OWNER’S MANUAL

Generator

EF4000DE EF5200DE EF6600DE

YG4000D YG5200D YG6600D

YG6600DE

LIT-19626-01-15 7WV-28199-11

AE00002

790-060

INTRODUCTION

Congratulations on your purchase of your new Yamaha. This manual will provide you with a good basic understanding of the operation and maintenance of this machine. If you have any questions regarding the operation or maintenance of your machine, please consult a Yamaha dealer.

PRI-I.D. NUMBER:

MODEL

PRI-I.D. CODE

SERIAL No.

AE00012

IDENTIFICATION NUMBER RECORDS

Record your Primary I.D., and serial numbers in the spaces provided, to assist you in ordering spare parts from a Yamaha dealer. Also record and keep these I.D. numbers in a separate place in case your machine is stolen.

AE00011

MACHINE IDENTIFICATION

The machine serial number is stamped in the location as shown.

NOTE:

The first three digits of these numbers are for model identification; the remaining digits are the unit production number. Keep a record of these numbers for reference when ordering parts from a Yamaha dealer.

AE00022

EF4000DE/EF5200DE/EF6600DE

YG4000D/YG5200D/YG6600D/YG6600DE

OWNER’S MANUAL

1st Edition, August 2003

Any reprinting or unauthorized use

without the written permission of

Yamaha Motor Corporation, U.S.A.

is expressly prohibited.

Printed in Japan.

P/N LIT-19626-01-15

AE00032

w

PLEASE READ AND UNDERSTAND THIS MANUAL COMPLETELY BEFORE OPERATING THE MACHINE.

NOTE:

9 Yamaha continually seeks advance-

ments in product design and quality. Therefore, while this manual contains the most current product information available at the time of printing, there may be minor discrepancies between your engine and this manual. If there is any question concerning this manual, please consult a Yamaha dealer.

9 This manual should be considered a

permanent part of this engine and should remain with this engine when resold.

Particularly important information is distinguished in this manual by the following notations.

-

The Safety Alert Symbol means ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!

w

Failure to follow WARNING instructions could result in severe injury or death the engine operator, a bystander, or a person inspecting or repairing the engine.

cC

A CAUTION indicates special precautions that must be taken to avoid damage to the engine.

NOTE:

A NOTE provides key information to make procedures easier or clearer.

to

AE00041

CONTENTS

LIMITED WARRANTY (EF- AND

EDL-SERIES) ........................................1

LIMITED WARRANTY (EC- AND

YG-SERIES) ..........................................2

LOCATION OF IMPORTANT LABELS.4

SAFETY INFORMATION.......................6

EXHAUST FUMES ARE

POISONOUS ......................................6

FUEL IS HIGHLY FLAMMABLE AND

POISONOUS ......................................6

ENGINE AND MUFFLER MAY

BE HOT ..............................................6

ELECTRIC SHOCK PREVENTION....7

CONNECTION NOTES ......................8

CONNECTION....................................8

EXTENSION CORD NOTES ..............8

CONTROL FUNCTION..........................9

DESCRIPTION ...................................9

CONTROL BOX................................11

OIL WARNING SYSTEM..................13

ENGINE SWITCH.............................13

STARTER SWITCH..........................13

AC SWITCH (N.F.B.) ........................14

ECONOMY IDLE SWITCH ...............14

VOLTAGE ADJUSTER.....................15

G.F.C.I. RECEPTACLE ....................15

PRE-OPERATION CHECK .................16

FUEL.................................................16

ENGINE OIL .....................................17

GROUND (Earth)..............................18

BATTERY .........................................18

OPERATION........................................19

STARTING THE ENGINE.................19

APPLICATION RANGE ....................21

CONNECTION..................................22

STOPPING THE ENGINE ................24

PERIODIC MAINTENANCE ................25

MAINTENANCE CHART ..................25

SPARK PLUG INSPECTION............27

CARBURETOR ADJUSTMENT .......27

ENGINE OIL REPLACEMENT .........28

AIR FILTER ......................................29

FUEL COCK .....................................30

FUEL TANK FILTER.........................30

MUFFLER SCREEN AND SPARK

ARRESTER ......................................31

BATTERY .........................................34

FUSE REPLACEMENT ....................35

G.F.C.I. RECEPTACLE TEST ..........35

TROUBLESHOOTING......................36

STORAGE ...........................................40

DRAIN THE FUEL ............................40

ENGINE ............................................40

BATTERY .........................................41

EXHAUST EMISSION CONTROL

SYSTEM AND COMPONENTS...........42

SPECIFICATIONS ...............................43

DIMENSIONS ...................................43

ENGINE ............................................43

GENERATOR ...................................43

WIRING DIAGRAM

EF4000DE ........................................44

EF5200DE ........................................45

EF6600DE ........................................46

YG4000D ..........................................47

YG5200D ..........................................48

YG6600D ..........................................49

YG6600DE........................................50

BATTERY TRAY INSTALLATION ......51

ENGINE HANGER INSTALLATION ...51

OPTIONAL PARTS INSTALLATION ..51

AE01119

YAMAHA MOTOR CORPORATION U.S.A.

EF- AND EDL-SERIES GENERATOR LIMITED WARRANTY

Yamaha Motor Corporation, U.S.A. hereby warrants that new Yamaha consumer generators purchased from an authorized Yamaha consumer generator dealer in the continental United States will be free from defects in material and workmanship for the period of time stated herein, subject to certain stated limitations.

THE PERIOD OF WARRANTY Any new EFseries or EDL-series Yamaha Generator purchased for private, non-commercial use from an authorized Yamaha consumer generator dealer in the continental United States will be warranted against defects in material or workmanship for a period two (2) years from date of purchase, subject to exclusions noted herein. Any Yamaha non-commercial generator purchased and utilized for commercial or rental applications will be warranted for a period one (1) year from the date of purchase, subject to exclusions noted herein.

DURING THE PERIOD OF WARRANTY any authorized Yamaha consumer generator dealer will, free of charge, repair or replace, at Yamaha’s option, any part adjudged defective by Yamaha due to faulty workmanship or material from the factory. Parts used in warranty repairs will be warranted for the balance of the product’s warranty period. All parts replaced under warranty become property of Yamaha Motor Corporation U.S.A.

GENERAL EXCLUSIONS from this warranty shall include any failures caused by: a. Installation of parts or accessories that are not

qualitatively equivalent to genuine Yamaha

parts. b. Abnormal strain, neglect, or abuse. c. Lack of proper maintenance. d. Accident or collision damage.

SPECIFIC EXCLUSIONS from this warranty shall include parts replaced due to normal wear or routine maintenance.

THE CUSTOMER’S RESPONSIBILITY under this warranty shall be to:

1. Operate and maintain the generator as speci-

fied in the appropriate Owner’s Manual;

2. Give notice to an authorized Yamaha consumer generator dealer of any and all apparent defects within ten (10) days after discovery, and make the unit available at that time for inspection and repairs at such dealer’s place of business.

WARRANTY TRANSFER: To transfer the warranty from the original purchaser to any subsequent purchaser(s), it is imperative that the unit be inspected and registered for warranty by an authorized Yamaha consumer generator dealer. In order for this warranty to remain in effect, this inspection and registration must take place within ten (10) days after transfer. An inspection and registration fee will be charged for this service. In no case will the warranty be extended beyond the original period.

YAMAHA MOTOR CORPORATION, U.S.A. MAKES NO OTHER WARRANTY OF ANY KIND, EXPRESSED OR IMPLIED. ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE WHICH EXCEED THE OBLIGATIONS AND TIME LIMITS STATED IN THIS WARRANTY ARE HEREBY DISCLAIMED BY YAMAHA MOTOR CORPORATION, U.S.A. AND EXCLUDED FROM THIS WARRANTY.

SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. ALSO EXCLUDED FROM THIS WARRANTY ARE ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES INCLUDING LOSS OF USE. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE EXCLUSION MAY NOT APPLY TO YOU.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.

YAMAHA MOTOR CORPORATION, U.S.A.

Post Office Box 6555

Cypress, California 90630

– 1 –

YAMAHA MOTOR CORPORATION U.S.A.

EC- AND YG-SERIES INDUSTRIAL GENERATOR LIMITED WARRANTY

Yamaha Motor Corporation, U.S.A. hereby warrants that new Yamaha EC- and YG-series generators purchased from an authorized Yamaha industrial generator dealer in the continental United States will be free from defects in material and workmanship for the period of time stated herein, subject to certain stated limitations.

THE PERIOD OF WARRANTY for Yamaha ECseries and YG-series generators shall be one (1) year from the date of purchase.

DURING THE PERIOD OF WARRANTY any authorized Yamaha industrial generator dealer will, free of charge, repair or replace, at Yamaha’s option, any part adjudged defective by Yamaha due to faulty workmanship or material from the factory. Parts used in warranty repairs will be warranted for the balance of the product’s warranty period. All parts replaced under warranty become property of Yamaha Motor Corporation U.S.A.

GENERAL EXCLUSIONS from this warranty shall include any failures caused by: a. Installation of parts or accessories that are not

qualitatively equivalent to genuine Yamaha

parts. b. Abnormal strain, neglect, or abuse. c. Lack of proper maintenance. d. Accident or collision damage.

