Texas instruments TMS320F2806, TMS320C2802, TMS320C2801, TMS320F28016, TMS320F28015 Data Manual

TMS320F2809, TMS320F2808, TMS320F2806
TMS320F2802, TMS320F2801, TMS320C2802
TMS320C2801, TMS320F28016, TMS320F28015

Digital Signal Processors

Data Manual

PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.

Literature Number: SPRS230M

October 2003–Revised March 2011

TMS320F2809, TMS320F2808, TMS320F2806
TMS320F2802, TMS320F2801, TMS320C2802
TMS320C2801, TMS320F28016, TMS320F28015

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

www.ti.com

Contents

1 F280x, F2801x, C280x DSPs .................................................................................................. 9

1.1 Features ...................................................................................................................... 9

1.2 Getting Started ............................................................................................................. 10

2 Introduction ...................................................................................................................... 11

2.1 Pin Assignments ........................................................................................................... 14

2.2 Signal Descriptions ........................................................................................................ 19

3 Functional Overview .......................................................................................................... 25

3.1 Memory Maps .............................................................................................................. 26

3.2 Brief Descriptions .......................................................................................................... 34

3.2.1 C28x CPU ....................................................................................................... 34

3.2.2 Memory Bus (Harvard Bus Architecture) .................................................................... 34

3.2.3 Peripheral Bus .................................................................................................. 34

3.2.4 Real-Time JTAG and Analysis ................................................................................ 35

3.2.5 Flash ............................................................................................................. 35

3.2.6 ROM .............................................................................................................. 35

3.2.7 M0, M1 SARAMs ............................................................................................... 35

3.2.8 L0, L1, H0 SARAMs ............................................................................................ 36

3.2.9 Boot ROM ....................................................................................................... 36

3.2.10 Security .......................................................................................................... 37

3.2.11 Peripheral Interrupt Expansion (PIE) Block ................................................................. 38

3.2.12 External Interrupts (XINT1, XINT2, XNMI) .................................................................. 38

3.2.13 Oscillator and PLL .............................................................................................. 38

3.2.14 Watchdog ........................................................................................................ 38

3.2.15 Peripheral Clocking ............................................................................................. 38

3.2.16 Low-Power Modes .............................................................................................. 38

3.2.17 Peripheral Frames 0, 1, 2 (PFn) .............................................................................. 39

3.2.18 General-Purpose Input/Output (GPIO) Multiplexer ......................................................... 39

3.2.19 32-Bit CPU-Timers (0, 1, 2) ................................................................................... 39

3.2.20 Control Peripherals ............................................................................................. 39

3.2.21 Serial Port Peripherals ......................................................................................... 40

3.3 Register Map ............................................................................................................... 40

3.4 Device Emulation Registers .............................................................................................. 42

3.5 Interrupts .................................................................................................................... 42

3.5.1 External Interrupts .............................................................................................. 45

3.6 System Control ............................................................................................................ 46

3.6.1 OSC and PLL Block ............................................................................................ 47

3.6.1.1 External Reference Oscillator Clock Option .................................................... 48

3.6.1.2 PLL-Based Clock Module ......................................................................... 49

3.6.1.3 Loss of Input Clock ................................................................................ 50

3.6.2 Watchdog Block ................................................................................................. 51

3.7 Low-Power Modes Block ................................................................................................. 52

4 Peripherals ....................................................................................................................... 53

4.1 32-Bit CPU-Timers 0/1/2 ................................................................................................. 53

4.2 Enhanced PWM Modules (ePWM1/2/3/4/5/6) ......................................................................... 55

4.3 Hi-Resolution PWM (HRPWM) .......................................................................................... 58

2 Contents Copyright © 2003–2011, Texas Instruments Incorporated

TMS320F2809, TMS320F2808, TMS320F2806

TMS320F2802, TMS320F2801, TMS320C2802

TMS320C2801, TMS320F28016, TMS320F28015

www.ti.com

4.4 Enhanced CAP Modules (eCAP1/2/3/4) ................................................................................ 58

4.5 Enhanced QEP Modules (eQEP1/2) .................................................................................... 61

4.6 Enhanced Analog-to-Digital Converter (ADC) Module ............................................................... 63

4.6.1 ADC Connections if the ADC Is Not Used .................................................................. 66

4.6.2 ADC Registers .................................................................................................. 67

4.7 Enhanced Controller Area Network (eCAN) Modules (eCAN-A and eCAN-B) .................................... 68

4.8 Serial Communications Interface (SCI) Modules (SCI-A, SCI-B) ................................................... 73

4.9 Serial Peripheral Interface (SPI) Modules (SPI-A, SPI-B, SPI-C, SPI-D) .......................................... 76

4.10 Inter-Integrated Circuit (I2C) ............................................................................................. 80

4.11 GPIO MUX ................................................................................................................. 82

5 Device Support ................................................................................................................. 86

5.1 Device and Development Support Tool Nomenclature ............................................................... 86

5.2 Documentation Support ................................................................................................... 88

5.3 Community Resources .................................................................................................... 93

6 Electrical Specifications ..................................................................................................... 94

6.1 Absolute Maximum Ratings .............................................................................................. 94

6.2 Recommended Operating Conditions .................................................................................. 95

6.3 Electrical Characteristics ................................................................................................. 95

6.4 Current Consumption ..................................................................................................... 96

6.4.1 Reducing Current Consumption ............................................................................. 100

6.4.2 Current Consumption Graphs ............................................................................... 101

6.5 Emulator Connection Without Signal Buffering for the DSP ....................................................... 103

6.6 Timing Parameter Symbology .......................................................................................... 104

6.6.1 General Notes on Timing Parameters ...................................................................... 104

6.6.2 Test Load Circuit .............................................................................................. 104

6.6.3 Device Clock Table ........................................................................................... 105

6.7 Clock Requirements and Characteristics ............................................................................. 106

6.8 Power Sequencing ....................................................................................................... 107

6.8.1 Power Management and Supervisory Circuit Solutions .................................................. 107

6.9 General-Purpose Input/Output (GPIO) ................................................................................ 110

6.9.1 GPIO - Output Timing ........................................................................................ 110

6.9.2 GPIO - Input Timing .......................................................................................... 111

6.9.3 Sampling Window Width for Input Signals ................................................................. 112

6.9.4 Low-Power Mode Wakeup Timing .......................................................................... 113

6.10 Enhanced Control Peripherals ......................................................................................... 116

6.10.1 Enhanced Pulse Width Modulator (ePWM) Timing ....................................................... 116

6.10.2 Trip-Zone Input Timing ....................................................................................... 116

6.10.3 External Interrupt Timing ..................................................................................... 118

6.10.4 I2C Electrical Specification and Timing .................................................................... 119

6.10.5 Serial Peripheral Interface (SPI) Master Mode Timing ................................................... 119

6.10.6 SPI Slave Mode Timing ...................................................................................... 124

6.10.7 On-Chip Analog-to-Digital Converter ....................................................................... 126

6.10.7.1 ADC Power-Up Control Bit Timing ............................................................. 127

6.10.7.2 Definitions ......................................................................................... 128

6.10.7.3 Sequential Sampling Mode (Single-Channel) (SMODE = 0) ............................... 129

6.10.7.4 Simultaneous Sampling Mode (Dual-Channel) (SMODE = 1) .............................. 130

6.11 Detailed Descriptions .................................................................................................... 131

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

Copyright © 2003–2011, Texas Instruments Incorporated Contents 3

TMS320F2809, TMS320F2808, TMS320F2806
TMS320F2802, TMS320F2801, TMS320C2802
TMS320C2801, TMS320F28016, TMS320F28015

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

6.12 Flash Timing .............................................................................................................. 132

6.13 ROM Timing (C280x only) .............................................................................................. 133

7 Migrating From F280x Devices to C280x Devices ................................................................. 134

7.1 Migration Issues .......................................................................................................... 134

8 Revision History .............................................................................................................. 135

9 Mechanical Data .............................................................................................................. 136

www.ti.com

4 Contents Copyright © 2003–2011, Texas Instruments Incorporated

TMS320F2809, TMS320F2808, TMS320F2806

TMS320F2802, TMS320F2801, TMS320C2802

TMS320C2801, TMS320F28016, TMS320F28015

www.ti.com

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

List of Figures

2-1 TMS320F2809, TMS320F2808 100-Pin PZ LQFP (Top View) ............................................................ 15

2-2 TMS320F2806 100-Pin PZ LQFP (Top View)................................................................................ 16

2-3 TMS320F2802, TMS320F2801, TMS320C2802, TMS320C2801 100-Pin PZ LQFP (Top View) ..................... 17

2-4 TMS320F2801x 100-Pin PZ LQFP (Top View) .............................................................................. 18

2-5 TMS320F2809, TMS320F2808, TMS320F2806,TMS320F2802, TMS320F2801,

TMS320F28016, TMS320F28015, TMS320C2802, TMS320C2801

100-Ball GGM and ZGM MicroStar BGA™ (Bottom View)................................................................. 18

3-1 Functional Block Diagram....................................................................................................... 26

3-2 F2809 Memory Map.............................................................................................................. 27

3-3 F2808 Memory Map.............................................................................................................. 28

3-4 F2806 Memory Map.............................................................................................................. 29

3-5 F2802, C2802 Memory Map .................................................................................................... 30

3-6 F2801, F28015, F28016, C2801 Memory Map............................................................................... 30

3-7 External and PIE Interrupt Sources............................................................................................ 44

3-8 Multiplexing of Interrupts Using the PIE Block ............................................................................... 44

3-9 Clock and Reset Domains ...................................................................................................... 46

3-10 OSC and PLL Block Diagram................................................................................................... 47

3-11 Using a 3.3-V External Oscillator............................................................................................... 48

3-12 Using a 1.8-V External Oscillator............................................................................................... 48

3-13 Using the Internal Oscillator .................................................................................................... 48

3-14 Watchdog Module................................................................................................................ 51

4-1 CPU-Timers....................................................................................................................... 53

4-2 CPU-Timer Interrupt Signals and Output Signal ............................................................................. 54

4-3 Multiple PWM Modules in a 280x System .................................................................................... 55

4-4 ePWM Sub-Modules Showing Critical Internal Signal Interconnections.................................................. 57

4-5 eCAP Functional Block Diagram ............................................................................................... 59

4-6 eQEP Functional Block Diagram............................................................................................... 61

4-7 Block Diagram of the ADC Module ............................................................................................ 64

4-8 ADC Pin Connections With Internal Reference .............................................................................. 65

4-9 ADC Pin Connections With External Reference ............................................................................. 66

4-10 eCAN Block Diagram and Interface Circuit ................................................................................... 69

4-11 eCAN-A Memory Map ........................................................................................................... 70

4-12 eCAN-B Memory Map ........................................................................................................... 71

4-13 Serial Communications Interface (SCI) Module Block Diagram............................................................ 75

4-14 SPI Module Block Diagram (Slave Mode) .................................................................................... 79

4-15 I2C Peripheral Module Interfaces .............................................................................................. 81

4-16 GPIO MUX Block Diagram...................................................................................................... 82

4-17 Qualification Using Sampling Window......................................................................................... 85

5-1 Example of TMS320x280x/2801x Device Nomenclature ................................................................... 87

6-1 Typical Operational Current Versus Frequency (F2808) .................................................................. 101

6-2 Typical Operational Power Versus Frequency (F2808).................................................................... 101

6-3 Typical Operational Current Versus Frequency (C280x).................................................................. 102

6-4 Typical Operational Power Versus Frequency (C280x) ................................................................... 102

6-5 Emulator Connection Without Signal Buffering for the DSP .............................................................. 103

6-6 3.3-V Test Load Circuit......................................................................................................... 104

6-7 Clock Timing..................................................................................................................... 107

6-8 Power-on Reset ................................................................................................................. 108

