Sony SLV-D910N-R User Manual
3-084-917-11 (1) GB
DVD Player/
Video Cassette
Recorder
Operating Instructions
PAL
SLV-D910N/R
© 2003 Sony Corporation
WARNING
Welcome!
To prevent fire or shock
hazard, do not expose
the unit to rain or
moisture.
To a v oi d electrical shoc k,
do not open the cabinet.
Refer servicing to
qualified personnel only.
Mains lead must only be
changed at a qualified
service shop.
This appliance is classified as
a CLASS 1 LASER product.
The CLASS 1 LASER
PRODUCT MARKING is
located on the rear exterior.
CAUTION
The use of optical instruments
with this product will in crease
eye hazard. As the laser beam
used in this DVD player/
Video Cassette Recorde r is
harmful to eyes, do not
attempt to disassemble the
cabinet.
Refer servicing to qualified
personnel only.
Precautions
Safety
• This unit operates on 220 –
240 V AC, 50 Hz. Check
that the unit’s operating
voltage is iden tical with
your local power supply.
• To prevent fire or shock
hazard, do not place objects
filled with liquids, such as
vases, on the apparatus.
• The unit is not
disconnected from the AC
power source (mains) as
long as it is co nn ected to
the wall outl et, even if the
unit itself has been turne d
off.
Installing
• Do not install the unit in a
confined space such as a
book or similar unit.
• Do not install the unit in an
inclined position. It is
designed to be operated in a
horizontal position only.
• Keep th e unit and discs
away from equip men t with
strong magnets, such as
microwave ovens, or large
loudspeakers.
• Do not place heavy objects
on the unit.
• Do not place the unit on
surfaces (rugs, blankets,
etc.) or near materi als
(curtains, draperies) t hat
may block the ventilation
slots.
Compatible colour
systems
This VCR is designed to
record using the PAL (B/G or
D/K) or MESECAM (B/G or
D/K) colour system and play
back using the PAL (B/G or
D/K) or MESECAM (B/G or
D/K) and NTSC 4.43 colour
systems. Recording of video
sources based on other colour
systems cannot be guaranteed.
Thank you for purchasing this
Sony DVD Player/Video
Cassette Recorder. Befo re
operating th is player, please
read this manual thoroughly
and retain it for future
reference.
2
WARNING
Caution
For use of the VCR
Television programmes, films,
video tapes and other
materials may be copyrighted.
Unauthorized rec ording of
such material may be contrary
to the provisions of the
copyright laws. Also, use of
this recorder with cable
television transmission may
require authorization from the
cable tele vision trans mitter
and/or programme owner.
For use of the DVD
player
This product incorporates
copyright protection
technology that is protected by
method claims of certai n U.S.
patents, other intellectual
property rights owned by
Macrovision Corporation, and
other rights owners. Use of
this copyright protection
technology must be authorized
by Macrovision Corpo rat i on,
and is intended for home and
other limited viewing uses
only unless otherwise
authorized by Macrovision
Corporation. Reverse
engineering or disassembly is
prohibited.
Caution
3
Table of contents
2 WARN ING
2 Welcome!
3 Caution
6 About this manual
6 This player can play the f ollowing discs
7 Notes about discs
Getting Started
8 Step 1 : Unpacking
9 Step 2 : Setting up the remote commander
11 Step 3 : Connecting the DVD-VCR
14 Step 4 : Setting up the DVD-VCR with the Auto Set Up function
17 Step 5 : Selecting the TV system
19 Step 6 : Selecting a language
20 Step 7 : Setting the clock
22 Step 8 : Presetting channels
30 Setting the PAY-TV/Canal Plus decoder
Basic Operations
33 Playing disc s
37 Guide to the on-screen display
39 Playing a tape
42 Recording TV programmes
46 Recording TV pr og ra m me s using the
timer
50 Checking/changing/cancelling timer
settings
4
Table of contents
Advanced Hookups
52 A/V Receiver hookup
54 S-Video hookup
DVD Settings and
Adjustments
55 Audio Setup
58 Screen Setup
61 Setting the display or sound track
language
63 Parental Control (limiting playback
by children)
DVD Additional Operations
66 Using the DVD’ s menu
68 Zooming into a scene
69 Changing the angles
70 Displaying the subtitle
71 Various play mode functions
(Programme play, Shuffle play,
Repeat play)
75 Changing the sound
76 Virtual surround setting
78 Playing an MP3 audio track
82 Playing JPEG image files
86 Playing VIDEO CDs with “MENU
ON/OFF” functions
VCR Additional Operations
88 Playing a tape with SQPB function
89 Quick Timer Recording
91 Recording stereo and bilingual
programmes
94 Searching using index function
96 Adjusting the picture (tracking)
98 Changing menu options
100 Editing
Additional Information
103 General setup information
105 Troubleshooting
110 Glossary
112 Specifications
114 Index to parts an d controls
119 DVD Audio/Subtitle Language
120 Index
Table of contents
5
About this manual
• The meaning of the icons used in thi s man ua l is
described below:
Icon Meaning
Functions available for DVD
VIDEOs and DVD-RWs/
DVD-Rs in video mode or
DVD+RWs/DVD+Rs
Functions avai lable for VID EO
CDs, Super VCDs or CD-Rs/
CD-RWs in video CD format
or Super VCD format
Functions available for DATA
CDs (CD-ROMs/C D -Rs / CD RWs containing MP3* audio
tracks or JPEG files)
Functions available for music
CDs or CD-Rs/CD-RWs in
music CD format
Functions available for VHS
VIDEOs
* MP3 (MPEG 1 Audio Layer 3) is a standard form at
defined by ISO /MPEG w hich compre sses audio data.
