BA C D
VG073100
VG073200
1
VE209900
VG072700
VG073300
VG073000
VC174000
VE089300
VC193200
VC271400
A
VC265600
VG072900
VC195300
A
VG073500
VC265600
VG072600
VG072400
2
3
VG073400
VC265300
VC265600
VG072000
VG071000
VG072100
VC271400
VG072500
VG072300
VG072200
VG071900
VG071100
VG071800
VC269600
VC271400
VG051100
VG072800
VG071600
VG071700
VG071500
VG071400
VG051100
VG071300
VG070900
VG071200
VC265300
VG051100
4
VG070500
VG070400
VG070600
VG070700
VG070300
Ver.1
2004.10
VG070800
EXPLODED PARTS DIAGRAM
MODEL
C-70 ZOOM / C-7000 ZOOM
OLYMPUS IMAGING CORP.
FIG.
1/2
BA C D
1
2
VG078200
VG078300
VG078100
VG079200
VC265600
VG079100
VG078800
VG078400
VG078900
VG078600
VC446700
VG079000
VC449100
VG079800
VG079300
VG056100
VG079700
VG080700
VG079400
VG078700
VG077700
VG076500
VG079600
VG079500
VG073600
VG077800
VG077900
VG079900
VG080100
VG080200
VG076900
VG080700
VG072100
VG080000
VG072100
VG051100
VG080500
VG073600
VG080400
VG080300
VC273000
3
VG080800
VG073900
VJ757800
VE712800
VE712900
VE713000
VE713100
VE713200
4
VG073800
VG072100
VG080600
VG074100
VG074000
WE126312
VG080700
VC273000
VG080700
VG078000
VC269700
VG074200
VG074900
VG074800
VG073700
VG078500
VG077400
VG075300
VG075000
VG074300
VG074700
WE132026
VE713300
VG077500
VG077300
VG075100
VG074400
VG075400
VG074600
VG074500
VG075500
VG075600
VG073600
VG077200
VG075200
VC269700
VG075900
VG075700
Ver.1
2004.10
VG077100
VG076300
VG072100
VG080700
VG076000
VG077600
VG077000
VG076800
VG076500
VG080700
VG072100
VG076400
VG051100
VG076200
VG051100
VG073600
EXPLODED PARTS DIAGRAM
MODEL
C-70 ZOOM / C-7000ZOOM
OLYMPUS IMAGING CORP.
VG076700
VG080700
VG076600
VG080700
VG080700
VG076100
VG075400
VG075800
FIG.
2/2
PARTS LIST C-70ZOOM / C-7000ZOOM
REF NO PARTS NO DESCRIPTION REMARKS NOTE
VC174000 STRAP RING 1-A1
VC193200 SPRING CLICK 1-B1
VC195300 STRAP HOLDER 1-B1
VC265300 SCR S-TPG PAN PCS 1.7X4 1-A3,1-C4
VC265600 SPECIAL SCREW-1.7X2.2 1-A2,etc
VC269600 SCR S-TPG PAN PCS 1.7X4.5 1-C2
VC269700 SCR S-TPG PAN PCS 1.7X4.0 2-A3,2-C3
VC271400 SCR S-TPG PAN PCS 1.7X3 1-B1,etc
VC273000 SCR S-TPG PAN PCS 1.7X3.5 2-A2,2-A3
VC446700 B SPRING 2-B1
VC449100 BATTERY LABEL 2-B2
F5004 VC796600 FUSE 32V 6A PW-1
F5001 VC796700 FUSE 32V 2A PW-1
VE089300 CLICK BALL 1-B1
VE209900 MOUNTING STRAP,R 1-A1