Copyright © 2003–2011, Texas Instruments Incorporated List of Figures 5

TMS320F2809, TMS320F2808, TMS320F2806
TMS320F2802, TMS320F2801, TMS320C2802
TMS320C2801, TMS320F28016, TMS320F28015

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

6-9 Warm Reset ..................................................................................................................... 109

6-10 Example of Effect of Writing Into PLLCR Register......................................................................... 110

6-11 General-Purpose Output Timing.............................................................................................. 111

6-12 Sampling Mode ................................................................................................................. 111

6-13 General-Purpose Input Timing................................................................................................ 112

6-14 IDLE Entry and Exit Timing.................................................................................................... 113

6-15 STANDBY Entry and Exit Timing Diagram.................................................................................. 114

6-16 HALT Wake-Up Using GPIOn................................................................................................. 115

6-17 PWM Hi-Z Characteristics..................................................................................................... 116

6-18 ADCSOCAO or ADCSOCBO Timing ........................................................................................ 118

6-19 External Interrupt Timing....................................................................................................... 118

6-20 SPI Master Mode External Timing (Clock Phase = 0) ..................................................................... 121

6-21 SPI Master Mode External Timing (Clock Phase = 1) ..................................................................... 123

6-22 SPI Slave Mode External Timing (Clock Phase = 0)....................................................................... 125

6-23 SPI Slave Mode External Timing (Clock Phase = 1)....................................................................... 126

6-24 ADC Power-Up Control Bit Timing ........................................................................................... 127

6-25 ADC Analog Input Impedance Model ........................................................................................ 128

6-26 Sequential Sampling Mode (Single-Channel) Timing...................................................................... 129

6-27 Simultaneous Sampling Mode Timing ....................................................................................... 130

www.ti.com

6 List of Figures Copyright © 2003–2011, Texas Instruments Incorporated

TMS320F2809, TMS320F2808, TMS320F2806

TMS320F2802, TMS320F2801, TMS320C2802

TMS320C2801, TMS320F28016, TMS320F28015

www.ti.com

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

List of Tables

2-1 Hardware Features (100-MHz Devices)....................................................................................... 12

2-2 Hardware Features (60-MHz Devices) ........................................................................................ 13

2-3 Signal Descriptions............................................................................................................... 19

3-1 Addresses of Flash Sectors in F2809 ......................................................................................... 31

3-2 Addresses of Flash Sectors in F2808 ......................................................................................... 31

3-3 Addresses of Flash Sectors in F2806, F2802................................................................................ 31

3-4 Addresses of Flash Sectors in F2801, F28015, F28016.................................................................... 32

3-5 Impact of Using the Code Security Module................................................................................... 32

3-6 Wait-states ........................................................................................................................ 33

3-7 Boot Mode Selection............................................................................................................. 36

3-8 Peripheral Frame 0 Registers .................................................................................................. 41

3-9 Peripheral Frame 1 Registers .................................................................................................. 41

3-10 Peripheral Frame 2 Registers .................................................................................................. 42

3-11 Device Emulation Registers..................................................................................................... 42

3-12 PIE Peripheral Interrupts ....................................................................................................... 44

3-13 PIE Configuration and Control Registers...................................................................................... 45

3-14 External Interrupt Registers..................................................................................................... 45

3-15 PLL, Clocking, Watchdog, and Low-Power Mode Registers .............................................................. 47

3-16 PLLCR Register Bit Definitions................................................................................................. 49

3-17 Possible PLL Configuration Modes ............................................................................................ 50

3-18 Low-Power Modes ............................................................................................................... 52

4-1 CPU-Timers 0, 1, 2 Configuration and Control Registers................................................................... 54

4-2 ePWM Control and Status Registers .......................................................................................... 56

4-3 eCAP Control and Status Registers ........................................................................................... 60

4-4 eQEP Control and Status Registers ........................................................................................... 62

4-5 ADC Registers ................................................................................................................... 67

4-6 3.3-V eCAN Transceivers ...................................................................................................... 69

4-7 CAN Register Map .............................................................................................................. 72

4-8 SCI-A Registers .................................................................................................................. 74

4-9 SCI-B Registers .................................................................................................................. 74

4-10 SPI-A Registers................................................................................................................... 77

4-11 SPI-B Registers................................................................................................................... 77

4-12 SPI-C Registers .................................................................................................................. 78

4-13 SPI-D Registers .................................................................................................................. 78

4-14 I2C-A Registers................................................................................................................... 81

4-15 GPIO Registers .................................................................................................................. 83

4-16 F2808 GPIO MUX Table ........................................................................................................ 84

5-1 TMS320x280x, 2801x Peripheral Selection Guide .......................................................................... 88

6-1 TMS320F2809, TMS320F2808 Current Consumption by Power-Supply Pins at 100-MHz SYSCLKOUT........... 96

6-2 TMS320F2806 Current Consumption by Power-Supply Pins at 100-MHz SYSCLKOUT ............................. 97

6-3 TMS320F2802, TMS320F2801 Current Consumption by Power-Supply Pins at 100-MHz SYSCLKOUT........... 98

6-4 TMS320C2802, TMS320C2801 Current Consumption by Power-Supply Pins at 100-MHz SYSCLKOUT .......... 99

6-5 Typical Current Consumption by Various Peripherals (at 100 MHz) .................................................... 100

6-6 TMS320x280x Clock Table and Nomenclature (100-MHz Devices)..................................................... 105

6-7 TMS320x280x/2801x Clock Table and Nomenclature (60-MHz Devices) .............................................. 105

6-8 Input Clock Frequency ......................................................................................................... 106

6-9 XCLKIN Timing Requirements - PLL Enabled ............................................................................. 106

Copyright © 2003–2011, Texas Instruments Incorporated List of Tables 7

TMS320F2809, TMS320F2808, TMS320F2806
TMS320F2802, TMS320F2801, TMS320C2802
TMS320C2801, TMS320F28016, TMS320F28015

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

6-10 XCLKIN Timing Requirements - PLL Disabled ............................................................................. 106

6-11 XCLKOUT Switching Characteristics (PLL Bypassed or Enabled) ...................................................... 106

6-12 Power Management and Supervisory Circuit Solutions ................................................................... 107

6-13 Reset (XRS) Timing Requirements .......................................................................................... 109

6-14 General-Purpose Output Switching Characteristics........................................................................ 110

6-15 General-Purpose Input Timing Requirements .............................................................................. 111

6-16 IDLE Mode Timing Requirements ........................................................................................... 113

6-17 IDLE Mode Switching Characteristics ....................................................................................... 113

6-18 STANDBY Mode Timing Requirements ..................................................................................... 114

6-19 STANDBY Mode Switching Characteristics ................................................................................ 114

6-20 HALT Mode Timing Requirements ........................................................................................... 115

6-21 HALT Mode Switching Characteristics ...................................................................................... 115

6-22 ePWM Timing Requirements ................................................................................................. 116

6-23 ePWM Switching Characteristics ............................................................................................ 116

6-24 Trip-Zone input Timing Requirements ....................................................................................... 116

6-25 High-Resolution PWM Characteristics at SYSCLKOUT = 60–100 MHz ................................................ 117

6-26 Enhanced Capture (eCAP) Timing Requirement .......................................................................... 117

6-27 eCAP Switching Characteristics ............................................................................................. 117

6-28 Enhanced Quadrature Encoder Pulse (eQEP) Timing Requirements .................................................. 117

6-29 eQEP Switching Characteristics ............................................................................................. 117

6-30 External ADC Start-of-Conversion Switching Characteristics............................................................. 118

6-31 External Interrupt Timing Requirements .................................................................................... 118

6-32 External Interrupt Switching Characteristics ................................................................................ 118

6-33 I2C Timing ...................................................................................................................... 119

6-34 SPI Master Mode External Timing (Clock Phase = 0) .................................................................... 120

6-35 SPI Master Mode External Timing (Clock Phase = 1) .................................................................... 122

6-36 SPI Slave Mode External Timing (Clock Phase = 0) ...................................................................... 124

6-37 SPI Slave Mode External Timing (Clock Phase = 1) ...................................................................... 125

6-38 ADC Electrical Characteristics (over recommended operating conditions) ............................................ 126

6-39 ADC Power-Up Delays......................................................................................................... 127

6-40 Current Consumption for Different ADC Configurations (at 12.5-MHz ADCCLK) ..................................... 127

6-41 Sequential Sampling Mode Timing ........................................................................................... 129

6-42 Simultaneous Sampling Mode Timing ....................................................................................... 130

6-43 Flash Endurance for A and S Temperature Material ...................................................................... 132

6-44 Flash Endurance for Q Temperature Material .............................................................................. 132

6-45 Flash Parameters at 100-MHz SYSCLKOUT............................................................................... 132

6-46 Flash/OTP Access Timing .................................................................................................... 132

6-47 Minimum Required Flash/OTP Wait-States at Different Frequencies ................................................... 133

6-48 ROM/OTP Access Timing .................................................................................................... 133

6-49 ROM/ROM (OTP area) Minimum Required Wait-States at Different Frequencies..................................... 133

9-1 F280x Thermal Model 100-pin GGM Results............................................................................... 136

9-2 F280x Thermal Model 100-pin PZ Results.................................................................................. 136

9-3 C280x Thermal Model 100-pin GGM Results............................................................................... 136

9-4 C280x Thermal Model 100-pin PZ Results.................................................................................. 136

9-5 F2809 Thermal Model 100-pin GGM Results .............................................................................. 136

9-6 F2809 Thermal Model 100-pin PZ Results ................................................................................. 137

www.ti.com

8 List of Tables Copyright © 2003–2011, Texas Instruments Incorporated

TMS320F2809, TMS320F2808, TMS320F2806

TMS320F2802, TMS320F2801, TMS320C2802

TMS320C2801, TMS320F28016, TMS320F28015

www.ti.com

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

Digital Signal Processors

Check for

Samples: TMS320F2809, TMS320F2808, TMS320F2806, TMS320F2802, TMS320F2801, TMS320C2802, TMS320C2801,

1 F280x, F2801x, C280x DSPs

1.1 Features

1234

• High-Performance Static CMOS Technology • 128-Bit Security Key/Lock

– 100 MHz (10-ns Cycle Time) – Protects Flash/OTP/L0/L1 Blocks
– 60 MHz (16.67-ns Cycle Time) – Prevents Firmware Reverse Engineering
– Low-Power (1.8-V Core, 3.3-V I/O) Design • Three 32-Bit CPU Timers

• JTAG Boundary Scan Support

• High-Performance 32-Bit CPU ( TMS320C28x™) – Up to 16 PWM Outputs

– 16 x 16 and 32 x 32 MAC Operations – Up to 6 HRPWM Outputs With 150-ps MEP
– 16 x 16 Dual MAC
– Harvard Bus Architecture
– Atomic Operations
– Fast Interrupt Response and Processing
– Unified Memory Programming Model
– Code-Efficient (in C/C++ and Assembly)

• On-Chip Memory

– F2809: 128K x 16 Flash, 18K x 16 SARAM

F2808: 64K x 16 Flash, 18K x 16 SARAM – One Inter-Integrated-Circuit (I2C) Bus
F2806: 32K x 16 Flash, 10K x 16 SARAM
F2802: 32K x 16 Flash, 6K x 16 SARAM
F2801: 16K x 16 Flash, 6K x 16 SARAM

F2801x: 16K x 16 Flash, 6K x 16 SARAM
– 1K x 16 OTP ROM (Flash Devices Only)
– C2802: 32K x 16 ROM, 6K x 16 SARAM

C2801: 16K x 16 ROM, 6K x 16 SARAM

• Boot ROM (4K x 16)
– With Software Boot Modes (via SCI, SPI,

CAN, I2C, and Parallel I/O)

– Standard Math Tables

• Clock and System Control
– Dynamic PLL Ratio Changes Supported
– On-Chip Oscillator
– Watchdog Timer Module

• Any GPIO A Pin Can Be Connected to One of
the Three External Core Interrupts

• Peripheral Interrupt Expansion (PIE) Block That
Supports All 43 Peripheral Interrupts

(1) IEEE Standard 1149.1-1990 Standard Test Access Port and

Boundary Scan Architecture

1

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas
Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

2TMS320C28x, Code Composer Studio, DSP/BIOS, MicroStar BGA, C28x, TI, TMS320C2000 are trademarks of Texas Instruments.
3eZdsp is a trademark of Spectrum Digital.
4All other trademarks are the property of their respective owners.

PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.

(1)

TMS320F28016, TMS320F28015

• Enhanced Control Peripherals

Resolution
– Up to Four Capture Inputs
– Up to Two Quadrature Encoder Interfaces
– Up to Six 32-bit/Six 16-bit Timers

• Serial Port Peripherals
– Up to 4 SPI Modules
– Up to 2 SCI (UART) Modules
– Up to 2 CAN Modules

• 12-Bit ADC, 16 Channels
– 2 x 8 Channel Input Multiplexer
– Two Sample-and-Hold
– Single/Simultaneous Conversions
– Fast Conversion Rate:

80 ns - 12.5 MSPS (F2809 only)
160 ns - 6.25 MSPS (280x)
267 ns - 3.75 MSPS (F2801x)

– Internal or External Reference

• Up to 35 Individually Programmable,
Multiplexed GPIO Pins With Input Filtering

• Advanced Emulation Features
– Analysis and Breakpoint Functions
– Real-Time Debug via Hardware

• Development Support Includes
– ANSI C/C++ Compiler/Assembler/Linker
– Code Composer Studio™ IDE
– DSP/BIOS™
– Digital Motor Control and Digital Power

Software Libraries

• Low-Power Modes and Power Savings
– IDLE, STANDBY, HALT Modes Supported
– Disable Individual Peripheral Clocks

Copyright © 2003–2011, Texas Instruments Incorporated

TMS320F2809, TMS320F2808, TMS320F2806
TMS320F2802, TMS320F2801, TMS320C2802
TMS320C2801, TMS320F28016, TMS320F28015

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

• Package Options • Temperature Options
– Thin Quad Flatpack (PZ) – A: –40°C to 85°C (PZ, GGM, ZGM)
– MicroStar BGA™ (GGM, ZGM) – S: –40°C to 125°C (PZ, GGM, ZGM)

– Q: –40°C to 125°C (PZ)

1.2 Getting Started

This section gives a brief overview of the steps to take when first developing for a C28x™ device. For
more detail on each of these steps, see the following:

• Getting Started With TMS320C28x Digital Signal Controllers (literature number SPRAAM0).

• C2000 Getting Started Website (http://www.ti.com/c2000getstarted)

Step 1. Acquire the appropriate development tools

The quickest way to begin working with a C28x device is to acquire an eZdsp™ kit for initial
development, which, in one package, includes:

• On-board JTAG emulation via USB or parallel port

• Appropriate emulation driver

• Code Composer Studio™ IDE for eZdsp
Once you have become familiar with the device and begin developing on your own

hardware, purchase Code Composer Studio™ IDE separately for software development and
a JTAG emulation tool to get started on your project.

www.ti.com

Step 2. Download starter software

To simplify programming for C28x devices, it is recommended that users download and use
the C/C++ Header Files and Example(s) to begin developing software for the C28x devices
and their various peripherals.

After downloading the appropriate header file package for your device, refer to the following
resources for step-by-step instructions on how to run the peripheral examples and use the
header file structure for your own software

• The Quick Start Readme in the /doc directory to run your first application.

• Programming TMS320x28xx and 28xxx Peripherals in C/C++ Application Report
(literature number SPRAA85)

Step 3. Download flash programming software

Many C28x devices include on-chip flash memory and tools that allow you to program the
flash with your software IP.

• Flash Tools: C28x Flash Tools

• TMS320F281x™ Flash Programming Solutions (literature number SPRB169)

• Running an Application from Internal Flash Memory on the TMS320F28xxx DSP
(literature number SPRA958)

Step 4. Move on to more advanced topics

For more application software and other advanced topics, visit the TI™ website at

http://www.ti.com or http://www.ti.com/c2000getstarted.

10 F280x, F2801x, C280x DSPs Copyright © 2003–2011, Texas Instruments Incorporated

Submit Documentation Feedback

Product Folder Link(s): TMS320F2809 TMS320F2808 TMS320F2806 TMS320F2802 TMS320F2801 TMS320C2802

TMS320C2801 TMS320F28016 TMS320F28015

www.ti.com

2 Introduction

The TMS320F2809, TMS320F2808, TMS320F2806, TMS320F2802, TMS320F2801, TMS320F28015,
TMS320F28016, TMS320C2802, and TMS320C2801 devices, members of the TMS320C28x™ DSP
generation, are highly integrated, high-performance solutions for demanding control applications.

Throughout this document, TMS320F2809, TMS320F2808, TMS320F2806, TMS320F2802,
TMS320F2801, TMS320C2802, TMS320C2801, TMS320F28015, and TMS320F28016 are abbreviated as
F2809, F2808, F2806, F2802, F2801, C2802, C2801, F28015, and F28016, respectively. TMS320F28015
and TMS320F28016 are abbreviated as F2801x. Table 2-1 provides a summary of features for each
device.

TMS320F2809, TMS320F2808, TMS320F2806

TMS320F2802, TMS320F2801, TMS320C2802

TMS320C2801, TMS320F28016, TMS320F28015

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

Copyright © 2003–2011, Texas Instruments Incorporated Introduction 11

Submit Documentation Feedback

Product Folder Link(s): TMS320F2809 TMS320F2808 TMS320F2806 TMS320F2802 TMS320F2801 TMS320C2802

TMS320C2801 TMS320F28016 TMS320F28015

TMS320F2809, TMS320F2808, TMS320F2806
TMS320F2802, TMS320F2801, TMS320C2802
TMS320C2801, TMS320F28016, TMS320F28015

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

Table 2-1. Hardware Features (100-MHz Devices)

www.ti.com

FEATURE TYPE

Instruction cycle (at 100 MHz) – 10 ns 10 ns 10 ns 10 ns 10 ns 10 ns 10 ns

Single-access RAM (SARAM) (16-bit word) – (L0, L1, M0, M1, (L0, L1, M0, M1,

3.3-V on-chip flash (16-bit word) – 128K 64K 32K 32K 16K – –
On-chip ROM (16-bit word) – – – – – – 32K 16K
Code security for on-chip flash/SARAM/OTP blocks – Yes Yes Yes Yes Yes Yes Yes
Boot ROM (4K x 16) – Yes Yes Yes Yes Yes Yes Yes
One-time programmable (OTP) ROM

(16-bit word)
PWM outputs 0 ePWM1/2/3/4/5/6 ePWM1/2/3/4/5/6 ePWM1/2/3/4/5/6 ePWM1/2/3 ePWM1/2/3 ePWM1/2/3 ePWM1/2/3

HRPWM channels 0 ePWM1A/2A/3A ePWM1A/2A/3A ePWM1A/2A/3A ePWM1A/2A/3A
32-bit CAPTURE inputs or auxiliary PWM outputs 0 eCAP1/2/3/4 eCAP1/2/3/4 eCAP1/2/3/4 eCAP1/2 eCAP1/2 eCAP1/2 eCAP1/2

32-bit QEP channels (four inputs/channel) 0 eQEP1/2 eQEP1/2 eQEP1/2 eQEP1 eQEP1 eQEP1 eQEP1
Watchdog timer – Yes Yes Yes Yes Yes Yes Yes
12-Bit, 16-channel ADC conversion time 1 80 ns 160 ns 160 ns 160 ns 160 ns 160 ns 160 ns
32-Bit CPU timers – 3 3 3 3 3 3 3
Serial Peripheral Interface (SPI) 0 SPI-A/B/C/D SPI-A/B/C/D SPI-A/B/C/D SPI-A/B SPI-A/B SPI-A/B SPI-A/B
Serial Communications Interface (SCI) 0 SCI-A/B SCI-A/B SCI-A/B SCI-A SCI-A SCI-A SCI-A
Enhanced Controller Area Network (eCAN) 0 eCAN-A/B eCAN-A/B eCAN-A eCAN-A eCAN-A eCAN-A eCAN-A
Inter-Integrated Circuit (I2C) 0 I2C-A I2C-A I2C-A I2C-A I2C-A I2C-A I2C-A
Digital I/O pins (shared) – 35 35 35 35 35 35 35
External interrupts – 3 3 3 3 3 3 3
Supply voltage 1.8-V Core, 3.3-V I/O – Yes Yes Yes Yes Yes Yes Yes

Packaging

Temperature options S: –40°C to 125°C – (PZ, GGM, ZGM) (PZ, GGM, ZGM) (PZ, GGM, ZGM) (PZ, GGM, ZGM) (PZ, GGM, ZGM) (PZ, GGM, ZGM) (PZ, GGM, ZGM)

Product status

(2)

100-Pin PZ – Yes Yes Yes Yes Yes Yes Yes
100-Ball GGM, ZGM – Yes Yes Yes Yes Yes Yes Yes
A: –40°C to 85°C – (PZ, GGM, ZGM) (PZ, GGM, ZGM) (PZ, GGM, ZGM) (PZ, GGM, ZGM) (PZ, GGM, ZGM) (PZ, GGM, ZGM) (PZ, GGM, ZGM)

Q: –40°C to 125°C – (PZ) (PZ) (PZ) (PZ) (PZ) (PZ) (PZ)

(1)

– 1K 1K 1K 1K 1K – –

– TMS TMS TMS TMS TMS TMS TMS

F2809 F2808 F2806 F2802 F2801 C2802 C2801

18K 18K
H0) H0)

ePWM1A/2A/3A/ ePWM1A/2A/ ePWM1A/2A/

4A/5A/6A 3A/4A 3A/4A

10K 6K 6K 6K 6K

(L0, L1, M0, M1) (L0, M0, M1) (L0, M0, M1) (L0, M0, M1) (L0, M0, M1)

(1) A type change represents a major functional feature difference in a peripheral module. Within a peripheral type, there may be minor differences between devices that do not affect the

basic functionality of the module. These device-specific differences are listed in the TMS320x28xx, 28xxx DSP Peripheral Reference Guide (literature number SPRU566) and in the
peripheral reference guides.

(2) See Section 5.1, Device and Development Support Tool Nomenclature, for descriptions of device stages.

