Silvercrest SAS 150 A1 User Manual [el]
Food Slicer SAS 150 A1
Food Slicer
Operation and Safety Notes
Allesschneider
Bedienungs- und Sicherheitshinweise
Ηλεκτρική πολυκοπτική συσκευή
Υποδείξεις χειρισμού και ασφάλειας
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the
device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειωθείτε με όλες τις λειτουργίες της
συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
GB / IE / CY Operation and Safety Notes Page 5
GR / CY Υποδείξεις χειρισμού και ασφάλειας Σελίδα 13
DE / AT / CH Bedienungs- und Sicherheitshinweise Seite 21
13
12
11
1
2
34
10
17
9
8
5
6
7
A B C
9
D
15
14
2 x
16 a
E
18
16
F
19
Table of contents
Introduction
Dear Customer ..............................................................................................................Page 6
Intended usage .............................................................................................................Page 6
Items supplied ................................................................................................................Page 6
Features .........................................................................................................................Page 6
Technical data ...............................................................................................................Page 7
Safety
Important safety instructions .........................................................................................Page 7
Before the First Usage
First steps .......................................................................................................................Page 8
Setting up the appliance ...............................................................................................Page 8
Adjust the infinite slice-thickness setting (see Fig. D) ...................................................Page 8
Operation
Working advice.............................................................................................................Page 8
Selecting mode of operation ........................................................................................Page 9
Setting the Vario-switch cutting blade speed...............................................................Page 9
Slice thickness – setting and cutting.............................................................................Page 9
Cleaning and maintenance
Cleaning ........................................................................................................................Page 10
Maintenance / Removing / assembling the cutting blade ...........................................Page 10
Special accessories .......................................................................................................Page 10
Warranty / Customer Service ...................................................................Page 11
Disposal ......................................................................................................................Page 11
Declaration of Conformity / Manufacturer....................................Page 12
5 GB/IE/CY
Introduction
The following pictograms are used in these operating instructions / on the device:
Read instruction manual!
Observe caution and safety notes!
Caution – electric shock!
Danger to life!
Proper procedure and handling.
V
Voltage
~
Food Slicer SAS 150 A1
Q
Introduction
Dear Customer,
before using the electric Multi-Purpose Slicer for the first time please read carefully
and thoroughly through these operating
instructions and the safety advice, completely familiarising yourself with the appliance. You may find it
useful to open out the page illustrating the slicer and
describing both it and its operation. Retain these instructions for future reference and pass them on to
whoever might acquire the appliance at a future date.
W
use of the appliance or are caused by incorrect
operation of it.
Not for commercial use.
Q
Directly after unpacking the appliance check it to
ensure that all components are available and that
there are no signs of visible damage.
1 Food Slicer SAS 150 A1
1 Cleaning brush
1 Food holder plate
1 Slice tray
1 Screw helper and 2 spare adjustment screws
1 Operating instructions
Watts (Effective power)
Keep children away from electrical
devices!
Damaged appliances, power cables
and power plugs mean potentially fatal
risks from electric shock. Regularly
check the condition of the appliance,
the power cables and the power plugs.
Dispose packaging and appliance in
an environmentally-friendly way!
Items supplied
Q
Intended usage
This appliance is intended exclusively for slicing
normal household foodstuffs. The food to be sliced
must be thawed, unpacked and free from bones
before it can be sliced with the appliance.
All other uses, and modifications to the appliance,
are deemed to be improper usage and may result
in serious physical injury. The manufacturer accepts
no liability for damages that result from improper
6 GB/IE/CY
Q
Features
1
Blade protector
2
Vario-switch for blade speed
3
Switch for intermittent / continuous operation
4
Knob for unlocking the blade covering
5
Appliance housing
6
Blade cover
7
Cable winder / Cable depot
8
Power cable
9
Supporting table with guide slot
10
Food carriage with thumb guard
11
Food holder plate
12
Cutting blade
13
Food support plate
14
Regulator (Infinite control slice-thickness
controller) (Fig. C)
15
Screw helper
16
Adjustment screws
16 a
Spare adjustment screws
17
Slice / catch tray
18
Screw-clip for blade disassembly (Fig. E)
19
Cleaning brush (Fig. F)
Q
Technical data
examined by an authorised service centre before you use it again.
