LCD Monitor

User Manual

SyncMaster 320MP

Safety Instructions

Notational

Note

These safety instructions must be followed to ensure your safety and prevent property damage. Make sure to read the instructions carefully and use the product in the correct manner.

Warning / Caution

Failure to follow directions noted by this symbol could result in bodily harm or damage to the equipment.

Notational Conventions

Power

Prohibited

Do not disassemble

Do not touch

When not used for extended period of time, set your computer to DPM. If using screen saver, set it to active screen mode. The images here are for reference only, and are not applicable in all cases (or

countries). Shortcut to Anti-Afterimage Instructions

Do not use a damaged power cord or plug or a damaged or loose power

outlet.

• Otherwise, this may result in electric shock or fire.

Important to read and understand at all times

Disconnect the plug from the outlet

Ground to prevent an electric shock

Do not touch the power plug with wet hands when removing or plug-

ging the plug into the outlet.

• Otherwise, this may result in electric shock.

Make sure to connect the power cord to a grounded power outlet.

• Otherwise, it may result in electric shock or personal injury.

Ensure that the power plug is plugged into the power outlet firmly and

correctly.

• Otherwise, this may result in fire.

Safety Instructions

Do not forcefully bend or pull the power plug and do not place any

heavy material on it.

• Otherwise, this may result in fire.

Do not connect multiple appliances to the same power outlet.

• Otherwise, this may cause fire due to overheating.

Do not disconnect the power cord while using the product.

• Otherwise, this may result in damage to the product due to electric shock.

To disconnect the apparatus from the mains, the plug must be pulled out from the mains socket, therefore the mains plug shall be readily operable.

• This may cause electric shock or fire.

Use only the power cord provided by our company. Do not use the provided power cord of another product.

Installation

• Otherwise, this may result in fire or electric shock.

Be sure to contact an authorized Service Center when installing your monitor in a location with heavy dust, high or low temperatures, high humidity, and exposed to chemical substances and where it operates for 24 hours such as at airports, train stations etc.

Failure to do so may cause serious damage to your monitor.

Ensure that at least two persons lift and move the product.

• Otherwise, it may be dropped and cause personal injury, and/or dam-

age the product.

When installing the product in a cabinet or rack, make sure that the front end of the bottom of the product does not project out.

• Otherwise, it may fall or cause personal injury.

• Use a cabinet or rack of a size appropriate to the product.

DO NOT PLACE CANDLES, MOSQUITO REPELLANT, CIGARETTES AND ANY HEATING APPLIANCES NEAR THE PRODUCT.

• Otherwise, this may result in fire.

Keep heating appliances as far away from the power cord or the product as possible.

• Otherwise, this may result in electric shock or fire.

Safety Instructions

Do not install it in a badly ventilated location such as a bookcase or closet.

• Otherwise, this may result in fire due to an increase in the internal

temperature.

When putting the product down, make sure to put it down softly.

• Otherwise, this may result in damage to the screen display.

Do not place the front of the product on the floor.

• Otherwise, this may result in damage to the screen display.

Ensure that an authorized installation company installs the wall mount.

• Otherwise, it may fall and cause personal injury.

• Make sure to install the specified wall mount.

Install your product in a well ventilated location. Ensure that there is a clearance of more than 10 cm from the wall.

Clean

• Otherwise, it may result in fire due to an increase in the internal tem-

perature.

Ensure that the packaging vinyl is kept away from children.

• Otherwise, it may result in serious harm (suffocation) if children play

with it.

If the height of your monitor is adjustable, do not place any object or part of your body on the stand when lowering it.

• This may cause damage to the product or the person carrying it.

When cleaning the monitor case or the surface of the TFT-LCD screen, wipe with a slightly moistened, soft fabric.

Do not spray cleaner directly onto the surface of the product.

• Otherwise, this may result in the discoloration and distortion of the

structure and the screen surface may peel off.

Clean the product using a soft cloth with a monitor cleaner only. If you must use a cleaner other than the monitor cleaner, dilute it with water at a ratio of 1:10.

When cleaning the power plug pins or dusting the power outlet, clean it with a dry cloth.

• Otherwise, it may result in fire.

Safety Instructions

When cleaning the product, make sure to disconnect the power cord.

• Otherwise, it may result in electric shock or fire.

When cleaning the product, disconnect the power cord and clean it softly with a dry cloth.

• (Do not use chemicals such as wax, benzene, alcohol, thinner, mos-

quito repellant, lubricant, or cleaner.) These may change the appearance of the product surface and peel off the indication labels on the product.

Since the product housing is easily scratched, make sure to use the specified cloth only.

• Use the specified cloth adding only a little water. As the product may

be scratched if there is any foreign material on the cloth, make sure to shake it thoroughly before using it.

When cleaning the product, do not spray water directly onto the main body of the product.

Others

• Ensure that water does not enter the product and that it is not wet.

• Otherwise, this may result in electric shock, fire or a malfunction.

The product is a high voltage product. Ensure that users do not disassemble, repair or modify the product themselves.

• Otherwise, this may result in electric shock or fire. If the product

needs to be repaired, contact a Service Center.

If there is a strange smell or a strange sound or smoke is coming from the product, disconnect the power plug immediately and contact a Service Center.

• Otherwise, this may result in electric shock or fire.

Do not place this product in a location exposed to moisture, dust, smoke, water, or in a car.

• Otherwise, this may result in electric shock or fire.

When you drop the product or the case is broken, turn the power off and disconnect the power cord. Contact a Service Center.

• Otherwise, this may result in electric shock or fire.

If thunder or lightening is occurring, do not touch the power cord or antenna cable.

• Otherwise, this may result in electric shock or fire.

Safety Instructions

Do not try to move the monitor by pulling only the wire or the signal cable.

• Otherwise, it may fall and result in electric shock, damage to the

product or fire due to damage to the cable.

Do not lift or move the product back and forwards or right and left while only holding the power cord or signal cables.

• Otherwise, it may fall and result in electric shock, damage to the

product or fire due to damage to the cable.

Make sure that the ventilating opening is not blocked by a table or curtain.

• Otherwise, it may result in fire due to an increase in the internal tem-

perature.

Do not place any containers containing water, vases, flowerpots, medicines as well as any metal on the product.

• If water or a foreign material enters the product, disconnect the power

cord and contact a Service Center.

• This may result in a product malfunction, electric shock, or fire.

Do not use or keep combustible spray or flammable material near the product.

• Otherwise, this may result in an explosion or fire.

Do not insert any metal, such as chopsticks, coins, pins and steel, or flammable objects, such as matches or paper, inside the product (through the ventilating openings, input and output terminals, etc).

• If water or foreign material enters the product, disconnect the power

cord and contact a Service Center.

• Otherwise, this may result in electric shock or fire.

When using a fixed screen for a long time, an afterimage or stain may occur.

• If you are not using your product for a long period of time, put it into

sleep mode or use a moving screen saver.

Set a resolution and frequency appropriate to the product.

• Otherwise, your eyesight may be damaged.

When using headphones or earphones, do not turn the volume too high.

• Having the sound too loud may damage your hearing.

If you continually move closer to the product screen, your eyesight may be failing.

Safety Instructions

Take a rest for at least five (5) minutes after using the monitor for one (1) hour.

This reduces the weariness of your eyes.

