RECHARGEABLE FLOOR SWEEPER SABD 3.7 LI C2
RECHARGEABLE FLOOR SWEEPER
Operating instructions
AKKU-BESEN
Bedienungsanleitung
IAN 290965
ΕΠΑΝΑΦΟΡΤΙΖΟΜΕΝΗ ΣΚΟΥΠΑ
Οδηүίες χρήσης
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειωθείτε με όλες τις λειτουργίες
της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
GB / IE / NI / CY Operating instructions Page 1
GR / CY Οδηүίες χρήσης Σελίδα 9
DE / AT / CH Bedienungsanleitung Seite 17
A
C
D
B
E
F
Contents
Introduction ...........................................................2
Intended use ..........................................................2
Package contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Appliance description ...................................................2
Technical data .........................................................2
Safety information .....................................................3
Before first use .........................................................4
Assembly of the cordless sweeper .....................................................4
Charging the battery ................................................................5
Working with the cordless sweeper .......................................5
Cleaning and Care ......................................................5
Housing ..........................................................................6
Dirt container .....................................................................6
Rotary brush ......................................................................6
Storage ...............................................................6
Troubleshooting ........................................................6
Disposal ..............................................................7
Disposal of the appliance ............................................................7
Disposal of the battery charger. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Disposal of packaging ..............................................................7
Kompernass Handels GmbH warranty .....................................7
Service ..........................................................................8
Importer .........................................................................8
SABD 3.7 LI C2
GB│IE│NI│CY
│
1 ■
Introduction
Congratulations on the purchase of your new
appliance.
You have selected a high-quality product.
The operating instructions are part of this product.
They contain important information about safety,
usage and disposal. Before using the product, please
familiarise yourself with all operating and safety
instructions. Use the product only as described and
for the range of applications specified. Please also
pass these operating instructions on to any future
owner.
Dirt container
- Release knob
Figure D:
3 Charger
Figure E:
! Cover
. Catch
0 Rotary brush
Figure F:
6 Driveshaft
Intended use
This appliance is intended only for sweeping dry
dirt in dry, enclosed rooms.
The appliance is intended exclusively for domestic
use.
Not for commercial use. Use the appliance only as
described in this manual.
Package contents
■ Rechargeable Floor Sweeper
■ Charger
■ Handle (3 handle elements, of which one with
handgrip)
■ Operating instructions
Appliance description
Figure A:
Grip
Handle (3 elements)
Holder
Figure B:
Button on push-in connection
Recess on handle
Figure C:
On/Off switch
Charging socket
Plastic cap/transport securing appliance
Charge indicator
Technical data
Charger
Input: 100 - 240 V ~,
50 / 60 Hz,
0.1 A max.
Output: 5.3 V
current) 500 mA
Type designation: GPE003W-053050-3
Protection class: II /
Efficiency class 5:
Manufacturer: Golden Profit
Electronics LTD
Polarity of coaxial
connector:
Limited power source (LPS) 2.65 W
The power supply complies with the requirements for
a limited power source (LPS) as per EN 60950-1.
Cordless sweeper
Input voltage/current: 5.3 V 500 mA
Battery working voltage: 3.7 V
Battery: lithium ion battery
1 x 3.7V, 1800mAh
Polarity:
Charging time with
empty battery Akku: 5 hrs.
Operating time with full battery charge (depending
on floor covering): approx. 50 min.
(direct
■ 2 │ GB
│IE│NI│
CY
SABD 3.7 LI C2
Safety information
DANGER – RISK OF ELECTRICAL SHOCK!
► Never charge the appliance with a damaged mains adapter!
To avoid risks, replace a damaged power adapter immediately.
To do this, contact Customer Services.
► To avoid risks, arrange to have damaged power cables and/or plugs
replaced as soon as possible by a qualified specialist.
Do not use the mains adapter outside.
► Ensure that the power cable does not become wet or moist during use.
Route the cable in such a way that it cannot be crushed or damaged.
WARNING! RISK OF INJURY!
► Operate the appliance only with the supplied accessories.
► Do not use the appliance to sweep exposed concrete, gravel or similar
surfaces.
► Do not use the appliance to clean deep-pile carpets or wet floor
coverings.
► This appliance may be used by children aged 8 years and above
or by persons with limited physical, sensory or mental capabilities
or lack of experience and knowledge, provided that they are under
supervision or have been told how to use the appliance safely and
are aware of the potential risks.
► Do not allow children to use the appliance as a plaything.
► Cleaning and user maintenance tasks may not be carried out by
children unless they are supervised.
► Only use this appliance for its intended purpose as described in this
operating instructions.
SABD 3.7 LI C2
GB│IE│NI│CY
│
3 ■
WARNING! RISK OF INJURY!
► This product contains rechargeable batteries. Do not throw the batteries
into a fire and do not subject them to high temperatures. There is a
risk of explosion!
► Do not use the appliance as a toy.
► Never leave children unsupervised in the vicinity of the appliance!
ATTENTION! PROPERTY DAMAGE!
► Only charge the appliance with the mains adapter/charger supplied
(Type GPE003W-053050-3)!
► Only this cordless sweeper may be charged with the supplied battery
charger; the charger is not suitable for other batteries.
► Never attempt to recharge non-rechargeable batteries.
Before first use
■ Remove the packaging material from the appli-
ance including the plastic cap , which safeguards the on/off switch from unintentional
pressure during transport.