This player can play the following disc s
Format of discs
DVD VIDEO
VIDEO CD
Music CD
Region code
Your player has a reg i on code printed on the
back of the unit and only wil l play DVD VIDEO
discs (playback onl y) labelled with ide nt i cal
region code s. T his system is used to protect
copyrights.
DVDs labelled will also play on this
ALL
player.
If you try to play an y ot her DVD, the mess age
“Playback prohibited by area limitations.” will
appear on the TV screen. Depending on the
DVD, no region code indic ation ma y be labell ed
even though playing the DVD is prohibited by
area restrictions.
X
SLV–DXXXX
00V 00Hz
NO.
00W
Region code
0-000-000-00
Example of discs that the player
cannot play
The player cannot pla y t he f ol l ow i ng discs:
• All CD-ROMs (including PHOTO CDs)/
CD-Rs/CD-RWs other than those recorded in
the follow ing formats:
– music CD format
– video CD format
– MP3 or JPE G format that conforms to
ISO9660* Level 1/L evel 2, or its extended
format, Joliet
• Data part of C D -Extras
• DVD-RWs in VR mode
• DVD-ROMs
• DVD Audio discs
• HD layer on Super Audio CDs
* A logical format of files and folders on CD-ROMs,
defined by ISO (International Standard
Organization).
The “DVD VIDEO” logo is a trademark.
6
Also, the play er canno t play the foll owin g disc s:
• A DVD with a different region code.
• A disc that has a non-standard shape (e.g.,
card, heart).
• A disc with paper or stickers on it.
• A disc that has t he adhe sive of celloph ane tap e
or a sticker still left on it.
Note
Some DVD-RWs/DVD-Rs, DVD+RWs/DVD+Rs or
CD-Rs/CD-RWs cannot be played on this player due to
the recording quality or physical condition of the disc,
or the characteristics of the recording device.
Furthermore, the d isc w ill not play if it has not been
correctly finalized. For more information , se e the
operating instructions fo r th e reco rd i ng de vice.
Note that discs created in the Packet Write format
cannot be played.
Note on playback operations of
DVDs and VIDEO CDs
Some playba ck operati ons of DVDs and VIDEO
CDs may be intentionally set by software
producers. Since this player plays DVDs and
VIDEO CDs ac cording to the disc contents the
software producers designed, so m e playback
features ma y no t be av ail ab le . A ls o, ref er to t he
instructions supplied with the DVDs or VIDEO
CDs.
Music discs encoded with
copyright protection technologies
This product is de si gned to playback di scs that
conform to the Compact Disc (CD) standard.
Recently, various m usic discs encoded w it h
copyright pr ot ection technologies are marketed
by some record companies. Please be aware that
among those discs, there are some that do not
conform to the CD standard and may not be
playable by this product.
Notes about discs
• To keep the disc clean, handle the disc by its
edge. Do not touch the sur fa ce.
• Do not expose the disc to direct sunlight or
heat sources such as hot air du cts, or l eave it in
a car parked in dir ect sunlight as the
temperature may rise considerably inside the
car.
• After playin g, store the disc in its case.
• Clean the disc with a cleaning cloth.
Wipe the disc from the center out.
• Do not use solvents such as benzine, thinner,
commercially available cleaners, or anti-static
spray intended for vi nyl LPs.
7
Getting Started
Step 1 :Unpacking
Check that you have received the following items with the DVD-VCR:
• Remote commander • Aerial cable
• R6 (size AA) batteries • Audio cord
(pinplug ×2 y pinplug ×2)
•Video cord
(pinplug ×1 y pinplug ×1)
Note
• The supplied remote commander is for the exclusive use of this DVD-VCR.
