Silvercrest SMK 15 A1 User Manual

Download
0LQL)ULGJH60.$
0LQL)ULGJH
2SHUDWLQJLQVWUXFWLRQV
Be sure to note the fold-out page ........
SMK 15 A1_11_V1.2_GB
1
16
15
14
13
12
11
10
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
English
Contents
1. Names of parts (see fold-out page). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3. Safety Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4. Operating the Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5. Cleaning and maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6. Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
7. Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
8. Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1. Names of parts
Carry handle Door shelf Mains lead Temperature selector Green indicator: appliance is in cooling
mode Function selector Voltage selector Car lead socket
(see fold-out page)
Mains lead socket Red indicator: appliance is in warming
mode Car lead Drip tray (removable) Air outlet Shelf (removable) Air inlet Exterior ventilation slots (on the back)
2. Description
2.1 Intended purpose
This SilverCrest SMK 15 A1 portable mini­cooler is intended to keep food and drink cool (maximum of 15 °C below ambient temperature) or hot.
It may only be used in dry indoor locations or run inside vehicles.
The device is intended only for private use, not for commercial operations.
2.2 Scope of supply
• 1 mini refrigerator
• 1 shelf
SMK 15 A1
• 1 car lead
• 1 mains lead
• 1 set of operating instructions
2.3 Function
Cooling and warming is by means of a thermoelectric Peltier element. This is free from wear, quiet and CFC-free.
The appliance can be connected either to the mains or to a car cigarette lighter.
3
3. Safety Information
3.1 Definition
You will find the following alerting terms in these instructions:
Warning!
High risk. Disregarding of the warning may lead to damages to life or physical condition.
Caution!
Medium risk. Disregarding of warning can cause material damage.
Note!
Low risk. Facts which should be considered when dealing with the device.
3.2 General information
• Please thoroughly read through the operating instructions before use. It is part of the device and must be available at any time.
• Only use the baby bottle warmer for the described intended use (see “2.1 Intended purpose” on page 3).
• Check whether the required supply voltage (see type label on device) corresponds with the mains socket.
• This device is not intended to be used by individuals (including children) limited physical, capabilities or with a lack of experience and/or lack of knowledge, unless supervised by a person responsible for their safety or they have received instructions from such a person as to how to use the device. Children should always be supervised to ensure that they do not play with the device.
• Do not use any accessories other than those provided.
sensory or mental
with
• If using the appliance for a prolonged time with power supplied via the cigarette lighter, take care that the car battery does not become fully discharged.
• Food may only be stored in suitable containers or the original packaging.
3.3 Protection against injury
Warning! The following safety
information is intended to protect you against injuries.
• Ensure that it is not possible for anyone to trip over or to get caught up in or step on the car lead 11 or mains lead 3 .
• If the appliance is used when travelling, it must be firmly secured to prevent it becoming a projectile in the event of an accident.
3.4 Protection against electric shock
Warning! The following safety
instructions are intended to protect you against electric shock.
• The device must not under any circumstances be used if the appliance or parts of it are damaged or if faults occur during operation. Have the appliance repaired in such cases by a qualified specialist. Do not attempt to carry out any repairs yourself. You will find the service address in “8. Warranty” on page 9.
• Water or any other liquids must never enter the device. Therefore: – never use outside; – never use in a very moist environment; – never place drinks or other liquids on
the appliance;
4
– always keep the mains lead 3 or car
lead 11 away from moisture.
• If liquid should enter the appliance, disconnect the power supply immediately and have the appliance repaired by a qualified technician. You will find the service address in “8. Warranty” on page 9.
• Never take hold of the mains lead 3 or car lead 11 when your hands are wet.
• Always unplug the connection leads from the power supply first and then from the appliance.
• If you are not using the appliance for a prolonged period of time, unplug the mains lead 3 or car lead 11 . This is the only way to ensure the complete absence of electric power and to protect against the appliance being switched on accidentally.
• If the appliance is used in boats, caravans, camper vans etc., the power supply must be protected during mains operation by an earth-leakage circuit­breaker.
3.5 For the safety of your child
Warning! Ensure the packaging
foil does not turn into a deadly trap for children. Packaging foils are not toys.
3.6 Protection against damage
Caution! The following information is
intended to protect the appliance against damage.
• Never pull the plug out of the wall socket or cigarette lighter by means of the leads. Always take hold of the plug.
• To avoid overheating, the appliance must not be operated near to heat sources or in direct sunlight.
• Ensure that the ventilation slots for the air inlet 15 and outlet 13 as well as the exterior ventilation slots 16 are never covered. Maintain a distance of 10 cm from walls and other objects.
• Corrosive substances or substances containing solvents must not be
4. Operating the Appliance
4.1 Using the appliance for the first time
1. For reasons of hygiene, clean the
appliance thoroughly inside and out before using it for the first time or if it has not been used for a long time (see “5.1 Cleaning the appliance” on page 7).
2. Select a location that is well ventilated
and protected from heat and sunlight.
3. Place the appliance on a level, non-slip
surface.
SMK 15 A1
4. Turn the function selector 6 and the voltage selector 7 to the OFF position.
4.2 Selecting a voltage
Use the voltage selector 7 to select the required voltage:
230V: operating on the mains 12V: operating on a car electrical
system
OFF : appliance is switched off.
5
4.3 Connecting the appliance to the mains
1. Plug the mains lead 3 into the socket 9 .
2. Connect the mains lead 3 with the mains
supply.
4.4 Connecting the appliance to the car electrical system
Note: When operated on a vehicle 12 V
system the cooling and warming performance is not quite so high as when operated on 230 V mains (see “7. Technical Data” on page 8).
