Nec DS 2000 DS Phone Program - Record Form

Download

Digital

System

Phone Program

Record Form

Table of Contents

About the Program Record Form General Programming Tips Entering the Program Mode Entering a Program Entering Data, Erasing Mistakes, and Moving Through Options Saving and Exiting

Programs

Program 1 - Class of Service Program 2 - Intercom Signaling Program 3 - Miscellaneous System Features Program 4 - System Timers Program 5 - PBX Trunk Access Codes Program 6 - Toll Restriction Program 7 - Music, External Paging, Relays Program 8 - System Messages

Program 10 - Line Port Characteristics Program 11 - Line Groups Program 12 - Line Features Program 14 - Extension Port Characteristics Program 15 - Programming Access Level Program 16 - Line and Line Group Access Program 17 - Key Assignments Program 18 - Extension Features (Part I) Program 18 - Extension Features (Part II)

Program 19 - Extension Hunt Groups Program 20 - System Initialization

● In Edit ➮ Preferences ➮ General, set the following:

– Default Magnification = Fit Width – Display Splash Screen at Startup = Disabled (box not checked) – Display Open Dialog Box at Startup = Disabled (box not checked)

● For easiest reading on-screen, select View ➮ Fit Width (or Ctrl K). This option

is automatically enabled if you set the

Default Magnification

in General

Preferences as described above.

● To return to the opening screen at any time, press Home.

To scroll up or down on a page, press PageDown or PageUp. To navigate between pages, press –>or <–.

● To increase the speed with which your Acrobat files load, try one of the following:

– In Windows 3.1, add

ACROREAD.EXE

to your Startup Group (with the Run

Minimized box checked).

– In Windows 95, add

ACROREAD.EXE

to the Windows\Start

Menu\Programs\StartUp folder (with Run Minimized selected).

You’ll have to maximize the first Acrobat file you run.

● Provides on-line viewing and printing.

● Extensive search and navigation capabilities.

● Ensures more timely turnaround of documents.

● When we provide an Acrobat manual with a product (e.g., Nitsuko TAPI Driver),

you are assured of having the most up-to-date manual available.

● With the installation of a PC fax/modem, it makes faxing of any brochure, user

guide, proposal or manual quick and easy.

● Acrobat Reader programs for Macintosh, DOS and UNIX platforms also can be

provided, if required.

● For Technical Support for the Acrobat Reader, contact:

Adobe Systems, Inc.

1585 Charleston Road

P.O. Box 7900

Mountain View, CA 94039-7900

Telephone Number: 415-961-4400

Adobe FaxY1 (technical/product information by fax): 206-628-5737

Adobe Electronic Bulletin Board (on-line information): 206-623-6984

URL: http://www.adobe.com

● To return to the opening screen, press the HOME key.

About the Program Record Form

The Program Record Form lets you record the way you configure a customer's DIGITAL SYSTEM and shows you how to enter the configuration data into system memory. For each program in the system, there is a form (grid) for recording the program's configuration data codes. Next to each grid are instructions for entering the data codes into system memory from a system programming extension (e.g., a display phone connected to port 00, initially extension 300).

You'll find the configuration data codes in the DIGITAL SYSTEM Administrator's Programming Guide (P/N N1872ADG**). Simply turn to a program and look for the heading, The data codes for each feature option are underneath.

Filling Out the Program Record Form

See also

How to Use Part II (Customizing the System)

in the DIGITAL SYSTEM Administrator's Programming Guide

General Programming Tips

There are four basic steps to entering data codes into system memory. Once you become familiar with them, you will not need to continually refer to the specific entry instructions with each program.

To enter data codes into memory:

1. Enter the program mode from the port 00 phone (initially extension 300) or from another system programming extension (see Program 15).

2. Enter a program.

3. Enter data using the dialpad, erase mistakes, and move through the program's feature options.

4. Save and Exit.

When you program the system for the first time, run Program 20 before any

Note:

others to ensure that the factory set values are in place.

Entering the Program Mode

To enter the program mode from the port 00 phone or another system programming extension (see Program 15):

1. Do not lift the handset.

2. Press # key.

3. Dial SP.

The code SP stands for "System Program" and is 77 on the dialpad.

4. Dial 5312.

The code 5312 is the DIGITAL SYSTEM password.

5. Press #.

If you leave the system in the program mode too long without pressing a key or dialing a code, you'll hear reorder (fast busy) tone, and the system automatically exits the program mode.

Entering a Program

To enter a program after you enter the program mode:

1. Press the program's key.

- i -

-Keys 1-20 give you access to programs 1-20. Keys 1-5 are on the left, keys

6-10 are on the right, keys 11-16 are directly below the dial pad. The HOLD (Program 17), CONF (Program 18), MIC/DND (Program 19), and ICM (Program 20) keys are in the last row of keys. Note: Program numbers 9 and 13 are not used.

Entering Data, Erasing Mistakes and Moving Through Options

To enter data after you enter a program:

1. Dial the data.

2. Press the # key.

This step stores the data and moves you to the next feature option.

For example, to enter the data code Y:

1. Dial Y, which is 9 on the dialpad.

2. Press #.

When you dial data for the last feature option in a program and press #, you exit the level you are working in and return to the previous level. In some cases, "returning to the previous level" means you exit the program and do not have to press SAVE to exit the program (see below).

To erase a mistake (in most cases):

1. Dial * after you dial the mistake but before you press # to store it.

If you make an invalid entry and press #, you will hear reorder (fast busy) tone. You can dial * (in most cases) during the reorder tone and re-enter the data.

