Toro 22546 Operator's Manual

Download
FormNo.3429-975RevB
StandardBucket,High-Volume Bucket,orGradingBucket
TXL2000ToolCarrier
ModelNo.22546—SerialNo.318000001andUp ModelNo.22547—SerialNo.318000001andUp ModelNo.22548—SerialNo.318000001andUp ModelNo.22576—SerialNo.318000001andUp
Registeratwww.T oro.com. OriginalInstructions(EN)
*3429-975*B
WARNING
CALIFORNIA
Proposition65Warning
Useofthisproductmaycauseexposure
tochemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orotherreproductiveharm.
g267815
Figure2
Highvolumebucket
Introduction
Thebucketisaload-bearingattachmentintendedto beusedonaT orotoolcarrier.Itisdesignedprimarily formovingrock,dirt,sand,orothermaterials.Using thisproductforpurposesotherthanitsintendeduse couldprovedangeroustoyouandbystanders.
Readthisinformationcarefullytolearnhowtooperate andmaintainyourproductproperlyandtoavoid injuryandproductdamage.Y ouareresponsiblefor operatingtheproductproperlyandsafely .
Visitwww.T oro.comforproductsafetyandoperation trainingmaterials,accessoryinformation,helpnding adealer,ortoregisteryourproduct.
Wheneveryouneedservice,genuineToroparts,or additionalinformation,contactanAuthorizedService DealerorToroCustomerServiceandhavethemodel andserialnumbersofyourproductready.Figure
1,Figure2,orFigure3identiesthelocationofthe
modelandserialnumbersontheproduct.Writethe numbersinthespaceprovided.
Important:Withyourmobiledevice,youcan
scantheQRcodeontheserialnumberdecal(if equipped)toaccesswarranty,parts,andother productinformation.
1.Modelandserialnumberlocation
g267814
Figure3
Gradingbucket
1.Modelandserialnumberlocation
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhas safetymessagesidentiedbythesafety-alertsymbol (Figure4),whichsignalsahazardthatmaycause seriousinjuryordeathifyoudonotfollowthe recommendedprecautions.
1.Modelandserialnumberlocation
©2019—TheToro®Company 8111LyndaleAvenueSouth Bloomington,MN55420
Standardbucket
Figure1
g000502
Figure4
1.Safety-alertsymbol
g267816
Thismanualuses2wordstohighlightinformation. Importantcallsattentiontospecialmechanical informationandNoteemphasizesgeneralinformation worthyofspecialattention.
Contactusatwww.Toro.com.
2
PrintedintheUSA
AllRightsReserved
Contents
Safety
Safety.......................................................................3
GeneralSafety...................................................3
SlopeSafety.......................................................4
BucketSafety.....................................................4
MaintenanceandStorageSafety........................4
SafetyandInstructionalDecals..........................5
ProductOverview.....................................................6
Specications....................................................6
MaximumMaterialDensityatCapacity...............7
Operation..................................................................8
InstallingandRemovingtheAttachment.............8
FillingtheBucket................................................8
TransportPosition..............................................9
Storage.....................................................................9
DANGER
Theremaybeburiedutilitylinesinthework area.Diggingintothemmaycauseashock oranexplosion.
Havethepropertyorworkareamarkedfor buriedlinesanddonotdiginmarkedareas. Contactyourlocalmarkingserviceorutility companytohavethepropertymarked(for example,intheUS,call811orinAustralia, call1100forthenationwidemarkingservice).
GeneralSafety
Alwaysfollowallsafetyinstructionstoavoidserious injuryordeath.
•Donottransportanattachmentwiththe
armsraisedorextended;alwaystransportthe attachmentclosetotheground,withtheloader armsretracted;refertoTransportPosition(page
9).
•Havethepropertyorworkareamarkedforburied
linesandotherobjects,anddonotdiginmarked areas.
•ReadandunderstandthecontentofthisOperator’s
Manualbeforestartingtheengine.
•Useyourfullattentionwhileoperatingthe
machine.Donotengageinanyactivitythat causesdistractions;otherwise,injuryorproperty damagemayoccur.
•Neverallowchildrenoruntrainedpeopleto
operatethemachine.
