Instructions

1204 Terminator (Class 1, Division 2)

(Catalog Number 1204-TFA1, 1204-TFB2)

Where this Option is Used The 1204 Terminator Option can be installed in most adjustable

frequency AC drive applications to increase protection of the AC
motor. The option is designed to be used with Allen-Bradley
Adjustable frequency AC drives. When installed at the motor
terminals, the terminator can reduce potentially destructive reflected
wave spikes that can occur with long motor leads.

What this Option Contains The Terminator Option contains the terminator device with an

2

attached 3 meter (10 feet) standard 4 wire 3mm
connection cable.

(12 gauge)

What these Instructions Contain

These instructions contain the information you need to properly
install the Terminator Option. Recommended mounting, connecting,
and grounding procedures are included. Major topics and page
numbers are listed below.

Catalog Number Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Dimensions, Weights and Cable Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Heat Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Determining the Maximum Cable Length for Your System . . . . . . . . . . . . . . . . . . . . . . . 4

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Drive Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Catalog Number Description The following table provides information about the catalog number

for the Terminator Option:

1204 –T F B2

First Position Second Position Third Position Fourth Position

Bulletin No. Type NEMA Rating Voltage Rating & Size

Maximum
Allowable Drive

1

Carrier Frequency

6 kHz

2 kHz

Description Letter Description Letter Description Code

Bulletin
Number

T Terminator F NEMA Type 4 A1 380-600V 0.37-3.7

B2 380-600V 1.5-597

1

Refer to the maximum cable length tables on pages 4 through 6.

Voltage
Rating

Drive
kW (HP)

(0.5-5)

(2.0-800)

2 1204 Terminator (Class 1, Division 2)

Dimensions, Weights and Cable Locations

6.4

(0.25)

Refer to the following diagram for terminator dimensions and cable
locations. The dimensions are given in millimeters and (inches). The
terminator weighs 3.86 kilograms (8.5 pounds).

182.9
(7.20)

170.2
(6.70)

14.2

(0.56)

Allen-Bradley

Bulletin 1204–TFXX Series A
AC Drive HP ZZZZ
Voltage WWWW VAC
Max. Carrier Freq. Y KHz
Type 4X Enclosure
Hazardous Locations
Class I, Division 2
Groups A, B, C, D
Temperature Code T3 (200˚ c)

See Instruction Manual For Mounting Instructions

FRONT

DANGER

CAN CAUSE SHOCK,

BURNS, OR DEATH

DISCONNECT AND LOCKOUT

ALL POWER SOURCES

BEFORE SERVICING

SURFACES

MAY BE HOT

ALLOW TO COOL

BEFORE SERVICING

Motor Terminator

U

CUS

L

®

LISTED

IND. CONT. EQ.

FOR USE IN HAZ. LOC.

8AA4

Assembled in Mexico

Out-Going Cable

155.5
(6.12)

127.0
(5.00)

SIDE

(4) Slots for M4 Hardware

Approximately

3048 (120)

88.9

(3.50)

BOTTOM

117.9
(4.64)

158.8
(6.25)

1204 Terminator (Class 1, Division 2) 3

Specifications The following specifications are provided for the Terminator Option.

Category Specifications

Input power 380-600V, Three-Phase
Maximum Drive Carrier

Frequency

1

Ambient temperature 0-40 degrees C (32-104 degrees F)
Humidity 5-95% non-condensing
Atmosphere Class 1, Division 2
Heat dissipation
Enclosure type IP65 (NEMA Type 4x)
Hazardous

Environment Rating
Agency certification U.L., C-UL
Altitude derating Full rating 0-1000 meters (0-3280 feet)

TFA1 – 6 kHz
TFB2 – 2 kHz

Refer to “Drive Programming” on page 9 for additional information.

1

Refer to the heat dissipation table below.

T3 (200

° C); Groups A, B, C, D

degrees C.

40

Ambient

Temperature

1

The drive PWM carrier frequency that you choose affects the heat dissipation and the surface temperature

of the terminator.

Limit

35

30

0 4,000

Heat Dissipation

This chart is based on an ambient temperature of 45 degrees C.

