Texas instruments TI InterActive! Getting Started
Getting Started
with
TI InterActive!
Microsoft, Windows, Windows NT, Abode, Acrobat, and Reader are trademarks of their
respective owners.
TI InterActive! contains Formula One from Visual Components. Copyright 1994-1997. All
rights reserved.
Exercise 5 data provided by Michael J. Shepston & Associates, www.scottsdalelaw.com
Copyright © 2000, 2001, 2003 Texas Instruments Incorporated.
é
Important
Texas Instruments makes no warranty, either express or implied,
including but not limited to any implied warranties of
merchantability and fitness for a particular purpose, regarding
any programs or book materials and makes such materials
available solely on an “as-is” basis.
In no event shall Texas Instruments be liable to anyone for
special, collateral, incidental, or consequential damages in
connection with or arising out of the purchase or use of these
materials, and the sole and exclusive liability of Texas
Instruments, regardless of the form of action, shall not exceed
the purchase price of this product. Moreover, Texas Instruments
shall not be liable for any claim of any kind whatsoever against
the use of these materials by any other party.
Table of Contents
Use the hands-on exercises in this book to familiarize yourself
with the basic features of the TI InterActive! software.
Introduction........................................................................................... 4
Installing TI InterActive!...................................................................... 5
Exercise 1: Performing Calculations in a Document..................... 10
Exercise 2: Storing Values as Variables........................................... 18
Exercise 3: Creating a Function-Graphing Assignment ................27
Exercise 4: Creating a Report ........................................................... 33
Exercise 5: Analyzing Data from a Web Site................................... 40
Exercise 6: Reviewing Miscellaneous Functions ........................... 46
Essential Skills for Using TI InterActive! ........................................ 50
Where Do I Go from Here?................................................................58
Texas Instruments (TI) Support and Service Information ...........59
Texas Instruments (TI) End-User License Agreement.................. 60
Index..................................................................................................... 62
Getting Started with TI InterActive! 3
Introduction
TI InterActive! is a document-creation program with the math
features of a powerful TI graphing handheld. It lets you build
documents that contain not only text and pictures but also
dynamically connected graphing and calculation objects.
What makes a TI InterActive! document different?
What can I do with TI InterActive!?
The interactive math objects in a TI InterActive! document set it
apart from the documents that you create with other Windows®
applications. Your documents can use data from the Internet,
TI data-collection tools, and supported TI graphing handhelds—
TI-83, TI-83 Plus, TI-83 Plus Silver Edition, TI-89, TI-92, TI-92
Plus, Voyage™ 200.
Internet data
Math calculations
Graphing
Handheld
Data-collection devices
Teachers can create:
Compelling classroom activities
¦
— You can create
activities that encourage learning by discovery.
Captivating lessons
¦
that cover necessary information while allowing exploration.
Homework that encourages learning
¦
conventional assignments or “live” assignments in the form of
TI InterActive! files that students can complete and return.
Students can create:
Informative reports
¦
preformatted labs and other types of reports.
Attractive, clear homework papers
¦
homework that shows the flow of your work with your results.
4 Getting Started with TI InterActive!
— You can design attractive lessons
— You can build printed,
— You or your teacher can create
— You can create
Installing TI InterActive!
TI InterActive! can be installed from a TI InterActive! CD-ROM
or from a file downloaded from the Web. Check the system
requirements below, and follow the steps for the installation
method that applies to you.
System requirements
The PC that you use to run TI InterActive! must have:
•
Microsoft® Windows® 98, Windows 2000, Windows ME,
Windows NT®, or Windows XP.
•
Microsoft Internet Explorer 5.5 or later.
•
Available RAM: 16 MB for Windows 98 (20 MB RAM
recommended), 32 MB for Windows ME or Windows NT, 64
MB for Windows 2000, or 128 MB for Windows XP.
•
A hard disk with available storage space: 19 MB for
TI InterActive! and 45–111 MB for Internet Explorer
(depending on installation type).
•
A CD-ROM drive (if installing from a CD).
•
A video monitor with VGA or better resolution.
•
A mouse or mouse-compatible pointing device.
To use the Internet features of TI InterActive!, your PC must have
a working Internet connection.
To read the electronic documentation, Acrobat Reader 3.02 or
later is also required (16 MB disk space required).