•Keepyourhandsandfeetawayfromthemoving
componentsandattachments.
•Donotoperatethemachinewithouttheguards
andothersafetyprotectivedevicesinplaceand workingonthemachine.
•Keepbystandersandpetsasafedistanceaway
fromthemachine.
•Stopthemachine,shutofftheengine,andremove
thekeybeforeservicing,fueling,orunclogging themachine.
Improperlyusingormaintainingthismachinecan resultininjury.T oreducethepotentialforinjury, complywiththesesafetyinstructionsandalways payattentiontothesafety-alertsymbol meansCaution,Warning,orDanger—personalsafety instruction.Failuretocomplywiththeseinstructions mayresultinpersonalinjuryordeath.
Youcanndadditionalsafetyinformationwhere neededthroughoutthisOperator’sManual.
3
,which
SlopeSafety
•Operatethemachineupanddownslopeswith
theheavyendofthemachineuphill.Weight distributionchangeswithattachments.Anempty load-bearingattachmentmakestherearofthe machinetheheavyend,andafullload-bearing attachmentmakesthefrontofthemachinethe heavyend.Mostotherattachmentsmakethefront ofmachinetheheavyend.
•Keeptheattachmentintheloweredposition
withtheloaderarmsretractedwhenonslopes.
Raisingtheattachmentorextendingtheloader armsonaslopeaffectsthestabilityofthemachine.
•Slopesareamajorfactorrelatedtolossofcontrol
andtip-overaccidents,whichcanresultinsevere injuryordeath.Operatingthemachineonany slopeoruneventerrainrequiresextracaution.
•Establishyourownproceduresandrulesfor
operatingonslopes.Theseproceduresmust includesurveyingthesitetodeterminewhich slopesaresafeformachineoperation.Always usecommonsenseandgoodjudgmentwhen performingthissurvey.
•Slowdownanduseextracareonhillsides.Ground
conditionscanaffectthestabilityofthemachine.
•Avoidstartingorstoppingonaslope.Ifthe
machinelosestraction,proceedslowly,straight downtheslope.
•Avoidturningonslopes.Ifyoumustturn,turn
slowlyandkeeptheheavyendofthemachine uphill.
•Usecautionwhenoperatingthemachinenearthe
following:
–Drop-offs
–Ditches
–Embankments
–Bodiesofwater
Themachinecouldsuddenlyrolloverifatrack goesovertheedgeortheedgecavesin.Maintain asafedistancebetweenthemachineandany hazard.
•Donotremoveoraddattachmentsonaslope.
•Donotparkthemachineonahillsideorslope.
BucketSafety
•Weargloves,eyeprotection,longpants,
substantialslip-resistantfootwear,andhearing protectionduringoperationorwhileadjustingor repairingthemachine.
•Afterstrikingaforeignobject,shutofftheengine,
removethekey,thoroughlyinspecttheattachment foranydamage,andrepairthedamagebefore startingandoperatingtheattachment.
•Alwayslowertheattachmentandshutoffthe
machineeachtimeyouleavetheoperating position.
•Whenliftingtheattachment,keepitleveland
preventtheloadfromspillingbackward.
•Keepallmovementsonslopesslowandgradual.
Donotmakesuddenchangesinspeedor direction.
•Ifyoufeeluneasyoperatingthemachineona
slope,donotdoit.
•Watchforholes,ruts,orbumps,asuneventerrain
couldoverturnthemachine.T allgrasscanhide obstacles.
•Usecautionwhenoperatingonwetsurfaces.
Reducedtractioncouldcausesliding.
•Evaluatetheareatoensurethatthegroundis
stableenoughtosupportthemachine.
MaintenanceandStorage Safety
•Checkfastenersatfrequentintervalsforproper
tightnesstoensurethattheequipmentisinsafe operatingcondition.
•RefertotheOperator’sManualforimportant
detailsifyoustoretheattachmentforanextended periodoftime
•Maintainorreplacesafetyandinstructionlabels,
asnecessary.
4
SafetyandInstructional
Decal139-2836isforModel22547.