1204-TFA1 Terminator 1204-TFB2 Terminator

Drive
Frequency

Length

meters (feet)

6 kHz 91 (300) 210W 142° C 220W 150° C

183 (600) 250W 160

4 kHz 91 (300) 170W 125

183 (600) 180W 130

2 kHz 91 (300) 80W 81

183 (600) 90W 88

460 Volts + 10% 600 Volts + 10% 460 Volts + 10% 600 Volts + 10%

Watts Heatsink° Watts Heatsink° Watts Heatsink° Watts Heatsink °

° C 260W 169° C
° C 180W 133° C

° C 210W 138° C
° C100W95° C 200W 139° C 290W 182° C
° C 140W 104° C 250W 160° C 360W 200° C

1,000

(3,300)

2,000

(6,600)

Altitude

Must Use 2 kHz

3,000

(9,900)

(13,200)

m

(ft)

4 1204 Terminator (Class 1, Division 2)

Determining the Maximum Cable Length for Your System

Use the following tables to determine the maximum cable length for
your system.

The values shown are for nominal input voltage and a drive carrier
frequency of 2 kHz. If you plan to operate your system at carrier
frequencies above 2 kHz, refer to the heat dissipation table on page 3.
If you plan to operate your system above the levels listed in the heat
dissipation table, consult the factory.

If you are running at high-line conditions (nominal line + 10%),
multiply the values by 0.85.

1305 Drive Maximum Motor Cable Length Restrictions

Lengths are given in meters and (feet)

w/ 1204–TFB2 Terminator w/ 1204–TFA1 Terminator

Motor Type Motor Type

A or B A B

Drive HP
(460V)

0.5 0.5 NR NR NR NR NR NR For applications/ installations using new
1 0.5 NR NR 76 (250) 61 (200) 76 (250) 121 (400)

2 0.5 91 (300) 121 (400) 99 (325) 61 (200) 152 (500) 121 (400)

3 1 91 (300) 182 (600) 99 (325) 61 (200) 182 (600) 121 (400)

5 2 121 (400) 182 (600) 99 (325) 61 (200) 182 (600) 121 (400)

NR = Not Recommended.

Type A Motor Characteristics: No phase paper or misplaced phase paper, lower quality insulation systems, corona inception voltages between 850 and 1000 volts.

Type B Motor Characteristics: Properly placed phase paper, medium quality insulation systems, corona inception voltages between 1000 and 1200 volts.

1329R/L Motors: These AC variable speed motors are “Power Matched” for use with Allen-Bradley drives. Each motor is energy efficient and designed

Motor HP
(460V)

1 NR NR 45 (150) 61 (200) 45 (150) 76 (250)

1 61 (200) 61 (200) 99 (325) 61 (200) 121 (400) 121 (400)
2 NR NR 91 (300) 61 (200) 91 (300) 121 (400)

2 91 (300) 121 (400) 99 (325) 61 (200) 152 (500) 121 (400)
3 NR NR 91 (300) 61 (200) 91 (300) 121 (400)

3 91 (300) 121 (400) 99 (325) 61 (200) 152 (500) 121 (400)
5 NR NR 91 (300) 61 (200) 91 (300) 121 (400)

Cable Type Cable Type Cable Type

Shielded Unshielded Shielded Unshielded Shielded Unshielded

to meet or exceed the requirements of the Federal Energy Act of 1992. All 1329R/L motors are optimized for variable speed operation
and include premium inverter grade insulation systems which meet or exceed NEMA MG1. Part 31.40.4.2.

With Allen-Bradley
1329R/L Motors

motors, no restrictions in lead length due to
voltage reflection are necessary. You should
observe standard practices for voltage drop,
cable capacitance, and other issues.

1204 Terminator (Class 1, Division 2) 5

1336 PLUSPLUS II/IMPACT™/FORCE
Maximum Motor Cable Length Restrictions (380-480 Volt Drives)

Lengths are given in meters and (feet)

w/1204-TFB2 Terminator w/1204-TFA1 Terminator

Motor Type Motor Type

A or B A B

Drive
Frame Drive kW (HP) Motor kW (HP)

A1 0.37 (0.5) 0.37 (0.5)

0.75 (1) 0.75 (1) 30.5 (100) 30.5 (100) 30.5 (100) 30.5 (100)

0.75 (1) 0.37 (0.5) 30.5 (100) 61.0 (200) 30.5 (100) 61.0 (200)

A2 1.2 (1.5) 1.2 (1.5) 30.5 (100) 30.5 (100) 61.0 (200) 61.0 (200)

0.75 (1) 30.5 (100) 30.5 (100) 61.0 (200) 61.0 (200)

0.37 (0.5) 30.5 (100) 30.5 (100) 61.0 (200) 61.0 (200)

