the door.

Refrigerator/User Manual	17 / 22 EN

WARNING: Unplug the product before cleaning it.

6 Maintenance and cleaning

Cleaning your fridge at regular intervals will extend the service life of the

product.

B

•Never use gasoline, benzene or similar substances for cleaning purposes.

•Never use any sharp and abrasive tools, soap, household cleaners, detergent and wax polish for cleaning.

•Dissolve one teaspoon of bicarbonate in half litre of water. Soak a cloth with the solution and wrung it thoroughly. Wipe the interior of the refrigerator with this cloth and the dry thoroughly.

•Make sure that no water enters the lamp housing and other electrical items.

•If you will not use the refrigerator for a long period of time, unplug it, remove all food inside, clean it and leave the door ajar.

•Check regularly that the door gaskets are clean. If not, clean them.

•To remove door and body shelves, remove all of its contents.

•Remove the door shelves by pulling them up. After cleaning, slide them from top to bottom to install.

•Never use cleaning agents or water that contain chlorine to clean the outer surfaces and chromium coated parts of the product. Chlorine causes corrosion on such metal surfaces.

6.1. Avoiding bad odours

Materials that may cause odour are not used in the production of our refrigerators. However, due to

inappropriate food preserving conditions and not cleaning the inner surface of the refrigerator as required can bring forth the problem of odour. Pay attention to following to avoid this problem:

•Keeping the refrigerator clean is important. Food residuals, stains, etc. can cause odour. Therefore, clean the refrigerator with bi-carbonate dissolved in water every few months. Never use detergents or soap.

•Keep the food in closed containers. Microorganisms spreading out from uncovered containers can cause unpleasant odours.

•Never keep the food that have passed best before dates and spoiled in the refrigerator.

6.2. Protecting the plastic surfaces

Do not put liquid oils or oil-cooked meals in your refrigerator in unsealed containers as they damage the plastic surfaces of the refrigerator. If oil is spilled or smeared onto the plastic surfaces, clean and rinse the relevant part of the surface at once with warm water.

	18 / 22 EN	Refrigerator/User Manual

7 Troubleshooting

Check this list before contacting the service. Doing so will save you time and money. This list includes frequent complaints that are not related to faulty workmanship or materials. Certain features mentioned herein may not apply to your product.

The refrigerator is not working.

•The power plug is not fully settled. >>> Plug it in to settle completely into the socket.

•The fuse connected to the socket powering the product or the main fuse is blown. >>> Check the fuses.

Condensation on the side wall of the cooler compartment (MULTI ZONE, COOL, CONTROL and FLEXI ZONE).

•The environment is too cold. >> Do not install the product in environments with temperatures below -5°C.

•The door is opened too frequently >>> Take care not to open the product’s door too frequently.

•The environment is too humid. >>> Do not install the product in humid environments.

•Foods containing liquids are kept in unsealed holders. >>> Keep the foods containing liquids in sealed holders.

•The product’s door is left open. >>> Do not keep the product’s door open for long periods.

•The thermostat is set to too low temperature. >>> Set the thermostat to appropriate temperature.

Compressor is not working.

•In case of sudden power failure or pulling the power plug off and putting back on, the gas pressure in the product’s cooling system is not balanced, which triggers the compressor thermic safeguard. The product will restart after approximately 6 minutes. If the product does not restart after this period, contact the service.

•Defrosting is active. >>> This is normal for a fully-automatic defrosting product. The defrosting is carried out periodically.

•The product is not plugged in. >>> Make sure the power cord is plugged in.

•The temperature setting is incorrect. >>> Select the appropriate temperature setting.

•The power is out. >>> The product will continue to operate normally once the power is restored.

The refrigerator's operating noise is increasing while in use.

•The product’s operating performance may vary depending on the ambient temperature variations. This is normal and not a malfunction.

Refrigerator/User Manual	19 / 22 EN

Troubleshooting

The refrigerator runs too often or for too long.

•The new product may be larger than the previous one. Larger products will run for longer periods.

•The room temperature may be high. >>> The product will normally run for long periods in higher room temperature.

•The product may have been recently plugged in or a new food item is placed inside. >>> The product will take longer to reach the set temperature when recently plugged in or a new food item is placed inside. This is normal

•Large quantities of hot food may have been recently placed into the product.

>>> Do not place hot food into the product.