Do not install it in an unstable location such as an unstable rack or uneven surface or a location exposed to vibrations.

• Otherwise, it may fall and cause personal injury and/or damage the

product.

• If you use the product in a location exposed to vibrations, it may

damage the product and result in fire.

When moving the product, turn the power off and disconnect the power plug, antenna cable, and all the cables connected to the product.

• Otherwise, it may result in electric shock or fire.

Ensure that children do not hang onto the product or climb up onto the product.

• The product may fall and cause personal injury or death.

If you do not use the product for a long period of time, disconnect the power cord from the power outlet.

• Otherwise, this may result in overheating or fire due to dust, and may

result in fire due to electric shock or leakage.

Do not place any heavy items or toys or confectionery, such as cookies etc. that may attract the attention of children and to the product.

• Your children may hang onto the product causing it to fall and this

may result in personal injury or death.

Be careful that children do not place the battery in their mouths when removed from the remote control. Place the battery in a location that children or infants cannot reach.

• If children have had the battery in their mouths, consult your doctor

immediately.

When replacing the battery, insert it with right polarity (+, -).

• Otherwise, the battery may become damaged or it may cause fire,

personal injury or damage due to leakage of the internal liquid.

Use only the specified standardized batteries, and do not use a new battery and a used battery at the same time.

• Otherwise, the batteries may be damaged or cause fire, personal in-

jury or damage due to a leakage of the internal liquid.

The batteries (and rechargeable batteries) are not ordinary refuse and must be returned for recycling purposes. The customer is responsible for returning the used or rechargeable batteries for recycling.

• The customer can return used or rechargeable batteries to a nearby

public recycling center or to a store selling the same type of the battery or rechargeable battery.

Safety Instructions

Do not place the product in a location exposed to direct sunlight or near any heat such as a fire or heater.

• This may reduce the lifetime of the product, and may result in fire.

Do not drop any objects onto the product or cause any impact to the product.

• Otherwise, this may result in electric shock or fire.

Do not use a humidifier or kitchen table near the product.

• Otherwise, this may result in electric shock or fire.

When there is a gas leak, do not touch the product or the power plug but ventilate immediately.

• If a spark occurs, it may cause an explosion or fire.

If the product has been turned on for a long time, the display panel becomes hot. Do not touch it.

• Keep the small accessories in a location out of the reach of children.

Be careful when adjusting the angle of the product or the height of the stand.

• This may result in personal injury as your hand or fingers may be-

come caught.

• Also, if you tilt the product too far, it may fall and cause personal

injury.

Do not install the product in a location low enough for children to reach.

• Otherwise, it may fall and result in personal injury.

• Since the front part of the product is heavy, install the product on a

level and stable surface.

Do not put any heavy objects on the product.

• This may result in personal injury and/or damage to the product.

Introduction

Package Contents

Note

Please make sure the following items are included with your LCD Display. If any items are missing, contact your dealer. Contact a local dealer to buy optional items.

Note

This stand is not for the Floor Standing Type.

Unpacking

Manuals

Quick Setup Guide Warranty Card

(Not available in all loca-

Cables

D-Sub Cable Power Cord

Others

LCD Display

User's Guide

tions)

Introduction

Others

Remote Control Batteries (AAA X 2)

(Not available in all loca-

BNC to RCA Adaptor Jack

Sold separately

DVI Cable Wall Mount KIT LAN Cable

HDD Cover

tions)

TV tuner box NetWork Box Semi Stand KIT

BNC Cable

Note

• You can purchase and connect a separate network box or TV tuner box. For information on how to use these, refer to their respective user manuals.

• You can only connect one external box.

Your LCD Display Front

Introduction

MENU button [MENU]

Opens the on-screen menu and exits from the menu. Also use to exit the OSD menu or return to the previous menu.

Navigate buttons (Up-Down buttons)

Moves from one menu item to another vertically or adjusts selected menu values.

Adjust buttons (Left-Right buttons) / Volume buttons

Moves from one menu item to another horizontally or adjusts selected menu values. When OSD is not on the screen, push the button to adjust volume.

ENTER button [ENTER]

Activates a highlighted menu item.

SOURCE button [SOURCE]

Switches from PC mode to Video mode. Changing the source is only allowed for external devices that are connected to the LCD Display at the time.

[PC] → [DVI] → [AV] → [HDMI] → [BNC]→ [Component]

Note

• The TV menu is available when a TV tuner box is installed.

• The MagicInfo menu is available when a network box is installed.

D.MENU

Opens the on-screen D.MENU.

Note

• This is available when a TV tuner box is installed.

Power button [ ]

Use this button for turning the LCD Display on and off.

Rear

Introduction

Power indicator

Shows PowerSaver mode by blinking green

Note

See PowerSaver described in the manual for further information regarding power saving functions. For energy conservation, turn your LCD Display OFF when it is not needed or when leaving it unattended for long periods.

Remote Control Sensor

Aim the remote control towards this spot on the LCD Display.

Note

For detailed information concerning cable connections, refer to Connecting Cables under Setup. The LCD Display 's configuration at the back may vary slightly depending on the LCD Display model.

POWER S/W ON [ │ ] / OFF [O]

Switches the LCD Display On/Off.

POWER IN

The power cord plugs into the LCD Display and the wall plug.

Introduction

RS232C OUT/IN (RS232C Serial PORT)

MDC(Multiple Display Control) Program Port

DVI / PC / HDMI IN [DVI/PC/HDMI AUDIO IN] (PC/DVI/HDMI Audio Connection Terminal (Input))

DVI / PC / HDMI IN [HDMI]

Connect the HDMI terminal at the back of your LCD Display to the HDMI terminal of your digital output device using a HDMI cable.

DVI / PC / HDMI IN [RGB](PC Video Connection Terminal)

Using a D-Sub Cable (15 pin D-Sub) - PC mode (Analog PC)

DVI / PC / HDMI IN [DVI] (PC Video Connection Terminal)

Using a DVI Cable (DVI-D to DVI-D) - DVI mode (Digital PC)

DC OUT [5V/1.5A]

Connect this to the POWER connector of a TV tuner box or network box.

AV IN [VIDEO] (VIDEO Connection Terminal)

Connect the [ VIDEO ] terminal of your monitor to the video output terminal of the external device using a VIDEO cable.

AV AUDIO IN [L-AUDIO-R](LCD Display Audio Connection Terminal (Input))

AV AUDIO OUT [L-AUDIO-R] (LCD Display Audio Connection Terminal (Output))

Introduction

BNC/COMPONENT OUT[R/PR, G/Y, B/PB, H, V]

(BNC/Component Connection Terminal (Output))

BNC (Analog PC) Connection: connecting the R, G, B, H, V ports.

Component Connection: connecting the PR, Y, PB ports.

BNC/COMPONENT IN[R/PR, G/Y, B/PB, H, V]

(BNC/Component Connection Terminal (Input))

Kensington Lock

The Kensington Lock is a device used to physically fix the system when using it in a public place. The locking device has to be purchased separately. The appearance and locking method may differ from the illustration depending on the manufacturer. Refer to the manual provided with the Kensington Lock for proper use. The locking device has to be purchased separately.

Note

The location of the Kensington Lock may be different depending on its model.

Using the Anti-Theft Kensington Lock

1. Insert the locking device into the Kensington

slot on the Monitor and turn it in the locking direction .