In the event of damage to the power cable 8,
the repair may only be carried out by the manufacturer, his service centre or a suitably qualified
specialist.
To avoid physical injuries:
Do not use the electric Multi-Purpose Slicer if
your hands are wet or you are standing on a
wet floor. Do not use the slicer if it is wet or moist.
The appliance may not be used outdoors.
Set up and store the electric Multi-
Purpose Slicer out of reach of children.
Nominal voltage: 230 V~ 50 Hz
Nominal power: 150 W
Continuous operation
time: COT = 10 Minutes
Cutting blade: reinforced, non-rusting
serrated blade, 17 cm
Q
Safety
Important safety
instructions
To avoid potentially fatal
electric shocks:
The electric Multi-Purpose Slicer may only be
connected to a 230 V AC electricity supply.
Always remove the plug from the
power socket before you clean the
slicer, if it malfunctions and when
you have finished using it. To disconnect the
appliance from the electricity supply never pull
the plug out by using the power cable
pull directly on the plug itself.
Never submerse the appliance in water and do
not expose it to rain or moisture. Should the appliance fall into water, First remove the plug
from the socket and then remove the appliance
from the water. Afterwards, have the slicer
8
, always
This device is not intended to be used by persons
(including children) with restricted physical,
sensory or mental abilities or with insufficient
experience and / or knowledge, unless they
are supervised by a person who is responsible
for their safety or they have received instruction
on how to use the device from such a responsible person. Children should be supervised in
order to ensure that they do not play with the
device.
Do not leave the electric Multi-Purpose Slicer
unattended if it is ready for immediate use.
Tips for personal safety
The electric Multi-Purpose Slicer is intended
exclusively for domestic use and not for commercial purposes.
Always ensure that the slicer is safely set up or
installed before you take it into use.
This appliance should always be used with the
food carriage
10
and the food holder plate 11.
Exceptions are possible, if for example the size
and shape of the food to be sliced does not
permit the use of these devices. Do not use the
appliance to cut bones or deep-frozen food.
Do not use the appliance if it is damaged in
any way. Promptly arrange to have the appliance repaired at an authorised service centre
or by an other suitably qualified specialist.
7 GB/IE/CY
Use the appliance with the supplied accesso-
ries only. No claims under the warranty nor a
liability for damages will be accepted if they result from improper or incorrect use of the slicer.
Place the catch tray 17 below the support
9
table
and on the housing such that the
sliced foods can fall in there directly and without hindrance after being cut.
Q
Before the First Usage
Q
First steps
Carefully remove the electric Multi-Purpose
Slicer from its packaging, remove all packaging materials and keep them together with the
main packaging.
Clean the electric Multi-Purpose Slicer before it
comes into contact with any foodstuffs (see also
the chapter “Cleaning”).
Q
Setting up the appliance
Specific safety advice on the
placing of the appliance
1. Never set the electric Multi-Purpose Slicer up
on a hot surface or near an open flame.
2. Ensure that the power cable
over hot or sharp-edged objects.
3. Do not allow the power cable
kinked or trapped and do not wrap it around
the electric Multi-Purpose Slicer.
Set the electric Multi-Purpose Slicer up on a
flat, non-slip surface close to a power socket.
Unwind the required length of power cable 8.
Insert the plug into the power socket.
Place the food carriage 10 on the supporting
table with guide slot
press the on the blade cover
side down, so that the holding clamps (on the
underside of the food carriage
sure that these have correctly engaged, in that
you check the mobility of the food carriage. Pull
to the front for removal of the food carriage
from the guide slot
port table
9
9
.
Push the food holder plate 11 on to the food
carriage
8 GB/IE/CY
10
.
