Powermate PM0125500 User Manual [en, es, fr]

Operator Manual

•

Manuel de l’opérateur • Manual del operador

ELECTRIC GENERATOR • GROUPE ELECTROGENE • GENERADOR ELECTRICO

PM0125500

	IMPORTANT – Please make certain that			IMPORTANT - Prière de vous assurer que			IMPORTANTE - Asegúrese que las
				les personnes destinées à utiliser cet			personas que utilizarán este equipo lean y
	persons who are to use this equipment
				appareil ont pris soin d'en lire et d'en			entiendan completamente estas
	thoroughly read and understand these
				comprendre le mode d'emploi ou les			instrucciones y cualquier instrucción
	instructions and any additional
				directives avant de le mettre en marche.			adicional proporcionada antes del
	instructions provided prior to operation.
							funcionamiento.
				Enregistrer le numéro de série figurant sur
	Record the serial number as indicated on
				la plaque signalétique du groupe			Registre de serie como se indica en la placa
	your Generator’s nameplate:
				électrogène:			del nombre de su generador:
		Serial No.______________________			Nº de série ____________________			No. de serie ___________________

STOP	DO NOT RETURN TO	ARRÊT NE PAS RETOURNER	ALTO NO LO DEVUELVA A
	STORE!	AU MAGASIN!	LA TIENDA!
	CALL US FIRST!	APPELEZ–NOUS D’ABORD!	¡PRIMERO LLÁMENOS!
	CUSTOMER HOTLINE	ASSISTANCE TELEPHONIQUE	LÍNEA DIRECTA DE ATENCIÓN
	1-800-445-1805	A LA CLIENTELE	AL CLIENTE
FOR QUESTIONS OR SERVICE		1-800-445-1805	1-800-445-1805
			PARA la INFORMACION de
	INFORMATION	POUR L'INFORMATION DE
		QUESTIONS OU SERVICE	PREGUNTAS O SERVICIO

www.powermate.com

12/11 0069285

TABLE OF CONTENTS

Safety and operation rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	3	Oil replacement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . . . 9
Spark arresting muffler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4	Air filter cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . . 9
Determining total wattage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	4	Fuel strainer cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . . 9
Operating voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	5	Valve Clearance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . 10
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	5	Spark arrester screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . 10
Generator features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	6	Brushes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . 10
Before operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	7	Inspecting the brushes . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . 10
Ground fault circuit interrupter (GFCI) . . . . . . . . . . . . . . . . . . . .	7	Heat shield . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . 10
Grounding the generator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	7	Engine carburetor icing. . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . 10
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	7	Quick starting tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . 10
Low oil sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	7	Service and storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . 10
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	7	Infrequent service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . 10
Positioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	7	Long term storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . 10
Starting the unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	8	Engine troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . 11
Pre-start preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	8	Engine specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . 11
Starting the engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	8	Service information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . 12
Applying load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	8	Limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . 12
Shutting the generator off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	8	Parts drawings and parts list . . . . . . . . . . . . . . . . . . . . . . . . . . . .	34-37
Periodic Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	9	Emission control warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	38-39
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	9
Spark plug. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	9
Oil type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	9

TABLE DES MATIERES

Régles d’opération et de sécurité . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Silencieux pare-étincelles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Determination de la puissance totale nécessaire . . . . . . . . . . . . . . . 14

Vérifier la tension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Caractéristiques du groupe electrogene. . . . . . . . . . . . . . . . . . . . . . 16 Avant de mettre en marche . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Protection avec disjoncteur différentiel (GFCI) . . . . . . . . . . . . . 17

Mise en place de l'appareil. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Lubrification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Le détecteur de bas niveau d'huile . . . . . . . . . . . . . . . . . . . . . . 17 Carburant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Positionnement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Démarrage de l'appareil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Préparatifs au démarrage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Démarrage du moteur . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Branchement des appareils . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Arrêt de l'appareil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Entretien périodique . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Entretien . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 La bougie d’allumage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Le type d’huile. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Remplacement d’huile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Nettoyage du filtre à air . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Nettoyage de la crépine du réservoir à carburant . . . . . . . . . . 19 Jeu des soupapes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