SPECIFIC EXCLUSIONS from this warranty shall include parts replaced due to normal wear or routine maintenance.

THE CUSTOMER’S RESPONSIBILITY under this warranty shall be to:

1. Operate and maintain the diesel generator as

specified in the appropriate Owner’s Manual;

2. Give notice to an authorized Yamaha industri-

al generator dealer of any and all apparent

defects within ten (10) days after discovery,

and make the unit available at that time for

inspection and repairs at such dealer’s place

of business.

WARRANTY TRANSFER: To transfer the warranty from the original purchaser to any subsequent purchaser(s), it is imperative that the unit be inspected and registered for warranty by an authorized Yamaha industrial generator dealer. In order for this warranty to remain in effect, this inspection and registration must take place within ten (10) days after transfer. An inspection and registration fee will be charged for this service. In no case will the warranty be extended beyond the original period.

YAMAHA MOTOR CORPORATION, U.S.A. MAKES NO OTHER WARRANTY OF ANY KIND, EXPRESSED OR IMPLIED. ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE WHICH EXCEED THE OBLIGATIONS AND TIME LIMITS STATED IN THIS WARRANTY ARE HEREBY DISCLAIMED BY YAMAHA MOTOR CORPORATION, U.S.A. AND EXCLUDED FROM THIS WARRANTY.

SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. ALSO EXCLUDED FROM THIS WARRANTY ARE ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES INCLUDING LOSS OF USE. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE EXCLUSION MAY NOT APPLY TO YOU.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.

YAMAHA MOTOR CORPORATION, U.S.A.

Post Office Box 6555

Cypress, California 90630

– 2 –

WARRANTY QUESTIONS AND ANSWERS

Q. What costs are my responsibility during the

warranty period? A. The customer’s responsibility includes all

costs of normal maintenance service, non-

warranty repairs, accident damages, as well

as oil and spark plugs.

Q. What are some examples of “abnormal” strain,

neglect, or abuse? A. These terms are general and overlap each

other in areas. Specific examples include:

Running the machine out of oil; lack of proper

maintenance; operating the machine with a

broken or damaged part which causes anoth-

er part to fail; and so on. If you have any

specific questions on operation or mainte-

nance, please contact your dealer for advice.

Q. Does the warranty cover incidental costs such

as transportation due to a failure? A. No. The warranty is limited to repair of the

machine itself.

Q. May I perform any or all of the recommended

maintenance shown in the Owner’s Manual

instead of having the dealer do them? A. Yes, if you are a qualified mechanic and follow

the procedures specified in the Owner’s and

Service Manual. We do recommend, however,

that items requiring special tools or equipment

be done by a Yamaha generator dealer.

Q. Will the warranty be void or cancelled if I do

not operate or maintain my new Yamaha

exactly as specified in the Owner’s Manual? A. No. The warranty on a new Yamaha cannot

be “voided” or “cancelled.”

However, if a particular failure is caused by

operation or maintenance other than as

shown in the Owner’s Manual, that failure

may not be covered under warranty.

Q. What responsibility does my dealer have

under this warranty? A. Each Yamaha generator dealer is expected

to:

1. Check the operation of the generator before sale.

2. Explain the operation, maintenance, and warranty requirements to your satisfaction at the time of sale, and upon your request at any later date.

In addition, each Yamaha generator dealer is held responsible for his setup, service and warranty repair work.

Q. Is the warranty transferable to second own-

ers?

A. Yes. The remainder of the existing warranty

can be transfered upon request.The unit has to be inspected and reregistered by an authorized Yamaha generator dealer for the policy to remain effective.

CUSTOMER SERVICE

If your machine requires warranty service, you must take it to any authorized Yamaha generator dealer within the continental United States. Be sure to bring your warranty registration identification or other valid proof of the original date of purchase. If a question or problem arises regarding warranty, first contact the owner of the dealership. Since all warranty matters are handled at the dealer level, this person is in the best position to help you. If you are still not satisfied and require additional assistance, please write:

YAMAHA MOTOR CORPORATION U.S.A. CUS-

TOMER RELATIONS DEPARTMENT

P.O. BOX 6555

Cypress, California 90630

CHANGE OF ADDRESS

The federal government requires each manufacturer to maintain a complete, up-to-date list of all first purchasers against the possibility of a safetyrelated defect and recall. This list is compiled from the purchase registrations sent to Yamaha Motor Corporation, U.S.A. by the selling dealer at the time of your purchase. If you should move after you have purchased your new generator, please advise us of your new address by sending a postcard listing your Yamaha model name, engine number, dealer number (or dealer’s name) as it is shown on your warranty identification, your name and new mailing address. Mail to:

YAMAHA MOTOR CORPORATION, U.S.A.

WARRANTY DEPARTMENT

P.O. Box 6555

Cypress, California 90630

This will ensure that Yamaha Motor Corporation, U.S.A. has an up-to-date registration record in accordance with federal law.

– 3 –

r

wt

q

e

y

rwtq

y

WARNING

Electrocution Or property damage can occur: Do not connect this generator to any building ’s electrical system unless an isolation switch has been installed by a licensed electrician. Refer to the owner’s manual.

HOT EXHAUST

WARNING

HOT AREA

DO NOT TOUCH

IMPORTANT ENGINE INFORMATION

ENGINE FAMILY :

zzzzzzzzzzzz

E M

REFER TO OWNER'S MANUAL FOR MAINTENANCE SPECIFICATIONS AND ADJUSTMENTS.

THIS ENGINE MEETS

zzzz-zzzz

CALIFORNIA EMISSION REGULATIONS FOR SMALL OFF-ROAD ENGINES.

THIS ENGINE CONFORMS TO PHASE 2 U.S.EPA REGULATIONS FOR SMALL NONROAD ENGINES.

YAMAHA MOTOR CO. LTD

zzz-2179R-zz

DISPLACEMENT

:

VALVE LASH (A)

rpm

NO OTHER ADJUSTMENTS NEEDED.

ENGINE OIL

:

IDLE SPEED

:

FUEL: THIS ENGINE IS CERTIFIED TO OPERATE ON UNLEADED GASOLINE.

IGNITION TIMING & IDLE MIXTURE

zzz

J

IN

:

TYPE

z.zz~z.zz

EX

:

z.zz~z.zz

zzzz

~

zzzz

AT NO LOAD

SESAE 10W-30

EMISSIONS COMPLIANCE PERIOD:CATEGORY A (EPA)

WARNING

READ THE OWNER‘S MANUAL AND ALL LABELS BEFORE OPERATING.

q

AVERTISSEMENT

8

ONLY OPERATE IN WELL-VENTILATED AREA. EXHAUST GAS CONTAINS POISONOUS CARBON MONOXIDE. CHECK FOR SPILLED FUEL OR FUEL LEAKS. STOP ENGINE BEFORE REFUELING. DO NOT OPERATE NEAR FLAMMABLE MATERIALS. ELECTROCUTION CAN OCCUR IF GENERATOR IS USED IN RAIN, SNOW, OR NEAR WATER. KEEP THIS UNIT DRY AT ALL TIMES.

8

8 8

8

MACHINE AU SEC EN TOUTES CIRCONSTANCES.

7NJ-24162-10

8 8 8

8 8

8

LISEZ LE MODE D‘EMPLOI ET TOUTES LES ETIQUETTES AVANT DE FAIRE FONCTIONNER LA MACHINE. FAITES FONCTIONNER UNIQUEMENT DANS DES LIEUX BIEN AERES.

LES GAZ D‘ECHAPPEMENT CONTIENNENT DU MONOXYDE DE CARBONE.

VERIFIEZ SI DU CARBURANT A ETE RENVERSE DU S‘IL FUIT. ARRETEZ LE MOTEUR AVANT DE FAIRE LE PLEIN DE CARBURANT. N‘UTILISEZ PAS A PROXIMITE DE MATERIAUX INFLAMMABLES. IL Y A RISQUE D‘ELECTROCUTION SI LE GENERATEUR FONCTIONNE SOUS LA PLUIE, DANS LA NEIGE, OU PRES DE L‘EAU. GARDEZ LA MACHINE AU SEC EN TOUTES CIRCONSTANCES.

4

0

2

4

6

8

10

ENGINE AIR INDEX

(

California onl

y

)

LEAST CLEAN

MOST CLEAN

NOTE

:

THE LOWER THE AIR INDEX, THE LESS THE POLLUTION

FOR THE FOLLOWING USE:

THIS ENGINE IS CERTIFIED TO BE EMISSION COMPLIANT

MODERATE

INTERMEDIATE

EXTENDED

CHECK OWNERS MANUAL FOR FURTHER DETAILS

THIS LABEL TO BE REMOVED BY TH E ULTIMATE PURCHASER ONLY!

AE00062

LOCATION OF IMPORTANT LABELS (For EF4000DE/YG4000D)

Please read the following labels carefully before operating this machine.

NOTE:

Maintain or replace safety and instruction labels, as necessary.

