Quectel Wireless Solutions 201705BG96NA Users Manual

BG96-NA

Hardware Design

LTE Module Series

Rev. BG96-NA_Hardware_Design_V1.0

Date: 2017-04-28

www.quectel.com

LTE Module Series

BG96-NA Hardware Design

Our aim is to provide customers with timely and comprehensive service. For any assistance, please contact our company headquarters:

Quectel Wireless Solutions Co., Ltd.

Office 501, Building 13, No.99, Tianzhou Road, Shanghai, China, 200233

Tel: [phone]

Email: [e-mail]

Or our local office. For more information, please visit:

http://www.quectel.com/support/salesupport.aspx

For technical support, or to report documentation errors, please visit: http://www.quectel.com/support/techsupport.aspx

Or Email to: [e-mail]

GENERAL NOTES

QUECTEL OFFERS THE INFORMATION AS A SERVICE TO ITS CUSTOMERS. THE INFORMATION

PROVIDED IS BASED UPON CUSTOMERS’ REQUIREMENTS. QUECTEL MAKES EVERY EFFORT

TO ENSURE THE QUALITY OF THE INFORMATION IT MAKES AVAILABLE. QUECTEL DOES NOT MAKE ANY WARRANTY AS TO THE INFORMATION CONTAINED HEREIN, AND DOES NOT ACCEPT ANY LIABILITY FOR ANY INJURY, LOSS OR DAMAGE OF ANY KIND INCURRED BY USE OF OR RELIANCE UPON THE INFORMATION. ALL INFORMATION SUPPLIED HEREIN IS SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.

COPYRIGHT

THE INFORMATION CONTAINED HERE IS PROPRIETARY TECHNICAL INFORMATION OF QUECTEL CO., LTD. TRANSMITTING, REPRODUCTION, DISSEMINATION AND EDITING OF THIS DOCUMENT AS WELL AS UTILIZATION OF THE CONTENT ARE FORBIDDEN WITHOUT PERMISSION. OFFENDERS WILL BE HELD LIABLE FOR PAYMENT OF DAMAGES. ALL RIGHTS ARE RESERVED IN THE EVENT OF A PATENT GRANT OR REGISTRATION OF A UTILITY MODEL OR DESIGN.

Copyright © Quectel Wireless Solutions Co., Ltd. 2017. All rights reserved.

BG96-NA_Hardware_Design

Confidential / Released

1 / 64

LTE Module Series

BG96-NA Hardware Design

About the Document

History

	Revision			Date		Author			Description
1.0			2017-04-28			Allen WANG/			Initial
						Daryl DU

BG96-NA_Hardware_Design

Confidential / Released

2 / 64

LTE Module Series

BG96-NA Hardware Design

Contents

About the Document...................................................................................................................................				2
Contents		.......................................................................................................................................................		3
Table Index...................................................................................................................................................				5
Figure Index .................................................................................................................................................				6
1	Introduction ..........................................................................................................................................			7
	1.1. ......................................................................................................................	Safety Information		8
2	Product ..................................................................................................................................Concept			9
	2.1. ...................................................................................................................	General Description		9
	2.2. ..........................................................................................................	Directives and Standards		9
	2.2.1. ................................................................................................................		FCC Statement	9
	2.3. ...........................................................................................................................	Key Features		11
	2.4. .................................................................................................................	Functional Diagram		13
	2.5. .....................................................................................................................	Evaluation Board		14
3	Application .......................................................................................................................Interfaces			15
	3.1. .................................................................................................................	General Description		15
	3.2. ........................................................................................................................	Pin Assignment		16
	3.3. .........................................................................................................................	Pin Description		17
	3.4. .....................................................................................................................	Operating Modes		22
	3.5. ...........................................................................................................................	Power Saving		23
	3.5.1. ....................................................................................................................		Sleep Mode	23
	.................................................................................................	3.5.1.1. UART Application		23
	........................................	3.5.1.2. USB Application with USB Remote Wakeup Function		24
	..........................	3.5.1.3. USB Application with USB Suspend/Resume and RI Function		24
	................................................	3.5.1.4. USB Application without USB Suspend Function		25
	3.5.2. ................................................................................................................		Airplane Mode	26
	3.6. ...........................................................................................................................	Power Supply		26
	3.6.1. .........................................................................................................		Power Supply Pins	26
	3.6.2. ..................................................................................................		Decrease Voltage Drop	27
	3.6.3. ..............................................................................................Monitor the Power Supply			28
	3.7. .......................................................................................................	Turn on and off Scenarios		28
	3.7.1. .............................................................................Turn on Module Using the PWRKEY			28
	3.7.2. ..............................................................................................................		Turn off Module	30
	.............................................................	3.7.2.1. Turn off Module Using the PWRKEY Pin		30
	...................................................................	3.7.2.2. Turn off Module Using AT Command		30
	3.8. .....................................................................................................................	Reset the Module		30
	3.9. ............................................................................................................	(U)SIM Card Interfaces		32
	3.10. ..........................................................................................................................	USB Interface		34
	3.11. ......................................................................................................................	UART Interfaces		36

