D-565ZOOM/C-450ZOOM
E. NOTICE OF MODIFICATION
Version-up of Firmware(1) ..................................................................................... E-2
Appearance change of parts .................................................................................. E-3
Addition of the finder screw (counterclockwise screw) ..................................... E-4
Change of the battery label ................................................................................... E-5
Change of parts ..................................................................................................... E-6
Rev .5
E-1 Ver.1
E. NOTICE OF MODIFICATION
D-565ZOOM/C-450ZOOM
SUBJECT
Version-up of Firmware (1)
2003.Sep.02
DESCRIPTION : The firmware for D-565ZOOM/C-450ZOOM is changed.
OLD NEW
v752-75 >>> v752-76
REASON : The modification of the following phenomenon
1.The recording to the memory card is not completed when the following operation is performed during
the recording to the card.
a: The changing of the image quality mode and the taking picture are repeated so that a buffer is not full.
b: The release button is kept pushing under the condition that memory card is almost full.
2. A blue frame is displayed on LCD monitor in the following operation.
a:QUICK-VIEW button is pushed when a memory card is full.
b:VIDEO-OUT cable is connected or disconnected.
3.A lens does not move when cover lens was opened after camera resetting was done in a cover lens
closed.
( camera reset: OK-button and QUICK-VIEW button are pushed at the same time in cover lens closed )
4.Indication of LCD monitor is separated into two parts when OK-button is pushed and a card cover
is opened after taking a photograph in LCD monitor is off.
5.USB communication fails on PC which VIA’s IC was built into.
REMARKS :update procedure
Refer to the D-3 of Service Maual .
OBJECT : Perform for all camera returned from a market.
E-2
Rev.1
Ver.1
D-565ZOOM/C-450ZOOM
E. NOTICE OF MODIFICATION
SUBJECT
Appearance change of parts
DESCRIPTION :
The design of VE462200 (1ZCoverRing) has been changed to ones without hair lines.
OLD NEW
2004.Jan.21
REASON :
Parts of a new product are reversely shared.
REMARKS :
The part number is not changed.
Old parts are not defective parts. (Running change)
Rev.2
Ver.1
E-3
E. NOTICE OF MODIFICATION
D-565ZOOM/C-450ZOOM
SUBJECT
Addition of the finder screw (counterclockwise screw)
DESCRIPTION : Finder screw (counterclockwise screw) is added.
Parts No. Parts Name
VE680100 PUTB1635L
REASON :
Finder screw was changed for improvement of the manufacturing process.
Along with the change, new finder screw is registered as a service part.
REMARKS :
Take actions below upon repair.
1. Basically, use original screws that are with the camera.
2. If use new Lens-ASSY or BaseFrame-ASSY, use the counterclockwise screw.
May.12.2004
E-4
Rev.3
Ver.1
D-565ZOOM/C-450ZOOM
E. NOTICE OF MODIFICATION
SUBJECT
Change of the battery label
DESCRIPTION : The battery label has been changed.
OLD NEW
VC194200 >>> VC236000
REASON :
An illustration of CR-V3 is added.
REMARKS :
Only new parts are supplied when old parts stock is used up (running change) .
Parts list will be updated when old parts stock is used up.
Jun.28.2004
Rev.4
Ver.1
E-5
E. NOTICE OF MODIFICATION
SUBJECT Change of Parts Aug.09.2004
D-565ZOOM/C-450ZOOM
DESCRIPTION : Change of Parts
OLD NEW
2ZFrame-ASSY VJ457800 > VJ457801
REASON :
Change common parts along with parts change of µ-10/µ [mju:] 300/Stylus 300 DIGITAL.
REMARKS :
Running change.
E-6
Rev.5
Ver.1