12

3

5

6

– 4 –

q

e

r

t

792-027a

q

e

w

t

792-028b

WARNING

Electrocution Or property damage can occur: Do not connect this generator to any building ’s electrical system unless an isolation switch has been installed by a licensed electrician. Refer to the owner’s manual.

HOT EXHAUST

IMPORTANT ENGINE INFORMATION

ENGINE FAMILY :

zzzzzzzzzzzz

E M

REFER TO OWNER'S MANUAL FOR MAINTENANCE SPECIFICATIONS AND ADJUSTMENTS.

THIS ENGINE MEETS

zzzz-zzzz

CALIFORNIA EMISSION REGULATIONS FOR SMALL OFF-ROAD ENGINES.

THIS ENGINE CONFORMS TO PHASE 2 U.S.EPA REGULATIONS FOR SMALL NONROAD ENGINES.

YAMAHA MOTOR CO. LTD

zzz-2179R-zz

DISPLACEMENT

:

VALVE LASH (A)

rpm

NO OTHER ADJUSTMENTS NEEDED.

ENGINE OIL

:

IDLE SPEED

:

FUEL: THIS ENGINE IS CERTIFIED TO OPERATE ON UNLEADED GASOLINE.

IGNITION TIMING & IDLE MIXTURE

zzz

J

IN

:

TYPE

z.zz~z.zz

EX

:

z.zz~z.zz

zzzz

~

zzzz

AT NO LOAD

SESAE 10W-30

EMISSIONS COMPLIANCE PERIOD:CATEGORY A (EPA)

WARNING

READ THE OWNER‘S MANUAL AND ALL LABELS BEFORE OPERATING.

q

AVERTISSEMENT

8

ONLY OPERATE IN WELL-VENTILATED AREA. EXHAUST GAS CONTAINS POISONOUS CARBON MONOXIDE. CHECK FOR SPILLED FUEL OR FUEL LEAKS. STOP ENGINE BEFORE REFUELING. DO NOT OPERATE NEAR FLAMMABLE MATERIALS. ELECTROCUTION CAN OCCUR IF GENERATOR IS USED IN RAIN, SNOW, OR NEAR WATER. KEEP THIS UNIT DRY AT ALL TIMES.

8

8 8

MACHINE AU SEC EN TOUTES CIRCONSTANCES.

7NJ-24162-10

8 8 8

8 8

8

LISEZ LE MODE D‘EMPLOI ET TOUTES LES ETIQUETTES AVANT DE FAIRE FONCTIONNER LA MACHINE. FAITES FONCTIONNER UNIQUEMENT DANS DES LIEUX BIEN AERES.

LES GAZ D‘ECHAPPEMENT CONTIENNENT DU MONOXYDE DE CARBONE.

VERIFIEZ SI DU CARBURANT A ETE RENVERSE DU S‘IL FUIT. ARRETEZ LE MOTEUR AVANT DE FAIRE LE PLEIN DE CARBURANT. N‘UTILISEZ PAS A PROXIMITE DE MATERIAUX INFLAMMABLES. IL Y A RISQUE D‘ELECTROCUTION SI LE GENERATEUR FONCTIONNE SOUS LA PLUIE, DANS LA NEIGE, OU PRES DE L‘EAU. GARDEZ LA MACHINE AU SEC EN TOUTES CIRCONSTANCES.

3

0

2

4

6

8

10

ENGINE AIR INDEX

(

California onl

y

)

LEAST CLEAN

MOST CLEAN

NOTE

:

THE LOWER THE AIR INDEX, THE LESS THE POLLUTION

FOR THE FOLLOWING USE:

THIS ENGINE IS CERTIFIED TO BE EMISSION COMPLIANT

MODERATE

INTERMEDIATE

EXTENDED

CHECK OWNERS MANUAL FOR FURTHER DETAILS

THIS LABEL TO BE REMOVED BY TH E ULTIMATE PURCHASER ONLY!

(For EF5200DE/EF6600DE/YG5200D/ YG6600D/YG6600DE)

12

4

5

– 5 –

741-002

741-003

741-005

AE00071

SAFETY INFORMATION

AE00072

EXHAUST FUMES ARE POISONOUS

9 Never operate the engine in a closed area or it

may cause unconsciousness and death within a short time. Operate the engine in a well ventilated area.

AE00075

FUEL IS HIGHLY FLAMMABLE AND POISONOUS

9 Always turn off the engine when refuelling. 9 Never refuel while smoking or in the vicinity of an

open flame.

9 Take care not to spill any fuel on the engine or

muffler when refuelling.

9 If you swallow any fuel, inhale fuel vapor, or allow

any to get in your eye(s), see your doctor immediately. If any fuel spills on your skin or clothing, immediately wash with soap and water and change your clothes.

9 When operating or transporting the machine, be

sure it is kept upright. If it tilts, fuel may leak from the carburetor or fuel tank.

741-004

AE00843

ENGINE AND MUFFLER MAY BE HOT

9 Place the machine in a place where pedestrians

or children are not likely to touch the machine.

741- 006

9 Avoid placing any flammable materials near the

exhaust outlet during operation.

741-007

– 6 –

741-008a

a

741-009

741-062e

q

9 Keep the machine at least 1 m (3 ft) from buildings

or other equipment, or the engine may overheat.

a 1 m (3 ft)

9 Avoid operating the engine with a dust cover.

q

9 Be sure to carry the generator only by its carrying

handle(s).

1 Carrying handle(s) (shaded)

741-060

AE00083

ELECTRIC SHOCK PREVENTION

9 Never operate the engine in rain or snow.

741-010

9 Never touch the machine with wet hands or elec-

trical shock will occur.

741-011

A

9 Be sure to ground (earth) the generator.

NOTE:

Use ground (earth) lead of sufficient current capacity.

1 Lead diameter

– 7 –

741-040a

q

w

q

w

q

741-065

B

Ground (earth) Lead Diameter:

0.12 mm (0.005 in)/ampere

EX;

10 Ampere → 1.2mm (0.05 in)

å EF4000DE/YG4000D B EF5200DE/EF6600DE/YG5200D/YG6600D/YG6600DE

AE00088

CONNECTION NOTES

9 Avoid connecting the generator to commercial power out-

let.

9 Avoid connecting the generator in parallel with any other

generator.

1 Correct 2 Incorrect

AE00091

CONNECTION

w

Before the generator can be connected to a building’s electrical system, a licensed electrician must install an isolation (transfer) switch in the building’s main fuse box. The switch is the connection point for generator power and allows selection of generator or main line power to the building. This will prevent the generator from charging the main power line (backfeeding) when the main power supply has failed or has been turned off for line repair. Backfeeding can electrocute or injure line maintenance personnel. Also, generator and building electrical system damage can occur when normal operating power returns if unit is used without an isolation switch.

AE00086

EXTENSION CORD NOTES

9 When using an extension cord, its total length

should not exceed

60 meters for cross section of 1.5 mm square



and

 

100 meters for cross section of 2.5 mm square.

9 This extension cord should be protected by a

tough flexible rubber sheath (IEC 245) or the equivalent to withstand mechanical stresses.

– 8 –

EF4000DE

e

qw u

oi

r

!0

!2

!3

t

y

!3!3

q

w

o

!2

!3

i

793-064a

!3

t

!1

!3

e

!0

r

y

AE00101

CONTROL FUNCTION

AE00102

DESCRIPTION (for EF4000DE/EF5200DE/EF6600DE)

1 Fuel tank 2 Fuel tank cap 3 Fuel cock 4 Air filter cover 5 Spark plug 6 Muffler 7 Ground (Earth) terminal 8 Oil filler cap 9 Oil drain plug 0 Recoil starter q Voltage adjuster (for EF5200DE/EF6600DE) w Fuel level gauge e Carrying handles (shaded)

EF5200DE/EF6600DE

– 9 –

YG4000D

e

qw i

uo

r

!0

!1

!2

!3

t

y

!3

w q!3

o!0

!3

!2

793-065a

t u

e

!1

r

y

!3

w q

o!0

!3

!2

793-066a

t

e

!1

r

y

!3

YG5200D/YG6600D

AE00102

DESCRIPTION (for YG4000D/YG5200D/YG6600D/ YG6600DE)

1 Fuel tank 2 Fuel tank cap 3 Fuel cock 4 Air filter cover 5 Spark plug 6 Muffler 7 Choke lever (for YG4000D/YG5200D/YG6600D) 8 Ground (Earth) terminal 9 Oil filler cap 0 Oil drain plug q Recoil starter w Fuel level gauge e Carrying handles (shaded)

YG6600DE

– 10 –

EF4000DE

q

wy

er

t

r

e

y

t

w

q

y

t

r

e

w

q

793-067

EF5200DE

AE00104

CONTROL BOX (for EF4000DE/ EF5200DE/EF6600DE)

1 AC switch (N.F.B.) 2 AC receptacle 3 Voltage meter 4 Oil warning light 5 Engine switch 6 Economy idle switch

EF6600DE

– 11 –

YG4000D

qw etyu

o

q

r

w

e

q

t

y

u

q

rq

e

q

t

y

u

w

793-068

r

q

e

q

t

y

u

i

w

793-069

YG5200D

YG6600D

AE00104

CONTROL BOX (for YG4000D/ YG5200D/YG6600D/ YG6600DE)

1 AC switch (N.F.B.) 2 G.F.C.I. receptacle 3 AC receptacle 4 Voltage meter

(for YG5200D/ YG6600D/YG6600DE)

5 Oil warning light 6 Engine switch 7 Economy idle switch 8 Starter switch

(for YG6600DE)

9 Pilot light

(for YG4000D)

YG6600DE

– 12 –

q

w

763-121a

700-027c

AE00111

OIL WARNING SYSTEM

When the oil level falls below the lower level, the engine stops automatically. Unless you refill with oil, the engine will not start again.

