Pioneer DVH-P4050MP User Manual

Download

Page 1

Operation Manual

DVD RECEIVER

DVH-P4050MP

English

Page 2

Contents

Thank you for buying this Pioneer product.

Please read through these operating instructions so you will know how to operate your model properly. After you have finished reading the instructions, keep this man-

ual in a safe place for future reference.

Be sure to read this

! Playable discs 6 ! DVD video disc region numbers 6 ! When an operation is prohibited 8

Precautions

IMPORTANT SAFEGUARDS 5 Precautions 5

– To ensure safe driving 5

Before You Start About this unit 6

– Playable discs 6 – DVD video disc region numbers 6

About this manual 6 Visit our website 7 Features 7

– About WMA 7 – About MP3 8 – About AAC 8 – About DivX 8

What the marks on DVDs indicate 8

– When an operation is prohibited 8

Protecting your unit from theft 8

– Removing the front panel 9 – Attaching the front panel 9

Use and care of the remote control 9

– Installing the battery 9 – Using the remote control 9

Operating this unit

What’s What 11

– Head unit 11 – Remote control 12

Basic Operations 15

– Power ON/OFF 15 – Selecting a source 15

– Built-in DVD player basic

operations 15

Tuner 16

– Basic Operations 16 – Storing and recalling broadcast

frequencies 17

– Introduction of advanced

operations 17

– Storing the strongest broadcast

frequencies 17

– Tuning in strong signals 17

Playing DVD video discs 18

– Watching a DVD video 18 – Basic operation of DVD video 18 – Specifying title 18 – Selecting a chapter directly 19 – Pausing DVD video playback 19 – Frame-by-frame playback 19 – Slow motion playback 19 – Changing audio language during

playback (Multi-audio) 20

– Changing the subtitle language during

playback (Multi-subtitle) 20

– Changing the viewing angle during

playback (Multi-angle) 20

– Resume playback (Bookmark) 21 – Automatic playback of DVDs 21 – CM skip/CM back 21 – Return to the specified scene 21 – Selecting the title list 21 – Introduction of advanced

operations 22

– Switching the information displays 23

Playing Video CDs 24

– Watching a Video CD 24 – Basic operation of Video CD 24 – Specifying track 25 – Selecting a track directly 25 – Pausing Video CD playback 25

Page 3

Contents

– Frame-by-frame playback 26 – Slow motion playback 26 – Introduction of advanced

operations 26

– Switching the information display 27

Playing DivX files 28

– Watching a DivX 28 – Basic Operations 28 – Selecting a file directly 28 – Playing DivX® VOD content 29 – Pausing playback 29 – Frame-by-frame playback 29 – Slow motion playback 29 – Changing audio language during

playback (Multi-audio) 30

– Selecting files from the file name

list 30

– Introduction of advanced

operations 30

– Switching the information displays 31

Playing CDs 32

– Listening to a CD 32 – Basic Operations 32 – Pausing playback 33 – Selecting a track directly 33 – Displaying text information on disc 33 – Selecting tracks from the track title

list 34

– Selecting tracks from the file name

list 34

– Introduction of advanced

operations 34

– Displaying the information display 36

Audio Adjustments 37

– Introduction of audio adjustments 37 – Using balance adjustment 37 – Using the equalizer 37 – Adjusting loudness 38 – Using subwoofer output 39

– Boosting the bass 39 – Using the high pass filter 39 – Adjusting source levels 40

Setting up the DVD player 40

– Introduction of DVD setup

adjustments 40

– Setting the subtitle language 40 – Setting the audio language 41 – Setting the menu language 41 – Switching the assist subtitle on or

off 42

– Setting the angle icon display 42 – Setting the aspect ratio 42 – Setting the parental lock 42 – Displaying your DivX® VOD

registration code 44

– Setting the DivX subtitle file 44 – Setting for digital output 44

Initial Settings 45

– Adjusting initial settings 45 – Setting the clock 45 – Setting the FM tuning step 45 – Setting the AM tuning step 45 – Switching the warning tone 45 – Switching the auxiliary setting 46 – Setting the AV input 46 – Setting the rear output and subwoofer

controller 46

– Switching the ever scroll 47

Other Functions 47

– Turning the clock display on or off 47 – Setting the level indicator 47 – Using the AUX source 47 – Using the external unit 48 – Using the PGM button 49 – Sound muting 49

Available accessories Multi-CD Player 50

– Basic Operations 50

Page 4

Contents

– Selecting a track directly 50 – Introduction of advanced

operations 50

– Using ITS playlists 51 – Using disc title functions 52 – Using CD TEXT functions 53

Additional Information

Troubleshooting 54 Error messages 55 Handling guideline of discs and player 57 DVD discs 57 DVD-R/DVD-RW discs 57 AVCHD recorded discs 58 CD-R/CD-RW discs 58 Dual Discs 58 Compressed audio files on the disc 58

– Example of a hierarchy 59 – Compressed audio compatibility 59

DivX video files 59

– DivX compatibility 60 Language code chart for DVD 61 Terms 62 Specifications 65

Page 5

Precautions

Section

IMPORTANT SAFEGUARDS

WARNING

! Do not attempt to install or service your

display by yourself. Installation or servicing of the display by persons without training and experience in electronic equipment and automotive accessories may be dangerous and could expose you to the risk of electric shock or other hazards.

Precautions

To ensure safe driving

WARNING

! To avoid the risk of accident and the potential

violation of applicable laws, the front DVD or TV (sold separately) feature should never be used while the vehicle is being driven. Also, rear displays should not be in a location where it is a visible distraction to the driver.

! In some countries or states the viewing of

images on a display inside a vehicle even by persons other than the driver may be illegal. Where such regulations apply, they must be obeyed and this unit’s DVD features should not be used.

! NEVER install the display in a location that

enables the driver to watch the DVD or Video CD while driving.

Precautions

When you park your car in a safe place and apply the parking brake, the picture appears on the screen.

Page 6

Section

Before You Start

About this unit

CAUTION

! Do not allow this unit to come into contact

with liquids. Electrical shock could result. Also, damage to this unit, smoke, and overheating could result from contact with liquids.

! “CLASS 1 LASER PRODUCT”

This product contains a laser diode of higher class than 1. To ensure continued safety, do not remove any covers or attempt to gain access to the inside of the product. Refer all servicing to qualified personnel.

! Keep this manual handy as a reference for op-

erating procedures and precautions.

! Always keep the volume low enough so that

you can hear sounds from outside the vehicle.

! Protect this unit from moisture. ! If the battery is disconnected or discharged,

the preset memory will be erased and must be reprogrammed.

! If this unit does not operate properly, contact

your dealer or nearest authorized Pioneer Service Station.

Playable discs

DVD, Video CD and CD discs that display the logos shown below can be played back on this player.

Notes

! This player can only play back discs bearing

is a trademark of DVD Format/Logo

Licensing Corporation.

the marks shown above.

DVD video disc region numbers

DVD video discs that have incompatible region numbers cannot be played on this player. The region number of the player can be found on the bottom of this unit. The illustration below shows the regions and corresponding region numbers.

DVD video

Video CD

About this manual

This unit features a number of sophisticated functions ensuring superior reception and operation. All the functions have been designed for the easiest possible use, but many are not self-explanatory. This operation manual will help you benefit fully from this unit’s potential and to maximize your listening enjoyment. We recommend that you familiarize yourself with the functions and their operation by reading through the manual before you begin using this unit. It is especially important that you read and observe WARNINGs and CAU- TIONs in this manual.

Page 7

Before You Start

Section

Visit our website

Visit us at the following site:

http://pioneer.jp/group/index-e.html

! We offer the latest information about

Pioneer Corporation on our website.

Features

DVD-R/RW compatibility

It is possible to play back DVD -R/RW discs recorded with the video format and Video Recording format. (Refer to DVD-R/DVD-RW discs on page 57.)

Video CDs featuring PBC compatibility

It is possible to play back Video CDs featuring PBC (playback control).

WMA, MP3 and AAC compatibility

Refer to Compressed audio compatibility on page 59.

DivX

video compatibility

Refer to DivX compatibility on page 60.

Dolby Digital/DTS compatibility

When using this unit with a Pioneer multichannel processor, you can enjoy the atmosphere and excitement provided by DVD movie and music software featuring 5.1 channel recordings. ! Manufactured under license from Dolby

Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

! Manufactured under license under U.S. Pa-

tent #: 5,451,942 & other U.S. and worldwide patents issued & pending. DTS and DTS Digital Out are registered trademarks and the DTS logos and Symbol are trademarks of DTS, Inc. © 1996-2007 DTS, Inc. All Rights Reserved.

Note

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

About WMA

The Windows Media™ logo printed on the box indicates that this unit can play back WMA data. ! Windows Media and the Windows logo are

trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.

! This unit may not operate correctly depend-

ing on the application used to encode WMA files.

Before You Start

Page 8

Section

Before You Start

About MP3

Supply of this product only conveys a license for private, non-commercial use and does not convey a license nor imply any right to use this product in any commercial (i.e. revenuegenerating) real time broadcasting (terrestrial, satellite, cable and/or any other media), broadcasting/streaming via internet, intranets and/ or other networks or in other electronic content distribution systems, such as pay-audio or audio-on-demand applications. An independent license for such use is required. For details, please visit http://www.mp3licensing.com.

About AAC

This unit plays back AAC files encoded by

iTunes

! iTunes is a trademark of Apple Inc., regis-

tered in the U.S. and other countries.

About DivX

DivX is a compressed digital video format created by the DivX This unit can play DivX video files recorded on CD-R/RW/ROM and DVD-R/RW/ROM discs. Keeping the same terminology as DVD video, individual DivX video files are called “Titles”. When naming files/titles on a CD-R/RW or a DVD-R/RW disc prior to burning, keep in mind that by default they will be played in alphabetical order. Official DivX Plays all versions of DivX

DivX

6) with standard playback of DivX media files ! DivX, DivX Certified, and associated logos

are trademarks of DivX, Inc. and are used under license.

video codec from DivX, Inc.

Certified product

video (including

What the marks on DVDs indicate

The marks below may be found on DVD disc labels and packages. They indicate the type of images and audio recorded on the disc, and the functions you can use.

Mark Meaning

16 : 9 LB

ALL

Indicates the number of audio systems.

Indicates the number of subtitle lan-

guages.

Indicates the number of viewing an-

gles.

Indicates the picture size (aspect ratio: screen width-to-height ratio) type.

Indicates the number of the region where playback is possible.

When an operation is prohibited

When you are watching a DVD and attempt to perform an operation, it may not be performed because of the programming on the disc. When this happens, the icon the screen. ! The icon

may not appear with certain

discs.

appears on

Protecting your unit from theft

The front panel can be detached to deter theft.

Important

! Never use force or grip the display and the

buttons too tightly when removing or attaching.

! Avoid subjecting the front panel to excessive

shock.

Page 9

Before You Start

Section

! Keep the front panel out of direct sunlight and

high temperatures.

Removing the front panel

1 Press DETACH to release the front panel.

2 Grab the front panel and remove.

3 Put the front panel into the provided protective case for safe keeping.

Attaching the front panel

1 Slide the front panel to the left until it clicks.

Front panel and the head unit are jointed on the left side. Make sure that the front panel has been jointed to the head unit.

2 Press the right side of the front panel until it is firmly seated.

# If you can’t attach the front panel to the head unit successfully, try again. Front panel may be damaged if you attach the front panel forcedly.

Use and care of the remote control

Installing the battery

Slide the tray on the back of the remote control out and insert the battery with the plus (+) and minus (–) poles aligned properly. ! When using for the first time, pull out the

film protruding from the tray.

WARNING

Keep the battery out of the reach of children. Should the battery be swallowed, consult a doctor immediately.

CAUTION

! Use one CR2025 (3 V) lithium battery. ! Remove the battery if the remote control is not

used for a month or longer.

! There is a danger of explosion if the battery is

incorrectly replaced. Replace only with the same or equivalent type.

! Do not handle the battery with metallic tools. ! Do not store the battery with metallic objects. ! If the battery leaks, wipe the remote control

completely clean and install a new battery.

! When disposing of used batteries, comply

with governmental regulations or environmental public institutions’ rules that apply in your country/area.

! Always check carefully that you are loading

the battery with its plus (+) and minus (–) poles facing the proper directions.

Before You Start

Using the remote control

Point the remote control in the direction of the front panel to operate. ! The remote control may not function prop-

erly in direct sunlight.

Page 10

Section

Before You Start

Important

! Do not store the remote control in high tem-

peratures or direct sunlight.

! Do not let the remote control fall onto the

floor, where it may become jammed under the brake or accelerator pedal.

Page 11

















Operating this unit

Section

Operating this unit

What’s What

Head unit

1 AUDIO button

Press to select various sound quality controls.

2 BAND button

Press to select among three FM bands and one AM band and to cancel the control mode of functions.

3 SOURCE button, VOLUME

This unit is turned on by selecting a source. Press to cycle through all the available sources. Rotate it to increase or decrease the volume.

4 Disc loading slot

Insert a disc to play.

5 EJECT button

Press to eject a disc from this unit.

6 CLOCK button

Press to change to the clock display.

7 AUX1 input jack (3.5 mm stereo/video jack)

Use to connect an auxiliary device.

a SW button

Press to select the subwoofer setting menu. Press and hold to select the bass boost setting menu.

b 1 to 6 buttons

These buttons can perform the same operation as NUMBER (1 to 6) buttons on the remote control. Press for preset tuning and disc number search when using a multi-CD/ DVD player.

c a/b/c/d buttons

Press to perform manual seek tuning, fast forward, reverse and track search controls. Also used for controlling functions.

d DISPLAY button

Press to select different displays.

e FUNCTION button

Press to select functions.

8 DETACH button

Press to remove the front panel from the head unit.

9 EQ button

Press to select various equalizer curves.

Page 12





































Section

Operating this unit

Remote control

Button names DVH mode DVD and S-DVD mode

1 SOURCE button Press to cycle through all the available sources. Press and hold to turn the source off.

2ATTbutton

VOLUME but-

tons

AUDIO button Press to change the audio language during DVD playback.

SUBTITLE but-

ton

ANGLE button Press to change the viewing angle during DVD playback.

AUTO PLAY

button

6 RETURN button Press to display the PBC (playback control) menu during PBC playback.

BOOKMARK

button

Press to quickly lower the volume level by about 90%. Press once more to return to the original volume level.

Press to increase or decrease the volume.

Press to change the subtitle language during DVD playback.

Press to turn the DVD auto-playback function on or off.

Press to operate the preprogrammed functions for each source. (Refer to Using the PGM button on page 49.)

Press to turn the bookmark function on or off. For details, refer to Resume play- back (Bookmark) on page 21.

Page 13

Operating this unit

Section

Remote control

operation mode switch

CM BACK/CM

SKIP

10 DIRECT button Press to do direct channel select. Not used.

A.MENU but-

ton

FUNCTION but-

ton

NUMBER but-

ton, CLEAR button

14 BAND button

DISPLAY but-

ton

PLAY/PAUSE

(f) button

REVERSE (m) button

FORWARD

(n) button

(o) button

NEXT (p)

button

STEP (r/q) buttons

STOP (g) but- ton

Move the thumb pad

Click the thumb pad

MENU button Press to display the DVD menu during DVD playback.

TOP MENU

button

Switch the operation mode between DVD, S-DVD and DVH modes. Normally, set to DVH. For details, refer to Using the remote control operation mode switch on the next page.

Press to skip progressively backward/forward through the video playing.

Functions are the same as AUDIO button on the head unit. Press to select various sound quality controls.

Press to select functions.

