Nokia 207 User Guide

User Guide

Nokia 207

Issue 2.0 EN

Psst...

This guide isn't all there is...

The instructions in this user guide are based on the latest available software version. If your device has not been updated to the latest available software, there may be differences in the availability and functionality of some features.

For info on Nokia Service terms and Privacy policy, go to www.nokia.com/privacy.

User Guide

Nokia 207

Psst... 2

Safety 4

Get started 5

Keys and parts 5

Insert a SIM card and battery 5

Insert a memory card 7

Charge the battery 7

Copy content from your old phone 8

Basics 9

Explore your phone 9

Display indicators 10

Prolong battery life 10

Personalise your home screen 11

Change your ringtone 11

Set a song as your ringtone 11

Nokia Store 12

Write text 12

People & messaging 13

Make or answer a call 13

Save a name and phone number 13

Send a message 14

Check your voice mail 14

Mail for Exchange 15

Set up your mail account 15

Send a mail 16

Get social 16

Internet 17

Browse the web 17

Add a website to your favourites 17

Entertainment 18

Play a song 18

Listen to the radio 18

Office 20

Add a calendar entry 20

Change the time and date 20

Set an alarm 20

Phone management & connectivity 21

Share your content using Slam 21

Back up content to a memory card 21

Restore original settings 22

Update your phone software 22

Access codes 22

Product and safety information 24

Safety

Read these simple guidelines. Not following them may be dangerous or illegal. For further info, read the complete user guide.

SWITCH OFF IN RESTRICTED AREAS

Switch the device off when mobile phone use is not allowed or when it may cause interference or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or

blasting areas. Obey all instructions in restricted areas.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect performance.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

BATTERIES, CHARGERS, AND OTHER ACCESSORIES

Use only batteries, chargers, and other accessories approved by Nokia for use with this device. Do not connect incompatible products.

KEEP YOUR DEVICE DRY

Your device is not water-resistant. Keep it dry.

PROTECT YOUR HEARING

To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use.

Get started

Get to grips with the basics, and have your phone up and running in no time.

Keys and parts

Explore the keys and parts of your new phone.

1 Audio connector (3.5 mm AHJ) 2Micro-USB connector 3 Scroll key 4End/Power key 5Microphone 6 Call key 7Selection keys 8Earpiece 9 Back cover release button 10 Antenna area

Avoid touching the antenna area while the antenna is in use. Contact with antennas affects the communication quality and may reduce battery life due to higher power level during operation.

Do not connect products that create an output signal, as this may damage the device. Do not connect any voltage source to the audio connector. If you connect an external device or headset, other than those approved for use with this device, to the audio connector, pay special attention to volume levels.

Tip: Lock the keys when not using your phone. Select Menu, and press *. To unlock, select Unlock, and press *.

Your phone uses S40 software.

The images in this guide may differ from your device screen.

Insert a SIM card and battery

Learn how to insert a SIM card and the battery.

The SIM1 holder under the battery can be used for both 3G and 2G SIMs.

1. Press the release button, and lift and remove the back cover.

Note: Switch the device off and disconnect the charger and any other device before removing

any covers. Avoid touching electronic components while changing any covers. Always store and use the device with any covers attached.

2. If the battery is in the phone, lift it out.

3. Lift the cover of the SIM1 holder, and put the SIM in, contact area face down.

Important: Your device uses a mini-UICC SIM card, also known as a micro-SIM card. Use of

incompatible SIM cards, or use of SIM card adapters, may damage the card or the device, and may corrupt data stored on the card.

4. Line up the battery contacts, and put the battery in.

5. Press the back cover down until it locks into place. To switch the phone on, press and hold the

power key

until the phone vibrates.

Insert a memory card

Read on to learn how to insert a memory card into your phone.

Use only compatible memory cards approved for use with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.

1. Press the release button, and lift and remove the back cover.

Note: Switch the device off and disconnect the charger and any other device before removing

any covers. Avoid touching electronic components while changing any covers. Always store and use the device with any covers attached.

2. Push the card in with the contact area face down until it locks into place.

3. To remove, push the card in, until it is released.

Important: Do not remove the memory card when an app is using it. Doing so may damage the

memory card and the device and corrupt data stored on the card.

Charge the battery

Your battery has been partially charged at the factory, but you may need to recharge it before you can use your phone.

1. Plug the charger into a wall outlet.

2. Connect the charger to the phone. When done, unplug the charger from the phone, then from the

wall outlet.

If the battery is completely discharged, it may take several minutes before the charging indicator is displayed or before any calls can be made.

Tip: You can use USB charging when a wall outlet is not available. Data can be transferred while charging the device. The efficiency of USB charging power varies significantly, and it may take a long time for charging to start and the device to start functioning.

Make sure your computer is switched on.

Copy content from your old phone

Easily get your contacts, calendar entries, and other stuff to your new phone.

1. Switch Bluetooth on in both phones. To switch Bluetooth on on your new phone, select Menu > Settings > Connectivity > Bluetooth.

2. On your new phone, select Menu > Settings > Sync & backup > Copy from dev..

3. Select what you want to copy, then select Done.

4. Choose your old phone from the list of found devices.

5. If asked, create a one-time passcode (such as 123), and select OK.

6. Check that the codes match on both phones.

7. Follow the instructions shown on both phones.

Basics

Learn how to get the most out of your new phone.

Explore your phone

Explore your phone with a simple key press.

1. To see the apps and features of your phone, press Menu.

2. To go to an app or feature, press the scroll key up, down, left, or right.

3. To open the app or select the feature, press Select.

Select

4. To go back to the previous view, press Back.

5. To go back to the home screen, press .

Back