NOTE:

If the engine stalls or does not start, turn the engine switch to "ON" position and then pull the recoil starter. If the oil warning light flickers for a few seconds, the engine oil is insufficient. Add oil and restart.

A

w

q

e

AE00121

ENGINE SWITCH

The engine switch controls the ignition system.

1 7 “ON”

Ignition circuit is switched on. The engine can be started.

763-119

B

2 5 “STOP”

Ignition circuit is switched off. The engine will not run.

3 6 “START”

Starting circuit is switched on. The starter motor starts.

å EF4000DE/EF5200DE/EF6600DE ∫ YG4000D/YG5200D/YG6600D/YG6600DE

cC

Take your hand off the switch immediately after the engine starts.

AE00920

STARTER SWITCH (for YG6600DE)

763-011

The starter switch controls the following item. Push: Starting circuit is switched on. Release: Starting circuit is switched off.

cC

Take your hand off the switch immediately after the engine starts.

– 13 –

q

w

763-124a

q

w

763-193a

q

w

q

w

A B

763-194d

q

w

q

763-195a

qq

C-1 C-2

D-1 D-2

AE00863

AC SWITCH (N.F.B.)

The AC switch (Non-Fuse Breaker) turns off automatically when the load exceeds the generator rated output.

1 I “ON” 2 3 “OFF”

å EF4000DE/YG4000D ∫ EF5200DE/EF6600DE/YG5200D/YG6600D/YG6600DE

C-1

Supplies AC 120V (EF4000DE/YG4000D)

C-2

Supplies AC 120V (EF5200DE/EF6600DE/YG5200D/ YG6600D/YG6600DE)

D-1

Supplies AC 120V and 240V (EF4000DE/YG4000D)

D-2

Supplies AC 120V and 240V (EF5200DE/EF6600DE/ YG5200D/YG6600D/YG6600DE)

cC

Reduce the load to the specified generator rated output if the AC switch (N.F.B.) turns off. If it turns off again, consult a Yamaha dealer.

AE00142

ECONOMY IDLE SWITCH

When the economy idle switch is turned to "ON", the engine speed is automatically reduced to idle when the generator load is reduced to 0.8 A or less. The results are better fuel consumption and less noise.

120V

Y

W

120V

240V

G

X

1 I “ON” 2 3 “OFF”

GR

NOTE:

The economy idle switch must be turned to "OFF" to increase engine speed to rated rpm when:

- using a load of 0.8 A or less.

779-017

- supplying AC 120V only from W with X.

– 14 –

779-039

AE00791

VOLTAGE ADJUSTER (for EF5200DE/EF6600DE)

The adjuster is equipped for adjusting output voltage to rated voltage.

NOTE:

Turn the adjuster clockwise or counterclockwise to increase or decrease output voltage.

779-037

q

AE00848

G.F.C.I. RECEPTACLE (for YG4000D/YG5200D/YG6600D/YG6600DE)

The G.F.C.I. (Ground Fault Circuit Interrupter) 1 shuts off power to the protected receptacles if a ground fault (electrical leak) is detected.

w

763-083

e

If the reset button 2 pops out 3, the equipment plugged into the receptacle may be faulty. If this happens, check the equipment carefully. If the equipment appears to be in good condition, press the reset button firmly until a click is heard. This will restore power. If the reset button pops out again, unplug the equipment immediately. Have the equipment inspected and repaired by a qualified repairperson before attempting

763-060

to use it again.

w

TO REDUCE THE CHANCE OF ELECTRICAL SHOCK:

9 Do not attempt to operate equipment if the

ground fault circuit interrupter reset button pops out repeatedly during use.

9 Test the ground fault circuit interrupter during

the pre-operation checks according to the maintenance instructions on page 35.

9 Remember that only receptacles labeled

“GFCI” have ground fault circuit interrupter protection.

– 15 –

741-001

AE00845

PRE-OPERATION CHECK

NOTE:

Pre-operation checks should be made each time the generator is used.

w

The engine and muffler will be very hot after the engine has been run. Avoid touching the engine and muffler while they are still hot with any part of your body or clothing during inspection or repair.

AE00856

FUEL

Make sure there is sufficient fuel in the tank.

Recommended fuel:

q

707-033a

Unleaded gasoline

Fuel tank capacity:

Total:

EF4000DE/YG4000D:

18.5 L (4.07 Imp gal, 4.89 US gal) EF5200DE/EF6600DE/YG5200D/YG6600D/ YG6600DE:

21.0 L (4.62 Imp gal, 5.55 US gal)

707-001

707-037

707-051

Your Yamaha engine has been designed to use regular unleaded gasoline with a pump octane number ((R + M)/2) of 86 or higher, or research octane number of 91 or higher.

1 Fuel level gauge

“F” Full “E” Empty

– 16 –

700-068

0°C

A YAMALUBE 4(10W-30)

D SAE 10W

C SAE #20

25°C

q

700-110

B SAE #30

w

9 Fuel is highly flammable and poisonous.

Check “SAFETY INFORMATION” (See page 6) carefully before refueling.

9 Do not fill above the top of the fuel filter or it

may overflow when the fuel heats up later and expands.

9 Wipe up any spilled fuel immediately. 9 After refueling, make sure the tank cap is tight-

ened securely.

AE00222

ENGINE OIL

Make sure the engine oil is at the upper level of the oil filler hole. Add oil as necessary.

1 Upper level

Recommended oil:

å YAMALUBE 4 (10W-30) or SAE 10W-30

type SE motor oil

∫ SAE #30 ç SAE #20 ∂ SAE 10W

Engine oil quantity:

EF4000DE/YG4000D:

1.0 L (0.88 lmp qt, 1.06 US qt) EF5200DE/EF6600DE/YG5200D/YG6600D/ YG6600DE:

1.1 L (0.97 lmp qt, 1.16 US qt)

80°F32°F

700-065

700-006

NOTE:

Recommended engine oil classification: API Service “SE” or “SF”.

cC

The generator has been shipped without engine oil. Fill with oil or it will not start.

– 17 –

741-061

A

AE00241

GROUND (Earth)

Make sure to ground (earth) the generator. Check "SAFETY INFORMATION" on page 7.

å EF4000DE/YG4000D ∫ EF5200DE/EF6600DE/YG5200D/YG6600D/YG6600DE

B

741-066

AE00231

BATTERY (for EF4000DE/EF5200DE/EF6600DE/YG6600DE) (See page 34 for more details)

Check the fluid level and fill if necessary. Use only distilled water if refilling is necessary.

830-002a

Installation

1. Turn the engine switch to the "STOP" position to prevent accidental short circuiting.

w

q

2. Install the battery on the battery mount tray securely.

NOTE:

Clamp the red wire to the positive (+) terminal first, then the black wire to the negative (–) terminal of the

762-004

battery. Do not reverse these positions.

e

w

Be sure to service battery leads to prevent arcing when the battery is not installed.

q

762-005

9 Disconnect the battery charging output lead.

Then insulate the generator side connector by folding it back on itself and carefully wraping it with electrical tape to prevent electrical contact with ground (earth) or any other leads.

9 Remove the battery leads from the generator.

1 Connector 2 Battery leads 3 Electrical tape

– 18 –

763-126b

q

761-047

A B

700-006a

q

AE00955

OPERATION

NOTE:

The generator has been shipped without engine oil. Fill with oil or it will not start.

1 Upper level

AE00918

STARTING THE ENGINE NOTE:

9 Before starting the engine, do not connect any

electric devices.

9 Turn the AC switch (N.F.B.) and economy idle

switch to the “OFF” position.

1 3 “OFF”

120V

q

qq

q

240V

763-196b

C

å AC switch (N.F.B.) for EF4000DE/YG4000D ∫ AC switch (N.F.B.) for EF5200DE/EF6600DE/YG5200D/

YG6600D/YG6600DE

ç Economy idle switch

1. Turn the fuel cock lever to the “ON” position.

1 “ON”

q

A

B

q

705-037

763-127c

q

2. Turn the engine switch to the “ON” position.

1 7 “ON”

å EF4000DE/EF5200DE/EF6600DE ∫ YG4000D/YG5200D/YG6600D/YG6600DE

– 19 –

701-025c

q

763-120a

q

Electric Starting Model:

701-033b

q

(for EF4000DE/EF5200DE/EF6600DE)

3. Turn the engine switch to “START”.

1 6 “START”

(for YG6600DE)

3. Push the starter switch to start the engine.

1 Starter switch

cC

q

A

763-011a

9 Take your hand off the switch immediately

after the engine starts.