Press 0 to 9 to input numbers. Buttons 1 to 6 can operate the preset tuning for the tuner or disc changing for multi-DVD player or multi-CD player. Press CLEAR to clear the input numbers.

Press to select among three FM bands and to cancel the control mode of functions.

Press to turn the information display on or off when the video is displayed. Depending on the selected source, pressing this button can switch the display indication on the head unit.

Press to switch sequentially between playback and pause.

Press to perform fast reverse.

Press to perform fast for ward.

Press to return to the previous track (chapter).

Press to go to the next track (chapter).

Press to move ahead one frame at a time during DVD/VideoCD playback. Press and hold for one second to activate slow playback. If a DVD-VR disc contains a still image, press r while displaying a still image to switch to the next image or video.

Not used. Press to stop playback.

Functions are the same as a/b/c/d buttons. Move to do fast forward, reverse and track search controls. Also used for controlling functions.

Click to display the disc title list, track title list, folder list or file list depending on the source.

Press to return to the top menu during DVD playback.

Press to select a menu item on the Video CDs featuring PBC (playback control).

Press to switch between media file types. (Refer to Switching the media file type on page 16.)

Move to select a menu on the DVD menu.

Click to select a menu on the DVD menu.

Operating this unit

Page 14

Section

Operating this unit

Using the remote control operation mode switch

There are three remote control operation modes on the remote control. If you want to operate this unit by remote control, turn the mode switch to DVH mode. In this case, both the head unit’s buttons and remote control can control this unit.

DVH mode operation

When operating this unit by remote control, the mode is normally switched to DVH. ! The thumb pad on the remote control can

perform the same operations as a/b/c/d buttons.

! Numbers (1 to 6) can perform the same op-

erations as 1 to 6 buttons on the head unit. — If you want to select a disc located at 7

to 12 by using buttons 1 to 6, press and hold the corresponding numbers, such as 1 for disc 7, until the disc number appears in the display.

DVD mode operation

If you switch the mode to DVD, the thumb pad and 0 to 10 operations are changed for DVD player.

S-DVD mode operation

Set to S-DVD mode if separately sold Pioneer DVD player or Multi-DVD player is controlled by this remote control. Separately sold DVD player or multi-DVD player is connected to this unit as an external unit. For details concerning operation, refer to instruction manual of the connected DVD player. Various operations can also be conducted with this unit’s remote control which is set to S-DVD mode. S-DVD mode operation are basically the same as that of the DVD mode operation.

If Pioneer DVD player (SDV-P7) is connected to this unit as a source DVD player, remote control code setting should be A in the initial settings of SDV-P7. Otherwise, the supplied remote control cannot control SDV-P7.

% When you want to operate the following functions, switch the mode to DVD:

! When operating the DVD menu by using

the thumb pad. (Refer to Basic operation of DVD video on page 18.)

! When operating the PBC menu by using 0

to 10. (Refer to Watching a Video CD on page 24.)

! When specifying title or track by using 0 to

10. (Refer to Specifying title on page 18 and

Specifying track on page 25.)

! When operating the DVD setup menu by

using the thumb pad. (Refer to Setting up the DVD player on page 40.)

Page 15

Operating this unit

Section

Basic Operations

Power ON/OFF

Turning the unit on

% Press SOURCE to turn the unit on.

Turning the unit off

% Press SOURCE and hold until the unit turns off.

Selecting a source

% Press SOURCE repeatedly to switch between the following sources. TUNER (tuner)—DVD (built-in DVD player)— MULTI CD (multi-CD player)—EXTERNAL (ex- ternal unit 1)—EXTERNAL (external unit 2)— AUX1 (AUX 1)—AUX2 (AUX 2)

Notes

! In the following cases, the sound source will

not change. — When no unit corresponding to the se-

lected source is connected.

— When there is no disc or magazine in the

player.

— When AUX (auxiliary input) is set to off

(refer to page 46).

! AUX1 is set to AUDIO by default. Set the

AUX1 to OFF when not in use (refer to Switch- ing the auxiliary setting on page 46).

! External unit refers to a Pioneer product (such

as ones available in the future) that, although incompatible as a source, enables control of basic functions with this unit. Two external units can be controlled with this unit. When two external units are connected, the external unit is automatically allocated to external unit 1 or external unit 2 by this unit.

! When this unit’s blue/white lead is connected

to the vehicle’s auto-antenna relay control terminal, the vehicle’s antenna extends when this unit’s source is turned on. To retract the antenna, turn the source off.

Built-in DVD player basic operations

Playing a disc

% Insert a disc into the disc loading slot.

# If you are playing a DVD or Video CD, a menu

may appear. Refer to Basic operation of DVD video on page 18 and Basic operation of Video CD on page 24. # When the automatic playback function is on, this unit will cancel the DVD menu and automatically start playback from the first chapter of the first title. Refer to Automatic playback of DVDs on page 21. # You can eject a disc by pressing EJECT.

Notes

! The DVD player plays one, standard, 12-cm or

8-cm (single) disc at a time. Do not use an adapter when playing 8-cm discs.

! Do not insert anything other than a disc into

the disc loading slot. Discs which can be played back are listed on Playable discs on page 6.

! If bookmark function is on, DVD playback re-

sumes from the selected point. For more details, refer to Resume playback (Bookmark) on page 21.

! If a disc contains a mixture of various media

file types such as DivX and MP3, you can switch between media file types to play. Refer to Switching the media file type on the next page.

! If you cannot insert a disc completely or if

after you insert a disc the disc does not play, check that the label side of the disc is up. Press EJECT to eject the disc, and check the disc for damage before inserting it again.

! There is sometimes a delay between starting

up disc playback and the sound being issued. When being read, FRMT READ is displayed.

! If an error message is displayed, refer to Error

messages on page 55.

Operating this unit

Page 16





Section

Operating this unit

Switching the media file type

When playing a disc containing a mixture of various media file types such as DivX and MP3, you can switch between media file types to play. ! This unit allows playback of the following

media file type recorded on CD-R/RW/ROM discs.

— Audio data (CD-DA) — Compressed audio files — DivX video files

! In case of DVD-R/RW/ROM, this unit does

not allow playback of audio data (CD-DA).

% Press BAND to switch between media file types.

Adjusting the volume

% Use VOLUME to adjust the sound level.

With the head unit, rotate VOLUME to increase or decrease the volume. With the remote control, press VOLUME to increase or decrease the volume.

Tuner

Basic Operations

Important

If you are using this unit in North, Central or South America, reset the AM tuning step (see Setting the AM tuning step on page 45).

1 Band indicator 2 Preset number indicator 3 Frequency indicator 4 5 (stereo) indicator

Appears when the selected frequency is being broadcast in stereo.

1 Press SOURCE to select the tuner.

2 Press BAND to select a band.

Press BAND until the desired band is displayed, FM1, FM2, FM3 for FM or AM.

3 To perform manual tuning, briefly press c or d.

4 To perform seek tuning, press and hold c or d for about one second and release.

The tuner will scan the frequencies until a broadcast strong enough for good reception is found.

# You can cancel seek tuning by briefly pressing c or d. # If you press and hold c or d you can skip sta- tions. Seek tuning starts as soon as you release the button.

Page 17





Operating this unit

Section

Storing and recalling broadcast frequencies

If you press any of the preset tuning buttons 1 to 6 you can easily store up to six broadcast frequencies for later recall with the touch of a button. ! Up to 18 FM stations, six for each of the

three FM bands, and six AM stations can be stored in memory.

% When you find a frequency that you want to store in memory, press one of preset tuning buttons 1 to 6 and hold until the preset number stops flashing.

The number you have pressed will flash in the preset number indicator and then remain lit. The selected radio station frequency has been stored in memory. The next time you press the same preset tuning button the radio station frequency is recalled from memory.

# You can also use a and b to recall radio sta- tion frequencies assigned to preset tuning buttons 1 to 6.

Introduction of advanced operations

# If you do not operate the function within about 30 seconds, the display is automatically returned to the frequency display.

Storing the strongest broadcast frequencies

BSM (best stations memory) lets you automatically store the six strongest broadcast frequencies under preset tuning buttons 1 to 6. Once stored you can tune in to those frequencies with the touch of button. ! Storing broadcast frequencies with BSM

may replace broadcast frequencies you have saved using buttons 1 to 6.

1 Press FUNCTION to select BSM.

2 Press a to turn BSM on.

The six strongest broadcast frequencies are stored in the order of their signal strength.

# To cancel the storage process, press b.

Tuning in strong signals

Local seek tuning lets you tune in only those radio stations with sufficiently strong signals for good reception.

1 Press FUNCTION to select LOCAL.

Operating this unit

1 Function display

Shows the function status.

2 LOC indicator

Appears when local seek tuning is on.

% Press FUNCTION repeatedly to switch between the following functions: BSM (best stations memory)—LOCAL (local

seek tuning)

# To return to the frequency display, press

BAND.

2 Press a to turn local seek tuning on.

Local seek sensitivity (e.g., LOCAL 2) appears in the display.

# To turn local seek tuning off, press b.

3 Press c or d to set the sensitivity.

There are four levels of sensitivity for FM and two levels for AM: FM: LOCAL 1—LOCAL 2—LOCAL 3—

LOCAL 4

AM: LOCAL 1—LOCAL 2 The LOCAL 4 setting allows reception of only the strongest stations, while lower settings let you receive progressively weaker stations.

Page 18





Section

Operating this unit

Playing DVD video discs

Watching a DVD video

Read the precautions for discs and player on Handling guideline of discs and player on page

57.

1 Title number indicator

Shows the title currently playing.

2 Chapter number indicator

Shows the chapter currently playing.

3 Play time indicator

Shows the elapsed playing time of the current chapter.

4 DVD-VR indicator

Basic operation of DVD video

1 Use the thumb pad to select the desired menu option.

When the DVD offers a menu, a menu is displayed.

# This function is available for DVD video.

2 Click the thumb pad.

Playback starts from the selected menu item.

# You can display the menu by pressing the MENU or TOP MENU while a disc is playing. Pressing either of these buttons again lets you start playback from the location selected from the menu. For details, refer to the instructions provided with the disc. # The way to display the menu differs depending on the disc.

3 To perform fast forward or reverse, press and hold m or n.

# If you continue pressing m or n for five seconds, the icon m or n is highlighted. When this happens, fast reverse/fast forward con-

tinues even if you release m or n. To resume playback at a desired point, press f. # Fast forward/fast reverse may not be possible at certain locations on some discs. If this happens, normal playback automatically resumes. # There is no sound on fast forward or reverse.

4 To skip back or forward to another chapter, press o or p.

Pressing p skips to the start of the next chapter. Pressing o once skips to the start of the current chapter. Pressing again will skip to the previous chapter. Chapter numbers are displayed for eight seconds.

5 To stop playback, press g.

# When you stop DVD playback by pressing g, that location on the disc is memorized enabling playback from that point when you play the disc again.

# To resume playback, press f. # If the remote control is set to DVH, g does

not operate.

Specifying title

To perform this function, set the remote control to DVD mode. ! You cannot operate this function by using

NUMBER when the remote control is set to DVH mode.

% Press 0 to 10 corresponding to a desired title number.

Title number is displayed for eight seconds and playback starts from the selected title.

! To select 3, press 3. ! To select 10, press 10 and 0 in that order. ! To select 23, press 10, 10 and 3 in that

order.

Page 19

Operating this unit

Section

Selecting a chapter directly

When using the remote control, you can select a chapter directly by entering the desired chapter number. ! To perform this function, set the remote

control to DVH mode.

1 Press DIRECT.

Chapter number input display appears.

2 Press NUMBER to enter the desired chapter number.

! To select 3, press 3. ! To select 10, press 1 and 0 in order.

# You can cancel the input number by pressing

CLEAR.

3 Press DIRECT.

The chapter of entered number will play.

Note

After entering the number input mode, if you do not perform an operation within about eight seconds, the mode is automatically canceled.

Pausing DVD video playback

Pause lets you temporarily stop disc playback.

% Press f during playback.

The icon e is displayed and playback is paused, letting you view a still image.

# To resume playback at the same point that you turned pause on, press f again.

Note

Depending on the disc and the playback location on the disc, the icon ing that still playback is not possible.

may be displayed, indicat-

Frame-by-frame playback

This lets you move ahead one frame at a time during playback.

% Press r.

Each time you press r, you move ahead one frame.

# To return to normal playback, press f.

Notes

! There is no sound during frame-by-frame play-

back.

! Depending on the disc and the playback loca-

tion on the disc, the icon indicating that frame-by-frame playback is not possible.

! With some discs, images may be unclear dur-

ing frame-by-frame playback.

! Reverse frame-by-frame playback is not possi-

ble.

may be displayed,

Slow motion playback

This lets you slow down playback speed.

1 Press r and hold during playback.

The icon playback begins.

# To return to normal playback, press f.

2 Press r or q to adjust playback speed during slow motion playback.

Each time you press r or q it changes the speed in four steps in the following order:

1/16—1/8—1/4—1/2

! There is no sound during slow motion play-

back.

! Depending on the disc and the playback loca-

tion on the disc, the icon indicating that slow motion playback is not possible.

! With some discs, images may be unclear dur-

ing slow motion playback.

! Reverse slow motion playback is not possible.

is displayed, forward slow motion

Notes

may be displayed,

Operating this unit

Page 20

Section

Operating this unit

Changing audio language during playback (Multi-audio)

DVDs can provide audio playback with different languages and different systems (Dolby Digital, DTS etc.). With DVDs featuring multiaudio recordings, you can switch between languages/audio systems during playback. ! You can select DTS audio but no sound in

reproduced.

! Multi-channel audio system can be se-

lected but the sound is reproduced in 2 channels.

1 Press AUDIO during playback.

The audio selection icon

is displayed for

eight seconds.

2 Press AUDIO while the audio selection icon is displayed.

The audio changes each time you press AUDIO.

Notes

! The number in the

package indicates the number of recorded languages/audio systems.

! With some DVDs, switching between lan-

guages/audio systems may only be possible using a menu display.

! You can also switch between languages/audio

systems using DVD setup menu. For details, refer to Setting the audio language on page 41.

mark on a DVD’s

Changing the subtitle language during playback (Multi-subtitle)

With DVDs featuring multi-subtitle recordings, you can switch between subtitle languages during playback.

1 Press SUBTITLE during playback.

The subtitle selection icon eight seconds.

is displayed for

2 Press SUBTITLE while the subtitle selection icon is displayed.

The subtitle language changes each time you press SUBTITLE.

Notes

! The number in the

age indicates the number of recorded subtitle languages.

! With some DVDs, switching between subtitle

languages may only be possible using a menu display.

! You can also switch between subtitle lan-

guages using DVD setup menu. For details, refer to Setting the subtitle language on page

40.

mark on a DVD’s pack-

Changing the viewing angle during playback (Multi-angle)

With DVDs featuring multi-angle (scenes shot from multiple angles) recordings, you can switch among viewing angles during playback.

! This function is available for DVD video. ! During playback of a scene shot from mul-

tiple angles, the angle icon played. Turn angle icon display on or off using SET-UP MENU. For details, refer to Setting the angle icon display on page 42.

1 Press ANGLE during playback of a scene shot from multiple angles.

The angle icon

and angle number are

displayed for eight seconds.

2 Press ANGLE while the angle icon and angle number are displayed.

The angle changes each time you press ANGLE.

Notes

! The

mark on a DVD’s package indicates it

features multi-angle scenes. The number in the

mark indicates the number of angles

from which scenes were shot.

is dis-

Page 21

Operating this unit

Section

! Pressing ANGLE during fast forward/fast re-

verse, pause or slow motion playback returns you to normal playback, but the viewing angle does not change.