2. Connect the Kensington Lock cable.

3. Fix the Kensington Lock to a desk or a heavy

stationary object.

Note

See Connecting Cables for further information regarding cable connections.

Remote Control

Note

The performance of the remote control may be affected by a TV or other electronic device operating near the LCD Display , causing a malfunction due to interference with the frequency.

Introduction

POWER

OFF

Number Buttons

DEL button + VOL -

MUTE

TV/DTV

INFO

COLOR BUTTONS

TTX/MIX

STILL AUTO S.MODE MDC LOCK

SOURCE

ENTER/PRE-CH

CH/P D.MENU GUIDE

RETURN

Up-Down Left-Right buttons

EXIT

SRS

MagicInfo P.MODE

DUAL/MTS

PIP SWAP

1. POWER

Off

3. Number Buttons Press to change the channel.

Turns the product On.

Turns the product Off.

Introduction

The "-" button operates only for DTV. It is used to select MMS

4. DEL button

5. + VOL - Adjusts the audio volume.

(multi-channel) for a DTV.

MUTE

7. TV/DTV Selects the TV and DTV mode directly.

8. MENU

10. INFO

11.COLOR BUTTONS Press to add or delete channels and to store channels to the favorite

12. TTX/MIX

13.STILL Press the button once to freeze the screen. Press it again to un-

Pauses (mutes) the audio output temporarily. This is displayed on the lower left corner of the screen. The audio resumes if MUTE or - VOL + is pressed in the Mute mode.

Opens the on-screen menu and exits from the menu or closes the adjustment menu.

Activates a highlighted menu item.

Current picture information is displayed on the upper left corner of the screen.

channel list in the “Channel List” menu. TV channels provide written information services via teletext.

- Teletext Buttons

For more information > TTX / MIX

freeze.

14.AUTO Adjusts the screen display automatically in PC mode. By changing

the resolution in the control panel, auto function is performed.

15. S.MODE When pressing this button, the current mode is displayed at the bottom centre of the screen. The LCD Display has a built-in high fidelity stereo amplifier. Then press the button again to circle through available preconfigured modes. ( Standard → Music → Movie → Speech → Custom )

16.MDC MDC Quick Launch Button.

17.LOCK Activates or deactivates all function keys on both the remote control and the LCD Display except for the Power and LOCK buttons.

18.

SOURCE

19. ENTER/PRE-CH

20. CH/P In TV mode, selects TV channels.

21.D.MENU DTV menu display

22.GUIDE Electronic Program Guide (EPG) display.

Press the button to change the input signal SOURCE. Changing the SOURCE is only allowed for external devices that

are connected to the monitor at the time. This button is used to return to the immediately previous channel.

23. RETURN

Returns to the previous menu.

Introduction

24. Up-Down Left-Right but-

tons

25. EXIT

26. SRS

27.MagicInfo MagicInfo Quick Launch Button.

28. P.MODE When you press this button, current picture mode is displayed on

Moves from one menu item to another horizontally, vertically or adjusts selected menu values.

Exits from the menu screen.

Selects SRS TruSurround XT mode.

the lower center of the screen.

AV / HDMI / TV : P.MODE

The LCD Display has four automatic picture settings that are preset at the factory. Then push button again to circle through available preconfigured modes. ( Dynamic → Standard → Movie → Custom )

PC / DVI / MagicInfo: M/B (MagicBright)

MagicBright is a feature providing the optimum viewing environment depending on the contents of the image you are watching. Then push button again to circle through available preconfigured modes. (Entertain → Internet → Text → Custom )

29.

DUAL/MTS

30. PIP Every time you press the button, a PIP screen appears.

31.SWAP Swaps the contents of the PIP and main image. The image in the

DUAL-

STEREO/MONO, DUAL l / DUAL ll and MONO/NICAM MONO/NICAM STEREO can be operated depending on the broadcasting type by using the DUAL button on the remote control while watching TV.

MTS-

You can select MTS (Multichannel Television Stereo) mode.

Audio Type MTS/S_Mode Default

FM Stereo Mono Mono Manual Change

Stereo SAP

- This fuction does not work for this LCD Display.

PIP window will appear on the main screen, and the main screen image will appear in the PIP window.

Mono ↔ Stereo Mono ↔ SAP

Mono

Mechanical Layout Mechanical Layout

- This fuction does not work for this LCD Display.

Introduction

Installation VESA Bracket

• When installing VESA, make sure to comply with the international VESA standards.

• Purchasing VESA Bracket and Installation Information : Please contact your nearest SAMSUNG

Distributor to place an order. After your order is placed, installation professionals will visit you and install the bracket.

• At least 2 persons are needed in order to move the LCD Display.

• SAMSUNG is not responsible for any product damage or any injury caused by installation at

customer's discretion.

Dimensions

Notice

For securing the bracket on a wall, use only machine screws of 6 mm diameter and 8 to 12 mm length.

Wall Bracket Installation

• Contact a technician for installing the wall bracket.

• SAMSUNG Electronics is not responsible for any damages to the product or harm to customers

when the installation is done by the customer.

• This product is for installing on cement walls. The product may not stay in place when installed

on plaster or wood.

Components

Only use the components and accessories shipped with the product.

Introduction

Wall Bracket(1) Hinge(Left 1, Right1)Plastic

Wall Bracket Assembly

Note

There are two hinges(left and right). Use the correct one.

1. Insert and tighten the Captive Screw in the direction of the arrow.

When done, mount the wall bracket on the wall.

Hanger (4)

Screw (A)(11)

Screw(B) (4)

Anchor (11)

There are two hinges(left and right). Use the correct one.

A - Captive Screw B - Wall Bracket C - Hinge (Left) D - Hinge (Right)

Introduction

2. Before drilling into the wall, check if the length between the two locking holes at the back of the

product is correct. If the length is too short or long, loosen all or some of the 4screws on the wall bracket to adjust

the length.

A - Length between the two locking holes

3. Check the installation diagram and mark the drill points on the wall. Use the 5.0 mm bit to drill

holes deeper than 35 mm. Fix each anchor in the corresponding hole. Match each of the brackets and hinge holes to the corresponding anchor holes and insert and tighten the 11 screws A.

To mount the product on the wall bracket

The shape of the product may vary depending on the model. (The assemblies of the plastic hanger and the screw are the same)

1. Remove the 4 screws on the back of the product.

Introduction

2. Insert the screw B into the plastic hanger.

Notice

• Mount the product on the wall bracket and make sure it is properly fixed to the left and right plastic hangers.

• Be careful when installing the product on the bracket as fingers can be caught in the holes.

• Make sure the wall bracket is securely fixed to the wall, or the product may not stay in place after installation.

3. Tighten the 4 screws in step 2 (plastic hanger + screw B)to the rear holes of the product.

4. Remove safety pin (3) and insert the 4 product holders into the corresponding bracket holes (1). Then place the product(2) so that it is firmly fixed to the bracket. Make sure to re-insert and tighten the safety pin (3) to securely hold the product to the bracket.

A - LCD Display B - Wall Bracket C - Wall

Wall Bracket Angle Adjustment

Adjust the bracket angle to -2° before installing it on the wall.

1. Fix the product to the wall bracket.

Introduction

2. Hold the product at the top in the center and pull it forward (direction of the arrow) to adjust the angle.

Note

You can adjust the bracket angle between -2° and 15°.

