DVD PLAYER
DV-K302CD DVD-V630
Operating Instructions
Please read through these operating instructions so you will know how to operate your model properly. After you have finished reading the instructions, put them away in a safe place for future reference.
• This player is not suitable for commercial use.
IMPORTANT
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user tothepresenceofuninsulated"dangerousvoltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
CAUTION:
TO PREVENT THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Theexclamationpointwithinanequilateraltriangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
|
|
|
|
|
|
|||
|
|
IMPORTANT SAFETY INSTRUCTIONS |
|
|||||
|
|
|
||||||
|
READ INSTRUCTIONS — All the safety and |
GROUNDING OR POLARIZATION |
OBJECT AND LIQUID ENTRY — Never push |
|||||
|
operating instructions should be read before |
• If this product is equipped with a polarized |
|
objects of any kind into this product through |
||||
|
the product is operated. |
alternating current line plug (a plug having one |
|
openingsas theymay touch dangerous voltage |
||||
|
RETAIN INSTRUCTIONS — The safety and |
blade wider than the other), it will fit into the |
|
points or short-out parts that could result in a |
||||
|
operating instructions should be retained for |
outlet only one way. This is a safety feature. If |
|
fire or electric shock. Never spill liquid of any |
||||
|
future reference. |
you are unable to insert the plug fully into the |
|
kind on the product. |
||||
|
HEED WARNINGS —All warnings on the product |
outlet, try reversing the plug. If the plug should |
SERVICING — Do not attempt to service this |
|||||
|
and in the operating instructions should be |
still fail to fit, contact your electrician to replace |
|
product yourself as opening or removing |
||||
|
adhered to. |
your obsolete outlet. Do not defeat the safety |
|
covers may expose you to dangerous voltage |
||||
|
FOLLOW INSTRUCTIONS — All operating and |
purpose of the polarized plug. |
|
or other hazards. Refer all servicing to qualified |
||||
|
use instructions should be followed. |
• If this product is equipped with a three-wire |
|
service personnel. |
||||
|
CLEANING — Unplug this product from the wall |
grounding type plug, a plug having a third |
DAMAGE REQUIRING SERVICE — Unplug this |
|||||
|
outlet before cleaning. The product should be |
(grounding) pin, it will only fit into a grounding |
|
product from the wall outlet and refer servicing |
||||
|
cleaned only with a polishing cloth or a soft dry |
type power outlet. This is a safety feature. If |
|
to qualified service personnel under the |
||||
|
cloth. Never clean with furniture wax, benzine, |
you are unable to insert the plug into the |
|
following conditions: |
||||
|
insecticides or other volatile liquids since they |
outlet, contact your electrician to replace your |
• |
When the power-supply cord or plug is |
||||
|
may corrode the cabinet. |
obsolete outlet. Do not defeat the safety |
|
damaged. |
||||
|
ATTACHMENTS — Do not use attachments not |
purpose of the grounding type plug. |
• If liquid has been spilled, or objects have fallen |
|||||
|
recommended by the product manufacturer |
POWER-CORD PROTECTION — Power-supply |
|
into the product. |
||||
|
as they may cause hazards. |
cords should be routed so that they are not |
• If the product has been exposed to rain or |
|||||
|
WATER AND MOISTURE — Do not use this |
likely to be walked on or pinched by items |
|
water. |
||||
|
product near water — for example, near a |
placed upon or against them, paying particular |
• If the product does not operate normally by |
|||||
|
bathtub, wash bowl, kitchen sink, or laundry |
attention to cords at plugs, convenience |
|
following the operating instructions. Adjust |
||||
|
tub; in a wet basement; or near a swimming |
receptacles, and the point where they exit |
|
only those controls that are covered by the |
||||
|
pool; and the like. |
from the product. |
|
operating instructions as an improper |
||||
|
ACCESSORIES — Do not place this product on |
OUTDOOR ANTENNA GROUNDING — If an |
|
adjustment of other controls may result in |
||||
|
an unstable cart, stand, tripod, bracket, or |
outside antenna or cable system is connected |
|
damage and will often require extensive work |
||||
|
table. The product may fall, causing serious |
to the product, be sure the antenna or cable |
|
by a qualified technician to restore the product |
||||
|
injury to a child or adult, and serious damage |
system is grounded so as to provide some |
|
to its normal operation. |
||||
|
to the product. Use only with a cart, stand, |
protection against voltage surges and built-up |
• If the product has been dropped or damaged |
|||||
|
tripod, bracket, or table recommended by the |
static charges. Article 810 of the National |
|
in any way. |
||||
|
manufacturer, or sold with the product. Any |
Electrical Code, ANSI/NFPA 70, provides |
• When the product exhibits a distinct change in |
|||||
|
mounting of the product should follow the |
information with regard to proper grounding of |
|
performance — this indicates a need for |
||||
|
manufacturer’s instructions, and should use a |
the mast and supporting structure, grounding |
|
service. |
||||
|
mounting accessory recommended by the |
of the lead-in wire to an antenna discharge |
REPLACEMENT PARTS — When replacement |
|||||
|
manufacturer. |
unit, size of grounding conductors, location of |
|
parts are required, be sure the service |
||||
|
CART — A product and cart combination should |
antenna-discharge unit, connection to |
|
technician has used replacement parts |
||||
|
be moved with care. Quick stops, excessive |
grounding electrodes, and requirements for |
|
specified by the manufacturer or have the |
||||
|
force, and uneven surfaces may cause the |
the grounding electrode. See Figure A. |
|
same characteristics as the original part. |
||||
|
product and cart combination to overturn. |
LIGHTNING — For added protection for this |
|
Unauthorized substitutions may result in fire, |
||||
|
|
|
product during a lightning storm, or when it is |
|
electric shock, or other hazards. |
|||
|
|
|
left unattended and unused for long periods of |
SAFETY CHECK — Upon completion of any |
||||
|
|
|
time, unplug it from the wall outlet and |
|
service or repairs to this product, ask the |
|||
|
|
|
disconnect the antenna or cable system. This |
|
service technician to perform safety checks to |
|||
|
|
|
will prevent damage to the product due to |
