Northstar 230 CDS User Manual

230 CDS

/ ENGLISH

1. DECLARATION OF CONFORMITY OF RECREATIONAL CRAFT WITH THE DESIGN, CONSTRUCTION AND NOISE EMISSION REQUIREMENTS OF DIRECTIVE 94/25/EC AS AMENDED BY

DIRECTIVE 2003/44/EC..................................................................................... 1

2. HOMOLOGATION, CERTIFICATION, DESIGN CATEGORY AND

IDENTIFICATION .............................................................................................. 4

2.1. EXPLANATION OF MANUFACTURER’S PLATE: ................................ 4

2.2. TECHNICAL DATA................................................................................... 5

2.3. CE CERTIFICATE ...................................................................................... 6

2.4. LOCATION OF FITTINGS AND ELECTRICAL EQUIPMENT..............7

2.5. LOCATION OF SEACOCKS AND THROUGH-HULL FITTINGS..........8

2.6. BLACKWATER SYSTEM.......................................................................... 8

3. SYSTEMS AND CIRCUITS............................................................................ 9

3.1. FIRE EXTINGUISHER SYSTEM............................................................... 9

3.2. ELECTRICAL SYSTEM............................................................................. 9

INDEX

NORTHSTAR MANUAL

Other Community Directives applied:

1. Declaration of Conformity of Recreational Craft with the Design, Construction and Noise Emission requirements of Directive 94/25/EC

DESCRIPTION OF CRAFT

as amended by Directive 2003/44/EC

Name of craft manufacturer: NORTHSTAR TEKNE ÜRETİMİ A.Ş.

Address : MOLLAFENARİ YOLU PELİTLİ KÖYÜ MEVKİİ

Town: GEBZE / KOCAELİ

Name of Authorised Representative (if applicable): 

Address: 

Town: 

Name of Notified Body for design and construction assessment

Address: Rue Abblé Cuypers 3

Town: BRUXELLES

ECtype-examination Certificate number:BMTSVT013

Name of Notified Body for noise emission assessment

Address: 

Town: 

Post Code: B-1040 Country: BELGIUM ID Number:0609

Post Code:  Country:  ID Number:

Post Code: TR - 41400 Country: TURKEY

Post Code:  Country: 

(if applicable): IMCI

Date: (yr/month/day) 2006 / 01 / 06

(if applicable): 

Craft Identification Number

T R M A R

Brand name of the craft: NORTHSTAR 230 CDS

Type of craft:

sailboat motorboat

inflatable

other (specify): 

Type of hull:

monohull multihull

other (specify): 

Construction material:

aluminium, aluminium alloys plastic, fiber reinforced plastic

steel, steel alloys wood



        

Type or number: POWER IB

Module used for construction assessment:

A Aa B+C B+D B+E B+F G H

Module used for noise emission assessment :

A Aa G H

other (specify): 

Maximum Design Category: A

Engine power: Max. Recommended: 172

Installed:

kW (if applicable)

B C D

kW,

NORTHSTAR MANUAL

Length of hull L

Type of main Propulsion:

sails petrol engine

diesel engine electric motor

oars

other (specify): 

Type of engine:

outboard inboard

z or sterndrive without integral exhaust

z or sterndrive with integral exhaust

other (specify): 

Deck

fully decked partly decked

open

: 7,39m Beam of hull Bh: 2,49 m Draught T: 0,49 m

(identification of the person empowered to sign on behalf of the manufacturer or his authorised representative)

Date and place of issue: (yr/month/day)  /  / 

(or an equivalent marking)

other (specify):

This declaration of conformity is issued under the sole responsibility of the manufacturer. I declare on behalf of the craft manufacturer that the craft mentioned above complies with all applicable essential requirements in the way specified (and is in conformity with the type for which above mentioned EC type examination certificate has been issued) – delete text between brackets if no EC type examination certificate has been issued

Name and function:Cengiz ARSAY Signature and title:President

NORTHSTAR MANUAL

methods

Essential requirements

(reference to relevant articles in

Other

normative

nnex IA & IC of the Directive)

General requirements (2)

Craft Identification Number – CIN (2.1) EN ISO 10087:2006 *

Builder’s Plate (2.2) 14945

Protection from falling overboard and means o reboarding (2.3)

Visibility from the main steering position (2.4) 11591

Owner’s manual (2.5) 10240

Integrity and structural requirements (3)

Structure (3.1) 12215 – 1, 12215-4

Stability and freeboard (3.2) 12217 – 1

Buoyancy and floatation (3.3) 12217 – 1

Openings in hull, deck and superstructure (3.4) 9093 , 9094 - 1 , 12216

Flooding (3.5) 11812

Manufacturer’s maximum recommended load (3.6)