Make sure to use the top center, and not the left or the right side of the product to adjust the angle.

Connections

Connecting a Computer

Using a Power cord with Earth

• In the event of failure, the earth lead may cause electric shock. Make sure to wire the earth lead in correctly, before connecting the AC power. When unwiring the earth lead, make sure to disconnect the AC power in advance.

Note

AV input devices such as DVD players, VCRs or camcorders as well as your computer can be connected to the LCD Display. For detailed information on connecting AV input devices, refer to the contents under Adjusting Your LCD Display.

Connect the power cord for your LCD Display to the power port on the back of the LCD Display. Turn on the power switch.

There are 2 ways to connect the D-sub to your LCD Display. Choose one of the following:

Using the D-sub (Analog) connector on the video card.

• Connect the D-sub to the 15-pin, RGB port on the back of your LCD Display and the 15 pin D-sub Port on the computer.

Using the DVI (Digital) connector on the video card.

• Connect the DVI Cable to the DVI port on the back of your LCD Display and the DVI port on the computer.

Connections

Note

• Turn on both your computer and the LCD Display.

• The DVI cable is optional.

• Contact a local SAMSUNG Electronics Service Center to buy optional items.

Using the BNC (Analog) connector on the video card.

• Connect the BNC Cable to the BNC/COMPONENT IN - R, G, B, H, V ports on the back of your LCD Display and the 15 pin D-sub Port on the computer.

Connect the audio cable for your LCD Display to the audio port on the back of your computer.

Connecting to Other devices

Using a Power cord with Earth

Note

Connecting AV Devices

1. Connect the port of the DVD, VCR (DVD / DTV Set-Top Box) to the [R-AUDIO-L] port of the LCD Display.

2. Then, start the DVD, VCR or Camcorders with a DVD disc or tape inserted.

3. Select AV using the SOURCE .

Note

The LCD Display has AV connection terminals to connect AV input devices like DVDs, VCRs or Camcorders. You may enjoy AV signals as long as the LCD Display is turned on.

Connecting to a Camcorder

Connections

1. Locate the AV output jacks on the camcorder. They are usually found on the side or back of the camcorder. Connect a set of audio cables between the AUDIO OUTPUT jacks on the camcorder and the AV AUDIO IN [L-AUDIO-R] on the LCD Display .

2. Connect a video cable between the VIDEO OUTPUT jack on the camcorder and the AV IN [VIDEO] on the LCD Display .

3. Select AV for the Camcorder connection using the SOURCE button on the front of the LCD Display or on the remote control.

4. Then, start the Camcorders with a tape inserted.

Note

The audio-video cables shown here are usually included with a Camcorder. (If not, check your local electronics store.) If your camcorder is stereo, you need to connect a set of two cables.

Connecting a DVD Player

1. Connect a set of audio cables between the AV AUDIO IN [L-AUDIO-R] on the LCD Display and the AUDIO OUT jacks on the DVD player.

2. Connect a Component cable between the BNC/COMPONENT IN- PR, Y, PB port on the LCD Display and the PR, Y, PB jacks on the DVD player.

Note

• Select Component for the connection to a DVD player using the SOURCE button on the front of

the LCD Display or on the remote control.

• Then, start the DVD Player with a DVD disc inserted.

Note

• A component cable is optional.

For an explanation of Component video, consult your DVD manual.

Connecting a DTV Set Top Box

Connections

Note

• The connections for a typical Set Top Box are shown below.

1. Connect a Component cable between the BNC/COMPONENT IN- PR, Y, PB port on the LCD Display and the PR, Y, PB jacks on the Set Top Box.

2. Connect a set of audio cables between the AV AUDIO IN [L-AUDIO-R] on the LCD Display and the AUDIO OUT jacks on the Set Top Box.

Note

• Select Component for the connection to a DTV Set Top Box using the SOURCE button on the

front of the LCD Display or on the remote control.

Note

• For an explanation of Component video, see your Set Top Box owner's manual.

Connecting Using a HDMI Cable

Note

• Input devices such as digital DVD are connected to the HDMI terminal of the LCD Display using

the HDMI cable.

• You cannot connect a PC to the HDMI terminal.

Connections

Connecting Using a DVI to HDMI Cable

Note

• Connect the DVI output terminal of a digital output device to the HDMI terminal of the LCD

Display using a DVI to HDMI cable.

• Connect the red and white jacks of an RCA to stereo (for PC) cable to the same colored audio

output terminals of the digital output device, and connect the opposite jack to the DVI / PC / HDMI AUDIO IN terminal of the LCD Display.

Connecting to an Audio System

Connections

Note

• Connect a set of audio cables between the AUX L, R jacks on the AUDIO SYSTEM and AUDIO

OUT [L-AUDIO-R] on LCD Display.

Using the Software

Monitor Driver

Note

When prompted by the operating system for the monitor driver, insert the CD-ROM included with this monitor. Driver installation is slightly different from one operating system to another. Follow the directions appropriate for the operating system you have.

Prepare a blank disk and download the driver program file at the Internet web site shown here.

Internet web site :

http://www.samsung.com/ (Worldwide)

Installing the Monitor Driver (Automatic)

1. Insert CD into the CD-ROM drive.

2. Click "Windows".

3. Choose your monitor model in the model list, then click the "OK" button.

4. If you can see following message window, then click the "Continue Anyway" button. Then click "OK" button (Microsoft® Windows® XP/2000 Operating System).

Using the Software

Note

This monitor driver is under certifying MS logo, and this installation doesn't damage your system.

The certified driver will be posted on Samsung Monitor homepage.

http://www.samsung.com/

Installing the Monitor Driver (Manual)

Microsoft® Windows Vista™‚ Operating System

1. Insert your Manual CD into your CD-ROM drive.

Click

(Start) and "Control Panel". Then, double-click on "Appearance and Personalization".

3. Click "Personalization" and then "Display Settings".

4. Click "Advanced Settings...".

5. Click "Properties" in the "Monitor" tab. If the "Properties" button is deactivated, it means the configuration for your monitor is completed. The monitor can be used as is.

If the message "Windows needs..." is displayed, as shown in the figure below, click "Continue".

Using the Software

Note

This monitor driver is under certifying MS logo, and this installation doesn't damage your system. The certified driver will be posted on Samsung Monitor homepage.

6. Click "Update Driver..." in the "Driver" tab.

7. Check the "Browse my computer for driver software" checkbox and click "Let me pick from a list of device drivers on my computer".

8. Click "Have Disk...” and select the folder (for example, D:\Drive) where the driver setup file is located, and click "OK".

Using the Software

9. Select the model that matches your monitor from the list of monitor models on the screen, and click "Next".

10.

Click "Close" → "Close" → "OK" → "OK" on the following screens displayed in sequence.

Microsoft® Windows® XP Operating System

Using the Software

1. Insert CD into the CD-ROM drive.

Click "Start" → "Control Panel" then click the "Appearance and Themes" icon.

3. Click "Display" icon and choose the "Settings" tab then click "Advanced...".

4. Click the "Properties" button on the "Monitor" tab and select "Driver" tab.

5. Click "Update Driver..." and select "Install from a list or..." then click "Next" button.

6. Select "Don't search, I will..." then click "Next" and then click "Have disk".

Using the Software

7. Click the "Browse" button then choose A:(D:\Driver) and choose your monitor model in the model list and click the "Next" button.