1.5 (2) 1.5 (2) 91.4 (300) 91.4 (300) 30.5 (100) 30.5 (100) 91.4 (300) 61.0 (200)

1.2 (1.5) 91.4 (300) 182.9 (600) 30.5 (100) 30.5 (100) 91.4 (300) 61.0 (200)

0.75 (1) 182.9 (600) 182.9 (600) 30.5 (100) 30.5 (100) 91.4 (300) 61.0 (200)

0.37 (0.5) 182.9 (600) 182.9 (600) 30.5 (100) 30.5 (100) 91.4 (300) 61.0 (200)

2.2 (3)

2.2 (3) 182.9 (600) 182.9 (600)

1.5 (2) 182.9 (600) 182.9 (600)

0.75 (1) 182.9 (600) 182.9 (600)

0.37 (0.5) 182.9 (600) 182.9 (600)

A3 3.7 (5)

3.7 (5) 182.9 (600) 182.9 (600)

2.2 (3) 182.9 (600) 182.9 (600)

1.5 (2) 182.9 (600) 182.9 (600)

0.75 (1) 182.9 (600) 182.9 (600)

0.37 (0.5) 182.9 (600) 182.9 (600)

A4 5.5-7.5 (7.5-10) 5.5-7.5 (7.5-10) 182.9 (600) 182.9 (600)
B 5.5-22 (7.5-30) 5.5-22 (7.5-30) 182.9 (600) 182.9 (600)
C 30-45 (X40-X60) 30-45 (40-60) 182.9 (600) 182.9 (600)
D 45-112 (60-X150) 45-112 (60-150) 182.9 (600) 182.9 (600)
E 112-187 (150-250) 112-224 (150-300) 182.9 (600) 182.9 (600)
F 187-336 (250-450) 187-336 (250-450) 182.9 (600) 182.9 (600)
G 187-448 (X250-600) 187-448 (250-600) 182.9 (600) 182.9 (600)
H 552-597 (700-800) 522-597 (700-800) 182.9 (600) 182.9 (600)

NR = Not Recommended

1

Values shown are for 480V nominal input voltage and drive carrier frequency of 2 kHz. Consult factory regarding operation at carrier frequencies above 2 kHz. Multiply
values by 0.85 for high line conditions. For input voltages of 380, 400 or 415V AC, multiply the table values by 1.25, 1.20 or 1.15, respectively.

2

Includes wire in conduit.

Cable Type Cable Type Cable Type

Shld.

2

Unshld. Shld.

2

Unshld. Shld.

2

30.5 (100) 61.0 (200) 30.5 (100) 61.0 (200) For applications/ installations

Use 1204-TFA1

Terminator

or 1329R/L Motor

Use 1204-TFB2 Terminator

or 1329R/L Motor

Unshld.

With Allen-Bradley
1329R/L Motors

using new motors, no restric­tions in lead length due to volt­age reflection are necessary.
You should observe standard
practices for voltage drop, cable
capacitance, and other issues.

1

Type A Motor Characteristics: No phase paper or misplaced phase paper, lower quality insulation systems, corona inception voltages between 850 and 1000 volts.

Type B Motor Characteristics: Properly placed phase paper, medium quality insulation systems, corona inception voltages between 1000 and 1200 volts.

1329R/L Motors: These AC variable speed motors are “Power Matched” for use with Allen-Bradley drives. Each motor is energy efficient and designed

to meet or exceed the requirements of the Federal Energy Act of 1992. All 1329R/L motors are optimized for variable speed operation
and include premium inverter grade insulation systems which meet or exceed NEMA MG1. Part 31.40.4.2.

6 1204 Terminator (Class 1, Division 2)

1336 PLUS/PLUS II/IMPACT™/FORCE
Maximum Motor Cable Length Restrictions (500-600 Volt Drives)

Lengths are given in meters and (feet)

w/1204-TFB2 Terminator w/1204-TFA1 Terminator

Motor Type Motor Type

Drive
Frame Drive kW (HP) Motor kW (HP)

A4 0.75 (1) 0.75 (1) NR 182.9 (600) 335.3 (1100) NR 61.0 (200) 182.9 (600)

0.37 (0.5) NR 182.9 (600) 335.3 (1100) NR 61.0 (200) 182.9 (600)

1.5 (2) 1.5 (2) NR 182.9 (600) 335.3 (1100) NR 61.0 (200) 182.9 (600)

1.2 (1.5) NR 182.9 (600) 335.3 (1100) NR 61.0 (200) 182.9 (600)