12 Introduction Copyright © 2003–2011, Texas Instruments Incorporated

Submit Documentation Feedback

Product Folder Link(s): TMS320F2809 TMS320F2808 TMS320F2806 TMS320F2802 TMS320F2801 TMS320C2802

TMS320C2801 TMS320F28016 TMS320F28015

www.ti.com

TMS320F2809, TMS320F2808, TMS320F2806

TMS320F2802, TMS320F2801, TMS320C2802

TMS320C2801, TMS320F28016, TMS320F28015

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

Table 2-2. Hardware Features (60-MHz Devices)

FEATURE TYPE

Instruction cycle (at 60 MHz) – 16.67 ns 16.67 ns 16.67 ns 16.67 ns
Single-access RAM (SARAM) (16-bit word) –

3.3-V on-chip flash (16-bit word) – 32K 16K 16K 16K
On-chip ROM (16-bit word) – – – – –
Code security for on-chip flash/SARAM/OTP blocks – Yes Yes Yes Yes
Boot ROM (4K x 16) – Yes Yes Yes Yes
One-time programmable (OTP) ROM

(16-bit word)
PWM outputs 0 ePWM1/2/3 ePWM1/2/3 ePWM1/2/3/4 ePWM1/2/3/4
HRPWM channels 0 ePWM1A/2A/3A ePWM1A/2A/3A ePWM1A/2A/3A/4A ePWM1A/2A/3A/4A
32-bit CAPTURE inputs or auxiliary PWM outputs 0 eCAP1/2 eCAP1/2 eCAP1/2 eCAP1/2
32-bit QEP channels (four inputs/channel) 0 eQEP1 eQEP1 - ­Watchdog timer – Yes Yes Yes Yes

No. of channels 16 16 16 16

12-Bit ADC MSPS 1 3.75 3.75 3.75 3.75

Conversion time 267 ns 267 ns 267 ns 267 ns
32-Bit CPU timers – 3 3 3 3
Serial Peripheral Interface (SPI) 0 SPI-A/B SPI-A/B SPI-A SPI-A
Serial Communications Interface (SCI) 0 SCI-A SCI-A SCI-A SCI-A
Enhanced Controller Area Network (eCAN) 0 eCAN-A eCAN-A eCAN-A ­Inter-Integrated Circuit (I2C) 0 I2C-A I2C-A I2C-A I2C-A
Digital I/O pins (shared) – 35 35 35 35
External interrupts – 3 3 3 3

Supply voltage –

Packaging

Temperature options S: –40°C to 125°C – (PZ GGM, ZGM) (PZ, GGM, ZGM) (PZ, GGM, ZGM) (PZ, GGM, ZGM)

Product status

(2)

100-Pin PZ – Yes Yes Yes Yes

100-Ball GGM, ZGM – Yes Yes Yes Yes

A: –40°C to 85°C – (PZ, GGM, ZGM) (PZ, GGM, ZGM) (PZ, GGM, ZGM) (PZ, GGM, ZGM)

Q: –40°C to 125°C – (PZ) (PZ) (PZ) (PZ)

(1)

– 1K 1K 1K 1K

– TMS TMS TMS TMS

F2802-60 F2801-60 F28016 F28015

6K 6K 6K 6K

(L0, M0, M1) (L0, M0, M1) (L0, M0, M1) (L0, M0, M1)

1.8-V Core, 1.8-V Core, 1.8-V Core, 1.8-V Core,

3.3-V I/O 3.3-V I/O 3.3-V I/O 3.3-V I/O

(1) A type change represents a major functional feature difference in a peripheral module. Within a peripheral type, there may be minor differences between devices that do not affect the

basic functionality of the module. These device-specific differences are listed in the TMS320x28xx, 28xxx DSP Peripheral Reference Guide (literature number SPRU566) and in the
peripheral reference guides.

(2) See Section 5.1, Device and Development Support Tool Nomenclature, for descriptions of device stages.

Copyright © 2003–2011, Texas Instruments Incorporated Introduction 13

Submit Documentation Feedback

Product Folder Link(s): TMS320F2809 TMS320F2808 TMS320F2806 TMS320F2802 TMS320F2801 TMS320C2802

TMS320C2801 TMS320F28016 TMS320F28015

50

49

48

47

46

45

44

43

42

41

40

39

38

37

36

35

34

33

32

31

30

29

28

27

26

76

75

74

51

53

54

55

56

57

58

59

60

61

62

63

64

65

66

67

68

69

70

71

72

73

52

77

78

79

80

81

82

83

84

85

86

87

88

89

90

91

92

93

94

95

96

97

98

99

100

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

1

GPIO0/EPWM1A

XRS

TRST

V

DD2A18

V

SS2AGND

V

DDAIO

GPIO13/ /CANRXB/SPISOMIBTZ2

V

DD3VFL

V

DD

V

DD

V

DDIO

V

DD

V

SS

V

SS

V

SS

V

SS

V

SS

V

SS

V

DDIO

GPIO26/ECAP3/EQEP2I/SPICLKB

TEST2

TEST1

GPIO25/ECAP2/EQEP2B/SPISOMIB

XCLKIN

X1

X2

EMU1

EMU0

GPIO24/ECAP1/EQEP2A/SPISIMOB

GPIO27/ECAP4/EQEP2S/SPISTEB

TDO

TCK

GPIO12/ /CANTXB/SPISIMOBTZ1

GPIO14/ /SCITXDB/SPICLKBTZ3

GPIO15/ /SCIRXDB/SPISTEBTZ4

GPIO30/CANRXA

ADCINA3

ADCINA7

ADCINA6

ADCINA5

ADCINA4

ADCINA2

ADCINA1

ADCINA0

ADCLO

GPIO31/CANTXA

GPIO29/SCITXDA//TZ6

GPIO33/SCLA/EPWMSYNCO/ADCSOCBO

GPIO4/EPWM3A

GPIO17/SPISOMIA/CANRXB/TZ6

GPIO5/EPWM3B/SPICLKD/ECAP1

GPIO18/SPICLKA/SCITXDB

GPIO6/EPWM4A/EPWMSYNCI/EPWMSYNCO

GPIO19/SPISTEA/SCIRXDB

GPIO7/EPWM4B/SPISTED/ECAP2

GPIO9/EPWM5B/SCITXDB/ECAP3

GPIO20/EQEP1A/SPISIMOC/CANTXB

GPIO10/EPWM6A/CANRXB/ADCSOCBO

GPIO8/EPWM5A/CANTXB/ADCSOCAO

XCLKOUT

GPIO21/EQEP1B/SPISOMIC/CANRXB

V

SS

V

SS

V

SS

V

SS

V

SS

V

SS1AGND

V

SSA2

V

SSAIO

V

DD

V

DDA2

V

DD1A18

V

DDIO

V

DD

V

DD

V

DDIO

GPIO11/EPWM6B/SCIRXDB/ECAP4

GPIO22/EQEP1S/SPICLKC/SCITXDB

TMS

TDI

GPIO23/EQEP1I/SPISTEC/SCIRXDB

ADCINB0

ADCINB1

ADCINB2

ADCINB3

ADCINB7

ADCINB6

ADCINB5

ADCINB4

ADCREFIN

ADCREFM

ADCREFP

ADCRESEXT

GPIO34

GPIO1/EPWM1B/SPISIMOD

GPIO2/EPWM2A

GPIO3/EPWM2B/SPISOMID

GPIO16/SPISIMOA/CANTXB/TZ5

GPIO32/SDAA/EPWMSYNCI/ADCSOCAO

GPIO28/SCIRXDA/TZ5

TMS320F2809, TMS320F2808, TMS320F2806
TMS320F2802, TMS320F2801, TMS320C2802
TMS320C2801, TMS320F28016, TMS320F28015

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

2.1 Pin Assignments

The TMS320F2809, TMS320F2808, TMS320F2806, TMS320F2802, TMS320F2801, TMS320C2802,
TMS320C2801, TMS320F28015, and TMS320F28016 100-pin PZ low-profile quad flatpack (LQFP) pin
assignments are shown in Figure 2-1, Figure 2-2, Figure 2-3, and Figure 2-4. The 100-ball GGM and ZGM
ball grid array (BGA) terminal assignments are shown in Figure 2-5. Table 2-3 describes the function(s) of
each pin.

www.ti.com

Figure 2-1. TMS320F2809, TMS320F2808 100-Pin PZ LQFP (Top View)

14 Introduction Copyright © 2003–2011, Texas Instruments Incorporated

Product Folder Link(s): TMS320F2809 TMS320F2808 TMS320F2806 TMS320F2802 TMS320F2801 TMS320C2802

Submit Documentation Feedback

TMS320C2801 TMS320F28016 TMS320F28015

50

49

48

47

46

45

44

43

42

41

40

39

38

37

36

35

34

33

32

31

30

29

28

27

26

76

75

74

51

53

54

55

56

57

58

59

60

61

62

63

64

65

66

67

68

69

70

71

72

73

52

77

78

79

80

81

82

83

84

85

86

87

88

89

90

91

92

93

94

95

96

97

98

99

100

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

1

GPIO0/EPWM1A

XRS

TRST

V

DD2A18

V

SS2AGND

V

DDAIO

GPIO13/ /SPISOMIBTZ2

V

DD3VFL

V

DD

V

DD

V

DDIO

V

DD

V

SS

V

SS

V

SS

V

SS

V

SS

V

SS

V

DDIO

GPIO26/ECAP3/EQEP2I/SPICLKB

TEST2

TEST1

GPIO25/ECAP2/EQEP2B/SPISOMIB

XCLKIN

X1

X2

EMU1

EMU0

GPIO24/ECAP1/EQEP2A/SPISIMOB

GPIO27/ECAP4/EQEP2S/SPISTEB

TDO

TCK

GPIO12/ /SPISIMOBTZ1

GPIO14/ /SCITXDB/SPICLKBTZ3

GPIO15/ /SCIRXDB/SPISTEBTZ4

GPIO30/CANRXA

ADCINA3

ADCINA7

ADCINA6

ADCINA5

ADCINA4

ADCINA2

ADCINA1

ADCINA0

ADCLO

GPIO31/CANTXA

GPIO29/SCITXDA//TZ6

GPIO33/SCLA/EPWMSYNCO/ADCSOCBO

GPIO4/EPWM3A

GPIO17/SPISOMIA/TZ6

GPIO5/EPWM3B/SPICLKD/ECAP1

GPIO18/SPICLKA/SCITXDB

GPIO6/EPWM4A/EPWMSYNCI/EPWMSYNCO

GPIO19/SPISTEA/SCIRXDB

GPIO7/EPWM4B/SPISTED/ECAP2

GPIO9/EPWM5B/SCITXDB/ECAP3

GPIO20/EQEP1A/SPISIMOC

GPIO10/EPWM6A/ADCSOCBO

GPIO8/EPWM5A/ADCSOCAO

XCLKOUT

GPIO21/EQEP1B/SPISOMIC

V

SS

V

SS

V

SS

V

SS

V

SS

V

SS1AGND

V

SSA2

V

SSAIO

V

DD

V

DDA2

V

DD1A18

V

DDIO

V

DD

V

DD

V

DDIO

GPIO11/EPWM6B/SCIRXDB/ECAP4

GPIO22/EQEP1S/SPICLKC/SCITXDB

TMS

TDI

GPIO23/EQEP1I/SPISTEC/SCIRXDB

ADCINB0

ADCINB1

ADCINB2

ADCINB3

ADCINB7

ADCINB6

ADCINB5

ADCINB4

ADCREFIN

ADCREFM

ADCREFP

ADCRESEXT

GPIO34

GPIO1/EPWM1B/SPISIMOD

GPIO2/EPWM2A

GPIO3/EPWM2B/SPISOMID

GPIO16/SPISIMOA/TZ5

GPIO32/SDAA/EPWMSYNCI/ADCSOCAO

GPIO28/SCIRXDA/TZ5

www.ti.com

TMS320F2809, TMS320F2808, TMS320F2806

TMS320F2802, TMS320F2801, TMS320C2802

TMS320C2801, TMS320F28016, TMS320F28015

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

Figure 2-2. TMS320F2806 100-Pin PZ LQFP (Top View)

Copyright © 2003–2011, Texas Instruments Incorporated Introduction 15

Product Folder Link(s): TMS320F2809 TMS320F2808 TMS320F2806 TMS320F2802 TMS320F2801 TMS320C2802

Submit Documentation Feedback

TMS320C2801 TMS320F28016 TMS320F28015

50

49

48

47

46

45

44

43

42

41

40

39

38

37

36

35

34

33

32

31

30

29

28

27

26

76

75

74

51

53

54

55

56

57

58

59

60

61

62

63

64

65

66

67

68

69

70

71

72

73

52

77

78

79

80

81

82

83

84

85

86

87

88

89

90

91

92

93

94

95

96

97

98

99

100

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

1

GPIO0/EPWM1A

XRS

TRST

V

DD2A18

V

SS2AGND

V

DDAIO

SPISOMIB/GPIO13/TZ2

V

DD3VFL

(A)