8. If you can see following message window, then click the "Continue Anyway" button. Then click "OK" button.

Note

This monitor driver is under certifying MS logo, and this installation doesn't damage your system.

The certified driver will be posted on Samsung Monitor homepage.

http://www.samsung.com/

9. Click the "Close" button then click "OK" button continually.

Using the Software

10. Monitor driver installation is completed.

Microsoft® Windows® 2000 Operating System

When you can see "Digital Signature Not Found" on your monitor, follow these steps.

1. Choose "OK" button on the "Insert disk" window.

2. Click the "Browse" button on the "File Needed" window.

3. Choose A:(D:\Driver) then click the "Open" button and then click "OK" button.

How to install

1. Click "Start", "Setting", "Control Panel".

2. Double click the "Display" icon.

3. Select the "Settings" tab and click "Advanced Properties" button.

4. Choose "Monitor".

Case1 : If the "Properties" button is inactive, it means your monitor is properly configured. Please stop installation

Case2 : If the "Properties" button is active, click the "Properties" button then follow next steps continually.

5. Click "Driver" and then click on "Update Driver..." then click on the "Next" button.

6. Choose "Display a list of the known drivers for this device so that I can choose a specific driver" then click "Next" and then click "Have disk".

7. Click the "Browse" button then choose A:(D:\Driver).

8. Click the "Open" button, then click "OK" button.

9. Choose your monitor model and click the "Next" button then click "Next" button.

10. Click the "Finish" button then the "Close" button.

If you can see the "Digital Signature Not Found" window then click the "Yes" button. And click the "Finish" button then the "Close" button.

Microsoft® Windows® Millennium Operating System

1. Click "Start", "Setting", "Control Panel".

2. Double click the "Display" icon.

3. Select the "Settings" tab and click "Advanced Properties" button.

Using the Software

4. Select the "Monitor" tab.

5. Click the "Change" button in the "Monitor Type" area.

6. Choose "Specify the location of the driver".

7. Choose "Display a list of all the driver in a specific location..." then click "Next" button.

8. Click the "Have Disk" button.

9. Specify A:\(D:\driver) then click "OK" button.

10. Select "Show all devices" and choose the monitor that corresponds to the one you connected to your computer and click "OK".

11. Continue choosing "Close" button and "OK" button until you close the Display Properties dialogue box.

Microsoft® Windows® NT Operating System

1. Click "Start", "Settings", "Control Panel", and then double-click "Display" icon.

2. In Display Registration Information window, click Settings Tab and then click "All Display Modes".

3. Select a mode that you wish to use (Resolution, Number of colors and Vertical frequency) and then click "OK".

4. Click "Apply" button if you see the screen working normally after clicking "Test". If the screen is not normal, change to a different mode (lower mode of resolution, colors or frequency).

Note

If there is no Mode at All Display Modes, select the level of resolution and vertical frequency by referring to the Preset Timing Modes in the user guide.

Linux Operating System

To execute X-Window, you need to make the X86Config file, which is a type of system setting file.

1. Press "Enter" at the first and the second screen after executing the X86Config file.

2. The third screen is for setting your mouse.

3. Set a mouse for your computer.

4. The next screen is for selecting a keyboard.

5. Set a Keyboard for your computer.

6. The next screen is for setting your monitor.

7. First of all, set a horizontal frequency for your monitor. (You can enter the frequency directly.)

8. Set a vertical frequency for your monitor. (You can enter the frequency directly.)

9. Enter the model name of your monitor. This information will not affect the actual execution of X-Window.

10. You have finished setting up your monitor. Execute X-Window after setting other requested hardware.

Introduction

A Multiple Display Control (MDC) is an appli cat ion allowing various di s play s to be easily and simultan eously operated on a PC. RS-232C, a standard of serial communication, is used for the communication between a PC and a display. Therefore, a serial cable should be connected between the serial po rt on a PC and the serial port on a display.

Main Screen

Click Start > Program > Samsung > MDC System to start the program.

Select a set to see the volume of the selected set within the slider.

Main Icons Select Button Remocon Info Grid Safet y L o ck Display Selection Port Selection Control Tools

1. Use the main icons to switch into each screen.

2. Allows you to enable or disable the remote co ntrol signal receiving function of the display unit.

3. Set the Saf ety Loc k f unction. When setting th e Lock function, yo u can only opera te power and lock bu ttons on the remote control and set.

4. The setting for the PC Serial Port can change. The original value is COM1.

5. Click Select all or Clear to select or clear all dis plays.

6. Use Grid to view brief inf ormation on select ed display.

7. Select a display from Dis play Selection.

8. Use Control Tools to c o ntrol displays.

<Note> The remote control Enable/Disable function operates whether or not the power is On/Off, and this

applies to all displays connected to the MDC. Ho wev er, regardless of the status at the time the MDC is shut down, the remo te co nt ro l s ignal receiving fun cti o n of all displays is initialize d to Enable when the MDC is closed.

Port Se lection

1. The Multiple Dis play Control is originally s et t o COM1.

2. If any port other than COM1 is used, COM1 through COM4 can be selected in the Port Selection Menu.

3. If the exact port na me th at is connected to the LCD Display using a serial cable is not selected, communication will be unavail abl e.

4. The selected port i s st ored in the pro gram and u s ed f or the next pr o gram as well .

Power Con trol

1. Click Po wer Control of th e main icons and the Power Control s creen appea rs .

Info Grid shows some basic information necessary to Power Control.

1) (Power Status)

2) Input

3) Image Size

4) On Timer

5) Off Timer

2. Use the Select All bu tton or Check Box to choos e a display to control.

Power Control allo ws controlling some of the fun ctions of the selected display.

Power On/Off

(

urns the power of th e s el e cted display On/Off.

2) Volume

- Controls the volume lev el of the selected displa y. It receives the volume value of the selected display from the sets and displays it in the slider.

When you cancel the s ele ction or choose Selec t A ll, t he v alue returns to the def ault value 10)

(Mute On/Off)

- Turns on/off the Mute function of the selected display. When selecting one set at a ti m e, turn on the Mute f unction f or the sele cted set. The Mute f unction is d i s ab led automatically when yo u adjust t he volume level.

The value s ret ur n to th e de f a ul t s et tings when you undo the selections or choose "Select All".)

The Power Control feature is available for all displays. The Volu me Control and Mute features are available only for the displays who se power statu s is ON.

Input Source

1. Cl ic k I n put Source of the main ic o ns an d the Input So u rce cont rol screen appear s . Click Select All or use C heck Box to select a displ ay to control.

• TV Mode

• PC Mode

Info Grid shows some basic information necessary to Input Source Control.

1) PC

- Changes the Input Source of the selected display to PC.

2) BNC

- Changes the Input Source of the selected display to BNC.

3) DVI

- Changes the Input Source of the selected display to DVI.

4) TV

-Chan

es the Input Source of the selected display to TV.

5) DTV

-Chan

es the Input Source of the selected display to DTV.

6) AV es the Input Source of the selected display to AV.

-Chan

7) S-Video

- Changes the Input Source of the selected display to S-

8) Component

-Chan

es the Input Source of the selected display to Component.

