TV SIMULATOR STS 12 B2
TV SIMULATOR
Operating instructions
TV-SIMULATOR
Bedienungsanleitung
IAN 284710
Before reading, unfold the page containing the illustrations and
familiarise yourself with all functions of the device.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und
machen Sie sich anschließend mit allen Funktionen des Gerätes
vertraut.
GB / IE/ NI Operating instructions Page 1
DE / AT / CH Bedienungsanleitung Seite 19
Index
Introduction ...............................2
Copyright .................................2
Intended use ..............................2
Scope of delivery and transport inspection .....3
Unpacking ...................................... 4
Disposal of the packaging ......................... 4
Operating elements ........................4
Technical data .............................5
Safety instructions .........................6
Functions .................................8
Setup ....................................9
Wall mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Operation ...............................12
Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Storage .................................14
Disposal of the appliance ...................14
Appendix ................................15
Kompernass Handels GmbH warranty ...............15
Service .......................................18
Importer ......................................18
STS 12 B2
GB│IE│NI
│
1 ■
Introduction
Congratulations on the purchase of your new appliance.
You have clearly decided in favour of a high-quality product.
These operating instructions are a part of this product. They
contain important information in regard to safety, use and
disposal. Before using the product, familiarise yourself with
all operating and safety instructions. Use this appliance only
as described and only for the specified areas of application.
In addition, pass these operating instructions on to whoever
might acquire the appliance at a future date.
Copyright
This documentation is copyright protected.
Any copying or reproduction of it, including as extracts,
as well as the reproduction of images, also in an altered
state, is only permitted with the written authorisation of the
manufacturer.
Intended use
This appliance is used to simulate light proportions similar
to those created by a TV set. This appliance is intended
exclusively for indoor use in private households. Do not use
it for commercial applications!
WARNING
Risks from unintended use!
Risks can be engendered if the appliance is used for
unintended purposes and/or other types of use.
► Use the appliance exclusively for its intended purposes.
► Observe the procedures described in these operating
instructions.
■ 2 │ GB
│IE│
NI
STS 12 B2
Claims of any kind for damage resulting from unintended
use, incompetent repairs, unauthorised modification or the
use of unauthorised spare parts will not be accepted. The
user alone bears the risk.
Scope of delivery and
transport inspection
WARNING
► Packaging materials should not be used as a plaything.
There is a risk of suffocation.
This appliance is supplied with the following components as
standard:
▯ TV Simulator
▯ Power adapter
▯ Assembly material (2 screws, 2 plugs, adhesive strips)
▯ Operating instructions
NOTE
► Check the contents to ensure that everything is available
and for signs of visible damage.
► If the contents are not complete, or are damaged
due to defective packaging or through transportation,
contact the Service Hotline (see chapter Service).
STS 12 B2
GB│IE│NI
│
3 ■
Unpacking
♦ Remove all appliance parts and these operating instruc-
tions from the carton.
♦ Remove all packaging materials from the appliance.
Disposal of the packaging
The packaging protects the appliance against transport
damage. The packaging materials are selected from the
point of view of their environmental friendliness and disposal
technology and are therefore recyclable.
The recirculation of packaging into the material
circuit saves on raw material and reduces the
amount of waste generated. Dispose of packaging
material that is no longer needed as per the
regionally established regulations.
Operating elements
Light surface
Power adapter
Barrel connector
Plug socket
Cable conduit
Switch
Holes for wall mounting
Twilight sensor
■ 4 │ GB
│IE│
NI
STS 12 B2
Technical data
Power adapter Type HX06D-0900200-AB
Input voltage
Current consumption 0,3 A max
100 - 240 V ~,
50 / 60 Hz
Output voltage 9 V
Output current 200 mA
Protection class
Polarity
Efficiency class 5
(direct current)
II /
Appliance
Input voltage 9 V (direct current)
Current consumption 200 mA
Polarity
STS 12 B2
GB│IE│NI
│
5 ■
Safety instructions
RISK OF ELECTRIC SHOCK!
► Ensure that water or moisture cannot
penetrate the appliance.
► Do not use the appliance if the power
adapter or the power cable are damaged.
Use the appliance/the mains adapter
indoors only! Do not use the appliance/the mains adapter outdoors!
WARNING - RISK OF INJURY!
► This appliance may be used by child-
ren aged 8 years and above and by
persons with limited physical, sensory
or mental capabilities or lack of experience and knowledge, provided that
they are under supervision or have
been told how to use the appliance safely and are aware of the potential risks.
Children must not use the appliance as
a plaything. Cleaning and user maintenance tasks may not be carried out by
children unless they are supervised.
■ 6 │ GB
│IE│
NI
STS 12 B2
WARNING - RISK OF INJURY!
► Do not use the appliance if people
suffering from epilepsy are in the
room. The changes in light levels can
cause epileptic seizures in people
susceptible to them.
► Before use, check the appliance for
visible external damage. Do not operate a damaged appliance or one that
has been dropped. There is also a
risk of personal injury!
► Never look directly into the LEDs!
They are very bright and can caause
injury to the eyes!
► Repairs must only be carried out by
authorised specialist companies or by
the Customer Service. Incompetent
repairs may result in risks for the user.
In addition, warranty claims become
void.
► Place the power cable such that no
one can stumble over it.
STS 12 B2
GB│IE│NI
│
7 ■
CAUTION - PROPERTY DAMAGE
► Do not operate the appliance close to
open flames (e.g. candles). The appliance could be irreparably damaged!
► Avoid direct sunlight. The appliance
could be irreparably damaged!
► This appliance must not be exposed to
rain. Protect the appliance against
moisture and the penetration of
liquids and objects into the housing.
Never submerge the appliance in
water and do not place objects filled
with liquids (such as vases) on the
appliance. The appliance could be
irreparably damaged!
► Operate the appliance only with
the supplied power adapter (type
HX06D-0900200-AB).
Functions
With this TV simulator you can simulate the flicker patterns
of a switched-on television and so feign your presence to
potential burglars.
For this purpose 5 different settings are available:
OFF 0: the appliance is switched off.
■ 8 │ GB
│IE│
NI
STS 12 B2
+2H: the LEDs switch on automatically at dusk and
then light up for 2 hours.
+4H: the LEDs switch on automatically at dusk and
then light up for 4 hours.
+6H: the LEDs switch on automatically at dusk and
then light up for 6 hours.
ON I: the LEDs light up in different colours and combinations.
Setup
Select a suitable location for setting up the appliance. This
location must fulfil the following criteria:
― The TV Simulator may not be directly visible from
outdoors.
― The flickering generated by the TV simulator must be
visible on the walls and/or ceiling from outdoors.
― A power socket must be easily accessible.
― The TV Simulator must be installed such that it can be
influenced by the twilight. This means that it must be
able to detect light from outside!
― The TV Simulator may not be located near a window
which could be well lit from outdoors, such as on a
busy street or next to street lights.
― There should be no additional time-controlled light
source in the room, e.g. a night light.
♦ Place the appliance on a firm and flat surface so that it
is stable and secure. To help prevent it from tipping over,
you can secure the stand with the adhesive strips.
CAUTION - PROPERTY DAMAGE
► Do not use the adhesive strips to hang the appliance on
a wall! The appliance may fall down and be irreparably
damaged!
STS 12 B2
GB│IE│NI
│
9 ■