V

DD

V

DD

V

DDIO

V

DD

V

SS

V

SS

V

SS

V

SS

V

SS

V

SS

V

DDIO

SPICLKB/GPIO26

TEST2

TEST1

GPIO25/ECAP2/SPISOMIB

XCLKIN

X1

X2

EMU1

EMU0

SPISIMOB/GPIO24/ECAP1

SPISTEB/GPIO27

TDO

TCK

SPISIMOB/GPIO12/TZ1

SPICLKB/GPIO14/TZ3

SPISTEB/GPIO15/TZ4

GPIO30/CANRXA

ADCINA3

ADCINA7

ADCINA6

ADCINA5

ADCINA4

ADCINA2

ADCINA1

ADCINA0

ADCLO

GPIO31/CANTXA

GPIO29/SCITXDA//TZ6

GPIO33/SCLA/EPWMSYNCO/ADCSOCBO

GPIO4/EPWM3A

GPIO17/SPISOMIA/TZ6

GPIO5/EPWM3B/ECAP1

GPIO18/SPICLKA

GPIO6/EPWMSYNCI/EPWMSYNCO

GPIO19/SPISTEA

GPIO7/ECAP2

GPIO9

GPIO20/EQEP1A

GPIO10/ADCSOCBO

GPIO8/ADCSOCAO

XCLKOUT

GPIO21/EQEP1B

V

SS

V

SS

V

SS

V

SS

V

SS

V

SS1AGND

V

SSA2

V

SSAIO

V

DD

V

DDA2

V

DD1A18

V

DDIO

V

DD

V

DD

V

DDIO

GPIO11

GPIO22/EQEP1S

TMS

TDI

GPIO23/EQEP1I

ADCINB0

ADCINB1

ADCINB2

ADCINB3

ADCINB7

ADCINB6

ADCINB5

ADCINB4

ADCREFIN

ADCREFM

ADCREFP

ADCRESEXT

GPIO34

GPIO1/EPWM1B

GPIO2/EPWM2A

GPIO3/EPWM2B

GPIO16/SPISIMOA/TZ5

GPIO32/SDAA/EPWMSYNCI/ADCSOCAO

GPIO28/SCIRXDA/TZ5

TMS320F2809, TMS320F2808, TMS320F2806
TMS320F2802, TMS320F2801, TMS320C2802
TMS320C2801, TMS320F28016, TMS320F28015

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

www.ti.com

A. On the C280x devices, the V

Figure 2-3. TMS320F2802, TMS320F2801, TMS320C2802, TMS320C2801 100-Pin PZ LQFP (Top View)

DD3VFL

pin is V

DDIO

.

16 Introduction Copyright © 2003–2011, Texas Instruments Incorporated

Submit Documentation Feedback

Product Folder Link(s): TMS320F2809 TMS320F2808 TMS320F2806 TMS320F2802 TMS320F2801 TMS320C2802

TMS320C2801 TMS320F28016 TMS320F28015

50

49

48

47

46

45

44

43

42

41

40

39

38

37

36

35

34

33

32

31

30

29

28

27

26

76

75

74

51

53

54

55

56

57

58

59

60

61

62

63

64

65

66

67

68

69

70

71

72

73

52

77

78

79

80

81

82

83

84

85

86

87

88

89

90

91

92

93

94

95

96

97

98

99

100

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

1

GPIO0/EPWM1A

XRS

TRST

V

DD2A18

V

SS2AGND

V

DDAIO

GPIO13/TZ2

V

DD3VFL

V

DD

V

DD

V

DDIO

V

DD

V

SS

V

SS

V

SS

V

SS

V

SS

V

SS

V

DDIO

GPIO26

TEST2

TEST1

GPIO25/ECAP2

XCLKIN

X1

X2

EMU1

EMU0

GPIO24/ECAP1

GPIO27

TDO

TCK

GPIO12/TZ1

GPIO14/TZ3

GPIO15/TZ4

GPIO30/CANRXA

(A)

ADCINA3

ADCINA7

ADCINA6

ADCINA5

ADCINA4

ADCINA2

ADCINA1

ADCINA0

ADCLO

GPIO31/CANTXA

(A)

GPIO29/SCITXDA//TZ6

GPIO33/SCLA/EPWMSYNCO/ADCSOCBO

GPIO4/EPWM3A

GPIO17/SPISOMIA/TZ6

GPIO5/EPWM3B/ECAP1

GPIO18/SPICLKA

GPIO6/EPWM4A/EPWMSYNCI/EPWMSYNCO

GPIO19/SPISTEA

GPIO7/EPWM4B/ECAP2

GPIO9

GPIO20

GPIO10/ADCSOCBO

GPIO8/ADCSOCAO

XCLKOUT

GPIO21

V

SS

V

SS

V

SS

V

SS

V

SS

V

SS1AGND

V

SSA2

V

SSAIO

V

DD

V

DDA2

V

DD1A18

V

DDIO

V

DD

V

DD

V

DDIO

GPIO11

GPIO22

TMS

TDI

GPIO23

ADCINB0

ADCINB1

ADCINB2

ADCINB3

ADCINB7

ADCINB6

ADCINB5

ADCINB4

ADCREFIN

ADCREFM

ADCREFP

ADCRESEXT

GPIO34

GPIO1/EPWM1B

GPIO2/EPWM2A

GPIO3/EPWM2B

GPIO16/SPISIMOA/TZ5

GPIO32/SDAA/EPWMSYNCI/ADCSOCAO

GPIO28/SCIRXDA/TZ5

www.ti.com

TMS320F2809, TMS320F2808, TMS320F2806

TMS320F2802, TMS320F2801, TMS320C2802

TMS320C2801, TMS320F28016, TMS320F28015

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

A. CANTXA (pin 7) and CANRXA (pin 6) pins are not applicable for the TMS320F28015.

Figure 2-4. TMS320F2801x 100-Pin PZ LQFP (Top View)

Copyright © 2003–2011, Texas Instruments Incorporated Introduction 17

Submit Documentation Feedback

Product Folder Link(s): TMS320F2809 TMS320F2808 TMS320F2806 TMS320F2802 TMS320F2801 TMS320C2802

TMS320C2801 TMS320F28016 TMS320F28015

4

C

B

A

D

E

21

3

K

F

G

H

J

5

7

6

98

10

Bottom View

TRST

TCK

TDI

TDO

TMS

EMU0

EMU1

V

DD3VFL

TEST1

TEST2

XCLKOUT

XCLKIN

X1

X2

XRS

GPIO0GPIO1

GPIO2 GPIO3 GPIO4

GPIO5

GPIO6GPIO7

GPIO9 GPIO8

GPIO10

GPIO11

GPIO12 GPIO13

GPIO14

GPIO15

GPIO16

GPIO17

GPIO18

GPIO19

GPIO20

GPIO21

GPIO22

GPIO23GPIO24GPIO25

GPIO26

GPIO27

GPIO28

GPIO29

GPIO30GPIO31

GPIO32

GPIO33

GPIO34

V

DDA2

V

DD1A18

V

SS1AGND

V

SSAIO

V

DDAIO

V

SSA2

ADCINA7

V

SS2AGND

V

DD2A18

V

DD

V

DD

V

DD

V

DD

V

DD

V

DD

V

DDIO

V

DDIO

V

DDIO

V

DDIO

V

SS

V

SS

V

SS

V

SS

V

SS

V

SS

V

SS

V

SS

V

SS

V

SS

V

SS

ADCINB2

ADCINA6

ADCINA5ADCINA4 ADCINA3 ADCINA2

ADCINA1 ADCINA0

ADCINB7

ADCINB1

ADCINB0

ADCLO

ADCRESEXT

ADCREFIN

ADCREFP

ADCREFM

ADCINB3 ADCINB5

ADCINB4

ADCINB6

TMS320F2809, TMS320F2808, TMS320F2806
TMS320F2802, TMS320F2801, TMS320C2802
TMS320C2801, TMS320F28016, TMS320F28015

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

www.ti.com

Figure 2-5. TMS320F2809, TMS320F2808, TMS320F2806,TMS320F2802, TMS320F2801,

TMS320F28016, TMS320F28015, TMS320C2802, TMS320C2801

100-Ball GGM and ZGM MicroStar BGA™ (Bottom View)

18 Introduction Copyright © 2003–2011, Texas Instruments Incorporated

Product Folder Link(s): TMS320F2809 TMS320F2808 TMS320F2806 TMS320F2802 TMS320F2801 TMS320C2802

Submit Documentation Feedback

TMS320C2801 TMS320F28016 TMS320F28015

TMS320F2809, TMS320F2808, TMS320F2806

TMS320F2802, TMS320F2801, TMS320C2802

TMS320C2801, TMS320F28016, TMS320F28015

www.ti.com

2.2 Signal Descriptions

Table 2-3 describes the signals on the 280x devices. All digital inputs are TTL-compatible. All outputs are

3.3 V with CMOS levels. Inputs are not 5-V tolerant.

Table 2-3. Signal Descriptions

PIN NO.

NAME DESCRIPTION

PIN #

TRST 84 A6 high test pin and must be maintained low at all times during normal device operation. An external

TCK 75 A10 JTAG test clock with internal pullup (I, ↑)
TMS 74 B10

TDI 73 C9

TDO 76 B9

EMU0 80 A8 (I/O/Z, 8 mA drive ↑)

EMU1 81 B7 (I/O/Z, 8 mA drive ↑)

V

DD3VFL

TEST1 97 A3 Test Pin. Reserved for TI. Must be left unconnected. (I/O)
TEST2 98 B3 Test Pin. Reserved for TI. Must be left unconnected. (I/O)

XCLKOUT 66 E8 (XCLKOUTDIV) in the XCLK register. At reset, XCLKOUT = SYSCLKOUT/4. The XCLKOUT signal

XCLKIN 90 B5 case, tie the X1 pin to GND. Alternately, when a crystal/resonator is used (or if an external 1.8-V

GGM/

PZ

96 C4

ZGM

BALL #

JTAG

JTAG test reset with internal pulldown. TRST, when driven high, gives the scan system control of
the operations of the device. If this signal is not connected or driven low, the device operates in its
functional mode, and the test reset signals are ignored.
NOTE: Do not use pullup resistors on TRST; it has an internal pull-down device. TRST is an active

pulldown resistor is required on this pin. The value of this resistor should be based on drive strength
of the debugger pods applicable to the design. A 2.2-kΩ resistor generally offers adequate
protection. Since this is application-specific, it is recommended that each target board be validated
for proper operation of the debugger and the application. (I, ↓)

JTAG test-mode select (TMS) with internal pullup. This serial control input is clocked into the TAP
controller on the rising edge of TCK. (I, ↑)

JTAG test data input (TDI) with internal pullup. TDI is clocked into the selected register (instruction
or data) on a rising edge of TCK. (I, ↑)

JTAG scan out, test data output (TDO). The contents of the selected register (instruction or data)
are shifted out of TDO on the falling edge of TCK. (O/Z 8 mA drive)

Emulator pin 0. When TRST is driven high, this pin is used as an interrupt to or from the emulator
system and is defined as input/output through the JTAG scan. This pin is also used to put the
device into boundary-scan mode. With the EMU0 pin at a logic-high state and the EMU1 pin at a
logic-low state, a rising edge on the TRST pin would latch the device into boundary-scan mode.

NOTE: An external pullup resistor is recommended on this pin. The value of this resistor should be
based on the drive strength of the debugger pods applicable to the design. A 2.2-kΩ to 4.7-kΩ
resistor is generally adequate. Since this is application-specific, it is recommended that each target
board be validated for proper operation of the debugger and the application.

Emulator pin 1. When TRST is driven high, this pin is used as an interrupt to or from the emulator
system and is defined as input/output through the JTAG scan. This pin is also used to put the
device into boundary-scan mode. With the EMU0 pin at a logic-high state and the EMU1 pin at a
logic-low state, a rising edge on the TRST pin would latch the device into boundary-scan mode.

NOTE: An external pullup resistor is recommended on this pin. The value of this resistor should be
based on the drive strength of the debugger pods applicable to the design. A 2.2-kΩ to 4.7-kΩ
resistor is generally adequate. Since this is application-specific, it is recommended that each target
board be validated for proper operation of the debugger and the application.