VE712800 Parallax Spacer 1 2-A4 NEW
VE712900 Parallax Spacer 2 2-A4 NEW
VE713000 Parallax Spacer 3 2-A4 NEW
VE713100 Parallax Spacer 4 2-A4 NEW
VE713200 Parallax Spacer 5 2-A4 NEW
VE713300 F Screw 2-B4 NEW
VG051100 PUK SCREW 1.7X2 1-B4,etc
VG056100 CAUTION LABEL 2-C2
VG070300 FRONT RING 1-A4 NEW
VG070400 F RING TAPE 1-B4 NEW
VG070500 LENS EARTH 1-B4 NEW
VG070600 FRONT COVER 1-B4 NEW
VG070700 FRONT COVER U 1-B4 NEW
VG070800 DC COVER 1-C4 NEW
VG070900 FRONT RING HOLDER 1-C4 NEW
VG071000 SPACER FRONT 1-A3 NEW
VG071100 SPACER CUSHION ST A 1-B3 NEW
VG071200 DC HOLDER 1-D4 NEW
VG071300 EARTH RIGHT 1-D4 NEW
VG071400 WIRE TB1-LCD 1-D3 NEW
VG071500 SPACER WIRE LCD 1-D3 NEW
VG071600 LCD 1-D2 NEW
VG071700 SPACER CUSHION ST B 1-D2 NEW
VG071800 MULTI HOLDER TAPE 1-C2 NEW
VG071900 MULTI HOLDER 1-B3 NEW
VG072000 SPACER BACK 1-A3 NEW
VG072100 EARTH SPRING 2-A2,etc NEW
VG072200 BACK SWITCH UNIT 1-B2 NEW
VG072300 BACK SWITCH UNIT HOLDER B 1-B2 NEW
VG072400 BACK TAPE D 1-A2 NEW
VG072500 SPACER TOP UNIT 1-B2 NEW
VG072600 TOP SWITCH UNIT 1-C2 NEW
VG072700 MULTI COVER 1-B1 NEW
VG072800 BACK COVER UNIT 1-D2 NEW
VG072900 LCD DECORATION 1-D1 NEW
VG073000 VF DECORATION 1-D1 NEW
VG073100 ST BUTTON 1-D1 NEW
VG073200 ST BUTTON SPRING 1-C1 NEW
CODE:20
Ver.1
- 1/3 -
PARTS LIST C-70ZOOM / C-7000ZOOM
REF NO PARTS NO DESCRIPTION REMARKS NOTE
VG073300 SPACER HOOK 1-C1 NEW
VG073400 SCR THIN 1.7X2 1-A2 NEW
VG073500 SCR PAN PCS 1.4X5 1-A2 NEW
VG073600 SPACER CONNECTOR 1-B4,etc NEW
VG073700 SPACER LENS B 2-A4 NEW
VG073800 SPACER LENS A 2-A4 NEW
VG073900 SPACER VF 2-A4 NEW
VG074000 TB-4 BOARD 2-A3 NEW
VG074100 LED SPRING 2-A3 NEW
VG074200 LED HOLDER 2-A3 NEW
VG074300 FPC UNIT 2-B3 NEW
VG074400 LPF 2-B4 NEW
VG074500 SPACER 2-B4 NEW
VG074600 CA-1 BOARD 2-B4 NEW
VG074700 LENZ FTP TAPE 2-B4 NEW
VG074800 SHIELD TAPE B-B S 2-B3 NEW
VG074900 SHIELD TAPE B-B M 2-B3 NEW
VG075000 FPC UNIT B 2-B3 NEW
VG075100 SPACER CUSHION CP1 2-B3 NEW
VG075200 SPACER CUSHION CA1 2-C3 NEW
VG075300 SHIELD TAPE B-B L 2-B3 NEW
VG075400 SPACER CA1 2-D3 NEW
VG075500 FPC CP1-TB1 2-B4 NEW
VG075600 SHIELD TAPE CP1-TB1 2-B4 NEW
VG075700 SPACER FPC 2-C4 NEW
VG075800 BOTTOM HOLDER 2-D4 NEW
VG075900 SPACER TB1 2-C4 NEW
VG076000 TB-1 BOARD 2-C4 NEW
VG076100 HOLDER CHASSIS 2-D3 NEW
VG076200 SHIELD CHASSIS 2-D3 NEW
VG076300 STAND 2-C3 NEW