To transfer programs and data between TI InterActive! and a
supported graphing handheld, or to collect samples from a
Calculator-Based Laboratory™ (CBL™), or Calculator-Based
Laboratory 2™ (CBL 2™), or Calculator-Based Ranger™ (CBR™),
your PC must have:
•
TI Connect™ 1.3.0.1 (11 MB disk space required).
•
An available USB port or a serial communication port
configured as Com 1, 2, 3, or 4. You also need the appropriate
TI Connectivity Cable — USB for Mac/Windows, Serial for
Windows (black), or Serial for Mac/Windows (gray).
Getting Started with TI InterActive! 5
For more information regarding TI products and support:
•
Visit the TI Education home page: education.ti.com
•
Or search the TI-Cares™ KnowledgeBase and submit e-mail
inquiries: education.ti.com/support
•
Or call toll-free: (800) TI-CARES (800) 842-2737
Installing the software on your computer
TIP
: If you currently
have Display set for
Large Fonts, change to
Small Fonts before
rebooting.
Starting TI InterActive!
To install TI InterActive! on your computer:
1. Close all open programs. Open programs can slow the
installation process.
2. Insert the TI InterActive! CD in your CD-ROM drive.
3. If the installer does not start automatically, click the
Windows Start button, and then click Run. Type
D:\setup.exe,
and then press Enter on the computer
keyboard. (Substitute the letter of your CD-ROM drive if it is
not D.)
4. Follow the installation instructions that are displayed. When
the installer has completed, it returns you to the Windows
desktop. You might need to reboot the computer before using
TI InterActive!.
After completing the installation, it’s a good idea to start
TI InterActive! and test the connections that you plan to use.
¦
There will be a new icon on your desktop. Double-click it.
Depending on your machine and its configuration, it may take
a few seconds for the application to open. TI InterActive! starts
with the cursor at the top of a blank document.
— or —
¦
Click the Windows Start button, point to Programs,
TI InterActive!, and then click TI InterActive!.
6 Getting Started with TI InterActive!
: You can open a
TIP
saved TI InterActive!
document from the
Windows Explorer by
double-clicking the
document.
TI InterActive! toolbar
Performs calculations and defines
variables and functions.
Specifies the mode settings for each
object.
Graphs functions and plots statistical
data.
Generates a table of values for
defined functions.
Enters and/or edits lists of data.
Enters and/or edits matrices.
Performs typical spreadsheet
operations.
Performs statistics regression
calculations on lists of data.
The buttons on the TI InterActive! toolbar give you quick access
to the program’s main features.
Performs statistical tests and
intervals.
Inserts a slider that lets you change
variable values.
Transfers data to/from a connected
TI device.
Captures the screen of a connected
TI device.
Collects data from a CBL™,
CBL 2™, or CBR™.
Browses the Web and extracts data
directly from Web pages.
Sends e-mail attachments of your
current document.
Getting Started with TI InterActive! 7
Testing your Internet connection
If you want to use the Internet features of TI InterActive!, your
PC must have a working Internet connection. Perform this test to
confirm that your connection is working.
1. On the toolbar, click the Web Browser button
. The
built-in Web browser opens and displays the TI InterActive!
home page.
2. Click the browser’s Close button . The Internet test is
complete.
What to do if the test fails
If you have problems completing this test, verify that you are
connected to an Internet Service Provider. If you are on a local
area network (LAN), check to ensure that you can access other
areas of your network or server. If you are using a dial-up
connection, check to ensure that your modem is working
properly.
Testing your e-mail connection
Many Web sites contain a button or block of text that you can
click to send an e-mail message to support personnel. Perform
this test to make sure your e-mail program is registered as your
e-mail client.
1. Click the Windows Start button, and then click Run.
2. In the text box, type
address.
8 Getting Started with TI InterActive!
mailto:
followed by your own e-mail
3. Click OK. Your e-mail software should start up and open a
blank message with your address shown as the recipient.
4. Type some text in the body of the message, and send it. When
you receive the message, the e-mail test is complete.
What to do if the test fails
Exiting TI InterActive!
: You can also exit
TIP
by pressing Alt+F4 or
clicking the Close
button
.
If you have problems completing this test, verify that you have an
e-mail client installed. If you do not, contact your Internet Service
Provider for assistance.
From the menu, click File 8 Exit. When you exit TI InterActive!,
you are prompted to save any unsaved changes that you have
made. Click the No button if you do not want to save the changes.
