AG35-Quecopen
Hardware Design
LTE Module Series
Rev. AG35-Quecopen_Hardware_Design_V1.3
Date: 2018-12-12
Status: Released
www.quectel.com
LTE Module Series
AG35-Quecopen
Hardware Design
Our aim is to provide customers with timely and comprehensive service. For any
assistance, please contact our company headquarters:
Quectel Wireless Solutions Co., Ltd.
7th Floor, Hongye Building, No.1801 Hongmei Road, Xuhui District, Shanghai 200233, China
Tel: +86 21 5108 6236
Email: info@quectel.com
Or our local office. For more information, please visit:
http://www.quectel.com/support/sales.htm
For technical support, or to report documentation errors, please visit:
http://www.quectel.com/support/technical.htm
Or email to: support@quectel.com
GENERAL NOTES
QUECTEL OFFERS THE INFORMATION AS A SERVICE TO ITS CUSTOMERS. THE INFORMATION
PROVIDED IS BASED UPON CUSTOMERS’ REQUIREMENTS. QUECTEL MAKES EVERY EFFORT
TO ENSURE THE QUALITY OF THE INFORMATION IT MAKES AVAILABLE. QUECTEL DOES NOT
MAKE ANY WARRANTY AS TO THE INFORMATION CONTAINED HEREIN, AND DOES NOT ACCEPT
ANY LIABILITY FOR ANY INJURY, LOSS OR DAMAGE OF ANY KIND INCURRED BY USE OF OR
RELIANCE UPON THE INFORMATION. ALL INFORMATION SUPPLIED HEREIN IS SUBJECT TO
CHANGE WITHOUT PRIOR NOTICE.
COPYRIGHT
THE INFORMATION CONTAINED HERE IS PROPRIETARY TECHNICAL INFORMATION OF
QUECTEL WIRELESS SOLUTIONS CO., LTD. TRANSMITTING, REPRODUCTION, DISSEMINATION
AND EDITING OF THIS DOCUMENT AS WELL AS UTILIZATION OF THE CONTENT ARE
FORBIDDEN WITHOUT PERMISSION. OFFENDERS WILL BE HELD LIABLE FOR PAYMENT OF
DAMAGES. ALL RIGHTS ARE RESERVED IN THE EVENT OF A PATENT GRANT OR
REGISTRATION OF A UTILITY MODEL OR DESIGN.
Copyright © Quectel Wireless Solutions Co., Ltd. 2018. All rights reserved.
AG35-QuecOpen_Hardware_Design 1 / 137
LTE Module Series
AG35-Quecopen
About the Document
History
Revision Date Author Description
Eden LIU/
1.0 2017-10-19
Dominic GONG/
Jun WU
Initial
Hardware Design
1.1 2018-03-19
Eden LIU/
Dominic GONG
1. Updated the variants and/or frequency bands of
AG35-Quecopen in Table 1.
2. Changed pins 132 and 133 into RESERVED
pins (Table 4, Table 8 and Figure 2).
3. Deleted SIM IC in Figure 1.
4. Updated transmitting power and GSM features in
Table 2.
5. Updated SD card interface into SDIO interface to
support both eMMC and SD card.
6. Added the description of eCall temperature
range in Table 2 and Chapter 6.3.
7. Updated GNSS data update rate into 10Hz in
Chapter 4.1.
8. Updated the description of PCM interface in
primary and auxiliary modes, and the auxiliary
mode timing (Figure 23) of PCM interface.
9. Updated antenna gain in Table 42, and added a
note for GNSS antenna.
10. Updated current consumption in Chapter 6.4.
11. Updated RF receiving sensitivity in Chapter 6.6.
12. Updated part of the description of thermal
consideration (Chapter 6.8).
1. Added variants and updated bands of the module
1.2 2018-08-27
AG35-QuecOpen_Hardware_Design 2 / 137
Eden LIU/
Dominic GONG
(Table 1).
2. Updated the PAM power supply diagram in the
functional diagram (Figure 1).
LTE Module Series
AG35-Quecopen
Hardware Design
3. Enabled SHDN_N, and added the description of
the pin in Table 4 and Chapter 3.7.2.3.
4. Changed the name of pin 143 from
OTG_PWR_EN to GPIO8 (Table 4).
5. Updated the description of alternate functions of
multiplexing pins (Table 5).
6. Enabled the analog audio interface, and added
the description of the interface in Table 4 and
Chapter 3.12.
7. Enabled UART4 and UART5 interfaces (Chapter
3.11).
8. Added a note for I2C1 interface (Chapter 3.13).
9. Updated the power domain and the reference
circuit with PHY application of SGMII interface
(Chapter 3.16).
10. Updated the pin definition of wireless connectivity
interfaces (Table 26) and the reference circuit for
connection with AF20 module (Figure 30).
11. Added ADC sample rate in Table 28.
12. Updated the reference circuit of USB_BOOT
interface (Figure 33).
13. Added the description of RTC function (Chapter
3.22).
14. Updated the frequency of Galileo and QZSS
(Table 49).
15. Updated current consumption values of the
module (Chapter 6.4).
16. Added RF output power of AG35-E (Chapter 6.5).
17. Added RF receiving sensitivity of AG35-E
(Chapter 6.6).
18. Updated the reflow soldering thermal profile and
related parameters (Chapter 8.2).
1. Updated supported bands of the module (Table
1).
2. Updated the functional diagram (Figure 1).
3. Updated the pin assignment (Figure 2).
4. Updated the drive current of STATUS pin (Table
4) and its reference circuit design (Figure 34).
5. Updated alternate functions of multiplexing pins
(Table 5).
1.3 2018-12-12
Eden LIU/
Dominic GONG/
Ethan SHAN
6. Updated the drive circuit of SHDN_N interface
(Figure 14).
7. Added a note relating to PCM interface (Chapter
3.13). Added GNSS performance values of
AG35-QuecOpen_Hardware_Design 3 / 137
LTE Module Series
AG35-Quecopen
Hardware Design
AG35-NA and AG35-J (Chapter 4.2).
8. Updated the maximum clock frequency of SPI2
interface into 38MHz (Chapter 3.15).
9. Updated current consumption values of the
module (Chapter 6.4).
10. Completed the RF output power values of the
module (Chapter 6.5).
11. Added the RF receiving sensitivity of AG35-E,
AG35-NA and AG35-J (Chapter 6.6).
1.4 2019-02-01 Eden 1. Updated the description of the notes (table 5).
AG35-QuecOpen_Hardware_Design 4 / 137
LTE Module Series
AG35-Quecopen
Hardware Design
Contents