VG076400 SPACER HOLDER CHASSIS 2-C3 NEW
VG076500 SPACER ST 2-C1,2-D3 NEW
VG076600 LCD HOLDER 2-D3 NEW
VG076700 ST UNIT 2-D2 NEW
VG076800 SPACER ST WIRE 2-C2 NEW
VG076900 SI TUBE S 2-D2 NEW
VG077000 SI TUBE L 2-C2 NEW
VG077100 SPEKER COVER 2-C3 NEW
VG077200 MICROPHONE 2-C3 NEW
VG077300 SPEAKER 2-B2 NEW
VG077400 SPEAKER PLATE HOLDER 2-B3 NEW
VG077500 BATTERY COVER 2-B2 NEW
VG077600 SLIDE PLATE 2-C2 NEW
VG077700 HINGE HOLDER 2-C2 NEW
VG077800 XD SW LEVER 2-C2 NEW
VG077900 XD SW LEVER SPRING 2-D2 NEW
VG078000 TB-2 BOARD 2-A2 NEW
VG078100 SPACER WIRE CRIP 2-A2 NEW
VG078200 FPC CP1-TB2 2-A1 NEW
VG078300 SPACER TB2 2-A1 NEW
VG078400 SHIELD TAPE PW1 2-A1 NEW
VG078500 SHIELD TAPE BAT 2-B2 NEW
CODE:20
Ver.1
- 2/3 -
PARTS LIST C-70ZOOM / C-7000ZOOM
REF NO PARTS NO DESCRIPTION REMARKS NOTE
VG078600 BATT HOLDER COVER 2-B2 NEW
VG078700 BATTERY HOLDER 2-C2 NEW
VG078800 BATTERY TERMINAL 2-A1 NEW
VG078900 WIRE BATT- 2-B1 NEW
VG079000 WIRE BATT+ 2-B1 NEW
VG079100 BATT LOCK LEVER 2-A1 NEW
VG079200 LOCK LEVER SPRING 2-A1 NEW
VG079300 SPACER HOLDER BATT 2-C1 NEW
VG079400 SPACER HOLDER 2-C2 NEW
VG079500 HINGE SHAFT HOLDER 2-C1 NEW
VG079600 CAPACITOR TAPE 2-C1 NEW
VG079700 PW-1 BOARD 2-C1 NEW
VG079800 SPACER WIRE SIDE 2-C1 NEW
VG079900 EARTH CP1-PW1 2-D1 NEW
VG080000 XD COVER 2-D1 NEW
VG080100 XD COVER TAPE 2-D1 NEW
VG080200 SPACER XD 2-D2 NEW
VG080300 CP-1 BOARD 2-D2 NEW
VG080400 SPACER CP1 2-D2 NEW
VG080500 SHIELD TAPE CP1 2-D1 NEW
VG080600 SPACER LED 2-A3 NEW
VG080700 SCR S-TPG PAN PCS 1.7X3.5 2-A2,etc NEW
VG080800 SCR S-TPG PAN PCS 1.7X5 2-A3 NEW
S3001 VG080900 SWITCH,PUSH 1T-1P CP-1 NEW
VJ720300 Lens-Assy Cab2 NEW
VJ757800 Finder-Assy 2-A4 NEW
WE126312 PUTB1.6-445SN 2-A3
WE132026 3PUTB1.6x4SN 2-B4
VT984300 Rated Label J (For Japan) NEW
VT984400 Rated Label U (For North America) NEW
VT984500 Rated Label EG (For Europe/Oceania/Asia/Taiwan) NEW
VT984600 Rated Label C (For China) NEW
VE825500 Rated Label Jk (For Japan, Made in Korea) NEW
VE825600 Rated Label Uk (For North America, Made in Korea) NEW
VE825700 Rated Label EGk (For Europe/Oceania, Made in Korea) NEW
VE946400 Rated Label B (For Asia/Taiwan, Made in Korea) NEW
VT472100 Rated Label Gk2 ("MADE IN KOREA" sticker)
VT984600 Rated Label CC (For China, Made in China) NEW
CODE:20
Ver.1
- 3/3 -