FLASH

3.3-V Flash Core Power Pin. This pin should be connected to 3.3 V at all times. On the ROM
parts (C280x), this pin should be connected to V

CLOCK

Output clock derived from SYSCLKOUT. XCLKOUT is either the same frequency, one-half the
frequency, or one-fourth the frequency of SYSCLKOUT. This is controlled by the bits 1, 0

can be turned off by setting XCLKOUTDIV to 3. Unlike other GPIO pins, the XCLKOUT pin is not
placed in high-impedance state during a reset. (O/Z, 8 mA drive).

External Oscillator Input. This pin is used to feed a clock from an external 3.3-V oscillator. In this
oscillator is fed into the X1 pin), tie the XCLKIN pin to GND. (I)

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

(1)

.

DDIO

(1) I = Input, O = Output, Z = High impedance, OD = Open drain, ↑ = Pullup, ↓ = Pulldown

Copyright © 2003–2011, Texas Instruments Incorporated Introduction 19

Submit Documentation Feedback

Product Folder Link(s): TMS320F2809 TMS320F2808 TMS320F2806 TMS320F2802 TMS320F2801 TMS320C2802

TMS320C2801 TMS320F28016 TMS320F28015

TMS320F2809, TMS320F2808, TMS320F2806
TMS320F2802, TMS320F2801, TMS320C2802
TMS320C2801, TMS320F28016, TMS320F28015

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

Table 2-3. Signal Descriptions (continued)

PIN NO.

NAME DESCRIPTION

PIN #

X1 88 E6 power supply. A 1.8-V external oscillator may be connected to the X1 pin. In this case, the XCLKIN

X2 86 C6

XRS 78 B8

ADCINA7 16 F3 ADC Group A, Channel 7 input (I)
ADCINA6 17 F4 ADC Group A, Channel 6 input (I)
ADCINA5 18 G4 ADC Group A, Channel 5 input (I)
ADCINA4 19 G1 ADC Group A, Channel 4 input (I)
ADCINA3 20 G2 ADC Group A, Channel 3 input (I)
ADCINA2 21 G3 ADC Group A, Channel 2 input (I)
ADCINA1 22 H1 ADC Group A, Channel 1 input (I)
ADCINA0 23 H2 ADC Group A, Channel 0 input (I)
ADCINB7 34 K5 ADC Group B, Channel 7 input (I)
ADCINB6 33 H4 ADC Group B, Channel 6 input (I)
ADCINB5 32 K4 ADC Group B, Channel 5 input (I)
ADCINB4 31 J4 ADC Group B, Channel 4 input (I)
ADCINB3 30 K3 ADC Group B, Channel 3 input (I)
ADCINB2 29 H3 ADC Group B, Channel 2 input (I)
ADCINB1 28 J3 ADC Group B, Channel 1 input (I)
ADCINB0 27 K2 ADC Group B, Channel 0 input (I)
ADCLO 24 J1 Low Reference (connect to analog ground) (I)
ADCRESEXT 38 F5 ADC External Current Bias Resistor. Connect a 22-kΩ resistor to analog ground.
ADCREFIN 35 J5 External reference input (I)

ADCREFP 37 G5

ADCREFM 36 H5

PZ

GGM/

ZGM

BALL #

Internal/External Oscillator Input. To use the internal oscillator, a quartz crystal or a ceramic
resonator may be connected across X1 and X2. The X1 pin is referenced to the 1.8-V core digital

pin must be connected to ground. If a 3.3-V external oscillator is used with the XCLKIN pin, X1 must
be tied to GND. (I)

Internal Oscillator Output. A quartz crystal or a ceramic resonator may be connected across X1 and
X2. If X2 is not used it must be left unconnected. (O)

RESET

Device Reset (in) and Watchdog Reset (out).
Device reset. XRS causes the device to terminate execution. The PC will point to the address
contained at the location 0x3FFFC0. When XRS is brought to a high level, execution begins at the
location pointed to by the PC. This pin is driven low by the DSP when a watchdog reset occurs.
During watchdog reset, the XRS pin is driven low for the watchdog reset duration of 512 OSCCLK
cycles. (I/OD, ↑)
The output buffer of this pin is an open-drain with an internal pullup. It is recommended that this pin
be driven by an open-drain device.

ADC SIGNALS

Internal Reference Positive Output. Requires a low ESR (under 1.5 Ω) ceramic bypass capacitor of

2.2 μF to analog ground. (O)
NOTE: Use the ADC Clock rate to derive the ESR specification from the capacitor data sheet that is
used in the system.

Internal Reference Medium Output. Requires a low ESR (under 1.5 Ω) ceramic bypass capacitor of

2.2 μF to analog ground. (O)
NOTE: Use the ADC Clock rate to derive the ESR specification from the capacitor data sheet that is
used in the system.

(1)

www.ti.com

20 Introduction Copyright © 2003–2011, Texas Instruments Incorporated

Submit Documentation Feedback

Product Folder Link(s): TMS320F2809 TMS320F2808 TMS320F2806 TMS320F2802 TMS320F2801 TMS320C2802

TMS320C2801 TMS320F28016 TMS320F28015

TMS320F2809, TMS320F2808, TMS320F2806

TMS320F2802, TMS320F2801, TMS320C2802

TMS320C2801, TMS320F28016, TMS320F28015

www.ti.com

Table 2-3. Signal Descriptions (continued)

PIN NO.

NAME DESCRIPTION

PIN #

V

DDA2

V

SSA2

V

DDAIO

V

SSAIO

V

DD1A18

V

SS1AGND

V

DD2A18

V

SS2AGND

V

DD

V

DD

V

DD

V

DD

V

DD

V

DD

V

DDIO

V

DDIO

V

DDIO

V

DDIO

V

SS

V

SS

V

SS

V

SS

V

SS

V

SS

V

SS

V

SS

V

SS

V

SS

V

SS

GPIO0 General-purpose input/output 0 (I/O/Z)
EPWM1A Enhanced PWM1 Output A and HRPWM channel (O)

- -

- ­GPIO1 General-purpose input/output 1 (I/O/Z)

EPWM1B Enhanced PWM1 Output B (O)
SPISIMOD SPI-D slave in, master out (I/O) (not available on 2801, 2802)

- ­GPIO2 General-purpose input/output 2 (I/O/Z)

EPWM2A Enhanced PWM2 Output A and HRPWM channel (O)

- -

- -

(1) Some peripheral functions may not be available in TMS320F2801x devices. See Table 2-2 for details.
(2) All GPIO pins are I/O/Z, 4-mA drive typical (unless otherwise indicated), and have an internal pullup, which can be selectively

enabled/disabled on a per-pin basis. This feature only applies to the GPIO pins. The GPIO function (shown in Italics) is the default at
reset. The peripheral signals that are listed under them are alternate functions.

(3) The pullups on GPIO0-GPIO11 pins are not enabled at reset.

GGM/

PZ

ZGM

BALL #

CPU AND I/O POWER PINS

15 F2 ADC Analog Power Pin (3.3 V)
14 F1 ADC Analog Ground Pin
26 J2 ADC Analog I/O Power Pin (3.3 V)
25 K1 ADC Analog I/O Ground Pin
12 E4 ADC Analog Power Pin (1.8 V)
13 E5 ADC Analog Ground Pin
40 J6 ADC Analog Power Pin (1.8 V)
39 K6 ADC Analog Ground Pin
10 E2
42 G6
59 F10
68 D7

CPU and Logic Digital Power Pins (1.8 V)

85 B6
93 D4

3 C2
46 H7
65 E9

Digital I/O Power Pin (3.3 V)

82 A7

2 B1
11 E3
41 H6
49 K9
55 H10
62 F7 Digital Ground Pins
69 D10
77 A9
87 D6
89 A5
94 A4

GPIOA AND PERIPHERAL SIGNALS

47 K8

44 K7

45 J7

(3)

(3)

(3)

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

(1)

(1) (2)

Copyright © 2003–2011, Texas Instruments Incorporated Introduction 21

Submit Documentation Feedback

Product Folder Link(s): TMS320F2809 TMS320F2808 TMS320F2806 TMS320F2802 TMS320F2801 TMS320C2802

TMS320C2801 TMS320F28016 TMS320F28015

TMS320F2809, TMS320F2808, TMS320F2806
TMS320F2802, TMS320F2801, TMS320C2802
TMS320C2801, TMS320F28016, TMS320F28015

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

Table 2-3. Signal Descriptions (continued)

PIN NO.

NAME DESCRIPTION

PIN #

GPIO3 General-purpose input/output 3 (I/O/Z)
EPWM2B Enhanced PWM2 Output B (O)
SPISOMID SPI-D slave out, master in (I/O) (not available on 2801, 2802)

GGM/

PZ

ZGM

BALL #

48 J8

(1)

- ­GPIO4 General-purpose input/output 4 (I/O/Z)

EPWM3A Enhanced PWM3 output A and HRPWM channel (O)

- -

51 J9

(1)

- ­GPIO5 General-purpose input/output 5 (I/O/Z)

EPWM3B Enhanced PWM3 output B (O)
SPICLKD SPI-D clock (I/O) (not available on 2801, 2802)

53 H9

(1)

ECAP1 Enhanced capture input/output 1 (I/O)
GPIO6 General-purpose input/output 6 (I/O/Z)

EPWM4A Enhanced PWM4 output A and HRPWM channel (O) (not available on 2801, 2802)
EPWMSYNCI External ePWM sync pulse input (I)

56 G9

(1)

EPWMSYNCO External ePWM sync pulse output (O)
GPIO7 General-purpose input/output 7 (I/O/Z)

EPWM4B Enhanced PWM4 output B (O) (not available on 2801, 2802)
SPISTED SPI-D slave transmit enable (I/O) (not available on 2801, 2802)

58 G8

(1)

ECAP2 Enhanced capture input/output 2 (I/O)
GPIO8 General-purpose input/output 8 (I/O/Z)

EPWM5A Enhanced PWM5 output A and HRPWM channel (O) (not available on 2801, 2802)
CANTXB Enhanced CAN-B transmit (O) (not available on 2801, 2802, F2806)

60 F9

(1)

ADCSOCAO ADC start-of-conversion A (O)
GPIO9 General-purpose input/output 9 (I/O/Z)

EPWM5B Enhanced PWM5 output B (O) (not available on 2801, 2802)
SCITXDB SCI-B transmit data (O) (not available on 2801, 2802)

61 F8

(1)

ECAP3 Enhanced capture input/output 3 (I/O) (not available on 2801, 2802)
GPIO10 General-purpose input/output 10 (I/O/Z)

EPWM6A Enhanced PWM6 output A and HRPWM channel (O) (not available on 2801, 2802)
CANRXB Enhanced CAN-B receive (I) (not available on 2801, 2802, F2806)

64 E10

(1)

ADCSOCBO ADC start-of-conversion B (O)
GPIO11 General-purpose input/output 11 (I/O/Z)

EPWM6B Enhanced PWM6 output B (O) (not available on 2801, 2802)
SCIRXDB SCI-B receive data (I) (not available on 2801, 2802)

70 D9

(1)

ECAP4 Enhanced CAP Input/Output 4 (I/O) (not available on 2801, 2802)
GPIO12 General-purpose input/output 12 (I/O/Z)

TZ1 Trip Zone input 1 (I)
CANTXB Enhanced CAN-B transmit (O) (not available on 2801, 2802, F2806)

1 B2

(2)

SPISIMOB SPI-B Slave in, Master out (I/O)
GPIO13 General-purpose input/output 13 (I/O/Z)

TZ2 Trip zone input 2 (I)
CANRXB Enhanced CAN-B receive (I) (not available on 2801, 2802, F2806)

95 B4

(2)

SPISOMIB SPI-B slave out, master in (I/O)
GPIO14 General-purpose input/output 14 (I/O/Z)

TZ3 Trip zone input 3 (I)
SCITXDB SCI-B transmit (O) (not available on 2801, 2802)

8 D3

(2)

SPICLKB SPI-B clock input/output (I/O)
GPIO15 General-purpose input/output 15 (I/O/Z)

TZ4 Trip zone input 4 (I)
SCIRXDB SCI-B receive (I) (not available on 2801, 2802)

9 E1

(2)

SPISTEB SPI-B slave transmit enable (I/O)
GPIO16 General-purpose input/output 16 (I/O/Z)

SPISIMOA SPI-A slave in, master out (I/O)
CANTXB Enhanced CAN-B transmit (O) (not available on 2801, 2802, F2806)

50 K10

(2)

TZ5 Trip zone input 5 (I)

(1) The pullups on GPIO0-GPIO11 pins are not enabled at reset.
(2) The pullups on GPIO12-GPIO34 are enabled upon reset.