•The doors were opened frequently or kept open for long periods. >>> The warm air moving inside will cause the product to run longer. Do not open the doors too frequently.

•The freezer or cooler door may be ajar. >>> Check that the doors are fully closed.

•The product may be set to temperature too low. >>> Set the temperature to a higher degree and wait for the product to reach the adjusted temperature.

•The cooler or freezer door washer may be dirty, worn out, broken or not properly settled. >>> Clean or replace the washer. Damaged / torn door washer will cause the product to run for longer periods to preserve the current temperature.

The freezer temperature is very low, but the cooler temperature is adequate.

•The freezer compartment temperature is set to a very low degree. >>> Set the freezer compartment temperature to a higher degree and check again.

The cooler temperature is very low, but the freezer temperature is adequate.

•The cooler compartment temperature is set to a very low degree. >>> Set the freezer compartment temperature to a higher degree and check again.

The food items kept in cooler compartment drawers are frozen.

•The cooler compartment temperature is set to a very low degree. >>> Set the freezer compartment temperature to a higher degree and check again.

	20 / 22 EN	Refrigerator/User Manual

Troubleshooting

The temperature in the cooler or the freezer is too high.

•The cooler compartment temperature is set to a very high degree. >>> Cooler compartment temperature setting has an effect on the freezer compartment temperature. Change the temperature of the cooler or freezer compartment and wait until the temperature of the related compartments come to the adequate level.

•The doors were opened frequently or kept open for long periods. >>> Do not open the doors too frequently.

•The door may be ajar. >>> Fully close the door.

•The product may have been recently plugged in or a new food item is placed inside. >>> This is normal. The product will take longer to reach the set temperature when recently plugged in or a new food item is placed inside.

•Large quantities of hot food may have been recently placed into the product.

>>> Do not place hot food into the product.

Shaking or noise.

•The ground is not level or durable. >>> If the product is shaking when moved slowly, adjust the stands to balance the product. Also make sure the ground is sufficiently durable to bear the product.

•Any items placed on the product may cause noise. >>> Remove any items placed on the product.

The product is making noise of liquid flowing, spraying etc.

•The product’s operating principles involve liquid and gas flows. >>> This is normal and not a malfunction.

There is sound of wind blowing coming from the product.

•The product uses a fan for the cooling process. This is normal and not a malfunction.

There is condensation on the product's internal walls.

•Hot or humid weather will increase icing and condensation. This is normal and not a malfunction.

•The doors were opened frequently or kept open for long periods. >>> Do not open the doors too frequently; if open, close the door.

•The door may be ajar. >>> Fully close the door.

There is condensation on the product's exterior or between the doors.

•The ambient weather may be humid, this is quite normal in humid weather. >>>

The condensation will dissipate when the humidity is reduced.

Refrigerator/User Manual	21 / 22 EN

Troubleshooting

The interior smells bad.

•The product is not cleaned regularly. >>> Clean the interior regularly using sponge, warm water and carbonated water.

•Certain holders and packaging materials may cause odour. >>> Use holders and packaging materials without free of odour.

•The foods were placed in unsealed holders. >>> Keep the foods in sealed holders. Microorganisms may spread out of unsealed food items and cause malodour.

•Remove any expired or spoilt foods from the product.

The door is not closing.

•Food packages may be blocking the door. >>> Relocate any items blocking the doors.

•The product is not standing in full upright position on the ground. >>> Adjust the stands to balance the product.

•The ground is not level or durable. >>> Make sure the ground is level and sufficiently durable to bear the product.

The vegetable bin is jammed.

•The food items may be in contact with the upper section of the drawer. >>>

Reorganize the food items in the drawer.

AWARNING: If the problem persists after following the instructions in this section, contact your vendor or an Authorized Service. Do not try to repair the product.

	22 / 22 EN	Refrigerator/User Manual

Kühlschrank/ Gefrierschrank

Bedienungsanleitung

DE

Sehr geehrter Kunde,

Wir möchten Ihnen eine optimale Effizienz Ihres Produkts bieten, welches in modernen Betrieben mit akribischen Qualitätskontrollen hergestellt wurde.

Hierzu bitten wir Sie die Bedienungsanleitung vollständig und gründlich durchzulesen und das Handbuch als Referenzquelle aufzubewahren. Wenn Sie das Produkt wiederum an eine andere Person weitergeben, geben Sie auch dieses Handbuch zusammen mit dem Produkt weiter.

