Zoom FIRE-18 User Manual
Operation Manual
Introduction
Thank you for selecting the
AMPLIFIER FIRE-18
Please take the time to read this manual carefully so as to get the most
out of this product and to ensure optimum performance and reliability.
Please keep this manual in a convenient place for future reference.
(simply called the "FIRE-18" in this manual).
ZOOM MODELING GUITAR
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
USAGE AND SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . 2
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Controls and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Input/preamplifier section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
◆
Effect section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
◆
Patch section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
◆
Output/control section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
◆
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Using the FIRE-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Basic operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Using effects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Loading and storing patches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Using the built-in tuner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Switching the mode with the foot switch . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Returning the FIRE-18 to the factory default settings
Drive Types and Effect Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
■
■
■
■
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Patch List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Loading a patch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
◆
Storing a patch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
◆
(all initialize)
DRIVE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
ZNR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
MODULATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
DELAY/REVERB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
. . . . . . . .15
USAGE AND SAFETY PRECAUTIONS
W
W
W
W
W
SAFETY PRECAUTIONS
In this manual, symbols are used to highlight warnings and cautions for you to read so that accidents can
be prevented. The meanings of these symbols are as follows:
This symbol indicates explanations about extremely dangerous
arning
Caution
Please observe the following safety tips and precautions to ensure hazard-free use of the FIRE-18.
• Power requirements
arning
• Environment
arning
matters. If users ignore this symbol and handle the device the wrong
way, serious injury or death could result.
This symbol indicates explanations about dangerous matters. If users
ignore this symbol and handle the device the wrong way, bodily injury
and damage to the equipment could result.
• Connect only to AC power outlets rated 100-120 V or 220-240 V 50/60Hz (depending on the
voltage range of the unit; refer to the back panel).
• Ground the unit by connecting the ground terminal of the power plug to a good external
ground. Do not ground to water pipe, gas pipe, telephone wiring, or lightning arrestor to
prevent the risk of electric shock or explosion.
• During lightning or when not using the unit for an extended time, disconnect the power cord
from the AC outlet.
• Do not pinch the power cord, bend it forcedly, or place heavy objects on the power cord.
Avoid using your FIRE-18 in environments where it will be exposed to:
• Extreme temperatures
• Heat sources such as radiators or stoves.
• High humidity or moisture
• Excessive dust or sand
• Excessive vibration or shock
Keep a minimum distance of 5 cm around the unit for sufficient ventilation.
Do not impede the ventilation openings with objects such as newspapers or curtains.
arning
• Handling
• Never place objects filled with liquids, such as vases, on the FIRE-18 since this can cause
arning
2
ZOOM FIRE-18
USAGE AND SAFETY PRECAUTIONS
W
W
electric shock.
• Do not place naked flame sources, such as lighted candles, on the FIRE-18 since this can cause
fire.
The FIRE-18 is a precision instrument. Do not exert undue pressure on the keys and other
controls. Also take care not to drop the unit, and do not subject it to shock or excessive pressure.
Caution
• Alterations
Never open the case of the FIRE-18 or attempt to modify the product in any way since this can
result in damage to the unit.
arning
• Volume
Do not use the FIRE-18 at a loud volume for a long time since this can cause hearing impairment.
arning
• Connecting cables and input and output jacks
You should always turn off the power to the FIRE-18 and all other equipment before connecting
or disconnecting any cables. Also make sure to disconnect all connection cables and the power
Caution
cord before moving the FIRE-18.
Usage Precautions
• Electrical interference
For safety considerations, the FIRE-18 has been designed to provide maximum protection against the
emission of electromagnetic radiation from inside the device, and protection from external interference.
However, equipment that is very susceptible to interference or that emits powerful electromagnetic waves
should not be placed near the FIRE-18, as the possibility of interference cannot be ruled out entirely.
With any type of digital control device, the FIRE-18 included, electromagnetic interference can cause
malfunctioning and can corrupt or destroy data. Care should be taken to minimize the risk of damage.
• Cleaning
Use a soft, dry cloth to clean the FIRE-18. If necessary, slightly moisten the cloth. Do not use abrasive
cleanser, wax, or solvents (such as paint thinner or cleaning alcohol), since these may dull the finish or
damage the surface.
Please keep this manual in a convenient place for future reference.
© ZOOM Corporation
Reproduction of this manual, in whole or in part, by any means, is prohibited.
ZOOM FIRE-18
3
Features
Features
The FIRE-18 is a guitar amplifier with the following features.
•Versatile guitar amplifier and compact effect sound modeling
The FIRE-18 lets you select from 22 drive (distortion) types which faithfully duplicate the sound
of famous guitar amplifiers and compact effects. The available choices range from vintage amps to
modern sharp distortion, covering every need. With the simple push of a key, you can boost the
sound, prolong sustain, and emphasize the bass or treble range.
• Digital effects ideal for guitar play
The FIRE-18 also incorporates a full range of modulation effects and reverb/delay effects.
• Store amp settings as “patches”
Multiple amplifier and effect settings can be easily stored as user “patches”. This allows you to
instantly call up a desired combination of settings and effects, using the keys on the panel of the
unit or an optional foot switch. A number of preset patches with recommended settings are also
available.