Liferaft stowage (3.7) 9650

Escape (3.8) 12216

Anchoring, mooring and towing (3.9) 15084

Handling characteristics (4) 11592

Standards

15085

14946

document/

Please specify in more detail

file

Technical

: Mandatory Standards)

EN ISO 8666:2002 *

Fuel system (5.2)

General – fuel system (5.2.1) 7840

Fuel tanks (5.2.2) 10088

Electrical systems (5.3) 10133

Steering systems (5.4)

General – steering system (5.4.1) 8848, 10592

Emergency arrangements (5.4.2)

Gas systems (5.5) 10239

Fire protection (5.6)

General – fire protection (5.6.1) 9094 - 1

Fire-fighting equipment (5.6.2) 9094 - 1

Navigation lights (5.7) COLREG / CEVNI

Discharge prevention (5.8) 8099

Annex I.B – Exhaust Emissions

nnex I.C – Noise Emissions2

Noise emission levels (I.C.1)

Owner’s manual (I.C.2)

see the Declaration of Conformity of the engine manufacturer

Engines and engine spaces (5.1)

Inboard engine (5.1.1) 9094

Ventilation (5.1.2) 11105

Exposed parts (5.1.3)

Outboard engine starting (5.1.4)

(*) Only to be completed for boats with inboard engines or sterndrive engines without integral exhaust

NORTHSTAR MANUAL

2. HOMOLOGATION, CERTIFICATION, DESIGN CATEGORY AND IDENTIFICATION

HIN : TR-MAR

Please write your boat’s HIN above.

Built by:

NORTHSTAR TEKNE URETIMI A.S.

PK 39 Gebze - Kocaeli - 41400 Turkey

for

NorthStar AS

Via Santa Franca 41,29100 Piacenza (PC) - ITALY

Category of design B (offshore) inspected by International Marine Certification Institute (IMCI)

2.1. EXPLANATION OF MANUFACTURER’S PLATE:

The manufacturer’s plate, which is fixed at the console, looks like the following:

Design Category B

The boat was built for the category of design B (Offshore)

Your boat has been certified to be in compliance with the relevant parts of the Recreational Craft Directive 94/25/EC as amended by Directive 2003/44/EC of the European Parliament. The CE mark on your boat means that your boat meets or exceeds applicable ISO (International Standards Organization) standards available at the time of manufacture.

Your rigid boat has been tested in regard to stability, freeboard, buoyancy and flotation according to EN ISO 12217-1 and your inflatable boat according to EN ISO 6185-3 so that, the requirements for the number of persons allowed and the additional loading could be determined.

Category B: Designed for offshore voyages where conditions up to, and including, wind force 8 and significant wave heights up to, and including 4 meters may be experienced.

The significant wave height is the mean height of the highest one-third of the waves, which approximately corresponds to the wave height estimated by an experienced observer. Some waves will be double this height.

For craft with outboard engines, mass of the craft in the light craft (unladen) condition (kg) includes the mass of the heaviest recommended outboard engine, but in some cases (a small rowing or outboard tender for example) the craft may be used with or without the outboard. In these

NORTHSTAR MANUAL

cases, it would be useful to also know the weight without the outboard motor (perhaps to see if it is light enough to carry on a car roof).

Max. = Maximum number of persons recommended

Max. + + = Maximum loading weight

Maximum recommended load includes the weight of all persons onboard, all provisions and personal effects, any equipment not included in the light craft mass, cargo (if any) and all consumable liquids (water, fuel, etc.)

Do not exceed the maximum number of persons. Regardless of the number of persons on board, the total weight of persons and equipment must never exceed the maximum recommended load. Always use the seats/seating spaces provided.

2.2. TECHNICAL DATA

Length Overall : 7,39 m.

Length Waterline : 6,19 m.

Beam : 2,49 m.

Draught : 0,49 m.

Freeboard : 1,03 m.

Weight without Engine : 1750 kg.

Max. Loading Weight (*) : 600 kg.

Max. Number Of Person (*) : 6

Max. Power (Petrol) : 172 kW (230 HP)

Design Category : B

Battery : 12V - See your engine’s manual for

recommendation

Fuel Tank Capacity : 280 lt.

Water Tank Capacity : 45 lt.

Holding Tank Capacity : 45 lt.

Strong points : 3 U bolts provided – one at the bow

and two at the stern

When loading the craft, never exceed the maximum recommended load. Always load the craft carefully and distribute loads appropriately to maintain design trim (approximately level). Avoid placing heavy weights high up.

0609 CE-marking with EC-identification number of the notified body, International Marine Certification Institute, as a proof that the boat was built according to the requirements of the Directive for Recreational Crafts 94/25/EC as amended by Directive 2003/44/EC.

Electric Bilge Pump Capacity : 2 x 31.5 l/min.

Manual Bilge Pump Capacity : 49 l/min.

