FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

ACCESSORIES AND CONSUMABLES

In the AEG webshop, you’ll find everything you need to keep all your AEG appliances looking spotless and working perfectly. Along with a wide range of accessories designed and built to the high quality standards you would expect, from specialist cookware to cutlery baskets, from bottle holders to delicate laundry bags…

Visit the webshop at:

www.aeg.com/shop

Contents 3

CONTENTS

4 Safety information

7 Product description

8 Control panel

10 Use of the appliance

10 Setting the water softener

12 Use of dishwasher salt

12 Use of detergent and rinse aid

13 Multitab function

14 Loading cutlery and dishes

17 Washing programmes

18 Select and start a washing programme

20 Care and cleaning

21 What to do if…

24 Technical data

24 Environment concerns

25 Installation

The following symbols are used in this user manual:

Important information concerning your personal safety and information on how to avoid damaging the appliance.

General information and tips

Environmental information

Subject to change without notice

4 Safety information

SAFETY INFORMATION

Before the installation and use, read this manual carefully:

•For your safety and the safety of your property.

•To help the environment.

•For the correct operation of the appliance.

Always keep these instructions with the appliance also if you move or give it to a different person.

The manufacturer is not responsible if an incorrect installation and use causes damage.

Children and vulnerable persons safety

•Do not let persons, children included, with reduced physical sensory, reduced mental functions or lack of experience and knowledge to use the appliance. They must have supervision or instruction for the operation of the appliance by a person who is responsible for their safety.

•Children must get supervision to make sure that they do not play with the appliance.

•Keep all packaging away from children. There is the risk of suffocation or injury.

•Keep all detergents in a safe area. Do not let the children touch the detergents.

•Keep children and pets away from the appliance when the door is open.

General safety

•Do not change the specifications of this appliance. There is the risk of injury and damage to the appliance.

•Obey the safety instructions from the detergent manufacturer to prevent burns to eyes, mouth and throat.

•Do not drink the water from the appliance. Particles of detergent can stay in your appliance.

•Do not keep the appliance door open without supervision. This to prevent injury and to fall on an open door.

•Do not sit or stand on the open door.

Use

•The appliance is only for domestic use. Do not use the appliance for other uses to prevent injury to persons and damage to property.

•Only use the appliance to clean accessories that are applicable for dishwashers.

•Do not put flammable products or items that are wet with flammable products in, near or on the appliance. Risk of explosion or fire.

•Put the knives and all items with sharp points in the cutlery basket with their points down. If not, put in a horizontal position in the upper basket or in the knife basket. (Not all models have the knife basket).

•Use only specified products for dishwashers (detergent, salt, rinse aid).

•Types of salt that are not specified for dishwashers can cause damage to the water softener.

Safety information
	5

•Fill the appliance with salt before you start a washing programme. Remaining salt in the appliance can cause corrosion or make a hole in the bottom of the appliance.

•Do not fill the rinse aid dispenser with other products than the rinse aid, (dishwasher cleaning agent, liquid detergent). This can cause damage to the appliance.

•Make sure that the spray arms can move freely before you start a washing programme.

•The appliance can release hot steam if you open the door while a washing programme operates. There is a risk of skin burns.

•Do not remove the dishes from the appliance until the washing programme is completed.

Care and cleaning

•Before you clean the appliance, deactivate it and disconnect the mains plug from the mains socket.

•Do not use flammable products or products that can cause corrosion.

•Do not use the appliance without the filters. Make sure that the installation of the filters is correct. An incorrect installation causes unsatisfactory washing results and damage to the appliance.

•Do not use spray water or steam to clean the appliance. Risk of electrical shock and damage to the appliance.

Installation

•Make sure that the appliance is not damaged. Do not install or connect a damaged appliance, contact the supplier.

•Remove all packaging before you install and use the appliance.

•Only a qualified person must do the electrical connection, the plumbing and the installation of the appliance. This to prevent the risks of structural damage or injury.

•Make sure that the mains plug is disconnected from the mains socket during installation.

•Do not drill into the sides of the appliance to prevent damage to hydraulic components and electrical components.

Frost precautions

•Do not install the appliance where the temperature is less than 0 °C.

•The manufacturer is not responsible for frost damage.

Water connection

•Use new hoses to connect the appliance to the water supply. Do not use used hoses.

•Do not connect the appliance to new pipes or pipes not used for a long time. Let the water flow for some minutes, then connect the inlet hose.