(1)

www.ti.com

22 Introduction Copyright © 2003–2011, Texas Instruments Incorporated

Submit Documentation Feedback

Product Folder Link(s): TMS320F2809 TMS320F2808 TMS320F2806 TMS320F2802 TMS320F2801 TMS320C2802

TMS320C2801 TMS320F28016 TMS320F28015

TMS320F2809, TMS320F2808, TMS320F2806

TMS320F2802, TMS320F2801, TMS320C2802

TMS320C2801, TMS320F28016, TMS320F28015

www.ti.com

Table 2-3. Signal Descriptions (continued)

PIN NO.

NAME DESCRIPTION

PIN #

GPIO17 General-purpose input/output 17 (I/O/Z)
SPISOMIA SPI-A slave out, master in (I/O)
CANRXB Enhanced CAN-B receive (I) (not available on 2801, 2802, F2806)
TZ6 Trip zone input 6 (I)

GPIO18 General-purpose input/output 18 (I/O/Z)
SPICLKA SPI-A clock input/output (I/O)
SCITXDB 54 H8 SCI-B transmit (O) (not available on 2801, 2802)

- -

- ­GPIO19 General-purpose input/output 19 (I/O/Z)

SPISTEA SPI-A slave transmit enable input/output (I/O)
SCIRXDB 57 G10 SCI-B receive (I) (not available on 2801, 2802)

- -

- ­GPIO20 General-purpose input/output 20 (I/O/Z)

EQEP1A Enhanced QEP1 input A (I)
SPISIMOC SPI-C slave in, master out (I/O) (not available on 2801, 2802)
CANTXB Enhanced CAN-B transmit (O) (not available on 2801, 2802, F2806)

GPIO21 General-purpose input/output 21 (I/O/Z)
EQEP1B Enhanced QEP1 input A (I)
SPISOMIC SPI-C master in, slave out (I/O) (not available on 2801, 2802)
CANRXB Enhanced CAN-B receive (I) (not available on 2801, 2802, F2806)

GPIO22 General-purpose input/output 22 (I/O/Z)
EQEP1S Enhanced QEP1 strobe (I/O)
SPICLKC SPI-C clock (I/O) (not available on 2801, 2802)
SCITXDB SCI-B transmit (O) (not available on 2801, 2802)

GPIO23 General-purpose input/output 23 (I/O/Z)
EQEP1I Enhanced QEP1 index (I/O)
SPISTEC SPI-C slave transmit enable (I/O) (not available on 2801, 2802)
SCIRXDB SCI-B receive (I) (not available on 2801, 2802)

GPIO24 General-purpose input/output 24 (I/O/Z)
ECAP1 Enhanced capture 1 (I/O)
EQEP2A Enhanced QEP2 input A (I) (not available on 2801, 2802)
SPISIMOB SPI-B slave in, master out (I/O)

GPIO25 General-purpose input/output 25 (I/O/Z)
ECAP2 Enhanced capture 2 (I/O)
EQEP2B Enhanced QEP2 input B (I) (not available on 2801, 2802)
SPISOMIB SPI-B master in, slave out (I/O)

GPIO26 General-purpose input/output 26 (I/O/Z)
ECAP3 Enhanced capture 3 (I/O) (not available on 2801, 2802)
EQEP2I Enhanced QEP2 index (I/O) (not available on 2801, 2802)
SPICLKB SPI-B clock (I/O)

GPIO27 General-purpose input/output 27 (I/O/Z)
ECAP4 Enhanced capture 4 (I/O) (not available on 2801, 2802)
EQEP2S Enhanced QEP2 strobe (I/O) (not available on 2801, 2802)
SPISTEB SPI-B slave transmit enable (I/O)

GPIO28 General-purpose input/output 28. This pin has an 8-mA (typical) output buffer. (I/O/Z)
SCIRXDA SCI receive data (I)

- ­TZ5 Trip zone input 5 (I)

GPIO29 General-purpose input/output 29. This pin has an 8-mA (typical) output buffer. (I/O/Z)
SCITXDA SCI transmit data (O)

- ­TZ6 Trip zone 6 input (I)

(1) The pullups on GPIO12-GPIO34 are enabled upon reset.

GGM/

PZ

ZGM

BALL #

52 J10

63 F6

67 E7

71 D8

72 C10

83 C7

91 C5

99 A2

79 C8

92 D5

4 C3

(1)

(1)

(1)

(1)

(1)

(1)

(1)

(1)

(1)

(1)

(1)

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

(1)

(1)

(1)

Copyright © 2003–2011, Texas Instruments Incorporated Introduction 23

Submit Documentation Feedback

Product Folder Link(s): TMS320F2809 TMS320F2808 TMS320F2806 TMS320F2802 TMS320F2801 TMS320C2802

TMS320C2801 TMS320F28016 TMS320F28015

TMS320F2809, TMS320F2808, TMS320F2806
TMS320F2802, TMS320F2801, TMS320C2802
TMS320C2801, TMS320F28016, TMS320F28015

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

Table 2-3. Signal Descriptions (continued)

PIN NO.

NAME DESCRIPTION

PIN #

GPIO30 General-purpose input/output 30. This pin has an 8-mA (typical) output buffer. (I/O/Z)
CANRXA Enhanced CAN-A receive data (I)

- -

- ­GPIO31 General-purpose input/output 31. This pin has an 8-mA (typical) output buffer. (I/O/Z)

CANTXA Enhanced CAN-A transmit data (O)

- -

- ­GPIO32 General-purpose input/output 32 (I/O/Z)

SDAA I2C data open-drain bidirectional port (I/OD)
EPWMSYNCI Enhanced PWM external sync pulse input (I)
ADCSOCAO ADC start-of-conversion (O)

GPIO33 General-Purpose Input/Output 33 (I/O/Z)
SCLA I2C clock open-drain bidirectional port (I/OD)
EPWMSYNCO Enhanced PWM external synch pulse output (O)
ADCSOCBO ADC start-of-conversion (O)

GPIO34 General-Purpose Input/Output 34 (I/O/Z)

- -

- -

- -

(1) The pullups on GPIO12-GPIO34 are enabled upon reset.

100 A1

GGM/

PZ

43 G7

ZGM

BALL #

6 D2

7 D1

5 C1

(1)

(1)

(1)

(1)

www.ti.com

(1)

(1)

NOTE

Some peripheral functions may not be available in TMS320F2801x devices. See Table 2-2
for details.

24 Introduction Copyright © 2003–2011, Texas Instruments Incorporated

Submit Documentation Feedback

Product Folder Link(s): TMS320F2809 TMS320F2808 TMS320F2806 TMS320F2802 TMS320F2801 TMS320C2802

TMS320C2801 TMS320F28016 TMS320F28015

INT[12:1]

Real-Time JTAG

(TDI, TDO, , TCK,

TMS, EMU0, EMU1)

TRST

C28x CPU
(100 MHz)

NMI, INT13

Memory Bus

INT14

SYSCLKOUT

RS

CLKIN

12-Bit ADC

ADCSOCA/B

SOCA/B

16 Channels

12

6

32

XCLKOUT

XRS

XCLKIN

X1

X2

32

System Control

(Oscillator, PLL,

Peripheral Clocking,

Low-Power Modes,

Watchdog)

ePWM1/2/3/4/5/6

(12 PWM Outputs,

6 Trip Zones,

6 16-bit Timers)

eCAP1/2/3/4

(4 32-bit Timers)

eQEP1/2

eCAN-A/B (32 mbox)

External Interrupt

Control

PIE

(96 Interrupts)

(A)

FIFO

FIFO

FIFO

SCI-A/B

GPIO MUX

I2C-A

SPI-A/B/C/D

4

8

4

2

16

4

GPIOs

(35)

TINT0

TINT1

TINT2

7

Peripheral Bus

M0 SARAM

1K x 16

M1 SARAM

1K x 16

Boot ROM

4K x 16

(1-wait state)

L0 SARAM

4K x 16
(0-wait)

L1 SARAM

4K x 16
(0-wait)

(B)

H0 SARAM

8K x 16
(0-wait)

(C)

ROM
32K x 16 (C2802)
16K x 16 (C2801)

FLASH

128K x 16 (F2809)

64K x 16 (F2808)
32K x 16 (F2806)
32K x 16 (F2802)
16K x 16 (F2801)

16K x 16 (F2801x)

OTP

1K x 16

(D)

Protected by the code-security module.

32-bit CPU TIMER 0

32-bit CPU TIMER 1

32-bit CPU TIMER 2

www.ti.com

3 Functional Overview

TMS320F2809, TMS320F2808, TMS320F2806

TMS320F2802, TMS320F2801, TMS320C2802

TMS320C2801, TMS320F28016, TMS320F28015

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

A. 43 of the possible 96 interrupts are used on the devices.
B. Not available in F2802, F2801, C2802, and C2801.
C. Not available in F2806, F2802, F2801, C2802, and C2801.
D. The 1K x 16 OTP has been replaced with 1K x 16 ROM for C280x devices.

Figure 3-1. Functional Block Diagram

Copyright © 2003–2011, Texas Instruments Incorporated Functional Overview 25

Submit Documentation Feedback

Product Folder Link(s): TMS320F2809 TMS320F2808 TMS320F2806 TMS320F2802 TMS320F2801 TMS320C2802

TMS320C2801 TMS320F28016 TMS320F28015

0x00 0000

Block Start

Address

Data Space

Prog Space

M0 Vector − RAM (32 x 32)

(Enabled if VMAP = 0)

M1 SARAM (1K y 16)

0x00 0400

Peripheral Frame 0

0x00 0800

0x00 0D00

Peripheral Frame 1

(protected)

0x00 6000

Peripheral Frame 2

(protected)

0x00 7000

L0 SARAM (0-wait)

(4K y 16, Secure Zone, Dual-Mapped)

0x00 8000

L1 SARAM (0-wait)

(4K y 16, Secure Zone, Dual-Mapped)

0x00 9000

H0 SARAM (0-wait)

(8K y 16, Dual-Mapped)

0x00 A000

0x00 C000

OTP

(1K y 16, Secure Zone)

0x3D 7800

0x3D 7C00

FLASH

(128K y 16, Secure Zone)

0x3D 8000

0x3F 7FF8

128-bit Password

L0 SARAM (0-wait)

(4K y 16, Secure Zone, Dual-Mapped)

0x3F 8000

L1 SARAM (0-wait)

(4K y 16, Secure Zone, Dual-Mapped)

0x3F 9000

H0 SARAM (0-wait)

(8K y 16, Dual-Mapped)

0x3F A000

0x3F F000

Boot ROM (4K y 16)

Vectors (32 y 32)

(enabled if VMAP = 1, ENPIE = 0)

0x3F FFC0

Low 64K [0000 − FFFF]

(24x/240x equivalent data space)

High 64K [3F0000 − 3FFFFF]

(24x/240x equivalent program space)

PIE Vector − RAM

(256 x 16)

(Enabled if ENPIE = 1)

0x00 0E00

0x3F C000

Reserved

Reserved

Reserved

Reserved

Reserved

M0 SARAM (1K y 16)

0x00 0040

Reserved

TMS320F2809, TMS320F2808, TMS320F2806
TMS320F2802, TMS320F2801, TMS320C2802
TMS320C2801, TMS320F28016, TMS320F28015

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

3.1 Memory Maps

www.ti.com

A. Memory blocks are not to scale.
B. Peripheral Frame 0, Peripheral Frame 1, and Peripheral Frame 2 memory maps are restricted to data memory only.