Check your model name
The instructions in this manual are for the 2 models: SLV-D910N and SL V-D910R. Check
your model name by looking at the rear panel of your DVD-VCR.
SLV-D910N is the model used for illustration purposes. Any difference in operation is
clearly indicated in the text, for example, “SLV-D910N only”.
8
Unpacking
Step 2 : Setting up the remote commander
Inserting the batteries
Insert two size AA (R6) batteries
by matching the + and – on the
batteries to the diagram inside the
battery compartment.
Insert the negative (–) end first,
then push in and down until the
positive (+) end clicks into
position.
Getting Started
Using the remote
Remote sensor
commander
You can use this remote
commander to operate this DVDVCR and a Sony TV. Buttons on
the remote commander marked
with a dot (•) can be used to
operate your Sony TV.
If the TV does not have the
symbol near the remote sensor , this
remote commander will not
operate the TV.
To operate Set TV / DVD·VIDEO to
the DVD player DVD·VIDEO
the VCR DVD·VIDEO
your TV TV
Notes
• With normal use, the batteries should last about three to six mont hs.
• If you do not use the remote commander for an extended period of time, remove the batteries
to avoid possible damage from batter y le akage.
• Do not use a new battery with an old one.
• Do not use different types of batteries.
• Do not leave the remote commander in an extremely hot or humid place.
• Do not drop any foreign object into the remote casing, particularly when replacing the batteries.
• Do not expose the remote sensor to di re ct light from the sun or lighting appa rat us. Do ing so
may cause a malfunction.
TV / DVD·VIDEO
SELECT VIDEO
SELECT DVD
, then press SELECT DVD and point at the remote sensor at
the DVD-VCR
, then press SELECT VIDEO and point at the remote sensor
at the DVD-VCR
and point at the remote sens or at your TV
continued
Setting up the remote commander
9
Controlling other TVs with the remote commander
The remote commander is preprogrammed to control non-Sony TVs. If your TV is
listed in the following table, set the ap propriate manufacturer’s code number.
Set TV / DVD·VIDEO at the top of the remote commander to TV.
1
Hold down ?/1, and enter your TV’s code number using the number buttons.
2
Then release ?/1.
Now you can use the ?/1, VOL +/–, PROG +/–, MUTING*, TV/VIDEO, 0-9 and
-/--* buttons to control your TV. You can also use the buttons marked with a dot (•) to
control a Sony TV. To control the DVD-VCR, reset TV
DVD·VIDEO.
* for Sony TV only
Code numbers of controllable TVs
If more than one code number is listed, try entering th em on e at a time until you find
the one that works with your TV.
/ DVD·VIDEO to
Manufacturer Code number
Sony 01, 02
Akai 68
Ferguson 52
Grundig 10, 11
Hitachi 24
JVC 33
Loewe 45
Mivar 09, 70
NEC 66
Nokia 15, 16, 69
Notes
• If you enter a new code numbe r, the code number previously entered will be erased.
• If the TV uses a different remote con tro l syst em from the one programmed to work with the
DVD-VCR, you cannot control your TV with the remote comm ander.
• When you replace the batteries of the remote commander, the code number may change. Set
the appropriate code number every time you replace the batterie s.
Manufacturer Code number
Panasonic 17, 49
Philips 06, 07 , 08
Saba 12, 13
Samsung 22, 23
Sanyo 25
Sharp 29
Telefunken 36
Thomson 43
Toshiba 38
10
Setting up the remote commander
Step 3 : Connecting the DVD-VCR
1
Note that “Advanced Hookups” (page 52) explains additional hookup methods that
will optimize the picture and sound for a true “hometheatre” experience.
If your TV has a Scart (EURO-AV ) connector, see page 12.
If your TV does not have a Scart (EURO-AV) connector
Mains
lead
AERIAL IN
Aerial cable (supplied)
: Signal flow
Disconnect the aerial cable from yo ur TV
and connect it to on the rear panel o f the
DVD-VCR.
to mains
Getting Started
2
3
Connect of the DVD-VC R and the
aerial input of your TV using the supplied
aerial cable.
Connect the mains lead to the mains.
Note
• When you connect the DVD-VCR a nd your TV only with an aerial ca ble, you have to tune
your TV to the DVD-VCR (see page 14).
continued
Connecting the DVD-VCR
11
If your TV has a Scar t (EURO-AV) connector
1
2
3
Scart
(EURO-AV)
: Signal flow
LINE-1
(EURO AV)
AERIAL IN
Aerial cable (supplied)
Scart cable (not supplied)
Disconnect the aerial cable from your
TV and connect it to on the rear
panel of the DVD-VCR.