•Make sure not to squash or cause damage to the water hoses when you install the appliance.

•Make sure that the water couplings are tight to prevent a water leakage.

•The first time you use the appliance, make sure that the hoses do not have water leaks.

6Safety information

•The water inlet hose has a safety valve and a double sheath with an inner mains cable. There is pressure in the water inlet hose only when the water flows. If there is a leak in the water inlet hose, the safety valve interrupts the flow of water.

–Be careful when you connect the water inlet hose:

–Do not put the water inlet hose or the safety valve in water.

–If the water inlet hose or the safety valve are damaged, immediately disconnect the mains plug from the mains socket.

–Contact the service centre to replace the water inlet hose with safety valve.

WARNING!

Dangerous voltage.

Electrical connection

•The appliance must be earthed.

•Make sure that the electrical information on the rating plate agrees with the power supply.

•Always use a correctly installed shockproof socket.

•Do not use multiple plugs and extension cables. There is a risk of fire.

•Do not replace or change the mains cable. Contact the service centre.

•Make sure not to squash or cause damage to the mains plug and cable behind the appliance.

•Make sure that there is access to the mains plug after the installation.

•Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.

Service centre

•Only a qualified person can repair or work on the appliance. Contact the service centre.

•Use only original spare parts.

To discard the appliance

•To prevent the risk of injury or damage:

–Disconnect the mains plug from the mains socket.

–Cut off the mains cable and discard it.

Product description
	7

–Remove the door catch. This prevents children or pets to be closed in the appliance. There is a risk of suffocation.

–Discard the appliance at the local waste disposal centre.

WARNING!

The dishwasher detergents are dangerous and can cause corrosion !

•If an accident occurs with these detergents, contact immediately a physician.

•If the detergent gets into the mouth, contact immediately a physician.

•If the detergent gets into the eyes, contact immediately a physician and clean the eyes with water.

•Keep dishwasher detergents in a safe area and out of children touch.

•Do not keep the appliance door open when there is detergent in the detergent dispenser.

•Fill the detergent dispenser only before you start a washing programme.

PRODUCT DESCRIPTION

1Upper basket

2Water hardness dial

3Salt container

4Detergent dispenser

5Rinse aid dispenser

6Rating plate

7Filters

8Lower spray arm

9Upper spray arm

8 Control panel

10 Worktop

CONTROL PANEL

5

1						2									3				4

A B C D E

6

1On/off button

2Programme selection buttons

3Delay start button

4Indicator lights

5Display

6Function buttons

		Indicator lights
Programme-in-progress		• It comes on when you select a washing programme.
		• It stays on for all the duration of the washing programme.
Multitab		It comes on when you activate the multitab function. Refer to 'Multi-
		tab function'.
Salt 1)		It comes on when it is necessary to fill the salt container. Refer to 'Use
		of dishwasher salt'.
		After you fill the container, the salt indicator light can stay on for some
		hours. This does not have an unwanted effect on the operation of the
		appliance.

			Control panel
				9
			Indicator lights
	Rinse aid 1)		It comes on when it is necessary to fill the rinse aid container. Refer to
			'Use of detergent and rinse aid'.

1)When the salt and/or rinse aid containers are empty, the related indicator lights do not come on while a washing programme operates.

Programme buttons

Press one of these buttons to set a washing programme. The related indicator comes on. Refer to 'Washing programmes'.

Delay start button

Use this button to delay the start of the washing programme with an interval between 1 and 19 hours. Refer to 'Select and start a washing programme'.

Display

The display shows:

•The electronic adjustment of the level of the water softener.

•Activation/deactivation of the rinse aid dispenser (only with multitab function on).

•The washing programme duration.

•Remaining time to the end of the washing programme.

•The end of a washing programme. The display shows a zero.

•Remaining time to the end of the delay start.

•Fault codes.

Function buttons

Use the function buttons for these operations:

•To adjust electronically the level of the water softener. Refer to 'Setting the water softener'.

•To activate/deactivate the multitab function. Refer to 'Multitab function'.

•To activate/deactivate the rinse aid dispenser when the multitab function is on. Refer to 'What to do if...'.

•To cancel the washing programme in progress or a delay start in progress. Refer to 'Select and start a washing programme'.

Setting mode

The appliance must be in setting mode for these operations:

•To select and start a washing programme and/or a delay start.

•To adjust electronically the level of the water softener.