C. Protected means the order of Write followed by Read operations is preserved rather than the pipeline order.
D. Certain memory ranges are EALLOW protected against spurious writes after configuration.

26 Functional Overview Copyright © 2003–2011, Texas Instruments Incorporated

Product Folder Link(s): TMS320F2809 TMS320F2808 TMS320F2806 TMS320F2802 TMS320F2801 TMS320C2802

User program cannot access these memory maps in program space.

Figure 3-2. F2809 Memory Map

Submit Documentation Feedback

TMS320C2801 TMS320F28016 TMS320F28015

0x00 0000

Block Start

Address

Data Space

Prog Space

M0 SARAM (1K y 16)

M1 SARAM (1K y 16)

0x00 0400

Peripheral Frame 0

0x00 0800

0x00 0D00

Peripheral Frame 1

(protected)

0x00 6000

Peripheral Frame 2

(protected)

0x00 7000

L0 SARAM (0-wait)

(4K y 16, Secure Zone, Dual-Mapped)

0x00 8000

L1 SARAM (0-wait)

(4K y 16, Secure Zone, Dual-Mapped)

0x00 9000

H0 SARAM (0-wait)

(8K y 16, Dual-Mapped)

0x00 A000

0x00 C000

OTP

(1K y 16, Secure Zone)

0x3D 7800

0x3D 7C00

FLASH

(64K y 16, Secure Zone)

0x3E 8000

0x3F 7FF8

128-bit Password

L0 SARAM (0-wait)

(4K y 16, Secure Zone, Dual-Mapped)

0x3F 8000

L1 SARAM (0-wait)

(4K y 16, Secure Zone, Dual-Mapped)

0x3F 9000

H0 SARAM (0-wait)

(8K y 16, Dual-Mapped)

0x3F A000

0x3F F000

Boot ROM (4K y 16)

Vectors (32 y 32)

(enabled if VMAP = 1, ENPIE = 0)

0x3F FFC0

Low 64K [0000 − FFFF]

(24x/240x equivalent data space)

High 64K [3F0000 − 3FFFFF]

(24x/240x equivalent program space)

PIE Vector − RAM

(256 x 16)

(Enabled if ENPIE = 1)

0x00 0E00

0x3F C000

M0 Vector − RAM (32 x 32)

(Enabled if VMAP = 0)

0x00 0040

Reserved

Reserved

Reserved

Reserved

Reserved

Reserved

www.ti.com

TMS320F2809, TMS320F2808, TMS320F2806

TMS320F2802, TMS320F2801, TMS320C2802

TMS320C2801, TMS320F28016, TMS320F28015

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

B. Peripheral Frame 0, Peripheral Frame 1, and Peripheral Frame 2 memory maps are restricted to data memory only.

C. Protected means the order of Write followed by Read operations is preserved rather than the pipeline order.
D. Certain memory ranges are EALLOW protected against spurious writes after configuration.

Copyright © 2003–2011, Texas Instruments Incorporated Functional Overview 27

A. Memory blocks are not to scale.

Product Folder Link(s): TMS320F2809 TMS320F2808 TMS320F2806 TMS320F2802 TMS320F2801 TMS320C2802

User program cannot access these memory maps in program space.

Figure 3-3. F2808 Memory Map

Submit Documentation Feedback

TMS320C2801 TMS320F28016 TMS320F28015

0x00 0000

Block Start

Address

Data Space

0x00 0400

0x00 0800

0x00 0D00

0x00 6000

0x00 7000

0x00 8000

0x00 9000

0x00 A000

0x3D 7800

0x3D 7C00

0x3F 7FF8
0x3F 8000

0x3F 9000

0x3F A000

0x3F F000

0x3F FFC0

OTP

(1K y 16, Secure Zone)

FLASH

(32K y 16, Secure Zone)

Boot ROM (4K y 16)

Low 64K [0000−FFFF]

(24x/240x equivalent data space)

High 64K [3F0000 −3FFFF]

(24x/240x equivalent program space)

M1 SARAM (1K y 16)

L0 SARAM (0-wait)

(4K y 16, Secure Zone, Dual-Mapped)

L1 SARAM (0-wait)

(4K y 16, Secure Zone, Dual-Mapped)

L0 SARAM (0-wait)

(4K y 16, Secure Zone, Dual-Mapped)

L1 SARAM (0-wait)

(4K y 16, Secure Zone, Dual-Mapped)

128-bit Password

0x3F 0000

Prog Space

Peripheral Frame 0

Peripheral Frame 1

(protected)

Peripheral Frame 2

(protected)

PIE Vector − RAM

(256 x 16)

(Enabled if ENPIE = 1)

Vectors (32 y 32)

(enabled if VMAP = 1, ENPIE = 0)

0x00 0E00

Reserved

Reserved

Reserved

Reserved

Reserved

Reserved

M0 SARAM (1K y 16)

M0 Vector − RAM (32 x 32)

(Enabled if VMAP = 0)

0x00 0040

TMS320F2809, TMS320F2808, TMS320F2806
TMS320F2802, TMS320F2801, TMS320C2802
TMS320C2801, TMS320F28016, TMS320F28015

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

www.ti.com

A. Memory blocks are not to scale.
B. Peripheral Frame 0, Peripheral Frame 1, and Peripheral Frame 2 memory maps are restricted to data memory only.

User program cannot access these memory maps in program space.
C. Protected means the order of Write followed by Read operations is preserved rather than the pipeline order.
D. Certain memory ranges are EALLOW protected against spurious writes after configuration.

28 Functional Overview Copyright © 2003–2011, Texas Instruments Incorporated

Product Folder Link(s): TMS320F2809 TMS320F2808 TMS320F2806 TMS320F2802 TMS320F2801 TMS320C2802

Figure 3-4. F2806 Memory Map

Submit Documentation Feedback

TMS320C2801 TMS320F28016 TMS320F28015

0x00 0000

Block Start

Address

0x00 0400

0x00 0800

0x00 0D00

0x00 6000

0x00 7000

0x00 8000

0x00 9000

0x3D 7800

0x3F 0000

0x3F 7FF8

0x3F 8000

0x3F 9000

0x3F F000

0x3F FFC0

OTP (F2802 Only)

(A)

(1K y 16, Secure Zone)

FLASH (F2802) or ROM (C2802)

(32K y 16, Secure Zone)

L0 (0-wait)

(4K y 16, Secure Zone, Dual-Mapped)

Boot ROM (4K y 16)

128-bit Password

Data Space Prog Space

0x3D 7C00

Vectors (32 y 32)

(enabled if VMAP = 1, ENPIE = 0)

Low 64K [0000−FFFF]

(24x/240x equivalent data space)

High 64K [3F0000 −3FFFF]

(24x/240x equivalent program space)

ЙЙЙЙЙ

ЙЙЙЙЙ

ЙЙЙЙЙ

ЙЙЙЙЙ

ЙЙЙЙЙ

M0 SARAM (1K y 16)

M1 SARAM (1K y 16)

Peripheral Frame 0

Peripheral Frame 1

(protected)

Peripheral Frame 2

(protected)

L0 SARAM (0-wait)

(4K y 16, Secure Zone, Dual-Mapped)

ЙЙЙЙЙ

ЙЙЙЙЙ

ЙЙЙЙЙ

ЙЙЙЙЙ

ЙЙЙЙЙ

ЙЙЙЙЙ

PIE Vector − RAM

(256 x 16)

(Enabled if ENPIE = 1)

0x00 0E00

Reserved

Reserved

Reserved

Reserved

Reserved

Reserved

0x00 0040

M0 Vector − RAM (32 x 32)

(Enabled if VMAP = 0)

www.ti.com

TMS320F2809, TMS320F2808, TMS320F2806

TMS320F2802, TMS320F2801, TMS320C2802

TMS320C2801, TMS320F28016, TMS320F28015

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

A. The 1K x 16 OTP has been replaced with 1K x 16 ROM in C2802.
B. Memory blocks are not to scale.
C. Peripheral Frame 0, Peripheral Frame 1, and Peripheral Frame 2 memory maps are restricted to data memory only.

D. Protected means the order of Write followed by Read operations is preserved rather than the pipeline order.
E. Certain memory ranges are EALLOW protected against spurious writes after configuration.
F. Some locations in ROM are reserved for TI. See Table 3-5 for more information.

Copyright © 2003–2011, Texas Instruments Incorporated Functional Overview 29

User program cannot access these memory maps in program space.

Figure 3-5. F2802, C2802 Memory Map

Product Folder Link(s): TMS320F2809 TMS320F2808 TMS320F2806 TMS320F2802 TMS320F2801 TMS320C2802

Submit Documentation Feedback

TMS320C2801 TMS320F28016 TMS320F28015

0x00 0000

Block Start

Address

0x00 0400

0x00 0800

0x00 0D00

0x00 6000

0x00 7000

0x00 8000

0x00 9000

0x3D 7800

0x3F 4000

0x3F 7FF8

0x3F 8000

0x3F 9000

0x3F F000

0x3F FFC0

OTP (F2801/F2801x Only)

(A)

(1K y 16, Secure Zone)

FLASH (F2801) or ROM (C2801)

(16K y 16, Secure Zone)

L0 (0-wait)

(4K y 16, Secure Zone, Dual-Mapped)

Boot ROM (4K y 16)

128-bit Password

Data Space Prog Space

0x3D 7C00

Vectors (32 y 32)

(enabled if VMAP = 1, ENPIE = 0)

Low 64K [0000−FFFF]

(24x/240x equivalent data space)

High 64K [3F0000 −3FFFF]

(24x/240x equivalent program space)

ЙЙЙЙЙ

ЙЙЙЙЙ

ЙЙЙЙЙ

ЙЙЙЙЙ

ЙЙЙЙЙ

M1 SARAM (1K y 16)

Peripheral Frame 0

Peripheral Frame 1

(protected)

Peripheral Frame 2

(protected)

L0 SARAM (0-wait)

(4K y 16, Secure Zone, Dual-Mapped)

ЙЙЙЙЙ

ЙЙЙЙЙ

ЙЙЙЙЙ

ЙЙЙЙЙ

ЙЙЙЙЙ

ЙЙЙЙЙ

PIE Vector − RAM

(256 x 16)

(Enabled if ENPIE = 1)

0x00 0E00

Reserved

Reserved

Reserved

M0 SARAM (1K y 16)

M0 Vector − RAM (32 x 32)

(Enabled if VMAP = 0)

0x00 0040

Reserved

Reserved

Reserved

TMS320F2809, TMS320F2808, TMS320F2806
TMS320F2802, TMS320F2801, TMS320C2802
TMS320C2801, TMS320F28016, TMS320F28015

SPRS230M–OCTOBER 2003–REVISED MARCH 2011

www.ti.com

A. The 1K x 16 OTP has been replaced with 1K x 16 ROM in C2801.
B. Memory blocks are not to scale.
C. Peripheral Frame 0, Peripheral Frame 1, and Peripheral Frame 2 memory maps are restricted to data memory only.

D. Protected means the order of Write followed by Read operations is preserved rather than the pipeline order.
E. Certain memory ranges are EALLOW protected against spurious writes after configuration.
F. Some locations in ROM are reserved for TI. See Table 3-5 for more information.

30 Functional Overview Copyright © 2003–2011, Texas Instruments Incorporated

User program cannot access these memory maps in program space.

Figure 3-6. F2801, F28015, F28016, C2801 Memory Map

Product Folder Link(s): TMS320F2809 TMS320F2808 TMS320F2806 TMS320F2802 TMS320F2801 TMS320C2802

Submit Documentation Feedback

TMS320C2801 TMS320F28016 TMS320F28015