Resume playback (Bookmark)

The Bookmark function lets you resume playback from a selected scene the next time the disc is loaded. To perform this function, set the remote control to DVD mode.

! This function is available for DVD video.

% During playback, press BOOKMARK at

the point you want to resume playback next time.

The selected scene will be bookmarked so that playback resumes from that point next time. You can bookmark up to five discs. After that, the oldest bookmark is replaced by the new one.

# To clear the bookmark on a disc, press and hold BOOKMARK during playback. # You can also bookmark a disc by pressing and holding EJECT at the point you want to bookmark. Next time you load the disc, playback will resume from the bookmarked point. Note that you can only bookmark one disc using this method. To clear the bookmark on a disc, press EJECT.

Automatic playback of DVDs

When a DVD disc with DVD menu is inserted, this unit will cancel the DVD menu automatically and start playback from the first chapter of the first title.

! This function is available for DVD video. ! Some DVDs may not operate properly. If

this function is not fully operated, turn this function off and start playback.

% Press AUTO PLAY to turn automatic playback on. A.PLAY ON is displayed.

# To turn automatic playback off, press

AUTO PLAY again.

# When the automatic playback is on, you cannot operate repeating play of DVD disc (refer to Repeating play on the next page).

CM skip/CM back

This function skips a reproduced image for a specified time. If the currently playing disc contains commercials, it is possible to skip them.

% To skip progressively backward or forward, press CM BACK or CM SKIP.

Each time you press CM BACK or CM SKIP it changes steps in the following order:

CM back

5 sec.—15 sec.—30 sec.— 1.0 min.—2.0 min.—3.0 min.

CM skip

30 sec.—1.0 min.—1.5 min.—2.0 min.—3.0 min.—5.0 min.—10.0 min. After displaying the selected option for two seconds, reproduced image skips.

# If you do not operate the function within about eight seconds, the display is automatically returned.

Return to the specified scene

You can return to the specified scene where the DVD you are currently playing has been preprogrammed to return.

! This function is available for DVD video.

% Press RETURN to return to the specified

scene.

# If a specified scene has not been preprogrammed in DVD disc, this function is not possible.

Selecting the title list

The title list lets you see the list of titles on a playing DVD-VR disc. The title list is displayed when playing DVD-VR disc with both original mode and playlist mode. You can easily select a desired title from the title list.

Operating this unit

Page 22





Section

Operating this unit

! This function is available for DVD-VR. ! You can also use the function menu to dis-

play the title name list. Titles can also be selected by using the a/b/c/d buttons on the head unit. Refer to Selecting the title list on the next page.

1 Click the thumb pad to display the list of titles.

2 Move the thumb pad up or down to change the desired title.

3 Move the thumb pad right to select the desired title.

When you select the title, that selection will begin to play.

# You can also select the title by clicking the thumb pad.

4 Press DISPLAY to return to the ordinary display.

# If you do not operate the list within about 30 seconds, the display automatically returns to the ordinary display.

Introduction of advanced operations

Following functions can be operated during playback.

For DVD video

REPEAT (repeat play)—LR SEL (audio output) —PAUSE (pause)—COMP (compression)

For DVD-VR discs

REPEAT (repeat play)—LR SEL (audio output) —PAUSE (pause)—item list—COMP (com- pression)—PLAYLIST (playlist)

# To return to the playback display, press BAND. # If you do not operate the function within about

30 seconds, the display is automatically returned to the playback display.

Repeating play

There are three repeat play ranges for the DVD playback : DSC (disc repeat), CPT (chapter repeat), and TTL (title repeat).

1 Press FUNCTION to select REPEAT.

2 Press c or d to select the repeat range.

! DSC – Repeat the current disc ! TTL – Repeat the current title ! CPT – Repeat the current chapter

# If you perform chapter search or fast forward/

reverse during CPT, the repeat play range changes to DSC. # You cannot operate repeating play when

DVD AUTO PLAY is on (refer to Automatic play- back of DVDs on the previous page).

Selecting audio output

When playing DVD video discs recorded with LPCM audio, you can switch the audio output.

1 Function display

Shows the function status.

2 RPT indicator

Shows when repeat range is selected to current chapter (title).

% Press FUNCTION to display the function names.

Press FUNCTION repeatedly to switch between the following functions:

1 Press FUNCTION to select LR SEL.

2 Press c or d to select the desired setting.

This switches you to the selected setting.

! L+R – Left and right ! L – Left ! R – Right ! MIX – mixing left and right

Page 23





Operating this unit

Section

Note

This function is possible only with Linear PCM sound.

Pausing DVD video playback

Pause lets you temporarily stop disc playback.

1 Press FUNCTION to select PAUSE.

2 Press a to turn pause on.

# To turn pause off, press b.

Selecting the title list

! This function is available for DVD-VR. ! You can also display the title name list by

clicking the thumb pad. Titles can also be selected by using the thumb pad. Refer to Selecting the title list on page 21.

1 Press FUNCTION to select the title list.

Press FUNCTION until the title list appears in the display.

2 Press a or b to scroll through the list of titles.

3 Press d to select the desired title.

When you select the title, that selection will begin to play.

2 Press a or b to select your favorite setting. COMP OFF—COMP 1—COMP 2

Selecting the play mode

You have two methods for playing DVD-VR disc; ORIGINAL (original) and PLAYLIST (playlist). ! Titles created with DVD recorders are

called original. Based on original, rearranged titles are called playlist. Playlists are created on DVD-R/RW discs.

! PLAYLIST can only be selected when a disc

that has a playlist is played.

! This function is available for DVD-VR.

1 Press FUNCTION to select the play mode. Press FUNCTION until ORIGINAL or PLAYLIST appears in the display.

2 Press c or d to select the play mode. ORIGINAL—PLAYLIST

# If the play mode is changed, playback starts from the beginning of the selected play mode.

Switching the information displays

When the separately sold display is connected to this unit, the following information will appear on it.

Operating this unit

4 Press DISPLAY to return to the ordinary display.

# If you do not operate the list within about 30 seconds, the display automatically returns to the ordinary display.

Using compression

Using the COMP (compression) function let you adjust the sound quality of disc.

1 Press FUNCTION to select COMP.

1 Disc icon 2 Media indicator 3 Title number indicator 4 Chapter number indicator 5 Play time indicator

Page 24







Section

Operating this unit

6 Variable message area

DVD video: shows the audio language, subtitle language, viewing angle, repeat range and speaker output channel. DVD-VR: shows the play mode, audio system, speaker output channel, subtitle setting and repeat range.

% Press DISPLAY to switch the information display.

Press DISPLAY repeatedly to switch between the following display modes: Information display 1—Information display 2 —Normal playback display

Playing Video CDs

Watching a Video CD

Read the precautions for discs and player on Handling guideline of discs and player on page

57.

1 Track number indicator

Shows the number of the track playing.

2 Play time indicator

Shows the elapsed playing time of the current track.

3 Media indicator

Basic operation of Video CD

1 Press NUMBER to select the desired menu option.

When a Video CD featuring the PBC (playback control) function starts playing, a menu is displayed.

! Playback starts from the selected menu

item.

! When the menu is two or more pages long,

press o or p to switch between displays.

# You can display the menu by pressing RETURN during PBC playback. For details, refer to the instructions provided with the disc. # PBC playback of Video CD cannot be cancelled. # Operation with the thumb pad is not possible.

2 To perform fast forward or reverse, press and hold m or n.

# If you continue pressing m or n for five seconds, the icon m or n is highlighted. When this happens, fast reverse/fast forward continues even if you release m or n. To resume playback at a desired point, press f.

Page 25

Operating this unit

Section

# Fast forward/fast reverse may not be possible at certain locations on some discs. If this happens, normal playback automatically resumes.

3 To skip back or forward to another track, press o or p.

Pressing p skips to the start of the next track. Pressing o once skips to the start of the current track. Pressing again will skip to the previous track. Track numbers are displayed for eight seconds.

# Using NUMBER also performs the same op- eration. For more details, refer to Specifying track on this page.

4 To stop playback, press g.

# When you stop Video CD playback by pressing

g, that location on the disc is memorized enabling playback from that point when you play the disc again.

# To resume playback, press f. # If the remote control is set to DVH, g does

not operate.

Specifying track

To perform this function, set the remote control to DVD mode. ! You cannot operate this function by using

NUMBER when the remote control is set to DVH mode.

% Press NUMBER corresponding to a desired track.

Track number is displayed for eight seconds and playback starts from the selected track.

! To select 3, press 3. ! To select 10, press 10 and 0 in that order. ! To select 23, press 10, 10 and 3 in that

order.

Notes

! With some discs, the icon

played and operation may not be possible.

! With Video CD, direct search is not possible

during PBC playback.

may be dis-

Selecting a track directly

When using the remote control, you can select a track directly by entering the desired track number. ! To perform this function, set the remote

control to DVH mode.

1 Press DIRECT.

Track number input display appears.

2 Press 0 to 9 to enter the desired track number.

! To select 3, press 3. ! To select 10, press 1 and 0 in order.

# You can cancel the input number by pressing

CLEAR.

3 Press DIRECT.

The track of entered number will play.

Notes

! After entering the number input mode, if you

do not perform an operation within about eight seconds, the mode is automatically canceled.

! During playback of Video CDs featuring PBC

(playback control), this function cannot be operated.

Pausing Video CD playback

Pause lets you temporarily stop disc playback.

% Press f during playback.

The icon e is displayed and playback is paused, letting you view a still image.

# To resume playback at the same point that you turned pause on, press f again.

Note

Depending on the disc and the playback location on the disc, the icon ing that still playback is not possible.

may be displayed, indicat-

Operating this unit

Page 26





Section

Operating this unit

Frame-by-frame playback

This lets you move ahead one frame at a time during playback.

% Press r.

Each time you press r, you move ahead one frame.

# To return to normal playback, press f.

Notes

! There is no sound during frame-by-frame play-

back.

! Depending on the disc and the playback loca-

tion on the disc, the icon indicating that frame-by-frame playback is not possible.

! With some discs, images may be unclear dur-

ing frame-by-frame playback.

! Reverse frame-by-frame playback is not possi-

ble.

may be displayed,

Slow motion playback

This lets you slow down playback speed.

1 Press r and hold during playback.

The icon playback begins.

# To return to normal playback, press f.

2 Press r or q to adjust playback speed during slow motion playback.

Each time you press r or q it changes the speed in four steps in the following order:

1/16—1/8—1/4—1/2

! There is no sound during slow motion play-

back.

! Depending on the disc and the playback loca-

tion on the disc, the icon indicating that slow motion playback is not possible.

! With some discs, images may be unclear dur-

ing slow motion playback.

! Reverse slow motion playback is not possible.

is displayed, forward slow motion

Notes

may be displayed,

Introduction of advanced operations

Following functions can be operated during playback.

1 Function display

Shows the function status.

2 RPT indicator

Shows when repeat range is selected to current track.

% Press FUNCTION to display the function names.

Press FUNCTION repeatedly to switch between the following functions:

REPEAT (repeat play)—LR SEL (audio output) —PAUSE (pause)—COMP (compression)

! During PBC (Playback Control) playback,

you cannot select REPEAT.

! To return to the playback display, press

BAND.

# If you do not operate the function within about 30 seconds, the display is automatically returned to the playback display.

Repeating play

Repeat play lets you play the same track over again. ! During playback of Video CDs featuring

PBC (playback control), this function cannot be operated.

1 Press FUNCTION to select REPEAT.

2 Press c or d to select the repeat range.

! DSC – Repeat the current disc ! TRK – Repeat the current track

# If you perform track search or fast forward/re-

verse, the repeat play range changes to DSC.

Page 27









Operating this unit

Selecting audio output

You can switch between stereo and monaural audio output.

Section

1 Press FUNCTION to select LR SEL.

2 Press c or d to select the desired setting.

This switches you to the selected setting.

! L+R – Left and right ! L – Left ! R – Right ! MIX – mixing left and right

Pausing playback

Pause lets you temporarily stop disc playback.

1 Press FUNCTION to select PAUSE.

2 Press a to turn pause on.

Playback of the current track pauses.

# To turn pause off, press b.

Using compression

Using the COMP (compression) function let you adjust the sound quality of disc.

1 Press FUNCTION to select COMP.

2 Press a or b to select your favorite setting. COMP OFF—COMP 1—COMP 2

Operating this unit

1 Disc icon 2 Media indicator 3 Track number indicator 4 Play time indicator 5 Repeat indicator 6 Speaker output channel indicator

% Press DISPLAY to switch the information display.

Press DISPLAY repeatedly to switch between the following display modes: Information display—Normal playback display

# When a Video CD featuring the PBC (playback control) function starts playing, PLAYBACK CON- TROL ON will be displayed instead of track number indicator and play time indicator.

Switching the information display

When the separately sold display is connected to this unit, the following information will appear on it.

Page 28





Section

Operating this unit

Playing DivX files

Watching a DivX

These are the basic steps necessary to play a DivX with your DVD player. More advanced DivX operation is explained starting on page

30.

1 Folder number indicator

Shows the folder number currently playing.

2 File number indicator

Shows the file number currently playing.

3 Play time indicator

Shows the elapsed playing time of the current file.

4 Media indicator

Basic Operations

1 Press a or b to select a folder.

# To return to folder 01 (ROOT), press and hold BAND. However, if folder 01 (ROOT) contains no files, playback commences with folder 02.

2 To perform fast forward or reverse, press and hold m or n.

If you continue pressing m or n for five seconds, the icon m or n is highlighted. When this happens, fast reverse/fast forward continues even if you release m or n.To resume playback at a desired point, press f.

# Fast forward/fast reverse may not be possible at certain locations on some discs. If this happens, normal playback automatically resumes. # This is fast forward and reverse operation only for the file being played. This operation is canceled when the previous or next file is reached.

3 To skip back or forward to another file, press o or p.

Pressing p skips to the start of the next file. Pressing o once skips to the start of the current file. Pressing again will skip to the previous file. Track numbers are displayed for eight seconds.

4 To stop playback, press g.

# To resume playback, press f. # If the remote control is set to DVH, g does

not operate.

Notes

! This DVD player can play back a DivX file re-

corded on CD-R/RW/ROM and DVD-R/RW/ ROM. (Refer to page 59 for files that can be played back.)

! Playback is carried out in order of file number.

Folders are skipped if they contain no files. (If folder 01 (ROOT) contains no files, playback commences with folder 02.)

! There is no sound on fast forward or reverse.

Selecting a file directly

When using the remote control, you can select a file directly by entering the desired file number. ! To perform this function, set the remote

control to DVH mode.

1 Press DIRECT.

File number input display appears.

2 Press 0 to 9 to enter the desired file number.

# You can cancel the input number by pressing

CLEAR.

3 Press DIRECT.

The file of entered number will play.

# After entering the number input mode, if you do not perform an operation within about eight seconds, the mode is automatically canceled.

Page 29

Operating this unit

Section

Playing DivX®VOD content

Some DivX VOD (video on demand) content may only be playable a fixed number of times. When you load a disc containing this type of DivX VOD content, the remaining number of plays is shown on-screen and you then have the option of playing the disc (thereby using up one of the remaining plays), or stopping. If you load a disc that contains expired DivX VOD content (for example, content that has zero remaining plays), EXPIRED is displayed. ! If your DivX VOD content allows an unlim-

ited number of plays, then you may load the disc into your player and play the content as often as you like, and no message will be displayed.

Important

! In order to play DivX VOD content on this unit,

you first need to register the unit with your DivX VOD content provider. About your registration code, refer to Displaying your DivX VOD registration code on page 44.