Das Benutzerhandbuch gewährleistet die schnelle und sichere Anwendung des Produkts.

•Vor der Installation und Anwendung des Produkts, lesen Sie bitte diese Bedienungsanleitung sorgfältig durch.

•Beachten Sie auf alle Fälle die Anleitung im Zusammenhang mit der Sicherheit.

•Da Sie diese Bedienungsanleitung auch in der Zukunft benötigen werden, sollte es leicht zugänglich aufbewahrt werden.

•Lesen Sie auch die, mit dem Produkt mitgelieferten, sonstigen Belege durch.

Beachten Sie, dass diese Anleitung für mehrere Produktmodelle anwendbar ist. Differenzen zwischen den Modellen sind eindeutig aufgeführt.

Symbole und Erläuterungen

In dieser Bedienungsanleitung befinden sich folgende Symbole:

C Wichtige Informationen

oder hilfreiche Tipps.

A Risiken für Gesundheit und

Produkt.

B Stromschlagrisiko.

Verpackung des Produktes, produziert

aus wiederverwertbarem Materialien entsprechend der nationalen Umweltschutzgesetze.

1Sicherheitsund
Umweltschutzanweisungen	3
Allgemeine Sicherheit................................	3
Verwendungszweck.....................................	7
Kindersicherheit.............................................	7
Einhaltung der WEEE-Richtlinie und
Entsorgung des Altprodukts....................	8
Einhaltung der RoHS-Richtlinie..............	8
Verpackungsinformation...........................	8
2 Ihr Kühlschrank/
Gefrierschrank	9
3 Installation10
Wenn Sie den Kühlschrank versetzen
möchten:.........................................................	10
Vor dem Einschalten..................................	10
Elektrischer Anschluss.............................	10
Verpackungsmaterialien entsorgen....	11
Altgeräte entsorgen...................................	11
Aufstellung und Installation....................	11
Füße einstellen............................................	12

4 Vorbereitung	13
Anzeigefeld...................................................	14
5 Nutzung des Kühlschrank/
Gefrierschranks	14
Doppeltes Kühlsystem..............................	16
Frische Lebensmittel tiefkühlen..........	16
Empfehlungen zur Konservierung
gefrorener Lebensmittel.........................	17
Lebensmittel platzieren...........................	17
Hinweise zum Tiefkühlen........................	18
Tür-offen-Warnung...................................	18
Wechseln des Türanschlags...................	18
6 Pflege und Reinigung	19
7 Problemlösung	20

	2 / 23 DE	Kühlschrank/Bedienungsanleitung

1 Sicherheitsund Umweltschutzanweisungen

Dieses Kapitel beinhaltet die Sicherheitshinweise, um VerletzungsgefahrundmaterielleSchädenzuvermeiden. Bei Nichtbeachtung dieser Hinweise erlischt sämtliche Garantieleistung des Geräts.

1.1. Allgemeine Sicherheit

•Dieses Gerät darf nicht von Personen mit eingeschränkten physischen, sensorischen oder geistigen Fähigkeiten bedient werden. Die

Bedienung dieses Geräts ist nur geeignet falls sie von einer verantwortlichen Person gründlich in die Bedienung des Gerätes eingewiesen wurden. Das Spielen von Kindern mit diesem Gerät ist nicht erlaubt.

•Falls während des Betriebs eine Störung auftritt, ziehen Sie das Gerät vom Netzstecker.

•Nachdem Sie den Netzstecker herausgezogen haben, warten Sie mindestens 5 Minuten bevor Sie es erneut einstecken. Ziehen Sie den Netzstecker aus, wenn das Produkt nicht in Betrieb ist. Den Stecker auf keinen Fall mit nassen Händen berühren! Ziehen Sie niemals am Netzkabel – ziehen Sie direkt am Stecker.

•Beim Einstecken des Netzsteckers in die Steckdose, das Ende des Steckers mit einem trockenen Tuch wischen.

•Sollte die Steckdose lose sein, den Stecker des Kühlschranks nicht einstecken.

•Während der Installation, Wartung oder Reparatur den Netzstecker aus der Steckdose ziehen.

Kühlschrank/Bedienungsanleitung	3 / 23 DE

Sicherheitsund Umweltschutzanweisungen

•Falls Sie das Gerät für eine gewisse Dauer nicht benutzen werden, ziehen Sie es aus dem Netzstecker und entleeren Sie den Innenraum.