Decals
Safetydecalsandinstructionsare easilyvisibletotheoperatorandare locatednearanyareaofpotential danger.Replaceanydecalthatis damagedormissing.
decal139-2836
139-2836
1.Tippinghazard—readtheTXL2000Operator’sManualfor loadlimits;themaximumloadwiththeattachmentretracted
decal125-6110
125-6110
is887kg(1,956lb);themaximumloadwiththeattachment extendedis412kg(909lb).
1.Crushinghazard—donotstandunderanypartofthe machine.
133-8061
Decal139-2834isforModel22576.
Decal139-2837isforModel22546.
decal133-8061
decal139-2837
139-2837
1.Tippinghazard—readtheTXL2000Operator’sManualfor loadlimits;themaximumloadwiththeattachmentretracted is870kg(1,917lb);themaximumloadwiththeattachment extendedis378kg(834lb).
139-2834
1.Tippinghazard—readtheTXL2000Operator’sManualfor loadlimits;themaximumloadwiththeattachmentretracted is907kg(2,000lb);themaximumloadwiththeattachment extendedis428kg(945lb).
decal139-2834
5
Decal139-2838isforModel22548.
ProductOverview
Specications
Note:Specicationsanddesignaresubjectto
changewithoutnotice.
Model22546—HighVolumeBucket
139-2838
1.Tippinghazard—readtheTXL2000Operator’sManualfor loadlimits;themaximumloadwiththeattachmentretracted is852kg(1,880lb);themaximumloadwiththeattachment extendedis410kg(905lb).
Width
Length
Height
decal139-2838
Weight
Capacity(SAEstruck capacity)
185cm(73inches)
124cm(49inches)
74cm(29inches)
385kg(849lb)
3
0.8m
(29.0ft3)
Model22547—StandardBucket
Width
Length
Height
Weight
Capacity(SAEstruck capacity)
140cm(55inches)
107cm(42inches)
64cm(25inches)
276kg(609lb)
3
0.4m
(12.8ft3)
Model22548—GradingBucket
Width
Length
Height51inches
Weight
Capacity(SAEstruck capacity)
140cm(55inches)
99cm(39inches(
239kg(527lb)
3
0.3m
(9.3ft3)
Model22576—StandardBucket
Width
Length
Height
Weight
Capacity(SAEstruck capacity)
Toensureoptimumperformanceandcontinuedsafety certicationofthemachine,useonlygenuineToro replacementpartsandaccessories.Replacement partsandaccessoriesmadebyothermanufacturers couldbedangerous,andsuchusecouldvoidthe productwarranty.
6
140cm(55inches)
107cm(42inches)
64cm(25inches)
243kg(535lb)
3
0.4m
(12.8ft3)
MaximumMaterialDensityat
MaterialDensity
Capacity
Thedensityofthematerialsmovedbythebucket variesand,therefore,sodoestheamountofmaterial thatthebucketcancarrybeforereachingthe maximumloadrating.Therst2tablesliststhe densityofmaterialthatcanbecarried,bothheaped andstruck(i.e.,leveledoff),inthebucket.The MaterialDensitytablelistscommonmaterialsand theirdensities.