|
determine that the product is in proper |
|||
|
|
|
lightning and power-line surges. |
|
operating condition. |
|||
|
VENTILATION — Slots and openings in the |
POWER LINES — An outside antenna system |
WALL OR CEILING MOUNTING — The product |
|||||
|
should not be located in the vicinity of overhead |
|
should not be mounted to a wall or ceiling. |
|||||
|
cabinet are provided for ventilation and to |
|
||||||
|
power lines or other electric light or power |
HEAT — The product should be situated away |
||||||
|
ensure reliable operation of the product and to |
|||||||
|
circuits, or where it can fall into such power |
|
from heat sources such as radiators, heat |
|||||
|
protectitfromoverheating,andtheseopenings |
|
||||||
|
lines or circuits. When installing an outside |
|
registers, stoves, or other products (including |
|||||
|
must not be blocked or covered. The openings |
|
||||||
|
antenna system, extreme care should be taken |
|
amplifiers) that produce heat. |
|||||
|
should never be blocked by placing the product |
to keep from touching such power lines or |
|
|
|
|||
|
on a bed, sofa, rug, or other similar surface. |
|
|
|
||||
|
circuits as contact with them might be fatal. |
|
|
|
||||
|
This product should not be placed in a built-in |
|
|
|
||||
|
OVERLOADING — Do not overload wall outlets, |
|
|
|
||||
|
installation such as a bookcase or rack unless |
extension cords, or integral convenience |
|
|
|
|||
|
proper ventilation is provided or the |
|
|
|
||||
|
receptacles as this can result in a risk of fire or |
|
ANTENNA |
|||||
|
manufacturer’s instructions have been |
|
||||||
|
electric shock. |
|
||||||
|
|
LEAD IN WIRE |
||||||
|
adhered to. |
|
||||||
|
|
|
|
|
||||
|
|
|
|
|
|
|
||
|
POWER SOURCES — This product should be |
|
|
GROUND |
ANTENNA |
|||
|
operated only from the type of power source |
|
|
|||||
|
|
|
CLAMP |
|
DISCHARGE UNIT |
|||
|
indicated on the marking label. If you are not |
|
|
|
||||
|
|
|
|
|
(NEC SECTION 810-20) |
|||
|
sure of the type of power supply to your |
|
|
|
|
|||
|
|
ELECTRIC |
|
|
|
|||
|
home, consult your product dealer or local |
|
|
GROUNDING CONDUCTORS |
||||
|
|
SERVICE |
|
|||||
|
power company. |
|
|
(NEC SECTION 810-21) |
||||
|
|
EQUIPMENT |
|
|||||
|
LOCATION – The appliance should be installed in |
|
|
GROUND CLAMPS |
||||
|
|
|
|
|
||||
|
a stable location. |
|
|
|
|
|||
|
|
|
|
|
POWER SERVICE GROUNDING |
|||
|
NONUSE PERIODS – The power cord of the |
|
|
Fig. A |
|
|||
|
|
|
|
ELECTRODE SYSTEM |
||||
|
appliance should be unplugged from the outlet |
|
|
|
|
|||
|
|
|
|
|
(NEC ART 250, PART H) |
|||
|
when left unused for a long period of time. |
|
|
|
|
|||
2 |
|
|
|
|
|
|
||
|
|
|
|
|
|
NEC — NATIONAL ELECTRICAL CODE |
||
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
CONGRATULATIONS ON YOUR PURCHASE OF THIS FINE PIONEER PRODUCT.
Pioneer is on the leading edge of DVD research for consumer products and this unit incorporates the latest technological developments.
We are sure you will be fully satisfied with the DVD player.
Thank you for your support.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
IMPORTANT NOTICE [For U.S. model]
The serial number for this equipment is located on the rear panel. Please write this serial number on your enclosed warranty card and keep it in a secure area. This is for your security.
CAUTION: This product satisfies FCC regulations when shielded cables and connectors are used to connect the unit to other equipment. To prevent electromagnetic interference with electric appliances such as radios and televisions, use shielded cables and connectors for connections.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
–Reorient or relocate the receiving antenna.
–Increase the separation between the equipment and receiver.
–Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
–Consult the dealer or an experienced radio/TV technician for help.
Information to User
Alteration or modifications carried out without appropriate authorization may invalidate the user's right to operate the equipment.
CAUTION
•Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.
•The use of optical instruments with this product will increase eye hazard.
[For Canadian model]
This Class B digital apparatus complies with Canadian ICES-003.
[Pour le modèle Canadien]
Cet appareil numérique de la Classe B est conforme à la norme NMB-003 du Canada.
[For Canadian model]
CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS (POLARIZED) PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.
ATTENTION: POUR PREVENIR LES CHOCS ELECTRIQUES NE PAS UTILISER CETTE FICHE POLARISEE AVEC UN PROLONGATEUR, UNE PRISE DE COURANT OU UNE AUTRE SORTIE DE COURANT, SAUF SI LES LAMES PEUVENT ETRE INSEREES A FOND SANS EN LAISSER AUCUNE PARTIE A DECOUVERT.
3
Features of This Player
Compatible with DVD, Super VCD (IEC standard), Video CD and CD formats
DVD, Super VCD (IEC standard), Video CD and CD discs that display the logos shown below can be played back on this DVD player. For more information on discs compatible with this player, refer to the table below.
Types of playable |
Diameter/ |
|
|
discs and their marks |
Playable sides |
|
Playback time |
DVD VIDEO |
DVD VIDEO |
|
Digital audio |
|
|
|
Digital video |
|
|
|
(MPEG 2) |
|
12 cm (5 in.)/ |
1 layer |
133 min. |
|
single-sided |
2 layer |
242 min. |
|
12 cm (5 in.)/ |
1 layer |
266 min. |
|
double-sided |
2 layer |
484 min. |
|
DVD VIDEO |
|
Digital audio |
|
|
|
|
|
|
|
Digital video |
|
|
|
(MPEG 2) |
|
8 cm (3 in.)/ |
1 layer |
41 min. |
|
single-sided |
2 layer |
75 min. |
|
8 cm (3 in.)/ |
1 layer |
82 min. |
|
double-sided |
2 layer |
150 min. |
Super VCD |
Super VCD |
|
Digital audio |
|
12 cm (5 in.)/ |
|
(MPEG 1) |
|
|
Digital video |
|
|
single-sided |
|
|
|
|
(MPEG 2) |
|
|
|
|
|
|
|
|
40 min. |
|
Super VCD single |
Digital audio |
|
|
8 cm (3 in.)/ |
|
(MPEG 1) |
|
|
Digital video |
|
|
single-sided |
|
|
|
|
(MPEG 2) |
|
|
|
|
|
|
|
|
10 min. |
VIDEO CD |
VIDEO CD |
|
Digital audio |
|
12 cm (5 in.)/ |
|
Digital video |
|
|
(MPEG 1) |
|
|
single-sided |
|
Max. 74 min. |
|
VIDEO CD single |
Digital audio |
|
|
8 cm (3 in.)/ |
|
Digital video |
|
|
(MPEG 1) |
|
|
single-sided |
|
Max. 20 min. |
CD |
CD |
|
Digital audio |
|
12 cm (5 in.)/ |
|
Max. 74 min. |
|
single-sided |
|
|
|
CD single |
|
Digital audio |
|
8 cm (3 in.)/ |
|
Max. 20 min. |
|
single-sided |
|
The disc format logos shown above are found on disc labels or on disc jackets.
•To prevent malfunction, do not use an 8 cm (3 in.) adaptor (for CDs).