! DivX VOD content is protected by a DRM (Di-

gital Rights Management) system. This restricts playback of content to specific, registered devices.

% If the message is displayed after loading a disc containing DivX VOD content, press f.

Playback of the DivX VOD content will start.

# To skip to the next file, press p. # If you do not want to play the DivX VOD con-

tent, press g.

Pausing playback

Pause lets you temporarily stop disc playback.

Note

Depending on the disc and the playback location on the disc, the icon ing that still playback is not possible.

may be displayed, indicat-

Frame-by-frame playback

This lets you move ahead one frame at a time during DivX playback.

% Press r.

Each time you press r, you move ahead one frame.

# To return to normal playback, press f.

Notes

! If a DVD-VR disc contains a still image, press

r while displaying a still image to switch to the next image or video.

! There is no sound during frame-by-frame play-

back.

! Depending on the disc and the playback loca-

tion on the disc, the icon indicating that frame-by-frame playback is not possible.

! With some discs, images may be unclear dur-

ing frame-by-frame playback.

! Reverse frame-by-frame playback is not possi-

ble.

may be displayed,

Slow motion playback

When playing DivX video file, this lets you slow down playback speed.

% Press r and hold during playback.

The icon playback begins.

# To return to normal playback, press f.

is displayed, forward slow motion

Operating this unit

% Press f during playback.

The icon e is displayed and playback is paused, letting you view a still image.

# To resume playback at the same point that you turned pause on, press f again.

Notes

! There is no sound during slow motion play-

back.

Page 30





Section

Operating this unit

! Depending on the disc and the playback loca-

tion on the disc, the icon indicating that slow motion playback is not possible.

! With some discs, images may be unclear dur-

ing slow motion playback.

! Reverse slow motion playback is not possible.

may be displayed,

Changing audio language during playback (Multi-audio)

When playing a DivX video disc recorded with dialog in two or more languages, you can switch audio language during playback.

1 Press AUDIO during playback.

The audio selection icon eight seconds.

2 Press AUDIO while the audio selection icon is displayed.

The audio changes each time you press AUDIO.

Note

Pressing AUDIO during fast forward/fast reverse, pause or slow motion playback returns you to normal playback.

is displayed for

2 Move the thumb pad up or down to change the list of file names (or folder names).

3 Move the thumb pad right to select the desired file name (or folder name).

When you select a file, the selection will begin to play. When you select a folder, a list of files (or folders) in the selected folder appears in the display.

# You can also select a file name (or folder name) by clicking the thumb pad. # To return to the previous list (the folder one level higher), move the thumb pad left.

4 Press DISPLAY to return to the ordinary display.

# If you do not operate the list within about 30 seconds, the display automatically returns to the ordinary display.

Introduction of advanced operations

Following functions can be operated during playback.

Selecting files from the file name list

File name list lets you see the list of file names (or folder names) and select one of them to playback. ! You can also use the function menu to dis-

play the list of files (or folders). File can also be selected by using the a/b/c/d buttons on the head unit. Refer to Selecting files from the file name list on the next page.

1 Click the thumb pad to display the list of files (or folders).

1 Function display

Shows the function status.

2 RPT indicator

Shows when repeat range is selected to TRK or FLD.

% Press FUNCTION to display the function names.

Press FUNCTION repeatedly to switch between the following functions: REPEAT (repeat play)—PAUSE (pause)—item list—COMP (comp)

! To return to the playback display, press

BAND.

Page 31





Operating this unit

Section

# If you do not operate the function within about 30 seconds, the display is automatically returned to the playback display.

Repeating play

For DivX video file playback, there are three repeat play ranges: FLD (folder repeat), TRK (file repeat) and DSC (repeat all files).

1 Press FUNCTION to select REPEAT.

2 Press c or d to select the repeat range.

! DSC – Repeat all files ! TRK – Repeat just the current file ! FLD – Repeat the current folder

# If you perform file search or fast forward/re-

verse during TRK, the repeat play range changes to FLD. # If you select another folder during repeat play, the repeat play range changes to disc repeat. # When FLD (folder repeat) is selected, it is not possible to play back a subfolder of that folder.

Pausing playback

Pause lets you temporarily stop disc playback.

1 Press FUNCTION to select PAUSE.

2 Press a to turn pause on.

Playback of the current file pauses.

# To turn pause off, press b.

Selecting files from the file name list

File name list lets you see the list of file names (or folder names) and select one of them to playback. ! You can also display the list of files (or

folders) by clicking the thumb pad. File can also be selected by using the thumb pad. Refer to Selecting files from the file name list on the previous page.

2 Press a or b to scroll through the list of file names (or folder names).

3 Press d to select the desired file name (or folder name).

When you select a file, the selection will begin to play. When you select a folder, a list of files (or folders) in the selected folder appears in the display.

# To return to the previous list (the folder one level higher), press c.

4 Press DISPLAY to return to the ordinary display.

# If you do not operate the list within about 30 seconds, the display automatically returns to the ordinary display.

Using compression

Using the COMP (compression) function let you adjust the sound quality of disc.

1 Press FUNCTION to select COMP.

2 Press a or b to select your favorite setting. COMP OFF—COMP 1—COMP 2

Switching the information displays

When the separately sold display is connected to this unit, the following information will appear on it.

Operating this unit

1 Press FUNCTION to select a file name list.

Press FUNCTION until the names of files or folders appears in the display.

1 Disc icon

When playing a disc containing various data format, MIXED appear on it.

Page 32







Section

Operating this unit

2 Media indicator 3 Folder number indicator 4 File number indicator 5 Play time indicator 6 Audio system indecator 7 Subtitle number indicator 8 Repeat indicator

% Press DISPLAY to switch the information display.

Press DISPLAY repeatedly to switch between the following display modes: Information display—Normal playback display

Playing CDs

Listening to a CD

Read the precautions for discs and player on Handling guideline of discs and player on page

57.

1 Folder number indicator

Shows the folder number currently playing when the compressed audio is playing.

2 Track (file) number indicator 3 Play time indicator 4 Media indicator 5 MP3/WMA/AAC indicator

Shows the type of audio file currently playing when the compressed audio is playing.

Basic Operations

1 Press a or b to select a folder when playing a compressed audio.

# You cannot select a folder that does not have a compressed audio file recorded in it. # To return to folder 01 (ROOT), press and hold BAND. However, if folder 01 (ROOT) contains no files, playback commences with folder 02.

2 To perform fast forward or reverse, press and hold c or d.

# You can also perform fast forward or reverse by pressing and holding m or n on the remote control. # If you select ROUGH, pressing and holding c or d enables you to search every 10 tracks in the current folder. (Refer to Searching every 10 tracks in the current disc or folder on page 36.)

3 To skip back or forward to another track, press c or d.

# You can also skip back or forward to another track by pressing o or p on the remote control.

Page 33

Operating this unit

Section

Notes

! There is sometimes a delay between starting

up disc playback and the sound being issued. When being read, FRMT READ is displayed.

! If an error message is displayed, refer to Error

messages on page 55.

! When playing CD-EXTRA or MIXED-MODE

CDs, compressed audio and CD-DA can be switched by pressing BAND.

! If you have switched between compressed

audio and CD-DA, playback starts at the first track on the disc.

! When playing back VBR (variable bit rate) re-

corded files, elapsed play time may not be displayed correctly.

! When playing compressed audio, there is no

sound on fast forward or reverse.

! Playback is carried out in order of file number.

Folders are skipped if they contain no files. (If folder 01 (ROOT) contains no files, playback commences with folder 02.)

Pausing playback

Pause lets you temporarily stop disc playback.

% Press f during playback.

The icon e is displayed and playback is paused.

# To resume playback at the same point that you turned pause on, press f again.

Note

Depending on the disc and the playback location on the disc, the icon ing that still playback is not possible.

may be displayed, indicat-

Selecting a track directly

When using the remote control, you can select a track directly by entering the desired track number. ! To perform this function, set the remote

control to DVH mode.

! When audio files are being played back,

you can select track in the current folder.

1 Press DIRECT.

Track number input display appears.

2 Press 0 to 9 to enter the desired track number.

# You can cancel the input number by pressing

CLEAR.

3 Press DIRECT.

The track for the entered number will play.

# After entering the number input mode, if you do not perform an operation within about eight seconds, the mode is automatically canceled.

Displaying text information on disc

% Press DISPLAY to select the desired text information.

For CD TEXT discs

Track number—DISC TITLE (disc title)— DSC ARTIST (disc artist name)—TRK TITLE (track title)—TRK ARTIST (track artist name)

For WMA/MP3/AAC discs

Folder number and file number — ALBM TITLE (album title)—TRK TITLE (track title)— FLDR NAME (folder name)—FILE NAME (file name)—ART NAME (artist name)

# Elapsed play time is always shown on the display.

Notes

! You can scroll to the left of the title by pressing

and holding DISPLAY.

! Audio CD that contains certain information

such as text and/or number is CD TEXT.

! If specific information has not been recorded

on a disc, NO XXXX will be displayed (e.g., NO NAME).

! Depending on the version of Windows Media

Player used to encode WMA files, album names and other text information may not be correctly displayed.

Operating this unit

Page 34







Section

Operating this unit

! When Ever Scroll is set to ON at the initial set-

ting, text information scrolls continuously in the display. Refer to Switching the ever scroll on page 47.

Selecting tracks from the track title list

Track title list lets you see the list of track titles on a CD TEXT disc and select one of them to play back. ! You can also use the function menu to dis-

play the track name list. Tracks can also be selected by using a/b/c/d buttons on the head unit. Refer to Selecting tracks from the list on the next page.

1 Click the thumb pad to display the list of track titles.

2 Move the thumb pad up or down to change the desired track title.

3 Move the thumb pad right to select the desired track title.

When you select a track, the selection will begin to play.

# You can also select the track by clicking the thumb pad.

2 Move the thumb pad up or down to change the list of file names (or folder names).

3 Move the thumb pad right to select the desired file name (or folder name).

When you select a file, the selection will begin to play. When you select a folder, a list of files (or folders) in the selected folder appears in the display.

# You can also select a file name (or folder name) by clicking the thumb pad. # To return to the previous list (the folder one level higher), move the thumb pad left.

4 Press DISPLAY to return to the ordinary display.

Introduction of advanced operations

Following functions can be operated during playback.

4 Press DISPLAY to return to the ordinary display.

Selecting tracks from the file name list

File name list lets you see the list of file names (or folder names) and select one of them to playback. ! You can also use the function menu to dis-

play the list of files (or folders). File can also be selected by using the a/b/c/d buttons on the head unit. Refer to Selecting tracks from the list on the next page.

1 Click the thumb pad to display the list of files (or folders).

1 Function display

Shows the function status.

2 RPT indicator

Shows when repeat range is selected to TRK or FLD.

3 RDM indicator

Shows when random play is on.

% Press FUNCTION repeatedly to switch between the following functions: REPEAT (repeat play)—RANDOM (random

play)—SCAN (scan play)—PAUSE (pause)— item list—SCH (search method)—COMP (compression)

# To return to the ordinary display, press BAND.

Page 35

Operating this unit

Section

Selecting a repeat play range

Repeat play plays the same track/folder within the selected repeat play range. Also, the repeat range determines the range of random play and scan play.

1 Press FUNCTION to select REPEAT.

2 Press c or d to select the repeat range.

! DSC – Repeat all tracks ! TRK – Repeat the current track ! FLD – Repeat the current folder

# If you select another folder during repeat play,

the repeat play range changes to disc repeat. # When playing CD, performing track search or fast forward/reverse cancels the repeat play automatically. # When playing compressed audio, performing track search or fast forward/reverse during TRK (track repeat) changes the repeat play range to folder repeat. # When FLD (folder repeat) is selected, it is not possible to play back a subfolder of that folder.

Playing tracks in random order

Tracks in a selected repeat range are played in random order. Refer to Repeating play on page 22.

1 Press FUNCTION to select RANDOM.

2 Press a to turn random play on.

Tracks play in a random order.

# To turn random play off, press b.

Scanning folders and tracks

Scan play searches the song within the selected repeat range. Refer to Repeating play on page 22.

1 Press FUNCTION to select SCAN.

2 Press a to turn scan play on.

The first 10 seconds of each track is played.

3 When you find the desired track (or folder) press b to turn scan play off.

# If the display has automatically returned to the playback display, select SCAN again by pressing FUNCTION. # After scanning of a disc (folder) is finished, normal playback of the tracks begins.

Pausing disc playback

1 Press FUNCTION to select PAUSE.

2 Press a to turn pause on.

Playback of the current track pauses.

# To turn pause off, press b. # Press f on the remote control repeatedly

during playback to turn pause on or off.

Selecting tracks from the list

For CD TEXT discs

! You can also display the track name list by

clicking the thumb pad. Tracks can also be selected by using the thumb pad. Refer to Selecting tracks from the track title list on the previous page.

1 Press FUNCTION to select the track title list.

Press FUNCTION until the track title list appears in the display.

2 Press a or b to scroll through the list of track

titles.

3 Press d to select the desired track title.

When you select a track, the selection will begin to play.

4 Press DISPLAY to return to the ordinary dis-

play.

For WMA/MP3/AAC discs

! You can also display the list of files (or

folders) by clicking the thumb pad. File can also be selected by using the thumb pad. Refer to Selecting tracks from the file name list on the previous page.

1 Press FUNCTION to select a file name list.

Press FUNCTION until the names of files or folders appears in the display.

2 Press a or b to scroll through the list of file

names (or folder names).

Operating this unit

Page 36





Section

Operating this unit

3 Press d to select the desired file name (or

folder name). When you select a file, the selection will begin to play. When you select a folder, a list of files (or folders) in the selected folder appears in the display.

! To return to the previous list (the folder

one level higher), press c.

4 Press DISPLAY to return to the ordinary dis-

play.

Searching every 10 tracks in the current disc or folder

You can switch the search method between fast forward/reverse and searching every 10 tracks. Selecting ROUGH enables you to search every 10 tracks.

1 Press FUNCTION to select SCH.

2 Press d to select ROUGH.

! FF/REV – Fast forward and reverse ! ROUGH – Searching every 10 tracks

# To select FF/REV, press c.

3 Press BAND to return to the playback display.

Displaying the information display

When the separately sold display is connected to this unit, the following information will appear on it. ! The information display is always shown on

the separately sold display.

1 Disc icon

When playing a disc containing various data format, MIXED appear on it.

2 Media indicator 3 Folder number indicator 4 Track (file) number indicator 5 Play time indicator 6 Repeat indicator 7 Random indicator 8 Scan indicator

4 Press and hold c or d to search every 10 tracks on a disc (folder).

# If the rest of track number is less than 10, press and hold c or d recalls the first (last) one.

Using compression

Using the COMP (compression) function let you adjust the sound quality of disc.

1 Press FUNCTION to select COMP.

2 Press a or b to select your favorite setting. COMP OFF—COMP 1—COMP 2

Page 37





Operating this unit

Section

Audio Adjustments

Introduction of audio adjustments

1 Audio display

Shows the audio adjustment status.

2 BASS indicator

Shows when the bass boost is in effect.

3 LOUD indicator

Appears in the display when loudness is turned on.

4 SW indicator

Shows when the subwoofer output is turned on.

% Press AUDIO to display the audio function names.