To accept the data on the display and move to the next feature option:

1. Press the # key.

Saving and Exiting

To save and exit after entering data:

1. Press the SAVE key.

Pressing SAVE moves you out of a program, one level at a time. You may have to press SAVE several times to exit all the way out.

Note:

Some instructions in the Program Record Form are abbreviated.

When You See: It Means This:

Dial data + # . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . .

SAVE . . . . . . . . . . .

DIAL . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Enter the system program information, then press # Press SAVE Press DIAL

- ii -

COS

Only Intercom Calls at Night Off-Premise Call Forward Break-In (Intrusion) Camp-On (Busy Extension) Internal Call Forward System Speed Dial Toll Restriction Level Only Local Calls (Day/Night)

Program 1 - Class of Service

Page 1

Cont'd next page

Only Local Calls at Night Extended Ring Privacy Callback Priority Direct Trunk Access/Camp-On All Call Page Page Zone 1 Access Page Zone 2 Access Page Zone 3 Access Silent Monitor No Single Line Flash/ACD Supervisor Single Ring for ASI/OPX Only CO Call FWD to VX

Program 1 - Class of Service (cont'd)

COS

To enter Program 1 data:

1. Enter program mode.

2. Press key 1.

3. Dial COS number + #.

4. To accept the displayed data: #.

To change the displayed data: Dial data + #.

5. Repeat step 4 until done.

6. Select an option:

Only Intercom Calls at Night

Off-Premise Call Forward

Break-In (Intrusion)

Camp-On (Busy Extension)

Internal Call Forward

# + dial 775312 + #.

To erase data before pressing #: Press *.

If you finish and do not see, "COS. NO.": SAVE.

- To program another COS: Go to step 3.

- To exit Program 1: SAVE.

- To enter another program after exiting: Press its key.

- To exit program mode: SAVE twice.

System Speed Dial

Toll Restriction Level

Only Local Calls (Day/Night)

Only Local Calls at Night

Extended Ring

Privacy

Callback Priority

Direct Trunk Access/Camp-On

All Call Page

Page Zone 1 Access

Page Zone 2 Access

Page Zone 3 Access

Silent Monitor

No Single Line Flash/ACD Supervisor

Single Ring for ASI/OPX

Only CO Call FWD to VX

Page 2

Program 2 - Intercom Signaling

Feature Name

Call Wait Tones

Handsfree

Voice-

Announced

Calls

Auto Handsfree

To enter Program 2 data:

1. Enter program mode.

2. Press key 2.

3. To accept the displayed data: #.

To change the displayed data: Dial data + #.

4. Repeat step 3 for all data.

5. Select an option:

Feature Data

# + dial 775312 + #.

- To erase data before pressing #: Press *.

If you finish and do not see, "SAVE TO EXIT": SAVE.

- To enter another program: Press its key.

- To exit program mode: SAVE.

Page 3

Program 3 - Miscellaneous System Features

Feature Name Feature Data Feature Name Feature Data

# Operators Voice Mail

Oper. 01 Ext.

Oper. 02 Ext.

Oper. 03 Ext.

Oper. 04 Ext.

# System Speed

Dial Digits

Side Tone Test

Digit

To enter Program 3 data:

1. Enter program mode.

# + dial 775312 + #.

2. Press key 3.

3. To accept the displayed data: #.

To change the displayed data: Dial data + #.

- To erase data before pressing #: Press *.

4. Repeat step 3 for all data.

If you finish and do not see, "SAVE TO EXIT": SAVE.

5. Select an option:

- To enter another program: Press its key.

- To exit program mode: SAVE.

Voice Mail

Master Ext.

Dial-Out # in

Speed Dial

Dial 1 Before

Area Code

Walking COS Security Code

Play MOH on

Transfer

AUX Port's

Baud Rate

Note: Before a number can be entered as the Voice Mail Master Extension, the VX (Voice Mail) prompt in Program 18 must be set to Y(es) and UCD group programming must be completed.

Page 4

Program 4 - System Timers

Timer Number Timer Name Duration

To enter Program 4 data:

1. Enter program mode.

2. Press key 4.

3. Dial Timer number + #.

4. To accept the displayed data: #. OR

To change the displayed data: Dial data + #.

5. Repeat steps 3-4 for remaining timers.

6. Select an option:

Park Orbit

Hold Recall

Camp-On

Line Response

Modem Reserve

# Ring Before Recall

# Delayed Rings

Flash Response

Dial Tone Detect

Make

Break

Interdigit

# + dial 775312 + #.

To erase data before pressing #: Press *.

- To exit Program 4: SAVE.

- To enter another program after exiting: Press its key.

- To exit program mode: SAVE twice.

Page 5

Program 5 - PBX Trunk Access Codes

PBX

ID Number

Access

Code

To enter Program 5 data:

1. Enter program mode.

# + dial 775312 + #.

2. Press key 5.

3. To accept the displayed data: #.

To change the displayed data: Dial data + #.

- To enter a wild card: DIAL + dial X (9) + #.

- To erase data: Press * + #.

4. Repeat step 3 for all data.

If you finish and do not see, "SAVE TO EXIT": SAVE.

5. Select an option:

- To enter another program: Press its key.

- To exit program mode: SAVE.

Page 6

Program 6 - Toll Restriction

Before you fill in data, either use the Copy and Paste commands to make additional copies of the Toll Restriction forms for each Toll Restriction level you wish to customize or print copies of the blank forms. You may not need to use all three forms for each level.