Getting Started with TI InterActive! 9
Exercise 1: Performing Calculations in a Document
You perform many calculations in TI InterActive! documents by
inserting a Math Box object. Data that you store and functions
that you define in a Math Box can be used by subsequent
objects, such as graphs, tables, and other Math Boxes.
This exercise shows you how to:
¦
Enter and format ordinary text.
¦
Access and use the Math Palette.
¦
Use a Math Box object to perform simple calculations in a
document.
¦
Enter math and other special functions symbols.
¦
Save a TI InterActive! document.
10 Getting Started with TI InterActive!
Entering and formatting text
Evaluating a math expression
Entering text in a TI InterActive! document is similar to entering
text in most text editors and word processors. For this exercise,
you enter a page title and then change the font and point size.
1. Type
Homework
on the first line of your document.
2. Highlight the typed text and select a different font type and
size from the font dialog box (Format 8 Font).
3. Place the cursor at the end of the line and press the Enter key
on the computer keyboard to start a new line.
Suppose you want to evaluate an expression such as
28 • 43
12
and
display both the expression and its result within the document.
1. Click the Math Box button
on the TI InterActive! toolbar.
An empty Math Box is inserted, accompanied by the TI Math
Palette.
The Math Box looks like
this while you are editing.
Math Palette
Getting Started with TI InterActive! 11
TIP
: Make sure you
insert a Math Box for
the expression.
TI InterActive! cannot
evaluate expressions
that you type as
ordinary text.
TIP
: You can also close
the Math Box by
selecting
Math Palette, or by
clicking anywhere in the
document.
on the
Setting the form of results
2. Type
2^8*43à12
into the Math Box. Press the Enter key on
the computer keyboard or click
on the Math Palette to
evaluate the expression. TI InterActive! evaluates the
expression, displays the result, and creates another Math
Box.
Expression is evaluated when you press the
Enter key on the computer keyboard, click
on the Math Palette, or click outside
of the Math Box.
Result
Empty math box for next calculation
3. Press the Esc key on the computer keyboard to close the
unused Math Box.
You might expect to see a decimal result instead of
preceding example. A close decimal equivalent is
917.33333
2752à3
in the
..., but
that’s only an approximation. By default, TI InterActive! retains
the more precise form:
2752à3
.
You can, however, change the form of any Math Box result by
setting the Computation Mode of the box.
1. Click anywhere in the existing Math Box to select it. A solid
border appears around the Math Box to show that it is
selected.
TIP
: You can also rightclick on the Math Box
and select Mode from
the drop-down menu.
12 Getting Started with TI InterActive!
2. Click the Mode Settings button
toolbar.
on the TI InterActive!
Note the three options available under Computation Mode:
: In Automatic mode,
TIP
you can force a decimal
result by using a
decimal in the entry.
Automatic
Uses
Approximate
where possible, but uses
Exact
when your entry contains a
decimal point. Also, certain functions may
display
Approximate
results even if your entry
does not contain a decimal point.
Any result that is not a whole number is
Exact
displayed in a fractional or symbolic form (
, etc.). This mode reduces rounding errors
,
2
p
that could be introduced by intermediate
results in chained calculations.
Approximate
All numeric results, where possible, are
displayed in decimal form.
3. Click the
Approximate
option to select it, and click OK. The
result in the Math Box becomes a decimal approximation.
4. Click the Mode Settings button
Computation Mode back to
again, and change the
Automatic
, the original setting,
and click OK.
1à2
,
The decimal point
in the entry forces
the Automatic
result to a decimal.
This chart compares the Computation Mode settings.
Entry
8à4 2 2 2.
8à6
8.5ù3
sqrt(2)à2
pù
2
pù
2. 6.28319
Automatic
Result
4
3
25.5
2
2
p
⋅
2
2
Getting Started with TI InterActive! 13
Exact
Result
4
3
51
2
2
2
p
⋅
p
⋅
2
Approximate
Result
1.33333
25.5
.707107
6.28319
6.28319
Entering an expression from the TI Math Palette
: If you type
TIP
the Math Box, you have
to also type the opening
parenthesis (.
cos
in
The TI Math Palette resembles a calculator keyboard. If you
prefer to use the mouse instead of the keyboard, you can click
the buttons on the palette.
1. Click to the right and below the Math Box that you have
already entered, and press Enter. This places the cursor at
the end of the document.
2. Click the Math Box button
. An empty Math Box is
inserted beneath the previous one.