•To activate/deactivate the multitab function.

•To activate/deactivate the rinse aid dispenser.

Press the on/off button. The appliance is in setting mode when:

– All the programme indicator lights come on.

10 Use of the appliance

Press the on/off button. The appliance is not in setting mode when:

–Only one programme indicator light comes on.

–The display shows the duration of a washing programme or a delay start.

–It is necessary to cancel the programme or the delay start to go back to the setting mode. Refer to 'Select and start a washing programme'.

USE OF THE APPLIANCE

1.Be sure that the set level of the water softener agrees with the water hardness in your area. If not, adjust the water softener.

2.Fill the salt container with dishwasher salt.

3.Fill the rinse aid dispenser with rinse aid.

4.Load cutlery and dishes into the appliance.

5.Set the correct washing programme for the type of load and soil.

6.Fill the detergent dispenser with the correct quantity of detergent.

7.Start the washing programme.

If you use the combi detergent tablets ('3 in 1', '4 in 1', '5 in 1'), use the multitab function (refer to 'Multitab function').

SETTING THE WATER SOFTENER

The water softener removes minerals and salts from the water supply. These minerals and salts can cause damage to the appliance.

Adjust the level of the water softener if this does not agree with the water hardness in your area.

Contact your local water authority to know the water hardness in your area.

	Water hardness							Water hardness ad-
								justment
German degrees	French degrees			mmol/l		Clarke de-		manually		elec-
(°dH)	(TH°)					grees				tronical-
										ly
51 - 70	91 - 125			9,1 - 12,5		64 - 88		2 1)		10
43 - 50	76 - 90			7,6 - 9,0		53 - 63		2 1)		9
37 - 42	65 - 75			6,5 - 7,5		46 - 52		21)		8
29 - 36	51 - 64			5,1 - 6,4		36 - 45		21)		7
23 - 28	40 - 50			4,0 - 5,0		28 - 35		21)		6
19 - 22	33 - 39			3,3 - 3,9		23 - 27		21)		51)
15 - 18	26 - 32			2,6 - 3,2		18 - 22		1		4
11 - 14	19 - 25			1,9 - 2,5		13 - 17		1		3

Setting the water softener

11

Water hardness

Water hardness ad-

justment

German degrees

French degrees

mmol/l

Clarke de-

manually

elec-

(°dH)

(TH°)

grees

tronical-

ly

4 - 10

7 - 18

0,7 - 1,8

5 - 12

1

2

< 4

< 7

< 0,7

< 5

12)

12)

1)Factory position.

2)Do not use salt at this level.

You must adjust the water softener manually and electronically.

Manual adjustment

Turn the water hardness dial to the position 1 or 2 (refer to the table).

Electronic adjustment

1.Switch on the appliance.

2.Make sure that the appliance is in setting mode.

3.Press and hold function buttons B and C until the indicator lights of function buttons A, B and C start to flash.

4.Release function buttons B and C.

5.Press function button A.

–The indicator lights for function buttons B and C go off.

–The indicator light for function button A continues to flash.

–The display shows the current adjustment.

Example: the display shows = level 5.

6.Press the function button A again and again until the display shows the necessary adjustment.

7.Press the on/off button to keep the operation.

If the water softener is set electronically to the level 1, the salt indicator light stays off.

12 Use of dishwasher salt

USE OF DISHWASHER SALT

How to fill the salt container

1. Turn the cap counterclockwise and open the salt container.

2. Fill the salt container with 1 litre of water (only for the first time you fill with salt).

3. Use the funnel to fill the salt container with salt.

4. Remove the salt around the opening of the salt container.

5. Turn the cap clockwise to close the salt container.

It is correct that water comes out from the salt container when you fill it with salt.

USE OF DETERGENT AND RINSE AID

4 5 6

8

7

Use of detergent

To help the environment, do not use more than the correct quantity of detergent. Follow the detergent manufacturer recommendations on the detergent packaging.

Do these steps to fill the detergent dispenser:

1. Press the release button 2 to open the lid 8 of the detergent dispenser.

2.Put the detergent in the dispenser 3 .

3.If the washing programme has a prewash phase, put a small quantity of detergent in the prewash detergent compartment 1 .

4.If you use the detergent tablets, put the tablet in the detergent dispenser .

Multitab function
	13

5. Close the detergent dispenser. Press the lid until it locks into position.

Different brands of detergent dissolve in different times. Some detergent tablets do not have the best cleaning results during short washing programmes. Use long washing programmes when you use the detergent tablets to fully remove the detergent.