Toll Level

Active Dial Pad

Special N11 Dialing

0 + Dialing

International Dialing

Equal Access Dialing

1 + NXX Dialing

Allow or Deny (See Table #1)

NXX Dialing

Allow or Deny (See Table #2)

NPA Dialing

Allow or Deny (See Table #3)

Table 1: Allow/Deny NNX Codes For Toll Calls

Table 2: Allow/Deny NNX Codes for Local Calls

6-Digit Analysis

Table 3: Allow/Deny NPA Codes

Page 7

Cont'd next page

Program 6 - Toll Restriction (cont'd)

Toll Level: Table 4: Allow/Deny Codes For Area Code:

Table 5: Allow/Deny Codes For Area Code:

Table 6: Allow/Deny Codes For Area Code:

Table 7: Allow/Deny Codes For Area Code:

Page 8

Cont'd next page

Program 6 - Toll Restriction (cont'd)

Toll Level: Table 8: Allow/Deny Codes For Area Code:

Table 9: Allow/Deny Codes For Area Code:

Table 10: Allow/Deny Codes For Area Code:

Table 11: Allow/Deny Codes For Area Code:

Page 9

Cont'd next page

Program 6 - Toll Restriction (cont'd)

Toll Level: Table 12: Allow/Deny Codes For Area Code:

Table 13: Allow/Deny Codes For Area Code:

To enter Program 6 data:

1. Enter program mode.

# + dial 775312 + #.

2. Press key 6.

3. For first-time programming or to initialize (reset) toll levels: Dial I + Y. Otherwise, go to step 5.

To stop initialization after dialing I: Dial N + go to step 5.

4. To allow the system to accept the new NPA codes, at the prompt "NEW DIAL PLAN-N", dial Y.

5. Dial P to program toll levels.

Re-order tone means: Go to step 1 and initialize in step 3.

6. Dial toll level + #.

7. To accept the displayed data: #.

To change the displayed data: Dial data + #.

- To erase data before pressing #: Press *.

- ADD-DELETE-LIST means you can enter Table data. Use a-c for Tables 1 through 3. Use the

steps on the following page for Tables 4 through 13. a. Dial A, D, or L. Or, to exit the table at this point: # and go to beginning of step 7. b. To add/delete: Dial codes.

To list more or exit list: # + go to step 7a. c. To save and exit table: # + go to beginning of step 7.

To save and go to "ADD-DELETE-LIST:" SAVE + go to step 7a.

8. Repeat step 7 for all data.

If you finish and do not see, "TOLL LEVEL": Press # until you see it.

Page 10

Cont'd next page

Program 6 - Toll Restriction (cont'd)

9. Select an option:

- To program another level: Go to step 6.

- To exit Program 6: SAVE.

- To enter another program after exiting: Press its key.

- To exit mode: SAVE twice.

To use the 6-Digit Analysis Tables (4 - 13) when you see ADD-DELETE- LIST on the display:

1. Dial A, D, or L.

Press # to exit the table (and Program 6).

2. Dial the area code intended for 6-digit analysis.

If you selected "Listing" in step 1, the system lists the codes now, four at a time. To see more codes or exit at the end of the list, press # and return to step 1. Steps 3-6 do not apply to listing.

3. Dial A for an Allow Table of NXX codes.

Dial D for a Deny Table of NXX codes.

4. Dial codes to be added or deleted.

5. Select an option:

- To save and go to "ADD-DELETE-LIST" for another area code: SAVE + Go to step 1.

- To save and exit toll level: # + Go to step 6 on the previous page.

- To save and exit Program 6: SAVE three times.

- To enter another program after exiting: Press its key.

- To SAVE and exit program mode: SAVE four times.

Page 11

Program 7 - Music, External Paging, Relays

Feature Name

Background

Music (BGM)

Music on Hold

External Page

Zone 1

Ring Over All

Call

External Page

Zone 2

BGM to Ext.

Zones

Interrupted Ring Relays

Page/Music

Volume

Relay 01 Owner

Relay 02 Owner

Feature

Data

To enter Program 7 data:

1. Enter program mode.

# + dial 775312 + #.

2. Press key 7.

3. To accept the displayed data: #.

To change the displayed data: Dial data + #.

To erase data before pressing #: Press *.

4. Repeat step 3 for all data.

If you finish and do not see, "SAVE TO EXIT": SAVE.

5. Select an option:

- To enter another program: Press its key.

- To exit program mode: SAVE.

Page 12

Program 8 - System Messages

Message No. Messages

600 601 602 603 604 605 606 607 608 609 610 611 612 613 614 615

To enter Program 8 data:

1. Enter program mode.

# + dial 775312 + #.

2. Press key 8.

3. Dial Message number + #.

4. To accept the displayed data: #.

To erase displayed data: Press * + Enter new message (see below) or press # and go to step 3.

To changed the displayed data: Enter entire message + #.

To enter message:

a. Press dialpad button for desired letter or number. To enter a blank space, Q, or Z: Press 0. b. To make a letter appear: Dial the number (1, 2, or 3) that corresponds to the letter's position on the button (e.g. dial 1 if you want the first letter).

To make a number appear: Dial 4. Note: To make a blank space, Q, or Z appear: Dial 1, 2, or 3, respectively. c. Repeat a-b for all characters (to erase previous character: LAST).

5. Repeat steps 3-4 for all messages.

6. Select an option:

- To exit Program 8: SAVE.