•Verwenden Sie niemals Dampfoder Sprühreiniger zum Reinigen und Abtauen Ihres Kühlschranks. Die Dämpfe oder Nebel können in Kontakt mit stromführenden Teilen geraten und Kurzschlüsse oder Stromschläge auslösen!

•Spritzen oder schütten Sie aus Sicherheitsgründen kein Wasser direkt auf oder in den Kühlschrank! Es besteht Stromschlaggefahr!

•Benutzen Sie das Gerät niemals, wenn die sich auf der Oberseite bzw. auf der Rückseite befindlichen Bereiche mit den elektronischen Leitern im Inneren geöffnet sind (Abdeckung der elektronischen Leiterplatten) (1).

1	1

•Das Gerät sollte bei Störungen auf keinen Fall betrieben werden, da eine Stromschlaggefahr besteht. Führen Sie nichts durch, bevor Sie mit dem Kundendienst Kontakt aufgenommen haben.

•Schließen Sie das Produkt an eine geerdete Steckdose an. Die Erdung muss durch einen Fachmann durchgeführt werden.

	4 / 23 DE	Kühlschrank/Bedienungsanleitung

Sicherheitsund Umweltschutzanweisungen

•Falls in Ihrem Produkt eine LED Beleuchtung vorhanden ist, wenden Sie sich beim Ersetzen oder bei einer Störung an den Kundendienst.

•Berühren Sie gefrorene Lebensmittel nicht mit der Hand! Sie könnten festfrieren!

•Legen Sie keine flüssigen Getränke in Flaschen oder Dosen in das Gefrierfach. Sie könnten platzen!

•Stellen Sie Getränke fest verschlossen und im senkrechten Zustand ab.

•Sprühen Sie keine entflammbaren Stoffe, in der Nähe des Kühlschranks, da eine Feuerund Explosionsgefahr besteht.

•Lagern Sie keine Produkte die entflammbar sind oder entflammbare Gase beinhalten (Spräydosen u. Ä.) oder explosive Stoffe in Ihrem Kühlschrank.

•Stellen Sie keine mit Flüssigkeit gefüllten Objekte auf den Kühlschrank. Bei elektrischen Geräten kann ein Wasserspritzer zu einem Kurzschluss oder zu einem Brand führen.

•Setzen Sie das Gerät keinem Regen, Schnee, direktem Sonnenlicht oder Wind aus, da dies die elektrische Sicherheit. Der Türgriff könnte sich lösen.

•Achten Sie darauf an den beweglichen Teilen im Innenraum des Geräts nicht Ihre Hände oder sonstige Teile Ihres Körper einzuklemmen.

•Verwenden Sie niemals die Türen und Fächer des Kühlschranks als Stützen oder Stufen. Dies würde zum Umkippen des Geräts oder zu Schäden an den

Kühlschrank/Bedienungsanleitung	5 / 23 DE

Sicherheitsund Umweltschutzanweisungen

Bestandteilen führen.

•Achten Sie darauf, dass das Netzkabel nicht zerquetscht wird.

1.1.1 HC Hinweis

Sofern Ihr Gerät mit dem Kühlmittel R600a arbeitet, achten Sie also darauf, Kühlkreislauf und Leitungen während Betrieb und Transport nicht zu beschädigen. Dieses Gas ist entflammbar. Bei Beschädigungen halten Sie das Produkt von potenziellen Zündquellen fern und sorgen Sie für eine gute Belüftung des Raumes, in dem das Gerät aufgestellt wurde.

Das Typenschild links im Innenraum informiert C Sie über den in Ihrem Gerät eingesetzten

Kühlmitteltyp.

1.1.2 Für Modelle mit Wasserspender

• Damit der Wasserkreislauf des Kühlschranks reibungslos arbeitet, muss der Druck des Versorgungswassers 1 bis 8 bar betragen. Wenn der Druck des Versorgungswassers 5 bar übersteigt, sollte ein Druckregler verwendet werden. Falls

der Druck der Wasserversorgung 8 bar übersteigt, sollte der Wasserkreislauf des Kühlschranks nicht an die Wasserversorgung angeschlossen werden. Falls Sie nicht wissen, wie Sie den Druck des Versorgungswassers messen, wenden Sie sich bitte an einen Experten.Verwenden Sie nur Trinkwasser.

	6 / 23 DE	Kühlschrank/Bedienungsanleitung