3. On the Math Palette, click
X ª µ ¶ d
. The entry looks
like this:
4. Click
. TI InterActive! displays the result and presents a
new empty Math Box, ready to receive an entry.
5. Press the Esc key on the computer keyboard to close the
unused Math Box, or click anywhere in the document.
14 Getting Started with TI InterActive!
Keystroke and Math Palette equivalents
: Click the
TIP
button
Math Palette for a list
of all TI InterActive!
functions and
symbols.
Catalog
on the
For this operation: Type this: Or click this:
×
(multiply)
÷
–
(subtract or negate)
x
2
x
–1
x
x
y
*
à
(hyphen)
–
sqrt(x)
^
x
^
x
y^x
2
–1
p
e
|
‡
x
x
Z
2
–1
: Click the a
TIP
drop-down menu to
find the
This character is
also available from
the X key.
q
character.
Appearance of items in a Math Box
ex
p
i
(imaginary number)
Let variable x = value y
Store value y to variable x
#e^(x)
pi
#i
x
:
y
=
y
x
À
x
e
p
i
:=
§
or
y
x
:
=
Using the TI Math Palette, you can change the appearance
properties of the entry and the result independently. You can
even hide the entry or its result.
Some of the properties you can control include:
¦
The font, size, and color used for the entry or result.
¦
Whether the result is displayed on the next line or the same
line as the entry.
¦
Whether the entry or result is displayed in text format,
2
such as
(x^2)/(4y)
, or in math format, such as
x
4y
.
¦
Whether the entry or result is shown or hidden. You cannot
hide both.
Getting Started with TI InterActive! 15
Changing the appearance of a Math Box
: Once you evaluate
TIP
the expression, the Input
and Output settings
return to the default
settings.
In this example, you can change the appearance of items in a
Math Box. Suppose you want to hide the expression or the result.
1. Click the down arrow
next to the default option in the
Input box. Click Hide Input.
2. To hide the result, click the down arrow
default option in the Output box. Click Hide Output.
16 Getting Started with TI InterActive!
next to the
3. Click (or on the Math Palette menu, click Edit 4 Properties)
to modify properties such as scaling factors, font type, size, and
color.
Saving a TI InterActive! document
TI InterActive! uses a .tii extension to identify its documents.
1. On the TI InterActive! toolbar, click the Save button
.
Because you have not yet saved this document,
TI InterActive! displays the Save As dialog box.
2. If necessary, navigate to the folder where you want to store
the document.
3. In the File name box, type a name (such as
first report
) for
the document.
4. Click Save.
Note:
You can also export a document to other formats. Choose
Export from the File menu. The options are Html Web Page, Word
Compatible, Rich Text Format, and Plain Text.
Getting Started with TI InterActive! 17
Exercise 2: Storing Values as Variables
You can store a value as a named variable and then use the name
to refer to that value in subsequent Math Boxes and graphs. When
TI InterActive! evaluates an expression containing the name, it
substitutes the value stored under that name.
This exercise shows you how to:
¦
Define a variable and assign a value to it.
¦
Display a variable’s value in a document.
¦
Remove a variable.
¦
Perform symbolic calculations.
¦
Reposition TI InterActive! objects in a document.
¦
Reset all variables.
18 Getting Started with TI InterActive!
Storing a value in a variable
: If you have
TIP
changed a document
and then attempt to
create a new document,
TI InterActive! gives you
the option to save the
first document before
proceeding.
This example creates a variable named
3
of the expression 5+8
in that variable.
num
and stores the result
1. On the TI InterActive! toolbar, click the New button
start a new, blank document.
2. Click the Math Box button
3. Type the variable name
num
to insert a new Math Box.
and then type := (both
characters are required from the keyboard), or click
the Math Palette.
num :=
4. Type the expression
will be stored in
num := 5+8^3
. The result—not the expression—
5+8^3
num
.
This means: Let the variable “num”
equal the result of 5+8
3
.
5. Press Enter on the computer keyboard. TI InterActive!
creates the variable
num
and stores the result there.
to
on
Checking a variable’s value
You can check the value of a variable by entering its name as the
entry in a subsequent Math Box.
1. Click the Math Box button
to insert a new Math Box, if
necessary.
2. Type the variable name
keyboard. The value currently stored in
num
and press Enter on the computer
num
is displayed as
the result.
Getting Started with TI InterActive! 19
Loading...