Assembly of the cordless sweeper
■ Attach the handle :
– Fit the 3 handle elements together by
pushing the push-in connection into the
handle. Press the knob on the push-in
connection inwards and push it into the
handle so that the head engages in
the recess on the handle . The handle
elements are now firmly fixed together
(see Figure B on the foldout page).
– Push the assembled handle with the push-
in connection into the holder on the appliance and rotate the handle until it engages.
■ Fitting the dirt container on the appliance:
■ 4 │ GB
│IE│NI│
CY
SABD 3.7 LI C2
– Push the dirt container into the appliance
with a slight tilting movement. Ensure that
the dirt container engages in the push-in
connection -.
Charging the battery
To ensure that the battery reaches its full performance potential, it is necessary to charge the battery for around 5 hours before the first use. Further
charges will take up to 5 hours depending on the
discharge level of the battery.
With a fully charged battery, the appliance provides an operating time of 50 minutes before
recharging will be again required.
ATTENTION! PROPERTY DAMAGE!
► Only use the charger 3 supplied.
► Operate the appliance only with the battery
fitted.
► Never attempt to remove the battery to
recharge it.
► Do not attempt to open the battery housing
or dismantle the battery. This will destroy it.
1) To charge the battery, ensure that the cordless
sweeper is switched off. If necessary, switch it
off using the on/off switch .
NOTE
Do not use the cordless sweeper when it is connected to the charger 3!
2) Insert the battery charger plug 3 into the
charging socket on the appliance and
then plug the mains plug into a mains socket.
3) While the battery is charging, the charge indicator lights up red. If this is not the case,
check the connectors and whether the cordless
sweeper is switched off.
4) Once the battery is fully charged, the charge
indicator lights up green. You can now use
the appliance with full power again.
5) First unplug the charger 3 from the mains
power socket and then the charger plug 3
from the charging socket on the appliance.
Working with the cordless
sweeper
WARNING! RISK OF INJURY!
Make sure you keep the rotating brush 0, rods
and appliance openings away from your face
and body.
NOTE
Never use the appliance without the dirt container attached. The dirt will simply be swirled
up!
■ Press the on/off switch to switch the cordless
sweeper on.
■ Move the cordless sweeper backwards and
forwards across the floor.
■ If you press the on/off button again, the
appliance will switch off
You can leave the handle engaged in the vertical
position during breaks.
NOTE
On some kinds of carpets, the cordless sweeper
may clatter or jump. If this is the case, work slowly
and in the opposite direction to the carpet pile.
Cleaning and Care
DANGER – RISK OF ELECTRICAL
SHOCK!
► Do not clean the appliance while charging
it. Always disconnect the battery charger 3
from the mains power socket before cleaning
the appliance!
NEVER immerse the appliance in water or
any other liquid!
WARNING! RISK OF INJURY!
Ensure that the appliance is not accidentally
switched on without the dirt container at-
tached or while cleaning the rotary brush 0.
Risk of injury!
SABD 3.7 LI C2
GB│IE│NI│CY
│
5 ■
ATTENTION! PROPERTY DAMAGE!
► Do not use abrasive or aggressive cleaning
materials. These may damage the surfaces.
Housing
■ Wipe off the appliance housing with a damp
cloth. If required, use a mild washing-up liquid
on the cloth.
■ Ensure that the appliance is completely dry be-
fore reconnecting it with the battery charger 3.
Dirt container
To ensure that the performance of the cordless
sweeper does not deteriorate, empty the dirt
container after every use.
■ Press the push-in connection - on the dirt
container and pull it off.
■ Empty the dirt container and push it back
onto the appliance so that it sits firmly on the
appliance and clicks into place on the release
knob -.
Rotary brush
If the rotary brush 0 stops turning because of a
severe dirt accumulation or because threads have
caught around it, proceed as follows:
Dismount the rotary brush 0. While doing this,
observe Figures E and F on the fold-out page in
this instruction manual:
1) Turn the cordless sweeper around and hold it
so that the rotary brush 0 is facing you.
2) Pull the hook on the locking appliance . and
take the side cover !off.
3) Pull the rotary brush 0 upwards out of the
appliance and then pull it out to the side.
4) Remove any dirt (on both sides of the brush
bristles) and clean the rotary brush 0. To do
this, take a damp cloth and wipe the individual
bristle bundles from the inside to the outside.
Replace the rotary brush 0.
1) Push the round side of the rotary brush 0 onto
the drive shaft 6.
2) In Push the square end of the rotary brush 0
into the housing so that the rotary brush 0 sits
straight in the housing again.
3) Replace the cover !and screw it down firmly.
Ensure that the locking appliance engages
properly.
Storage
ATTENTION! PROPERTY DAMAGE!
► Ensure that the appliance is switched off
before putting it away. Otherwise the battery
could be damaged by excessive discharging.
■ Store the cleaned appliance in a clean, dust-free
and dry place.
Troubleshooting
The appliance will not start.
■ The battery is discharged. Recharge the appli-
ance.
■ The appliance is defective. Contact the
Customer Service department.
The rotary brush 0 generates loud noises
when revolving.
■ The rotary brush 0 is soiled. Clean the rotary
brush 0.
■ The rotary brush 0 is not inserted properly.
Check whether the rotary brush 0 is correctly
fitted and correct the fitting if required.
■ 6 │ GB
│IE│NI│
CY
SABD 3.7 LI C2
Loading...