Model22546—High-VolumeBucket
BucketCapacity
Heapedbucket
Struck(leveled) bucket
Model22547—StandardBucket
BucketCapacity
Heapedbucket
Struck(leveled) bucket
Model22548—GradingBucket
BucketCapacity
Heapedbucket
Struck(leveled) bucket
Model22576—StandardBucket
BucketCapacity
Heapedbucket
Struck(leveled) bucket
Maximum Density—Loader armsretracted
910kg/m
(57lb/ft
1105kg/m
(69lb/ft
3
3
)(28lb/ft
3
3
)(33lb/ft
Maximum Density—Loader armsretracted
1922kg/m
(120lb/ft
2419kg/m
(151lb/ft
3
3
)(55lb/ft
3
3
)(70lb/ft
Maximum Density—Loader armsretracted
2280kg/m
(142lb/ft
3186kg/m
(199lb/ft
3
3
)(63lb/ft
3
3
)(88lb/ft
Maximum Density—Loader armsretracted
1970kg/m
(123lb/ft
2499kg/m
(156lb/ft
3
3
)(57lb/ft
3
3
)(72lb/ft
Maximum Density—Loader armsextended
441kg/m
536kg/m
Maximum Density—Loader armsextended
881kg/m
1121kg/m
Maximum Density—Loader armsextended
1010kg/m
1412kg/m
Maximum Density—Loader armsextended
913kg/m
1,153kg/m
Material
Caliche1250kg/m
Density(Approximate)
3
(78lb/ft
3
)
Clay:
Naturalbed
Dry
Wet
Withgravel,dry
Withgravel,wet
1600kg/m
1480kg/m
1660kg/m
1420kg/m
1540kg/m
3
(104lb/ft
3
(93lb/ft
3
(104lb/ft
3
(89lb/ft
3
(96lb/ft
3
)
3
)
3
)
3
)
3
)
Coal:
Anthracite,broken
Bituminous,broken
3
3
)
3
3
)
Earth:
Dry,packed
Wet,packed
Loam
Granite,brokenorlarge
1100kg/m
830kg/m
1510kg/m
1600kg/m
1250kg/m
1660kg/m
3
(69lb/ft
3
(52lb/ft
3
(94lb/ft
3
(100lb/ft
3
(78lb/ft
3
(104lb/ft
3
)
3
)
3
)
3
)
3
)
3
)
crushed
Gravel:
Dry
3
3
)
3
3
)
Pitrun(graveledsand)1930kg/m
Dry,13to51mm(1/2to2 inch)
Wet,13to51mm(1/2to2 inch)
Limestone,brokenorcrushed
1510kg/m
1690kg/m
2020kg/m
1540kg/m
3
(94lb/ft
3
(120lb/ft
3
(106lb/ft
3
(126lb/ft
3
(96lb/ft
3
)
3
)
3
)
3
)
3
)
Sand:
Dry
Wet
3
3
)
3
3
)
Withgravel,dry
Withgravel,wet
Sandstone,broken1510kg/m
Shale1250kg/m
1420kg/m
1840kg/m
1720kg/m
2020kg/m
Slag,broken1750kg/m
Stone,crushed1600kg/m
Topsoil
3
3
)
3
3
)
950kg/m
3
(89lb/ft
3
(115lb/ft
3
(107lb/ft
3
(126lb/ft
3
(94lb/ft
3
(78lb/ft
3
(109lb/ft
3
(100lb/ft
3
(59lb/ft
3
)
3
)
3
)
3
)
3
)
3
)
3
)
3
)
3
)
7
Operation
Determinetheleftandrightsidesofthemachinefrom thenormaloperatingposition.
InstallingandRemoving theAttachment
FillingtheBucket
1.Positionthebucketleveltotheground.
2.Driveforwardandinsertthebucketintothepile ofmaterial.
3.Whenthebucketisfull,drivethemachinein reverseandgentlytiltthebucketrearwardto decreasetheliftingresistancewhenyouliftthe load.
RefertotheOperator’sManualforthetractionunitfor theinstallationandremovalprocedure.
Important:Beforeinstallingtheattachment,
positionthemachineonalevelsurface,ensure thatthemountplatesarefreeofanydirtordebris, andensurethatthepinsrotatefreely .Ifthepins donotrotatefreely,greasethem.
Note:Alwaysusethetractionunittoliftandmove
theattachment.
WARNING
Ifyoudonotfullyseatthequick-attach pinsthroughtheattachmentmountplate, theattachmentcouldfalloffthemachine, crushingyouorbystanders.
Ensurethatthequick-attachpinsarefully seatedintheattachmentmountplate.
Important:Alwayscarryloadscloseto
thegroundwiththearmsretracted(if applicable);refertoTransportPosition(page
9).
g266856
Figure5
8
TransportPosition
Whentransportingaload,keeptheattachmentas closetothegroundaspossible,nomorethan15cm (6inches)abovethelowestposition.Tiltitrearwardto keeptheloadlevel.
Figure6
Storage
1.Beforelong-termstorage,washtheattachment withmilddetergentandwatertoremovedirtand grime.
2.Paintallscratchedorbaremetalsurfaces.
Note:PaintisavailablefromyourAuthorized
ServiceDealer.