- To enter another program after exiting: Press its key.

- To exit program mode: SAVE twice.

Page 13

Program 10 - Line Port Characteristics

Line Number

01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16

Circuit

Type

Line

Gain

PBX Line

Side Tone Test

Name

17 18 19 20 21 22 23 24

Cont'd next page

Page 14

Program 10 - Line Port Characteristics (cont'd)

To enter Program 10 data:

1. Enter program mode.

# + dial 775312 + #.

2. Press key 10.

3. Dial Line number + #.

4. To accept the displayed data: #.

To change the displayed data: Dial data + #.

- To erase data before pressing #: Press *.

-To enter circuit type X: DIAL + dial X.

- To enter a name:

a. Press dialpad button for desired character. To enter a blank space, Q, or Z: Press 0.

b. To make a letter appear: Dial the number (1, 2, or 3) that corresponds to the letter's position

on the button (e.g. dial 1 if you want the first letter).

To make a number appear: Dial 4.

Note: To make a blank space, Q, or Z appear: Dial 1, 2, or 3, respectively.

c. Repeat a-b for all characters (to erase previous character: LAST).

5. Repeat step 4 for all data.

If you finish and do not see, "LINE NO.": SAVE.

6. Select an option:

- To program another line: Go to step 3.

- To exit Program 10: SAVE.

- To enter another program after exiting: Press its key.

- To exit program mode: SAVE twice.

Page 15

Program 11 - Line Groups

Group Number Line Members

90 91 92 93 94 95 96 97 98

To enter Program 11 data:

1. Enter program mode.

# + dial 775312 + #.

2. Press key 11.

3. Dial Group number + #.

4. To accept the displayed data: #.

To enter or change the displayed data: Dial data + #.

- To erase data before pressing #: Press *.

- To erase a line from the group, dial *. Dialing * for the first member of the group erases the entire group.

5. Repeat step 4 for all data in group.

6. Press SAVE.

7. Select an option:

- To program another line group: Go to step 3.

- To exit Program 11: SAVE.

- To enter another program after exiting: Press its key.

- To exit program mode: SAVE twice.

Page 16

Line Number

CPG (Call Pickup Group) TR (Toll Restriction) DTD (Direct Termination Day) DTN (Direct Termination

Program 12 - Line Features

Page 17

Night) COS (Class Of Service)

Cont'd next page

Program 12 - Line Features (cont'd)

To enter Program 12 data:

1. Enter program mode.

# + 775312 + #.

2. Press key 12.

3. Dial Line number + #.

4. Dial feature's abbreviation + #.

5. To accept the displayed data: #.

To change the displayed data: Dial data + #.

- To accept DTD or DTN data, you may have to press SAVE instead.

- To erase data before pressing #: Press *.

6. Repeat steps 4-5 for all features.

7. Press SAVE.

8. Select an option:

- To enter data for another line: Dial Y + go to step 3.

- To exit Program 12: SAVE.

- To enter another program after exiting: Press its key.

- To exit program mode: SAVE twice.

Page 18

Program 14 - Extension Port Characteristics

Port Number

00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15

Extension

Number

Circuit

Type

DSS Owner

DSS

Block

Name (16 characters, maximum)

16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32

* Note:

33 34 35

A DSS console cannot be installed in an Expansion Cabinet.

Page 19

Cont'd next page

Program 14 - Extension Port Characteristics (cont'd)

Port Number

36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51

Extension

Number

Circuit

Type

DSS Owner

DSS

Block

Name (16 characters, maximum)

52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68

* Note:

69 70 71

A DSS console cannot be installed in an Expansion Cabinet.

Page 20

Cont'd next page

Program 14 - Extension Port Characteristics (cont'd)

To enter Program 14 data:

1. Enter program mode.

# + dial 775312 + #.

2. Press key 14.

3. Dial Port number + #.

4. To accept the displayed data: #.

To change the displayed data: Dial data + #.

- To erase data before pressing #: Press *.

- To enter circuit X: DIAL + dial X.

- To enter circuit Z: DIAL + dial 0.

- To enter a letter, number, blank:

- Press dial pad button that has desired character. Zero button=blank, Q, Z (in that order).

- Dial digit (1, 2, 3)=letter's position on button (e.g., dial 1 for 1st letter).

Dial 4 for the button's number.

- To erase last character, press LAST.

- Repeat above steps for entire message.

5. Repeat step 4 for all data.

If you finish and do not see, "STN PORT NO.": SAVE.

6. Select an option:

- To program a port: Go to step 3.

- To exit Program 14: SAVE.

- To enter another program after exiting: Press its key.

- To exit program mode: SAVE twice.

Note: You cannot change the circuit type of the extension from which you are programming; you must use another extension that has program access level 04 or 05.

Page 21

Program 15 - Programming Access Level

Extension

Program

Access Level

300 324 348 301 325 349 302 326 350 303 327 351 304 328 352 305 329 353 306 330 354 307 331 355 308 332 356 309 333 357 310 334 358 311 335 359 312 336 360

Extension

Program

Access Level

Extension

Program

Access Level

313 337 361 314 338 362 315 339 363 316 340 364 317 341 365 318 342 366 319 343 367 320 344 368 321 345 369 322 346 370 323 347 371

Cont'd next page

Page 22

Program 15 - Programming Access Level (cont'd)

To enter Program 15 data:

1. Enter program mode.

# + dial 775312 + #.

2. Press key 15.

3. Dial extension + #.

4. To accept the displayed data: #.

To change the displayed data: Dial data + #.

