CUSTOMER SERVICE INFORMATION
PLEASE READ!
For your questions regarding this product,
please contact us at:
Taylor Precision Products
2220 Entrada Del Sol, Suite A
Las Cruces, New Mexico 88001
1-866-843-3905
www.taylorusa.com
Please contact us before returning to retailer.
Wireless Thermometer with
Remote Pager plus Timer
Instruction Manual
2
3
Thank you for purchasing a Taylor®Wireless
Thermometer with Remote Pager plus Timer
This product helps to eliminate over-cooking or under-cooking
foods. Presetting the thermometer to the recommended cooking
temperatures and/or cooking times is simple and ensures that food
will be cooked to your preferred taste. Please read this instruction
manual carefully before use. Keep these instructions handy for future
reference.
Battery Information
The base thermometer unit operates on 2 AAA batteries (included).
The remote unit operates on 2 AAA batteries (included).
The thermometer units are equipped with a low battery warning:
Base Unit: A low battery icon appears in the upper right corner of
the LCD.
Remote Sensor:
The low battery light illuminates.
If these warnings appear, or if readings grow dim or irregular, the batteries may need to be replaced.
To install or replace the batteries on both units:
1. Use 2 AAA batteries for each unit.Always replace both batteries
at the same time; do not combine old and new batteries.
2. Remove the battery compartment cover, located on the back of
the unit.
3. Remove the old batteries from the battery compartment (if applicable).
4. Place the new batteries into the compartment as indicated.
5. Replace the battery compartment cover.
NOTE: Do not dispose of batteries in fire. Batteries may explode or leak.
Do not mix old and new batteries.Do not mixAlkaline, carbon-zinc
(standard) or Nickel-Cadmium (rechargeable) batteries. Remove the batteries if the thermometer will not be used for a long period of time.
3
On/Off Operation
1. Place the base unit as close as possible to the remote sensor. This
will ensure easy synchronization between the base and remote.
After set up is complete, keep the units within effective transmission range (within 200 feet).
2. Turn on the base unit first by pressing the On/Off button.The LCD
will turn on and the unit will beep.
3. Turn on the remote unit by pressing the On/Off
button (located on the back).The remote will
vibrate, beep and the “ ” light will blink.
4. Set volume on remote: Off–Low–High. The
volume switch is located on the top of the
remote.
5.The remote will automatically search for a
signal from the base. The remote’s ready light
“ ” will blink, indicating the remote is receiving a signal from the base.The ready light will
continue to blink every 8 seconds again indicating that the remote is receiving signals from
the base.
6. If transmission is interrupted, the ready light
will stop blinking and the remote will vibrate 3 times every 30 seconds.To synchronize the units again, place the base and
remote near each other and press and hold
the “ ” button located on the back of the
base unit.
Press “On/Off ” on base unit
Press “On/Off ” on remote
2
3
Select volume level
4
Green light =
transmission OK
5
4
No green light &
remote vibrates=
Press “ ” on base
6
7.Auto off feature to conserve battery power:The base unit will automatically turn off after 30 minutes if there is no change in temperature or no buttons are pressed.The remote unit will vibrate
then automatically turn off if the transmission signal is lost for 5
minutes.The remote unit will also turn off automatically if the base
is turned off.
Positioning the thermometer units
1. The base unit may be placed on a flat surface using the clip stand
on the back of the unit. It may also be attached to a metal surface
using the magnets on the back.
2. The remote sensor’s clip stand may be used to stand the remote
on a flat surface or clip on a belt loop.The magnets may be used
to attach it to a metal surface. Use the lanyard to wear it around
the neck (take care not to allow the remote to touch hot items or
working appliances). Simply thread the lanyard through the opening on the remote and loop the lanyard through itself.
3. During use, keep the base unit and remote sensor within effective
transmission range, which is 200 feet in usual circumstances.
4. Do Not stick to surfaces that exceed 200°F (100°C).
Thermometer Programming
Operation
1. Your thermometer is preset to read temperatures in Fahrenheit.To switch to Celsius,
push the switch on the back of the base unit
to ºC.
2. If necessary, press the “On/Off” buttons.
The default setting “Beef” appears.
5
°F/°C selection
Turn on base, then remote
1
2
3. Press the “Meat” button to scroll through
the meat choices. Press
the “Select” button to
select the displayed
meat type.The default
taste setting “Medium” flashes.
4. Press the “Taste” button to scroll through
the taste choices. Press
the “Select” button to
select the displayed
taste.The Set Temperature digits will blink.
5. Press the “Select” button to accept
the Set Temperature displayed. Or
change the temperature manually.
Press the “Hr/+” button to increase
the temperature by 1 degree or
press the “Min/-” button to decrease the temperature by 1 degree. (Note: when the
temperature is manually changed, a “CUST” icon will appear to
note a custom temperature has been programmed.)