•Discs other than the ones indicated above cannot be played on this unit.
•DVDs that have incompatible region numbers, DVDAudio, DVD-ROM, and CD-ROM cannot be played on this unit. The region number of the player can be found on the rear panel.
What is Super VCD?
This player supports the IEC’s Super VCD standard. Compared to the Video CD standard, Super VCD offers superior picture quality, and allows two stereo soundtracks to be recorded. Super VCD also supports the widescreen size.
Compatible with a wide range of DVD digital audio output formats
DVDs are recorded in one of four types of digital audio formats (as of October 1998). The digital audio output jacks of this player output Dolby Digital*, DTS**, MPEG, and linear PCM digital bitstreams.
This player has a function that converts Dolby Digital and MPEG audio formats into the linear PCM format. This allows playback of DVDs recorded in Dolby Digital and MPEG without the need for a decoder.
Equipped with six channel discrete audio output and an internal Dolby Digital decoder
Enjoy the cinematic surround sound produced by Dolby Digital audio soundtracks without the need for an external decoder. This player features six channel discrete audio output jacks so you can connect this player directly to an amplifier or receiver with 6 channel discrete input, and utilize the player’s built-in Dolby Digital decoding capabilities.
*Manufactured under license from Dolby Laboratories. “Dolby”, “AC–3” and the double-D symbol are trademarks of Dolby Laboratories. Confidential unpublished works, © 19921997 Dolby Laboratories. All rights reserved.
** “DTS” is a trademark of Digital Theater Systems, Inc.
You can enjoy the unique operation of a 3-disc changer
A disc that is currently playing can be easily exchanged with two other discs. In addition, you can play your favorite disc with the press of a button.
4
Easy setup and adjustment using on-screen menus
Press SETUP on the remote control to open the Setup screen and you’ll find setting up and adjusting the system easy to do with on-screen menus conveniently organized and arranged. Additionally, on-screen information ( i ) appears to clarify the functions and explain the options available. Below are just a few examples.
Answer a few questions and have all the necessary audio, video, and on-screen language adjustments set automatically by the player using the Setup Navigator (page 22).
Audio1 2 Video Language General
Setup Navigator
Setup Navigator Start
Not Used
Setting up using the Setup Navigator
Move ENTER Select SETUP Exit
1 Audio2 Video Language General
Speaker Setting |
|
|
|
Center |
L |
R |
|
Speaker ······ |
|||
On |
|
||
|
|
SW |
|
|
LS |
RS |
Move |
|
|
RETURN |
Return |
–/+ |
ENTER |
Select |
SETUP |
Exit |
Setup the on-screen speaker system to match your home audio system in the Audio 2 menu for ideal presentation of multichannel audio (page 32).
This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
Wide range of DVD viewing options
Multi-Language Subtitles (page 42)
You can select a subtitle language or turn subtitles off when watching movies or other media with subtitles available.
Subtitle :1 English |
|
Subtitle :2 Spanish |
HELLO! |
HOLA! |
Multiple Languages (page 43)
You can select the language on when watching movies or other media that have multiple language and/or audio soundtracks recorded on them.
|
|
Dolby Digital |
|
|
|
Dolby Digital |
Audio |
: 1 English |
5.1CH |
|
Audio |
: 2 Spanish |
5.1CH |
HELLO |
HOLA |
Multi-Angle (page 49)
You can view scenes from different camera angles when watching movies or other media with multiple angle playback available.
ANGLE : 2/4 |
ANGLE |
: 3/4 |
This mark indicates this may not be possible with certain discs.
Energy-saving design
This unit is designed to use minimal electricity when this player is in standby mode. Regarding the amount of power consumed in standby mode, refer to “Specifications” on page 64 (backcover).
5
Differences in Disc
Composition
DVD
DVDs are divided into units referred to as titles, and titles are divided into chapters. A DVD which contains a movie may have only one title with many or no chapter divisions. Karaoke DVDs may have many titles, assigning a title to each song on the disc. Menu screens do not belong to any title.
DVD player functions generally apply to titles on a disc or chapters within a selected title. The player functions available may also vary from title to title, depending on the disc. When discs have a unique title division, it should be noted that search and program functions may be affected.
|
Title 1 |
|
|
|
|
Title 2 |
|
||
|
|
|
|
|
|||||
Chapter 1 |
Chapter 2 |
|
Chapter 1 |
Chapter 2 |
How to Proceed in This Manual
DVD is an incredible format that presents the highest quality digital audio and video available today.
Because using the DVD player and DVDs may be confusing at first, following the order below should help you get through the important stages of getting set up so you can start using your player as soon as possible.
Get familiar with the player.
Refer to the section “Before Using” on page 8 to confirm that all the accessories were included with the player. If you are new to DVD, it might be beneficial for you to go through the “Names and Functions” section starting on page 10 to get familiar with the parts and buttons on the main unit and remote control as they will be referred to throughout this manual.
There is also a list of terms that can be found on page 62 if you are having trouble understanding some of the terminology associated with DVD.
Make the necessary connections.
No entertainment system seems to be set up exactly the same way. The “Making Connections” section
DVD starting on page 16 shows how video and audio connections may be made to suit your home entertainment system.
Super VCD/Video CD/CD
Super VCDs, Video CDs and CDs are divided into units referred to as tracks (Super VCD and Video CD tracks may also be referred to as scenes). One song generally corresponds to one track. Some tracks are further divided into units referred to as indexes. Super VCDs/ Video CDs with PBC (Playback Control) also contain menus recorded on the disc which enable easy access to the contents of the disc.
When played back on a DVD player, Super VCDs, Video CDs and CDs are considered to be a single title, regardless of the number of tracks.
Track 1 |
|
Track 2 |
Track 3 |
|
Track 4 |
|
|
|
|
|
|
|
|
Super VCD/Video CD
Track 1 |
Track 2 |
Track 3 |
Track 4 |
Track 5 |
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
CD
Set up the necessary player menus.
Before you can begin to enjoy the benefits of the DVD format, you should set up the player to output the video and audio information that corresponds to your system. The section “Setting Up the Player” starting on page 22 explains how to use the Setup screen menus as well as how to make the necessary initial adjustments. The Setup screen menus are used in a number of functions. Learning the procedure for operating the menus will make using this player much easier and more enjoyable.
Play a disc.
When all the connections and setups have been made, you are ready to play a DVD, Super VCD, Video CD, or CD with the player. The section “Getting Started Using Your DVD Player” starting on page 26 outlines the basic player operations.
Enjoy the many features available.
Once you are comfortable using the basic player functions, you are ready to take advantage of the various options DVD and this player have to offer. The section “Advanced Functions” starting on page 46 describes how to use the features available on many DVDs.