Use of rinse aid

Rinse aid makes it possible to dry the dishes without streaks and stains.

The rinse aid dispenser automatically adds rinse aid during the last rinsing phase.

Do these steps to fill the rinse aid dispenser:

1. Press the release button 5 to open the lid 7 of the rinse aid dispenser.

2.Fill the rinse aid dispenser 4 with rinse aid. The mark 'max' shows the maximum level.

3.Remove the spilled rinse aid with an absorbent cloth to prevent too much foam during the washing programme.

4.Close the rinse aid dispenser. Press the lid until it locks into position.

Adjust the rinse aid dosage

Factory set: position 4.

You can set the rinse aid dosage between position 1 (lowest dosage) and position 6 (highest dosage).

Turn the rinse aid selector 6 to increase or decrease the dosage.

MULTITAB FUNCTION

The multitab function is for combi detergent tablets.

These tablets contain agents as detergent, rinse aid and dishwasher salt. Some types of tablets can contain other agents.

Be sure that these tablets are applicable for the water hardness in your area (refer to the instructions on the packaging of the products).

The multitab function deactivates the flow of rinse aid and salt.

The multitab function deactivates the indicators of salt and rinse aid. The programme duration can increase if you use the multitab function.

Activate or deactivate the multitab function before the start of a washing programme. You cannot activate or deactivate the function when a washing programme operates.

To activate the multitab function

1.Activate the appliance.

2.Make sure that the appliance is in setting mode.

3.Press and hold function buttons (D) and (E) at the same time until the multitab indicator comes on.

4.Release function buttons (D) and (E). The function is activated.

• When you activate the multitab function, it stays on until you deactivate it.

14 Loading cutlery and dishes

To deactivate the multitab function and use separately detergent, salt and rinse aid

1.Activate the appliance.

2.Make sure that the appliance is in setting mode.

3.Press and hold at the same time, function buttons (D) and (E) until the multitab indicator goes on.

4.Release function buttons (D) and (E). The function is deactivated.

5.Fill the salt container and the rinse aid dispenser.

6.Adjust the water hardness to the highest level.

7.Start a washing programme without dishes.

8.When the washing programme is completed, adjust the water softener to the water hardness in your area.

9.Adjust the quantity of rinse aid.

LOADING CUTLERY AND DISHES

Hints and tips

•Do not put in the appliance items that can absorb water (sponges, household cloths).

•Remove the remaining food from the items.

•Make soft the remaining burned food on the items.

•Put hollow items (cups, glasses and pans) with the opening down.

•Make sure that water does not collect in containers or in bowls.

•Make sure that cutlery and dishes do not bond together.

•Make sure that the glasses do not touch other glasses.

•Put small items in the cutlery basket.

•Mix the spoons with other cutlery to prevent them to bond together.

•When you put the items in the baskets, make sure that the water can touch all surfaces.

•Put light items in the upper basket. Make sure that the items do not move.

•Water droplets can collect on plastic items and non-stick pans.

Lower basket

Put the saucepans, lids, plates, salad bowls and cutlery in the lower basket. Put the service dishes and large lids around the edge of the basket.

	Loading cutlery and dishes
								15

The rows of prongs in the lower basket can be flat to load pots, pans and bowls.

The cutlery basket

Put the forks and spoons with the handles down. Put the knives with the handles up.

Mix the spoons with other cutlery to prevent them to bond together.

Use the cutlery grid. If the dimensions of the cutlery prevent use of the cutlery grid, you can easily remove it.

16 Loading cutlery and dishes

Upper basket

The upper basket is for plates (maximum 24 cm in diameter), saucers, salad bowls, cups, glasses, pots and lids. Arrange the items to let water touch all surfaces.

Prevent to put plates in the first three sectors in the front part of the basket. Make sure the plates tilt forward.

Put the glasses with long stems in the cup racks with the stems up. For longer items, fold the cup racks up.

Adjustment of the height of the upper basket

You can put the upper basket in two positions to increase the load flexibility.