9 If the engine fails to start, release the switch,

wait a few seconds, then try again. Each attempt should be as short as possible to preserve the battery. Do not crank the engine more than 10 seconds on any one attempt.

Manual Starting Model: (for YG4000D/YG5200D/YG6600D)

3. Turn the choke lever to the “1” position.

1 Choke lever

å YG4000D ∫ YG5200D/YG6600D

B

NOTE:

The choke is not required to start a warm engine. Turn the choke lever to the operating position.

4. Pull slowly on the recoil starter until it is engaged, then pull it briskly.

5. After the engine starts, warm up the engine until the engine does not stop when the choke lever is returned to the operating position.

704-010

– 20 –

701-025d

q

701-033c

q

A

B

AE00970

APPLICATION RANGE

AC

NOTE:

Especially in areas below freezing point, keep the choke lever at the halfway position until the engine is warmed up.

6. When the engine is warm, turn the choke lever back to the operating position (fully to the left).

1 Operating position

å YG4000D ∫ YG5200D/YG6600D

Power factor 1 0.8–0.95

EF4000DE/YG4000D –3,500W –2,800W –1,190W

EF5200DE/YG5200D –4,500W –3,600W –1,530W

EF6600DE

YG6600D –6,000W –4,800W –2,040W

YG6600DE

0.4–0.75

(Efficiency 0.85)

NOTE:

9 “–” means below. 9 Application wattage indicates when each device is used by itself.

cC

Be sure the total load is within generator rated output otherwise generator damage will occur.

NOTE:

Some precision equipment is voltage sensitive and may require a more uniform voltage supply than portable generators provide. Examples include some medical equipment, personal computers, and some inverters that sense peak and RMS voltage values. Consult the precision-equipment vendor before relying on any portable generator to provide power to such equipment.

– 21 –

779-032a

761-006

763-194e

q

763-195a

qq

761-046

AE00949

CONNECTION

Alternating Current (AC)

cC

9 Be sure all electric devices including the lines

and plug connections are in good condition before connection to the generator.

9 Be sure any electric devices are turned off

before plugging it in.

9 Be sure the total load is within generator rated

output.

9 Be sure the receptacle load current is within

receptacle rated current.

A B

q

A-1 A-2

B-1 B-2

779-039a

1. Wind the power lead 2 or 3 turns around frame.

2. Start the engine.

3. Plug into AC receptacle.

4. Make sure the voltage meter indicates the rated voltage (except for YG4000D) or the pilot light is on (for YG4000D).

å Voltage meter ∫ Pilot light

If the voltage meter does not indicate the rated voltage, adjust output voltage to rated voltage (for EF5200DE/EF6600DE).

1 Voltage adjuster

NOTE:

Turn the adjuster clockwise or counterclockwise to increase or decrease output voltage.

5. Turn the AC switch (N.F.B.) and economy idle switch to the “ON” and turn on any electric devices.

1 I “ON”

A-1

AC120V can be used. (EF4000DE/YG4000D)

A-2

AC120V can be used. (EF5200DE/EF6600DE/ YG5200D/YG6600D/YG6600DE)

B-1

AC120V and 240V can be used. (EF4000DE/YG4000D)

B-1

AC120V and 240V can be used. (EF5200DE/ EF6600DE/YG5200D/YG6600D/YG6600DE)

– 22 –

240V

120V

GR

779-017

W

X

G

Y

763-129a

q

763-210

C

q

763-211

For YG4000D, YG5200D and YG6600D(E), also turn the individual AC switch (N.F.B.) to the “ON” position.

1 I “ON”

ç Individual AC switch (YG4000D)

D

∂ Individual AC switch (YG5200D and YG6600D(E))

cC

Reduce the load to the specified generator rated output if an AC switch turns off. If it turns off again, consult a Yamaha dealer.

NOTE:

E

9 The 4-blade plug receptacle can supply both 120V

and 240V power sources.

9 The economy idle switch must be turned to “OFF”

to increase engine speed to rated rpm when:

- using a load of 0.8A or less.

- supplying AC120V only from W with X.

´ Economy idle switch

1 I “ON”

– 23 –

705-038

q

763-130b

q

761-047

AE00840

763-126b

q

120V

240V

qq

763-196b

STOPPING THE ENGINE NOTE:

9 Turn off any electric devices. 9 Turn the AC switch (N.F.B.) and economy idle

switch to the “OFF” position.

A B

C

A B

1 3 “OFF”

å AC switch (N.F.B.) (for EF4000DE/YG4000D) ∫ AC switch (N.F.B.) (for EF5200DE/EF6600DE/YG5200D/

YG6600D/YG6600DE)

ç Economy idle switch

1. Disconnect any electric devices.

2. Turn the engine switch to the “STOP” position.

1 5 “STOP”

å EF4000DE/EF5200DE/EF6600DE ∫ YG4000D/YG5200D/YG6600D/YG6600DE

3. Turn the fuel cock lever to “OFF”.

1 “OFF”

– 24 –

AE00401

PERIODIC MAINTENANCE

AE00403

MAINTENANCE CHART

Regular maintenance is most important for best performance and safe operation.

w

Stop the engine before starting maintenance work.

Pre-Ope-

No. Item Remarks

Check condition.

**

1. Spark Plug

**

2.* Valve Clearance when engine is 0

** Crankcase

3.* breather system

**

4.* Idle speed

**

5. Exhaust System

6. Engine Oil

**

7. Air Filter Replace if 0

8. Fuel Filter

Adjust gap and clean. Replace if necessary.

Check and adjust

cold.

Check breather hose for cracks or damage. Replace if necessary.

Check and adjust engine idle speed.

Check for leakage. Retighten or *replace gasket

if necessary.

Check muffler screen and spark arrester. Clean/ 0 replace if necessary.

Check oil level 0

Replace 00

Clean.

necessary.

Clean fuel cock and fuel tank 0 filter. Replace if necessary.

ration check

(daily)

0

Initial Every

1

month

or 20 Hr

3

months

or 50 Hr

0

months

or 100 Hr

6

months

or 300 Hr

* : It is recommended that these items be serviced by a Yamaha dealer. ** : Related to emission control system.

– 25 –

12

0

Pre-Ope-

No. Item Remarks

Check fuel hose

9. Fuel Line

**Choke lever

for YG4000D Check choke



10.



YG5200D operation.



YG6600D

11. Cooling System

12. Starting System

**

13.* Decarbonization

14. Generation meter indication or 0

G.F.C.I. receptacle

for YG4000D Check operation



.

15. YG5200D *Repair if 0

 

YG6600D necessary.



YG6600DE

Fittings/ and fasteners.

16*

Fasteners Correct if

Battery

for EF4000DE



17. EF5200DE *Check specific



EF6600DE gravity and brea-

 

YG6600DE ther pipe ope- 0

: It is recommended that these items be serviced by a Yamaha dealer.

*

: Related to emission control system.

**

for crack or damage. *Replace if necessary.

  

Check for fan damage.

Check recoil starter operation.

More frequently if necessary.

Check the voltage

pilot light.

   

Check all fittings

necessary.

Check battery fluid level. Add distilled 0 water.

   

ration. Correct if necessary.

ration check (daily)

0

Initial Every

1

month

or 20 Hr

3

months

or 50 Hr

months

or 100 Hr

0

6

12

months

or 300 Hr

0

cC

Use only Yamaha specified genuine parts for replacement. Ask an authorized Yamaha dealer for further attention.

– 26 –

760-011

a

760-001a

AE00971

SPARK PLUG INSPECTION

You should periodically remove and inspect the spark plug.

1. Check for discoloration and remove the carbon.

Standard electrode color:

Tan Color

2. Check the spark plug type and gap.

Standard Spark Plug:

BPR4ES (NGK)

Spark Plug Gap:

0.7–0.8 mm (0.028–0.031 in)

a Gap

3. Install the spark plug.

Spark Plug Torque:

20 N•m (2 kgf•m, 14 lbf•ft)

AE00431

CARBURETOR ADJUSTMENT

The carburetor is a vital part of the engine. Adjusting should be left to a Yamaha dealer with the professional knowledge, specialized data, and equipment to do so properly.

– 27 –

700-006a

q

700-065

0°C

25°C

80°F32°F

A YAMALUBE 4(10W-30)

D SAE 10W

C SAE #20

B SAE #30

AE00972

ENGINE OIL REPLACEMENT

1. Place the machine on a level surface and warm up the engine for several minutes. Then stop the engine.

2. Remove the oil filler cap.

3. Place an oil pan under the engine. Remove the oil drain plug so that the oil can be completely

e

drained.

4. Check the drain plug, gasket, oil filler cap and Oring. If damaged, replace.

w

q

700-067

1 Oil drain plug 2 Gasket 3 O-ring

5. Reinstall the oil drain plug.

Drain Plug Torque:

30 N•m (3.0 kgf•m, 22 lbf•ft)

6. Add engine oil to the upper level.

1 Upper level

Recommended oil:

å YAMALUBE 4 (10W-30) or SAE 10W-30

type SE motor oil

∫ SAE #30 ç SAE #20 ∂ SAE 10W

Engine oil quantity:

EF4000DE/YG4000D:

1.0 L (0.88 Imp qt, 1.06 US qt) EF5200DE/EF6600DE/YG5200D/YG6600D/ YG6600DE:

1.1 L (0.97 lmp qt, 1.16 US qt)

NOTE:

Recommended engine oil classification: API Service “SE” or “SF”.

cC

Be sure no foreign material enters the crankcase.