Connect of the DVD-VCR and the
aerial input of your TV using the
supplied aerial cable.
Connect LINE-1 (EURO AV) on the
DVD-VCR and the Scart (EURO-AV)
connector on the TV with the optional
Scart cable.
This connection improves picture and
sound quality. Whenever you want to
watch the DVD-VCR picture, press
TV/VIDEO to display the VCR
indicator in the display window.
Mains
lead
to mains
4
12
Connecting the DVD-VCR
Connect the mains lead to the mains.
Additional connection
T o a satellite or digital tuner
with Line Through
Using the Line Through
function, you can watch
programmes from a satellite or
digital tuner connected to this
DVD-VCR on the TV even
when the DVD-VCR is turned
off. When you turn on the
satellite or digital tuner, this
DVD-VCR automatically sends
the signal from the satellite or
digital tuner to the TV without
turning itself on.
Connect the satellite or digital tuner to the LINE-3 connector as shown above.
1
Turn off the DVD-VCR.
2
To watch a programme, turn on the satellite or digital tuner and the TV.
Notes
• This function may not work with some types of satellite or digital tuners.
• When the DVD-V CR is turned o ff, set the TV to the v ideo channel.
LINE-3
LINE OUT
Scart cable (not supplied)
: Signal flow
Getting Started
Connecting the DVD-VCR
13
Step 4 : Setting up the DVD-VCR with the
Auto Set Up function
Before using the DVD-VCR for the first
time, set up the DVD-VCR using the Auto
Set Up function. With this function, you can
set TV channels, and DVD-VCR clock
automatically.
SET UP
V/v/B/b
ENTER
1
Turn on your TV and set it to the video channel.
If your TV does not have a Scart (EURO-AV) connector, tune the TV to
channel 32 (the initial RF channel for this DVD-VCR). Refer to your TV
manual for TV tuning instructions. If the picture does not appear clearly,
see “To change the RF channel” on page 16.
2
Connect the mains lead to the mains.
• SLV-D910N
The DVD-VCR automatically turns on and
the “LANGUAGE SET” menu appears.
• SLV-D910R
The DVD-VCR automatically turns on and
auto tuning starts. (“LANGUAGE SET” and “COUNTRY
SELECTION” are skipped only for this model.)
14
Setting up the DVD-VCR with the Auto Set Up function
LANGUAGE SET
B
English
Magyar
Cesky
Polski
Russian
Turkish
V
v
ENTER
RETURN
SET UP
3
ENTER
Press V/v to select the desired language, then
press ENTER repeatedly.
The “COUNTRY SELECTION” menu appears.
The abbreviations of the countries
are as follows:
Abbreviation Country
A Austria
B Belgium
DK Denmark
FIN Finland
DGermany
NL Netherlands
I Italy
N Norway
P Portugal
Abbreviation Country
ESpain
S Sweden
CH Switzerland
TR Turkey
GR Greece
HU Hungary
PL Poland
CZ Czech
A
B
DK
FIN
D
vVb
NL
I
N
P
E
B
COUNTRY SELECTION
S
PL
CH
CZ
B
TR
Others
GR
HU
SET UP
RETURN
ENTER
Getting Started
4
ENTER
Press V/v/B/b to select the abbreviation of
your country from the table in step 3, then press
ENTER.
Please wait
AUTO SETUP
10%
If your country does not appear, select “Others”.
The DVD-VCR starts searching for all of the
SET UP
receivable channels and presets them (in the
RETURN
appropriate order for your local area).
If you want to change the order of the channels or disable unwanted
programme positions, see “Changing/disabling programme positions” on
page 24.
After the search is complete, the current tim e appears for any stations that
transmit a time signal. If the time does not appear, set the clock manually.
See “Setting the clock” on page 20.
continued
Setting up the DVD-VCR with the Auto Set Up function
15
To cancel the Auto Set Up function
Press SET UP.
To change the RF channel
If the picture does not appear cl early on the TV, change the RF chann el on the DVDVCR and TV. Select “Install” in the “OPTION” menu, then press V/v to select
“Video Output CH”. Select the RF channel by pressing the B/b buttons and press
ENTER. Then, tune the TV to the new RF channel so that a cl ear picture appears.
Tip
• If you want to change the lan guage for the on-screen display from the one preset in t h e Auto
Set Up function, see page 19.
Notes
• Whenever you operate the Auto Set Up func ti on, so m e of t he se tt ing s (ti mer, etc.) will be
reset. If this happens, you have to set them again.