Maximum height of the dishes in:

		the upper basket		the lower basket
Higher position		20 cm		31 cm
Lower position		24 cm		27 cm

Do these steps to move the upper basket to the higher position:

	Washing programmes	17
1.	Pull the basket out until it stops.
2.	Carefully lift the two sides until the mech-
	anism is engaged and the basket is stable.
Do these steps to move the upper basket to
the lower position:
1.	Pull the basket out until it stops.
2.	Carefully lift up the two sides.
3.	Hold the mechanism and let it fall back
	down slowly.
CAUTION!
•	Do not lift or lower the basket on one side
	only.

•If the basket is in the upper position, do not put cups on the cup racks.

WASHING PROGRAMMES

Programme				Type of soil		Type of load		Programme description
				All		Crockery, cutlery, pots		Prewash
1)						and pans		Wash 45 °C or 70 °C
								Rinses
								Dry
				Heavy soil		Crockery, cutlery, pots		Prewash
						and pans		Wash 70 °C
								Rinses
								Dry
				Fresh soil		Crockery and cutlery		Wash 60 °C
2)								Rinse
				Normal soil		Crockery and cutlery		Prewash
3)								Wash 50 °C
								Rinses
								Dry
				Use this programme to quickly rinse the				Rinse
				dishes. This prevents the remaining food
				to bond on the dishes and bad odours to
				come out from the appliance.
				Do not use detergent with this pro-
				gramme

1)The appliance senses the type of soil and the quantity of items in the baskets. It automatically adjusts the temperature and quantity of the water, the energy consumption and the programme time.

2)With this programme you can wash a load with fresh soil. It gives good washing results in a short time.

3)This is the standard programme for test institutes. With this programme you have the most efficient use of water and energy consumption for crockery and cutlery with normal soil. Refer to the supplied leaflet for test information.

	Select and start a washing programme
18
	Consumption values
		Programme1)		Energy (kWh)		Water (litre)
				1,1 - 1,8		12 - 23
				1,5 - 1,7		16 - 18
				0,9		9
				1,0 - 1,1		13 - 15
				0,1		4

1) The display shows the programme time.

The water pressure and temperature, the variations of the mains supply and the quantity of dishes can change the consumption values.

SELECT AND START A WASHING PROGRAMME

Select and start a washing programme without delay start

1.Switch on the appliance.

2.Make sure that the appliance is in setting mode.

3.Select a washing programme. Refer to 'Washing programmes'.

–The related programme indicator light comes on.

–All other programme indicator lights go off.

–The programme duration flashes in the display.

–The programme-in-progress indicator light comes on.

4.Close the appliance door. The washing programme starts automatically.

–The programme-in-progress indicator light remains on.

You can select the washing programme also with the door closed. When you press a programme button, you have only 3 seconds to select a different washing programme. After these 3 seconds, the washing programme start automatically.

Select and start a washing programme with delay start

1.Switch on the appliance and select a washing programme.

2.Press the delay start button again and again until the display shows the necessary number of hours for the delay start.

3.Close the appliance door.

–The countdown starts automatically.

–The programme-in-progress indicator light goes off.

–When the countdown is completed, the washing programme starts automatically.

–The programme-in-progress indicator light comes on.

Select and start a washing programme
	19

The opening of the appliance door interrupts the countdown. When you close the door, the countdown continues from the point of interruption.

You can select the delay start also with the door closed. When you select a washing programme, you have only 3 seconds to select the delay start. After these 3 seconds, the washing programme starts automatically.

Interruption of a washing programme

•Open the appliance door.

–The washing programme stops.

•Close the appliance door.

–The washing programme continues from the point of interruption.

How to cancel a washing programme or a delay start

If a washing programme or a delay start has not started, you can change the selection. When a washing programme or a delay start are in progress, it is not possible to change the selection. It is necessary to cancel the washing programme or the delay start to make a new selection.

When you cancel the delay start, this automatically cancels the selected washing programme. You have to select the washing programme again.

1.Press and hold the function buttons B and C until all the programme lights come on

2.Make sure that there is detergent in the detergent dispenser before you start a new washing programme.

End of the washing programme

When the washing programme is completed, the display shows a zero.

•The programme-progress indicator is off.

•The end indicator is on.

1.Deactivate the appliance.

2.Open the appliance door.

For better drying results, keep the appliance door ajar for some minutes.

• If you do not switch off the appliance, after three minutes from the end of the washing programme:

–all indicator lights go off,

–the display shows one horizontal bar, This helps to decrease energy consumption.

Press one of the buttons (not the on/off button), the display and the indicator lights come on again.

20 Care and cleaning

Remove the items from the baskets

•Let the dishes become cold before you remove them from the appliance. Hot dishes can be easily damaged.