3.Storetheattachmentinaclean,drygarageor storagearea.Coverittoprotectitandkeepit clean.
g240205
1.Nomorethan15cm(6 inches)abovethelowest position
2.Tilttheloadrearward
9
Notes:
Notes:
CaliforniaProposition65WarningInformation
Whatisthiswarning?
Youmayseeaproductforsalethathasawarninglabellikethefollowing:
WARNING:CancerandReproductiveHarm—www.p65Warnings.ca.gov.
WhatisProp65?
Prop65appliestoanycompanyoperatinginCalifornia,sellingproductsinCalifornia,ormanufacturingproductsthatmaybesoldinorbroughtinto California.ItmandatesthattheGovernorofCaliforniamaintainandpublishalistofchemicalsknowntocausecancer,birthdefects,and/orother reproductiveharm.Thelist,whichisupdatedannually,includeshundredsofchemicalsfoundinmanyeverydayitems.ThepurposeofProp65isto informthepublicaboutexposuretothesechemicals.
Prop65doesnotbanthesaleofproductscontainingthesechemicalsbutinsteadrequireswarningsonanyproduct,productpackaging,orliteraturewith theproduct.Moreover,aProp65warningdoesnotmeanthataproductisinviolationofanyproductsafetystandardsorrequirements.Infact,the CaliforniagovernmenthasclariedthataProp65warning“isnotthesameasaregulatorydecisionthataproductis‘safe’or‘unsafe.’”Manyofthese chemicalshavebeenusedineverydayproductsforyearswithoutdocumentedharm.Formoreinformation,gotohttps://oag.ca.gov/prop65/faqs-view-all
AProp65warningmeansthatacompanyhaseither(1)evaluatedtheexposureandhasconcludedthatitexceedsthe“nosignicantrisklevel”;or(2) haschosentoprovideawarningbasedonitsunderstandingaboutthepresenceofalistedchemicalwithoutattemptingtoevaluatetheexposure.
Doesthislawapplyeverywhere?
Prop65warningsarerequiredunderCalifornialawonly.ThesewarningsareseenthroughoutCaliforniainawiderangeofsettings,includingbutnot limitedtorestaurants,grocerystores,hotels,schools,andhospitals,andonawidevarietyofproducts.Additionally ,someonlineandmailorder retailersprovideProp65warningsontheirwebsitesorincatalogs.
.
HowdotheCaliforniawarningscomparetofederallimits?
Prop65standardsareoftenmorestringentthanfederalandinternationalstandards.TherearevarioussubstancesthatrequireaProp65warning atlevelsthatarefarlowerthanfederalactionlimits.Forexample,theProp65standardforwarningsforleadis0.5μg/day,whichiswellbelow thefederalandinternationalstandards.
Whydon’tallsimilarproductscarrythewarning?
•ProductssoldinCaliforniarequireProp65labellingwhilesimilarproductssoldelsewheredonot.
•AcompanyinvolvedinaProp65lawsuitreachingasettlementmayberequiredtouseProp65warningsforitsproducts,butothercompanies
makingsimilarproductsmayhavenosuchrequirement.
•TheenforcementofProp65isinconsistent.
•CompaniesmayelectnottoprovidewarningsbecausetheyconcludethattheyarenotrequiredtodosounderProp65;alackofwarningsfora
productdoesnotmeanthattheproductisfreeoflistedchemicalsatsimilarlevels.
WhydoesToroincludethiswarning?
Torohaschosentoprovideconsumerswithasmuchinformationaspossiblesothattheycanmakeinformeddecisionsabouttheproductstheybuyand use.T oroprovideswarningsincertaincasesbasedonitsknowledgeofthepresenceofoneormorelistedchemicalswithoutevaluatingthelevelof exposure,asnotallthelistedchemicalsprovideexposurelimitrequirements.WhiletheexposurefromT oroproductsmaybenegligibleorwellwithinthe “nosignicantrisk”range,outofanabundanceofcaution,T orohaselectedtoprovidetheProp65warnings.Moreover,ifT orodoesnotprovidethese warnings,itcouldbesuedbytheStateofCaliforniaorbyprivatepartiesseekingtoenforceProp65andsubjecttosubstantialpenalties.
RevA
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