Press AUDIO repeatedly to switch between the following audio functions: FADER (balance adjustment)—PWRFL (graphic equalizer adjustment)—50HZ 0 (7-band graphic equalizer adjustment)—LOUD (loudness)—SUB.W (subwoofer on/off setting)— 80HZ 0 (subwoofer setting)—BASS (bass boost)—HPF (high pass filter)—SLA (source level adjustment)

# When the rear output setting is R-SP S/W, you cannot adjust front/rear speaker balance. Refer to

Setting the rear output and subwoofer controller

on page 46. # You can select 80HZ 0 (subwoofer setting) only when subwoofer output is turned on in SUB.W (subwoofer on/off setting). # When the subwoofer controller setting is P/O FULL, you cannot switch to SUB.W (subwoofer on/off setting). (Refer to page 46.) # When selecting FM as the source, you cannot switch to SLA. # To return to the display of each source, press BAND.

# If you do not operate the audio function within about 30 seconds, the display is automatically returned to the source display.

Using balance adjustment

You can change the fader/balance setting so that it can provide the ideal listening environment in all occupied seats.

1 Press AUDIO to select FADER.

# If the balance setting has been previously adjusted, BAL will be displayed.

2 Press a or b to adjust front/rear speaker balance. FADER F15 to FADER R15 is displayed as the

front/rear speaker balance moves from front to rear.

# FADER 0 is the proper setting when only two speakers are used.

3 Press c or d to adjust left/right speaker balance. BAL L15 to BAL R15 is displayed as the left/

right speaker balance moves from left to right.

Using the equalizer

The equalizer lets you adjust the equalization to match the car’s interior acoustic characteristics as desired.

Recalling equalizer curves

There are seven stored equalizer curves which you can easily recall at any time. Here is a list of the equalizer curves.

Display Equalizer curve

POWERFUL (PWRFL) Powerful

NATURAL Natural

VOCAL Vocal

CUSTOM 1 Custom 1

CUSTOM 2 Custom 2

Operating this unit

Page 38

Section

Operating this unit

EQ FLAT Flat

SUPER BASS (S-BASS) Super bass

! CUSTOM 1 and CUSTOM 2 are adjusted

equalizer curves that you create. Adjustments can be made with a 7-band graphic equalizer.

! When EQ FLAT is selected, no supplement

or correction is made to the sound. This is useful to check the effect of the equalizer curves by switching alternatively between EQ FLAT and a set equalizer curve.

% Press EQ to select the equalizer.

Press EQ repeatedly to switch between the following equalizers:

POWERFUL (PWRFL)—NATURAL—VOCAL— CUSTOM 1—CUSTOM 2—EQ FLAT— SUPER BASS (S-BASS)

Adjusting equalizer curves

The factory supplied equalizer curves, with the exception of EQ FLAT, can be adjusted to a fine degree (nuance control).

1 Press AUDIO to select PWRFL. PWRFL appears in the display.

If the equalizer curve has been previously selected, the curve of that previously selected will be displayed instead of PWRFL.

2 Press c or d to select an equalizer curve.

3 Press a or b to adjust the equalizer curve.

Each press of a or b increases or decreases the equalizer curve respectively. +6 to –4 (or –6) is displayed as the equalizer curve is increased or decreased.

# The actual range of the adjustments are different depending on which equalizer curve is selected. # The equalizer curve with all frequencies set to 0 cannot be adjusted.

Adjusting 7-band graphic equalizer

For CUSTOM 1 and CUSTOM 2 equalizer curves, you can adjust the level of each band. ! A separate CUSTOM 1 curve can be cre-

ated for each source. If you make adjustments when a curve other than CUSTOM 2 is selected, the equalizer curve settings will be memorized in CUSTOM 1.

! A CUSTOM 2 curve can be created com-

mon to all sources. If you make adjustments when the CUSTOM 2 curve is selected, the CUSTOM 2 curve will be updated.

1 Recall the equalizer curve you want to adjust.

See Recalling equalizer curves on the previous page.

2 Press AUDIO to select 7-band graphic equalizer adjustment.

Frequency and the level (e.g., 50HZ 0) appears in the display.

3 Press c or d to select the equalizer band to adjust.

Each press of c or d selects equalizer bands in the following order:

50HZ—125HZ—315HZ—800HZ—2KHZ— 5KHZ—12.5KHZ

4 Press a or b to adjust the level of the equalizer band.

Each press of a or b increases or decreases the level of the equalization band. +6 to –6 is displayed as the level is increased or decreased.

# You can then select another band and adjust the level.

5 Press BAND to cancel the 7-band graphic equalizer adjustment.

Adjusting loudness

Loudness compensates for deficiencies in the low- and high-sound ranges at low volume.

Page 39

Operating this unit

Section

1 Press AUDIO to select LOUD.

2 Press a to turn loudness on.

Loudness level (e.g., LOUD MID) appears in the display.

# To turn loudness off, press b.

3 Press c or d to select a desired level. LOW (low)—MID (mid)—HIGH (high)

Using subwoofer output

This unit is equipped with a subwoofer output which can be turned on or off.

1 Press SW to select SUB.W.

# You can also select the subwoofer setting menu by pressing AUDIO on the unit.

2 Press a to turn subwoofer output on. SUB.W NOR appears in the display. Subwoo-

fer output is now on.

# If the subwoofer output phase has been set to the reverse, SUB.W REV will be displayed. # To turn subwoofer output off, press b.

3 Press c or d to select the phase of subwoofer output.

Press c to select reverse phase and REV appears in the display. Press d to select normal phase and NOR appears in the display.

Adjusting subwoofer settings

When the subwoofer output is on, you can adjust the cut-off frequency and the output level of the subwoofer.

1 Press SW to select 80HZ 0.

# You can also select the subwoofer setting menu by pressing AUDIO on the unit. # When the subwoofer output is on, you can select 80HZ 0 (subwoofer setting).

3 Press a or b to adjust the output level of the subwoofer. +6 to –24 is displayed as the level is increased

or decreased.

Operating this unit

Boosting the bass

Bass boost function boosts the bass level of sound.

1 Press AUDIO to select BASS.

# You can also select the bass boost setting by pressing and holding SW.

2 Press a or b to select a desired level. 0 to +6 is displayed as the level is increased or

decreased.

Using the high pass filter

When you do not want low sounds from the subwoofer output frequency range to play from the front or rear speakers, turn on the HPF (high pass filter). Only frequencies higher than those in the selected range are output from the front or rear speakers.

1 Press AUDIO to select HPF.

2 Press a to turn high pass filter on. HPF 80HZ appears in the display. High pass

filter is now on.

# If the high pass filter has been previously adjusted, the frequency of that previously selected will be displayed instead of HPF 80HZ. # To turn high pass filter off, press b.

3 Press c or d to select cut-off frequency. 50HZ—63HZ—80HZ—100HZ—125HZ

Only frequencies higher than those in the selected range are outputted from the front or rear speakers.

2 Press c or d to select cut-off frequency. 50HZ—63HZ—80HZ—100HZ—125HZ

Only frequencies lower than those in the selected range are outputted from the subwoofer.

Page 40



Section

Operating this unit

Adjusting source levels

SLA (source level adjustment) lets you adjust the volume level of each source to prevent radical changes in volume when switching between sources. ! Settings are based on the FM volume level,

which remains unchanged.

1 Compare the FM volume level with the level of the source you wish to adjust.

2 Press AUDIO to select SLA.

3 Press a or b to adjust the source volume. SLA +4 to SLA –4 is displayed as the source

volume is increased or decreased.

Notes

! The AM volume level can also be adjusted

with source level adjustments.

! Video CD, CD, compressed audio and DivX

are set to the same source level adjustment volume automatically.

! External unit 1 and external unit 2 are set to

the same source level adjustment volume automatically.

Setting up the DVD player

Introduction of DVD setup adjustments

You can use this menu to change audio, subtitle, parental lock and other DVD settings. This menu can be operated only by using the remote control. ! To perform this function, set the remote

control to DVD mode.

1 DVD setup menu display

Shows the DVD setup menu names.

1 Press g.

2 Press MENU when the disc is stopped.

The DVD setup menu is displayed.

3 Move the thumb pad up or down to display the DVD setup function names.

Move the thumb pad up or down to switch the following DVD setup functions:

S.TTL LANG (subtitle language settings)— AUDIO LANG (audio language settings)— MENU LANG (menu language settings)— ASSIST (assist subtitle)—ANGLE (angle icon)

—TV ASPECT (TV aspect)—PARENTAL (paren- tal lock)—DIVX VOD (DivX VOD)— DIVX S.TTL (DivX subtitle)—DIGI OUT (digital output setting)

Note

If you press MENU during display of a DVD setup menu, the DVD setup menu is canceled and the unit returns to the previous display.

Setting the subtitle language

You can set a desired subtitle language. If the selected subtitle language is recorded on the DVD, subtitles are displayed in that language.

Page 41

Operating this unit

Section

1 Move the thumb pad up or down to select S.TTL LANG.

2 Click the thumb pad.

A subtitle language menu is displayed.

3 Move the thumb pad left or right to select the desired language.

4 Click the thumb pad.

A subtitle language is set.

Notes

! If the selected language is not recorded on

the disc, the language specified on the disc is displayed.

! You can also switch the subtitle language dur-

ing playback with SUBTITLE. (Refer to Chan-

ging the subtitle language during playback (Multi-subtitle) on page 20.)

! Even if you use SUBTITLE to switch the subti-

tle language, this does not affect the settings here.

! Pressing RETURN takes you back to the pre-

vious display.

When you select OTHERS

When you select OTHERS, a language code input display is shown. Refer to Language code chart for DVD on page 61, use the number buttons to input the four digit code of the desired language, and then move the thumb pad right.

Note

Pressing CLEAR cancels the input numbers.

3 Move the thumb pad left or right to select the desired audio language.

4 Click the thumb pad.

The audio language is set.

Notes

! If the selected language is not recorded on

the disc, the language specified on the disc is outputted.

! You can also switch the audio language dur-

ing playback with AUDIO. (Refer to Changing

audio language during playback (Multi-audio)

on page 20.)

! Even if you use AUDIO to switch the audio

language, this does not affect the settings here.

! Pressing RETURN takes you back to the pre-

vious display.

! If you have selected OTHERS, refer to When

you select OTHERS on this page.

Setting the menu language

You can set the preferred language for displays of menus recorded on a disc.

1 Move the thumb pad up or down to select MENU LANG.

2 Click the thumb pad.

A menu language menu is displayed.

3 Move the thumb pad left or right to select the desired menu language.

4 Click the thumb pad.

The menu language is set.

Operating this unit

Setting the audio language

You can set the preferred audio language.

1 Move the thumb pad up or down to select AUDIO LANG.

2 Click the thumb pad.

An audio language menu is displayed.

Notes

! If the selected language is not recorded on

the disc, the language specified on the disc is outputted.

! Pressing RETURN takes you back to the pre-

vious display.

! If you have selected OTHERS, refer to When

you select OTHERS on this page.

Page 42

Section

Operating this unit

Switching the assist subtitle on or off

If assist subtitles are recorded on a DVD disc, you can display them by turning the assist subtitle function on. You can turn assist subtitles on or off as desired.

1 Move the thumb pad up or down to select ASSIST.

2 Click the thumb pad.

3 Move the thumb pad left or right to select on or off.

Each time you move the thumb pad left or right the selected setting switches on or off.

4 Click the thumb pad.

The assist subtitle is set on or off.

Note

Pressing RETURN takes you back to the previous display.

Setting the angle icon display

You can set it up so that the angle icon appears on scenes where the angle can be switched.

1 Move the thumb pad up or down to select ANGLE.

2 Click the thumb pad.

3 Move the thumb pad left or right to select on or off.

Each time you move the thumb pad left or right the selected setting switches on or off.

4 Click the thumb pad.

Angle icon display is set on or off.

Note

Pressing RETURN takes you back to the previous display.

Setting the aspect ratio

There are two kinds of display. A wide screen display has a width-to-height ratio (TV aspect) of 16:9, while a regular display has a TV aspect of 4:3. Be sure to select the correct TV aspect for the display you use. ! When using a regular display, select either

LETTER BOX or PANSCAN. Selecting 16:9 may result in an unnatural picture.

1 Move the thumb pad up or down to select TV ASPECT.

2 Click the thumb pad.

TV aspect menu is displayed.

3 Move the thumb pad left or right to select the desired TV aspect.

! 16:9 – Wide screen picture (16:9) is dis-

played as it is (initial setting)

! LETTER BOX – The picture is the shape of a

letterbox with black bands at the top and bottom of the screen

! PANSCAN – The picture is cut short at the

right and left of the screen

4 Click the thumb pad.

The selected TV aspect is set.

Notes

! When playing discs that do not specify

PANSCAN, playback is with LETTER BOX even if you select PANSCAN setting. Confirm whether the disc package bears the mark. (See page 8.)

! Some discs do not enable changing of the TV

aspect. For details, refer to the disc’s instructions.

! Pressing RETURN takes you back to the pre-

vious display.

16 : 9 LB

Setting the parental lock

Some DVD video discs let you use parental lock to restrict children from viewing violent and adult-oriented scenes. You can set the parental lock to your desired level.

Page 43

Operating this unit

Section

! When you set a parental lock level and then

play a disc featuring parental lock, code number input indications may be displayed. In this case, playback will begin when the correct code number is input.

Setting the code number and level

You need to have registered a code number for playing back discs with parantal lock. ! We recommend to keep a record of your

code number in case you forget it.

1 Move the thumb pad up or down to select PARENTAL.

2 Click the thumb pad.

Parental lock setting menu is displayed.

3 Press 0 to 9 to input a four digit code number.

4 Move the thumb pad left or right to move the cursor to the previous or next position.

5 Move the cursor to the last position by moving the thumb pad right after entering the four digit code number.

The code number is set, and you can now set the level.

6 Move the thumb pad left or right to select the desired level.

! LEVEL 8 – Playback of the entire disc is pos-

sible (initial setting)

! LEVEL 7 to LEVEL 2 – Playback of discs for

children and non-adult-oriented discs is possible

! LEVEL 1 – Playback of discs for children

only is possible

7 Click the thumb pad.

The parental lock level is set.

Notes

! The parental lock level is recorded on the disc.

Look for the level indication written at the disc package, included literature or on the disc itself. Parental lock of this unit is not possible if

a parental lock level is not recorded in the disc.

! With some discs, the parental lock may be ac-

tive only on the scenes with certain levels. The playback of those scenes will be skipped. For details, refer to the instruction manual that came with the discs.

! Pressing RETURN takes you back to the pre-

vious display.

Changing the level

You can change the set parental lock level.

1 Move the thumb pad up or down to select PARENTAL.

2 Click the thumb pad.

Parental lock setting menu is displayed.

3 Press 0 to 9 to input the registered code number.

4 Move the thumb pad left or right to move the cursor to the previous or next position.

5 Move the cursor to the last position by moving the thumb pad right after entering the four digit code number.

This enters the code number, and you can now change the level.

# If you input an incorrect code number, the

is displayed. Press CLEAR and input the

icon correct code number.

# If you forget your code number, refer to If you forget your code number on the next page.

6 Move the thumb pad left or right to select the desired level.

7 Click the thumb pad.

The parental lock level is set.

Note

Pressing RETURN takes you back to the previous display.

Operating this unit

Page 44

Section

Operating this unit

If you forget your code number

Refer to Changing the level on the previous page, and press CLEAR 10 times. The registered code number is canceled, letting you register a new one.

Displaying your DivX®VOD registration code

In order to play DivX VOD (video on demand) content on this unit, you first need to register the unit with your DivX VOD content provider. You do this by generating a DivX VOD registration code, which you submit to your provider.

1 Move the thumb pad up or down to select DIVX VOD.

2 Click the thumb pad.

Your 8-digit registration code is displayed.

! Make a note of the code as you will need it

when you register with a DivX VOD provider.

Note

Pressing RETURN takes you back to the previous display.

Setting the DivX subtitle file

You can select whether to display DivX external subtitles or not. ! DivX subtitles will be displayed even when

this setting is on if no DivX external subtitle files exist.