L'écran pare-étincelles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Les balais . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Inspection des balais . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Écrans de chaleur. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Givrage du carburateur. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Trucs de démarrage rapide . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Usage et entreposage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Usage peu fréquent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Entreposage à long terme . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Depannage du moteur . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Caracteristiques du moteur. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Service clientèle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Garantie limitée. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Schema des pièces et liste des pièces . . . . . . . . . . . . . . . . . . . . 34-37

INDICE

Reglas de seguridad y de funcionamiento . . . . . . . . . . . . . . . . . . . . 23

Silenciador apagachispas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Como determinar el vataje total . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Requerimiento de voltaje . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Instalacion. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Caracteristicas del generador. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Antes de la operacion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Protección de interruptor de circuito de falla de

conexión a tierra (GFCI, por sus siglas en inglés). . . . . . . . . . . 27 Puesta a tierra del generador. . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Lubricacion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

El sensor del nivel bajo de aceite . . . . . . . . . . . . . . . . . . . . . . . 27

Combustible . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Colocación . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Arranque de la unidad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Preparacion antes de arrancar. . . . . . . . . . . . . . . . . . . . . . . . . . 28

Arranque del motor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Como aplicar una carga . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Apagado del generador . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Mantenimiento periódico. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Mantenimiento . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Bujia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Tipo de aceite . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Cambio del aceite . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Cómo limpiar el filtro de aire. . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Limpieza del filtro de combustible . . . . . . . . . . . . . . . . . . . . . . 29

Claridad de la valvula . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Protector del parachispas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 Escobillas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Revisión de las escobillas . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Escudo contra el calor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Congelamiento del carburador del motor . . . . . . . . . . . . . . . . . 30

Instrucciones rápidas para el arranque . . . . . . . . . . . . . . . . . . 30 Servicio y almacenamiento. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Servicio poco frecuente . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Almacenamiento a largo plazo . . . . . . . . . . . . . . . . . . . . . . . . . 30

Deteccion de fallos del motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 Especificaciones del motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 Informacion de servicio al cliente . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 Garantia limitada. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Diagrama de piezas y lista de piezas . . . . . . . . . . . . . . . . . . . . . 34-37

2	Customer Hotline [phone]

SAFETY INFORMATION

DANGER indicates a potentially hazardous situation which, if not avoided, WILL result in death or serious injury.

WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate personal injury, or property damage.

SAFETY AND OPERATION RULES

WARNING - Failure to follow these instructions and warnings may result in death, personal injury, or property damage.

1.Read carefully and understand operator manual prior to operation of this product. Follow all warnings and instructions.

2.Know your equipment. Consider the applications, limitations, and the potential hazards specific to your unit.

3.Equipment must be placed on a firm, supporting surface.

4.Load must be kept within rating stated on generator nameplate. Overloading will damage the unit or shorten its life.

5.Engine must not be run at excessive speeds. Operating an engine at excessive speeds increases the hazard of personal injury.

Do not tamper with parts which may increase or decrease the governed speed.

6.To prevent accidental starting, always remove the spark plug or cable from the spark plug before maintaining the generator or engine.

7.Units with broken or missing parts, or without protective housing or covers, should never be operated. Contact your service center for replacement parts.

8.Units should not be operated or stored in wet or damp conditions or on highly conductive locations such as metal decking and steel work.

9.Keep the generator clean and free of oil, mud and other foreign matter.

10.Extension cords, power cords, and all electrical equipment must be in good condition. Never operate electrical equipment with damaged or defective cords.

11.Store the generator in a well ventilated area with the fuel tank empty. Fuel should not be stored near the generator.

12.Your generator should never be operated under these conditions:

a.Uncontrolled change in engine speed.

b.Electrical output loss.

c.Overheating in connected equipment.

d.Sparking.

e.Damaged receptacles.

f.Engine misfire.

g.Excessive vibration.

h.Flame or smoke.

i.Enclosed compartment.

j.Rain, snow or inclement weather. Do not let the unit get wet when operating.

13.Check the fuel system periodically for leaks or signs of deterioration such as chafed or spongy hose, loose or missing clamps, or damaged tank or cap. All defects should be corrected before operation.