• Auto preset starts automatically only when you plug in the mains lead for the first time after
you purchase the DVD-VCR.
• If you want to use the Auto Set Up function aga i n, select “Install” in the “OPTION” me nu,
then press V/v to select “Auto Set up” , the n repeat step 3.
• Auto preset can be performe d by pressing x on the unit
during power off with no tape inserted.
continuously for 5 seconds or more
16
Setting up the DVD-VCR with the Auto Set Up function
Step 5 : Selecting the TV system
You must select th e appropriate TV system
for your area.
Before you start…
• Tur n on the DVD-VCR and your TV.
• To control the DVD-VCR, set TV /
DVD·VIDEO
to DVD·VIDEO on the
remote (page 9).
• Set your TV to the video channel so that
the signal from the player appears on the
TV screen.
• If the DVD player is in play mode, you
cannot display the setup menu. Stop the
DVD playback.
1
SET UP
ENTER
Press SET UP, then press V/v to select
(OPTION), then press ENTER.
Language
Clock
Install
User Set
Auto Power Off
Screen Messages
V
v
SET UP
V/v/B/b
ENTER
:English
RETURN
ENTER
OPTION
[ Off ]
[ On ]
SET UP
Getting Started
2
3
ENTER
ENTER
Press V/v to select “Install”, then press
ENTER.
The “INSTALL” menu appears.
Press V/v to select “TV System”, then press
B/b to select the appropriate TV system.
Select “G” for the B/G TV system, or “K” for
the D/K TV system.
INSTALL
Auto Setup
Manual Setup
V
V
TV System
Video Output CH
v
ENTER
Auto Setup
Manual Setup
TV System
Video Output CH
Bvb
RETURN
RETURN
[
CH32
SET UP
INSTALL
[
CH32
SET UP
continued
Selecting the TV system
[
]
K
]
[
]
K
]
17
4
SET UP
Press SET UP to exit the menu.
18
Selecting the TV system
Step 6 :Selecting a language
You can change the on-screen display
language.
Before you start…
• Tur n on the DVD-VCR and your TV.
• To control the DVD-VCR, set TV
/
DVD·VIDEO to DVD·VIDEO on the
remote (page 9).
• Set your TV to the video channel so that
the signal from the player appears on the
TV screen.
• If the DVD player is in play mode, you
cannot display the setup menu. Stop the
DVD playback.
1
SET UP
ENTER
Press SET UP, then press V/v to select
(OPTION), then press ENTER.
Language
Clock
Install
User Set
Auto Power Off
Screen Messages
V
v
SET UP
V/v/B/b
ENTER
:English
RETURN
ENTER
OPTION
[ Off ]
[ On ]
SET UP
Getting Started
2
3
4
ENTER
ENTER
SET UP
Press V/v to select “Language” , then press
ENTER.
The “LANGUAGE SET” menu appears.
B
English
Magyar
Cesky
Polski
Russian
Turkish
V
v
ENTER
Press V/v to select the desired language, then press ENTER.
Press SET UP to exit the menu.
Selecting a language
LANGUAGE SET
SET UP
RETURN
19
Step 7 : Setting the clock
You must set the time and date on the DVDVCR to use the timer features properly.
The Auto Clock Set function* w orks only if a
station in your area i s broadcasting a time
signal.
* SLV-D910N only
Before you start…
• Turn on the DVD-VCR and your TV.
• To control the DVD-VCR, set TV
DVD·VIDEO
to DVD·VIDEO on the
/
remote (page 9).
• Set your TV to the video channel so that
the signal from the player appe ars on the
TV screen.
• If th e DVD player is in play mo de, you
cannot display the setup menu. Stop the
DVD playback.
1
SET UP
ENTER
Press SET UP, then press V/v to select
(OPTION), then press ENTER.
Language
Clock
Install
User Set
Auto Power Off
Screen Messages
V
v
SET UP
V/v/B/b
ENTER
:English
RETURN
ENTER
OPTION
[ Off ]
[ On ]
SET UP
2
3
20
Setting the clock
ENTER
ENTER
Press V/v to select “Clock”, then press
ENTER.
The “CLOCK SET” menu appears.
Press V/v to set the hour.
Time Date
12:00 1/JAN /2003 WED
Autoclock
B
vVb
B
vVb
RETURN
ENTER
Time Date
18:00 1/JAN /2003 WED
Autoclock
RETURN
ENTER
CLOCK SET
Year
[ On ]
SET UP
CLOCK SET
Year
[ On ]
SET UP
4
ENTER
Press b to select the minutes and set the
minutes by pressing V/v.