0.75 (1) NR 182.9 (600) 335.3 (1100) NR 61.0 (200) 182.9 (600)

0.37 (0.5) NR 182.9 (600) 335.3 (1100) NR 61.0 (200) 182.9 (600)

2.2 (3) 2.2 (3) NR 182.9 (600) 335.3 (1100) NR 61.0 (200) 182.9 (600)

1.5 (2) NR 182.9 (600) 335.3 (1100) NR 61.0 (200) 182.9 (600)

0.75 (1) NR 182.9 (600) 335.3 (1100) NR 61.0 (200) 182.9 (600)

0.37 (0.5) NR 182.9 (600) 335.3 (1100) NR 61.0 (200) 182.9 (600)

3.7 (5) 3.7 (5) NR 182.9 (600) 335.3 (1100) NR 61.0 (200) 182.9 (600)

2.2 (3) NR 182.9 (600) 335.3 (1100) NR 61.0 (200) 182.9 (600)

1.5 (2) NR 182.9 (600) 335.3 (1100) NR 61.0 (200) 182.9 (600)

0.75 (1) NR 182.9 (600) 335.3 (1100) NR 61.0 (200) 182.9 (600)

0.37 (0.5) NR 182.9 (600) 335.3 (1100) NR 61.0 (200) 182.9 (600)

B 5.5-15 (7.5-20) 5.5-15(7.5-20) 91.4 (300) 182.9 (600)
C 18.5-45 (25-60) 18.5-45 (25-60) 91.4 (300) 182.9 (600)
D 56-93 (75-125) 56-93 (75-125) 91.4 (300) 182.9 (600)
E 112-224 (150-X300) 112-224 (150-X300) 91.4 (300) 182.9 (600)
F 187-336 (250-450) 187-336 (250-450) 91.4 (300) 182.9 (600)
G 224-448 (300-600) 224-448 (300-600) 91.4 (300) 182.9 (600)
H 522-597 (700-800) 522-597 (700-800) 91.4 (300) 182.9 (600)

NR = Not Recommended

1

Values shown are for nominal input voltage and drive carrier frequency of 2 kHz. Consult factory regarding operation at carrier frequencies above 2 kHz. Multiply values
by 0.85 for high line conditions.

2

Information not available at time of printing.

A B 1329R/L A B

Any Cable Any Cable Any Cable Any Cable Any Cable Any Cable

2
2
2
2
2
2
2

NR 61.0 (200) 182.9 (600)
NR 61.0 (200) 182.9 (600)
NR 61.0 (200) 182.9 (600)
NR 61.0 (200) 182.9 (600)
NR 61.0 (200) 182.9 (600)
NR 61.0 (200) 182.9 (600)
NR 61.0 (200) 182.9 (600)

1

With
Allen-Bradley
1329R/L Motors

Type A Motor Characteristics: No phase paper or misplaced phase paper, lower quality insulation systems, corona inception voltages between 850 and 1000 volts.

Type B Motor Characteristics: Properly placed phase paper, medium quality insulation systems, corona inception voltages between 1000 and 1200 volts.

1329R/L Motors: These AC variable speed motors are “Power Matched” for use with Allen-Bradley drives. Each motor is energy efficient and designed

to meet or exceed the requirements of the Federal Energy Act of 1992. All 1329R/L motors are optimized for variable speed operation
and include premium inverter grade insulation systems which meet or exceed NEMA MG1. Part 31.40.4.2.

PowerFlex 70/700/700H See the PowerFlex Reference Manual, Volume 1,

publication PFLEX-RM001 available online at

www.rockwellautomation.com/literature.

PowerFlex 700S See the PowerFlex Reference Manual, Volume 2,

publication PFLEX-RM002 available online at
www.rockwellautomation.com/literature.

1204 Terminator (Class 1, Division 2) 7

Installation Installation of the 1204 Terminator must be in accordance with

Class I, Division 2 wiring methods as defined in Article 501-4(b) of
the National Electrical Code, NFPA 70 for installations within the
United States, or as specified in Section 18-152 of the Canadian
Electrical Code for installation within Canada.

WARNING: EXPLOSION HAZARD

!

• Substitution of components may impair suitability for

Class I, Division 2.

• When in hazardous locations, turn off power before

replacing or wiring modules.

• Do not disconnect equipment unless power has been

switched off or the area is known to be nonhazardous.