14.The generator should be operated, serviced, and refueled only under the following conditions:

a.Start and run the generator outdoors. Do not run the generator in an enclosed area, even if doors or windows are open; avoid areas where vapors may be trapped, such as pits, garages, cellars, excavations and boat bilges. DANGER - CARBON MONOXIDE HAZARD: The engine exhaust contains carbon monoxide, a poisonous, odorless, invisible gas which, if breathed, may cause death or serious personal injury. If you start to feel sick, dizzy or weak while using the generator, shut it off and get to fresh air right away; you may have carbon monoxide poisoning.

b.Good ventilation for cooling. Air flow and temperatures are important for air cooled units. Temperatures should not exceed 104º F ambient (40º C).

c.Refuel the generator in a well lighted area. Avoid fuel spills and never refuel while the generator is running. Allow engine to cool for two minutes prior to refueling.

English

3

Customer Hotline [phone]

d.Do not refuel near open flames, pilot lights, or sparking electrical equipment such as power tools, welders, and grinders.

e.The muffler and air cleaner must be installed and in good condition at all times as they function as flame arresters if backfiring occurs.

f.Do not smoke near the generator.

15.Ensure that generator is properly grounded. (See “Grounding the generator” section in this

manual.)

16.Do not wear loose clothing, jewelry, or anything that may be caught in the starter or other rotating parts.

17.Unit must reach operating speed before electrical loads are connected. Disconnect loads before turning off engine.

18.To prevent surging that may possibly damage equipment, do not allow engine to run out of fuel when electrical loads are applied.

19.When powering solid state equipment, a Power Line Conditioner should be used to avoid possible damage to equipment.

20.Do not stick anything through ventilating slots, even when the generator is not operating. This can damage the generator or cause personal injury.

21.Before transporting the generator in a vehicle, drain all fuel to prevent leakage that may occur.

22.Use proper lifting techniques when transporting the generator from site to site. Improper lifting techniques may result in personal injury.

23.To avoid burns, do not touch engine muffler or other engine or generator surfaces which became hot during operation.

SPARK ARRESTER

YOUR PRODUCT MAY NOT BE EQUIPPED WITH A SPARK ARRESTING MUFFLER. If the product will be used around flammable materials, such as agricultural crops, forests, brush, grass, or other similar items, then an approved spark arrester should be installed and is legally required in the State of California. The California statutes requiring a spark arrester are Sections 13005(b), 4442 and 4443. Spark Arresters are also required on some U.S. Forest Service land and may also be legally required under other statutes and ordinances. An approved spark arrester is available from our product dealers, or may be ordered from Pramac America, LLC, P.O. Box 6001, Kearney, Nebraska 68847. 1-800-445-1805.

DETERMINING TOTAL WATTAGE

In order to prevent overloading and possible damage to your generator it is necessary to know the total wattage of the connected load. To determine which tools and/or appliances your generator will run follow these steps:

1.Determine if you want to run one item or multiple items simultaneously.

2.Check wattage requirements for the items you will be running by referring to the load’s nameplate or by calculating it (multiply amps x volts = watts).

3.Total the watts for each item. If the nameplate only gives volts and amps, multiply volts x amps = watts.

1 KW = 1,000 watts.

4.Motorized appliances or tools require more than their rated wattage for start up.

NOTE: Allow 2 1/2 to 4 times the listed wattage for starting equipment powered by electric motors.

5.The generator’s rated watts should match or exceed the total number of watts required for the equipment you want to run.

6.Always connect the heaviest load to the generator first, then add other items one at a time.

English

4

Customer Hotline [phone]

OPERATING VOLTAGE

CAUTION: Operating voltage and frequency requirement of all electronic equipment should be checked prior to plugging them into this generator. Damage may result if the equipment is not designed to operate within a +/- 10% voltage variation, and +/- 3 hz frequency variation from the generator name plate ratings. To avoid damage, always have an additional load plugged into the generator if solid state equipment (such as a television set) is used. A power line conditioner is recommended for some solid state applications.

A power line conditioner should be used when running one or more of the following solid state items:

Garage door openers

Kitchen appliances with digital displays

Televisions

Stereos

Personal computers

Quartz clocks

Copy machines

Telephone equipment

Other solid state equipment may require a power line conditioner. For more information, contact our Customer Service Department at 1-800-445-1805.

INSTALLATION

To avoid possible personal injury or equipment damage, a registered electrician or an authorized service representative should perform installation and all service. Under no circumstances should an unqualified person attempt to wire into a utility circuit.

To avoid backfeeding into utility systems, isolation of the residence electrical system is required.

Before temporary connection of the generator to the residence electrical system, turn off the main service/disconnect.