– 28 –

710-037a

710-058a

q

A

AE00914

AIR FILTER

1. Remove the air filter cover and element.

2. Wash the element in solvent and dry.

3. Oil the element and squeeze out excess oil. The element should be wet but not dripping.

Recommended oil:

Foam-air-filter oil

or

SAE #20 motor oil

cC

Do not wring out the element. This could cause it to tear.

NOTE:

For EF4000DE/YG4000D, the dry foam urethane (sponge) 1 is installed to absorb any excessive oil that comes out of the air filter element. Therefore do not apply oil to the sponge 1. If it gets oily, squeeze out the oil.

B

4. Insert the element into the air filter.

NOTE:

Be sure the element sealing surface matches the air filter so there is no air leak.

cC

The engine should never run without the element; excessive piston and cylinder wear may result.

w

Never use solvent while smoking or in the vicinity of an open flame.

å EF4000DE/YG4000D ∫ EF5200DE/EF6600DE/YG5200D/YG6600D/YG6600DE

– 29 –

705-065a

AE00461

FUEL COCK

w

Never use or be near fuel and solvent while smoking or in the vicinity of an open flame.

1. Stop the engine.

2. Turn the fuel cock lever to “OFF”.

3. Remove the fuel cock cup and gasket.

4. Clean the cup with solvent and wipe it off.

5. Check the gasket. Replace it if damaged.

6. Reinstall the gasket and fuel cock cup.

w

Be sure the fuel cock cup is tightened securely.

AE00471

q

FUEL TANK FILTER

1. Remove the fuel tank cap and filter.

1 Filter

2. Clean the filter with solvent. If damaged, replace.

3. Wipe the filter and insert it.

w

Be sure the tank cap is tightened securely.

707-043b

– 30 –

741-001

711-012d

q

711-055

w

q

w

A B

AE00443

MUFFLER SCREEN AND SPARK ARRESTER (For EF4000DE/YG4000D)

w

The engine and muffler will be very hot after the engine has been run. Avoid touching the engine and muffler while they are still hot with any part of your body or clothing during inspection or repair.

1. Remove the muffler screen.

1 Muffler screen 2 Screw

å EF4000DE ∫ YG4000D

2. Use a flathead screw driver to pry the spark arrester out from the muffler.

711-012b

3. Remove the spark arrester.

1 Spark arrester

4. Remove the carbon deposits on the muffler screen and spark arrester using a wire brush.

711-022

cC

When cleaning, use the wire brush lightly to avoid damaging or scratching of the muffler screen and spark arrester.

711-050

– 31 –

711-012a

q

w

5. Check the muffler screen and spark arrester.

711-057

741-001

711-056

q

w

e

Replace them if damaged.

6. Install the spark arrester.

NOTE:

Align the spark arrester projection with the hole in the muffler pipe.

A B

1 Projection 2 Hole

7. Install the muffler screen.

å EF4000DE ∫ YG4000D

AE00841

MUFFLER SCREEN AND SPARK ARRESTER (For EF5200DE/EF6600DE/YG5200D/YG6600D/ YG6600DE)

w

The engine and muffler will be very hot after the engine has been run. Avoid touching the engine and muffler while they are still hot with any part of your body or clothing during inspection or repair.

1. Remove the muffler protector and muffler screen.

1 Muffler protector 2 Muffler screen 3 Screw

2. Use a flathead screw driver to pry the spark arrester out from the muffler.

711-028

– 32 –

711-029

q

3. Remove the spark arrester.

711-050

1 Spark arrester

4. Remove the carbon deposits on the muffler screen and spark arrester using a wire brush.

711-022

cC

When cleaning, use the wire brush lightly to avoid damaging or scratching of the muffler screen and spark arrester.

5. Check the muffler screen and spark arrester. Replace them if damaged.

w

q

6. Install the spark arrester.

NOTE:

Align the spark arrester projection with the hole in the muffler pipe.

711-029a

1 Projection 2 Hole

7. Install the muffler screen and muffler protector.

711-027a

– 33 –

762-039

762-001a

AE00842

BATTERY (for EF4000DE/EF5200DE/EF6600DE/YG6600DE) Replenishing the battery fluid

1. Check the fluid level. The level should be between the upper and lower level marks.

1 Upper level 2 Lower level

q w

2. Add only distilled water if necessary.

cC

9 Normal tap water contains minerals which are

harmful to a battery; therefore, refill only with distilled water.

9 Do not disconnect the battery during engine

operation.

9 Avoid operating the generator with the battery

removed.

762-002

762-012

w

Battery electrolyte is poisonous and dangerous, causing severe burns, etc. It contains sulfuric (sulphuric) acid. Avoid contact with skin, EYES or clothing. Antidote: EXTERNAL-Flush with water. INTERNAL-Drink large quantities of water or milk. Follow with milk of magnesia, beaten egg or vegetable oil. Call physician immediately. Eyes: Flush with water for 15 minutes and get prompt medical attention. Batteries produce explosive gases. Keep sparks, flame, cigarettes, etc. away. Ventilate when charging or using in closed space. Always cover eyes when working near batteries. KEEP OUT OF REACH OF CHILDREN.

– 34 –

779-033a

779-034a

w

er

q

763-083a

AE00895

FUSE REPLACEMENT (for EF4000DE/EF5200DE/EF6600DE/YG6600DE)

w

Be sure to use specified fuse. A wrong fuse will cause electrical system damage and A FIRE HAZARD.

cC

Be sure the engine switch is turned off to prevent accidental short circuiting.

1. Loosen the control panel screws and then remove the control panel.

2. Replace the blown fuse with one of proper amperage.

Specified fuse: 10A

NOTE:

If the fuse immediately blows again, consult a Yamaha dealer.

AE00501

G.F.C.I. RECEPTACLE TEST (for YG4000D/YG5200D/YG6600D/YG6600DE)

1. Start the engine.

2. Turn the AC switch (N.F.B.) to the “ON” position.

3. Press the test button 1, then check the position of the reset button 2.

G.F.C.I. Reset

Button Position

after Test

Pop Out 3 Correct

Stay In 4 Incorrect

G.F.C.I. Receptacle

Operation

763-059

4. If G.F.C.I. operation is correct, push in the reset button. If the G.F.C.I. operates incorrectly, consult a Yamaha dealer.

w

Do not operate the generator with a faulty G.F.C.I. circuit. Electric shock could occur. Have the generator repaired by a qualified mechanic.

– 35 –

707-001

705-037a

763-127d

700-006

AE00512

TROUBLESHOOTING

Engine won’t start

1. Fuel systems No fuel supplied to combustion chamber.

2 No fuel in tank .... Supply fuel.

2 Clogged fuel line .... Clean fuel line.

2 Foreign matter in fuel cock .... Clean fuel cock.

2 Clogged carburetor .... Clean carburetor.

2. Engine oil system Insufficient

2 Oil level is low .... Add engine oil.

A B

3. Electrical systems

2 Engine switch to “ON”.

Poor spark

2 Spark plug dirty with carbon or wet .... Remove

carbon or wipe spark plug dry.

2 Faulty ignition system .... Consult dealer.

4. Compression Insufficient

2 Worn out piston and cylinder .... Consult dealer.

2 Loose cylinder head nuts .... Tighten nuts proper-

ly.

2 Damaged gasket .... Replace gasket.

760-009

– 36 –

AE00515

FOR EF4000DE/EF5200DE/EF6600DE/YG6600DE

A ENGINE DOES NOT START

B

Turn the engine switch to “ON”, then turn the engine switch to “START” (for EF4000DE/EF5200DE/EF6600DE) or push the starter switch (for YG6600DE). And check if the starter motor cranks.

F

Turn the engine switch to “START” or push the starter switch, and check if the oil warning light flickers.

L

Turn the engine switch to “START” or push the starter switch, and check the spark plug for spark strength. (See “WARNING”).

C Cranks D Does not crank

G Does not flicker H Flickers

w

9 To prevent FIRE HAZARDS be

sure fuel is not present in the spark plug area.

9 To prevent FIRE HAZARDS be

sure to place the spark plug as far way as possible from the spark plug hole and carburetor area.

9 To prevent ELECTRIC SHOCK

do not hold spark plug lead with hand while testing.

763-213

M Engine does not start. N Engine starts.

R

Check the following

9 Fuel cock clogging 9 Air cleaner element

clogging.

S Clogged

TOK

– 37 –

U

Clean or Replace; Consult a Yamaha dealer.

V Consult a Yamaha dealer.

E

Faulty battery and/or starter motor. Consult a Yamaha dealer.

I Check engine oil level.

J OK K Level low

Consult a Yamaha dealer.

O Check the spark plug.

9 Type: 9 Gap:

P Incorrect Q OK

Replace or Adjust Gap.

Add engine oil.

Clean the spark plug.