Time Date
18:30 1/JAN /2003 WED
Autoclock
B
vVb
ENTER
RETURN
CLOCK SET
Year
[ On ]
SET UP
Getting Started
5
6
7
8
ENTER
ENTER
Set the day, month, and year in sequence by
pressing b to select the item to be set, and
press V/v to select the digits, then press b.
The day of the week is set automatically.
For SLV-D910R, skip step 6.
Press V/v to select “On” for the setting of the
Auto Clock Set function. (SLV-D910N only)
The DVD-VCR automatically sets the clock
according to the time signal broadcast between
Time Date
18:30 28/SEP /2003 SUN
Autoclock
B
vVb
Time Date
18:30 28/SEP /2003 SUN
Autoclock
ENTER
CLOCK SET
Year
[ On ]
RETURN
CLOCK SET
Year
[ On ]
SET UP
the channels PR 1 to PR 5.
If you do not need the Auto Clock Set function,
vVb
ENTER
RETURN
SET UP
B
select “Off”.
Press ENTER to confirm the setting.
ENTER
SET UP
Tips
• If you set “Autoclock” to “On”, the Auto Clock Set fun ction is activated whenever the
• To change the digits while setting, press B to return to the item to be changed, and select the
Press SET UP to exit the menu.
DVD-VCR is turned off. The time is adjusted automatically by making reference to the time
signal from the station (SLV-D910N only).
digits by pressing V/v.
Note
• The clock display appears when VIDEO mode is selected with no tape inserted or when the
DVD-VCR is turned off.
Setting the clock
21
Step 8 : Presetting channels
If some channels could not be preset using
the Auto Set Up function, you can preset
them manually.
Before you start…
• Turn on the DVD-VCR and your TV.
• To control the DVD-VCR, set TV
DVD·VIDEO to DVD·VIDEO on the
remote (page 9).
• Set your TV to the video channel so that
the signal from the player appe ars on the
TV screen.
• If th e DVD player is in play mo de, you
cannot display the setup menu. Stop the
DVD playback.
/
SET UP
V/v/B/b
ENTER
O RETURN
1
2
22
Presetting channels
SET UP
ENTER
ENTER
Press SET UP, then press V/v to select
(OPTION), then press ENTER.
Press V/v to select “Install”, t hen press
ENTER.
The “INSTALL” me nu appears.
Language
Clock
Install
User Set
Auto Power Off
Screen Messages
V
v
Auto Setup
Manual Setup
TV System
Video Output CH
V
v
ENTER
ENTER
:English
RETURN
RETURN
OPTION
[ Off ]
[ On ]
SET UP
INSTALL
[
[
CH32
SET UP
]
K
]
3
ENTER
Press V/v to select “Manual Setup”, then
press ENTER.
PR
1
2
3
4
5
VvB
RETURN
TV STATION TABLE
CH
NAME
027
AAB –
029
LMN –
030
CDE –
032
I J K –
SWAPPING :
DELETE :
DEC
OFF
OFF
OFF
OFF
ENTER
CLEAR
Getting Started
4
5
6
7
ENTER
ENTER
ENTER
ENTER
Press V/v to select the row which you want to
preset, then press b.
To display other pages for programme
positions 6 to 80, press V/v repeatedly.
Press B/b repeatedly until the channel you
want is displayed.
Press V/v to select “NAME”, then press b.
Enter the station name.
1 Press V/v to select a character.
Each time you press V, the character
changes as shown below.
A t B t … t Z t 0 t 1 t … t 9
t A
PR
CH
MFT
DECODER
NAME
b
VvB
RETURN
PR
CH
MFT
DECODER
NAME
b
VvB
RETURN
PR
CH
MFT
DECODER
NAME
b
VvB
RETURN
PR
CH
MFT
DECODER
NAME
b
VvB
RETURN
MANUAL TUNING
: 5
: – – –
: –
: OFF
: – – – –
MANUAL TUNING
: 5
: – – –
: –
: OFF
: – – – –
MANUAL TUNING
: 5
: 033
: –
: OFF
: – – – –
MANUAL TUNING
: 5
: 033
: –
: OFF
: O – – –
ENTERMEMORY :
ENTERMEMORY :
ENTERMEMORY :
ENTERMEMORY :
8
ENTER
2 Press b to set the next character.
The next space flashes.
To correct a character, press B/b until the character you want to correct
flashes, then reset it.
You can set up to 4 charac te rs for the st ation name.
Press ENTER to confirm the station name.
continued
Presetting channels
23
9
RETURN
SET UP
Press O RETURN, then press SET UP to exit the menu.
If the picture is not clear
If the picture is not cl ear, you may use t he Manual Fine Tuning (MFT) function.