- To erase data before pressing #: Press *.

5. Repeat steps 3-4 for all extensions.

6. Select an option:

- To exit Program 15: SAVE.

- To enter another program after exiting: Press its key.

- To exit program mode: SAVE twice.

Page 23

330

329

328

327

326

325

324

323

322

321

320

319

318

317

316

315

314

313

312

311

310

309

308

307

306

305

304

303

302

301

Program 16 - Line and Line Group Access

Extension

300

Line ____ Access Line ____ Access Line ____ Access Line ____ Access Line ____ Access Line ____ Access Line ____ Access Line ____ Access

Page 24

Cont'd next page

Line ____ Access Line ____ Access Line ____ Access Line ____ Access Line ____ Access Line ____ Access Line ____ Access Line ____ Access Group 90 Access Group 91 Access Group 92 Access Group 93 Access Group 94 Access Group 95 Access

361

360

359

358

357

356

355

354

353

352

351

350

349

348

347

346

345

344

343

342

341

340

339

338

337

336

335

334

333

332

Program 16 - Line and Line Group Access (cont'd)

Extension

331

Line ____ Access Line ____ Access Line ____ Access Line ____ Access Line ____ Access Line ____ Access Line ____ Access Line ____ Access

Page 25

Cont'd next page

Program 16 - Line and Line Group Access (cont'd)

Extension

362 363 364 365 366 367 368 369 370 371

To enter Program 16 data:

1. Enter program mode.

2. Press key 16.

3. Dial extension + #.

4. Dial L for line or G for group data.

5. Dial Line or Group number + #.

6. To accept the displayed data: #,

To change the displayed data: Dial data + #.

7. Repeat steps 5-6 for all lines/groups.

8. Press SAVE.

9. Select an option:

Line ____ Access

# + dial 775312 + #.

- To erase data before pressing #: Press *.

- To enter line or group data for same extension: Go to step 4.

- To enter data for another extension: SAVE + dial Y + go to step 3.

- To exit Program 16: SAVE twice.

- To enter another program after exiting: Press its key.

- To exit program mode: SAVE three times.

Line ____ Access

Group 90 Access

Group 91 Access

Group 92 Access

Group 93 Access

Group 94 Access

Group 95 Access

Page 26

Program 17 - Key Assignments

Before you fill in data, either use the Copy and Paste commands to make additional copies of the blank Key Assignment forms for each installed Multibutton phone and DSS Console or print copies of the forms required. There is a form for the phone and the console. Make sure you copy the correct one.

Extension

Number

Keyset Phone

(Dial pad located here)

HOLD CONF MIC/DND ICM MSG HF

Cont'd next page

Page 27

Program 17 - Key Assignments (cont'd)

Extension

Number

DSS Console

Cont'd next page

Page 28

Program 17 - Key Assignments (cont'd)

To enter Program 17 data:

1. Enter program mode.

- # + dial 775312 + #.

- If you are programming assignments for a DSS Console, you must program from the phone assigned to the console.

2. Press key 17 (HOLD).

You see "DEST ICM NO:" (i.e., destination extension).

3. Dial extension (XXX) to be programmed + #.

You see "SOURCE:" (i.e., source extension). If you are programming assignments for your DSS Console, enter your entension number.

4. To program the keys at extension XXX: Dial extension (XXX) again + #.

To copy keys from extension YYY to XXX: Dial YYY + # + go to step 8 if you do not need to change individual keys after you copy; otherwise, go to step 5.

- This procedure does not copy Speed Dial (stored) numbers, Ring Assign. (Program 18 [II]), or Line Access (Program 16).

- If you are programming assignments for your DSS Console, enter your entension number.

5. Press key you wish to program.

- For DSS Consoles, press DSS Console key.

6. To accept the displayed data: #.

To change the displayed data: Dial key data + #.

Remember: To dial "Z", dial 0 (zero).

7. Repeat steps 5-6 for other keys.

8. Press SAVE and select an option:

- To program another extension: Dial Y + go to step 3.

- To exit Program 17: SAVE.

- To enter another program after exiting: Press its key.

- To exit program mode: SAVE twice.

Page 29

330

329

328

327

326

325

324

323

322

321

320

319

318

317

316

315

314

313

312

311

310

309

308

307

306

305

304

303

302

301

Program 18 - Extension Features (Part I)

Extension

300

DND (Do Not Disturb) COS (Class of Service) RG (Ring Group) CPG (Call Pickup Group) PRG (Privacy Release Group)

Page 30

Cont'd next page

OHR (Off-Hook Ring) BLF (DSS/BLF Lamps) LDU (Line Dial-Up) PZ (Page Zone Member) SO (Station Operator) SDB (Speed Dial Block) VX (Voice Mail) DS (Data set) DB (Door Box) - Alert 1 DB (Door Box) - Alert 2 DB (Door Box) - Alert 3 DB (Door Box) - Alert 4

361

360

359

358

357

356

355

354

353

352

351

350

349

348

347

346

345

344

343

342

341

340

339

338

337

336

335

334

333

332

Program 18 - Extension Features (Part I) (cont'd)

Extension

331

DND (Do Not Disturb) COS (Class of Service) RG (Ring Group) CPG (Call Pickup Group) PRG (Privacy Release Group)

Page 31

Cont'd next page

Program 18 - Extension Features (Part I) (cont'd)

Extension

362 363 364 365 366 367 368 369 370 371

To enter Program 18 (Part I) data:

1. Enter program mode.

2. Press key 18 (CONF).

3. Dial extension + #.

4. Dial feature abbreviation + #.

5. To accept the displayed data: #.

To change data: Dial data + #.

