CCS Technical Documentation
RH-17 Series Transceivers
Parts Lists
Issue 1 04/2003 Confidential Nokia Corporation
RH-17
Parts Lists CCS Technical Documenta tion
Page 2 Nokia Corporation Confidential Issue 1 04/2003
RH-17
CCS Technical Documentation Parts Lists
Contents
Page No
Exploded View............................................................................................................... 5
Assembly Parts List .....................................................................................................5
Parts Lists....................................................................................................................... 6
RH-17 (2280) — EDMS Issue 7.7 Code: 0202073 .....................................................6
Issue 1 04/2003 Nokia Corporation Confidential Page 3
RH-17
r
Parts Lists CCS Technical Documenta tion
Exploded View
A-cover Assy
Screws
UI Assy
Shield Cans
Power Button
PIFA Assy
Battery
B-cover
Assembly Parts List
Qty Description
Screws
PWB Board
Headset Jack
Whip Antenna Assy
D-cove
Product Code:
RH-17 - RH-17NA - RH-17R
1 A-cover (blue) 9497267
6 Screws 6290159
1 UI assembly: 9481010
1 PWB module: 0202073
1 Shield cans 9517260
9517261
9517262
1 Headset jack 5400293
1 Power button: 9452765
1 PIFA assembly: 0660290
1 Whip antenna assembly 0660288
1 D-cover 9497266
1 Battery 0670398
1 B-cover (blue) 9497265
Page 4 Nokia Corporation Confidential Issue 1 04/2003
RH-17
CCS Technical Documentation Parts Lists
Parts Lists
RH-17 (2280) — EDMS Issue 7.7 Code: 0202073
Item Code Side X Y Description Value Type
R100 1620027 Top T 5 res network 0W06 2X47R J 0404
R101 1620027 Top T 5 res network 0W06 2X47R J 0404
R102 1620027 Top T 6 res network 0W06 2X47R J 0404
R104 1430812 Top T 5 chip res 0W06 220K J 0402
R105 1825031 Top T 4 varistor array
2XVWM16V
R107 1430804 Bottom Q 8 chip res 0W06 100K J 0402
R109 1430690 chip res jumper ORO 0402
R110 1430804 Top T 6 chip res 0W06 100K J 0402
R112 1825031 Top T 5 varistor array
2XVWM16V
R150 1620031 Bottom Q 4 res network 0W06 2X1K0 J 0404
R152 1430796 Bottom R 4 chip res 0W06 47K J 0402
R159 1430762 Bottom S 3 chip res 0W06 2K2 J 0402
R160 1620117 Bottom S 3 res network 0W06 2X5R6 J 0404
R161 1620031 Bottom R 3 res network 0W06 2X1K0 J 0404
R162 1620031 Bottom S 4 res network 0W06 2X1K0 J 0404
R163 1620031 Bottom S 4 res network 0W06 2X1K0 J 0404
R164 1620031 Bottom Q 3 res network 0W06 2X1K0 J 0404
R165 1620031 Bottom S 4 res network 0W06 2X1K0 J 0404
VC50 0405
VC50 0405
R166 1430796 Bottom R 3 chip res 0W06 47K J 0402
R168 1620031 Bottom Q 4 res network 0W06 2X1K0 J 0404
R169 1430700 Bottom R 3 chip res 0W06 10R J 0402
R170 1825031 Top C 3 varistor array
2XVWM16V
R171 1620031 Bottom S 4 res network 0W06 2X1K0 J 0404
R172 1430796 Bottom R 4 chip res 0W06 47K J 0402
R179 1430804 Top D 2 chip res 0W06 100K J 0402
R180 1620117 Bottom Q 2 res network 0W06 2X5R6 J 0404
R195 1430796 Top D 2 chip res 0W06 47K J 0402
R200 1419003 Bottom N 3 chip res 0W5 0R22 J 200PPM 1210
VC50 0405
Issue 1 04/2003 Nokia Corporation Confidential Page 5