BG96-NA_Hardware_Design

Confidential / Released

3 / 64

					LTE Module Series
					BG96-NA Hardware Design
	3.12.	I2C Interfaces ..........................................................................................................................			38
	3.13.	Network Status Indication........................................................................................................			39
	3.14.	STATUS ...................................................................................................................................			40
	3.15.	Behavior of the RI ....................................................................................................................			40
	3.16.	USB_BOOT Interface ..............................................................................................................			41
4	GNSS Receiver...................................................................................................................................				42
	4.1.	General Description.................................................................................................................			42
	4.2.	GNSS Performance .................................................................................................................			42
	4.3.	Layout Guidelines ....................................................................................................................			43
5	Antenna Interfaces.............................................................................................................................				44
	5.1.	Main Antenna Interface ...........................................................................................................			44
	5.1.1.		Pin Definition ..................................................................................................................		44
	5.1.2.		Operating Frequency .....................................................................................................		44
	5.1.3. Reference Design of RF Antenna Interface ...................................................................				44
	5.1.4. Reference Design of RF Layout.....................................................................................				45
	5.2.	GNSS Antenna Interface .........................................................................................................			47
	5.3.	Antenna Installation .................................................................................................................			48
	5.3.1.		Antenna Requirements ..................................................................................................		48
	5.3.2. Recommended RF Connector for Antenna Installation .................................................				49
6	Electrical, Reliability and Radio Characteristics ............................................................................				51
	6.1.	Absolute Maximum Ratings.....................................................................................................			51
	6.2.	Power Supply Ratings .............................................................................................................			51
	6.3.	Operating Temperature............................................................................................................			52
	6.4.	Current Consumption ..............................................................................................................			52
	6.5.	RF Output Power .....................................................................................................................			53
	6.6.	RF Receiving Sensitivity..........................................................................................................			53
	6.7.	Electrostatic Discharge............................................................................................................			53
7	Mechanical Dimensions ....................................................................................................................				54
	7.1.	Mechanical Dimensions of the Module....................................................................................			54
	7.2.	Recommended Footprint .........................................................................................................			56
	7.3.	Design Effect Drawings of the Module ....................................................................................			57
8	Storage, Manufacturing and Packaging ..........................................................................................				58
	8.1.	Storage ....................................................................................................................................			58
	8.2.	Manufacturing and Welding.....................................................................................................			59
	8.3.	Packaging ................................................................................................................................			59
9	Appendix A References.....................................................................................................................				60
10	Appendix B GPRS Coding Schemes ...............................................................................................				64
11	Appendix C GPRS Multi-slot Classes..............................................................................................				65
12	Appendix D EDGE Modulation and Coding Schemes ...................................................................				66