6
Table of Contents |
|
Before Using ........................................ |
8 |
Checking Accessories ..................................... |
8 |
Preparing the Remote Control ......................... |
8 |
Names and Functions ....................... |
10 |
Front Panel .................................................... |
10 |
Display Window ............................................. |
12 |
Rear Panel ..................................................... |
13 |
Remote Control ............................................. |
14 |
Making Connections ......................... |
16 |
Connecting Your DVD Player ......................... |
16 |
Audio Connections ........................................ |
18 |
Video Connections ......................................... |
20 |
System Control Connections ......................... |
21 |
Setting Up the Player ....................... |
22 |
Using the Setup Navigator............................. |
22 |
Getting Started Using Your DVD |
|
Player.................................................. |
26 |
Playing DVDs, Super VCDs, |
|
Video CDs and CDs .................................. |
26 |
Improving Picture Quality .............................. |
27 |
Chapter (Track) Skip Forward/Skip Back ........ |
28 |
Forward and Reverse Scanning ..................... |
28 |
Stopping Playback and Switching |
|
Power Off ................................................ |
29 |
Adjusting Audio and |
|
Video Settings ................................... |
30 |
Using the Setup Screen Menus .................... |
30 |
Changing the Setup Screen to “Expert” |
|
Menu Mode ............................................. |
31 |
Setting Analog Audio Connections to an AV |
|
Amplifier or Receiver ............................... |
31 |
Setting Your Speaker System for |
|
Multichannel Audio Playback ................... |
32 |
Setting the Digital Audio Output To Be |
|
Compatible with Your AV Components .... |
33 |
Setting the TV Screen Size ............................ |
34 |
Adjusting the OSD (On-Screen Display) ........ |
35 |
Karaoke Operation ............................ |
36 |
Karaoke Entertainment .................................. |
36 |
Adjusting to Create the Desired Sound ......... |
37 |
One-Touch Karaoke ....................................... |
38 |
Reserving a Desired Song ............................. |
38 |
Making Settings on the Karaoke |
|
Setup Menu ............................................. |
39 |
Setting the Language Options |
......... |
42 |
Selecting a Subtitle Language |
|
|
(Multi-Language Subtitles) ....................... |
|
42 |
Changing the Audio Language |
|
|
(Multi-Language Function) ....................... |
|
43 |
Setting Language and Subtitle Preferences |
|
|
in the Setup Screen Menus ..................... |
|
44 |
Advanced Functions ......................... |
|
46 |
Adjusting the Dynamic Range of the |
|
|
Audio Soundtrack ..................................... |
|
46 |
Selecting Picture Quality Appropriate for |
|
|
Program Content...................................... |
|
46 |
Still Frame/Slow Play/ |
|
|
Frame Advance Playback ......................... |
|
47 |
Searching for a Title, Chapter, Track, |
|
|
or Location on a Disc ............................... |
|
48 |
Viewing from a Desired Camera Angle |
|
|
(Multi-Angle) ............................................. |
|
49 |
Changing to Surround .................................... |
|
49 |
Repeat Play .................................................... |
|
50 |
Setting the Parental Lock Level ..................... |
|
51 |
Continuing Playback from a |
|
|
Specified Location (Last Memory) ........... |
53 |
|
Memorizing Settings for Often |
|
|
Viewed DVDs (Condition Memory) .......... |
54 |
|
Viewing Disc Information .............................. |
|
55 |
Changing the Background Color |
|
|
of the Screen ........................................... |
|
56 |
Resetting the Player to System Settings ....... |
56 |
|
Additional Information ..................... |
|
57 |
Disc Care ....................................................... |
|
57 |
For Proper and Long Use of This Unit ........... |
58 |
|
Language Code List ....................................... |
|
59 |
Troubleshooting ............................................. |
|
60 |
Terms ............................................................. |
|
62 |
Specifications ................................... |
Backcover |
7
Before Using
CheckingAccessories
Please confirm that the following were received with the player.
Audio cord
Preparing the Remote Control
Inserting batteries into the remote control
1 While pushing the tab on the battery compartment cover toward the center of the remote, pull out in the direction indicated by the arrow.
Video cord
Remote control unit
AA/R6P batteries
Power cord
Operating instructions (this manual)
2 Insert batteries.
Make sure to match the plus (+) and minus
(–) polarity guides on the batteries with the marks inside the battery compartment.
3 Close the cover.
Notes
•Do not mix old and new batteries.
•When replacing batteries, use all new batteries.
•When not using the remote control for a long period of time (over 1 month), remove the batteries to avoid possible damage from battery corrosion. If battery leakage occurs, wipe the battery liquid from the battery component, then insert new batteries.
8
Remote control operation
When operating the remote control, point it at the remote sensor (ë) located on the player’s front panel. The remote control can be used up to 23 feet (7 m) from the player and within a 30° angle on each side of the sensor.
30°
30° 7m (23ft)
Notes
•Exposing the remote sensor to direct sunlight or strong light may cause faulty operation.
•If the CONTROL IN jack on the player’s rear panel is connected to the CONTROL OUT jack of another component, point the remote control at the other component to operate the player. Operation will not be possible when pointed at this player (page 21).
USING BEFORE
9
Names and
Functions
Front Panel
1 |
2 |
3 |
|
4 |
|
|
5 |
|
|
|
|
|
|
6 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
DISC |
|
|
|
1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
9 |
0 |
+10 |
1 |
2 |
3 |
|
|
DVD PLAYER |
|
|
|
|
|
|
|
|
|
|
|
|
7 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
DISC |
STANDBY |
OPEN/CLOSE CHANGE |
KEY CONTROL |
|
|
HIGH |
POWER
LOW
OFF ON
8
9
0
ECHO |
MIC 1 |
MIC 2 |
MIC 1 |
MIC 2 |
5.1CH |
ONE-TOUCH KARAOKE PLAYBACK |
- |
|
|
|
|
|
ë |
KARAOKE MODE CONTROL |
|
|
|
|
|
|
MODE |
|
|
MIN MAX |
MIN MAX |
MIN MAX |
|
MIC CONTROL |
|
|
|
|
) ( |
* & ^ |
% |
$ # @ ! ~ = |
1 |
[Models having a STANDBY/ON button on the |
|
5 Disc illumination |
|
|
main unit] |
|
|
Lights when a DVD is loaded and when no disc is |
|
STANDBY/ON button |
|
loaded. |
|
|
Press to switch the player on or to put in standby |
|
Turns off when a disc other than a DVD is played |
|
|
(pages 26 and 36). |
|
|
back. |
1 |
[Models having a POWER switch on the main |
|
6 DISC buttons and indicator |
|
|
unit] |
|
|
Use to select discs in the player directly (page 26). |
|
POWER switch |
|
|
|
Press to switch the player on or off (pages 26, 29 and 36).
When this switch is "ON", the remote control can be used to switch the player between the "ON" state and standby.
2STANDBY indicator
Indicates that the player is in standby, using a minimum amount of power to maintain system settings.