9) MagicInfo

he Input source of MagicInfo works only on MagicInfo model.

10) HDMI

-Chan

es the Input Source of the selected display to HDMI.

11) Channel

- Channel arrow appears when the Input Source is TV.

TV Source can be selected only in products with TV and controlling channels is allowed only when Input Source is TV.

The Input Source Control feature is available only for the displays whose power status is ON.

ideo.

Image Size

PC, BN C, DV I

1. Click Image Size of the main icons and the Image Size control screen appears.

Info Grid shows some basic information necessary to Image Size Control.

( Power Status)

- Shows the p o w er s tatus of the current dis play.

2) Imag e Si ze

- Shows the current Image Size of the display in use.

3) Input

- Shows the current Input Source of the d i s p la y in use.

4) Info Grid dis plays only the displays whos e Input Source is PC, BNC, DVI.

5) PC So urce - When yo u click Image Size, the P C Source tab f irst appear .

- The Image Size Control button controls Image Size available for PC, BNC, DVI.

6) Video Source

- Clic k th e Vi d eo Source tab to control Ima g e Si ze f o r re spectiv e Inp u t So u rc e.

The Input source of MagicInfo works only on MagicInfo model. The Input source of TV works only on TV model. Image Size Control is available only for the displays for which power status is ON.

Image Size

TV, AV, S-Video, Component, DVI(HDCP), HDMI, DTV

1. Click Image Size of the main icons and the Image Size control screen appears.

Info Grid shows some basic information necessary to Image Size Control.

1) Click the Video Source tab to adjust Image Size for TV, AV, S-Video, Component, DVI(HDCP), HDMI, DTV.

Click Select All or use C heck Box to select a displ ay to control.

2) Info Grid displays only the display having TV, AV, S-Video, Component or DVI(HDCP) as input source.

3) Switch Ima ge Size of the selected disp lay randomly.

Note: Auto Wide, Zoom1 and Zoom2 are not available for selection when the input signal type for Component and DVI (HDCP) is 720p or 1080i. (The Auto Wide mode is a vailable only for TV, AV, and S-Video.)

4) The screen modes can only be adjusted when a TV (PAL only) is connected and the Image Size item is set to Auto

Wide.

The Input source of MagicInfo works only on MagicInfo model. The Input source of TV works only on TV model. The Image Size Control feature is available only for the displays whose power status is ON.

Time

1. Click Time of the main icons and the Time Control screen appears.

Info Grid shows some basic information necessary to Time Control.

1) Current Time

- Set the current time for the selected display (PC Time).

- To change the current time , firs t change the PC Ti me.

2) On Time Setup

- Set the Ho ur, Minute , AM/PM of O n T im e Setup, Status, So urce, Volu m e o f the selected display.

3) Off Time Setup

- Set the Ho ur, Minute , and AM/PM, Status for O ff Time Set up of the se l ected display.

4) Shows the On Time settings.

5) Shows the Off Time settings.

The Input source of MagicInfo works only on MagicInfo model. The Input source of TV works only on TV model. Time Control is available only for the displays for which the power status is ON. At On Time Setup, TV Source functions only for TV Model. At On Time Setup, MagicInfo Source functions only for MagicInfo Model.

PIP

PIP Size

1. Click PIP of the main icons and the PIP control s creen appears. Click Select All or use C heck Box to select a displ ay to control.

Info Grid shows some basic information necessary to PIP Size Control.

1) PIP Size

- Shows the curren t PI P Size of the display in use.

2) OFF

- Turns off the PIP of the selected display.

3) Large

- Turns on the PIP of the selected display and changes the size to Large.

4) Small

- Turns on the PIP of the selected display and changes the size to Small.

5) Double 1

- Turns on the PIP of the selected display and changes the size to Double 1.

6) Double 2

- Turns on the PIP of the selected display and changes the size to Double 2.

7) Double 3 (Picture By Picture)

- Turns on the PBP of the selected display and changes the size to Double 3.

The Input source of MagicInfo works only on MagicInfo model. The Input source of TV works only on TV model. PIP Size can be controlled with turning on the LCD Display power.

PIP

PIP Source

1. Click PIP of the main icons and the PIP control s creen appears.

Info Grid shows some basic information necessary to PIP Source Control.

1) PIP Source

- PIP Source can be co ntrolled with turning on the LCD Dis play power.

2) PC

- Changes the source of the PIP of the selected display to PC.

3) BNC

- Changes the source of the PIP of the selected display to BNC.

4) DVI

- Changes the source of the PIP of the selected display to DVI.

5) AV

- Changes the source of the PIP of the selected display to AV.

6) S-Video

- Changes the source of the PIP of the selected display to S-Video.

7) Component

- Changes the source of the PIP of the selected display to Component.

8) HDMI

- Changes the source of the PIP of the selected display to HDMI.

Note: Some of the PIP Sources may not be available for selection, depending on the input source type of the Main Screen.

The Input source of MagicInfo works only on MagicInfo model. The PIP Control feature is available only for th e displays whose power stat us is ON and the PIP

function is set to ON.

Settings


1. Click Settin gs o f the main icons and the Settings Control sc reen appears.

Info Grid shows some basic information necessary to Settings Control.

Adj

When each f unction is selected, the set value of the selec ted functio n is displayed in the slide.When selected, each function fetches the value for the set and displ ays it on the s l i d e bar. Whe n "Select All" is chosen, the default va l ue is displayed. Changing a value in this scree n will automatically c han ge the mode to "CUSTOM ."

1) Picture

- Available only for TV, AV , S -Vid eo, C o mpo nent, HDMI, DTV.

2) Contrast

usts C o ntrast of the selec ted display.

3) Brightness

- Adjusts Brightness of the selected display.

4) Sharpness

usts Sharpness of th e selected display.

5) Color

usts Color of the se lected display.

6) Tint

- Adjusts Tint of the selected display.

- Available only for NT.

7) C olor Tone usts the Color To ne for the selected display.

8) Color Temp usts the Color Temp for the selected di splay.

9) Brightness Sens or

usts th e Brightness Sensor for the selected display.

10) Dynamic Contrast usts the Dynamic Contrast for the selected display.

The Input source of MagicInfo works only on MagicInfo model. Color Temp is only enabled if the Color Tone is set to Off. The Input source of TV works only on TV model. This feature is available only for the displays whose power status is ON and if no selection is made, the

factory default is displayed.

Settings

Pictu r e PC

1. Click Settin gs o f the main icons and the Settings Control sc reen appears.

Adj

Info Grid shows some basic information necessary to Settings Control. When each function is selected, the set value of the selected function is displayed in the slide. When selected, each function fetches the value for the set and displays it on the slide bar. When "Select All" is chosen, the default val ue is displayed. Changin g a va lue in this screen will automatic ally change the mode to "CU STOM."

1) Picture PC

- Available only for PC, BNC , DV I.

2) Contrast

usts C o ntrast of the selec ted display.

3) Brightness usts Brightness for the selected display.

4) Red

usts red Color of the selected display.

- Available only for NT.

5) Green

usts green Color of the se lected display.

- Available only for NT.

6) Blue

usts blue Color of the selected display.

- Available only for NT.

7) C olor Tone

usts the Color To ne for the selected display.

8) Color Temp usts the Color Temp for the selected di splay.

9) Brightness Sens or usts th e Brightness Sensor for the selected display.