BG96-NA_Hardware_Design

Confidential / Released

4 / 64

	LTE Module Series
	BG96-NA Hardware Design
Table Index
TABLE 1: FREQUENCY BANDS OF BG96-NA MODULE..................................................................................	9
TABLE 2: KEY FEATURES OF BG96-NA ..........................................................................................................	11
TABLE 3: I/O PARAMETERS DEFINITION.......................................................................................................	17
TABLE 4: PIN DESCRIPTION ...........................................................................................................................	17
TABLE 5: OVERVIEW OF OPERATING MODES .............................................................................................	22
TABLE 6: VBAT AND GND PINS.......................................................................................................................	27
TABLE 7: PWRKEY PIN DESCRIPTION ..........................................................................................................	28
TABLE 8: RESET_N PIN DESCRIPTION .........................................................................................................	31
TABLE 9: PIN DEFINITION OF THE (U)SIM CARD INTERFACES .................................................................	32
TABLE 10: PIN DESCRIPTION OF USB INTERFACE .....................................................................................	34
TABLE 11: PIN DEFINITION OF UART1 INTERFACE .....................................................................................	36
TABLE 12: PIN DEFINITION OF UART2 INTERFACE .....................................................................................	36
TABLE 13: LOGIC LEVELS OF DIGITAL I/O ....................................................................................................	37
TABLE 14: PIN DEFINITION OF I2C INTERFACES.........................................................................................	38
TABLE 15: PIN DEFINITION OF NETWORK STATUS INDICATOR ................................................................	39
TABLE 16: WORKING STATE OF THE NETWORK STATUS INDICATOR......................................................	39
TABLE 17: PIN DEFINITION OF STATUS ........................................................................................................	40
TABLE 18: DEFAULT BEHAVIOR OF RI...........................................................................................................	41
TABLE 19: PIN DEFINITION OF USB_BOOT INTERFACE .............................................................................	41
TABLE 20: GNSS PERFORMANCE .................................................................................................................	42
TABLE 21: PIN DEFINITION OF THE RF ANTENNA INTERFACE..................................................................	44
TABLE 22: MODULE OPERATING FREQUENCIES ........................................................................................	44
TABLE 23: PIN DEFINITION OF GNSS ANTENNA INTERFACE.....................................................................	47
TABLE 24: GNSS FREQUENCY.......................................................................................................................	47
TABLE 25: MAIN ANTENNA REQUIREMENTS ...............................................................................................	48
TABLE 26: ABSOLUTE MAXIMUM RATINGS ..................................................................................................	51
TABLE 27: POWER SUPPLY RATINGS ...........................................................................................................	51
TABLE 28: OPERATING TEMPERATURE........................................................................................................	52
TABLE 29: CONDUCTED RF OUTPUT POWER .............................................................................................	53
TABLE 30: BG96-NA CONDUCTED RF RECEIVING SENSITIVITY ...............................................................	53
TABLE 31: RELATED DOCUMENTS ...............................................................................................................	60
TABLE 32: TERMS AND ABBREVIATIONS ......................................................................................................	60
TABLE 33: DESCRIPTION OF DIFFERENT CODING SCHEMES ..................................................................	64
TABLE 34: GPRS MULTI-SLOT CLASSES ......................................................................................................	65
TABLE 35: EDGE MODULATION AND CODING SCHEMES...........................................................................	66

BG96-NA_Hardware_Design

Confidential / Released

5 / 64

LTE Module Series

BG96-NA Hardware Design

Figure Index
FIGURE 1: FUNCTIONAL DIAGRAM ...............................................................................................................	13
FIGURE 2: PIN ASSIGNMENT (TOP VIEW).....................................................................................................	16
FIGURE 3: SLEEP MODE APPLICATION VIA UART.......................................................................................	23
FIGURE 4: SLEEP MODE APPLICATION WITH USB REMOTE WAKEUP ....................................................	24
FIGURE 5: SLEEP MODE APPLICATION WITH RI .........................................................................................	25
FIGURE 6: SLEEP MODE APPLICATION WITHOUT SUSPEND FUNCTION ................................................	25
FIGURE 7: STAR STRUCTURE OF THE POWER SUPPLY............................................................................	27
FIGURE 8: TURN ON THE MODULE USING DRIVING CIRCUIT ...................................................................	28
FIGURE 9: TURN ON THE MODULE USING KEYSTROKE ...........................................................................	29
FIGURE 10: TIMING OF TURNING ON MODULE ...........................................................................................	29
FIGURE 11: TIMING OF TURNING OFF MODULE..........................................................................................	30
FIGURE 12: REFERENCE CIRCUIT OF RESET_N BY USING DRIVING CIRCUIT ......................................	31
FIGURE 13: REFERENCE CIRCUIT OF RESET_N BY USING BUTTON ......................................................	31
FIGURE 14: TIMING OF RESETTING MODULE .............................................................................................	32
FIGURE 15: REFERENCE CIRCUIT OF (U)SIM CARD INTERFACE WITH AN 8-PIN (U)SIM CARD
CONNECTOR ............................................................................................................................................	33
FIGURE 16: REFERENCE CIRCUIT OF (U)SIM CARD INTERFACE WITH A 6-PIN (U)SIM CARD
CONNECTOR ............................................................................................................................................	34
FIGURE 17: REFERENCE CIRCUIT OF USB APPLICATION .........................................................................	35
FIGURE 18: REFERENCE CIRCUIT WITH TRANSLATOR CHIP ...................................................................	37
FIGURE 19: REFERENCE CIRCUIT WITH TRANSISTOR CIRCUIT ..............................................................	38
FIGURE 20: REFERENCE CIRCUIT OF THE NETWORK INDICATOR ..........................................................	39
FIGURE 21: REFERENCE CIRCUIT OF THE STATUS ...................................................................................	40
FIGURE 22: REFERENCE CIRCUIT OF USB_BOOT INTERFACE ................................................................	41
FIGURE 23: REFERENCE CIRCUIT OF RF ANTENNA INTERFACE .............................................................	45
FIGURE 24: MICROSTRIP LINE DESIGN ON A 2-LAYER PCB......................................................................	45
FIGURE 25: COPLANAR WAVEGUIDE LINE DESIGN ON A 2-LAYER PCB..................................................	46
FIGURE 26: COPLANAR WAVEGUIDE LINE DESIGN ON A 4-LAYER PCB (LAYER 3 AS REFERENCE
GROUND) ..................................................................................................................................................	46
FIGURE 27: COPLANAR WAVEGUIDE LINE DESIGN ON A 4-LAYER PCB (LAYER 4 AS REFERENCE
GROUND) ..................................................................................................................................................	46
FIGURE 28: REFERENCE CIRCUIT OF GNSS ANTENNA INTERFACE........................................................	48
FIGURE 29: DIMENSIONS OF THE UF.L-R-SMT CONNECTOR (UNIT: MM) ................................................	49
FIGURE 30: MECHANICALS OF UF.L-LP CONNECTORS .............................................................................	49
FIGURE 31: SPACE FACTOR OF MATED CONNECTOR (UNIT: MM) ...........................................................	50
FIGURE 32: MODULE TOP AND SIDE DIMENSIONS.....................................................................................	54
FIGURE 33: MODULE BOTTOM DIMENSIONS (BOTTOM VIEW) .................................................................	55
FIGURE 34: RECOMMENDED FOOTPRINT (TOP VIEW) ..............................................................................	56
FIGURE 35: TOP VIEW OF THE MODULE ......................................................................................................	57
FIGURE 36: BOTTOM VIEW OF THE MODULE..............................................................................................	57
FIGURE 37: REFLOW SOLDERING THERMAL PROFILE..............................................................................	59