To install the terminator, follow these steps:

1. Remove all power connected to the system.

ATTENTION: Electric shock can cause injury or

!

death. Remove all power before working with this
product. Verify that the voltage on the bus capacitors
has discharged. Measure the DC bus voltage at the +
and – terminals of TB1. The voltage must be zero.

ATTENTION: The terminator surfaces may be hot
enough to cause serious burns. You should take this into
consideration when deciding where to mount your
terminator.

2. Mount the terminator on a metal surface.

Metal Surface

Top View Top View

Air Flow

Allen-Bradley

Motor Terminator

Bulletin 1204–TFXX Series A
AC Drive HP ZZZZ
Voltage WWWW VAC
Max. Carrier Freq. Y KHz
Type 4X Enclosure

U

CUS

L

®

Hazardous Locations

LISTED

IND. CONT. EQ.

Class I, Division 2

FOR USE IN HAZ. LOC.

Groups A, B, C, D

8AA4

Temperature Code T3 (200˚ c)

Assembled in Mexico

DANGER

CAN CAUSE SHOCK,
BURNS, OR DEATH

DISCONNECT AND LOCKOUT

ALL POWER SOURCES

BEFORE SERVICING

SURFACES
MAY BE HOT

ALLOW TO COOL

BEFORE SERVICING

See Instruction Manual For Mounting Instructions

Important: Heatsink Fins Must be Vertical.

See Instruction Manual For Mounting Instructions

DANGER

CAN CAUSE SHOCK,

BURNS, OR DEATH

DISCONNECT AND LOCKOUT

MAY BE HOT

SURFACES

ALL POWER SOURCES

BEFORE SERVICING

BEFORE SERVICING

ALLOW TO COOL

Carrier Freq.

Voltage 380-600 VAC

AC Drive HP .5 to 600

Bulletin 1204-TFB2 Series A

≤

2 KHz

L

I

I

S

N

T

D

E

Made in U.S.A.

®

D

C

O

9

N

6

T

6

X

E

Q

L

I

I

S

N

T

D

E

®

D

C

O

9

N

6

T

6

X

E

Q

Allen-Bradley

Motor Terminator

Front View Front View Front View

8 1204 Terminator (Class 1, Division 2)

3. You must allow at least 152.4 mm (6 in.) on each side of the unit

and 304.8 mm (12 in.) on the top and bottom of the unit for
proper air circulation.

152.4 mm
(6.0 in.)

304.8 mm

304.8 mm
(12.0 in.)

Allen-Bradley

Bulletin 1204–TFXX Series A
AC Drive HP ZZZZ
Voltage WWWW VAC
Max. Carrier Freq. Y KHz
Type 4X Enclosure
Hazardous Locations
Class I, Division 2
Groups A, B, C, D
Temperature Code T3 (200˚ c)

See Instruction Manual For Mounting Instructions

(12.0 in.)

DANGER

CAN CAUSE SHOCK,
BURNS, OR DEATH

DISCONNECT AND LOCKOUT

ALL POWER SOURCES

BEFORE SERVICING

SURFACES
MAY BE HOT

ALLOW TO COOL

BEFORE SERVICING

Motor Terminator

U

CUS

L

®

LISTED

IND. CONT. EQ.

FOR USE IN HAZ. LOC.

8AA4

Assembled in Mexico

Front View

152.4 mm
(6.0 in.)

152.4 mm
(6.0 in.)

152.4 mm
(6.0 in.)

Top View

ATTENTION: The terminator surfaces may be hot enough

!

to cause serious burns. If your system consistently runs at
line voltages above nominal, you should place a shroud
around the terminator to prevent accidental exposure.

4. If your system consistently runs at line voltages above nominal

and you are mounting the terminator in a high-traffic area where
the potential for contact is high, you should place a shroud of
expanded metal or mesh screen around the terminator. The shroud
should not restrict air flow to the terminator, nor should it be
closer than 152.4 mm (6 in.) to the terminator at any point.

152.4 mm
(6.0 in.)

152.4 mm
(6.0 in.)

152.4 mm

152.4 mm
(6.0 in.)

Allen-Bradley

Motor Terminator

Bulletin 1204–TFXX Series A
AC Drive HP ZZZZ
Voltage WWWW VAC
Max. Carrier Freq. Y KHz
Type 4X Enclosure

U

CUS

L

®

Hazardous Locations

LISTED

Class I, Division 2

IND. CONT. EQ.

Groups A, B, C, D

FOR USE IN HAZ. LOC.