6. Press “Select” when the desired temperature is displayed.The Set Temperature digits
stop flashing.The unit will beep, indicating
the thermometer is set.
7. To change the programming, press the Meat
button and repeat the steps above.
6
Press “Meat”
3
then “Select”
3
Press “Taste”
4
then “Select”
4
Can press “Hr/+” or “Min/-” to
change temperature
5
Press “Select”.
Unit beeps and is set.
6
General Cooking Procedures
1. Preheat the grill or oven to desired cooking temperature. Place
the food in the oven or grill.
2. Sterilize the metal probe by inserting it into
an appropriate solution such as boiling water for several minutes.
Make sure the sensor plug on the end of the cord is plugged into
the thermometer base unit. (Note: if the probe is not plugged in
properly, the display will show “LL.L”.)
3. Insert the metal probe into the thickest part
of the food to be cooked. Do not come in
contact with bone, fat or gristle, as these
areas will not provide accurate temperature
readings.
4. Place the food into the oven or grill.The thermometer display unit
must be placed outside of the oven or grill (do not put the plastic
display unit in the oven or grill).The probe cord will be held in
place by the oven door. Be careful not to crimp the probe cord
with the oven door or grill lid. Note: If cooking on a grill, be sure
the grill lid does not crimp the cord – the lid should be open
enough to allow space for the cord. The cord should not come
into direct contact with cooking surface or flame.
5.The current internal temperature of the food appears on the LCD
screen of the base unit.As cooking progresses, the base and remote units will signal temperature alerts in the following manner:
• When the current temperature is within 20 degrees of the target
temperature, the remote will beep 3 times, vibrate and flash; the
base will beep 3 times and flash. Note: the unit uses to different
beep tones to help you identify between thermometer and timer
notifications. Only the remote will vibrate.
Sensor plug
2
3 beeps =
20 degrees from done
5
7
• When the current temperature is within 10 degrees of the target
temperature, the remote will beep 5 times, vibrate and flash.The
base will beep 5 times and flash.
• When the current temperature and target temperature are equal
(indicating the food is done), the units consistently beep, vibrate
and flash (base will not vibrate). Press the “Start/Stop” button to
turn off the alarm.
6. When the food is ready, remove it from the oven or grill with a
heat resistant glove. DO NOTTOUCH THE HOT PROBE OR
FOOD WITHYOUR BARE HANDS!
7. The base unit has a convenient backlight feature for easy temperature viewing.While the
unit is on, press the Backlight button to turn
on the backlight for 10 seconds. The base
backlight will also automatically illuminate
when any key is depressed.
8. The food may continue to cook after removed from heat.The
probe may be left in the food to continue monitoring internal temperature.
8
Press “Backlight” for light
7
5 beeps =
10 degrees from done
Constant beeps =
done.
Press “Start/Stop
to stop beeps.
Timer Operation
This unit is also equipped with a convenient timer. It can operate as
an independent timer or work along with the thermometer function.
1. If necessary, turn the base and remote on
(see on/off operation).
2. Press the “Timer/Thermometer” button.
The Timer digits flash.
3. Press the “Hr/+” button to set the hours.
Press the “Min/-” button to set the minutes.
Press “Start/Stop” to
confirm. Press and hold
the buttons to advance the
digits quickly.
4. Press the “Start/Stop” button to start timer
countdown.
5. Press the “Start/Stop” button to pause timer.
Press “Start/Stop” again to resume timer
countdown.To add extra time, press
“Start/Stop” to pause,“Hr/+” or “Min/-” to increase time, and “Start/Stop” to resume.To reset timer to zero,
first pause the timer, then press “Hr/+” and “Min/-” at the same
time to clear.
9
Press “Timer/
Thermometer”
2
Press “Hr/+”
3
Press “Min/-”
3
then “Select”
3
Press “Start/Stop”
4
6.As time progresses, the base and remote units will signal timer
alerts in the following manner:
• 10 minutes before the time is up, the remote will beep 3 times,
vibrate and flash. The base will beep 3 times and flash.
Note: that the unit uses to different beep tones to help you identify between thermometer and timer notifications. Only the remote will vibrate.
• 5 minutes before the time is up, the remote will beep 5 times, vibrate and flash.The base will beep 5 times and flash.
• When the timer reaches zero, the units consistently beep, vibrate
and flash (only remote vibrates)
10
3 beeps =
10 minutes from done
6
5 beeps =
5 minutes from done
6
Constant beeps = done
6
Press “Start/Stop”
to stop beeps
7. Press the “Start/Stop” button on the base unit to stop the alarm
and timer.
8. The timer will time up to 39 hours, 59 minutes and 59 seconds.
(The seconds will appear when remaining time is less than one
minute).
Clock Feature
To program the clock:
1. While the base unit is off, press the “Select”
button.The clock digits flash.