Turns off when the player is on.
Some models do not have a STANDBY indicator.
3KEY CONTROL buttons
Use to adjust the levels of the key in 11 steps (pages 37 and 41).
4Number buttons (1-9, 0, +10)
Use to perform direct title and chapter/track searches, and to input numerical values
(pages 27, 38 and 48).
7OPEN/CLOSE 0 button
Press to open and close the disc tray (pages 26 and 29).
8DISC CHANGE button
Press to select the next disc in the player (pages 26 and 29).
9 4 1 (reverse) button
Press to go back to previous chapters/tracks. Press and hold to perform reverse playback scanning (page 28).
0Á ¢ (forward) button
Press to advance to chapters/tracks. Press and hold to perform fast-forward scanning (page 28).
-3 (play) button
Press to start or resume playback (pages 26 and 28).
= 8 (pause) button
|
Press during playback to pause. Press again to |
10 |
resume playback (page 47). |
|
~7 (stop) button
Press to stop playback. Pressing once enables playback to resume from a point shortly before the location where it stopped. Pressing twice causes the disc to return to the beginning of the disc if playback starts again. Resume play is possible only in Normal mode (page 29).
!PLAYBACK CONTROL button and indicator
Use to switch the playback control for the Super VCD/Video CD on or off. (page 27)
@KARAOKE MODE button and indicator
Use to switch between Karaoke mode and Normal mode. (pages 26 and 36)
#ONE-TOUCH KARAOKE button and indicator
Use to switch One-Touch Karaoke mode on or off. (page 38)
$5.1 CH MODE button and indicator
Press to switch the audio output between 5.1 channel audio and 2 channel audio. It is also possible to set the default audio output in the Setup screen Audio 2 menu (pages 24 and 31).
%Display window
Displays system information (page 12).
^Disc tray
When loading discs, place discs in the disc tray with the label side facing up (pages 26 and 29).
&Remote sensor
Point the remote control toward the remote sensor to operate the player (page 9).
*MIC1, MIC2 and MIC CONTROL jacks
Use to connect a microphone. (pages 36 and 37)
(MIC1 and MIC2 volume level knobs
Use to adjust the volume level of the microphone. (page 36)
)Digital Echo level knob
Use to adjust the echo level. (page 37)
FUNCTIONS AND NAMES
11
Display Window
|
1 2 3 4 5 6 7 8 9 0 |
- = ~ ! |
|||||
96 kHz |
ANGLE |
REPEAT |
GUI |
COND. MEMORY |
DOLBY |
||
VOCAL PARTNER |
TRK |
LAST MEMORY |
DIGITAL |
||||
DOWN MIX |
|
|
TOTAL |
|
REMAIN |
||
LFE |
TITLE |
CHP |
|
||||
L |
C R |
|
|||||
|
|
|
|
|
|||
LS S RS |
|
|
|
|
|
|
|
$ |
# |
|
|
@ |
|
|
|
1 96 kHz indicator |
|
|
= DTS indicator |
|
|
Indicates play of a disc outputting an audio signal with a sampling frequency of 96 kHz.
2ANGLE indicator
Indicates Multi-Angle playback is in progress (page 49).
3TITLE indicator
Indicates a title number is being displayed.
4VOCAL indicator
Indicates that the Vocal function is on.
5VOCAL PARTNER indicator
Indicates that the Vocal Partner function is on.
6REPEAT indicator
Indicates that the Repeat function is on (page 50).
7TRK and CHP indicator
Indicates a chapter or track number is being displayed.
8GUI indicator
Lights when the Karaoke or Setup on-screen menus are being displayed (pages 22 and 30).
9LAST MEMORY indicator
Indicates the Last Memory location is recorded in memory for the currently loaded DVD or Video CD (page 53).
0COND. MEMORY indicator
Indicates that Condition Memory settings are memorized for the currently loaded DVD (page 54).
-TOTAL indicator
Indicates that the disc in the player is stopped and DISPLAY has been pressed (page 55).
Indicates DVD DTS audio playback.
~REMAIN indicator
Indicates that the remaining playback time of a title or chapter/track is being displayed.
!DOLBY DIGITAL indicator
Indicates Dolby Digital audio playback on DVDs.
@Counter display
Displays the playback mode, type of disc, title and chapter/track numbers, playback time, etc.
#Program Format indicators
During Dolby Digital playback depending on the audio format recorded on the disc loaded in the player, the following indicators light to show the channels being played back.
L:Left front*1*2, C: Center*1, R: Right front*1*2, LS: Left surround*1, S: Surround (mono)*2,
RS: Right surround*1
LFE: Low frequency effects*1,
*1: Lights to indicate playback of a 5.1 ch Dolby Digital source.
*2: Lights to indicate playback of a Dolby Surround source.
The LFE (low frequency effects) channel indicator indicates 5.1 channel audio that contains a channel for low frequency sounds that are used by the sub woofer.
Note
During playback of Dolby Digital multiplex compatible DVD karaoke discs, the Program Format indicators do not light.
$DOWNMIX indicator
During multichannel audio playback, indicates that the out put signal has been “downmixed” from the original audio source. This is an automatic function performed by the player in order to present the most appropriate audio mix to the speakers present in your system.
12
Rear Panel
1 |
2 3 |
4 5 6 7 |
8 9 |
0 |
- |
|
|
|
Y |
|
|
|
|
|
|
COMPONENT |
|
|
|
|
|
|
VIDEO OUT |
|
|
|
CONTROL |
VIDEO OUT S-VIDEO OUT |
VIDEO |
PB |
|
|
|
TV SYSTEM |
|
|
|
|
||
|
PAL |
OUT |
|
|
|
|
IN |
SELECT |
|
|
|
|
|
|
NTSC AUTO |
|
|
|
|
|
|
|
|
PR |
|
|
|
|
|
|
AUDIO OUT (2CH) |
AUDIO OUT (5.1CH) |
||
|
|
|
1 |
2 |
FRONT |
SURROUND |
|
DIGITAL OUT |
|
|
|
|
|
|
OPT. |
|
L |
|
L |
CENTER |
|
|
|
ATTENUATOR |
|
|
|
|
|
|
OFF |
|
|
|
|
|
|
ON |
|
|
SUB |
|
|
|
R |
|
R |
|
|
|
|
|
WOOFER |
AC IN
FUNCTIONS AND NAMES
1DIGITAL OUT jacks (coaxial, optical (OPT.))
Use to output the digital audio signal recorded on discs. You can output the digital signal via either coaxial or optical output jack to an AV amplifier or receiver (page 18).
2CONTROL IN jack
Use to connect this player to another component bearing the Pioneer ë mark. This lets you control this unit as though it were a component in a system. Player operations are then performed by pointing the remote control at the component that the player is connected to (page 21).
