Watson-Marlow GD30P User Manual

OPERATORS MANUAL

Operators Manual

Machine Type:

GD30P

GD30P

GD30P OM 1.01 EN Ver 1.01 Date 2006-10-24 Page 1 of 14

OPERATORS MANUAL

1 DECLARATION OF CONFORMITY .....................................................................................................3

2 CAUTION....................................................................................................................................................4

3 GENERAL INFORMATION ....................................................................................................................5

3.1 Unpacking and inspection.......................................................................................................5

3.2 The Dispensing Principle........................................................................................................5

3.3 Installation...............................................................................................................................6

3.4 Addressing of filling station ..................................................................................................... 7

4 DAILY USE .................................................................................................................................................8

4.1 Pump Connections..................................................................................................................8

5 PROGRAMMING.......................................................................................................................................9

5.1 Programming principle............................................................................................................9

5.2 GD30P parameters.................................................................................................................9

Machine Type:

GD30P

6 CLEANING AND MAINTENANCE ......................................................................................................11

6.1 Daily cleaning........................................................................................................................11

6.2 Maintenance......................................................................................................................... 11

6.3 Disposal:............................................................................................................................... 11

7 INTERFACE AND CHANGE OF POWER...........................................................................................12

7.1 Interface................................................................................................................................ 12

7.2 Change of voltage................................................................................................................. 13

8 ANNEX A...................................................................................................................................................14

GD30P OM 1.01 EN Ver 1.01 Date 2006-10-24 Page 2 of 14

®

OPERATORS MANUAL

1 DECLARATION OF CONFORMITY

We Flexicon A/S
Frejasvej 2-6
DK-4100 Ringsted

declare on our sole responsibility that the product:

GD30P

Model
Serial No.
Supply
Year

YYMM XXXX

230V/50Hz/350W

Machine Type:

Flexicon a s

denmark

GD30P

2006

GD30P

to which this declaration relates is in conformity with the f ollowing standar d( s) :

DS/EN ISO 12100 Safety of machinery - Basic concepts, general

principles of design

DS/EN 60204 Safety of machinery – Electrical equipment of

machines

according to the provisions in the Directives:

98/37/EC On the approximation of the laws of t he Member

States relating to machinery.

73/23/EEC On the harmonization of the laws of Member

States relating to electrical equipment designed
for use within certain voltage limits

2004/108/EC On the approximation of the laws of t he Member

States relating to electromagnetic compatibility

Ringsted, October 2006 Mads Ulric Jensen
Signature.

GD30P OM 1.01 EN Ver 1.01 Date 2006-10-24 Page 3 of 14

OPERATORS MANUAL

2 CAUTION

This manual should be read before using t he GD30P.
Explanations to the pictograms:

Warning against touching/Warning against opening:

Warning against high voltage:

Machine Type:

GD30P

When operating the GD30P, make sure that t he dispenser head is closed.
The mains switch is used for emergency stopping .
The GD30P should only be used for dosing and f illing of liquid fluids.
The GD30P must be placed on a stable bed plate and in such a way, that it is not exposed to great

humidity, high temperatures or ot her abnormal operating-environments. I t is not to be used in
explosion hazardous environments.

It is prohibited to maintain or clean t he G D30P, when it is connected to the power supply.
It is prohibited for unauthor ised per sonnel to open the cover of the GD30P's electrical par t s .
Always remember that the GD30P must be earthed by way of the switch.
Handle the filling needles with caution.
The pump must not run dry.

The pump needs a filling nozzle with cut off valve.

GD30P OM 1.01 EN Ver 1.01 Date 2006-10-24 Page 4 of 14

OPERATORS MANUAL

Machine Type:

GD30P

3 GENERAL INFORMATION

3.1 Unpacking and inspection

GD30P is a dispenser in the Flexicon Multi Filling System (FMFS). The GD30P cannot do
fillings by itself, but must be connected to Flexicon's control unit, MC12, or to a PC with
RS485 multidrop communication.

Please check that all ordered items have been received and that no items were damaged
during transport. In case of any defects or omissions, please contact Flexicon A/S or your
supplier immediately.

When ordering spare parts or accessories for the GD30P, please state the serial number
stamped. The serial number is stamped on the label on the bottom of the GD30P.

Please check that the connected mains plug is of the correct type with the correct earthed
switch.
If this is not the case, the correct type of plug must be mounted with the following
connections.

Yellow/green - earth
Blue - neutral
Brown - phase

ALWAYS REMEMBER that this machine must be earthed.

3.2 The Dispensing Principle

GD30P operates with a pump of positive displacement rotary type. The volume at the inlet
increases when the gears rotate and the product ids drawn into the pump. It is then
transported in the space between the gears and the periphery of the body to the discharge
side. The volume between the gears is reduced here and the product is forced out through
the outlet.

The gears operate without metallic contact with casing. The pumps have gears in AISI 316
acid resistant steel (PTFE impregnated). This gives an efficient performance and gentle
handling of liquids products.

The gaskets are made of EPDM.
THE PUMP MUST NOT RUN DRY.
The best performance is reached with a positive product support.
The pump needs a filling nozzle with cut off valve.

GD30P OM 1.01 EN Ver 1.01 Date 2006-10-24 Page 5 of 14