If your generator is to be used as a stand-by power source in case of utility power failure, it should be installed by a registered electrician and in compliance with all applicable local electrical codes.

Proper use requires that a double throw transfer switch be installed by a licensed qualified electrician so that the building's electrical circuits may be safely switched between utility power and the generator's output, thereby preventing backfeed into the power utility's electrical system.

To avoid backfeeding into utility systems, isolation of the residence electrical system is required. Before temporary connection of a generator to the residence electrical system turn off the main switch. Before making permanent connections a double throw transfer switch must be installed. To avoid electrocution or property damage, only a trained electrician should connect generator to residence electrical system. California law requires isolation of the residence electrical system before connecting a generator to residence electrical systems. Temporary connection not recommended due to backfeeding.

Always follow local codes and regulations that apply to the installation of any item that concerns this product.

1.NFPA 70 - National Electrical Code.

2.NFPA 37 - Standard for Installation and Use of Stationary Combustible Engines.

3.Agricultural Wiring handbook of Farm Standby Electric Power.

English

5

Customer Hotline [phone]

GENERATOR FEATURES

A.Control Panel

NOTE: Total power drawn from all receptacles must not exceed the nameplate ratings.

B.120 V, 20 Ampere Receptacle

20 amps of current may be drawn from the receptacle.

However, total power drawn must be kept within nameplate ratings.

C.120/240 V, 30 Ampere Twistlock Receptacle

Maximum full load current may be drawn from the

120/240 volt receptacle, provided it is the only receptacle used. Total current must be limited to the nameplate rating. If the 120/240 volt receptacle is used along with the 120 volt

receptacle, the total load drawn must not exceed the nameplate ratings.

D.Receptacle Covers

E.Circuit Protectors

The receptacles are protected by an AC circuit protector. If the generator is overloaded or an external short circuit occurs, the circuit protector will trip. If this occurs, disconnect all electrical loads and try to determine the cause of the problem before attempting to use the generator again. If overloading causes the circuit protector to trip, reduce the load. NOTE: Continuous tripping of the circuit protector may cause damage to generator or equipment. The circuit protector may be reset by pushing the button of the protector.

F.Slide-Out Quick Instruction Card

G.Ground Terminal

H.Hour Meter

•Press and release mode button to toggle between Total Timer and Timer 1 (TMR1).

•Total Timer displays and records the total hours your generator has run. Total Timer is not resettable.

•Timer 1 can be used to track operating hours for service intervals. Timer 1 is resettable by holding the mode button down for 3 seconds while TMR1 is displayed.

I.Engine On/Off Switch

J.389 CC OHV Engine

K.Recoil Starter

L.Engine Choke Lever

M.Oil Filler Cap

N.Oil Drain Plug

O.7 Gallon Metal Fuel Tank

P.Fuel Tank Cap

Q.Fuel Gauge

R.Fuel Shut-Off Valve

S.Air Filter

T.Folding Handle

B E C Q P O

I

A

H G

D E L

F

S K

T J R N M

English

6

Customer Hotline [phone]

BEFORE OPERATION

GROUND FAULT CIRCUIT INTERRUPTER (GFCI) PROTECTION

Some jobsites and local codes may require GFCI protection for personnel before operation of your generator. If your generator is not already equipped with a GFCI receptacle, GFCI In-line cord sets may be purchased from your local electrical supply store or home builder appliance store.

These cord sets are available in various plug and amperage configurations. (Make sure your generator is properly Grounded.)

GROUNDING THE GENERATOR

The National Electric Code requires that this product be properly connected to an appropriate earth ground to help prevent electric shock. A ground terminal connected to the frame of the generator has been provided for this purpose. Connecting a length of heavy gauge (12 AWG min.) copper wire between the generator Ground Terminal and a copper rod driven into the ground should provide a suitable ground connection. However, consult with a local electrician to insure that local codes are being adhered to.

GROUND TERMINAL LOCATION:

Ground

Terminal

Do not use a pipe carrying combustible material as the ground source.

LUBRICATION

DO NOT attempt to start this engine without filling the crank case with the proper amount and type of oil. Your generator has been shipped from the factory without oil in the crankcase. Operating the unit without oil can damage the engine.

Fill the engine with oil according to the operator manual. For units with a dipstick, fill oil to the proper level. Units without a dipstick should be filled to the top of the opening of the oil fill.