1 Move the thumb pad up or down to select DIVX S.TTL.

2 Click the thumb pad.

3 Move the thumb pad left or right to select on or off.

! ON – Display the DivX external subtitles ! OFF – Display the DivX subtitles

4 Click the thumb pad.

DivX subtitle is set on or off.

Notes

! Up to 42 characters can be displayed on one

line. If more than 42 characters are set, the line breaks and the characters are displayed on the next line.

! Up to 126 characters can be displayed on one

screen. If more then 126 characters are set, the excess characters will not be displayed.

! Pressing RETURN takes you back to the pre-

vious display.

Setting for digital output

When the Pioneer multi-channel processor (DEQ-P7650) and the Pioneer audio master unit (AXM-P7650) are connected to this unit, operate this function.

Audio which is outputted from digital output of this unit can be selected. Normally, set to STREAM. If this unit’s digital output is not used, there is no need to change settings. ! Selecting LPCM enables you to switch the

output channel if playing the following type of discs. (Refer to Selecting audio output on page 22.)

— Dual mono mode DVD video discs — Bilingual DVD-VR discs

1 Move the thumb pad up or down to select DIGI OUT.

2 Click the thumb pad.

The digital output setting is displayed.

3 Move the thumb pad left or right to select the desired digital output setting.

! STREAM – The Dolby Digital/DTS signal is

output as it is (initial setting)

! LPCM – The Dolby Digital/DTS signal is con-

verted to and output as a linear PCM signal

4 Click the thumb pad.

The selected digital output setting is determined.

Note

Pressing RETURN takes you back to the previous display.

Page 45



Operating this unit

Section

Initial Settings

Adjusting initial settings

Using the initial settings, you can customize various system settings to achieve optimal performance from this unit.

1 Function display

Shows the function status.

1 Press SOURCE and hold until the unit turns off.

2 Press FUNCTION and hold until function name appears in the display.

3 Press FUNCTION to select one of the initial settings.

Press FUNCTION to select one of the initial settings. CLOCK AJST (clock)—FM STP (FM tuning step)—AM STP (AM tuning step)—WARN (warning tone)—AUX1 (auxiliary input1)— AUX2 (auxiliary input2)—V.IN (AV input setting)—R-SP (rear output and subwoofer controller)—E-SCRL (ever scroll)

# To cancel initial settings, press BAND. # You can also cancel initial settings by holding

down FUNCTION until the unit turns off.

Setting the FM tuning step

The FM tuning step employed by seek tuning can be switched between 100 kHz, the preset step, and 50 kHz.

1 Press FUNCTION to select FM STP.

2 Press c or d to select the FM tuning step.

Press c to select 50 (50 kHz). Press d to select 100 (100 kHz).

Note

If seek tuning is performed in 50 kHz steps, stations may be tuned in imprecisely. Tune in the stations with manual tuning or use seek tuning again.

Setting the AM tuning step

The AM tuning step can be switched between 9 kHz, the preset step, and 10 kHz. When using the tuner in North, Central or South America, reset the tuning step from 9 kHz (531 kHz to 1 602 kHz allowable) to 10 kHz (530 kHz to 1 640 kHz allowable).

1 Press FUNCTION to select AM STP.

2 Press c or d to select the AM tuning step. Press c to select 9 (9 kHz). Press d to select 10 (10 kHz).

Operating this unit

Setting the clock

Use these instructions to set the clock.

1 Press FUNCTION to select CLOCK AJST.

2 Press c or d to select the segment you wish to set.

Hour—Minute As you select segments of the clock display, the selected segment blinks.

3 Press a or b to set the clock.

Pressing a will increase the value of the selected segment. Pressing b will decrease the value of the selected segment.

Switching the warning tone

If the front panel is not detached from the head unit within five seconds of turning off the ignition, a warning tone will sound. You can turn off the warning tone.

1 Press FUNCTION to select WARN.

2 Press a or b to turn WARN on or off.

Page 46

Section

Operating this unit

Switching the auxiliary setting

Auxiliary devices connected to this unit can be activated individually. Set each AUX source to ON when using. For more information about connecting or using auxiliary devices, refer to Using the AUX source on the next page.

Switching the auxiliary 1 setting

1 Press FUNCTION to select AUX1.

2 Press c or d to select desired setting.

! VIDEO – an iPod with video capabilities

connected with 4-pole mini plug cable (e.g., CD-V150M)

! AUDIO – auxiliary device connected with

stereo mini plug cable

! OFF – No auxiliary device is connected

Switching the auxiliary 2 setting

1 Press FUNCTION to select AUX2.

2 Press a or b to turn AUX2 on or off.

Setting the AV input

You can connect AV components to the AV input with an RCA cable. Switch the AV input setting according to the connected AV component. For more details, refer to the installation manual. ! Select EXT-V to watch video of a connected

video unit as EXTERNAL source.

! Select AUX to watch video of an auxiliary

device as AUX2 source.

1 Press FUNCTION to select V.IN.

2 Press c or d to select your desired setting.

! OFF – No video component connected ! EXT-V – External video unit ! AUX – Auxiliary device

# To watch video of AUX source, set auxiliary 2

setting on. For details, refer to Switching the auxiliary setting on this page.

Setting the rear output and subwoofer controller

This unit’s rear output (rear speaker leads output and RCA rear output) can be used for fullrange speaker (R-SP FULL) or subwoofer (R-SP S/W) connection. If you switch the rear output setting to R-SP S/W, you can connect a rear speaker lead directly to a subwoofer without using an auxiliary amp. Initially, the unit is set for rear full-range speaker connection (R-SP FULL). When rear output is connected to full range speakers (when R-SP FULL is selected), you can connect other full range speakers (P/O FULL) or a subwoofer (P/O S/W) to the RCA rear output.

1 Press FUNCTION to select R-SP.

2 Press a or b to switch the rear output setting.

Pressing a or b will switch between R-SP FULL (full-range speaker) and R-SP S/W (subwoofer) and that status will be displayed.

# When no subwoofer is connected to the rear output, select R-SP FULL. # When a subwoofer is connected to the rear output, set for subwoofer R-SP S/W. # When the rear output setting is R-SP S/W, you cannot operate the following procedure.

3 Press c or d to switch the subwoofer output or rear output.

Pressing c or d will switch between P/O S/W and P/O FULL and that status will be displayed.

Notes

! Even if you change this setting, there is no

output unless you turn the subwoofer output on (refer to Using subwoofer output on page

39).

! If you change this setting, subwoofer output

in the audio menu return to the factory settings.

Page 47

Operating this unit

Section

Switching the ever scroll

When Ever Scroll is set to ON, recorded text information scrolls continuously in the display. Set to OFF if you prefer the information to scroll just once.

1 Press FUNCTION to select E-SCRL.

2 Press a or b to turn E-SCRL on or off.

Other Functions

Turning the clock display on or off

You can turn the clock display on or off.

Operating this unit

% Press CLOCK to turn the clock display on or off.

Each press of CLOCK turns the clock display on or off.

# The clock display disappears temporarily when you perform other operations, but the clock display appears again after 25 seconds.

Setting the level indicator

Level indicators can be changed. Style of the level indicator differs depending on the source.

% Press EQ and hold to select the level indicator.

Press EQ and hold repeatedly to switch between the following settings: Level indicator 1—Level indicator 2—Entertainment—off

Using the AUX source

A separately sold auxiliary device such as VCR or portable device can be connected to this unit. When connected, auxiliary device is automatically recognized as AUX source and assigned to AUX.

About AUX connection method

There are two methods to connect auxiliary devices to this unit.

Mini pin plug cable (AUX1)

When connecting auxiliary device using a mini plug cable

iPod and portable audio/video player can be connected to this unit via mini plug cable.

Page 48

Section

Operating this unit

! If an iPod with video capabilities is con-

nected to this unit via 3.5 mm plug (4 pole) cable (e.g., CD-V150M), you can enjoy the video contents of the iPod.

! It is possible to connect a portable audio/

video player by using a 3.5 mm plug (4 pole) to RCA cable, which is sold separately. However, depending on the cable, reverse connection between Red (right side audio) cable and yellow (video) cable is required. Otherwise, audio and video may not be correctly reproduced.

% Insert the mini plug into the AUX input jack on this unit.

IP-BUS-RCA interconnector (AUX2)

When connecting auxiliary device using an IPBUS-RCA Interconnector (sold separately)

% Use an IP-BUS-RCA Interconnector such as the CD-RB20/CD-RB10 (sold separetely) to connect this unit to auxiliary device featuring RCA output.

For more details, refer to the IP-BUS-RCA Interconnector owner’s manual.

# You can only make this type of connection if the auxiliary device has RCA outputs.

Selecting AUX as the source

% Press SOURCE to select AUX (AUX1 or AUX2) as the source.

# If the auxiliary setting is not turned on, AUX cannot be selected. For more details, see Switch- ing the auxiliary setting on page 46.

2 Press a or b to select a letter of the alphabet.

Each press of a will display alphabet, numbers or symbols in ascending order (A B C ...). Each press of b will display a letter in descending order.

3 Press d to move the cursor to the next character position.

When the letter you want is displayed, press d to move the cursor to the next position and then select the next letter. Press c to move backwards in the display.

4 Move the cursor to the last position by pressing d after entering the title.

When you press d one more time, the entered title is stored in memory.

5 Press BAND to return to the playback display.

Using the external unit

External unit refers to a Pioneer product (such as ones available in the future) that, although incompatible as a source, enables control of basic functions with this unit. Two external units can be controlled with this unit. When two external units are connected, the external unit is automatically allocated to external unit 1 or external unit 2 by this unit. Basic operations of the external unit are explained below. Allocated functions are different depending on the connected external unit. For details concerning functions, refer to external unit’s owner’s manual.

Setting the AUX title

The title displayed for the AUX1 or AUX2 source can be changed.

1 After you have selected AUX as the source, press FUNCTION and hold until TITLE IN appears in the display.

Selecting the external unit as the source

% Press SOURCE to select EXTERNAL as the source.

Page 49

Operating this unit

Section

Basic operation

Functions allocated to the following operations are different depending on the connected external unit. For details concerning functions, refer to the connected external unit’s owner’s manual.

% Press BAND.

% Press and hold BAND.

% Press c or d.

% Press and hold c or d.

% Press a or b.

Using the functions allocated to 1 to 6 keys

% Press any of 1 to 6 buttons.

Advanced operations

% Press FUNCTION repeatedly to switch between the following functions: FUNC1 (function 1)—FUNC2 (function 2)— FUNC3 (function 3)—FUNC4 (function 4)— AUTO/MANUAL (auto/manual)

# You can also select the function by pressing

FUNCTION on the remote control. # You can also turn FUNC1 on or off by pressing BOOKMARK on the remote control.

# To return to the ordinary display, press BAND.

% Press BOOKMARK and hold to turn

BSM on when selecting TUNER as the source.

Press BOOKMARK and hold until the BSM turns on.

# To cancel the storage process, press BOOKMARK again.

% Press BOOKMARK and hold to turn BSSM on when selecting TV as the source.

Press BOOKMARK and hold until the BSSM turns on.

# To cancel the storage process, press BOOKMARK again.

Sound muting

Sound from this unit is muted automatically in the following cases: ! When a call is made or received using a

cellular telephone connected to this unit.

! When the voice guidance is output from a

Pioneer navigation unit connected to this unit.

The sound is turned off, MUTE is displayed and no audio adjustments, except volume control, are possible. Operation returns to normal when the phone connection or the voice guidance is ended.

Operating this unit

Using the PGM button

You can operate the preprogrammed functions for each source by using BOOKMARK.

% Press BOOKMARK to turn pause on when selecting the following sources:

! DVD – Built-in DVD player ! MULTI CD – Multi-CD player

# To turn pause off, press BOOKMARK again.

Page 50









Section

Available accessories

Multi-CD Player

Basic Operations

You can use this unit to control a multi-CD player, which is sold separately. ! Only functions described in this manual are

supported by 50-disc multi-CD players.

! This unit is not designed to operate disc title

list functions with a 50-disc multi-CD player. For information about the disc title list functions, refer to Selecting discs from the disc title list on page 53.

1 Disc number indicator 2 Track number indicator 3 Play time indicator

1 Press SOURCE to select the multi-CD player.

2 Press a or b to select a disc you want to listen to.

# You can also select a disc by using 1 to 6 but- tons.

! For discs 1 to 6, press the corresponding

button number.

! For discs 7 to 12, press and hold the corre-

sponding numbers, such as 1 for disc 7, until the disc number appears in the display.

3 To perform fast forward or reverse, press and hold c or d.

4 To skip back or forward to another track, press c or d.

Notes

! When multi-CD player completes preparatory

operations, READY is displayed.

! If an error message such as

ERROR 02- (ERROR-02-)XX is displayed, refer to the multi-CD player owner’s manual.

! If there are no discs in the multi-CD player ma-

gazine, NO DISC is displayed.

Selecting a track directly

The operation is the same as that of the builtin DVD player. For details concerning operation, refer to Se- lecting a track directly on page 33.

Introduction of advanced operations

You can only use COMP (compression and DBE) with a multi-CD player that supports them.

1 Function display

Shows the function status.

2 RDM indicator

Shows when random play is on.

3 RPT indicator

Shows when repeat range is selected to TRK or DSC.

Function mode 1

% Press FUNCTION repeatedly to switch between the following functions: REPEAT (repeat play)—TITLE LIST (disc title

list)—RANDOM (random play)—SCAN (scan play)—ITS (ITS play)—PAUSE (pause)—COMP (compression and DBE)

# To return to the playback display, press BAND. # If you do not operate the function within about

30 seconds, the display is automatically returned to the playback display.

Function mode 2

% Press FUNCTION and hold repeatedly to switch between the following functions: TITLE IN (disc title input)—ITS (ITS program-

ming)

# To return to the playback display, press BAND.

Page 51

Available accessories

Section

Function and operation

REPEAT, RANDOM, SCAN, PAUSE, COMP and TITLE IN operations are basically the same as that of the built-in DVD player.

Function name Operation

Refer to Repeating play on page 22. However, the repeat play ranges you can select are different from that of the built-in DVD player. The

REPEAT

TITLE LIST

RANDOM

SCAN

ITS

PAUSE

COMP

TITLE IN

ITS

repeat play ranges of the multi-CD player are: ! MCD – Repeat all discs in the

multi-CD player

! TRK – Repeat just the current

track

! DSC – Repeat the current disc

Refer to Selecting discs from the disc title list on page 53.

Refer to Playing tracks in random order on page 35.

Refer to Scanning folders and tracks on page 35.

Refer to Using ITS playlists on this page.

Refer to Pausing disc playback on page 35.

Refer to Using compression on page 36. Multi-CD player has DBE (dynamic bass emphasis) function instead of BMX. The settings can be switched as below:

COMP OFF—COMP 1—COMP 2 —COMP OFF—DBE 1—DBE 2

Refer to Setting the AUX title on page 48.

Refer to Using ITS playlists on this page.

Notes

! If you select other discs during repeat play,

the repeat play range changes to MCD.

! If you perform track search or fast forward/re-

verse during TRK, the repeat play range changes to DSC.

! After track or disc scanning is finished, nor-

mal playback of the tracks begins again.

! When playing a CD TEXT disc on a CD TEXT

compatible multi-CD player, you cannot switch to TITLE IN. The disc title is already recorded on the CD TEXT disc.

Available accessories

Using ITS playlists

ITS (instant track selection) lets you make a playlist of favorite tracks from the multi-CD player magazine. After you have added your favorite tracks to the playlist, you can turn on ITS play and play just those selections.