BG96-NA_Hardware_Design

Confidential / Released

6 / 64

LTE Module Series

BG96-NA Hardware Design

1 Introduction

This document defines the BG96-NA module and describes its air interface and hardware interface which are connected with your application.

This document can help you quickly understand module interface specifications, electrical and mechanical details, etc. Associated with application note and user guide, you can use BG96-NA module to design and set up mobile applications easily.

BG96-NA_Hardware_Design

Confidential / Released

7 / 64

LTE Module Series

BG96-NA Hardware Design

1.1. Safety Information

The following safety precautions must be observed during all phases of the operation, such as usage, service or repair of any cellular terminal or mobile incorporating BG96-NA module. Manufacturers of the cellular terminal should send the following safety information to users and operating personnel, and incorporate these guidelines into all manuals supplied with the product. If not so, Quectel assumes no liability for the customer’s failure to comply with these precautions.

Full attention must be given to driving at all times in order to reduce the risk of an accident. Using a mobile while driving (even with a handsfree kit) causes distraction and can lead to an accident. You must comply with laws and regulations restricting the use of wireless devices while driving.

Switch off the cellular terminal or mobile before boarding an aircraft. Make sure it is switched off. The operation of wireless appliances in an aircraft is forbidden, so as to prevent interference with communication systems. Consult the airline staff about the use of wireless devices on boarding the aircraft, if your device offers an Airplane Mode which must be enabled prior to boarding an aircraft.

Switch off your wireless device when in hospitals,clinics or other health care facilities. These requests are desinged to prevent possible interference with sensitive medical equipment.

Cellular terminals or mobiles operatingover radio frequency signal and cellular network cannot be guaranteed to connect in all conditions, for example no mobile fee or with an invalid (U)SIM card. While you are in this condition and need emergent help, please remember using emergency call. In order to make or receive a call, the cellular terminal or mobile must be switched on and in a service area with adequate cellular signal strength.

Your cellular terminal or mobile contains a transmitter and receiver. When it is ON, it receives and transmits radio frequency energy. RF interference can occur if it is used close to TV set, radio, computer or other electric equipment.

In locations with potentially explosive atmospheres, obey all posted signs to turn off wireless devices such as your phone or other cellular terminals. Areas with potentially explosive atmospheres include fuelling areas, below decks on boats, fuel or chemical transfer or storage facilities, areas where the air contains chemicals or particles such as grain, dust or metal powders, etc.

BG96-NA_Hardware_Design

Confidential / Released

8 / 64

LTE Module Series

BG96-NA Hardware Design

2 Product Concept

2.1. General Description

BG96-NA module is an embedded IoT (LTE Cat M1) wireless communication module without receive diversity. It supports Half-duplex LTE-FDD wireless communication, which provides data connectivity on LTE-FDD networks. The following table shows the frequency bands of BG96-NA module.