LOW OIL SENSOR

The unit is equipped with a low oil sensor. If the oil level becomes lower than required, the sensor will activate a warning device or stop the engine.

If generator shuts off and the oil level is within specifications, check to see if generator is sitting at an angle that forces oil to shift. Place on an even surface to correct this. If engine fails to start, the oil level may not be sufficient to deactivate low oil level switch. Make sure the sump is completely full of oil.

FUEL

Fill the tank with clean, fresh unleaded automotive gasoline. Regular grade gasoline may be used provided a high octane rating is obtained (at least 85 pump octane). We recommend always using a fuel stabilizer. A fuel stabilizer will minimize the formulation of fuel gum deposits during storage. The fuel stabilizer can be added to the gasoline in the fuel tank, or into the gasoline in a storage container.

•SLOWLY ADD UNLEADED GASOLINE TO FUEL TANK

•DO NOT OVERFILL TANK

•DO NOT FILL ABOVE TOP OF FUEL SCREEN. THIS WILL ALLOW EXPANSION IN HOT WEATHER AND PREVENT OVERFLOW.

POSITIONING

•Place the generator set on a flat and solid surface to prevent it from sinking.

•Keep fuel, oil or other explosives at a safe distance from the generator set.

•Select a site that is well ventilated and protected from the weather.

•Place the generator set safely away from people and animals.

CAUTION: TILTING CAN CAUSE FUEL SPILLAGE

English

7

Customer Hotline [phone]

STARTING THE UNIT

Gasoline is very dangerous.

Serious injury or death may result from fire caused by gasoline contacting hot surfaces.

1.Do not fill fuel tank with engine running.

2.Do not spill fuel while refilling tank.

3.Do not mix oil with gasoline.

4.Follow all instructions and warnings in the operator manual.

PRE-START PREPARATION

Before starting the generator, check for loose or missing parts and for any damage which may have occurred during shipment.

This generator must not be operated without all factory installed heat shields in place. Failure to comply may cause the fuel tank to overheat and result in personal injury from fire.

STARTING THE ENGINE

1.Check oil level and fuel.

2.Disconnect all electrical loads from the unit.

3.Open fuel shut off valve (A).

4.Adjust choke (B) as necessary.

5.Set the engine switch (C) to the “ON" position.

6.Pull on the starter rope (D) with fast steady pull. As the engine warms up, readjust the choke.

C

B

	START		RUN
					A

D

Allow generator to run at no load for five minutes upon each initial start-up to permit engine and generator to stabilize.

•Provide adequate ventilation for toxic exhaust gases and cooling air flow.

•Do not start or run the generator in an enclosed area, even if door or windows are open.

•Engines give off carbon monoxide, an odorless, colorless, poison gas.

•Breathing carbon monoxide can cause nausea, fainting or death.

APPLYING LOAD

This unit has been pretested and adjusted to handle its full capacity. When starting the generator, disconnect all load. Apply load only after generator is running. Voltage is regulated via the engine speed adjusted at the factory for correct output. Readjusting will void warranty.

When applying a load, do not exceed the maximum wattage rating of the generator when using one or more receptacles. Also, do not exceed the amperage rating of any one receptacle.

Do not apply heavy electrical load during break-in period (the first two to three hours of operations).

SHUTTING THE GENERATOR OFF

1.Remove entire electrical load.

2.Let the engine run for two minutes without load.

3.Move the engine switch to the “OFF” position.

4.Do not leave the generator until it has completely stopped.

5.Close the fuel shut off valve if the engine is to be put in storage or transported.

6.If a cover is used, do not install until unit has cooled.

7.If the generator will not be used again for an extended time period, refer to the SERVICE AND STORAGE section of this manual.

English

8

Customer Hotline [phone]

BAFFLE

FILTER ELEMENT

FRONT COVER BACK

COVER

LOCK SCREW

PERIODIC MAINTENANCE

	ITEM	NOTES	Daily (Before	Initial	Every	Every
			operation)	20 hours	50 hours	100 hours
Spark Plug		Check condition. Adjust gap and			9
		clean. Replace if necessary.
Engine Oil		Check oil level.	9	9		9
		Replace.
Air Filter		Clean, replace if necessary.			9
Fuel Filter		Clean fuel filter and fuel tank strainer.				9
		Replace if necessary.
Fuel Line		Check fuel hose for cracks or other	9
		damage. Replace if necessary.
Exhaust		Check for leakage. Retighten or	9
System		replace gasket if necessary.
		Check muffler screen. Clean/replace			9
		if necessary.
Carburetor		Check choke operation.	9
Starting		Check recoil starter operation.	9
System
Fittings/		Check. Replace if necessary.				9
Fasteners