– 38 –

AE00515

FOR YG4000D/YG5200D/YG6600D

A ENGINE DOES NOT START

B

Turn the engine switch to “ON”, then pull the recoil starter and check if the oil warning light flickers.

E Check engine oil level.

C Does not flicker D Flickers

H

Pull the recoil starter and check the spark plug for spark strength. (See “WARNING”)

w

9 To prevent FIRE HAZARDS be

sure fuel is not present in the spark plug area.

9 To prevent FIRE HAZARDS be

sure to place the spark plug as far way as possible from the spark plug hole and carburetor area.

9 To prevent ELECTRIC SHOCK do

not hold spark plug lead with hand while testing.

Engine does not

I J

start.

Engine starts.

F OK G Level low

Consult a Yamaha dealer.

K Check the spark plug.

9 Type: 9 Gap:

L Incorrect M OK

Replace or Adjust Gap.

Add engine oil.

Clean the spark plug.

N

Check the following

9 Fuel cock clogging 9 Air cleaner element

clogging.

O Clogged

POK

– 39 –

Q

Clean or Replace; Consult a Yamaha dealer.

R Consult a Yamaha dealer.

707-084

q

w

e

r

å

∫

a

AE00601

STORAGE

Long term storage of your machine will require some preventive procedures to guard against deterioration.

AE00611

DRAIN THE FUEL

1. Drain the fuel tank, fuel cock, and carburetor float bowl.

a Carburetor drain plug

2. Pour a cup of SAE 10W30 or 20W40 motor oil into the tank.

3. Shake the tank to coat the inner surfaces thoroughly.

4. Drain off the excess oil.

å EF4000DE/EF5200DE/YG4000D/YG5200D ∫ EF6600DE/YG6600D/YG6600DE

AE00621

ENGINE

1. Remove the spark plug, pour about one tablespoon of SAE 10W30 or 20W40 motor oil into the spark plug hole and reinstall the spark plug. Recoil start the engine by turning over several times (with ignition off) to coat the cylinder walls with oil.

2. Pull the recoil starter until you feel compression. Then stop pulling. (This prevents the cylinder and valves from rusting).

3. Clean exterior of the generator and apply a rust inhibitor.

4. Store the generator in a dry, well-ventilated place, with the cover placed over it.

5. The generator must remain in a vertical position when stored, carried or operated.

712-010

– 40 –

762-003

AE00633

BATTERY (for EF4000DE/EF5200DE/EF6600DE/YG6600DE)

1. Remove the battery.

2. Check the fluid level. Add only distilled water if necessary. (See page 34; “BATTERYReplenishing the battery fluid”)

3. After checking the fluid level, charge the battery.

4. Store the battery in a cool, dark and dry place and charge it once a month.

Do not store the battery in an excessively warm or cold place [i.e., less than 0°C (30°F) or more than 30°C (90°F)].

w

9 Disconnect the negative lead first, then the

positive lead from the battery.

9 Connect the positive lead first, then the nega-

tive lead to the battery when installing the battery.

9 Never smoke or make and break connections

at the battery while charging. Sparks may ignite the battery gas.

9 Be sure the battery terminals are tight and that

the battery vent tube is properly routed and is securely attached to the battery.

cC

9 Do not disconnect the battery during engine

operation.

9 Avoid operating the generator with the battery

removed.

AE00632

RECOMMENDED BATTERY (for EF4000DE/EF5200DE/EF6600DE/YG6600DE)

Recommended battery:

Capacity: 12V/26A•h

NOTE:

9 Clamp the red wire to the positive (+) terminal and

the black wire to the negative (–) terminal of the battery. Do not reverse these positions.

9 Be sure the battery is installed on the battery

mount tray securely.

– 41 –

AE00789

EXHAUST EMISSION CONTROL SYSTEM AND COMPONENTS

Item Acronym

9 CARB. ASSY., LH. & JT., ......................CARB (Carburetor)

CARBURETOR2

9 T.C.I. MAGNETO ASSY. & .....................EI (Electronic Ignition)

PLUG, SPARK

9 CRANKCASE1 & HEAD, .......................PCV (Positive Crankcase

CYLINDER1 Ventilation)

9 AIR FILTER ASSY. .................................ACL (Air Cleaner)

9 MUFF., 2, CAP, NET, WIRE2 &

ARRESTER, SPARK

The above items and the corresponding acronyms are provided in accordance with U.S. EPA REGULATIONS FOR NEW NONROAD SPARK-IGNITION NONHANDHELD ENGINES and the CALIFORNIA REGULATIONS FOR 1995 AND LATER SMALL OFFROAD ENGINES. The acronyms conform to the latest version of the SAE’s recommended practice docu- ment J1930, “Diagnostic Acronyms, Terms, and Definitions For Electrical/Electronic System”.

It is recommended that these items be serviced by a Yamaha dealer.

– 42 –

AE00701

SPECIFICATIONS

AE00702

DIMENSIONS

Unit EF4000DE EF5200DEEF6600DE YG4000D YG5200D YG6600D Overall Length mm (in) 804 (31.7) 894 (35.2) 894 (35.2) 580 (22.8) 670 (26.4) 670 (26.4) 894 (35.2) Overall Width mm (in) 525 (20.7) 520 (20.5) 520 (20.5) 525 (20.7) 510 (20.1) 510 (20.1) 520 (20.5) Overall Height mm (in) 510 (20.1) 510 (20.1) 510 (20.1) 560 (22.0) 560 (22.0) 560 (22.0) 560 (22.0) Dry Weight kg (lb) 66 (145.5) 90 (198.4) 90 (198.4) 60 (132.3) 85 (187.3) 85 (187.3) 92 (202.8)

AE00704

ENGINE

Unit

Type Air cooled 4-stroke gasoline OHV Cylinder Arrangement Displacement cm

3

Bore × Stroke mm (in) 75.0 × 57.0 78.0 × 63.0 85.0 × 63.0

Rated Output kW (HP)/r/min 4.5 (6.1)/3600 5.8 (7.8)/3600 7.1 (9.5)/3600 Operation Hours Hr 8.5 7.6 6.6 Fuel Unleaded gasoline Fuel Tank Capacity L (Imp gal, US gal) 18.5 (4.07, 4.89) 21.0 (4.62, 5.55) Engine Oil Quantity L (Imp qt, US qt) 1.0 (0.88, 1.06) 1.1 (0.97, 1.16) Ignition System TCI Spark Plug: Type BPR4ES (NGK)

Gap mm (in) 0.7–0.8 (0.028–0.031)

Noise Level* dB (A) 69 73 74

EF4000DE/ EF5200DE/

YG4000D YG5200D

Inclined, 1 cylinder

251 301 357

(2.95 × 2.24) (3.07 × 2.48) (3.35 × 2.48)

* : Measured at rated operation from 7 m (23 ft) distance.

YG6600DE

EF6600DE/

YG6600D/

YG6600DE

AE00707

GENERATOR

Unit

EF4000DE EF5200DE EF6600DE YG4000D YG5200D YG6600D

AC Output

Rated voltage V 120/240 Rated frequency Hz 60 Rated current A 29.2/14.6 37.5/18.8 50.0/25.0 29.2/14.6 37.5/18.8 50.0/25.0 50.0/25.0 Rated output kVA 3.5 4.5 6.0 3.5 4.5 6.0 6.0 Safety Device: Type

N.F.B.

– 43 –

YG6600DE

AE00751

GG GG

-

+

770-030

R

Br

R

BrBr

R

R/W

L/W

W

WW

Y

B

B/W

R

B/W

R/W

W

G/R G/RB

R

M

B/W

B/WB/W

R/W

R/WR/W

W

WW

G/R G/R

G/RG/R

B

BB

B

L

R

G/Y

G G

W

WW WW

W W

R

L

Br

R

L

Br

120V

240V

G

Y

RBrR

Br

V

R

L

G/Y

L

G/Y

B

G

L/W

Y

G

B/W Y

W G/R R R

B

B R/B

B/W R/W

R

R G/R

W

L Y B/W B

B

B/W

R/W

R/BBB/W

B/W

R

RR

BB

BRB/W

OFF

ON

START

L/W

G/R

B

Y

G/RYB

L/WL/W Y

G

G Y L/W

q

w

e

r

t

u

i

y

o

!0

!1

!2

!3

!4

!5

!6

!7

!8

!9

@0

@1

@2

@3

@4

@5

@6

@7

WIRING DIAGRAM

EF4000DE

1 Rotor assembly 2 Stator assembly 3 Main coil 4 Sub coil 5 Voltage meter 6 N.F.B. 7 AC receptacle 8 AC receptacle 9 AC receptacle 0 Engine switch q Remote control terminal w Rectifier e Fuse r Rectifier/regulator

t Condenser y Economy idle unit u Oil warning unit i Oil warning light o Economy idle switch p Solenoid valve a Battery s Carburetor heater d Oil level switch f Charging coil g T.C.I.unit h Spark plug j Starter motor

– 44 –

Color code

B Black Br Brown G Green L Blue R Red W White B/W Black/White G/R Green/White G/Y Green/Yellow L/W Blue/White R/W Red/White Y Yellow