Table 1: Frequency Bands of BG96-NA Module

	Module		LTE Bands		GSM		Rx-diversity		GNSS (Optional)
									GPS,
	BG96-NA		FDD: B4/B13		Not Supported		Not Supported		GLONASS,
									BeiDou/Compass,
									Galileo, QZSS

With a compact profile of 22.5mm × 26.5mm × 2.3mm, BG96-NA can meet almost all requirements for M2M applications such as automotive, metering, tracking system, security, router, wireless POS, mobile computing device, PDA phone, tablet PC, etc.

BG96-NA is an SMD type module which can be embedded into application through its 102 LGA pads.

BG96-NA supports internet service protocols like TCP, UDP and PPP. Extended AT commands have been developed for customers to use these internet service protocols easily.

2.2. Directives and Standards

The BG96-NA module is designed to comply with the FCC statements. FCC ID: XMR201705BG96NA The Host system using BG96-NA should have label “contains FCC ID: XMR201705BG96NA

2.2.1. FCC Statement

According to the definition of mobile and fixed device is described in Part 2.1091(b), this device is a mobile device.

BG96-NA_Hardware_Design

Confidential / Released

9 / 64

LTE Module Series

BG96-NA Hardware Design

And the following conditions must be met:

1. This Modular Approval is limited to OEM installation for mobile and fixed applications only.

The antenna installation and operating configurations of this transmitter, including any applicable source-based timeaveraging duty factor, antenna gain and cable loss must satisfy MPE categorical Exclusion Requirements of 2.1091.

2.The EUT is a mobile device; maintain at least a 20 cm separation between the EUT and the user’s body and must not transmit simultaneously with any other antenna or transmitter.

3.A label with the following statements must be attached to the host end product: This device contains FCC ID: XMR201705BG96NA.

4.To comply with FCC regulations limiting both maximum RF output power and human exposure to RF radiation, maximum antenna gain (including cable loss) must not exceed:

LTE band 4 <4dBiLTE band 13 <4dBi

5.This module must not transmit simultaneously with any other antenna or transmitter

6.The host end product must include a user manual that clearly defines operating requirements and conditions that must be observed to ensure compliance with current FCC RF exposure guidelines.

For portable devices, in addition to the conditions 3 through 6 described above, a separate approval is required to satisfy the SAR requirements of FCC Part 2.1093.

If the device is used for other equipment that separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations.

For this device, OEM integrators must be provided with labeling instructions of finished products. Please refer to KDB784748 D01 v07, section 8. Page 6/7 last two paragraphs:

A certified modular has the option to use a permanently affixed label, or an electronic label. For a permanently affixed label, the module must be label led withan FCC ID - Section 2.926 (see 2.2 Certification (labelling requirements) above). The OEM manual must provide clear instructions explaining to the OEM the labelling requirements, options and OEM user manual instructions that are required (see next paragraph).

For a host using a certified modular with a standard fixed label, if (1) the module’s FCC ID is not visible when installed in the host, or (2) if the host is marketed so that end users do not have straight forward commonly used methods for access to remove the module so that the FCC ID of the module is visible; then an additional permanent label referring to the enclosed module: “Contains Transmitter Module FCC ID:XMR201705BG96NA” or “Contains FCC ID: XMR201705BG96NA” must be used. The host OEM user manual must also contain clear instructions on how end users can find and/or access the module and the FCC ID.

The final host / module combination may also need to be evaluated against the FCC Part 15B criteria for

BG96-NA_Hardware_Design

Confidential / Released

10 / 64

LTE Module Series

BG96-NA Hardware Design

unintentional radiators in order to be properly authorized for operation as a Part 15 digital device.

The user’s manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. In cases where the manual is provided only in a form other than paper, such as on a computer disk or over the Internet, the information required by this section may be included in the manual in that alternative form, provided the user can reasonably be expected to have the capability to access information in that form.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment.

To ensure compliance with all non-transmitter functions the host manufacturer is responsible for ensuring compliance with the module(s) installed and fully operational. For example, if a host was previously authorized as an unintentional radiator under the Declaration of Conformity procedure without a transmitter certified module and a module is added, the host manufacturer is responsible for ensuring that the after the module is installed and operational the host continues to be compliant with the Part 15B unintentional radiator requirements.

2.3. Key Features

The following table describes the detailed features of BG96-NA module.