10) Dynamic Contrast usts the Dynamic Contrast for the selected display.

The Input source of MagicInfo works only on MagicInfo model. The Input source of TV works only on TV model. Color Temp is only enabled if the Color Tone is set to Off. This feature is available only for the displays whose power status is ON and if no selection is made, the

factory default is displayed.

Settings

Adj

Audio

1. Click Settin gs o f the main icons and the Settings Control sc reen appears.

1) Audio

- Controls audio settings for all input sources.

2) Bass

usts Bass of the selected display.

3) Treble

usts Treble of t he selected display.

4) Balance

usts Balance of the selected display.

5) SRS TS XT

- SRS TS XT Sound ON/OFF of the selected display.

6) Sound Select

- Select either Main or Sub when PIP is On.

The Input source of MagicInfo works only on MagicInfo model. The Input source of TV works only on TV model. This feature is available only for the displays whose power status is ON and if no selection is made, the

factory default is displayed.

Settings

Image Lock

1. Click Settin gs o f the main icons and the Settings Control sc reen appears.

Info Grid shows some basic information necessary to Settings Control.

1) Image Lock

- Available only for PC, BNC.

2) Coarse

- Adjusts Coarse of the selected display.

3) Fine

- Adjusts Fine of the selected display.

4) Position

- Adjusts Position of the selected display.

5) Auto Adjustment

- Self-Ad just to the incoming PC signal.

The Input source of MagicInfo works only on MagicInfo model. The Input source of TV works only on TV model. Settings Control is available only for the displays for which the power status is ON.

Maintenance

Lamp Control

1. Click on the "Maintenance" icon in the Main Icon column to displa y th e Maintenance screen .

An "Info Grid" showing several basic data items appears.

1) Maintenance

llows the Main ten ance Control functio n f or all input sources.

2) Auto Lamp Control

- Automatically adjusts the backlight of the s elected display at a specified time. he Manual Lamp Control automatically turns off if you adjust using the Auto Lamp Control.

3) Manual Lamp Control

- Allows you to adjust the backlight of the selected display regardle s s of the t ime. he Auto Lamp Contro l automatically turns off if you adjust using the Manua l Lamp Control.

The Maintenance Control feature is available only for the displays whose power status is ON. The Input source of MagicInfo works only on MagicInfo model. The Input source of TV works only on TV model.

Maintenance

Scroll

1. Click on the "Maintenance" icon in the Main Icon column to displa y th e Maintenance screen .

1) Scroll

- This function is used to remove the afterimages that occur when a still screen is displayed on the selected

display for a long time.

2) Pixel Shif t

- This allows the screen to be moved finely at the specified time interval.

3) Safety Screen

- The Safety Screen func tion is used to prevent a f ter images from occurring when a still screen is display ed on the

monitor for a long time . The In terval item is used to set the repetition cycle in hour u nits and the Time item is used to set the time when the Safety Screen function must be performed. The Type item can be set to Sc ro ll, Pixel, Bar, Eraser , Al l White, or Pattern.

4) Safety Screen2

- This function is used to prev ent afterimages fro m occurring. There ar e five (5) types that yo u can select and

control with this function.

For the Scroll type, the Time item can be set to 1, 2, 3, 4 or 5. For the Bar and Eraser types, it can be set to 10, 20, 30, 40 or 50. For the All White and Pattern type, it ca n be set to 1, 5, 10, 20 or 30.

The Input source of MagicInfo works only on MagicInfo model. The Input source of TV works only on TV model. The Maintenance Control feature is available only for the displays whose power status is ON.

Maintenance

Video Wall

1. Click on the "Maintenance" icon in the Main Icon column to displa y th e Maintenance screen .

1) Video Wall

- A Video Wall is a set of video screens that are connected together, so that each screen shows a part of the whole picture or so tha t th e same picture is repeated on each screen.

2) Video Wall (Screen divider)

- The screen c an be divided into . You can select a number of screens with a different layout when dividing.

z Select a mode fr o m Screen divider.

Select a display from Dis play Selection.

The place will be set up by press ing a number in the selec ted mode.

z The MDC program supplied by Samsung supports up to 5x5 LCD Displayes.

3) On / Off

urns on/off the Video Wall function of the selected display.

4) Format

he form at can be se lected t o s e e a divided screen.

z Full

Natural

You may not operate this function in MagicInfo. The Input source of TV works only on TV model. The Maintenance Control function is available only for the displays where the power status is ON.

Troubleshooting

The display you wish t o co nt ro l do es not appear on the Powe r Control Info Grid

- Check the connection of RS232C. (Check if it is properly connected to the Com1 port)

- Check the displays to see if any of the other displays connected have the same ID. If more than one displays have the same ID, those dis plays are not properly detected by the program due to data conflict.

- Check if the Display Set ID is a number between 0 and 25. (Adjust using the Display menu)

Note : A Display Set ID must be a value between 0 and 25 .

2. The display y ou wis h to control does not appear on the other Control Info Grids

- Check to see if the display power is ON. (You can che ck this in Power Control Info Grid)

- Check if you can change the input source of the display.

3. The dialogue box appears repeatedly.

- Check to see if the displa y y o u wish to control is selected.

4. Both On Timer and Off Timer have been set but different time is showing.

- Apply cur rent time to synch r o n ize the display cl o cks.

5. The remote may not function properly when you turn off the remote Function, disconnect the RS-232C cable, or exit the program in an I rregular manne r. Rerun the pr o gram and turn th e remote function again to Resto re normal functions.

<Note> This program may malfunction due to problems in com munication circuits or i nt erference from elect ro nic

appliances n earby.

Settings Value Display In Multiple Display Mode

When there are more t han one disp l ays connected, the settings val ues are dis p layed as fo l l o ws.

1. No selection: Dis play s th e Factory Default Value .

2. Selected one display: Fetches and d isplays t he s ettings value for the select ed display.

3. Selected one display (ID1) and add anothe r dis play (ID3): The pro gram, which was displaying th e settings value o f ID 1, fetches and displays the va lue of ID3.

4. Selected all sets using Select All: Returns to the Factory Default Value.

Adjusting the LCD Display

Input

Available Modes

•

PC / BNC / DVI

•

HDMI

•

Component

Note

• The TV menu is available when a TV tuner box is installed.

• The MagicInfo menu is available when a network box is installed.

Source List

MENU → ENTER → [Input] → ENTER → [Source List] → , → ENTER

Use to select PC, DVI or other external input sources connected to the LCD Display. Use to select the screen of your choice.

1. PC

2. DVI

3. AV

4. HDMI

This is deactivated when a TV tuner box is installed.

5. BNC

6. Component

• The direct button on the remote control is the 'SOURCE' button.

• For PC and DVI, this is deactivated if the cable is disconnected.

Edit Name

MENU → ENTER → [Input] → → ENTER → [Edit Name] → , → ENTER

Adjusting the LCD Display

BNC mode is not supported if the component cable is connected. To use BNC mode, remove the component cable and connect the BNC cable.

Component mode is not supported if the BNC cable is connected. To use Component mode, remove the BNC cable and connect the Component cable.

Note

Name the input device connected to the input jacks to make your input source selection easier.