8
does not pass
8
to become
9
(see Fig. B). Now
6
high standing
10
) engage. En-
and lift it from the sup-
Q
Adjust the infinite slice-thickness setting (see Fig. D)
Through variable tightenings of the adjusting
16
screws
you can determine the movement rate
of the infinite slice-thickness setting
Screw both of the adjusting screws 16 tight
with the screwdriver
15
.
Check, by turning the infinite slice-thickness
control knob
14
, to see if the desired movement
rate is suitable.
If it is not,
- loosen both adjusting screws
movement rate or
- tighten both adjusting screws
stiffer movement rate.
Q
Operation
Q
Working advice
Specific safety advice for
slicing and for the handling of
the appliance
1. Never touch the cuttingblade
er is in operation!
There is a risk of grave personal injury!
2. Always use the food carriage
holder plate
of foodstuff).
Press the pieces of food to be sliced forward
using the food holder
3. Use the slicer only for cutting normal house-
hold foods and not for other purposes. Do not
10
use the slicer for cutting deep-frozen foods,
bones, foods with large kernels or for the
slicing of still packaged foods.
4. Never use the slicer continuously for more than
10 minutes .
11
(Exception: very large pieces
11
.
14
.
16
for a lighter
16
further for a
12
when the slic-
10
and the food
OperationSafety / Before the First Usage / Operation
5. The cutting blade 12 continues to rotate for a
short while after the slicer has been switched off.
6. For reasons of safety, the slice thickness must
be returned to the “0“ setting after use.
Soft foodstuffs:
Direct the food carriage 10 slowly against the
12
cutter
. Soft foodstuffs, for example hams or
cheeses, are best cut when they are at a low
temperature / lightly chilled.
Hard foodstuffs:
With hard foodstuffs you can direct the food car-
10
riage
somewhat faster against the cutter 12.
You can thus quickly prepare your required
amount of of sliced foods, for example salami,
bread or gherkins.
Q
Selecting mode of operation
Note:
The two operating modes can be switched on
and off with the rocker switch for intermittent /
continuous operation
3
.
Continuous operation / max. 10 minutes
(switch in position “I“):
Set the switch for intermittent / continuous oper-
3
ation
to position “I“. The cutting blade
12
runs without it being necessary to hold the switch
in this position. Halting continuous operation:
Move the switch for intermittent / continuous
3
operation
into the “0” position and wait
until the cutting blade comes to a complete
standstill.
Intermittent operation (switch for
intermittent / continuous operation
in position “II“):
Set the switch for intermittent / continuous
3
operation
to position “II“.The cutting blade
will continue to run for as long as the switch
for intermittent / continuous operation is
held in this position. Halting intermittent operation: Release the switch for intermittent / continuous operation
3
and wait until the cutting
blade comes to a complete standstill.
Q
Setting the Vario-switch
cutting blade speed
Low revolutions / Revolution symbol
narrow end:
Set a low revolution speed when you want to
cut soft foodstuffs.Push the Vario-switch
completely in the direction of the sharp end.
High revolutions / Revolution symbol
wide end:
Use a high revolution speed for slicing hard
foodstuffs. Push the Vario-switch
in the direction of the broad end.
Note: Between the maximum and minimum
adjustments you can naturally also carry out
further individual settings. Practice appropriate
trial slicings.
Q
Slice thickness – setting
and cutting
Set the required slice thickness using the control
14
knob
(see Figure C). The settings on the scale
do not correspond with the slice thickness in mm.
For safety reasons the cuttingblade
in setting “0“.
Place the food to be sliced on the food
carriage
10
. If necessary, press the food to be
sliced with the food holder plate
against the food support
Switch the appliance on and, whilst lightly
pressing the food to be sliced forward, guide
it along the cutting blade
slicer always set the food support plate
the “0“ setting so that the sharp blade is covered.
The cutting blade
12
is ideally suitable for cutting wafer-thin slices of cold cuts or boiled ham
(see Fig. A).
To safeguard your fingers always use the food
carriage
10
and the food holder plate 11 (Ex-
ception: slicing very large pieces of foodstuffs).
12
13
.
12
. After using the
2
2
completely
is covered
11
lightly
13
into
9 GB/IE/CY
Loading...