Table 2: Key Features of BG96-NA

		Features			Details
	Power Supply				Supply voltage: 3.3V~4.3V
					Typical supply voltage: 3.8V
	Transmitting Power				Class 3 (23dBm±2.7dB) for LTE-FDD bands
					Support up to LTE Cat M1
	LTE Features				Support 1.08MHz RF bandwidth
					Support SISO in DL direction
					Cat M1: Max. 375kbps (DL)/375kbps (UL)
					Support TCP/UDP/PPP protocols
	Internet Protocol				Support PAP (Password Authentication Protocol) and CHAP (Challenge
	Features*				Handshake Authentication Protocol) protocols which are usually used for
					PPP connections
	SMS*				Text and PDU mode
					Point to point MO and MT
	BG96-NA_Hardware_Design					Confidential / Released	11 / 64

LTE Module Series

BG96-NA Hardware Design

		SMS cell broadcast
		SMS storage: ME by default
	(U)SIM Interface	Support (U)SIM card: 1.8V, 3.0V
		Compliant with USB 2.0 specification (slave only); the data transfer rate
		can reach up to 480Mbps
		Used for AT command communication, data transmission, GNSS NMEA
	USB Interface	output, software debugging and firmware upgrade
		Support USB drivers for Windows XP, Windows Vista, Windows 7,
		Windows 8/8.1, Window 10, Linux 2.6 or later, Android
		4.0/4.2/4.4/5.0/5.1/6.0
		UART1:
		Used for AT command communication and data transmission
		Baud rate reach up to 3000000bps; 115200bps by default
	UART Interface	Support RTS and CTS hardware flow control
		UART2:
		Used for module debugging and log output
		115200bps baud rate
	AT Commands	3GPP TS 27.007 and 3GPP TS 27.005 AT commands, as well as
		Quectel enhanced AT commands
	Network Indication	One NETLIGHT pin for network connectivity status indication
	Antenna Interfaces	Including main antenna (ANT_MAIN) and GNSS antenna (ANT_GNSS)
		interfaces
	Physical Characteristics	Size: 22.5mm × 26.5mm × 2.3mm
		Weight: 3.1g
	Temperature Range	Operation temperature range: -35°C ~ +75°C1)
		Extended temperature range: -40°C ~ +85°C2)
	Firmware Upgrade	USB interface and DFOTA*
	RoHS	All hardware components are fully compliant with EU RoHS directive

NOTES

1. 1) Within operation temperature range, the module is 3GPP compliant.

2. 2) Within extended temperature range, the module remains the ability to establish and maintain SMS, data transmission, etc. There is no unrecoverable malfunction. Only one or more parameters like Pout

might reduce in their value and exceed the specified tolerances. When the temperature returns to the normal operating temperature levels, the module will meet 3GPP compliant again.

3. “*” means under development.

BG96-NA_Hardware_Design

Confidential / Released

12 / 64

LTE Module Series

BG96-NA Hardware Design

2.4. Functional Diagram

The following figure shows a block diagram of BG96-NA and illustrates the major functional parts.

Power management

Baseband

DDR+NAND flash

Radio frequency

Peripheral interfaces

ANT_MAIN

ANT_GNSS

		Switch		Filter
		Tx
VBAT_RF				LNA
		PA	PRx
				GNSS
					NAND
			Transceiver		DDR2
					SDRAM
			IQ	Control
VBAT_BB	PMIC
		Control
PWRKEY
RESET_N			Baseband
STATUS
		19.2M
		XO
	VDD_EXT	USB	USIM	I2C	UART	GPIOs

Figure 1: Functional Diagram

NOTE

“*” means under development.

BG96-NA_Hardware_Design

Confidential / Released

13 / 64

LTE Module Series

BG96-NA Hardware Design

2.5. Evaluation Board

In order to help customers develop applications conveniently with BG96-NA, Quectel supplies the evaluation board (EVB), USB data cable, earphone, antenna and other peripherals to control or test the module.

BG96-NA_Hardware_Design

Confidential / Released

14 / 64

LTE Module Series

BG96-NA Hardware Design

3 Application Interfaces

3.1. General Description

BG96-NA is equipped with 62-pin 1.1mm pitch SMT pads plus 40-pin ground pads and reserved pads that can be connected to customers’ cellular application platform. The subsequent chapters will provide detailed description of interfaces listed below:

Power supply

(U)SIM card interfaces

USB interface

UART interfaces

Network status indication

USB_BOOT interface

BG96-NA_Hardware_Design

Confidential / Released

15 / 64

LTE Module Series

BG96-NA Hardware Design

3.2. Pin Assignment

The following figure shows the pin assignment of the BG96-NA module.