VCR / DVD / Cable STB / HD STB / Satellite STB / AV Receiver / DVD Receiver / Game / Camcorder / DVD Combo / DHR / PC

Picture [PC / BNC / DVI Mode]

Available Modes

•

PC / BNC / DVI

•

HDMI

•

Component

Note

• The TV menu is available when a TV tuner box is installed.

• The MagicInfo menu is available when a network box is installed.

MagicBright

MENU → → ENTER → [Picture] → ENTER → [MagicBright] → , → ENTER

Adjusting the LCD Display

MagicBright

the image you are watching. Currently four different modes are available: Entertain, Internet, Text and Custom. Each mode has its own pre-configured brightness value. You can easily select one of the four settings by simply pressing the MagicBright control button.

1. Entertain

High brightness For documents or works involving heavy text.

2. Internet

Medium brightness For working with a mixture of images such as texts and graphics.

3. Text

Normal brightness For documents or works involving heavy text.

4. Custom

Although the values are carefully chosen by our engineers, the pre-configured values may not be comfortable to your eyes depending on your taste.

is a feature providing the optimum viewing environment depending on the contents of

Custom

Contrast

If this is the case, adjust the brightness and contrast by using the OSD menu.

By using the on-screen menus, the contrast and brightness can be changed to your personal preference. MENU →

Note

By adjusting the picture using the Custom function, MagicBright will change to Custom mode.

MENU → → ENTER → [Picture] → → ENTER → [Custom] → ENTER→ [Contrast] → ,

→ ENTER

→ ENTER → [Picture] → → ENTER → [Custom]

Adjusts the Contrast.

Brightness

MENU → → ENTER → [Picture] → → ENTER → [Custom] → → ENTER → [Brightness] →

Adjusts the Brightness.

Sharpness

MENU → → ENTER → [Picture] → → ENTER → [Custom] → → → ENTER → [Sharp- ness] →

Adjusts the Sharpness.

Adjusting the LCD Display

, → ENTER

Color Tone

MENU → → ENTER → [Picture] → → →ENTER → [Color Tone] → , → ENTER

The color tones can be changed.

1. Off

2. Cool

3. Normal

4. Warm

5. Custom

Note

If you set the Color Tone to Cool, Normal, Warm, or Custom, the Color Temp function is disabled.

If you set the Color Tone to Off, the Color Control function is disabled

Color Control

Adjusts individual Red, Green, Blue color balance. MENU →

→ ENTER → [Picture] → → → → ENTER → [Color Control]

Red

Adjusting the LCD Display

Note

If you adjust the picture by using the Color Control function, Color Tone will turn to the Custom mode.

MENU → [Red] → , → ENTER

Green

MENU → → ENTER → [Picture] → → → → ENTER → [Color Control] → → ENTER → [Green] → , → ENTER

Blue

MENU → → ENTER → [Picture] → → → → ENTER → [Color Control] → → → ENTER → f [Blue] → , → ENTER

Color Temp

MENU → → ENTER → [Picture] → → → → ENTER → [Color Temp] → , → ENTER

→ ENTER → [Picture] → → → → ENTER → [Color Control] → ENTER →

Color Temp is a measure of the 'warmth' of the image colors.

This function is only enabled if the Color Tone is set to Off.

Image Lock

Image Lock is used to fine-tune and get the best image by removing noise that creates unstable images with jitters and shakiness. If satisfactory results are not obtained using the Fine adjustment, use the Coarse adjustment and then use Fine again.

(Available in PC mode only) MENU → → ENTER → [Picture] → → → → → ENTER → [Image Lock]

Coarse

MENU → → ENTER → [Picture] → → → → → ENTER → [Image Lock] → ENTER → [Coarse] → , → ENTER

Note

Removes noise such as vertical stripes. Coarse adjustment may move the screen image area. You may relocate it to the center using the horizontal control menu.

Fine

MENU → → ENTER → [Picture] → → → → → ENTER → [Image Lock] → → ENTER → [Fine] →

Removes noise such as horizontal stripes. If the noise persists even after Fine tuning, repeat it after adjusting the frequency (clock speed).

H-Position

Adjusting the LCD Display

, → ENTER

MENU → ENTER → [H-Position] → , → ENTER

Adjusts the screen location horizontally.

V-Position

MENU → → ENTER → [V-Position] → , → ENTER

Adjusts the screen location vertically.

Auto Adjustment

MENU → → ENTER → [Picture] → → → → → → ENTER → [Auto Adjustment ]

The values of Fine, Coarse, Position are adjusted automatically. By changing the resolution in the control panel, the auto function is performed.

→ ENTER → [Picture] → → → → → ENTER → [Image Lock] → → →

(Available in PC mode only)

Note

The direct button on the remote control is the 'AUTO' button.

Signal Balance

This is used to make up for the weak RGB signal transmitted by a long signal cable. MENU → → ENTER → [Picture] → → → → → → → ENTER → [Signal Balance] (Available in PC mode only)

Signal Balance

MENU → → ENTER → [Picture] → → → → → → → ENTER → [Signal Balance] → ENTER → [Signal Balance] → , → ENTER

Selects either On or Off with the signal control.

Signal Control

Adjusting the LCD Display

MENU →

→ ENTER → [Signal Control]

1. R-Gain

2. G-Gain

3. B-Gain

→ ENTER → [Picture] → → → → → → → ENTER → [Signal Balance] →

MENU →

ance] →

MENU → → ENTER → [Picture] → → → → → → → ENTER → [Signal Bal- ance] → → ENTER → [Signal Control] → → ENTER→ [G-Gain] → , → ENTER

MENU → → ENTER → [Picture] → → → → → → → ENTER → [Signal Bal- ance] → → ENTER → [Signal Control] → → → ENTER→ [B-Gain] → , → ENTER

→ ENTER → [Picture] → → → → → → → ENTER → [Signal Bal-

→ ENTER → [Signal Control] → ENTER → [R-Gain] → , → ENTER

4. R-Offset

MENU → → ENTER → [Picture] → → → → → → → ENTER → [Signal Bal-

ance] →

ENTER

5. G-Offset

MENU → → ENTER → [Picture] → → → → → → → ENTER → [Signal Bal-

ance] → → ENTER → [Signal Control] → → → → → ENTER→ [G-Offset] → ,

→ ENTER

6. B-Offset

→ ENTER → [Signal Control] → → → → ENTER→ [R-Offset] → , →

Size

Adjusting the LCD Display

MENU → → ENTER → [Picture] → → → → → → → ENTER → [Signal Bal-

ance] → → ENTER → [Signal Control] → → → → → → ENTER→ [B-Offset] →

, → ENTER

MENU → → ENTER → [Picture] → → → → → → → → ENTER → [Size] → , → ENTER

The Size can be switched.

1. 16:9

2. 4:3

Dynamic Contrast

MENU → → ENTER → [Picture] → → → → → → → → ENTER → [Dynamic Contrast ]

→ , → ENTER

Dynamic Contrast automatically detects the distribution of the visual signal and adjusts to create an optimum contrast.

1. Off

2. On

Picture [ AV / HDMI / Component Mode]

Available Modes

•

PC / BNC / DVI

•

Mode

Adjusting the LCD Display

•

HDMI

•

Component

Note

• The TV menu is available when a TV tuner box is installed.

• The MagicInfo menu is available when a network box is installed.

MENU → → ENTER → [Picture] → ENTER → [Mode] → , → ENTER