MAINTENANCE

SPARK PLUG

Remove the spark plug and clean the electrodes section with a wire brush or sandpaper. Next, set the gap at .024/.031 inches (0.6-0.8 mm) by adjusting the negative electrode. Replace the spark plug with correct torque: 14 ft-lb (20 N.m)

Replace with only the same type of spark plug which was removed. An improper spark plug can cause the engine to overheat, emit smoke, or otherwise perform poorly.

OIL TYPE

Use new good quality oil, SJ or later service category. The oil to be used depends upon the temperature at which the engine is operated:

Below 32° F (0° C) . . . . . . . . .SAE 10W, 10W-30, or 10W-40 32 to 80° F (0 to 25° C) . . . . . .SAE 20W, 10W-30, or 10W-40 80 to 95° F (25 to 35° C) . . . . .SAE 30W, 10W-30, or 10W-40 Above 95° F (35° C) . . . . . . . . . . . . . . . . . . . . . . . . .SAE 40W

OIL REPLACEMENT

1.Change oil while engine is warm.

2.Place the generator unit on a level surface.

3.Remove the oil filler cap.

4.Open the oil drain plug and let oil drain completely into a

pan placed under the engine.

5.Check gaskets. Replace if required.

6.Reinstall the oil drain plug and refill engine with clean oil.

7.Replace the oil filler cap.

AIR FILTER CLEANING

1.Unscrew the air filter cover.

2.Remove filter element and wash well in solvent.

3.Pour a small amount of oil onto the filter element and gently squeeze out any

excess oil.

4.Replace the filter

element and air filter cover.

5. Be sure the filter cover seals properly all around.

FUEL STRAINER CLEANING

1.Remove the plastic fuel strainer, located below the fuel tank cap.

2.Wash the strainer in solvent and replace.

English

9

Customer Hotline [phone]

VALVE CLEARANCE

Intake — 0.1 mm - 0.15 mm (.004 inch - .006 inch) Exhaust — 0.15 mm - 0.20 mm (.006 inch - .008 inch)

After the first 50 hours of operation, check the valve clearance in the engine and adjust if necessary.

NOTICE: If unsure about doing this procedure or the proper tools are not available, take the generator to the nearest service center to have the valve clearance adjusted. This is a very important procedure to ensure longest life for the engine.

SPARK ARRESTER SCREEN

Remove screen every 50 hours for cleaning and inspection.

Replace if damaged.

Clean and inspect the spark arrester as follows:

1.Remove the screen retainer by removing the retainer clamp.

2.Remove the retainer screw from the muffler outlet tube.

3.Slide the spark arrester screen out from the muffler outlet tube.

4.Be careful not to damage the spark arresting screen. The spark arrester must be free of breaks and holes. If screen is not damaged, clean it with a commerical solvent.

5.Replace the screen and retainer and secure with retainer screw and clamp.

GENERATOR: Brushes

The brushes in the generator should be inspected once every year for chips and cracks. Brushes should be replaced when they are worn to 1/4 inch (7mm).

NOTE: Replace brushes in sets only, never separately. Replace only with brushes specified in parts list. Other brushes may appear to be identical but may have completely different mechanical and electrical characteristics.

INSPECTING THE BRUSHES:

1.Remove 2 screws (V) and end cover (W).

2.Remove screw (X) holding the brush module (Y).

3.Disconnect the blue (+) and yellow (-) brush wires from the tabs.

4.Replace if worn to 1/4 inch (7mm).

5.Do not over tighten screw.

HEAT SHIELD:

Inspect to ensure that all heat shields and heat deflectors are intact and in place. Do not remove any parts or modify parts. Removing or modifying parts could cause serious damage to the unit.

ENGINE: Carburetor Icing

During the winter months, rare atmospheric conditions may develop which will cause an icing condition in the carburetor. If this develops, the engine may run rough, loose power, and may stall. Call Product Service for more information.

QUICK STARTING TIPS FOR UNITS THAT HAVE BEEN SITTING FOR AWHILE:

If your unit has been sitting around for a long time period and is hard to start, try doing some of these easy steps before calling the Customer Hotline.