6. Repeat steps 4-5 for all features.

7. Press SAVE or Go to step 4 in a Program 18 (Part II) procedure.

8. Select an option:

DND (Do Not Disturb)

COS (Class of Service)

(Ring Group)

CPG

(Call Pickup Group)

PRG

(Privacy Release Group)

OHR (Off-Hook Ring)

BLF (DSS/BLF Lamps)

# + dial 775312 + #.

To dial PZ: Dial P0.

- To erase a data entry before you press #: Press *.

- To accept the SO (station operator) data, you may have to press SAVE instead.

- To enter Part I data for another extension: Dial Y + go to step 3.

- To exit Program 18: SAVE.

- To enter another program after exiting: Press its key.

- To exit program mode: SAVE twice.

LDU (Line Dial-Up)

(Page Zone Member)

(Station Operator)

SDB

(Speed Dial Block)

VX (Voice Mail)

DS (Data set)

DB (Door Box) - Alert 1

DB (Door Box) - Alert 2

DB (Door Box) - Alert 3

DB (Door Box) - Alert 4

Page 32

Program 18 - Extension Features (Part II)

Before you fill in data, either use the Copy and Paste commands to make additional copies of the blank Extension Feature forms for each installed extension or print copies of the blank forms as needed.

Extension:

Feature

RA (Ringing Assignment) NR (Night Ringing) DRA (Direct Ringing Assign.) PLA (Prime Line Assign.)

Line # ________

HS (Headset) VA (Voice-Announce Calls) VP (Voice Page Thru Spkr) VO (Whisper Page) RLP (Ringing Line Pref.)

Line # ________

Feature Y/N

Line # ________

Personal Speed Dial Numbers

Bin 50: Bin 20: Bin 51: Bin 21: Bin 52: Bin 22: Bin 53: Bin 23: Bin 54: Bin 24: Bin 55: Bin 25: Bin 56: Bin 26: Bin 57: Bin 27: Bin 58: Bin 28: Bin 59: Bin 29:

Key 1: Key 13: Key 2: Key 14: Key 3: Key 15: Key 4: Key 16: Key 5: Key 17: Key 6: Key 18: Key 7: Key 19: Key 8: Key 20:

Key 9: Key 21: Key 10: Key 22: Key 11: Key 23: Key 12: Key 24:

Page 33

Cont'd next page

Program 18, Part II (cont'd)

Direct Station Selection (and Call Coverage) and Hotline Layout

Keys 1-15 are Direct Station Selection keys. The Call Coverage and Hotline keys can be anywhere, depending on how they are assigned in Program 17. You can use the DSS procedure below to change the extension associated with a DSS or Call Coverage key.

Keyset Phone

HOLD CONF MIC/DND ICM MSG HF

To enter Program 18 data for HS, VA, VP, VO, RLP:

1. Enter the program mode.

# + dial 775312 + #.

2. Press key 18 (CONF).

3. Dial extension + #.

4. Dial feature abbreviation + #.

5. To accept the displayed data: #.

To change the displayed data: Dial data + #.

6. Select an option:

- To program another feature: Go to step 4 (in any Program 18 procedure).

- To program another extension: SAVE + dial Y + go to step 3 (in any Program 18 procedure).

- To exit Program 18: SAVE twice.

- To enter another program after exiting: Press its key.

- To exit program mode: SAVE three times.

(Dial pad located here)

Page 34

Cont'd next page

Program 18, Part II (cont'd)

To enter Program 18 data for RA, NR, DRA, PLA:

1. Enter program mode.

# + dial 775312 + #.

2. Press key 18 (CONF).

3. Dial extension + #.

4. Dial feature abbreviation + #.

The Line keys you can program light steadily or flash. Steady means the feature is disabled, flashing means it is enabled.

5. Dial a line number.

Press a Line key.

6. To change or enter data: Dial data (Y)es or (N)o, press #.

7. Repeat steps 5-6 for all lines.

8. Select an option:

- To program another feature for same extension: SAVE + go to step 4 (in any Program 18 procedure).

- To program another extension: SAVE twice + dial Y + go to step 3 (in any Program 18 procedure).

- To exit Program 18: SAVE three times.

- To enter another program after exiting: Press its key.

- To exit program mode: SAVE four times.

To enter Program 18 data for Personal Speed Dial (SD):

1. Enter the program mode.

# + dial 775312 + #.

2. Press key 18 (CONF).

3. Dial extension + #.

4. Dial SD + #.

5. Dial bin number + #.

Press lit bin key (to make a SD bin keys, see Program 17).

6. If you can store a name: Enter name + #. Or, skip to step 7.

To enter a letter, number, blank:

- Press dial pad button that has desired character. Zero button=blank, Q, Z (in that order).

- Dial digit (1, 2, 3)=letter's position on button (e.g., dial 1 for 1st letter).

Dial 4 for the button's number.

- To erase last character, press LAST.

- Repeat above steps for entire message.

7. Store a line as follows: Press a Line key or (Dial line number + #).

- Reorder tone means you cannot store that line. Go to step 4.

- To store Intercom feature codes: Press ICM in step 7, dial codes in step 8.

8. To accept the displayed data: # + go to step 5.

To change the displayed data: Dial telephone number + #.