3TV SYSTEM switch
Use to change the TV signal mode to either PAL or NTSC according to the type of TV and disc to be used. When the switch is in the AUTO position, the player outputs the format on the disc as is
(page 21). (The TV SYSTEM switch is not present on DVD-V630.)
4VIDEO OUT jack
Connect to the video input on a TV or monitor or AV amplifier or receiver with video input capability. When using this jack, be sure to set VIDEO OUT SELECT to the left position (page 20).
5S-VIDEO OUT jack
If your TV or monitor has an S-video input, clear picture reproduction is possible by connecting the player to your TV or monitor via the S-video jack. When using this jack, be sure to set VIDEO OUT SELECT to the left position (page 20).
6VIDEO OUT SELECT switch
Use to set which output is used to output the video signals. Select either video/S-video or component video signal output depending on the connections you make (page 20).
7COMPONENT VIDEO OUT jacks
If your projection monitor, projector or similar component has component video inputs, you can produce a higher quality picture on your projection monitor or projector by connecting to the component video outputs on this unit. When using these jacks, be sure to set VIDEO OUT SELECT to the right position (page 20).
8ATTENUATOR switch
Usually set to OFF. Switch it ON if the sound is distorted when enjoying Karaoke (page 37).
9AUDIO OUT (2 CH) jacks
Use to output two-channel audio (analog) to the audio stereo inputs on a TV or stereo amplifier. If you are connecting to a receiver that has both digital and analog input jacks for DVD player connection, it may be beneficial to make both connections (page 19).
0AUDIO OUT (5.1 CH) jacks
Use to output 6 discrete audio channels of decoded digital audio to a receiver or amplifier with discrete audio inputs (page 19).
-AC IN power cord connection terminal
Use to connect the power cord to the wall outlet (page 16).
13
Remote Control
1 |
|
|
|
|
@ |
|
2 |
|
LAST |
CONDITION OPEN/CLOSE |
# |
||
|
|
MEMORY |
MEMORY |
|
|
|
3 |
AUDIO |
SUBTITLE |
ANGLE |
DISPLAY |
$ |
|
4 |
SETUP |
MENU |
TOP MENU |
% |
||
5 |
^ |
|||||
KARAOKE |
|
|
|
|||
|
|
|
RETURN |
& |
||
6 |
SETUP |
|
|
|||
|
|
|
|
* |
||
|
|
|
|
|
||
|
|
ENTER |
|
( |
||
|
PREVIOUS |
|
|
NEXT |
) |
|
7 |
|
|
|
|
||
REV |
PLAY |
FWD |
_ |
|||
8 |
|
|
|
|
||
|
STEP/SLOW |
|
STOP |
+ |
||
9 |
1 |
2 |
3 |
C |
Á |
|
|
|
|
CLEAR |
|
||
0 |
4 |
5 |
6 |
+10 |
ª |
|
|
7 |
8 |
9 |
0 |
£ |
|
- |
PROGRAM |
REPEAT |
A-B |
SEARCH MODE |
||
|
|
|
¢ |
|||
= |
|
PLAYBACK |
|
|
||
|
VNR |
CONTROL |
KEY CONTROL |
|||
~ |
|
1 |
2 |
3 |
° |
|
|
|
DISC |
|
|
||
! |
|
|
|
ë |
¤ |
|
|
|
|
|
(Buttons indicated with * are used for menu operation.)
1 (standby/on) button
Press to switch the player on or to put in standby (pages 26 and 29).
2LAST MEMORY button
You can resume DVD or Video CD playback from the point you last watched even if the disc is removed from the player. Press LAST MEMORY during playback to set a Last Memory point. When you want to resume playback of that disc, press LAST MEMORY in the stop mode and playback starts from the memorized point. Last Memory locations can be stored for up to 5 DVDs and 1 Video CD (page 53).
3AUDIO button
Press repeatedly to select one of the audio languages and/or audio formats programmed on a DVD (page 43).
For Video CD and CD in Normal mode, each press changes the audio output as follows.
=Stereo = 1/L (Left) =2/R (Right)
For Super VCD, each press changes the audio output as follows.
•Normal mode
=1 Stereo =1L =1R
2R +2L +2 Stereo +
•Karaoke mode 1 += 2
4SUBTITLE button
Press repeatedly to select one of the subtitle languages programmed on a DVD or to turn the subtitles off (page 42).
5SETUP button*
Press when the player is in either play or stop mode to open and close the Setup screen (page 30).
6KARAOKE SETUP button*
Press to open or close the Karaoke Setup screen (page 39).
7PREVIOUS 4/NEXT ¢ buttons
During playback, press PREVIOUS 4 to go back to a previous chapter/track and NEXT ¢ to advance to the next chapter/track (page 28).
8REV 1/FWD Á (fast reverse/forward) buttons
During playback of DVD, Super VCD and Video CD, press FWD Á to perform fast forward scanning. Press REV 1 to perform fast reverse scanning of DVD, Super VCD and Video CD. When a CD is loaded, audio scanning is performed (page 28).
14
98 (pause) button
Press to pause playback of a disc. Press again to resume playback (page 47).
0Number buttons (1-9, 0, +10)*
Use to perform direct title and chapter/track searches, and to input numerical values (pages 27, 38, and 48).
-PROGRAMbutton
You can use this button to program up to 24 subsequent tracks while you are singing. (page 38)
=REPEAT button
Press to repeat playback (page 50).
~VNR button
Press to turn on the video noise reduction function (page 27).
!PLAYBACK CONTROL button
Use to switch the playback control for the Super VCD/Video CD on or off. (page 27)
@OPEN/CLOSE 0 button
Press to open or close the disc tray (pages 26 and 29).
#CONDITION MEMORY button
You can store in memory the settings for up to 15 DVDs. Press CONDITION MEMORY during DVD playback to memorize the settings (page 54).
$DISPLAY button
Press during playback to display statistical disc information. Press repeatedly to display different information (page 55).
%ANGLE button
Some DVDs are recorded with various camera angle playback options. Press ANGLE repeatedly to display different camera angles (page 49).
^TOP MENU button*
Press to call up the top menu programmed on the DVD. Depending on the DVD, the top menu may be identical to the DVD menu (page 27).
&MENUbutton*
Use to display or close the DVD menu screen (page 27).
*RETURN button*
Use to go one menu back (current settings are maintained). Use RETURN when you do not want to change the option setting in a menu (pages 27, 31, and 52).
(Cursor buttons (2/3/5/°)*
Use to move through the options on menu screens and to change settings (pages 22, 26, and 30).
)ENTER button*
Use to implement settings selected with the cursor buttons or to set items highlighted in a menu (pages 22, 26, and 30).
_PLAY 3 button
Press to start disc playback (pages 26 and 29).