							GND		GND		ANT MAIN			GND		GND				RESERVED					RESERVED		GND		GND		VBAT RF			VBAT RF		RESERVED		GND
							62		61		60			59		58				57					56		55		54		53			52		51		50
PSM_IND				1																																				49
ADC1				2																																				48
																		82				81			80			79
GND				3																																				47
RESERVED				4														102				101			100			99												46
RESERVED
				5		RESERVED																																		45
									63				83																			98				78
RESERVED				6																																				44
RESERVED
				7					64				84																			97				77				43
USB_VBUS				8																																				42
USB_DP				9					65				85																			96				76				41
USB_DM				10																																				40
									66				86																			95				75	USB_BOOT
RESERVED				11																																				39
									67				87																			94				74
RESERVED				12																																				38
RESERVED				13																																				37
									68				88																			93				73
RESERVED				14																																				36
PWRKEY1)																	89					90			91			92
				15																																				35
RESERVED				16													69					70			71			72												34
RESET_N				17																																				33
RESERVED				18																																				32
							19		20		21			22		23				24					25		26		27		28			29		30		31
							RESERVED		STATUS		NETLIGHT			RXD DBG			TXD DBG			ADC0					RESERVED		RESERVED		RESERVED		RESERVED			EXT VDD		DTR		GND

ANT_GNSS

GND

USIM_GND

USIM_CLK

USIM_DATA

USIM_RST

USIM_VDD

USIM_PRESENCE I2C_SDA I2C_SCL

RI

DCD

RTS

CTS

TXD

RXD

VBAT_BB

VBAT_BB

POWER	USB	UART		I2S		GND
			USIM		ANT		RESERVED OTHERS

Figure 2: Pin Assignment (Top View)

NOTES

1.Keep all RESERVED pins and unused pins unconnected.

2.GND pads should be connected to ground in the design.

3.1) PWRKEY output voltage is 0.8V because of the diode drop in the Qualcomm chipset.

4.“*” means under development.

BG96-NA_Hardware_Design

Confidential / Released

16 / 64

LTE Module Series

BG96-NA Hardware Design

3.3. Pin Description

The following tables show the pin definition and description of BG96-NA.

Table 3: I/O Parameters Definition

Type	Description
IO	Bidirectional
DI	Digital input
DO	Digital output
PI	Power input
PO	Power output
AI	Analog input
AO	Analog output
OD	Open drain

Table 4: Pin Description

Power Supply

	Pin Name	Pin No.	I/O	Description	DC	Comment
					Characteristics
				Power supply	Vmax=4.3V
	VBAT_BB	32, 33	PI	for module	Vmin=3.3V
				baseband part.	Vnorm=3.8V
				Power supply	Vmax=4.3V
	VBAT_RF	52, 53	PI	for module RF	Vmin=3.3V
				part.	Vnorm=3.8V
	VDD_EXT	29	PO	Provide 1.8V for	Vnorm=1.8V	Power supply for external
				external circuit.	IOmax=50mA	GPIO’s pull up circuits.
		3, 31, 48,
		50, 54, 55,
		58, 59, 61,
	GND	62, 67~74,		Ground
		79~82,

89~91,

100~102

BG96-NA_Hardware_Design

Confidential / Released

17 / 64

									LTE Module Series
								BG96-NA Hardware Design
		Turn on/off
		Pin Name		Pin No.		I/O	Description	DC	Comment
								Characteristics
								VIHmax=2.1V	The output voltage is
							Turn on/off the		0.8V because of the
		PWRKEY		15		DI		VIHmin=1.3V
							module		diode drop in the
								VILmax=0.5V
									Qualcomm chipset.
							Reset the	VIHmax=2.1V	If unused, keep this pin
		RESET_N		17		DI		VIHmin=1.3V
							module		open.
								VILmax=0.5V
		Status Indication
		Pin Name		Pin No.		I/O	Description	DC	Comment
								Characteristics
							Indicate the		1.8V power domain.
							module’s	VOHmin=1.35V
		STATUS		20		OD			If unused, keep this pin
							operating	VOLmax=0.45V
									open.
							status.
							Indicate the
		NETLIGHT		21		DO	module’s	VOHmin=1.35V	1.8V power domain.
							network activity	VOLmax=0.45V	If unused, keep it open.
							status.
		USB Interface
		Pin Name		Pin No.		I/O	Description	DC	Comment
								Characteristics
								Vmax=5.25V
		USB_VBUS		8		PI	USB detection	Vmin=3.0V
								Vnorm=5.0V
							USB differential	Compliant with	Require differential
		USB_DP		9		IO		USB 2.0 standard
							data bus (+)		impedance of 90 ohm.
								specification.
							USB differential	Compliant with	Require differential
		USB_DM		10		IO		USB 2.0 standard
							data bus (-)		impedance of 90 ohm.
								specification.
		(U)SIM Interface
		Pin Name		Pin No.		I/O	Description	DC	Comment
								Characteristics
							Specified
		USIM_GND		47			ground for
							(U)SIM card