(*) Recommended values

NORTHSTAR MANUAL

2.3. CE CERTIFICATE

NORTHSTAR MANUAL

2.4. LOCATION OF FITTINGS AND ELECTRICAL EQUIPMENT

A : ELECTRIC BILGE PUMP

B : GAS CONTAINER

C : WATER FILL

D : MANUAL BILGE PUMP

E : MAIN BATTERY SWITCH

F : ELECTRIC BILGE PUMP

G : AUTOMATIC FIRE EXTINGUISHER

H : BLACKWATER DISCHARGE

I : FUEL FILL

J : FIRE EXTINGUISHER

K : LIFERAFT AREA

L : EXIT

M : EXIT

(*) Not available in all models

NORTHSTAR MANUAL

2.5. LOCATION OF SEACOCKS AND THROUGH-HULL FITTINGS

2.6. BLACKWATER SYSTEM

Blackwater System

1- Toilet 2- Holding Tank 3- Vent

4- Y-valve 5- Pump-out deck fitting 6- Macerator pump 7- Seacock and valve

Deck

Sea

(*) Not available in all models

NORTHSTAR MANUAL

3. SYSTEMS AND CIRCUITS

3.1. FIRE EXTINGUISHER SYSTEM

Please check the location of fire extinguisher holder.Make sure that you fix an approved fire extinguisher on the holder before using your boat.

Your boat also has fixed fire-extinguisher system located in the engineroom.Please read the instruction manual of fixed fire extinguisher system.

3.2. ELECTRICAL SYSTEM

A main cut off switch is provided inside the aft storage by the battery box. This cut-off switch disconnects the battery from the electrical system of your boat.

Two switch panels with fuses are provided on the console for electrical equipment. You can control the navigation lights, pole light, livewell pump (if fitted), shower pump, cabin lighting and the bilge pumps. Since your boat is equipped with two automatic bilge pumps, separate 3 position switches on the console are provided for their operation. When your boat remains in the water, leave bilge pump switches at Auto position for automatic operation.

Before discharging, shut down engines and blowers.

Please check the Skipper’s Manual for general information.

Above is how your electrical switch panels look like. Fuses are found in the fuse holders below the switches. To replace, open the fuse holder with a screwdriver and close after installing a new fuse. Periodically check your fuses and carry spares.

NORTHSTAR MANUAL

If a fuse consistently blows, please have your electrical circuitry checked by a professional.

NorthStar 230 CDS is equipped with a removable 360° Pole light that satisfies the 1 meter rule of the COLREGS which requires a minimum of 1 meter height difference between the navigation lights and the pole light.

You are not required to keep this light installed during daytime when there is good visibility. At night or when the visibility condition dictates the use of the pole light, simply remove it from its location under the aft center locker and install it in the plug provided on the aft starboard side of the boat. To retain it, tighten the locking collar. When not in use, simply remove it by loosening its collar and stow it under its storage location.

A switch will operate the port/starboard navigation light and must be used in the dark or when the visibility condition dictates while underway. Fuse 15A

A lighter type socket is provided to run extra accessories such as a spotlight or to charge the mobile phone.

Battery acid is corrosive, so you have to protect eyes and skin if you have to work on it. You must rinse splashes of acid with fresh water and consult a doctor immediately. You can neutralize splashes of acid on the skin or on clothes with acid transformer or soapsuds.

If one has drunk acid, please contact your doctor immediately.

Check and top up acid level periodically. Check from time to time if the battery terminals have a tight sit and if there are corrosion patches.

NORTHSTAR MANUAL

SSteel Fuel Tank

SSteel Fuel Fill

SSteel railing

Charge Plug Macerator

Water Pump

Cabin Lights Running Lights

Anchor Lights Horn

Bilge Pump 1 Bilge Pump 2

Bilge Pump 12 V

Switch Panel 12 V

Negative Bus

Fuel Gauge

Automatic Fire Extinguisher

Blower

Fuel Tank Sender

Engine Ignition Key

Alarm

Engine Gauges

Main switch

Battery

Electric System of Northstar 230 CDS Standard

NORTHSTAR MANUAL

Main switch

Negative Bus

Battery

SSteel Fuel Tank

Automatic Fire Extinguisher

Blower

SSteel Fuel

Fill

Fuel Tank

Sender

Fuel Gauge

Alarm

Engine Gauges

Engine Ignition Key

SSteel railing

Windlass

Charge Plug Macerator Refrigerator

Water Pump

Cabin Lights Compass Light

Running Lights Anchor Lights

Horn Bilge Pump 1 Bilge Pump 2

Bilge Pump 12 V

Switch Panel

12 V

Switch Panel

12 V

Windlass

Electric System of Northstar 230 CDS Full

NORTHSTAR MANUAL

MAINTENANCE LOG

DATE HOURS MAINTENANCE PERFORMED BY WHO