+STEP/SLOW e/E buttons
Press STEP/SLOW E during playback to view slow playback. In pause mode, press STEP/SLOW E to advance DVDs and Super VCDs/Video CDs frame by frame and STEP/SLOW e to back up a few frames at a time. Reverse STEP/SLOW is not possible with a Super VCD/Video CD. (page 47).
ÁSTOP 7 button
Press to stop playback. In Normal mode, pressing once enables playback to resume from a point shortly before the location where it was stopped. Pressing twice causes the disc to return to the beginning of the disc when playback starts again (page 29).
ªCLEAR button
Works in conjunction with a number of player functions. Use to cancel repeat (page 50).
£SEARCH MODE button
Press to perform a title, chapter/track or time search (page 48).
¢A-B button
Press at the beginning and end of the section you want to repeat or to mark a location you want to return to (page 50).
°KEY CONTROL buttons
Use to adjust the levels of the key in 11 steps. (pages 37 and 41)
¤DISC buttons (1-3)
Use to select discs in the player directly (page 26).
FUNCTIONS AND NAMES
15
Making
Connections
Connecting Your DVD Player
Unlike any other audiovisual media format, DVD offers a wide array of audio and video output options which allows playback to be enjoyed in any number of system configurations from a standard TV with stereo audio input to a home theater system with a projection monitor and full surround sound capabilities.
Connection Guide
The illustration on this page shows the basic setup using the audio and video cords included with this player. Use this illustration as a guide to setting up your home system.
An explanation of each type of audio and video connection available can be found on the following pages. To determine the best audio and video connection setup for your system, refer to the manuals supplied with the components you are making connections to.
In addition to making physical connections to your TV or monitor, it is also necessary to assign the TV screen size. You can use the [Setup Navigator] in the Setup screen General menu to set whether you are using a wide screen or standard size TV or monitor (page 23). Additionally, you can use the [TV Screen] setting in the Setup screen Video menu (page 34).
Notes
•When making connections to this unit or when changing
connections, check that the unit is in standby (off) by pressing STANDBY/ON (POWER), and unplug the power cord from the power outlet.
•The analog video output on this player uses copy protect circuitry to prevent the video playback on DVDs from being copied. If you connect the player to a TV via a VCR, or record and playback the contents of a disc with a VCR, the playback picture may not be normal.
|
|
|
Y |
|
|
|
|
|
|
COMPONENT |
|
|
|
|
|
|
VIDEO OUT |
|
|
|
CONTROL |
VIDEO OUT S-VIDEO OUT |
VIDEO |
PB |
|
|
|
TV SYSTEM |
|
|
|
|
||
|
PAL |
OUT |
|
|
|
|
IN |
SELECT |
|
|
|
|
|
|
NTSC AUTO |
|
|
|
|
|
|
|
|
PR |
|
|
|
|
|
|
AUDIO OUT (2CH) |
AUDIO OUT (5.1CH) |
||
|
|
|
1 |
2 |
FRONT |
SURROUND |
|
DIGITAL OUT |
|
|
|
|
|
|
OPT. |
|
L |
|
L |
CENTER |
|
|
|
ATTENUATOR |
|
|
|
|
|
|
OFF |
|
|
|
|
|
|
ON |
|
|
SUB |
|
|
|
R |
|
R |
|
|
|
|
|
WOOFER |
AC IN
Video cord (Included)
TV or monitor
VIDEO IN |
S-VIDEO IN |
Make video connections from the VIDEO OUT jack on the player to the VIDEO IN jack on the TV or monitor using the video cord included with the player. Set the VIDEO OUT SELECT to the left position.
Audio cord (Included)
DV-K302CD: Finally, connect to a power outlet (110–127 V, 220–240 V). DVD-V630: Finally, connect to a power outlet (120 V).
L R
AUDIO IN
Make audio connections from one of the AUDIO OUT jacks on the player to the AUDIO IN jacks on the TV or monitor using the stereo audio cord included with the player. Be sure to match the color of the plugs with the color of the jacks (red and white).
When music sounds distorted during Karaoke, set the attenuator switch to the ON position.
16
Home Theater Component
Connections
The connections on this page demonstrate the versatility of this player to conform to any number of home entertainment systems.
Please note that the illustration shown on this page is meant as an example. Please refer to the manuals supplied with the components to which you are making connections to determine the best possible setup for your home system.
An explanation of each type of audio and video connection available can be found on pages 18 to 20.
S-video connection produces a high quality video image. If you have a TV or monitor that features an S-video input, make video connections from the S-VIDEO OUT jack on the player to the S-VIDEO IN jack on the TV or monitor using an S-video cord (not included).
|
|
|
Y |
|
|
|
|
COMPONENT |
|
|
|
|
VIDEO OUT |
|
CONTROL |
VIDEO OUT S-VIDEO OUT |
VIDEO |
PB |
|
TV SYSTEM |
|
|
||
|
PAL |
OUT |
|
|
IN |
SELECT |
|
|
|
|
NTSC AUTO |
|
|
|
|
|
|
PR |
|
|
|
|
AUDIO OUT (2CH) |
|
|
|
|
1 |
2 |
|
DIGITAL OUT |
|
|
|
|
OPT. |
|
L |
|
|
|
|
ATTENUATOR |
|
|
|
|
OFF |
|
|
|
|
ON |
|
|
|
|
R |
|
TV or monitor
VIDEO IN S-VIDEO IN
S-video cord (Not included)
AUDIO OUT (5.1CH)
FRONT |
SURROUND |
L |
CENTER |
R |
SUB |
WOOFER |
AC IN
CONNECTIONS MAKING
Coaxial cord (Not included)
Make connections from the DIGITAL OUT (coaxial.) on the player to the digital coaxial input on an AV receiver, amplifier or other component with internal multichannel decoding capabilities.
AV amplifier or receiver
DIGITAL IN
2 stereo audio audio cords (1 included), and 2 single
cords (or
another stereo audio cord)
(not included)
5.1 CH INPUT
CENTER
L
R
FRONT SURROUND SUB
WOOFER
DV-K302CD: Finally, connect to a power outlet
(110–127 V, 220–240 V) DVD-V630:
Finally, connect to a power outlet (120 V)
Make connections from the AUDIO OUT (5.1 CH) on the player to an AV receiver or amplifier with 6 channel discrete input, often referred to as “5.1 channel ready” or “Dolby Digital ready”. This allows you to use the high quality Dolby Digital decoding capabilities of the player (page 19). When making this kind of connection, be sure to select “5.1 Channel” in the Setup Navigator [Analog Jacks] screen, in the Setup screen Audio 2 menu [Audio Out] setting, or by pressing 5.1 CH MODE on the front panel (pages 24 and 31).
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Front |
|
Front |
Center |
|
Rear |
|
Rear |
Sub woofer |
|||||
Speaker (L) |
Speaker (R) |
Speaker |
Speaker (L) |
Speaker (R) |
||||||||||
|
17
Audio Connections
This player features two digital (optical and coaxial) and also analog 2 channel and 5.1 channel audio output connection possibilities.