After step 5, press V/v to select “MFT ”. Pr ess B/b to get a clear picture. Then
press ENTER.
Tips
• T o s et th e p rog ram me p osi tion fo r t he de code r, see “Setting the PAY-TV/Canal Pl us dec od er”
on page 30.
• The DVD-VCR must receive channel information for station names to appear automatically.
Note
• When adjusting MFT, the menu may become difficult to read due to interference from the
picture being received.
Changing/disabling programme positions
After setting the channels, you can change
the programme positions as you like. If any
programme positions are unused or contain
unwanted channels, yo u can disable them.
Y ou can also change the station names. If the
station names are not displayed, you can
enter them manually.
Changing programme
positions
Before you start…
• Turn on the DVD-VCR and your TV.
• To control the DVD-VCR, set TV
DVD·VIDEO to DVD·VIDEO on the
remote (page 9).
• Set your TV to the video channel so that
the signal from the player appe ars on the
TV screen.
• If th e DVD player is in play mo de, you
cannot display the setup menu. Stop the
DVD playback.
24
Presetting channels
SET UP
/
V/v/B/b
ENTER
O RETURN
1
SET UP
ENTER
Press SET UP, then press V/v to select
(OPTION), then press ENTER.
Language
Clock
Install
User Set
Auto Power Off
Screen Messages
V
v
ENTER
:English
RETURN
OPTION
[ Off ]
[ On ]
SET UP
Getting Started
2
3
4
5
ENTER
ENTER
ENTER
ENTER
Press V/v to select “Install”, then press
ENTER.
The “INSTALL” menu appears.
Press V/v to select “Man ual Setup”, the n press
ENTER.
Press V/v to select the row containing the
programme position you want to cha nge.
To display other pages for programme
positions 6 to 80, press V/v repeatedly.
Press ENTER, then press V/v to move to the
desired programme position.
V
v
PR
1
2
3
4
5
VvB
RETURN
PR
1
2
3
4
5
VvB
RETURN
PR
1
2
3
4
5CH029
VvB
RETURN
Auto Setup
Manual Setup
TV System
Video Output CH
RETURN
ENTER
TV STATION TABLE
CH
NAME
027
AAB –
029
LMN –
030
CDE –
032
I J K –
SWAPPING :
DELETE :
TV STATION TABLE
CH
NAME
027
AAB –
029
LMN –
030
CDE –
032
I J K –
SWAPPING :
DELETE :
TV STATION TABLE
NAME
027
AAB –
030
CDE –
032
I J K –
LMN –
SWAPPING :
DELETE :
INSTALL
[
[
CH32
SET UP
DEC
OFF
OFF
OFF
OFF
ENTER
CLEAR
DEC
OFF
OFF
OFF
OFF
ENTER
CLEAR
DEC
OFF
OFF
OFF
OFF
ENTER
CLEAR
]
K
]
6
ENTER
Press ENTER to confirm the setting.
T o c hange t he p rogramme position of a noth er station, repea t steps 4 throug h 6.
continued
Presetting channels
25
7
RETURN
SET UP
Press O RETURN, then press SET UP to exit the menu.
Disabling unwanted programme positions
After presetting channels, you can di sable
unused programme positions. The disabled
positions will be skipped later when you
press the PROG+/– buttons.
Before you start…
• Turn on the DVD-VCR and your TV.
• To control the DVD-VCR, set TV
DVD·VIDEO to DVD·VIDEO on the
remote (page 9).
• Set your TV to the video channel so that
the signal from the player appe ars on the
TV screen.
• If th e DVD player is in play mo de, you
cannot display the setup menu. Stop the
DVD playback.
/
CLEAR
SET UP
1
26
Presetting channels
SET UP
ENTER
Press SET UP, then press V/v to select
(OPTION), then press ENTER.
Language
Clock
Install
User Set
Auto Power Off
Screen Messages
V
v
V/v/B/b
ENTER
O RETURN
:English
RETURN
ENTER
OPTION
[ Off ]
[ On ]
SET UP
2
ENTER
Press V/v to select “Install”, then press
ENTER.
The “INSTALL” menu appears.
Auto Setup
Manual Setup
TV System
Video Output CH
INSTALL
[
[
CH32
]
K
]
3
4
5
6
ENTER
ENTER
CLEAR
V
Press V/v to select “Man ual Setup”, the n press
ENTER.
Press V/v to select the row which you want to
disable.
To display other pages for programme
positions 6 to 80, press V/v repeatedly.
Press CLEAR.