BG96-NA_Hardware_Design

Confidential / Released

18 / 64

LTE Module Series

BG96-NA Hardware Design

			For 1.8V (U)SIM:
			Vmax=1.9V
			Vmin=1.7V
USIM_VDD	43	PO	Power supply

for (U)SIM card For 3.0V (U)SIM:

Vmax=3.05V

Vmin=2.7V

IOmax=50mA

Either 1.8V or 3.0V is supported by the module automatically.

					For 1.8V (U)SIM:
					VILmax=0.6V
					VIHmin=1.2V
					VOLmax=0.45V
				Data signal of	VOHmin=1.35V
	USIM_DATA	45	IO
				(U)SIM card
					For 3.0V (U)SIM:
					VILmax=1.0V
					VIHmin=1.95V
					VOLmax=0.45V
					VOHmin=2.55V
					For 1.8V (U)SIM:
					VOLmax=0.45V
				Clock signal of	VOHmin=1.35V
	USIM_CLK	46	DO
				(U)SIM card
					For 3.0V (U)SIM:
					VOLmax=0.45V
					VOHmin=2.55V
					For 1.8V (U)SIM:
					VOLmax=0.45V
				Reset signal of	VOHmin=1.35V
	USIM_RST	44	DO
				(U)SIM card
					For 3.0V (U)SIM:
					VOLmax=0.45V
					VOHmin=2.55V
				(U)SIM card	VILmin=-0.3V
	USIM_				VILmax=0.6V	1.8V power domain.
		42	DI	insertion
	PRESENCE				VIHmin=1.2V	If unused, keep it open.
				detection
					VIHmax=2.0V
	UART1 Interface
	Pin Name	Pin No.	I/O	Description	DC	Comment
					Characteristics
	RI	39	DO	Ring indicator	VOLmax=0.45V	1.8V power domain.
					VOHmin=1.35V	If unused, keep it open.

BG96-NA_Hardware_Design

Confidential / Released

19 / 64

									LTE Module Series
								BG96-NA Hardware Design
		DCD		38		DO	Data carrier	VOLmax=0.45V	1.8V power domain.
							detection	VOHmin=1.35V	If unused, keep it open.
								VILmin=-0.3V
		RTS		37		DI	Request to	VILmax=0.6V	1.8V power domain.
							send	VIHmin=1.2V	If unused, keep it open.
								VIHmax=2.0V
		CTS		36		DO	Clear to send	VOLmax=0.45V	1.8V power domain.
								VOHmin=1.35V	If unused, keep it open.
		TXD		35		DO	Transmit data	VOLmax=0.45V	1.8V power domain.
								VOHmin=1.35V	If unused, keep it open.
								VILmin=-0.3V
		RXD		34		DI	Receive data	VILmax=0.6V	1.8V power domain.
								VIHmin=1.2V	If unused, keep it open.
								VIHmax=2.0V
								VILmin=-0.3V	1.8V power domain.
							Data terminal		Pull-up by default. Low
								VILmax=0.6V
		DTR		30		DI	ready, sleep		level wakes up the
								VIHmin=1.2V
							mode control.		module.
								VIHmax=2.0V
									If unused, keep it open.
		UART2 Interface
		Pin Name		Pin No.		I/O	Description	DC	Comment
								Characteristics
		DBG_TXD		23		DO	Transmit data	VOLmax=0.45V	1.8V power domain.
								VOHmin=1.35V	If unused, keep it open.
								VILmin=-0.3V
		DBG_RXD		22		DI	Receive data	VILmax=0.6V	1.8V power domain.
								VIHmin=1.2V	If unused, keep it open.
								VIHmax=2.0V
		I2C Interface
		Pin Name		Pin No.		I/O	Description	DC	Comment
								Characteristics
							I2C serial clock.		External pull-up resistor is
									required.
		I2C_SCL		40		OD	Used for
									1.8V only. If unused, keep
							external codec.
									it open.
							I2C serial data.		External pull-up resistor is
									required.
		I2C_SDA		41		OD	Used for
									1.8V only. If unused, keep
							external codec.
									it open.

RF Interface

	BG96-NA_Hardware_Design	Confidential / Released	20 / 64