Digital Audio Connections:
You can enjoy the digital audio recorded on DVD discs from both optical digital and coaxial digital output jacks.
When making digital audio connections, do not make connections from both the coaxial and optical digital outputs to the same component.
When a DVD recorded in Dolby Digital, DTS, or MPEG is loaded, noise will be output if you have made connections via the digital audio jacks to a receiver or amplifier that cannot decode a Dolby Digital, DTS, or MPEG digital bitstream. In this case, be sure to set the [Digital Jack] setting in the Setup Navigator to best reflect the type of system you are using (page 25). Additionally, the digital audio settings can be adjusted manually in the Setup screen Audio 1 menu (page 33).
DIGITAL OUT (Optical)
The digital signal is transmitted as light pulses through a optical cable.
•Use to connect to an AV amplifier or receiver with built-in Dolby Digital, DTS, or MPEG decoder.
•Use a optical cable (not supplied) to connect the digital optical output on the player to the digital optical input on an AV amplifier or receiver.
AV amplifier or receiver with built-in Dolby Digital, DTS, or MPEG decoder
DIGITAL OUT (Coaxial)
The digital signal is transmitted electronically through a coaxial cable.
•Use to connect to an AV amplifier or receiver with built-in Dolby Digital, DTS, or MPEG decoder.
•Use a coaxial cable (not supplied) to connect the coaxial digital output on the player to the coaxial digital input on an AV amplifier or receiver.
AV amplifier or receiver with built-in Dolby Digital, DTS, or MPEG decoder
DIGITAL OUT
DIGITAL IN
OPT.
Note
There is no digital output when using Karaoke mode.
DIGITAL OUT |
DIGITAL IN |
OPT. |
Note
There is no digital output when using Karaoke mode.
18
Analog Audio Connection:
After making physical connections to either the AUDIO OUT (2 CH) or AUDIO OUT (5.1 CH) analog jacks, be sure to identify which output you are going to be using in the [Analog Jacks] screen of the Setup Navigator
(page 24). You can also manually set the output in the [Audio Out] setting of the Setup screen Audio 2 menu (page 31).
Notes
•When “5.1 Channel” is selected, the front right (R) and front left
(L) audio channels output from the AUDIO OUT (2 CH) analog jacks (page 31).
•The [Audio Out] setting creates an audio output default for the player. If connections are made to both AUDIO OUT (2 CH) and AUDIO OUT (5.1 CH) analog jacks to make different audio connections for multichannel and stereo audio sources, it is possible to switch between 2 channel and 5.1 channel audio output by pressing 5.1 CH MODE on the front panel. However, this button does not work when the GUI indicator is lit.
2 CHANNEL AUDIO OUT
•Make analog audio connections to a stereo amplifier or receiver.
•Analog audio connections can also be made to a TV or monitor with stereo input jacks.
•Use the supplied audio cable to connect one of the AUDIO OUT (2 CH) analog jacks on the player to the audio input on the stereo amplifier or receiver.
•When making analog audio connections, be sure to match the color of the plugs with the color of the jacks (red and white).
Stereo amplifier or receiver
5.1 CHANNEL AUDIO OUT
5.1 channel audio refers to the current industry surround sound standard requiring two front speakers, a center speaker, two surround (rear) speakers and a sub woofer. Although in actuality there are 6 channels; because the sub woofer channel, or LFE channel, makes up a mere fraction of the total audio soundtrack, it has been designated as the 0.1 of the 5.1 system.
By utilizing the player’s internal multichannel audio decoder, the audio of Dolby Digital DVDs can be output from the 5.1 channel discrete outputs to an AV amplifier or receiver with 5.1 channel input capability.
• |
Use audio cables to make connections from the |
|
||||||||
|
player’s AUDIO OUT (5.1 CH) jacks to the equivalent |
|
||||||||
|
input jacks on the AV amplifier or receiver. |
MAKING |
||||||||
• |
When making 5.1 channel analog audio connections, |
|||||||||
|
||||||||||
|
be sure to match the left and right channels on both |
|
||||||||
|
components, and also make sure that the jacks of all |
CONNECTIONS |
||||||||
|
the channels are connected correctly on both |
|||||||||
|
|
|||||||||
|
components. |
|
||||||||
• |
Either 2 single audio cords or a stereo cord may be |
|
||||||||
|
used to connect the CENTER and SUB WOOFER |
|
||||||||
|
channels to the AV amplifier or receiver. |
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
AUDIO OUT (5.1CH)
FRONT |
SURROUND |
L |
CENTER |
R |
SUB |
WOOFER |
AUDIO OUT (2CH)
1 2
L
AUDIO IN
R L
5.1 CH INPUT
CENTER
R
L
R
FRONT SURROUND SUB
WOOFER
TV or monitor
AV amplifier or receiver
AUDIO OUT (2CH)
1 2
L
AUDIO IN
R L
R
19
Video Connections
This player features S-video, composite video, and component video output possibilities. Check the manual supplied with your TV or monitor to determine the best possible connection for your system.
In addition to making physical connections to your TV or monitor, it is also necessary to assign the TV screen size. You can use the [Setup Navigator] in the Setup screen General to set whether you are using a wide screen or standard size TV or monitor (page 23). Additionally, you can use the [TV Screen] setting in the Setup screen Video menu (page 34).
S-VIDEO OUT
•Make S-video connections to a TV or monitor with S-video input to produce a high quality video image.
•Use an S-video cable (not supplied) to connect the output on the player to S-video input on the TV or monitor.
•When making S-video connections, be sure to set the VIDEO OUT SELECT switch on the rear panel of the player to the left to assign S-video output.
VIDEO
OUT
SELECT
TV or monitor
S-VIDEO OUT |
S-VIDEO IN |
VIDEO OUT
•Make composite video connections to a standard TV or monitor with a video input jack.
•Use the supplied video cable to connect the video output jack on the player to the video input on the TV or monitor.
•Be sure to match the color of the plug with the color of the jack (yellow).
•When making video connections, make sure to set the VIDEO OUT SELECT switch on the rear panel of the player to the left to assign composite video output.
VIDEO
OUT
SELECT
TV or monitor
VIDEO OUT |
VIDEO IN |
COMPONENT VIDEO OUT
•Make component video connections to a projection monitor, projector or TV with component inputs to produce a higher quality video image.
•Use component video cables or 3 video cords (not supplied) to connect the COMPONENT VIDEO OUT jacks on the player to the component jacks on the monitor.
•When making component video connections, make sure to set the VIDEO OUT SELECT switch on the rear panel of the player to the right to assign component video output.
Projection monitor, projector or TV
VIDEO
OUT
SELECT
COMPONENT
VIDEO IN
Y
Y
COMPONENT
VIDEO OUT
PB
PB
PR
PR
20