• Built-in auto-chromatic tuner
An easy-to-use auto-chromatic tuner is built right into the unit.
•Versatile input/output configuration
The AUX IN jack makes it easy to connect a CD player, MD player or other source device. The
RECORDING/PHONES jack lets you plug in a pair of headphones or a recorder.
4
ZOOM FIRE-18
Controls and Functions
Controls and Functions
Input/preamplifier section
Patch section Effect section
◆
Input/preamplifier section
This section comprises the input jack and controls for adjusting distortion depth and tone.
(1) (2)
(3) (4) (5)
(7)
(6)
(1) [VARIATION] key
(2) [DRIVE TYPE] knob
Select the simulated amp type and distortion (drive) type.
The [DRIVE TYPE] knob gives access to 11 types, and the [VARIATION] key provides further
variations (vintage/standard). The LED for the currently selected variation lights up.
(3) [GAIN] knob
Adjusts the input gain. Turning this knob up increases distortion depth.
(4) [BASS]/[MIDDLE]/[TREBLE] knobs
This is a 3-band equalizer that allows boost/cut in the low, medium, and high frequency range.
(5) [LEVEL] knob
Adjusts the volume after passing the preamplifier.
(6) [INPUT] jack
Connect the electric guitar here, using a dedicated instrument cable.
(7) [BOOST] key
Setting this key to ON (LED lit) boosts the sound pressure level.
(8)
Output/control section
(9)
(10)
ZOOM FIRE-18
5
Controls and Functions
(8) [SUSTAIN] key
Setting this key to ON (LED lit) produces longer sustain.
(9) [EDGE] key
Setting this key to ON (LED lit) emphasizes the high frequencies.
(10)
[BOTTOM] key
Setting this key to ON (LED lit) emphasizes the low frequencies.
◆
Effect section
This section controls the built-in digital effects. The FIRE-18 provides modulation effects and
delay/reverb effects.
(1)
(2)
(1) [MODULATION] key
Switches the modulation effect on and off.
(2) [DELAY/REVERB] key
Switches the delay/reverb effect on and off.
(3) VALUE [Q]/[W] keys
Serve to change effect settings and values.
◆
Patch section
This section lets you store and recall effect patches. It also serves to operate the built-in tuner and
noise reduction functions.
(3)
(3) (5)(6)
(1)
(2)
(1) [MANUAL] key
(2) [PROGRAM/BANK] key
These keys switch between manual mode, where you use the controls on the front panel to shape
the sound, and program mode where you use settings stored in preprogrammed patches.
When the [MANUAL] key is ON (LED lit), the manual mode is selected. When the [PROGRAM/
BANK] key is ON (LED lit), the program mode is selected. (The default setting at power-on is
manual mode.)
6
(4)
(7)
(8)
ZOOM FIRE-18
Controls and Functions
(3) Display
Shows the number of the currently selected patch, or the value of setting parameters of the FIRE-18.
(4) [Q]/[W] keys
Serve to switch between patches and to adjust ZNR (ZOOM Noise Reduction).
(5) [STORE] key
Stores the current settings as a user patch.
(6) [EXIT] key
Cancels an operation and calls up the number of the currently selected patch onto the display.
(7) [TUNER] key
This key activates the built-in tuner of the FIRE-18.
(8) [ZNR] key
This key turns ZOOM Noise Reduction on or off. (ZNR is ON by default at power-on.)
◆
Output/control section
This section lets you adjust the overall amp volume and connect external devices including a foot switch.
(1)
(2)
(3) (4) (5)
(1) [MASTER] knob
Adjusts the volume.
(2) [POWER] switch
Controls the power on/off status.
(3) FOOT SW jack
A separately available foot switch (ZOOM FS-01) can be connected here, allowing you to toggle
between manual mode and program mode with your foot.
(4) [AUX IN] jack
This is a stereo input that accepts the signal from a CD player or MD player.
(5) [RECORDING/PHONES] jack
This is a stereo output that can be used to connect a recording device or a pair of headphones.
ZOOM FIRE-18
7
Connections
Guitar
Connections
When connecting a multi-effect
device (such as the ZOOM 606
or 707II) between the guitar and
the FIRE-18, set the [DRIVE
TYPE] knob to "PLAIN".
606 or similar effect pedal
To input the signal from a CD player or
other stereo playback device, use a stereo
cable and connect it to the [AUX IN] jack.
The signal input here is mixed internally
with the guitar signal.
CD player or similar
FS-01
To toggle between manual
mode and program mode
with your foot, connect the
separately available foot
switch ZOOM FS-01 here.
To record the output of the FIRE-18,
connect the recording device such as
the ZOOM MRS-1266 to the
[RECORDING/PHONES] jack.
8
To monitor the output of the
FIRE-18 with headphones,
connect the headphone plug to
the [RECORDING/PHONES]
jack. (When a plug is inserted in
this jack, the speaker output is
automatically turned off.)
Power Cord
Headphones
MRS-802 or similar recording device
ZOOM FIRE-18