- You can store any number allowed by the toll level of the extension you program from. Numbers longer than 16 digits flow to the next bin.

- To enter a pause: HOLD.

Page 35

Cont'd next page

Program 18, Part II (cont'd)

- To enter a Flash, press MSG, or to enter a Delay, press DIAL. These options are only available with software versions AUX Module 02.10/Base 02.00 and higher.

- To enter *: DIAL + press *.

- To enter #: DIAL + press #.

9. Select an option:

- To program more bins: Go to step 5.

- To program another feature: SAVE + go to step 4 in any Program 18.

- To program another extension: SAVE twice + dial Y + go to step 3.

- To exit Program 18: SAVE three times.

- To enter another program after exiting: Press its key.

- To exit program mode: SAVE four times.

To enter Program 18 data for DSS:

1. Enter the program mode.

# + dial 775312 + #.

2. Press key 18 (CONF).

3. Dial extension + #.

4. Dial DSS or HL + #.

DSS keys (1-15) flash, any Call Coverage and Hotline keys flash.

5. Press a flashing key.

6. To accept the displayed data: #.

To change the displayed data: Dial data + #.

7. Repeat steps 5-6 for all DSS keys you wish to program.

8. Select an option:

- To program another extension for DSS: SAVE twice + dial Y + go to step 3 (in any Program 18 procedure).

- To program another feature for same extension: SAVE + go to step 4 (in any Program 18 procedure).

- To exit Program 18: SAVE three times.

- To enter another program after exiting: Press its key.

- To exit program mode: SAVE four times.

Page 36

Cont'd next page

Program 18, Part II (cont'd)

Form for System Speed Dial

Bin Number System Speed Dial Numbers and Names

Page 37

Cont'd next page

Program 18, Part II (cont'd)

To enter Program 18 data for System Speed Dial (SD):

1. Enter the program mode.

# + dial 775312 + #.

2. Press key 18 (CONF).

3. Dial the number of the extension you are programming from + #.

4. Dial SD + #.

5. Dial bin number + #.

6. If you can store a name: Enter name + #. Or skip to step 7.

To enter a letter, number, blank:

- Press dial pad button that has desired character. Zero button=blank, Q, Z (in that order).

- Dial digit (1, 2, 3)=letter's position on button (e.g., dial 1 for 1st letter).

Dial 4 for the button's number.

- To erase last character, press LAST.

- Repeat above steps for entire message.

7. Store a line: Press a Line key or (Dial line number + #).

- Reorder tone means you cannot store that line. Go to step 4.

- To store Intercom feature codes: Press ICM in step 7, dial codes in step 8.

8. To accept the displayed data: # + go to step 5.

To change the displayed data: Dial telephone number + #.

- You can store any outside number allowed by the toll restriction level of the extension you program from. Numbers longer than 16 digits automatically flow to the next bin.

- To enter a pause: HOLD.

- To enter a Flash, press MSG, or to enter a Delay, press DIAL. These options are only available available with software versions AUX Module 02.10/Base 02.00 and higher.

- To enter *: DIAL + dial *.

- To enter #: DIAL + dial #.

9. Select an option:

- To program more bins: Go to step 5.

- To program another feature: SAVE + go to step 4 (in any Program 18 procedure).

- To program another extension: SAVE twice + dial Y + go to step 3 (in any Program 18 procedure).

- To exit Program 18: SAVE three times.

- To enter another program after exiting: Press its key.

- To exit program mode: SAVE four times.

Page 38

Program 19 - Extension Hunt Groups

Before you fill in data, either use the Copy and Paste commands to make additional copies of the blank Circular/Terminal or UCD/ACD Hunt Group form for each such group you wish to program or print and copy the forms as needed.

Form for Circular/Terminal Hunt Group

Group Name:

Member

Extension

Hunt Type

Member

Extension

Hunt Type

Member

Extension

Hunt Type

To enter Program 19 data for Circular or Terminal Hunt (types 01, 02, 03):

1. Enter program mode.

# + dial 775312 + #.

2. Press key 19 (MIC/DND).

3. Dial 01, 02, or 03 (it doesn't matter).

4. Dial Member Extension + #.

5. Dial Hunt Type + #.

6. Repeat steps 4-5 for all Member Extension

7. Select an option:

- To program another group: # until you see "HUNT TYPE -" + Go to step 3 in any Program 19 procedure.

- To exit Program 19: SAVE.

- To enter another program after exiting: Press its key.

- To exit program mode: SAVE twice.

Note: To accept the displayed data in any step: #.

Page 39

Cont'd next page

To delete a member of a Circular or Terminal group:

1. Enter program mode.

# + dial 775312 + #.

2. Press key 19 (MIC/DND).

3. Dial 01, 02, or 03 (it doesn't matter).

4. Dial first Member Extension in group + #.

5. Press # until you see the extension you want to delete.

6. If the extension is the last extension in a Terminal hunt group: Dial 300 + #.

If the extension is in the middle of a group, dial the extension that comes after it + #.

For example, if the group is 304, 305, 306 and you want to delete 305:

- Press # until you see 305 (as explained in step 5).

- Dial 306 + #.

7. Continue as follows:

- Press # until you see "HUNT TYPE - ".

- Dial 01, 02, or 03 + #.

- Dial the extension you just deleted + #.

- Dial 00 for Hunt Type + #.

8. Press SAVE until you exit program mode.

Note: To accept the displayed data in any step: #.