Creating a playlist with ITS programming

You can use ITS to enter and play back up to 99 tracks per disc from up to 100 discs (with the disc titles). (With multi-CD players sold before the CDX-P1250 and CDX-P650, up to 24 tracks can be stored in the playlist.)

1 Play a CD that you want to program.

Press a or b to select the CD.

2 Press FUNCTION and hold until TITLE IN appears in the display, then press FUNCTION to select ITS.

# If you select ITS (ITS play) in function mode 1, press and hold FUNCTION to enable you to select

ITS directly.

3 Select the desired track by pressing c or d.

4 Press a to store the currently playing track in the playlist. ITS IN is displayed briefly and the currently

playing selection is added to your playlist. The display then shows ITS again.

5 Press BAND to return to the playback display.

Note

After data for 100 discs is stored in memory, data for a new disc will overwrite the oldest one.

Page 52

Section

Available accessories

Playback from your ITS playlist

ITS play lets you listen to the tracks that you have entered into your ITS playlist. When you turn on ITS play, tracks from your ITS playlist in the multi-CD player begin to play.

1 Select the repeat range.

Refer to Playing tracks in random order on page 35.

2 Press FUNCTION to select ITS.

3 Press a to turn ITS play on. ITS ON appears in the display. Playback be-

gins of those tracks from your playlist within the previously selected MCD or DSC ranges.

# If no tracks in the current range are programmed for ITS play, then ITS EMPTY is displayed. # To turn ITS play off, press b.

Erasing a track from your ITS playlist

You can delete a track from your ITS playlist if ITS play is on. If ITS play is already on, skip to step 2. If ITS play is not already on, press FUNCTION.

1 Play the CD with the track you want to delete from your ITS playlist, and turn ITS play on.

Refer to Playback from your ITS playlist on this page.

2 Press FUNCTION and hold until ITS appears in the display.

3 Select the desired track by pressing c or d.

4 Press b to erase the track from your ITS playlist.

The currently playing selection is erased from your ITS playlist and playback of the next track begins.

# If there are no tracks from your playlist in the current range, ITS EMPTY is displayed and normal playback resumes.

5 Press BAND to return to the playback display.

Erasing a CD from your ITS playlist

You can delete all tracks of a CD from your ITS playlist if ITS play is off.

1 Play the CD that you want to delete.

Press a or b to select the CD.

2 Press FUNCTION and hold until TITLE IN appears in the display, then press FUNCTION to select ITS.

3 Press b to erase all tracks on the currently playing CD from your ITS playlist.

All tracks on the currently playing CD are deleted from your playlist and ITS CLEAR is displayed.

4 Press BAND to return to the playback display.

Using disc title functions

You can input CD titles and display the titles. Then, you can easily search for and play a desired disc.

Entering disc titles

Use the disc title input feature to store up to 100 CD titles (with ITS playlist) into the multiCD player. Each title can be up to 10 characters long. For details concerning operation, refer to Set- ting the AUX title on page 48. ! Titles remain in the memory even after the

disc is removed from the magazine, and are recalled when the disc is reinserted.

! After data for 100 discs is stored in mem-

ory, data for a new disc will overwrite the oldest one.

Displaying disc titles

You can display the text information of any disc that has the disc title entered. The operation is the same as that of the builtin DVD player. Refer to Displaying text information on disc on page 33.

Page 53

Available accessories

Selecting discs from the disc title list

Disc title list lets you see the list of disc titles entered in the multi-CD player and select one of them to play back. ! You can also perform the following opera-

tions by using the thumb pad.

1 Press FUNCTION to select TITLE LIST.

2 Press c or d to select a disc from the disc title list.

# If no title is entered for a disc, NO D-TITLE is displayed.

3 Press a to play your favorite CD title.

That selection will begin to play.

Using CD TEXT functions

You can use these functions only with a CD TEXT compatible multi-CD player.

The operation is the same as that of the builtin DVD player. Refer to Displaying text information on disc on page 33.

Section

Available accessories

Page 54

Appendix

Additional Information

Troubleshooting

Common

Symptom Cause Action (See)

Power doesn’t turn on. The unit doesn’t operate.

Operation with the remote control isn’t possible. The unit does not operate correctly even when the appropriate remote control buttons are pressed.

Playback is not possible. The disc is dirty. Clean disc. (Page 57)

No sounds are heard. The volume level will not rise.

The icon eration is not possible.

The picture stops (pauses) and the unit cannot be operated.

There is no sound. Volume level is low.

There is audio and video skipping.

The picture is stretched, the aspect is incorrect.

When the ignition switch is turned ON (or turned to ACC), the motor sounds.

is displayed, and op-

Leads and connectors are incorrectly connected.

The fuse is blown. Rectify the reason for the fuse blowing, then

Noise and other factors are causing the built-in microprocessor to operate incorrectly.

The remote control operation mode is incorrect.

Battery power is low. Load new battery. (Page 9)

Some operations are prohibited with certain discs.

The loaded disc is a type this unit cannot play.

Non compatible video system disc is loaded.

Cables are not connected correctly. Connect the cables correctly.

The unit is performing still, slow motion or frame-by-frame playback.

The operation is prohibited for the disc.

The operation is not compatible with the disc’s organization.

Reading of data has become impossible during playback.

The volume level is low. Adjust the volume level.

The attenuator is on. Turn the attenuator off.

The unit is not firmly secured. Secure the unit firmly.

The aspect setting is incorrect for the display.

The unit is confirming whether a disc is loaded or not.

Confirm once more that all connections are correct.

replace the fuse. Be very sure to install a fuse with the same rating.

Turn the unit off and then on.

Switch to the correct remote control mode. (Page 14)

Check by using another disc.

Check what type the disc is.

Change to a disc compatible to your video system.

There is no sound during still, slow motion or frame-by-frame playback.

This operation is not possible.

After stopping playback once, start playback once more.

Select the appropriate setting for your display. (Page 42)

This is a normal operation.

Problems during DVD playback

Symptom Cause Action (See)

Playback is not possible. The loaded disc has a different re-

gion number from this unit.

Replace the disc with one featuring the same region number as this unit. (Page 6, Page 63)

Page 55

Additional Information

Appendix

A parental lock message is displayed and playback is not possible.

Parental lock cannot be canceled.

Dialog language (and subtitle language) cannot be switched.

No subtitles are displayed. The DVD playing does not feature

Playback is not with the audio language and subtitle language settings selected in the DVD setup menu.

Switching the viewing angle is not possible.

The picture is extremely unclear/ distorted and dark during playback.

Parental lock is on. Turn parental lock off or change the level.

The code number is incorrect. Input the correct code number. (Page 42)

You have forgotten your code number.

The DVD playing does not feature multiple language recordings.

You can only switch between items indicated in the disc menu.

subtitles.

You can only switch between items indicated in the disc menu.

The DVD playing does not feature dialog or subtitles in the language selected in the DVD setup menu.

The DVD playing does not feature scenes shot from multiple angles.

You are trying to switch to multiple angle viewing of a scene that is not recorded from multiple angles.

The disc features a signal to prohibit copying. (Some discs may have this.)

(Page 42)

Press CLEAR 10 times to cancel the code number. (Page 44)

You cannot switch among multiple languages if they are not recorded on the disc.

Switch using the disc menu.

Subtitles are not displayed if they are not recorded on the disc.

Switch using the disc menu.

Switching to a selected language is not possible if the language selected in the DVD setup menu is not recorded on the disc. (Page 40)

You cannot switch between multiple angles if the DVD does not feature scenes recorded from multiple angles.

Switch between multiple angles when watching scenes recorded from multiple angles.

Since this unit is compatible with the copy guard analog copy protect system, when playing a disc that has a signal prohibiting copying, the picture may suffer from horizontal stripes or other imperfections when viewed on some displays. This does not mean this unit is malfunctioning.

Additional Information

Problems during Video CD playback

Symptom Cause Action

The PBC (playback control) menu display cannot be called up.

Repeat play and track/time search are not possible.

The Video CD playing does not feature PBC.

The Video CD playing features PBC. This operation is not possible with Video CDs

This operation is not possible with Video CDs not featuring PBC.

featuring PBC.

Error messages

When you contact your dealer or your nearest Pioneer Service Center, be sure to have the error message recorded.

Page 56

Appendix

Additional Information

Message Cause Action

ERROR 02- (ERROR-02-)XX Dirty disc Clean disc.

Scratched disc Replace disc.

The disc is loaded upside down Check that the disc is loaded correctly.

R ERROR (DIFFERENT REGION DISC)

NON-PLAY (NON-PLAYABLE DISC)

HEAT (THERMAL PROTECTION IN MOTION)

PROTECT (PROTECTED DISC) All the files on the inserted disc are

The disc does not have the same region number as this unit

This type of disc cannot be played by this unit

The inserted disc does not contain any files that can be played back

The temperature of this unit is outside the normal operating range

secured by DRM

Replace the DVD video with one bearing the correct region number.

Replace the disc with one this unit can play.

Replace disc.

Wait until the unit’s temperature returns to within normal operating limits.

Replace disc.

Page 57

Additional Information

Appendix

Handling guideline of discs and player

! Use only conventional, fully circular discs.

Do not use shaped discs.

! Use 12-cm or 8-cm disc. Do not use an

adapter when playing 8-cm discs.

! Do not insert anything other than a disc

into the disc loading slot. Discs which can be played back are listed on Playable discs on page 6.

! Do not use cracked, chipped, warped, or

otherwise damaged discs as they may damage the player.

! Do not touch the recorded surface of the

discs.

! Store discs in their cases when not in use. ! Avoid leaving discs in excessively hot envir-

onments including under direct sunlight.

! Do not attach labels, write on or apply che-

micals to the surface of the discs.

! To clean a disc, wipe the disc with a soft

cloth outward from the center.

! Condensation may temporarily impair the

player’s performance. Leave it to adjust to the warmer temperature for about one hour. Also, wipe any dump discs with a soft cloth.

! Road shocks may interrupt disc playback. ! Read the precautions for discs before

using them.

DVD discs

! With some DVD video discs, it may not be

possible to use certain functions.

! It may not be possible to play back some

DVD video discs.

! When DVD-R/DVD-RW discs are used,

playback is possible only for discs which have been finalized.

! When DVD-R/DVD-RW discs are used,

playback is possible only for discs which have been recorded with the Video format (video mode). It is not possible to play back DVD-RW discs which have been recorded with the Video Recording format (VR mode).

! It may not be possible to play back DVD-R/

DVD-RW discs which have been recorded with the Video format (video mode), because of disc characteristics, scratches or dirt on the disc, or dirt, condensation, etc. on the lens of this unit.

! It is not possible to play back DVD-ROM/

DVD-RAM discs.

! Playback of discs may not be possible be-

cause of disc characteristics, disc format, recorded application, playback environment, storage conditions, and so on.

DVD-R/DVD-RW discs

! Unfinalized DVD-R/-RW discs which have

been recorded with the Video format (video mode) cannot be played back.

! DVD-R/-RW discs which have been re-

corded with the Video Recording format (VR mode) can be played back. However, unfinalized disc may not be played back. Unplayable disc should be finalized. In addition, finalized DVD-R DL (Dual Layer) disc cannot be recorded/edited.

! DVD-R DL (Dual Layer) discs which have

been recorded with the Video Recording format (VR mode) can be played back. However, this unit is not compatible with Layer Jump recording mode.

! For more information about recording

mode, please contact manufacture of DVD recorder or application.

Additional Information

Page 58

Appendix

Additional Information

! The following logo indicates that this unit is

compatible with DVD-RW discs which have been recorded with the Video Recording format (VR mode).

AVCHD recorded discs

! This unit is not compatible with discs re-

corded in AVCHD (Advanced Video Codec High Definition) format. Do not insert AVCHD discs. If inserted, the disc may not be ejected.

CD-R/CD-RW discs

! When CD-R/CD-RW discs are used, play-

back is possible only for discs which have been finalized.

! It may not be possible to play back CD-R/

CD-RW discs recorded on a music CD recorder or a personal computer because of disc characteristics, scratches or dirt on the disc, or dirt, condensation, etc., on the lens of this unit.

! Playback of discs recorded on a personal

computer may not be possible, depending on the application settings and the environment. Please record with the correct format. (For details, contact the manufacturer of the application.)

! Playback of CD-R/CD-RW discs may be-

come impossible in case of direct exposure to sunlight, high temperatures, or the storage conditions in the vehicle.

! Titles and other text information recorded

on a CD-R/CD-RW disc may not be displayed by this unit (in the case of audio data (CD-DA)).

! Read the precautions with CD -R/CD-RW

discs before using them.

Dual Discs

! Dual Discs are two-sided discs that have a

recordable CD for audio on one side and a recordable DVD for video on the other.

! Playback of the DVD side is possible with

this unit. However, since the CD side of Dual Discs is not physically compatible with the general CD standard, it may not be possible to play the CD side with this unit.

! Frequent loading and ejecting of a Dual

Disc may result in scratches on the disc. Serious scratches can lead to playback problems on this unit. In some cases, a Dual Disc may become stuck in the disc loading slot and will not eject. To prevent this, we recommend you refrain from using Dual Disc with this unit.

! Please refer to the information from the

disc manufacturer for more detailed information about Dual Discs.

Compressed audio files on the disc

! Depending on the version of Windows

Media Player used to encode WMA files, album names and other text information may not be correctly displayed.

! There may be a slight delay when starting

playback of audio files encoded with image data.

! ISO 9660 Level 1 and 2 compliant. Romeo

and Joliet file systems are both compatible with this player.

! Multi-session playback is possible. ! Compressed audio files are not compatible

with packet write data transfer.

! Only 64 characters from the beginning can

be displayed as a file name (including the extension such as .wma or .mp3) or a folder name.

! Folder selection sequence or other opera-

tion may be altered depending on the encoding or writing software.

Page 59

Additional Information

Appendix

! Regardless of the length of blank section

between the songs of original recording, compressed audio discs play with a short pause between songs.

! File extensions such as .wma or .mp3 must

be used properly.

Example of a hierarchy

: Folder

: Compressed audio file

3 4

Level 1 Level 2 Level 3 Level 4

! This unit assigns folder numbers. The user

cannot assign folder numbers.

! It is possible to play back up to 255 folders

on one disc.

Compressed audio compatibility

WMA

! Compatible format: WMA encoded by

Windows Media Player

! Bit rate: 5 kbps to 320 kbps (CBR), VBR ! Sampling frequency: 8 kHz to 48 kHz ! Windows Media Audio 9 Professional, Loss-

less, Voice: No

MP3

! Bit rate: 8 kbps to 320 kbps (CBR), VBR ! Sampling frequency: 8 kHz to 48 kHz (8 kHz

to 48 kHz for emphasis)

! Compatible ID3 tag version: 1.0, 1.1, 2.2, 2.3

(ID3 tag Version 2.x is given priority than Version 1.x.)

! M3u playlist: No

! MP3i (MP3 interactive), mp3 PRO: No

AAC

! Compatible format: AAC encoded by

iTunes

! Bit rate: 8 kbps to 320 kbps (CBR) ! VBR: No ! Sampling frequency: 8 kHz to 44.1 kHz ! Apple Lossless: No

DivX video files

! Depending on the file information composi-

tion such as the number of audio stream, there may be a slight delay in the start of playback on discs.

! Some special operation may be prohibited

because of the composition of DivX files.

! DivX files downloaded only from DivX part-

ner site are guarantee of proper operation. Unauthorized DivX file may not operate properly.

! DRM rental file cannot be operated until

starting playing back.

! This unit corresponds to a DivX file display

up to 1 590 minutes 43 seconds. Also, search operation beyond this time limit is prohibited.