•First remove the items from the lower basket, then from the upper basket.

•There can be water on the sides and on the door of the appliance. Stainless steel becomes cool more quickly than the dishes.

CARE AND CLEANING

To remove and clean the filters

Dirty filters decrease the washing results. Make a check at intervals and if necessary, clean them.

The appliance has three filters:

•Coarse filter (A)

•Microfilter (B)

•Flat filter (C).

1.To unlock the filters (A) and (B), turn the handle on the microfilter (B) approximately 1/4 counterclockwise and remove.

2.Hold the coarse filter (A) by the handle and remove it from the microfilter (B).

A

B

C

What to do if… 21

3.Remove the flat filter (C) from the bottom of the appliance.

4.Fully clean the filters with water.

5.Put the flat filter (C) to its initial position. Make sure that it assembles correctly in the two guides (D).

6.Put the coarse filter (A) in the microfilter

(B) and push the filters together.

7.Put the filters (A) and (B) in position. Turn the handle on the microfilter (B) clockwise until it locks in position.

D

To clean the spray arms

Do not remove the spray arms.

If the holes in the spray arms become clogged, remove remaining parts of soil with a thin pointed object.

To clean the external surfaces

Clean the external surfaces of the appliance and control panel with a moist soft cloth. Only use neutral detergents.

Do not use abrasive products, abrasive cleaning pads or solvents (acetone).

WHAT TO DO IF…

The start of the appliance does not occur or it stops during operation.

First try to find a solution to the problem (refer to the table). If not, contact the service centre.

With some malfunctions, the display shows an alarm code:

• - The appliance does not fill with water

• - The appliance does not drain the water

• - The anti-flood device is on.

WARNING!

Deactivate the appliance before you do the checks.

Malfunction		Possible cause	Possible solution
The appliance does not fill with		The water tap is blocked or	Clean the water tap.
water.		there is limescale on it.
		The water pressure is too low.	Contact your local water au-
			thority.
		The water tap is closed.	Open the water tap.
		The filter in the water inlet	Clean the filter.
		hose is blocked.

	What to do if…
22
	Malfunction		Possible cause	Possible solution
			The connection of the water	Make sure that the connection
			inlet hose is not correct.	is correct.
			The water inlet hose is dam-	Make sure that the water inlet
			aged.	hose has no damages.
	The appliance does not drain		There is a blockage in the sink	Clean the sink spigot.
	the water.		spigot.
			The connection of the water	Make sure that the connection
			drain hose is not correct.	is correct.
			The water drain hose is dam-	Make sure that the water drain
			aged.	hose has no damages.
	The anti-flood device is on.			Close the water tap and con-
				tact the service centre.
	The start of the washing pro-		The appliance door is open.	Close the appliance door.
	gramme does not occur.
			The mains plug is not connec-	Connect the mains plug.
			ted in the mains socket.
			The fuse in the fuse box is	Replace the fuse.
			damaged.
			The delay start is set.	• Cancel the delay start.
				• When the countdown is
				completed, the washing pro-
				gramme starts automatical-
				ly.

After the check, activate the appliance. The programme continues from the point of interruption.

If the malfunction occurs again, contact the service centre.

If the display shows other alarm codes, contact the service centre. The necessary information for the service centre is on the rating plate. Record this information:

–Model (MOD.) ........................................................

–Product number (PNC) ..........................................

–Serial number (S.N.) ..............................................

The washing results and drying results are not satisfactory

Problem	Possible cause		Possible solution
The dishes are not clean.	The selected washing pro-		Make sure that the washing
	gramme was not applicable for		programme is applicable for
	the type of load and soil.		the type of load and soil.
	The baskets were not loaded		Load the baskets correctly.
	correctly, water did not touch
	all surfaces.