8AA4

Temperature Code T3 (200˚ c)

Assembled in Mexico

DANGER

CAN CAUSE SHOCK,
BURNS, OR DEATH

DISCONNECT AND LOCKOUT

ALL POWER SOURCES

BEFORE SERVICING

SURFACES

MAY BE HOT

ALLOW TO COOL
BEFORE SERVICING

See Instruction Manual For Mounting Instructions

152.4 mm
(6.0 in.)

152.4 mm
(6.0 in.)

152.4 mm
(6.0 in.)

Shroud

(6.0 in.)

Shroud

Front View

Top View

5. Connect the red, white and black cable conductors to the

corresponding three-phase motor leads/terminals.

6. Attach the green cable conductor to the motor ground that is

connected directly to the drive PE terminal.

152.4 mm
(6.0 in.)

1204 Terminator (Class 1, Division 2) 9

Drive Programming If the default PWM frequency is greater than the maximum drive

carrier frequency listed on page 3, you must re-program the drive to a
value that is less than or equal to the maximum drive carrier
frequency.

Grounding Follow the recommended grounding practices provided in your drive

User Manual. The following illustration shows an example of the
system grounding practices.

Motor

Terminator*

Conduit/4-Wire Cable

Nearest

Building Structure Steel

R (L1)

S (L2)

ESC SEL

T (L3)

PE

RIO/DH+

or Analog

Common

Mode Core*

To Computer/Position Controller

(for TE shield ground, see "

Control and Signal Wiring"

U (T1)
V (T2)

JOG

W (T3)
PE/Gnd.

Common

Mode
Core*

Shield*

Shield

Motor Frame

* Options that can be

installed as needed.

)

Motor Frame

Local Codes

Allen-Bradley

Motor Terminator

Bulletin 1204–TFXX Series A
AC Drive HP ZZZZ
Voltage WWWW VAC
Max. Carrier Freq. Y KHz
Type 4X Enclosure

U

CUS

L

®

Hazardous Locations

LISTED

Class I, Division 2

IND. CONT. EQ.

Groups A, B, C, D

FOR USE IN HAZ. LOC.

8AA4

Temperature Code T3 (200˚ c)

Assembled in Mexico

DANGER

CAN CAUSE SHOCK,
BURNS, OR DEATH

DISCONNECT AND LOCKOUT

ALL POWER SOURCES
BEFORE SERVICING

SURFACES
MAY BE HOT

ALLOW TO COOL

BEFORE SERVICING

See Instruction Manual For Mounting Instructions

PE

Ground per

Important: If you cannot connect the terminator directly to the motor

mounted junction box, an auxiliary junction box can be
used. However, the terminator-to-motor connection length
should be no more than 6 meters (20 feet).
If installed in hazardous location, an auxiliary junction box
rated Class 1, Division 2 must be used.

ATTENTION: The National Codes and standards (NEC,

!

VDE, BSI, etc.) and local codes outline provisions for safely
installing electrical equipment. Installation must comply
with specifications regarding wire types, conductor sizes,
branch circuit protection, and disconnect devices. Failure
to do so may result in personal injury and/or equipment
damage.

You can power up the system once proper installation, drive
programming, and grounding is completed.

10 1204 Terminator (Class 1, Division 2)

Maintenance The terminator does not require routine maintenance. However, you

should periodically remove dust to allow for maximum cooling
efficiency.

ATTENTION: Electric shock can cause injury or death.

!

!

Remove all power before touching the terminator.

ATTENTION: The terminator surfaces may be hot enough
to cause serious burns. Allow the terminator time to cool
down before touching any surface.

Notes

1204 Terminator (Class 1, Division 2) 11

www.rockwellautomation.com

Power, Control and Information Solutions Headquarters

Americas: Rockwell Automation, 1201 South Second Street, Milwaukee, WI 53204 USA, Tel: [phone], Fax: [phone]
Europe/Middle East/Africa: Rockwell Automation, Vorstlaan/Boulevard du Souverain 36, 1170 Brussels, Belgium, Tel: [phone], Fax: [phone]
Asia Pacific: Rockwell Automation, Level 14, Core F, Cyberport 3, 100 Cyberport Road, Hong Kong, Tel: [phone], Fax: [phone]

Publication 1204-5.0 – July 2005 P/N 74002-112-01 (04)

Supersedes May 2005 Copyright © 2005 Rockwell Automation, Inc. All rights reserved. Printed in USA.