EF5200DE

-

+

M

R/WR

@3

G

Y

@2

Y

#0

@4

@5

@6

@9

@8

@7

!3

!1

OFF

ON

START

B

B/W

R

B

B/W

B

B/W

R

R/W

B

R

B/W

Br

B

B/WR

R/W

B

R/B

R

B/W

R/W

Br

B

R/BRB/W

R/W Br

G/R

L/W

B

Y

G/R

L/W

B

Y

G/R

L/W

B

Y

G/R

L/W

B

Y

!2

y

u

i

!9

o

!0

!8

!7

!6

!5

!4

@1

@0

w

r

t

q

e

Br

770-031

1 Rotor assembly 2 Stator assembly 3 Main coil 4 Sub coil 5 Exciter coil 6 Voltage meter 7 N.F.B. 8 AC receptacle 9 AC receptacle 0 AC receptacle q Engine switch w Remote control terminal e Rectifier r Fuse t Rectifier/regulator y Voltage adjuster

u AVR i Condenser o Economy idle unit p Oil warning unit a Oil warning light s Economy idle switch d Solenoid valve f Battery g Carburetor heater h Oil level switch j Charging coil k T.C.I.unit l Spark plug

Color code

B Black Br Brown G Green L Blue R Red W White B/W Black/White G/R Green/White G/Y Green/Yellow L/W Blue/White R/W Red/White Y Yellow

; Starter motor

– 45 –

EF6600DE

-

+

M

R/WR

@4

@3

G

Y

@2

Y

#0

#1

@5

@6

@9

@8

@7

!3

!1

OFF

ON

START

B

B/W

R R/W L/R

Y

B

B/W

R R/W L/R

Y

B

B/W

RR/W

L/R

Y

B

R

L/R

B/W

R/W

Y

B

B/WR

R/W

L/R

Y

B

R/B

R

B/W

R/W

Br

B

R/BRB/W

R/W Br

G/R

L/W

B

Y

G/R

L/W

B

Y

G/R

L/W

B

Y

G/R

L/W

B

Y

!2

y

u

i

!9

o

!0

!8

!7

!6

!5

!4

@1

@0

w

r

t

q

e

R

B

G/Y

LR

G/Y

Br

G/Y

R

Br

R

Br

L

770-032

1 Rotor assembly 2 Stator assembly 3 Main coil 4 Sub coil 5 Exciter coil 6 Voltage meter 7 N.F.B. 8 AC receptacle 9 AC receptacle 0 AC receptacle q Engine switch w Remote control terminal e Rectifier r Fuse t Rectifier/regulator y Voltage adjuster

u AVR i Condenser o Economy idle unit p Oil warning unit a Oil warning light s Economy idle switch d Solenoid valve f Battery g Carburetor solenoid valve h Carburetor heater j Oil level switch k Charging coil l T.C.I.unit ; Spark plug z Starter motor

– 46 –

Color code

B Black Br Brown G Green L Blue R Red W White B/W Black/White G/R Green/White G/Y Green/Yellow L/W Blue/White R/W Red/White Y Yellow

YG4000D

120V

240V

L

B/W

L

B

B/W

G

W

G W

W

G

B/W Y

Y

G

L/W

Y

W

L/W Y

L

G/RYB

L/W

G/R

B Y

L Y B/W

B/W

B

G/Y

L

R R

G/Y G/Y

R

G/Y

L

RBrR

Br

Br Br Br

L/W

GGWWGG

WW

R

L

Br

R

L

Br

G

Y

B

G Y L/W

q

w

e

r

t

y

u

i

o

!0

!1

!2

!3

!4

!5

!6

!7

!8

!9

@0

@1

1 Rotor assembly 2 Stator assembly 3 Main coil 4 Sub coil 5 Pilot light 6 N.F.B. 7 GFCI receptacle 8 AC receptacle 9 AC receptacle 0 Engine switch q Rectifier

w Condenser e Economy idle unit r Oil warning unit t Oil warning light y Economy idle switch u Solenoid valve i Oil level switch o Charging coil p T.C.I.unit a Spark plug

Color code

B Black Br Brown G Green L Blue R Red W White B/W Black/White G/R Green/White G/Y Green/Yellow L/W Blue/White R/W Red/White Y Yellow

– 47 –

YG5200D

L

R

Br

L

R

Br

120V

240V

120V

Y

G

GG

Y

GG

Y

G

W

B

W

B

W

B

W

Gy

G

GY

L/W

Br

R

Br

R

L

G/Y

R

G/Y

R

L

G/Y

Br

G/Y

Br

R

V

B

L

G/R

B/W

G/R

B/W

Y

L/W

B

Y

G/R

L/W

B

Y

B

L/W Y

G/R

YBL/W

!2

@0 @1

@2

@3

!8

!9

!6

!7

L Y B/W B

!3

!4

B/W

B

!1

q

t

e

r

w

y

u

i

oo

!0

!5

u

Y

B

W

G

B

R

G

Y

B

W

G

B

R

G

1 Rotor assembly 2 Stator assembly 3 Main coil 4 Sub coil 5 Exciter field coil 6 Voltage meter 7 N.F.B. 8 GFCI receptacle 9 AC receptacle 0 AC receptacle q Engine switch w Rectifier

e AVR r Condenser t Economy idle unit y Oil warning unit u Oil warning light i Economy idle switch o Solenoid valve p Oil level switch a Charging coil s T.C.I.unit d Spark plug

Color code

B Black Br Brown G Green L Blue R Red W White B/W Black/White G/R Green/White G/Y Green/Yellow L/W Blue/White R/W Red/White Y Yellow

– 48 –

YG6600D

L

R

Br

L

R

Br

120V

240V

120V

Y

G

GG

Y

GG

Y

G

W

B

W

B

W

B

W

Gy

G

GY

L/W

Br

R

Br

R

L

G/Y

R

G/Y

R

L

G/Y

Br

G/Y

Br

R

V

B

L

G/R

B/W

G/R

B/W

Y

B

G/R

L/W

B

Y

B L/W

Y

G/R

YBL/W

!2

@1

@2

@3

!8

!9

!6

!7

L Y B/W B

!3

!4

q

t

e

r

w

y

u

i

oo

!0

!5

u

Y

B

W

G

B

R

G

Y

B

W

G

B

R

G

Y

@0

@4

L/R

B/W

B

!1

L/W

770-027

1 Rotor assembly 2 Stator assembly 3 Main coil 4 Sub coil 5 Exciter field coil 6 Voltage meter 7 N.F.B. 8 GFCI receptacle 9 AC receptacle 0 AC receptacle q Engine switch w Rectifier

e AVR r Condenser t Economy idle unit y Oil warning unit u Oil warning light i Economy idle switch o Solenoid valve p Carburetor solenoid valve a Oil level switch s Charging coil d T.C.I.unit f Spark plug

Color code

B Black Br Brown G Green L Blue R Red W White B/W Black/White G/R Green/White G/Y Green/Yellow L/W Blue/White R/W Red/White Y Yellow

– 49 –

YG6600DE

!1

!2

!3

!7

@4

@6

@9

@7

@8

K03

#1

L

R

Br

L

R

Br

120V

240V

120V

Y G G

GG

Y

GG

Y

Y G G

W

B

W

B

B W

W

B

B W

Gy

G

Y

L/W

Br

R

L

G/Y

R

G/Y

R

L

G/Y

Br

G/Y

Br

R

V

B

L

B/W

G/R

B/W

Y

B

G/R L/W

B Y

B

L/W

Y

G/R

G/RYB

L/W

@1

L Y B/W B

!7

!8

B/W

B

q

t

e

r

w

y

u

i

oo

!0

!9

u

Y

B W

W G

B

G

Y

B W

W

G

B

R G

Y

@5

@3

@2

@0

!2

L/W

!4

!6

!5

G/R

B

G/R

W

R/W

L/W

L/R

R

RG/R

W

R/WBR/W

R/BBrR

R/WBRBrR/W

R/B

B

Y

L/R

R/W

R

R/W

R

G/R

W

G/R

B

R

770-028b

-

+

M

R/W

R

Br

R

1 Rotor assembly 2 Stator assembly 3 Main coil 4 Sub coil 5 Exciter coil 6 Voltage meter 7 N.F.B. 8 GFCI receptacle 9 AC receptacle 0 AC receptacle q Starter switch w Engine switch e Remote control terminal r Rectifier t Fuse y Rectifier/regulator

u AVR i Condenser o Economy idle unit p Oil warning unit a Oil warning light s Economy idle switch d Solenoid valve f Battery g Carburetor solenoid valve h Carburetor heater j Oil level switch k Charging coil l T.C.I.unit ; Spark plug z Starter motor

Color code

B Black Br Brown G Green L Blue R Red W White B/W Black/White G/R Green/White G/Y Green/Yellow L/W Blue/White

Y Yellow

R/W Red/White

– 50 –

AE00761

BATTERY TRAY INSTALLATION (for EF4000DE/EF5200DE/EF6600DE/ YG6600DE)

AE00762

OPTIONAL PARTS INSTALLATION

AE00763

Two wheel kit

AE00795

ENGINE HANGER INSTALLATION (for YG4000D/YG5200D/YG6600D/ YG6600DE)

– 51 –