The selected row will be cleared as shown on
the right.
v
PR
1
2
3
4
5
VvB
RETURN
PR
1
2
3
4
5
VvB
RETURN
PR
1
2
3
4
5
VvB
RETURN
ENTER
TV STATION TABLE
CH
NAME
027
AAB –
029
LMN –
030
CDE –
032
SWAPPING :
TV STATION TABLE
CH
NAME
027
AAB –
029
LMN –
030
CDE –
032
SWAPPING :
TV STATION TABLE
CH
NAME
027
AAB –
030
CDE –
032
SWAPPING :
RETURN
I J K –
DELETE :
I J K –
DELETE :
I J K –
DELETE :
Repeat steps 4 and 5 fo r any other programme positions you want to
disable.
SET UP
DEC
OFF
OFF
OFF
OFF
ENTER
CLEAR
DEC
OFF
OFF
OFF
OFF
ENTER
CLEAR
DEC
OFF
OFF
OFF
ENTER
CLEAR
Getting Started
7
Press O RETURN, then press SET UP to exit the menu.
RETURN
SET UP
Note
• Be sure to select the programm e position you want to disable corre ct ly. If you disable a
programme position by mistake, you need to reset that channel manua lly.
continued
Presetting channels
27
Changing the station names
You can change or enter the station names
(up to 4 characters). The DVD-VCR must
receive channel information for station
names to appear automatically.
Before you start…
• Turn on the DVD-VCR and your TV.
• To control the DVD-VCR, set TV
DVD·VIDEO
to DVD·VIDEO on the
remote (page 9).
• Set your TV to the video channel so that
the signal from the player appe ars on the
TV screen.
• If th e DVD player is in play mo de, you
cannot display the setup menu. Stop the
DVD playback.
/
SET UP
V/v/B/b
ENTER
O RETURN
1
2
3
SET UP
ENTER
ENTER
ENTER
Press SET UP, then press V/v to select
(OPTION), then press ENTER.
Press V/v to select “Install”, then press
ENTER.
The “INSTALL” me nu appears.
Press V/v to select “Ma nual Setup”, then pre ss
ENTER.
Language
Clock
Install
User Set
Auto Power Off
Screen Messages
V
v
ENTER
Auto Setup
Manual Setup
TV System
Video Output CH
V
v
ENTER
CH
PR
027
1
029
2
030
3
032
4
5
033 OFF
VvB
RETURN
OPTION
:English
[ Off ]
[ On ]
SET UP
RETURN
INSTALL
[
[
CH32
SET UP
RETURN
TV STATION TABLE
NAME
DEC
AAB –
OFF
LMN –
OFF
CDE –
OFF
I J K –
OFF
ENTER
SWAPPING :
CLEAR
DELETE :
]
K
]
28
Presetting channels
4
ENTER
Press V/v to select the row which you want to
change or enter the station name, then press b.
To display other pages for programme
positions 6 to 80, press v/V repeatedly.
PR
CH
MFT
DECODER
NAME
b
VvB
RETURN
MANUAL TUNING
: 5
: 033
: –
: OFF
: – – – –
ENTERMEMORY :
Getting Started
5
6
7
8
ENTER
ENTER
ENTER
RETURN
SET UP
Press V/v to select “NAME”, then press b.
Enter the station name.
1 Press V/v to select a character.
Each time you press V, the character
changes as shown below.
A t B t … t Z t 0 t 1 t … t 9
t A
PR
CH
MFT
DECODER
NAME
b
VvB
RETURN
PR
CH
MFT
DECODER
NAME
b
VvB
RETURN
MANUAL TUNING
: 5
: 033
: –
: OFF
: – – – –
MANUAL TUNING
: 5
: 033
: –
: OFF
: O – – –
2 Press b to set the next character.
The next space flashes.
To correct a character, press B/b until the character you want to correct
flashes, then reset it.
You can set up to 4 charac te rs for the st ation name.
Press ENTER to confirm the new name.
Press O RETURN, then press SET UP to exit the menu.
ENTERMEMORY :
ENTERMEMORY :
Presetting channels
29
Setting the PAY-TV/Canal Plus decoder
(SLV-D910N only)
You can watch or record PAY-TV/Canal Plus programmes if you connect a decoder (not
supplied ) to the DVD-VCR.
Connecting a decoder
PAY-TV/Canal
Plus decoder
AERIAL IN
LINE-3
Scart cable
(not supplied)
Scart
(EURO-AV)
LINE-1 (EURO AV)
Scart
(EURO-AV)
: Signal flow
Aerial cable (supplied)
Scart cable (not supplied)
30
Setting the PAY-TV/Canal Plus decoder (SLV-D910N only)
Loading...