1. Plug the car lead 11 into the socket 8 .
2. Connect the car lead 11 to the car elec-
trical system, e.g. the cigarette lighter.
Note: You may need to pull the red cap
off the car plug.
4.5 Selecting a function
Use the function selector 6 to select the required function:
OFF: appliance is switched off. WARM: appliance warms and the red
indicator 10 lights up.
COOL: appliance cools and the green
indicator 5 lights up.
4.6 Select operating temperature
Set the operating temperature on tempera­ture selector 4 . Set temperature selector 4 to
for minimum output. Refrigeration perfor­mance can be increased, if required, by tur­ning temperature selector 4 towards (maximum output). However, this will incre­ase energy consumption. To save energy, output can be reduced again by turning temperature selector 4 back towards (minimum output).
4.7 Emptying the drip tray
Condensation water may collect in the drip tray 12 . Depending on the duration and intensity of operation, the drip tray 12 should be checked regularly and emptied if necessary:
1. Pull the drip tray 12 forwards and out.
2. Empty out any condensation water present.
3. Push the drip tray 12 back in.
4.8 Setting the temperature for
warming
If the WARM function is selected the appliance warms and the red indicator 10 lights up. It is neither necessary nor possible to set the temperature separately.
4.9 Tips for saving energy
In order not to waste energy when using the mini refrigerator, please note the following points for cooling:
• Set up the mini refrigerator in as cool an environment as possible. Avoid direct sunlight.
• Set up the mini refrigerator to allow sufficient cool air to circulate around it at all times.
• Allow warm food to cool down first before putting it into the appliance to cool.
• Do not open the door more often than is absolutely necessary.
• Do not leave the door open for longer than is absolutely necessary.
• Switch off the mini refrigerator if it is not required.
In order not to waste energy when using the mini refrigerator, please note the following points for keeping warm:
6
• Set up the mini refrigerator in as warm an environment as possible.
• Set up the mini refrigerator to allow sufficient air to circulate around it at all times.
• Try to prevent warm food from cooling down before putting it into the appliance to keep warm.
5. Cleaning and maintenance
5.1 Cleaning the appliance
To ensure your appliance gives you lasting service, you should clean it regularly.
Warning! To avoid the danger of an electric shock or damage: –Always disconnect the power
supply before cleaning.
–Never immerse the appliance in
water.
–Never allow water or cleaning
agent to run into the appliance.
Caution! Never use caustic or abrasive cleaning agents, as they could damage the appliance.
1. Pull out the drip tray 12 and empty it.
2. Clean the drip tray 12 in the sink.
3. Remove the shelf 14 and clean it in the sink.
4. Clean the appliance with a damp cloth. You could also use a mild washing-up liquid if necessary.
5. Wipe it off with clean water.
6. Replace the drip tray 12 and shelf 14.
7. Do not use the appliance again until it is fully dry.
• Do not open the door more often than is absolutely necessary.
• Do not leave the door open for longer than is absolutely necessary.
• Switch off the mini refrigerator if it is not required.
5.2 Changing the fuse in the car lead
There is a fuse in the car lead 11 to protect the car’s electrical system. If there is no power supply and the car lead 11 stops working, you should check and, if applicable, change this fuse.
A
B
1. Twist the cap A a little anticlockwise and pull it forwards and off.
2. Undo the screw B.
D
C
3. Remove half of the plug C.
SMK 15 A1 7
4. Remove the fuse D. 5. Insert a new type T6.3AL 250V fuse.
6. Reassemble the car plug in the reverse order.
E
Note: The metal tip E is held by the fuse.
Check that it is correctly positioned when reassembling the plug.
6. Disposal
6.1 Appliance
The symbol with the crossed­out rubbish bin on wheels means that within the European Union, the product must be dis­posed of to a sorted rubbish
collection. This applies to the product and all accessories which are marked with this symbol. Marked products must not be disposed of via the regular domestic waste but must be handed in to a recycling centre for electrical or electronic devices. Recycling helps to reduce the use of
raw materials and to relieve the environ­ment. You can obtain information about dis­posal and the location of your nearest recycling centre from your local waste management service, for example, or Yellow Pages.
6.2 Packaging
Dispose of the packaging in accordance with the environmental regulations in your particular country. In Germany, make use of Dual System collection (Green Dot) for disposing of the packaging.
7. Technical Data
Mains connection: 230 V~, 50 Hz Connection to car electrical system: 12 V Power consumption at 230 V: Cooling: max. 60 W, warming: max. 50 W Power consumption at 12 V: Cooling: max. 50 W, warming: max. 40 W Design temperature: 16 °C Net capacity: 15 l Gross capacity: 16 l Blowing agent: C Climate class: N
5H10
8
Protection class: II
Parts that come into contact with food are suitable for foodstuffs:
8. Warranty
The warranty for your appliance is valid for 3 years from the date of purchase. The war­ranty does not cover damage resulting from improper connection, the use of another manufacturer’s parts, normal wear and tear, the use of force, improper use, or attempts to carry out repairs yourself. The appliance has been manufactured in accordance with strict quality guidelines and checked before leaving the factory.
Nonetheless, should operational faults occur, please contact the Service Centre first.
Please do not send in any appliance before contacting our Service Centre.
To enable us to process your request quickly, please have ready your proof of purchase and the product number (for this appliance: SMK 15 A1).
Please contact our service hotline for guarantee claims and technical matters:
00800/4212 4212 (Monday to Friday between
8 a.m. and 4 p.m.)
E-mail: hoyer-gb@teknihall.com
SMK 15 A1 9