				What to do if…
						23
	Problem	Possible cause		Possible solution
		The spray arms could not turn		Make sure that an incorrect ar-
		freely because of incorrect ar-		rangement of the load does not
		rangement of the load.		cause a blockage of the spray
				arms.
		The filters are dirty or not as-		Make sure that the filters are
		sembled and installed correctly.		clean and correctly assembled
				and installed.
		The quantity of detergent was		Make sure that the quantity of
		not sufficient or missing.		detergent is sufficient.
	Limescale particles on the	The salt container is empty.		Fill the salt container with dish-
	dishes.			washer salt.
		Incorrect water softener ad-		Adjust the water softener.
		justment
		The salt container cap is not		Make sure that the salt con-
		closed correctly.		tainer cap is closed correctly.
	There are streaks, milky stains,	Rinse aid dosage is too high.		Decrease the rinse aid dosage.
	or a bluish layer on glasses and
	dishes.
	Dry water drop stains on	Rinse aid dosage is too low.		Increase the rinse aid dosage.
	glasses and dishes.
		The detergent can be the		Use a different brand of deter-
		cause.		gent.
	The dishes are wet.	You have set a washing pro-		Let the door stay ajar for some
		gramme without drying phase		minutes before you remove the
		or with a decreased drying		dishes.
		phase.
	The dishes are wet and dull.	The rinse aid dispenser is emp-		Fill the rinse aid dispenser with
		ty.		rinse aid.
		The multitab function is on		Activate the rinse aid dispense.
		(this function automatically
		deactivates the rinse aid dis-
		penser).

How to activate the rinse aid dispenser

1.Switch on the appliance.

2.Make sure that the appliance is in setting mode.

3.Press and hold function buttons B and C.

–The indicator lights for function buttons A, B, and C start to flash.

4.Release function buttons B and C.

5.Press function button B.

–The indicator lights for function buttons A and C go off.

–The indicator light for function button B continues to flash.

24 Technical data

– The display shows the current set.

Rinse aid dispenser deactivated

Rinse aid dispenser activated

6.Press function button B again.

– The display shows the new adjustment.

7.Switch off the appliance to keep the operation.

TECHNICAL DATA

Dimensions		Width	600 mm
		Height	850 mm
		Depth	610 mm
Electrical connection		Voltage	220-240 V
		Overall power	2200 W
		Fuse	10 A
		Frequency	50 Hz
Water supply pressure		min.	0,5 bar (0,05 MPa)
		max.	8 bar (0,8 MPa)
Water supply 1)		Cold water or hot water	max. 60 °C
Capacity		Place settings	12

1) Connect the water inlet hose to a water tap with 3/4" thread.

If the hot water comes from alternative sources of energy, (e.g. solar panels, photovoltaic panels and aeolian), use a hot water supply to decrease energy consumption.

ENVIRONMENT CONCERNS

The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local council, your household waste disposal service or the shop where you purchased the product.

The packaging materials are environmentally friendly and can be recycled. The plastic components are identified by markings, e.g. >PE<, >PS<, etc. Discard the packaging materials in the applicable container at the community waste disposal facilities.

Installation 25

WARNING!

To discard the appliance, follow the procedure:

•Pull the mains plug out of the socket.

•Cut off the mains cable and mains plug and discard them.

•Discard the door catch. This prevents the children to close themselves inside the appliance and endanger their lives.

INSTALLATION

Installation under a counter

Put the appliance adjacent to a water tap and a water drain.

Remove the appliance worktop to install it under a sink unit or a kitchen worktop. Make sure that the dimensions of the recess

agree with the dimensions in the picture.

How to remove the appliance worktop

1.Remove the rear screws (1).

2.Pull the worktop from the behind of the

appliance (2).

26 Installation

3. Lift the worktop and move it from the front slots (3).

4. Use the adjustable feet to adjust the level

of the appliance.

5. Install the appliance under the kitchen worktop. Do not squash or bend the water

hoses during the installation.

To adjust the level of the appliance

A correct level of the appliance lets the door to close and seal correctly.

With an incorrect appliance level, the door does catches on the sides of the cabinet. Loosen or tighten the adjustable feet to make the appliance level.

Water drain connection

Connect the water drain hose to:

•The sink spigot and attach it under the work surface. This prevents that the waste water from the sink goes back into the appliance.

•A stand pipe with vent-hole. The internal di-

ameter must be minimum 4 cm.	max 85 cm
Remove the sink plug when the appliance
drains the water to prevent that the water goes	cm
back into the appliance.		min 40 cm
The drain hose extension must not be longer	400
	max
than 2 m. The internal diameter must not be
smaller than the diameter of the hose.

If you connect the water drain hose to a trap spigot under the sink, remove the plastic membrane

(A). If you do not remove the membrane, remaining food can cause a blockage in the drain hose spigot

A safety device impedes the dirty water to go back into the appliance. If, the spigot of the sink has a 'non-return valve', this can cause the appliance to drain incorrectly. Remove the non-return valve.