1.Check the oil level.

2.Replace the old fuel.

3.Change the spark plug.

4.Check the fuel lines. Make sure the fuel shut off valve is open.

5.Check all generator parts for integrity.

6.Clean the Carburetor.

SERVICE AND STORAGE

INFREQUENT SERVICE

If the unit is used infrequently, difficult starting may result. To eliminate hard starting, follow these instructions:

1.Run the generator at least 30 minutes every month.

2.Run the generator, then close the fuel shut-off valve and allow the unit to run until the engine stops.

3.Move the engine switch to the “OFF” position.

LONG TERM STORAGE

When the generator set is not being operated or is being stored more than one month, follow these instructions:

1.Replenish engine oil to upper level.

2.Run the generator, then close the fuel shut-off valve and allow the unit to run until the engine stops.

3.Move the engine switch to the “OFF” position.

4.After the unit has cooled, drain gasoline from fuel tank, fuel line and carburetor.

5.Pour about one teaspoon of engine oil through the spark plug hole, pull the recoil starter several times and replace the plug. Then pull the starter until you feel the piston is on its compression stroke and leave it in that position. This closes both the intake and exhaust valves to prevent the inside of the cylinder from rusting.

6.Cover the unit and store in a clean, dry place that is well ventilated away from open flame or sparks.

NOTE: We recommend always using a fuel stabilizer. A fuel stabilizer will minimize the formulation of fuel gum deposits during storage. The fuel stabilizer can be added to the gasoline in the fuel tank, or into the gasoline in a storage container.

English

10

Customer Hotline [phone]

ENGINE TROUBLESHOOTING

ENGINE SPECIFICATIONS

Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-stroke, single cylinder, gasoline, OHV Displacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .389 cc, 23.74 cubic inches Nominal RPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3600 Starting System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Recoil Oil Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . 37 oz. (1.1 L) Spark Plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .NGK BPR7ES or equivalent Governor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Mechanical (adjustable) Cooling System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Forced air cooling Air Cleaner Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Foam element

English

11

Customer Hotline [phone]

SERVICE INFORMATION

LIMITED WARRANTY

1.

2.

3.

REGISTER YOUR PRODUCT

Register your Powermate® generator online at www.powermate.com.

English

Warranty Coverage: Pramac America, LLC (the Company) warrants to the original retail customer in North America that it will repair or replace, free of charge, any parts found by the Company or its authorized service

representative to be defective in material or workmanship. This warranty covers the cost of replacement parts and labor for defects in material or workmanship.

Not Covered:

·Transportation charges for sending the product to the Company or its authorized service representative for warranty service, or for shipping repaired or replacement products back to the customer; these charges must be borne by the customer.

·If a separate operator's manual and engine warranty from the engine manufacturer is included with this product, only that warranty will apply to the engine.

·Damages caused by abuse or accident, and the effects of corrosion, erosion and normal wear and tear.

·Warranty is voided if the customer fails to install, maintain and operate the product in accordance with the instructions and recommendations of the Company set forth in the owner's manual, or if the product is used as rental equipment.

·The Company will not pay for repairs or adjustments to the product, or for any costs or labor, performed without the Company's prior authorization.

Warranty Period: Two (2) years from the date of purchase on products used solely for consumer applications; if a product is used for business or commercial applications, the

the warranty period will be limited to one (1) year from the date of purchase. For warranty service, the customer must provide dated proof of purchase and must notify the Company within the warranty period.

For warranty service: Call toll free 800-445-1805, or write to Pramac America, LLC, Product Services, 4970 Airport Road, P. O. Box 6001, Kearney, NE 68847.

EXCLUSIONS AND LIMITATIONS: THE COMPANY MAKES NO OTHER WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY AND OF FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY DISCLAIMED. THE WARRANTY SERVICE DESCRIBED ABOVE IS THE EXCLUSIVE REMEDY UNDER THIS WARRANTY; LIABILITY FOR INCIDENTAL AND CONSEQUENTIAL DAMAGES IS EXCLUDED TO THE EXTENT PERMITTED BY LAW.

This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. Some states do not allow a disclaimer of implied warranties, or the exclusion or limitation of incidental and consequential damages, so the above disclaimers and exclusions may not apply to you.

12	Customer Hotline [phone]