To add a member to a Circular or Terminal Group:

1. Enter program mode.

# + dial 775312 + #.

2. Press key 19 (MIC/DND).

3. Dial 01, 02, or 03 (it doesn't matter).

4. Dial first Member Extension + #.

5. Press # until you see the extension before which you want to add an extension.

For example, if the group is 304, 305, 306 and you want to add 307 before 306: Press # until you see 306.

6. Dial the extension you want to add + #. Dial its Hunt Type + #. Repeat for the extension after it.

To continue with the example set up in step 5: Do step 6 for extension 307, then 306.

7. Press # until you see "HUNT TYPE-".

8. Press SAVE until you exit program mode.

Note: To accept the displayed data in any step: #.

Cont'd next page

Page 40

Program 19 - Extension Hunt Groups (cont'd)

Form for a UCD/ACD Hunt Group

Before you fill in the data, either use the Cut and Paste commands to make additional copies of the blank forms for each UCD/ACD group you wish to program or print and copy the forms as needed.

Hunt

Type

Master

Extension

Group Name:

Overflow

Extension

Supervisor

Extension

Member

Extension

Hunt Type

Member

Extension

Hunt Type

Member

Extension

Hunt Type

To enter Program 19 data for UCD/ACD Hunt (type 04, 05):

1. Enter program mode.

# + dial 775312 + #.

2. Press key 19 (MIC/DND).

3. Dial Hunt Type + #.

4. Dial Master Extension + #.

5. For type 04: Go to step 6. For type 05: Dial Overflow + #.

6. Press # to move past "MASTER EXT." prompt.

To delete a group: Dial * + SAVE + Go to step 10.

7. Dial a Member Extension when you see UCD MEMBER + #.

- To move past a member: #.

- To delete a member: Dial *.

Page 41

Cont'd next page

Program 19 - Extension Hunt Groups (cont'd)

8. Repeat step 7 for all members.

9. Press SAVE.

10. Select an option:

- To program another group: Go to step 3 in any Program 19 procedure.

- To exit Program 19: SAVE.

- To enter another program after exiting: Press its key.

- To exit program mode: SAVE twice.

Note: To accept the displayed data in any step: #.

To enter Program 19 data for ACD Supervisor:

1. Enter program mode.

# + dial 775312 + #.

2. Press key 19 (MIC/DND).

3. Dial 00 for Hunt Type + #.

4. Dial Master Extension for Supervisor's group + #.

You see "UCD MEMBER."

5. Dial Supervisor Extension + #.

This step automatically places the Supervisor Extension in the associated UCD group.

6. Select an option:

- To program another Supervisor, go to step 3.

- To exit Program 19: SAVE.

- To enter another program after exiting: Press its key.

- To exit program mode: SAVE twice.

To delete an ACD Supervisor

1. Enter program mode.

# + dial 775312 + #.

2. Press key 19 (MIC/DND).

3. Dial Hunt Type for Supervisor's group + #.

4. Dial Master Extension for Supervisor's group + #.

5. Press # until you see Supervisor's Extension.

6. Press *.

7. Press SAVE.

8. Select an option:

- To delete more Supervisor Extensions: Go to step 3.

- To exit Program 19: SAVE.

- To enter another program after exiting: Press its key.

- To exit program mode: SAVE twice.

Note: To accept the displayed data in any step: #.

Page 42

Program 20 - System Initialization

To use Program 20:

1. Enter program mode.

# + dial 775312 + #.

2. Press key 20 (ICM).

3. Dial Y to initialize and wait for the date and time to display. When you see the date and time, this means initialization is complete.

Dial N to exit Program 20 without initialization.

- To enter another program: Press its key.

- To exit program mode: Press SAVE.

Page 43

Nitsuko America, Telecom Division

4 Forest Parkway

Shelton, CT 06484

TEL: 203-926-5400 FAX: 203-929-0535

Other Important Telephone Numbers

Sales: ..................................................................

Customer Service:................................................

Customer Service FAX:........................................

Technical Service: ...............................................

Discontinued Product Service: ............................

Technical Training:...............................................

Emergency Technical Service (After Hours): ......

(Excludes discontinued products)

203-926-5450 203-926-5444 203-926-5454 203-925-8801 900-990-2541 203-926-5430 203-929-7920

Digital System Program Record Form

Part No. N1872PRF04 Issue 1-0, June 1996 Printed in U.S.A.

4 FOREST PARKWAY, SHELTON, CT 06484 TEL: 203-926-5400 FAX: 203-929-0535

This manual has been developed by Nitsuko America. It is intended for the use of its

customers and service personnel and should be read in its entirety before attempting to install or program the system. Any comments or suggestions for improving this manual would be appreciated. Forward your remarks to:

Nitsuko America, Telecom Division 4 Forest Parkway Shelton, CT 06484

Attention: Manager, Technical Publications

Nothing contained in this manual shall be deemed to be, and this manual does not constitute, a warranty of, or representation with respect to, any of the equipment covered. This manual is subject to change without notice and Nitsuko America has no obligation to provide any updates or corrections to this manual. Further, Nitsuko America also reserves the right, without prior notice, to make changes in equipment design or components as it deems appropriate. No representation is made that this manual is complete or accurate in all respects and Nitsuko America shall not be liable for any errors or omissions. In no event shall Nitsuko America be liable for any incidental or consequential damages in connection with the use of this manual. This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be photocopied or reproduced without prior written consent of Nitsuko America.

Nec DS 2000 DS Phone Program - Record Form

Specifications and Main Features

Frequently Asked Questions

User Manual