2. Press the “Hr/+” button to change the
hour. Press the “Min/-”
button to change the
minutes. Press and
hold the buttons to advance the digits quickly.
3. Press “Select”.The clock is set.
RESET: If you are having problems with the
unit, you can press the reset button on the
back of the base.This will cause the same effect as taking the batteries out.The unit will reset itself.
Care and Precautions
1. Always wear a heat resistant glove when touching the metal probe
or cord during or just after cooking. DO NOT TOUCH WITH
BARE HANDS!
2. Keep the metal probe and cord away from children.
3. Sterilize metal probe each time before use.
4. Do not expose the thermometer to: water, direct heat, a hot surface or direct sunlight for an extended period of time.This may
cause damage to the plastic casing or the electric circuits and
components inside.
11
Press “Select”
1
Press “Hr/+” and then2Press “Min/-” to set time
2
Press “Select”
3
5. Do not expose the probe directly to flames. Do not put the probe
in foods to exceed cooking temperatures of 500°F (260°C), as this
may reduce the life and accuracy of the thermometer sensor.
6. Do not use this thermometer in a microwave oven.
7. Moisture inside the plug-in opening of the thermometer will result
in an incorrect temperature reading. Dry the sensor plug with a
cloth every time before plugging it into the thermometer.
8. DO NOT USE THE CORD AND PROBE FOR OVEN
TEMPERATURES HIGHER THAN 500°F (260 °C).
9. Do not dispose of batteries in fire. Batteries may explode or leak.
Do not mix old and new batteries. Do not mix Alkaline, carbonzinc (standard) or Nickel-Cadmium (rechargeable) batteries. Remove the batteries if the thermometer will not be used for a long
period of time.
Minimum Internal Cooking Temperatures as
Recommended by the USDA*
IMPORTANT! These are the minimum INTERNAL temperatures
that food much reach to be considered safe to eat, no matter how
you prepare them.We recommend the following guide lines but personal taste temperatures may be different from the below.The temperature can be manually changed if desired. Press “HR/+” to
increase or “MIN/-” to decrease the temperature by 1 degree.
Fresh Ground Beef,Veal, Pork 160°F / 72°C
Beef,Veal, Lamb - roast, steaks, chops
*Rare 140°F / 60°C
Medium Rare 145°F / 63°C
Medium 160°F / 72°C
Well Done 170°F / 77°C
Fresh Pork - roast, steaks, chops
Medium 160°F / 72°C
Well Done 170°F / 77°C
Ham
Fresh (Raw) 160°F / 72°C
Precooked (to reheat) 140°F / 60°C
Poultry
Ground Chicken,Turkey 165°F / 74°C
Whole Chicken,Turkey 165°F / 74°C
Breast, Roasts 165°F / 74°C
Thighs and Wings 165°F / 74°C
Fish - cook until opaque and
flakes easily with fork 145°F / 63°C
Stuffing - cooked alone or in bird 165°F / 74°C
Egg Dishes 160°F / 72°C
Leftovers, Casseroles 165°F / 74°C
12
*The USDA does NOT
recommend RARE
140°F as a safe eating
temperature.
When running the
probe cable into
an oven be sure to
gently close
the door to avoid
crimping or
severing the cable.
Transmission Collision
Signals from other household devices, such as doorbells,home security
systems and entry controls,may interfere.This is normal and does not
affect the general performance of this product.The transmission will
resume once the interference recedes.
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation.If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the
following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
Modifications not authorized by the manufacturer may void users
authority to operate this device.
One Year Limited Warranty
Taylor® warrants this product to be free from defects in material or
workmanship for one (1) year from date of original purchase for
original purchaser. It does not cover damages or wear resulting from
accident, misuse, abuse, commercial use, or unauthorized adjustment
and/or repair.
If service is required, do not return to retailer. Should this product
require service (or replacement at our option), please pack the item
carefully and return it prepaid, along with store receipt showing the
date of purchase and a note explaining reason for return to:
Taylor Precision Products
2220 Entrada Del Sol, Suite A
Las Cruces, New Mexico 88001
www.taylorusa.com
There are no express warranties except as listed above.This warranty gives you specific legal rights, and you may have other rights
which vary from state to state.
Questions about this product:
If service is required, do not return to retailer. For service call 1
(866) 843-3905 from 7:30 am to 4:30 pm, Mountain Standard Time,
Monday through Friday.To assist us in serving you, please have the
model number and date of purchase available.
For additional product information, or warranty information in
Canada or elsewhere outside the USA, please contact us through
www.taylorusa.com.
Made to our exact specifications in China.
© 2009 Taylor Precision Products and its affiliated companies, all
rights reserved.Taylor® and Leading the Way in Accuracy are registered trademarks of Taylor Precision Products and its affiliated companies. All rights reserved.
CP1479.818 10.09
14
Loading...