! If a file contains more than 4 GB, playback

is stopped on the way.

! DivX VOD file playback requires ID code of

this unit to DivX VOD provider. About ID code, refer to Displaying your DivX gistration code on page 44.

! File extensions such as .avi or .divx must be

used properly.

! For more details about DivX, visit the follow-

ing site: http://www.divx.com/

VOD re-

Additional Information

Page 60

Appendix

Additional Information

DivX compatibility

! Compatible format: DivX video format im-

plemented in relation to DivX standards

! DivX Ultra format: No ! DivX files without video data: No ! Compatible audio codec: MP2, MP3, Dolby

Digital

! LPCM: No ! Bit rate: 8 kbps to 320 kbps (CBR), VBR ! Sampling frequency: 8 kHz to 48 kHz ! Compatible external subtitle file extension:

.srt

Page 61

Additional Information

Language code chart for DVD

Language (code), input code Language (code), input code Language (code), input code

Japanese (ja), 1001 Guarani (gn), 0714 Pashto, Pushto (ps), 1619 English (en), 0514 Gujarati (gu), 0721 Quechua (qu), 1721 French (fr), 0618 Hausa (ha), 0801 Rhaeto-Romance (rm), 1813 Spanish (es), 0519 Hindi (hi), 0809 Kirundi (rn), 1814 German (de), 0405 Croatian (hr), 0818 Romanian (ro), 1815 Italian (it), 0920 Hungarian (hu), 0821 Kinyarwanda (rw), 1823 Chinese (zh), 2608 Armenian (hy), 0825 Sanskrit (sa), 1901 Dutch (nl), 1412 Interlingua (ia), 0901 Sindhi (sd), 1904 Portuguese (pt), 1620 Interlingue (ie), 0905 Sangho (sg), 1907 Swedish (sv), 1922 Inupiak (ik), 0911 Serbo-Croatian (sh), 1908 Russian (ru), 1821 Indonesian (in), 0914 Sinhalese (si), 1909 Korean (ko), 1115 Icelandic (is), 0919 Slovak (sk), 1911 Greek (el), 0512 Hebrew (iw), 0923 Slovenian (sl), 1912 Afar (aa), 0101 Yiddish (ji), 1009 Samoan (sm), 1913 Abkhazian (ab), 0102 Javanese (jw), 1023 Shona (sn), 1914 Afrikaans (af), 0106 Georgian (ka), 1101 Somali (so), 1915 Amharic (am), 0113 Kazakh (kk), 1111 Albanian (sq), 1917 Arabic (ar), 0118 Greenlandic (kl), 1112 Serbian (sr), 1918 Assamese (as), 0119 Cambodian (km), 1113 Siswati (ss), 1919 Aymara (ay), 0125 Kannada (kn), 1114 Sesotho (st), 1920 Azerbaijani (az), 0126 Kashmiri (ks), 1119 Sundanese (su), 1921 Bashkir (ba), 0201 Kurdish (ku), 1121 Swahili (sw), 1923 Byelorussian (be), 0205 Kirghiz (ky), 1125 Tamil (ta), 2001 Bulgarian (bg), 0207 Latin (la), 1201 Telugu (te), 2005 Bihari (bh), 0208 Lingala (ln), 1214 Tajik (tg), 2007 Bislama (bi), 0209 Laothian (lo), 1215 Thai (th), 2008 Bengali (bn), 0214 Lithuanian (lt), 1220 Tigrinya (ti), 2009 Tibetan (bo), 0215 Latvian (lv), 1222 Turkmen (tk), 2011 Breton (br), 0218 Malagasy (mg), 1307 Tagalog (tl), 2012 Catalan (ca), 0301 Maori (mi), 1309 Setswana (tn), 2014 Corsican (co), 0315 Macedonian (mk), 1311 Tonga (to), 2015 Czech (cs), 0319 Malayalam (ml), 1312 Turkish (tr), 2018 Welsh (cy), 0325 Mongolian (mn), 1314 Tsonga (ts), 2019 Danish (da), 0401 Moldavian (mo), 1315 Tatar (tt), 2020 Bhutani (dz), 0426 Marathi (mr), 1318 Twi (tw), 2023 Esperanto (eo), 0515 Malay (ms), 1319 Ukrainian (uk), 2111 Estonian (et), 0520 Maltese (mt), 1320 Urdu (ur), 2118 Basque (eu), 0521 Burmese (my), 1325 Uzbek (uz), 2126 Persian (fa), 0601 Nauru (na), 1401 Vietnamese (vi), 2209 Finnish (fi), 0609 Nepali (ne), 1405 Volapük (vo), 2215 Fiji (fj), 0610 Norwegian (no), 1415 Wolof (wo), 2315 Faroese (fo), 0615 Occitan (oc), 1503 Xhosa (xh), 2408 Frisian (fy), 0625 Oromo (om), 1513 Yoruba (yo), 2515 Irish (ga), 0701 Oriya (or), 1518 Zulu (zu), 2621 Scots-Gaelic (gd), 0704 Panjabi (pa), 1601 Galician (gl), 0712 Polish (pl), 1612

Appendix

Additional Information

Page 62

Appendix

Additional Information

Terms

AAC

AAC is short for Advanced Audio Coding and refers to an audio compression technology standard used with MPEG 2 and MPEG 4.

Aspect ratio

This is the width-to-height ratio of a TV screen. A regular display has an aspect ratio of 4:3. Wide screen displays have an aspect ratio of 16:9, providing a bigger picture for exceptional presence and atmosphere.

Bit rate

This expresses data volume per second, or bps (bits per second) units. The higher the rate, the more information is available to reproduce the sound. Using the same encoding method (such as MP3), the higher the rate, the better the sound.

Chapter

DVD titles are in turn divided into chapters which are numbered in the same way as the chapters of a book. With DVD video discs featuring chapters, you can quickly find a desired scene with chapter search.

DivX

DivX is a popular media technology created by DivX, Inc. DivX media files contain highly compressed video with high visual quality that maintains a relatively small file size. DivX files can also include advanced media features like menus, subtitles, and alternate audio tracks. Many DivX media files are available for download online, and you can create your own using your personal content and easy-to-use tools from DivX.com.

DivX Certified

DivX Certified products are officially tested by the creators of DivX and guaranteed to play all versions of DivX video, including DivX 6.

DVD-VR

DVD-VR (Video Recording) format enables you to edit directly to the DVD video disc. DVD-VR

formats allow you to add new video, change menus, add chapters, split clip, remove video segments and move.

ID3 tag

This is a method of embedding track-related information in an MP3 file. This embedded information can include the track title, the artist’s name, the album title, the music genre, the year of production, comments and other data. The contents can be freely edited using software with ID3 Tag editing functions. Although the tags are restricted as to the number of characters, the information can be viewed when the track is played back.

ISO9660 format

This is the international standard for the format logic of CD-ROM folders and files. For the ISO9660 format, there are regulations for the following two levels.

Level 1:

The file name is in 8.3 format (the name consists of up to 8 characters, half-byte English capital letters and half-byte numerals and the “_” sign, with a file-extension of three characters).

Level 2:

The file name can have up to 31 characters (including the separation mark “.” and a file extension). Each folder contains less than 8 hierarchies.

Extended formats

Joliet: File names can have up to 64 characters. Romeo: File names can have up to 128 characters.

Linear PCM (LPCM)/Pulse code modulation

This stands for linear pulse code modulation, which is the signal recording system used for music CDs and DVDs. Generally, DVDs are recorded with higher sampling frequency and bit rate than CDs. Therefore, DVDs can provide higher sound quality.

Page 63

Additional Information

Appendix

m3u

Playlists created using the “WINAMP” software have a playlist file extension (.m3u).

MP3

MP3 is short for MPEG Audio Layer 3. It is an audio compression standard set by a working group (MPEG) of the ISO (International Standards Organization). MP3 is able to compress audio data to about 1/10th the level of a conventional disc.

MPEG

This stands for Moving Pictures Experts Group, and is an international video image compression standard. Some DVDs feature digital audio compressed and recorded using this system.

Multi-angle

With regular TV programs, although multiple cameras are used to simultaneously shoot scenes, only images from one camera at a time are transmitted to your TV. Some DVDs feature scenes shot from multiple angles, letting you choose your viewing angle as desired.

Multi-audio (Multilingual dialog)

Some DVDs feature dialog recorded in multiple languages. Dialog in up to 8 languages can be recorded on a single disc, letting you choose as desired.

Multi-session

Multi-session is a recording method that allows additional data to be recorded later. When recording data on a CD-ROM, CD-R or CD-RW, etc., all data from beginning to end is treated as a single unit or session. Multi-session is a method of recording more than 2 sessions on one disc.

Multi-subtitle

Subtitles in up to 32 languages can be recorded on a single DVD, letting you choose as desired.

Optical digital output/input

By transmitting and receiving audio signals in a digital signal format, the chance of sonic quality deteriorating in the course of transmission is minimized. An optical digital output/ input is designed to transmit and receive digital signals optically.

Packet write

This is a general term for a method of writing on CD-R, etc., at the time required for a file, just as is done with files on floppy or hard discs.

Parental lock

Some DVD video discs with violent or adult-oriented scenes feature parental lock which prevents children from viewing such scenes. With this kind of disc, if you set the unit’s parental lock level, playback of scenes inappropriate for children will be disabled, or these scenes will be skipped.

Playback control (PBC)

This is a playback control signal recorded on Video CDs (Version 2.0). Using menu displays provided by Video CDs with PBC lets you enjoy playback of simple interactive software and software with search functions. You can also enjoy viewing high- and standard-resolution still images.

Region number

DVD players and DVD discs feature region numbers indicating the area in which they were purchased. Playback of a DVD is not possible unless it features the same region number as the DVD player. This unit’s region number is displayed on the bottom of the unit.

Title

DVD video discs have high data capacity, enabling recording of multiple movies on a single disc. If, for example, one disc contains three separate movies, they are divided into title 1, title 2 and title 3. This lets you enjoy the convenience of title search and other functions.

Additional Information

Page 64

Appendix

Additional Information

VBR

VBR is short for variable bit rate. Generally speaking CBR (constant bit rate) is more widely used. But by flexibly adjusting the bit rate according to the needs of audio compression, it is possible to achieve compressionpriority sound quality.

WMA

WMA is short for Windows Media™ Audio and refers to an audio compression technology that is developed by Microsoft Corporation. WMA data can be encoded by using Windows Media Player version 7 or later. Windows Media and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.

Page 65

Additional Information

Appendix

Specifications

General

Rated power source ............... 14.4 V DC

(allowable voltage range:

12.0 V to 14.4 V DC)

Grounding system ................... Negative type

Max. current consumption

..................................................... 10.0 A

Dimensions (W × H × D):

DIN

Chassis ..................... 1 78 mm × 5 0 mm × 161

Nos e ........................... 188 m m × 58 mm × 19 mm

Chassis ..................... 1 78 mm × 5 0 mm × 165

Nos e ........................... 170 m m × 46 mm × 15 mm

Weight .......................................... 1.4 k g

Audio

Maximum power output ....... 50 W × 4

50 W × 2/4 W + 70 W × 1/2 W (for subwoofer)

Continuous power output ... 22 W × 4 (50 Hz to 15 000

Hz, 5% THD, 4 W load, both channels driven)

Load impedance ...................... 4 W to 8 W ×4

4 W to 8 W ×2+2W ×1

Preout max ou tp ut lev el ....... 2 .2 V

Equalizer (7-Band Graphic Equalizer):

Freq ue nc y .......................... 50/125/315/800/2k/5k/12.5k

Gai n ...................................... ±12 dB

HPF:

Freq ue nc y .......................... 50/63/80/100/125 Hz

Slo pe .................................... –12 dB/oct

Subwoofer (mono):

Freq ue nc y .......................... 50/63/80/100/125 Hz

Slo pe .................................... –18 dB/oct

Gai n ...................................... +6 dB to –24 dB

Phase .................................. Normal/ Reverse

Bass boost:

Gai n ...................................... +12 dB to 0 dB

DVD Player

System .......................................... DVD v ideo, DVD-VR, Video

CD, CD, WMA, MP3, AAC,

DivX system Region number:

for Middle East Asian and South African models

........................................... 2

for Southeast Asian models

........................................... 3

for South American and Oceanian models

........................................... 4

Usa bl e disc s .............................. DVD vi de o, V ideo C D,

Freq ue nc y resp on se ............... 5 Hz to 44 000 Hz (with DVD,

Signal-to-noise ratio ............... 97 dB (1 kHz) (I EC -A ne t-

Output level:

Vid eo .................................... 1 .0 Vp-p/75 W (±0.2 V)

Number of channels .............. 2 (st er eo )

MP3 decod in g form at ........... MPEG-1 & 2 Audio Layer 3

WMA decoding format ......... Ver. 7, 7.1, 8, 9, 10, 11 (2ch

AAC decoding format ............ MPEG-4 AAC (iTunes

DivX decoding format ............ Home Theater Ver. 3, 4, 5.2

dtsCD, CD, CD-R/RW, DVDR/RW

at sampling frequency 96 kHz)

work) (CD: 96 dB (1 kHz) (IEC-A network))

audio) (Windows Media Player)

coded only) (.m4a) (Ver. 7.2 and earlier)

(.avi, .divx)

en-

FM tuner

Freq ue nc y range ...................... 87.5 MHz to 108.0 MHz

Usable sensitivity ..................... 8 d Bf (0.7 µV/75 W, mono,

Signal-to-noise ratio ............... 75 dB (IE C -A net wo rk)

S/N: 30 dB)

AM tuner

Freq ue nc y range ...................... 531 k Hz to 1 602 kHz (9 k Hz )

Usable sensitivity ..................... 18 µV (S/ N: 2 0 dB)

Signal-to-noise ratio ............... 65 dB (IE C -A net wo rk)

530 kHz to 1640 kHz (10 kHz)

Infrared remote control

Wavelength ................................. 945 nm

Out pu t ........................................... typ; 10 mw/ sr per Inf ra red

LED

Note

Specifications and the design are subject to modifications without notice due to improvements.

Additional Information

Page 66

PIONEER CORPORATION

4-1, MEGURO 1-CHOME, MEGURO-KU TOKYO 153-8654, JAPAN

PIONEER ELECTRONICS (USA) INC.

P.O. Box 1540, Long Beach, California 90801-1540, U.S.A. TEL: (800) 421-1404

PIONEER EUROPE NV

Haven 1087, Keetberglaan 1, B-9120 Melsele, Belgium TEL: (0) 3/570.05.11

PIONEER ELECTRONICS ASIACENTRE PTE. LTD.

253 Alexandra Road, #04-01, Singapore 159936 TEL: 65-6472-7555

PIONEER ELECTRONICS AUSTRALIA PTY. LTD.

178-184 Boundary Road, Braeside, Victoria 3195, Australia TEL: (03) 9586-6300

PIONEER ELECTRONICS OF CANADA, INC.

300 Allstate Parkway, Markham, Ontario L3R 0P2, Canada TEL: 1-877-283-5901 TEL: 905-479-4411

PIONEER ELECTRONICS DE MEXICO, S.A. de C.V.

Blvd.Manuel Avila Camacho 138 10 piso Col.Lomas de Chapultepec, Mexico, D.F. 11000 TEL: 55-9178-4270

先鋒股份有限公司

總公司 : 台北市中山北路二段44號13樓

電話 : (02) 2521-3588

先鋒電子（香港）有限公司

香港九龍尖沙咀海港城世界商業中心

9樓901-6室電話 : (0852) 2848-6488

Printed in Thailand

<CRB2725-A/N> RC, RD, RI
